FRU

CRU ID

DESCRIPTION

01FR013

1

ADL45WCA 20V2.25A ad CMN

01FR014

1

ADL45WCB 20V2.25A ad CMN

01FR015

1

ADL45WCC 20V2.25A ad CMN

01FR016

1

ADL45WCD 20V2.25A ad CMN

01FR017

1

ADL45WCK 20V2.25A ad CMN

01FR018

1

ADL45WCE 20V2.25A ad CMN

01FR019

1

ADL45WCF 20V2.25A ad CMN

01FR020

1

ADL45WCG 20V2.25A ad CMN

01FR021

1

ADL45WCH 20V2.25A ad CMN

01FR036

1

PA-1450-55LK 20V2.25A COO

01FR109

1

ADP-45DW A 20V2.25A COO

01FR110

1

ADP-45DW J 20V2.25A COO

01FR111

1

ADP-45DW B 20V2.25A COO

01FR112

1

ADP-45DW D 20V2.25A COO

01FR113

1

ADP-45DW H 20V2.25A COO

01FR114

1

ADP-45DW G 20V2.25A COO

01FR115

1

ADP-45DW E 20V2.25A COO

01FR116

1

ADP-45DW C 20V2.25A COO

01FR117

1

ADP-45DW K 20V2.25A COO

01FR118

1

PA-1450-55LN 20V2.25A COO

01FR119

1

PA-1450-55LG 20V2.25A COO

01FR120

1

PA-1450-55LL 20V2.25A COO

01FR121

1

PA-1450-55LI 20V2.25A COO

01FR122

1

PA-1450-55LR 20V2.25A COO

01FR123

1

PA-1450-55LS 20V2.25A COO

01FR124

1

PA-1450-55LU 20V2.25A COO

01FR125

1

PA-1450-55LZ 20V2.25A COO

01FR126

1

ADL45WCA 20V2.25A COO

01FR127

1

ADL45WCB 20V2.25A COO

01FR128

1

ADL45WCC 20V2.25A COO

01FR129

1

ADL45WCD 20V2.25A COO

01FR130

1

ADL45WCK 20V2.25A COO

01FR131

1

ADL45WCE 20V2.25A COO

01FR132

1

ADL45WCF 20V2.25A COO

01FR133

1

ADL45WCG 20V2.25A COO

01FR134

1

ADL45WCH 20V2.25A COO

5A10H42917

1

Liteon PA-1450-55LK 20V2.25A

5A10H42918

1

Liteon PA-1450-55LZ 20V2.25A

5A10H42919

1

Liteon PA-1450-55LR 20V2.25A

5A10H42920

1

Liteon PA-1450-55LG 20V2.25A

5A10H42921

1

Liteon PA-1450-55LN 20V2.25A

5A10H42922

1

Liteon PA-1450-55LS 20V2.25A

5A10H42923

1

Liteon PA-1450-55LL 20V2.25A

AC ADAPTERS

Miix 520 FRU BOM; MT: 20M3, 20M4

5A10H42925

1

Liteon PA-1450-55LU 20V2.25A

5A10H42926

1

Liteon PA-1450-55LI 20V2.25A

5A10H43616

1

Chicony ADL45WCH 20V2.25A

5A10H43617

1

Delta ADP-45DW G 20V2.25A

5A10H43618

1

Chicony ADL45WCB 20V2.25A

5A10H43619

1

Chicony ADL45WCK 20V2.25A

5A10H43620

1

Delta ADP-45DW A 20V2.25A

5A10H43621

1

Delta ADP-45DW D 20V2.25A

5A10H43622

1

Chicony ADL45WCF 20V2.25A

5A10H43623

1

Delta ADP-45DW J 20V2.25A

5A10H43624

1

Delta ADP-45DW K 20V2.25A

5A10H43625

1

Chicony ADL45WCC 20V2.25A

5A10H43626

1

Delta ADP-45DW E 20V2.25A

5A10H43627

1

Delta ADP-45DW H 20V2.25A

5A10H43628

1

Chicony ADL45WCG 20V2.25A

5A10H43629

