Fru P/N Cru Id FRU Description

45N0473 1 Common Delta 45W 2pin CMN modified AC Adapter

45N0474 1 Common Liteon 45W 2pin CMN modified AC Adapter

45N0475 1 Common Chicony 45W 2pin CMN modified AC Adapter

45N0490 1 Common Delta 45W 3pin CMN modified AC Adapter

45N0491 1 Common Liteon 45W 3pin CMN modified AC Adapter

45N0492 1 Common Chicony 45W 3pin CMN modified AC Adapter

04W3784 N EM770

04W3793 N NFC

03X6601 N mini DP to VGA Adapter

04W3769 N intel WLAN Adapter

60Y3303 N Foxconn Bluetooth

60Y3305 N Liteon Bluetooth

00HM117 N WLAN antenna ASM

00HW105 N WLAN antenna ASM HT

45N1101 N Base Simplo 4cell

45N1103 N Tablet Simplo 3cell

04X0443 N RTC battery

00HM085 N Pln i3-3217U N-AMT Y-TPM Win8Pro Y-Digitizer

00HM086 N Pln i3-3217U N-AMT N-TPM Win8Pro Y-Digitizer

00HM087 N Pln i3-3217U N-AMT Y-TPM Win8Pro N-Digitizer

00HM088 N Pln i3-3217U N-AMT N-TPM Win8Pro N-Digitizer

00HM089 N Pln i3-3217U N-AMT Y-TPM Win8 Standard Y-Digitizer

00HM090 N Pln i3-3217U N-AMT N-TPM Win8 Standard Y-Digitizer

00HM091 N Pln i3-3217U N-AMT Y-TPM Win8 Standard N-Digitizer

00HM092 N Pln i3-3217U N-AMT N-TPM Win8 Standard N-Digitizer

00HM093 N Pln i3-3217U N-AMT Y-TPM No O/S Y-Digitizer

00HM094 N Pln i3-3217U N-AMT N-TPM No O/S Y-Digitizer

00HM095 N Pln i3-3217U N-AMT Y-TPM No O/S N-Digitizer

00HM096 N Pln i3-3217U N-AMT N-TPM No O/S N-Digitizer

04X0357 N Plni5-3427U Y-A Y-T W8Pro

04X0358 N Pln i5-3427U Y-A N-T W8Pro

04X0359 N Plni5-3317U N-A Y-T W8Pro

04X0360 N Plni5-3317U N-A N-T W8Pro

04X0363 N Plni5-3427U Y-A Y-T W8Std

04X0364 N Plni5-3427U Y-A N-T W8Std

04X0365 N Plni5-3317U N-A Y-T W8Std

04X0366 N Plni5-3317U N-A N-T W8Std

04X0369 N Plni5-3427U Y-A Y-T NoO/S

04X0370 N Plni5-3427U Y-A N-T NoO/S

04X0371 N Plni5-3317U N-A Y-T NoO/S

ThinkPad Helix FRU BOM; MT: 3697, 3698, 3700, 3701, 3702

AC ADAPTERS

ADAPTERS

ANTENNAS

BATTERIES

PLANARS

04X0372 N Plni5-3317U N-A N-T NoO/S

04X0711 N Plni5-3337U N-A Y-T W8Pro

04X0712 N Plni5-3337U N-A N-T W8Pro

04X0713 N Plni5-3337U N-A Y-T W8Std

04X0714 N Plni5-3337U N-A N-T W8Std

04X0715 N Plni5-3337U N-A Y-T NoO/S

04X0716 N Plni5-3337U N-A N-T NoO/S

04X0837 N Plni7-3667U Y-A Y-T W8Pro

04X0838 N Plni7-3667U Y-A N-T W8Pro

04X0839 N Plni7-3667U Y-A Y-T W8Std

04X0840 N Plni7-3667U Y-A N-T W8Std

