Processor Intel Celeron, Intel Pentium, or 6th Generation Intel Core i3 / i5 / i7 Processor

Processor Cores /

Threads

Frequency

Base/Max(GHz) Cache Memory Types Integrated

Graphics

Intel

vPro

Pentium G4400 2 / 2 3.3G 3 MB DDR4-2133 HD 510 No

Pentium G4500 2 / 2 3.5G 3 MB DDR4-2133 HD 530 No

Core i3-6100 2 / 4 3.7 G 3 MB DDR4-2133 HD 530 No

Core i3-6300 2 / 4 3.8 G 4 MB DDR4-2133 HD 530 No

Core i5-6400 4 / 4 2.7 G / 3.3 G 6 MB DDR4-2133 HD 530 No

Core i5-6500 4 / 4 3.2 G / 3.6 G 6 MB DDR4-2133 HD 530 vPro

Core i5-6600 4 / 4 3.3 G / 3.9 G 6 MB DDR4-2133 HD 530 vPro

Core i7-6700 4 / 8 3.4 G / 4.0 G 8 MB DDR4-2133 HD 530 vPro

Memory 32GB max, DDR4 2133, two 260-pin SO-DIMM sockets, dual-channel capable

Disk

Optical

Media reader

Some: SATA 6.0Gb/s, 2.5" Wide, 5400 rpm or 7200 rpm

Some: Solid State Hybrid Drive (SSHD) / with 8GB MLC NAND flash memory,

SATA 6.0Gb/s, 2.5" Wide, 5400 rpm

Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" Wide

Some: DVD, SATA 1.5Gb/s, 9.5mm high

Some: DVD burner, SATA 1.5Gb/s, 9.5mm high

Optional 9-in-1 media card reader

Graphics

Display

Light sensor

Multi-touch

Camera

Controls

Intel HD Graphics 510/530 in processor, uses main memory, DirectX 12,

external monitor support via DisplayPort;

Max resolution: 4096x2304 (DP)@60Hz

23.8" (604.5mm) Full HD 1080p (1920x1080) TFT color, WVA panel, wide viewing

angle (+/- 89°), LED backlight, 250 nits, 16:9 aspect ratio, 1000:1 contrast ratio,

anti-glare for both touch models and non-touch models, work as standalone

monitor via DisplayPort (DP in / out combo)

None

Optional Projected Capacitive Touch (PCT) technology, supports 10-point touch

Optional 2.0-megapixel camera, fixed focus, supports 1080p, with dual array digital

microphone, LED indicator, physical switch on/off, Skype for Business certified

Microphone mute, monitor mode switch, brightness up/down buttons, and power

button

Chipset Intel Q170 Chipset

Rear ports

Side ports

M.2 card slot

Four USB 3.0, ethernet (RJ-45), DisplayPort in/out combo port,

optional serial (9-pin),

Two USB 3.0 (one is Always On and fast charge), optional card reader,

one headphone / microphone combo jack (3.5mm)

One M.2 Card slot (for WLAN)

Audio support High Definition (HD) Audio, Realtek ALC286 / two internal stereo speakers (3W x 2),

Dolby Audio certified, Skype for Business certified

WLAN13

Bluetooth

Ethernet

Some: 11ac wireless, M.2 Card, Qualcomm Atheros QCA9377 (dual band),

Wi-Fi + Bluetooth 4.1 combo adapter, 1x1

Some: 11ac wireless, M.2 Card, Qualcomm Atheros QCA6174 (dual band),

Wi-Fi + Bluetooth 4.1 combo adapter, 2x2

Some: 11ac wireless, M.2 Card, Intel Dual Band Wireless-AC 3165,

Wi-Fi + Bluetooth 4.0 combo adapter, 1x1

Some: 11ac wireless, M.2 Card, Intel Dual Band Wireless-AC 8260,

Wi-Fi + Bluetooth 4.1 combo adapter, 2x2

Some: 11ac wireless, M.2 Card, Intel Dual Band Wireless-AC 8260,

Wi-Fi + Bluetooth 4.1 combo adapter, Intel vPro technology support, 2x2

Some: Bluetooth 4.0 or 4.1 wireless, integrated in Wi-Fi + Bluetooth combo adapter

