Lenovo BIOS Windows

M

a

nag

e

m

e

n

t

Instrumentation

In

t

e

rf

a

c

e

Deployment Guide for

Desktop

Date:April

2010

First Edition (April 2010)

© Copyright Lenovo 2010. All rights reserved.

@Copyright Lenovo 2010

I

Contents

Preface .................................................................................................................................... III

Chapter 1. Overview ............................................................................................................... 1

Using Windows Management Instrumentation ................................................................................................. 1

Key benefits ..................................................................................................................................................... 1

Function ................................................................................................................................................... 2

Environment ............................................................................................................................................ 2

Interface ................................................................................................................................................... 2

Supported computers ....................................................................................................................................... 2

Chapter 2. Script Classes and Parameter ............................................................................. 3

Configuring BIOS settings .............................................................................................................................. 3

Return types ...................................................................................................................................................... 5

Password Authentication ................................................................................................................................. 5

Available BIOS setting names ........................................................................................................................ 6

Chapter 3. Typical Usage ........................................................................................................ 9

Listing current BIOS settings .......................................................................................................................... 9

Changing BIOS settings .................................................................................................................................. 9

Changing the boot order .................................................................................................................................. 9

Restoring default settings .............................................................................................................................. 10

Changing an existing hardware password .................................................................................................... 10

Limitations ...................................................................................................................................................... 11

Chapter 4. Security ................................................................................................................ 13

Appendix A. Sample Visual Basic scripts for configuring BIOS settings ......................... 15

Restore default settings ................................................................................................................................... 15

List all BIOS settings on the local computer .................................................................................................. 16

Set a single BIOS setting on the local computer ............................................................................................. 16

Set a single BIOS setting on the local computer if a Administrator password exists ...................................... 17

List all BIOS settings on a remote computer .................................................................................................. 18

Set a single BIOS setting on a remote computer ............................................................................................. 18

Set a single BIOS setting on a remote computer when a Administrator password exists ............................... 19

Set a Administrator password on the local computer when a Administrator password exists ........................ 20

Set a Administrator password on a remote computer when a Administrator password exists ........................ 21

Appendix B. Notices .............................................................................................................. 23

Trademarks ..................................................................................................................................................... 24

@Copyright Lenovo 2010

III

Preface

The purpose of this guide is to explain how to modify BIOS

settings, boot order using Windows Management Instrumentation

(WMI) through the Lenovo client-management interface. This

guide is intended for skilled IT administrators who are familiar

with configuring BIOS settings on computers in their

organizations.

This guide is provided in a ZIP file package that contains this

deployment guide as well as Visual Basic sample scripts to use

when configuring BIOS settings.

This deployment guide is developed for IT professionals to assist

with the unique challenges that they encounter. If you have

suggestions or comments, communicate with your Lenovo®

authorized representative. To learn more about the technologies that

can help you lower the total cost of ownership and to check for

periodic updates to this guide, visit the following Web site:

www.lenovo.com/support

@Copyright Lenovo 2010

1

Chapter 1. Overview

IT administrators are always looking for easier ways to manage

client computer BIOS settings, which include hardware settings,

and the boot order. The Lenovo BIOS WMI interface provides a

simplified way to change these settings. Lenovo has developed a

BIOS interface that can be manipulated through Windows

Management Instrumentation (WMI). The Lenovo BIOS WMI

interface enables IT administrators to make queries on current

BIOS settings, restore settings to their factory defaults, change

single settings, reset or change passwords, and modify the boot

order either at client computers or remotely.

Using Windows Management Instrumentation

WMI is provided as a standard feature in most Windows® operating

systems. It provides a powerful set of functions, such as

query-based information retrieval and event notification, which

enables users to manage both local and remote computers. The

Lenovo BIOS WMI interface extends the capabilities of WMI to

allow management of BIOS settings.

The following illustration shows how WMI can be used to access

Lenovo BIOS settings.

WMI uses Windows Script host (WSH) to interpret scripts. You can

write your scripts in either Windows Visual Basic Scripting Edition

(VBScript) or JavaScript.

