Pro4000 Series User's Guide
April 2012 www.lexmark.com
Machine type(s):
4447
Model(s):
Pro4000: 0n0, 0nE; Pro4000c: 000
Contents
Safety information.......................................................................................6
About your printer.......................................................................................7
Thank you for choosing this printer!.........................................................................................................7
Minimizing your printer's environmental impact......................................................................................7
Finding information about the printer......................................................................................................8
Understanding the parts of the printer...................................................................................................10
Selecting a location for the printer..........................................................................................................12
Ordering and replacing supplies.................................................................13
Ordering ink cartridges............................................................................................................................13
Using genuine Lexmark ink cartridges.....................................................................................................13
Replacing ink cartridges..........................................................................................................................14
Ordering paper and other supplies.........................................................................................................15
Recycling Lexmark products....................................................................................................................15
Using the printer control panel buttons and menus....................................16
Using the printer control panel...............................................................................................................16
Changing the Sleep timeout....................................................................................................................18
Saving paper and energy.........................................................................................................................18
Restoring factory default settings...........................................................................................................18
Setting the security PIN of the printer....................................................................................................19
Using shortcuts..........................................................................................20
What are shortcuts?................................................................................................................................20
Getting started........................................................................................................................................21
Using the printer software.........................................................................23
Minimum system requirements..............................................................................................................23
Using the Windows printer software......................................................................................................23
Using the Macintosh printer software....................................................................................................25
Finding and installing optional software.................................................................................................26
Updating the printer software................................................................................................................26
Downloading PCL and PS drivers (Windows only)...................................................................................27
Reinstalling the printer software.............................................................................................................27
Contents 2
Loading paper and original documents.......................................................29
Loading the paper tray............................................................................................................................29
Loading various paper types...................................................................................................................31
Saving paper settings..............................................................................................................................34
Loading original documents on the scanner glass...................................................................................34
Loading original documents into the ADF...............................................................................................35
Using different paper sizes and types.....................................................................................................36
Linking trays............................................................................................................................................39
Printing......................................................................................................40
Tips for printing.......................................................................................................................................40
Printing basic documents........................................................................................................................40
Printing specialty documents..................................................................................................................44
Working with photos...............................................................................................................................47
Printing on both sides of the paper (duplexing)......................................................................................50
Managing print jobs................................................................................................................................53
Printing from a mobile device.................................................................................................................56
Copying......................................................................................................58
Tips for copying.......................................................................................................................................58
Making copies.........................................................................................................................................58
Copying an ID card...................................................................................................................................59
Enlarging or reducing images..................................................................................................................59
Adjusting copy quality.............................................................................................................................60
Making a copy lighter or darker..............................................................................................................60
Collating copies using the printer control panel.....................................................................................60
Placing separator sheets between copies...............................................................................................61
Copying multiple pages on one sheet.....................................................................................................61
Placing an overlay message on each page..............................................................................................61
Removing the background of a copy.......................................................................................................62
Making a duplex (two-sided) copy..........................................................................................................62
Canceling copy jobs.................................................................................................................................63
Scanning....................................................................................................64
Tips for scanning......................................................................................................................................64
Scanning to a local computer..................................................................................................................64
Contents 3
Scanning to a network computer............................................................................................................65
Scanning to a network folder..................................................................................................................65
Scanning to a flash drive or memory card...............................................................................................66
Scanning photos......................................................................................................................................67
Scanning documents for editing..............................................................................................................68
Scanning directly to e‑mail using the printer software...........................................................................69
Scanning to a PDF....................................................................................................................................70
Scanning FAQ...........................................................................................................................................71
Canceling scan jobs.................................................................................................................................71
E-mailing....................................................................................................72
Setting up the printer to e-mail...............................................................................................................72
Creating an e-mail contact list.................................................................................................................73
Sending e-mail.........................................................................................................................................74
Canceling an e‑mail.................................................................................................................................75
Faxing........................................................................................................76
Setting up the printer to fax....................................................................................................................76
Configuring the fax settings.....................................................................................................................87
Creating a contact list..............................................................................................................................89
Sending faxes...........................................................................................................................................91
Receiving faxes........................................................................................................................................92
Faxing FAQ...............................................................................................................................................94
Networking..............................................................................................101
Installing the printer on a wireless network..........................................................................................101
Advanced wireless setup.......................................................................................................................108
Installing the printer on an Ethernet network......................................................................................110
Performing network management tasks...............................................................................................112
Networking FAQ....................................................................................................................................117
Using the Embedded Web Server.............................................................130
Accessing the Embedded Web Server...................................................................................................130
Understanding the home page..............................................................................................................130
Customizing printer settings.................................................................................................................131
Maintaining the printer............................................................................133
Maintaining ink cartridges.....................................................................................................................133
Contents 4
Cleaning the exterior of the printer......................................................................................................134
Cleaning the scanner glass....................................................................................................................135
Moving the printer to another location................................................................................................135
Troubleshooting.......................................................................................137
Before you troubleshoot.......................................................................................................................137
If Troubleshooting does not solve your problem..................................................................................137
Setup troubleshooting...........................................................................................................................137
Understanding printer messages..........................................................................................................142
Clearing paper jams...............................................................................................................................148
Print troubleshooting............................................................................................................................151
Copy and scan troubleshooting.............................................................................................................153
E-mail troubleshooting..........................................................................................................................155
Fax troubleshooting..............................................................................................................................156
Memory card troubleshooting..............................................................................................................161
Network troubleshooting......................................................................................................................162
Embedded Web Server does not open.................................................................................................174
Contacting customer support................................................................................................................175
Notices.....................................................................................................176
Product information..............................................................................................................................176
Edition notice........................................................................................................................................176
Power consumption..............................................................................................................................179
Index........................................................................................................190
Contents 5
Safety information
Connect the power cord to a properly grounded electrical outlet that is near the product and easily accessible.
Use only the power supply and power cord provided with this product or the manufacturer's authorized replacements.
CAUTION—POTENTIAL INJURY: To reduce risk of fire, use only the telecommunications (RJ‑11) cord provided
with this product or a UL Listed 26 AWG or larger replacement when connecting this product to the public
switched telephone network.
CAUTION—SHOCK HAZARD: Make sure that all external connections (such as Ethernet and telephone system
connections) are properly installed in their marked plug-in ports.
This product is designed, tested, and approved to meet strict global safety standards with the use of specific
manufacturer's components. The safety features of some parts may not always be obvious. The manufacturer is not
responsible for the use of other replacement parts.
CAUTION—POTENTIAL INJURY: Do not cut, twist, bind, crush, or place heavy objects on the power cord. Do not
subject the power cord to abrasion or stress. Do not pinch the power cord between objects such as furniture
and walls. If any of these things happen, a risk of fire or electrical shock results. Inspect the power cord regularly
for signs of such problems. Remove the power cord from the electrical outlet before inspecting it.
Refer service or repairs, other than those described in the user documentation, to a professional service person.
CAUTION—POTENTIAL INJURY: The lithium battery in this product is not intended to be replaced. There is a
danger of explosion if a lithium battery is incorrectly replaced. Do not recharge, disassemble, or incinerate a
lithium battery. Discard used lithium batteries according to the manufacturer's instructions and local
regulations.
IMPORTANT SAFETY INSTRUCTIONS: When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury to persons, including the following:
•Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
•Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of
electric shock from lightning.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
CAUTION—SHOCK HAZARD: To avoid the risk of electric shock when cleaning the exterior of the printer, unplug
the power cord from the wall outlet and disconnect all cables from the printer before proceeding.
CAUTION—SHOCK HAZARD: Do not use the fax feature during a lightning storm. Do not set up this product or
make any electrical or cabling connections, such as the fax feature, power cord, or telephone, during a lightning
storm.
SAVE THESE INSTRUCTIONS.
Safety information 6
About your printer
Thank you for choosing this printer!
We've worked hard to make sure it will meet your needs.
To start using your new printer right away, use the setup materials that came with the printer, and then skim the User’s
Guide to learn how to perform basic tasks. To get the most out of your printer, read the User’s Guide carefully, and
make sure you check the latest updates on our Web site.
We're committed to delivering performance and value with our printers, and we want to make sure you're satisfied. If
you do encounter any problems along the way, one of our knowledgeable support representatives will be delighted to
help you get back on track fast. And if you find something we could do better, please let us know. After all, you are the
reason we do what we do, and your suggestions help us do it better.
Minimizing your printer's environmental impact
We are committed to protecting the environment and are continually improving our printers to reduce their
environmental impact. By selecting certain printer settings or tasks, you may be able to reduce your printer's
environmental impact even further.
Conserving energy
•Select the lowest Sleep timeout. The Sleep feature puts the printer in a minimum‑power standby mode after the
printer has been idle for a set amount of time (the Sleep timeout).
•Reduce the screen brightness. Dim the printer display to lower the power consumption of your printer.
•Share your printer. Wireless/network printers allow you to share a single printer among multiple computers, thus
conserving energy and other resources.
Conserving paper
•Print more than one page image on one side of the paper. The Pages per Sheet feature allows you to print multiple
pages on one sheet. You can print up to 16 page images on one side of a sheet of paper.
•Print on both sides of the paper. Two‑sided printing (duplexing) lets you print on both sides of the paper manually
or automatically (depending on your printer model).
•Preview print jobs before printing. Use the preview features found in Toolbars, the Print or Print Preview dialog,
or the printer display (depending on your printer model).
•Use recycled paper.
•Reduce the margins of documents to be printed.
•Scan and save. To avoid printing multiple copies, you can scan documents or photos and save them to a computer
program, application, or flash drive for presentation (depending on your printer model).
About your printer 7
Conserving ink
•Use Quick Print or Draft Mode. These modes can be used to print documents using less ink than normal and are
recommended for printing documents that are mostly text.
•Use font types and font settings that require less ink. Most programs or applications let you adjust the darkness
of the colors.
•Use high‑yield cartridges. Inks in high‑yield cartridges allow you to print more pages.
•Preview print jobs before printing. Use the preview features found in Toolbars, the Print Preview dialog, or the
printer display (depending on your printer model).
Recycling
•Return ink cartridges for reuse or recycling through the Lexmark Cartridge Collection Program. To return an ink
cartridge, go to www.lexmark.com/recycle. Follow the instructions to request a postage‑paid bag.
•Recycle the product packaging.
•Recycle your old printer instead of throwing it away.
•Recycle paper from discarded print jobs.
•Use recycled paper.
To read the Lexmark Environmental Sustainability Report, see www.lexmark.com/environment.
Note: Your printer may not come with some of these programs or some of the functions of these programs,
depending on the features of the printer that you purchased.
Finding information about the printer
Publications
What are you looking for? Find it here
Initial setup instructions:
•Connecting the printer
•Installing the printer software
Setup documentation
The setup documentation came with the printer and is
also available on the Lexmark Web site at
http://support.lexmark.com.
About your printer 8
What are you looking for? Find it here
Additional setup and instructions for using the printer:
•Selecting and storing paper and specialty media
•Loading paper
•Performing printing, copying, scanning, and faxing tasks,
depending on your printer model
•Configuring printer settings
•Viewing and printing documents and photos
•Setting up and using printer software
•Setting up and configuring the printer on a network,
depending on your printer model
•Caring for and maintaining the printer
•Troubleshooting and solving problems
User's Guide
The User's Guide is available on the installation software
CD.
For updates, check our Web site at
http://support.lexmark.com.
Creating and customizing printer solutions, depending on your
printer model
SmartSolutions User's Guide
Go to http://smartsolutions.lexmark.com.
Help using the printer software Windows or Mac Help
Open a printer software program or application, and
then click Help.
Click
?
to view context‑sensitive information.
Notes:
•The Help installs automatically with the printer
software.
•The printer software is located in the printer
program folder or on the desktop, depending on
your operating system.
The latest supplemental information, updates, and online
technical support:
•Troubleshooting hints and tips
•Frequently asked questions
•Documentation
•Driver downloads
•Live chat support
•E‑mail support
Lexmark Support Web site—
http://support.lexmark.com
Note: Select your region, and then select your product
to view the appropriate support site.
Record the following information (located on the store
receipt and the back of the printer), and have it ready
when you contact support so that they may serve you
faster:
•MAC address number
•Serial number
•Date purchased
•Store where purchased
About your printer 9
What are you looking for? Find it here
Telephone support In the US, call us at:
1-800-395-4039
Monday–Friday (9:00 AM–9:00 PM ET), Saturday
(12:00 noon–6:00 PM ET)
Support telephone numbers and hours of operation for
your region or country can be found on the Support Web
site (http://support.lexmark.com) or on the printed
warranty that came with your printer.
Warranty information •In the US—See the Statement of Limited Warranty
included with this printer, or at
http://support.lexmark.com.
•In other countries or regions—See the printed
warranty that came with your printer.
Note: Your printer may not come with some of these programs or some of the functions of these programs,
depending on the features of the printer that you purchased.
Understanding the parts of the printer
Use the To
1Automatic Document
Feeder (ADF)
•Scan, copy, or fax multiple‑page documents.
•Access ADF paper jams.
About your printer 10
Use the To
2ADF input tray Load original documents into the ADF.
Notes:
•Do not load postcards, photos, small items, or thin media (such as magazine
clippings) into the ADF. Place these items on the scanner glass.
•After scanning, copying, or faxing, you can lift the right end of the input tray to
retrieve the original documents easily.
3PictBridge and USB port Connect a PictBridge-enabled digital camera or a flash drive to the printer.
4Card reader light Check the card reader status. The light comes on when a memory card is inserted and
blinks when a memory card is being accessed.
5Memory card slot Insert a memory card.
6Ink cartridge access door Install, remove, or replace ink cartridges.
7Paper tray (Tray 1) Load paper.
8Second paper tray (Tray 2)
Note: This option is
available only in select
printer models.
Load additional paper.
You can load the same type of paper as in Tray 1. You can also load a different type of
paper and change the default paper settings so the printer uses paper from Tray 2 for
certain types of print jobs.
9Exit bin Hold paper as it exits.
Note: For the printer to be ready for any print job, make sure to fully extend the exit
bin and to flip out the bin extender.
10 Bin extender Catch the paper as it exits.
Note: For the printer to be ready for any print job, make sure to fully extend the exit
bin and to flip out the bin extender.
11 Printer control panel Operate the printer.
Use the To
12 Customer support
label
Identify the model number of the printer, the customer support hot line, and the ink
cartridge information.
13 Scanner glass Scan, copy, or fax photos and documents.
14 Power supply with port Connect the printer to the power cord.
About your printer 11
Use the To
15 Duplex unit •Print on both sides of a sheet of paper.
•Access paper jams.
16 USB port Connect the printer to a computer using a USB cable.
Warning—Potential Damage: Do not touch the USB port except when plugging in or
removing a USB cable or installation cable.
Note: Remove the sticker to access the port.
17 Ethernet port Connect your printer to a computer, a local network, an external DSL, or a cable modem.
18 LINE port Connect the printer to an active telephone line through a standard wall jack (RJ‑11), DSL
filter, or VoIP adapter, or any other adapter that allows you to access the phone line to send
and receive faxes.
19 EXT port Connect additional devices (telephone or answering machine) to the printer and the
telephone line. Use this port if you do not have a dedicated fax line for the printer and if
this connection method is supported in your country or region.
Note: Remove the plug to access the port.
Selecting a location for the printer
When selecting a location for the printer, leave enough room to open trays (including optional trays), covers, and doors,
depending on the features of your printer. It is important to:
•Provide a flat, sturdy, and stable surface.
•Keep the printer:
–Away from the direct airflow of air conditioners, heaters, or ventilators
–Free from direct sunlight, humidity extremes, or temperature fluctuations
–Clean, dry, and free of dust
About your printer 12
Ordering and replacing supplies
Ordering ink cartridges
Make sure to order the cartridges that are available in your region.
•Region 1: For the United States, Canada, and Latin America, use 200, 200XL, or 200XLA cartridges.
•Region 2: For the European Union (EU), the European Economic Area (EEA), and Switzerland, use 210, 210XL, or
200XLA cartridges.
•Region 3: For Africa, the Middle East, Central Eastern Europe (non‑EU), the Commonwealth of Independent States
(CIS), and the Asia Pacific region, use 220, 220XL, or 200XLA cartridges.
1 Licensed for a single use only. After use, return this cartridge to Lexmark for remanufacturing, refilling, or recycling.
2 Available only on the Lexmark Web site at www.lexmark.com.
Notes:
•To get more ink, order high‑yield ink cartridges.
•Depending on your country or region, you may get the ink cartridges individually or in packs.
•You can order a mix of standard ink cartridges and high‑yield ink cartridges, depending on your needs.
•For page yield information, visit www.lexmark.com/yields.
•The cartridges used for printing documents can also be used for printing photos.
•For best results, use only genuine Lexmark ink cartridges.
Using genuine Lexmark ink cartridges
Lexmark printers, ink cartridges, and photo paper are designed to perform together for superior print quality, and our
inks are formulated to work with your printer and help extend the life of your product. We recommend that you use
only genuine Lexmark ink cartridges.
Lexmark's warranty does not cover damage caused by non-Lexmark ink or ink cartridges.
Ordering and replacing supplies 13
Replacing ink cartridges
Make sure you have a new ink cartridge or cartridges before you begin. You must install new cartridges immediately
after removing the old ones, or the ink remaining in the printhead nozzles may dry out.
1Turn on your printer.
2Open the ink cartridge access door.
Warning—Potential Damage: Do not extend the ink cartridge access door beyond 90 degrees when opening to
prevent it from breaking.
3Press the release tab, and then remove the used ink cartridge or cartridges.
4Insert each ink cartridge until it clicks into place.
Note: Install the new ink cartridges immediately after removing them from the packaging to avoid exposing the
ink to air.
5Close the ink cartridge access door.
Ordering and replacing supplies 14
Notes:
•If Align Printer appears on the printer display, then touch Continue or press OK , depending on your
printer model.
•Do not remove the alignment page until printing is finished.
Ordering paper and other supplies
To order supplies or to locate a dealer near you, visit our Web site at www.lexmark.com.
Item Part Number
USB cable 1021294
For more information, go to www.lexmark.com.
Paper Paper size
Lexmark Photo Paper •Letter
•A4
•4 x 6 in.
•L
Notes:
•Availability may vary by country or region.
•For best results when printing photos or other high-quality images, use Lexmark Photo Paper.
•For more information, go to www.lexmark.com.
Recycling Lexmark products
To return Lexmark products for recycling:
1Visit our Web site at www.lexmark.com/recycle.
2Find the product type you want to recycle, and then select your country or region from the list.
3Follow the instructions on the computer screen.
Note: Printer supplies and hardware not listed in a Lexmark collection program may be recycled through your local
recycling center. Contact your local recycling center to determine the items they accept.
Ordering and replacing supplies 15
Using the printer control panel buttons and menus
Using the printer control panel
12345
6
7
Use To
1Power •Turn the printer on and off.
•Switch to Sleep mode.
Note: When the printer is on, press to switch to Sleep mode. Press and hold
for three seconds to turn off the printer.
2Display
Note: The display is
turned off in Sleep
mode.
View:
•Printer status
•Messages
•Menus
3Arrow buttons Navigate through menu items that appear on the display.
4Home Return to the home screen.
5Keypad In Copy mode or Photo mode:
Enter the number of copies or prints you want to make.
In Fax mode:
•Enter fax numbers.
•Operate an automated answering system.
•Select letters when creating a Speed Dial list.
•Type numbers to enter or edit the date and time shown on the display.
6Back •Return to the previous screen.
•Exit from one menu level to a higher one.
7Select
OK
•Select menu options.
•Save settings.
Using the printer control panel buttons and menus 16
Use To
8Redial Display the last number dialed. Press the left or right arrow button to view the last five numbers
dialed.
9Pause Insert a three-second pause in a fax number to wait for an outside line or get through an
automated answering system. Enter a pause only when you have already begun entering the
number.
10 Dial Tone Dial the telephone number manually using the keypad before sending the fax.
11 Address Book Access fax numbers from a saved list of numbers.
12 Color Switch to color mode.
13 Black Switch to black‑and‑white mode.
14 Start Start a job, depending on which mode is selected.
15 Cancel •Cancel a print, copy, scan, or fax job in progress.
•Clear current settings or error messages, and return to previous settings.
16 Ethernet indicator Check the Ethernet connection of your printer.
17 Wi‑Fi indicator Check the wireless connection of your printer.
Note: This feature may be available only in select printer models.
Using the printer control panel buttons and menus 17
Changing the Sleep timeout
The Sleep timeout is the time it takes for the printer to switch to Sleep mode when the printer is left idle. The Sleep
feature optimizes energy efficiency by reducing the printer power consumption. To save the most energy, select the
lowest Sleep timeout.
1From the printer control panel, navigate to:
> Setup >
OK
> Device Setup >
OK
> Sleep >
OK
2Press the up or down arrow button to select or use the keypad to enter the value of the Sleep timeout, and then
press OK .
Saving paper and energy
To significantly cut paper usage and reduce paper waste, activate duplex printing:
1From the printer control panel, navigate to:
> Setup > OK > Print Mode Setup > OK > 2‑Sided Copy, Standalone > OK
2Press the up or down arrow button to scroll to On, and then press OK .
To optimize energy efficiency, reduce the Sleep timeout and Screen Brightness:
1From the printer control panel, navigate to:
> Setup > OK > Device Setup > OK > Sleep > OK
2Press the up or down arrow button to select or use the keypad to enter the Sleep timeout value, and then press
OK .
3From the printer control panel, navigate to:
> Setup > OK > Device Setup > OK > Screen Brightness > OK
4Press the up or down arrow button to scroll to Dim, and then press OK .
Note: If you select 2‑Sided Copy, Standalone, then the printer prints on both sides of the paper (duplex) for
copy and fax jobs, and for printing in Windows and Macintosh, depending on your printer model.
Restoring factory default settings
Resetting to factory default settings will delete all the printer settings you have previously selected.
1From the printer control panel, navigate to:
> Setup > OK > Restore Factory Defaults > OK
2Press the up or down arrow button to scroll to Restore All Printer Settings, and then press OK .
3Press the left or right arrow button to scroll to Yes, and then press OK .
The printer restarts automatically after resetting to factory default settings.
4When prompted to set the initial settings of your printer, make your selections using the printer control panel
buttons.
Initial Setup Complete appears on the display.
Using the printer control panel buttons and menus 18
Setting the security PIN of the printer
To prevent unauthorized changes in specific menu settings, you can set a security PIN for the printer.
1From the printer control panel, navigate to:
> Setup >
OK
> Security Setup >
OK
> Set Admin PIN
2Enter your four‑digit PIN, and then press OK .
Note: Make sure you remember your security PIN. To recover a lost PIN, you will need the assistance of
customer support.
3From the Security Setup menu, navigate to:
Lock Settings > OK > On > OK
Note: When Lock Settings is set to On, you need to enter the security PIN every time you want to change some
printer settings. To disable the security PIN, set Lock Settings to Off.
Using the printer control panel buttons and menus 19
Using shortcuts
What are shortcuts?
A shortcut is a way to quickly accomplish printing, copying, scanning, e‑mailing, or faxing tasks with the printer. You
can configure and save a set of frequently used printer settings available for a given task and then assign a shortcut
number and shortcut name to it.
The shortcut number and shortcut name serve as the identification for a particular task and its printer settings. When
you want to perform a task with those settings, you do not need to go through the usual process of adjusting the settings
and options. Simply enter the shortcut number or select the shortcut name and number on the printer control panel,
and the task will launch automatically.
Configure the shortcut settings for a task in the Embedded Web Server:
Select To
Copy Copy a document or photo.
Eco‑Copy Copy a document or photo using two‑sided or draft setting.
ID Card Copy Copy both sides of an ID card onto a single page.
Scan to Fax Scan a document or photo and send it through fax.
Scan to E‑mail Scan a document or photo and send it through e‑mail.
Note: Make sure the printer is connected to the network and the Internet
through an Ethernet or wireless connection.
Scan to Computer Scan a document or photo and send it to your computer.
Note: Make sure the printer is connected to the computer locally (USB).
Scan to Network Scan a document or photo and save it to a network folder.
Note: Make sure the printer is connected to the Internet through an Ethernet
or wireless connection.
Scan to Memory Device Scan a document or photo and save it to a memory card or flash drive (depending
on your printer model).
Print a File Print a document from your computer.
Note: Make sure the printer is connected to the computer through the same
Ethernet or wireless network.
Example:
A lawyer who uses his printer to send e-mails to clients normally navigates through the printer control panel to select
the feature and its available options. Instead of doing that, he can configure the printer settings (such as the message
title and recipient) from the Embedded Web Server, and then assign a shortcut number and shortcut name to the task.
Every time he enters the shortcut number or selects the shortcut name on the printer control panel, the printer
automatically sends the documents according to the selected settings.
Using shortcuts 20
Getting started
During installation, a link will be provided for you to create shortcuts. If you were not able to create your shortcuts
during installation, then you may create the shortcuts through your printer software.
Launching the shortcuts page using the printer software
Before you begin, make sure:
•Your printer and computer are each connected to the network through an Ethernet or wireless connection.
•Your printer is turned on.
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Navigate to:
Printer Home > select your printer > Settings > Configure Shortcuts
For Macintosh users
1From the Finder, navigate to:
Applications > select your printer folder > Shortcuts
2Select your printer from the list, and then click Launch.
Creating a shortcut
1Launch the shortcuts page, and then navigate to:
Add New Shortcut > select a task
2Assign a shortcut number and shortcut name, and then specify the settings.
Notes:
•A shortcut number is the number you assign to a particular task and its printer settings. You can assign
shortcut numbers from 1 to 999.
•If you configured the shortcut to show the settings before running, then the settings will appear on the
printer display. Adjust the settings if necessary.
3Click Add.
Modifying or deleting a shortcut
1Launch the shortcuts page, and then select a shortcut.
2Do either of the following:
•Make the necessary changes, and then click Save Changes.
•Click Delete.
Using shortcuts 21
Using shortcuts on the printer
Make sure you have created a shortcut.
From the printer control panel, navigate to:
> Shortcuts > OK > select a shortcut > OK
or
> > enter the shortcut number > OK
Note: If you configured the shortcut to show the settings before running, then the settings will appear on the printer
display. Adjust the settings if necessary.
Using shortcuts 22
Using the printer software
Minimum system requirements
The printer software requires up to 500MB of free disk space.
Supported operating systems
•Microsoft Windows 7 (SP1)
•Microsoft Windows Server 2008 (R2)
•Microsoft Windows Server 2003 (SP2)
•Microsoft Windows Vista (SP2)
•Microsoft Windows XP (SP3)
•Macintosh Intel OS X version 10.7.0 or later
•Macintosh Intel OS X version 10.6.0 or later
•Macintosh Intel OS X version 10.5.0 or later
•Macintosh Intel OS X version 10.4.4 or later*
•Macintosh PowerPC OS X version 10.5.0 or later
•Macintosh PowerPC OS X version 10.4.0 or later*
•Ubuntu Linux 11.10, 10.10, 10.04, 9.10, and 9.04*
•Red Hat Enterprise Linux WS 6, WS 5, and WS 4*
•Red Flag Linux Desktop 6.0*
•SUSE Linux Enterprise Server 11 and 10*
•SUSE Linux Enterprise Desktop 11 and 10*
•Linux openSUSE 12.1, 11.4, 11.3, and 11.2*
•Linpus Linux Desktop 9.6*
•Fedora 16 and 14*
•Debian GNU/Linux 6.0 and 5.0*
* The printer driver for this operating system is available only at http://support.lexmark.com.
Note: Information on additional operating system versions that are compatible with the printer may be available on
our Web site.
Using the Windows printer software
Software installed during printer installation
When you set up the printer using the installation software CD, all the necessary software was installed. You may have
chosen to install some additional programs. The following table provides an overview of various software programs
and what they can help you do.
If you did not install these additional programs during initial installation, then reinsert the installation software CD, run
the installation software, and then click Advanced Options > Install Additional Software.
Using the printer software 23
Printer software
Use the To
LexmarkTM Printer Home
(referred to as Printer Home)
•Launch applications or programs.
•Scan or e‑mail a photo or document.
•Edit scanned documents.
•Scan documents to PDF.
•Adjust settings for the printer.
•Order supplies.
•Maintain ink cartridges.
•Register the printer.
•Contact technical support.
•Access the User's Guide.
Lexmark Phone Book
(referred to as Phone Book)
Manage your fax contacts.
Abbyy Sprint OCR Scan a document and produce text that you can edit with a word‑processing
program.
Lexmark Wireless Setup Utility
(referred to as Wireless Setup Utility)
•Set up the wireless printer on a wireless network.
•Change the wireless settings of the printer.
Note: This program is installed automatically with the printer software if the
printer has wireless capability.
Lexmark Tools for Office
(referred to as Tools for Office)
Access your favorite settings in Microsoft Office 2007.
Printer Setup Utility Configure the fax and e‑mail settings of your printer.
Status Messenger Learn more about the printing problems encountered.
Status Monitor Center •Check the supplies status of your printer.
•Order supplies online.
Product Update Receive automatic notifications of updates to your printer software when new
updates are available.
Printing Preferences When you click File > Print > Properties with a document open, a Printing
Preferences dialog appears. The dialog lets you select options for the print job,
such as the following:
•Select the number of copies to print.
•Print two‑sided copies.
•Select the paper type.
•Add a watermark.
•Enhance images.
•Save settings.
Note: Printing Preferences is installed automatically with the printer software.
Note: Your printer may not come with some of these programs or some of the functions of these programs,
depending on the features of the printer that you purchased.
Using the printer software 24
Using the Macintosh printer software
Launching the Print dialog
Use the Print dialog to adjust the print settings and schedule print jobs.
With a document or photo open, choose File > Print.
Launching an application
1From the Finder, navigate to:
Applications > select your printer folder
2Double‑click the application that you want to use.
Use the To
Printer Settings •Customize settings for fax jobs.
•Create and edit the Contacts list.
•Configure e‑mail connectivity settings.
•Configure the language, country, date, and time.
Shortcuts Speed up usual tasks with your printer.
Wireless Setup
Assistant
Set up the printer on a wireless network.
Note: This application is automatically installed with the printer software if the printer has
wireless capability.
Uninstaller Remove the printer software from your computer.
Notes:
•Your printer may not come with these applications, depending on the features of the printer that you purchased
or the installation type (standard or custom) chosen when you installed the printer.
•To take advantage of the full features of your printer, select the custom install option during installation, and
then select all packages listed.
Accessing Web links
Web links are links to predefined Web pages that are saved in the printer folder.
1From the Finder, navigate to:
Applications > select your printer folder > Web Links
2Double‑click the Web link that you want to visit.
Use To
Customer Support Contact customer support.
Lexmark Software Updates Download and install the latest printer software.
Lexmark Online Visit the Lexmark Web site.
Order Supplies Online Order ink or supplies.
Using the printer software 25
Use To
Printer Registration Register your printer.
Visit Lexmark SmartSolutions •Visit the SmartSolutions Web site.
•Choose your custom solutions.
Note: Your printer may not come with these Web links, depending on the features of the printer that you purchased.
Finding and installing optional software
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Navigate to:
Printer Home > select your printer > Support > Online support
4From the Web site, select your printer and then download the driver.
5Install additional or optional software.
For Macintosh users
1From the Finder, navigate to:
Applications > select your printer folder > Web Links > Lexmark Software Updates
2From the Web site, select your printer and then download the driver.
3Install additional or optional software.
Updating the printer software
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Select your printer, and then click Product Update.
4Follow the instructions on the computer screen.
For Macintosh users
1From the Finder, navigate to:
Applications > select your printer folder > Web Links > Lexmark Software Updates
2From the Web site, select your printer and then download the driver.
Using the printer software 26
Downloading PCL and PS drivers (Windows only)
Universal Print Drivers (PCL 5 emulation, PCL XL emulation, and PS emulation) can be downloaded from our Web site.
You need to search for your printer model to view compatible drivers.
Reinstalling the printer software
When you set up the printer using the installation software CD, all the necessary software was installed. If you
encountered problems while installing, or if your printer does not appear in the printers folder or as a printer option
when you send a print job, then try uninstalling and reinstalling the printer.
Uninstalling the printer software
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Click the uninstaller.
4Follow the instructions on the computer screen.
5Once the uninstall process is complete, restart your computer.
For Macintosh users
1Close all open applications.
2From the Finder, navigate to:
Applications > select your printer folder
3Double‑click Uninstaller.
4Follow the instructions on the computer screen.
Installing the printer software
Note: If you installed the printer software on this computer before but need to reinstall the software, then uninstall
the current software first.
For Windows users
1Close all open software programs.
2Insert the installation software CD.
If the installation dialog screen does not appear after a minute, then launch the CD manually:
aClick , or click Start and then click Run.
bIn the Start Search or Run box, type D:\setup.exe, where D is the letter of your CD or DVD drive.
cPress Enter, or click OK.
Using the printer software 27
3Click Install, and then follow the instructions on the computer screen.
For Macintosh users
Note: To take advantage of the full features of your printer, select the custom install option, and then select all
packages listed.
1Close all open applications.
2Insert the installation software CD.
If the installation dialog does not appear after a minute, then click the CD icon on the desktop.
3Double-click the software installer package, and then follow the instructions on the computer screen.
Using the Internet
1Go to the Lexmark Web site at www.lexmark.com.
2Navigate to:
SUPPORT & DOWNLOADS > select your printer > select your operating system
3Download the driver, and then install the printer software.
Note: Updated printer software may be available at http://support.lexmark.com.
Using the printer software 28
Loading paper and original documents
Loading the paper tray
Make sure:
•The printer is turned on.
•You use paper designed for inkjet printers.
•The paper is not used or damaged.
•You follow the instructions that came with the specialty media.
•The paper does not buckle when you adjust the paper guides.
1Lift the exit bin, and then pull out the tray completely.
2Move the paper guides to the sides of the tray.
Loading paper and original documents 29
3If you are loading legal‑size paper, then squeeze the tab and pull to extend the tray.
4Load the paper with the printable side facedown.
5Adjust the paper guides to rest against the left, right, and bottom edges of the paper.
Note: Make sure the paper is below the maximum fill line located on the edge of the paper tray. Overloading
the tray can cause paper jams.
Loading paper and original documents 30
6Insert the tray.
Note: If you extended the tray to accommodate legal-size paper, then the tray sticks out from the front of the
printer when inserted.
