Please read this manual carefully before operating

your set and retain it for future reference.

BB5530A (BB5530A, S53A2-D)

OWNER’S MANUAL

Network 3D Blu-ray™

Sound Bar

Getting Started2

Getting Started

Safety Information

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK) NO

USER-SERVICEABLE PARTS INSIDE REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

This lightning ash with arrowhead

symbol within an equilateral triangle

is intended to alert the user to the

presence of uninsulated dangerous

voltage within the product’s

enclosure that may be of sucient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an

equilateral triangle is intended

to alert the user to the presence

of important operating and

maintenance (servicing)

instructions in the literature accompanying the

product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK

HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN

OR MOISTURE.

WARNING: Do not install this equipment in a

conned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings.

Install in accordance with the manufacturer’s

instructions.

Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the

product and to protect it from over heating. The

openings shall be never be blocked by placing

the product on a bed, sofa, rug or other similar

surface. This product shall not be placed in a built-

in installation such as a bookcase or rack unless

proper ventilation is provided or the manufacturer’s

instruction has been adhered to.

CAUTION : CLASS 1M VISIBLE AND INVISIBLE LASER

RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY

WITH OPTICAL INSTRUMENTS

Use of controls, adjustments or the performance of

procedures other than those specied herein may

result in hazardous radiation exposure.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon

a dedicated circuit;

That is, a single outlet circuit which powers only

that appliance and has no additional outlets or

branch circuits. Check the specication page of this

owner’s manual to be certain. Do not overload wall

outlets. Overloaded wall outlets, loose or damaged

wall outlets, extension cords, frayed power cords, or

damaged or cracked wire insulation are dangerous.

Any of these conditions could result in electric

shock or re. Periodically examine the cord of your

appliance, and if its appearance indicates damage

or deterioration, unplug it, discontinue use of the

appliance, and have the cord replaced with an

exact replacement part by an authorized service

center. Protect the power cord from physical or

mechanical abuse, such as being twisted, kinked,

pinched, closed in a door, or walked upon. Pay

particular attention to plugs, wall outlets, and

the point where the cord exits the appliance. To

disconnect power from the mains, pull out the

mains cord plug. When installing the product,

ensure that the plug is easily accessible.

Getting Started 3

Getting Started

This device is equipped with a portable battery or

accumulator.

Safety way to remove the battery or the

battery from the equipment: Remove the

old battery or battery pack, follow the steps

in reverse order than the assembly. To prevent

contamination of the environment and bring on

possible threat to human and animal health, the

old battery or the battery put it in the appropriate

container at designated collection points. Do

not dispose of batteries or battery together with

other waste. It is recommended that you use

local, free reimbursement systems batteries and

accumulators. The battery shall not be exposed to

excessive heat such as sunshine, re or the like.

CAUTION: The apparatus shall not be exposed to

water (dripping or splashing) and no objects lled

with liquids, such as vases, shall be placed on the

apparatus.

Disposal of your old appliance

1. When this crossed-out wheeled bin

symbol is attached to a product it

means the product is covered by the

European Directive 2002/96/EC.

2. All electrical and electronic products

should be disposed of separately

from the municipal waste stream

via designated collection facilities

appointed by the government or the

local authorities.

3. The correct disposal of your old

appliance will help prevent potential

negative consequences for the

environment and human health.

4. For more detailed information about

disposal of your old appliance, please

contact your city office, waste disposal

service or the shop where you

purchased the product.

Disposal of waste batteries/accumulators

1. When this crossed-out wheeled

bin symbol is attached to batteries/

accumulators of Your product it means

they are covered by European Directive

2006/66/EC.

2. This symbol may be combined with

chemical symbols for mercury(Hg),

cadmium(Cd) or lead(Pb) if the battery

Contains more that 0.0005% of

mercury,0.002% of cadmium or 0.004%

of lead.

3. All batteries/accumulators should be

disposed separately from the municipal

waste stream via designated collection

facilities appointed by the government

or the local authorities.

4. The correct disposal of Your old

batteries/accumulators will help

to prevent potential negative

consequences for the environment,

animal and human health.

5. For more detailed information about

disposal of Your old batteries/

accumulators, please contact Your

city office, waste disposal service or

the shop where You purchased the

product.

Getting Started4

Getting Started

For Wireless product European Union Notice

LG Electronics hereby declares that this/these

product(s) is/are in compliance with the essential

requirements and other relevant provisions of

Directive 1999/5/EC, 2004/108/EC, 2006/95/EC,

2009/125/EC and 2011/65/EU.

Please contact to the following address for

obtaining a copy of the DoC (Declaration of

Conformity).

Contact oce for compliance of this product:

LG Electronics Inc.

EU Representative, Krijgsman 1,

1186 DM Amstelveen, The Netherlands

yPlease note that this is NOT a Customer Service

contact point. For Customer Service Information,

see Warranty Card or contact the dealer that you

purchased this product.

Indoor use only.

RF Radiation Exposure Statement

This equipment should be installed and operated

with minimum distance 20 cm between the

radiator and your body.

Notes on copyrights

yBecause AACS (Advanced Access Content

System) is approved as content protection

system for Blu-ray Disc format, similar to use of

CSS (Content Scramble System) for DVD format,

certain restrictions are imposed on playback,

analog signal output, etc., of AACS protected

content. The operation of this product and

restrictions on this product may vary depending

on your time of purchase as those restrictions

may be adopted and/or changed by AACS after

the production of this product.

yFurthermore, BD-ROM Mark and BD+ are

additionally used as content protection systems

for Blu-ray Disc format, which imposes certain

restrictions including playback restrictions for

BD-ROM Mark and/or BD+ protected content. To

obtain additional information on AACS, BD-ROM

Mark, BD+, or this product, please contact an

authorized Customer Service Center.

yMany BD-ROM/DVD discs are encoded with

copy protection. Because of this, you should only

connect your player directly to your TV, not to a

VCR. Connecting to a VCR results in a distorted

picture from copy-protected discs.

yThis product incorporates copyright protection

technology that is protected by U.S. patents

and other intellectual property rights. Use of

this copyright protection technology must be

authorized by Rovi Corporation, and is intended

for home and other limited viewing uses only

unless otherwise authorized by Rovi Corporation.

Reverse engineering or disassembly is prohibited.

yUnder the U.S. Copyright laws and Copyright

laws of other countries, unauthorized recording,

use, display, distribution, or revision of television

programs, videotapes, BD-ROM discs, DVDs, CDs

and other materials may subject you to civil and/

or criminal liability.

Getting Started 5

Getting Started

Important Notice for TV colour

system

The colour system of this player diers according to

currently playing discs.

For example, when the player plays the disc

recorded in the NTSC colour system, the image is

output as an NTSC signal.

Only the multi system colour TV can receive all

signals output from the player.

yIf you have a PAL colour system TV, you will see

just distorted images when using discs or video

contents recorded in NTSC.

yThe multi system colour TV changes the colour

system automatically according to input signals.

In case that the colour system is not changed

automatically, turn it o and then on to see

normal images on screen.

yEven if the disc recorded in NTSC colour system

are well displayed on your TV, these may not be

recorded correctly on your recorder.

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant

woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing contents in 3D,

it is strongly recommended to stop the

playback and rest until you feel normal.

> Caution

Table of Contents6

Table of Contents

1 Getting Started

2 Safety Information

8 Introduction

8 – Playable discs and symbols used in

this manual

9 – About the “7” symbol display

9 – Regional code

9 – System Select

10 Remote Control

11 Front panel

12 Rear panel

12 Active woofer

2 Connecting

13 Mounting the main unit on a wall

15 Setting up

15 – Wireless connection

16 Connecting to your TV

17 – What is SIMPLINK?

17 – ARC (Audio Return Channel) function

18 – Resolution setting

19 Antenna connection

19 Connections with external device

19 – PORT. IN connection

20 – OPTICAL IN connection

20 – HDMI IN 1/2 connection

21 Connecting to your Home Network

21 – Wired network connection

22 – Wired network setup

23 – Wireless network connection

23 – Wireless network setup

3 System Setting

26 Initial Setup

28 Settings

28 – Adjust the setup settings

28 – [NETWORK] menu

29 – [DISPLAY] menu

31 – [LANGUAGE] menu

31 – [AUDIO] menu

33 – [LOCK] menu

34 – [OTHERS] menu

4 Operating

36 Sound Effect

36 3D Sound Effect

37 Home Menu Display

37 – Using [HOME] menu

37 – Using the Smart Share

38 Playing the Linked Devices

38 – Playing a disc

38 – Playing Blu-ray 3D disc

39 – Playing a file on disc/USB device

40 – Playing a file on a network server

41 Using Home Network Server for PC

41 – Installing Nero MediaHome 4

Essentials

41 – Sharing files and folders

42 – About Nero MediaHome 4 Essentials

42 – System requirements

43 General Playback

43 – Basic operations for video and audio

content

43 – Basic operations for photo content

43 – Using the disc menu

44 – Resume playback

44 – Last scene memory

45 On-Screen Display

45 – To control video playback

46 – To control photo view

47 Advanced Playback

47 – Repeat playback

47 – Repeating a specific portion

47 – Playing from selected time

48 – Selecting a subtitle language

48 – Hearing a different audio

48 – Watching from a different angle

48 – Changing the TV Aspect Ratio

49 – Changing subtitle Code Page

49 – Changing the Picture Mode

49 – Viewing content information

50 – Changing content list view

50 – Selecting a subtitle file

51 – Listening to music during slide show

51 – Converting 2D content to 3D

52 Advanced Features

Table of Contents 7

52 – Wi-Fi Direct™

53 – Enjoying Miracast™

54 – Enjoying BD-Live™

54 – LG AV Remote

55 – Audio CD recording

55 – Recording from FM radio or

PORTABLE source

56 – Viewing information from Gracenote

Media Database

57 Playing the iPod

57 – Enjoying iPod on the screen

57 – Enjoying the iPod IN mode

59 Radio Operations

59 – Listening to the radio

59 – Presetting the Radio Stations

59 – Deleting a saved station

59 – Deleting all the saved stations

59 – Improving poor FM reception

59 – See information about a radio station

60 Using an USB keyboard or mouse

60 Using the Premium

61 Using the LG Smart World

61 – Signing in

62 – Searching online content

62 Using the My Apps Menu

63 Using Bluetooth technology

63 – Listening to music stored on the

Bluetooth devices

5 Troubleshooting

65 Troubleshooting

65 – General

66 – Network

67 – Picture

67 – Sound

67 – Customer Support

67 – Open Source Software Notice

6 Appendix

68 Controlling a TV with the Supplied

Remote Control

68 – Setting up the remote to control your

69 Network Software Update

69 – Network update notification

69 – Software update

71 Additional Information

71 – File requirement

72 – AVCHD (Advanced Video Codec High

Definition)

73 – About DLNA

73 – Certain system requirements

73 – Compatibility notes

74 Audio Output Specifications

75 Area Code List

76 Language Code List

77 Trademarks and Licenses

80 Specifications

82 Maintenance

82 – Handling the unit

82 – Notes on discs

83 Important Information relating to Network

Services

Some of the content in this manual may dier from your player depending on the software of the

player or your service provider.

Getting Started8

Getting Started

Introduction

Playable discs and symbols used in this manual

Media/Term Logo Symbol Description

Blu-ray

yDiscs such as movies that can be purchased or

rented.

y“Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs.

yBD-R/RE discs that are recorded in BDAV format.

yBD-R/RE discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

DVD-ROM

DVD-R

DVD-RW

DVD+R

DVD+RW

(12 cm)

yDiscs such as movies that can be purchased or

rented.

yMovie mode and nalized only

ySupports the dual layer disc also

oFinalized AVCHD format

yDVD±R/RW discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

DVD-RW (VR)

(12 cm) rVR mode and nalized only

Audio CD

(12 cm) tAudio CD

CD-R/RW

(12 cm)

yCD-R/RW discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

Note –,Indicates special notes and operating features.

Caution –>Indicates cautions for preventing possible damages

from abuse.

Getting Started 9

Getting Started

yDepending on the conditions of the

recording equipment or the CD-R/RW (or

DVD±R/RW) disc itself, some CD-R/RW (or

DVD±R/RW) discs cannot be played on the

unit.

yDepending on the recording software & the

nalization, some recorded discs (CD-R/RW,

DVD±R/RW, BD-R/RE) may not be playable.

yBD-R/RE, DVD±R/RW and CD-R/RW discs

recorded using a personal computer or a

DVD or CD Recorder may not play if the

disc is damaged or dirty, or if there is dirt or

condensation on the player’s lens.

yIf you record a disc using a personal

computer, even if it is recorded in a

compatible format, there are cases in which

it may not play because of the settings of

the application software used to create the

disc. (Check with the software publisher for

more detailed information.)

yThis player requires discs and recordings to

meet certain technical standards in order to

achieve optimal playback quality.

yPre-recorded DVDs are automatically set to

these standards. There are many dierent

types of recordable disc formats (including

CD-R containing MP3 or WMA les) and

these require certain pre-existing conditions

to ensure compatible playback.

yCustomers should note that permission

is required in order to download MP3 /

WMA les and music from the Internet.

Our company has no right to grant such

permission. Permission should always be

sought from the copyright owner.

yYou have to set the disc format option

to [Mastered] in order to make the discs

compatible with the LG players when

formatting rewritable discs. When setting

the option to Live System, you cannot use

it on LG player. (Mastered/Live File System :

Disc format system for windows Vista)

, Note About the “7” symbol display

“7” may appear on your TV display during

operation and indicates that the function explained

in this owner’s manual is not available on that

specic media.

Regional code

This unit has a regional code printed on the rear of

the unit. This unit can play only BD-ROM or DVD

discs labeled same as the rear of the unit or “ALL”.

System Select

Press B (OPEN/CLOSE) when a disc is inserted,

and do not remove the disc. Press and hold M

(PAUSE) for more than ve seconds while [OPEN] is

displayed in the display window.

Getting Started10

Getting Started

Remote Control

Battery Installation

Remove the battery cover on the

rear of the Remote Control, and

insert two R03 (size AAA) batteries

with 4 and 5 matched correctly.

• • • • • • a • • • • • •

1 (POWER): Switches the player

ON or OFF.

B (OPEN/CLOSE): Ejects a disc.

FUNCTION: Changes input mode.

0-9 numerical buttons: Selects

numbered options in a menu.

CLEAR: Removes a number when

setting the password or network

connection.

REPEAT (h): Repeats a desired

section or sequence.

• • • • • • b • • • • •

c/v (SCAN): Searches

backward or forward.

C/V (SKIP): Goes to the

next or previous chapter / track /

le.

Z (STOP): Stops playback.

z (PLAY): Starts playback.

M (PAUSE): Pauses playback.

SPEAKER LEVEL: Sets the sound

level of desired speaker.

SOUND EFFECT: Selects a sound

eect mode.

VOL +/-: Adjusts speaker volume.

OPTICAL/TV SOUND: Changes

input mode to optical directly.

MUTE: Mute the unit.

• • • • • • c • • • • •

HOME ( ): Displays or exits the

[Home].

3D SOUND: Selects a 3D sound

eect mode.

INFO/MENU (m): Displays or

exits On-Screen Display.