Key benefits

The Lenovo BIOS WMI interface provides the following benefits:

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

2

Function

·Flexible BIOS configuration, including the ability to change a

single BIOS setting or all BIOS settings

·Bios password management , including update Administrator

passwords, power-on passwords(POP), hard disk

drive(HDD)passwords

·No dependency on a specific BIOS level

Environment

·Remote or local capabilities

·Support of unattended operations

·No software installation, including managed object format (MOF),

required

·Replaces DOS-based BIOS configuration tools

Interface

·Easy to adopt for various management servers

·Replaces current SMI interface

·Common interface for different products

Supported computers

BIOS setup through WMI descripted in this document is

supported on the following new Thinkcentre products only:

·Thinkcentre M90/M90p

@Copyright Lenovo 2010

3

Chapter 2. Script Classes and Parameter

This chapter contains WMI implementation details for configuring

BIOS settings.

Configuring BIOS settings

The following interface details can be used to access Lenovo BIOS

settings.

·Namespace: "\root\WMI"

·Base Class: "Lenovo_BIOSElement"

·Interface details (see Table 1)

Table 1. Interface Details

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

4

Class Name Type Parameter/Return Example

Lenovo_BiosSetting Query CurrentSetting:”Item,Value” “Wake Up on LAN,

Eanbled”

Lenovo_SetBiosSetting Method “Item,Value;” “Wake Up on

LAN,Disabled;”

Lenovo_SaveBiosSettings Method “Password,Encoding,KbdLa

ng;”

“pswd,ascii,us;“

Lenovo_DiscardBiosSettings Method “;” “;”

Lenovo_LoadDefaultSettings Method “;” “;”

Lenovo_BiosPasswordSettings Query

PasswordMode:”Value”

-0:Legacy Mode

-Others: Reserved

PasswordState:”Value”

-BIT0=1: User password is

installed

-BIT1=1:Admin password is

installed

-BIT2=1:Hard disk

passwords are installed

MinLength:”Value”

-1:always one byte

MaxLength:”Value”

-64:always 64 byte

SupportedKeyboard:”Value

”

-BIT0=1:Support US

keyboard

-BIT1=1:Support French

keyboard

-BIT2=1:Support German

keyboard

SupportedEncodings:”Value

”

-BIT0=1: support ASCII

password input

-BIT1=1:support scancode

password input

Port0HardDiskPasswordStat

e:”Value”

-BIT0=1:User hard disk

password is installed

-BIT1=1:Master hard disk

password is installed

Port1HardDiskPasswordStat

e:”Value”

Port2HardDiskPasswordStat

e:”Value”

Port3HardDiskPasswordStat

e:”Value”

Port4HardDiskPasswordStat

e:”Value”

Port5HardDiskPasswordStat

e:”Value”

PasswordMode:1

PasswordState:0

MinLength:1

MaxLength:64

SuportedKeyboard:7

SupportedEncodings:3

Port0HardDiskPasswordS

tate:00

Port1HardDiskPasswordS

tate:00

Port2HardDiskPasswordS

tate:00

Port3HardDiskPasswordS

tate:00

Port4HardDiskPasswordS

tate:00

Port5HardDiskPasswordS

tate:00

Lenovo_SetBiosPassword Method “PasswordType,CurrentPass

word,

NewPassword,Encoding,Kb

“pop,oldpop,

newpop,ascii,us;”

@Copyright Lenovo 2010

5

Notes:

1. See Appendix A, “Sample Visual Basic scripts for configuring

BIOS settings,”on page 15 for Visual Basic sample scripts.

2. See Table 4 on page 6 for a listing of acceptable setting names.

Return types

You will receive one of the following return types after making

changes to BIOS settings:

Table 2. Return Types

Return Type

Description

Success

Operation completed successfully.

Not

Supported The feature is not supported on this system.

Invalid

Parameter The item or value provided is not valid.

Access

Denied The change could not be made due to an authentication

problem. If a supervisor password exists, the correct supervisor

password must be provided.

System Busy BIOS changes have already been made that need to be

committed. Reboot the system and try again

Password Authentication

If an Administrator password is already set, you must specify that

administrator password before you can change any BIOS settings.

The format for password parameters is "abc,ascii,us" with

descriptions in Table 3.

Table 3. Password parameters format, password authentication

Parameter

Description

Possible selections

Parameter 1

Current password ·“abc” - raw ascii character

·“1e302e” – scancode

Parameter 2

Password encoding ·“ascii”

·“scancode”

Parameter 3

Keyboard languages

(valid only if encoding is ″ascii″)

·

″us″ - English US, English,

French-Canadian, Italian, Japanese,

Korean, Norwegian, Polish,

Portuguese,

Spanish-European, Spanish-Latin

American, Swiss, Turkish

·″fr″ - French-European, Belgian

·″gr″ - German, Czech, Slovak, Slovenian

dLang;”

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

6

Available BIOS setting names

Some BIOS settings are dependent on the presence of certain

hardware features. Settings might vary on different computers.