7Fully extend the exit bin, and then flip out the bin extender to catch the paper as it exits.
Loading various paper types
Note: Different paper types and sizes should not be loaded together in the paper tray.
Load up to Make sure
300 sheets of plain paper •The paper is designed for use with inkjet printers.
•The paper guides rest against the left, right, and bottom edges of the
paper.
Loading paper and original documents 31
Load up to Make sure
100 sheets of coated paper
25 sheets of photo paper
25 sheets of glossy paper
•The paper is loaded with the glossy or printable side facedown. If you are
not sure which side is printable, then see the instructions that came with
the paper.
•The paper guides rest against the left, right, and bottom edges of the
paper.
•You do not touch or scratch the glossy surface of the unprinted paper to
prevent smudges or marks that may affect the quality of your prints.
Notes:
•For best results, allow photos to dry at least 24 hours before stacking,
displaying, or storing.
•For best results, load more photo paper than needed, but do not
exceed the maximum number of sheets for your paper type.
10 envelopes
•The envelopes are designed for use with inkjet printers.
•The envelopes are loaded with the printable side facedown and the flap
to the left as shown.
•You load the envelopes in the center of the tray as indicated by the icon.
Load them all the way to the back of the tray.
•You print the envelopes in landscape orientation.
•The paper guides rest against the left, right, and bottom edges of the
envelopes.
•You select the correct envelope size. Set the left and right margins so that
the envelope text will be correctly positioned on the envelope.
Warning—Potential Damage: Do not use envelopes that have metal
clasps, string ties, or metal folding bars.
Notes:
•Do not load envelopes with holes, perforations, cutouts, or deep
embossing.
•Do not use envelopes that have exposed flap adhesive.
Loading paper and original documents 32
Load up to Make sure
25 sheets of labels •You use full label sheets. Partial sheets (with areas exposed by missing
labels) may cause labels to peel off during printing, resulting in a paper
jam.
•You load A4‑ or letter‑size label sheets.
•The labels are loaded with the printable side facedown.
•The top of the labels feeds into the printer first.
•The paper guides rest against the left, right, and bottom edges of the label
sheets.
50 transparencies •The transparencies are loaded with the rough side facedown.
•You load A4‑ or letter‑size transparencies.
•You remove any paper backing sheets from the transparencies before
loading.
•If the transparencies have a removable strip, then each strip faces down.
•The paper guides rest against the left, right, and bottom edges of the
transparencies.
Note: Transparencies require more drying time. Remove each
transparency as it exits, and allow it to dry to avoid ink smudging.
10 iron-on transfers •You follow the loading instructions that came with the iron-on transfers.
•The transfers are loaded with the printable side facedown.
•The paper guides rest against the edges of the transfers.
Note: For best results, load transfers one at a time.
25 index cards, photo papers, or postcards •The thickness does not exceed 0.025 inches (0.635 mm).
•Photo paper is loaded with the printable side facedown.
•You load the photo paper in the center of the tray.
•The paper guides rest against the left, right, and bottom edges of the
paper.
Note: For best results, allow photos to dry at least 24 hours before
stacking, displaying, or storing.
Loading paper and original documents 33
Saving paper settings
You can adjust the settings for your print and copy jobs to match the paper size and type you have loaded in the printer.
1From the printer control panel, press .
2Adjust the settings as needed:
•If you want to set the paper size, then navigate to:
Setup > OK > Paper Setup > OK > Paper Size > OK > select the default paper size > OK
•If you want to set the paper type, then navigate to:
Setup > OK > Paper Setup > OK > Paper Type > OK > select the default paper type > OK
Loading original documents on the scanner glass
1Open the scanner cover and place the document facedown on the scanner glass.
2Close the scanner cover.
Loading paper and original documents 34
Loading original documents into the ADF
Note: Make sure the paper is below the maximum fill line located on the edge of the paper guide. Overloading the
tray can cause paper jams.
1Adjust the paper guides on the ADF input tray to the width of the original document.
2Load the original document faceup and top edge first, until the tip of the document fits snugly into the ADF.
You can load the following paper sizes:
•Letter
•Legal
•8 x 10 inches
•A4
•B5
•A5
•20 x 25 cm
•Executive
•Oficio (Mexico)
•Folio
Note: Make sure that the paper size loaded matches the paper size setting in the scan options menu.
Loading paper and original documents 35
Using different paper sizes and types
For best results, choose a recommended paper for a print job.
Recommended paper brands
For e‑mails, received faxes, internal documents, and similar print jobs
Size Recommended paper Weight Set paper type to
Letter PrintWorks 30% Recycled
Multipurpose Paper #00011
20 lb Plain
A4 UPM Future Multitech 80 g/m2Plain
For colorful and high‑coverage documents
Size Recommended paper Weight Set paper type to
Letter Georgia Pacific Everyday Ink Jet
and Laser Paper #214305
24 lb ColorLok Certified Plain
Hammermill Ultra Premium Laser
Print #16600‑0
Note: For best results, set Page
Dry Time to Extended.
24 lb Premium Plain
Georgia Pacific Premium
Multipurpose Paper #214306
20 lb Colorlok Certified Plain
A4 M‑Real Data Copy Colour Printing
Note: For best results, set Page
Dry Time to Extended.
90 g/m2Premium Plain
SOPORCEL Navigator Universal
Multifunctional
80 g/m2Premium Plain
For résumés, letterhead documents, and similar print jobs
Size Recommended paper Weight Set paper type to
Letter Wausau Professional Series Royal
Linen paper, 30% recycled,
#WAU74089
24 lb Premium Plain
For photos, brochures, business cards, iron‑on transfers, window clings, and other specialty print jobs
Paper and
specialty media
One‑sided or
two‑sided
printing
Recommended paper Set paper type to
Photo One‑sided Lexmark PerfectFinishTM Photo Lexmark PerfectFinish Photo
Lexmark Photo Lexmark Photo
Loading paper and original documents 36
Paper and
specialty media
One‑sided or
two‑sided
printing
Recommended paper Set paper type to
Matte brochure Two‑sided Inkjet matte brochure papers for light‑ or
moderate‑coverage printing:
•Printworks Matte Photo Paper
#00471
•Paperworks Inkjet 2‑sided Matte
Coated 8.5x11 32lb/120g 60pk P/C:
PPPJJ32‑2
Inkjet matte brochure paper for
heavier‑coverage printing:
•Paperworks Inkjet 2‑sided Matte
Coated 8.5x11 44lb/165g 60pk P/C:
PPPJJ44
Inkjet Matte Brochure
Glossy brochure •Red River Zeppelin SemiGloss
•Paperworks Inkjet 2‑sided Semi‑Gloss
P/C:PPPJJ48 and Manufacturer
#:JANUSSM8511
Inkjet Glossy Brochure
Avery specialty •Avery Half‑Fold Greeting Cards for
Inkjet Printers #3265
•Avery Tri‑Fold Brochures for Inkjet
Printers #8324
•Avery Two‑Side Printable Clean Edge
Business cards for Inkjet Printers
#8871
Business Card
Iron‑on transfer One‑sided Avery T‑shirt Transfers for Inkjet Printers
#3271
Iron‑On Transfer
Clear window
cling
Micro Format, Inc., Super Color Cling
#SP5676
Transparency
Transparent film 3M Inkjet Transparency Film #CG3480 Transparency
Setting the paper size and type
You can adjust the settings for your print and copy jobs to match the paper size and type you have loaded in the printer.
Using the printer control panel
1From the printer control panel, press .
2Adjust the settings as needed:
•If you want to set the paper size, then navigate to:
Setup > OK > Paper Setup > OK > Paper Size > OK > select the paper size you want > OK
•If you want to set the paper type, then navigate to:
Setup > OK > Paper setup > OK > Paper Type > OK > select the paper type you want > OK
Loading paper and original documents 37
Using the printer software
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Click the Paper/Finishing tab, and then select the size or type of paper to use, and the paper source or tray.
4Click OK.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the Page Setup dialog, set the printer, paper size, and orientation.
3Click OK.
4From the menu bar, choose File > Print.
5From the Printer pop‑up menu, choose your printer.
6From the print options pop‑up menu, choose Quality & Media.
7From the Paper Type pop‑up menu, choose the type of paper to use.
Setting the page dry time
Using the control panel
1From the printer control panel, navigate to:
> Setup > OK > Print Mode Setup > OK > Page Dry Time > OK
2Press the up or down arrow button to scroll to the dry time setting you want, and then press OK .
Note: The dry time varies depending on the print quality selected for the print job. Select Extended to extend the
dry time for your prints.
Using the printer software
For Windows users
1Click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Layout tab > Print on Both Sides (Duplex) area > select a dry time setting
Note: Under conditions of high humidity, or if the normal drying time does not allow the ink to dry completely,
select Extended.
4Click OK.
Loading paper and original documents 38
For Macintosh users
1From the Apple menu, navigate to:
System Preferences > Print & Fax > select your printer
2Navigate to:
Open Print Queue > Printer Setup > Driver tab
or
Printer Setup > Installable Options
3From the Two‑Sided Printing Dry Time pop‑up menu, choose a dry time setting.
Note: Under conditions of high humidity, or if the normal drying time does not allow the ink to dry completely,
choose Extended.
4Click OK or Apply Changes.
Linking trays
Tray linking is useful for large print jobs or multiple copies. If two trays contain paper of the same size and type, and
the trays have the same settings, then the trays are automatically linked. When one tray is empty, the print job continues
using the linked tray.
From the printer control panel, navigate to:
> Setup > OK > Paper Setup > OK > Paper Tray Linking >
OK
> Automatic > OK
Notes:
•Optional trays are purchased separately. For more information, contact the place where you purchased the
printer.
•Make sure the printer is off before installing the optional tray.
•The paper type and paper size in the default paper tray and the optional tray should match to avoid a media
type mismatch error.
Loading paper and original documents 39
Printing
Tips for printing
•Make sure the exit bin is fully extended and the bin extender is flipped out.
•Use the appropriate paper for your print job.
•Select a higher print quality for better prints.
•Make sure there is enough ink in the ink cartridges.
•Remove each sheet as it is printed when printing photos or when working with specialty media.
Printing basic documents
Printing a document
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Select the print quality, the number of copies to print, the type of paper to use, and how the pages should print.
4Click OK to close any printer software dialogs.
5Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the Page Setup dialog, set the printer, paper size, and orientation.
3Click OK.
4From the menu bar, choose File > Print.
5From the Printer pop‑up menu, choose your printer.
6From the print options menu, choose the print quality, the number of copies to print, the type of paper to use, and
how the pages should print.
7Click Print.
Printing 40
Printing using advanced color options
Color printing is enabled by default. To optimize print colors for a special print job, use Color Preference and Advanced
Color Options.
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Quality tab > Color Extras area
4Select either Color Preference or Advanced Color Options.
•If you select Color Preference, then select either Natural or Vivid.
•If you select Advanced Color Options, then select Use ICC test Chart Process.
5From the “Ink to Use” area, select either of the following:
•Color + Black to use four inks including black.
•Color Only to use cyan, magenta, and yellow inks.
6Click OK to close any printer software dialogs.
7Click OK or Print.
For Macintosh users
1With a document open, choose File > Print.
2From the printer pop‑up menu, choose your printer.
3From the print options pop‑up menu, choose Quality & Media > Advanced Options.
4From the “Ink to Use” pop‑up menu, choose either of the following:
•Color + Black to use four inks including black.
•Color Only to use cyan, magenta, and yellow inks.
5From the Color Preferences area, choose Natural or Vivid, or choose Use ICC Test Chart Process.
6Click Print.
Collating printed copies
When printing multiple copies of a document, you can choose to print each copy as a set (collated) or to print the copies
as groups of pages (not collated).
Collated Not collated
Notes:
•The collate option is available only when you are printing multiple copies.
Printing 41
•To prevent smudging when printing photos, remove each photo as it exits the printer, and then let it dry before
stacking.
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Layout tab > Copies area
4Enter the number of copies that you want to print, and then select Collate.
5Click OK to close any printer software dialogs.
6Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the Page Setup dialog, set the printer, paper size, and orientation.
3Click OK.
4From the menu bar, choose File > Print.
5From the Printer pop‑up menu, choose your printer.
6From the Copies area, enter the number of copies that you want to print, and then select Collated.
7Click Print.
Changing the print order of pages
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Layout tab > Copies area
4To change the current page order, select the Reverse page order check box.
5Click OK to close any printer software dialogs.
6Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the Page Setup dialog, set the printer, paper size, and orientation.
3Click OK.
4From the menu bar, choose File > Print.
Printing 42
5From the Printer pop‑up menu, choose your printer.
6From the print options pop-up menu, choose Paper Handling.
7From the Page Order pop‑up menu, choose a page order:
•To print the first page first, choose Normal.
•To print the last page first, choose Reverse.
8Click Print.
Printing multiple pages on one sheet
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Layout tab > Page Layouts area > select Multiple pages per side (N‑Up)
4Select the number of page images to print on each side.
5Adjust other settings as needed.
6Click OK to close any printer software dialogs.
7Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the Page Setup dialog, set the printer, paper size, and orientation.
3Click OK.
4From the menu bar, choose File > Print.
5From the Printer pop‑up menu, choose your printer.
6From the print options pop‑up menu, choose Layout.
7From the Pages per Sheet pop‑up menu, choose the number of page images to print on each page.
8Adjust other settings as needed.
9Click Print.
Printing 43
Printing documents from a memory card or flash drive
Notes:
•The printer reads only one memory device at a time.
•Make sure the memory device contains document files that are supported by the printer.
1Insert a memory card or flash drive.
When the printer detects the memory device, Memory Card Detected or Storage Device Detected
appears on the display.
2If document files are stored on the memory device, then the printer automatically switches to File Print mode.
If document files and image files are stored on the memory device, then press the left or right arrow button to scroll
to Documents, and then press OK .
3Press the up or down arrow button to scroll to the document, and then press OK to select the document for printing.
4From the Print Options menu screen, use the arrow buttons to select your printing options, and then press OK , if
necessary.
Note: You may select the number of copies, color mode, print quality, paper settings, and paper‑saving options.
You can also enhance sharpness and use separator sheets.
5Press .
Printing specialty documents
Printing envelopes
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Paper/Finishing tab > Paper size list > select your envelope size
If no size matches the envelope size, then click Manage Custom Sizes and set a custom size.
4Navigate to:
Paper type list > select Envelope
5Navigate to:
Layout tab > Page Orientation area > select an orientation
6Click OK to close any printer software dialogs.
7Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the “Format for” pop‑up menu, choose your printer.
Printing 44
3From the Paper Size pop‑up menu, choose your envelope size.
If no size matches the envelope size, then set a custom size.
4Select an orientation, and then click OK.
5From the menu bar, choose File > Print.
6From the Printer pop‑up menu, choose your printer.
7Click Print.
Notes:
•Most envelopes use landscape orientation.
•Make sure the same orientation is also selected in the application.
Printing on labels
Notes:
•Make sure the top of the label sheet feeds into the printer first.
•Make sure the adhesive on the labels does not extend to within 1 mm of the edge of the label sheet.
•Make sure the paper guide or paper guides rest against the edges of the label sheet.
•Use full label sheets. Partial sheets (with areas exposed by missing labels) may cause labels to peel off during
printing, resulting in a paper jam.
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Paper/Finishing tab > Manage Custom Sizes > New
4Type a name and adjust the settings as needed to create a custom size, and then click OK.
5Navigate to:
Paper type list > select the created custom type
6Click OK to close any printer software dialogs.
7Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the “Format for” pop‑up menu, choose your printer.
3From the Paper Size pop‑up menu, choose your paper size.
If no paper size matches the label sheet size, then set a custom size.
4Select an orientation, and then click OK.
5From the menu bar, choose File > Print.
Printing 45
6From the Printer pop‑up menu, choose your printer.
7From the print options pop‑up menu, choose Quality & Media.
8From the Paper Type pop‑up menu, choose Labels.
9From the Print Quality menu, choose a print quality other than Quick Print or Draft.
10 Click Print.
Printing on custom‑size paper
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Paper/Finishing tab > Manage Custom Sizes > New
4Type a name and adjust the settings as needed to create a custom size, and then click OK.
5Click Close, and then click OK to close any printer software dialogs.
6Click OK or Print.
For Macintosh users
1With a document open, choose File > Page Setup.
2From the “Format for” pop‑up menu, choose your printer.
3From the Paper Size pop‑up menu, choose Manage Custom Sizes.
4Adjust the settings as needed to create a custom size, and then click OK.
5Click OK.
6From the menu bar, choose File > Print.
7From the printer pop‑up menu, choose your printer.
8Click Print.
Printing 46
Working with photos
Supported memory cards and file types
Memory card File type
•Secure Digital (SD)
•Secure Digital High Capacity (SDHC)
•Micro Secure Digital (with adapter) (Micro SD)
•Mini Secure Digital (with adapter) (Mini SD)
•MultiMedia Card (MMC)
•Reduced Size MultiMedia Card (with adapter) (RS‑MMC)
•MultiMedia Card mobile (with adapter) (MMCmobile)
•Memory Stick
•Memory Stick PRO
•Memory Stick Duo (with adapter)
•Memory Stick PRO Duo (with adapter)
•xD‑Picture Card
•xD‑Picture Card (Type H)
•xD‑Picture Card (Type M)
Documents:
•.pdf (Adobe Portable Document Format)
Images:
•.jpg, .jpeg, .jpe (Joint Photographic Experts Group)
•.tiff, .tif (Tagged Image File Format)
Using a memory card or flash drive with the printer
Insert a memory card into the card slot or a flash drive into the USB port.
Printing 47
Inserting a memory card Inserting a flash drive
Notes:
•Insert the card with the brand name label facing up.
•Make sure any arrows on the card point toward the printer.
•If necessary, connect the memory card to the adapter that
came with it.
•Make sure that the memory card inserted is supported by the
printer. For more information, see “Supported memory cards
and file types” on page 47.
•The card reader light comes on when a memory card is inserted
and blinks when a memory card is being accessed.
Notes:
•The flash drive uses the same port that is used
for a PictBridge camera cable.
•An adapter may be necessary if your flash drive
does not fit directly into the port.
Warning—Potential Damage: Do not touch any cables, ports, any
network adapter, any connector, the memory device, or the printer in the
areas shown while actively printing, reading, or writing from the memory
device. A loss of data can occur.
Follow the instructions on the printer display or select from available options.
Notes:
•If the printer does not recognize the memory device, then remove and reinsert it.
•The printer reads only one memory device at a time.
Printing 48
Printing photos from a memory card or flash drive
1Load photo paper.
2Insert a memory card, flash drive, or digital camera set to mass storage mode.
If image files and document files are stored in the memory device, then press the left or right arrow button to select
Photos, and then press OK .
Note: Only files with supported file types will be shown.
3Use the up or down arrow button to select a photo printing option, and then press OK .
•Select and Print allows you to choose a layout, the number of photos per page, paper settings, photo
size, photo quality, and to sharpen the quality of graphics.
•Print Photos allows you to print all photos, selected photos by photo range, and print photos using
predefined photo size templates.
4To adjust the print settings, press the up or down arrow button to scroll to the option you want to set, and then
press the left or right arrow button to scroll to the setting you want. If necessary, press
OK
to make a selection.
5Press .
Note: For best results, allow the prints to dry at least 24 hours before stacking, displaying, or storing.
Printing photos from a PictBridge-enabled digital camera
PictBridge is a technology available in most digital cameras that lets you print directly from your digital camera without
using a computer.
1Insert one end of the USB cable into the camera.
Note: Use only the USB cable that came with the camera.
2Insert the other end of the cable into the PictBridge port on the front of the printer.
Notes:
•Make sure that the digital camera is set to the correct USB mode. If the camera USB selection is incorrect,
then the camera is detected as a flash drive, or an error message is displayed on the printer control panel.
For more information, see the documentation that came with the camera.
•The printer reads only one memory device at a time.
Printing 49
Warning—Potential Damage: Do not touch any open connector, the
memory device, or the printer in the areas shown while actively
printing, reading, or writing from the memory device. A loss of data
can occur.
3If the PictBridge connection is successful, then the following message appears on the display: Use PictBridge
Device to choose and print photos. Press OK to select printer default
settings.
4If you want to change the default print settings:
aPress OK to access the PictBridge menu.
bPress the arrow buttons to select the paper source, paper setup, photo size, number of photos per page and
print quality. You can also enhance the quality of graphics. Press OK each time you make a selection.
Note: The printer will use the default print settings unless you change the print settings from the camera.
5See the documentation that came with the camera to begin printing.
Note: If you insert the USB cable of the PictBridge‑enabled camera while the printer is performing another job, then
wait for the job to finish before printing from the camera.
Printing on both sides of the paper (duplexing)
Printing on both sides of the paper (duplexing) automatically
The automatic duplex unit supports A4‑, A5‑, letter‑, legal‑, statement‑, and executive‑size paper.
Notes:
•Other paper sizes may be supported.
•Two-sided printing is not supported on envelopes, card stock, or photo paper.
•Do not remove the page until printing is finished.
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Layout tab > Print on Both Sides (Duplex) area > select Print on both sides
4Click OK to close any printer software dialogs.
5Click OK or Print.
Printing 50
To return to single-sided printing, repeat steps 1 and 2, and then navigate to:
Layout tab > Print on Both Sides (Duplex) area > select Print on one side only
For Macintosh users
1With a document open, choose File > Page Setup.
2From the Page Setup dialog, set the printer, paper size, and orientation.
3Click OK.
4From the menu bar, choose File > Print.
5From the Printer pop‑up menu, choose your printer.
6From the print options pop‑up menu, choose Quality & Media.
7From the Paper Type pop‑up menu, choose Plain Paper.
8From the print options pop‑up menu, choose Layout.
9From the Two‑Sided pop‑up menu, choose Long‑Edge binding or Short‑Edge binding.
•For Long‑Edge binding, pages are bound along the long edge of the page (left edge for portrait, top edge for
landscape).
Portrait Landscape
1
2
1
2
•For Short‑Edge binding, pages are bound along the short edge of the page (top edge for portrait, left edge for
landscape).
Portrait Landscape
10 Click Print.
Printing 51
Setting the duplex printing dry time
Using the control panel
1From the printer control panel, navigate to:
> Setup > OK > Print Mode Setup > OK > Page Dry Time > OK
2Press the up or down arrow button to scroll to the dry time setting you want, and then press OK .
Note: The dry time varies depending on the print quality selected for the print job. Select Extended to extend the
dry time for your prints.
Using the printer software
For Windows users
1Click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Layout tab > Print on Both Sides (Duplex) area > select a dry time setting
Note: Under conditions of high humidity, or if the normal drying time does not allow the ink to dry completely,
select Extended.
4Click OK.
For Macintosh users
1From the Apple menu, navigate to:
System Preferences > Print & Fax > select your printer
2Navigate to:
Open Print Queue > Printer Setup > Driver tab
or
Printer Setup > Installable Options
3From the Two‑Sided Printing Dry Time pop‑up menu, choose a dry time setting.
Note: Under conditions of high humidity, or if the normal drying time does not allow the ink to dry completely,
choose Extended.
4Click OK or Apply Changes.
Printing 52
Managing print jobs
Finding the print queue for your printer
A print queue represents the printer that is connected to your computer. The print queue name is usually the printer
model or the printer nickname assigned when installing or adding the printer.
Note: Several print queues may appear in the list depending on how the printer is connected (USB, Ethernet,
wireless). Make sure you know how your printer is connected to the computer to be able to select the correct print
queue.
For Windows users
1Open the printers folder.
aClick , or click Start and then click Run.
bIn the Start Search or Run box, type control printers.
cPress Enter, or click OK.
2Find the print queue for your printer (Network or USB).
3If the print queue is not in the list, then create a new print queue.
For Macintosh users
1From the Apple menu, navigate to:
System Preferences > Print & Fax > the print queue for your printer
2If the print queue is not in the list, then create a new print queue.
Creating a print queue
For Windows users
1From the Printer Tasks area, click Add a Printer.
2Follow the instructions on the computer screen.
For more information, see the documentation that came with your operating system.
For Macintosh users
1From the Print & Fax area, click +.
2If necessary, click the Default or Default Browser tab.
3Select your printer from the list.
Note: Printers connected to the network or locally through a USB cable may have the same default printer
name. If necessary, use the Name field to rename the printer.
4Click Add.
Printing 53
Setting your printer as the default printer
Your printer should be selected automatically from the Print dialog when you send a print job. If you have to manually
select your printer, then it is not the default printer.
To set the default printer:
For Windows users
1Click , or click Start and then click Run.
2In the Start Search or Run box, type control printers.
3Press Enter, or click OK.
The printers folder opens.
4Right‑click the printer, and then select Set as Default Printer.
For Macintosh users
1From the Apple menu, navigate to:
System Preferences > Print & Fax
2Select the printer from the Default Printer pop‑up menu, or select the printer and click Make Default.
Changing the default printing mode
To conserve ink, you can change the default printing mode for all print jobs to Draft or Quick Print. It uses less ink and
is recommended for printing text-only documents. If you need to change to a different print mode to print photos or
other high-quality documents, then you can select a different mode from the Print dialog before sending the print job.
For Windows users
1With a document open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Quality tab > select a print quality > OK
For Macintosh users
1With a document open, choose File > Print.
2From the printer pop‑up menu, choose your printer.
3From the print options pop-up menu, choose Quality & Media.
4From the Print Quality pop‑up menu, choose a print quality.
5Click OK.
Printing 54
Pausing print jobs
For Windows users
1Click , or click Start and then click Run.
2In the Start Search or Run box, type control printers.
3Press Enter, or click OK.
The printers folder opens.
4Right‑click the printer, and then select Open or See what's printing.
5Pause the print job:
•If you want to pause a particular print job, then right‑click the document name, and then select Pause.
•If you want to pause all print jobs in the queue, then click Printer, and then select Pause Printing.
For Macintosh users
1Click the printer icon on the Dock.
The print queue dialog appears.
2Pause the print job:
•If you want to pause a particular print job, then choose the document name, and then click Hold.
•If you want to pause all print jobs in the queue, then click Pause Printer or Stop Jobs.
Resuming print jobs
For Windows users
1Click , or click Start and then click Run.
2In the Start Search or Run box, type control printers.
3Press Enter, or click OK.
The printers folder opens.
4Right‑click the printer, and then select Open or See what's printing.
5Resume the print job:
•If you want to resume a particular print job, then right‑click the document name, and then select Resume or
Restart.
•If you want to resume all print jobs in the queue, then click Printer, and then clear the selection for Pause
Printing.
For Macintosh users
1From the Apple menu, navigate to:
System Preferences > Print & Fax > select your printer
2Click Open Print Queue or Set Up Printers.
The print queue dialog appears.
Printing 55
3Resume the print job:
•If you want to resume a particular print job, then choose the document name, and then click Resume.
•If you want to resume all print jobs in the queue, then click Resume Printer or Start Jobs.
Canceling print jobs
To cancel a print job from the printer control panel, press , and then press OK . Printing stops and the printer returns
to the home screen.
To cancel a print job from the computer, do the following:
For Windows users
1Click , or click Start and then click Run.
2In the Start Search or Run box, type control printers.
3Press Enter, or click OK.
The printers folder opens.
4Right‑click the printer, and then select Open or See what's printing.
5Cancel the print job:
•If you want to cancel a particular print job, then right‑click the document name, and then select Cancel.
•If you want to cancel all print jobs in the queue, then click Printer > Cancel All Documents.
For Macintosh users
1Click the printer icon on the Dock.
The print queue dialog appears.
2Choose the job you want to cancel, and then click Delete.
Printing from a mobile device
What is LexPrint?
LexPrint is a free application that lets you print easily from your iPad, iPhone, or iPod touch using any Lexmark printer
connected to the same wireless network. It lets you print Web pages, photos from the photo album, or photos you
recently captured using the camera of your mobile device, depending on its features. You can also customize print
settings from your mobile device.
Depending on your Lexmark printer model, you may need to download the LexPrint Listener application from our Web
site at www.lexmark.com/lexprint.
Printing 56
Supported printers
LexPrint enables your mobile device to communicate with Lexmark printers found on the same network.
•For select printer models that support Direct Image and Zeroconf or Bonjour, you can print directly from your mobile
device to the printer without using LexPrint Listener. To check if your printer model supports these features, visit
www.lexmark.com/lexprint.
•For other Lexmark printers, your mobile device can send print jobs to your printer as long as the printer software
and LexPrint Listener are installed on the computer where the printer is connected.
Note: The application referred to as Rendezvous in Mac OS X version 10.2 is now called Bonjour by Apple Inc.
Printing 57
Copying
ADF Scanner glass
Use the ADF for multiple‑page documents.
Note: The ADF is available only in select printer models. If you
purchased a printer without an ADF, then load original
documents or photos on the scanner glass.
Use the scanner glass for single pages, small items (such
as postcards or photos), transparencies, photo paper, or
thin media (such as magazine clippings).
Tips for copying
•Make sure the exit bin is fully extended and the bin extender is flipped out.
•Use the ADF when scanning two‑sided pages if your printer supports duplex scanning and the ADF supports the
original document size.
•Use the scanner glass when scanning two‑sided pages if your printer does not support duplex scanning or the ADF
does not support the original document size.
•When using the ADF, adjust the paper guides on the ADF to the width of the original document.
•To easily retrieve a document after copying or scanning, lift the ADF input tray.
•When using the scanner glass, close the scanner cover, if possible, to avoid dark edges on the scanned image.
•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)
into the ADF. Place these items on the scanner glass.
•When the document to be copied is in place with the settings you want, press to start copying.
Making copies
1Load paper.
2Load an original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Copies
4Press the left or right arrow button to select the number of copies.
Copying 58
5From the Copy menu screen, press the up or down arrow button to scroll to the option you want to set, and then
press the left or right arrow button to scroll to the setting you want. If necessary, press OK to make a selection.
6Select the copy mode:
•Press to switch to color mode.
•Press to switch to black‑and‑white mode.
When you select color or black‑only printing, the light that corresponds to your choice comes on.
7Press .
Note: The selected copy settings are reset to the factory default after two minutes of printer inactivity.
Copying an ID card
1Load plain A4‑ or letter‑size paper.
2From the printer control panel, navigate to:
> Copy > OK > ID Card Copy
3Press , and then load the front side of the ID card facedown at the placement corner of the scanner glass.
4Press .
5When prompted to copy the back side of the ID card, press the left or right arrow button to scroll to Yes, and then
press OK .
6Load the back side of the ID card facedown at the placement corner of the scanner glass, and then press .
Enlarging or reducing images
1Load paper.
2Load the original document facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Scale
4Press the left or right arrow button to scroll to the Scale setting you want.
Notes:
•If you select Custom %, then press OK , and then press the left or right arrow button to select a custom
percent value. Press OK to save the setting.
•If you select Borderless, then the printer will reduce or enlarge the document or photo as necessary to print
a borderless copy on the paper size that you selected. For best results with this setting, use photo paper and
set the paper type to Photo.
•If you select Fit to Page, then the printer scales the document or photo proportionately to fit a single page.
5Press .
Copying 59
Adjusting copy quality
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Quality
4Press the left or right arrow button to set the copy quality.
5From the Copy menu, select Content Type.
6Press the left or right arrow button to scroll to the type that describes the original document, and then press
OK
.
7From the Copy menu, select Content Source.
8Press the left or right arrow button to scroll to the option that describes how the original document was produced,
and then press OK .
9Press .
Making a copy lighter or darker
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Darkness
4Press the left or right arrow button to adjust the darkness of your prints.
•Pressing the left arrow button makes the copy lighter.
•Pressing the right arrow button makes the copy darker.
5Press .
Collating copies using the printer control panel
If you print multiple copies of a document, then you can choose to print each copy as a set (collated) or to print the
copies as groups of pages (not collated).
Collated Not collated
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy >
OK
> Copies
Copying 60
4Press the left or right arrow button to select the number of copies.
5Press the up or down arrow button until Collate appears.
6Press the left or right arrow button to scroll to On, and then press .
Placing separator sheets between copies
A separator sheet is a sheet of paper placed between pages, copies, or jobs based on the setting selected. This feature
is useful when printing transparencies.
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Separator Sheets
Note: Collate must be set to On for the separator sheets to be placed between copies. If Collate is set to Off,
then the separator sheets are added at the end of the print job.
4Press the left or right arrow button to select a separator sheet setting, and then press .
Copying multiple pages on one sheet
You can copy multiple pages on one sheet by printing smaller images of each page. For example, you can condense a
20‑page document into five pages if you use this setting to print four page images per sheet.
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Pages per Side
4Press the left or right arrow button to select the paper orientation and the number of pages that you want to copy
on a sheet of paper. You may print up to four page images on one sheet.
5Press .
Placing an overlay message on each page
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Overlay
4Press the left or right arrow button to select an overlay setting.
Note: For select printer models with a keypad, use the keypad to enter a custom text overlay, and then press
OK
. To change a character, press the left arrow button. To add a space, press the number 0.
5Press .
Copying 61
Removing the background of a copy
The Background Removal feature adjusts the amount of background visible on a copy.
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > Background Removal
4Press the left or right arrow button to select the amount of background removal.
5Press .
Making a duplex (two-sided) copy
Making a duplex (two‑sided) copy automatically
The automatic duplex unit supports A4-, A5-, letter-, legal-, statement-, and executive-size paper. If you need to make
two‑sided copies using other paper sizes, then see the instructions for making a two‑sided copy manually.
Note: You cannot make two‑sided copies on envelopes, card stock, or photo paper.
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
3From the printer control panel, navigate to:
> Copy > OK > 2‑Sided Copies
4Press the left or right arrow button to select a two‑sided copying option:
•If you are copying a one‑sided document, then press the arrow buttons to scroll to 1‑sided to 2‑sided.
•If you are copying a two-sided document and using the scanner glass, then press the arrow buttons to scroll to
2‑sided to 2‑sided.
•If you want to specify the page orientation and layout of the original document and the copy, then press the
arrow buttons to scroll to Advanced. Press OK every time you make a selection, and then press until you
reach the Copy menu.
Notes:
•For long-edged binding, pages are bound along the long edge of the page (left edge for portrait orientation
and top edge for landscape orientation).
•For short-edged binding, pages are bound along the short edge of the page (top edge for portrait orientation
and left edge for landscape orientation).
5Press , and then follow the instructions on the printer display.
