Overview for ThinkPad X1 Tablet Thin Keyboard (4X30L07457)

ThinkPad X1 Tablet, the best 2-in-1 for Business with Modular Accessories. Get

more features and functions. Easily install and setup.

ThinkPad X1 Tablet Thin Keyboard is a thin mechanical, full QWERTY keyboard,

with three colors: Black, Silver and Red.

Key Features:

 Thickness: 5.0mm

 TrackPoint with 3.5mm height(will be separated option)

 6pin Pogo connector, living hinge interface

 3+2 Button clickpad w/multi touch

 One pen holder to support Active Pen

 White Back light LED

 Supporting 3 Keyboard positions with modules(ThinkPad X1 Tablet

Productivity Module; Presenter Module and 3D Imaging Module)

-High angle

-Typing angle

-Flat angle

TECHNICAL INFORMATION

Key stroke

1x1 key and Other Key

1.35 ± 0.15 (mm)

G / H / B Key

1.2 ± 0.2 (mm)

space Key

1.35 ± 0.2 (mm)

Esc, Del, Fx Key

1.35 ± 0.2 (mm)

TrackPoint Button

0.8 +0.3 / -0.1 (mm)

key pitch

X- direction Key pitch: 18.5mm

Y-direction Key pitch: 18mm

ELECTIRCAL SPECIFICATIONS

External Port: Living Hinge Interface (6pin POGO connector)

2

PHYSICAL SPECIFICATIONS

 Approximate height: 5.2 mm (0.20in)

 Approximate width: 289.84 mm (11.41 in)

 Approximate length: 228.47 mm (8.99 in)

 Weight: 298.3 g (0.66lb)

Package dimension:

 Unit Box (1): 374*296*40mm

 Weight(with package): 547.3 g (1.20 lb)

 Multipack Carton (1/11): 480*385*313mm

OPERATING ENVIRONMENT

 Temperature: 5 to 40 deg C (41 to 104 deg F)

 8,000ft (2,438m):

Operating w/o any in drive 5.0°C - 35.0°C (41°F - 95°F)

Non-operating 5.0°C - 43.0°C (41°F -109°F)

 16,404ft (5,000m):

Operating unpressurized condition 5.0°C - 31.3°C (41°F - 88°F)

 Relative Humidity:

Operating 8% - 95%

Non-operating 5% - 95%

 Storage : -20°C ～ 60°C

 Shipping : -20°C ～ 60°C

 Corrosive Gas/Particulates

 Corrosive Gas : G1

 Particulates : P1

Thermal specification

Condition

Program: Internet Browsing + Wi-Fi/ WWAN

Ambient room temperature: 25deg.C

Configuration: Stand alone

Criteria

Palmrest 45deg.C

All other surface

Metal 36deg.C

Plastic 38deg.C

3

1.5 OS support list

 Windows 8.1 Professional x86 (64-bit)

 Windows 10.0 Professional x86 (64bit)

Note: Follow Graf system preload OS requirement

AGENCY APPROVALS

 EU DOC

 CE (EMC)

 CB Report

 C-UL

 UL

 FCC

 ICES

 VCCI

 BSMI

 RCM

 CCC (Safety & EMI)

 KCC (EMI+Safety)

 NOM (Mexico)

 EAC

PACKAGING:

One box (plain brown box)

SHIPMENT GROUP

 Keyboard (pen holder included)

 Warranty Poster

Warrenty:

1 year

CABLE ORDERS REQUIRED: No

INSTALLATION TIME: Approximately five minutes

PACKAGING: One brown box

4

SHIPMENT GROUP

 ThinkPad X1 Tablet Thin Keyboard

 Warranty Poster

CHARGES - FRU PARTS

Field Replaceable Units (FRU)