Direction buttons: Selects an

option in the menu.

PRESET +/-: Selects programme

of Radio.

TUNING +/-: Tunes in the desired

radio station.

ENTER (b): Acknowledges menu

selection.

BACK ( ): Exits the menu or

returns to the previous screen.

TITLE/POPUP: Displays the DVD

title menu or BD-ROM’s popup

menu, if available.

DISC MENU: Accesses menu on a

disc.

• • • • • • d • • • • •

Colored (R, G, Y, B) buttons:

- Use to navigate BD-ROM menus.

They are also used as shortcut

buttons for specic menus.

- B button: Selects mono/ stereo

in FM mode.

RDS: Radio Data System.

PTY: Views the programme type

of the RDS.

PTY SEARCH:

Searches programme type.

SUBTITLE: Selects a subtitle

language.

AUDIO: Selects an audio language

or audio channel.

SLEEP: Sets a certain period of

time after which the unit will

switch to o.

MUSIC ID: When connected

to the network, can provide

information about the current

song while movie playback.

? : This button is not available.

X (REC): Records from an Audio

CD, FM radio, or PORTABLE source

to USB.

TV Control Buttons: See page

68.

Getting Started 11

Getting Started

Front panel

c d

a Disc Slot

b Operation buttons

1/! (Power)

-/+ (Volume)

DM (Play / Pause)

I (Stop)

F (Function)

Changes the input source or function.

R (Open / Close)

c iPod/ iPhone/ iPad/ USB Port

d Display Window

Precautions in using the touch buttons

yUse the touch buttons with clean and dry

hands.

- In a humid environment, wipe out any

moisture on the touch buttons before

using.

yDo not press the touch buttons hard to

make it work.

- If you apply too much strength, it can

damage the sensor of the touch buttons.

yTouch the button that you want to work in

order to operate the function correctly.

yBe careful not to have any conductive

material such as metallic object on the

touch buttons. It can cause malfunctions.

> Caution

Getting Started12

Getting Started

Rear panel

a LAN Port

b HDMI OUT TO TV

c HDMI IN 1/2

d Antenna Connector

e PORT. IN

f OPTICAL IN

Active woofer

a LED (connection status)

Yellow: The connection is completed.

Yellow (blink): The woofer is trying to connect.

RED: The connection is in standby mode or

failed.

b Speaker duct

Be careful to make sure children not to put

their hands or any objects into the speaker

duct.

> Caution

c PAIRING button

Connecting 13

Connecting

Mounting the main

unit on a wall

You can mount the main unit on a wall.

Prepare screws and brackets supplied.

Preperation

Unit Wall bracket

WALL BRACKET

INSTALL GUIDE

1. Match the TV BOTTOM LINE of WALL BRACKET

INSTALL GUIDE with the bottom of TV and

attach to the position.

2. When you mount it on a wall (concrete), use the

wall plugs (Not supplied). You should drill some

holes. A guide sheet (WALL BRACKET INSTALL

GUIDE) is supplied to drill. Use the sheet to

check the point to drill.

Screws and Wall Plugs are not supplied for

mounting the unit. We recommend the Hilti

(HUD-1 6 x 30) for the mounting. Please

purchase it.

, Note

3. Remove the WALL BRACKET INSTALL GUIDE.

4. Fix it with screws (not supplied) as shown in the

illustration below.

Connecting14

Connecting

5. Hang the main unit onto the brackets, as shown

below.

yDo not hang onto the installed unit and

avoid any impact to the unit.

ySecure the unit rmly to the wall so that it

does not fall o. If the unit falls o, it may

result in an injury or damage to the product.

yWhen the unit is installed on a wall, please

make sure that a child does not pull any of

connecting cables, as it may cause it to fall.

> Caution

Detach the unit from the bracket as shown

below.

, Note

Connecting 15

Connecting

Setting up

Wireless connection

LED indicator of wireless subwoofer

LED Color Operation

Yellow The wireless subwoofer is

receiving the signal of the

unit.

Yellow (blink) The wireless subwoofer is

trying to connect.

Red The Wireless subwoofer is in

standby mode.

O (No display) The Wireless subwoofer is

turned o.

Initial setting of an ID for the

wireless subwoofer

1. Connect the power cord of the Wireless

subwoofer to the outlet.

2. Turn on the main unit : The main unit and

wireless subwoofer will be automatically

connected.

Setting an ID for the wireless

subwoofer

When the unit is manufactured, the ID is already

set. If interference occurs or you use a new wireless

subwoofer, an ID should be set again.

1. Press HOME ( ).

2. Use

I/i to select the [Setup] and

press ENTER (b). The [Setup] menu appears.

3. Use

U/u to select [AUDIO] option then press i

to move to the second level.

4. Use

U/u to select the [Connect wireless

speakers] option then press ENTER (b) or i to

move to the third level.

The [Wireless Speaker Connection Guide]

appears.

5. Press PAIRING button on the subwoofer.

- If you see the yellow LED indicator light,

pairing was successful.

6. Use

I/i to select the [Speaker test] and press

ENTER (b) for wireless speaker connection test.

yIf there is a strong electromagnetic wave

product nearby, interference may occur. Put

the unit (Wireless subwoofer and main unit)

away from there.

yIf you operate main unit then wireless

subwoofer (rear speakers) sound within a

few seconds in standby mode.

ySet the distance between this unit and

subwoofer Receiver within 10 m (32 ft.).

yOptimum performance can be

implemented only when the unit and

the Wireless subwoofer within distance

of 2 m (6 ft.) to 10 m (32 ft.) is used since

communication failure may occur if longer

distance is used.

yIt takes a few seconds (and may take longer)

for the Wireless Transmitter and subwoofer

to communicate with each other.

, Note

Connecting16

Connecting

Connecting to your TV

If you have a HDMI TV or monitor, you can connect

it to this player using a HDMI cable (Type A, High

Speed HDMI™ Cable). Connect the HDMI jack on

the player to the HDMI jack on a HDMI compatible

TV or monitor.

Rear of the unit

HDMI cable

Set the TV’s source to HDMI (refer to TV’s owner’s

manual).

Please refer to the manuals of your TV, Stereo

System or other devices as necessary to make

the best connections.

, Note

Additional information for HDMI

yWhen you connect a HDMI or DVI compatible

device make sure of the following:

-Try switching o the HDMI/DVI device and

this player. Next, switch on the HDMI/DVI

device and leave it for around 30 seconds,

then switch on this player.

-The connected device’s video input is set

correctly for this unit.

-The connected device is compatible with

720x576p, 1280x720p, 1920x1080i or

1920x1080p video input.

yNot all HDCP-compatible HDMI or DVI devices

will work with this player.

-The picture will not be displayed properly

with non-HDCP device.

yIf a connected HDMI device does not accept

the audio output of the player, the HDMI

device’s audio sound may be distorted or

may not output.

yWhen you use HDMI connection, you can

change the resolution for the HDMI output.

(Refer to “Resolution setting” on page 18)

ySelect the type of video output from the

HDMI OUT jack using [HDMI Color Setting]

option on the [Settings] menu (page 30).

yChanging the resolution when the

connection has already been established

may result in malfunctions. To solve the

problem, turn o the player and then turn it

on again.

yWhen the HDMI connection with HDCP

is not veried, TV screen is changed to

black screen. In this case, check the HDMI

connection, or disconnect the HDMI cable.

yIf there are noises or lines on the screen,

please check the HDMI cable (length is

generally limited to 4.5 m (15 ft.)).

, Note

Connecting 17

Connecting

What is SIMPLINK?

Some functions of this unit are controlled by the

TV’s remote control when this unit and LG TV’s with

SIMPLINK are connected through HDMI connection.

Controllable functions by LG TV’s remote control;

Play, Pause, Scan, Skip, Stop, Power O, etc.

Refer to the TV owner’s manual for the details of

SIMPLINK function.

LG TV’s with SIMPLINK function has the logo as

shown above.

Depending on the disc type or playing status,

some SIMPLINK operation may dier from your

purpose or not work.

, Note

ARC (Audio Return Channel)

function

The ARC function enables an HDMI capable TV to

send the audio stream to HDMI OUT of this player.

To use this function:

-Your TV must support the HDMI-CEC and ARC

function and the HDMI-CEC and ARC must be

set to On.

-The setting method of HDMI-CEC and ARC may

dier depending on the TV. For details about

ARC function, refer to your TV manual.

-You must use the HDMI cable (Type A, High

Speed HDMI™ cable with Ethernet).

-You must connect with the HDMI IN that

supports the ARC function using the HDMI OUT

on this player.

-You can connect only one Home Theater to TV

compatible with ARC.

To activate [SIMPLINK / ARC] function, set this

option to [On] (page 35).

, Note

Connecting18

Connecting

Resolution setting

The player provides several output resolutions for

HDMI OUT jack. You can change the resolution

using [Settings] menu.

1. Press HOME ( ).

2. Use A/D to select the [Settings] and press

ENTER (b). The [Settings] menu appears.

3. Use W/S to select [DISPLAY] option then

press D to move to the second level.

4. Use W/S to select the [Resolution] option

then press ENTER (b) to move to the third level.

5. Use

W/S to select the desired resolution then

press ENTER (b) to confirm your selection.

yIf your TV does not accept the resolution

you have set on the player, you can set

resolution to 576p as follows:

1. Press HOME ( ) to disappear the HOME

menu.

2. Press

Z (STOP) for more than 5 seconds.

yIf you select a resolution manually and then

connect the HDMI jack to TV and your TV

does not accept it, the resolution setting is

set to [Auto].

yIf you select a resolution that your TV

does not accept, the warning message

will appear. After resolution change,

if you cannot see the screen, please

wait 20 seconds and the resolution will

automatically revert back to the previous

resolution.

yThe 1080p video output frame rate may

be automatically set to either 24 Hz or

50 Hz depending both on the capability

and preference of the connected TV and

based on the native video frame rate of the

content on the BD-ROM disc.

, Note

Connecting 19

Connecting

Antenna connection

Connect the supplied antenna for listening to the

radio.

Rear of the unit

After connecting the FM wire antenna, be sure

to fully extend it.

, Note

Connections with

external device

PORT. IN connection

You can enjoy the sound from your portable audio

player through the speakers of this system.

Connect the headphones (or line out ) jack of the

portable audio player into the PORT. IN socket of

this unit. And then select the [PORTABLE] option by

pressing FUNCTION.

You can also use the F (Function) button on the

front panel to select the input mode.

Rear of the unit

MP3 player, etc...

Connecting20

Connecting

OPTICAL IN connection

You can enjoy the sound from your component

with a digital optical connection through the

speakers of this system.

Connect the optical output jack of your component

into the OPTICAL IN jack on the unit. And then

select the [OPTICAL] option by pressing FUNCTION.

Or press OPTICAL/TV SOUND to select directly.

You can also use the F (Function) button on the

front panel to select the input mode.

To the digital

optical output jack

of your component

Rear of the unit

HDMI IN 1/2 connection

You can enjoy the pictures and sound from your

component through this connection.

Connect the HDMI OUT jack of your component

into the HDMI IN 1 or 2 jack on this unit. And

then select the [HDMI IN 1/2] option by pressing

FUNCTION.

You can also use the F (Function) button on the

front panel to select the input mode.

To the HDMI OUT jack of

your component

(set-top box, digital

satellite receiver, video

game machine, etc.)

Rear of the unit

yYou cannot change the video resolution in

the HDMI IN 1/2 mode. Change the video

resolution of the connected component.

yIf the video output signal is abnormal when

your personal computer is connected to

HDMI IN 1/2 jack, change the resolution

of your personal computer to 576p, 720p,

1080i or 1080p.

yThe player sends audio from the HDMI

inputs to both the HDMI output and to the

unit’s speakers.

, Note

Connecting 21

Connecting

Connecting to your

Home Network

This player can be connected to a local area

network (LAN) via the LAN port on the rear panel or

the internal wireless module.

By connecting the unit to a broadband home

network, you have access to services such as

software updates, BD-Live interactivity and online

content services.

Wired network connection

Using a wired network provides the best

performance, because the attached devices

connect directly to the network and are not subject

to radio frequency interference.

Please refer to the documentation for your network

device for further instructions.

Connect the player’s LAN port to the corresponding

port on your Modem or Router using a

commercially available LAN or Ethernet cable.

yWhen plugging or unplugging the LAN

cable, hold the plug portion of the cable.

When unplugging, do not pull on the LAN

cable but unplug while pressing down on

the lock.

yDo not connect a modular phone cable to

the LAN port.

ySince there are various connection

congurations, please follow the

specications of your telecommunication

carrier or internet service provider.

yIf you want to access content from DLNA

servers, this player must be connected to

the same local area network with them via a

router.

yTo set your PC as a DLNA server, install the

supplied Nero MediaHome 4 on your PC

(page 41).

, Note

Rear of the unit

Router

Broadband

service

DLNA certied servers

Connecting22

Connecting

Wired network setup

If there is a DHCP server on the local area network

(LAN) via wired connection, this player will

automatically be allocated an IP address. After

making the physical connection, a small number of

home networks may require the player’s network

setting to be adjusted. Adjust the [NETWORK]

setting as follow.

Preparation

Before setting the wired network, you need to

connect the broadband internet to your home

network.

1. Select [Connection Setting] option in the

[Settings] menu then press ENTER (b).

2. Read the preparations for the network settings

and then press ENTER (b) while [Start] is

highlighted.

Network will automatically be connected to the

unit.

Advanced Setting

If you want to set the network settings manually,

use W/S to select [Advanced Setting] on the

[Network Setting] menu and press ENTER (b).

1. Use W/S to select [Wired] and press ENTER

(b).

2. Use

W/S/A/D to select the IP mode

between [Dynamic] and [Static].

Normally, select [Dynamic] to allocate an IP

address automatically.

If there is no DHCP server on the network and

you want to set the IP address manually, select

[Static] then set [IP Address], [Subnet Mask],

[Gateway] and [DNS Server] using W/S/

A/D and numerical buttons. If you make a

mistake while entering a number, press CLEAR

to clear the highlighted part.

, Note

3. Select [Next] and press ENTER (b) to apply

network settings.

Network connection status is displayed on the

screen.

4. Press ENTER (b) while [OK] is highlighted to

finish the wired network settings.

Connecting 23

Connecting

Wireless network connection

Another connection option is to use an Access Point

or a wireless router. The network conguration and

connection method may vary depending on the

equipment in use and the network environment.

Wireless

Communication

DLNA certied servers

Access Point or

Wireless Router

Broadband

service

Refer to the setup instructions supplied with

your access point or wireless router for detailed

connection steps and network settings.

For best performance, a direct wired connection

from this player to your home network’s router or

cable/DSL modem is always the best option.

If you do chose to use the wireless option, note that

performance can sometimes be aected by other

electronic devices in the home.

Wireless network setup

For the wireless network connection, the player

needs to be set up for network communication.

This adjustment can be done from the [Settings]

menu. Adjust the [NETWORK] setting as follow.

Setting up the access point or the wireless router

is required before connecting the player to the

network.

Preparation

Before setting the wireless network, you need

to:

-connect the broadband internet to the

wireless home network.

-set the access point or wireless router.

-note the SSID and security code of the

network.

