OWNER’S MANUAL
DIGITAL A/V RECEIVER
SYSTEM
MODEL
AR805TS (AR805TS, SR85TS-F/S/C/W)
P/NO : MFL63267063
Please read this manual carefully before operating
your set and retain it for future reference.
2Safety Information
Safety Information
1
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK) NO USER-
SERVICEABLE PARTS INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle is
intended to alert the user to the presence
of uninsulated dangerous voltage within
the product’s enclosure that may be of
sucient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
Cautions and Warnings
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a
dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact
replacement part by an authorized service centre.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where the cord
exits the appliance. To disconnect power from the
mains, pull out the mains cord plug. When installing
the product, ensure that the plug is easily accessible.
3
Safety Information
Safety Information
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the battery
from the equipment:
Remove the old battery or battery pack, follow the
steps in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do not
dispose of batteries or battery together with other
waste. It is recommended that you use local, free
reimbursement systems batteries and accumulators.
The battery shall not be exposed to excessive heat
such as sunshine, re or the like.
Copyrights
It is forbidden by law to copy, broadcast, show,
broadcast via cable, play in public, or rent
copyrighted material without permission. This
product features the copy protection function
developed by Macrovision. Copy protection signals
are recorded on some discs. When recording and
playing the pictures of these discs picture noise
will appear. This product incorporates copyright
protection technology that is protected by U.S.
patents and other intellectual property rights. Use
of this copyright protection technology must be
authorized by Macrovision, and is intended for home
and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE
WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS
TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525
OR 625 PROGRESSIVE SCAN PICTURE PROBLEMS,
IT IS RECOMMENDED THAT THE USER SWITCH THE
CONNECTION TO THE ‘STANDARD DEFINITION’
OUTPUT. IF THERE ARE QUESTIONS REGARDING
OUR TV SET COMPATIBILITY WITH THIS MODEL 525p
AND 625p UNIT, PLEASE CONTACT OUR CUSTOMER
SERVICE CENTER.
You have to set the disc format option to [Mastered]
in order to make the discs compatible with the LG
players when formatting rewritable discs. When
setting the option to Live File System, you cannot
use it on LG players.
(Mastered/ Live File System : Disc format system for
Windows Vista)
4Contents
Contents
1
Safety Information
2 Cautions and Warnings
3 Copyrights
2
Preparation
6 Introduction
6 About the “ ” Symbol
Display
6 Symbols Used in this
Manual
6 Accessories
7 Required cables
8 Remote control
10 Front panel
11 Rear panel
3
Installation
12 Installing speakers
13 Connecting speakers
14 Connecting to Your TV
14 Video/Audio (Left/Right)
connection
15 HDMI connection
16 Resolution Setting
16 Connecting TV or components
with HDMI jack
17 Connecting components with
analog video and audio jacks
17 AV IN 1 connection
17 AV IN 2 connection
18 Connecting components with
Digital Audio jacks
18 Optical digital audio
connection
18 Coaxial digital audio
connection
19 Connecting the portable device
19 Connecting the antennas
20 Connecting the headphones
21 Settings
21 Adjusting the Setup
Settings
21 [Language] Menu
21 [Display] Menu
22 [Audio] Menu
23 [Others] Menu
5
1
2
3
4
5
6
7
Contents
4
Operation
24 Turning On the unit
24 Selecting the input source
25 Adjusting the speaker levels
26 Enjoying various sound mode
26 Sound Effect
27 Bass Blast
27 Setting the USER EQ
27 Listening to FM/AM radio
27 Automatic tuning
27 Manual tuning
28 Presetting radio stations
28 Tuning to preset stations
28 Deleting the preset stations
28 Deleting all the preset
stations
29 Playing the USB device
29 Basic operations
31 Listening to music
32 Playing a movie file
34 Viewing a photo
35 Dimmer
35 Screen Saver
36 Using the Sleep Timer
36 Using microphone
5
Maintenance
37 Handling the Unit
6
Troubleshooting
38 Troubleshooting
7
Appendix
40 Trademarks and Licenses
41 Specifications
6Preparation
Preparation
2
2
Preparation
Introduction
About the “ ” Symbol Display
“ ” may appear on your TV display during
operation and indicates that the function
explained in this owner’s manual is not
available on that specic media.