FRU Option

Description Part #

Part# HS

-------------------- ----------------------------- ----------- --

-

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (US) 01AW600 4X30L07457

R1

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (CFA) 01AW601 4X30L07491

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (CFR) 01AW602 4X30L07458

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (LAS) 01AW603 4X30L07489

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (BR) 01AW604 4X30L07490

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (ARA) 01AW605 4X30L07459

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (BE) 01AW606 4X30L07460

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (BG) 01AW607 4X30L07483

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (CZ) 01AW608 4X30L07461

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (DK) 01AW609 4X30L07462

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (ES) 01AW610 4X30L07463

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (FR) 01AW611 4X30L07464

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (DE) 01AW612 4X30L07465

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (GR) 01AW613 4X30L07466

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (IL) 01AW614 4X30L07468

5

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (HU) 01AW615 4X30L07467

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (IS) 01AW616 4X30L07482

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (IT) 01AW617 4X30L07469

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (NL) 01AW619 4X30L07470

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (NO) 01AW620 4X30L07471

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (PL) 01AW621 4X30L07472

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (PT) 01AW622 4X30L07473

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (RU) 01AW623 4X30L07474

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (SK) 01AW624 4X30L07475

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (SI) 01AW625 4X30L07476

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (SE) 01AW626 4X30L07477

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (CH) 01AW627 4X30L07478

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (TR) 01AW628 4X30L07479

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (GB) 01AW629 4X30L07480

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (USI) 01AW630 4X30L07481

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (JP) 01AW631 4X30L07484

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (KR) 01AW632 4X30L07487

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (TW) 01AW633 4X30L07485

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (TH) 01AW634 4X30L07486

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (IN) 01AW636 4X30L07488

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (EE) 01AW637 4X30L07493

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (CFB) 01AW638 4X30L07492

ThinkPad X1 Tablet Thin Keyboard

-Midnight Black (LT) 01AW639 4X30L07494

6

ThinkPad X1 Tablet Thin Keyboard

-Red (US) 01AW650 4X30L07419

ThinkPad X1 Tablet Thin Keyboard

-Red (CFA) 01AW651 4X30L07453

ThinkPad X1 Tablet Thin Keyboard

-Red (CFR) 01AW652 4X30L07420

ThinkPad X1 Tablet Thin Keyboard

-Red (LAS) 01AW653 4X30L07451

ThinkPad X1 Tablet Thin Keyboard

-Red (BR) 01AW654 4X30L07452

ThinkPad X1 Tablet Thin Keyboard

-Red (ARA) 01AW655 4X30L07421

ThinkPad X1 Tablet Thin Keyboard

-Red (BE) 01AW656 4X30L07422

ThinkPad X1 Tablet Thin Keyboard

-Red (BG) 01AW657 4X30L07445

ThinkPad X1 Tablet Thin Keyboard

-Red (CZ) 01AW658 4X30L07423

ThinkPad X1 Tablet Thin Keyboard

-Red (DK) 01AW659 4X30L07424

ThinkPad X1 Tablet Thin Keyboard

-Red (ES) 01AW660 4X30L07425

ThinkPad X1 Tablet Thin Keyboard

-Red (FR) 01AW661 4X30L07426

ThinkPad X1 Tablet Thin Keyboard

-Red (DE) 01AW662 4X30L07427

ThinkPad X1 Tablet Thin Keyboard

-Red (GR) 01AW663 4X30L07428

ThinkPad X1 Tablet Thin Keyboard

-Red (IL) 01AW664 4X30L07430

ThinkPad X1 Tablet Thin Keyboard

-Red (HU) 01AW665 4X30L07429

ThinkPad X1 Tablet Thin Keyboard

-Red (IS) 01AW666 4X30L07444

ThinkPad X1 Tablet Thin Keyboard

-Red (IT) 01AW667 4X30L07431

