Lenovo ThinkCentre M83 Mini Tower
with optional WLAN and graphic card
Lenovo ThinkCentre M83 Small Pro
with optional dual graphic cards
* Cable lock only available on some special bid
models
Lenovo ThinkCentre M83 Small Pro
(inside view)
Lenovo ThinkCentre M83 Small Pro
with Lenovo ThinkVision Monitor
Optional 2.5" bay on
Lenovo ThinkCentre M83 Small Pro
* Come with optional 2.5" 2nd HDD
ThinkCentre M83 Small Pro, Mini Tower
Lenovo ThinkCentre M83 Mini Tower
with Lenovo ThinkVision Monitor
Preloaded operating system
Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 SFF Pro (10AM) - TopSeller Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i3-4130 Processor (2 cores / 4 threads, 3.4GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i5-4670 Processor (4 cores / 4 threads, 3.4GHz, 6MB cache),
Turbo Boost 2.0 (3.8GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4400 or 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk Some: SATA 6.0Gb/s, 7200 rpm, 3.5" wide
Some: 500GB (5400 rpm) hybrid hard disk / with 8GB MLC NAND flash memory,
SATA 6.0Gb/s, 2.5" wide
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" Wide
2nd disk
Optical
Some: SATA 6.0Gb/s, 7200 rpm, 3.5" wide
Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA SATA cables match SATA devices (each 1-drop to device), three SATA 6.0Gb/s
connectors, one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader Some: 29-in-1 media reader, internal USB 2.0
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), optional parallel
(25-pin), ethernet (RJ-45), one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN Some: 11b/g/n wireless, PCIe Half Mini Card, Intel Centrino Wireless-N 105, 1x1
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Floor Stand Optional system floor stand for vertical orientation
Power supply 240 watts, autosensing
Machine ● SFF Pro (12.9L), business black color; metal case
● (WxDxH) 13.31" X 14.76" X 4.02"; 338mm X 375mm X 102mm
● 17.20 lb (7.8 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk and optical drive removal
Bay Bay 1: 5.25", 1.6" high, external, std optical
Bay 2: 3.5", 1" high, internal, std disk
Bay 3: 2.5", N/A, internal, opt or come with opt 2.5" 2nd disk
Bay 4: 3.5", 0.5" high, external, opt reader
Slot Slot 1: Low Profile, PCI Express 3.0 x16 (40w max)
Slot 2: Low Profile, PCIe 2.0 x1
Slot 3: Low Profile, PCIe 2.0 x16 (x4 elec, 40w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AM0002US 3x4 i5-4670 4GBx1 1TB 7200 None HD 4600 USB None None None None None Win7 Pro64 (DG) 07/30/13
10AM0003US 3x4 i5-4570 4GBx1 500G 7200 None HD 4600 None None None None None None Win7 Pro64 (DG) 07/30/13
10AM0004US 3x4 i7-4770 8GBx1 1TB 7200 Intel 105 GT 620 USB Serial Parallel None Stand None Win7 Pro64 (DG) 07/30/13
10AM0005US 3x4 i5-4570 8GBx1 1TB 7200 Intel 105 GT 620 USB Serial Parallel None Stand None Win7 Pro64 (DG) 07/30/13
10AM0006US 3x4 i7-4770 4GBx1 500G 7200 None HD 4600 None None None None Stand None Win7 Pro64 (DG) 07/30/13
10AM0007US 3x4 i5-4570 4GBx1 500G 7200 None HD 4600 None None None None Stand None Win7 Pro64 (DG) 07/30/13
10AM000AUS 3x4 i7-4770 4GBx1 1TB 7200 None HD 4600 None None None None Stand None Win7 Pro64 (DG) 08/20/13
10AM000BUS 3x4 i5-4570 4GBx1 128G SSD 1TB None Media HD 4600 None None None None Stand None Win7 Pro64 (DG) 08/20/13
10AM0009US 3x4 i3-4130 4GBx1 500G 7200 None HD 4400 None None None None Stand None Win7 Pro64 (DG) 08/20/13
10AM000CUS 3x4 i3-4130 4GBx1 500G Hybrid None HD 4400 None None None None Stand None Win7 Pro64 (DG) 08/20/13
See footnotes for important warranty information
US model(s) announced July 30, 2013 or August 20, 2013
Lenovo
(MSK1S-3) September 2013
Type-model
Pro-
cessor Memory8
2nd
disk Graphics
Slot x
bay
Additional
Front
USB 2.0
Chassis
intrusion
switch
ENERGY
STAR 6.0
optical
disk
Floor
stand
SATA disk
GB rpm
Ann date
(mm/dd/yy)Preload
PCIe
WLAN
2nd
serial
port Parallel
port
Media
。reader
Preloaded operating system
Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 SFF Pro (10AM) - TopSeller - II Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Pentium G3220 Processor (2 cores / 2 threads, 3.0GHz, 3MB cache),
Intel HD Graphics, 1333MHz DDR3 memory controller
Intel Core i3-4130 Processor (2 cores / 4 threads, 3.4GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i5-4670 Processor (4 cores / 4 threads, 3.4GHz, 6MB cache),
Turbo Boost 2.0 (3.8GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics or Intel HD Graphics 4400/4600 in processor, uses main memory,
DirectX 11, one VGA, two DisplayPort, supports three independent displays, works
along with discrete graphics to support up to five independent monitors;
Max resolution: 2560x1600 (DP)@60Hz; 1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 7450, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one DVI-I (includes DVI-to-VGA dongle),