1. Select [Connection Setting] option in the

[Settings] menu then press ENTER (b).

2. Read the preparations for the network settings

and then press ENTER (b) while [Start] is

highlighted.

If wired network is not connected to the unit, all

available networks are displayed on the screen.

3. Use

W/S to select a desired SSID of wireless

network and press ENTER (b).

If you have security on your access point, you

need to input the security code as necessary.

If you use other characters than the english

alphabet or digits for the SSID name of your

access point or wireless router, it may be

displayed dierently.

, Note

Connecting24

Connecting

yWEP security mode generally have 4 keys

available on an access point setting. If your

access point or wireless router use WEP

security, enter the security code of the key

“No.1” to connect on your home network.

yAn Access Point is a device that allows you

to connect to your home network wirelessly.

, Note

4. Use

W/S/A/D to select the IP mode

between [Dynamic] and [Static].

Normally, select [Dynamic] to allocate an IP

address automatically.

If there is no DHCP server on the network and

you want to set the IP address manually, select

[Static] then set [IP Address], [Subnet Mask],

[Gateway] and [DNS Server] using W/S/

A/D and numerical buttons. If you make a

mistake while entering a number, press CLEAR

to clear the highlighted part.

, Note

5. Select [Next] and press ENTER (b) to apply

network settings.

Network connection status is displayed on the

screen.

6. Select [OK] and press ENTER (b) to complete

the network connection.

Advanced Setting

If you want to set the network settings manually,

use W/S to select [Advanced Setting] on the

[Network Setting] menu and press ENTER (b).

1. Use W/S to select [Wireless] and press ENTER

(b).

[AP List] - Scans all available access points or

wireless routers within range and display them

as a list.

[Network name (SSID)] – Your access point

may not be broadcasting its network name

(SSID). Check your access point settings through

your computer and either set your access

point to broadcast SSID, or manually enter the

network name in [Network name(SSID)].

[PBC] – If your access point or wireless

router that supports the PBC (Push Button

Configuration) method, select this option and

press the Push Button on your access point

within 120 counts. You do not need to know the

network name (SSID) and security code of your

access point.

[PIN] – If your access point supports the PIN

Code configuration method based on WPS(Wi-

Fi Protected Setup), select this option and

note the code number on the screen. And

then, enter the PIN number on a setting menu

of your access point to connect. Refer to the

documentation for your network device.

2. Follow the instructions of each connection

method on the screen.

To use PBC and PIN network connection,

security mode of your access point must be

set to OPEN or AES.

, Note

Connecting 25

Connecting

Notes on network connection

yMany network connection problems during

set up can often be xed by re-setting the

router or modem. After connecting the player

to the home network, quickly power o and/

or disconnect the power cable of the home

network router or cable modem. Then power on

and/or connect the power cable again.

yDepending on the internet service provider (ISP),

the number of devices that can receive internet

service may be limited by the applicable terms

of service. For details, contact your ISP.

yOur company is not responsible for any

malfunction of the player and/or the internet

connection feature due to communication

errors/malfunctions associated with your

broadband internet connection, or other

connected equipment.

yThe features of BD-ROM discs made available

through the Internet Connection feature are not

created or provided by our company, and our

company is not responsible for their functionality

or continued availability. Some disc related

material available by the Internet Connection

may not be compatible with this player. If you

have questions about such content, please

contact the producer of the disc.

ySome internet content may require a higher

bandwidth connection.

yEven if the player is properly connected and

congured, some internet content may not

operate properly because of internet congestion,

the quality or bandwidth of your internet service,

or problems at the provider of the content.

ySome internet connection operations may not

be possible due to certain restrictions set by the

Internet service provider (ISP) supplying your

broadband Internet connection.

yAny fees charged by an ISP including, without

limitation, connection charges are your

responsibility.

yA 10 Base-T or 100 Base-TX LAN port is required

for wired connection to this player. If your

internet service does not allow for such a

connection, you will not be able to connect the

player.

yYou must use a Router to use xDSL service.

yA DSL modem is required to use DSL service and

a cable modem is required to use cable modem

service. Depending on the access method of and

subscriber agreement with your ISP, you may not

be able to use the internet connection feature

contained in this player or you may be limited

to the number of devices you can connect at

the same time. (If your ISP limits subscription to

one device, this player may not be allowed to

connect when a PC is already connected.)

yThe use of a “Router” may not be allowed or its

usage may be limited depending on the policies

and restrictions of your ISP. For details, contact

your ISP directly.

yThe wireless network operate at 2.4 GHz

radio frequencies that are also used by other

household devices such as cordless telephone,

Bluetooth® devices, microwave oven, and can be

aected by interference from them.

yTurn o all unused network equipment in

your local home network. Some devices may

generate network trac.

yFor the purpose of the better transmission,

placing the player from the access point as close

as possible.

yIn some instances, placing the access point or

wireless router at least 0.45 m (1.5 ft.) above the

oor may improve the reception.

yMove closer to the access point if possible or re-

orient the player so there is nothing between it

and the access point.

yThe reception quality over wireless depends on

many factors such as type of the access point,

distance between the player and access point,

and the location of the player.

ySet your access point or wireless router to

Infrastructure mode. Ad-hoc mode is not

supported.

3 System Setting

System Setting26

System Setting

Initial Setup

When you turn on the unit for the rst time, the

initial setup wizard appears on the screen. Set the

display language and network settings on the initial

setup wizard.

1. Press

1 (POWER).

The initial setup wizard appears on the screen.

2. Use

W/S/A/D to select a display language

and press ENTER (b).

3. Read and prepare the preparations for the

network settings and then press ENTER (b)

while [Start] is highlighted.

If wired network is connected, the network

connection setting will automatically be

finished.

4. All available networks are displayed on the

screen. Use W/S to select [Wired Network]

or desired SSID of wireless network and press

ENTER (b).

If you have security on your access point, you

need to input the security code as necessary.

5. Use

W/S/A/D to select the IP mode

between [Dynamic] and [Static].

Normally, select [Dynamic] to allocate an IP

address automatically.

6. Select [Next] and press ENTER (b) to apply

network settings.

Network connection status is displayed on the

screen.

For details on network settings, refer to

“Connecting to your Home Network” on page

21.

System Setting 27

System Setting

7. Select [Next] and press ENTER (b).

8. You can listen to TV sound through this unit’s

speaker automatically when TV is turned on. TV

and this unit should be connected with optical

cable.

Press W to move and press A/D to select [On]

or [Off ]. Select [Next] and press ENTER (b).

9. Check all the settings that you have set in the

previous steps.

Press ENTER (b) while [Finish] is highlighted

to finish the initial setup settings. If there is any

settings to be changed, use W/S/A/D to

select 1 and press ENTER (b).

System Setting28

System Setting

Settings

Adjust the setup settings

You can change the settings of the player in the

[Settings] menu.

1. Press HOME ( ).

2. Use

A/D to select the [Settings] and press

ENTER (b). The [Settings] menu appears.

3. Use

W/S to select the first setup option, and

press D to move to the second level.

4. Use

W/S to select a second setup option, and

press ENTER (b) to move to the third level.

5. Use

W/S to select a desired setting, and press

ENTER (b) to confirm your selection.

[NETWORK] menu

The [NETWORK] settings are needed to use the

software update, BD-Live and online content

services.

Connection Setting

If your home network environment is ready to

connect the player, the player needs to be set the

wired or wireless network connection for network

communication. (See “Connecting to your Home

Network” on page 21.)

Connection Status

If you want to check the network status on this

player, select the [Connection Status] options and

press ENTER (b) to check whether a connection

to the network and the internet have been

established.

BD-LIVE connection

You can restrict Internet access when BD-Live

functions are used.

[Permitted]

Internet access is permitted for all BD-Live

content.

[Partially permitted]

Internet access is permitted only for BD-Live

content which have content owner certicates.

Internet access and AACS Online functions are

prohibited for all BD-Live content without a

certicate.

[Prohibited]

Internet access is prohibited for all BD-Live

content.

System Setting

Smart Service Setting

[Country Setting]

Select your area for displaying proper online

content service.

[Initialize]

Depending on the region, [Initialize] function

may not be available.

Device Name

You can make a network name using virtual

keyboard. This player will be recognised by the

name you are entering on your home network.

Wi-Fi Direct

This player is a Wi-Fi Direct™ certied device. Wi-Fi

Direct™ is the technology that devices to connect

each other without connecting to an Access point

or a router. Press ENTER (b) to display the Wi-Fi

Direct menu. Refer to page 52 for the device Refer to page 52 for the device

connection.

Network Play

This function allows you to control the playback

of media streamed from DLNA media server by a

DLNA certied smartphone. Most DLNA certied

smartphone has a function to control the playback

media on your home network. Set this option to

[On] for allowing your smartphone to control this

unit. Refer to instructions of your DLNA certied

smartphone or the application for more detailed

information.

yThis unit and the DLNA Certied

Smartphone must be connected to the

same network.

yTo use the [Network Play] function using a

DLNA certied smartphone, press HOME

() to display the home menu before

connecting to this unit.

yWhile controlling the unit using the

[Network Play] function, the remote control

may not work.

yAvailable le formats described on page

71 are not always supported on [Network

Play] function.

, Note

[DISPLAY] menu

TV Aspect Ratio

Select a TV aspect ratio option according to your TV

type.

[4:3 Letter Box]

Select when a standard 4:3 TV is connected.

Displays theatrical images with masking bars

above and below the picture.

[4:3 Pan Scan]

Select when a standard 4:3 TV is connected.

Displays pictures cropped to ll your TV screen.

Both sides of the picture are cut o.

[16:9 Original]

Select when a 16:9 wide TV is connected. The

4:3 picture is displayed with an original 4:3

aspect ratio, with black bars appearing at the

left and right sides.

[16:9 Full]

Select when a 16:9 wide TV is connected. The

4:3 picture is adjusted horizontally (in a linear

proportion) to ll the entire screen.

You cannot select [4:3 Letter Box] and

[4:3 Pan Scan] option when the resolution is

set to higher than 720p.

, Note

System Setting

System Setting30

System Setting

Resolution

Sets the output resolution of the HDMI video signal.

Refer to page 18 for details about the resolution

setting.

[Auto]

If the HDMI OUT jack is connected to

TVs providing display information (EDID),

automatically selects the resolution best suited

to the connected TV.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[576p]

Outputs 576 lines of progressive video.

Ultra HD Upscaling

This feature allows the unit to up-scale the original

video resolution to Ultra HD resolution and output

via HDMI connection.

[Auto]

If you connect a display capable of displaying

Ultra HD resolution, this unit will output video

signals in Ultra HD resolution automatically.

[O ]

The unit will turn o the Up-scaling feature.

yThis unit will output video signals in Ultra

HD resolution when it plays BD-ROM disc

formatted in 24 Hz.

yThe playback pictures may be momentarily

interrupted when the resolutions switch.

, Note

1080p Display Mode

When the resolution is set to 1080p, select

[24 Hz] for smooth presentation of lm material

(1080p/24 Hz) with a HDMI-equipped display

compatible with 1080p/24 Hz input.

yWhen you select [24 Hz], you may

experience some picture disturbance when

the video switches video and lm material.

In this case, select [50 Hz].

yEven when [1080p Display Mode] is set to

[24 Hz], if your TV is not compatible with

1080p/24 Hz, the actual frame frequency of

the video output will be 50 Hz to match the

video source format.

, Note

HDMI Color Setting

Select the type of output from the HDMI OUT jack.

For this setting, please refer to the manuals of your

display device.

[YCbCr]

Select when connecting to a HDMI display

device.

[RGB]

Select when connecting to a DVI display

device.

3D Mode

Select the type of output mode for Blu-ray 3D disc

playback.

[O ]

Blu-ray 3D disc playback will output as 2D

mode like a normal BD-ROM disc playback.

[On]

Blu-ray 3D disc playback will output as 3D

mode.

Home Menu Guide

This function allows you to display or delete the

guide bubble on the [HOME] menu. Set this option

to [On] for displaying guide.

System Setting 31

System Setting

[LANGUAGE] menu

Display Menu

Select a language for the [Settings] menu and on-

screen display.

Disc Menu / Disc Audio /

Disc Subtitle

Select the language you prefer for the audio track

(disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the

disc was recorded.

[Other]

Press ENTER (b) to select another language.

Use number buttons then press ENTER (b)

to enter the corresponding 4-digit number

according to the language code list on page

76.

[O] (Disc Subtitle only)

Turn o Subtitle.

Depending on the disc, your language setting

may not work.

, Note

[AUDIO] menu

Each disc has a variety of audio output options. Set

the player’s Audio options according to the type of

audio system you use.

Since many factors aect the type of audio

output, see “Audio Output Specications” on

page 74 for details.

, Note

Digital Output

[PCM Stereo] (HDMI only)

Select if you connect this unit’s HDMI OUT jack

to a device with two-channel digital stereo

decoder.

[PCM Multi-Ch] (HDMI only)

Select if you connect this unit’s HDMI OUT jack

to a device with multi-channel digital decoder.

[DTS Re-Encode] (HDMI only)

Select if you connect this unit’s HDMI OUT jack

to a device with DTS decoder.

[BitStream] (HDMI only)

Select if you connect this unit’s HDMI OUT jack

to a device with LPCM, Dolby Digital, Dolby

Digital Plus, Dolby TrueHD, DTS and DTS-HD

decoder.

yWhen [Digital Output] option is set to [PCM

Multi-Ch], the audio may output as PCM

Stereo if the PCM Multi-Ch information is

not detected from HDMI device with EDID.

yIf the [Digital Output] option is set to [DTS

Re-Encode], the DTS Re-Encode audio is

outputted for BD-ROM discs with secondary

audio and the original audio is outputted

for the other discs (like [BitStream]).

yThis setting is not available on the input

signal from an external device.

, Note

System Setting32

System Setting

DRC (Dynamic Range Control)

This function allows you to listen to a movie at a

lower volume without losing clarity of sound.

[Auto]

The dynamic range of the Dolby TrueHD audio

output is specied by itself.

And the dynamic range of the Dolby Digital

and Dolby Digital Plus are operated as same as

the [On] mode.

[On]

Compress the dynamic range of the Dolby

Digital, Dolby Digital Plus or Dolby TrueHD

audio output.

[O ]

Turns o this function.

The DRC setting can be changed only when a

disc is not inserted or the unit is in complete

stop mode.

, Note

Connect wireless speakers

You can set up wireless connection manually, when

your connection is not completed. Refer to page

15.

HD AV Sync

Sometimes Digital TV encounters a delay between

picture and sound. If this happens you can

compensate by setting a delay on the sound so

that it eectively ‘waits’ for the picture to arrive:

this is called HD AV Sync. Use A D to scroll up and

down through the delay amount, which you can

set at anything between 0 and 300 ms.

Auto Volume

With Auto Volume function on, the unit

automatically adjusts the outputted volume level to

make it raised or lowered if the sound is too loud or

small. So you can enjoy the sound at comportable

level not too loud or small.

System Setting 33

System Setting

[LOCK] menu

The [LOCK] settings aect only Blu-ray Disc and

DVD playback.

To access the any features in [LOCK] settings, you

must enter the 4-digit security code you have

created.