Making a duplex (two‑sided) copy manually
1Load paper.
2Load the original document faceup into the ADF or facedown on the scanner glass.
Copying 62
3From the printer control panel, navigate to:
> Copy > OK > Copies
4Press the left or right arrow button to select the number of copies.
5From the Copy menu screen, press the up or down arrow button to scroll to the option you want to set, and then
press the left or right arrow button to scroll to the setting you want. If necessary, press OK to make a selection.
6Select the copy mode:
•Press to switch to color mode.
•Press to switch to black‑and‑white mode.
When you select color or black‑only printing, the light that corresponds to your choice comes on.
7Press to print on one side of the paper.
8Load the next page of the document.
•If you are copying a one‑sided document, then load the next page faceup into the ADF or facedown on the
scanner glass.
•If you are copying a two‑sided document, then flip the original document, and then reload it faceup into the
ADF or facedown on the scanner glass.
9Remove the paper from the exit bin, and then reload the paper to print the other side of the document.
Make sure the paper is loaded with the printable side facedown.
10 When prompted to confirm the paper settings, press the left or right arrow button to scroll to Yes, and then press
OK .
11 Press .
Canceling copy jobs
To cancel a copy job, press , and then press OK .
Scanning stops and the printer returns to the previous menu.
Copying 63
Scanning
ADF Scanner glass
Use the ADF for multiple‑page documents.
Note: The ADF is available only in select printer models. If you
purchased a printer without an ADF, then load original
documents or photos on the scanner glass.
Use the scanner glass for single pages, small items (such
as postcards or photos), transparencies, photo paper, or
thin media (such as magazine clippings).
Tips for scanning
•Use the ADF when scanning two‑sided pages if your printer supports duplex scanning and the ADF supports the
original document size.
•Use the scanner glass when scanning two‑sided pages if your printer does not support duplex scanning or the ADF
does not support the original document size.
•When using the ADF, adjust the paper guides on the ADF to the width of the original document.
•To easily retrieve a document after copying or scanning, lift the ADF input tray.
•When using the scanner glass, close the scanner cover, if possible, to avoid dark edges on the scanned image.
•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)
into the ADF. Place these items on the scanner glass.
•When the document to be scanned is in place with the settings you want, press to start scanning.
Scanning to a local computer
1Load the original document faceup into the ADF or facedown on the scanner glass.
2From the printer control panel, navigate to:
> Scan > OK > Computer > USB‑Connected Computer > OK
The USB‑connected computer will receive the scan by default.
Note: Make sure the scan software is installed on the destination computer.
Scanning 64
3Press the up or down arrow button to scroll to the scan option you want to set, and then press the left or right
arrow button to scroll to the setting you want.
Set the color, quality, original image size, and other scan options. If necessary, press OK each time you make a
selection.
4Press .
Scanning to a network computer
1Load the original document faceup into the ADF or facedown on the scanner glass.
2From the printer control panel, navigate to:
> Scan > OK > Computer
3Press the left or right arrow button to manually select the name of the destination computer, and then press OK .
Notes:
•You may be prompted to enter a PIN if the computer requires it.
•To assign a computer name and a PIN to the computer, see the Help for the printer software associated with
your operating system.
4Press the up or down arrow button to scroll to the scan option you want to set, and then press the left or right
arrow button to scroll to the setting you want.
Set the color, quality, original image size, and other scan options. If necessary, press OK each time you make a
selection.
5Press .
Note: For Macintosh users, you may need to enable scanning to your computer through Image Capture to scan
documents using a network printer and save the scan output.
Scanning to a network folder
Notes:
•This feature may not appear in the Embedded Web Server, depending on your printer model.
•Make sure you have created a folder shortcut before you begin. For more information, see “Adding a network
folder shortcut” on page 66.
1Load the original document faceup into the ADF or facedown on the scanner glass.
2From the printer control panel, navigate to:
> Scan > OK > Network Folder > OK
3Press the left or right arrow button to scroll to the name of the network shared folder you want, and then press
OK .
4Press the up or down arrow button to scroll to the scan option you want to set, and then press the left or right
arrow button to scroll to the setting you want.
Scanning 65
5Set the color, quality, original image size, and other scan options. If necessary, press OK each time you make a
selection.
6Press .
Note: For Macintosh users, you may need to enable scanning to your computer through Image Capture to scan
documents using a network printer and save the scan output.
Adding a network folder shortcut
1On your computer, create a shared folder with read/write access.
2On a Web browser, type your printer IP address, and then press Enter.
3Navigate to either of the following:
•Settings > Scan‑to‑Network Folder Setup
•Settings > Manage Shortcuts > Add New Shortcut > Scan to Network
4Enter the necessary information, and then click Add.
Note: To avoid unsaved changes to your settings, make sure the network folder shortcut name is different from that
of your folder name.
Scanning to a flash drive or memory card
Notes:
•Some features are available only in select printer models.
•Make sure your flash drive or memory card is not write‑protected.
1Load the original document faceup into the ADF or facedown on the scanner glass.
2From the printer control panel navigate to:
> Scan > OK > Memory Device
3Insert the flash drive or memory card, and then press OK .
Note: The printer reads only one memory device at a time.
4Press the up or down arrow button to scroll to the scan option you want to set, and then press the left or right
arrow button to scroll to the setting you want.
Set the color, quality, original image size, and other scan options. If necessary, press OK each time you make a
selection.
5Press .
Follow the instructions on the printer display.
Scanning 66
Scanning photos
For Windows users
1Load the photo or photos facedown on the scanner glass.
2Click or Start.
3Click All Programs or Programs, and then select the printer program folder from the list.
4Navigate to:
Printer Home > select your printer > Scan > Advanced scan
5From the Scan Source list, select Flatbed.
6From the Scan Settings tab, select the appropriate settings:
aSet Resolution (dpi) to 150 dpi or more.
bSet Color Depth to Color.
cSet Content Type to Photo.
dFrom the Original Types list, select the item that best describes your original photo.
•For example, if you are scanning a glossy photo printed on your inkjet printer, then select Inkjet Glossy.
•If you are scanning a glossy photo purchased from a photo print service, then select Retail Photo.
7Click Scan, and then follow the instructions on the computer screen.
8When the scan is complete, save the photo or photos as JPEG(*.JPG).
For Macintosh users
1Load the photo or photos facedown on the scanner glass.
2From the Applications folder in the Finder, launch Image Capture.
3From the list of devices, select your printer.
Note: If your printer name is not present in the list of devices, then you need to create a print queue for your
printer. For more information, see the documentation that came with your operating system.
4Adjust the scan settings as follows:
aSet Kind to Color.
bSet Resolution to 150 dpi or more.
cSet Format to JPEG.
dSet Original Type to the item that best describes your original photo.
•For example, if you are scanning a glossy photo printed on your inkjet printer, then select Inkjet Glossy Photo.
•If you are scanning a glossy photo purchased from a photo print service, then select Retail Glossy Photo.
5Start the scan job.
Scanning 67
Scanning directly from the printer control panel
1Load the photo or photos facedown on the scanner glass.
Note: If you have sheets loaded on the ADF and photos loaded on the scanner glass, then the sheets on the ADF
will be scanned. Make sure to clear the ADF if you want to scan the photos on the scanner glass.
2From the printer control panel, navigate to:
> Scan > OK > select a scan destination
If necessary, follow the instructions on the printer display.
Note: If you have selected a computer as the scan destination, then make sure that the scan software is
installed on the destination computer.
3From the Scan Options menu, press the up or down arrow button to scroll to the scan option you want to set, and
then press the left or right arrow button to select an appropriate setting.
If necessary, press OK each time you make a selection.
aSet File Type to Photo.
bSet Quality to 150 dpi or more.
cSet Content Type to Photo.
dSet Content Source to the option that best describes your original photo.
•For example, if you are scanning a glossy photo printed on your inkjet printer, then select Inkjet Glossy.
•If you are scanning a glossy photo purchased from a photo print service, then select Retail Photo.
4Press .
Scanning documents for editing
An Optical Character Recognition (OCR) application allows you to edit an original text document that has been scanned.
In order for this to work, you must have an OCR application stored on a local or network computer and you must be
able to select it from the list of applications when you set up the scan.
When selecting settings for the scan, select to scan to the local computer or network computer where the OCR is
installed.
For Windows users
1Load the original document faceup into the ADF or facedown on the scanner glass.
2Click or Start.
3Click All Programs or Programs, and then select the printer program folder from the list.
4Navigate to:
Printer Home > select your printer > Scan > Document
Scanning starts and the scan progress dialog appears.
5When the scan is finished, save the document.
The file will be converted into a format that can be edited.
6Open the document in the appropriate application to edit it.
Scanning 68
For Macintosh users
1Load the original document faceup into the ADF or facedown on the scanner glass.
2From the Applications folder in the Finder, launch the application you want to use.
Notes:
•Use any application that supports your printer and lets you work with the OCR software, ABBYY FineReader.
•If the OCR software is missing, then insert the installation software CD. Reinstall the printer software using
the custom install option so you can manually select all of the packages listed.
3From the list of devices, select your printer.
Note: For information on finding the list of devices, check the documentation that came with the application or
search for Scanning an image in the Search field of the Help menu.
4Adjust the scan settings as needed.
Note: Use a scan resolution of 300 dpi or more.
If applicable, click
?
on the preview dialog for more information.
5Set the OCR software as the scan destination, and then start the scan job.
6If necessary, select the format to which you want to convert the file.
7Save the file.
Note: Depending on your settings, the file may open immediately in the appropriate application so you can start
editing.
Scanning directly to e‑mail using the printer software
Make sure you have set up your e‑mail settings before proceeding. For more information, see the section on e‑mailing
in the User’s Guide.
For Windows users
1Load an original document faceup into the ADF or facedown on the scanner glass.
2Click or Start.
3Click All Programs or Programs, and then select the printer program folder from the list.
4Navigate to:
Printer Home > select your printer > Scan
5Select Email photo, Email document, or Email PDF.
Note: You can select Email document only if an OCR application is stored on your computer.
Scanning starts and the scan progress dialog appears. When the scan is finished, a new e‑mail message is created
with the scanned document automatically attached.
6Compose your e‑mail message.
Note: If your e-mail program does not open automatically, then you can scan the document to the computer and
then send it through e-mail as an attachment.
Scanning 69
For Macintosh users
1Load an original document faceup into the ADF or facedown on the scanner glass.
2From the Applications folder in the Finder, launch the application you want to use.
Note: Use any application that supports both your printer and an e‑mailing option, such as Image Capture.
3From the list of devices, select your printer.
Note: For information on finding the list of devices, check the documentation that came with the application, or
search for Scanning an image in the Search field of the Help menu.
4Adjust the scan settings as needed.
If applicable, click
?
on the preview dialog for more information.
5Set the e‑mail application as the scan destination, and then start the scan job.
6Compose your e‑mail message.
Scanning to a PDF
For Windows users
1Load an original document faceup into the ADF or facedown on the scanner glass.
2Click or Start.
3Click All Programs or Programs, and then select the printer program folder from the list.
4Navigate to:
Printer Home > select your printer > Scan > PDF
Scanning starts and the scan progress dialog appears.
5Save the document as a PDF.
For Macintosh users
1Load an original document faceup into the ADF or facedown on the scanner glass.
2From the Applications folder in the Finder, launch the application you want to use.
Note: Use any application that supports your printer.
3From the list of devices, select your printer.
Note: For information on finding the list of devices, check the documentation that came with the application or
search for Scanning an image in the Search field of the Help menu.
4Adjust the scan settings as needed.
If applicable, click
?
on the preview dialog for more information.
5Set the application that supports the PDF format as the scan destination, and then start the scan job.
6Save the document as a PDF.
Scanning 70
Scanning FAQ
How can I improve the quality of a scan?
•Make sure your original documents are in good condition.
•Make sure the application that receives the scanned document is appropriate. For example, if you are scanning a
photo to edit it, then make sure you choose a photo editing application to receive the scan. If you are scanning a
document to edit the text, then make sure you choose an OCR application.
•Use either of the following high resolutions:
–300 dpi for photos
–600 dpi for text and graphic documents
How can I adjust the color of a scan?
From the scan options menu, do the following:
•Select the Content Type option that describes the original document.
•Select the Content Source or Original Type option that describes how the original document was produced.
How do I scan in black and white?
Color is the default for all scans. To scan in black and white, press on the printer control panel.
Why am I being asked for a PIN?
PINs are a security measure used to restrict the scanned information from going into certain locations, or to keep what
is being scanned from being seen or used by others. You may be prompted to enter a PIN if the network computer you
are scanning to requires one.
To learn how PINs get assigned to network computers, see the Help for the printer software associated with your
operating system.
Canceling scan jobs
Do one or more of the following:
•From the printer control panel, press , and then press OK .
Scanning stops and the printer returns to the previous menu.
•If you are sending the scan job using the printer software, then cancel the scan job from the software dialog.
Scanning 71
E-mailing
You can use your printer to send e-mail to one or more recipients without using a computer provided you have set up
the scan to e-mail task through shortcuts. For more information, see the section on shortcuts in the User's Guide.
Before you can send e-mail using the printer control panel, you must first configure the network connection and e-mail
settings of your printer.
Setting up the printer to e-mail
Setting up the e-mail function
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Navigate to:
Printer Home > select your printer > Settings > Set up the printer to e‑mail
The E‑mail Setup Wizard opens.
4Follow the instructions on the computer screen.
For Macintosh users
1From the Finder, navigate to:
Applications > select your printer folder > Printer Settings > Email
2Follow the instructions on the computer screen, and then click Save Settings.
Configuring e‑mail settings
1Type the printer IP address into the address field of your Web browser.
If you do not know the IP address of the printer, you can:
•View the IP address on the printer control panel in the TCP/IP section under the Networks/Ports menu.
•Print a network setup page or the menu settings pages and locate the IP address in the TCP/IP section.
2Click Settings > E-mail/FTP Settings > E-mail Settings.
3Fill in the fields with the appropriate information.
4Click Submit.
E-mailing 72
Creating an e-mail contact list
Creating an e‑mail contact list using the computer
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Navigate to:
Printer Home > select your printer > Fax > Edit contact list > Select from phone book
4From the Phone Book field, select a phone book.
You can select any mail client phone book where you store e‑mail addresses.
5Select the contact that you want to add, and then click Add to or change list to import the contact.
6Click OK.
For Macintosh users
1From the Finder, navigate to:
Applications > select your printer folder
2Double‑click Printer Settings.
3Navigate to:
Contacts tab > Individuals tab
4Click to open the Address Book.
Note: To add contacts, you need to import contacts from the Address Book on your Macintosh computer. If the
contact is not in the Mac Address Book, then first add the contact to the address book and then import it.
5From the Address Book, click and drag the contacts that you want to add to the Contacts list.
For more information, click Help or
?
to view the help information for the fax software.
E-mailing 73
Sending e-mail
ADF Scanner glass
Use the ADF for multiple‑page documents.
Note: The ADF is available only in select printer models. If you
purchased a printer without an ADF, then load original
documents or photos on the scanner glass.
Use the scanner glass for single pages, small items (such
as postcards or photos), transparencies, photo paper, or
thin media (such as magazine clippings).
Tips for e‑mailing
•Make sure to enter your e‑mail account information and set up the SMTP server before sending an e‑mail.
•Make sure the printer is connected to an Ethernet or wireless network before sending an e‑mail.
If necessary, make sure the network is connected to the Internet for the printer to communicate with the SMTP
server. If the printer cannot connect to the Internet, then contact your system support person.
The printer supports only one active network connection (Ethernet or wireless) at a time.
•Add contacts to your address book. When sending an e‑mail, you can just select contacts from your address book
instead of typing their e‑mail addresses repeatedly.
•Use the ADF when scanning two‑sided pages if your printer supports duplex scanning and the ADF supports the
original document size.
•Use the scanner glass when scanning two‑sided pages if your printer does not support duplex scanning or the ADF
does not support the original document size.
•When using the ADF, adjust the paper guides on the ADF to the width of the original document.
•To easily retrieve a document after copying or scanning, lift the ADF input tray.
•When using the scanner glass, close the scanner cover, if possible, to avoid dark edges on the scanned image.
•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)
into the ADF. Place these items on the scanner glass.
•When the document to be e-mailed is in place with the settings you want, press to start scanning.
E-mailing 74
Canceling an e‑mail
Do one or more of the following:
•From the printer control panel, press , and then press OK .
•If you are sending the e‑mail using the printer software, then cancel the e-mail from the software dialog.
E-mailing 75
Faxing
CAUTION—POTENTIAL INJURY: To reduce risk of fire, use only the telecommunications (RJ‑11) cord provided
with this product or a UL Listed 26 AWG or larger replacement when connecting this product to the public
switched telephone network.
CAUTION—SHOCK HAZARD: Do not use the fax feature during a lightning storm. Do not set up this product or
make any electrical or cabling connections, such as the fax feature, power cord, or telephone, during a lightning
storm.
Setting up the printer to fax
Scenario 1: Standard telephone line
Setup 1: Printer is connected to a dedicated fax line
To connect:
Connect the cable from the wall jack to the port of the printer.
Tips for this setup:
•You can set the printer to receive faxes automatically (Auto Answer On) or manually (Auto Answer Off).
•If you want to receive faxes automatically (Auto Answer On), then set the printer to pick up on any number of rings
that you want.
Faxing 76
Setup 2: Printer is sharing the line with an answering machine
Connected to the same telephone wall jack
To connect:
1Connect the cable from the wall jack to the port of the printer.
2Remove the protective plug from the port of the printer, and then connect the answering machine to the port.
Connected to different wall jacks
Faxing 77
To connect:
Connect the cable from the wall jack to the port of the printer.
Tips for this setup:
•If you have only one telephone number on your line, then you need to set the printer to receive faxes automatically
(Auto Answer On).
•Set the printer to pick up calls two rings after the answering machine. For example, if the answering machine picks
up calls after four rings, then set the printer to pick up after six rings. This way, the answering machine picks up
calls first and your voice calls are received. If the call is a fax, then the printer detects the fax signal on the line and
takes over the call.
•If you subscribe to a distinctive ring service provided by your telephone company, then make sure that you set the
correct ring pattern for the printer. Otherwise, the printer will not receive faxes even if you have set it to receive
faxes automatically.
Setup 3: Printer is sharing the line with a telephone subscribed to voice mail service
To connect:
1Connect the cable from the wall jack to the port of the printer.
2Remove the protective plug from the port of the printer, and then connect the telephone to the port.
Faxing 78
Tips for this setup:
•This setup works best if you subscribe to a distinctive ring service. If you have distinctive ring service, then make
sure that you set the correct ring pattern for the printer. Otherwise, the printer will not receive faxes even if you
have set it to receive faxes automatically.
•If you have only one telephone number on your line, then you need to set the printer to receive faxes manually
(Auto Answer Off).
When you answer the telephone and you hear fax tones, press *9* or the manual answer code on the telephone
to receive the fax.
•You can also set the printer to receive faxes automatically (Auto Answer On), but you need to turn off the voice
mail service when you are expecting a fax. This setting works best if you are using voice mail more often than fax.
Scenario 2: Digital Subscriber Line (DSL)
A Digital Subscriber Line splits your regular telephone line into two channels: voice and Internet. Telephone and fax
signals travel through the voice channel, and Internet signals pass through the other channel. This way, you can use
the same line for analog voice calls (including faxes) and digital Internet access.
To minimize interference between the two channels and ensure a quality connection, you need to install a DSL filter
for the analog devices (fax machine, telephone, answering machine) in your network. Interference causes noise and
static on the telephone, failed and poor quality faxes for the printer, and slow Internet connection on your computer.
Faxing 79
To install a filter for the printer:
1Connect the line port of the DSL filter to the wall jack.
2Connect a telephone cable from the port on the back of the printer to the phone port on the DSL filter.
3To continue using a computer for Internet access, connect the computer to the DSL HPN port on the DSL filter.
4To connect a telephone to the printer, remove the protective plug from the port of the printer and then connect
the telephone to the port.
Scenario 3: VoIP telephone service
To connect:
1Connect one end of a telephone cable to the port of the printer.
2Connect the other end of the cable to the port labeled Phone Line 1 or Phone Port on the VoIP adapter.
The port labeled Phone Line 2 or Fax Port is not always active. You may need to pay extra to your VoIP provider if
you want to activate the second phone port.
3Remove the protective plug from the port of the printer, and then connect the telephone to the port.
Faxing 80
Tips for this setup:
•To make sure that the phone port on the VoIP adapter is active, plug an analog telephone into the phone port, and
then listen for a dial tone. If you hear a dial tone, then the port is active.
•If you need two phone ports for your devices but do not want to pay extra, then do not plug the printer into the
second phone port. You can use a phone splitter. Plug the phone splitter into the Phone Line 1 or Phone Port, and
then plug the printer and telephone into the splitter.
Make sure you use a phone splitter, not a line splitter. To make sure that you are using the correct splitter, plug an
analog telephone into the splitter and then listen for a dial tone.
Scenario 4: Digital telephone service through a cable provider
Setup 1: Printer is connected directly to a cable modem
Follow this setup if you normally connect your telephone to a cable modem.
To connect:
1Connect one end of a telephone cable to the port of the printer.
2Connect the other end of the cable to the port labeled Phone Line 1 or Phone Port on the cable modem.
The port labeled Phone Line 2 or Fax Port is not always active. You may need to pay extra to your cable provider if
you want to activate the second phone port.
3Remove the protective plug from the port of the printer, and then connect the telephone to the port.
Faxing 81
Tips for this setup:
•To make sure that the phone port on the cable modem is active, plug an analog telephone into the phone port, and
then listen for a dial tone. If you hear a dial tone, then the port is active.
•If you need two phone ports for your devices but do not want to pay extra, then do not plug the printer into the
second phone port. You can use a phone splitter. Plug the phone splitter into the Phone Line 1 or Phone Port , and
then plug the printer and telephone into the splitter.
Make sure you use a phone splitter, not a line splitter. To make sure that you are using the correct splitter, plug an
analog telephone into the splitter and then listen for a dial tone.
Setup 2: Printer is connected to a wall jack; cable modem is installed elsewhere in the house
Follow this setup if your cable provider activated the wall jacks in your house so that you do not have to plug your
devices into the cable modem. Your cable telephone service comes from the wall jacks.
To connect:
1Connect the cable from the wall jack to the port of the printer.
2Remove the protective plug from the port of the printer, and then connect the telephone to the port.
Faxing 82
Scenario 5: Country‑ or region‑specific setup
Different countries or regions have different types of telephone wall jacks. The standard wall jack adopted by most
countries or regions is the Registered Jack-11 (RJ-11). You need to have an RJ‑11 plug, or a telephone cable that has an
RJ‑11 connector, so you can connect a device to an RJ‑11 wall jack.
The fax ports on the back of the printer and the telephone cable that comes with the printer have RJ‑11 connectors. If
you have a different type of connector in your country or region, then you may need to use an RJ‑11 adapter.
Connecting the printer to a non‑RJ‑11 wall jack
EXT
LINE
To connect:
1Connect one end of a telephone cable to the port of the printer.
2Connect the other end of the cable to the RJ‑11 adapter, and then connect the adapter to the wall jack.
Faxing 83
3If you want to connect another device (telephone or answering machine) to the same wall jack, and if the device
has a non‑RJ 11 connector, then connect it directly to the wall jack.
Notes:
•Do not remove the wrap plug from the port of the printer.
•The printer may not come with an RJ-11 adapter in your country or region.
If the additional device (telephone or answering machine) has an RJ-11 connector, then you can remove the wrap plug
and connect the device to the port of the printer.
Connecting the printer in countries or regions that use serial connection
In some countries or regions, you need to plug all devices into the wall jack. You cannot plug a telephone or answering
machine into the port of the printer. This is called serial connection.
Austria Germany Portugal
Belgium Ireland Spain
Denmark Italy Sweden
France Netherlands Switzerland
Finland Norway United Kingdom
Warning—Potential Damage: If your country or region is on the list, then do not remove the wrap plug from the
port of the printer. It is necessary for the proper functioning of the devices on the telephone line.
Faxing 84
EXT
LINE
To connect:
Connect the cable from the wall jack to the port of the printer.
Connecting the printer to a wall jack in Germany
The German wall jack has two kinds of ports. The N ports are for fax machines, modems, and answering machines. The
F port is for telephones.
NFN
Faxing 85
Connect the printer to any of the N ports.
To connect:
1Connect one end of a telephone cable to the port of the printer.
2Connect the other end of the cable to the RJ‑11 adapter, and then connect the adapter to an N port.
3If you want to connect a telephone and answering machine to the same wall jack, then connect the devices as
shown.
Entering your user information
Your user information includes your name or your company name, your fax number (which is your telephone number,
unless you have a dedicated fax telephone line), and the time and date on your fax machine when a transmission is
made. This information appears in the header and footer of the faxes that you send.
In some countries, you cannot send a fax without this information. Some fax machines block faxes without sender
information, so make sure that you enter this information in your printer.
Setting the fax header
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Dialing and Sending > OK > Fax Name > OK
2Enter your name or your company name, and then press OK .
•To change a character, press the left arrow button.
•To add a space, press the number 0.
Faxing 86
3Press the arrow buttons to scroll to Fax Number, and then press OK .
4Enter your fax number or your telephone number, and then press OK .
Setting the fax footer
From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering >
OK
> Fax Footer > OK > On > OK
Setting the date and time
1From the printer control panel, navigate to:
> Setup >
OK
> Device Setup >
OK
> Date/Time >
OK
2Enter the date, and then press OK .
3Enter the time, and then press OK .
Configuring the fax settings
You can configure the fax settings through the printer control panel or the computer through the Printer Setup Utility.
If you configure the fax settings through the printer control panel, then the Printer Setup Utility imports those settings.
The changes appear the next time you launch the Printer Setup Utility. The printer also saves the settings that you
select in the utility, unless you set the printer to block changes made from the computer.
Configuring fax settings using the printer control panel
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK
2Configure the fax settings using the selections in the menu:
From here You can
Address Book Set up, view, or print the Address Book.
Fax Reports •Print activity logs. Activity logs let you view the sent and received
fax history of your printer.
•Print confirmation pages or transmission reports. These reports
let you know if the faxes that you send are sent successfully.
Faxing 87
From here You can
Ringing and Answering •Set the printer to receive faxes automatically or manually. Turn
Auto Answer to On or Off.
•Adjust the ringing volume.
•Set the number of rings. This is important if you choose to receive
faxes automatically (Auto Answer On).
•Set the distinctive ring. If you subscribe to the distinctive ring
feature on your telephone line, then set the correct pattern for
the printer in this menu.
•Enable fax forwarding.
•Set a manual answer code. This is the code you press to receive
faxes manually.
•Set the Caller ID pattern that you want. Some countries or
regions have multiple patterns.
•Set the printer to fit incoming faxes into a page when printing.
•Set the fax footer.
2‑Sided Faxes •Set the printer to print incoming faxes on both sides of the paper.
Dialing and Sending •Set your fax name and fax number.
•Adjust the dialing volume.
•Set the dial method, redial time, number of redial attempts,
dialing prefix, and fax sending speed.
•Convert sent faxes into modes that receiving fax machines
recognize. Otherwise, such faxes are aborted.
•Enable error correction during transmission.
Fax Blocking Block unwanted incoming faxes.
Configuring fax settings using the fax software
Before you begin, make sure that:
•The printer is properly connected to the telephone line.
•The printer is turned on and connected to the computer.
•The printer is not in Sleep mode. If the printer is in Sleep mode, then press to wake up the printer.
Using the Fax Setup Wizard in Windows
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Click Printer Home > Fax > Set up the printer to fax.
The Fax Setup Wizard opens.
4Run the Fax Setup Wizard. Make sure you select the correct telephone service and connection. The wizard configures
optimal fax settings based on your connection.
Note: If you want to configure the advanced fax settings, then from the Printer Home, click Fax > Configure the
advanced fax settings. This launches the Printer Setup Utility.
Faxing 88
Using the Printer Settings in Macintosh
1From the Applications folder in the Finder, or from the Finder desktop, double-click the printer folder.
2Double-click Printer Settings.
3Configure the fax settings using the printer software.
To view the help information for the fax software, click Help or
?
.
Creating a contact list
You can create a contact list using the Address Book in the printer control panel or the computer through the Phone
Book. If you create a contact list in the printer control panel, then the Phone Book automatically saves those contacts
as Phone Book entries. Likewise, when you add contacts to the Phone Book, the printer automatically saves them to
the printer Address Book.
You can save up to 89 contacts and 10 fax groups in the contact list.
Creating a contact list using the printer control panel
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Address Book > OK
2To add a fax number to your Address Book:
aPress the arrow buttons to scroll to Add Entry, and then press OK .
bUse the keypad to enter the contact name in the Name field.
•To change a character, press the left arrow button.
•To add a space, press the number 0.
cPress the up or down arrow button to move the cursor to the Number field.
dUse the keypad to enter the fax number in the Number field, and then press OK to save the entry.
eIf you want to add another entry, then repeat steps a through d.
3To add a fax group:
aPress the arrow buttons to scroll to Add Group, and then press OK .
bUse the keypad to enter a group name, and then press
OK
.
•To change a character, press the left arrow button.
•To add a space, press the number 0.
cPress the arrow buttons to select whether you want to add a contact manually or import a contact. Press OK
when you make a selection.
•If you want to add a contact manually, then use the keypad to enter the fax number, and then press
OK
.
•If you want to import a contact, then press the arrow buttons to select a contact from the Address Book.
Press
OK
when you make a selection.
dWhen you are finished adding contacts to the group, select Done.
Faxing 89
Creating a contact list using the fax software
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Navigate to:
Printer Home > select your printer > Fax > Edit contact list
The Contacts tab of the Printer Setup Utility opens.
4Click Select from phone book.
5From the Phone Book field, select a phone book.
6Select the contact that you want to add, and then click Add to or change list to import the contact.
Note: To add contacts, you need to import contacts from the phone books on your computer that are supported
by the fax software. In addition to the software Address Book, you may also have phone books of the mail
clients installed on your computer, such as Microsoft Outlook.
7Click OK.
For Macintosh users
1From the Finder, navigate to:
Applications > select your printer folder
2Double‑click Printer Settings.
3Click the Contacts tab.
•To add contacts, click the Individuals tab.
•To add fax groups, click the Groups tab.
4Click to open the Address Book.
Note: To add contacts, you need to import contacts from the Address Book on your Macintosh computer. If the
contact is not in the Mac Address Book, then first add the contact to the address book, and then import it.
5From the Address Book, click and drag the contacts that you want to add to the Contacts list.
For more information, click Help or
?
to view the help information for the fax software.
Faxing 90
Sending faxes
ADF Scanner glass
Use the ADF for multiple‑page documents.
Note: The ADF is available only in select printer models. If you
purchased a printer without an ADF, then load original
documents or photos on the scanner glass.
Use the scanner glass for single pages, small items (such
as postcards or photos), transparencies, photo paper, or
thin media (such as magazine clippings).
Tips for sending faxes
•Make sure the printer is on and connected to a working telephone, DSL, or VoIP line. The line is working if you hear
a dial tone.
•Make sure the paper exit tray is fully extended and the tray extension is flipped out.
•Depending on your printer model, use the ADF when scanning two‑sided (duplex) pages.
•To easily retrieve a document after copying or scanning, lift the ADF input tray.
•When using the ADF, adjust the paper guide on the ADF to the width of the original document.
•When using the scanner glass, close the scanner cover, if possible, to avoid dark edges on the scanned image.
•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)
into the ADF. Place these items on the scanner glass.
•When the document to be faxed is in place with the settings you want, press to send the fax.
Sending faxes using the printer control panel
1From the printer control panel, navigate to:
> Fax
2Enter a fax number, or press Address Book to select a number from the Speed Dial or Group Dial list.
3If you want to send a fax to a single recipient, then press OK .
If you want to send a fax to a group of numbers (broadcast fax), then press the left or right arrow button to enter
another number, and then press OK . Repeat this step to add more numbers.
Faxing 91
4Press the Color/Black button to select a color or black‑and‑white fax.
5Press to start the fax job.
Warning—Potential Damage: Do not touch the cables or the and ports while actively sending a fax.
Tip:
•You can send a broadcast fax to up to 30 recipients.
Sending faxes using the computer
For Windows users
1With a document open, click File > Print.
2Make sure to select the fax version of your printer, and then click Properties, Preferences, Options, or Setup.
3Click the Fax tab, and then make sure Enable Fax is selected.
4Enter the recipient fax number or numbers in the “Fax number(s)” field.
You can enter fax numbers manually or by using the Phone Book feature.
5If necessary, enter a prefix in the Dialing Prefix dialog.
6Select the appropriate paper size and page orientation.
7Select Include Cover Page with Fax, and enter the appropriate information if you want to include a cover page with
the fax.
8Click OK.
For Macintosh users
1With a document open, choose File > Print.
2From the Printer pop‑up menu, select the fax version of your printer.
Note: In order to see the fax options on the Print dialog, you must use the fax driver for your printer. If the fax
version of the printer is not on the list, then choose Add a printer, and then choose the fax version of the
printer.
3Enter the name and number of the recipient.
4Click Fax.
Receiving faxes
Tips for receiving faxes
When receiving faxes:
•Make sure that the printer is on and connected to a working telephone, DSL, or VoIP line. The line is working if you
hear a dial tone.
•If you set the printer to receive faxes manually (Auto Answer Off), then make sure that the ringer volume is not set
to Off.
Faxing 92
•If you have set the printer to receive faxes automatically (Auto Answer On), then load paper in the printer.
Receiving faxes automatically
1Make sure that Auto Answer is on:
From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering >
OK
> Auto Answer > OK > On > OK
2Set the number of rings before the printer picks up incoming faxes:
aPress the arrow buttons to scroll to Pick Up On, and then press OK .
bPress the arrow buttons to scroll to the number of rings that you want, and then press
OK
to save the setting.
When the number of rings you set is detected, the printer automatically receives the incoming fax.
Warning—Potential Damage: Do not touch the cables or the and ports while actively receiving a fax.
Tips:
•If the printer is sharing the line with other analog devices (telephone, answering machine), then set the printer to
pick up calls two rings after the answering machine. For example, if the answering machine picks up calls after four
rings, then set the printer to pick up after six rings. This way, the answering machine picks up calls first and your
voice calls are received. If the call is a fax, then the printer detects the fax signal on the line and takes over the call.
