FRU PN CRU ID Description

45N0314 1TPG plug Delta 65W 3pin

45N0316 1TPG plug Delta 65W 2pin

45N0318 1TPG plug Liteon 65W 3pin

45N0320 1TPG plug Liteon 65W 2pin

45N0322 1TPG plug Chicony 65W3pin

45N0324 1TPG plug Chicony 65W2pin

45N0503 1 TPG plug Liteon 65W 2pin CMN modified AC Adapter (secondary)

45N0505 1 TPG plug Chicony 65W 2pin CMN modified AC Adapter (primary)

45N0508 1 TPG plug Liteon 65W 3pin CMN modified AC Adapter (primary)

45N0510 1 TPG plug Chicony 65W 3pin CMN modified AC Adapter (secondary)

04W3763 2 CBT 2*2 Combo

04W3764 2 LTN 2*2 Combo

04W3765 2 Jackson Peak 1

04W3786 2 H5321gw

04W3834 2 Cybertan BCM43228+BCM20702 2*2 abgn WLAN & BT 4.0 HMC Combo (primary)

04W3835 2 Liteon BCM43228+BCM20702 2*2 abgn WLAN & BT 4.0 HMC Combo (secondary)

04Y1413 NHDD sub card

04Y1420 N Sensor Board

60Y3195 2 6250 WiMax

60Y3253 2 TP 22 WLAN

04Y1418 N Antenna KIT - WNC

04Y1419 N Antenna KIT - JPC

04W6920 N RTC Battery

45N1169 N Sony 8cell 47Wh

04W3652 N BKT extender half card

00HM814 N Sensor Cable

04Y1563 NDC-in cable

04Y1567 NLVDS Cable ASM

04Y1568 NPower Cable ASM

04W1049 N HD CAMERA GS CHY IMX119

91P9642 1 TP CAP set

04X0717 Nplni3-2365M2 W8SYTPM fuse

04X0718 Nplni3-2365M2 W8PYTPM fuse

04X0719 Nplni3-2375M2 W8SYTPM fuse

04X0720 Nplni3-2375M2 W8PYTPM fuse

04X0721 Nplni3-3217U4 W8SYTPM fuse

04X0722 Nplni3-3217U4 W8PYTPM fuse

04X0723 Nplni3-3227U4 W8SYTPM fuse

04X0724 Nplni3-3227U4 W8PYTPM fuse

04X0725 Nplni5-3317U4 W8SYTPM fuse

04X0726 Nplni5-3317U4 W8PYTPM fuse

CAPS

PLANARS

ANTENNAS

BATTERIES

BRACKETS

CABLES

CAMERAS

ADAPTERS

S230u FRU List; MT 3347, 20C4

ADAPTERS, WIRELESS CARDS AND SUBCARDS

04X0727 Nplni5-3337U4 W8SYTPM fuse

04X0728 Nplni5-3337U4 W8PYTPM fuse

04X0729 Nplni5-3427U4 W8SYTPM fuse

04X0730 Nplni5-3427U4 W8PYTPM fuse

04X0731 Nplni7-3517U8 W8SYTPM fuse

04X0732 Nplni7-3517U8 W8PYTPM fuse

04X0733 Nplni7-3537U8 W8SYTPM fuse

04X0734 Nplni7-3537U8 W8PYTPM fuse

04X0735 Nplni3-2365M2 W8SNTPM fuse

04X0736 Nplni3-2365M2 W8PNTPM fuse

04X0737 Nplni3-2375M2 W8SNTPM fuse

04X0738 Nplni3-2375M2 W8PNTPM fuse

04X0739 Nplni3-3217U4 W8SNTPM fuse

04X0740 Nplni3-3217U4 W8PNTPM fuse

04X0741 Nplni3-3227U4 W8SNTPM fuse

04X0742 Nplni3-3227U4 W8PNTPM fuse

04X0743 Nplni5-3317U4 W8SNTPM fuse

04X0744 Nplni5-3317U4 W8PNTPM fuse

04X0745 Nplni5-3337U4 W8SNTPM fuse

04X0746 Nplni5-3337U4 W8PNTPM fuse

04X0747 Nplni5-3427U4 W8SNTPM fuse

04X0748 Nplni5-3427U4 W8PNTPM fuse

04X0749 Nplni7-3517U8 W8SNTPM fuse

04X0750 Nplni7-3517U8 W8PNTPM fuse

04X0751 Nplni7-3537U8 W8SNTPM fuse

04X0752 Nplni7-3537U8 W8PNTPM fuse

04X0852 Nplni3-3217U2 W8SYTPM fuse

04X0853 Nplni3-3217U2 W8PYTPM fuse

04X0854 Nplni3-3217U2 W8SNTPM fuse

04X0855 Nplni3-3217U2 W8PNTPM fuse

04X4009 N plni7-3667U W8P YTPM/YAES

04X4010 N plni7-3667U W8S YTPM/YAES