Symbols Used in this Manual
NOTE
Indicates special notes and operating features.
CAUTION
Indicates cautions for preventing possible
damages from abuse.
A section whose title has one of the following
symbols are applicable only to the disc
represented by the symbol.
MOVIE
Movie les contained in
the USB
MUSIC
Music les contained in
the USB
Photo les contained in
the USB
Accessories
Please check and identify the supplied
accessories.
FM antenna (1) AM antenna (1)
HDMI cable (1) Speaker cables (5)
Analog audio cable
(1)
Composite video
cable (1)
Remote control (1) Batteries (2)
7Preparation
Preparation
2
Required cables
The hookup diagrams on the subsequent
pages assume the use of the following
connection cables.
You must purchase the connection cables
separately if necessary.
• Analog audio cable
White (L)
Red (R)
• Composite video cable
Yellow
• Analog audio/Composite video cable
Yellow (Video)
White (L/audio)
Red (R/audio)
• Optical digital audio cable
• Coaxial digital audio cable
• USB cable
• HDMI cable
• Portable cable
NOTE
• Turn o the power to all components before
making any connections.
• When connecting an audio/video cable, be
sure to match the colour-coded pins to the
appropriate jacks on the components: yellow
(video) to yellow; white (left, audio) to white;
and red (right, audio) to red.
• When connecting optical digital cables, insert
the cable plugs straight in until they click into
place.
• Do not bend or tie optical digital cables.
8Preparation
Preparation
2
Remote control
Battery Installation
Remove the battery cover
on the rear of the Remote
Control, and insert two R03
(size AAA) batteries with
and matched correctly.
• • • • • • • • • a • • • • • • • •
POWER (1): Switches the unit ON or OFF.
TV control buttons: Controls the TV. (LG TV
only)
-
-1-: Turns the TV on or o.
-AV/INPUT : Switches the TV’s input source
between the TV and other input sources.
INPUT buttons: Selects the input source you
want to use. (Page 25)
-AV: Selects the input source connected to
AV IN 1/2 jack.
-PORTABLE: Selects the input source
connected to PORT. IN jack.
-OPTICAL: Selects the input source
connected to OPTICAL IN 1/2 jack.
-COAXIAL: Selects the input source
connected to COAXIAL IN 1/2 jack.
-HDMI IN: Selects the input source
connected to HDMI IN jack.
-RADIO: Selects the FM/AM.
-USB: Selects the input source connected to
USB port.
CLEAR: Deletes a preset stations. (Page 28)
-REPEAT: Selects a play mode. (Repeat
playback/ Random playback) (Page 32)
AUTO DJ: Selects the AUTO DJ mode.
(Page 32)
DIMMER: The display window is darken by
half. (Page 35)
SLEEP: Sets the system to turn o
automatically at a specied time. (Page 36)
9Preparation
Preparation
2
• • • • • • • • • b • • • • • • • •
./> (SKIP): Goes to the next or previous
chapter / track / le.
m/M (SCAN): Searches backward or
forward.
x (STOP): Stops playback.
N(PLAY): Starts playback.
X (PAUSE): Pauses playback.
• • • • • • • • • c • • • • • • • •
SPEAKER LEVEL: Sets the sound level of
desired speaker. (Page 25)
SOUND EFFECT: Selects a sound eect mode.
(Page 26)
VOL (-/+) : Adjusts speaker volume.
MUTE ( ): Turns o the sound temporarily.
Press the button again to restore the sound.
BASS BLAST: Selects the BASS BLAST sound
mode directly. (Page 27)
• • • • • • • • • d • • • • • • • •
SETUP: Displays or exits the [SETUP] menu.
RETURN (O): Moves backwards in the menu
or exits the setup menu.
INFO/DISPLAY ( ): Displays or exits On-
screen Display. (Page 33, 35)
ENTER ( ): Acknowledges menu selection.
MARKER: Marks music les on the [MUSIC]
menu. (Page 31)
PRESET (-/+): Selects a preset stations.
TUNING (-/+): Tunes in the desired radio
station.
U/u/I/i (up/ down/ left/ right): Selects an
option in the menu.
