Overview for ThinkPad X1 Tablet Productivity Module (4X50L08495)

ThinkPad X1 Tablet, the best 2-in-1 for Business with Modular Accessories. Get more

features and functions. Easy installation and setup. Extend more Ports, battery and

Keyboard with Productivity module and Thin Keyboard together.

ThinkPad X1 Tablet Productivity module is a modular accessory for X1 tablet to

extend below ports and features:

1. Full HDMI interface *1

2. Onelink+ Port *1

3. USB3.0 Type A *1

4. 2Cell battery for additional 5 hours

SPECIFICATIONS

Basic Function

 ThinkPad X1 Tablet Productivity Module is attached to cartridge interface

connector on bottom of system.

 Productivity Module has POGO pin interface, Thin Keyboard can attach to

cartridge.

 Projector has following function.

– Standard HDMI interface

– ProLink Interface

– USB 3.0 Type-A interface

– 2 Cell Cylindrical battery

 All of IO ports are working as extension of system.

 Customer can do hot attach /detach to system by using eject lever.

 This Cartridge doesn’t have battery charger. It has a battery works as

secondary battery (can use as tablet battery). Cannot charge tablet battery.

PHYSICAL SPECIFICATIONS -- UNPACKED

Physical dimensions: 290mm*52mm*23mm

Net weight: 260g

PHYSICAL SPECIFICATIONS -- PACKED

 Unit Box: 374mm*116mm*57mm

 Gross weight : 420g

 Multipack Carton(1/8): 489mm*387mm*138mm

2

OPERATING ENVIRONMENT

Operating temperature:5.0℃ to 35.0℃

Relative Humidity 8% to 95%

AGENCY APPROVALS

 CE

 FCC

 VCCI

 BSMI

 CB

 Korea KCC (EMC+Safety)

 USA (UL)

 Mexico (NOM)

 WW (CB)

PACKAGING: Brown Box

SHIPMENT GROUP

 ThinkPad X1 Tablet Productivity Module

 Warranty poster

CHARGES - FRU PARTS

- 1 Years warranty

Field Replaceable Units (FRU)

FRU Option

Description Part # Part # H S

----------- ------ ------- - -

ThinkPad X1 Tablet

Productivity Module

03X7189

4X50L08495

R1

Note.

'H' Warranty Handling - 'R' for Return or 'S' for Scrap

'S' Recommended Stock - An entry in this column indicates the

recommended stocking quantity to support

1000 units

To view current service field replaceable unit (FRU) parts, visit

http://www.lenovo.com/support Customers can order extra, or replacement dongles

via: Options Continuation Program (OCP). For more information, please visit:

www.lenovo.com/ocp