1

Chicony ADL45WCA 20V2.25A

5A10H43630

1

Delta ADP-45DW B 20V2.25A

5A10H43631

1

Chicony ADL45WCD 20V2.25A

5A10H43632

1

Delta ADP-45DW C 20V2.25A

5A10H43633

1

Chicony ADL45WCE 20V2.25A

5B10L68713

N

BATTERY 3N 4955mAh 7.68V 80U1

5B10P92321

N

RTC Battery 3N 81CG

5B20Q58460

N

MB 3N20M3 I78550WIN16G TPMWWLTE

5B20Q58461

N

MB 3N20M3 I58250WIN8G TPMWW LTE

5B20Q58462

N

MB 3N20M3 I37100WIN 4G TPMWWLTE

5B20Q58463

N

MB 3N20M3 I58250WIN16GTPMWW LTE

5B20Q58598

N

MB 3N 20M3 I78550WIN 16G TPM/WW

5B20Q58599

N

MB 3N 20M3 I37100WIN 4G TPM/WW

5B20Q58600

N

MB 3N 20M3 I58250WIN 8G TPM/WW

5B20Q58601

N

MB 3N 20M3 I58250WIN 16G TPM/WW

5B20Q62277

N

MB 3N20M3 I37130WIN4G TPMWW LTE

5B20Q62278

N

MB 3N20M3 I78550WIN 8G TPM WW

5B20Q62279

N

MB 3N20M3 I78550WIN8G TPMWW LTE

5B20Q62280

N

MB 3N20M3 I37130WIN 4G TPM WW

5B40M13897

N

CAMERA Bracket 3N 80U1

5B40P95195

N

FPR Bracket 3N 81CG

5C10M13887

N

TP Cable 3N 80U1

5C10M13898

N

LVDS Cable 3N 80U1

5C20P92329

N

CAM 3N 81CG WIN10 5M rear W/omic

5C20P92336

N

CAM 3N 81CG WIN10 8M rear W/omic

5C20P92403

N

CAM 3N 81CG WIN10 5M front W/omic

BATTERIES

PLANARS

BRACKETS

CABLES

CAMERAS

MISC CARDS

5C50M13880

N

FUNCTION BD 3N 80U1 W/cable

5C50N11752

N

SD BD 3N 80XE W/cable

5C50P92343

N

IO Board 3N 81CG W/cable

5CB0P92324

N

LCD Cover 3N 81CG Grey WF FPR 5M

5CB0P92335

N

LCD Cover 3N 81CG Grey LTE FPR 5M

5CB0P92357

N

Stand Cover 3N 81CG Grey

5CB0P92391

N

Hinge Cover 3N 81CG Grey

5CB0P95169

N

LCD Cover 3N 81CG Grey LTE FPR 8M

5CB0P95172

N

LCD Cover 3N 81CG Grey WF FPR 8M

5D10P92347

N

LCD Module 3N81CG W/TP/Bezel LTE

5D10P92363

N

LCD Module 3N 81CG W/TP/Bezel WF

5F10P92392

N

CPU FAN 3N 81CG

5F30P95170

N

FINGER_PRT 3N 81CG W/cable IG

5H40P92337

N

Heatsink 3N 81CG

5H50M56916

N

Hinge L+R 3N 80U1 Black

5L10Q58512

N

Label Kit 3N 20M3/20M4

00JT921

N

PEN Holder,Black,J

00JT922

N

PEN Holder,Black,C

5M20N77739

N

Pen Holder_BT L 80VV

5M40P92387

N

Dual Mic Module 3N 81CG

5N20N88530

1

Bel-F4C-DOK-BacklightKBD-ASSY

5N20N88531

1

ITA-F4C-DOK-BacklightKBD-ASSY

5N20N88534

1

USI-F4C-DOK-BacklightKBD-ASSY

5N20N88538

1

Sw-F4C-DOK-BacklightKBD-ASSY

5N20N88539

1

KOR-F4C-DOK-NonBacklightKBD-ASSY

5N20N88540

1

TUR-F4C-DOK-BacklightKBD-ASSY

5N20N88542

1

ARA-F4C-DOK-NonBacklightKBD-ASSY

5N20N88544

1

