Lenovo Tp Helix Fru Bom 20150209 User Manual X140e Laptop (Think Pad) Type 20BL
1970-01-01
User Manual: Lenovo Tp Helix Fru Bom 20150209 X140e Laptop (ThinkPad) - Type 20BL ThinkPad X140e, 20BL
Open the PDF directly: View PDF
.
Page Count: 6
PN CRU ID Description
45N0290 1 Common Delta 45W 3pin <PRIMARY>
45N0292 1 Common Delta 45W 2pin <PRIMARY>
45N0294 1 Common Liteon 45W 3pin <SECONDARY>
45N0296 1 Common Liteon 45W 2pin <SECONDARY>
45N0298 1 Common Chicony 45W 3pin <SECONDARY>
45N0300 1 Common Chicony 45W 2pin <SECONDARY>
60Y3303 N Bluetooth Card - Foxconn
60Y3305 N Bluetooth Card - Liteon
04W3824 N Bluetooth Card 4.0 Brazil PPB
04W3769 N Intel WLAN Adapter
04W3793 N NFC WLAN Module
04X3797 N Ericsson C5621gw WWAN LGA Module
04W3784 N Sierra EM7700 WWAN Module
03X6601 1 Mini Display Port to VGA Adapter
04W6947 1 USB 2.0 Ethernet Adapter - External Cable
04X0511 N Tablet I/O Board
04X0524 N Keyboard Dock I/O Board
45N1101 N Base Built-in Battery, Simplo 4cell
45N1103 N Tablet Built-in Battery, Simplo 3cell
04X0443 N Backup Battery
04X0357 N Planar i5-3427U with AMT, TPM and Digitizer; Win 8 Pro
04X0358 N Planar i5-3427U with AMT and Digitizer; Win 8 Pro
04X0359 N Planar i5-3317U with TPM and Digitizer; Win 8 Pro
04X0360 N Planar i5-3317U with Digitizer; Win 8 Pro
04X0363 N Planar i5-3427U with AMT, TPM and Digitizer; Win 8 Std
04X0364 N Planar i5-3427U with AMT and Digitizer; Win 8 Std
04X0365 N Planar i5-3317U with TPM and Digitizer; Win 8 Std
04X0366 N Planar i5-3317U with Digitizer; Win 8 Std
04X0369 N Planar i5-3427U with AMT, TPM and Digitizer; No O/S
04X0370 N Planar i5-3427U with AMT and Digitizer; No O/S
04X0371 N Planar i5-3317U with TPM and Digitizer; No O/S
04X0372 N Planar i5-3317U with Digitizer; No O/S
04X0711 N Planar i5-3337U with TPM and Digitizer; Win 8 Pro
04X0712 N Planar i5-3337U with Digitizer; Win 8 Pro
04X0713 N Planar i5-3337U with TPM and Digitizer; Win 8 Std
04X0714 N Planar i5-3337U with Digitizer; Win 8 Std
04X0715 N Planar i5-3337U with TPM and Digitizer; No O/S
SUBCARDS
ThinkPad Helix, MT 3697, 3701
POWER ADAPTERS
BATTERIES
PLANARS WITH DIGITIZER
BLUETOOTH CARDS
WIRELESS LAN CARDS
WIRELESS WAN CARDS
ADAPTERS
04X0716 N Planar i5-3337U with Digitizer; No O/S
04X0837 NPlanar i7-3667U with AMT, TPM and Digitizer; Win 8 Pro
04X0838 NPlanar i7-3667U with AMT and Digitizer; Win 8 Pro
04X0839 NPlanar i7-3667U with AMT, TPM and Digitizer; Win 8 Std
04X0840 NPlanar i7-3667U with AMT and Digitizer; Win 8 Std
04X0841 NPlanar i7-3667U with AMT, TPM and Digitizer; No O/S