04X0377 N LCD Btn Bezel S230uTwist

04Y1565 N HDD Cover

04Y1566 N Button Bezel

04Y1570 N Swivel cover

03T2887 1 Adobe PremiereElements 10

03T6427 1 Adobe Acrobat X Standard

04W0570 1 B500 Toshiba

04W0576 1 C320AF Seagate

04W0582 1 7200RPM SATA 320GB 7.0mm AF 6Gb/s Toshiba AQUARIUS-C SLIM-320

04W0583 1 7200RPM SATA 500GB 7.0mm AF 6Gb/s Toshiba AQUARIUS-C SLIM-500

04W0592 1 5400RPM 500GB 7.0mm 6Gb/s WD MN500S-500

04W3923 1 5400 JAGUAR-B7 500

04W3926 1 5400 MN500S 500GB

04W3927 1 7200 JAGUAR-C7 320

04W3929 1 7200 JAGUAR-C7 500

04X0502 2 SSD ASM HG5 128

SSD'S

COVERS

CD-ROM

HDD'S

04X0764 2 SSD ASM PM830 128

04X0765 2 SSD ASM PM830 256

04X4695 2 SSD OPAL 256GB 7.0mm 6Gb/s Samsung 2.5"PM841-OPAL256

75Y5477 2SSD128GB Samsung

75Y5479 2 SSOPAL256 Samsung

45N8331 N mSATA 16GB SanDisk Cache

45N8375 NmSATA 16GB Samsung Cache

45N8377 N mSATA 24GB Samsung Cache

45N8379 N mSATA 24GB SanDisk Cache

04W6940 N UMA Delta + Auras

04Y1417 N Hinge KIT

04W2926 1 KBD USE Chicony

04W2927 1 KBD CFA Chicony

04W2928 1 KBD CFR Chicony

04W2929 1 KBD LAS Chicony

04W2930 1KBD BRA - Primary

04W2931 1 KBD ARA Chicony

04W2932 1 KBD BEL Chicony

04W2933 1 KBD BUL Chicony

04W2934 1 KBD CZH Chicony

04W2935 1 KBD DEN Chicony

04W2936 1 KBD SPA Chicony

04W2937 1 KBD FRA Chicony

04W2938 1 KBD GER Chicony

04W2939 1 KBD GRK Chicony

04W2940 1 KBD HBW Chicony

04W2941 1 KBD HGN Chicony

04W2942 1 KBD ICE Chicony

04W2943 1 KBD ITA Chicony

04W2944 1 KBD KAZ Chicony

04W2945 1 KBD NET Chicony

04W2946 1 KBD NOR Chicony

04W2947 1 KBD POL Chicony

04W2948 1 KBD POR Chicony

04W2949 1 KBD RUS Chicony

04W2950 1 KBD SLK Chicony

04W2951 1 KBD SCB Chicony

04W2952 1 KBD SWE Chicony

04W2953 1 KBD SWS Chicony

04W2954 1 KBD TUR Chicony

04W2955 1 KBD UKE Chicony

04W2956 1 KBD USI Chicony

04W2957 1 KBD JPN Chicony

04W2958 1 KBD KOR Chicony

04W2959 1 KBD TWN Chicony

04W2960 1 KBD THA Chicony

04W2961 1 KBD TUF Chicony

04W2962 1 KBD IND Chicony

mSATA DRIVES

THERMALS

HINGES

KEYBOARDS

04W2963 1 KBD USE Liteon - 2ndary

04W2964 1 KBD CFA Liteon - 2ndary

04W2965 1 KBD CFR Liteon - 2ndary

04W2966 1 KBD LAS Liteon - 2ndary

04W2967 1KBD BRA - Secondary

04W2968 1 KBD ARA Liteon - 2ndary

04W2969 1 KBD BEL Liteon - 2ndary

04W2970 1 KBD BUL Liteon - 2ndary

04W2971 1 KBD CZH Liteon - 2ndary

04W2972 1 KBD DEN Liteon - 2ndary

04W2973 1 KBD SPA Liteon - 2ndary

04W2974 1 KBD FRA Liteon - 2ndary

04W2975 1 KBD GER Liteon - 2ndary

04W2976 1 KBD GRK Liteon - 2ndary

04W2977 1 KBD HBW Liteon - 2ndary

04W2978 1 KBD HGN Liteon - 2ndary

04W2979 1 KBD ICE Liteon - 2ndary

04W2980 1 KBD ITA Liteon - 2ndary

04W2981 1 KBD KAZ Liteon - 2ndary

04W2982 1 KBD NET Liteon - 2ndary

04W2983 1 KBD NOR Liteon - 2ndary

04W2984 1 KBD POL Liteon - 2ndary

04W2985 1 KBD POR Liteon - 2ndary

