Lenovo Yoga 500-14IBD/
Yoga 500-14IHW/
Yoga 500-14ACL/
Yoga 500-14ACZ/
Yoga 500-15IBD/
Yoga 500-15IHW/
Yoga 500-15ACL
Hardware
Maintenance
Manual
Notes:
• Before using this information and the product it supports, be sure to read the general information under
“Notices” on page 94.
• This manual applies to the following models: Lenovo Yoga 500-14IBD/Yoga 500-14IHW/
Yoga 500-14ACL/Yoga 500-14ACZ/Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL.
The illustrations used in this manual are for Lenovo Yoga 500-15IBD unless otherwise stated.
First Edition (Mar. 2015)
© Copyright Lenovo 2015. All rights reserved.
LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneral
ServicesAdministration“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionsset
forthinContractNo.GS-35F-05925.
©2015Lenovo
iii
Contents
About this manual ....................................... iv
Safety information ........................................ 1
Generalsafety................................................ 2
Electricalsafety.............................................. 3
Safetyinspectionguide.................................. 5
Handlingdevicesthataresensitiveto
electrostaticdischarge.................................... 6
Groundingrequirements................................. 6
Safetynotices:multilingualtranslations.......... 7
Lasercompliancestatement......................... 14
Important service information ................... 16
StrategyforreplacingFRUs......................... 16
Strategyforreplacingaharddiskdrive............17
Importantnoticeforreplacingasystem
board................................................................17
Importantinformationaboutreplacing
RoHScompliantFRUs................................. 18
General checkout ...................................... 19
Whattodorst............................................. 20
Powersystemcheckout................................ 21
CheckingtheACadapter.................................21
Checkingoperationalcharging.........................22
Checkingthebatterypack................................22
Related service information ...................... 23
Restoringthefactorycontentsbyusing
OneKeyRecovery........................................ 23
Restoreoffactorydefault.................................23
Passwords.................................................... 24
Power-onpassword..........................................24
Hard-diskpassword..........................................24
Administratorpassword....................................24
Powermanagement..................................... 25
Screenblankstate............................................25
Puttingthecomputertosleeporshutting
itdown..............................................................25
Puttingyourcomputertosleep.........................25
Shuttingdownthecomputer.............................25
Lenovo Yoga 500-14IBD/Yoga 500-14IHW/
Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/
Yoga 500-15ACL ......................................... 26
Specications............................................... 26
Statusindicators........................................... 28
Fnkeycombinations/Hotkeys....................... 29
FRUreplacementnotices............................. 30
Screwnotices..................................................30
RemovingandreplacinganFRU................. 31
1010Basecover...............................................32
1020Batterypack.............................................35
1030Harddiskdrive.........................................37
1040PCIExpressMiniCardfor
wirelessLAN.....................................................40
1050DIMM.......................................................42
1060IOboard...................................................43
1070Speakers.................................................44
1080
FanassemblyandHeatSinkassembly.... 45
1090
Systemboard............................................ 47
1100Touchpadmoduleanduppercase...........55
1110LCDunit...................................................59
1120HingesandLCDcover.............................62
1130Sensorboardandantennaassembly.....66
1140LCDmodule.............................................71
1150Integratedcamera....................................73
Locations...................................................... 74
Frontviewandright-sideview..........................74
BottomandLeft-sideview...............................76
Partslist........................................................ 77
Overall..............................................................78
LCDFRUs........................................................87
Miscellaneousparts..........................................89
ACadapters......................................................90
Screws..............................................................90
Powercords......................................................91
Notices......................................................... 94
Trademarks.................................................. 95
iv
About this manual
Thismanualcontainsserviceandreferenceinformationforthefollowing
Lenovoproduct:
Lenovo Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ/Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Usethismanualtotroubleshootproblems.
Themanualisdividedintothefollowingsections:
• Thecommonsectionsprovidegeneralinformation,guidelines,andsafety
informationrequiredforservicingcomputers.
• Theproduct-specicsectionincludesservice,reference,andproduct-specic
partsinformation.
Important:
This manual is intended only for trained servicers who are familiar with Lenovo
products. Use this manual to troubleshoot problems effectively.
Before servicing a Lenovo product, make sure to read all the information under
“Safety information” on page 1 and “Important service information” on page 16.
1
Safety information
Safety information
Thischapterpresentsthefollowingsafetyinformationthatyouneedtoget
familiarwithbeforeyouserviceaLenovoYoga500-14IBD/Yoga500-14IHW/
Yoga500-14ACL/Yoga500-14ACZ/Yoga500-15IBD/Yoga500-15IHW/
Yoga500-15ACLcomputer:
• “Generalsafety”onpage2
• “Electricalsafety”onpage3
• “Safetyinspectionguide”onpage5
• “Handlingdevicesthataresensitivetoelectrostaticdischarge”onpage6
• “Groundingrequirements”onpage6
• “Safetynotices:multilingualtranslations”onpage7
• “Lasercompliancestatement”onpage14
2
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
General safety
Followtheserulesbelowtoensuregeneralsafety:
• Observeagoodhousekeeping inthe areawherethemachinesareput
duringandafterthemaintenance.
• Whenliftinganyheavyobject:
1. Makesurethatyoucanstandsafelywithoutslipping.
2. Distributetheweightoftheobjectequallybetweenyourfeet.
3. Useaslowliftingforce.Nevermovesuddenlyortwistwhenyouattempt
toliftit.
4. Liftitbystandingorpushingupwithyourlegmuscles;thisactioncould
avoidthestrainfromthemusclesinyourback.Donotattempttoliftany
objectthatweighsmorethan16kg(35lb)orthatyouthinkistooheavy
foryou.
• Donotperformany actionthatcauseshazardstothecustomer,or that
makesthemachineunsafe.
• Beforeyou startthe machine,makesurethatotherservicerepresentatives
andthecustomerarenotinahazardousposition.
• Pleaseremovecoversand otherparts ina safeplace,awayfromall
personnel,whileyouareservicingthemachine.
• Keepyourtoolcaseawayfromwalkareassothatotherpeoplewillnot trip
overit.
• Donotwearlooseclothingthatcanbetrappedinthemovingparts ofthe
machine.Makesurethatyoursleevesarefastenedorrolledupaboveyour
elbows.Ifyourhairislong,fastenit.
• Inserttheendsofyournecktieorscarfinsideclothingor fastenit withthe
nonconductiveclip,about8centimeters(3inches)fromtheend.
• Donotwearjewelry,chains,metal-frameeyeglasses,ormetalfastenersfor
yourclothing.
Attention:Metalobjectsaregoodelectricalconductors.
• Wearsafetyglasses whenyouarehammering,drilling,soldering,cutting
wire,attachingsprings,usingsolvents,orworkinginanyotherconditions
thatmaybehazardoustoyoureyes.
• Afterservice, reinstallall safetyshields,guards,labels,and groundwires.
Replaceanysafetydevicethatiswornordefective.
• Reinstallallcoverscorrectlybeforereturningthemachinetothecustomer.
• Fanlouversonthemachinehelp toprevent theoverheating ofinternal
components.Donotobstructfanlouvers orcover themwith labelsor
stickers.
3
Safety information
Electrical safety
Observethefollowingruleswhenworkingonelectricalequipments.
Important:
Use only approved tools and test equipments. Some hand tools have handles
covered with a soft material that does not insulate you when working with live
electrical currents.
Many customers have rubber floor mats near their machines that contain small
conductive bers to decrease electrostatic discharges. Do not use such kind of mat
to protect yourself from electrical shock.
• Findtheroomemergency power-off(EPO)switch,disconnectingswitchor
electricaloutlet.Ifanelectricalaccident occurs,you canthen operatethe
switchorunplugthepowercordquickly.
• Donotworkalone underhazardousconditionsornear theequipment that
hashazardousvoltages.
• Disconnectallpowerbefore:
– Performingamechanicalinspection
– Workingnearpowersupplies
– Removingorinstallingmainunits
• Beforeyoustarttoworkonthemachine,unplug thepower cord.Ifyou
cannotunplugit,askthecustomerto power-offthewall boxthatsupplies
powertothemachine,andtolockthewallboxintheoffposition.
• Ifyouneedtoworkonamachinethathasexposedelectricalcircuits,
observethefollowingprecautions:
– Ensurethatanotherperson,familiarwiththepower-offcontrols,isnear
you.
Attention:Anotherperson mustbetheretoswitchoffthepower,if
necessary.
– Useonlyonehandwhenworkingwithpowered-onelectricalequipment;
keeptheotherhandinyourpocketorbehindyourback.
Attention:Anelectricalshockcanoccuronlywhenthereisacomplete
circuit.Byobservingtheaboverule,you maypreventacurrentfrom
passingthroughyourbody.
– Whenusingtesters,setthecontrolscorrectlyandusetheapproved
probeleadsandaccessoriesforthattester.
– Standonsuitablerubbermats(obtainedlocally,ifnecessary)toinsulate
youfromgroundssuchasmetaloorstripsandmachineframes.
Observethespecialsafetyprecautionswhenyouworkwithveryhighvoltages;
instructionsfortheseprecautionsareinthesafetysectionsofmaintenance
information.Beextremelycarefulwhenyoumeasurethehighvoltages.
• Regularlyinspectandmaintainyourelectricalhandtoolsforsafeoperational
condition.
• Donotusewornorbrokentoolsandtesters.
• Neverassumethatpowerhasbeendisconnectedfromacircuit.First,check
ittomakesurethatithasbeenpoweredoff.
4
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
• Alwayslookcarefullyforpossiblehazardsinyourworkarea.Examplesof
thesehazardsaremoistoors,nongroundedpowerextensioncables,power
surges,andmissingsafetygrounds.
• Donottouchliveelectricalcircuits withthe reflectivesurface ofaplastic
dentalmirror.Thesurfaceisconductive;suchtouchingcancausepersonal
injuryandmachinedamage.
• Donotservicethefollowingpartswiththepoweronwhentheyareremoved
fromtheirnormaloperatingplacesinamachine:
– Powersupplyunits
– Pumps
– Blowersandfans
– Motorgenerators
andsimilarunits.(Thispracticeensurescorrectgroundingoftheunits.)
• Ifanelectricalaccidentoccurs:
– Caution:donotbecomeavictimyourself.
– Switchoffthepower.
– Sendthevictimtogetmedicalaid.
5
Safety information
Safety inspection guide
Thepurpose ofthis inspectionguideistoassistyouinidentifyingpotential
unsafeconditions.Aseachmachine wasdesigned andbuilt, requiredsafety
itemswereinstalledtoprotectusersandservicepersonnelfrominjury.This
guideaddressesonlythoseitems.Youshouldusegoodjudgmenttoidentify
potentialsafetyhazardsaccordingtotheattachmentofnon-Lenovofeaturesor
optionsnotcoveredbythisinspectionguide.
Ifanyunsafeconditionsarepresent,youmustdetermine howserious the
apparenthazardcouldbeandwhetheryoucancontinuewithoutrstcorrecting
theproblem.
Considertheseconditionsandthesafetyhazardstheypresent:
• Electricalhazards,especiallyprimarypower(primaryvoltageontheframe
cancauseseriousorfatalelectricalshock)
• Explosivehazards,suchasadamagedCRTfaceorabulgingcapacitor
• Mechanicalhazards,suchaslooseormissinghardware
Todeterminewhether thereareanypotentialunsafeconditions,usethe
followingchecklistatthebeginningofeveryservicetask.Beginthecheckswith
thepoweroff,andthepowercorddisconnected.
Checklist:
1. Checkexteriorcoversfordamage(loose,broken,orsharpedges).
2. Turnoffthecomputer.Disconnectthepowercord.
3. Checkthepowercordfor:
a. Athird-wiregroundconnectoringoodcondition.Useametertomeasure
third-wiregroundcontinuityfor0.1ohmorlessbetweentheexternal
groundpinandtheframeground.
b. Thepowercordshouldbethetypespeciedinthepartslist.
c. Insulationmustnotbefrayedorworn.
4. Checkforcrackedorbulgingbatteries.
5. Removethecover.
6. Checkforanyobviousnon-Lenovoalterations.Usegoodjudgmentastothe
safetyofanynon-Lenovoalterations.
7. Checkinsidetheunitforanyobviousunsafeconditions,suchasmetal
filings,contamination,waterorotherliquids,orsignsoffireorsmoke
damage.
8. Checkforworn,frayed,orpinchedcables.
9. Checkthatthepower-supplycover fasteners(screwsorrivets)havenot
beenremovedortamperedwith.
6
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Handling devices that are sensitive to electrostatic discharge
Anycomputerpartcontainingtransistorsorintegratedcircuits(ICs)shouldbe
consideredsensitivetoelectrostaticdischarge(ESD).ESDdamagecanoccur
whenthere isa differenceinchargebetween objects.Protect againstESD
damagebyequalizingthechargesothatthemachine,thepart,theworkmat,
andthepersonhandlingthepartareallatthesamecharge.
Notes:
1. Use product-specific ESD procedures when they exceed the requirements
noted here.
2. Make sure that the ESD protective devices you use have been certied (ISO
9000) as fully effective.
WhenhandlingESD-sensitiveparts:
• Keepthepartsinprotectivepackagesuntiltheyareinsertedintotheproduct.
• Avoidcontactwithotherpeople.
• Wearagroundedwriststrapagainstyourskintoeliminate staticonyour
body.
• Preventthepartfromtouchingyourclothing.Mostclothingisinsulativeand
retainsachargeevenwhenyouarewearingawriststrap.
• Usetheblacksideofagroundedworkmattoprovideastatic-freework
surface.ThematisespeciallyusefulwhenhandlingESD-sensitivedevices.
• Selectagroundingsystem,suchasthoselistedbelow,toprovideprotection
thatmeetsthespecicservicerequirement.
Note:
The use of a grounding system to guard against ESD damage is desirable but not
necessary.
– AttachtheESDgroundcliptoanyframeground,groundbraid,orgreen-
wireground.