one DisplayPort, 25 watts;
Max resolution: 2560x1600 (DisplayPort, DVI-I)@60Hz
DP dongle None
Disk Some: SATA 6.0Gb/s, 7200 rpm, 2.5" wide
Some: SATA 6.0Gb/s, 7200 rpm, 3.5" wide
Some: 1TB (7200 rpm) hybrid hard disk / with 8GB MLC NAND flash memory,
SATA 6.0Gb/s, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA SATA cables match SATA devices (each 1-drop to device), three SATA 6.0Gb/s
connectors, one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), optional parallel
(25-pin), ethernet (RJ-45), one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Floor Stand Optional system floor stand for vertical orientation
Power supply 240 watts, autosensing
Machine ● SFF Pro (12.9L), business black color; metal case
● (WxDxH) 13.31" X 14.76" X 4.02"; 338mm X 375mm X 102mm
● 17.20 lb (7.8 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk and optical drive removal
Bay Bay 1: 5.25", 1.6" high, external, std optical
Bay 2: 3.5", 1" high, internal, std disk
Bay 3: 2.5", N/A, internal, opt or come with opt 2.5" 2nd disk
Bay 4: 3.5", 0.5" high, external, opt reader
Slot Slot 1: Low Profile, PCI Express 3.0 x16 (40w max)
Slot 2: Low Profile, PCIe 2.0 x1
Slot 3: Low Profile, PCIe 2.0 x16 (x4 elec, 40w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AM000JUS 3x4 i3-4130 4GBx1 500G 3.5" 2.5" bay None None HD 7450 USB None None None Stand None Win7 P64 DG Win8.1 02/04/14
10AM000KUS 3x4 i5-4570 4GBx1 500G 3.5" 2.5" bay None None HD 7450 USB None None None Stand None Win7 P64 DG Win8.1 02/04/14
10AM000LUS 3x4 i7-4770 4GBx1 500G 3.5" 2.5" bay None None HD 7450 USB None None None Stand None Win7 P64 DG Win8.1 02/04/14
10AM000MUS 3x4 i7-4770 8GBx1 1TB Hybrid 2.5" bay None None HD 7450 USB None None None Stand None Win7 P64 DG Win8.1 02/04/14
10AM000NUS 3x4 G3220 4GBx1 500G 3.5" 2.5" bay None None HD 7450 USB None None None Stand None Win7 P64 DG Win8.1 02/04/14
10AM000PUS 3x4 i3-4130 4GBx1 500G 2.5" 2.5" bay None None HD 4400 None None None None None None Win7 P64 DG Win8.1 02/25/14
10AM000QUS 3x4 i5-4570 4GBx1 500G 2.5" 2.5" bay None None HD 4600 None None None None None None Win7 P64 DG Win8.1 02/25/14
10AM000RUS 3x4 i5-4670 4GBx1 1TB 3.5" 2.5" bay None None HD 4600 None None None None None None Win7 P64 DG Win8.1 02/25/14
10AM000SUS 3x4 i7-4770 4GBx1 1TB 3.5" 2.5" bay None None HD 4600 None None None None None None Win7 P64 DG Win8.1 02/25/14
10AM000TUS 3x4 i3-4130 4GBx1 500G 3.5" 2.5" bay None None HD 4400 None None None None Stand None Win7 P64 DG Win8.1 04/01/14
See footnotes for important warranty information
US model(s) announced February 04, February 25, or April 1, 2014
Lenovo
(MSK1S-5) April 2014
Type-model
Pro-
cessor Memory8
Optional
2.5" Bay Graphics
Slot x
bay
Additional
Front
USB 2.0
Chassis
intrusion
switch
ENERGY
STAR 6.0
optical
disk
Floor
standSATA disk
Ann date
(mm/dd/yy)Preload
PCIe
WLAN
2nd
serial
port
Parallel
port
Media
。reader
Preloaded operating system
Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
●Small and medium business (SMB) model(s), part of the US TopSeller Program
ThinkCentre M83 Mini Tower (10AL) - TopSeller Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i5-4670 Processor (4 cores / 4 threads, 3.4GHz, 6MB cache),
Turbo Boost 2.0 (3.8GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 8470, DirectX 11, 3D Hardware Acceleration,
512MB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 25 watts,
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
Some: AMD Radeon HD 8570, DirectX 11, 3D Hardware Acceleration,
2GB, PCI Express 3.0 x16 adapter (8x elec), one VGA, one HDMI, 40 watts;
Max resolution: 4096x2160 (HDMI)@24Hz; 2048x1536 (VGA)@85Hz
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk SATA 6.0Gb/s 7200 rpm, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), optional parallel
(25-pin), ethernet (RJ-45), one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AL0008US 3x5 i5-4670 4GBx1 1TB 7200 DVD±RW None None HD 4600 USB None None None None Win7 Pro64 (DG) 07/30/13
10AL0009US 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 Pro64 (DG) 07/30/13
10AL000AUS 3x5 i7-4770 4GBx1 500GB 7200 DVD±RW None None HD 4600 USB None None None None Win7 Pro64 (DG) 07/30/13
10AL000BUS 3x5 i5-4670 4GBx1 500GB 7200 DVD±RW None None HD 4600 USB None None None None Win7 Pro64 (DG) 07/30/13
10AL000CUS 3x5 i5-4670 4GBx2 1TB 7200 DVD±RW None None HD 4600 USB Serial Parallel None None Win7 Pro64 (DG) 07/30/13
10AL000DUS 3x5 i5-4670 4GBx1 500GB 7200 DVD±RW None None HD 8470 USB Serial Parallel None None Win7 Pro64 (DG) 07/30/13
10AL000EUS 3x5 i7-4770 4GBx2 1TB 7200 DVD±RW None None GT 620 USB Serial Parallel None None Win7 Pro64 (DG) 07/30/13
10AL000FUS 3x5 i7-4770 4GBx2 500GB 7200 DVD±RW None None HD 8570 USB Serial Parallel None None Win7 Pro64 (DG) 07/30/13
10AL000GUS 3x5 i7-4770 4GBx1 1TB 7200 DVD±RW None None HD 4600 None None None None None Win7 Pro64 (DG) 08/20/13