Notes:

1. BIOS settings and values are case sensitive.

2. The security-related options are not changed even if the

“load default” is requested.

Table 4. List of available BIOS settings

Item Name Option Value Related item

Floppy Driver A "Disabled","Enabled" N

Serial Port1 Address

"3F8/IRQ4","2F8/IRQ3","3E8/IRQ4","2E8/I

RQ3","Disabled"

N

Serial Port2 Address

"3F8/IRQ4","2F8/IRQ3","3E8/IRQ4","2E8/I

RQ3","Disabled"

N

Parallel Port Address "378","278","3BC","Disabled" N

Parallel Port Mode "ECP+EPP","ECP","EPP"

Parallel Port

Address

EPP Version "1.9","1.7"

Parallel Port

Address

ECP Mode DMA Channel "DMA3","DMA1"

Parallel Port

Address

Parallel Port IRQ "IRQ7","IRQ5"

Parallel Port

Address

USB Support "Disabled","Enabled" N

USB Legacy Support "Enabled","Disabled" USB Support

Front USB Ports "Disabled","Enabled" USB Support

Rear USB Ports "Disabled","Enabled" USB Support

USB Port 1 "Disabled","Enabled"

USB Support

&Front USB

Ports

USB Port 2 "Disabled","Enabled"

USB Support

&Front USB

Ports

USB Port 3 "Disabled","Enabled"

USB Support

&Rear USB

Ports

USB Port 4 "Disabled","Enabled"

USB Support

&Rear USB

Ports

USB Port 5 "Disabled","Enabled"

USB Support

&Rear USB

Ports

USB Port 6 "Disabled","Enabled"

USB Support

&Rear USB

Ports

USB Port 7 "Disabled","Enabled"

USB Support

&Rear USB

Ports

USB Port 8 "Disabled","Enabled"

USB Support

&Rear USB

Ports

EHCI Controller 1 "Disabled","Enabled" USB Support

@Copyright Lenovo 2010

7

&Rear USB

Ports

EHCI Controller 2 "Disabled","Enabled"

USB Support

&Rear USB

Ports

External SATA Port "Disabled","Enabled" N

SATA Controller "Disabled","Enabled" N

Configure SATA as "IDE","AHCI","RAID"

SATA

Controller

Hard Disk Pre-delay

"Disabled","3 Seconds","6 Seconds","9

Seconds",

"12 Seconds","15 Seconds","21

Seconds","30 Seconds"

N

Select Active Video "IGD","PCI","PEG","Auto" N

Pre-Allocated Memory

Size

"32MB","64MB","128MB"

Select Active

Video

Total Graphics Memory "128MB","256MB","Maximum"

Select Active

Video

PAVP "Disabled","Enabled"

Select Active

Video

Onboard Audio

Controller

"Disabled","Enabled" N

Onboard Ethernet

Controller

"Disabled","Enabled" N

Boot Agent "PXE","SMC","Disable"

Onboard

Ethernet

Controller

Plug & Play OS "No","Yes" N

Legacy Free "Disabled","Enabled" N

Intel(R) SpeedStep(TM)

Technology

"Disabled","Enabled" N

Core Multi-Processing "Enabled","Disabled" N

Hyper Threading

Technology

"Disabled","Enabled" N

Execute Disable Bit "Disabled","Enabled" N

Intel (R)Virtualization

Technology

"Disabled","Enabled" N

VT-d "Disabled","Enabled" N

TxT "Disabled","Enabled" N

C State Supported "C1","C1C3","C1C3C6" N

Turbo Mode "Disabled","Enabled" N

Intel(R) AMT Control "Disabled","Enabled" N

Intel(R) AMT Reset "Disabled","Enabled" N

Press <CTRL-P> to enter

MEBx

"Disabled","Enabled" N

Console Type "VT100","VT100-8bit","PC-ANSI-7bit","P

C-ANSI","VT100+", "VT-UTF8","ASCII" N

Continue C.R. after POST "On","Off" N

After Power Loss "Power Off","Power On","Last State" N

Wake Up on LAN "Primary","Automatic","Disabled" N

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

8

Wake from PCI Modem "Primary","Automatic","Disabled" N

Wake from Serial Port

Ring

"Primary","Automatic","Disabled" N

Wake from PCI Device "Primary","Automatic","Disabled" N

Wake Up on Alarm

"Single Event","Daily Event","Weekly

Event","Disabled"

N

Startup Sequence "Primary","Automatic"

Wake Up on

Alarm

Alarm Day of Week

"Sunday","Monday","Tuesday","Wednes

day","Thursday",

"Friday","Saturday"

Wake Up on

Alarm

Hardware Password

Manager

"Disabled","Enabled" N

Require Admin.