– Whenworkingonadouble-insulatedorbattery-operatedsystem,usean
ESDcommongroundorreferencepoint.Youcanusecoaxorconnector-
outsideshellsonthesesystems.
– Usetheroundgroundprongoftheacplugonac-operatedcomputers.
Grounding requirements
Electricalgroundingofthecomputerisrequiredforoperatorsafetyandcorrect
systemfunction.Propergroundingoftheelectricaloutletcanbeveriedbya
certiedelectrician.
7
Safety information
Safety notices: multilingual translations
Thesafetynoticesin thissection areprovidedinEnglish,French,German,
Hebrew,Italian,Japanese,andSpanish.
Safety notice 1
Before the computer is powered on after FRU replacement, make sure all screws,
springs, and other small parts are in place and are not left loose inside the
computer. Verify this by shaking the computer and listening for rattling sounds.
Metallic parts or metal akes can cause electrical shorts.
Avant de remettre l’ordinateur sous tension après remplacement d’une unité en
clientèle, vériez que tous les ressorts, vis et autres pièces sont bien en place et
bien xées. Pour ce faire, secouez l’unité et assurez-vous qu’aucun bruit suspect
ne se produit. Des pièces métalliques ou des copeaux de métal pourraient causer
un court-circuit.
Bevor nach einem FRU-Austausch der Computer wieder angeschlossen wird,
muß sichergestellt werden, daß keine Schrauben, Federn oder andere Kleinteile
fehlen oder im Gehäuse vergessen wurden. Der Computer muß geschüttelt und auf
Klappergeräusche geprüft werden. Metallteile oder-splitter können Kurzschlüsse
erzeugen.
Prima di accendere l’elaboratore dopo che é stata effettuata la sostituzione di una
FRU, accertarsi che tutte le viti, le molle e tutte le altri parti di piccole dimensioni
siano nella corretta posizione e non siano sparse all’interno dell’elaboratore.
Vericare ciò scuotendo l’elaboratore e prestando attenzione ad eventuali rumori;
eventuali parti o pezzetti metallici possono provocare cortocircuiti pericolosi.
Antes de encender el sistema despues de sustituir una FRU, compruebe que
todos los tornillos, muelles y demás piezas pequeñas se encuentran en su sitio
y no se encuentran sueltas dentro del sistema. Compruébelo agitando el sistema
y escuchando los posibles ruidos que provocarían. Las piezas metálicas pueden
causar cortocircuitos eléctricos.
8
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Safety notice 2
DANGER
Some standby batteries contain a small amount of nickel and cadmium. Do not
disassemble a standby battery, recharge it, throw it into fire or water, or short-
circuit it. Dispose of the battery as required by local ordinances or regulations.
Use only the battery in the appropriate parts listing. Use of an incorrect battery can
result in ignition or explosion of the battery.
Certaines batteries de secours contiennent du nickel et du cadmium. Ne les
démontez pas, ne les rechargez pas, ne les exposez ni au feu ni à l’eau. Ne
les mettez pas en court-circuit. Pour les mettre au rebut, conformez-vous à la
réglementation en vigueur. Lorsque vous remplacez la pile de sauvegarde ou celle
de l’horloge temps réel, veillez à n’utiliser que les modèles cités dans la liste de
pièces détachées adéquate. Une batterie ou une pile inappropriée risque de prendre
feu ou d’exploser.
Die Bereitschaftsbatterie, die sich unter dem Diskettenlaufwerk befindet,
kann geringe Mengen Nickel und Cadmium enthalten. Sie darf nicht zerlegt,
wiederaufgeladen, kurzgeschlossen, oder Feuer oder Wasser ausgesetzt werden.
Bei der Entsorgung die örtlichen Bestimmungen für Sondermüll beachten. Beim
Ersetzen der Bereitschafts-oder Systembatterie nur Batterien des Typs verwenden,
der in der Ersatzteilliste aufgeführt ist. Der Einsatz falscher Batterien kann zu
Entzündung oder Explosion führen.
Alcune batterie di riserva contengono una piccola quantità di nichel e cadmio.
Non smontarle, ricaricarle, gettarle nel fuoco o nell’acqua né cortocircuitarle.
Smaltirle secondo la normativa in vigore (DPR 915/82, successive disposizioni e
disposizioni locali). Quando si sostituisce la batteria dell’RTC (real time clock) o
la batteria di supporto, utilizzare soltanto i tipi inseriti nell’appropriato Catalogo
parti. L’impiego di una batteria non adatta potrebbe determinare l’incendio o
l’esplosione della batteria stessa.
Algunas baterías de reserva contienen una pequeña cantidad de níquel y cadmio.
No las desmonte, ni recargue, ni las eche al fuego o al agua ni las cortocircuite.
Deséchelas tal como dispone la normativa local. Utilice sólo baterías que se
encuentren en la lista de piezas. La utilización de una batería no apropiada puede
provocar la ignición o explosión de la misma.
9
Safety information
Safety notice 3
DANGER
The battery pack contains small amounts of nickel. Do not disassemble it, throw
it into re or water, or short-circuit it. Dispose of the battery pack as required by
local ordinances or regulations. Use only the battery in the appropriate parts listing
when replacing the battery pack. Use of an incorrect battery can result in ignition
or explosion of the battery.
La batterie contient du nickel. Ne la démontez pas, ne l’exposez ni au feu ni à l’eau.
Ne la mettez pas en court-circuit. Pour la mettre au rebut, conformez-vous à la
réglementation en vigueur. Lorsque vous remplacez la batterie, veillez à n’utiliser
que les modèles cités dans la liste de pièces détachées adéquate. En effet, une
batterie inappropriée risque de prendre feu ou d’exploser.
Akkus enthalten geringe Mengen von Nickel. Sie dürfen nicht zerlegt,
wiederaufgeladen, kurzgeschlossen, oder Feuer oder Wasser ausgesetzt werden.
Bei der Entsorgung die örtlichen Bestimmungen für Sondermüll beachten. Beim
Ersetzen der Batterie nur Batterien des Typs verwenden, der in der Ersatzteilliste
aufgeführt ist. Der Einsatz falscher Batterien kann zu Entzündung oder Explosion
führen.
La batteria contiene piccole quantità di nichel. Non smontarla, gettarla nel fuoco
o nell’acqua né cortocircuitarla. Smaltirla secondo la normativa in vigore (DPR
915/82, successive disposizioni e disposizioni locali). Quando si sostituisce la
batteria, utilizzare soltanto i tipi inseriti nell’appropriato Catalogo parti. L’impiego
di una batteria non adatta potrebbe determinare l’incendio o l’esplosione della
batteria stessa.
Las baterías contienen pequeñas cantidades de níquel. No las desmonte, ni
recargue, ni las eche al fuego o al agua ni las cortocircuite. Deséchelas tal como
dispone la normativa local. Utilice sólo baterías que se encuentren en la lista de
piezas al sustituir la batería. La utilización de una batería no apropiada puede
provocar la ignición o explosión de la misma.
10
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Safety notice 4
DANGER
The lithium battery can cause a fire, an explosion, or a severe burn. Do not
recharge it, remove its polarized connector, disassemble it, heat it above 100°C
(212°F), incinerate it, or expose its cell contents to water. Dispose of the battery as
required by local ordinances or regulations. Use only the battery in the appropriate
parts listing. Use of an incorrect battery can result in ignition or explosion of the
battery.
La pile de sauvegarde contient du lithium. Elle présente des risques d’incendie,
d’explosion ou de brûlures graves. Ne la rechargez pas, ne retirez pas son
connecteur polarisé et ne la démontez pas. Ne l’exposez pas à une temperature
supérieure à 100°C, ne la faites pas brûler et n’en exposez pas le contenu à l’eau.
Mettez la pile au rebut conformément à la réglementation en vigueur. Une pile
inappropriée risque de prendre feu ou d’exploser.
Die Systembatterie ist eine Lithiumbatterie. Sie kann sich entzünden, explodieren
oder schwere Verbrennungen hervorrufen. Batterien dieses Typs dürfen nicht
aufgeladen, zerlegt, über 100 C erhitzt oder verbrannt werden. Auch darf ihr
Inhalt nicht mit Wasser in Verbindung gebracht oder der zur richtigen Polung
angebrachte Verbindungsstecker entfernt werden. Bei der Entsorgung die örtlichen
Bestimmungen für Sondermüll beachten. Beim Ersetzen der Batterie nur Batterien
des Typs verwenden, der in der Ersatzteilliste aufgeführt ist. Der Einsatz falscher
Batterien kann zu Entzündung oder Explosion führen.
La batteria di supporto e una batteria al litio e puo incendiarsi, esplodere o
procurare gravi ustioni. Evitare di ricaricarla, smontarne il connettore polarizzato,
smontarla, riscaldarla ad una temperatura superiore ai 100 gradi centigradi,
incendiarla o gettarla in acqua. Smaltirla secondo la normativa in vigore (DPR
915/82, successive disposizioni e disposizioni locali). L’impiego di una batteria
non adatta potrebbe determinare l’incendio o l’esplosione della batteria stessa.
La batería de repuesto es una batería de litio y puede provocar incendios,
explosiones o quemaduras graves. No la recargue, ni quite el conector polarizado,
ni la desmonte, ni caliente por encima de los 100°C (212°F), ni la incinere ni
exponga el contenido de sus celdas al agua. Deséchela tal como dispone la
normativa local.
11
Safety information
Safety notice 5
If the LCD breaks and the uid from inside the LCD gets into your eyes or on your
hands, immediately wash the affected areas with water at least for 15 minutes.
Seek medical care if any symptoms caused by the uid are present after washing.
Si le panneau d’afchage à cristaux liquides se brise et que vous recevez dans les
yeux ou sur les mains une partie du uide, rincez-les abondamment pendant au
moins quinze minutes. Consultez un médecin si des symptômes persistent après le
lavage.
Die Leuchtstoffröhre im LCD-Bildschirm enthält Quecksilber. Bei der Entsorgung
die örtlichen Bestimmungen für Sondermüll beachten. Der LCD-Bildschirm
besteht aus Glas und kann zerbrechen, wenn er unsachgemäß behandelt wird
oder der Computer auf den Boden fällt. Wenn der Bildschirm beschädigt ist und
die darin befindliche Flüssigkeit in Kontakt mit Haut und Augen gerät, sollten
die betroffenen Stellen mindestens 15 Minuten mit Wasser abgespült und bei
Beschwerden anschließend ein Arzt aufgesucht werden.
Nel caso che caso l’LCD si dovesse rompere ed il liquido in esso contenuto
entrasse in contatto con gli occhi o le mani, lavare immediatamente le parti
interessate con acqua corrente per almeno 15 minuti; poi consultare un medico se i
sintomi dovessero permanere.
Si la LCD se rompe y el uido de su interior entra en contacto con sus ojos o sus
manos, lave inmediatamente las áreas afectadas con agua durante 15 minutos
como mínimo. Obtenga atención medica si se presenta algún síntoma del uido
despues de lavarse.
12
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Safety notice 6
DANGER
To avoid shock, do not remove the plastic cover that protects the lower part of the
inverter card.
An d’éviter tout risque de choc électrique, ne retirez pas le cache en plastique
protégeant la partie inférieure de la carte d’alimentation.
Aus Sicherheitsgründen die Kunststoffabdeckung, die den unteren Teil der
Spannungswandlerplatine umgibt, nicht entfernen.
Per evitare scosse elettriche, non rimuovere la copertura in plastica che avvolge la
parte inferiore della scheda invertitore.
Para evitar descargas, no quite la cubierta de plástico que rodea la parte baja de la
tarjeta invertida.
Safety notice 7
DANGER
Though the main batteries have low voltage, a shorted or grounded battery can
produce enough current to burn personnel or combustible materials.
Bien que le voltage des batteries principales soit peu élevé, le court-circuit ou la
mise à la masse d’une batterie peut produire sufsamment de courant pour brûler
des matériaux combustibles ou causer des brûlures corporelles graves.
Obwohl Hauptbatterien eine niedrige Spannung haben, können sie doch bei
Kurzschluß oder Erdung genug Strom abgeben, um brennbare Materialien zu
entzünden oder Verletzungen bei Personen hervorzurufen.
Sebbene le batterie di alimentazione siano a basso voltaggio, una batteria in
corto circuito o a massa può fornire corrente sufficiente da bruciare materiali
combustibili o provocare ustioni ai tecnici di manutenzione.
Aunque las baterías principales tienen un voltaje bajo, una batería cortocircuitada
o con contacto a tierra puede producir la corriente suciente como para quemar
material combustible o provocar quemaduras en el personal.
13
Safety information
Safety notice 8
DANGER
Before removing any FRU, turn off the computer, unplug all power cords from
electrical outlets, remove the battery pack, and then disconnect any interconnecting
cables.
Avant de retirer une unité remplaçable en clientèle, mettez le système hors tension,
débranchez tous les cordons d’alimentation des socles de prise de courant, retirez
la batterie et déconnectez tous les cordons d’interface.
Die Stromzufuhr muß abgeschaltet, alle Stromkabel aus der Steckdose gezogen,
der Akku entfernt und alle Verbindungskabel abgenommen sein, bevor eine FRU
entfernt wird.
Prima di rimuovere qualsiasi FRU, spegnere il sistema, scollegare dalle prese
elettriche tutti i cavi di alimentazione, rimuovere la batteria e poi scollegare i cavi
di interconnessione.
Antes de quitar una FRU, apague el sistema, desenchufe todos los cables de
las tomas de corriente eléctrica, quite la batería y, a continuación, desconecte
cualquier cable de conexión entre dispositivos.