See footnotes for important warranty information
US model(s) announced July 30, 2013 or August 20, 2013
Lenovo
(MSK1T-4) August 2013
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN Parallel
port
Preloaded operating system
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
●Small and medium business (SMB) model(s), part of the US TopSeller Program
ThinkCentre M83 Mini Tower (10AL) - TopSeller - II Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 7450, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one DVI-I (includes DVI-to-VGA dongle),
one DisplayPort, 25 watts;
Max resolution: 2560x1600 (DisplayPort, DVI-I)@60Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Some: 1TB (7200 rpm) hybrid hard disk / with 8GB MLC NAND flash memory,
SATA 6.0Gb/s, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), optional parallel
(25-pin), ethernet (RJ-45), one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AL000QUS 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None None HD 7450 USB None None None None Win7 P64 DG Win8.1 02/04/14
10AL000RUS 3x5 i7-4770 8GBx1 500GB 7200 DVD±RW None None HD 7450 USB None None None None Win7 P64 DG Win8.1 02/04/14
10AL000SUS 3x5 i7-4770 8GBx1 1TB 7200 DVD±RW None None HD 7450 USB None None None None Win7 P64 DG Win8.1 02/04/14
10AL000TUS 3x5 i7-4770 8GBx1 1TB Hybrid DVD±RW None None HD 7450 USB None None None None Win7 P64 DG Win8.1 02/04/14
10AL000UUS 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 02/25/14
10AL000VUS 3x5 i7-4770 4GBx1 1TB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 02/25/14
See footnotes for important warranty information
US model(s) announced February 4, 2014 or February 25, 2014
Lenovo
(MSK1T-6) February 2014
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
Parallel
port
Preloaded operating system
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 Mini Tower (10AL) - TopSeller - III Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Pentium G3240 Processor (2 cores / 2 threads, 3.1GHz, 3MB cache),
Intel HD Graphics, 1333MHz DDR3 memory controller
Intel Core i3-4150 Processor (2 cores / 4 threads, 3.5GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4590 Processor (4 cores / 4 threads, 3.3GHz, 6MB cache),
Turbo Boost 2.0 (3.7GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4790 Processor (4 cores / 8 threads, 3.6GHz, 8MB cache),
Turbo Boost 2.0 (4.0GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 7450, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one DVI-I (includes DVI-to-VGA dongle),
one DisplayPort, 25 watts;
Max resolution: 2560x1600 (DisplayPort, DVI-I)@60Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), optional parallel
(25-pin), ethernet (RJ-45), one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AL0014US 3x5 i7-4790 4GBx1 500GB 7200 DVD±RW None None HD 7450 None None None None None Win7 P64 DG Win8.1 10/14
10AL0017US 3x5 G3240 4GBx1 500GB 7200 DVD±RW None None Intel HD None None None None None Win7 P64 DG Win8.1 10/14
10AL000XUS 3x5 i5-4590 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14
10AL0013US 3x5 i7-4790 8GBx1 256G SSD DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14
10AL000YUS 3x5 i5-4590 4GBx1 1TB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14
10AL0016US 3x5 i3-4150 4GBx1 1TB 7200 DVD±RW None None HD 4400 None None None None None Win7 P64 DG Win8.1 10/14
10AL0012US 3x5 i7-4790 4GBx1 1TB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14
10AL0010US 3x5 i5-4590 8GBx1 256G SSD DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14
10AL0015US 3x5 i3-4150 4GBx1 500GB 7200 DVD±RW None None HD 4400 None None None None None Win7 P64 DG Win8.1 10/14
10AL0011US 3x5 i7-4790 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14
See footnotes for important warranty information Lenovo
(MSK1T-7) October 2014
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0
Ann date
(mm/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
Parallel
port
Preloaded operating system
Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
●3-year limited warranty
ThinkCentre M83 SFF Pro (10AN) Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i3-4130 Processor (2 cores / 4 threads, 3.4GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 8470, DirectX 11, 3D Hardware Acceleration,
512MB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 25 watts,
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
Some: AMD Radeon HD 8570, DirectX 11, 3D Hardware Acceleration,
2GB, PCI Express 3.0 x16 adapter (8x elec), one VGA, one HDMI, 40 watts;
Max resolution: 4096x2160 (HDMI)@24Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Some: 1TB (7200 rpm) hybrid hard disk / with 8GB MLC NAND flash memory,
SATA 6.0Gb/s, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader Some: 29-in-1 media reader, internal USB 2.0