If the printer is on a dedicated fax line, then you may set the printer to pick up on any number of rings.
•If you have multiple numbers on a single line, or if you subscribe to a distinctive ring service provided by your
telephone company, then make sure that you set the correct ring pattern for the printer. Otherwise, the printer
will not receive faxes even if you have set it to receive faxes automatically.
Receiving faxes manually
1Turn off Auto Answer:
From the printer control panel, navigate to:
> Setup >
OK
> Fax Setup >
OK
> Ringing and Answering >
OK
> Auto Answer > OK > Off >
OK
2When the telephone rings and you hear fax tones when you pick up the handset, press on the printer or *9* on
the telephone attached to the printer.
Warning—Potential Damage: Do not touch the cables or the and ports while actively receiving a fax.
Tips:
•The default code for answering faxes manually is *9*, but for increased security, you can change it to a number
that only you know. You can enter up to 7 characters for your code. The valid characters are the digits 0–9 and the
characters # and *.
•Make sure that the telephone is plugged into the port on the back of the printer and that the printer is connected
to the wall jack through the port.
Faxing 93
Faxing FAQ
If I skipped the fax setup initially, do I need to run the installer again to set up the
fax?
You do not need to run the installer again. You can set up and configure the fax through the fax software that was
installed with the printer software.
1Connect the printer to the telephone line. For more information, see “Setting up the printer to fax” on page 76.
2Configure the fax settings using the fax software. To access the fax software:
For Windows users
aClick or Start.
bClick All Programs or Programs, and then select the printer program folder from the list.
cClick Printer Home > Fax >Set up the printer to fax.
The Fax Setup Wizard opens.
dRun the wizard. Make sure you select the correct telephone service and connection. The wizard configures
optimal fax settings based on your connection.
For Macintosh users
aFrom the Applications folder in the Finder, or from the Finder desktop, double-click the printer folder.
bDouble-click Printer Settings, and then configure the fax settings.
What is a splitter and what type of splitter should I use?
If there are limited wall jacks in your home or limited ports on your adapter, then you can use a phone splitter. A splitter
splits the telephone signal and allows you to connect multiple devices to the wall jack. It has two or more ports where
you can plug the devices. Do not use a line splitter.
To make sure that you are using the correct splitter, plug an analog telephone into the splitter and then listen for a dial
tone.
What is my fax number?
In most cases, your telephone number is also your fax number. If you subscribe to the Distinctive Ring Pattern Detection
(DRPD) service offered by telephone companies, then your fax number is the number that you assigned to the printer.
Make sure that you enter the correct distinctive ring pattern for that number in the fax software or in the Fax Setup
menu of the printer control panel.
If you have more than one telephone line, then make sure that you enter the number for the line on which the printer
is connected.
Faxing 94
What is my dialing prefix?
The dialing prefix is the number or series of numbers that you press before you can dial the actual fax number or
telephone number. If the printer is in an office setting or in a private branch exchange, then this can be a specific number
that you need to press so you can make a call outside the office. This can also be a country code or an area code that
you need to enter if you are sending faxes outside of town. This can be very useful if you frequently send faxes to the
same country or area. When you set the dialing prefix in the utility, the printer automatically inputs the prefix when
you dial the fax number or telephone number.
You can enter up to 8 characters as your dialing prefix. The valid characters are the numbers 0–9, the letters P and W
(uppercase and lowercase), and the characters pound (#) and star (*). If you are using the fax software to enter the dial
prefix, then you may also include the characters minus and comma.
Notes:
•Some of these characters may not be available, depending on the printer you purchased.
•Characters may vary depending on whether you are using the printer control panel or the computer keyboard.
When do I need to set Auto Answer to On?
Auto Answer is set to On by default, which lets the printer receive faxes automatically.
If the printer is connected to the same telephone line with an answering machine, then you must set Auto Answer to
On so that you can receive both your voice calls and your faxes. Make sure that the answering machine is set to pick
up on fewer rings than the rings set in the printer. This lets the other devices pick up the voice calls first. If an incoming
call is a fax, the printer can detect fax signals on the line and takes the call.
How many rings should I set?
If the printer is sharing a line with an answering machine, then set the printer to pick up after a greater number of rings
than the answering machine. For example, if the answering machine picks up calls after four rings, then set the printer
to pick up after six rings. This way, the answering machine picks up calls first and your voice calls are received. If the
call is a fax, then the printer detects the fax signal on the line and takes over the call.
If the printer is on a dedicated fax line, then you may set the printer to pick up on any number of rings that you want.
How do I set the distinctive ring for the printer?
Setting the correct ring is important if you subscribe to the Distinctive Ring Pattern Detection (DRPD) feature offered
by telephone companies. This feature allows you to have multiple telephone numbers on one telephone line. Each
telephone number has a designated ring pattern (All Rings, Single Ring Only, Double Ring Only, Triple Ring Only, Single
or Double Rings Only, Single or Triple Rings Only, Double or Triple Rings Only). The different ring patterns let you know
what telephone number was dialed, and what device you should use to answer the call.
Assign one of your telephone numbers to the printer as the fax number, and then set the printer to answer the ring
pattern of that number. If the pattern is set incorrectly, then the printer rings, but it never receives the fax.
Distinctive Ring is also called Ident-a-Call, Smart Ring, Teen Ring, RingMaster, or IdentaRing.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering >
OK
> Ring Pattern > OK
2Press the arrow buttons to scroll to the ring pattern you want, and then press OK .
Faxing 95
How can I check the dial tone?
A dial tone lets you know if the telephone line is working or if the printer is properly connected to the telephone line.
If you encounter problems sending and receiving faxes, then make sure you can hear a dial tone on the line and through
the printer.
Make sure the telephone line and the wall jack are working
1Plug an analog telephone into the wall jack.
2Listen for a dial tone through the telephone handset.
If you hear a dial tone, then the telephone line and the wall jack are working.
If you do not hear a dial tone, plug the analog telephone into a second wall jack, and then listen for a dial tone. If
you hear a dial tone, then the telephone line is working but the first wall jack is not working.
Make sure the printer is connected properly to the telephone line
1While the printer is connected to a telephone line through the port on the back of the printer, plug an analog
telephone into the port of the printer.
2Listen for a dial tone.
If you hear a dial tone, then the telephone line is working and properly connected to the printer.
If you do not hear a dial tone through both the wall jack and the printer, then see the “Fax troubleshooting checklist”
on page 156.
How do I adjust the speaker volume on the printer?
Listen to the dial tone to check if the telephone line is working and to check if the cables and devices are connected
properly in your telephone network. If you set the printer to receive faxes manually, then make sure that you set the
ringer volume loud enough for you to hear it.
Adjusting the dialing volume
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Dialing and Sending > OK > Speaker Volume > OK
2Press the up or down arrow buttons to select a dial volume setting, and then press OK .
Adjusting the ringer volume
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering >
OK
> Ringer Volume > OK
2Press the up or down arrow buttons to select a ringer volume setting, and then press OK .
Faxing 96
How can I make sure that fax calls go to the printer and voice calls go to the
answering machine?
To make sure the printer picks up incoming faxes, set Auto Answer to On, and then set the printer to pick up after a
greater number of rings than the answering machine. For example, if the answering machine picks up calls after four
rings, then set the printer to pick up after six rings. This way, the answering machine picks up calls first and your voice
calls are received. If the call is a fax, then the printer detects the fax signal on the line and takes over the call.
What settings work best with voice mail service?
Voice mail and fax can share the same telephone line if you subscribe to a distinctive ring service offered by your
telephone company. This feature allows you to have multiple telephone numbers on one telephone line. Each telephone
number has a designated ring pattern (All Rings, Single Ring Only, Double Ring Only, Triple Ring Only, Single or Double
Rings Only, Single or Triple Rings Only, Double or Triple Rings Only). The different ring patterns let you know which
telephone number was dialed, and which device you should use to answer the call.
If you do not have distinctive ring service, then set the printer to receive faxes manually (Auto Answer Off). This setting
lets you receive both voice calls and fax calls, but works best if you use voice mail more often. You need to turn off
voice mail whenever you are expecting a fax.
How do I change the resolution of the documents that I fax?
The resolution, or fax quality, of the documents that you send may affect fax transmission. The receiving fax machine
may not support high resolutions and may not be able to receive your fax. You can fix this by enabling Auto Fax
Conversion, but the automatic conversion may result in an unreadable fax, especially if the original document is already
blurred.
Choose a fax quality that best suits the capacity of the receiving fax machine and the quality of the original document.
Quality Black resolution Color resolution
Standard 200 x 100 200 x 200
Fine 200 x 200 200 x 200
Superfine 300 x 300 200 x 200
Ultrafine 300 x 300 (half‑toned) 200 x 200
When sending a fax, after entering the fax number, press the arrow buttons to select a fax quality, and then
press OK .
How do I send a fax at a scheduled time?
1From the printer control panel, navigate to:
> Fax
2Enter the fax number of the recipient, or press Address Book to select a number from the Speed Dial or Group Dial
list.
3Press the arrow buttons to scroll to Schedule Fax.
Faxing 97
4Enter the time you want to send the fax, and then press OK .
5Press to start scanning the document and to save the scheduled fax.
The printer sends the fax at the designated time. Do not turn off the printer or unplug it from the telephone line
before the scheduled time.
How do I send a fax using a phone calling card?
1Press Dial tone.
You should hear the dial tone of the telephone line.
2Enter the calling card information, and then when you are connected to the telephone carrier, follow the prompts.
3When prompted, enter the fax number of the recipient, and then press .
How do I know that the fax was sent successfully?
You can set the printer to print a confirmation page, or transmission report, every time you send a fax. This report
includes the date and time that the fax was sent. If the fax job is unsuccessful, then the report also includes the cause
of the error.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Fax Reports > OK > Transmission Log Printing > OK
2Press the arrow buttons to select a report printing option:
•If you want to print a report every time you send a fax, then select Print Log.
•If you do not want to print the report, then select Do not print log.
•If you want to save on ink and print a report only when a fax job is unsuccessful, then select Print only for error.
3Press OK .
How do I print the fax history of the printer?
You can print reports of sent or received faxes, or both.
1From the printer control panel, navigate to:
> Setup >
OK
> Fax Setup >
OK
> Fax Reports >
OK
2Press the arrow buttons to select a report printing option:
•If you want to print the log of all sent or received fax activity, then select Print Job Log.
•If you want to print the log of all calls to and from your printer, then select Print Call Log.
Faxing 98
How do I print a fax on both sides of the paper?
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > 2‑Sided Faxes > OK
2Press the arrow buttons to select a setting:
•Never—Incoming faxes are never printed on both sides of the paper regardless of the 2‑sided button setting.
•Always—Incoming faxes are always printed on both sides of the paper regardless of the 2‑sided button setting.
3Press OK .
How do I forward a fax?
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering >
OK
> Fax Forward > OK
2Press the arrow buttons to scroll to Forward or Print & Forward, and then press OK .
3Using the keypad, enter the number to which you want to forward the fax, and then press OK .
When you enable this option, all the faxes that you receive are automatically forwarded until you disable it.
To disable fax forwarding, return to the Fax Forward menu, and then select Off.
Can I block faxes?
You can block faxes from specific numbers. You can also block junk faxes and faxes from unidentified senders (senders
without a Caller ID). This feature is helpful if you want to receive faxes automatically but want to filter the faxes that
you receive.
1Turn on fax blocking.
From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Fax Blocking > OK > Turn On/Off > OK > On > OK
2Add a number to block.
aPress the arrow buttons to scroll to Add, and then press OK .
bUse the keypad to enter the name of the person you want to block.
cPress the down arrow button to move the cursor to the Number field.
dUse the keypad to enter the fax number, and then press OK .
eRepeat steps 2b through 2d until you have added all the numbers that you want to block. You can block up to
50 numbers.
3Block unidentified faxes (faxes without a Caller ID number).
aPress the arrow buttons to scroll to Block No ID, and then press OK .
bPress the arrow buttons to scroll to On, and then press OK to save the setting.
Faxing 99
Can I retrieve failed faxes?
The printer saves an incoming fax in the printer memory before it prints the fax. If the printer runs out of ink or runs
out of paper, then the printer will automatically print the fax after the error is resolved.
If a fax was not sent or received due to power loss, then the printer will automatically send any outgoing faxes or print
any incoming faxes that were saved in the printer memory when the power is restored.
Faxing 100
Networking
Installing the printer on a wireless network
Wireless network compatibility
Your printer may contain an IEEE 802.11b, IEEE 802.11g, or IEEE 802.11n wireless print server. Your printer is compatible
with IEEE 802.11 b/g/n routers that are Wi-Fi certified.
Note: If your printer has an IEEE 802.11g wireless print server and you are having issues with an n router, then verify
with your router manufacturer that the current mode setting is compatible with g devices, as this setting varies
depending on the router brand or model.
Supported network security options
The printer supports three wireless security options: WPA2/WPA, WEP, and no security.
WPA2/WPA
WPA (Wi-Fi Protected Access) and WPA2 (Wi-Fi Protected Access 2) offer stronger wireless network security than WEP.
WPA2 and WPA are similar types of security. WPA2 uses a more complex encryption method and is more secure than
WPA. Both WPA2 and WPA use a series of characters, called the WPA pre‑shared key or passphrase, to protect wireless
networks from unauthorized access.
WPA2/WPA passphrases must be:
•Exactly 64 hexadecimal characters. Hexadecimal characters are A–F, a–f, and 0–9.
or
•From 8 to 63 ASCII characters. ASCII characters are letters, numbers, punctuation, and symbols found on a keyboard.
ASCII characters in a WPA passphrase are case-sensitive.
Every device on the wireless network must use the same WPA passphrase. WPA security is an option only on
infrastructure networks with access points (wireless routers) and network cards that support WPA. Most newer wireless
network equipment also offer WPA2 security as an option.
Note: If your network uses WPA2 or WPA security, then select WPA Personal when you are prompted to select the
type of security your network uses.
WEP
WEP (Wired Equivalent Privacy) is the most basic and the weakest type of wireless security. WEP security relies on a
series of characters called the WEP key.
Every device on the wireless network must use the same WEP key. WEP security can be used on both ad hoc and
infrastructure networks.
Networking 101
A valid WEP key has:
•Exactly 10 or 26 hexadecimal characters. Hexadecimal characters are A–F, a–f, and 0–9.
or
•Exactly 5 or 13 ASCII characters. ASCII characters are letters, numbers, punctuation, and symbols found on a
keyboard.
No Security
It is not recommended to use no security at all on a home wireless network. Using no security means that anyone within
range of your wireless network can use your network resources—including Internet access— if your wireless network
is connected to the Internet. The range of your wireless network may extend far beyond the walls of your home, allowing
access to your network from the street or from your neighbors’ homes.
Printing a network setup page
A network setup page lists the configuration settings of the printer, including the IP address and MAC address of the
printer.
1Load plain paper.
2From the printer control panel, navigate to:
> Setup > OK > Network Setup > OK > Print Network Setup Page > OK
Information you will need during wireless setup
To set up the printer for wireless printing, you need to know the following:
•The name of your wireless network, which is also known as the SSID (Service Set Identifier)
•If encryption was used to secure your network
•The security key (either a WEP key or WPA/WPA2 preshared key/passphrase)
To find the WPA/WPA2 preshared key/passphrase for the wireless network, see the documentation that came with
the access point (wireless router), see the Web page associated with the access point, or consult your system support
person.
If your access point is using WEP security, then the WEP key should be:
•Exactly 10 or 26 hexadecimal characters
or
•Exactly 5 or 13 ASCII characters
If your access point is using WPA or WPA2 security, then the WPA/WPA2 preshared key/passphrase should be:
•Exactly 64 hexadecimal characters
or
•From 8 to 63 ASCII characters
Notes:
•Hexadecimal characters are A–F, a–f, and 0–9.
•ASCII characters are letters, numbers, and symbols found on a keyboard. ASCII characters in a WPA/WPA2
preshared key/passphrase are case‑sensitive.
Networking 102
If your wireless network is not using security, then you will not have a security key.
Note: If you do not know the SSID of the network that your computer is connected to, then launch the wireless
utility of the computer network adapter and look for the network name. If you cannot find the SSID or the security
information for your network, then see the documentation that came with the access point, or contact your system
support person.
Information you will need during advanced wireless setup
The Wireless Setup Utility does not detect the wireless network SSID for you during advanced wireless setup. You must
know the following information before configuring the wireless printer settings manually:
Wireless Mode
Check your wireless network type:
Infrastructure—All devices on a wireless network communicate with each other through an access point (wireless
router).
Ad Hoc—Network devices communicate directly with each other without the use of centralized security or access
point. Ad hoc mode may be available only in select printer models or operating systems.
Note: Infrastructure is the recommended network configuration because of its faster transfer speeds, better security
options, and ease of configuration.
Network Name (SSID)
This is the identifying name that distinguishes a network from other networks in the area.
Channel
Auto is selected by default and cannot be changed if the network is configured in infrastructure mode.
Notes:
•If the network is set up in ad hoc mode, then select the channel that other devices in the network are using.
All devices in an ad hoc network must use the same channel to communicate with each other.
•The printer can communicate on only one wireless network at a time. Configuring the printer for an ad hoc
wireless network will keep it from working on any other wireless network, either ad hoc or infrastructure.
Authentication
Determine if you have an infrastructure or ad hoc setup, and then check the corresponding authentication type.
Note: Some authentication types may be available only in select printer models or operating systems.
Wireless mode Authentication type
Infrastructure •Open Mode
•Shared Mode
•WPA Personal
•WPA2‑Personal
•WPA2‑Enterprise
•802.1X ‑ RADIUS
Ad hoc Open Mode
Networking 103
Encryption
Check the encryption method used on your network.
Note: Some authentication types may be available only in select printer models or operating systems.
Authentication type Encryption method
Open Mode •None
•WEP
Shared Mode WEP
WPA Personal TKIP
WPA2‑Personal •TKIP
•AES
WPA2‑Enterprise •TKIP
•AES
802.1X ‑ RADIUS •None
•WEP‑DynamicKeys
•WEP‑StaticKeys
•WPA‑TKIP
•WPA‑AES
Installing the printer on a wireless network
Before you begin, make sure that:
•Your wireless network is set up and working properly.
•The computer you are using is connected to the same wireless network where you want to set up the printer.
•You know the network name (SSID) and the WEP key or WPA/WPA2 preshared key/passphrase of the wireless
network you want to connect to.
For Windows users
1Close all open software programs.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then launch the CD manually:
aClick , or click Start and then click Run.
bIn the Start Search or Run dialog, type D:\setup.exe, where D is the letter of your CD or DVD drive.
cPress Enter, or click OK.
3Click Install, and then follow the instructions on the computer screen.
Note: Select Wireless connection when prompted to select a connection type.
Networking 104
For Macintosh users
1Close all open applications.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then click the CD icon on the desktop.
3Double-click the software installer package, and then follow the instructions on the computer screen.
Note: Select Wireless connection when prompted to select a connection type.
Installing the printer on other computers
When the printer is set up on the wireless network, it can be accessed wirelessly by any other computer on the network.
However, you will need to install the printer driver on every computer that will access it. You do not need to configure
the printer again, although you will need to run the setup software on each computer to install the driver.
For Windows users
1Close all open software programs.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then launch the CD manually:
aClick , or click Start and then click Run.
bIn the Start Search or Run dialog, type D:\setup.exe, where D is the letter of your CD or DVD drive.
cPress Enter, or click OK.
3Click Install, and then follow the instructions on the computer screen.
For Macintosh users
1Close all open applications.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then click the CD icon on the desktop.
3Double-click the software installer package.
4Select My printer is already set up. I am installing it on a new computer.
5Click Continue, and then follow the instructions on the computer screen.
Determining the printer status using the network indicator light
The Wi‑Fi or Ethernet indicator light shows the network status of the printer.
Notes:
•The network indicator light is located on the printer control panel. The printer may have an Ethernet or a
wireless indicator light, or both, depending on your printer model. To find out if your printer has Ethernet or
wireless capability, see the Quick Reference Guide, or contact your system support person.
•The printer supports one local (USB) connection and one network connection (Ethernet or wireless) at a time. It
is not possible to use both Ethernet and wireless at the same time.
Networking 105
Indicator light Printer status
Off •The printer is turned off or is powering up.
•The printer is not connected to an Ethernet or a wireless network and is in Sleep mode.
•The printer has not been configured for an Ethernet or a wireless network.
•The printer is configured for an ad hoc connection, but it is not currently communicating with another
ad hoc device.
Blinking green •The printer has been configured for an Ethernet network, but it cannot establish a connection with the
network.
•The printer is out of the range of the access point (wireless router).
•The printer is trying to communicate with the access point, but the access point is turned off or is not
working properly.
•The access point has been turned off, and then turned back on, and the printer is trying to establish a
connection with the network.
•The wireless settings of the printer may no longer be valid.
Check if the SSID, WEP key or WPA/WPA2 preshared key/passphrase, security type, and IP address that
the printer uses are still correct.
Solid green •The printer is connected to an Ethernet or a wireless network and is ready for use.
•The printer is connected to your computer or mobile device through an ad hoc connection.
Special wireless installation instructions
The following instructions apply to customers outside of North America who are using a wireless broadband box. Some
examples of these boxes include LiveBox, AliceBox, N9UF Box, Freebox, and Club Internet.
Before you begin
•Make sure your box is wireless‑enabled and activated to work on a wireless network. For more information about
configuring the box to work wirelessly, see the documentation that came with your box.
•Make sure your box is turned on and that your computer is on and connected to your wireless network.
Adding the printer to your wireless network
1Set up your printer for wireless networking using the setup instructions provided.
Stop when you are prompted to select a network.
2If there is an association/registration button on the back of your box, then press it before selecting a network.
Note: After pressing the association/registration button, you have five minutes to complete the printer
installation.
3Return to the computer screen.
From the wireless networks list that appears, select your network, and then click Continue.
If your wireless network does not appear in the list, then:
aConnect to another wireless network.
For Windows users
Click Unlisted Network.
Networking 106
For Macintosh users
Select Other Wireless Network from the list, and then click Continue.
bEnter the details about your wireless network.
Note: Your WEP, WPA, or WPA2 key may be obtained from the bottom of the box, the documentation that
came with the box, or from the box Web page. If you have already changed the key for your wireless
network, then use the key you created.
4Follow the instructions on the computer screen to complete the installation.
Assigning a static IP address
The printer is automatically assigned an IP address through DHCP on most networks.
1Complete the wireless or Ethernet setup, allowing the printer to receive a DHCP address from a DHCP server on
the network.
2Print a network setup page to see the IP address currently assigned to the printer.
3Open a Web browser, and then type the printer IP address in the address field. Press Enter.
Note: If you are using a proxy server, then temporarily disable it to load the Embedded Web Server correctly.
4Click Settings > Network/Ports > TCP/IP > Set static IP address.
5In the Address field, type the IP address you want to assign to the printer, and then click Submit.
To verify, type the static IP address in the Web browser address field, and then press Enter.
For more information, contact your system support person.
Changing wireless settings after installation
To change the wireless settings on the printer, such as the configured network and the security key, do the following:
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Select your printer, and then navigate to:
Printer Home > Settings > Wireless setup utility
4Follow the instructions on the computer screen.
For Macintosh users
1From the Applications folder in the Finder, or from the Finder desktop, double-click the printer folder.
2Double‑click Wireless Setup Assistant.
3Follow the instructions on the computer screen.
Networking 107
Advanced wireless setup
Adding a printer to an existing ad hoc wireless network
Before you begin, make sure:
•Your wireless network adapter is properly attached to your computer and is working.
•The ad hoc wireless network that the printer will connect to is available. For more information on creating an ad
hoc wireless network, see the documentation that came with your operating system.
Notes:
•The recommended way to set up your wireless network is to use an access point. This network setup is called
infrastructure network.
•If your computer has My WiFi or Wi-Fi Direct, then you can create direct connections to your wireless printer.
For more information, see the documentation that came with your computer.
•The printer can communicate on only one wireless network at a time. Configuring the printer for an ad hoc
wireless network will remove it from any other wireless network, either ad hoc or infrastructure, for which it is
configured.
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Select your printer, and then navigate to:
Printer Home > Settings > Wireless setup utility
4Follow the instructions on the computer screen.
Note: Windows Vista computers may need to be reconnected to the ad hoc network after restarting.
For Macintosh users
1From the Applications folder in the Finder, or from the Finder desktop, double-click the printer folder.
2Double‑click Wireless Setup Assistant.
3Follow the instructions on the computer screen.
Networking 108
Configuring Wi‑Fi Protected Setup manually
Note: Make sure your access point (wireless router) is Wi‑Fi Protected Setup (WPS) certified. For more information,
see the User’s Guide.
If your printer or device has not yet been configured for wireless connection and you want to configure it using WPS,
then push the WPS button on the wireless router. Wait for the printer control panel to display a message to begin WPS
configuration. There might be a short delay before the message appears. If nothing happens after 30 seconds, then do
one of the following:
USE THE PUSH BUTTON CONFIGURATION (PBC) METHOD
1From the printer control panel, navigate to:
> Setup >
OK
> Network Setup >
OK
> Wireless 802.11b/g/n >
OK
> Network Connection Setup >
OK
> Wireless >
OK > Wi‑Fi Protected Setup > OK > WPS PBC Mode > OK
2Follow the instructions on the printer display.
USE THE PERSONAL IDENTIFICATION NUMBER (PIN) METHOD
1From the printer control panel, navigate to:
> Setup > OK > Network Setup > OK > Wireless 802.11b/g/n > OK > Network Connection Setup > OK > Wireless >
OK > Wi‑Fi Protected Setup > OK > WPS PIN Mode > OK
2Follow the instructions on the printer display.
Configuring security
Simple wireless networks require WEP keys or a WPA/WPA2 preshared key/passphrase, or may not have any security
at all. More‑advanced wireless network security can require one or more certificates and an authentication server. If
the network requires a certificate and you do not have it, then fill out the certificate request form provided within the
Wireless Setup Utility and follow the procedure of your organization in requesting a certificate for network access.
The following is a list of supported types of wireless network security and their requirements:
WEP
•WEP key (up to four keys may be required)
•Default WEP Transmit Key (if more than one WEP key is configured, this specifies which one to use)
WPA Personal, WPA2‑Personal or WPA2‑Enterprise
•Preshared key
•Encryption (AES or TKIP)
EAP‑MD5, MSCHAPv2, or LEAP
•RADIUS user name
•RADIUS password
Networking 109
PEAP
•RADIUS user name
•RADIUS password
•CA certificate
EAP‑TLS
•RADIUS user name
•CA certificate
•Signed certificate
EAP‑TTLS
•Appropriate inner authentication
•RADIUS user name
•RADIUS password
•CA certificate
Configuring 802.1X Authentication
The information to complete is dependent on the 802.1X security mechanism you select. Some require user names,
passwords, and/or certificates. If your network contains multiple access points with different modes of authentication,
then you can select and configure more than one authentication mechanism.
1From the Configure 802.1X Authentication dialog, select an authentication mechanism.
If you have selected Do this
EAP‑MD5, LEAP, or
MSCHAPv2
Proceed to the next step.
PEAP or EAP‑TTLS Click Install CA Certificate, and then type the path to the CA certificate, or click Browse to
locate the certificate file.
EAP‑TLS aClick Install Signed Certificate, and then type the path to the signed certificate, or click
Browse to locate the certificate file.
bClick Install CA Certificate, and then type the path to the CA certificate, or click Browse
to locate the certificate file.
2Type the necessary information that the authentication server requires.
3Click OK, and then follow the instructions on the computer screen.
Installing the printer on an Ethernet network
Information you will need to set up the printer on an Ethernet network
Make sure you have the following information before you begin:
•A valid, unique IP address for the printer to use
•The gateway for the network
Networking 110
•The network mask of the network where the printer will be used
•The name of the domain where the printer will reside
•The hostname of the printer
•Any security information required for authentication to the network
Note: Make sure you have an Ethernet cable to connect the printer to the network, and an available port, either on a
networking device or a wall jack, that physically connects the printer to the network.
Installing the printer on an Ethernet network
Before you install the printer on an Ethernet network, make sure that:
•You have completed the initial setup of the printer.
•Your network is set up and working properly.
•Your computer is connected to your network.
For Windows users
1Close all open software programs.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then launch the CD manually:
aClick , or click Start and then click Run.
bIn the Start Search or Run dialog, type D:\setup.exe, where D is the letter of your CD or DVD drive.
cPress Enter, or click OK.
3Click Install, and then follow the instructions on the computer screen.
Note: Select Ethernet connection when prompted to select a connection type.
For Macintosh users
1Close all open applications.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then click the CD icon on the desktop.
3Double-click the software installer package.
4Follow the instructions on the computer screen.
Note: Select Ethernet connection when prompted to select a connection type.
Networking 111
Performing network management tasks
Switching between USB, Ethernet, and wireless connections (Windows only)
You can change the way you access your printer, depending on your needs. The following procedures assume that you
have configured your printer for one type of connection and that the printer drivers are installed on the computer. See
related topics on troubleshooting specific connection types if you encounter difficulties during configuration.
Note: The printer supports one active local (USB) connection and one active network connection (Ethernet or
wireless) at a time. It is not possible to connect the printer to both Ethernet and wireless networks at the same time.
Using the printer wirelessly
Select the connection type that describes how you currently access your printer:
If the printer is currently set up locally (using USB connection)
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Select your printer, and then navigate to:
Printer Home > Settings > Wireless setup utility
4Follow the instructions on the computer screen.
Note: There is no need to remove the USB cable connecting the printer to the computer during wireless
configuration.
If the printer is currently set up for Ethernet
1Unplug the Ethernet cable from the printer.
2Place the printer close to the computer you want to use to configure the printer for wireless access.
Note: You will need to connect the printer to the computer with a USB cable. Make sure the printer is close
enough to the computer for your USB cable to reach both.
3Click or Start.
4Click All Programs or Programs, and then select the printer program folder from the list.
5Select your printer, and then navigate to:
Printer Home > Settings > Wireless setup utility
6Follow the instructions on the computer screen.
Using the printer locally (USB)
Select the connection type that describes how you currently access your printer:
If the printer is currently set up for Ethernet
1Attach a USB cable to the computer and to the printer.
2Wait a moment for Windows to locate the driver and finish setting up the printer.
Networking 112
3Select the USB printer. See “Selecting a printer” on page 113.
If the printer is currently set up for wireless
1Attach a USB cable to the computer and to the printer.
2Wait a moment for Windows to locate the driver and finish setting up the printer.
3Select the USB printer. See “Selecting a printer” on page 113.
Note: You can continue to use the printer through Ethernet or wireless connection.
Using the printer over an Ethernet network
Select the connection type that describes how you currently access your printer:
If the printer is currently set up for wireless
1Plug an Ethernet cable into the printer and into an available port on a switch or wall jack.
2Wait one minute for the Ethernet network adapter to become active and acquire an IP address from the network.
3Select the Network printer. See “Selecting a printer” on page 113.
Note: The wireless adapter of the printer is disabled while it is connected to an Ethernet network.
If the printer is currently set up locally (using USB connection)
1Plug an Ethernet cable into the printer and into an available port on a switch or wall jack.
2Insert the Software and Documentation CD into the computer you want to use to configure the printer.
3Follow the instructions on the computer screen for configuring a printer on an Ethernet network.
4Select the Network printer. See “Selecting a printer” on page 113.
Note: You will need a USB cable to complete the configuration.
Selecting a printer
1Open the printers folder.
aClick or Start.
bIn the Start Search or Run box, type control printers.
cPress Enter, or click OK.
2Right‑click the printer you want to use (Network or USB).
3Select Set as Default Printer from the menu.
4Close the “Printers” or “Printers and Faxes” window.
Networking 113
Switching between USB, Ethernet, and wireless connections (Macintosh only)
You can change the way you access your printer depending on your needs. The following procedures assume that you
have configured your printer for one type of connection and that the drivers are installed on the computer. See related
topics on troubleshooting specific connection types if you encounter difficulties during configuration.
Note: The printer supports one active local connection (USB) and one active network connection (Ethernet or
wireless) at a time. It is not possible to connect to both Ethernet and wireless at the same time.
Using the printer wirelessly
Select the connection type that describes how you currently access your printer:
If the printer is currently set up locally (using USB connection)
1Close all open applications.
2Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then click the CD icon on the desktop.
3Double‑click Lexmark Extras > Lexmark Setup Assistant.
4Follow the instructions on the computer screen.
Note: There is no need to remove the USB cable connecting the printer to the computer during wireless
configuration.
If the printer is currently set up for Ethernet
1Unplug the Ethernet cable from the printer.
2Place the printer close to the computer you want to use to configure the printer for wireless access.
Note: You will need to connect the printer to the computer with a USB cable. Make sure the printer is close
enough to the computer for your USB cable to reach both.
3Close all open applications.
4Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then click the CD icon on the desktop.
5Double‑click Lexmark Extras > Lexmark Setup Assistant.
6Follow the instructions on the computer screen.
7A second print queue will be created. Remove the Ethernet queue if you do not want to switch back to accessing
the printer over an Ethernet connection.
Using the printer locally (USB)
Select the connection type that describes how you currently access your printer:
If the printer is currently set up for Ethernet
1Firmly plug the square end of the USB cable into the back of the printer.
2Firmly plug the rectangular end of the USB cable into the USB port of the computer.
Networking 114
3Add the printer (see “Add the printer” on page 115).
4A second print queue will be created. Remove the Ethernet queue if you do not want to switch back to accessing
the printer over an Ethernet connection.
If the printer is currently set up for wireless
1Attach a USB cable to the computer and to the printer.
2Add the printer (see “Add the printer” on page 115).
3A second print queue will be created. Remove the wireless queue if you do not want to switch back to accessing
the printer over a wireless connection.
Using the printer over an Ethernet network
Select the connection type that describes how you currently access your printer:
If the printer is currently set up for wireless
1Plug an Ethernet cable into the printer and to an available port on a switch or wall jack.
2Wait a minute for the Ethernet network interface to become active and acquire an IP address from the network.
3Add the printer (see “Add the printer” on page 115).
4A second print queue will be created. Remove the wireless queue if you do not want to switch back to accessing
the printer over a wireless network.
If the printer is currently set up locally (using USB connection)
1Plug an Ethernet cable into the printer and to an available port on a switch or wall jack.
