Overview for ThinkPad Thunderbolt 3 Dock (40AC0135WW)

The ThinkPad Thunderbolt 3 Dock is a pioneering, 13 port docking solution

powered by Intel Thunderbolt™ technology. Now, you can connect and rapidly

charge like never before via a USB Type-CTM port all while experiencing

complete control of your workstation and essential accessories. The dock not

only lets you transfer data at lightning fast speeds, but also gives you the option

to display and share your files in vibrant 4k resolution. Having your most

productive and innovative workstation to date is as simple as connecting your

system to the dock.

Features and benefits:

A Power Hub on Your Desk

Experience stable, reliable, and continuous power for your laptop and mobile

devices – with the Thunderbolt port and always-power-on USB 3.0 port. Plus

perfect pairing for ThinkPad X1 rapid charging.

Need to see detail while multi-tasking?

Enjoy UHD video experience with dual video output or with up to three FHD

displays for multi-tasking with ease.

All Your Peripherals – Just How You Want Them

Displays, Gigabit Ethernet, speakers and other USB peripherals – get immediate

connection to peripherals with a single cable.

Lightning Fast Big Data Transfer

The front Thunderbolt port offers up to 40Gbps data transfer speeds – 4 times

faster than the average dock for larger files such as video editing or CAD files.

Enterprise IT Companion

Now it’s easier for your IT team to manage selected ThinkPad systems with

solutions such as PXE boot, and Wake-On LAN. Plus, it also support passing

ThinkPad MAC address through the dock for the IT to identify the system –

adding an extra level of safety against unauthorized users, and boosting your

network security.

To find more information about docks, please visit:

http://www.lenovo.com/support/docks

For the latest compatible systems, please visit the Accessories Compatibility

Guide:

http://www.lenovo.com/accessoriesguide

2

SPECIFICATIONS

PHYSICAL SPECIFICATIONS

 Approximate height: 30 mm (1.18 in)

 Approximate width: 220 mm (8.66 in)

 Approximate depth: 80 mm (3.15 in)

 Approximate weight: 250 g (0.55 lb)

 Thunderbolt 3 cable length: 500mm (1.97 in)

 Approximate height when packaged in box: 90 mm (3.54 in)

 Approximate width when packaged in box: 268mm (10.55 in)

 Approximate depth when packaged in box: 165 mm (6.5 in)

 Approximate weight when packaged in box: 1100g (2.43lb)

OPERATING ENVIRONMENT

 Temperature: 5 deg to 40 deg C (41 deg to 104 deg (F))

 Relative humidity: 5% to 95%

STORAGE ENVIRONMENT

 Temperature: -20 deg to 60 deg C (-4 deg to 140 deg (F))

 Relative humidity: 5% to 95%

AGENCY APPROVALS

 CB

 cULus(US/Canada)

 BSMI(TW)

 NOM(Mexico)

 CU EAC

 FCC(USA)/ICES(Canada)

 CE-EMC, TUV mark(Europe)

 VCCI(Japan)

 KCC(Korea)

 RCM(Australia)

 Ukraine DoC

 Serbia Kvalitet

 COC(Saudi Arabia)

 SABS LoA(South Africa)

 Israel SII

3

CABLE ORDERS REQUIRED: No

INSTALLATION TIME: Approximately five minutes

PACKAGING: One plain brown box

SHIPMENT GROUP

Plain brown box:

 The ThinkPad Thunderbolt 3 Dock

 135W slim tip AC Power adapter

 Power cord

 Thunderbolt 3 Cable

 Setup Poster

WARRANTY TERMS

3 Year

CHARGES - FRU PARTS

Field Replaceable Units (FRU)

- Thunderbolt 3 cable: 03X7134

Product Name

Dock

FRU PN

Power

Adapter

FRU

Power Line

Cord FRU

H

CRU

Option PN

ThinkPad Thunderbolt 3

Dock-US, CAN,MX

03X7133

45N0556

42T5008

R

YES

40AC0135U

S

ThinkPad Thunderbolt 3

Dock - Argentina

03X7133

45N0556

42T5020

R

YES

40AC0135A

R

ThinkPad Thunderbolt 3

Dock- Brazil

03X7133

45N0556

42T5180

R

YES

40AC0135B

R

ThinkPad Thunderbolt 3

Dock- JP

03X7133

45N0556

04T0753

R

YES

40AC0135JP

ThinkPad Thunderbolt 3

Dock- EU/INA/ROK

03X7133

45N0554

42T5029

R

YES

40AC0135E

U

ThinkPad Thunderbolt 3

Dock- Denmark

03X7133

45N0554

42T5041

R

YES

40AC0135D

K

ThinkPad Thunderbolt 3

Dock- India

03X7133

45N0554

42T5083

R

YES

40AC0135IN

ThinkPad Thunderbolt 3

Dock- SA/Srilanka/Bang

ladesh

03X7133

45N0554

42T5056

R

YES

40AC0135SA

4

ThinkPad Thunderbolt 3

Dock-

UK/HK/MY/SGP/Sandi

Arabia

03X7133

45N0554

42T5035

R

YES

40AC0135U

K

ThinkPad Thunderbolt 3

Dock- Switzerland

03X7133

45N0554

42T5044

R

YES

40AC0135C

H

ThinkPad Thunderbolt 3

Dock- Italy/Chile

03X7133

45N0554

42T5047

R

YES

40AC0135IT

ThinkPad Thunderbolt 3

Dock-Israel

03X7133

45N0554

42T5062

R

YES

40AC0135IS

ThinkPad Thunderbolt 3

Dock- ANZ/Fuji/Papa new

guinea

03X7133

45N0554

42T5050

R

YES

40AC0135A

U

ThinkPad Thunderbolt 3

Dock- China

03X7133

45N0554

42T5065

R

YES

40AC0135C

N

ThinkPad Thunderbolt 3

Dock-

Taiwan/TH/Phillipines/Gua

m

03X7133

45N0554

42T5071

R

YES

40AC0135T

W

The following Web link can be used to see the list of current service

http://www.lenovo.com/support