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), optional parallel
(25-pin), ethernet (RJ-45), one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Floor Stand Optional system floor stand for vertical orientation
Power supply 240 watts, autosensing
Machine ● SFF Pro (12.9L), business black color; metal case
● (WxDxH) 13.31" X 14.76" X 4.02"; 338mm X 375mm X 102mm
● 17.20 lb (7.8 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk and optical drive removal
Bay Bay 1: 5.25", 1.6" high, external, std optical
Bay 2: 3.5", 1" high, internal, std disk
Bay 3: 2.5", N/A, internal, opt or come with opt 2.5" 2nd disk
Bay 4: 3.5", 0.5" high, external, opt reader
Slot Slot 1: Low Profile, PCI Express 3.0 x16 (40w max)
Slot 2: Low Profile, PCIe 2.0 x1
Slot 3: Low Profile, PCIe 2.0 x16 (x4 elec, 40w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AN0006US 3x4 i5-4570 4GBx1 500G 7200 DVD±RW None Reader HD 8470 None None None None Stand None Win7 Pro64 (DG) 07/30/13
10AN000GUS 3x4 i5-4570 4GBx1 500G 7200 DVD±RW None None HD 4600 USB None None None Stand None Win7 Pro64 (DG) 08/27/13
10AN000HUS 3x4 i7-4770 4GBx1 500G 7200 DVD±RW None None HD 4600 USB None None None Stand None Win7 Pro64 (DG) 08/27/13
10AN000JUS 3x4 i7-4770 8GBx1 1TB 7200 DVD±RW None None HD 4600 USB None None None Stand None Win7 Pro64 (DG) 08/27/13
10AN000KUS 3x4 i5-4570 8GBx1 1TB 7200 DVD±RW None None HD 8570 USB None None None Stand None Win7 Pro64 (DG) 08/27/13
10AN000XUS 3x4 i3-4130 4GBx1 500G 7200 DVD±RW None None HD 4400 USB None None None Stand None Win7 Pro64 (DG) 10/22/13
10AN000YUS 3x4 i3-4130 8GBx1 1TB Hybrid DVD±RW None None HD 8570 USB None None None Stand None Win7 Pro64 (DG) 10/22/13
See footnotes for important warranty information
US model(s) announced July 30, 2013, August 27, 2013, or October 22, 2013
Lenovo
(MSK1S-4) October 2013
Type-model
Pro-
cessor Memory8
SATA
optical Graphics
Slot x
bay
Additional
Front
USB 2.0
Chassis
intrusion
switch
ENERGY
STAR 6.0
optical
disk
Floor
stand
SATA disk
GB rpm
Ann date
(mm/dd/yy)Preload
PCIe
WLAN
2nd
serial
port Parallel
port
Media
reader
Preloaded operating system
Some: Windows 7 Professional 64
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
EPEAT Gold rating
ENERGY STAR 6.0-compliant
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 SFF Pro (10AH) - ES 6.0 Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i3-4150 Processor (2 cores / 4 threads, 3.5GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller,
Intel Core i5-4590 Processor (4 cores / 4 threads, 3.3GHz, 6MB cache),
Turbo Boost 2.0 (3.7GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4790 Processor (4 cores / 8 threads, 3.6GHz, 8MB cache),
Turbo Boost 2.0 (4.0GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Max resolution: 2560x1600 (DP)@60Hz;1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 8570, DirectX 11, 3D Hardware Acceleration,
2GB, PCI Express 3.0 x16 adapter (8x elec), one VGA, one HDMI, 40 watts;
Max resolution: 4096x2160 (HDMI)@24Hz; 2048x1536 (VGA)@85Hz
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide
Optical Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4 Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, mic (stereo, 3.5mm), headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN Some: 11ac/a/b/g/n wireless, PCIe Half Mini Card, Intel Dual Band Wireless-AC 7260,
Wi-Fi + BT combo adapter, 2x2
Some: 11b/g/n, PCIe Half Mini Card, Intel Wireless-N 7260, Wi-Fi + BT 4.0 combo, 2x2
Bluetooth Some: Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Optional internal speaker for business audio (1 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Floor Stand Optional system floor stand for vertical orientation
Power supply 240 watts, autosensing, 85% PSU
Machine ● SFF Pro (12.9L), business black color; metal case
● (WxDxH) 13.31" X 14.76" X 4.02"; 338mm X 375mm X 102mm
● 17.20 lb (7.8 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk and optical drive removal
Bay Bay 1: 5.25", 1.6" high, external, std optical
Bay 2: 3.5", 1" high, internal, std disk
Bay 3: 2.5", N/A, internal, opt or come with opt 2.5" 2nd disk
Bay 4: 3.5", 0.5" high, external, opt reader
Slot Slot 1: Low Profile, PCI Express 3.0 x16 (40w max)
Slot 2: Low Profile, PCIe 2.0 x1
Slot 3: Low Profile, PCIe 2.0 x16 (x4 elec, 40w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AH000JUS 3x4 i5-4570 4GBx1 1TB 7200 DVD Intel 105 None HD 8470 USB None Switch Stand Speaker ES6.0 Win7 Pro64 07/13
10AH0042US 3x4 i5-4570 4GBx1 500G 7200 DVD±RW 2.5" bay None None HD 7450 USB None None Stand Speaker ES6.0 Win7 P64 DG Win8.1 02/14
10AH006HUS 3x4 i5-4590 4GBx1 500G 7200 DVD±RW 2.5" bay 7260 b/g/n None HD 8570 None None None None Speaker ES6.0 Win7 P64 DG Win8.1 10/14
10AH006JUS 3x4 i7-4790 8GBx1 1TB 7200 DVD±RW 2.5" bay 7260 b/g/n None HD 4600 None None None None None ES6.0 Win7 P64 DG Win8.1 10/14