MONO/STEREO: Selects mono/stereo in FM
mode. (Page 27)
• • • • • • • • • e • • • • • • • •
MIC VOL (-/+): Adjusts the microphone
volume. (Page 36)
ECHO VOL (-/+): Adjusts the echo volume.
(Page 36)
0 to 9 numerical buttons: Selects numbered
options in a menu.
10 Preparation
Preparation
2
kl
jn o p
m
a STANDBY/ON (1/[)
Switches the unit ON or OFF.
b INPUT SELECTOR
Selects the input source. Rotate this knob
until the input source you want appears in
the display window.
c Display window
Shows the current status of the unit.
d MASTER VOLUME
Adjusts the speaker volume.
e PHONES connector
Connects a stereo headphone plug (
3.5 mm) to PHONES connector for private
listening. (Page 20)
f MULTI CONTROL
Adjusts the various options.
g BASS BLAST
Selects the BASS BLAST sound mode
directly. (Page 27)
h SOUND EFFECT
Selects a sound eect mode. (Page 26)
i USER EQ
Sets the USER EQ mode (BASS, MIDDLE
and TREBLE). (Page 27)
j ENTER
Acknowledges menu selection.
k PLAY/PAUSE
Starts playback.
Pauses playback, press it again to exit
pause status.
Moves to the BASS mode if you press PLAY/
PAUSE on the front panel while the “USER
EQ” is displayed in the display window.
l STOP
Stops playback.
m MIC
Connects a microphone ( 6.3 mm) to
MIC jack.
n PORT. IN
Connects a portable device (MP3 player,
etc) to PORT. IN jack.
o AV IN 2 (L-AUDIO-R, VIDEO)
Connects the components with analog
audio/video output jacks (camcorder,
video game, etc).
p USB port (5 V 500 mA)
Connects an USB device to USB port.
Front panel
11Preparation
Preparation
2
a Speakers connectors
Connects the speaker cables.
b OPTICAL IN 1/2
Connects other components with an
optical digital audio output.
c COAXIAL IN 1/2
Connects other components with a coaxial
digital audio output.
d HDMI IN
Connects the component with HDMI
output.
e HDMI OUT
Connects a TV or component with HDMI
input.
f AV IN 1 (L-AUDIO-R, VIDEO)
Connects the components with analog
audio/video output jacks (DVD player, Blu-
ray disc player, Satellite tuner, Set-top box,
etc).
g AUDIO L/R OUTPUT
Connects the components with analog
audio input jacks.
h Antenna connectors
FM – Connects the FM wired antenna.
AM – Connects the AM loop antenna.
i VIDEO OUT
Connects to your TV or projector with
video input.
Rear panel
b
adefghi
c
12 Installation
Installation
3
Installing speakers
The unit allows you to use 5.2 channel system.
The following illustration shows an example
of positioning the system. Note that the
illustrations in these instructions dier from the
actual unit for explanation purposes. For the
best possible rear sound, all the speakers other
than the subwoofer should be placed at the
same distance from the listening position (A).
Example of 5.2 channel speaker system
conguration
F
C
B
A
F
D
E
A
A
A
A
A
A
A
H
G
A Front speaker (left)/ B Front speaker
(right)
Place the front speakers to the sides of the
monitor or screen and as ush with the screen
surface as possible.
C Center speaker
Place the center speaker above or below the
monitor or screen.
D Rear speaker (left)/ E Rear speaker
(right)
Place these speakers behind your listening
position, facing slightly inwards.
F/G Subwoofer
The position of the subwoofer is not so
critical, because low bass sounds are not
highly directional. But it is better to place
the subwoofer near the front speakers. Turn
it slightly toward the center of the room to
reduce the wall reections.
H Unit
CAUTION
• Be careful that the speaker
should not fall down.
Otherwise it may result in the
speaker malfunctioning and
causing personal injury and/
or property damage.
• Make sure to install the speaker with other
people in order to prevent it from falling and
causing injuries to the installer.
3
Installation
13Installation
Installation
3
Connecting speakers
Before connecting the cables, be sure to
disconnect the AC power cord.