04X0841 N Plni7-3667U Y-A Y-T NoO/S

04X0842 N Plni7-3667U Y-A N-T NoO/S

04X1623 N Plni7-3667U yA yT W8P N-D

04X1624 N Plni7-3667U yA nT W8P N-D

04X1625 N Plni5-3427U yA yT W8P N-D

04X1626 N Plni5-3427U yA nT W8P N-D

04X1627 N Plni5-3317U nA yT W8P N-D

04X1628 N Plni5-3317U nA nT W8P N-D

04X1629 N Plni5-3337U nA yT W8P N-D

04X1630 N Plni5-3337U nA nT W8P N-D

04X1631 N Plni7-3667U yA yT W8S N-D

04X1632 N Plni7-3667U yA nT W8S N-D

04X1633 N Plni5-3427U yA yT W8S N-D

04X1634 N Plni5-3427U yA nT W8S N-D

04X1635 N Plni5-3317U nA yT W8S N-D

04X1636 N Plni5-3317U nA nT W8S N-D

04X1637 N Plni5-3337U nA yT W8S N-D

04X1638 N Plni5-3337U nA nT W8S N-D

04X1639 N Plni7-3667U yAyT nO/S N-D

04X1640 N Plni7-3667U yAnT nO/S N-D

04X1641 N Plni5-3427U yAyT nO/S N-D

04X1642 N Plni5-3427U yAnT nO/S N-D

04X1643 N Plni5-3317U nAyT nO/S N-D

04X1644 N Plni5-3317U nAnT nO/S N-D

04X1645 N Plni5-3337U nAyT nO/S N-D

04X1646 N Plni5-3337U nAnT nO/S N-D

04X3790 N bulk kit Kensington lock bracket 10 pieces

04X0509 N DC-in Cable

04X0525 N Docking cable

04X6485 N LVDS fiat cable

04X6486 N Touch sensor flat cable

04X6487 N Digitizer flat cable

04Y0114 N OUT CAMERA CHY <PRIMARY>

04Y0115 N OUT CAMERA LTN <SECONDARY>

BRACKETS

CABLES

CAMERAS

04X0503 N Rear Cover Asm WiFi

04X0504 N Rear Cover Asm 3G

04X0505 N Rear Cover Asm LTE

04X0506 N Rear Cover Asm WiFi NFC

04X0507 N Rear Cover Asm 3G NFC

04X0508 N Rear Cover Asm LTE NFC

04X0510 N SIM Tray

04X0520 N Bottom Cover Asm

04X0521 N Back Cover Asm

04X0522 N Hinge Mg Cover Asm

04Y2139 N mSATA 128GB Micron

04Y2141 N mSATA 256GB Micron

45N8399 N mSATA 128GB Toshiba <SECONDARY>

45N8401 N mSATA 256GB Toshiba <SECONDARY>

45N8461 N mSATA 180GB Intel

04X0431 N Thermal module for Pad

04X4699 N Thermal module for Base

04X0523 N Hinge

03X6583 N Helix Keyboard Dock-US

03X6843 N Helix keyboard base - French

03X6844 N Helix keyboard base - UK English

03X6845 N Helix keyboard base - German

04X0627 1 KBD USE CHY <PRIMARY>

04X0628 1 KBD CFR CHY <PRIMARY>

04X0629 1 KBD ARA CHY <PRIMARY>

04X0630 1 KBD BEL CHY <PRIMARY>

04X0631 1 KBD CZH CHY <PRIMARY>

04X0632 1 KBD DEN CHY <PRIMARY>

04X0633 1 KBD SPA CHY <PRIMARY>

04X0634 1 KBD FRA CHY <PRIMARY>

04X0635 1 KBD GER CHY <PRIMARY>