10AH006KUS 3x4 i7-4790 8GBx1 1TB 7200 DVD±RW 2.5" bay 7260 ac None GT 620 None None None None None ES6.0 Win7 P64 DG Win8.1 10/14
10AH006BUS 3x4 i3-4150 4GBx1 500G 7200 DVD±RW 2.5" bay None None HD 4400 None None None None Speaker ES6.0 Win7 P64 DG Win8.1 10/14
10AH006DUS 3x4 i3-4150 8GBx1 256G SSD DVD±RW 2.5" bay 7260 b/g/n None HD 4400 None None None None Speaker ES6.0 Win7 P64 DG Win8.1 10/14
10AH006FUS 3x4 i5-4590 8GBx1 256G SSD DVD±RW 2.5" bay 7260 b/g/n None HD 4600 None None None None Speaker ES6.0 Win7 P64 DG Win8.1 10/14
10AH006EUS 3x4 i5-4590 4GBx1 500G 7200 DVD±RW 2.5" bay None None HD 4600 None None None None Speaker ES6.0 Win7 P64 DG Win8.1 10/14
10AH006CUS 3x4 i3-4150 4GBx1 1TB 7200 DVD±RW 2.5" bay 7260 b/g/n None HD 4400 None None None None Speaker ES6.0 Win7 P64 DG Win8.1 10/14
10AH006GUS 3x4 i7-4790 4GBx1 500G 7200 DVD±RW 2.5" bay 7260 b/g/n None HD 4600 None None None None None ES6.0 Win7 P64 DG Win8.1 10/14
See footnotes for important warranty information Lenovo
(MSK1S-1) October 2014
Type-model
Pro-
cessor Memory8
SATA
optical Graphics
Slot x
bay
Additional
Front
USB 2.0
Chassis
intrusion
switch
ENERGY
STAR 6.0
optical
disk
Floor
stand
SATA disk
GB rpm
Media
reader
Ann date
(mm/yy)Preload
PCIe
WLAN
2nd
serial
port
Optional
2.5" Bay
Internal
Speaker
Preloaded operating system
Some: Windows 7 Professional 64
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
EPEAT Gold rating
ENERGY STAR 6.0-compliant
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 SFF Pro (10AH) - ES 6.0 (GMP) Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i5-4590 Processor (4 cores / 4 threads, 3.3GHz, 6MB cache),
Turbo Boost 2.0 (3.7GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 8470, DirectX 11, 3D Hardware Acceleration,
512MB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 25 watts,
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 2.5" wide
Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Optical Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4 Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN Some: 11b/g/n wireless, PCIe Half Mini Card, Intel Centrino Wireless-N 105, 1x1
Some: 11b/g/n wireless, PCIe Half Mini Card, Realtek RTL8723BE, Wi-Fi/BT 4.0, 1x1
Bluetooth Some: Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Floor Stand Optional system floor stand for vertical orientation
Power supply 240 watts, autosensing, 85% PSU
Machine ● SFF Pro (12.9L), business black color; metal case
● (WxDxH) 13.31" X 14.76" X 4.02"; 338mm X 375mm X 102mm
● 17.20 lb (7.8 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk and optical drive removal
Bay Bay 1: 5.25", 1.6" high, external, std optical
Bay 2: 3.5", 1" high, internal, std disk
Bay 3: 2.5", N/A, internal, opt or come with opt 2.5" 2nd disk
Bay 4: 3.5", 0.5" high, external, opt reader
Slot Slot 1: Low Profile, PCI Express 3.0 x16 (40w max)
Slot 2: Low Profile, PCIe 2.0 x1
Slot 3: Low Profile, PCIe 2.0 x16 (x4 elec, 40w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AH0015US 3x4 i5-4570 2GBx1 500G 3.5" DVD None HD 4600 None None Switch None ES6.0 G P Win7 Pro64 07/30/13
10AH0016US 3x4 i5-4570 4GBx1 500G 3.5" DVD None HD 4600 USB None Switch Stand ES6.0 G P Win7 Pro64 (DG) 07/30/13
10AH0017US 3x4 i5-4570 4GBx1 1TB 3.5" DVD Intel 105 HD 8470 USB None Switch Stand ES6.0 G P Win7 Pro64 (DG) 07/30/13
10AH001HUS 3x4 i5-4570 4GBx1 500G 3.5" DVD±RW None HD 4600 USB None Switch Stand ES6.0 G P Win7 Pro64 (DG) 08/20/13
10AH001JUS 3x4 i5-4570 4GBx1 1TB 3.5" DVD±RW Intel 105 HD 8470 USB None Switch Stand ES6.0 G P Win7 Pro64 (DG) 08/20/13
10AH0043US 3x4 i5-4570 2GBx1 500G 2.5" DVD None HD 4600 None None Switch None ES6.0 G P Win7 Pro64 03/11/14
10AH0054US 3x4 i5-4590 2GBx1 500G 2.5" DVD None HD 4600 None None Switch None ES6.0 G P Win7 Pro64 06/10/14
10AH005XUS 3x4 i5-4590 4GBx1 500G 3.5" DVD±RW None HD 4600 USB None Switch Stand ES6.0 G P Win7 P64 DG Win8.1 07/08/14
10AH005YUS 3x4 i5-4590 4GBx1 1TB 3.5" DVD±RW 8723BE GT 620 None None Switch Stand ES6.0 G P Win7 P64 DG Win8.1 07/08/14
See footnotes for important warranty information Lenovo
(MSK1S-2) July 2014
Type-model
Pro-
cessor Memory8
SATA
optical Graphics
Slot x
bay
Additional
Front
USB 2.0
Chassis
intrusion
switch
ENERGY
STAR 6.0
optical
disk
Floor
stand
SATA disk
GB rpm
Ann date
(mm/dd/yy)Preload
PCIe
WLAN
2nd
serial
port Global (G)
GMP (P)
Preloaded operating system
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 Mini Tower (10AK) Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i3-4130 Processor (2 cores / 4 threads, 3.4GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller,
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller,
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4400/4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
Some: AMD Radeon HD 8570, DirectX 11, 3D Hardware Acceleration,