Password when Flash

"No","Yes" N

Require POP On Restart "No","Yes" N

Preboot Authentication "Disabled","Enabled" N

Erase Fingerprint Data "No","Yes" N

Require HDP On Restart "Yes","No" N

TCG Security Feature "Disable","Inactive","Active" N

Clear TCG Security

Feature

"No","Yes" N

Configuration Change

Detection

"Disabled","Enabled" N

Primary Boot Sequence

"Floppy Drive", "Hard Drive", "CD/DVD

Drive", "Network Card", "USB Floppy",

"USB Hard Disk", "USB CD/DVD", "USB

Key"

N

Automatic Boot

Sequence

N

Error Boot Sequence N

Manufacturing Boot

Sequence

N

Quick Boot "Disabled","Enabled" N

Boot Up Num-Lock

Status

"Off","On" N

Keyboardless Operation "Disabled","Enabled" N

Option Keys Display "Disabled","Enabled" N

Option Keys Display

Style

"Normal","Legacy" N

Startup Device Menu

Prompt

"Disabled","Enabled" N

Serial Number Style

"Legacy

Style","MTM&SN-1","MTM&SN-2","1S-M

TM-SN"

N

Note：

for “Serial Number Style”:

Legacy Style means display the legacy seven digit serial number

MTM&SN-1 means concatenation of Machine Type with Serial Number

(mmmmsssssss)

MTM&SN-2 means concatenation of Machine Type/Model and Serial Number

(mmmmmmmsssssss)

1S-MTM-SN means concatenation of "1S", Machine Type/Model and Serial Number

(1Smmmmmmmsssssss)

@Copyright Lenovo 2010

9

Chapter 3. Typical Usage

Through WMI, you can configure BIOS settings in the

following ways:

·List BIOS settings

·Change BIOS settings

·Change the boot order (sometimes referred to as the startup

sequence)

·Load default BIOS settings

Listing current BIOS settings

For a list of all available BIOS settings that can be changed

through WMI on a specific computer, use the

Lenovo_BiosSetting class (see “List all BIOS settings on the

local computer” on page 16 and “List all BIOS settings on a

remote computer” on page 18 for sample scripts).

See Table 3 on page 4 for a list of available BIOS settings.

Changing BIOS settings

To change a BIOS setting, complete the following steps:

1. Identify the BIOS setting you want to change using the

Lenovo_BiosSetting class (see “List all BIOS settings on the local

computer” on page 16 and “List all BIOS settings on a remote

computer” on page 18 for sample scripts).

2. Identify the value to which the setting will be changed.

Note: See Table 4 on page 4 for a list of available values for a

particular setting.

3. Change the BIOS setting to the desired value using the

Lenovo_SetBiosSetting class, then use the Lenovo_SaveBiosSetting

class to save the settings (see “Set a single BIOS setting on the local

computer” on page 16 and “Set a single BIOS setting on a remote

computer” on page 17 for sample scripts).

Note: BIOS settings and values are case sensitive.

After making changes to the BIOS settings, you must reboot the

computer before the changes will take effect.

Changing the boot order

To change the boot order, complete the following steps:

1. Determine the current setting for “BootOrder” by using the

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

10

Lenovo_BiosSetting class (see “List all BIOS settings on the local

computer” on page 16 and “List all BIOS settings on the remote

computer” on page 18for sample scripts).

2. To set a new boot order, use the Lenovo_SetBiosSetting class,

then use the Lenovo_SaveBiosSetting class to save the settings

(see “Set a single BIOS setting on the local computer” on page 16

and “Set a single BIOS setting on a remote computer” on page 17

for sample scripts). Specify a new boot order by

listing the

boot

devices in order, separated by colons. Devices that are not

specified are excluded from the boot order. In the following

example, the CD/DVD drive is the first boot device and hard

disk drive is the second boot device and so on.