If you have not entered a password yet, you are

prompted to do so. Enter a 4-digit password twice,

and press ENTER (b) to create a new password.

Password

You can create or change the password.

[None]

Enter a 4-digit password twice, and press

ENTER (b) to create a new password.

[Change]

Enter the current password and press ENTER

(b). Enter a 4-digit password twice, and press

ENTER (b) to create a new password.

If you forget your password

If you forget your password, you can clear it using

the following steps:

1. Remove any disc that might be in the player.

2. Select [Password] option in the [Settings] menu.

3. Use Number buttons to enter “210499”. The

password is cleared.

If you make a mistake before pressing ENTER

(b), press CLEAR. Then input the correct

password.

, Note

DVD Rating

Blocks playback of rated DVD based on their

content. (Not all discs are rated.)

[Rating 1-8]

Rating one (1) has the most restrictions and

rating eight (8) is the least restrictive.

[Unlock]

If you select [Unlock], parental control is not

active and the disc plays in full.

Blu-ray Disc Rating

Set an age limit of BD-ROM play. Use number

buttons to input an age limit for BD-ROM viewing.

[255]

All BD-ROM can be played.

[0-254]

Prohibits play of BD-ROM with corresponding

ratings recorded on them.

The [Blu-ray Disc Rating] will be applied

only for the Blu-ray disc that containing the

Advanced Rating Control.

, Note

Area Code

Enter the code of the area whose standards were

used to rate the DVD video disc, based on the list

on page 75.

System Setting34

System Setting

[OTHERS] menu

Pointer

Sets the speed and size of an USB mouse’s pointer.

[Speed]

Sets the moving speed of an USB mouse.

[Size]

Chooses the pointer size of an USB mouse.

The Pointer function is optimized for

convenience of Internet usage.

, Note

DivX(R) VOD

ABOUT DIVX VIDEO: DivX® is a digital video format

created by DivX, LLC, a subsidiary of Rovi Corporation.

This is an ocial DivX Certied® device that plays

DivX video. Visit divx.com for more information and

software tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX

Certied® device must be registered in order to play

purchased DivX Video-on-Demand (VOD) movies.

To obtain your registration code, locate the DivX

VOD section in your device setup menu. Go to vod.

divx.com for more information on how to complete

your registration.

[Register]

Displays the registration code of your player.

[Deregister]

Deactivate your player and display the

deactivation code.

All the downloaded videos from DivX(R) VOD

with this player’s registration code can only be

played on this unit.

, Note

Quick Start

This player can stay in standby mode with low

power consumption, so that the player can

instantly boot without delay when you turn on this

unit. Set this option to [On] for activating [Quick

Start] function.

y[Quick Start] function may not be available

at the moment. This function will become

available through at software update.

yIf [Quick Start] option is set to [On] and an

AC power is accidently re-connected to

the player by power failure etc., the player

automatically boots itself to be the standby

status. Before operating the player, wait for a

while until the player is in standby status.

yWhen [Quick Start] is set to [On], power

consumption will be higher than when

[Quick Start] is set to [O ].

, Note

Auto Power Off

The screen saver appears when you leave the

player in Stop mode for about 5 minutes. If you

set this option to [On], the unit automatically

turns o within 20 minutes since the Screen Saver

is displayed. Set this option to [O] to leave the

screen saver until the unit is operated by the user.

When you set [Auto Power O] function in

setting menu on, this unit will be o itself to

save electronic consumption in the case main

unit is not connected to external device and is

not used for 25 minutes.

So does this unit after six hours since Main unit

has been connected to other device using

analog input.

, Note

System Setting 35

System Setting

TV Sound Connecting

You can listen to TV sound through this unit’s

speaker automatically when TV is turned on. TV and

this unit should be connected with optical cable.

Press W to move and press A/D to select [On] or

[Off ]. Select [OK] and press ENTER (b).

Initialize

[Factory Set]

You can reset the player to its original factory

settings.

[Blu-ray Storage Clear]

Initializes the BD-Live content from the

connected USB storage.

If you reset the player to its original factory

settings using [Factory Set] option, you have to

set all the activation for the online services and

network settings again.

, Note

Software

[Information]

Displays the current software version.

[Update]

You can update the software by connecting

the unit directly to the software update server

(page 69).

SIMPLINK / ARC

-The SIMPLINK function allows you to control this

unit with LG TV’s remote control.

-The ARC function enables an HDMI capable TV

to send the audio stream to HDMI OUT of this

player.

Set this option to [On] for activating [SIMPLINK /

ARC] function (page 17).(page 17)..

4 Operating

Operating36

Operating

Sound Effect

You can select a suitable sound mode. Press SOUND

EFFECT repeatedly until the desired mode appears

on the front panel display or the TV screen. The

displayed items for the equalizer maybe dierent

depending on sound sources and eects.

[Natural Plus]: You can enjoy the natural sound

eect same as 4.1 channel.

[Natural]: You can enjoy comfortable and natural

sound.

[Bypass]: Software with multichannel surround

audio signals is played according to the way it was

recorded.

[Bass Blast]: Reinforce the bass sound eect from

front left and right speaker and subwoofer.

[Clear Voice]: This mode makes voice sound clear,

improving the quality of voice sound.

[Game]: You can enjoy more virtual sound while

playing video games.

[Night]: This may be useful when you want to

watch movies at low volumes late at night.

[Up Scaler]: When listening to MP3 les or other

compressed music, you can enhance the sound.

This mode is available only to 2 channel sources.

[Loudness]: Improves bass and treble sound.

[User EQ]: You can adjust the sound by raising or

lowering the level of specic frequency.

Setting the [User EQ]

1. Use

W/S to select the desired frequency.

2. Use

A/D to select the desired level.

Select [Cancel] option then press ENTER (b) to

cancel the setting.

Select [Reset] option then press ENTER (b) to reset

the all adjustments.

3D Sound Effect

3D Sound features create a wider spot so you can

enjoy more immersive and cinematic surround

sound. Press 3D SOUND repeatedly until the desired

mode appears on the front panel display or the TV

screen.

[3D Music]: This mode delivers outstanding

surround sound, providing a concert hall-like music

experience in your home.

[3D Movie]: This mode delivers outstanding

surround sound, providing a theater-like movie

experience in your home.

Operating 37

Operating

Home Menu Display

Using [HOME] menu

The home menu appears when you press HOME

( ). Use W/S/A/D to select a category and

press ENTER (b).

Depending on the region, the [LG Smart

World], [My Apps] service and [Search]

function may not be available.

, Note

a[Smart Share] - Displays Smart Share menu.

b[Premium] - Displays the Premium home

screen (page 60).

c[LG Smart World] - Displays LG Apps titles

provided to the unit (page 61).

d[My Apps] - Displays the [My Apps] screen

(page 62).

e[Input] - Changes input mode.

f[Settings] - Adjusts the system settings.

g[Search] - Searches for desired LG Apps and

other content.

h[Sign In] - Displays Sign In menu.

Using the Smart Share

You can play video, photo and audio content on

the unit by inserting a disc, connecting an USB

device or using home network (DLNA).

1. Press HOME ( ) to display the home menu.

2. Select [Smart Share] and press ENTER (b).

aDisplays all linked device.

bDisplays video, photo or audio content.

cDisplays the le or folder on linked device.

Operating38

Operating

Playing the Linked

Devices

Playing a disc

erot

1. Insert a disc in the disc slot.

For the most Audio CD, BD-ROM and

DVD-ROM discs, playback starts automatically.

2. Press HOME ( ) and then select [Smart Share].

3. Select disc icon.

yPlayback functions described in this manual

are not always available in every les and

media. Some functions can be restricted

depending on many factors.

yDepending on the BD-ROM titles, an USB

device connection may be needed for the

proper playback.

yUnnalized DVD-VR format discs may not

be played in this player.

ySome DVD-VR discs are made with CPRM

data by DVD RECORDER. This unit cannot

support these kinds of discs.

, Note

Playing Blu-ray 3D disc

This player can play the Blu-ray 3D disc which

contains separate views for the left and right eyes.

Preparation

In order to playback Blu-ray 3D title in

stereoscopic 3D mode, you need to:

Check your TV is 3D capable and has HDMI

input(s).

y Wear 3D glasses to enjoy the 3D experience

if it is necessary.

Check whether the BD-ROM title is the Blu-

ray 3D disc or not.

Connect an HDMI cable (Type A, High

Speed HDMI™ Cable) between the player’s

HDMI output and TV’s HDMI input.

1. Press HOME ( ), and set the [3D Mode] option

on the [Settings] menu to [On] (page 30).

2. Insert a disc in the disc slot.

The playback starts automatically.

3. Refer to the owner’s manual of your 3D-ready

TV for the further instruction.

You may need to adjust the display settings and

focus on your TV’s setting for the improved 3D

eect.

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a video

in 3D mode for inrm, child and pregnant

woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing content in 3D,

it is strongly recommended to stop the

playback and rest until you feel normal.

> Caution

Operating 39

Operating

Playing a file on disc/USB

device

yui

This player can play video, audio and photo les

contained in the disc or USB device.

1. Insert a data disc in the disc slot or connect an

USB device.

When you connect the USB device on the HOME

menu, the player plays an audio le contained in

the USB storage device automatically. If the USB

storage device is containing various types of les, a

menu for the le type selection will appear.

File loading may takes few minutes depending on

the number of content stored in the USB storage

device. Press ENTER (b) while [Cancel] is selected

to stop loading.

2. Press HOME ( ).

3. Select [Smart Share] and press ENTER (b).

4. Select the desired linked device in the category.

5. Select [Movie], [Photo] or [Music].

6. Select a file using W/S/A/D, and press

d(PLAY) or ENTER (b) to play the file.

Notes on USB device

yThis player supports USB ash drive/external

HDD formatted in FAT32 and NTFS when

accessing les (music, photo, movie). However,

for BD-Live, use the USB ash drive / external

HDD formatted in FAT32.

yThis unit can support up to 4 partitions of the

USB device.

yDo not extract the USB device during operation

(play, etc.).

yAn USB device which requires additional

program installation when you have connected

it to a computer, is not supported.

yUSB device: USB device that supports USB1.1

and USB2.0.

yVideo, audio and photo les can be played. For

details of operations on each le, refer to relevant

pages.

yRegular back up is recommended to prevent

data loss.

yIf you use an USB extension cable, USB HUB or

USB Multi-reader, the USB device may not be

recognized.

ySome USB device may not work with this unit.

yDigital camera and mobile phone are not

supported.

yUSB Port of the unit cannot be connected to PC.

The unit cannot be used as a storage device.

Operating40

Operating

Playing a file on a network

server

yui

This player can play video, audio and photo les

located in a DLNA server through your home

network.

1. Check the network connection and settings

(page 21).

2. Press HOME ( ).

3. Select [Smart Share] and press ENTER (b).

4. Select a DLNA media server in the category.

5. Select [Movie], [Photo] or [Music].

6. Select a file using W/S/A/D, and press

d(PLAY) or ENTER (b) to play the file.

yThe le requirements are described on page

71.

yThe thumbnail of the unplayable les can

be displayed, but those cannot be played

on this player.

yThe subtitle le name and video le name

have to be the same and located at the

same folder.

yThe playback and operating quality may be

aected by your home network condition.

yYou may experience connection problems

depending on your server’s environment.

yTo set your PC as a DLNA server, install the

supplied Nero MediaHome 4 on your PC

(page 41).

, Note

Operating 41

Operating

Using Home Network

Server for PC

DLNA stands for Digital Living Network Alliance,

which allows users to access video, photo and

audio les stored in server and enjoy them on TV

via home networking.

Before connecting to PC to play a le , Nero

MediaHome 4 Essentials program should be

installed on your PC.

Installing Nero MediaHome 4

Essentials

Windows

Start up your computer, and insert the supplied CD-

ROM disc into your computer’s CD-ROM drive. An

installation wizard will walk you through the quick

and uncomplicated installation process. To install

Nero MediaHome 4 Essentials, proceed as follows:

1. Close all Microsoft Windows programs and exit

any anti-virus software that may be running.

2. Insert the supplied CD-ROM disc into your

computer’s CD-ROM drive.

3. Click [Nero MediaHome 4 Essentials].

4. Click [Run] to start installation.

5. Click [Nero MediaHome 4 Essentials]. The

installation is prepared and the installation

wizard appears.

6. Click the [Next] button to display the serial

number input screen. Click [Next] to go to the

next step.

7. If you accept all conditions, click [I accept

the License Conditions] check box and click

[Next]. Installation is not possible without this

agreement.

8. Click [Typical] and click [Next]. The installation

process is started.

9. If you want to take part in the anonymous

collection of data, select the check box and click

the [Next] button.

10. Click the [Exit] button to complete the

installation.

MAC OS X

1. Start up your computer, and insert the supplied

CD-ROM disc into your computer’s CD-ROM

drive.

2. Browse the CD-ROM drive and open the

“MediaHome_4_Essentials_MAC” folder.

3. Double-click the “Nero MediaHome.dmg” image

le. The Nero MediaHome window is opened.

4. In the Nero MediaHome window, drag the Nero

MediaHome icon either to the Applications

folder within the window or to any other

desired location.

5. You can now start the application by double-

clicking the Nero MediaHome icon in the

location you dragged it to.

Sharing files and folders

On your computer, you must share the folder

contained video, audio and/or photo content to

play them on this player.

This parts explains the procedure for selecting the

shared folders on your computer.

1. Double-click the “Nero MediaHome 4 Essentials”

icon.

2. Click [Network] icon on the left and dene your

network name in the [Network name] eld. The

Network name you enter will be recognized by

your player.

3. Click [Shares] icon on the left.

4. Click [Local Folders] tab on the [Shares] screen.

5. Click [Add] icon to open the [Browse Folder]

window.

6. Select the folder containing the les you want

to share. The selected folder is added to the list

of shared folders.

7. Click [Start Server] icon to start the server.

yIf the shared folders or les are not displayed

on the player, click the folder on the [Local

Folders] tab and click [Rescan Folder] at the

[More] button.

yVisit www.nero.com for more information

and software tools.

, Note

Operating42

About Nero MediaHome 4

Essentials

Nero MediaHome 4 Essentials is a software for

sharing video, audio and photo les stored on your

computer to this unit as a DLNA-compatible digital

media server.

yThe Nero MediaHome 4 Essentials CD-

ROM is designed for PCs and should not

be inserted in this player or in any product

other than a PC.

yThe supplied Nero MediaHome 4 Essentials

CD-ROM is a customized software edition

only for sharing les and folders to this

player.

yThe supplied Nero MediaHome 4 Essentials

software does not support following

functions: Transcoding, Remote UI, TV

control, Internet services and Apple iTunes.

yThe supplied Nero MediaHome 4 Essentials

software can be downloaded at

-Windows : http://www.nero.com/

download.php?id=nmhlgewin

-Mac OS : http://www.nero.com/

download.php?id=nmhlgemac

yThis manual explains operations with

the English version of Nero MediaHome

4 Essentials as examples. Follow the

explanation referring to the actual

operations of your language version.