2GB, PCI Express 3.0 x16 adapter (8x elec), one VGA, one HDMI, 40 watts;
Max resolution: 4096x2160 (HDMI)@24Hz; 2048x1536 (VGA)@85Hz
Some: AMD Radeon HD 7450, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one DVI-I (includes DVI-to-VGA dongle),
one DisplayPort, 25 watts;
Max resolution: 2560x1600 (DisplayPort, DVI-I)@60Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Some: 1TB (7200 rpm) hybrid hard disk / with 8GB MLC NAND flash memory,
SATA 6.0Gb/s, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AK0004US 3x5 i5-4570 8GBx1 500GB 7200 DVD±RW None None GT 620 USB None None None None Win7 P64 DG Win8 07/30/13
10AK0005US 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8 07/30/13
10AK0006US 3x5 i7-4770 8GBx1 500GB 7200 DVD±RW None None GT 620 USB None None None None Win7 P64 DG Win8 07/30/13
10AK0007US 3x5 i7-4770 8GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8 07/30/13
10AK000LUS 3x5 i3-4130 4GBx1 500GB 7200 DVD±RW None None HD 4400 USB None None None None Win7 P64 DG Win8 10/22/13
10AK000MUS 3x5 i3-4130 8GBx1 1TB Hybrid DVD±RW None None HD 8570 USB None None None None Win7 P64 DG Win8 10/22/13
10AK000QUS 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None None HD 7450 USB None None None None Win7 P64 DG Win8.1 02/04/14
See footnotes for important warranty information
US model(s) announced July 30, 2013, October 22, 2013, or February 4, 2014
Lenovo
(MSK1T-3) February 2014
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0
Global (G)
GMP (P)
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
Preloaded operating system
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 Mini Tower (10AK) - II Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i3-4130 Processor (2 cores / 4 threads, 3.4GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller,
Intel Core i7-4770 Processor (4 cores / 8 threads, 3.4GHz, 8MB cache),
Turbo Boost 2.0 (3.9GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller,
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4400/4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
Some: AMD Radeon HD 8570, DirectX 11, 3D Hardware Acceleration,
2GB, PCI Express 3.0 x16 adapter (8x elec), one VGA, one HDMI, 40 watts;
Max resolution: 4096x2160 (HDMI)@24Hz; 2048x1536 (VGA)@85Hz
Some: AMD Radeon HD 7450, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one DVI-I (includes DVI-to-VGA dongle),
one DisplayPort, 25 watts;
Max resolution: 2560x1600 (DisplayPort, DVI-I)@60Hz
DP dongle None
Disk Some: SATA 6.0Gb/s 7200 rpm, 3.5" wide
Some: 1TB (7200 rpm) hybrid hard disk / with 8GB MLC NAND flash memory,
SATA 6.0Gb/s, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AK0012US 3x5 i3-4150 4GBx1 500GB 7200 DVD±RW None None HD 4400 None None None None None Win7 P64 DG Win8.1 10/14/14
10AK0013US 3x5 i3-4150 4GBx1 1TB 7200 DVD±RW None None HD 4400 None None None None None Win7 P64 DG Win8.1 10/14/14
10AK0015US 3x5 i5-4590 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14/14
10AK0016US 3x5 i5-4590 8GBx1 1TB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14/14
10AK0019US 3x5 i7-4790 8GBx1 1TB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14/14
10AK0017US 3x5 i5-4590 4GBx1 256G SSD DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14/14
10AK0018US 3x5 i7-4790 4GBx1 500GB 7200 DVD±RW None None HD 4600 None None None None None Win7 P64 DG Win8.1 10/14/14
See footnotes for important warranty information Lenovo
(MSK1T-8) October 2014
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0
Global (G)
GMP (P)
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
Preloaded operating system
Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Password Manager
Preloaded applications (only some listed)
● Lenovo Support
● Lenovo Companion
● Lenovo Cloud Storage by SugarSync
● Desktop Power Manager
● Norton Studio
● AccuWeather
● Evernote
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● ThinkVantage System Update
● Lenovo Solution Center
● Norton Internet Security
(30 days of virus definitions)
● Skype
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
EPEAT Gold rating
ENERGY STAR 6.0-compliant
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 Mini Tower (10AG) - ES 6.0 Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i3-4150 Processor (2 cores / 4 threads, 3.5GHz, 3MB cache),
Intel HD Graphics 4400, 1600MHz DDR3 memory controller
Intel Core i5-4590 Processor (4 cores / 4 threads, 3.3GHz, 6MB cache),
Turbo Boost 2.0 (3.7GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i7-4790 Processor (4 cores / 8 threads, 3.6GHz, 8MB cache),
Turbo Boost 2.0 (4.0GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 7450, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one DVI-I (includes DVI-to-VGA dongle),
one DisplayPort, 25 watts;
Max resolution: 2560x1600 (DisplayPort, DVI-I)@60Hz
DP dongle None
Disk SATA 6.0Gb/s 7200 rpm, 3.5" wide