Example: Change primary boot sequence,

Primary Boot Sequence,CD/DVD Drive:Hard Drive:Network

Card:USB Key:USB Floppy:USB Hard Disk

Restoring default settings

To restore default BIOS settings, use the Lenovo_LoadDefaultSettings class,

and then use the Lenovo_SaveBiosSettings class to save the BIOS changes

(see sample scripts).

Changing an existing hardware password

To update a password, specify a password type and format the

password. The format for password parameters is ″pap,abc,def,ascii,us″

with descriptions

in Table

5 (see “Set a Administrator password on the

local computer when a Administrator password exists” on page 20 and

“Set a Administrator password on a remote computer when a

Administrator password exists” on page 21 for sample scripts).

Table 5. Password parameters format, changing existing hardware password

Parameter Description Possible seletctions

Parameter 1 Password type

string

“pap”:Administrator password

“pop”:Power-on password

“uhdp0”: User password of HDD0

“mhdp0”:Master pasword of HDD0

“uhdp1”:User password of HDD1

“mhdp1”:Master password of HDD1

“uhdp2”:User password of HDD2

“mhdp2”:Mater password of HDD2

“uhdp3”:User password of HDD3

“mhdp3”:Master password of HDD3

“uhdp4”:User password of HDD4

“mhdp4”:Master password of HDD4

“uhdp5”:User password of HDD5

“mhdp5”:Master password of HDD5

Parameter 2

Current

password

string

“abc”:raw ascii character

“1e302e”:scancode

Parameter 3

New password

string

“def”:raw ascii character

“201221”:scancode

Parameter 4

Password

encoding

“ascii”

“Scancode”

Parameter 5

Keyboard ·“us″- English US, English UK,

@Copyright Lenovo 2010

11

Languages

Chinese-Traditional, Danish, Dutch,

French-Canadian, Italian, Japanese,

Korean, Norwegian, Polish,

Portuguese,

Spanish-European, Spanish-Latin

American, Swiss, Turkish

·

″fr″ - French-European, Belgian

·

″gr″ - German, Czech, Slovak,

Slovenian

Limitations

The following WMI limitations exist for BIOS setup:

·Administrator password, POP,HDP and the item”Hardware Password

Manager” cannot be changed simutaneously during one power cycle. If

you want to change these settings, you must reboot the system after

changing one of them.

·A password cannot be set using this method when one does not already

exist. Passwords can only be updated or cleared.

·When user try to batch update BIOS settings, make sure that the related

item of each item is in correct state, because once one item’s related item is

Disabled or with special setting, this item will be hidden and can not be

updated through WMI. Please reference Table 4 for detail relationship

between items.

@Copyright Lenovo 2010

13

Chapter 4. Security

WMI-based administration scripts operating over a remote connection send

data over the network in clear text by default. You can enhance security by

modifying WMI-based administration scripts to establish an encrypted

remote connection as follows:

1. Set an impersonation level of ″impersonate″

2. Set an authentication level of ″pktPrivacy″

See Appendix A, “Sample Visual Basic scripts for configuring BIOS

settings,” on page 15 for sample scripts used to implement WMI-based

administration scripts that include these parameters for encryption.

@Copyright Lenovo 2010

15

Appendix A. Sample Visual Basic scripts for

configuring BIOS settings

The Visual Basic command line scripts in the ZIP file are examples

that you may find helpful when configuring BIOS settings.

The scripts in the ZIP file can be used as-is on Windows XP ,

Windows Vista or Windows 7 to modify BIOS settings on your

Lenovo computer. The scripts can be executed on a command

prompt using the cscript.exe utility. On Windows Vista, you must

run the scripts from an administrator command prompt.

Note: The scripts in this appendix are for reference only. To copy

and paste scripts, use the scripts in the ZIP file. Pay attention to that

symbol “;” is treated as the end of paramter in script, so make sure

each method input paramter in script will end with “;”

Restore default settings

Use the example scripts in the ZIP file as templates to restore default

settings on the local computer.

Syntax:

cscript.exe LoadDefaults.vbs

Example:

cscript.exe LoadDefaults.vbs

’

’ Load default BIOS settings

’

On Error Resume Next

Dim colItems

strComputer = “LOCALHOST” ‘Change as needed

Set objWMIService = GetObject(“WinMgmts:” _

&"{ImpersonationLevel=Impersonate}!\\" & strComputer _

&"\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_LoadDefaultSettings")

strReturn = "error"

For Each objItem in colItems

ObjItem.LoadDefaultSettings ";", strReturn

Next

WScript.Echo " LoadDefaultSettings: " + strReturn

If strReturn < > "Success" Then

WScript.Quit

End If

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SaveBiosSettings")

strReturn = "error"

For Each objItem in colItems

ObjItem.SaveBiosSettings ";", strReturn

Next

WScript.Echo " SaveBiosSettings: " + strReturn

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

16

List all BIOS settings on the local computer

Use the sample scripts in the ZIP file as templates to list all

BIOS settings and values on the local computer.