14
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Laser compliance statement
SomemodelsofLenovocomputerareequippedfromthefactorywithan
opticalstorage devicesuchasaCD-ROMdriveor aDVD-ROM drive.Such
devicesarealsosoldseparatelyasoptions.Ifoneofthesedrivesisinstalled,
itiscertiedintheU.S.toconformto therequirementsoftheDepartmentof
HealthandHumanServices21CodeofFederalRegulations(DHHS21CFR)
SubchapterJforClass1laserproducts.Elsewhere,the driveis certifiedto
conformtotherequirements ofthe InternationalElectrotechnicalCommission
(IEC)825andCENELECEN60825forClass1laserproducts.
IfaCD-ROMdrive,aDVD-ROMdrive,oranotherlaserdeviceisinstalled,note
thefollowing:
CAUTION
Use of controls or adjustments or performance of procedures other than those
specied herein might result in hazardous radiation exposure.
O uso de controles, ajustes ou desempenho de procedimentos diferentes daqueles
aqui especicados pode resultar em perigosa exposição à radiação.
Pour éviter tout risque d’exposition au rayon laser, respectez les consignes de
réglage et d’utilisation des commandes, ainsi que les procédures décrites.
Werden Steuer- und Einstellelemente anders als hier festgesetzt verwendet, kann
gefährliche Laserstrahlung auftreten.
L’utilizzo di controlli, regolazioni o l’esecuzione di procedure diverse da quelle
specicate possono provocare l’esposizione a.
El uso de controles o ajustes o la ejecución de procedimientos distintos de los aquí
especicados puede provocar la exposición a radiaciones peligrosas.
OpeningtheCD-ROMdrive,theDVD-ROMdrive,oranyotheropticalstorage
devicecouldresultinexposuretohazardouslaser radiation.Thereareno
serviceablepartsinsidethosedrives.Do not open.
15
Safety information
ACD-ROMdrive,aDVD-ROMdrive,oranyotherstoragedeviceinstalledmay
containanembeddedClass3AorClass3Blaserdiode.Notethefollowing:
DANGER
Emits visible and invisible laser radiation when open. Do not stare into the beam,
do not view directly with optical instruments, and avoid direct exposure to the
beam.
Radiação por raio laser ao abrir. Não olhe xo no feixe de luz, não olhe diretamente
por meio de instrumentos óticos e evite exposição direta com o feixe de luz.
Rayonnement laser si carter ouvert. Évitez de fixer le faisceau, de le regarder
directement avec des instruments optiques, ou de vous exposer au rayon.
Laserstrahlung bei geöffnetem Gerät. Nicht direkt oder über optische Instrumente
in den Laserstrahl sehen und den Strahlungsbereich meiden.
Kinyitáskor lézersugár ! Ne nézzen bele se szabad szemmel, se optikai
eszközökkel. Kerülje a sugárnyalábbal való érintkezést!
Aprendo l’unità vengono emesse radiazioni laser. Non fissare il fascio, non
guardarlo direttamente con strumenti ottici e evitare l’esposizione diretta al fascio.
Radiación láser al abrir. No mire jamente ni examine con instrumental óptico el
haz de luz. Evite la exposición directa al haz.
16
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Important service information
Thischapterpresentsthefollowingimportantserviceinformation:
• “StrategyforreplacingFRUs”onpage16
– “Strategyforreplacingaharddiskdrive”onpage17
– “Importantnoticeforreplacingasystemboard”onpage17
• “ImportantinformationaboutreplacingRoHScompliantFRUs”onpage18
Important:
BIOS and device driver xes are customer-installable. The BIOS and device drivers
are posted on the customer support site:
http://support.lenovo.com.
Strategy for replacing FRUs
Before replacing parts:
Makesurethatall softwarexes, drivers,andBIOSdownloadsareinstalled
beforereplacinganyFRUslistedinthismanual.
Afterasystemboardisreplaced,ensurethatthelatestBIOSisloadedtothe
systemboardbeforecompletingtheserviceaction.
Todownloadsoftwarexes,drivers,andBIOS,followthestepsbelow:
1. Gotohttp://support.lenovo.com.
2. Entertheserialnumberorselectaproduct oruse Lenovosmart
downloading.
3. SelecttheBIOS/Driver/Applicationsanddownload.
4. Followthedirectionsonthescreenandinstallthenecessarysoftware.
17
Important service information
Usethefollowingstrategytopreventunnecessaryexpenseforreplacingand
servicingFRUs:
• IfyouareinstructedtoreplaceanFRU,butthereplacementdoesnotsolve
theproblem,reinstalltheoriginalFRUbeforeyoucontinue.
• Somecomputers havebothaprocessorboardand asystem board.Ifyou
areinstructedtoreplaceeitherofthem,andreplacingoneofthemdoesnot
solvetheproblem,reinstallthatboard,andthenreplacetheotherone.
• IfanadapteroradeviceconsistsofmorethanoneFRU,anyoftheFRUs
maybethecauseofthe error.Beforereplacingtheadapterordevice,
removetheFRUsonebyonetoseeifthesymptomschange.Replaceonly
theFRUthatchangedthesymptoms.
Attention:Thesetup configurationonthecomputeryouareservicingmay
havebeencustomized.RunningAutomaticConfiguration mayalter the
settings.Notethecurrentcongurationsettings(usingtheViewConguration
option);then,whenservice hasbeen completed,verifythatthosesettings
remainineffect.
Strategy for replacing a hard disk drive
Alwaystrytorun alow-level formatbeforereplacingaharddiskdrive.This
willcauseallcustomerdataontheharddisk tobe lost.Make surethatthe
customerhasacurrentbackupofthedatabeforeperformingthisaction.
Attention:Thedrivestartupsequenceinthecomputeryouareservicingmay
havebeenchanged.Beextremelycareful duringwrite operationssuch as
copying,saving,orformatting.Ifyouselectanincorrectdrive,dataorprograms
canbeoverwritten.
Important notice for replacing a system board
Somecomponentsmountedon asystem boardare verysensitive. Improper
handlingcancausedamagetothosecomponents,andmaycauseasystem
malfunction.
Attention:Whenhandlingasystemboard:
• Donotdropthesystemboardorapplyanyexcessiveforcetoit.
• Avoidroughhandlingofanykind.
• Avoidbendingthe systemboardandhardpushingtopreventcrackingat
eachBGA(BallGridArray)chipset.
18
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Important information about replacing RoHS compliant FRUs
RoHS, The Restriction of Hazardous Substances in Electrical and
Electronic Equipment Directive (2002/95/EC) is a European Union legal
requirement affecting the global electronics industry. RoHS requirements
must be implemented on Lenovo products placed on the market after
June 2006. Products on the market before June 2006 are not required to
have RoHS compliant parts. If the original FRU parts are non-compliant,
replacement parts can also be non-compliant. In all cases if the original
FRU parts are RoHS compliant, the replacement part must also be RoHS
compliant.
Note:RoHS andnon-RoHS FRUpartnumberswiththesametandfunction
areidentiedwithuniqueFRUpartnumbers.
Lenovoplans totransit toRoHScompliancewellbeforetheimplementation
dateandexpectsits suppliersto bereadytosupportLenovo’srequirements
andscheduleintheEU.Productssoldin2005and2006willcontainsome
RoHScompliantFRUs.Thefollowingstatementpertainstotheseproductsand
anyproductLenovoproducescontainingRoHScompliantFRUs.
RoHScompliantFRUshaveuniqueFRUpartnumbers.Before orafter the
RoHSimplementationdate,failed RoHScompliant partsmust alwaysbe
replacedwithRoHScompliantones,so onlythe FRUsidentied ascompliant
inthesystemHMMordirectsubstitutionsforthoseFRUsmaybeused.
Products marketed before June 2006 Products marketed after June 2006
Current or
original part
Replacement FRU Current or
original part
Replacement FRU
Non-RoHS CanbeNon-RoHS
MustbeRoHS MustbeRoHS
Non-RoHS CanbeRoHS
Non-RoHS CansubtoRoHS
RoHS MustbeRoHS
Note:AdirectsubstitutionisapartwithadifferentFRUpartnumberthat is
automaticallyshippedbythedistributioncenteratthetimeoftheorder.
19
General checkout
General checkout
Thischapterpresentsthefollowinginformation:
• “Whattodorst”onpage20
• “Powersystemcheckout”onpage21
Beforeyougotothecheckout,makesuretoreadthefollowingimportantnotes:
Important notes:
• Onlycertiedtrainedpersonnelcanservicethecomputer.
• BeforereplacinganyFRU, readthe entirepageonremovingandreplacing
FRUs.
• CarefullyremovescrewsforreusewhenreplacingFRUs.
• Beextremelycarefulduringsuchwriteoperationsascopying,saving,or
formatting. Drives in the computer that you are servicing sequence might
have been altered. If you select an incorrect drive, data or programs might be
overwritten.
• ReplaceanFRUonlywithanotherFRUofthecorrectmodel. When you
replace an FRU, make sure that the machine model and the FRU part number are
correct by referring to the FRU parts list.
• AnFRUshouldnotbereplacedjustbecauseofasingle,unreproduciblefailure.
Single failures can occur for a variety of reasons that have nothing to do with a
hardware defect, such as cosmic radiation, electrostatic discharge, or software
errors. Consider replacing an FRU only when a problem recurs. If you suspect that
an FRU is defective, clear the error logs and run the test again. If the error does
not recur, do not replace the FRU.
• BecarefulnottoreplaceanondefectiveFRU.
20
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
What to do rst
WhenyoudoreturnanFRU,youmustincludethefollowinginformationinthe
partsexchangeformorpartsreturnformthatyouattachtoit:
1. Nameandphonenumberofservicer
2. Dateofservice
3. Dateonwhichthemachinefailed
4. Dateofpurchase
5. ProcedureindexandpagenumberinwhichthefailingFRUwasdetected
6. FailingFRUnameandpartnumber
7. Machinetype,modelnumber,andserialnumber
8. Customer’snameandaddress
Note for warranty:During thewarrantyperiod,thecustomer maybe
responsiblefor repaircosts ifthe computerdamagewascausedbymisuse,
accident,modification,unsuitablephysicaloroperatingenvironment,or
impropermaintenancebythecustomer.
Thefollowingisa listof somecommon itemsthatarenotcoveredunder
warrantyandsomesymptoms thatmight indicatethat thesystemwas
subjectedtostressbeyondnormaluse.
Beforecheckingproblemswiththecomputer,determinewhetherthedamageis
coveredunderthewarrantybyreferringtothefollowinglist:
The following are not covered under warranty:
• LCDpanelcrackedfromtheapplicationofexcessive forceor frombeing
dropped
• Scratched(cosmetic)parts
• Distortion,deformation,ordiscolorationofthecosmeticparts
• Plasticparts,latches,pins,orconnectorsthathavebeencrackedorbroken
byexcessiveforce
• Damagecausedbyliquidspilledintothesystem
• DamagecausedbytheimproperinsertionofaPCCardortheinstallationof
anincompatiblecard
• Improperdiskinsertionoruseofanopticaldrive
• Diskettedrivedamagecausedbypressure onthe diskettedrive cover,
foreignmaterialinthedrive,ortheinsertionofadiskettewithmultiplelabels
• Damagedorbentdisketteejectbutton
• Fusesblownbyattachmentofanonsupporteddevice
• Forgottencomputerpassword(makingthecomputerunusable)
• Stickykeyscausedbyspillingaliquidontothekeyboard
• UseofanincorrectACadapteronlaptopproducts
The following symptoms might indicate damage caused by nonwarranted
activities:
• Missingpartsmightbeasymptomofunauthorizedserviceormodication.
• Ifthespindleofaharddiskdrivebecomesnoisy,itmayhavebeensubjected
toexcessiveforce,ordropped.
21
General checkout
Power system checkout
Toverifyasymptom,followthestepsbelow:
1. Turnoffthecomputer.
2. Removethebatterypack.
3. ConnecttheACadapter.
4. Makesurethatpowerissuppliedwhenyouturnonthecomputer.
5. Turnoffthecomputer.
6. DisconnecttheACadapterandinstallthechargedbatterypack.
7. Makesurethatthebatterypacksuppliespowerwhenyouturnonthe
computer.
Ifyoususpectapowerproblem,seetheappropriateoneofthefollowingpower
supplycheckouts:
• “CheckingtheACadapter”onpage21
• “Checkingoperationalcharging”onpage22
• “Checkingthebatterypack”onpage22
Checking the AC adapter
YouareherebecausethecomputerfailsonlywhentheACadapterisused.
• Ifthepower-onindicatordoesnotturnon,checkthepower cordof theAC
adapterforcorrectcontinuityandinstallation.
• Ifthecomputerdoes notcharge duringoperation, goto“Checking
operationalcharging”.
TochecktheACadapter,followthestepsbelow:
1. UnplugtheACadaptercablefromthecomputer.
2. Measuretheoutput voltageattheplugoftheACadapter cable.See the
followinggure:
Voltage (V DC)
+5
D-
Pin
1
2
D+3
GND4
05
1
2
3
4
5
Note:OutputvoltagefortheACadapterpinNo.5maydifferfromtheoneyou
areservicing.
3. Ifthevoltageisnotcorrect,replacetheACadapter.
4. Ifthevoltageisacceptable,dothefollowing:
• Replacethesystemboard.
• Iftheproblempersists,goto
“LenovoYoga500-14IBD/Yoga500-14IHW/
Yoga500-14ACL/Yoga500-14ACZ/Yoga500-15IBD/Yoga500-15IHW/
Yoga500-15ACL”onpage26.
Note:NoisefromtheACadapterdoesnotalwaysindicateadefect.
22
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Checking operational charging
Tocheckwhetherthebatterycharges properlyduringoperation,usea
dischargedbattery packorabatterypackthathas lessthan50%ofthetotal
powerremainingwheninstalledinthecomputer.
Performoperationalcharging.Ifthebatterystatus indicatoror icondoesnot
lighton,removethebatterypackandletitreturntoroomtemperature.Reinstall
thebatterypack.Ifthechargeindicatororicon isstilloff,replacethebattery
pack.
Ifthechargeindicator stilldoesnotlighton,replacethesystemboard.Then
reinstallthebatterypack.Ifitisstillnotcharged,gotothenextsection.