Optical Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN None
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing, 85% PSU
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AG0012US 3x5 i5-4570 4GBx1 500G 7200 DVD±RW None None HD 7450 USB None None ES6.0 None Win7 P64 DG Win8.1 02/04/14
10AG001NUS 3x5 i5-4590 4GBx1 500G 7200 DVD±RW None None HD 4600 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG002BUS 3x5 i5-4590 8GBx1 256G SSD DVD±RW None None HD 4600 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG002AUS 3x5 i5-4590 4GBx1 1TB 7200 DVD±RW None None HD 4600 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG0029US 3x5 i3-4150 4GBx1 500G 7200 DVD±RW None None HD 7450 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG0026US 3x5 i7-4790 8GBx1 256G SSD DVD±RW None None HD 4600 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG0025US 3x5 i7-4790 4GBx1 500G 7200 DVD±RW None None HD 4600 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG0028US 3x5 i3-4150 4GBx1 1TB 7200 DVD±RW None None HD 4400 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG0027US 3x5 i3-4150 4GBx1 500G 7200 DVD±RW None None HD 4400 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
10AG0024US 3x5 i7-4790 4GBx1 1TB 7200 DVD±RW None None HD 4600 None None None ES6.0 None Win7 P64 DG Win8.1 10/14/14
See footnotes for important warranty information Lenovo
(MSK1T-5) October 2014
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0 Global
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
Preloaded operating system
Windows 8 Pro 64-bit
Ready to install applications (only some
listed)
● Password Manager
Preloaded applications (only some listed)
● Lenovo Support
● Lenovo Companion
● Lenovo Cloud Storage by SugarSync
● Desktop Power Manager
● Norton Studio
● AccuWeather
● Evernote
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● ThinkVantage System Update
● Lenovo Solution Center
● Norton Internet Security
(30 days of virus definitions)
● Skype
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
EPEAT Gold rating
ENERGY STAR 6.0-compliant
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
●3-year limited warranty
ThinkCentre M83 Mini Tower (10AG) - ES 6.0 ( Windows 8) Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), integrated Intel HD Graphics 4600,
integrated 1600MHz dual-channel DDR3 memory controller, Virtualization Technology
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 8470, DirectX 11, 3D Hardware Acceleration,
512MB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 25 watts,
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk SATA 6.0Gb/s 7200 rpm, 3.5" wide
Optical DVD-ROM DL SATA 1.5Gb/s 16-48X Max4 Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN Some: 11b/g/n wireless, PCIe Half Mini Card, Intel Centrino Wireless-N 105, 1x1
Bluetooth None
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing, 85% PSU
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AG000CUS 3x5 i5-4570 4GBx1 1TB 7200 DVD Intel 105 None HD 8470 USB None Switch ES6.0 None Win8 Pro64 07/30/13
See footnotes for important warranty information
US model(s) announced July 30, 2013
Lenovo
(MSK1T-1) August 2013
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm
Media
reader
Additional
Front
USB 2.0 Global
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
Preloaded operating system
Some: Windows 7 Professional 64
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8 Pro 64-bit
Some: Windows 7 Professional 64
preinstalled through downgrade
rights in Windows 8.1 Pro 64-bit
Ready to install applications (only some
listed)
● Rescue and Recovery
● Password Manager
Preloaded applications (only some listed)
● ThinkVantage Product Recovery
● ThinkVantage System Update
● ThinkVantage Communication Utility
● Desktop Power Manager
● View Management Utility
● Lenovo Cloud Storage by SugarSync
● Lenovo Solution Center
● Lenovo Message Center Plus
● Norton Internet Security
(30 days of virus definitions)
● Adobe Reader
● Skype
● Microsoft Office preloaded;
purchase a product key to activate
● Cyberlink PowerDVD (DVD±RW, DVD)
● Cyberlink Power2Go (DVD±RW)
● Cyberlink PowerProducer (DVD±RW)
● Evernote
● Intel AppUp
● Intel Small Business Advantage
● Nitro Pro
Security
● Security chip (see information on left)
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● Serial port I/O control
● Individual USB port disablement
● Chassis intrusion switch on selected
model(s)
EPEAT Gold rating
ENERGY STAR 6.0-compliant
ULE Gold
Cisco EnergyWise compatible
GREENGUARD certified
RoHS-compliant
Supports ThinkVantage Technologies
For compatible accessories,
please go to TC-AQP sheet;
For Lenovo service upgrade options,
please go to S-TC sheet
ThinkCentre M83 Mini Tower (10AG) - ES 6.0 (GMP) Product Specifications Reference (PSREF)
Positioning Mainstream enterprise stability and manageability