Speaker system connection
Front speaker (R)
Black Red
Rear speaker (L)
Black
Rear speaker (R)
Black
SubwooferSubwoofer
Center speaker
Noir
Front speaker (L)
Noir
Red Red
Red Red
1. Connect the wires to the unit. To connect
the cable to the unit, press each plastic
nger pad to open the connection terminal.
Insert the wire and release the nger pad.
Connect the black end of each wire to the
terminals marked -(minus) and the other
end to the terminals marked + (plus).
2. Connect the wires to the speakers. Connect
the other end of each wire to the correct
speaker according to the color coding:
Color Speaker Position
Green Center Center
Orange Subwoofer Any front
position
Red Front Front right
White Front Front left
Grey Rear Rear right
Blue Rear Rear left
To connect the cable to the speakers,
press each plastic nger pad to open the
connection terminals on the base of each
speaker. Insert the wire and release the
nger pad.
CAUTION
• Be careful to make sure children not to put their
hands or any objects into the *speaker duct.
*Speaker duct: A hall for plentiful bass sound on
speaker cabinet (enclosure).
• Place the centre speaker at a safe distance from
the child’s reach. Otherwise it may result in the
speaker falling down and causing personal
injury and/or property damage.
• The speakers contain magnet parts, so color
irregularity may occur on the TV screen or PC
monitor screen. Please use the speakers far away
from either TV screen or PC monitor.
14 Installation
Installation
3
Connecting to Your TV
You can watch the selected input image when
you connect the VIDEO OUT or HDMI OUT jack
to a TV.
It is not necessary to connect all the cables.
Connect the cables according to the jacks of
your components.
• Video/Audio (Left/Right) connection
(page 14)
• HDMI connection (page 15)
NOTE
• Before connecting the cables, be sure to
disconnect the AC power cord.
• Turn o the power to all components before
making any connections.
• When connecting an audio/video cable, be
sure to match the colour-coded pins to the
appropriate jacks on the components: yellow
(video) to yellow; white (left, audio) to white;
and red (right, audio) to red.
Video/Audio (Left/Right)
connection
Connect the VIDEO OUT jack on the unit to
the video in jack on the TV using a video cable.
Connect the left and right AUDIO OUT jacks of
the unit to the audio left and right IN jacks on
the TV using the audio cables.
Video/Audio Connection
Video
cable
Audio cable
Unit
TV
Set the TV’s source to VIDEO (refer to TV’s
Owner’s manual).
15Installation
Installation
3
HDMI connection
If you have a HDMI TV or monitor, you can
connect it to this unit using a HDMI cable.
Connect the HDMI OUT jack on the unit to
the HDMI IN jack on a HDMI compatible TV or
monitor.
HDMI Connection
Unit
TV
HDMI
Cable
Set the TV’s source to HDMI (refer to TV’s
Owner’s manual).
NOTE
• HDMI is the abbreviated name for High
Denition Multimedia Interface. It is an interface
which transmits video and audio signals in
digital format. If a connected HDMI device does
not accept the audio output of the unit, the
HDMI device’s audio sound may be distorted or
may not output.
• When you use HDMI connection, you can
change the resolution for the HDMI output.
(Refer to “Resolution Setting” on page 16.)
• When you connect a HDMI or DVI compatible
device make sure of the following:
-Try switching o the HDMI/DVI device and
this unit. Next, switch on the HDMI/DVI
device and leave it for around 30 seconds,
then switch on this unit.
-The connected device’s video input is set
correctly for this unit.
-The connected device is compatible with
720 x 480i (or 576i), 720 x 480p (or 576p),
1 280 x 720p, 1 920 x 1 080i or 1 920 x 1 080p
video input.
• Not all HDCP-compatible HDMI or DVI devices
will work with this unit.
-The picture will not be displayed properly
with non-HDCP device.
-This unit does not playback and TV screen is
changed to black screen.
• If there is noise or lines on the screen, please
check the HDMI cable and use a higher version
cable than 1.2A HDMI cable.
• Changing the resolution when the connection
has already been established may result in
malfunctions. To solve the problem, turn o the
player and then turn it on again.
• When the HDMI connection with HDCP is not
veried, TV screen is changed to black screen.
In this case, check the HDMI connection, or
disconnect the HDMI cable.
16 Installation
Installation
3
Resolution Setting
The unit provides several output resolutions for
HDMI OUT jack. You can change the resolution
using [Setup] menu.