Checking the battery pack
BatterychargingdoesnotstartuntilthePowerMetershowsthatlessthan95%
ofthetotalpowerremains;underthisconditionthebatterypackcanchargeto
100%ofitscapacity.Thisprotectsthebatterypackfrombeingoverchargedor
fromhavingashortenedlife.
Tocheckyourbattery,moveyourcursortothePowerMetericonintheicontray
oftheWindows®taskbarandwaitforamoment(butdo notclick it),andthe
percentageofbatterypowerremainingisdisplayed.Togetdetailedinformation
aboutthebattery,double-clickthePowerMetericon.
Note:Ifthebatterypackbecomeshot,itmaynotbe ableto becharged.
Removeitfromthecomputerandleaveitatroomtemperatureforawhile.After
itcoolsdown,reinstallandrechargeit.
23
Related service information
Related service information
Thischapterpresentsthefollowinginformation:
• “RestoringthefactorycontentsbyusingOneKeyRecovery”onpage23
• “Passwords”onpage24
• “Powermanagement”onpage25
Restoring the factory contents by using OneKey Recovery
Restore of factory default
TheLenovoYoga500-14IBD/Yoga500-14IHW/Yoga500-14ACL/
Yoga500-14ACZ/Yoga500-15IBD/Yoga500-15IHW/Yoga500-15ACL
computerscomewithpre-installedOneKeyRecoverySystem.Inordertosave
applicationlesandtheinitialbackeduplesofthesystem,theharddiskina
Lenovocomputerincludesahiddenpartitionwhenitisshipped.Ifyouneedto
restorethesystemtothepointofyourrstbootup,justenterLenovoOneKey
RecoverySystemandrunSystem Recovery.FordetailsofOneKeyRecovery
System,seethe User Guide for Lenovo OneKey Recovery System.
Note: This will delete all the new data on the system partition (C drive), which
is not recoverable. Make sure to back up your critical data before you perform this
action.
24
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Passwords
Asmany asthree passwordsmaybeneededforanyLenovo computer:
thepower-onpassword(POP), thehard diskpassword(HDP),andthe
administratorpassword.
Ifanyofthesepasswordshasbeenset,apromptforitappearsonthescreen
wheneverthecomputeristurnedon.Thecomputerdoesnotstartuntilthe
passwordisentered.
Power-on password
Apower-onpassword (POP)protects thesystem frombeing poweredonby
anunauthorized person.Thepasswordmust beenteredbefore anoperating
systemcanbebooted.
Hard-disk password
Therearetwohard-diskpasswords(HDPs):
+UserHDP-fortheuser
+MasterHDP-for thesystemadministrator,who canuse itto getaccessto
theharddiskdriveeveniftheuserhaschangedtheuserHDP
Attention:IftheuserHDPhasbeen forgotten,check whethera masterHDP
hasbeenset.Ifithas,itcanbeusedforaccesstotheharddiskdrive.If
nomasterHDPisavailable, neitherLenovo norLenovoauthorizedservice
techniciansprovideanyservicestoreseteithertheuserorthemasterHDP,or
torecoverdatafromtheharddiskdrive.Thehard diskdrive canbereplaced
forascheduledfee.
Administrator password
Administratorpasswordcontrolstheaccessofthewholesetuputility.Only
AdministratorpasswordwassetthenUserpasswordcanbeset.IfAdministrator
passwordwascleared,theUserpasswordwasclearedtoo.
25
Related service information
Power management
Note:PowermanagementmodesarenotsupportedforAPMoperatingsystem.
Toreducepowerconsumption,thecomputer hasthreepowermanagement
modes:screenblank,sleep(standby),andshutdown.
Screen blank state
Ifthetimesetonthe“Turnoffmonitor”timerinthe operatingsystem expires,
theLCDbacklightturns off.Youcan alsoturnofftheLCDbacklightby
pressingF9.
Toendscreenblankstateandresumenormaloperation,pressanykey.
Putting the computer to sleep or shutting it down
Whenyouhavenishedworkingwithyourcomputer,youcanputittosleepor
shutitdown.
Putting your computer to sleep
Ifyouwillbeawayfromyourcomputerforonlyashorttime,putthecomputerto
sleep.Whenthecomputerisinsleepmode,youcanquicklywakeittoresumeuse,
bypassingthestartupprocess.Toputthecomputertosleep,dooneofthefollowing:
• Closethedisplaypanel.
• Pressthepowerbutton.
• OpentheCharmsandthenselectSettings → Power → Sleep.
Attention:Waituntilthe powerindicatorlightstartsblinking(indicatingthat
thecomputerisinsleepmode)before youmoveyourcomputer.Movingyour
computerwhile thehard diskisspinningcandamagetheharddisk,causing
lossofdata.
Towakethecomputer,dooneofthefollowing:
• Pressanykeyonthekeyboard.(Notebookmodeonly)
• Pressthepowerbutton.
Shutting down the computer
Ifyouarenotgoingtouseyourcomputerforalongtime,shutitdown.Toshut
downyourcomputer:
• Openthecharmsbar,thenselectSettings → Power → Shut down.
• Pressandholdorright-clicktheStartbuttoninthelower-leftcornerand
selectShut down or sign out→Shut down.
• Select → Shut downintheupper-rightcorneroftheStartscreen.
Note:TheoperationdependsontheBIOSsetup.Pleaserefertotheactualproduct.
26
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Lenovo Yoga 500-14IBD/Yoga 500-14IHW/
Yoga 500-14ACL/Yoga 500-14ACZ/Yoga 500-15IBD/
Yoga 500-15IHW/Yoga 500-15ACL
Thischapter presentsthefollowingproduct-specificservice referencesand
product-specicpartsinformation:
• “Specications”onpage26
• “Statusindicators”onpage28
• “Fnkeycombinations/Hotkeys”onpage29
• “FRUreplacementnotices”onpage30
• “RemovingandreplacinganFRU”onpage31
• “Locations”onpage74
• “Partslist”onpage77
Specications
ThefollowingtableliststhespecificationsoftheLenovoYoga500-14IBD/
Yoga500-14IHW/Yoga500-14ACL/Yoga500-14ACZ/Yoga500-15IBD/
Yoga500-15IHW/Yoga500-15ACL:
Table 1. Specications
Feature Description
Processor • Seethesystempropertiesofyourcomputer,youcandothisas
follows:
 OpentheControl Panel,andthenselectSystem and Security →
System.
Busarchitecture • DDR3L
• PCIExpressbus
• DMI
Graphicmemory
chip
• IntegratedGraphics:GT2orGT3,Accordingtodifferent
CPU/AMDCarrizoAPU
• DiscretedGraghics (Option):Integrated/Nvidia N16V-GM/
NvidiaN16S-GT/AMD15W
Display • 14.0"16:9,1,366×768pixelsHD/1,920×1,080pixelsFHD
• 15.6"16:9,1,366×768pixelsHD/1,920×1,080pixelsFHD
Standard
memory • 1,600MHzSODIMM×1(max8GB)
CMOSRAM • 256Bytes
Harddiskdrive • 2.5-inch,7mmSATAII/SATAIII
• 500GB/1TB5,400rpm
I/Oport • Comboaudiojack×1
• RJ-45×1
• HDMIport×1
• USB2.0port×1,USB3.0port×2
• 4in1slot×1(SD/SDHC/SDXC/MMC)
27
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Table 1. Specications (continued)
Feature Description
Audio • 1/8"Comboaudiojack
• 1.5Wspeakers×2
• Single/ArrayDigitalMIC
Ethernet(onthe
systemboard) • 1,000Mbps
Bluetooth
wireless • Combinedincombocard
Keyboard • 6rowISOfullsizekeyboard
Touchpad • Multi-touchtype
Integrated
camera • HD/0.3M
Battery • 3cells/2cells,45Wh/30Wh
ACadapter • DIS65W,UMA45W
Pre-installed
operating
system
• Linpuslite/DOS
• WindowsMobile
• Windows8.1/10(orsimilarupdatein12months)
28
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Status indicators
Thesystemstatusindicatorsbelowshowthecomputerstatus:
12
Table 2. Status indicators
Indicator Indicator
status Meaning
1 Batterystatusindicator
On(solidwhite) Thebatteryhasmorethan20%
charge.
On(solidamber) Thebatteryhasbetween5%and
20%charge.
Blinkingquickly
(amber)
Thebatteryhaslessthan5%
charge.
Blinkingslowly
(amber)
Thebatteryisbeingcharged.
Whenthebatterychargereaches
20%,theblinkingcolorwillchange
towhite.
Blinkingslowly
(white)
Thebatteryhasbetween20%and
80%chargeandisstillcharging.
Whenthebatteryreaches80%
chargethelightwillstopblinking,
butchargingwillcontinueuntilthe
batteryisfullycharged.
2 Powerstatusindicator On(solidwhite) Thecomputerispoweredon.
Blinking Thecomputerisinsleepmode.
Off Thecomputerispoweredoff.
29
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Fn key combinations/Hotkeys
Thefollowing tableshows thefunctionofeachcombination ofFn witha
functionkey.
Table 3. Fn key combinations
Lenovo Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
Fn + Home: Activatesthepausefunction.
Fn + End: Activatesthebreakfunction.
Fn + PgUp : Enables/disablesthescrolllock.
Fn + PgDn : Activatestheinsertfunction.
Fn + Space
(on select models): Adjuststhekeyboardbacklight(off→dim→bright→off).
Lenovo Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Fn + Home: Activatesthepausefunction.
Fn + End: Activatesthebreakfunction.
Fn + PgUp : Enables/disablesthescrolllock.
Fn + PgDn : Activatesthesystemrequest.
Fn + Space
(on select models): Adjuststhekeyboardbacklight(off→dim→bright→off).
Youcan accesscertain systemsettings quicklyby pressingthe appropriate
hotkeys.
Table 4. Hotkeys
: Mutes/unmutesthesound. : Enables/disablesAirplane
mode.
: Decreasesthevolumelevel. : Displaysallcurrentlyactive
apps.
: Increasesthevolumelevel. : Turnson/offthebacklightof
theLCDscreen.
: Closesthecurrentlyactive
window. :
Togglesthedisplaybetween
thecomputerandanexternal
device.
: Refreshesthedesktoporthe
currentlyactivewindow. : Decreasesthedisplay
brightness.
: Enables/disablesthe
touchpad. : Increasesthedisplay
brightness.
30
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
FRU replacement notices
Thissection presentsnoticesrelatedtoremoving andreplacingparts. Read
thissectioncarefullybeforereplacinganyFRU.
Screw notices
Loosescrewscancause areliability problem.IntheLenovocomputer,this
problemisaddressedwithspecialnylon-coatedscrewsthathavethefollowing
characteristics:
• Theymaintaintightconnections.
• Theydonoteasilycomeloose,evenwithshockorvibration.
• Theyarehardertotighten.
Dothefollowingwhenyouservicethismachine:
• Keepthescrewkitinyourtoolbag.
• CarefullyremovescrewsforreusewhenreplacingFRUs.
• Useatorquescrewdriverifyouhaveone.
Tightenscrewsasfollows:
• Plastic to plastic
 Turnanadditional90° afterthe screwhead touchesthe surfaceofthe
plasticpart:
more than 90°
(Cross-section)
• Logic card to plastic
 Turnanadditional180°afterthescrewheadtouchesthesurfaceofthe
logiccard:
more than 180°
(Cross-section)
• Torque driver
 Ifyouhaveatorquescrewdriver,refertothe“Torque”columnforeachstep.
• Makesurethatyouusethecorrectscrews.Ifyouhaveatorquescrewdriver,
tightenallscrewsrmlytothetorqueshowninthetable.Carefully remove
screws for reuse when replacing FRUs. Make sure that all screws are
tightened rmly.
• Ensuretorque screwdriversarecalibratedcorrectlyfollowing country
specications.
31
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Removing and replacing an FRU
Thissectionpresentsexplodedgures withtheinstructionstoindicatehowto
removeandreplacetheFRU.Makesuretoobservethefollowinggeneralrules:
1. Donotattempttoserviceanycomputerunlessyouhavebeentrainedand
certied.Anuntrainedpersonrunstheriskofdamagingparts.
2. BeforereplacinganyFRU,review“FRUreplacementnotices”onpage30.
3. Beginby removingany FRUsthat haveto beremoved beforethe failing
FRU.AnyofsuchFRUsarelistedatthetopofthepage.Removethemin
theorderinwhichtheyarelisted.
4. FollowthecorrectsequenceinthestepstoremovetheFRU,asgiveninthe
guresbythenumbersinsquarecallouts.
5. WhenturningascrewtoreplaceanFRU,turnitinthedirectionasgivenby
thearrowinthegure.
6. WhenremovingtheFRU,move itinthedirectionasgivenbythearrow in
thegure.
7. Toput thenewFRUinplace,reversetheremovalproceduresandfollow
anyofthenotesthatpertain toreplacement. Forinformation about
connectingandarranginginternalcables,see“Locations”onpage74.
8. WhenreplacinganFRU,usethecorrectscrewasshownintheprocedures.
DANGER
Before removing any FRU, turn off the computer, unplug all power cords from
electrical outlets, remove the battery pack, and then disconnect any of the
interconnecting cables.
Attention:AfterreplacinganFRU,donotturnonthecomputeruntilyouhave
madesurethatallscrews,springs,andothersmallpartsareinplaceandnone
areloose insidethe computer.Verifythis byshakingthecomputergently and
listeningforrattlingsounds.Metallic partsormetalakescancauseelectrical
shortcircuits.
Attention:Thesystem boardissensitiveto,andcanbe damagedby,
electrostaticdischarge. Beforetouchingit,establishpersonal groundingby
touchingagroundpointwithonehandorusinganelectrostaticdischarge(ESD)
strap(P/N6405959)toremovepotentialshockreasons.
Notes:
• The following procedures about removing and replacing FRUs are the same for the
Lenovo Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL.
