Processor Intel Pentium or 6th Generation Intel Core™ i3 / i5 / i7 Processor

Processor Cores /

Threads

Frequency

Base/Max(GHz) Cache Memory Types Integrated

Graphics

Celeron G3900T 2 / 2 2.6 G 2 MB DDR4-2133 HD 510

Pentium G4400T 2 / 2 2.9 G 3 MB DDR4-2133 HD 510

Core i3-6100T 2 / 4 3.2 G 3 MB DDR4-2133 HD 530

Core i5-6400T 4 / 4 2.2 G / 2.8 G 6 MB DDR4-2133 HD 530

Core i7-6700T 4 / 8 2.8 G / 3.6 G 8 MB DDR4-2133 HD 530

Memory 16GB max, DDR4 2133, two 260-pin SO-DIMM sockets, dual-channel capable

Disk

Optical

Media reader

Some: SATA 6.0Gb/s, 2.5" Wide, 5400 rpm or 7200 rpm

Some: M.2 Solid State Drive (SSD) / PCIe interface, NVMe

Some: DVD burner, SATA 1.5Gb/s, 9.5mm high

6-in-1 media card reader

Graphics

Display

Multi-touch

Camera

Controls

Intel HD Graphics 510/530 in processor, uses main memory, DirectX 12,

and optional NVIDIA GeForce 940MX, 2GB memory, DirectX 12,

external monitor support via HDMI out;

Max resolution: 1920x1080 (HDMI)@60Hz

23" (584.2mm) Full HD 1080p (1920x1080), Wide Viewing Angle

(horizontal: +/- 89°; vertical: +/- 89°), LED backlight, 250 nits, 16:9 aspect ratio,

1000:1 contrast ratio, anti-glare, borderless design,

work as standalone monitor via HDMI in

None

Some: 1.0-megapixel camera, fixed focus, supports 720p, with digital

microphone, LED indicator, with privacy camera cover

Power on/off button on right side

Chipset Intel H110 Chipset

Rear ports

Side ports

M.2 card slot

Three USB 2.0, ethernet (RJ-45), HDMI in port, HDMI out port

Two USB 3.0, optional card reader, headphone / microphone combo jack (3.5mm)

Two M.2 Card slots (one for WLAN, one for M.2 SSD)

Audio support High Definition (HD) Audio, Realtek ALC233 / two internal speakers (3W x 2)

WLAN13

Bluetooth™

Ethernet

Some: 11ac wireless, M.2 Card, Realtek RTL8821AE (dual band),

Wi-Fi + Bluetooth 4.0 combo adapter, 1x1

Some: 11ac wireless, M.2 Card, Qualcomm Atheros QCA6174 (dual band),

Wi-Fi + Bluetooth 4.1 combo adapter, 2x2

Some: 11ac wireless, M.2 Card, Intel Dual Band Wireless-AC 3165,

Wi-Fi + Bluetooth 4.0 combo adapter, 1x1

Some: 11ac wireless, M.2 Card, Intel Dual Band Wireless-AC 8260,

Wi-Fi + Bluetooth 4.1 combo adapter, 2x2

Some: Bluetooth 4.0 or 4.1 wireless, integrated in Wi-Fi + Bluetooth combo adapter

One gigabit ethernet port, Realtek RTL8111G, Wake on LAN

Manageability

Security chip

Security features

None

None

● Security slot (in rear for attachment of

optional Kensington MicroSaver cable;

Kensington lock also locks chassis)

● Smart USB protection, allows keyboard/

mouse only, blocks all storage devices

● Power-on, admin, hard disk password

● Boot sequence control

● Boot without keyboard and mouse

● Individual USB port disablement

Keyboard

Mouse

Some: Lenovo Slim USB Keyboard (USB connector), black

Some: Ultraslim Plus Wireless Keyboard (2.4GHz via USB receiver), black

Some: Optical USB Mouse, black, Lenovo logo

Some: Ultraslim Plus Wireless Mouse (2.4GHz via USB receiver), black

Mechanical ● Black and business grey color

● Support VESA mount (100mm)

● Toolless back cover, memory, M.2 SSD, optical removal

Dimensions (WxDxH)

Max weight

(lb / kg)

Adjustments

Without stand: 20.7 X 1.9 X 13.3 (inch);

525.5 X 49.1 X 338.8 (mm) 11.0 / 5.00 N/A

With Monitor

stand:

20.7 X 9.0 X 16.7 (inch);

525.5 X 227.9 X 423.3 (mm) 14.1 / 6.39 Tilt: 24° back, -5° forward

Swivel: +/-45°

With UltraFlex

II stand:

20.7 X 9.4 X 16.2 (inch);

525.5 X 238.6 X 410.4 (mm) 16.7 / 7.58

Tilt: 61° back, -5° forward;

Lift: 160mm;

Swivel: +/-45°

Power supply Some: 90 watts external adapter, autosensing, 88% PSU (for integrated models)

Some: 120 watts external adapter, autosensing, 89% PSU (for discrete models)

Limited warranty3Some: 1-year or 3-year, depot repair service

Some: 1-year or 3-year, limited onsite service

For Lenovo service upgrade options, please go to S-TC sheet

Preload Preloaded operating system

Some: Windows 10 Pro 64-bit

Some: Windows 10 Home 64-bit

Preloaded applications (only some listed)

● Lenovo Rescue System

● Driver and Application Installation

● Lenovo Solution Center

● Lenovo Bluetooth Lock

● Lenovo SHAREit

● McAfee LiveSafe™ (30-day trial)

● Microsoft Office preloaded;

purchase a product key to activate

● Lenovo Companion

Environment ENERGY STAR 6.1）(Need 85% PSU and Windows OS);

ErP Lot 3; GREENGUARD; RoHS-compliant

Accessories For compatible accessories, please go to http://www.lenovoquickpick.com/

Lenovo V510z Platform Specifications Product Specifications Reference (PSREF)

See footnotes for more detailed information  Lenovo

(V510z-Spec) October 2016