04W2986 1 KBD RUS Liteon - 2ndary

04W2987 1 KBD SLK Liteon - 2ndary

04W2988 1 KBD SCB Liteon - 2ndary

04W2989 1 KBD SWE Liteon - 2ndary

04W2990 1 KBD SWS Liteon - 2ndary

04W2991 1 KBD TUR Liteon - 2ndary

04W2992 1 KBD UKE Liteon - 2ndary

04W2993 1 KBD USI Liteon - 2ndary

04W2994 1 KBD JPN Liteon - 2ndary

04W2995 1 KBD KOR Liteon - 2ndary

04W2996 1 KBD TWN Liteon - 2ndary

04W2997 1 KBD THA Liteon - 2ndary

04W2998 1 KBD TUF Liteon - 2ndary

04W2999 1 KBD IND Liteon - 2ndary

42T5004 1 US/Canada-1.0M

42T5008 1 US/Canada-1.0M

42T5014 1 Japan-1.0M

42T5020 1 Argentina-1.0M

42T5029 1 Europe-1.0M

42T5035 1 UK-1.0M

42T5041 1 Denmark-1.0M

42T5044 1 SWS-1.0M

42T5047 1 Italy-1.0M

42T5050 1 ANZ-1.0M

42T5056 1 SA-1.0M

42T5062 1 Israel-1.0M

42T5065 1 China-1.0M

42T5071 1 Taiwan-1.0M

LINE CORDS

42T5077 1 Korea-1.0M

42T5083 1 India-1.0M

42T5180 1 Brazil-1.0M 2p

04Y1412 N Keyboard Bezel ASM

04Y1414 NSpeaker ASM

04Y1415 N Touch panel Sub ASM

04Y1416 NRear cover ASM

04Y1420 N Psensor set

04Y1562 NScrew Kit

04Y1564 NBase Cover Asm

04Y1569 NButton sub card

04Y1571 NSystem Misc Kit

04Y1572 NLCD Misc Kit

04Y9613 1 DVD Win8x64 CT/EN

04Y9614 1 DVD Win8x64 CZ/EN

04Y9615 1 DVD Win8x64 FR

04Y9616 1 DVD Win8x64 GK/EN

04Y9617 1 DVD Win8x64 GR

04Y9618 1 DVD Win8x64 HB/EN

04Y9619 1 DVD Win8x64 HU/EN

04Y9620 1 DVD Win8x64 JP

04Y9670 1 DVD Win8x64 KR/EN

04Y9671 1 DVD Win8x64 PL

04Y9672 1 DVD Win8x64 PO/EN

04Y9673 1 DVD Win8x64 RO/EN

04Y9674 1 DVD Win8x64 SK/EN

04Y9675 1 DVD Win8x64 SP

04Y9676 1 DVD Win8x64 US

04Y9677 1 DVD Win8x64 C&L EMEA

04Y9678 1 DVD Win8x64 C&L HK/CS/EN

04Y9679 1 DVD Win8x64 C&L Nordics

04Y9680 1 DVD Win8x64 C&L SL/CR/EN

04Y9682 1 DVD Win8x64 UK

04Y9683 1 DVD Win8SLx64 AR/EN

04Y9685 1 DVD Win8SLx64 FR

04Y9686 1 DVD Win8SLx64 PO/EN

04Y9687 1 DVD Win8SLx64 RU

04Y9688 1 DVD Win8SLx64 SP

04Y9689 1 DVD Win8SLx64 SR/EN

04Y9690 1 DVD Win8SLx64 TR/EN

04Y9691 1 DVD Win8SLx64 US

04Y9692 1 DVD Win8CNx64 CS

04Y9693 1 DVD Win8PROx64 AR/EN

04Y9695 1 DVD Win8PROx64 CS

04Y9696 1 DVD Win8PROx64 CT/EN

04Y9697 1 DVD Win8PROx64 CZ/EN

04Y9698 1 DVD Win8PROx64 FR

04Y9699 1 DVD Win8PROx64 GK/EN

04Y9700 1 DVD Win8PROx64 GR

04Y9701 1 DVD Win8PROx64 HB/EN

MECHANICAL ASSEMBLIES

RECOVERY MEDIA

04Y9702 1 DVD Win8PROx64 HU/EN

04Y9703 1 DVD Win8PROx64 JP

04Y9704 1 DVD Win8PROx64 KR/EN

04Y9705 1 DVD Win8PROx64 PL

04Y9706 1 DVD Win8PROx64 PO/EN

04Y9707 1 DVD Win8PROx64 RO/EN

04Y9708 1 DVD Win8PROx64 RU

04Y9709 1 DVD Win8PROx64 SK/EN

04Y9710 1 DVD Win8PROx64 SP

04Y9711 1 DVD Win8PROx64 SR/EN

04Y9712 1 DVD Win8PROx64 TR/EN

04Y9713 1 DVD Win8PROx64 US

04Y9714 1 DVD Win8PROx64 C&L EMEA

04Y9715 1 DVD Win8PROx64 C&L HK/CS/EN

04Y9716 1 DVD Win8PROx64 C&L Nordics

04Y9717 1 DVD Win8PROx64 C&L SL/CR/EN

04Y9719 1 DVD Win8PROx64 UK