Syntax:

cscript.exe ListAll.vbs

Example:

cscript.exe ListAll.vbs

’

’ List all BIOS settings

’

On Error Resume Next

Dim colItems

strComputer = "LOCALHOST" ’ Change as needed.

Set objWMIService = GetObject("WinMgmts:" _

&"{ImpersonationLevel=Impersonate}!\\" & strComputer _

&"\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_BiosSetting")

For Each objItem in colItems

If Len(objItem.CurrentSetting) > 0 Then

Setting = ObjItem.CurrentSetting

StrItem = Left(ObjItem.CurrentSetting,InStr(

ObjItem.CurrentSetting, “,”)-1)

StrValue = Mid(ObjItem.CurrentSetting,InStr(

ObjItem.CurrentSetting, “,”)-1)

WScript.Echo StrItem + " = " + StrValue

End If

Next

Set a single BIOS setting on the local computer

Use the sample scripts in the ZIP file as templates to set a single

BIOS setting on the local computer.

Syntax

: cscript.exe SetConfig.vbs [Item] [Value]

Example

: cscript.exe SetConfig.vbs “Wake Up on LAN” Disabled

’

’ Set specific BIOS Setting

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count < > 2 Then

WScript.Echo "SetConfig.vbs [setting] [value]"

WScript.Quit

End If

strRequest = WScript.Arguments(0) + "," + WScript.Arguments(1) +

";"

strComputer = "LOCALHOST" ’ Change as needed.

Set objWMIService = GetObject("WinMgmts:"_

&"{ImpersonationLevel=Impersonate}!\\" & strComputer _

&"\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SetBiosSetting")

For Each objItem in colItems

ObjItem.SetBiosSetting strRequest, strReturn

Next

WScript.Echo strRequest

@Copyright Lenovo 2010

17

WScript.Echo " SetBiosSetting: " + strReturn

If strReturn < > "Success" Then

WScript.Quit

End If

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SaveBiosSettings)

strReturn = "error"

For Each objItem in colItems

ObjItem.SaveBiosSettings ";", strReturn

Next

WScript.Echo strRequest

WScript.Echo " SaveBiosSettings: " + strReturn

Set a single BIOS setting on the local computer if a

Administrator password exists

Use the sample scripts in the ZIP file as templates to set a single

BIOS setting on the local computer.

Syntax

: cscript.exe SetConfigPassword.vbs [Item] [Value]

[Password+Encoding]

Example

: cscript.exe SetConfigPassword.vbs “Wake Up on LAN”

Disabled “pass,ascii,us”

’

’ Set specific BIOS Setting

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count < > 3 Then

WScript.Echo "SetConfigPassword.vbs [setting] [value]

[password+encoding]"

WScript.Quit

End If

strRequest = WScript.Arguments(0) + "," + WScript.Arguments(1) +

";"

strComputer = "LOCALHOST" ’ Change as needed.

Set objWMIService = GetObject("WinMgmts:"_

&"{ImpersonationLevel=Impersonate}!\\" & strComputer _

&"\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SetBiosSetting")

For Each objItem in colItems

ObjItem.SetBiosSetting strRequest, strReturn

Next

WScript.Echo strRequest

WScript.Echo " SetBiosSetting: " + strReturn

If strReturn < > "Success" Then

WScript.Quit

End If

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SaveBiosSettings)

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

18

strReturn = "error"

For Each objItem in colItems

ObjItem.SaveBiosSettings Wscript.Arguments(2)+";", strReturn

Next

WScript.Echo strRequest

WScript.Echo " SaveBiosSettings: " + strReturn

List all BIOS settings on a remote computer

Use the sample scripts in the ZIP file as templates to list all

BIOS settings and values on a remote computer.