2Insert the Software and Documentation CD into the computer you want to use to configure the printer.
3Follow the instructions on the computer screen.
Note: You will need a USB cable to complete the configuration.
Add the printer
In Mac OS X version 10.5 or later
1From the Apple menu, navigate to:
System Preferences > Print & Fax
or
System Preferences > Print & Scan
2Click +.
3Click the Default or Default Browser tab, and then select your printer.
4Click Add.
In Mac OS X version 10.4 or earlier
1From the Finder, choose Utilities.
2Double‑click Printer Setup Utility or Print Center.
Networking 115
3From the Printer List dialog, choose the printer you want to use, and then click Add.
4From the Printer Browser, select your printer, and then click Add.
Sharing a printer in a Windows environment
1Prepare the computers to share the printer:
aMake all computers printing to the printer accessible through Network Neighborhood by enabling File and Print
Sharing. See the Windows documentation for instructions on enabling File and Print Sharing.
bInstall the printer software on all computers that will print to the printer.
2Identify the printer:
aOn the computer that is attached to the printer, open the printers folder:
1Click , or click Start and then click Run.
2In the Start Search or Run box, type control printers.
3Press Enter, or click OK.
bRight‑click the name of your printer.
cClick Sharing or Printer Properties.
dFrom the Sharing tab, select Share this printer or Shared as.
eAssign a distinctive name, and then click OK.
3Locate the printer from the remote computer:
Note: The remote computer is the one that is not attached to the printer.
aOpen the printers folder:
1Click , or click Start and then click Run.
2In the Start Search or Run box, type control printers.
3Press Enter, or click OK.
bRight‑click the name of your printer.
cClick Properties or Printer properties.
dClick Ports > Add Port > Local Port > New Port.
eType the Universal Naming Convention (UNC) Port Name, which consists of the server name and the distinctive
printer name that was specified in step 2 on page 116. The name should be in the form \\server\printer.
fClick OK.
gClick Close on the Printer Ports dialog.
hMake sure the new port is selected on the Ports tab, and then click Apply.
iClick OK.
Sharing a printer in a Macintosh environment
1From the Finder, choose Help > Mac Help.
2In the Search field, type sharing the printer on a network, and then press return.
Networking 116
3Select only one of the following:
•Sharing your printer with Mac OS X users—Let other Macintosh computers on the network that use Mac OS X
version 10.4 or later use any printer connected to your Macintosh computer.
•Sharing your printer with Windows users—Let Windows computers on the network use any printer connected
to your Macintosh computer.
4Follow the instructions on the computer screen.
Note: Windows users should see the Windows documentation for information on adding a network printer
connected to a Macintosh computer.
Networking FAQ
What is Wi‑Fi Protected Setup?
Wi
‑
Fi Protected Setup (WPS) is a simple and secure configuration that allows you to establish a wireless home network
and enable network security without requiring prior knowledge of Wi‑Fi technology. It is no longer necessary to
configure the network name (SSID) and WEP key or WPA passphrase for network devices.
Note: WPS supports only networks that communicate through access points (wireless routers).
The printer supports the following methods in connecting to a wireless network:
•Personal Identification Number (PIN)—A PIN on the printer is entered into the wireless settings of the access point.
•Push Button Configuration (PBC)—Buttons on both the printer and the access point are pushed within a given period
of time.
Look for any of these identifier marks to check if your access point is WPS certified:
You can find these WPS logos on the side, back, or top of your access point.
For more information on accessing the wireless settings and determining the WPS capability of your access point, see
the documentation that came with the access point or contact your system support person.
Where do I find my WEP key or WPA/WPA2 preshared key/passphrase?
•Contact your system support person.
–The person who set up your network usually keeps the WEP key or WPA/WPA2 preshared key/passphrase.
–If your wireless network was set up by your Internet Service Provider (ISP), then you might find the information
in the documentation they provided.
•See the documentation that came with your access point (wireless router).
If your access point is using the default settings, then you can find the information in the documentation.
•View the security settings on the access point.
1Open a Web browser, and then type the IP address of the access point in the address field. Press Enter.
Networking 117
Notes:
–To obtain the IP address of the access point, see the documentation that came with it or contact your
system support person.
–If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2Enter the user name and password for the access point when prompted.
Note: The WEP key or WPA/WPA2 preshared key/passphrase is not the same as the password for the
access point. The password lets you access the access point settings. The WEP key or WPA/WPA2 preshared
key/passphrase allows printers and computers to join your wireless network.
3Look for the WEP key or WPA/WPA2 preshared key/passphrase.
What is an SSID?
A Service Set Identifier (SSID) is the name that identifies a wireless network. All devices on the network must know the
SSID of the wireless network, or they will not be able to communicate with each other. Usually, the wireless network
broadcasts the SSID to allow wireless devices in the area to connect to it. Sometimes, the SSID is not broadcast for
security reasons.
If the SSID of your wireless network is not broadcast, then it cannot be detected automatically and will not show up in
the list of available wireless networks. You must enter the network information manually in this situation.
An SSID can contain up to 32 alphanumeric characters. Alphanumeric characters are a combination of alphabetic (letters
A to Z) and numeric (numbers 0 to 9) characters.
Where do I find my SSID?
•View the settings on the access point (wireless router).
Most access points have a built‑in Web server that can be accessed using a Web browser.
•Check your computer to see if a program was installed with your wireless network adapter.
Many network adapters provide a software application that allows you to view the wireless settings of your
computer, including your SSID.
If you are unable to locate your SSID using either of these methods, then contact your system support person.
What is a network?
A network is a collection of devices such as computers, printers, Ethernet hubs, access points, and routers connected
together for communication through cables or through a wireless connection. A network can be wired, wireless, or
designed to have both wired and wireless devices.
How do I find out what type of security my network is using?
•Contact your system support person.
The person who set up your network usually keeps your wireless information.
•See the documentation that came with your access point (wireless router).
•Check the characters of the password that you use to access your wireless network.
If you are not using a password, then choose None or No Security.
Networking 118
Characters Security type
Exactly 10 or 26 hexadecimal characters
or
Exactly 5 or 13 ASCII characters
WEP
Exactly 64 hexadecimal characters
or
From 8 to 63 ASCII characters
WPA or WPA2
Notes:
–Hexadecimal characters are A–F, a–f, and 0–9.
–ASCII characters are letters, numbers, and symbols found on a keyboard. ASCII characters in a WPA/WPA2
preshared key/passphrase are case‑sensitive.
•View the security settings on the access point.
1Open a Web browser. Type the IP address of the access point in the address field, and then press Enter.
Notes:
–To obtain the IP address of the access point, see the documentation that came with it, or contact your
system support person.
–If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2Enter the user name and password for the access point when prompted.
Note: The WEP key or WPA/WPA2 preshared key/passphrase is not the same as the password for the
access point. The password lets you access the access point settings. The WEP key or WPA/WPA2 preshared
key/passphrase allows printers and computers to join your wireless network.
3Look for the WEP key or WPA/WPA2 preshared key/passphrase.
How are home networks configured?
For desktop computers, laptops, and printers to communicate with each other over a network, they must be connected
by cables and/or have wireless network adapters built in or installed in them.
There are many different ways a network can be set up. Four common examples appear below.
Note: The printers in the following diagrams represent printers with internal print servers built into them so that
they can communicate over a network.
Wireless network examples
Scenario 1: Mixed wired and wireless connections on a network with Internet access
•All computers and printers connect to the network through a router with Ethernet and wireless capabilities.
•Some computers and printers connect wirelessly to the router; others connect over a wired connection.
Networking 119
•The network is connected to the Internet through a DSL or cable modem.
Internet
Scenario 2: Wireless network with Internet access
•All computers and printers connect to the network using a wireless access point or wireless router.
•The wireless access point connects the network to the Internet through a DSL or cable modem.
Internet
Scenario 3: Wireless network with no Internet access
•Computers and printers connect to the network using a wireless access point.
•The network has no connection to the Internet.
Networking 120
Scenario 4: Computer connected wirelessly to a printer without Internet access
•A computer is directly connected to a printer without going through a wireless router.
•This configuration is referred to as an ad hoc network.
•The network has no connection to the Internet.
Note: Most computers can connect to only one wireless network at a time. If you access the Internet over a wireless
connection, you will lose Internet access if you are connected to an ad hoc network.
What is a USB cable?
A Universal Serial Bus (USB) cable is primarily used to connect a USB device to a host. Common hosts include computers
and video game consoles. Through the USB port and cable, it is possible to connect computer peripherals such as mouse
devices, keyboards, digital cameras, printers, personal media players, flash drives, and external hard drives. For many
of those devices, USB has become the standard connection method.
Why do I need a USB cable?
When setting up the printer on your wireless network, the printer will need to temporarily connect to a computer using
the USB cable. This temporary connection may be used to set up the wireless settings of the printer.
Note: A USB cable is not necessary when connecting to a wireless network through Wi‑Fi Protected Setup (WPS).
How do I attach the USB cable?
The USB cable attaches to a USB port on the computer and to the square connector on the back of the printer. This
connection allows you to configure the printer for a network or local (USB) installation.
The USB port on the computer and on the printer are each marked with .
Note: Do not connect the USB cable until prompted to do.
1If the USB port at the back of the printer is covered by a sticker, then make sure to remove it.
Networking 121
2Firmly plug the square end of the USB cable into the back of the printer.
3Firmly plug the rectangular end of the USB cable into the USB port of the computer.
4Follow the instructions on the computer screen.
How are infrastructure and ad hoc networks different?
Wireless networks can operate in one of two modes: infrastructure or ad hoc.
In infrastructure mode, all devices on a wireless network communicate with each other through an access point (wireless
router).
In ad hoc mode, a computer with a wireless network adapter communicates directly with a printer equipped with a
wireless print server.
Infrastructure Ad hoc
Characteristics
Communication Through an access point Directly between devices
Security More security options WEP or no security
Range Determined by the range and number
of access points
Restricted to the range of individual
devices on the network
Networking 122
Infrastructure Ad hoc
Speed Usually faster Usually slower
Requirements for all devices
Unique IP address for each device Yes Yes
Mode set to Infrastructure mode Ad hoc mode
Same SSID Yes, including the access point Yes
Same channel Yes, including the access point Yes
We recommend setting up a network in infrastructure mode using the installation software CD. Infrastructure mode
provides:
•Increased network security
•Increased reliability
•Faster performance
•Easier setup
Finding the signal strength
The signal strength tells you how strongly the computer or printer is receiving the wireless signal from the wireless
network. Poor signal quality could affect connectivity during configuration.
Checking computer connectivity
1From your computer system tray, click the wireless icon that corresponds to the software managing your wireless
network adapter.
2Check the signal quality.
Checking printer connectivity
•From the printer, print a network setup page.
In the Wireless section, look for Quality.
•View the signal strength from the printer control panel.
Navigate to:
> Setup > OK > Network Setup > OK > Wireless 802.11 b/g/n > OK > Network Connection Setup > OK > Wireless >
OK > View Signal Quality > OK
To improve signal quality, remove sources of interference or move wireless devices closer to the access point (wireless
router).
Networking 123
How can I improve wireless signal strength?
A common reason wireless printers fail to communicate over a network is poor wireless signal quality. If the signal is
too weak, too distorted, or blocked by an object, it cannot carry information between the access point and the printer.
To determine if the printer is receiving a strong signal from the access point, print a network setup page. The Quality
field indicates the relative strength of the wireless signal the printer is receiving. Drops in signal strength can be
intermittent, however, and although the signal quality appears high, it may drop during certain conditions.
If you think signal strength is a problem between your access point (wireless router) and the printer, then try one or
more of the following:
Notes:
•The solutions below are for infrastructure networks. If you are using an ad hoc network, then adjust the
computer when the solution suggests adjusting the access point.
•Ad hoc networks have a much shorter range than infrastructure networks. Try moving the printer closer to the
computer if they seem to have trouble communicating.
MOVE THE PRINTER CLOSER TO THE ACCESS POINT
If the printer is too far away from the access point, then it will not be able to communicate with other devices on
the network. For most indoor wireless networks, the maximum distance between the access point and the printer
is approximately 100 feet (30 meters). This distance could be longer or shorter, depending upon the layout of the
network and the limitations of the access point.
REMOVE OBSTACLES BETWEEN THE ACCESS POINT AND THE PRINTER
The wireless signal from your access point will pass through most objects. Most walls, floors, furniture, and other
objects will not block the wireless signal. However, there are materials that are too dense for the signal to pass
through, such as objects containing metal and concrete. Arrange your printer and access point so that the signal is
not blocked by such objects.
REMOVE SOURCES OF INTERFERENCE
Other types of radio frequencies can cause problems with the wireless signal on your network, resulting to printing
issues that seem to come and go.
•Turn off potential sources of interference where possible.
•Avoid using microwave ovens, cordless phones (but not cellular phones), baby monitors, almost any kitchen
appliance, wireless surveillance equipment, or any appliance containing a motor when printing over your wireless
network.
•If another wireless network is operating in the vicinity, then change the wireless channel on the access point.
•Do not place your access point on a printer or other electronic device. Such devices can also interfere with the
wireless signal.
ARRANGE THE NETWORK TO REDUCE SIGNAL ABSORPTION
Even when the wireless signal is able to pass through an object, it is slightly weakened. If it passes through too many
objects, then it can be significantly weakened. All objects absorb part of the wireless signal when it passes through
them, and certain types of objects absorb enough to cause communications problems. Place your access point as
high in the room as possible to avoid signal absorption.
Networking 124
How can I make sure my computer and printer are connected to the same
wireless network?
If the printer is not on the same wireless network as the computer, then you will not be able to print wirelessly. The
SSID of the printer must match the SSID of the computer, if the computer is already connected to the wireless network.
For Windows users
1Obtain the SSID of the network that the computer is connected to:
aType the IP address of your access point (wireless router) in the address field of your Web browser.
If you do not know the IP address of the access point, then do the following:
1Click , or click Start and then click Run.
2In the Start Search or Run dialog, type cmd.
3Press Enter, or click OK.
4Type ipconfig, and then press Enter. Check the Wireless Network Connection section:
•The “Default Gateway” entry is typically the access point.
•The IP address appears as four sets of numbers separated by periods, such as 192.168.2.134.
bType the user name and password of the router when prompted.
cClick OK.
dIn the Wireless settings section, look for the SSID.
eWrite down the SSID.
Note: Make sure you copy it exactly, including any capital letters.
2Obtain the SSID of the network that the printer is connected to:
aFrom the printer, print a network setup page.
bIn the Wireless section, look for SSID.
3Compare the SSID of the computer and SSID of the printer.
If the SSIDs are the same, then the computer and the printer are connected to the same wireless network.
If the SSIDs are not the same, then run the utility again to set up the printer on the wireless network used by the
computer.
For Macintosh users with an AirPort base station
In Mac OS X version 10.5 or later
1From the Apple menu, navigate to:
System Preferences > Network > AirPort
or
System Preferences > Network > Wi‑Fi
The SSID of the network that the computer is connected to is displayed in the Network Name menu.
2Write down the SSID.
Networking 125
In Mac OS X version 10.4 or earlier
1From the Finder, navigate to:
Applications > Internet Connect > AirPort
The SSID of the network that the computer is connected to is displayed in the Network menu.
2Write down the SSID.
For Macintosh users with an access point
1Type the IP address of the access point in the address field of your Web browser and continue to step 2.
If you do not know the IP address of the access point, then do the following:
aFrom the Apple menu, navigate to:
System Preferences > Network > AirPort
or
System Preferences > Network > Wi‑Fi
bClick Advanced or Configure.
cClick TCP/IP.
The Router entry is typically the access point.
2Type your user name and password when prompted, and then click OK.
3In the Wireless settings section, look for the SSID.
4Write down the SSID, security type, and the WEP key or WPA/WPA2 preshared key/passphrase (if shown).
Notes:
•Make sure you copy the network information down exactly, including any capital letters.
•Store the SSID and the WEP key or WPA/WPA2 preshared key/passphrase in a safe place for future
reference.
Can I use my printer on a USB and a network connection at the same time?
Yes; the printer supports a simultaneous USB and network connection. The printer can be configured in the following
ways:
•Locally attached (connected to a computer using a USB cable)
•Wireless network
•Ethernet network
•Wireless network and locally attached simultaneously
•Ethernet network and locally attached simultaneously
What is a MAC address?
A Media Access Control (MAC) address is a 48‑bit identifier associated with the hardware of network equipment. The
MAC address may also be called the physical address because it is connected to the hardware of a device instead of its
software. The MAC address is displayed as a hexadecimal number in this format: 01-23-45-67-89-AB.
Networking 126
While it is possible to change the MAC address of a network device, it is not common practice to do so. For this reason,
MAC addresses are considered permanent. IP addresses are easily changed, so MAC addresses are a more reliable
method of identifying a specific device on a network.
Routers with security capabilities may allow filtering of MAC addresses on networks. This allows a managed list of
devices to access the network, identified by their MAC addresses, as well as prevent access from unwanted devices. If
your network uses MAC address filtering, then be sure to add the MAC address of the printer to the list of allowed
devices.
How do I find the MAC address?
Network devices have a unique hardware identification number to distinguish them from other devices on the network.
This is called the MAC (Media Access Control) address. Other devices sometimes use a type of MAC address called
Universally Administered Address (UAA).
When installing the printer on a network, make sure you select the printer with the correct MAC address.
The MAC address of the internal print server is a series of letters and numbers.
Notes:
•A list of MAC addresses can be set on an access point (wireless router) so that only devices with matching MAC
addresses are allowed to operate on the network. This is called MAC filtering. If MAC filtering is enabled in your
access point and you want to add a printer to your network, then the MAC address of the printer must be
included in the MAC filter list.
Networking 127
•If you are using an AirPort base station, then the MAC address may be referred to as AirPort ID, and MAC
address filtering may be accessed through MAC Address Access Control.
What is an IP address?
An IP address is a unique number used by devices (such as a wireless printer, computer, or access point (wireless router))
on an IP network to locate and communicate with each other. Devices on an IP network can communicate with each
other only if they have unique and valid IP addresses. A unique IP address means no two devices on the same network
have the same IP address.
An IP address is a group of four numbers separated by periods. An example of an IP address is 123.123.123.123.
What is TCP/IP?
Networks are able to function when computers, printers, and other devices are able to send data to each other, either
through cables or wireless signals. This transfer of data is made possible by sets of data transmission rules called
protocols. A protocol can be thought of as a language that has rules so that participants can effectively communicate
with each other.
Different types of networks use different protocols, but Transmission Control Protocol/Internet Protocol (TCP/IP) is the
most popular. TCP/IP is used to send data over the Internet as well as over most corporate and home networks.
Every device on a network that uses TCP/IP must have an IP address. IP addresses are essentially unique computer
names in a numeric format, used to transfer data around a network. IP addresses allow TCP/IP to confirm requests for,
and receipt of, data by various devices on the network.
How do I locate IP addresses?
For Windows users
1Click , or click Start and then click Run.
2In the Start Search or Run dialog, type cmd.
3Press Enter, or click OK.
4Type ipconfig, and then press Enter.
The IP address appears as four sets of numbers separated by periods, such as 192.168.0.100.
For Macintosh users
1From the Apple menu, navigate to:
About This Mac > More Info
2From the Contents pane, choose Network.
3If you are connected over a wireless network, then choose AirPort from the Active Services list.
Networking 128
Locating the printer IP address
•From the printer, print a network setup page.
In the TCP/IP section, look for Address.
•View the printer settings.
From the printer control panel, navigate to:
> Setup >
OK
> Network Setup >
OK
> Wireless 802.11 b/g/n >
OK
> Network Connection Setup >
OK
> TCP/IP >
OK > IP Address > OK
or
> Setup >
OK
> Network Setup >
OK
> Ethernet 10/100 >
OK
> Network Connection Setup >
OK
> TCP/IP >
OK
>
IP Address > OK
How are IP addresses assigned?
An IP address may be assigned automatically by the network using DHCP. Once the printer is set up on a computer, the
computer sends all print jobs across the network to the printer using this address.
If the IP address is not automatically assigned, you will be asked during wireless setup to manually enter an address
and other network information after selecting your printer from the available list.
What is a key index?
An access point (wireless router) can be configured with as many as four WEP keys. Only one key is used on the network
at a time, however. The keys are numbered, and the number of a key is referred to as its key index. All devices on the
wireless network must be configured to use the same key index when multiple WEP keys are configured on the access
point.
Select the same key index on your printer as you are using on your access point.
What is the difference between Guided and Advanced setup?
Use Guided setup if:
•The printer and the computer communicate on the same wireless network.
•You want the Wireless Setup Utility to automatically detect the network for you.
•You want to connect your printer to the wireless network using Wi‑Fi Protected Setup (WPS).
Use Advanced setup if:
•The printer and the installing computer are not on the same wireless network, or if the computer does not have
wireless access.
•The wireless network requires certificates.
•Enterprise‑level security is employed on the wireless network.
•You know the network SSID and security information and want to enter the information on a single screen.
•The printer will be configured for a remote network.
•You know your network information and want to enter it quickly.
•You are configuring a printer for a wireless network that uses 802.1X authentication.
Networking 129
Using the Embedded Web Server
The Embedded Web Server lets you view and remotely customize printer settings even when you are not physically
near the printer. You can also view reports on printer activities, monitor and order printer supplies online, contact
customer support, and download updates for your printer.
The Embedded Web Server requires that the printer is connected to your network through Ethernet connection. For
more information on connecting the printer to your network, see the printer User’s Guide.
Accessing the Embedded Web Server
Note: Make sure the printer is connected to your network. For more information, see the printer User’s Guide.
1Obtain the printer IP address:
•From the printer home screen
•From the TCP/IP section in the Networks/Ports menu
Note: An IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.
2Open a Web browser, and then type the printer IP address in the address field.
The Embedded Web Server appears.
Understanding the home page
Use the To
1Navigation pane Access the Embedded Web Server menus.
2Header bar •View a brief summary of your printer supplies.
•View the information on printer model, IP address, contact information, and location.
•Access the Search function.
Note: The search fields may not appear in the Embedded Web Server, depending on your
printer model.
3Information pane View specific information and access submenu items, depending on the menu selected from the
navigation pane.
Using the Embedded Web Server 130
Customizing printer settings
1From the navigation pane, select Settings.
2Do one of the following:
Click To
General Settings View and customize general printer settings.
Copy Settings View and customize settings for making copies.
Note: This feature may not appear in the Embedded Web Server, depending on your
printer model.
Fax Settings View and customize settings for sending and receiving faxes.
Note: This feature may not appear in the Embedded Web Server, depending on your
printer model.
E-mail/FTP Settings View and customize settings for sending e-mails, or sending files to a File Transfer
Protocol (FTP) address.
Note: This feature may not appear in the Embedded Web Server, depending on your
printer model.
Print Settings View and customize print settings.
Paper Setup View and customize paper setup options.
Network/Ports View and customize network settings.
Security View and customize security settings for the printer and Embedded Web Server.
Note: This feature may not appear in the Embedded Web Server, depending on your
printer model.
E-mail Alert Setup Set up the e-mail server for the Embedded Web Server, and then customize e-mail alert
settings.
Scan‑to‑Network Folder
Setup
Add or manage a folder destination when the Scan to Network application is used.
Notes:
•This feature may not appear in the Embedded Web Server, depending on your
printer model.
•To use this feature, first make sure you are using the Hyper Text Transfer Protocol
Secure (HTTPS) connection.
Manage Shortcuts Add or manage shortcut settings for a printer task.
Note: This feature may not appear in the Embedded Web Server, depending on your
printer model.
Manage Profiles View the IP address of a profile, or delete it.
Note: This feature may not appear in the Embedded Web Server, depending on your
printer model.
Address Book Setup Add or manage address book contacts when sending e‑mails.
Intervention Management View any messages from the printer requesting intervention from the user.
Import/Export Import or export a configuration file.
Additional Solutions Install, customize, or uninstall a solution.
Using the Embedded Web Server 131
Click To
Device Management Allow the Embedded Web Server to collect data from the printer.
3Click Submit to save, or click Reset Form to discard the new settings.
Using the Embedded Web Server 132
Maintaining the printer
Maintaining ink cartridges
In addition to the following tasks that you can perform, your printer performs automatic maintenance cycles if it is
plugged into a properly grounded, working electrical outlet. It will briefly come out of Sleep mode or will temporarily
turn on if it is turned off.
Checking ink levels
Using the printer control panel
From the printer control panel, navigate to:
> Setup > OK >Maintenance > OK > Check Ink Levels > OK
Using the printer software
For Windows users
1Click or Start.
2Click All Programs or Programs, and then select the printer program folder from the list.
3Navigate to:
Printer Home > select your printer > Maintenance tab > Supplies Status
For Macintosh users
1From the Apple menu, navigate to:
System Preferences > Print & Fax > select your printer
2Click Options & Supplies or Print Queue.
3Click Supply Levels.
Aligning the printhead
If the characters or lines on your printed image appear jagged or wavy, then you may need to align the printhead.
1Load plain paper.
2From the printer control panel, navigate to:
> Setup > OK >Maintenance > OK > Align Printer > OK
An alignment page prints.
Note: Do not remove the alignment page until printing is finished.
If you aligned the cartridges to improve print quality, then print your document again. If print quality has not improved,
then clean the printhead nozzles.
Maintaining the printer 133
Cleaning the printhead nozzles
If you have not been using the printer for a long period, then you may need to clean the printhead nozzles to improve
the quality of your prints. Keep your printer plugged to a properly grounded, working electrical outlet to allow it to
perform automatic maintenance cycles.
Notes:
•Cleaning the printhead nozzles uses ink, so clean them only when necessary.
•Deep cleaning uses more ink, so try the Clean Printhead option first to save ink.
•If the ink levels are too low, then you must replace the ink cartridges before you can clean the printhead
nozzles.
1From the printer control panel, navigate to:
> Setup > OK > Maintenance > OK
2Press the up or down arrow button to scroll to Clean Printhead or Deep Clean Printhead, and then
press OK .
3Press the up or down arrow button to scroll to a cleaning option, and then press OK .
Wait until the printer is ready.
Cleaning the exterior of the printer
1Make sure that the printer is turned off and unplugged from the wall outlet.
CAUTION—SHOCK HAZARD: To avoid the risk of electric shock when cleaning the exterior of the printer,
unplug the power cord from the wall outlet and disconnect all cables to the printer before proceeding.
2Remove all paper from the printer.
3Dampen a clean, lint‑free cloth with water.
Warning—Potential Damage: Do not use household cleaners or detergents, as they may damage the finish of
the printer.
4Wipe only the outside of the printer, making sure to remove any ink residue that has accumulated on the exit bin.
Warning—Potential Damage: Using a damp cloth to clean the interior may cause damage to your printer.
5Make sure the printer is dry before beginning a new print job.
Maintaining the printer 134
Cleaning the scanner glass
Clean the scanner glass and other related parts when vertical streaks appear on your printed pages or when you see
marks or smudges on such parts.
1Dampen a clean, lint‑free cloth with water.
2Gently wipe clean the scanner glass and other related parts.
1Backing material
2Scanner glass
3ADF scanner glass
4ADF press plate
Note: Make sure all ink or corrective fluid on the document is dry before placing the document on the scanner glass.
Moving the printer to another location
When moving the printer and optional trays to another location, follow these precautions:
•Any cart used to move the printer must have a surface able to support the full footprint of the printer. Any cart
used to move the options must have a surface able to support the dimensions of the options.
•Make sure the bin extender and the exit bin are in their original positions.
•Keep the printer in an upright position.
•Make sure to remove the ink cartridges from the printer.
Maintaining the printer 135
•Store the used ink cartridges in a box with the nozzles faceup.
•Avoid severe jarring movements.
•If available, use the original packaging of the printer with the needed padding to keep the printer protected during
transport.
Maintaining the printer 136
Troubleshooting
Before you troubleshoot
Use this checklist to solve most printer problems:
•Make sure the power cord is plugged into the printer and into a properly grounded, working electrical outlet.
•Make sure the printer is turned on.
•Make sure the printer is securely connected to the computer, print server, or network access point.
•Check the printer for error messages, and resolve any errors.
•Check for paper jam messages, and clear any jams.
•Check the ink cartridges, and install new cartridges if necessary.
•Turn the printer off, wait about 10 seconds, and then turn the printer back on.
Note: Make sure the printer is not in Sleep mode. Press and hold for three seconds to turn off the printer.
If Troubleshooting does not solve your problem
Visit our Web site at http://support.lexmark.com to find the following:
•Knowledgebase articles with the latest information and troubleshooting for your printer
•Live online customer support
•Contact numbers for telephone customer support
•Firmware and software updates
Setup troubleshooting
•“Incorrect language appears on the display” on page 138
•“Software did not install” on page 138
•“Recovering the security PIN of the printer” on page 138
•“Print job does not print or is missing pages” on page 139
•“Printer is printing blank pages” on page 140
•“Printer is busy or does not respond” on page 140
•“Cannot delete documents from the print queue” on page 141
•“Cannot print through USB” on page 141
Troubleshooting 137
Incorrect language appears on the display
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CHANGE THE LANGUAGE USING THE PRINTER MENUS
1From the printer control panel, navigate to:
> Setup > OK > Device Setup > OK > Language > OK
2Press the up or down arrow button to scroll to the language you want, and then press
OK
.
3To confirm the setting, press the left or right arrow button to scroll to Yes, and then press OK .
Software did not install
If you encountered problems while installing, or if your printer does not appear in the list in the printers folder or as a
printer option when sending a print job, then try uninstalling and reinstalling the software.
Before you reinstall the software, do the following:
MAKE SURE THAT YOUR COMPUTER MEETS THE MINIMUM SYSTEM REQUIREMENTS
TEMPORARILY DISABLE SECURITY PROGRAMS IN WINDOWS BEFORE INSTALLING THE SOFTWARE
CHECK THE USB CONNECTION
1Check the USB cable for any obvious damage. If the cable is damaged, then use a new one.
2Firmly plug the square end of the USB cable into the back of the printer.
3Firmly plug the rectangular end of the USB cable into the USB port of the computer.
The USB port is marked with .
Note: If you continue to have problems, then try another USB port on the computer. You may have connected to a
defective port.
RECONNECT THE PRINTER POWER SUPPLY
1Turn off the printer.
Note: Make sure the printer is not in Sleep mode. Press and hold for three seconds to turn off the printer.
2Unplug the power cord from the wall outlet, and then pull out the power cord from the power supply.
3After one minute, reconnect the power cord into the power supply, and then plug the power cord into the wall
outlet.
4Turn on the printer.
Recovering the security PIN of the printer
Contact customer support.
Troubleshooting 138
Print job does not print or is missing pages
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
MAKE SURE THE INK CARTRIDGES ARE INSERTED CORRECTLY
1Turn the printer on, and then open the ink cartridge access door.
2Make sure the cartridges are inserted correctly.
The cartridges should click firmly into their matching color slots.
3Close the ink cartridge access door.
SELECT YOUR PRINTER FROM THE PRINT DIALOG BEFORE SENDING THE PRINT JOB
Note: This solution applies to Macintosh users only.
1With a document open, choose File > Print.
2From the printer pop-up menu, choose your printer, and then click Print.
If your printer does not appear on the Printer list, then choose Add Printer. From the list of printers in the Default
tab, select your printer, and then click Add.
If your printer does not appear on the list, then try either of the following:
•For a USB-connected printer, remove and then reconnect the USB cable.
•For a printer that is wirelessly connected, see the Wireless troubleshooting section.
MAKE SURE THE PRINT JOB IS NOT PAUSED
MAKE SURE YOUR PRINTER IS SET AS THE DEFAULT PRINTER
RECONNECT THE PRINTER POWER SUPPLY
1Turn off the printer.
Note: Make sure the printer is not in Sleep mode. Press and hold for three seconds to turn off the printer.
2Unplug the power cord from the wall outlet, and then pull out the power cord from the power supply.
3After one minute, reconnect the power cord into the power supply, and then plug the power cord into the wall
outlet.
4Turn on the printer.
REMOVE AND RECONNECT THE USB CABLE CONNECTED TO YOUR PRINTER
CHECK THE USB CONNECTION
1Check the USB cable for any obvious damage. If the cable is damaged, then use a new one.
2Firmly plug the square end of the USB cable into the back of the printer.
Troubleshooting 139
3Firmly plug the rectangular end of the USB cable into the USB port of the computer.
The USB port is marked with .
Note: If you continue to have problems, then try another USB port on the computer. You may have connected to a
defective port.
REMOVE AND REINSTALL THE PRINTER SOFTWARE
Printer is printing blank pages
Blank pages may be caused by improperly installed ink cartridges.
REINSTALL THE INK CARTRIDGES AND DEEP CLEAN AND ALIGN THE PRINTHEAD
1Reinstall the ink cartridges. For more information, see “Replacing ink cartridges” on page 14.
The cartridges should click firmly into their matching color slots.
2Load plain, unmarked paper.
3From the printer control panel, navigate to:
> Setup > OK > Maintenance > OK > Deep Clean Printhead > OK
4Press the up or down arrow button to scroll to a cleaning option, and then press OK .
Wait until the printer is ready.
5From the printer control panel, navigate to:
> Setup > OK > Maintenance > OK > Align Printer > OK
An alignment page prints.
Note: Do not remove the alignment page until printing is finished.
Printer is busy or does not respond
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
MAKE SURE THE PRINTER IS NOT IN SLEEP MODE
If the power light is blinking on and off slowly, then the printer is in Sleep mode. Press to wake up the printer.
If the printer will not come out of Sleep mode, then reset the power:
1Unplug the power cord from the wall outlet, and then wait 10 seconds.
2Insert the power cord into the wall outlet, and then turn on the printer.
If this problem persists, then check our Web site for updates for your printer software or firmware.
Troubleshooting 140
RECONNECT THE PRINTER POWER SUPPLY
1Turn off the printer.
Note: Make sure the printer is not in Sleep mode. Press and hold for three seconds to turn off the printer.
2Unplug the power cord from the wall outlet, and then pull out the power cord from the power supply.
3After one minute, reconnect the power cord into the power supply, and then plug the power cord into the wall
outlet.
4Turn on the printer.
Cannot delete documents from the print queue
If you have jobs stuck in the print queue and cannot delete them to get other jobs to print, then the computer and
printer may not be communicating.