Processor Intel Core i5-4570 Processor (4 cores / 4 threads, 3.2GHz, 6MB cache),
Turbo Boost 2.0 (3.6GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Intel Core i5-4590 Processor (4 cores / 4 threads, 3.3GHz, 6MB cache),
Turbo Boost 2.0 (3.7GHz), Intel HD Graphics 4600, 1600MHz DDR3 memory controller
Implementation Processor in LGA1150 socket
Memory 32GB max, UDIMM, PC3-12800 1600MHz DDR3, four 240-pin DIMM sockets
Graphics Intel HD Graphics 4600 in processor, uses main memory, DirectX 11,
one VGA, two DisplayPort, supports three independent displays, works along with
discrete graphics to support up to five independent monitors;
Maximum resolution: 2560x1600 (DisplayPort)@60Hz;
1920x1200 (VGA)@60Hz (Reduced Blanking)
Some: AMD Radeon HD 8470, DirectX 11, 3D Hardware Acceleration,
512MB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 25 watts,
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
Some: NVIDIA Geforce GT 620, DirectX 11, 3D Hardware Acceleration,
1GB, PCI Express 2.0 x16 adapter, one VGA, one DisplayPort, 30 watts;
Max resolution: 2560x1600 (DisplayPort)@60Hz; 2048x1536 (VGA)@85Hz
DP dongle None
Disk SATA 6.0Gb/s 7200 rpm, 3.5" wide
Optical Some: DVD-ROM DL SATA 1.5Gb/s 16-48X Max4 Drive
Some: Super Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
SATA controller Serial ATA, SATA 6.0Gb/s, integrated in chipset
Onboard SATA Two SATA cables (each 1-drop to device), three SATA 6.0Gb/s connectors,
one eSATA connector (SATA 6.0Gb/s)
eSATA port None
Media reader None
Chipset Intel Q85 Express Chipset
Front ports Two USB 3.0, two optional USB 2.0, microphone (stereo, 3.5mm),
headphone (stereo, 3.5mm)
Rear ports Two USB 3.0, four USB 2.0, serial (9-pin), optional 2nd serial (9-pin), ethernet (RJ-45),
one VGA, two DisplayPort,
additional VGA, DisplayPort, or HDMI ports on optional graphic card on some models
Rear audio ports Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
PCIe WLAN Some: 11b/g/n wireless, PCIe Half Mini Card, Intel Centrino Wireless-N 105, 1x1
Some: 11b/g/n wireless, PCIe Half Mini Card, Realtek RTL8723BE, Wi-Fi/BT 4.0, 1x1
Bluetooth Some: Bluetooth 4.0 wireless, integrated in Wi-Fi + Bluetooth combo adapter
Audio High Definition (HD) Audio, Realtek ALC662 codec
Speaker Internal speaker for business audio (1.5 watt)
IEEE 1394 None
Ethernet One gigabit ethernet port, Intel I217-LM (Clarkville), Wake on LAN
Manageability Intel Standard Manageability
Modem None
Security chip Trusted Platform Module (TPM1.2-compliant)
Keyboard Some: Preferred Pro USB Keyboard (USB connector), black, Lenovo logo
Some: Lenovo USB Fingerprint Keyboard (USB connector)
Mouse Enhanced Optical USB Mouse, black, Lenovo logo
Power supply 280 watts, autosensing, 85% PSU
Machine ● Mini Tower (25L), business black color, metal case
● (WxDxH) 6.89" X 17.41" X 16.32"; 175mm X 442.3mm X 414.5mm
● 24.69 lb (11.20 kg) in maximum configuration
● Toolless cover removal, adapter retention
● Toolless disk, optical drive removal
Bay Bay 1: 5.25", 1.6" high, access, std optical
Bay 2: 5.25", 1.6" high, access, open
Bay 3: 3.5", 1" high, access, opt reader
Bay 4: 3.5", 1" high, no access, std disk
Bay 5: 3.5", 1" high, no access, opt disk
Slot Slot 1: half-length, full-height, PCIe 3.0 x16 (75w max)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75w max)
Limited Warranty 3-years, limited onsite service, 8 am-5 pm, Mon - Fri coverage excluding holidays,
next business day response time / service upgrades available
10AG000PUS 3x5 i5-4570 4GBx1 1TB 7200 DVD Intel 105 HD 8470 USB None Switch USB ES6.0 G P Win7 Pro64 (DG) 07/30/13
10AG000QUS 3x5 i5-4570 2GBx1 500GB 7200 DVD None HD 4600 None None Switch USB ES6.0 G P Win7 Pro64 07/30/13
10AG000RUS 3x5 i5-4570 4GBx1 500GB 7200 DVD None HD 4600 USB None Switch USB ES6.0 G P Win7 Pro64 (DG) 07/30/13
10AG000SUS 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None HD 4600 USB None Switch Finger ES6.0 G P Win7 Pro64 (DG) 08/20/13
10AG000TUS 3x5 i5-4570 4GBx1 1TB 7200 DVD±RW Intel 105 HD 8470 USB None Switch USB ES6.0 G P Win7 Pro64 (DG) 08/20/13
10AG000UUS 3x5 i5-4570 4GBx1 500GB 7200 DVD±RW None HD 4600 USB None Switch USB ES6.0 G P Win7 Pro64 (DG) 09/10/13
10AG001KUS 3x5 i5-4590 2GBx1 500GB 7200 DVD None HD 4600 None None Switch USB ES6.0 G P Win7 Pro64 06/10/14
10AG001PUS 3x5 i5-4590 4GBx1 500GB 7200 DVD±RW None HD 4600 USB None Switch USB ES6.0 G P Win7 P64 DG Win 8.1 07/08/14
10AG001QUS 3x5 i5-4590 4GBx1 1TB 7200 DVD±RW 8723BE GT 620 None None Switch USB ES6.0 G P Win7 P64 DG Win 8.1 07/08/14
See footnotes for important warranty information Lenovo
(MSK1T-2) July 2014
Type-model Processor Memory8
SATA
optical Graphics
Slot x
bay Preload
ENERGY
STAR 6.0
SATA disk
GB rpm Key-
board
Additional
Front
USB 2.0
Global (G)
GMP (P)
Ann date
(mm/dd/yy)
Chassis
intrusion
switch
②
optical
disk
③
⑤
2nd
serial
port
PCIe
WLAN