Syntax:

cscript.exe

ListAllRemote.vbs [Hostname]

Example:

cscript.exe

ListAllRemote.vbs mattdev-c5

’

’ List all BIOS settings

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count <> 1 Then

WScript.Echo"ListAllRemote.vbs [hostname]"

WScript.Quit

End If

strComputer = WScript.Arguments(0)

Set objWMIService = GetObject("WinMgmts:" _

&"{ImpersonationLevel=Impersonate," _

&"authenticationLevel=pktPrivacy}!\\" _

& strComputer & "\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_BiosSetting")

For Each objItem in colItems

If Len(objItem.CurrentSetting) > 0 Then

Setting = ObjItem.CurrentSetting

StrItem = Left(ObjItem.CurrentSetting, InStr(

ObjItem.CurrentSetting, ",")-1

）

StrValue = Mid(ObjItem.CurrentSetting, InStr(

ObjItem.CurrentSetting,

",")+1

，

256

）

WScript.Echo StrItem + " = " + StrValue

End If

Next

Set a single BIOS setting on a remote computer

Use the sample scripts in the ZIP file as templates to set a single

BIOS setting on a remote computer.

Syntax:

cscript.exe

SetConfigRemote.vbs [Item] [Value]

[Hostname]

Example:

cscript.exe

SetConfigRemote.vbs

“Wake Up on LAN”

Disabled mattdev-c5

’

’ Set specific BIOS Setting

@Copyright Lenovo 2010

19

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count < > 3 Then

WScript.Echo "SetConfigRemote.vbs [setting] [value] [hostname]"

WScript.Quit

End If

strRequest = WScript.Arguments(0) + "," + WScript.Arguments(1) +

";"

strComputer = WScript.Arguments(2)

Set objWMIService = GetObject("WinMgmts:" _

&"{ImpersonationLevel=Impersonate," _

&"authenticationLevel=pktPrivacy}!\\" _

& strComputer & "\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SetBiosSetting")

For Each objItem in colItems

ObjItem.SetBiosSetting strRequest, strReturn

Next

WScript.Echo strRequest

WScript.Echo " SetBiosSetting: " + strReturn

If strReturn <> "Success" Then

WScript.Quit

End If

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SaveBiosSettings")

strReturn = "error"

For Each objItem in colItems

ObjItem.SaveBiosSettings ";", strReturn

Next

WScript.Echo strRequest

WScript.Echo " SaveBiosSettings: " + strReturn

Set a single BIOS setting on a remote computer when

a Administrator password exists

Use the sample scripts in the ZIP file as templates to set a single

BIOS setting on a remote computer.

Syntax:

cscript.exe

SetConfigPasswordRemote.vbs [Item]

[Value] [Password+Encoding] [Hostname]

Example:

cscript.exe

SetConfigPasswordRemote.vbs

“Wake Up on

LAN”

Disabled “pass,ascii,us” mattdev-c5

’

’ Set specific BIOS Setting

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count < > 4 Then

WScript.Echo "SetConfigPasswordRemote.vbs [Item] [value]

[password+encoding] [hostname]"

WScript.Quit

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

20

End If

strRequest = WScript.Arguments(0) + "," + WScript.Arguments(1) +

";"

strComputer = WScript.Arguments(3)

Set objWMIService = GetObject("WinMgmts:" _

&"{ImpersonationLevel=Impersonate," _

&"authenticationLevel=pktPrivacy}!\\" _

& strComputer & "\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SetBiosSetting")

For Each objItem in colItems

ObjItem.SetBiosSetting strRequest, strReturn

Next

WScript.Echo strRequest

WScript.Echo " SetBiosSetting: " + strReturn

If strReturn <> "Success" Then

WScript.Quit

End If

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SaveBiosSettings")

strReturn = "error"

For Each objItem in colItems

ObjItem.SaveBiosSettings Wscript.Arguments(2)+";", strReturn

Next

WScript.Echo strRequest

WScript.Echo " SaveBiosSettings: " + strReturn

Set a Administrator password on the local computer

when a Administrator password exists

Use the sample scripts in the ZIP file as templates to set a single

BIOS setting on a remote computer.

Note: You cannot set a password if one does not already exist.