04X0636 1 KBD GRK CHY <PRIMARY>

04X0637 1 KBD HGN CHY <PRIMARY>

04X0638 1 KBD HBW CHY <PRIMARY>

04X0639 1 KBD ITA CHY <PRIMARY>

04X0640 1 KBD NET CHY <PRIMARY>

04X0641 1 KBD NOR CHY <PRIMARY>

04X0642 1 KBD POL CHY<PRIMARY>

04X0643 1 KBD POR CHY <PRIMARY>

04X0644 1 KBD RUS CHY <PRIMARY>

04X0645 1 KBD SLK CHY <PRIMARY>

04X0646 1 KBD SCB CHY <PRIMARY>

THERMALS

COVERS

HDD'S

HINGES

KEYBOARD DOCKS

KEYBOARDS

04X0647 1 KBD SWE CHY <PRIMARY>

04X0648 1 KBD SWS CHY <PRIMARY>

04X0649 1 KBD TUR CHY <PRIMARY>

04X0650 1 KBD UKE CHY <PRIMARY>

04X0651 1 KBD USI CHY <PRIMARY>

04X0652 1 KBD ICE CHY <PRIMARY>

04X0653 1 KBD BUL CHY <PRIMARY>

04X0655 1 KBD TWN CHY <PRIMARY>

04X0656 1 KBD THA CHY <PRIMARY>

04X0657 1 KBD KOR CHY <PRIMARY>

04X0658 1 KBD IND CHY <PRIMARY>

04X0659 1 KBD LAS CHY <PRIMARY>

04X0660 1 KBD BRA CHY <PRIMARY>

04X0661 1 KBD CFA CHY <PRIMARY>

04X0662 1 KBD CFB CHY <PRIMARY>

04X0663 1 KBD USE SRX <SECONDARY>

04X0664 1 KBD CFR SRX <SECONDARY>

04X0665 1 KBD ARA SRX <SECONDARY>

04X0666 1 KBD BEL SRX <SECONDARY>

04X0667 1 KBD CZH SRX <SECONDARY>

04X0668 1 KBD DEN SRX <SECONDARY>

04X0669 1 KBD SPA SRX <SECONDARY>

04X0670 1 KBD FRA SRX <SECONDARY>

04X0671 1 KBD GER SRX <SECONDARY>

04X0672 1 KBD GRK SRX <SECONDARY>

04X0673 1 KBD HGN SRX <SECONDARY>

04X0674 1 KBD HBW SRX <SECONDARY>

04X0675 1 KBD ITA SRX <SECONDARY>

04X0676 1 KBD NET SRX <SECONDARY>

04X0677 1 KBD NOR SRX <SECONDARY>

04X0678 1 KBD POL SRX <SECONDARY>

04X0679 1 KBD POR SRX <SECONDARY>

04X0680 1 KBD RUS SRX <SECONDARY>

04X0681 1 KBD SLK SRX <SECONDARY>

04X0682 1 KBD SCB SRX <SECONDARY>

04X0683 1 KBD SWE SRX <SECONDARY>

04X0684 1 KBD SWS SRX <SECONDARY>

04X0685 1 KBD TUR SRX <SECONDARY>

04X0686 1 KBD UKE SRX <SECONDARY>

04X0687 1 KBD USI SRX <SECONDARY>

04X0688 1 KBD ICE SRX <SECONDARY>

04X0689 1 KBD BUL SRX <SECONDARY>

04X0691 1 KBD TWN SRX <SECONDARY>

04X0692 1 KBD THA SRX <SECONDARY>

04X0693 1 KBD KOR SRX <SECONDARY>

04X0694 1 KBD IND SRX <SECONDARY>

04X0695 1 KBD LAS SRX <SECONDARY>

04X0696 1 KBD BRA SRX <SECONDARY>

04X0697 1 KBD CFA SRX <SECONDARY>

04X0698 1 KBD CFB SRX <SECONDARY>

04X0527 N Label kit

42T5004 1 US/Canada-1.0M

42T5008 1 US/Canada-1.0M

42T5014 1 Japan-1.0M

42T5020 1 Argentina-1.0M

42T5029 1 Europe-1.0M