• The illustrations used in this section are of the Lenovo Yoga 500-15IBD, unless
otherwise stated.
32
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
1010 Base cover
Figure 1. Removal steps of base cover
Removethescrews1.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
1
1
1
1
1
1
11
1
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
1
1
1
1
1
1
1
1
1
1
Step Screw (quantity) Color Torque
1M2.0×6.0mm,Phillipshead,nylok-coated(10)
LCASEtoUCASE(Yoga500-14IBD/
Yoga500-14IHW/Yoga500-14ACL/
Yoga500-14ACZ)
Black 2.0kgf*cm
1M2.0×6.0mm,Phillipshead,nylok-coated(11)
LCASEtoUCASE(Yoga500-15IBD/
Yoga500-15IHW/Yoga500-15ACL)
Black 2.0kgf*cm
33
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 1. Removal steps of base cover (continued)
Removethebasecoverinthedirectionsshownbyarrows2and3.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
3
2
2
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
3
2
2
34
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Note: Applying labels to the base cover
ThenewbasecoverFRUis shippedwith akit containinglabels ofseveral
kinds.Whenyoureplacethebasecover,youneedtoapplythefollowinglabels:
Thefollowinglabelsneedtobepeeledofffromtheoldbasecoverandputon
thenewbasecover.
a Barcodelabel
b Ratinglabel
c GMLlabel
d BTlabel(forUS/CA/TW)
e WLlabel(forUS/CA/TW)
f KCClabel(forKorea)
g Postellabel(forIndonesia)
h Dsidelabel(forIndonesia)
i BISlabel(forIndia)
j WL/BTlabel(forIsrael)
k WL/BTlabel(forBrazil)
l WLlabel(forSouthAfrica)
Forsomemodels,youalsoneedtoapplyoneortwoFCClabels.Checkthe
oldbasecover;ifithasoneortwoFCClabels,ndduplicatesoftheminthe
labelkitandapplythemtothenewbasecover.
Forthelocationofeachlabel,refertothefollowinggure:
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
a
c
deghi
j
kl
f
b b
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
deghi
j
kl
f
a
c
b b
35
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1020 Battery pack
Foraccess,removethisFRU:
• “1010Basecover”onpage32
DANGER
Only use the battery specied in the parts list for your computer. Any other battery
could ignite or explode.
Figure 2. Removal steps of battery pack
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
Disconnectthe FPCconnector inthedirectionshownbyarrows1and2.
Unplugthebatteryconnectorinthedirectionshownbyarrow3,thenremove
thescrews4.Removethebatterypack5.
5
4
4
3
2
1
Step Screw (quantity) Color Torque
4M2.0×4.0mm,Phillipshead,nylok-coated(2)
BatterytoUCASE(Yoga500-14IBD/
Yoga500-14IHW/Yoga500-14ACL/
Yoga500-14ACZ)
Black 2.0kgf*cm
36
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 2. Removal steps of battery pack (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Unplugthebatteryconnectorinthedirectionshownbyarrow1,thenremove
thescrews2.Removethebatterypack3.
1
22
3
Step Screw (quantity) Color Torque
2M2.0×2.5mm,Phillipshead,nylok-coated(2)
BatterytoUCASE(Yoga500-15IBD/
Yoga500-15IHW/Yoga500-15ACL)
Black 2.0kgf*cm
When installing:Makesurethattheconnectorsareattachedrmly.
37
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1030 Hard disk drive
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
Attention:
• Donotdropthehard diskdriveorapplyanyphysicalshockto it. The hard
disk drive is sensitive to physical shock. Improper handling can cause damage and
permanent loss of data.
• Before removing the drive, suggest the customer to backup all the information on
it if possible.
• Never remove the drive while the system is operating or in suspend mode.
Figure 3. Removal steps of hard disk drive
Removethethreescrews1.Pulltheharddiskdriverinthedirectionshownby
arrow2.Thenremovetheharddiskdrive.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
1
1
2
38
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 3. Removal steps of hard disk drive (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
1
1
2
Step Screw (quantity) Color Torque
1M2.0×2.5mm,Phillipshead,nylok-coated(3)
HDDBrkttoUCASE
Black 2.0kgf*cm
When installing:MakesurethattheHDDconnectorisattachedrmly.
39
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 3. Removal steps of hard disk drive (continued)
Peelofftheharddiskdrivemylarlabelinthedirectionshownbyarrow3.
Removethescrews4anddetachthemetalframefromtheharddiskdrive.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
3
4
4
4
4
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
3
4
4
4
4
Step Screw (quantity) Color Torque
4M3.0×4.0mm,Phillipshead,nylok-coated(4)
HDDBrkttoHDD
Silver 2.5kgf*cm
40
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
1040 PCI Express Mini Card for wireless LAN
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
Figure 4. Removal steps of PCI Express Mini Card for wireless LAN
DisconnectthetwowirelessLANcables(black,white)1,andthenremovethe
screw2.
2
11
Instep1,unplugthejacksbyusingthe removaltoolantennaRFconnector
(P/N:08K7159),orpickuptheconnectorswithyourngersandgentlyunplug
theminthedirectionshownbythearrows.
Notes:ThewirelessLANcardhas2cablesinstep1.
 ThewirelessLANcardinsomemodelsmighthave3cablesinstep1.
Step Screw (quantity) Color Torque
2M2.0×2.5mm,Phillipshead,nylok-coated(1)
NGFFtoMB
Black 2.0kgf*cm
41
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 4. Removal steps of PCI Express Mini Card for wireless LAN (continued)
Removethecardinthedirectionshownbyarrow3.
3
When installing:
• Inmodelswitha wirelessLAN cardthathastwoantennaconnectors,plug
theblackcable(1st)(MAIN)intothejacklabeledMAIN,andthewhitecable
(2nd)(AUX)intothejacklabeledAUXonthecard.
• InmodelswithawirelessLANcardthathasthreeantennaconnectors,plug
theblackcable(1st)(MAIN)intothejacklabeled1,thegreycable(3rd)into
thejacklabeled3,andthewhitecable(2nd)(AUX)intothejacklabeled2on
thecard.
42
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
1050 DIMM
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
Figure 5. Removal steps of DIMM
Releasethe twolatchesonbothedges ofthesocketatthesametime inthe
directionsshown byarrows 1,andthenunplugtheDIMMin thedirection
shownbyarrow2.
1 1
2
When installing:InsertthenotchedendoftheDIMMintothesocket.Pushthe
DIMMrmly,andpivotituntilitsnapsintoplace.Makesurethatitisrmlyxed
intheslotandisdifculttomove.
43
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1060 IO board
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
Figure 6. Removal steps of IO board
DetachtheLEDboardconnectorinthedirectionsshownbyarrows1and2.
Removethescrew3.
1
23
Step Screw (quantity) Color Torque
3M2.0×4.0mm,Phillipshead,nylok-coated(1)
IOtoHingetoUcase(Yoga500-14IBD/
Yoga500-14IHW/Yoga500-14ACL/
Yoga500-14ACZ)
Black 2.0kgf*cm
3M2.0×2.5mm,Phillipshead,nylok-coated(1)
IOtoUcase(Yoga500-15IBD/Yoga500-15IHW/
Yoga500-15ACL)
Black 2.0kgf*cm
RemovetheLEDboardinthedirectionshownbyarrow4.
4
When installing:Makesurethattheconnectorisattachedrmly.
44
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
1070 Speakers
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
Figure 7. Removal steps of speakers
Detachtheconnectorinthedirectionshownbyarrow1.
1
Removethespeakersinthedirectionshownbyarrows2.
2
2
When installing:Makesurethattheconnectorisattachedrmly.
45
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1080
Fan assembly and Heat Sink assembly
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
Figure 8. Removal steps of fan assembly and heat sink assembly
Unplugthefanconnectorinthedirectionshownbyarrow1.Loosentheve
screws2.Releasethecablesfromthecableguides3.
2
2
2
2
2
1
33
46
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 8. Removal steps of fan assembly and heat sink assembly (continued)
RemovetheFanandHeatSinkinthedirectionshownbyarrow4.
4
When installing:
• Routetheantennacablesalongthecableguides.Asyouroutethecables,
makesurethattheyarenotsubjectedtoanytension.Tensioncould cause
thecablestobedamagedbythecableguides,orawiretobebroken.
• Makesurethattheconnectorisattachedrmly.
ab
When installing:
Beforeyou attachthe fanassemblytothecomputer,apply thermalgrease,
atanamountof0.2grams,tothe  partshowninthegureabove.Either
toomuchortoo lessgrease applicationcancauseathermalproblemdueto
imperfectcontactwithacomponent.
47
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1090
System board
Important notices for handling the system board:
When handling the system board, bear the following in mind.
• Be careful not to drop the system board on a bench top that has a hard surface,
such as metal, wood, or composite.
• Avoid rough handling of any kind.
• During the whole process, make sure not to drop or stack the system board.
• If you put a system board down, make sure to put it only on a padded surface such
as an ESD mat or conductive corrugated material.
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
Figure 9. Removal steps of system board
DetachtheLCDcableinthedirectionshownbyarrows1and2.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
2
48
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
2
When installing:Makesurethattheconnectorisattachedrmly.
Removethescrews3.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
3
3
3
3
3
49
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
33
3
33
33
Step Screw (quantity) Color Torque
3M2.0×4.0mm,Phillipshead,nylok-coated(5)
HingetoUCASE(Yoga500-14IBD/
Yoga500-14IHW/Yoga500-14ACL/
Yoga500-14ACZ)
Black 2.0kgf*cm
3M2.5×4.0mm,Phillipshead,nylok-coated(7)
HingetoUCASE(Yoga500-15IBD/
Yoga500-15IHW/Yoga500-15ACL)
Silver 2.5kgf*cm
Openthehinges4.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
4
4
4
50
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
4
4
4
DisconnecttheDC-incableinthedirectionshownbyarrow5.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
5
51
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
5
When installing:Makesurethattheconnectorisattachedrmly.
RemovetheDC-incableinthedirectionshownbyarrows6.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
6
6
52
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
6
6
Disconnectthe connectorsinthedirectionshown byarrows 7,8and9.
Removethescrewsj.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
10
10
7
8
9
8
9
53
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
7
8
9
8
8
9
9
10
10
Step Screw (quantity) Color Torque
jM2.0×2.5mm,Phillipshead,nylok-coated(2)
M/BtoUcase
Silver/
Black
2.0kgf*cm
When installing:Makesurethattheconnectorsareattachedrmly.
Removethesystemboardk.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
11
54
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 9. Removal steps of system board (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
11
55
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1100 Touchpad module and upper case
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
• “1090Systemboard”onpage47
Figure 10. Removal steps of touchpad module and upper case
Peeloffthekeyboardmylarinthedirectionshownbyarrow1.Removethe
twoscrews2.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
2
2
56
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 10. Removal steps of touchpad module and upper case (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
2
1
2
Step Screw (quantity) Color Torque
2M2.0×2.5mm,Phillipshead,nylok-coated(2)
TPBracketrtoUcase
Black 2.0kgf*cm
57
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 10. Removal steps of touchpad module and upper case (continued)
Removethetouchpadmodulefromtheuppercaseinthedirectionshownby
arrows3and4.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
3
34
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
3
34
58
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 10. Removal steps of touchpad module and upper case (continued)
Removetheuppercaseinthedirectionshownbyarrow5.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
5
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
5
59
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1110 LCD unit
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
• “1090Systemboard”onpage47
• “1100Touchpadmoduleanduppercase”onpage55
Figure 11. Removal steps of LCD unit
RemoveLCDbezelscrewpads1andthescrews2.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
1
2
2
60
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 11. Removal steps of LCD unit (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
1
2
2
Step Screw (quantity) Color Torque
2M2.0×4.0mm,Phillips-head,nylok-coated(2)
BezelcovertoPanel
Black/
Silver
2.0kgf*cm
61
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 11. Removal steps of LCD unit (continued)
SeparatethehingecoverfromtherestofLCDunitwithapryingtool3.Remove
thehingecoverandLCDbezelcoverinthedirectionshownbyarrows4.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
4
4
4
3
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
4
34
4
62
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
1120 Hinges and LCD cover
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
• “1090Systemboard”onpage47
• “1100Touchpadmoduleanduppercase”onpage55
• “1110LCDunit”onpage59
Figure 12. Removal steps of hinges and LCD cover
Adjustthehinges1andremovethehingerubbers2.Removethescrew3.
ThenremovetheLCDmoduleinthedirectionshownbyarrow4.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
3
3
2
1
4
4
63
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 12. Removal steps of hinges and LCD cover (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
3
2
1
4
4
Step Screw (quantity) Color Torque
3M2.0×4.0mm,Phillips-head,nylok-coated(2)
BezeltoPanel(Yoga500-14IBD/Yoga500-14IHW/
Yoga500-14ACL/Yoga500-14ACZ)
Black 2.0kgf*cm
3M2.0×4.0mm,Phillips-head,nylok-coated(1)
BezeltoPanel(Yoga500-15IBD/
Yoga500-15IHW/Yoga500-15ACL)
Silver 2.0kgf*cm
When installing:
• Makesurethattheconnectorisattachedrmly.
• PushtheLCDmoduleinthedirectionshownbythearrowonillustration
below,otherwisethehooksoftheLCDcovermightbedamaged.
64
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 12. Removal steps of hinges and LCD cover (continued)
Removethescrews5.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
5
5
5
5
5
5
5
5
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
5
5
5
5
5
5
5
5
Step Screw (quantity) Color Torque
5M2×2.5mm,Phillips-head,nylok-coated(8)
LCD-BrkttoHingetoPanel
Black 2.0kgf*cm
65
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 12. Removal steps of hinges and LCD cover (continued)
Removethehinges6.