04X0842 NPlanar i7-3667U with AMT and Digitizer; No O/S
04X1623 N Planar i7-3667U with AMT, TPM; No Digitizer; Win 8 Pro
04X1624 N Planar i7-3667U with AMT; No Digitizer; Win 8 Pro
04X1625 N Planar i5-3427U with AMT and TPM; No Digitizer; Win 8 Pro
04X1626 N Planar i5-3427U with AMT; No Digitizer; Win 8 Pro
04X1627 N Planar i5-3317U with TPM; No Digitizer; Win 8 Pro
04X1628 N Planar i5-3317U No Digitizer; Win 8 Pro
04X1629 N Planar i5-3337U with TPM; No Digitizer; Win 8 Pro
04X1630 N Planar i5-3337U No Digitizer; Win 8 Pro
04X1631 N Planar i7-3667U with AMT and TPM; No Digitizer; Win 8 Std
04X1632 N Planar i7-3667U with AMT; No Digitizer; Win 8 Std
04X1633 N Planar i5-3427U with AMT and TPM; No Digitizer; Win 8 Std
04X1634 N Planar i5-3427U with AMT; No Digitizer; Win 8 Std
04X1635 N Planar i5-3317U with TPM; No Digitizer; Win 8 Std
04X1636 N Planar i5-3317U No Digitizer; Win 8 Std
04X1637 N Planar i5-3337U with TPM; No Digitizer; Win 8 Std
04X1638 N Planar i5-3337U No Digitizer; Win 8 Std
04X1639 N Planar i7-3667U with AMT and TPM; No Digitizer; No O/S
04X1640 N Planar i7-3667U with AMT; No Digitizer; No O/S
04X1641 N Planar i5-3427U with AMT and TPM; No Digitizer; No O/S
04X1642 N Planar i5-3427U with AMT; No Digitizer; No O/S
04X1643 N Planar i5-3317U with TPM; No Digitizer; No O/S
04X1644 N Planar i5-3317U No Digitizer; No O/S
04X1645 N Planar i5-3337U with TPM; No Digitizer; No O/S
04X1646 N Planar i5-3337U No Digitizer; No O/S
04X0509 N DC-in Cable Assembly (including cable and bracket)
04X0525 N Dock Connectors and Cables (inludes both left and right cables)
04Y0114 N Camera Assembly with Cable; Chicony <PRIMARY>
04Y0115 N Camera Assembly with Cable; LiteOn <SECONDARY>
04X0503 N Tablet base cover assembly with WiFi Antenna
04X0504 N Tablet base cover assembly with 3G Antenna
04X0505 N Tablet base cover assembly with LTE Antenna
04X0506 N Tablet base cover assembly with WiFi/NFC Antenna
04X0507 N Tablet base cover assembly with 3G/NFC Antenna
04X0508 N Tablet base cover assembly with LTE/NFC Antenna
04X0510 N SIM Card Tray
04X0520 N Base Cover
CAMERAS
TABLET COVERS (includes speakers, label trays, and wireless antennas)
PLANARS WITH NO DIGITIZER
CABLES
KEYBOARD DOCK COVERS
04X0521 N Dock and Hinge assembly back cover
04X0522 N dock and hinge assembly
04Y2139 N mSATA 128GB Micron <PRIMARY>
45N8399 N mSATA 128GB Toshiba <SECONDARY>
04Y2141 N mSATA 256GB Micron <PRIMARY>
45N8401 N mSATA 256GB Toshiba <SECONDARY>
45N8461 N mSATA 180GB Intel