42T5035 1 UK-1.0M

42T5041 1 Denmark-1.0M

42T5044 1 SWS-1.0M

42T5047 1 Italy-1.0M

42T5050 1 ANZ-1.0M

42T5056 1 SA-1.0M

42T5062 1 Israel-1.0M

42T5065 1 China-1.0M

42T5071 1 Taiwan-1.0M

42T5077 1 Korea-1.0M

42T5083 1 India-1.0M

42T5180 1 Brazil-1.0M 2p

42T5089 1 US/CA,1M,3P,NON-LH,VLX

42T5093 1 US/CA,1M,2P,NON-LH,VLX

42T5099 1 JP,1M,2P,NON-LH,VLX

42T5105 1 AR,1M,2P,NON-LH,VLX

42T5114 1 EU,1M,3P,NON-LH,VLX

42T5120 1 GB,1M,3P,NON-LH,VLX

42T5126 1 DK,1M,3P,NON-LH,VLX

42T5129 1 CH,1M,3P,NON-LH,VLX

42T5132 1 IT,1M,3P,NON-LH,VLX

42T5135 1 AU,1M,3P,NON-LH,VLX

42T5141 1 ZA,1M,3P,NON-LH,VLX

42T5147 1 IL,1M,3P,NON-LH,VLX

42T5150 1 CN,1M,3P,NON-LH,VLX

42T5156 1 TW,1M,3P,NON-LH,VLX

42T5162 1 KR,1M,3P,NON-LH,VLX

42T5168 1 IN,1M,3P,NON-LH,VLX

42T5183 1 BR,1M,2P,NON-LH,VLX

45N0129 1 US/CA,1M,3P,NON-LH,LUX

45N0130 1 US/CA,1M,2P,NON-LH,LUX

45N0131 1 CN,1M,3P,NON-LH,LUX

45N0377 1 CN,1M,3P,NON-LH,LTK

45N0379 1 DK,1M,3P,NON-LH,LTK

45N0380 1 CH,1M,3P,NON-LH,LTK

45N0382 1 IL,1M,3P,NON-LH,LTK

45N0383 1 US/CA,1M,3P,NON-LH,LTK

45N0384 1 GB,1M,3P,NON-LH,LTK

LABELS

LINE CORDS

45N0385 1 IN,1M,3P,NON-LH,LTK

45N0386 1 IT,1M,3P,NON-LH,LTK

45N0387 1 KR,1M,3P,NON-LH,LTK

45N0388 1 AU,1M,3P,NON-LH,LTK

45N0389 1 TW,1M,3P,NON-LH,LTK

45N0391 1 ZA,1M,3P,NON-LH,LTK

45N0392 1 EU,1M,3P,NON-LH,LTK

45N0394 1 AR,1M,2P,NON-LH,LTK

45N0397 1 BR,1M,2P,NON-LH,LTK

45N0399 1 US/CA,1M,2P,NON-LH,LTK

45N0406 1 JP,1M,2P,NON-LH,LTK

45N0410 1 DK,1M,3P,NON-LH,LUX

45N0411 1 CH,1M,3P,NON-LH,LUX

45N0413 1 IL,1M,3P,NON-LH,LUX

45N0414 1 GB,1M,3P,NON-LH,LUX

45N0416 1 IT,1M,3P,NON-LH,LUX

45N0417 1 KR,1M,3P,NON-LH,LUX

45N0418 1 AU,1M,3P,NON-LH,LUX

45N0419 1 TW,1M,3P,NON-LH,LUX

45N0421 1 ZA,1M,3P,NON-LH,LUX

45N0422 1 EU,1M,3P,NON-LH,LUX

45N0423 1 AR,1M,2P,NON-LH,LUX

45N0426 1 BR,1M,2P,NON-LH,LUX

45N0434 1 JP,1M,2P,NON-LH,LUX

00HM496 N Pad Misc kit

00HM497 N Base Misc kit

00HM498 N NFC module

00HT110 N ThinkPad Helix Keyboard C-Cover w/Keyboard Japanese

04X0373 N AUO 11.6 FHD LCD+Touch

04X0374 N AUO11.6FHD LCD+Touch+Dig

04X0381 1 Stylus Pen

04X3921 N WWAN Misc kit

00EU471 1 DVD Win8x64 CT/EN

00EU472 1 DVD Win8x64 CZ/EN

00EU473 1 DVD Win8x64 EI

00EU474 1 DVD Win8x64 FR

00EU475 1 DVD Win8x64 GK/EN

00EU476 1 DVD Win8x64 GR