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
6
6
6
6
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
6
6
6
6
66
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
1130 Sensor board and antenna assembly
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
• “1090Systemboard”onpage47
• “1100Touchpadmoduleanduppercase”onpage55
• “1110LCDunit”onpage59
• “1120HingesandLCDcover”onpage62
Figure 13. Removal steps of sensor board and antenna assembly
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
Peelofftheadhesivetapesecuringthecables1.
1
1
1
67
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 13. Removal steps of sensor board and antenna assembly (continued)
Detachthesensorboardconnectorinthedirectionshownbyarrow2.
2
When installing:Makesurethattheconnectorisattachedrmly.
68
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 13. Removal steps of sensor board and antenna assembly (continued)
Peelofftheadhesivetapesecuringtheantennaboards.Releasethecables
fromthecableguide,andthenremovetheantennaassemblyandsensor
boardcableinthedirectionshownbyarrows3.
3
3
3
Removethesensorboardinthedirectionshownbyarrow4.
4
69
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Figure 13. Removal steps of sensor board and antenna assembly (continued)
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Detachthesensorboardconnectorinthedirectionshownbyarrow1,then
removethesensorboardinthedirectionshownbyarrow2.
2
1
When installing:Makesurethattheconnectorisattachedrmly.
Peelofftheadhesivetapesecuringthecables3.
3
3
3
70
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 13. Removal steps of sensor board and antenna assembly (continued)
Peelofftheadhesivetapesecuringtheantennaboards.Releasethecables
fromthecableguide,andthenremovetheantennaassemblyandsensor
boardcableinthedirectionshownbyarrows4.
4
4
4
When installing:Routetheantennacablesalongthecableguidesandsecure
theantenna boardswith adhesivetape.As youroutethecables,make sure
thattheyarenot subjectedtoanytension.Tensioncouldcausethecablesto
bedamagedbythecableguides,orawiretobebroken.
71
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1140 LCD module
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
• “1090Systemboard”onpage47
• “1100Touchpadmoduleanduppercase”onpage55
• “1110LCDunit”onpage59
• “1120HingesandLCDcover”onpage62
Figure 14. Removal steps of LCD module
Detachthethreeconnectorsinthedirectionsshownbyarrows1.
1
1
1
When installing:Makesurethattheconnectorsareattachedrmly.
72
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Figure 14. Removal steps of LCD module (continued)
RemovetheLCDcable2.
2
73
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1150 Integrated camera
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage32
• “1020Batterypack”onpage35
• “1030Harddiskdrive”onpage37
• “1040PCIExpressMiniCardforwirelessLAN”onpage40
• “1060IOboard”onpage43
• “1070Speakers”onpage44
• “1080FanassemblyandHeatSinkassembly”onpage45
• “1090Systemboard”onpage47
• “1100Touchpadmoduleanduppercase”onpage55
• “1110LCDunit”onpage59
• “1120HingesandLCDcover”onpage62
• “1140LCDmodule”onpage71
Figure 15. Removal steps of integrated camera
Note:TheintegratedcameraisstucktothetopoftheLCDcover.Becareful
whenremovingit.
Removetheintegratedcamerainthedirectionshownbyarrow1.
1
When installing:SticktheintegratedcameratotheLCDcoverandadjustthe
placementoftheboardtomakesuretheconnectorsareattachedrmly.
74
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Locations
Front view and right-side view
1 Integratedcamera
2 Built-inmicrophone
3 WirelessLANantennas
4 Multi-touchscreen
5 HDMIport
6 RJ-45port
7 USBport
8 Novobutton
9 Powerbutton
J Batterystatusindicator
Note:Forthedescriptionofeachindicator,see“Statusindicators”onpage28.
K Touchpad
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
13
3
4
11
5
6
7
8
9
2
10
75
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
3
3
2
4
11
5
6
7
8
9
10
76
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Bottom and Left-side view
1 Speaker
2 Volumeupbutton
3 Volumedownbutton
4 Rotationlockbutton
5 Comboaudiojack
6 Memorycardslot
7 USBport
8 ACpoweradapterjack
9 Kensingtonlockslot
j Ventilationslots
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
2
3
4
6
5
9
8
7
1
10
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
2
3
4
6
5
9
8
7
1
10
77
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Parts list
Thissectionpresentsthefollowingserviceparts:
• “Overall”onpage78
• “LCDFRUs”onpage87
• “Miscellaneousparts”onpage89
• “ACadapters”onpage90
• “Screws”onpage90
• “Powercords”onpage91
Note:
Each FRU is available for all types or models, unless specic types or models are
specied.
Attention:
DonotattempttoreplaceanFRUonyourown.IfanFRUisdamaged,contact
aLenovoauthorizedserviceroramarketing representativeforreplacement
orrepair.Onlyqualiedtechnicianscaninspectorrepairthisproduct.
78
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Overall
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/
Yoga 500-14ACZ
1
3
4
b
6
8
10
12
11
9
7
5
2
a
79
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
1
3
4
b
6
8
10
12
11
9
7
5
2
a
80
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Table 5. Parts list—Overall
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
a-b
See“Miscellaneousparts”onpage89.
1
LCDunit(see“LCDFRUs”onpage87.)
2
UpperCaseWFlex3-1470US 5CB0H91250
N ● ● ●
2
UpperCaseWFlex3-1470BKLUS 5CB0H91126
N ● ● ●
2
UpperCaseWFlex3-1470UK 5CB0H91156
N ● ● ●
2
UpperCaseWFlex3-1470BKLUK 5CB0H91188
N ● ● ●
2 UpperCaseWFlex3-1470NBKLAR
5CB0J34024
N ●
2 UpperCaseWFlex3-1470NBKLGK
5CB0J34081
N ●
2 UpperCaseWFlex3-1470NBKLHE
5CB0J34019
N ●
2UpperCaseWFlex3-1470NBKL
INDIA
5CB0J34075
N ●
2 UpperCaseWFlex3-1470NBKLKR
5CB0J34014
N ●
2 UpperCaseWFlex3-1470NBKLTC
5CB0J34069
N ●
2 UpperCaseWFlex3-1470NBKLRU
5CB0J34007
N ●
2 UpperCaseWFlex3-1470NBKLTH
5CB0J34061
N ●
2UpperCaseWFlex3-1470NBKLUS
INT
5CB0J34013
N ●
2 UpperCaseWFlex3-1470BKLAR
5CB0J34107
N ●
2 UpperCaseWFlex3-1470BKLGK
5CB0J34071
N ●
2 UpperCaseWFlex3-1470BKLHE
5CB0J34009
N ●
2 UpperCaseWFlex3-1470BKLINDIA
5CB0J34065
N ●
2 UpperCaseWFlex3-1470BKLKR
5CB0J34001
N ●
2 UpperCaseWFlex3-1470BKLTC
5CB0J34055
N ●
2 UpperCaseWFlex3-1470BKLRU
5CB0J34106
N ●
2 UpperCaseWFlex3-1470BKLTH
5CB0J34053
N ●
2 UpperCaseWFlex3-1470BKLUSINT
5CB0J34105
N ●
2 UpperCaseWFlex3-1470BKLUSA
5CB0J34044
N ●
2 UpperCaseWFlex3-1470NBKLIT
5CB0J34070
N ●
2 UpperCaseWFlex3-1470NBKLSP
5CB0J34008
N ●
2 UpperCaseWFlex3-1470NBKLTR
5CB0J34062
N ●
2 UpperCaseWFlex3-1470NBKLPO
5CB0J34000
N ●
2 UpperCaseWFlex3-1470NBKLLA
5CB0J34054
N ●
2 UpperCaseWFlex3-1470NBKLEF-C
5CB0J34108
N ●
2 UpperCaseWFlex3-1470NBKLFR
5CB0J34046
N ●
2 UpperCaseWFlex3-1470NBKLGR
5CB0J34003
N ●
2 UpperCaseWFlex3-1470NBKLBZ
5CB0J34057
N ●
2 UpperCaseWFlex3-1470NBKLAR-E
5CB0J34110
N ●
2UpperCaseWFlex3-1470NBKL
DUTH
5CB0J34047
N ●
2 UpperCaseWFlex3-1470NBKLHG
5CB0J34020
N ●
2 UpperCaseWFlex3-1470NBKLND
5CB0J34076
N ●
2 UpperCaseWFlex3-1470NBKLBE
5CB0J34015
N ●
2 UpperCaseWFlex3-1470NBKLICE
5CB0J34067
N ●
2 UpperCaseWFlex3-1470NBKLSA
5CB0J34010
N ●
81
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Table 5. Parts list—Overall (continued)
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
2 Upper Case W Flex3-1470 NBKL SW
5CB0J34063
N●
2Upper Case W Flex3-1470 NBKL CZ-
SK
5CB0J34021
N●
2 Upper Case W Flex3-1470 NBKL BG
5CB0J34077
N●
2 Upper Case W Flex3-1470 BKL IT
5CB0J34101
N●
2 Upper Case W Flex3-1470 BKL SP
5CB0J34040
N●
2 Upper Case W Flex3-1470 BKL TR
5CB0J34093
N●
2 Upper Case W Flex3-1470 BKL PO
5CB0J34049
N●
2 Upper Case W Flex3-1470 BKL LA
5CB0J34102
N●
2 Upper Case W Flex3-1470 BKL EF-C
5CB0J34041
N●
2 Upper Case W Flex3-1470 BKL FR
5CB0J34094
N●
2 Upper Case W Flex3-1470 BKL GR
5CB0J34031
N●
2 Upper Case W Flex3-1470 BKL BZ
5CB0J34098
N●
2 Upper Case W Flex3-1470 BKL AR-E
5CB0J34036
N●
2 Upper Case W Flex3-1470 BKL DUTH
5CB0J34089
N●
2 Upper Case W Flex3-1470 BKL HG
5CB0J34028
N●
2 Upper Case W Flex3-1470 BKL ND
5CB0J34084
N●
2 Upper Case W Flex3-1470 BKL BE
5CB0J34022
N●
2 Upper Case W Flex3-1470 BKL ICE
5CB0J34078
N●
2 Upper Case W Flex3-1470 BKL SA
5CB0J34037
N●
2 Upper Case W Flex3-1470 BKL SW
5CB0J34090
N●
2 Upper Case W Flex3-1470 BKL CZ-SK
5CB0J34029
N●
2 Upper Case W Flex3-1470 BKL BG
5CB0J34085
N●
2
Upper Case W Flex3-1570 US 5CB0H91211
N● ●
2
Upper Case W Flex3-1570 BKL US 5CB0H91243
N● ●
2
Upper Case W Flex3-1570 UK 5CB0H91271
N● ●
2
Upper Case W Flex3-1570 BKL UK 5CB0H91148
N● ●
3
Touchpad Module W Flex3-1470W/C 5T60H91163
N●●●
3
Thouchpad Module W Flex3-150 5T60H91179
N● ●
4
Speaker W Flex3-1470 5SB0H91206
N●●●
4
Speaker W Flex3-1570 5SB0H91212
N● ●
5
Thermal Module W Flex 3-1470UMA 5H40H91253
N● ● ● ●
5
Thermal Module W Flex 3-1470DIS 5H40H91134
N● ● ● ●
5 Thermal Module W Flex3-1435 DIS
5H40J40285
N●
5 Thermal Module W Flex3-1435 UMA
5H40J40284
N●
6
I/O Board W Flex3-1470 W/Cable 5C50H91127
N●●●
6
I/O Board W Flex3-1570 W/Cable 5C50H91267
N● ●
7
MB W Flex3-1470 NOKI3-5005UMA B 5B20H91171
N●
7
MB W Flex3-1470 W8SI3-5005UMA B 5B20H91207
N●
7