04X0431 N Tablet Thermal/Fan Assembly (fan cable included)
04X0432 N Thermal Fan Assembly for Keyboard Dock (fan cable included)
04X0523 N Hinge (single hinge included)
03X6843 N FRU for Helix complete keyboard base - French
03X6844 N FRU for Helix complete keyboard base - UK English
03X6845 N FRU for Helix complete keyboard base – German
03X6583 N FRU for Helix complete keyboard base – US English
04X0627 N KBD USE CHY <PRIMARY>
04X0628 N KBD CFR CHY <PRIMARY>
04X0629 N KBD ARA CHY <PRIMARY>
04X0630 N KBD BEL CHY <PRIMARY>
04X0631 N KBD CZH CHY <PRIMARY>
04X0632 N KBD DEN CHY <PRIMARY>
04X0633 N KBD SPA CHY <PRIMARY>
04X0634 N KBD FRA CHY <PRIMARY>
04X0635 N KBD GER CHY <PRIMARY>
04X0636 N KBD GRK CHY <PRIMARY>
04X0637 N KBD HGN CHY <PRIMARY>
04X0638 N KBD HBW CHY <PRIMARY>
04X0639 N KBD ITA CHY <PRIMARY>
04X0640 N KBD NET CHY <PRIMARY>
04X0641 N KBD NOR CHY <PRIMARY>
04X0642 N KBD POL CHY<PRIMARY>
04X0643 N KBD POR CHY <PRIMARY>
04X0644 N KBD RUS CHY <PRIMARY>
04X0645 N KBD SLK CHY <PRIMARY>
04X0646 N KBD SCB CHY <PRIMARY>
04X0647 N KBD SWE CHY <PRIMARY>
04X0648 N KBD SWS CHY <PRIMARY>
04X0649 N KBD TUR CHY <PRIMARY>
04X0650 N KBD UKE CHY <PRIMARY>
04X0651 N KBD USI CHY <PRIMARY>
04X0652 N KBD ICE CHY <PRIMARY>
04X0653 N KBD BUL CHY <PRIMARY>
04X0654 N KBD JPN CHY <PRIMARY>
04X0655 N KBD TWN CHY <PRIMARY>
mSATA DRIVES
THERMAL ASSEMBLIES
HINGES
KEYBOARDS
KEYBOARD BASE ASSEMBLIES
04X0656 N KBD THA CHY <PRIMARY>
04X0657 N KBD KOR CHY <PRIMARY>
04X0658 N KBD IND CHY <PRIMARY>
04X0659 N KBD LAS CHY <PRIMARY>
04X0660 N KBD BRA CHY <PRIMARY>
04X0661 N KBD CFA CHY <PRIMARY>
04X0662 N KBD CFB CHY <PRIMARY>
04X0663 N KBD USE SRX <SECONDARY>
04X0664 N KBD CFR SRX <SECONDARY>
04X0665 N KBD ARA SRX <SECONDARY>
04X0666 N KBD BEL SRX <SECONDARY>
04X0667 N KBD CZH SRX <SECONDARY>
04X0668 N KBD DEN SRX <SECONDARY>
04X0669 N KBD SPA SRX <SECONDARY>
04X0670 N KBD FRA SRX <SECONDARY>
04X0671 N KBD GER SRX <SECONDARY>
04X0672 N KBD GRK SRX <SECONDARY>
04X0673 N KBD HGN SRX <SECONDARY>
04X0674 N KBD HBW SRX <SECONDARY>
04X0675 N KBD ITA SRX <SECONDARY>
04X0676 N KBD NET SRX <SECONDARY>
04X0677 N KBD NOR SRX <SECONDARY>
04X0678 N KBD POL SRX <SECONDARY>
04X0679 N KBD POR SRX <SECONDARY>
04X0680 N KBD RUS SRX <SECONDARY>
04X0681 N KBD SLK SRX <SECONDARY>
04X0682 N KBD SCB SRX <SECONDARY>
04X0683 N KBD SWE SRX <SECONDARY>
04X0684 N KBD SWS SRX <SECONDARY>
04X0685 N KBD TUR SRX <SECONDARY>
04X0686 N KBD UKE SRX <SECONDARY>
04X0687 N KBD USI SRX <SECONDARY>
04X0688 N KBD ICE SRX <SECONDARY>
04X0689 N KBD BUL SRX <SECONDARY>