BUL-F4C-DOK-BacklightKBD-ASSY

5N20N88546

1

Hun-F4C-DOK-BacklightKBD-ASSY

5N20N88547

1

HEB-F4C-DOK-BacklightKBD-ASSY

5N20N88549

1

Ukra-F4C-DOK-NonBacklightKBD-ASSY

5N20N88550

1

KOR-F4C-DOK-BacklightKBD-ASSY

5N20N88552

1

Fr-Ar-F4C-DOK-BacklightKBD-ASSY

5N20N88553

1

UK-F4C-DOK-BacklightKBD-ASSY

5N20N88555

1

Bel-F4C-DOK-NonBacklightKBD-ASSY

5N20N88559

1

FR-F4C-DOK-BacklightKBD-ASSY

5N20N88560

1

Nod-F4C-DOK-NonBacklightKBD-ASSY

HEATSINKS

HINGES

LABELS

MECHANICALS

MICROPHONES

KEYBOARDS

FINGERPRINT READERS

COVERS

LCD DISPLAYS

FANS

5N20N88563

1

LSP-F4C-DOK-BacklightKBD-ASSY

5N20N88564

1

BUL-F4C-DOK-NonBacklightKBD-ASSY

5N20N88565

1

THA-F4C-DOK-BacklightKBD-ASSY

5N20N88566

1

JAP-F4C-DOK-BacklightKBD-ASSY

5N20N88567

1

Sle-F4C-DOK-NonBacklightKBD-ASSY

5N20N88569

1

Sw-F4C-DOK-NonBacklightKBD-ASSY

5N20N88570

1

RU-F4C-DOK-BacklightKBD-ASSY

5N20N88571

1

TUR-F4C-DOK-NonBacklightKBD-ASSY

5N20N88575

1

THA-F4C-DOK-NonBacklightKBD-ASSY

5N20N88578

1

GE-F4C-DOK-BacklightKBD-ASSY

5N20N88579

1

GRE-F4C-DOK-NonBacklightKBD-ASSY

5N20N88580

1

CFEn-F4C-DOK-BacklightKBD-ASSY

5N20N88581

1

US-F4C-DOK-BacklightKBD-ASSY

5N20N88582

1

UK-F4C-DOK-NonBacklightKBD-ASSY

5N20N88583

1

HEB-F4C-DOK-NonBacklightKBD-ASSY

5N20N88584

1

DUT-F4C-DOK-NonBacklightKBD-ASSY

5N20N88585

1

TC-F4C-DOK-BacklightKBD-ASSY

5N20N88586

1

SPA-F4C-DOK-NonBacklightKBD-ASSY

5N20N88588

1

ID-F4C-DOK-NonBacklightKBD-ASSY

5N20N88589

1

Sle-F4C-DOK-BacklightKBD-ASSY

5N20N88590

1

ARA-F4C-DOK-BacklightKBD-ASSY

5N20N88591

1

POR-F4C-DOK-BacklightKBD-ASSY

5N20N88592

1

RU-F4C-DOK-NonBacklightKBD-ASSY

5N20N88594

1

ID-F4C-DOK-BacklightKBD-ASSY

5N20N88595

1

CFEn-F4C-DOK-NonBacklightKBD-ASSY

5N20N88596

1

TC-F4C-DOK-NonBacklightKBD-ASSY

5N20N88599

1

GRE-F4C-DOK-BacklightKBD-ASSY

5N20N88601

1

Hun-F4C-DOK-NonBacklightKBD-ASSY

5N20N88605

1

SPA-F4C-DOK-BacklightKBD-ASSY

5N20N88606

1

Nod-F4C-DOK-BacklightKBD-ASSY

5N20N88607

1

US-F4C-DOK-NonBacklightKBD-ASSY

5N20N88608

1

GE-F4C-DOK-NonBacklightKBD-ASSY

5N20N88609

1

Ukra-F4C-DOK-BacklightKBD-ASSY

5N20N88610

1

ITA-F4C-DOK-NonBacklightKBD-ASSY

5N20N88611

1

FR-F4C-DOK-NonBacklightKBD-ASSY

5N20N88613

1

CzhSlk-F4C-DOK-BacklightKBD-ASSY

5N20N88614

1

POR-F4C-DOK-NonBacklightKBD-ASSY

5N20N88615

1

JAP-F4C-DOK-NonBacklightKBD-ASSY