MB W Flex3-1470 W8PI3-5005UMA B 5B20H91247
N●
7
MB W Flex3-1470NOK3805 GT2G 5B20H91128
N●
7
MB W Flex3-1470W8S3805 GT2G 5B20H91199
N●
7
MB W Flex3-1470W8P3805 GT2G 5B20H91235
N●
7
MB W Flex3-1470NOKI3-5010GT2G B 5B20H91119
N●
82
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Table 5. Parts list—Overall (continued)
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
7
MBWFlex3-1470W8SI3-5010GT2GB 5B20H91160
N ●
7
MBWFlex3-1470W8PI3-5010GT2GB 5B20H91198
N ●
7
MBWFlex3-1470NOKI5-5200GT2GB 5B20H91239
N ●
7
MBWFlex3-1470W8SI5-5200GT2GB 5B20H91122
N ●
7
MBWFlex3-1470W8PI5-5200GT2GB 5B20H91161
N ●
7
MBWFlex3-1470NOKI5-5200GM2GB 5B20H91201
N ●
7
MBWFlex3-1470W8SI5-5200GM2GB 5B20H91240
N ●
7
MBWFlex3-1470W8PI5-5200GM2GB 5B20H91123
N ●
7
MBWFlex3-1470NOKI7-5500GM2GB 5B20H91164
N ●
7
MBWFlex3-1470W8SI7-5500GM2GB 5B20H91219
N ●
7
MBWFlex3-1470W8PI7-5500GM2GB 5B20H91259
N ●
7
MBWFlex3-1470NOK3805UMA 5B20H91185
N ●
7
MBWFlex3-1470W8S3805UMA 5B20H91139
N ●
7
MBWFlex3-1470W8P3805UMA 5B20H91174
N ●
7
MBWFlex3-1470NOK3805GM2G 5B20H91209
N ●
7
MBWFlex3-1470W8S805GM2G 5B20H91246
N ●
7
MBWFlex3-1470W8P3805GM2G 5B20H91129
N ●
7
MBWFlex3-1470NOKI3-5005GT2GB 5B20H91169
N ●
7
MBWFlex3-1470W8SI3-5005GT2GB 5B20H91232
N ●
7
MBWFlex3-1470W8PI3-5005GT2GB 5B20H91272
N ●
7
MBWFlex3-1470NOKI3-5005GM2GB 5B20H91157
N ●
7
MBWFlex3-1470W8SI3-5005GM2GB 5B20H91196
N ●
7
MBWFlex3-1470W8PI3-5005GM2GB 5B20H91234
N ●
7
MBWFlex3-1470NOKI3-5010UMAB 5B20H91273
N ●
7
MBWFlex3-1470W8SI3-5010UMAB 5B20H91155
N ●
7
MBWFlex3-1470W8PI3-5010UMAB 5B20H91191
N ●
7
MBWFlex3-1470NOKI3-5010GM2GB 5B20H91229
N ●
7
MBWFlex3-1470W8SI3-5010GM2GB 5B20H91268
N ●
7
MBWFlex3-1470W8PI3-5010GM2GB 5B20H91152
N ●
7
MBWFlex3-1470NOKI5-5200UMAB 5B20H91189
N ●
7
MBWFlex3-1470W8SI5-5200UMAB 5B20H91226
N ●
7
MBWFlex3-1470W8PI5-5200UMAB 5B20H91264
N ●
7
MBWFlex3-1470NOKI7-5500UMAB 5B20H91147
N ●
7
MBWFlex3-1470W8SI7-5500UMAB 5B20H91186
N ●
7
MBWFlex3-1470W8PI7-5500UMAB 5B20H91220
N ●
7
MBWFlex3-1470NOKI7-5500GT2GB 5B20H91257
N ●
7
MBWFlex3-1470W8SI7-5500GT2GB 5B20H91151
N ●
7
MBWFlex3-1470W8PI7-5500GT2GB 5B20H91190
N ●
7
MBWFlex3-1470NOKI3-4005UMAHSW 5B20H91143
N ●
7
MBWFlex3-1470W8SI3-4005UMAHSW 5B20H91181
N ●
7
MBWFlex3-1470W8PI3-4005UMAHSW 5B20H91218
N ●
7
MBWFlex3-1470NOKI3-4005GM2GH 5B20H91256
N ●
7
MBWFlex3-1470W8SI3-4005GM2GH 5B20H91142
N ●
7
MBWFlex3-1470W8PI3-4005GM2GH 5B20H91184
N ●
83
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Table 5. Parts list—Overall (continued)
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
7
MBWFlex3-1470NOKI3-4030GM2GH 5B20H91222
N ●
7
MBWFlex3-1470W8SI3-4030GM2GH 5B20H91262
N ●
7
MBWFlex3-1470W8PI3-4030GM2GH 5B20H91146
N ●
7
MBWFlex3-1470NOKI3-4030UMAH 5B20H91228
N ●
7
MBWFlex3-1470W8SI3-4030UMAH 5B20H91265
N ●
7
MBWFlex3-1470W8PI3-4030UMAH 5B20H91149
N ●
7MBWFlex3-1435NOKA4-72102G
5B20J46141
N ●
7MBWFlex3-1435WINA4-72102G
5B20J46139
N ●
7MBWFlex3-1435NOKA4-7210UMA
5B20J46144
N ●
7MBWFlex3-1435WINA4-7210UMA
5B20J46147
N ●
7MBWFlex3-1435NOKA6-73102G
5B20J46134
N ●
7MBWFlex3-1435WINA6-73102G
5B20J46136
N ●
7MBWFlex3-1435NOKA6-7310UMA
5B20J46140
N ●
7MBWFlex3-1435WINA6-7310UMA
5B20J46146
N ●
7MBWFlex3-1435NOKA8-74102G
5B20J46135
N ●
7MBWFlex3-1435WINA8-74102G
5B20J46137
N ●
7MBWFlex3-1435NOKA8-7410UMA
5B20J46142
N ●
7MBWFlex3-1435WINA8-7410UMA
5B20J46138
N ●
7MBWFlex3-1435NOKE1-70102G
5B20J46143
N ●
7MBWFlex3-1435WINE1-70102G
5B20J46145
N ●
7MBWFlex3-1435NOKE1-7010UMA
5B20J46148
N ●
7MBWFlex3-1435WINE1-7010UMA
5B20J46133
N ●
7
MBWFlex3-1570NOKI3-5010UMAB 5B20H91263
N ●
7
MBWFlex3-1570W8SI3-5010UMAB 5B20H91145
N ●
7
MBWFlex3-1570W8PI3-5010UMAB 5B20H91183
N ●
7
MBWFlex3-1570NOK3805GT2GB 5B20H91216
N ●
7
MBWFlex3-1570W8S3805GT2GB 5B20H91255
N ●
7
MBWFlex3-1570W8P3805GT2GB 5B20H91138
N ●
7
MBWFlex3-1570NOKI5-5200GT2GB 5B20H91176
N ●
7
MBWFlex3-1570W8SI5-5200GT2GB 5B20H91214
N ●
7
MBWFlex3-1570W8PI5-5200GT2GB 5B20H91252
N ●
7
MBWFlex3-1570NOKI3-5010GT2GB 5B20H91136
N ●
7
MBWFlex3-1570W8SI3-5010GT2GB 5B20H91175
N ●
7
MBWFlex3-1570W8PI3-5010GT2GB 5B20H91221
N ●
7
MBWFlex3-1570NOKI7-5500GT2GB 5B20H91261
N ●
7
MBWFlex3-1570W8SI7-5500GT2GB 5B20H91144
N ●
7
MBWFlex3-1570W8PI7-5500GT2GB 5B20H91182
N ●
7
MBWFlex3-1570NOK3805UMABDW 5B20H91132
N ●
7
MBWFlex3-1570W8S3805UMABDW 5B20H91224
N ●
7
MBWFlex3-1570W8P3805UMABDW 5B20H91258
N ●
7
MBWFlex3-1570NOK3805GM2GB 5B20H91140
N ●
7
MBWFlex3-1570W8S3805GM2GB 5B20H91177
N ●
7
MBWFlex3-1570W8P3805GM2GB 5B20H91213
N ●
7
MBWFlex3-1570NOKI3-5010GM2GB 5B20H91251
N ●
84
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Table 5. Parts list—Overall (continued)
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
7
MBWFlex3-1570W8SI3-5010GM2GB 5B20H91135
N ●
7
MBWFlex3-1570W8PI3-5010GM2GB 5B20H91173
N ●
7
MBWFlex3-1570NOKI5-5200UMAB 5B20H91210
N ●
7
MBWFlex3-1570W8SI5-5200UMAB 5B20H91248
N ●
7
MBWFlex3-1570W8PI5-5200UMAB 5B20H91130
N ●
7
MBWFlex3-1570NOKI5-5200GM2GB 5B20H91168
N ●
7
MBWFlex3-1570W8SI5-5200GM2GB 5B20H91205
N ●
7
MBWFlex3-1570W8PI5-5200GM2GB 5B20H91245
N ●
7
MBWFlex3-1570NOKI7-5500UMAB 5B20H91131
N ●
7
MBWFlex3-1570W8SI7-5500UMAB 5B20H91167
N ●
7
MBWFlex3-1570W8PI7-5500UMAB 5B20H91203
N ●
7
MBWFlex3-1570NOKI7-5500GM2GB 5B20H91242
N ●
7
MBWFlex3-1570W8SI7-5500GM2GB 5B20H91125
N ●
7
MBWFlex3-1570W8PI7-5500GM2GB 5B20H91165
N ●
7
MBWFlex3-1570NOKI3-5005UMAB 5B20H91158
N ●
7
MBWFlex3-1570W8SI3-5005UMAB 5B20H91194
N ●
7
MBWFlex3-1570W8PI3-5005UMAB 5B20H91231
N ●
7
MBWFlex3-1570NOKI3-5005GT2GB 5B20H91270
N ●
7
MBWFlex3-1570W8SI3-5005GT2GB 5B20H91154
N ●
7
MBWFlex3-1570W8PI3-5005GT2GB 5B20H91192
N ●
7
MBWFlex3-1570NOKI3-5005GM2GB 5B20H91230
N ●
7
MBWFlex3-1570W8SI3-5005GM2GB 5B20H91269
N ●
7
MBWFlex3-1570W8PI3-5005GM2GB 5B20H91153
N ●
7
MBWFlex3-1570NOKI3-4005UMAH 5B20H91244
N ●
7
MBWFlex3-1570W8SI3-4005UMAH 5B20H91124
N ●
7
MBWFlex3-1570W8PI3-4005UMAH 5B20H91162
N ●
7
MBWFlex3-1570NOKI3-4005GM2GH 5B20H91200
N ●
7
MBWFlex3-1570W8SI3-4005GM2GH 5B20H91236
N ●
7
MBWFlex3-1570W8PI3-4005GM2GH 5B20H91120
N ●
7
MBWFlex3-1570NOKI3-4030GM2GH 5B20H91159
N ●
7
MBWFlex3-1570W8SI3-4030GM2GH 5B20H91197
N ●
7
MBWFlex3-1570W8PI3-4030GM2GH 5B20H91249
N ●
7
MBWFlex3-1570NOKI3-4030UMAH 5B20H91202
N ●
7
MBWFlex3-1570W8SI3-4030UMAH 5B20H91238
N ●
7
MBWFlex3-1570W8PI3-4030UMAH 5B20H91121
N ●
8
WLAN&BT,Intel31601x1AC+BTPCIE
M.2ROMWLANSAR
SW10A11513
N ● ● ● ●
8
WLAN&BT,CbtBCM431621x1AC+BT4.0
PCIEM.2WLANV2
SW10A11586
N●●●●●●●
8
WLAN&BT,LtnNFA3451x1AC+BT4.0
PCIEM.2WLANV2
SW10A11628
N●●●●●●●
8
WLAN&BT,CbtBCM43522x2AC+BT4.0
PCIEM.2WLAN
20200480
N ● ● ●
85
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Table 5. Parts list—Overall (continued)
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
8
WLAN&BT,LtnNFA3442x2AC+BT4.0
PCIEM.2WLANV2
SW10A11630
N ● ● ●
8
WLAN&BT,LtnNFA3351x1BN+BT4.0
PCIEM.2WLAN
20200558
N●●●●●●●
9
RAM,4GBDDR3L1600,
M471B5173EB0-YK0
5M30G18425
N●●●●●●●
9
RAM,4GBDDR3L1600,
HMT451S6BFR8A-PB/
RD4GBDDR3L1600
11202706
N●●●●●●●
9
RAM,4GBDDR3L1600,
RMT3170MN68F9F-1600N-die/25nm/
4GbMono
5M30G75129
N●●●●●●●
9
RAM,4GBDDR3L1600,MT8KTF51264HZ-
1G6E14GBDDR3L1600
11202125
N●●●●●●●
9
RAM,8GBDDR3L1600,MEMORY
M471B1G73EB0-YK016008GB
5M30G18424
N ● ● ● ● ●
9
RAM,8GBDDR3L1600,HMT41GS6BFR8A-
PB/RD8GBDDR3L1600
11202707
N ● ● ● ● ●
9
RAM,8GBDDR3L1600,
RMT3160ME68FAF-16008GBDDR3L1600
11202450
N ● ● ● ● ●
9
RAM,8GBDDR3L1600,MT16KTF1G64HZ-
1G6E18GBDDR3L1600
11201304
N ● ● ● ● ●
10
Battery,TeslaSP/AL14M2P21
7.4V30Wh2cellbty
5B10G78612
N●●●●●●●
10
Battery,TeslaSP/CL14M2P21
7.4V30Wh2cellbty
5B10G78610
N●●●●●●●
10
Battery,TeslaSP/AL14M3P21
11.1V45Wh3cellbty
5B10G78611
N●●●●●●●
10
Battery,TeslaSP/CL14M3P21
11.1V45Wh3cellbty
5B10G78609
N●●●●●●●
11
Harddiskdrive,ST500LT0126G7mm
5.4K500GHDD
16200383
N●●●●●●●
11
Harddiskdrive,WD5000LPCX-24C6HT0 16200395
N●●●●●●●
11
Harddiskdrive,500G,HTS545050A7E660
6G7mm5.4K500GHDD
5H20H14223
N ● ● ●
11
Harddiskdrive,TSBMQ01ABF0506G
7mm5.4K500GHDD
16200433
N●●●●
11
Harddiskdrive,ST500LM0006G7mm
500G+8GSSHD
16200391
N●●●●●●●
11
Harddiskdrive,WD10SPCX-24HWST1
6G7mm1THDD
16200554
N●●●●●●●
11
Harddiskdrive,HTS541010A7E630
7mm5400rpm1THDD
16200658
N ● ● ●
11
Harddiskdrive,TSBMQ02ABF1006G
7mm5.4k1TBHDD
5H20G09709
N●●●●
11
Harddiskdrive,WD10S21X-24R1BT0
7mm5400rpm1TB+8GSSHD
16200681
N ● ● ● ●
12
LowerCaseWFlex3-1470Red 5CB0H91133
N ● ●
86
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Table 5. Parts list—Overall (continued)
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
12
LowerCaseWFlex3-1470Black 5CB0H91166
N ● ●
12
LowerCaseWFlex3-1470White 5CB0H91195
N ● ●
12
LowerCaseWFlex3-1435Black 5CB0J40286
N ●
12
LowerCaseWFlex3-1435Red 5CB0J46654
N ●
12
LowerCaseWFlex3-1435White 5CB0J46659
N ●
12
LowerCaseWFlex3-1570Black 5CB0H91141
N ● ●
12
LowerCaseWFlex3-1570White 5CB0H91172
N ● ●
—
ACadapter(see“ACadapters”onpage90).
87
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
LCD FRUs
InLenovoYoga500-14IBD/Yoga500-14IHW/Yoga500-14ACL/Yoga500-14ACZ/
Yoga500-15IBD/Yoga500-15IHW/Yoga500-15ACL,therearefollowingtypesofLCDs.
• “14.0-in.HDLED”
• “15.6-in.HDLED”
1
3
6
8
9
7
5
4
2
88
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Table 6. Parts list—LCD FRUs
No.
