UserGuide

Lenovo S5000
Quick Start Guide v1.0
Read this guide carefully before using your tablet.
All information labeled with * in this guide refers only to
the WLAN + 3G model (Lenovo S5000-H).
Type: CMOS
Pixels: 5 MP Autofocus (back)+ 1.6 MP (front)
GPS
Height: 191 mm Width: 116 mm Depth: 7.9 mm
Weight: 246 g *249 g
CPU: MTK 8125 Quad Core 1.2 GHz
*MTK 8389 Quad Core 1.2 GHz
Size: 7 inches (diagonal) Screen: Multi-touch display
Resolution: 1280 × 800 LCD type: IPS
Model: Lenovo S5000-F; *Lenovo S5000-H;
②Bluetooth 4.0 WLAN 802.11b/g/n *WCDMA, GSM
① Actual product may differ.
② Launch with Android 4.2 which only supports BT 4.0 PXP profile.
Battery: 3450 mAh
Wireless communication
Display
Model and system
Power and battery
CPU
① Size and weight
Camera
Version: WLAN *WLAN + 3G
System: Android 4.2
60039; Z0AC *60040; Z0AD
Technical specifications
Back camera
Micro USB
Front camera
On/Off button
Volume up
Earphone jack *Micro SIM card slot
5
10
Receiver / Speaker 2
6
3
789
4
1
6
8
10
Volume down
3
5
7
9
2
1
4
Microphone
Free Tablet Stand
123
You can get a free tablet stand that is made of recyclable paper from
the packing box.
* The WLAN model ( Lenovo S5000-F ) does not have a Micro SIM card
slot.
First glance
Step 1. Insert the SIM eject tool into the hole on the Micro SIM card
tray.
Step 2. Pull out the Micro SIM card tray and place the Micro SIM card
in the tray.
Step 3. Carefully replace the tray.
You can use cellular services with the WLAN + 3G model (Lenovo
S5000-H) by inserting the Micro SIM card provided by your carrier
services. Install the Micro SIM card as shown.
Only Micro SIM cards work with your tablet and Micro SIM cards are for
mobile data only.
Do not insert or remove the SIM card while your tablet is turned on.
Doing so may permanently damage your Micro SIM card or tablet.
*Installing the Micro SIM card
Method 1. Connect your tablet to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
For more information about battery safety, see the Important Product
Information Guide.
2
1
Before using your tablet, you might need to charge the battery.
Charge the battery as shown.
Charging the battery
5SC9A463LO
Printed in China
Learn more
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be trademarks
or service marks of others.
First Edition (Sep.2013)
© Copyright Lenovo 2013.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or
software is delivered pursuant a General Services Administra-
tion “GSA” contract, use, reproduction, or disclosure is subject
to restrictions set forth in Contract No. GS-35F-05925.
For more information about your tablet functions, please refer
to the “Feature Guide” app in your tablet.
For “Regulatory Notices” and other useful manuals, please
access “User Guide” from the Browser favorites in your tablet.
Getting support
For support on network service and billing, please contact
your wireless network operator. For instructions on how to use
your tablet, go to http://support.lenovo.com/.
Radio and Telecommunications Terminal Equipment Directive
This product is in compliance with the essential requirements
and other relevant provisions of the Radio and Telecommuni-
cations Terminal Equipment Directive, 1999/5/EC.