RESTART THE COMPUTER AND TRY AGAIN
REMOVE AND RECONNECT THE USB CABLE CONNECTED TO YOUR PRINTER
Cannot print through USB
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CHECK THE USB CONNECTION
1Check the USB cable for any obvious damage. If the cable is damaged, then use a new one.
2Firmly plug the square end of the USB cable into the back of the printer.
3Firmly plug the rectangular end of the USB cable into the USB port of the computer.
The USB port is marked with .
Note: If you continue to have problems, then try another USB port on the computer. You may have connected to a
defective port.
MAKE SURE THE USB PORT IS ENABLED IN WINDOWS
1Click , or click Start and then click Run.
2In the Start Search or Run box, type devmgmt.msc.
3Press Enter, or click OK.
The Device Manager opens.
4Click the plus sign (+) beside Universal Serial Bus controllers.
If USB Host Controller and USB Root Hub are listed, then the USB port is enabled.
For more information, see the computer documentation.
Troubleshooting 141
REMOVE AND REINSTALL THE PRINTER SOFTWARE
Understanding printer messages
Alignment Problem
Try one or more of the following:
•Load plain, unmarked paper, and then realign the printhead.
Note: The printer will read any markings on used paper, which could cause the alignment error message to
reappear.
•Press OK to retry, or press to clear the message.
Cannot Collate Job
Try one or more of the following:
•Press OK to continue printing the pages that were saved in the printer memory, and then collate the remainder of
the print job.
•Press to cancel the current print job.
Change [Paper Source] to [Size] Paper
Try one or more of the following:
•Press OK to continue printing after loading the correct paper size and paper type in the default paper tray.
•Press to cancel the current job.
Change [Paper Source] to [Size] [Type] Paper
Try one or more of the following:
•Press OK to continue printing after loading the correct paper size and paper type in the default paper tray.
•Press to cancel the current job.
Close Printer
The printer is open. Close the printer to clear the message.
Troubleshooting 142
Duplex Unit Missing
Try one or more of the following:
•Make sure the duplex unit is properly installed at the back of the printer to clear the message.
•Cancel the current job.
Ink Cartridge Access Door Open
The ink cartridge access door is either open or detached.
•If the ink cartridge access door is open, then close it to clear the message.
•If the ink cartridge access door is detached, then reattach it to clear the message.
Troubleshooting 143
1Insert the door hinges into place until they click. Make sure the door is inserted at a 90-degree position.
2Close the ink cartridge access door to clear the message.
Ink Cartridge Error
The printer is unable to authenticate one or more of the installed ink cartridges. Try one or more of the following:
•Press to cancel the current job.
•Use only genuine Lexmark ink cartridges.
•Install the specified ink cartridges properly.
•Turn the printer off, then wait about 10 seconds, and then turn the printer back on.
Note: Make sure the printer is not in Sleep mode. Press and hold for three seconds to turn off the printer.
•See the User's Guide or visit the Lexmark Support Web site at http://support.lexmark.com for more information.
Ink Cartridge Missing
Try one or more of the following:
•Install the specified missing ink cartridge or cartridges.
•Reinsert the specified ink cartridge or cartridges.
•Press OK or to clear the message.
•See the User's Guide or visit the Lexmark Support Web site at http://support.lexmark.com for a list of supported
ink cartridges.
Ink Cartridge Unsupported
Try one or more of the following:
•Replace the unrecognized ink cartridge with one that is supported by your printer.
•Use only genuine Lexmark ink cartridges.
•Press
OK
or to clear the message.
•See the User's Guide or visit the Lexmark Support Web site at http://support.lexmark.com for a list of supported
ink cartridges.
Troubleshooting 144
Ink Low
You may need to replace the specified ink cartridge soon. Try one or more of the following:
•Press OK or to clear the message and continue printing.
Note: Depending on your printer settings, you may not be allowed to continue printing until you replace the
specified cartridge.
•See the User's Guide or visit the Lexmark Support Web site at http://support.lexmark.com for a list of supported
ink cartridges.
Load [Paper Source] with [Size] Paper
Try one or more of the following:
•Load the specified paper in the tray.
•Press OK to clear the message and continue printing.
•Press to cancel the current job.
Load [Paper Source] with [Size] [Type] Paper
Try one or more of the following:
•Load the specified paper in the tray.
•Press OK to clear the message and continue printing.
•Press to cancel the current job.
Memory Device Error
Try one or more of the following:
•Remove the memory device, and then reinsert it into the card slot or USB port.
•Touch OK or press OK to clear the message.
Network [x] Software Error
[x] is the number of the network connection.
Try one or more of the following:
•Press OK to clear the message.
•Turn the printer off and then back on to reset the printer.
Paper Tray [x] Detected
Try one or more of the following:
•Press OK to clear the message.
•Use the arrow buttons to select Change Settings, and then select the paper size and paper type of the media loaded.
Press OK for each selection.
Troubleshooting 145
Paper Tray [x] Removed
Do one or more of the following:
•Insert the specified paper tray into the printer.
•Press OK to clear the message.
Printer Memory Full
Try one or more of the following:
•Depending on your printer model, touch OK or press OK to clear the message, and then try printing again.
•From the computer, adjust the printer settings to reduce the quality of the print job, and then try printing again.
Printhead Cannot Move
Try one or more of the following:
•Open the printer to remove any obstructions to the printhead, and then close the printer.
•Press OK to clear the message.
Printhead Error
There is a problem with the printhead. Contact technical support.
Printhead Warning
Clean or Deep Clean the printhead to restore print quality.
Notes:
•Cleaning the printhead nozzles uses ink, so clean them only when necessary.
•Deep cleaning uses more ink, so try the Clean Printhead option first to save ink.
•If the ink levels are too low, then you must replace the ink cartridges before you can clean the printhead
nozzles.
•See the User's Guide for more information on how to clean the printhead nozzles.
Replace Ink Cartridge
Try one or more of the following:
•Replace the ink cartridge with one that is supported by your printer.
•Press OK to clear the message.
•See the User's Guide or visit the Lexmark Support Web site at http://support.lexmark.com for a list of supported
ink cartridges.
Scanned Document Too Long
The scan job exceeds the maximum number of pages. Press to clear the message and cancel the current scan job.
Troubleshooting 146
Scanner ADF Cover Open
Try one or more of the following:
•Close the ADF cover to clear the message.
•Press to cancel the current scan job.
Scanner Disabled
Try one or more of the following:
•Check the printer software settings or the Administration settings from the printer to enable the scanner.
For more information, contact customer support.
•Press OK to clear the message.
Short Paper
Try one or more of the following:
•Touch OK or press OK , depending on your printer model.
•Make sure the paper size is correctly set.
•Load paper with the correct size in the tray or on the paper support.
•Check the paper guides, and then make sure the paper is properly loaded in the tray or on the paper support.
•Cancel the current print job.
Standard Network Software Error
Try one or more of the following:
•Press OK to clear the message.
•Turn the printer off and then back on to reset the printer.
Unrecoverable Scan Error
Try one or more of the following:
•Restart your printer.
•Update your printer firmware. For more information, visit http://support.lexmark.com.
USB Device Not Supported
Remove the unrecognized USB device and replace it with a supported device.
USB Hub Not Supported
Remove the unrecognized USB hub.
Troubleshooting 147
Clearing paper jams
•“Paper jam in the printer” on page 148
•“Paper jam in the duplex unit” on page 148
•“Paper jam in the ADF (select models only)” on page 149
•“Paper or specialty media misfeeds” on page 150
Paper jam in the printer
Note: The parts inside the printer are sensitive. Avoid unnecessarily touching these parts while clearing jams.
1Check the paper tray, exit bin, or jam clearance area for any jammed paper.
Notes:
•For select models that support a second tray, make sure you also check the second tray.
•If the paper tray was removed, then make sure you do not replace the tray until the jam is cleared.
•Make sure you do not tilt the printer when checking the jam clearance area. Grasp and pull the latch under
the printer control panel to open the printer.
•Before clearing the jam, make sure the printhead is moved to the side and away from the jammed paper.
2Firmly grasp the paper, and then gently pull it out.
Note: Be careful not to tear the paper while removing it.
3If necessary, close the printer to clear the message.
Paper jam in the duplex unit
Note: The parts inside the printer are sensitive. Avoid unnecessarily touching these parts while clearing jams.
Troubleshooting 148
1Pull up the duplex latch and remove the duplex unit.
2Firmly grasp the paper, and then gently pull it out.
Note: Be careful not to tear the paper while removing it.
3Reinsert the duplex unit to clear the message.
Paper jam in the ADF (select models only)
Note: The parts inside the printer are sensitive. Avoid unnecessarily touching these parts while clearing jams.
1Open the ADF cover, and then gently pull out the jammed paper.
Troubleshooting 149
Notes:
•Make sure the ADF cover is fully opened to ensure that the jammed paper is properly removed.
•Be careful not to tear the paper while removing it.
2Close the ADF cover.
Note: Make sure there is no paper on the ADF input tray before closing the ADF cover.
3If necessary, touch OK or press OK , depending on your printer model.
4Resume the copy, scan, or fax job.
Paper or specialty media misfeeds
These are possible solutions if paper or specialty media misfeeds or skews, or if multiple sheets feed or stick together.
Try one or more of the following:
CHECK PAPER CONDITION
Use only new, unwrinkled paper.
CHECK PAPER LOADING
•Load a smaller amount of paper into the printer.
•Load paper with the print side facedown. (If you are not sure which side is the printable side, see the instructions
that came with the paper.)
•Check the loading instructions for your paper or specialty media.
REMOVE EACH PAGE AS IT IS PRINTED
ADJUST THE PAPER GUIDES TO FIT THE LOADED PAPER
Troubleshooting 150
Print troubleshooting
•“Poor quality at the edges of the page” on page 151
•“Streaks or lines on printed image” on page 152
•“Print speed is slow” on page 152
•“Computer slows down when printing” on page 153
Poor quality at the edges of the page
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CHECK MINIMUM PRINT SETTINGS
Unless you are using the borderless feature, use these minimum print margin settings:
•Left and right margins:
–6.35 mm (0.25 in.) for letter‑size paper
–3.37 mm (0.133 in.) for all paper sizes except letter
•Top margin: 1.7 mm (0.067 in.)
•Bottom margin: 12.7 mm (0.5 in.)
SELECT THE BORDERLESS PRINT FEATURE
For Windows users
1With a photo open, click File > Print.
2Click Properties, Preferences, Options, or Setup.
3Navigate to:
Paper/Finishing tab > select a borderless setting > OK
4Click Print.
For Macintosh users
1With a photo open, choose File > Page Setup.
2From the “Format for” pop‑up menu, choose your printer.
3From the Paper Size pop‑up menu, choose a paper size that has “(Borderless)” in its name.
For example, if you loaded a 4 x 6 photo paper, then choose US 4 x 6 in (Borderless).
4Click OK.
5From the menu bar, choose File > Print.
6From the Printer pop‑up menu, choose your printer.
7From the print options pop‑up menu, choose Quality & Media.
8From the Paper Type pop‑up menu, choose a paper type.
Troubleshooting 151
9From the Print Quality pop‑up menu, choose Best or Photo.
10 Click Print.
Streaks or lines on printed image
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CHECK THE INK LEVELS
Replace low or empty ink cartridges.
SELECT A HIGHER PRINT QUALITY FROM THE PRINTER SOFTWARE
MAKE SURE THE INK CARTRIDGES ARE PROPERLY INSTALLED
ALIGN THE PRINTHEAD
CLEAN OR DEEP CLEAN THE PRINTHEAD NOZZLES
Note: If these solutions do not remove the streaks or lines on the printed image, then contact technical support.
Printed page has ink smears or smudges
Note: The following solutions apply to ink smears or smudges that occur in the printer.
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
SELECT A RECOMMENDED PAPER FOR THE PRINT JOB
For more information, see the section on “Using different paper sizes and types” in the User’s Guide.
SET THE PAGE DRY TIME VALUE TO EXTENDED
Under conditions of high humidity, or for certain paper types and brands, the normal drying time may not allow the
ink to dry completely. For more information, see “Setting the page dry time” in the User’s Guide.
Print speed is slow
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
SELECT A LOWER PRINT QUALITY FROM THE PRINTER SOFTWARE
MANUALLY SELECT A PAPER TYPE THAT MATCHES THE TYPE OF PAPER YOU ARE USING
REMOVE AND REINSTALL THE PRINTER SOFTWARE
Troubleshooting 152
MAXIMIZE COMPUTER PROCESSING SPEED
•Close all applications not in use.
•Minimize the number and size of graphics and images in the document.
ADD MEMORY TO THE COMPUTER
Consider upgrading the RAM.
Computer slows down when printing
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CHECK THE USB CONNECTION BETWEEN THE PRINTER AND COMPUTER
If your computer is connected to the printer through a USB cable, then try using a different USB cable.
REFRESH YOUR NETWORK CONNECTIONS
1If your computer is connected to an Ethernet or wireless network, then turn off the access point (wireless router)
and turn it back on.
2Wait one minute for the printer and computer to reestablish the connection.
CLOSE ALL APPLICATIONS NOT IN USE
Temporarily close unused applications or end processes that are taking too much memory from your computer.
CHECK YOUR COMPUTER PERFORMANCE
You may need to change how your computer manages resources and processes.
For more information on improving computer performance, see the documentation that came with your operating
system.
Copy and scan troubleshooting
•“Copier or scanner does not respond” on page 154
•“Scanner unit does not close” on page 154
•“Poor copy or scanned image quality” on page 154
•“Partial copies or scans of documents or photos” on page 154
•“Scan was not successful” on page 155
•“Scanning takes too long or freezes the computer” on page 155
•“Cannot scan to a computer over a network” on page 155
Troubleshooting 153
Copier or scanner does not respond
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
SET YOUR PRINTER AS THE DEFAULT PRINTER
REMOVE AND REINSTALL THE PRINTER SOFTWARE
Scanner unit does not close
1Lift the scanner unit.
2Remove any obstruction keeping the scanner unit open.
3Lower the scanner unit.
Poor copy or scanned image quality
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CLEAN THE SCANNER GLASS
ADJUST THE SCAN QUALITY
REVIEW THE TIPS FOR COPYING, SCANNING, AND IMPROVING PRINT QUALITY
USE A CLEARER VERSION OF THE ORIGINAL DOCUMENT OR IMAGE
MAKE SURE THE DOCUMENT OR PHOTO IS LOADED FACEDOWN ON THE SCANNER GLASS AND IN THE CORRECT
CORNER
Partial copies or scans of documents or photos
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
MAKE SURE THE DOCUMENT OR PHOTO IS LOADED FACEDOWN ON THE SCANNER GLASS AND IN THE
PLACEMENT CORNER
SELECT A PAPER SIZE THAT MATCHES THE LOADED PAPER
MAKE SURE THE ORIGINAL SIZE SETTING MATCHES THE SIZE OF THE DOCUMENT YOU ARE SCANNING
Troubleshooting 154
Scan was not successful
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CHECK THE USB CONNECTION
1Check the USB cable for any obvious damage. If the cable is damaged, then use a new one.
2Firmly plug the square end of the USB cable into the back of the printer.
3Firmly plug the rectangular end of the USB cable into the USB port of the computer.
The USB port is marked with .
Note: If you continue to have problems, then try another USB port on the computer. You may have connected to a
defective port.
RESTART THE COMPUTER
Scanning takes too long or freezes the computer
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
CLOSE OTHER SOFTWARE PROGRAMS THAT ARE NOT BEING USED
RESTART THE COMPUTER
Cannot scan to a computer over a network
If the "Before you troubleshoot" checklist does not solve the problem, then try one or more of the following:
MAKE SURE THE PRINTER AND THE DESTINATION COMPUTER ARE CONNECTED TO THE SAME NETWORK
MAKE SURE THE PRINTER SOFTWARE IS INSTALLED ON THE DESTINATION COMPUTER
E-mail troubleshooting
•“Cannot send e‑mail” on page 155
Cannot send e‑mail
CHECK YOUR E‑MAIL CONFIGURATION SETTINGS
Make sure you have correctly completed the e‑mail setup and successfully configured an SMTP server.
Troubleshooting 155
CHECK YOUR NETWORK CONNECTION
Make sure the printer is connected to an Ethernet or wireless network. Your network must be connected to the
Internet for the printer to communicate with the SMTP server.
CHECK YOUR PROXY CONFIGURATION
Your proxy server configuration should allow SMTP server connections. For help with your proxy server or SMTP
settings, contact your system support person.
MAKE SURE TO ENTER A VALID RECIPIENT E‑MAIL ADDRESS
MAKE SURE THE RECIPIENT MAILBOX IS NOT FULL
This causes e‑mail to bounce back to your inbox.
Fax troubleshooting
•“Fax troubleshooting checklist” on page 156
•“Cannot send faxes” on page 157
•“Cannot receive faxes” on page 158
•“Cannot run the fax software” on page 159
For detailed descriptions of common terms and tasks, see the following:
•“Setting up the printer to fax” on page 76
•“Faxing FAQ” on page 94
Fax troubleshooting checklist
If you encounter problems sending and receiving faxes, then check the connection first:
1Check for a dial tone on the telephone line by plugging an analog telephone into the wall jack, DSL filter, VoIP device,
or cable modem where you connected the printer. Make sure you plug the telephone into the same port.
If you do not hear a dial tone, then contact your line provider.
2While the printer is connected to the telephone line, check for a dial tone by plugging an analog telephone into the
port of the printer.
If you do not hear a dial tone, then use the checklist below. Listen for a dial tone after checking each item.
If you hear a dial tone but still have problems sending and receiving faxes, then see the other topics in this section.
Connection checklist
•Make sure that the printer and other devices on the line (if applicable) are set up and configured correctly according
to your setup scenario.
•Make sure that the cables are connected to the correct ports.
•Make sure that the cables are securely plugged in.
Check the cable connections for the following hardware, if applicable:
Troubleshooting 156
Power supply Answering machine Cable modem Splitter
Telephone VoIP adapter DSL filter RJ‑11 adapter
•If the printer is connected to a Digital Subscriber Line, then make sure you are using a DSL filter for the printer.
•If the printer is connected to a VoIP adapter or cable modem, then make sure that the printer is plugged into the
first phone port.
•If you are using a splitter, then make sure that you are using a phone splitter. Do not use a line splitter.
Cannot send faxes
If the “Fax troubleshooting checklist” does not solve the problem, then try one or more of the following:
MAKE SURE THAT YOU HAVE REGISTERED YOUR USER INFORMATION IN THE PRINTER
If you did not enter your user information during initial setup, then enter your fax name and fax number. In some
countries, you cannot send a fax without entering your fax name or company name. Some fax machines also block
unknown faxes or faxes without sender information.
DECREASE THE TRANSMISSION SPEED OF THE FAX MODEM
The modem of the printer can transmit data at 33,600 bps. This is the maximum speed at which the printer can send
and receive faxes. It is not necessary, however, to set the modem to its fastest transmission capability. The speed of
the modem of the receiving fax machine must match or be greater than the speed at which you are sending your
fax. Otherwise, your fax will not be received.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Dialing and Sending > OK > Max Send Speed > OK
2Select a sending speed, and then press OK .
ENABLE ERROR CORRECTION
Errors and blurs may appear in the faxed document if there is too much noise on the line. This option enables the
printer to transmit the bad blocks of data again and correct the errors. When a fax has too many errors, the fax may
be rejected by the receiving fax machine.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Dialing and Sending > OK > Error Correction > OK
2Check to see if error correction is set to On.
If it is not set to On, then press the arrow buttons to select On, and then press OK .
Troubleshooting 157
ENABLE AUTOMATIC FAX CONVERSION
If the receiving fax machine does not support color fax, then this option automatically converts the outgoing color
fax to black and white. It also automatically reduces the resolution of the fax to a resolution that the receiving machine
can support.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Dialing and Sending > OK > Auto Fax Convert >
OK
2Check to see if automatic fax conversion is set to On.
If it is not set to On, then press the arrow buttons to select On, and then press OK .
MAKE SURE THAT THE DIAL PREFIX SETTING IS CORRECT
The dialing prefix is the number or series of numbers that you press before you can dial the actual fax number or
telephone number. If the printer is in an office setting or in a private branch exchange, this can be a specific number
that you need to press so you can make a call outside the office.
Make sure that the dial prefix entered in the printer is correct for your network.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Dialing and Sending > OK > Dial Prefix > OK
2Press the arrow buttons to create or modify the prefix.
3If the prefix is not correct, enter the correct prefix, and then press OK .
Cannot receive faxes
If the “Fax troubleshooting checklist” does not solve the problem, then try one or more of the following:
MAKE SURE THAT YOU HAVE CONFIGURED THE CORRECT SETTINGS FOR YOUR SETUP
The fax settings depend on whether the printer is connected to its own fax line or shares the line with other devices.
If the printer is sharing the telephone line with an answering machine, then make sure that the following are set:
•Auto Answer is On.
•The printer picks up on a greater number of rings than the answering machine.
•The printer picks up on the correct distinctive ring (if you subscribe to a distinctive ring service).
If the printer is sharing the telephone line with a telephone subscribed to voice mail, then make sure that the following
are set:
•Auto Answer is Off (if you have only one number on the telephone line).
•The printer picks up on the correct distinctive ring (if you subscribe to a distinctive ring service).
MAKE SURE THAT THE PRINTER IS CONNECTED TO AN ANALOG PORT
The printer is an analog device. If you are using a PBX system, then make sure that the printer is connected to an
analog port on the PBX. You may need a digital line converter that converts digital signals into analog signals.
Troubleshooting 158
MAKE SURE THAT THE PRINTER MEMORY IS NOT FULL
The printer saves an incoming fax to the printer memory before it prints the fax. If the printer runs out of ink or runs
out of paper while receiving the fax, then the printer saves the fax so you can print it later. However, if the printer
memory is full, then the printer may not be able to receive more incoming faxes. An error message appears on the
display when the printer memory is full. Resolve the error to free up space in the printer memory.
MAKE SURE THAT FAX FORWARDING IS DISABLED
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering > OK > Fax Forward > OK
2Press the arrow buttons to scroll to Off, and then press OK .
INCREASE THE RINGER VOLUME
If you set the printer to receive faxes manually (Auto Answer Off), then increase the ringer volume.
MAKE SURE THAT YOU HAVE THE CORRECT MANUAL ANSWER CODE
If you set the printer to receive faxes manually (Auto Answer Off), then you need to press the correct code when a
fax comes in so that the printer can receive it.
1From the printer control panel, navigate to:
> Setup > OK > Fax Setup > OK > Ringing and Answering > OK > Manual Pickup Code > OK
2Copy the manual answer code that appears on the display.
Note: To increase the security, you can change your manual pickup code to a number that only you know. You can
enter up to 7 characters for your code. The valid characters are the digits 0–9 and the characters # and *.
Cannot run the fax software
The printer must be connected to a telephone, DSL, VoIP, or cable service before you can configure the fax settings in
the fax software.
MAKE SURE A FAX DRIVER IS INSTALLED
The fax option is available for use only with the PostScript driver or the Universal Fax Driver. For information on
installing these drivers, see the Software and Documentation CD.
MAKE SURE THE PRINTER IS CONNECTED TO A TELEPHONE LINE
You need to connect the printer to your telephone line (through a standard wall jack, a DSL filter, a VoIP adapter, or
a cable modem) before you can open the fax software and configure the fax settings.
Troubleshooting 159
Fax error messages on the printer control panel
Error Message: What it indicates: Possible solutions:
Remote Fax Error The receiving fax machine cannot
receive the fax. The error on the
receiving end could be due to several
factors.
•Resend the fax. There may have
been a problem with the quality of
the connection.
•Decrease the transmission speed of
your fax modem.
•Register your user information. In
some countries, you cannot send a
fax without registering your fax
name and fax number. Some fax
machines also block faxes without
sender information.
Fax Mode Unsupported The receiving fax machine does not
support color fax or the scan resolution
of the document that you are sending.
•Enable Auto Fax Conversion. The
printer automatically converts color
faxes to black and lowers the scan
resolution of the document.
•Lower the fax quality.
•Reformat the document on
Letter‑size paper.
Unsupported Compression The fax modem of the receiving fax
machine does not support data
compression. Fax modems compress
data to speed up transmission, but the
receiving fax modem needs to have the
same compression code.
•Lower the transmission speed of the
fax modem, and then resend the
fax.
•Enable Auto Fax Conversion.
Unsupported Resolution The receiving fax machine does not
support the scan resolution of the
document that you are sending.
•Lower the fax quality.
•Enable Auto Fax Conversion.
Unrecoverable Fax Error The fax modem encountered critical
errors.
Turn off the printer, turn it back on, and
then resend the fax.
Fax Modem Error The fax modem of the printer may be
busy, or the fax modem may have
encountered problems during
transmission.
Turn off the printer, turn it back on, and
then resend the fax.
Phone Line is connected to
the incorrect jack on the
back of the machine.
The telephone cable is connected to
the wrong port on the back of the
printer.
Connect the phone cable to the port
on the back of the printer.
Digital line detected The printer is connected to a digital
line.
The printer is an analog device and must
be connected to an analog line. To
connect the printer to a digital line, you
must use a digital line converter or a
filter.
For more information, see the ”Setting
up the printer to fax” section.
Troubleshooting 160
Error Message: What it indicates: Possible solutions:
Failed to Connect
Phone Line Error
Phone Line Not Connected
The printer cannot detect a dial tone. See the “Fax troubleshooting checklist.”
Phone Line Busy Your telephone line or the telephone
line of the receiving fax machine is
busy. This happens especially if the
printer is sharing the line with other
devices (telephone, answering
machine).
•Set the printer to redial.
•Increase the time between the
redial attempts.
•Place a test call to the number to
which you want to send a fax to
make sure that it is working
correctly.
•If the telephone line is being used
by another device, then wait until
the other device is finished before
sending the fax.
•Schedule to resend the fax at a later
time.
•Set the printer to scan before
dialing. The scanned document is
saved in the printer memory. The
printer can then retrieve it and
automatically redial the number.
No Answer Auto Answer may have been turned off
on the receiving fax machine.
•Verify the number, and then resend
the fax.
•Set the printer to redial.
Note: Depending on your country
or region, there may be a limit on
the number of redial attempts,
regardless of the redial settings
that you set in your printer.
•Schedule to resend the fax at a later
time.
No Caller ID
Call Stopped
Your printer stopped the call because
the incoming fax has no sender
information. You may have chosen to
block faxes with no Caller ID or faxes
without Caller IDs are not allowed in
your country or region.
Disable Block No‑ID.
To troubleshoot error messages in the fax software, click Help to view the help information for the fax software.
Memory card troubleshooting
•“Memory card troubleshooting checklist” on page 162
•“Nothing happens when a memory card is inserted” on page 162
Troubleshooting 161
Memory card troubleshooting checklist
Before you troubleshoot, use the following checklist to solve most memory card problems:
•Make sure that the memory card you are using can be used in the printer.
•Make sure the memory card is not damaged.
•Make sure memory card contains supported file types.
Nothing happens when a memory card is inserted
If the "Memory card troubleshooting checklist" does not solve the problem, then try the following:
REINSERT THE MEMORY CARD
The memory card may have been inserted too slowly. Remove and then reinsert the memory card quickly.
Network troubleshooting
•“Network troubleshooting checklist” on page 162
•“The Continue button is unavailable” on page 163
•“Computer firewall is blocking communication with the printer” on page 165
•“Communication with printer lost when connected to Virtual Private Network (VPN)” on page 165
Network troubleshooting checklist
Before beginning to troubleshoot the wireless printer, verify the following:
General Networking
Make sure:
•The printer, the computer, and the access point (wireless router) are all plugged in and turned on.
•The wireless network is working properly.
Try accessing other computers on your wireless network. If your network has Internet access, try connecting to the
Internet over a wireless connection.
•The printer driver is installed on the computer from which you are performing a task.
•The correct printer port is selected.
•The IP address, gateway, and network mask are correct for your network.
Print a network setup page from the printer to check the network settings.
•All switches, hubs, and other connecting devices are turned on.
Ethernet Networking
Make sure:
•The Ethernet cable and connectors are not damaged.
Check the connectors at both ends for any obvious damage. If possible, use a new cable.
•The Ethernet cable is firmly plugged in to the printer and to the network hub or wall connection.
Troubleshooting 162
Wireless Networking
Make sure:
•The SSID is correct.
Print a network setup page from the printer to check the network settings.
•Your wireless security settings are correct.
Log in to the access point and check the security settings.
If you are not sure if your security information is correct, run the wireless setup again.
•The printer and the computer are within the range of the wireless network.
•The computer and printer are both connected to the same wireless network.
•The printer is located away from obstacles or electronic devices that could interfere with the wireless signal.
Make sure the printer and wireless access point are not separated by poles, walls, or support columns containing
metal or concrete.
Many devices can interfere with the wireless signal, including baby monitors, motors, cordless phones, security
system cameras, other wireless networks, and some Bluetooth devices.
•The computer is not connected to a VPN.
•Your computer firewall is updated to the most recent version and allows the printer software to communicate over
the network.
The Continue button is unavailable
Try the following solutions in the order they appear until the Continue button becomes active and available:
CHECK IF THE USB CABLE IS SECURELY PLUGGED INTO THE USB PORTS ON BOTH THE COMPUTER AND THE
PRINTER
USB ports are marked with .
MAKE SURE THE PRINTER IS PLUGGED IN AND TURNED ON
Make sure the button is lit. If you have just turned on the printer, then you might need to disconnect the USB
cable and then reconnect it.
MAKE SURE THE USB PORT ON THE COMPUTER IS WORKING
Test the USB port by connecting other devices to it. If you can successfully use other devices from the port, then the
port is working.
Notes:
•Your port may be working fine, but certain conflicts can occur with multiple USB devices. Try disconnecting
one of your other USB devices.
•If the USB port on the computer is not working, then try using the other USB ports on the computer.
Troubleshooting 163
MAKE SURE THE USB CABLE IS WORKING
Try using a different USB cable. If you are using a cable longer than 10 feet, then try using a shorter cable.
Note: USB hubs, extension cables, port replicators, and docking stations may cause connection issues. Try
disconnecting these devices so that your printer is directly connected to your computer.
MAKE SURE YOU ARE USING THE CORRECT CD FOR YOUR PRINTER MODEL
Compare the printer model on the CD to the printer model on the printer. The numbers should either match exactly
or be within the same series.
If unsure, look for an updated version of the printer software on the Lexmark Web site. For more information, see
the printer User's Guide.
RECONNECT THE PRINTER POWER SUPPLY
1Turn off the printer.
Note: Make sure the printer is not in Sleep mode. Press and hold for three seconds to turn off the printer.
2Unplug the power cord from the wall outlet, and then pull out the power cord from the power supply.
3After one minute, reconnect the power cord into the power supply, and then plug the power cord into the wall
outlet.
4Turn on the printer.
RUN THE INSTALLER AGAIN
1Close the installer.
2Remove the CD, and then restart the computer.
3Insert the CD, and then run the installer again.
MAKE SURE YOUR COMPUTER IS ABLE TO ACKNOWLEDGE USB ACTIVITY ON THE USB PORT
Open the Device Manager to check if it has activity whenever a USB device is connected to a USB port:
1Click , or click Start and then click Run.
2In the Start Search or Run box, type devmgmt.msc.
3Press Enter, or click OK.
4Watch the Device Manager window while connecting a USB cable or another device to the USB port. The window
refreshes when the Device Manager recognizes the USB connection.
•If there is activity on the Device Manager but none of the previous solutions worked, then call customer
support.
•If there is no activity on the Device Manager, then there may be a problem with your computer and its USB
support. The computer must recognize the USB connection in order for installation to work.
Troubleshooting 164
Computer firewall is blocking communication with the printer
Firewall settings may have stopped the printer from connecting to your computer.
If a firewall is installed on your computer, then do one of the following:
•Turn off your computer firewall.
•Update your computer firewall to the most recent version, and then allow the printer software to communicate
over the network.
For more information on turning off and updating the firewall, see the help pages of your operating system.
Communication with printer lost when connected to Virtual Private Network
(VPN)
You will lose your connection to a wireless printer on your local network when connected to most Virtual Private
Networks (VPNs).
Most Virtual Private Networks allow computers to communicate with only the VPN and no other network at the same
time. Disconnect from the VPN before installing the driver on the computer or before running the wireless setup on
the computer.
To check if the computer is currently connected to a VPN, open your VPN Client software, and then check your VPN
connections. If you do not have a VPN Client software installed, then check the connections manually using the Windows
VPN Client.
If you would like to have the ability to connect to your local network and to a VPN at the same time, then request the
system support person for the VPN to allow split tunneling. Be aware that some organizations will not allow split
tunneling due to security or technical concerns.
If you want to connect only to a VPN, then the documents you want to print will not be printed until you have ended
the VPN session. If you want to continue printing while connected to a VPN, then connect the printer to the computer
using a USB cable. For more information, see the User’s Guide.
Wireless troubleshooting
•“Resetting the wireless settings to factory defaults” on page 165
•“Cannot print over wireless network” on page 166
•“Wireless print server not installed” on page 169
•“'Communication not available' message appears when printing wirelessly” on page 169
•“Resolving intermittent wireless communications issues” on page 171
Resetting the wireless settings to factory defaults
1From the printer control panel, navigate to:
> Setup > OK > Restore Factory Defaults > OK
2Press the up or down arrow button to scroll to Restore Network Settings, and then press OK .
Troubleshooting 165
3Press the left or right arrow button to scroll to Yes, and then press OK .
The printer restarts automatically after resetting the wireless settings to factory defaults.
4When prompted to set the initial settings of your printer, make your selections using the printer control panel
buttons.
Initial Setup Complete appears on the display.
Cannot print over wireless network
If you encountered problems while installing, or if your printer does not appear in the printers folder or as a printer
option when sending a print job, then try uninstalling and reinstalling the software.
Before you reinstall the software, check the troubleshooting checklist, and then do the following:
TURN THE ACCESS POINT (WIRELESS ROUTER) OFF AND THEN BACK ON
Wait one minute for the printer and computer to reestablish the connection. This can sometimes refresh network
connections and resolve connectivity issues.
DISCONNECT FROM VPN SESSION
When you are connected to another network through a VPN connection, you will not be able to access the printer
over your wireless network. End your VPN session, and then try printing again.
MAKE SURE DEMO MODE IS TURNED OFF
Select printer features are not available when Demo Mode is turned on.