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
1 BezelCoverWFlex3-1470L/R/M
5B30H91254
N ● ● ●
1 BezelCoverWFlex3-1470L/R/M
5B30J15974
N ● ●
2 LCDModuleWFlex3-1470FHD
5D10H91421
N ● ● ●
2 LCDModuleWFlex3-1470HD
5D10H91420
N ● ● ●
2 LCDModuleWFlex3-1570FHD
5D10H91423
N ● ●
2 LCDModuleWFlex3-1570HD
5D10H91422
N ● ●
3Camera,BISBNC416YTKHDNBcamera
5C20G89272
N●●●●●●●
3Camera,AVCHAA-6D0F03HDNBcamera
5C20G89276
N●●●●●●●
3 Camera,CCYCNFEH39HDNBcamera
5C20G89264
N●●●●●●●
3Camera,BISBNC7VTKTD0.3MNBcamera
5C20G89273
N●●●●●●●
3Camera,LTN4SF015N20.3MNBcamera
5C20G89274
N●●●●●●●
3Camera,AVCHAA-584B010.3MNBcamera
5C20G89267
N●●●●●●●
3CameraWS41-70HDW/2MIC
5C20J32317
N ● ● ● ●
3CameraWS41-700.3M/1MIC
5C20J32316
N ● ● ● ●
3 CameraWFlex3-1435HD1.0M2MIC
5C20J46195
N ●
3 CameraWFlex3-1435VGA0.3M1MIC
5C20J46196
N ●
4 HingeWFlex3-1470W/Rubber
5H50H91217
N ● ● ●
4 HingeWFlex3-1570W/Rubber
5H50H91180
N ● ●
5 LCDCableWFlex3-1470
5C10H91193
N ● ● ●
5 LCDCableWFlex3-1570
5C10H91208
N ● ●
6SensorBoardCableWFlex3-1470
5C10H91225
N ● ● ●
6SensorBoardCableWFlex3-1570
5C10H91266
N ● ●
7AntennaWFlex3-1470Main+Aux
5A30H91223
N ● ●
7AntennaWFlex3-1435
5A30J40283
N ●
7AntennaWFlex3-1570Main+Aux
5A30H91118
N ● ●
8 SensorBoardWFlex3-1470
5C50H91215
N ● ●
8 SensorBoardWFlex3-1435
5C50J40287
N ●
8 SensorBoardWFlex3-1570
5C50H91233
N ● ●
9 LCDCoverWFlex3-1470Red
5CB0H91227
N ● ● ●
9 LCDCoverWFlex3-1470Black
5CB0H91260
N ● ● ●
9 LCDCoverWFlex3-1470White
5CB0H91137
N ● ● ●
9 LCDCoverWFlex3-1570BLKW/BKT
5CB0H91204
N ● ●
9 LCDCoverWFlex3-1570WHTW/BKT
5CB0H91241
N ● ●
89
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Miscellaneous parts
Table 7. Parts list—Miscellaneous parts
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
Systemmiscellaneousparts:
N
• (
a
)HDDBracketWFlex3-1470 5B40H91170 ● ● ● ● ●
Cablemiscellaneousparts:
• (
b
)DCINCableWS41-70 5C10H71415 ● ● ●
• (
b
)DC-INCableWFlex3-1570 5C10H91237 ● ●
Note:Italicizedlettersinparenthesesare
referencestotheexplodedview in“Overall” on
page78.
90
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
AC adapters
Table 8. Parts list—3-pin AC adapters
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
Adapter,45W(3pin),DeltaADLX45NDC3A
20V2.25Aadap(CMN)
36200602 *●●●●●●●
Adapter,45W(3pin),LiteonADLX45NLC3A
20V2.25Aadap(CMN)
36200606 *●●●●●●●
Adapter,45W(3pin),ChiconyADLX45NCC3A
20V2.25Aadap(CMN)
36200610 *●●●●●●●
Adapter,65W(3pin),LiteonADLX65NLC3A
20V3.25Aadap(CMN)
36200607 *●●●●●●●
Adapter,65W(3pin),ChiconyADLX65NCC3A
20V3.25Aadap(CMN)
36200611 * ●●●●●●●
Adapter,65W(3pin),DeltaADLX65NDC3A
20V3.25Aadapter
36200249 *●●●●●●●
Screws
Table 9. Parts list—screws
FRU FRU no.
CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
ScrewPackWFlex3-1470 5S10H91178 N ● ● ●
ScrewPackWFlex3-1570 5S10H91187 N ● ●
91
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Power cords
ALenovopowercordforaspeciccountryorregionisusuallyavailableonlyinthatcountryorregion:
Table 10. Parts list—3-pin power cords
Region P/N CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
UK3pin
• LINETEKLP-61L+H03VV-F+LS151m
145000593
*●●●●●●●
UK3pin
• LongwellLP-61L+H03VV-F+LS-181m
145000561
UK3pin
• VOLEXMP5004+H03VV-F+VAC5S1m
145000605
UK3pin
• lux0031+H03VV-F0.75/3C+00111m
145500000
Europe3pin
• LINETEKLP-34+H03VV-F+LS151m
145000585
Europe3pin
• LongwellLP-34A+H03VV-F+LS-181m
145000553
Europe3pin
• VOLEXM2511+HO3VV-F+VAC5S1m
145000525
Europe3pin
• lux0033+H03VV-F0.75/3C+00111m
145500001
US3pin
• LINETEKLP-30B+SPT-2+LS151m
145000594
US3pin
• LongwellLP-30B+SPT-218AWG+LS-181m
145000562
US3pin
• VolexUS15S3+SPT-2+VAC5S1m
145000537
US3pin
• lux0014+SPT-260°C18/3C+00161m
145500002
China3pin
• LINETEKPC323+RVV300/300+LS151m
145000600
China3pin
• LongwellLSG-31+RVV300/300+LS-181m
145000568
China3pin
• VOLEXGB10S3+RVV300/500+VAC5S1m
145000538
China3pin
• lux0036+RVV300/3000.75/3C+00021m
145500003
India3pin
• LINETEKPE-361+H05VV-F+LS151m
145000592
India3pin
• LongwellLP-67+BIS+LS-181m
145000560
India3pin
• lux0046+IS6940.75/3C+00111mcode
145500004
Japan3pin
• LINETEKLS15+VCTF+LP-541m
145000587
Japan3pin
• LongwellLP-54+VCTF+LS-181m
145000555
92
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Table 10. Parts list—3-pin power cords (continued)
Region P/N CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
Japan3pin
• VOLEXVAC5S+VCTF+M7551m
145000530
*●●●●●●●
Japan3pin
• lux0018(E)+VCTF0.75/3C+00211m
145500005
Australia3pin
• LINETEKLS15+H03VV-F+LP-23A1m
145000589
Australia3pin
• LongwellLP-23A+LFC-3R+LS-181m
145000557
Australia3pin
• VOLEXAU10S3+H03VV-F+VAC5S1m
145000532
Australia3pin
• lux0038+H03VV-F0.75/3C+00111m
145500006
Taiwan3pin
• LINETEKLS15+VCTF+LP-531m
145000588
Taiwan3pin
• LongwellLP-71+VCTF+LS-331m
145000556
Taiwan3pin
• VOLEXTW15CS3+VCTF+VAC5S1m
145000531
Taiwan3pin
• lux0019+VCTF0.75/3C+00211m
145500007
Korea3pin
• LINETEKLS15+H05VV-F+LP-E04A1m
145000590
Korea3pin
• LongwellLP-486+KTLH03VV-F+LS-51m
145000558
Korea3pin
• VOLEXM2511+KETIIEC+VAC5S1m
145000533
Korea3pin
• lux0033+H03VV-F0.75/3C+00111m
145500008
Italy3pin
• LINETEKLS15+H03VV-F+PE-3361m
145000591
Italy3pin
• LongwellLP-22+H03VV-F+LS-181m
145000559
Italy3pin
• VOLEXIT10S3+HO3VV-F+VAC5S1m
145000535
Italy3pin
• lux0029+H03VV-F0.75/3C+00111m
145500009
SouthAfrica3pin
• LINETEKLS15+H03VV-F+PE-3641m
145000586
SouthAfrica3pin
• LongwellLP-39+H03VV-F+LS-181m
145000554
SouthAfrica3pin
• lux0044+H03VV-F0.75/3C+00111m
145500010
Brazil3pin
• LINETEKLS15H03VV-FLP26A1m
145000596
93
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL
Table 10. Parts list—3-pin power cords (continued)
Region P/N CRU
ID.
Yoga
500-
14IBD
Yoga
500-
14IHW
Yoga
500-
14ACL
Yoga
500-
14ACZ
Yoga
500-
15IBD
Yoga
500-
15IHW
Yoga
500-
15ACL
Brazil3pin
• LongwellLP-46+H03VV-F+LS-181m
145000564
*●●●●●●●
Brazil3pin
• VOLEXCH10S3+H03VV-F+VAC5S1m
145000527
Brazil3pin
• lux0034+H03VV-F0.75/3C+00111m
145500011
Israel3pin
• LINETEKLS15+H03VV-F+LP-411m
145000595
Israel3pin
• LongwellLP-41+H03VV-F+LS-181m
145000563
Israel3pin
• VOLEXSI16S3+H03VV-F+VAC5S1m
145000526
Israel3pin
• lux0041+H03VV-F0.75/3C+00111m
145500012
Switzerland3pin
• LINETEKLS15+H03VV-F+LP-371m
145000597
Switzerland3pin
• LongwellLP-37+H03VV-F+LS-181m
145000565
Switzerland3pin
• VOLEXMP232+H03VV-F+VAC5S1m
145000524
Switzerland3pin
• lux0027+H03VV-F0.75/3C+00111m
145500013
Denmark3pin
• LINETEKLS15+H03VV-F+LP-381m
145000598
Denmark3pin
• LongwellLP-40+H03VV-F+LS-181m
145000566
Denmark3pin
• VOLEXMP233D+H03VV-F+VAC5S1m
145000534
Denmark3pin
• lux0048+H03VV-F0.75/3C+00111m
145500014
Argentina3pin
• LINETEKLS15+H03VV-F+LP391m
145000599
Argentina3pin
• LongwellLP-24+H03VV-F+LS-181m
145000567
Argentina3pin
• VOLEXVA2073+H03VV-F+VAC5S1m
145000528
Argentina3pin
• lux0040+H03VV-F0.75/3C+00111m
145500015
94
Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/
Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL Hardware Maintenance Manual
Notices
Lenovomaynotoffertheproducts,services,orfeaturesdiscussedinthis
documentinallcountries.ConsultyourlocalLenovorepresentativefor
informationontheproducts andservices currentlyavailableinyourarea.Any
referencetoaLenovoproduct,program,orserviceisnot intendedtostateor
implythatonlythatLenovoproduct,program,orservicemaybeused.Any
functionallyequivalent product,program, orservicethatdoesnotinfringe
anyLenovo intellectualpropertyrightmaybeusedinstead. However,itisthe
user’sresponsibilitytoevaluateandverifytheoperationofanyotherproduct,
program,orservice.
Lenovomayhavepatentsorpendingpatentapplicationscoveringsubjectmatter
describedinthisdocument.The furnishingofthisdocumentdoesnotgiveyou
anylicensetothesepatents.
LENOVOGROUPLTD.PROVIDESTHISPUBLICATION“ASIS”
WITHOUTWARRANTYOFANYKIND, EITHEREXPRESS ORIMPLIED,
INCLUDING,BUTNOTLIMITEDTO,THEIMPLIEDWARRANTIESOFNON-
INFRINGEMENT,MERCHANTABILITYORFITNESSFORAPARTICULAR
PURPOSE.Somejurisdictionsdonotallowdisclaimerofexpressorimplied
warrantiesincertaintransactions,therefore,thisstatementmaynotapplytoyou.
Thisinformation couldinclude technicalinaccuraciesor typographicalerrors.
Changesareperiodicallymade tothe informationherein; thesechanges
willbeincorporatedin neweditions ofthe publication.Lenovomaymake
improvementsand/or changesin theproduct(s)and/ortheprogram(s)
describedinthispublicationatanytimewithoutnotice.
Theproductsdescribedin thisdocument arenotintendedforusein
implantationorotherlifesupportapplicationswheremalfunctionmay resultin
injuryordeathtopersons.Theinformationcontainedinthisdocumentdoesnot
affectorchange Lenovoproduct specicationsor warranties.Nothinginthis
documentshalloperateasanexpressorimpliedlicenseorindemnityunderthe
intellectualpropertyrightsofLenovoorthird parties.Allinformationcontained
inthisdocumentwasobtainedinspecicenvironmentsandispresentedasan
illustration.Theresultobtainedinotheroperatingenvironmentsmayvary.
Lenovomayuseordistributeanyoftheinformationyousupplyinanywayit
believesappropriatewithoutincurringanyobligationtoyou.
Anyreferencesinthispublicationtonon-LenovoWebsitesareprovidedfor
convenienceonlyanddonotinanymannerserveasanendorsementofthose
Websites.Thematerials atthoseWebsitesarenotpartofthematerials for
thisLenovoproduct,anduseofthoseWebsitesisatyourownrisk.
95
Notices
Anyperformance datacontainedherein wasdetermined inacontrolled
environment.Therefore,theresultobtainedin otheroperating environments
mayvarysignificantly. Somemeasurementsmayhavebeenmadeon
development-levelsystemsandthereisnoguaranteethatthesemeasurements
willbethesameongenerallyavailablesystems.Furthermore,some
measurementsmayhavebeenestimatedthroughextrapolation.Actualresults
mayvary.Usersofthisdocumentshouldverifytheapplicabledatafortheir
specicenvironment.
Trademarks
ThefollowingtermsaretrademarksorregisteredtrademarksofLenovointhe
UnitedStates,othercountries,orboth.
Lenovo
OneKey
MicrosoftandWindowsaretrademarksofMicrosoftCorporationin theUnited
States,othercountries,orboth.
Othercompany,products,orservicenamesmaybetrademarks orservice
marksofothers.

Navigation menu