00EU477 1 DVD Win8x64 HB/EN

00EU478 1 DVD Win8x64 HK/EN

00EU479 1 DVD Win8x64 HU/EN

00EU480 1 DVD Win8x64 JP

00EU481 1 DVD Win8x64 KR/EN

00EU482 1 DVD Win8x64 PL

00EU483 1 DVD Win8x64 PO/EN

00EU484 1 DVD Win8x64 RO/EN

RECOVERY MEDIA

MECHANICALS

00EU485 1 DVD Win8x64 SK/EN

00EU486 1 DVD Win8x64 SP

00EU487 1 DVD Win8x64 US

00EU488 1 DVD Win8x64 C&L EMEA

00EU489 1 DVD Win8x64 C&L Nordics

00EU490 1 DVD Win8x64 C&L SL/CR/EN

00EU491 1 DVD Win8x64 UD

00EU492 1 DVD Win8PROx64 AR/EN

00EU493 1 DVD Win8PROx64 BR

00EU494 1 DVD Win8PROx64 CS

00EU495 1 DVD Win8PROx64 CT/EN

00EU496 1 DVD Win8PROx64 CZ/EN

00EU497 1 DVD Win8PROx64 EI

00EU498 1 DVD Win8PROx64 FR

00EU499 1 DVD Win8PROx64 GK/EN

00EU500 1 DVD Win8PROx64 GR

00EU501 1 DVD Win8PROx64 HB/EN

00EU502 1 DVD Win8PROx64 HK/EN

00EU503 1 DVD Win8PROx64 HU/EN

00EU504 1 DVD Win8PROx64 JP

00EU504 1 DVD Win8PROx64 JP

00EU505 1 DVD Win8PROx64 KR/EN

00EU506 1 DVD Win8PROx64 PL

00EU507 1 DVD Win8PROx64 PO/EN

00EU508 1 DVD Win8PROx64 RO/EN

00EU509 1 DVD Win8PROx64 RU

00EU510 1 DVD Win8PROx64 SK/EN

00EU511 1 DVD Win8PROx64 SP

00EU512 1 DVD Win8PROx64 SR/EN

00EU513 1 DVD Win8PROx64 TR/EN

00EU514 1 DVD Win8PROx64 US

00EU514 1 DVD Win8PROx64 US

00EU515 1 DVD Win8PROx64 C&L EMEA

00EU516 1 DVD Win8PROx64 C&L Nordics

00EU517 1 DVD Win8PROx64 C&L SL/CR/EN

00EU518 1 DVD Win8PROx64 UD

00EU519 1 DVD Win8SLx64 AR/EN

00EU520 1 DVD Win8SLx64 BR

00EU521 1 DVD Win8SLx64 EI

00EU522 1 DVD Win8SLx64 FR

00EU523 1 DVD Win8SLx64 PO/EN

00EU524 1 DVD Win8SLx64 RU

00EU525 1 DVD Win8SLx64 SP

00EU526 1 DVD Win8SLx64 SR/EN

00EU527 1 DVD Win8SLx64 TR/EN

00EU528 1 DVD Win8SLx64 US

00EU529 1 DVD Win8CNx64 CS

00EV089 1 DVD Win8x64 AR/EN

04X4418 N Lenovo SSD mSATAFRUSSD 180GB Intel mSATA Sierra Star-180

04Y2102 N Lenovo SSD mSATA FRU SSD 128GB Toshiba HG5d-128 - Primary

04Y2103 N Lenovo SSD mSATA FRU SSD 256GB Toshiba mSATA HG5d-256 - Primary

04Y2177 N Lenovo SSD mSATA FRU SSD 128GB Samsung mSATA PM841-128

04Y2179 N Lenovo SSD mSATA FRU SSD 256GB Samsung mSATA PM841-256 - Secondary

04X0511 N I/O Board

04X0524 N Keyboard Dock I/O Board

04X3784 N USB 2.0 Ethernet Adapter

04X3797 N Ericsson C5621

04X6005 N Intel Taylor Peak SFF 2*2 11abgn WLAN Indonesia SKU

SSD'S

WIRELESS AND SUBCARDS
