Processor Intel Celeron, Intel Pentium, or 6th Generation Intel Core™ i3 / i5 / i7 Processor
Processor Cores /
Threads
Frequency
Base/Max(GHz) Cache Memory Types Integrated
Graphics
Celeron G3900 2 / 2 2.8 G 2 MB DDR4-2133 HD 510
Pentium G4400 2 / 2 3.3G 3 MB DDR4-2133 HD 510
Core i3-6100 2 / 4 3.7 G 3 MB DDR4-2133 HD 530
Core i3-6320 2 / 4 3.9 G 4 MB DDR4-2133 HD 530
Core i5-6400 4 / 4 2.7 G / 3.3 G 6 MB DDR4-2133 HD 530
Core i5-6500 4 / 4 3.2 G / 3.6 G 6 MB DDR4-2133 HD 530
Core i7-6700 4 / 8 3.4 G / 4.0 G 8 MB DDR4-2133 HD 530
Memory 32GB max, UDIMM, DDR4 2133, two 288-pin DIMM sockets, dual-channel capable
Disk
Optical
Onboard SATA
Media reader
Some: SATA 6.0Gb/s, 3.5" Wide, 7200 rpm
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" Wide
Some: DVD-ROM DL SATA 1.5Gb/s Drive
Some: Super Multi-Burner DVD±RW SATA 1.5Gb/s Drive
Three onboard SATA 6.0Gb/s connectors (for HDD/SSD and ODD)
Optional 10-in-1 media reader
Graphics
DP cable
Intel HD Graphics 510/530 in processor, uses main memory, DirectX 12,
one VGA, one DisplayPort™, supports two independent displays, works along with
discrete graphics to support more displays;
Max resolution: 4096x2304 (DP)@60Hz; 1920x1200 (VGA)@60Hz
Some: NVIDIA Geforce GT 720, DirectX 12, 2GB, PCIe 3.0 x8 adapter,
one VGA, one HDMI, 25 watts;
Max resolution: 1920x1080 (HDMI)@60Hz; 2048x1536 (VGA)@85Hz
Some: NVIDIA Geforce GT 720, DirectX 12, 1GB, PCIe 3.0 x8 adapter,
one VGA, one HDMI, 25 watts;
Max resolution: 1920x1080 (HDMI)@60Hz; 2048x1536 (VGA)@85Hz
None
Chipset Intel H110 Chipset
Front ports
Rear ports
Rear audio ports
IEEE 1394
Two USB 3.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Two USB 3.0, two USB 2.0, serial (9-pin), ethernet (RJ-45), VGA, DisplayPort,
additional VGA or HDMI on optional graphic card on some models
Line-in (3.5mm), line-out (3.5mm), microphone (3.5mm)
None
Audio support High Definition (HD) Audio, Realtek ALC662 codec
WLAN13
Bluetooth™
Ethernet
Modem
Some: 11ac wireless, M.2 Card, Qualcomm Atheros QCA9377 (dual band),
Wi-Fi + Bluetooth 4.1 combo adapter, 1x1
Some: 11ac wireless, M.2 Card, Intel Dual Band Wireless-AC 3165,
Wi-Fi + Bluetooth 4.0 combo adapter, 1x1
Some: Bluetooth 4.0/4.1 wireless, integrated in Wi-Fi + Bluetooth combo adapter
One gigabit ethernet port, Realtek RTL8111GN, Wake on LAN
None
Manageability
Security chip
Security features
None
None
● One lock to secure both cover and
entire system to fixed object:
-Padlock loop (in rear for opt padlock)
-Security slot (in rear for optional
Kensington MicroSaver cable)
● Power-on password
● Administrator password
● Hard disk password
● Boot sequence control
● Boot without keyboard and mouse
● USB port disablement
Keyboard
Mouse Lenovo Slim USB Keyboard (USB connector), black, Lenovo logo
Enhanced Optical USB Mouse, black, Lenovo logo
Mechanical ● Tower (20L for chassis, 24L for chassis and front bezel), black color, metal case
● 6.3" W X 16.7" D X 15.5" H
● 160mm W X 424mm D X 394mm H
● 13.7 lb (6.2 kg) in maximum configuration
Bay 1: 5.25, 1.6" high, external, optical
Bay 2: 3.5", 1" high, internal, std disk
Bay 3: 3.5", 1" high, internal, std disk
Bay 4: N/A, N/A, access, opt reader
Slot 1: half-length, full-height, PCIe 3.0 x16
Slot 2: M.2 slot (for WLAN)
Power supply 180 watts, autosensing, 85% PSU
Limited warranty3Some: 1-year or 3-year, depot service
Some: 1-year or 3-year, limited onsite service
For Lenovo service upgrade options, please go to S-TC sheet
Preload Preloaded operating system
Some: Windows 10 Pro 64-bit
Some: Windows 10 Home 64-bit
Some: Windows 7 Professional 64 preinstalled through downgrade rights
in Windows 10 Pro 64-bit
Preloaded applications (only some listed)
● Lenovo Rescue System
● Driver and Application Installation
● Lenovo Solution Center
● Lenovo Bluetooth Lock
● Lenovo SHAREit
● McAfee LiveSafe™ (30-day trial)
● Microsoft Office preloaded;
purchase a product key to activate
● Lenovo Companion (Win10 only)
● Adobe Reader (Win7 only)
Environment ENERGY STAR 6.1(Need 85% PSU and Windows OS);
EPEAT Gold rating (only for US, need 85% PSU and Windows OS);
ErP Lot 3; GREENGUARD; RoHS-compliant
Accessories For compatible accessories, please go to http://www.lenovoquickpick.com/
Lenovo S510 Tower Platform Specifications Product Specifications Reference (PSREF)
See footnotes for more detailed information Lenovo
(Lenovo S510 Tower-Spec) April 2016