Gigabit ethernet, Intel Ethernet Connection I219-LM (Jacksonville), Wake on LAN

Manageability

Security chip

Security features

Intel Active Management Technology 11.0 (Intel AMT 11.0);

Intel vPro technology on some models (require choosing a vPro-support Wi-Fi

adapter to enable vPro function through wireless connection)

Trusted Platform Module (TPM 1.2-compliant)

● Security slot (in rear for attachment of

optional Kensington MicroSaver cable;

Kensington lock also locks chassis)

● Smart USB protection, allows keyboard/

mouse only, blocks all storage devices

● Power-on, admin, hard disk password

● Boot sequence control

● Boot without keyboard and mouse

● Individual USB port disablement

● Optional Chassis intrusion switch

Keyboard

Mouse

Some: Preferred Pro USB Keyboard (USB connector), Lenovo logo

Some: Lenovo； Slim USB Keyboard (USB connector), black

Some: Ultraslim Plus Wireless Keyboard (2.4GHz via USB receiver), black

Some: Enhanced Optical USB Mouse, black, Lenovo logo

Some: Ultraslim Plus Wireless Mouse (2.4GHz via USB receiver), black

Mechanical ● Business black color

● Toolless back cover, stand, disk, memory removal

● Support VESA mount (100mm)

Dimensions (WxDxH)

Max weight (lb / kg) Adjustments

Without stand: 23.0 X 1.8 X 15.4 (inch);

584 X 45 X 390 (mm)

(Touch) 17.2 / 7.8

(Non-touch) 15.0 / 6.8 N/A

With Basic

Monitor stand:

23.0 X 9.6 X 18.0 (inch);

584 X 245 X 458 (mm) (Non-touch) 19.4 / 8.8 Tilt: 45° back,

-5° forward

With UltraFlex

II stand:

23.0X 10.0 X 19.9 (inch);

584 X 253 X 505 (mm)

(Touch) 22.7 / 10.3

(Non-touch) 20.7 / 9.4

Tilt: 60° back,

-5° forward;

Lift: 110mm;

Swivel: +/-45°

Power supply 150 watts, autosensing, 85% PSU

Limited warranty3Some: 1-year or 3-year, depot repair service

Some: 1-year or 3-year, limited onsite service

Some: 3-years, limited onsite service, OID (Onsite International Delivery) /

For Lenovo service upgrade options, please go to S-TC sheet

Preload Preloaded operating system

Some: Windows 7 Professional 32/64

preinstalled through downgrade

rights in Windows 10 Pro 64-bit

Some: Windows 7 Professional 64

Some: Windows 10 Pro 64-bit

Some: Windows 10 Home 64-bit

Preloaded applications (only some

listed)

● Desktop Power Manager

● Lenovo Solution Center

● Lenovo REACHit

● Lenovo SHAREit

● Lenovo Bluetooth Lock

(for models with Wi-Fi/BT card)

● McAfee LiveSafe (30-day trial)

● Microsoft Office preloaded;

purchase a product key to activate

● PowerDVD Create (DVD±RW)

● Lenovo ThinkVantage Tools

- Only for Window 10

● Lenovo Companion

● Cyberlink PowerDVD (DVD, DVD±RW)

● Lenovo QuickOptimizer

- Only for Window 7

● Rescue and Recovery

● Password Manager

● ThinkVantage System Update

● Lenovo Message Center Plus

● Adobe Reader

Environment EPEAT Gold rating; ENERGY STAR 6.1; TCO Certified Edge;

TUV Green Mark; ULE Gold; ErP Lot 3; GREENGUARD certified;

RoHS-compliant

Accessories For compatible accessories, please go to TC-AQP sheet

ThinkCentre M900z Platform Specifications Product Specifications Reference (PSREF)

See footnotes for more detailed information  Lenovo

(M900z-Spec) November 2015