04X0690 N KBD JPN SRX <SECONDARY>
04X0691 N KBD TWN SRX <SECONDARY>
04X0692 N KBD THA SRX <SECONDARY>
04X0693 N KBD KOR SRX <SECONDARY>
04X0694 N KBD IND SRX <SECONDARY>
04X0695 N KBD LAS SRX <SECONDARY>
04X0696 N KBD BRA SRX <SECONDARY>
04X0697 N KBD CFA SRX <SECONDARY>
04X0698 N KBD CFB SRX <SECONDARY>
42T5004 1 US/Canada-1.0M
42T5008 1 US/Canada-1.0M
42T5014 1 Japan-1.0M
42T5020 1 Argentina-1.0M
LINE CORDS
42T5029 1 Europe-1.0M
42T5035 1 UK-1.0M
42T5041 1 Denmark-1.0M
42T5044 1 SWS-1.0M
42T5047 1 Italy-1.0M
42T5050 1 ANZ-1.0M
42T5056 1 SA-1.0M
42T5062 1 Israel-1.0M
42T5065 1 China-1.0M
42T5071 1 Taiwan-1.0M
42T5077 1 Korea-1.0M
42T5083 1 India-1.0M
42T5180 1 Brazil-1.0M 2p
04X0373 N AUO 11.6 FHD LCD + Touch
04X0374 N AUO 11.6FHD LCD + Touch + Digitizer
04X0381 1 Tablet Digitizer Stylus Pen
04T8739 1 Win8_64 CT/EN
04T8740 1 Win8_64 CZ/EN
04T8741 1 Win8_64 EI
04T8742 1 Win8_64 FR
04T8743 1 Win8_64 GK/EN
04T8744 1 Win8_64 GR
04T8745 1 Win8_64 HB/EN
04T8746 1 Win8_64 HK/EN
04T8747 1 Win8_64 HU/EN
04T8748 1 Win8_64 JP
04T8749 1 Win8_64 KR/EN
04T8750 1 Win8_64 PL
04T8751 1 Win8_64 PO/EN
04T8752 1 Win8_64 RO/EN
04T8753 1 Win8_64 SK/EN
04T8754 1 Win8_64 SP
04T8755 1 Win8_64 UD
04T8756 1 Win8_64 US
04T8757 1 Win8_64 C&L Nordics
04T8758 1 Win8_64 C&L EMEA
04T8759 1 Win8_64 C&L Croatian
04T8760 1 Win8Pro64 AR/EN
04T8761 1 Win8Pro64 BR
04T8762 1 Win8Pro64 CS
04T8763 1 Win8Pro64 CT/EN
04T8764 1 Win8Pro64 CZ/EN
04T8765 1 Win8Pro64 EI
04T8766 1 Win8Pro64 FR
04T8767 1 Win8Pro64 GK/EN
LCD'S (includes LCD cable and LCD Bezel)
DIGITIZER PEN
RECOVERY MEDIA
04T8768 1 Win8Pro64 GR
04T8769 1 Win8Pro64 HB/EN
04T8770 1 Win8Pro64 HK/EN
04T8771 1 Win8Pro64 HU/EN
04T8772 1 Win8Pro64 JP
04T8773 1 Win8Pro64 KR/EN
04T8774 1 Win8Pro64 PL
04T8775 1 Win8Pro64 PO/EN
04T8776 1 Win8Pro64 RO/EN
04T8777 1 Win8Pro64 RU
04T8778 1 Win8Pro64 SK/EN
04T8779 1 Win8Pro64 SP
04T8780 1 Win8Pro64 SR/EN
04T8781 1 Win8Pro64 TR/EN
04T8782 1 Win8Pro64 UD
04T8783 1 Win8Pro64 US
04T8784 1 Win8Pro64 C&L Nordics
04T8785 1 Win8Pro64 C&L EMEA
04T8786 1 Win8Pro64 C&L Croatian
04T8787 1 Win8SL64 AR/EN
04T8788 1 Win8SL64 BR
04T8789 1 Win8SL64 EI
04T8790 1 Win8SL64 FR
04T8791 1 Win8SL64 PO/EN
04T8792 1 Win8SL64 RU
04T8793 1 Win8SL64 SP
04T8794 1 Win8SL64 SR/EN
04T8795 1 Win8SL64 TR/EN
04T8796 1 Win8SL64 US
04T8797 1 Win8China64 CS
04X0527 N Label kit for bottom cover (shipped with base cover; can be ordered separately)
04X0519 N Pad Miscellaneous kit
04X0526 N Base Assembly Misc kit
04X3790 N Kensington Lock Bar (includes 10 lock bars)
MISC AND OTHER