ThinkPad X1 Tablet Thin Keyboard

-Red (NL) 01AW669 4X30L07432

ThinkPad X1 Tablet Thin Keyboard

-Red (NO) 01AW670 4X30L07433

ThinkPad X1 Tablet Thin Keyboard

-Red (PL) 01AW671 4X30L07434

ThinkPad X1 Tablet Thin Keyboard

-Red (PT) 01AW672 4X30L07435

ThinkPad X1 Tablet Thin Keyboard

7

-Red (RU) 01AW673 4X30L07436

ThinkPad X1 Tablet Thin Keyboard

-Red (SK) 01AW674 4X30L07437

ThinkPad X1 Tablet Thin Keyboard

-Red (SI) 01AW675 4X30L07438

ThinkPad X1 Tablet Thin Keyboard

-Red (SE) 01AW676 4X30L07439

ThinkPad X1 Tablet Thin Keyboard

-Red (CH) 01AW677 4X30L07440

ThinkPad X1 Tablet Thin Keyboard

-Red (TR) 01AW678 4X30L07441

ThinkPad X1 Tablet Thin Keyboard

-Red (GB) 01AW679 4X30L07442

ThinkPad X1 Tablet Thin Keyboard

-Red (USI) 01AW680 4X30L07443

ThinkPad X1 Tablet Thin Keyboard

-Red (JP) 01AW681 4X30L07446

ThinkPad X1 Tablet Thin Keyboard

-Red (KR) 01AW682 4X30L07449

ThinkPad X1 Tablet Thin Keyboard

-Red (TW) 01AW683 4X30L07447

ThinkPad X1 Tablet Thin Keyboard

-Red (TH) 01AW684 4X30L07448

ThinkPad X1 Tablet Thin Keyboard

-Red (IN) 01AW686 4X30L07450

ThinkPad X1 Tablet Thin Keyboard

-Red (EE) 01AW687 4X30L07455

ThinkPad X1 Tablet Thin Keyboard

-Red (CFB) 01AW688 4X30L07454

ThinkPad X1 Tablet Thin Keyboard

-Red (LT) 01AW689 4X30L07456

ThinkPad X1 Tablet Thin Keyboard

-Silver (US) 01AW700 4X30L07495

ThinkPad X1 Tablet Thin Keyboard

-Silver (CFA) 01AW701 4X30L07529

ThinkPad X1 Tablet Thin Keyboard

-Silver (CFR) 01AW702 4X30L07496

ThinkPad X1 Tablet Thin Keyboard

-Silver (LAS) 01AW703 4X30L07527

ThinkPad X1 Tablet Thin Keyboard

-Silver (BR) 01AW704 4X30L07528

ThinkPad X1 Tablet Thin Keyboard

-Silver (ARA) 01AW705 4X30L07497

ThinkPad X1 Tablet Thin Keyboard

-Silver (BE) 01AW706 4X30L07498

8

ThinkPad X1 Tablet Thin Keyboard

-Silver (BG) 01AW707 4X30L07521

ThinkPad X1 Tablet Thin Keyboard

-Silver (CZ) 01AW708 4X30L07499

ThinkPad X1 Tablet Thin Keyboard

-Silver (DK) 01AW709 4X30L07500

ThinkPad X1 Tablet Thin Keyboard

-Silver (ES) 01AW710 4X30L07501

ThinkPad X1 Tablet Thin Keyboard

-Silver (FR) 01AW711 4X30L07502

ThinkPad X1 Tablet Thin Keyboard

-Silver (DE) 01AW712 4X30L07503

ThinkPad X1 Tablet Thin Keyboard

-Silver (GR) 01AW713 4X30L07504

ThinkPad X1 Tablet Thin Keyboard

-Silver (IL) 01AW714 4X30L07506

ThinkPad X1 Tablet Thin Keyboard

-Silver (HU) 01AW715 4X30L07505

ThinkPad X1 Tablet Thin Keyboard

-Silver (IS) 01AW716 4X30L07520

ThinkPad X1 Tablet Thin Keyboard

-Silver (IT) 01AW717 4X30L07507

ThinkPad X1 Tablet Thin Keyboard

-Silver (NL) 01AW719 4X30L07508

ThinkPad X1 Tablet Thin Keyboard

-Silver (NO) 01AW720 4X30L07509

ThinkPad X1 Tablet Thin Keyboard

-Silver (PL) 01AW721 4X30L07510

ThinkPad X1 Tablet Thin Keyboard

-Silver (PT) 01AW722 4X30L07511

ThinkPad X1 Tablet Thin Keyboard

-Silver (RU) 01AW723 4X30L07512

ThinkPad X1 Tablet Thin Keyboard

-Silver (SK) 01AW724 4X30L07513

ThinkPad X1 Tablet Thin Keyboard

-Silver (SI) 01AW725 4X30L07514

ThinkPad X1 Tablet Thin Keyboard

-Silver (SE) 01AW726 4X30L07515

ThinkPad X1 Tablet Thin Keyboard

-Silver (CH) 01AW727 4X30L07516

ThinkPad X1 Tablet Thin Keyboard

-Silver (TR) 01AW728 4X30L07517

ThinkPad X1 Tablet Thin Keyboard

-Silver (GB) 01AW729 4X30L07518

ThinkPad X1 Tablet Thin Keyboard

-Silver (USI) 01AW730 4X30L07519

9

ThinkPad X1 Tablet Thin Keyboard

-Silver (JP) 01AW731 4X30L07522

ThinkPad X1 Tablet Thin Keyboard

-Silver (KR) 01AW732 4X30L07525

ThinkPad X1 Tablet Thin Keyboard

-Silver (TW) 01AW733 4X30L07523

ThinkPad X1 Tablet Thin Keyboard

-Silver (TH) 01AW734 4X30L07524

ThinkPad X1 Tablet Thin Keyboard

-Silver (IN) 01AW736 4X30L07526

ThinkPad X1 Tablet Thin Keyboard

-Silver (EE) 01AW737 4X30L07531

ThinkPad X1 Tablet Thin Keyboard

-Silver (CFB) 01AW738 4X30L07530

ThinkPad X1 Tablet Thin Keyboard

-Silver (LT) 01AW739 4X30L07532

ThinkPad X1 Tablet Thin Keyboard

- Midnight Black (NRD) 01AW640 4X30L29362

ThinkPad X1 Tablet Thin Keyboard

-Red(NRD) 01AW690 4X30L29363

ThinkPad X1 Tablet Thin Keyboard

-Silver (NRD) 01AW740 4X30L29364

Note.

'H' Warranty Handling - 'R' for Return or 'S' for Scrap

'S' Recommended Stock - An entry in this column indicates the

recommended stocking quantity to support

1000 units