, Note

System requirements

Windows PC

yWindows® XP (Service Pack 2 or higher), Windows

Vista® (no Service Pack required), Windows® 7

(no Service Pack required), Windows® XP Media

Center Edition 2005 (Service Pack 2 or higher),

Windows Server® 2003

yWindows Vista® 64-bit edition (application runs

in 32-bit mode)

yWindows® 7 64-bit edition (application runs in

32-bit mode)

yHard drive space: 200 MB hard drive space for a

typical installation of Nero MediaHome stand-

alone

y1.2 GHz Intel® Pentium® III or AMD

Sempron™ 2200+ processors

yMemory: 256 MB RAM

yGraphics card with at least 32 MB video memory,

minimum resolution of 800 x 600 pixels, and 16-

bit color settings

yWindows® Internet Explorer® 6.0 or higher

yDirectX® 9.0c revision 30 (August 2006) or higher

yNetwork environment: 100 Mb Ethernet, WLAN

Macintosh

yMac OS X 10.5 (Leopard) or 10.6 (Snow Leopard)

yMacintosh computer with an Intel x86 processor

yHard drive space: 200 MB hard drive space for a

typical installation of Nero MediaHome stand-

alone

yMemory: 256 MB RAM

Operating 43

Operating

General Playback

Basic operations for video and

audio content

To stop playback

Press Z (STOP) during playback.

To pause playback

Press M (PAUSE) during playback.

Press d (PLAY) to resume playback.

To play frame-by-frame (Video)

Press M (PAUSE) during video playback.

Press M (PAUSE) repeatedly to play Frame-by-Frame

playback.

To scan forward or backward

Press c or v to play fast forward or fast reverse

during playback.

You can change the various playback speeds by

pressing c or v repeatedly.

To slow down the playing speed

While the playback is paused, press v repeatedly

to play various speeds of slow motion.

To skip to the next/previous

chapter/track/file

During playback, press C or V to go to the

next chapter/track/le or to return to the beginning

of the current chapter/track/le.

Press C twice briey to step back to the previous

chapter/track/le.

In the le list menu of a server, there may have

many types of content in a folder together. In this

case, press C or V to go to the previous or

next content with same type.

Basic operations for photo

content

To play a slide show

Press d (PLAY) to start slide show.

To stop a slide show

Press Z (STOP) while slide show.

To pause a slide show

Press M (PAUSE) while slide show.

Press d (PLAY) to re-start the slide show.

To skip to the next/previous photo

While viewing a photo in full screen, press A or D

to go to the previous or next photo.

Using the disc menu

ero

To display the disc menu

The menu screen may be displayed rst after

loading a disc which contains a menu. If you want

to display the disc menu during playback, press

DISC MENU.

Use W/S/A/D buttons to navigate through

menu items.

To display the Popup menu

Some BD-ROM discs contain Popup menu that

appears during playback.

Press TITLE/POPUP during playback, and use W/

S/A/D buttons to navigate through menu

items.

Operating44

Operating

Resume playback

eroyt

The unit records the point where you pressed the

Z (STOP) depending on the disc.

If “MZ (Resume Stop)” appears on the screen briey,

press d (PLAY) to resume playback (from the scene

point).

If you press Z (STOP) twice or unload the disc,

“Z(Complete Stop)” appears on the screen. The unit

will clear the stopped point.

yThe resume point may be cleared when a

button is pressed (for example; 1 (POWER),

B (OPEN/CLOSE), etc).

yOn BD-ROM discs with BD-J, the resume

playback function does not work.

yIf you press Z (STOP) once during BD-ROM

interactive title playback, the unit will be in

Complete Stop mode.

, Note

Last scene memory

This unit memorizes the last scene from the last disc

that is viewed. The last scene remains in memory

even if you remove the disc from the unit or switch

o the unit. If you load a disc that has the scene

memorized, the scene is automatically recalled.

yLast Scene Memory function for a previous

disc is erased once a dierent disc is played.

yThis function may not work depending on

the disc.

yOn BD-ROM discs with BD-J, the last scene

memory function does not work.

yThis unit does not memorize settings of

a disc if you switch o the unit before

commencing to play it.

, Note

Operating 45

Operating

On-Screen Display

You can display and adjust various information and

settings about the content.

To control video playback

eroy

You can control playback and set options while

watching videos.

During playback, press INFO/MENU (m).

aProgress bar - Displays the current position

and total playing time.

b[Disc Menu] - Accesses menu on a disc.

c[Title/Popup] - Displays the DVD title menu

or BD-ROM’s popup menu, if available.

d[Option] - Displays playback information.

e[Music ID] - When connected to the network,

can provide information about the current

song during video playback.

f[Repeat] - Repeats a desired section or

sequence (page 47).

g[3D] - Adjusts the 3D setting (page 51).

Displaying content information on-

screen

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b).

aTitle – Current title number/total number of

titles

bChapter – Current chapter number/total

number of chapters

cTime – Elapsed playing time/total playback

time

dAudio – Selected audio language or channel

eSubtitle – Selected subtitle.

fAngle – Selected angle/total number of

angles

gTV Aspect Ratio – Selected TV aspect ratio

hPicture Mode – Selected picture mode

iMovie Information – Select this option and

press ENTER (b) to display movie information

from Gracenote Media Database (BD-ROM/

DVD only).

Operating46

Operating

yIf no button is pressed for a few seconds,

the on-screen display disappears.

yA title number cannot be selected on some

discs.

yAvailable items may dier depending on

discs or titles.

yIf an interactive Blu-ray Disc is playing back,

some setting information is displayed on

the screen but prohibited to be changed.

yTo use the [Movie Information] option, the

player must be connected to the broadband

internet for accessing the Gracenote Media

Database.

yLG is a licensee of Gracenote technology

and is not responsible or liable for

information from the Gracenote Media

Database.

, Note

To control photo view

Controls playback and sets options while viewing

pictures in full screen.

You can control playback and set options while

viewing pictures in full screen.

While viewing pictures, press INFO/MENU (m).

a[Slideshow] - Starts or pause slide show.

b[Music] - Select the background music for the

slide show (page 51).

c[Option] - Displays slide show options.

d[Rotate] - Rotates the photo clockwise.

e[Zoom] - Displays the [Zoom] menu.

Setting the slide show option

You can use various options during viewing a

photo in full screen.

1. While viewing pictures, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

a[Speed] - Use A/D to select a delaying

speed between photos in a slide show.

b[Eect] - Use A/D to select a transition

effect between photos in a slide show.

c[Music Select] – Select the background music

for the slide show (page 51).

Operating 47

Operating

Advanced Playback

Repeat playback

erotu

Blu-ray Disc / DVD / Video les

During playback, press REPEAT (h) to select a

desired repeat mode.

A-B – Selected portion will be repeated continually.

Chapter – The current chapter will be played back

repeatedly.

Title – The current title will be played back

repeatedly.

All – All the titles or les will be played back

repeatedly.

O – Returns to normal playback.

To return to normal playback, press CLEAR.

Audio CDs/Audio les

During playback, press REPEAT (h) repeatedly to

select a desired repeat mode.

– Selected portion will be repeated continually.

(Audio CD only)

Track– The current track or le will be played

back repeatedly.

All – All the tracks or les will be played back

repeatedly.

All – All the tracks or les will be played

back repeatedly in random order.

– The tracks or les will be played back in

random order.

To return to normal playback, press CLEAR.

This function may not work on some disc or

title.

, Note

Repeating a specific portion

eroty

This player can repeat a portion you have selected.

1. During playback, press REPEAT (h) to select

[A-B] and press ENTER (b) at the beginning of

the portion you wish to repeat.

2. Press ENTER (b) at the end of the portion. Your

selected portion will be repeated continually.

3. To return to normal playback, press CLEAR.

yYou cannot select a portion less than 3

seconds.

yThis function may not work on some disc or

title.

, Note

Playing from selected time

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Select the [Time] option and then input the

required start time in hours, minutes, and

seconds from left to right.

For example, to nd a scene at 2 hours, 10

minutes, and 20 seconds, enter “21020”.

Press A/D to skip the playback 60 seconds

forward or backward.

4. Press ENTER (b) to start playback from selected

time.

yThis function may not work on some disc or

titles.

yThis function may not work depending on

the le type and ability of the DLNA server.

, Note

Operating48

Operating

Selecting a subtitle language

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [Subtitle] option.

4. Use

A/D to select desired subtitle language.

By pressing ENTER (b), you can set various

subtitle options.

5. Press BACK (1) to exit the On-Screen display.

Some discs allow you to change subtitle

selections only via the disc menu. If this is the

case, press TITLE/POPUP or DISC MENU button

and choose the appropriate subtitle from the

selections on the disc menu.

, Note

Hearing a different audio

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [Audio] option.

4. Use

A/D to select desired audio language,

audio track or audio channel.

ySome discs allow you to change audio

selections only via the disc menu. In this

case, press TITLE/POPUP or DISC MENU

button and choose the appropriate audio

from the selections on the disc menu.

yImmediately after you have switched sound,

there may be a temporary discrepancy

between the display and actual sound.

yOn BD-ROM disc, the multi audio format

(5.1CH or 7.1CH) is displayed with [MultiCH]

in the on-screen display.

yYou can select the [Audio] option on the

On-Screen display directely by pressing

AUDIO button.

, Note

Watching from a different

angle

If the disc contains scenes recorded at dierent

camera angles, you can change to a dierent

camera angle during playback.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [Angle] option.

4. Use

A/D to select desired angle.

5. Press BACK (1) to exit the On-Screen display.

Changing the TV Aspect Ratio

eoy

You can change the TV aspect ratio setting during

playback.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [TV Aspect Ratio]

option.

4. Use

A/D to select desired option.

5. Press BACK (1) to exit the On-Screen display.

Even if you change the value of the [TV Aspect

Ratio] option in On-Screen display, the [TV

Aspect Ratio] option in the [Settings] menu is

not changed.

, Note

Operating 49

Operating

Changing subtitle Code Page

If the subtitle is displayed in broken letter, you can

change the subtitle code page to view the subtitle

le properly.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [Code Page] option.

4. Use

A/D to select desired code option.

5. Press BACK (1) to exit the On-Screen display.

Changing the Picture Mode

eroy

You can change the [Picture mode] option during

playback.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [Picture Mode] option.

4. Use

A/D to select desired option.

5. Press BACK (1) to exit the On-Screen display.

Setting the [User setting] option

1. During playback, press INFO/MENU (m).

2. Select an [Option] using A/D, and press

ENTER (b)

3. Use

W/S to select the [Picture Mode] option.

4. Use

A/D to select the [User setting] option,

and press ENTER (b).

5. Use

W/S/A/D to adjust the [Picture Mode]

options.

Select [Default] option then press ENTER (b) to

reset the all video adjustments.

6. Use

W/S/A/D to select the [Close] option,

and press ENTER (b) to nish setting.

Viewing content information

The player can display the content information.

1. Select a le using W/S/A/D.

2. Press INFO/MENU (m) to display the option

menu.

The le information appears on the screen.

During video playback, you can display the le

information by pressing TITLE/POPUP.

The information displayed on the screen

may not correct comparing actual content

information.

, Note

Operating50

Operating

Changing content list view

yui

On the [Smart Share] menu, you can change the

content list view.

Press red (R) colored button repeatedly.

Selecting a subtitle ﬁle

If the subtitle le name is dierent from the video

le name, you need to select the subtitle le on the

[Movie] menu before playing the movie.

1. Use

W/S/A/D to select the subtitle le you

wish to play in the [Movie] menu.

2. Press ENTER (b).

Press ENTER (b) again to deselect the subtitle

le. Selected subtitle le will be displayed when

you play the video le.

yIf you press Z (STOP) during playback, the

subtitle selection is cancelled.

yThis function is not available for playing le

on a server via home network.

, Note

Operating 51

Operating

Listening to music during slide

show

You can display photo les while listening to audio

les.

1. While viewing a photo in full screen, press INFO/

MENU (m) to display the option menu.

2. Select an [Option] using A/D, and press

ENTER (b).

3. Use

W/S to select [Music Select] option, and

press ENTER (b) to display the [Music Select]

menu.

4. Use

W/S to select a device, and press ENTER

(b).

Available device may differ depending on the

location of the current photo file.

Photo location Available Device

Disc, USB Disc, USB

DLNA server DLNA server

5. Use

W/S to select a file or a folder you wish to

play.

Select g and press ENTER (b) to display the

upper directory.

When selecting audio le from a server, folder

selection is not available. Only le selection is

available.

, Note

6. Use

D to select [OK], and press ENTER (b) to

complete music selection.

Converting 2D content to 3D

eroy

This function allows you to convert 2D content to

3D. You can adjust 3D’s depth and distance on the

[3D] option while playing back.

1. During playback, press INFO/MENU (m).

2. Select a [3D], and press ENTER (b).

3. Use

W/S/A/D to select desired options.

Select [Default] option then press ENTER (b) to

reset the all adjustments.

4. Use

W/S/A/D to select the [Close] option,

and press ENTER (b) to nish setting.

yWhen you have set to Ultra HD resolution,

if you select the [On] in [3D], the Ultra HD

resolution is automatically changed to the

original resolution.

yMovie les which is upper 30 fps (frame

rate) may not be converted to 3D.

, Note

Operating52

Operating

Advanced Features

Wi-Fi Direct™

Connecting to a Wi-Fi Direct™

certified device

yui

This player can play movie, music and photo les

located in a Wi-Fi Direct™ certied device. The Wi-Fi

Direct™ technology make the player to be directely

connected to a Wi-Fi Direct™ certied device

without connecting to a network device such as an

access point.

On Wi-Fi Direct™ certied device

1. Turn on the Wi-Fi Direct™ certied device and

run its Wi-Fi Direct function.

2. Run DLNA application on the device.

On your player

3. Select [NETWORK] option in the [Settings]

menu then press ENTER (b).

4. Select [Wi-Fi Direct] option, and press ENTER

(b).

5. Select a Wi-Fi Direct™ device on the list using

W/S, and press ENTER (b).

Wi-Fi Direct™ connection will be proceeded.

Follow the procedure on the screen.

If you want to rescan available Wi-Fi Direct™

device, Select the [Refresh List] and press ENTER

(b).

To select a server from the device list, files or

folders must be shared by DLNA server from the

connected Wi-Fi Direct™ device.

6. Select [Movie], [Photo] or [Music] using W/S/

A/D, and press ENTER (b).

7. Select a le using W/S/A/D, and press

ENTER (b) to play the le.

yFor the purpose of the better transmission,

placing the player from the Wi-Fi Direct™

certied server as close as possible.

yThis unit can connect only 1 device at a

time. Multiple connection is not available.

yIf this player and a Wi-Fi Direct™ device

are connected to the different local area

network, Wi-Fi Direct™ connection may not

available.

yIf a Wi-Fi Direct™ certified device is not in

Wi-Fi direct standby mode, this product can

not find the device.

yWhen you connect a Wi-Fi Direct™

certified device to your player, PIN network

connection is not supported.

yThis product cannot connect to a Wi-Fi

direct™ device which is in Group Owner

mode.

, Note

Operating 53

Operating

Enjoying Miracast™

You can mirror Miracast certied device’s screen

and sound onto TV screen through your player

wirelessly.

On Miracast™ certied device

1. Turn on the Miracast certied device and run its

[Miracast] function.