From the printer control panel, navigate to:
> Setup > OK > Demo Mode > OK > Off > OK
CHECK YOUR WEP KEY OR WPA PASSPHRASE
If your access point is using WEP security, then the WEP key should be:
•Exactly 10 or 26 hexadecimal characters. Hexadecimal characters are A–F, a–f, and 0–9.
or
•Exactly 5 or 13 ASCII characters. ASCII characters are letters, numbers, and symbols found on a keyboard. ASCII
characters in a WEP key are case‑sensitive.
If your access point is using WPA or WPA2 security, then the WPA/WPA2 preshared key/passphrase should be:
•Exactly 64 hexadecimal characters. Hexadecimal characters are A–F, a–f, and 0–9.
or
•From 8 to 63 ASCII characters. ASCII characters are letters, numbers, and symbols found on a keyboard. ASCII
characters in a WPA passphrase are case‑sensitive.
Note: If you do not know this information, then see the documentation that came with the access point, or
contact your system support person.
Troubleshooting 166
CHECK IF YOUR ACCESS POINT HAS AN ASSOCIATION/REGISTRATION BUTTON
Wireless broadband boxes in Europe, the Middle East, and Africa such as Livebox, AliceBox, N9UF Box, Freebox, or
Club Internet may require you to press an association/registration button when adding the printer to your wireless
network.
If you are using one of these boxes and need more information, then see the documentation that came with your
box, or contact your internet service provider (ISP).
MOVE YOUR ACCESS POINT AWAY FROM OTHER ELECTRONIC DEVICES
There may be temporary interference from electronic devices such as microwave ovens or other appliances, cordless
phones, baby monitors, and security system cameras. Make sure your access point is not positioned too closely to
these devices.
MOVE THE COMPUTER, PRINTER, OR BOTH CLOSER TO THE ACCESS POINT
The range of your wireless network depends on many factors, including the abilities of your access point and network
adapters. If you are having trouble printing, then try placing the computer and printer no more than 100 feet apart.
CHECK THE WIRELESS SIGNAL QUALITY
Print a network setup page and check the signal quality. If the signal quality is listed as good or excellent, then another
factor is causing the problem.
CHECK YOUR ADVANCED SECURITY SETTINGS
•If you are using MAC (Media Access Control) address filtering to limit access to your wireless network, then you
must add the printer MAC address to the list of addresses allowed to connect to the access point.
•If you set the access point to issue a limited number of IP addresses, then you must change this so that the printer
can be added.
Note: If you do not know how to make these changes, then see the documentation that came with the access
point, or contact the person who set up your wireless network.
MAKE SURE YOUR COMPUTER IS CONNECTED TO YOUR ACCESS POINT
•See if you have access to the Internet by opening your Web browser and accessing any site.
•If there are other computers or resources on your wireless network, then check to see if you can access them
from your computer.
MAKE SURE THAT YOUR COMPUTER AND PRINTER ARE CONNECTED TO THE SAME WIRELESS NETWORK
If the printer is not on the same wireless network as the computer, then you will not be able to print wirelessly. The
SSID of the printer must match the SSID of the computer, if the computer is already connected to the wireless network.
For Windows users
1Obtain the SSID of the network that the computer is connected to.
aType the IP address of your access point into the address field of your Web browser.
If you do not know the IP address of the access point, then do the following:
1Click , or click Start and then click Run.
2In the Start Search or Run dialog, type cmd.
3Press Enter, or click OK.
Troubleshooting 167
4Type ipconfig, and then press Enter. Check the Wireless Network Connection section:
•The “Default Gateway” entry is typically the access point .
•The IP address appears as four sets of numbers separated by periods, such as 192.168.2.134.
bType the user name and password of the access point when prompted.
cClick OK.
dIn the Wireless settings section, look for the SSID.
eWrite down the SSID.
Note: Make sure you copy it exactly, including any capital letters.
2Obtain the SSID of the network that the printer is connected to:
aFrom the printer, print a network setup page.
bIn the Wireless section, look for SSID.
3Compare the SSID of the computer and SSID of the printer.
If the SSIDs are the same, then the computer and the printer are connected to the same wireless network.
If the SSIDs are not the same, then run the utility again to set up the printer on the wireless network used by the
computer.
For Macintosh users with an AirPort base station
In Mac OS X version 10.5 or later
1From the Apple menu, navigate to:
System Preferences > Network > AirPort
or
System Preferences > Network > Wi‑Fi
The SSID of the network that the computer is connected to is displayed in the Network Name menu.
2Write down the SSID.
In Mac OS X version 10.4 or earlier
1From the Finder, navigate to:
Applications > Internet Connect > AirPort
The SSID of the network that the computer is connected to is displayed in the Network menu.
2Write down the SSID.
For Macintosh users with an access point
1Type the IP address of the access point in the address field of your Web browser, and then continue to step 2.
If you do not know the IP address of the access point, then do the following:
aFrom the Apple menu, navigate to:
System Preferences > Network > AirPort
or
System Preferences > Network > Wi‑Fi
bClick Advanced or Configure.
Troubleshooting 168
cClick TCP/IP.
The Router entry is typically the access point.
2Type your user name and password when prompted, and then click OK.
3In the Wireless settings section, look for the SSID.
4Write down the SSID, security type, and the WEP key or WPA/WPA2 preshared key/passphrase (if shown).
Notes:
•Make sure you copy the network information down exactly, including any capital letters.
•Store the SSID and the WEP key or WPA/WPA2 preshared key/passphrase in a safe place for future
reference.
MAKE SURE YOUR OPERATING SYSTEM IS COMPATIBLE WITH WIRELESS PRINTING THROUGH AIRPORT
The printer supports wireless printing only through AirPort base stations for Mac OS X version 10.5 or later.
Wireless print server not installed
You may see a message during installation indicating that the printer does not have a wireless print server installed. If
you are sure the printer is capable of wireless printing, try the following:
CHECK POWER
Make sure the light is on.
“Communication not available” message appears when printing wirelessly
Try one or more of the following:
MAKE SURE YOUR COMPUTER AND PRINTER HAVE VALID IP ADDRESSES FOR THE NETWORK
If you are using a laptop and have power saving settings enabled, then you may see the ”Communication not available”
message on your computer screen when you attempt to print wirelessly. This can occur if the laptop hard drive has
powered down.
If you see this message, then wait a few seconds and then try to print again. The laptop and printer require a few
seconds to power up again and reconnect to the wireless network.
If you see this message again after you have waited long enough for the printer and the laptop to connect to the
network, then there may be a problem with your wireless network.
Make sure that the laptop and printer have both received IP addresses:
For Windows users
1Click , or click Start and then click Run.
2In the Start Search or Run dialog, type cmd.
3Press Enter, or click OK.
4Type ipconfig, and then press Enter.
The IP address appears as four sets of numbers separated by periods, such as 192.168.0.100.
Troubleshooting 169
For Macintosh users
1From the Apple menu, navigate to:
About This Mac > More Info
2From the Contents pane, choose Network.
3If you are connected over a wireless network, then choose AirPort from the Active Services list.
The Router entry is typically the access point.
Locating the printer IP address
•From the printer, print a network setup page.
In the TCP/IP section, look for Address.
•View the printer settings.
From the printer control panel, navigate to:
> Setup > OK > Network Setup > OK > Wireless 802.11 b/g/n > OK > Network Connection Setup > OK >
TCP/IP > OK > IP Address > OK
or
> Setup > OK > Network Setup >
OK
> Ethernet 10/100 > OK > Network Connection Setup >
OK
> TCP/IP >
OK > IP Address > OK
If the printer or the laptop does not have an IP address, or if either has an address of 169.254.x.y (where x and y are
any two numbers between 0 and 255), then do the following:
1Turn off the device that does not have a valid IP address (the laptop, the printer, or both).
2Turn on the device, and then check the IP addresses again.
If the printer or the laptop still does not receive a valid IP address, then there is a problem with your wireless network.
Try the following:
•Make sure your access point (wireless router) is turned on and is working.
•Remove any objects that could be blocking the signal.
•Temporarily turn off any unnecessary wireless devices on your network and pause any network‑intensive
activities, like large file transfers or network games. If the network is too busy, then it is possible that the printer
is not receiving the IP address within the allowed time.
•Make sure your DHCP server, which may also be your wireless router, is working and is configured to assign IP
addresses. If you are not sure how to do this, then refer to the manual that came with your wireless router.
If the printer and computer have valid IP addresses and the network is operating correctly, then continue
troubleshooting.
MAKE SURE THE WIRELESS PORT IS SELECTED
Note: This solution applies to Windows users only.
1Click , or click Start and then click Run.
2In the Start Search or Run dialog, type control printers.
3Press Enter, or click OK.
4Right‑click the printer, and then select Properties or Printer properties from the menu.
Troubleshooting 170
5Click the Ports tab, and then locate the selected port.
The selected port has a check mark beside it in the Port column.
6If the Description column of the selected port indicates that it is a USB port, then scroll through the list and select
the port with Printer Port in the Description column. Check the printer model in the Printer column to make sure
you select the right printer port.
7Click OK, and then try to print again.
MAKE SURE BIDIRECTIONAL COMMUNICATION IS ENABLED
Note: This solution applies to Windows users only.
1Click , or click Start and then click Run.
2In the Start Search or Run dialog, type control printers.
3Press Enter, or click OK.
4Right‑click the printer, and then select Properties or Printer properties from the menu.
5Click the Ports tab.
6Click the box next to Enable bidirectional support if it is not already checked.
7Click Apply > OK, and then try to print again.
Resolving intermittent wireless communications issues
You may notice that your printer works for a short time and then stops working, although apparently nothing has
changed on your wireless network.
Many different issues can interrupt network communications, and sometimes more than one problem exists at the
same time. Try one or more of the following:
DISCONNECT FROM ALL VPNS WHEN ATTEMPTING TO USE THE WIRELESS NETWORK
Most Virtual Private Networks (VPNs) allow computers to communicate with only the VPN and no other network at
the same time. Disconnect from the VPN before installing the driver on the computer or before running the wireless
setup on the computer.
To check if the computer is currently connected to a VPN, open your VPN Client software and check your VPN
connections. If you do not have a VPN Client software installed, then check the connections manually using the
Windows VPN Client.
If you would like to have the ability to connect to your local network and to a VPN at the same time, then request
the system support person for the VPN to allow split tunneling. Be aware that some organizations will not allow split
tunneling due to security or technical concerns.
TURN OFF THE ACCESS POINT (WIRELESS ROUTER) AND TURN IT BACK ON
Wait one minute for the printer and computer to reestablish the connection. This can sometimes refresh network
connections and resolve connectivity issues.
Troubleshooting 171
ELIMINATE NETWORK CONGESTION
If a wireless network is too busy, then the computer and printer may have difficulty communicating with each other.
Some causes of wireless network congestion can include:
•Transferring large files across the network
•Networked games
•Peer‑to‑peer file swapping applications
•Streaming video
•Too many computers on the wireless network at once
ELIMINATE SOURCES OF INTERFERENCE
Common household items can potentially disrupt wireless network communications. Cordless phones (but not
cellular phones), microwave ovens, baby monitors, almost any kitchen appliance, wireless surveillance equipment,
nearby wireless networks, and any appliance containing a motor can disrupt wireless network communications.
Try turning on any potential sources of interference and see if it causes the problem. If it does, then separate your
wireless network from the device.
CHANGE THE CHANNEL THE ACCESS POINT USES
You can sometimes eliminate interference from unknown sources by changing the channel your access point uses
to broadcast. There are three distinct channels on a router. See the documentation that came with your router to
determine which three apply. Other channels are offered as options, but these overlap. If the router is configured
to use the default settings, then change the channel setting to use a different distinct channel. If you are not sure
how to change the channel, then see the documentation that came with your access point.
CONFIGURE THE ACCESS POINT WITH A UNIQUE SSID
Many wireless networks use the SSID that the router was originally configured by the manufacturer to use. Using
the default SSID can cause problems when more than one network is operating in the same area with the same SSID.
The printer or computer may attempt to attach to the wrong network, although it will appear to be trying to connect
to the correct network.
To avoid this type of interference, change the SSID on your access point from the default. If you are not sure how to
change the SSID, then see the documentation that came with your access point.
Note: You must change the SSID on all of the other devices that access your wireless network if you change the
SSID on the access point.
ASSIGN STATIC IP ADDRESSES TO ALL DEVICES IN THE NETWORK
Most wireless networks use a DHCP server (Dynamic Host Configuration Protocol) built in to the wireless router to
assign IP addresses to clients on the wireless network. DHCP addresses are assigned when they are needed, as when
a new device is added to the wireless network or when it is powered on. Wireless devices must send a request to
the router, and receive an IP address in response so they can function on the network. Because the wireless router
performs many other tasks besides assigning addresses, it sometimes does not respond quickly enough with an
address. The requesting device sometimes gives up before it receives an address.
Try assigning static IP addresses to the devices in your network to resolve this issue.
Troubleshooting 172
To assign a static IP address to the printer:
1Complete the wireless setup, allowing the printer to receive a DHCP address from a DHCP server on the network.
2Print a network setup page to see what IP address is currently assigned to the printer.
3Open a Web browser and then type the printer IP address in the address field. Press Enter.
4Click Settings > Network/Ports > TCP/IP > Set static IP address.
5In the Address field, type the IP address you want to assign to the printer, and then click Submit.
Confirm that the IP address is updated by typing the static IP address in the browser address field and checking to
see if the Embedded Web Server reloads. For more information on assigning static IP addresses, see the
documentation that came with your router and operating system.
CHECK FOR KNOWN ISSUES WITH THE ACCESS POINT
Some wireless routers have documented defects that were identified and resolved by the manufacturers. Visit the
company Web site of the router manufacturer. Check for firmware updates and other advice from the manufacturer.
See the documentation that came with your wireless router if you are not sure how to reach the manufacturer Web
site.
CHECK FOR WIRELESS NETWORK ADAPTER UPDATES
If you are having trouble printing from one particular computer, then check the Web site of the manufacturer of the
wireless network adapter card in that computer. It is possible that there is an updated driver available that could
resolve the issue.
CHANGE ALL NETWORK DEVICES TO THE SAME TYPE
While it is possible to successfully mix 802.11b, 802.11g, and 802.11n devices on the same wireless network, the
faster devices will sometimes prevent the slower devices from communicating.
Try turning on only the network devices of the same type and see if network communications improve. If this solves
the problem, then you may want to upgrade your older devices with newer wireless network adapters.
PURCHASE A NEW ROUTER
If your router is several years old, then it may not be fully compatible with the newer wireless devices on your network.
Consider purchasing a newer router that is fully compliant with the 802.11 IEEE specifications.
Ethernet network troubleshooting
Printer does not appear in the list of printers found on the network
CHECK THE ETHERNET CABLE
•Check the Ethernet cable and the Ethernet connectors at both ends for any obvious damage.
•Firmly plug one end of the Ethernet cable into the printer. Firmly plug the other end of the Ethernet cable into
the network hub or wall connection.
•Try using a different cable. Damage to the cable may not be obvious.
Troubleshooting 173
MAKE SURE THE PRINTER POWER IS ON
Make sure the printer is connected to a power source and is turned on.
MAKE SURE THAT THE NETWORK IS OPERATING PROPERLY
•Try to access other computers on the network.
•Make sure all switches, hubs, and other connecting devices are turned on.
MAKE SURE THE PRINTER HAS VALID NETWORK SETTINGS
Print a network setup page from the printer and check the following. See the “Networking” section of the User's
Guide for instructions on how to print a network setup page.
•Verify that the IP address is correct for your network.
•Verify that the gateway is correct.
•Verify that the network mask is the same as the network mask used for other computers and printers on your
network.
Cannot print to the network printer
CHECK THE ETHERNET CABLE
•Check the Ethernet cable and the Ethernet connectors at both ends for any obvious damage.
•Firmly plug one end of the Ethernet cable into the printer. Firmly plug the other end of the Ethernet cable into
the network hub or wall connection.
•Try using a different cable. Damage to the cable may not be obvious.
MAKE SURE THE PRINTER POWER IS ON
Make sure the printer is connected to a power source and is turned on.
MAKE SURE THAT THE NETWORK IS OPERATING PROPERLY
•Try to access other computers on the network.
•Make sure all switches, hubs, and other connecting devices are turned on.
UNINSTALL AND REINSTALL THE SOFTWARE
See the “Reinstalling the printer software” section of the User’s Guide.
Embedded Web Server does not open
Try one or more of the following:
CHECK THE NETWORK CONNECTION
Make sure the printer and computer are turned on and connected to the same network.
Troubleshooting 174
CHECK THE ADDRESS ENTERED IN THE WEB BROWSER
•Depending on the network settings, you may need to type “https://” instead of “http://” before the printer
IP address to access the Embedded Web Server. For more information, contact your system support person.
•Make sure printer IP address is correct.
TEMPORARILY DISABLE WEB PROXY SERVERS
Proxy servers may block or restrict you from accessing certain Web sites including the Embedded Web Server. For
more information, contact your system support person.
Contacting customer support
When you contact customer support, you will need to be able to describe the problem you are experiencing, the message
on the printer display, and the troubleshooting steps you have already taken to find a solution.
You need to know your printer model type and serial number. For more information, see the label on the inside top
front cover of the printer. The serial number is also listed on the menu settings page.
Lexmark has various ways to help you solve your printing problem. Visit the Lexmark Web site at
http://support.lexmark.com, and then select one of the following:
Tech Library You can browse our library of manuals, support documentation, drivers, and other downloads to help you
solve common problems.
E-mail You can send an e-mail to the Lexmark team, describing your problem. A Lexmark team representative will
respond and provide you with information to solve your problem.
Live chat You can chat directly with a Lexmark Service Representative. They can work with you to solve your printer
problem or provide Assisted Service where the Lexmark Service Representative can remotely connect to your
computer through the Internet to troubleshoot problems, install updates, or complete other tasks to help
you successfully use your Lexmark product.
Telephone support is also available. In the U.S. or Canada, call 1-800-539-6275. For other countries or regions, visit the
Lexmark Web site at http://support.lexmark.com.
Troubleshooting 175
Notices
Product information
Product name:
Lexmark Pro4000 Series
Machine type:
4447
Model(s):
Pro4000: 0n0, 0nE; Pro4000c: 000
Edition notice
April 2012
The following paragraph does not apply to any country where such provisions are inconsistent with local law:
LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain
transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in later editions. Improvements or changes in the products or
the programs described may be made at any time.
References in this publication to products, programs, or services do not imply that the manufacturer intends to make
these available in all countries in which it operates. Any reference to a product, program, or service is not intended to
state or imply that only that product, program, or service may be used. Any functionally equivalent product, program,
or service that does not infringe any existing intellectual property right may be used instead. Evaluation and verification
of operation in conjunction with other products, programs, or services, except those expressly designated by the
manufacturer, are the user’s responsibility.
For Lexmark technical support, visit http://support.lexmark.com.
For information on supplies and downloads, visit www.lexmark.com.
If you don't have access to the Internet, you can contact Lexmark by mail:
Lexmark International, Inc.
Bldg 004-2/CSC
740 New Circle Road NW
Lexington, KY 40550
USA
© 2012 Lexmark International, Inc.
All rights reserved.
Notices 176
GOVERNMENT END USERS
The Software Program and any related documentation are "Commercial Items," as that term is defined in 48 C.F.R.
2.101, "Computer Software" and "Commercial Computer Software Documentation," as such terms are used in 48 C.F.R.
12.212 or 48 C.F.R. 227.7202, as applicable. Consistent with 48 C.F.R. 12.212 or 48 C.F.R. 227.7202-1 through 227.7207-4,
as applicable, the Commercial Computer Software and Commercial Software Documentation are licensed to the U.S.
Government end users (a) only as Commerical Items and (b) with only those rights as are granted to all other end users
pursuant to the terms and conditions herein.
Trademarks
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United
States and/or other countries.
Mac and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries.
PCL® is a registered trademark of the Hewlett-Packard Company.
All other trademarks are the property of their respective owners.
AirPrint and the AirPrint logo are trademarks of Apple, Inc.
Federal Communications Commission (FCC) compliance information statement
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
The FCC Class B limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult your point of purchase or service representative for additional suggestions.
Notices 177
The manufacturer is not responsible for radio or television interference caused by using other than recommended
cables or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could
void the user's authority to operate this equipment.
Note: To assure compliance with FCC regulations on electromagnetic interference for a Class B computing device,
use a properly shielded and grounded cable such as Lexmark part number 1021231 for parallel attach or 1021294 for
USB attach. Use of a substitute cable not properly shielded and grounded may result in a violation of FCC
regulations.
Any questions regarding this compliance information statement should be directed to:
Director of Lexmark Technology & Services
Lexmark International, Inc.
740 West New Circle Road
Lexington, KY 40550
(859) 232–3000
Modular component notice
This product may contain the following modular component(s):
Lexmark regulatory type/model LEX-M03-003; FCC ID: US:2G2CN00BM03003; Industry Canada IC:2376A-M03003
Lexmark regulatory type/model LEX-M01-003; FCC ID: IYLM01003; Industry Canada IC:2376A-M01003
Noise emission levels
The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296.
Note: Some modes may not apply to your product.
1-meter average sound pressure, dBA
Printing 52 dBA
Scanning 47 dBA
Copying 52 dBA
Ready inaudible
Values are subject to change. See www.lexmark.com for current values.
Waste from Electrical and Electronic Equipment (WEEE) directive
Notices 178
The WEEE logo signifies specific recycling programs and procedures for electronic products in countries of the European
Union. We encourage the recycling of our products. If you have further questions about recycling options, visit the
Lexmark Web site at www.lexmark.com for your local sales office phone number.
Battery notice
This product contains Perchlorate material. Special handling may apply. For more information, go to
http://www.dtsc.ca.gov/hazardouswaste/perchlorate/.
Static sensitivity notice
This symbol identifies static-sensitive parts. Do not touch in the areas near these symbols without first touching the
metal frame of the printer.
ENERGY STAR
Any Lexmark product bearing the ENERGY STAR emblem on the product or on a start-up screen is certified to comply
with Environmental Protection Agency (EPA) ENERGY STAR requirements as configured when shipped by Lexmark.
Temperature information
Ambient temperature 15°C to 32°C (60°F to 90°F)
Shipping and storage temperature -40°C to 60°C (-40°F to 140°F), 1°C to 60°C (34°F to 140°F)
Power consumption
Product power consumption
The following table documents the power consumption characteristics of the product.
Note: Some modes may not apply to your product.
Notices 179
Mode Description Power consumption (Watts)
Printing The product is generating hard‑copy output from electronic inputs. 37 W
Copy The product is generating hard‑copy output from hard‑copy original
documents.
36 W
Scan The product is scanning hard‑copy documents. 19 W
Ready The product is waiting for a print job. 12 W
Sleep Mode The product is in a high‑level energy‑saving mode. 5.3 W
Off The product is plugged into a wall outlet, but the power switch is turned off. 0.55 W
The power consumption levels listed in the previous table represent time-averaged measurements. Instantaneous
power draws may be substantially higher than the average.
Values are subject to change. See www.lexmark.com for current values.
Sleep Mode
This product is designed with an energy-saving mode called Sleep Mode. The Sleep Mode saves energy by lowering
power consumption during extended periods of inactivity. The Sleep Mode is automatically engaged after this product
is not used for a specified period of time, called the Sleep Mode Timeout.
Factory default Sleep Mode Timeout for this product (in minutes): 30
By using the configuration menus, the Sleep Mode Timeout can be modified between 1 minute and 240 minutes. Setting
the Sleep Mode Timeout to a low value reduces energy consumption, but may increase the response time of the product.
Setting the Sleep Mode Timeout to a high value maintains a fast response, but uses more energy.
Off mode
If this product has an off mode which still consumes a small amount of power, then to completely stop product power
consumption, disconnect the power supply cord from the electrical outlet.
Total energy usage
It is sometimes helpful to calculate the total product energy usage. Since power consumption claims are provided in
power units of Watts, the power consumption should be multiplied by the time the product spends in each mode in
order to calculate energy usage. The total product energy usage is the sum of each mode's energy usage.
Industry Canada compliance statement
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Standard
ICES-003.
Avis de conformité aux normes de l’industrie du Canada
Cet appareil numérique de classe B est conforme aux exigences de la norme canadienne relative aux équipements
pouvant causer des interférences NMB-003.
Notices 180
European Community (EC) directives conformity
This product is in conformity with the protection requirements of EC Council directives 2004/108/EC, 2006/95/EC and
2009/125/EC on the approximation and harmonization of the laws of the Member States relating to electromagnetic
compatibility, safety of electrical equipment designed for use within certain voltage limits and the ecodesign of energy-
related products.
The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA.
The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium
Tower III, 1095 Budapest HUNGARY, A declaration of conformity to the requirements of the Directives is available upon
request from the Authorized Representative.
This product satisfies the Class B limits of EN 55022 and safety requirements of EN 60950.
Regulatory notices for telecommunication terminal equipment
This section contains regulatory information pertaining to products that contain telecommunication terminal
equipment such as facsimile.
Notice to users of the US telephone network: FCC requirements
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the Administrative Council
for Terminal Attachments (ACTA). On the back of this equipment is a label that contains, among other information, a
product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to your telephone
company.
This equipment uses the RJ-11C Universal Service Order Code (USOC) jack.
A plug and jack used to connect this equipment to the premises’ wiring and telephone network must comply with the
applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is
provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See your
setup documentation for more information.
The Ringer Equivalence Number (REN) is used to determine the number of devices that may be connected to a telephone
line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most
but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact your local telephone company. For products approved
after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX.
The digits represented by ## are the REN without a decimal point (for example, 03 is a REN of 0.3). For earlier products,
the REN is shown separately on the label.
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that
temporary discontinuance of service may be required. If advance notice is not practical, the telephone company will
notify the customer as soon as possible. You will also be advised of your right to file a complaint with the FCC.
The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the
operation of this equipment. If this happens, the telephone company will provide advance notice in order for you to
make necessary modifications to maintain uninterrupted service.
If you experience trouble with this equipment, for repair or warranty information, contact Lexmark International, Inc.
at www.lexmark.com or your Lexmark representative. If the equipment is causing harm to the telephone network, the
telephone company may request that you disconnect the equipment until the problem is resolved.
Notices 181
This equipment contains no user serviceable parts. For repair and warranty information, contact Lexmark International,
Inc. See the previous paragraph for contact information.
Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service
commission, or corporation commission for information.
If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this
equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment,
consult your telephone company or a qualified installer.
Telephone companies report that electrical surges, typically lightning transients, are very destructive to customer
terminal equipment connected to AC power sources. This has been identified as a major nationwide problem. It is
recommended that the customer install an appropriate AC surge arrestor in the AC outlet to which this device is
connected. An appropriate AC surge arrestor is defined as one that is suitably rated, and certified by UL (Underwriter's
Laboratories), another NRTL (Nationally Recognized Testing Laboratory), or a recognized safety certification body in
the country/region of use. This is to avoid damage to the equipment caused by local lightning strikes and other electrical
surges.
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic
device, including fax machines, to send any message unless said message clearly contains in a margin at the top or
bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification
of the business or other entity, or other individual sending the message, and the telephone number of the sending
machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or
any other number for which charges exceed local or long-distance transmission charges.)
See your user documentation in order to program this information into your fax machine.
Notice to users of the Canadian telephone network
This product meets the applicable Industry Canada technical specifications. The Ringer Equivalence Number (REN) is
an indication of the maximum number of terminals allowed to be connected to a telephone interface. The terminus of
an interface may consist of any combination of devices, subject only to the requirement that the sum of the RENs of
all the devices does not exceed five. The modem REN is located on the rear of the equipment on the product labeling.
Telephone companies report that electrical surges, typically lightning transients, are very destructive to customer
terminal equipment connected to AC power sources. This has been identified as a major nationwide problem. It is
recommended that the customer install an appropriate AC surge arrestor in the AC outlet to which this device is
connected. An appropriate AC surge arrestor is defined as one that is suitably rated, and certified by UL (Underwriter’s
Laboratories), another NRTL (Nationally Recognized Testing Laboratory), or a recognized safety certification body in
the country/region of use. This is to avoid damage to the equipment caused by local lightning strikes and other electrical
surges.
This equipment uses CA11A telephone jacks.
Avis réservé aux utilisateurs du réseau téléphonique du Canada
Ce produit est conforme aux spécifications techniques d’Industrie Canada. Le numéro REN (ringer equivalence number :
numéro d’équivalence de sonnerie) fournit une indication du nombre maximum de terminaux pouvant être connectés
à l’interface téléphonique. En bout de ligne, le nombre d’appareils qui peuvent être connectés n’est pas directement
limité, mais la somme des REN de ces appareils ne doit pas dépasser cinq. Le numéro REN du modem est indiqué sur
l’étiquette produit située à l’arrière de l’équipement.
Les compagnies de téléphone constatent que les surtensions électriques, en particulier celles dues à la foudre,
entraînent d'importants dégâts sur les terminaux privés connectés à des sources d’alimentation CA. Il s’agit-là d’un
problème majeur d’échelle nationale. En conséquence, il vous est recommandé de brancher un parasurtenseur dans
Notices 182
la prise de courant à laquelle l’équipement est connecté. Utilisez un parasurtenseur répondant à des caractéristiques
nominales satisfaisantes et certifié par le laboratoire d’assureurs UL (Underwriter’s Laboratories), un autre laboratoire
agréé de type NRTL (Nationally Recognized Testing Laboratory) ou un organisme de certification agréé dans votre région
ou pays. Ceci prévient tout endommagement de l’équipement causé par les orages et autres surtensions électriques.
Cet équipement utilise des prises de téléphone CA11A.
Notice to users of the New Zealand telephone network
The following are special conditions for the Facsimile User Instructions. The grant of a telepermit for any item of terminal
equipment indicates only that Telecom has accepted that the item complies with minimum conditions for connection
to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above
all, it provides no assurance that any item will work correctly in all respects with another item of telepermitted
equipment of a different make or model, nor does it imply that any product is compatible with all of Telecom's network
services.
This equipment shall not be set up to make automatic calls to the Telecom's 111 Emergency Service.
This equipment may not provide for the effective hand-over of a call to another device connected to the same line.
This equipment should not be used under any circumstances that may constitute a nuisance to other Telecom
customers.
Some parameters required for compliance with Telecom's telepermit requirements are dependent on the equipment
associated with this device. The associated equipment shall be set to operate within the following limits for compliance
to Telecom's specifications:
•There shall be no more than 10 call attempts to the same number within any 30 minute period for any single manual
call initiation, and
•The equipment shall go on-hook for a period of not less than 30 seconds between the end of one attempt and the
beginning of the next call attempt.
•The equipment shall be set to ensure that automatic calls to different numbers are spaced such that there is not
less than 5 seconds between the end of one call attempt and the beginning of another.
Using this product in Switzerland
This product requires a Swiss billing tone filter (Lexmark part number 14B5109 or 80D1877) to be installed on any line
which receives metering pulses in Switzerland. The filter must be used, as metering pulses are present on all analog
telephone lines in Switzerland.
Utilisation de ce produit en Suisse
Cet appareil nécessite l’utilisation d’un filtre de tonalité de facturation suisse (nº de référence Lexmark : 14B5109 ou
80D1877) devant être installé sur toute ligne recevant des impulsions de comptage en Suisse. Ce filtre doit être utilisé
pour toute installation car ces impulsions existent sur toutes les lignes téléphoniques suisses.
Verwendung dieses Produkts in der Schweiz
Für dieses Produkt muss ein schweizerischer Billing Tone Filter zur Zählzeichenübertragung (Lexmark Teilenummer
14B5109 oder 80D1877) für jede Leitung installiert werden, über die in der Schweiz Zeitsteuertakte übertragen werden.
Die Verwendung des Filters ist obligatorisch, da in allen analogen Telefonleitungen in der Schweiz Zeitsteuertakte
vorhanden sind.
Notices 183
Uso del prodotto in Svizzera
Questo prodotto richiede un filtro toni Billing svizzero, (codice Lexmark 14B5109 o 80D1877) da installare su tutte le
linee che ricevono impulsi remoti in Svizzera. È necessario utilizzare il filtro poiché gli impulsi remoti sono presenti su
tutte le linee analogiche in Svizzera.
Notice to Users in the European Union
Products bearing the CE mark are in conformity with the protection requirements of EC Council directives 2004/108/EC,
2006/95/EC, and 1999/5/EC on the approximation and harmonization of the laws of the Member States relating to
electromagnetic compatibility, safety of electrical equipment designed for use within certain voltage limits and on radio
equipment and telecommunications terminal equipment.
Compliance is indicated by the CE marking.
The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA.
The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium
Tower III, 1095 Budapest HUNGARY, A declaration of conformity to the requirements of the Directives is available upon
request from the Authorized Representative.
Refer to the table at the end of the Notices section for further compliance information.
Regulatory notices for wireless products
This section contains the following regulatory information pertaining to wireless products that contain transmitters,
for example, but not limited to, wireless network cards or proximity card readers.
Exposure to radio frequency radiation
The radiated output power of this device is far below the radio frequency exposure limits of the FCC and other regulatory
agencies. A minimum separation of 20 cm (8 inches) must be maintained between the antenna and any persons for
this device to satisfy the RF exposure requirements of the FCC and other regulatory agencies.
Industry Canada (Canada)
This device complies with Industry Canada specification RSS-210. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This device has been designed to operate only with the antenna provided. Use of any other antenna is strictly prohibited
per regulations of Industry Canada.
To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from
windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to
licensing.
Notices 184
The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF
fields in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health
Canada's Web site www.hc-sc.gc.ca/rpb.
The term "IC:" before the certification/registration number only signifies that the Industry Canada technical
specifications were met.
Industry Canada (Canada)
Cet appareil est conforme à la norme RSS-210 d'Industry Canada. Son fonctionnement est soumis aux deux conditions
suivantes :
(1) cet appareil ne doit pas provoquer d'interférences et (2) il doit accepter toute interférence reçue, y compris celles
risquant d'altérer son fonctionnement.
Cet appareil a été conçu pour fonctionner uniquement avec l'antenne fournie. L'utilisation de toute autre antenne est
strictement interdite par la réglementation d'Industry Canada.
En application des réglementations d'Industry Canada, l'utilisation d'une antenne de gain supérieur est strictement
interdite.