5N20N88616

1

LSP-F4C-DOK-NonBacklightKBD-ASSY

5N20N88617

1

USI-F4C-DOK-NonBacklightKBD-ASSY

5N20N88619

1

DUT-F4C-DOK-BacklightKBD-ASSY

5N20N88621

1

CzSk-F4C-DOK-NonBacklightKBD-ASSY

5N20N88625

1

FrAr-F4C-DOK-NonBacklightKBD-ASSY

5S10P92396

1

Screw Pack 3N 81CG

5SB0P92369

N

Speaker 3N 81CG L+R 80? 1wx2

SPEAKERS

SCREW KIT

5SD0L07883

N

SS MZVLW1T0HMLH-000L2 1T

5SD0L73443

N

SS MZVLW512HMJP 512G PCIE SSD

5SD0L73444

N

SS MZVLW256HEHP 256G PCIE SSD

5SD0L73445

N

SS MZVLW128HEGR 128G PCIE SSD

5SD0M56299

N

TSB XG4 256G M.2 2280 PCIe SSD

5SD0M56300

N

TSB XG4 512G M.2 2280 PCIe SSD

5SD0M56301

N

TSB XG4 128G M.2 2280 PCIe SSD

5SD0N04881

N

LIT CA1 128GB M.2 2280 PCIe SSD

5T70J33309

1

Wacom ESP10110C5 D9.5 BK A Pen

5T70K13856

1

Wacom ESP10113C5 D9.5 BK A Pen

5T70K13857

1

Wacom ESP10112B5 D9.5 BK A Pen

5T70M55297

1

WCM ESP101B21C5 D9.5 BT Pen

5T70M94878

1

WCM ESP101B26C5 D9.5 BT Pen

5T70M94879

1

WCM ESP101B27B5 D9.5 BT Pen

5T70M94881

1

WCM ESP101B28B5 D9.5 BT Pen

5T70P15727

1

Wacom ESP101B31C5 D9.5 BK A Pen

5T70P15728

1

Wacom ESP101B32C5 D9.5 BK A Pen

01AX704

N

Wireless,CMB,IN,8265 NV M2

01AX713

N

Wireless,CMB,LTN,NFA344A M2

01AX714

N

Wireless,CMB,FBC,L830CN

01AX753

N

Wireless,CMB,FBC,831EAU

5R30Q64459

0

W10x64 HOME PT-EN RUSB

5R30Q64460

0

W10x64 PRO EN-RU-UR RUSB

5R30Q64461

0

W10x64 HOME EM EN-RU-UR RUSB

5R30Q64462

0

W10x64 HOME EM EN-AR RUSB

5R30Q64463

0

W10x64 HOME EM Nordic RUSB

5R30Q64464

0

W10x64 HOME EN-IL RUSB

5R30Q64465

0

W10x64 PRO Switzer RUSB

5R30Q64466

0

W10x64 HOME EM EN-CR-SL RUSB

5R30Q64467

0

W10x64 HOME EN-IT RUSB

5R30Q64468

0

W10x64 HOME Nordic RUSB

5R30Q64469

0

W10x64 PRO Nordic RUSB

5R30Q64470

0

W10x64 HOME EN RUSB

5R30Q64471

0

W10x64 PRO CN RUSB

5R30Q64472

0

W10x64 PRO EN-SE RUSB

5R30Q64473

0

W10x64 HOME Russian RUSB

5R30Q64474

0

W10x64 HOME GR RUSB

5R30Q64475

0

W10x64 HOME Benelux RUSB

5R30Q64476

0

W10x64 HOME EM EN RUSB

5R30Q64477

0

W10x64 HOME EM Polish RUSB

5R30Q64478

0

W10x64 HOME EM HU-EN RUSB

5R30Q64479

0

W10x64 HOME PT(Br) RUSB

5R30Q64480

0

W10x64 HOME EM EN-KR RUSB

RECOVERY MEDIA

SOLID STATE DRIVES

TOUCH PENS

WIRELESS CARDS

5R30Q64481

0

W10x64 HOME HU-EN RUSB

5R30Q64482

0

W10x64 HOME EM EN-IL RUSB

5R30Q64483

0

W10x64 PRO EN RUSB

5R30Q64484

0

W10x64 HOME EN-RO RUSB