On your player

2. Press HOME ( ).

3. Select [Miracast] and press ENTER (b).

4. Select a Miracast device on the list using W/S,

and press ENTER (b).

Miracast function will be proceeded

automatically.

If you want to rescan available Miracast device,

select [Refresh List] and press ENTER (b).

yFor the purpose of the better mirroring,

place Miracast certied device from the

player as close as possible.

yThis unit can connect only 1 device at a

time. Multiple connection is not available.

yWhile mirroring, Wireless network or Wi-Fi

Direct cannot be used simultaneously.

yIf a Miracast certified device is not in

[Miracast] standby mode, this player cannot

find the device.

yDepending on your wireless network

condition, mirroring may be unstable.

yWhile mirroring, the screen may be cut o

depending on your TV’s setting. In this case,

please adjust the display settings on your

TV.

, Note

Operating54

Operating

Enjoying BD-Live™

BD-ROM supporting BD-Live that has a network

extension function allows you to enjoy more

functions such as downloading new movie trailers

by connecting this unit to the internet.

1. Check the network connection and settings

(page 21).

2. Insert an USB storage device to the USB port.

An USB storage device is needed to download

bonus content.

3. Press HOME ( ), and set the [BD-LIVE

connection] option on the [Settings] menu

(page 28).

Depending on a disc, the BD-Live function may

not be operated if [BD-LIVE connection] option

is set to [Partially Permitted].

4. Insert a BD-ROM with BD-Live.

The operations may dier depending on the

disc. Refer to the manual supplied with the disc.

Do not extract the connected USB device

while content is being downloaded or a

Blu-ray disc is still in the disc slot. Doing so

may damage the connected USB device and

BD-Live features may not operate properly

with the damaged USB device anymore. If the

connected USB device seems damaged from

such an action, you can format the connected

USB device from the PC and reuse it with this

player.

> Caution

ySome BD-Live content may be restrictively

accessed in some territories by content

provider’s own decision.

yIt may take up to several minutes to load

and start enjoying BD-Live content.

yFor BD-Live, use the USB ash drive /

external HDD formatted in FAT32 only.

, Note

LG AV Remote

You can control this player with your iPhone

or Android phone via your home network. This

player and your phone must be connected to your

wireless network device such as access point. Visit

“Apple iTunes” or “Google Android Market (Google

Play Store)” for detailed information of “LG AV

Remote”.

Operating 55

Operating

Audio CD recording

You can record one desired track or all of the tracks

in Audio CD to an USB storage device.

1. Insert an USB storage device to the USB port.

2. Insert an Audio CD into the player.

The playback starts automatically.

3. Press (X) REC button to start [CD Recording].

Stop mode During

playback

Recording

track All of the tracks playing track

Recording

time 4X speed normal speed

Recording from FM radio or

PORTABLE source

You can record from FM radio or PORTABLE source

to an USB storage device.

1. Insert an USB storage device to the USB port.

2. In FM radio mode, tune to the desired radio

station (See “Radio Operations” on page 59)

or in PORTABLE mode, start playback from the

external source.

3. Press (X) REC button on the remote control.

-The recording is saved as a le in “EXT_REC”

folder.

yFor recording, use the USB ash drive /

external HDD formatted in FAT32 only.

yAudio track is recorded to an audio le with

192 kbps. FM radio and PORTABLE source

are recorded to an audio le with 128 kbps.

yAudio CD recording time in the table is

approximate.

yActual recording time for USB storage

device varies depending on the USB storage

device’s ability.

yMake sure that there is minimum of 50 MB

free space is needed when recording into

the USB storage device.

yThe length of the recording source should

be longer than 20 seconds for the proper

recording.

yDo not turn o this player or extract the

connected USB storage device during the

recording.

, Note

The recording or copying features on this

player are provided for your personal and

non-commercial use. The making of

unauthorized copies of copy-protected

material, including computer programs, les,

broadcasts and sound recordings, may be an

infringement of copyrights and constitute a

criminal oense. This equipment should not be

used for such purposes. LG expressly disclaims

any responsibility for illegal distribution or

use of unauthorized content in commercial

purpose.

Be Responsible

Respect Copyrights

> Caution

Operating56

Operating

Viewing information from

Gracenote Media Database

The player can access the Gracenote Media

Database and load the music information so that

Track name, Artist Name, Genre and other text

information can be displayed on the list.

Audio CD

When you insert an Audio CD, the player starts

playback automatically and loads the music title

from the Gracenote Media Database.

If there is no music information from the database,

music titles will not appear on the screen.

Music ﬁle

Select a music le using W/S/A/D and press

INFO/MENU (m) or MUSIC ID.

The player accesses to Gracenote Media Database

for the music information.

Blu-ray Disc/DVD/Movie ﬁle

1. While listening to a music from the movie being

played, press INFO/MENU (m).

2. Select a [Music ID] using A/D, and press

ENTER (b).

The player starts loading the music information

from the Gracenote Media Database.

You can also start loading the music

information directly by pressing MUSIC ID.

, Note

yThe player must be connected to the

broadband internet for accessing the

Gracenote Media Database.

yIf the music information is not in the

Gracenote Media Database, message

appears on the screen.

yDepending on the cases, it will takes a few

minutes to load music information from the

Gracenote Media Database.

yInformation may be displayed in broken

letters, if the language you selected is not

available on the Gracenote Media Database.

yThis function is not available for on-line

content and content in DLNA servers.

yLG is a licensee of Gracenote technology

and is not responsible or liable for

information from the Gracenote Media

Database.

yAudio CDs that users made for their only

private purposes cannot be supported in

this feature because they are not in the

Gracenote Media Database.

ySupported music le extensions :

mp3, wma, m4a, wav

, Note

Operating 57

Operating

Playing the iPod

You can enjoy the sound with your iPod. For details

about iPod, refer to the iPod’s User Guide.

Preparation

Before connecting the iPod, turn this unit o and

reduce the volume of this unit to its minimum.

Use the iPod cable supplied with your iPod.

, Note

1. Connect the iPod to the USB port.

If you turn this unit on, your iPod is

automatically turned on and recharging starts.

When you connect the iPod on the HOME

menu, the player plays a music automatically.

2. Select a le using W/S/A/D, and press

ENTER (b) to play the le.

Enjoying iPod on the screen

1. Connect the iPod to the USB port.

2. Press HOME ( ).

3. Select [Smart Share] using A/D, select the

iPod on the menu.

4. Select a le using W/S/A/D, and press

ENTER (b) to play.

Power scroll

You can search easily a content by power scroll

on the screen.

Select a power scroll using D and select the

initial of the desired content.

Press REPEAT (h) to select a desired repeat

mode :Track (;), All (:), Shuffle All (l :),

Shuffle (l), Off (No display)

If the iPod’s OSD language is selected to

simple chinese, the power scroll function is not

operated correctly.

, Note

Enjoying the iPod IN mode

Please control directly from your iPod. You can

control your music in your iPod with the supplied

remote control.

1. Connect the iPod to the USB port.

If you turn this unit on, your iPod is

automatically turned on and recharging starts.

2. Press FUNCTION to select iPod in mode.

W/S/A/D Selects an option in the menu.

ENTER (b) Starts playback the music.

M or d (PLAY)

To pause while it is playing. To

resume playing, press M or d

(PLAY) again.

(Press and hold)

c/vFast-forward or rewind a song

C/VSkip the playback forward or

backward .

Operating58

Operating

yAn error message “CHECK” or “Connected

iPod model is not supported.” appears when:

-your iPod is not available for the function

to be operated.

yAn error message “CHECK” or “Please update

your iPod’s software.” appears when:

-your iPod has an old software version.

/ Update your iPod software to latest

version.

yIf this unit displays an error message, follow

the message. An error message “CHECK” or

“Please check your iPod.” appears when:

-the communication between this unit

and your iPod is failed.

/ Connect & reconnect your iPod in this

unit.

-your iPod is not connected rmly.

-this unit recognises your iPod as

unknown device.

yYour iPod is exceptionally low on power.

/ The battery needs to be charged.

/ If you charge the battery while iPod

is extremely low in power, it may take

longer to charge.

yCompatibility with your iPod may vary

depending on the type of your iPod.

yiPod touch, iPhone and iPad have any

dierence in operation other than iPod.

You may need any additional control to use

them with this unit. (e.g. “slide to unlock”)

yIf you use an application, make a call, or

send and receive SMS text message, etc. on

iPod touch, iPhone or iPad, disconnect it

from to the USB port of this unit and then

use it.

yDepending on your iPod’s software version,

it may not be possible to control your iPod

from this unit. We recommend installing the

latest software version.

yThis unit supports the models as follows.

- iPad nano 4G, 5G, 6G, 7G

- iPod touch 3G, 4G, 5G

- iPhone 3GS, 4, 4S, 5

- iPad, iPad2, iPad3, iPad4

- iPad mini

yIf you have a problem with your iPod, please

visit www.apple.com/support/ipod.

, Note

Operating 59

Operating

Radio Operations

Be sure that the antenna is connected.

(Refer to the page 19)

Listening to the radio

1. Press FUNCTION until TUNER (FM) appears in

the display window. The last received station is

tuned in.

2. Press and hold TUNING (-/+) for about two

seconds until the frequency indication starts to

change. Scanning stops when the unit tunes in

a station. Or Press TUNING (-/+) repeatedly.

3. Adjust the volume by pressing VOL (+/-).

Presetting the Radio Stations

You can preset 50 stations for FM.

Before tuning, make sure that you have turned

down the volume.

1. Press FUNCTION until the TUNER (FM) appears

in the display window.

2. Select the desired frequency by using TUNING

(-/+).

3. Press ENTER (b) a preset number will ash in

the display window.

4. Press PRESET (-/+) to select the preset number

you want.

5. Press ENTER (b). The station is stored.

6. Repeat the steps 2 to 5 to store other stations.

Deleting a saved station

1. Press PRESET (- / +) to select a preset number

you want to delete.

2. Press CLEAR, the preset number will blink in the

display window.

3. Press CLEAR again, to delete the selected preset

number.

Deleting all the saved stations

Press and hold CLEAR for two seconds.

“ERASE ALL” will ash up. Press CLEAR again. Then all

the saved stations are deleted.

Improving poor FM reception

Press B (blue) (MONO/STEREO) colored button on

the remote control. This will change the tuner from

stereo to mono and usually improve the reception.

See information about a radio

station

The FM tuner is supplied with the RDS (Radio Data

System) facility. This shows information about the

radio station being listened to. Press RDS repeatedly

to cycle through the various data types:

(Programme Service Name)

The name of the channel will appear in

the display

PTY

(Programme Type Recognition)

The programme type (e.g. Jazz or News)

will appear in the display.

(Radio Text)

A text message contains special

information from the broadcast station.

This text may scroll across the display.

(Time controlled by the channel)

This shows the time and date as

broadcast by the station.

Operating60

Operating

Using an USB

keyboard or mouse

You can connect an USB keyboard and/or mouse

to type text and navigate menus.

1. Connect an USB keyboard or mouse to the USB

port.

2. Use the keyboard to type text, or the mouse to

navigate menus.

The following keyboards and mice are

recommended.

-Logitech Wireless Combo MK520

-Logitech Wireless Combo MK320

-Logitech Wireless Combo MK260

-Microsoft Wireless Desktop 5000

-Microsoft Wireless Desktop 3000

-Microsoft Wireless Desktop 2000

-Microsoft Wireless Desktop 800

, Note

Using the Premium

You can use various content services via Internet

with the Premium feature.

1. Check the network connection and settings

(page 21).

2. Press HOME ( ).

3. Select the [Premium] using A/D, and press

ENTER (b).

4. Select an online service using W/S/A/D,

and press ENTER (b).

yFor detailed information of each service,

contact to the content provider or visit

support link of the service.

yThe content of Premium services and

service related information, including user

interface, is subject to changes. Please refer

to the web site of each service for most up-

to-date information.

yUsing Premium features with wireless

network connection may result in improper

streaming speed by interference from

household devices that are using radio

frequencies.

yIf you want to change the country setting,

go to [Settings] > [NETWORK] > [Smart

Service Setting] > [Country Setting]. Select

[Manual] and press ENTER (b) on [Country

Setting] menu.

, Note

Operating 61

Operating

Using the LG Smart

World

You can use the LG application services on

this player via Internet. You can easily nd and

download various applications from LG Smart

World.

1. Check the network connection and settings

(page 21).

2. Press HOME ( ).

3. Select the [LG Smart World], and press ENTER

(b).

4. Select a category using A/D, and press ENTER

(b).

5. Use

W/S/A/D to select an application, and

press ENTER (b) to display the information.

6. Press ENTER (b) while [Install] icon is

highlighted. The application will be installed to

the player.

To install an application to the player, user

needs to sign in. Refer to page 61 for more

information of signning in.

7. Press red (R) colored button to display the [My

Apps] screen.

8. Select the installed application and press ENTER

(b) to excute it.

yDepending on the region, the [LG Smart

World], [My Apps] service and [Search]

function may not be available.

yTo install a paid application, you need to be

a paid member. Visit www.lgappstv.com for

more information.

, Note

Signing in

To use the [LG Smart World] feature, you need to

1. On the home menu, select [ ] icon and press

ENTER (b).

2. Fill the [ID] and [Password] field using the virtual

keyboard.

If you do not have an account, press red (R)

colored button to register.

3. Use

W/S/A/D to select [OK], and press

ENTER (b) to sign in with your account.

If you select the [Auto Sign In] check box,

your ID and password are remembered and

automatically signed in without entering them.

To view the information of your account and

applications, select [ ] icon and press ENTER

(b) on the home menu, and select [My Page]

option.

, Note

Operating62

Operating

Searching online content

If you are having diculties nding specic content

from online services, you can use the all-in-one

search function by entering keywords in the [ ]

menu.

1. Press HOME ( ).

2. Select the [ ] icon on the home menu using

W/S/A/D, and press ENTER (b).

The [ ] menu appears on the screen.

3. Press ENTER (b). The virtual keyboard appears

automatically.

4. Use

W/S/A/D to select letters then press

ENTER (b) to confirm your selection on the

virtual keyboard.

5. When you finish entering the keyword, select

[] and press ENTER (b) to display search result.

6. Use

W/S/A/D to select a desired content,

and press ENTER (b) to move to the selected

content directly.

yDepending on the region, the [LG Smart

World], [My Apps] service and [Search]

function may not be available.

yThe search function does not search

content in every online services. It works

only in certain online services.

, Note

Using the My Apps

You can move or delete an installed application in

the [My Apps] menu.

1. Press HOME ( ).

2. Select the [My Apps], and press ENTER (b).

3. On the [My Apps] menu, press red (R) colored

button.

Move an application

1. Select an application, and press ENTER (b) to

display the options.

2. Use

W/S to select [Move], and press ENTER

(b).

3. Use

W/S/A/D to select a position you want

to move to, and press ENTER (b).

Delete an application

1. Select an application, and press ENTER (b) to

display the options.

2. Use

W/S to select [Delete], and press

ENTER(b).

3. Use

A/D to select [Yes], and press ENTER (b)

to confirm.

Depending on the region, the [LG Smart

World], [My Apps] service and [Search]

function may not be available.