Pour empêcher toute interférence radio au service faisant l'objet d'une licence, cet appareil doit être utilisé à l'intérieur
et loin des fenêtres afin de garantir une protection optimale.
Si le matériel (ou son antenne d'émission) est installé à l'extérieur, il doit faire l'objet d'une licence.
L'installateur de cet équipement radio doit veiller à ce que l'antenne soit implantée et dirigée de manière à n'émettre
aucun champ HF dépassant les limites fixées pour l'ensemble de la population par Santé Canada. Reportez-vous au
Code de sécurité 6 que vous pouvez consulter sur le site Web de Santé Canada www.hc-sc.gc.ca/rpb.
Le terme « IC » précédant le numéro de d'accréditation/inscription signifie simplement que le produit est conforme
aux spécifications techniques d'Industry Canada.
Notice to users in the European Union
This product is in conformity with the protection requirements of EC Council directives 2004/108/EC, 2006/95/EC,
1999/5/EC, and 2009/125/EC on the approximation and harmonization of the laws of the Member States relating to
electromagnetic compatibility, safety of electrical equipment designed for use within certain voltage limits, radio
equipment and telecommunications terminal equipment and on the ecodesign of energy-related products.
Compliance is indicated by the CE marking.
The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA.
The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium
Tower III, 1095 Budapest HUNGARY, A declaration of conformity to the requirements of the Directives is available upon
request from the Authorized Representative.
This product satisfies the Class B limits of EN 55022 and safety requirements of EN 60950.
Products equipped with 2.4GHz Wireless LAN option are in conformity with the protection requirements of EC Council
directives 2004/108/EC, 2006/95/EC, 1999/5/EC, and 2009/125/EC on the approximation and harmonization of the
laws of the Member States relating to electromagnetic compatibility, safety of electrical equipment designed for use
Notices 185
within certain voltage limits and on radio equipment and telecommunications terminal equipment and on the ecodesign
of energy-related products.
Compliance is indicated by the CE marking.
Operation is allowed in all EU and EFTA countries, but is restricted to indoor use only.
The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA.
The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium
Tower III, 1095 Budapest HUNGARY, A declaration of conformity to the requirements of the Directives is available upon
request from the Authorized Representative.
This product may be used in the countries indicated in the table below.
AT BE BG CH CY CZ DE DK EE
EL ES FI FR HR HU IE IS IT
LI LT LU LV MT NL NO PL PT
RO SE SI SK TR UK
Česky Společnost Lexmark International, Inc. tímto prohlašuje, že výrobek tento výrobek je ve shodě se základními
požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk Lexmark International, Inc. erklærer herved, at dette produkt overholder de væsentlige krav og øvrige relevante
krav i direktiv 1999/5/EF.
Deutsch Hiermit erklärt Lexmark International, Inc., dass sich das Gerät dieses Gerät in Übereinstimmung mit den
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG
befindet.
Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Η LEXMARK INTERNATIONAL, INC. ΔΗΛΩΝΕΙ ΟΤΙ ΑΥΤΟ ΤΟ ΠΡΟΪΟΝ
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ
ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
English Hereby, Lexmark International, Inc., declares that this type of equipment is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Español Por medio de la presente, Lexmark International, Inc. declara que este producto cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Eesti Käesolevaga kinnitab Lexmark International, Inc., et seade see toode vastab direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele muudele asjakohastele sätetele.
Suomi Lexmark International, Inc. vakuuttaa täten, että tämä tuote on direktiivin 1999/5/EY oleellisten vaatimusten
ja muiden sitä koskevien direktiivin ehtojen mukainen.
Français Par la présente, Lexmark International, Inc. déclare que l'appareil ce produit est conforme aux exigences
fondamentales et autres dispositions pertinentes de la directive 1999/5/CE.
Magyar Alulírott, Lexmark International, Inc. nyilatkozom, hogy a termék megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Íslenska Hér með lýsir Lexmark International, Inc. yfir því að þessi vara er í samræmi við grunnkröfur og aðrar
kröfur, sem gerðar eru í tilskipun 1999/5/EC.
Notices 186
Italiano Con la presente Lexmark International, Inc. dichiara che questo questo prodotto è conforme ai requisiti
essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski Ar šo Lexmark International, Inc. deklarē, ka šis izstrādājums atbilst Direktīvas 1999/5/EK būtiskajām
prasībām un citiem ar to saistītajiem noteikumiem.
LietuviųŠiuo Lexmark International, Inc. deklaruoja, kad šis produktas atitinka esminius reikalavimus ir kitas
1999/5/EB direktyvos nuostatas.
Malti Bil-preżenti, Lexmark International, Inc., jiddikjara li dan il-prodott huwa konformi mal-ħtiġijiet
essenzjali u ma dispożizzjonijiet oħrajn relevanti li jinsabu fid-Direttiva 1999/5/KE.
Nederlands Hierbij verklaart Lexmark International, Inc. dat het toestel dit product in overeenstemming is met de essentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Norsk Lexmark International, Inc. erklærer herved at dette produktet er i samsvar med de grunnleggende krav og
øvrige relevante krav i direktiv 1999/5/EF.
Polski Niniejszym Lexmark International, Inc. oświadcza, że niniejszy produkt jest zgodny z zasadniczymi
wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
Português A Lexmark International Inc. declara que este este produto está conforme com os requisitos essenciais e outras
disposições da Diretiva 1999/5/CE.
Slovensky Lexmark International, Inc. týmto vyhlasuje, že tento produkt spĺňa základné požiadavky a všetky
príslušné ustanovenia smernice 1999/5/ES.
Slovensko Lexmark International, Inc. izjavlja, da je ta izdelek v skladu z bistvenimi zahtevami in ostalimi
relevantnimi določili direktive 1999/5/ES.
Svenska Härmed intygar Lexmark International, Inc. att denna produkt står i överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Statement of Limited Warranty
Lexmark Pro4000 Series
Lexmark International, Inc., Lexington, KY
This limited warranty applies to the United States and Canada. For customers outside the U.S., refer to the country-
specific warranty information that came with your product.
This limited warranty applies to this product only if it was originally purchased for your use, and not for resale, from
Lexmark or a Lexmark Remarketer, referred to in this statement as “Remarketer.”
Limited warranty
Lexmark warrants that this product:
—Is manufactured from new parts, or new and serviceable used parts, which perform like new parts
—Is, during normal use, free from defects in material and workmanship
If this product does not function as warranted during the warranty period, contact a Remarketer or Lexmark for repair
or replacement (at Lexmark's option).
If this product is a feature or option, this statement applies only when that feature or option is used with the product
for which it was intended. To obtain warranty service, you may be required to present the feature or option with the
product.
Notices 187
If you transfer this product to another user, warranty service under the terms of this statement is available to that user
for the remainder of the warranty period. You should transfer proof of original purchase and this statement to that
user.
Limited warranty service
The warranty period starts on the date of original purchase as shown on the purchase receipt and ends 12 months later
provided that the warranty period for any supplies and for any maintenance items included with the printer shall end
earlier if it, or its original contents, are substantially used up, depleted, or consumed.
To obtain warranty service you may be required to present proof of original purchase. You may be required to deliver
your product to the Remarketer or Lexmark, or ship it prepaid and suitably packaged to a Lexmark designated location.
You are responsible for loss of, or damage to, a product in transit to the Remarketer or the Lexmark designated location.
When warranty service involves the exchange of a product or part, the item replaced becomes the property of the
Remarketer or Lexmark. The replacement may be a new or repaired item.
The replacement item assumes the remaining warranty period of the original product.
Replacement is not available to you if the product you present for exchange is defaced, altered, in need of a repair not
included in warranty service, damaged beyond repair, or if the product is not free of all legal obligations, restrictions,
liens, and encumbrances.
Before you present this product for warranty service, remove all print cartridges, programs, data, and removable storage
media (unless directed otherwise by Lexmark).
For further explanation of your warranty alternatives and the nearest Lexmark authorized servicer in your area contact
Lexmark on the World Wide Web at http://support.lexmark.com.
Remote technical support is provided for this product throughout its warranty period. For products no longer covered
by a Lexmark warranty, technical support may not be available or only be available for a fee.
Extent of limited warranty
Lexmark does not warrant uninterrupted or error-free operation of any product or the durability or longevity of prints
produced by any product.
Warranty service does not include repair of failures caused by:
—Modification or unauthorized attachments
—Accidents, misuse, abuse or use inconsistent with Lexmark user’s guides, manuals, instructions or guidance
—Unsuitable physical or operating environment
—Maintenance by anyone other than Lexmark or a Lexmark authorized servicer
—Operation of a product beyond the limit of its duty cycle
—Use of printing media outside of Lexmark specifications
—Refurbishment, repair, refilling or remanufacture by a third party of products, supplies or parts
—Products, supplies, parts, materials (such as toners and inks), software, or interfaces not furnished by Lexmark
TO THE EXTENT PERMITTED BY APPLICABLE LAW, NEITHER LEXMARK NOR ITS THIRD PARTY SUPPLIERS OR
REMARKETERS MAKE ANY OTHER WARRANTY OR CONDITION OF ANY KIND, WHETHER EXPRESS OR IMPLIED, WITH
RESPECT TO THIS PRODUCT, AND SPECIFICALLY DISCLAIM THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND SATISFACTORY QUALITY. ANY WARRANTIES THAT
MAY NOT BE DISCLAIMED UNDER APPLICABLE LAW ARE LIMITED IN DURATION TO THE WARRANTY PERIOD. NO
Notices 188
WARRANTIES, EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD. ALL INFORMATION, SPECIFICATIONS, PRICES,
AND SERVICES ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE.
Limitation of liability
Your sole remedy under this limited warranty is set forth in this document. For any claim concerning performance or
nonperformance of Lexmark or a Remarketer for this product under this limited warranty, you may recover actual
damages up to the limit set forth in the following paragraph.
Lexmark's liability for actual damages from any cause whatsoever will be limited to the amount you paid for the product
that caused the damages. This limitation of liability will not apply to claims by you for bodily injury or damage to real
property or tangible personal property for which Lexmark is legally liable. IN NO EVENT WILL LEXMARK BE LIABLE FOR
ANY LOST PROFITS, LOST SAVINGS, INCIDENTAL DAMAGE, OR OTHER ECONOMIC OR CONSEQUENTIAL DAMAGES.
This is true even if you advise Lexmark or a Remarketer of the possibility of such damages. Lexmark is not liable for any
claim by you based on a third party claim.
This limitation of remedies also applies to claims against any Suppliers and Remarketers of Lexmark. Lexmark's and its
Suppliers' and Remarketers' limitations of remedies are not cumulative. Such Suppliers and Remarketers are intended
beneficiaries of this limitation.
Additional rights
Some states do not allow limitations on how long an implied warranty lasts, or do not allow the exclusion or limitation
of incidental or consequential damages, so the limitations or exclusions contained above may not apply to you.
This limited warranty gives you specific legal rights. You may also have other rights that vary from state to state.
Notices 189
Index
Numerics
2‑sided, fax
setting 87
802.1X authentication 110
A
ad hoc network 122
ad hoc wireless network
adding a printer 108
adding
network folder shortcut 65
additional computers
installing wireless printer 105
Additional Solutions
customize printer settings
using 131
Address Book
setting up 89, 90
Address Book Setup
customize printer settings
using 131
Address Book, fax
setting 87
ADF input tray
location 11
ADF press plate
cleaning 135
ADF scanner glass
cleaning 135
adjusting
scan color 71
adjusting dialing and ringer
volume 96
adjusting speaker volume 96
advanced wireless setup 103
AliceBox 106
aligning the printhead 133
Alignment Problem 142
answering machine
best settings for fax 97
setting up 76
appliances
wireless network 124
assigning IP address 129
authentication
802.1X 110
Auto Answer
when to turn on 95
Automatic Document Feeder (ADF)
clearing a paper jam in 149
loading documents 35
location 10
paper capacity 35
supported paper sizes 35
automatic fax conversion
setting 87
B
background, removing 62
backing material
cleaning 135
bidirectional communication
enabling 169
bin extender
location 11
black and white scanning 71
blocking faxes 99
broadcast fax, sending
immediately 91
buttons, printer control panel
Address Book 17
arrow buttons 16
Back 16
Black 17
Cancel 17
Color 17
Dial Tone 17
Home 16
keypad 16
Pause 17
Power 16
Redial 17
Select 16
Start 17
C
cable
installation 121
USB 121
Caller ID 86
Caller ID pattern, fax
setting 87
camera
connecting 49
canceling
copy job 63
e‑mail 75
print job 56
scan job 71
Cannot Collate Job 142
cannot delete documents from
print queue 141
cannot open Embedded Web
Server 174
cannot print over wireless
network 166
cannot print through USB 141
cannot print to network
printer 174
cannot receive faxes 158
cannot run fax software 159
cannot scan to computer over a
network 155
cannot send e‑mail 155
cannot send faxes 157
card reader light
location 11
cartridges, ink
ordering 13
using genuine Lexmark 13
certificate requests 110
Change [Paper Source] to [Size]
[Type] Paper 142
Change [Paper Source] to [Size]
Paper 142
changing default printing mode 54
changing page order 42
changing print order 42
changing Sleep timeout 18
changing wireless settings after
installation (Macintosh) 107
changing wireless settings after
installation (Windows) 107
checking
ink levels 133
checking an unresponsive
printer 137
checking the dial tone 96
checklist
before you troubleshoot 137
fax troubleshooting 156
memory card troubleshooting 162
choosing a splitter, faxing 94
cleaning exterior of the printer 134
Index 190
cleaning printhead nozzles 134
Close Printer 142
Club Internet 106
coated paper
loading 32
collating copies 60
color scanning 71
Communication not available
message 169
computer slows down when
printing 153
configuring
fax settings 87, 88
IP address 107
configuring e‑mail settings 72
configuring security settings 109
configuring Wi‑Fi Protected Setup
PBC, Push Button Configuration
method 109
PIN, Personal Identification
Number method 109
confirmation page, fax 98
connection
configurations 126
conserving energy 18
conserving energy, ink, and paper 7
conserving paper 18
contact list
setting up 89, 90
contact list, e‑mail
creating 73
setting up 73
contacting customer support 175
Continue button unavailable 163
copier or scanner does not
respond 154
copies
making 58
copy and scan troubleshooting
cannot scan to computer over a
network 155
copier or scanner does not
respond 154
partial document or photo
scans 154
poor scanned image quality 154
scan not successful 155
scanning takes too long or freezes
the computer 155
copy job
canceling 63
copy quality, adjusting 60
Copy Settings
customize printer settings
using 131
copy troubleshooting
scanner unit does not close 154
copying 58
adding an overlay message 61
adjusting quality 60
collating copies 60
enlarging an image 59
ID cards 59
making a copy lighter or darker 60
multiple page images on one
sheet 61
on both sides of the paper 62
Pages per Side 61
placing separator sheets between
copies 61
reducing an image 59
removing background 62
tips 58
customer support 137
customer support label
location 11
custom‑size paper
printing on 46
D
date and time
setting 86
default printer, setting 54
default printing mode
changing 54
defaults
restoring factory defaults 18
Device Management
customize printer settings
using 131
dial method, fax
setting 87
dial tone
checking 96
dial tone volume
adjusting 96
dialing prefix 95
Digital Subscriber Line (DSL)
fax setup 79
digital telephone service
fax setup 81
distinctive ring 95
documents
adding a network folder
shortcut 65
faxing using the computer 92
faxing using the control panel 91
loading into the Automatic
Document Feeder (ADF) 35
loading on scanner glass 34
printing 40
scanning for editing 68
scanning using the printer control
panel 65
scanning using the touch
screen 64
downloading PCL drivers 27
downloading PS drivers 27
downloading Universal Print
Driver 27
drivers
downloading 27
DSL filter 79
duplex
copying, automatic 62
copying, manual 62
faxing 99
printing, automatic 50
duplex printing dry time
setting 38, 52
duplex unit
location 12
Duplex Unit Missing 143
E
EAP 109
EAP‑MD5 110
EAP‑TLS 110
EAP‑TTLS 110
Embedded Web Server
accessing 130
problem accessing 174
emission
notices 177, 178, 180, 181, 184,
185
energy
conserving 7
enlarging an image 59
entering
fax user information 86
envelopes
loading 32, 44
printing 44
Index 191
error correction, fax
setting 87
error using memory card 162
Ethernet 126
network indicator light 105
Ethernet network
information needed for setting up
Ethernet printing 110
Ethernet port
location 12
Ethernet setup
information needed for 110
exit bin
location 11
EXT port
location 12
extending the duplex printing dry
time 52
extending the two‑sided printing
dry time 38
exterior of the printer
cleaning 134
e‑mail
canceling 75
E‑mail Alert Setup
customize printer settings
using 131
e‑mail function
setting up 72
e‑mail troubleshooting
cannot send e‑mail 155
E‑mail/FTP Settings
customize printer settings
using 131
e‑mailing
Address Book 73
configuring e‑mail settings 72
scanned documents 69
setting up e‑mail function 72
tips 74
F
factory default settings
restoring 18
failed faxes
retrieving 100
fax
confirmation page 98
printer memory 100
transmission report 98
fax activity report 98
fax blocking
setting 87
fax error messages
Digital Line Detected 160
Failed To Connect 161
Fax Mode Unsupported 160
Fax Modem Error 160
No Answer 161
No Caller ID 161
Phone Line Busy 161
Phone Line Error 161
Phone Line is connected to the
incorrect jack on the back of the
machine 160
Phone Line Not Connected 161
Remote Fax Error 160
Unrecoverable Fax Error 160
Unsupported Compression 160
Unsupported Resolution 160
fax footer
setting 87
fax forwarding 99
fax header
setting 87
fax header and footer
setting 86
fax number 94
fax quality
setting 97
fax resolution
setting 97
fax sending speed
setting 87
Fax Settings
customize printer settings
using 131
fax settings
configuring 87, 88
for answering machine 97
for voice mail 97
fax setup
country‑ or region‑specific 83
digital telephone service 81
DSL connection 79
standard telephone line
connection 76
VoIP 80
Fax Setup Wizard 88
fax troubleshooting
cannot receive faxes 158
cannot run fax software 159
cannot send faxes 157
error messages, printer control
panel 160
fax troubleshooting checklist 156
faxing
Address Book 89, 90
blocking 99
calling card, using 98
dial prefix 95
distinctive ring 95
duplex 99
fax history 98
pick up on 95
receiving automatically 93
receiving manually 93
rings 95
scheduling 97
sending a broadcast fax
immediately 91
sending using the control
panel 91
setup 94
tips, receiving 92
tips, sending 91
two‑sided 99
using the computer 92
using the control panel 91
faxing tips
receiving faxes automatically 93
FCC notices 177, 181, 184
file types
supported 47
finding
information 8
MAC address 127
print queue 53
publications 8
Web site 8
firewall on computer 165
flash drive
inserting 47
printing documents from 44
scanning to 66
forwarding faxes 99
France
special wireless setup
instructions 106
Freebox 106
frequently asked questions
USB cable 121
Index 192
G
General Settings
customize printer settings
using 131
glossy paper
loading 32
greeting cards
loading 33
Group Dial
setting up 89, 90
H
header bar 130
home page
areas 130
understanding 130
I
ID cards
copying 59
Import/Export
customize printer settings
using 131
improving scan quality 71
incorrect language appears on
display 138
index cards
loading 33
information
finding 8
information needed for setting up
printer on Ethernet network 110
information pane 130
information you will need during
wireless setup 102
infrastructure network 122
ink
conserving 7
ink cartridge access door
location 11
Ink Cartridge Access Door
Open 143
Ink Cartridge Error 144
Ink Cartridge Missing 144
ink cartridges
ordering 13
replacing 14
using genuine Lexmark 13
ink levels
checking 133
Ink Low 145
inserting a memory card or flash
drive 47
installation
cable 121
installing
network printer 129
installing optional software 26
installing printer
on wired network
(Macintosh) 111
on wired network (Windows) 111
on wireless network
(Macintosh) 104
on wireless network
(Windows) 104
installing printer on wired network
(Macintosh) 111
installing printer on wired network
(Windows) 111
installing printer software 27
installing wireless printer
additional computers 105
interference
wireless network 124
Intervention Management
customize printer settings
using 131
IP address 128
configuring 107
IP address of computer
finding 128
IP address of printer
finding 128
IP address, assigning 129
iron-on transfers
loading 33
J
jams and misfeeds troubleshooting
paper jam in the ADF 149
paper jam in the duplex unit 148
paper jam in the printer 148
paper or specialty media 150
junk faxes
blocking 99
K
key index 129
L
labels
loading 33
printing 45
language
changing 138
LEAP 109, 110
LexPrint 56
line filter 79
LINE port
location 12
linking trays 39
LiveBox 106
Load [Paper Source] with [Size]
[Type] Paper 145
Load [Paper Source] with [Size]
Paper 145
loading
documents into the Automatic
Document Feeder (ADF) 35
documents on scanner glass 34
envelopes 44
paper tray 29
various paper types 31
locating
SSID 118
WEP key 117
WPA/WPA2 preshared
key/passphrase 117
M
MAC address 126
finding 127
MAC address filtering 126
Macintosh
installing printer on wireless
network 104
USB 114
wireless 114
Macintosh printer software
using 25
Manage Profiles
customize printer settings
using 131
Manage Shortcuts
customize printer settings
using 131
memory card
inserting 47
printing documents from 44
scanning to 66
Index 193
supported types 47
memory card cannot be
inserted 162
memory card slot
location 11
memory card troubleshooting
checklist 162
nothing happens when memory
card is inserted 162
Memory Device Access Error 145
minimum system requirements 23
moving the printer 135
MSCHAPv2 110
multiple pages per sheet,
printing 43
multiple WEP keys 129
N
N9UF Box 106
navigation pane 130
Network [x] Software Error 145
network connection
with USB 126
network indicator light 105
network overview 118
network printer
installing 129
network security 118
network setup page
printing 102
network troubleshooting
cannot print to network
printer 174
printer to be configured does not
appear in list of printers found
on network 173
Network/Ports
customize printer settings
using 131
networking
sharing the printer with a
Macintosh computer 116
sharing the printer with a
Windows computer 116
noise emission levels 178
nothing happens when memory
card is inserted 162
notices 177, 178, 179, 180, 181,
182, 183, 184, 185, 186
O
on‑hook faxing 98
ordering paper and other
supplies 15
P
page does not print 139
page order
changing 42
Pages per Side copies 61
paper
conserving 7
loading 29, 31
paper and other supplies
ordering 15
paper default settings
saving 34
paper jam in the ADF 149
paper jam in the duplex unit 148
paper jam in the printer 148
paper or specialty media
misfeeds 150
Paper Setup
customize printer settings
using 131
paper size and type
setting 37
paper tray
location 11
Paper Tray [x] Detected 145
Paper Tray [x] Removed 146
paper, recommended brands
types and sizes 36
partial document or photo
scans 154
parts
diagram 10
password 118
pausing
print job 55
PDF
creating from scan 70
PEAP 109, 110
Personal Identification Number
method
using 109
phone book
setting up 89, 90
phone plug 83
phone splitter 80
photo cards
loading 33
photo paper
loading 32
photos
making borderless copies 59
printing from a memory card or
flash drive 49
PictBridge and USB port
location 11
PictBridge-enabled camera,
connecting 49
PIN
setting for security 19
poor quality at the edges of
page 151
poor scanned image quality 154
postcards
loading 33
power supply port
location 11
Print dialog
launching 25
print job
canceling 56
pausing 55
resuming 55
print order
changing 42
print queue
creating 53
finding 53
Print Settings
customize printer settings
using 131
print speed is slow 152
print troubleshooting
cannot delete documents from
print queue 141
computer slows down when
printing 153
poor quality at the edges of
page 151
printed page has ink smears or
smudges 152
slow print speed 152
streaks or lines on printed
image 152
printed page has ink smears or
smudges 152
printer
moving 135
Index 194
selecting a location 12
sharing 116
sharing in Windows 116
printer control panel
buttons 16
display 16
Ethernet indicator 16
layout 16
location 11
using 16
Wi‑Fi indicator 17
printer does not respond 140
printer memory
fax 100
Printer Memory Full 146
printer messages
Alignment Problem 142
Cannot Collate Job 142
Change [Paper Source] to [Size]
[Type] Paper 142
Change [Paper Source] to [Size]
Paper 142
Close Printer 142
Duplex Unit Missing 143
Ink Cartridge Access Door
Open 143
Ink Cartridge Error 144
Ink Cartridge Missing 144
Ink Low 145
Load [Paper Source] with [Size]
[Type] Paper 145
Load [Paper Source] with [Size]
Paper 145
Memory Device Access Error 145
Paper Tray [x] Detected 145
Paper Tray [x] Removed 146
Printer Memory Full 146
Printhead Cannot Move 146
Printhead Error 146
Printhead Warning 146
Replace Ink Cartridge 146
Scanned Document Too Long 146
Scanner ADF Cover Open 147
Scanner Disabled 147
Short Paper 147
Unrecoverable Scan Error 147
Unsupported Cartridge 144
USB Device Not Supported 147
USB Hub Not Supported 147
printer printing blank pages 140
printer problems, basic
solutions 137
Printer Settings 88
printer settings, customizing
Additional Solutions 131
Address Book Setup 131
Copy Settings 131
Device Management 131
E‑mail Alert Setup 131
E‑mail/FTP Settings 131
Fax Settings 131
General Settings 131
Import/Export 131
Intervention Management 131
Manage Profiles 131
Manage Shortcuts 131
Network/Ports 131
Paper Setup 131
Print Settings 131
Scan‑to‑Network Folder
Setup 131
Security 131
printer software
installing 27
uninstalling 27
printer status
determining 105
printer to be configured does not
appear in list of printers found on
network 173
printer, setting as default 54
printers
supported 57
printhead
aligning 133
Printhead Cannot Move 146
Printhead Error 146
printhead nozzles
cleaning 134
Printhead Warning 146
printing
advanced color 41
collate 41
custom‑size paper 46
documents 40
documents from a memory card
or flash drive 44
envelopes 44
first page first 42
from a PictBridge‑enabled
camera 49
labels 45
multiple pages on one sheet 43
network setup page 102
on both sides of the paper 50
photos from a memory card or
flash drive 49
tips 40
two‑sided 50
printing a confirmation page 98
printing a transmission report 98
printing using advanced color
options 41
protocol 128
publications
finding 8
Push Button Configuration method
using 109
R
received history report 98
receiving faxes
Auto Answer setting 93
automatically 93
manually 93
tips 93
recommended paper brands
types and sizes 36
recovering the security PIN 138
recycling 7
Lexmark products 15
WEEE statement 178
redial attempts, fax
setting 87
redial time, fax
setting 87
reducing an image 59
registering
fax user information 86
Transmit Terminal Identification
(TTI) 86
Replace Ink Cartridge 146
replacing ink cartridges 14
reports
fax history 98
reports, fax
setting 87
resetting
wireless settings to factory
defaults 165
resetting to factory defaults 18
resuming
print job 55
retrieving failed faxes 100
ringer volume
adjusting 96
Index 195
RJ‑11 adapter 83
S
safety information 6
saving energy 18
saving paper 18
saving paper default settings 34
scan
improving quality 71
PIN 71
scan job
canceling 71
scan was not successful 155
Scanned Document Too Long 146
Scanner ADF Cover Open 147
Scanner Disabled 147
scanner glass
cleaning 135
location 11
scanner unit does not close 154
scanning
creating a PDF from scan 70
documents for editing 68
documents for e‑mailing 69
in black and white 71
tips 64
to a flash drive 66
to a local computer 64
to a memory card 66
to a network 65
to a network computer 65
to a network folder 65
using the printer control panel 65
using the touch screen 64
scanning photos
using the Macintosh printer
software 67
using the printer control panel 68
using the Windows printer
software 67
scanning takes too long or freezes
the computer 155
Scan‑to‑Network Folder Setup
customize printer settings
using 131
scheduled fax
sending 97
Security
customize printer settings
using 131
security
configuring 109
wireless network 101
security information
wireless network 118
security key 118
security PIN
recovering 138
setting 19
selecting the wireless port 169
sender information
registering 86
sending a scheduled fax 97
sending faxes, tips 91
sent history report 98
setting
Auto Answer 95
Caller ID 86
fax header and footer 86
fax quality 97
maximum sending speed 87
sender information 86
Transmit Terminal Identification
(TTI) 86
setting the duplex printing dry
time 52
setting the paper size and type 37
setting the two‑sided printing dry
time 38
setting up fax
country‑ or region‑specific 83
digital telephone service 81
DSL connection 79
standard telephone line
connection 76
VoIP connection 80
setting up printer
faxing 94
on wired network
(Macintosh) 111
on wired network (Windows) 111
on wireless network
(Macintosh) 104
on wireless network
(Windows) 104
setup troubleshooting
cannot print through USB 141
incorrect language appears on
display 138
page does not print 139
printer does not respond 140
printer printing blank pages 140
recovering security PIN 138
software did not install 138
shared printing 116
sharing printer in Windows 116
Short Paper 147
shortcut
creating 21
deleting 21
modifying 21
shortcuts 20, 21
using shortcuts on printer 22
shortcuts page
launching 21
signal strength
finding 123
Sleep timeout
changing 18
software did not install 138
software updates
checking 26
software, optional
finding, installing 26
speaker volume
adjusting 96
Speed Dial
setting up 89
splitter, choosing 94
SSID
finding 125
locating 118
wireless network 118
Standard Network Software
Error 147
streaks or lines on printed
image 152
supported memory cards and file
types 47
supported operating systems 23
supported printers 57
switching from Ethernet
to USB, using Windows 112
to wireless, using Windows 112
switching from USB
to Ethernet, using Windows 112
to wireless, using Mac OS X 114
to wireless, using Windows 112
switching from wireless
to Ethernet, using Windows 112
to USB, using Mac OS X 114
to USB, using Windows 112
T
TCP/IP 128
Index 196
telecommunication
notices 181, 182, 183, 184
tips for
copying 58
e‑mailing 74
printing 40
receiving faxes 92
scanning 64
sending faxes 91
transmission report, fax 98
transmit key
WEP 109
transparencies
loading 33
tray
loading paper 29
trays
linking 39
troubleshooting
cannot open Embedded Web
Server 174
checking an unresponsive
printer 137
contacting customer
support 137, 175
Continue button is
unavailable 163
fax checklist 156
solving basic printer
problems 137
wireless network 162
troubleshooting, copy
scanner unit does not close 154
troubleshooting, copy and scan
cannot scan to computer over a
network 155
copier or scanner does not
respond 154
partial document or photo
scans 154
poor scanned image quality 154
scan not successful 155
scanning takes too long or freezes
the computer 155
troubleshooting, e‑mail
cannot send e‑mail 155
troubleshooting, fax
cannot receive faxes 158
cannot run fax software 159
cannot send faxes 157
error messages, printer control
panel 160
troubleshooting, jams and
misfeeds
paper jam in the ADF 149
paper jam in the duplex unit 148
paper jam in the printer 148
paper or specialty media 150
troubleshooting, memory card
checklist 162
nothing happens when memory
card is inserted 162
troubleshooting, network
cannot print to network
printer 174
printer to be configured does not
appear in list of printers found
on network 173
troubleshooting, print
cannot delete documents from
print queue 141
computer slows down when
printing 153
ink smears or smudges 152
poor quality at the edges of
page 151
slow print speed 152
streaks or lines on printed
image 152
troubleshooting, setup
cannot print through USB 141
incorrect language appears on
display 138
page does not print 139
printer does not respond 140
printer printing blank pages 140
recovering security PIN 138
software did not install 138
troubleshooting, wireless
cannot print over wireless
network 166
changing wireless settings after
installation (Macintosh) 107
changing wireless settings after
installation (Windows) 107
resolving communication
problems 171
two‑sided
copying, automatic 62
copying, manual 62
two‑sided printing
supported paper sizes and paper
types 50
two‑sided printing dry time
setting 38, 52
TX report, fax 98
U
UK
special wireless setup
instructions 106
uninstalling printer software 27
Universal Print Driver
downloading 27
Unrecoverable Scan Error 147
Unsupported Cartridge 144
updating printer software 26
USB 126
cable 121
Macintosh 114
USB cable 121
definition 121
USB connection
with network connection 126
USB Device Not Supported 147
USB Hub Not Supported 147
USB port
location 12
user information, fax
setting 87
V
Virtual Private Network 165
voice mail
setting up 76
voice mail, fax settings 97
Voice over Internet Protocol (VoIP)
fax setup 80
VoIP adapter 80
volume, adjusting
ringer and dial tone 96
speaker 96
VPN
lost connection to printer 165
printing locally 165
W
Web Links
accessing 25
Web site
finding 8
WEP 101, 109
WEP key
key index 129
Index 197
locating 117
WEP transmit key 109
Windows
installing printer on wireless
network 104
Windows software
Abbyy Sprint OCR 23
Phone Book 23
Printer Home 23
Printer Setup Utility 23
Printing Preferences 23
Product Update 23
Status Messenger 23
Status Monitor Center 23
Tools for Office 23
Wireless Setup Utility 23
wired (Ethernet) networking for
Macintosh 111
wired (Ethernet) networking for
Windows 111
wireless 126
Macintosh 114
network indicator light 105
wireless network
adding a printer to existing ad hoc
network 108
advanced setup 103
common home
configurations 119
information you will need for
setting up wireless printing 102
installing printer on
(Macintosh) 104
installing printer on
(Windows) 104
interference 124
resolving communication
problems 171
security 101
security information 118
signal strength 123
SSID 118
troubleshooting 162
types of wireless networks 122
wireless network compatibility 101
wireless print server
not installed 169
wireless settings
changing after installation
(Macintosh) 107
changing after installation
(Windows) 107
resetting to factory defaults 165
wireless setup
advanced 103, 129
guided 129
information needed for 102
wireless signal
strength 123
wireless signal absorption 124
wireless troubleshooting
cannot print over wireless
network 166
changing wireless settings after
installation (Macintosh) 107
changing wireless settings after
installation (Windows) 107
lost connection to printer 165
printer and computer on different
networks 125
printer works intermittently on
wireless network 171
Wi‑Fi Protected Setup
configuring manually 109
using 117
Wi‑Fi Protected Setup logo
identifying 117
WPA 101, 109
WPA/WPA2 preshared/passphrase
locating 117
WPA2 101
Index 198

Navigation menu