5R30Q64485

0

W10x64 PRO Polish RUSB

5R30Q64486

0

W10x64 HOME GRE-EN RUSB

5R30Q64487

0

W10x64 HOME Spanish RUSB

5R30Q64488

0

W10x64 HOME EN-KR RUSB

5R30Q64489

0

W10x64 HOME EM EN-TR RUSB

5R30Q64490

0

W10x64 PRO PT-EN RUSB

5R30Q64491

0

W10x64 HOME EN-TR RUSB

5R30Q64492

0

W10x64 HOME EN-SC RUSB

5R30Q64493

0

W10x64 PRO HU-EN RUSB

5R30Q64494

0

W10x64 HOME EN-SE RUSB

5R30Q64495

0

W10x64 PRO EN-IL RUSB

5R30Q64496

0

W10x64 HOME EN-CR-SL RUSB

5R30Q64497

0

W10x64 HOME EM GR RUSB

5R30Q64498

0

W10x64 HOME EM EN-CZ-SK RUSB

5R30Q64499

0

W10x64 Chinese RUSB

5R30Q64500

0

W10x64 HOME EM GRE-EN RUSB

5R30Q64501

0

W10x64 PRO Benelux RUSB

5R30Q64502

0

W10x64 HOME EM TW RUSB

5R30Q64503

0

W10x64 HOME TW RUSB

5R30Q64504

0

W10x64 HOME EN-RU-UR RUSB

5R30Q64505

0

W10x64 PRO Russian RUSB

5R30Q64506

0

W10x64 HOME EM EN-IT RUSB

5R30Q64507

0

W10x64 PRO HK RUSB

5R30Q64508

0

W10x64 PRO EN-SC RUSB

5R30Q64509

0

W10x64 HOME EM PT(Br) RUSB

5R30Q64510

0

W10x64 PRO GRE-EN RUSB

5R30Q64511

0

W10x64 HOME EM EN-SE RUSB

5R30Q64512

0

W10x64 HOME Switzer RUSB

5R30Q64513

0

W10x64 PRO FR RUSB

5R30Q64514

0

W10x64 HOME EM Benelux RUSB

5R30Q64515

0

W10x64 HOME EN-AR RUSB

5R30Q64516

0

W10x64 HOME HK RUSB

5R30Q64517

0

W10x64 PRO EN-AR RUSB

5R30Q64518

0

W10x64 PRO EN-CR-SL RUSB

5R30Q64519

0

W10x64 HOME FR RUSB

5R30Q64520

0

W10x64 PRO EN-FR RUSB

5R30Q64521

0

W10x64 HOME Polish RUSB

5R30Q64522

0

W10x64 PRO JP RUSB

5R30Q64523

0

W10x64 PRO EN-CZ-SK RUSB

5R30Q64524

0

W10x64 HOME EN-CZ-SK RUSB

5R30Q64525

0

W10x64 HOME JP RUSB

5R30Q64526

0

W10x64 PRO EN-TR RUSB

5R30Q64527

0

W10x64 HOME EM EN-FR RUSB

5R30Q64528

0

W10x64 PRO PT(Br) RUSB

5R30Q64529

0

W10x64 PRO Spanish RUSB

5R30Q64530

0

W10x64 HOME EM Switzer RUSB

5R30Q64531

0

W10x64 HOME EM FR RUSB

5R30Q64532

0

W10x64 HOME EM Spanish RUSB

5R30Q64533

0

W10x64 HOME EM HK RUSB

5R30Q64534

0

W10x64 PRO GR RUSB

5R30Q64535

0

W10x64 HOME EM Russian RUSB

5R30Q64536

0

W10x64 HOME EM PT-EN RUSB

5R30Q64537

0

W10x64 HOME EM EN-SC RUSB

5R30Q64538

0

W10x64 PRO EN-IT RUSB

5R30Q64539

0

W10x64 PRO EN-RO RUSB

5R30Q64540

0

W10x64 HOME EM JP RUSB

5R30Q64541

0

W10x64 PRO TW RUSB

5R30Q64542

0

W10x64 HOME EN-FR RUSB

5R30Q64543

0

W10x64 PRO EN-KR RUSB

5R30Q64544

0

W10x64 HOME EM EN-RO RUSB