Syntax:

cscript.exe

SetAdminPassword.vbs [old password] [new

password] [encoding]

Example:

cscript.exe

SetAdminPassword.vbs

oldpass

newpass

“ascii,us”

’

’ Update Administrator password

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count < > 3 Then

WScript.Echo "SetAdminPassword.vbs [oldpassword] [newpassword]

[encoding]"

WScript.Quit

End If

strRequest=“pap,”+WScript.Arguments(0)+","+ WScript.Arguments(1)

+ ","Wscript.Arguments(2)+”;”

strCompter = “LOCALHOST” ‘change as needed

Set objWMIService = GetObject("WinMgmts:" _

@Copyright Lenovo 2010

21

&"{ImpersonationLevel=Impersonate," _

&"authenticationLevel=pktPrivacy}!\\" _

& strComputer & "\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SetBiosPassword")

strReturn = “error”

For Each objItem in colItems

ObjItem.SetBiosPassword strRequest, strReturn

Next

WScript.Echo strRequest

WScript.Echo " SetBiosPassword: " + strReturn

Set a Administrator password on a remote computer

when a Administrator password exists

Use the sample scripts in the ZIP file as templates to set a single

BIOS setting on a remote computer.

Note: You cannot set a password if one does not already exist.

Syntax:

cscript.exe

SetAdminPasswordRemote.vbs [old password]

[new password] [encoding] [hostname]

Example:

cscript.exe

SetAdminPasswordRemote.vbs

oldpass

newpass

“ascii,us” mattdev-c5

’

’ Update Administrator password

’

On Error Resume Next

Dim colItems

If WScript.Arguments.Count < > 4 Then

WScript.Echo "SetAdminPasswordRemote.vbs [oldpassword]

[newpassword] [encoding] [hostname]"

WScript.Quit

End If

strRequest=“pap,”+WScript.Arguments(0)+","+ WScript.Arguments(1)

+ ","Wscript.Arguments(2)+”;”

strCompter = Wscript.Arguments(3) ‘change as needed

Set objWMIService = GetObject("WinMgmts:" _

&"{ImpersonationLevel=Impersonate," _

&"authenticationLevel=pktPrivacy}!\\" _

& strComputer & "\root\wmi")

Set colItems = objWMIService.ExecQuery("Select * from

Lenovo_SetBiosPassword")

strReturn = “error”

For Each objItem in colItems

ObjItem.SetBiosPassword strRequest, strReturn

Next

WScript.Echo strRequest

WScript.Echo " SetBiosPassword: " + strReturn

@Copyright Lenovo 2010

23

Appendix B. Notices

Lenovo may not offer the products, services, or features discussed

in this document in all countries. Consult your local Lenovo

representative for information on the products and services

currently available in your area. Any reference to a Lenovo

product, program, or service is not intended to state or imply that

only that Lenovo product, program, or service may be used. Any

functionally equivalent product, program, or service that does not

infringe any Lenovo intellectual property right may be used

instead. However, it is the

user

’s responsibility to evaluate and

verify the operation of any other product, program, or service.

Lenovo may have patents or pending patent applications

covering subject matter described in this document. The

furnishing of this document does not give you any license to

these patents. You can send license inquiries, in writing, to:

Lenovo (United States), Inc

1009 Think Place

Building One

Morrisville, NC 27560

USA

Attention: Lenovo Director of Licensing

LENOVO GROUP LTD. PROVIDES THIS PUBLICATION “AS IS”

WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions

do not allow disclaimer of express or implied warranties in certain

transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or

typographical errors. Changes are periodically made to the

information herein; these changes will be incorporated in new

editions of the publication. Lenovo may make improvements

and/or changes in the product(s) and/or the program(s) described

in this publication at any time without notice.

The products described in this document are not intended for use

in implantation or other life support applications where

malfunction may result in injury or death to persons. The

information contained in this document does not affect or change

Lenovo product specifications or warranties. Nothing in this

document shall operate as an express or implied license or

indemnity under the intellectual property rights of Lenovo or

third parties. All information contained in this document was

obtained in specific environments and is presented as an

illustration. The result obtained in other operating environments

may vary.

Lenovo may use or distribute any of the information you

supply in any way it believes appropriate without incurring

any obligation to you.

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Desktop

24

Any references in this publication to non-Lenovo Web sites are

provided for convenience only and do not in any manner serve as

an endorsement of those Web sites. The materials at those Web sites

are not part of the materials for this Lenovo product, and use of

those Web sites is at your own risk.

Trademarks

The following terms are trademarks of Lenovo in the

United States, other countries, or both:

Lenovo

the Lenovo logo

Thinkcentre

ThinkVantage

Microsoft, Windows, Windows Vista, and Active Directory are

trademarks or registered trademarks of Microsoft Corporation

in the United States, other countries, or both.

Other company, product, or service names may be trademarks or

service marks of others.