, Note

Operating 63

Operating

Using Bluetooth

technology

About Bluetooth

Bluetooth® is wireless communication technology

for short range connection.

The available range is within 10 meters.

(The sound may be interrupted when the

connection interfered by the other electronic wave

or you connect the bluetooth in the other rooms.)

Connecting individual devices under

Bluetooth® wireless technology does not incur any

charges. A mobile phone with

Bluetooth® wireless technology can be operated

via the Cascade if the connection was made via

Bluetooth® wireless technology.

Available Devices : Mobile phone, MP3, Laptop,

PDA

Bluetooth Profiles

In order to use Bluetooth wireless technology,

devices must be able to interpret certain profiles.

This unit is compatible with following profile.

A2DP (Advanced Audio Distribution Profile)

Listening to music stored on

the Bluetooth devices

Pairing your unit and Bluetooth

device

Before you start the pairing procedure, make

sure the Bluetooth feature is turned on in to your

Bluetooth device. Refer to your Bluetooth device’s

user guide. Once a pairing operation is performed,

it does not need to be performed again.

1. Select the Bluetooth function by using the

FUNCTION.

Appears “BT READY” in display window.

2. Operate the Bluetooth device and perform the

pairing operation. When searching for this unit

with the Bluetooth device, a list of the devices

found may appear in the Bluetooth device

display depending on the type of Bluetooth

device.Your unit appears as “LG-HTS”.

3. When this unit successfully paired with your

Bluetooth device, Bluetooth LED of this unit

lights up and “BTPAIRED” appears in the display

window.

Depending on the Bluetooth device type,

some device have a dierent pairing way.

, Note

4. Listen to music.

To play a music stored on your Bluetooth device,

refer to your Bluetooth device’s user guide.

If you change the function of the unit, the

Bluetooth function is disconnected, operate

pairing again.

, Note

Operating64

Operating

yThe sound may be interrupted when

the connection interfered by the other

electronic wave.

yYou cannot control the Bluetooth device

with this unit.

yPairing is limited one Bluetooth device per

one unit and multi-pairing is not supported.

yAlthough the distance between your

Bluetooth and the set is less than 10m, there

are obstacles between both, your Bluetooth

device cannot be connected.

yDepending on the type of the device,

you may not be able to use the Bluetooth

function.

yWhen not connected the Bluetooth, “BT

READY” appears on the display window.

yThe Electrical malfunction due to devices

using same frequency such as Medical

equipment, Microwaves or wireless

LAN devices, the connection will be

disconnected.

yWhen someone stands and interrupts

communication between Bluetooth device

and the player, the connection will be

disconnected.

yIf the gotten away of the distance between

Bluetooth and the unit, the sound quality

is lower and lower the connection will

disconnect when the space between the

Bluetooth and the unit gets out of the

operating range of Bluetooth.

yThe device with Bluetooth wireless

technology is disconnected, if you turn o

the main unit or put the device away from

the main unit more than 10m.

, Note

5 Troubleshooting

Troubleshooting 65

Troubleshooting

General

Symptom Cause & Solution

The Power does not turned on.

yPlug the power cord into the wall outlet securely.

The unit does not start

playback.

yInsert a playable disc. (Check the disc type, color system, and regional

code.)

yPlace the disc with the playback side down.

yClean the disc.

yCancel the Rating function or change the rating level.

The connected USB storage

device is not recognized.

yTry using dierent USB cable, some USB cables may not support

enough current for normal USB operation.

yIf you use an USB extension cable or USB HUB, the USB devices may

not be recognized.

yAn USB device which requires additional program installation when

you have connected it to a computer is not supported.

yThis unit supports only USB Flash Drive and USB External HDD with

FAT32 or NTFS format.

The angle cannot be changed.

yMulti-angles are not recorded on the DVD Video being played.

Cannot play video, photo or

audio les.

yThe les are not recorded in a format that the unit can play.

yThe unit does not support the codec of the video le.

The remote control does not

work properly.

yThe remote control is not pointed at the remote sensor of the unit.

yThe remote control is too far from the unit.

yThere is an obstacle in the path of the remote control and the unit.

yThe batteries in the remote control are exhausted.

The unit is plugged in, but the

power will not turn on or o.

You can reset the unit as follows.

yUnplug the power cord, wait at least ve seconds, and then plug it in

again.

The unit is not operating

normally.

Troubleshooting66

Troubleshooting

Network

Symptom Cause & Solution

BD-Live feature does not work.

yThe connected USB storage may not have enough space. Connect

the USB storage with at least 1GB free space.

yEnsure that the unit is correctly connected to the local area network

and can access the internet (page 21).

yYour broadband speed may not fast enough to use the BD-Live

features. Contact your Internet Service Provider (ISP) and increase the

broadband speed is recommended.

yThe [BD-LIVE connection] option in the [Settings] menu is set to

[Prohibited]. Set the option to [Permitted].

Streaming video services (such

as YouTube™, etc.) are often

stopped or “buer” during

playback.

yYour broadband service speed may not be fast enough to stream

video services. Contact your Internet Service Provider (ISP) and

increase the broadband speed is recommended.

Media servers are not displayed

on the device list.

yThe rewall or anti-virus software on your media server is running.

Turn o the rewall or anti-virus software running on your media

server.

yThe player is not connected to the local area network that your media

server is connected.

Cannot connect the player to

the access point or wireless

LAN router.

yThe wireless communication may be interrupted from household

devices that are using radio frequencies. Move the player away from

them.

Access point is not displayed

on the “Access point name” list.

yThe access point or wireless LAN router may not broadcast its SSID.

Set your access point to broadcast its SSID through your computer.

yYour network device such as access point may not set with available

frequency range and channel that this player can support.

Try setting the frequency range and channel on the network device

setting.

Troubleshooting 67

Troubleshooting


Symptom Cause & Solution

There is no picture.

ySelect the appropriate video input mode on the TV so the picture

from the unit appears on the TV screen.

yConnect the video connection securely.

yCheck the [HDMI Color Setting] in the [Settings] menu is set to the

appropriate item that conforms to your video connection.

yYour TV may not support the resolution you have set on the player.

Change the resolution that your TV accepts.

yThe player’s HDMI OUT jack is connected to a DVI device that does

not support copyright protection.

Picture noise appears

yYou are playing a disc recorded in a colour system that is dierent

from your TV.

ySet the resolution which your TV accepts.

Blu-ray 3D disc playback does

not output 3D views.

yConnect the player to your TV with HDMI cable (Type A, High Speed

HDMI™ Cable).

yYour TV may not support “HDMI 3D mandatory format”.

yThe [3D Mode] option in the [Settings] menu is set to [O ].

Set the option to [On].

Sound

Symptom Cause & Solution

There is no sound or the sound

is distorted.

yThe unit is in scan, slow motion, or pause mode.

yThe sound volume is low.

Customer Support

You can update the Player using the latest software to enhance the products operation and/or add new

features. To obtain the latest software for this player (if updates have been made), please visit

http://www.lg.com or contact LG Electronics customer care center.

Open Source Software Notice

To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit

http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are

available to download with the source code.

6 Appendix

Appendix68

Appendix

Controlling a TV with

the Supplied Remote

Control

You can control your TV using the buttons below.

By pressing You can

1 (TV POWER) Turn the TV on or o.

AV/INPUT

Switch the TV’s input source

between the TV and other

input sources.

PR/CH W/S Scan up or down through

memorized channels.

VOL +/– Adjust the volume of the TV

Depending on the unit being connected, you

may not be able to control your TV using some

of the buttons.

, Note

Setting up the remote to

control your TV

You can operate your TV with the supplied remote

control.

If your TV is listed in the table below, set the

appropriate manufacturer code.

1. While holding down 1 (TV POWER) button, and

press the manufacturer code for your TV with

the numerical buttons (see the table below).

Manufacturer Code number

LG 1(Default), 2

Zenith 1, 3, 4

GoldStar 1, 2

Samsung 6, 7

Sony 8, 9

Hitachi 4

2. Release the 1 (TV POWER) button to complete

setting.

Depending on your TV, some or all buttons may not

function on the TV, even after entering the correct

manufacturer code. When you replace the batteries

of the remote, the code number you have set may

be reset to the default setting. Set the appropriate

code number again.

Appendix 69

Appendix

Network Software

Update

Network update notification

From time to time, performance improvements

and/or additional features or services may be

made available to units that are connected to a

broadband home network. If there is new software

available and the unit is connected to a broadband

home network, the player will inform you about the

update as follows.

Option 1:

1. The update menu will appear on the screen

when you turn off the player.

2. Use

A/D to select a desired option and then

press ENTER (b).

[OK] Starts the software update.

[Cancel] Exits the update menu and turns

the power o.

Option 2:

If the software update is available from the update

server, the “Update” icon appears in the Home

menu. Press blue (B) colored button to start the

update procedure.

Software update

You can update the player using the latest software

to enhance the products operation and/or add

new features. You can update the software by

connecting the unit directly to the software update

server.

yBefore updating the software in your player,

remove any disc and USB Device from the

player.

yBefore updating the software in your player,

turn the player o and then turn it back on.

yDuring the software update procedure,

do not turn o the player or disconnect

AC power, or do not press any button.

yIf you cancel the update, turn o the power

and turn it on for stable performance.

yThis unit cannot be updated to previous

software version.

, Note

1. Check the network connection and settings

(page 21).

2. Select [Software] option in the [Settings] menu

then press ENTER (b).

3. Select [Update] option, and press ENTER (b).

The player will check for the newest update.

yPressing ENTER (b) while checking for the

update will end the process.

yIf there is no update available, the Message,

“No update is found.” appears. Press ENTER

(b) to return to the [Home Menu].

, Note

Appendix70

Appendix

4. If newer version exists, the message “Do you

want to download it?” appears.

5. Select [OK] to start update. (Selecting [Cancel]

will end the update.)

6. The player starts downloading the newest

update from the server. (Downloading will

takes several minutes depending on your home

network condition)

7. When downloading is completed, the message,

“Download is complete. Do you want to

update?” appears.

8. Select [OK] to start updating. (Selecting [Cancel]

will end the update and downloaded file will

not be re-usable. To update software the next

time, the software update procedure has to be

started from the beginning again.)

Do not turn o the power during the software

update.

> Caution

9. When update is completed, the power will be

turned off automatically in a few seconds.

10. Turn the power back on. The system now

operates with the new version.

The Software Update function may not

work properly depending on your internet

environment. In this case, you can obtain

the latest software from the authorized LG

Electronics Service Center then update your

player. Refer to “Customer Support” on page

67.

, Note

Appendix 71

Appendix

Additional Information

File requirement

Video files

File

Location

File

Extension Codec Format Audio

Format Subtitle

Disc,

USB

“.avi”, “.mpg”, “.divx”,

“.mpeg”, “.mkv”, “.mp4”,

“.asf”, “.wmv”, “.m4v”

(DRM free), “.vob”,

“.3gp”, “.mov”, “.trp”,

“.m2t”, “.mpe”, “.m1v”,

“.m2v”, “.wm”, ”.v”, “.ts”,

“.dat”

DIVX 3.11, DIVX4,

DIVX5. DIVX6 (standard

playback only)

XVID, MPEG1 SS, H.264/

MPEG-4 AVC, MPEG2

PS, MPEG2 TS, VC-1 SM

(WMV3)

Dolby

Digital,

DTS, MP3,

WMA,

AAC, AC3

SubRip (.srt / .txt), SAMI

(.smi), SubStation Alpha

(.ssa/.txt), MicroDVD

(.sub/.txt), VobSub (.sub),

SubViewer 1.0 (.sub),

SubViewer 2.0 (.sub/.

txt), TMPlayer (.txt), DVD

Subtitle System (.txt)

DLNA

“.avi”, “.mpg”, “.divx”,

“.mpeg”, “.mkv”, “.mp4”,

“.asf”, “.wmv”, “.m4v”

(DRM free), “.mov”, “.trp”,

“.m2t”, “.mpe”, “.m1v”,

“.m2v”, ”.v”, “.ts”

DIVX 3.11, DIVX4,

DIVX5. DIVX6 (standard

playback only)

XVID, MPEG1 SS, H.264/

MPEG-4 AVC, MPEG2

PS, MPEG2 TS, VC-1 SM

(WMV3)

Dolby

Digital,

DTS, MP3,

WMA,

AAC, AC3

SubRip (.srt / .txt), SAMI

(.smi), SubStation Alpha

(.ssa/.txt), MicroDVD (.sub/.

txt), SubViewer 1.0 (.sub),

SubViewer 2.0 (.sub/.

txt), TMPlayer (.txt), DVD

Subtitle System (.txt)

Audio files

File

Location

File

Extension Sampling Frequency Bitrate Note

Disc,

USB

“mp3”, “.wma”,

“.wav”, “.m4a”

(DRM free),

“.ac”

within 32 - 48 kHz

(WMA), within 16 - 48

kHz (MP3)

within 32 - 192 kbps

(WMA), within 32 - 320

kbps (MP3)

Some wav les are

not supported on

this player.

DLNA

“mp3”, “.wma”,

“.wav”, “.m4a”

(DRM free)

within 32 - 48 kHz

(WMA), within 16 - 48

kHz (MP3)

within 32 - 192 kbps

(WMA), within 32 - 320

kbps (MP3)

Some wav les are

not supported on

this player.

Photo files

File

Location

File

Extension

Recommended

Size Note

Disc,

USB,

DLNA

“.jpg”, “.jpeg”,

“.png”, “.gif”

Less than 4,000 x 3,000 x 24 bit/pixel

Less than 3,000 x 3,000 x 32 bit/pixel

Progressive and lossless

compression photo image les

are not supported.

ySupplied bundle DLNA server for Macintosh edition has limitations in le compatibility, such as ASF, WMA

and WMV.

Appendix72

Appendix

yThe le name is limited to 180 characters.

yMaximum les/Folder: Less than 2000 (total

number of les and folders)

yDepending on the size and number of the

les, it may take several minutes to read the

content on the media.

yFile compatibility may dier depending on

the server.

yBecause the compatibility on DLNA server

are tested on the bundle DLNA server

(Nero MediaHome 4 Essentials Windows

edition) environment, le requirements and

playback functions may dier depending on

media servers.

yThe le requirements on page 71 are

not always compatible. There may have

some restrictions by le features and media

server’s ability.

yPlaying video subtitle les are only available

on DLNA media server created by supplied

Nero MediaHome 4 Essentials software on

this player package.

yThe les from removable media such as USB

drive, DVD-drive etc. on your media server

may not be shared properly.

yThis unit cannot support the ID3 Tag

embedded MP3 le.

yThe total playback time of audio le

indicated on the screen may not correct for

VBR les.

yHD video les contained on the CD/DVD or

USB 1.0/1.1 may not played properly.

Blu-ray Disc or USB 2.0 are recommended to

play back HD video les.

yThis player supports H.264/MPEG-4 AVC

prole Main, High at Level 4.1. A le with

higher level may not be supported.

yThis player does not support les that are

recorded with GMC*1 or Qpel*2.

*1 GMC – Global Motion Compensation

*2 Qpel – Quarter pixel

, Note

yA “avi” le which is encoded “WMV 9 codec”

is not supported.

yThis player supports UTF-8 les even it

contains Unicode subtitle content. This

player can not support the pure Unicode

subtitle les.

yDepending on the types of le or ways of

recording, it may not play back.

yA disc which was recorded by multi-session

on normal PC is not supported on this

player.

yTo be playback a video le, video le name

and Subtitle le name must be the same.

yWhen you play a video le with a extension

such as “.ts”, “.m2ts”, “.mts”, “.tp”, “.Trp” or “.m2t”,

your player may not support subtitle les.

yThe total playback time of audio le

indicated on the screen may not correct for

VBR les.

yVideo / Audio codec compatibility may

dier depending on video le.

, Note

AVCHD (Advanced Video

Codec High Definition)

yThis player can playback AVCHD format discs.

These discs are normally recorded and used in

camcorders.

yThe AVCHD format is a high denition digital

video camera format.

yThe MPEG-4 AVC/H.264 format is capable of

compressing images at higher eciency than

that of the conventional image compressing

format.

yThis player can playback AVCHD discs using

“x.v.Color” format.

ySome AVCHD format discs may not play

depending on the recording condition.

yAVCHD format discs need to be nalized.

y“x.v.Color” oers a wider color range than normal

DVD camcorder discs.

Appendix 73

Appendix

About DLNA

This Player is a DLNA Certied digital media player

that can display and play video, photo and audio

content from your DLNA-compatible digital media

server (PC and Consumer Electronics).

The Digital Living Network Alliance (DLNA) is a

cross-industry organization of consumer electronics,

computing industry and mobile device companies.

Digital Living provides consumers with easy sharing

of digital media through your home network.

The DLNA certication logo makes it easy

to nd products that comply with the DLNA

Interoperability Guidelines. This unit complies with

DLNA Interoperability Guidelines v1.5.

When a PC running DLNA server software or

other DLNA compatible device is connected to

this player, some setting changes of software or

other devices may be required. Please refer to the

operating instructions for the software or device for

more information.

Certain system requirements

For high denition video playback:

yHigh denition display that has HDMI input jack.

yBD-ROM disc with high denition content.

yHDMI or HDCP capable DVI input on your display

device is required for some content (as specied

by disc authors).

Compatibility notes

yBecause BD-ROM is a new format, certain disc,

digital connection and other compatibility issues

are possible. If you experience compatibility

problems, please contact an authorized

Customer Service Center.

yThis unit allows you to enjoy functions such

as picture-in-picture, secondary audio and

Virtual packages, etc., with BD-ROM supporting

BONUSVIEW (BD-ROM version 2 Prole 1 version

1.1). Secondary video and audio can be played

from a disc compatible with the picture-in-

picture function. For the playback method, refer

to the instructions in the disc.

yViewing high-denition content and up-

converting standard DVD content may require a

HDMI-capable input or HDCP-capable DVI input

on your display device.

ySome BD-ROM and DVD discs may restrict the

use of some operation commands or features.

yYou can use an USB device to store some disc

related information, including downloaded

online content. The disc you are using will

control how long this information is retained.

Appendix74

Appendix

Audio Output Specifications

Jack/Setting

Source

HDMI OUT

PCM Stereo PCM

Multi-Ch

DTS Re-encode

3BitStream

Dolby Digital PCM 2ch PCM 5.1ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch PCM 5.1ch DTS Dolby Digital Plus

Dolby TrueHD PCM 2ch PCM 5.1ch DTS Dolby TrueHD

DTS PCM 2ch PCM 5.1ch DTS DTS

DTS-HD PCM 2ch PCM 5.1ch DTS DTS-HD

Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch

Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch

Linear PCM 7.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 7.1ch

*1 The secondary and interactive audio may not

be included in the output bitstream if [Digital

Output] option is set to [BitStream]. (Except

LPCM Codec : the output always include

interactive and secondary audio.)

*2 This player automatically selects the HDMI

audio according to the decoding capability

of the connected HDMI device even though

[Digital Output] option is set to [BitStream].

*3 If the [Digital Output] option is set to [DTS re-

encode], the audio output is limited to 48 kHz

and 5.1Ch. If the [Digital Output] option is set

to [DTS re-encode], the DTS Re-encode audio

is outputted for BD-ROM discs, and the original

audio is outputted for the other discs (like

[BitStream]).

yThe audio is outputted as PCM 48 kHz/16 bit for

MP3/WMA le and PCM 44.1kHz/16 bit for Audio

CD during playback.

yWith digital audio connection (HDMI OUT),

Disc Menu button sounds of BD-ROM may not

be heard if the [Digital Output] option is set to

[BitStream].

yIf the audio format of the digital output does

not match the capabilities of your receiver, the

receiver will produce a strong, distorted sound

or no sound at all.

yMulti-channel Digital Surround Sound via

digital connection can only be obtained if your

receiver is equipped with a Digital Multi-channel

decoder.

yThis setting is not available on the input signal

from an external device.

Appendix 75

Appendix

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian

Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan TW

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

Appendix76

Appendix

Language Code List

Use this list to input your desired language for the following initial settings: [Disc Audio],

[Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Afar 6565

Afrikaans 6570

Albanian 8381

Amharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Japanese 7465

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laotian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

Appendix 77

Appendix

Trademarks and

Licenses

Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™,

BONUSVIEW™ and the logos are trademarks of

the Blu-ray Disc Association.

“DVD Logo” is a trademark of DVD Format/Logo

Licensing Corporation.

Java is a trademark of Oracle and/or its aliates.

HDMI, the HDMI logo and High-Denition

Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United

States and other countries.

“x.v.Color” is a trademark of Sony Corporation.

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol

are trademarks of Dolby Laboratories.

DLNA®, the DLNA Logo and DLNA CERTIFIED® are

trademarks, service marks, or certication marks

of the Digital Living Network Alliance.

Manufactured under license under U.S. Patent

Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;

7,392,195; 7,272,567; 7,333,929; 7,212,872 & other

U.S. and worldwide patents issued & pending.

DTS-HD, the Symbol, & DTS-HD and the Symbol

together are registered trademarks & DTS-HD

Master Audio | Essential is a trademark of DTS,

Rights Reserved.

The Wi-Fi CERTIFIED Logo is a certication mark

of the Wi-Fi Alliance.

The Wi-Fi Protected Setup Mark is a trademark of

the Wi-Fi Alliance.

“AVCHD” and the “AVCHD” logo are trademarks of

Panasonic Corporation and Sony Corporation.

DivX®, DivX Certied® and associated logos are

trademarks of Rovi Corporation or its subsidiaries

and are used under license.

Appendix78

Appendix

“Made for iPod,” “Made for iPhone,” and “Made for

iPad” mean that an electronic accessory has been

designed to connect specically to iPod, iPhone,

or iPad, respectively, and has been certied

by the developer to meet Apple performance

standards. Apple is not responsible for the

operation of this device or its compliance with

safety and regulatory standards. Please note that

the use of this accessory with iPod, iPhone, or

iPad may aect wireless performance.

Bluetooth® wireless technology is a system which

allows radio contact between electronic devices

within a max. range of 10 meters.

Connecting individual devices under Bluetooth®

wireless technology does not incur any charges.

A mobile phone with Bluetooth® wireless tech-

nology can be operated via the Cascade if the

connection was made via Bluetooth® wireless

technology.

The Bluetooth® word mark and logos are owned

by the Bluetooth® SIG, Inc. and any use of such

marks by LG Electronics is under license.

Other trademarks and trade names are those of

their respective owners.

Cinavia Notice

This product uses Cinavia technology to limit the

use of unauthorized copies of some commercially-

produced lm and videos and their soundtracks.

When a prohibited use of an unauthorized copy is

detected, a message will be displayed and playback

or copying will be interrupted.

More information about Cinavia technology

is provided at the Cinavia Online Consumer

Information Center at http://www.cinavia.com. To

request additional information about Cinavia by

mail, send a postcard with your mailing address

to: Cinavia Consumer Information Center, P.O. Box

86851, San Diego, CA, 92138, USA.

This product incorporates proprietary technology

under license from Verance Corporation and is

protected by U.S. Patent 7,369,677 and other U.S.

and worldwide patents issued and pending as well

as copyright and trade secret protection for certain

aspects of such technology. Cinavia is a trademark

Reverse engineering or disassembly is prohibited.

Appendix 79

Appendix

Gracenote®, Gracenote logo and logotype,

and the “Powered by Gracenote” logo are

either registered trademarks or trademarks of

Gracenote, Inc. in the United States and/or other

countries.

Music recognition technology and related data

are provided by Gracenote®.

or its providers.

Gracenote® End User License Agreement

This application or device contains software from

Gracenote, Inc. of Emeryville, California

(“Gracenote”). The software from Gracenote (the

“Gracenote Software”) enables this application to

perform disc and/or le identication and obtain

music-related information, including name, artist,

track, and title information (“Gracenote Data”) from

online servers or embedded databases (collectively,

“Gracenote Servers”) and to perform other

functions. You may use Gracenote Data only by

means of the intended End-User functions of this

application or device.

You agree that you will use Gracenote Data, the

Gracenote Software, and Gracenote Servers for

your own personal non-commercial use only. You

agree not to assign, copy, transfer or transmit the

Gracenote Software or any Gracenote Data to any

third party. YOU AGREE NOT TO USE OR EXPLOIT

GRACENOTE DATA, THE GRACENOTE SOFTWARE,

OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY

PERMITTED HEREIN.

You agree that your non-exclusive license to use

the Gracenote Data, the Gracenote Software, and

Gracenote Servers will terminate if you violate

these restrictions. If your license terminates, you

agree to cease any and all use of the Gracenote

Data, the Gracenote Software, and Gracenote

Servers. Gracenote reserves all rights in Gracenote

Data, the Gracenote Software, and the Gracenote

Servers, including all ownership rights. Under

no circumstances will Gracenote become liable

for any payment to you for any information that

you provide. You agree that Gracenote, Inc. may

enforce its rights under this Agreement against you

directly in its own name.

The Gracenote service uses a unique identier to

track queries for statistical purposes. The purpose

of a randomly assigned numeric identier is to

allow the Gracenote service to count queries

without knowing anything about who you are.

For more information, see the web page for the

Gracenote Privacy Policy for the Gracenote service.

The Gracenote Software and each item of

Gracenote Data are licensed to you “AS IS.”

Gracenote makes no representations or warranties,

express or implied, regarding the accuracy of any

Gracenote Data from in the Gracenote Servers.

Gracenote reserves the right to delete data from

the Gracenote Servers or to change data categories

for any cause that Gracenote deems sucient. No

warranty is made that the Gracenote Software or

Gracenote Servers are error-free or that functioning

of Gracenote Software or Gracenote Servers will

be uninterrupted. Gracenote is not obligated to

provide you with new enhanced or additional data

types or categories that Gracenote may provide in

the future and is free to discontinue its services at

any time.

GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS

OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,

IMPLIED WARRANTIES OF MERCHANTABILITY,

FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND

NON-INFRINGEMENT. GRACENOTE DOES NOT

WARRANT THE RESULTS THAT WILL BE OBTAINED

BY YOUR USE OF THE GRACENOTE SOFTWARE

OR ANY GRACENOTE SERVER. IN NO CASE WILL

GRACENOTE BE LIABLE FOR ANY CONSEQUENTIAL

OR INCIDENTAL DAMAGES OR FOR ANY LOST

PROFITS OR LOST REVENUES.

Appendix80

Appendix

Specifications

General

Power requirements Refer to main label.

Power consumption Refer to main label.

Dimensions (W x H x D) Approx. 950 mm x 136 mm x 75 mm

Net Weight (Approx.) 4.6 kg

Operating temperature 5 °C to 35 °C (41 °F to 95 °F)

Operating humidity 5 % to 90 %

Inputs/Outputs

HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector)

DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1

PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1

Tuner

FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz

Amplier

Power output, (RMS), THD 10 %

Total 430 W

Front 70 W x 2

Rear 70 W x 2

Sub-Woofer 150 W

Appendix 81

Appendix

System

Laser Semiconductor laser

wavelength 405 nm / 650 nm

Signal system Standard PAL/NTSC color TV system

LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX

Wireless LAN (internal antenna) Integrated IEEE 802.11n (5 GHz and 2.4 GHz bands) wireless

networking access, compatible with 802.11a/b/g Wi-Fi networks.

Bus Power Supply (USB) DC 5 V 0 2.1 A MAX

Speakers

Subwoofer

Type 1 Way 1 speaker Max. Input power 300 W

Impedance Rated 3 Ω Net Dimensions

(W x H x D) 221 mm x 351.5 mm x 281 mm

Input Power 150 W Net Weight 7.6 kg

Power

requirements Refer to main label. Power

consumption Refer to main label.

yDesign and specications are subject to change without notice.

Appendix82

Appendix

Maintenance

Handling the unit

When shipping the unit

Please save the original shipping carton and

packing materials. If you need to ship the unit, for

maximum protection, re-pack the unit as it was

originally packed at the factory.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the

surfaces are extremely dirty, use a soft cloth lightly

moistened with a mild detergent solution. Do not

use strong solvents such as alcohol, benzine, or

thinner, as these might damage the surface of the

unit.

Keeping the exterior surfaces clean

yDo not use volatile liquids such as insecticide

spray near the unit.

yWiping with strong pressure may damage the

surface.

yDo not leave rubber or plastic products in

contact with the unit for a long period of time.

Maintaining the unit

The unit is a high-tech, precision device. If the

optical pick-up lens and disc drive parts are dirty

or worn, the picture quality could be diminished.

For details, please contact your nearest authorized

service center.

Notes on discs

Handling discs

Do not touch the playback side of the disc. Hold

the disc by the edges so that ngerprints do not

get on the surface. Never stick paper or tape on the

disc.

Storing discs

After playing, store the disc in its case. Do not

expose the disc to direct sunlight or sources of heat

and never leave it in a parked car exposed to direct

sunlight.

Cleaning discs

Fingerprints and dust on the disc can cause poor

picture quality and sound distortion. Before playing,

clean the disc with a clean cloth. Wipe the disc from

the center to out.

Do not use strong solvents such as alcohol,

benzine, thinner, commercially available cleaners,

or anti-static spray intended for older vinyl records.

Appendix 83

Appendix

Important Information

relating to Network

Services

All information, data, documents, communications,

downloads, les, text, images, photographs,

graphics, videos, webcasts, publications, tools,

resources, software, code, programs, applets,

widgets, applications, products and other content

(“Content”) and all services and oerings (“Services”)

provided or made available by or through any

third party (each a “Service Provider”) is the sole

responsibility of the Service Provider from whom it

originated.

The availability of and access to Content and

Services furnished by the Service Provider through

the LGE Device are subject to change at any time,

without prior notice, including, but not limited to

the suspension, removal or cessation of all or any

part of the Content or Services.

Should you have any inquiry or problem related

to the Content or Services, you may refer to the

Service Provider’s website for the most up-to-

date information. LGE is neither responsible nor

liable for customer service related to the Content

and Services. Any question or request for service

relating to the Content or Services should be made

directly to the respective Content and Service

Providers.

Please note that LGE is not responsible for any

Content or Services provided by the Service

Provider or any changes to, removal of, or cessation

of such Content or Services and does not warrant

or guaranty the availability of or access to such

Content or Services.