1. Press SETUP.
The [Setup] menu appears.
2. Use U/u to select [Display] option then
press i to move to the second level.
3. Use U/u to select the [Resolution] option
then press i to move to the third level.
4. Use U/u to select the desired resolution
then press ENTER ( ) to conrm your
selection.
NOTE
If your TV does not accept the resolution you have
set on the player, you can set resolution to 480p (or
576p) as follows:
Press x (STOP) for more than 5 seconds.
Connecting TV or
components with
HDMI jack
1. Connect the HDMI OUT jack on the unit to
the HDMI IN jack on a HDMI compatible TV
or monitor. Connect the HDMI IN jack on
the unit to your components with HDMI
OUT jack using a HDMI cable.
HDMI Connection
HDMI cable
HDMI cable
TV, Monitor, etc
Blu-ray disc player,
DVD player, etc
Unit
2. Set the input source to HDMI (Page 24).
17Installation
Installation
3
Connecting components
with analog video and
audio jacks
It is not necessary to connect all the cables.
Connect the cables according to the jacks
of your components. Before connecting the
cables, be sure to disconnect the AC power
cord.
AV IN 1 connection
1. Connect the VIDEO IN jack on the unit to
the VIDEO OUT jack on your component
using a video cable. Connect the left and
right AUDIO IN jacks of the unit to the audio
left and right OUT jacks on your component
using the audio cables.
Analog Video/Audio Connection
Unit
Video
cable
Audio cable
Blu-ray disc player,
DVD player, etc
2. Connect the unit to your TV. Refer the
“Video/Audio (Left/Right) connection” on
the page 14.
3. Set the input source to AV 1 (Page 24).
AV IN 2 connection
1. Connect the VIDEO IN jack on the unit to
the VIDEO OUT jack on your component
using a video cable. Connect the left and
right AUDIO IN jacks of the unit to the audio
left and right OUT jacks on your component
using the audio cables.
Analog Video/Audio Connection
Unit
Video
cable
Audio cable
Camcorder, video
game, etc
2. Connect the unit to your TV. Refer the
“Video/Audio (Left/Right) connection” on
the page 14.
3. Set the input source to AV 2 (Page 24).
18 Installation
Installation
3
Connecting
components with
Digital Audio jacks
It is not necessary to connect all the cables.
Connect the cables according to the jacks
of your components. Before connecting the
cables, be sure to disconnect the AC power
cord.
Optical digital audio
connection
1. Connect the OPTICAL IN 1/2 jack on the
unit to your components with OPTICAL
OUT jack using an optical digital audio
cable.
OPTICAL IN connection
Unit
Blu-ray disc player,
DVD player, etc
2. Set the input source to OPTICAL 1/ OPTICAL
2 (Page 24).
Coaxial digital audio
connection
1. Connect the COAXIAL IN 1/2 jack on the
unit to your components with COAXIAL
OUT jack using a coaxial digital audio cable.
COAXIAL IN connection
Unit
Blu-ray disc player,
DVD player, etc
2. Set the input source to COAXIAL 1/
COAXIAL 2 (Page 24).
19Installation
Installation
3
Connecting the
portable device
1. Connect the PORT. IN jack on the unit to the
LINE OUT jack on your Portable device (MP3
player, etc...) using a portable cable ( 3.5
mm).
Portable device connection
Unit
Portable device
(MP3 player, etc...)
2. Set the input source to PORTABLE (Page 24).
Connecting the
antennas
Connect the supplied AM loop antenna and
FM wire antenna.
Before connecting the antenna, be sure to
disconnect the AC power cord.
Antennas connection
Unit
AM loop antenna
FM wire antenna
NOTE
• To prevent noise pickup, keep the AM Loop
antenna away from the unit and other
components.
• Be sure to fully extend the FM wire antenna.
• After connecting the FM wire antenna, keep it as
horizontal as possible.
20 Installation
Installation
3
Connecting the
headphones
Connect a pair of stereo headphones ( 3.5
mm phone plug) to the unit’s PHONES jack for
private listening.
Headphones connection
Unit
Headphones
NOTE
• Always turn down the volume before
connecting your headphones.
• The speakers are turned o while the
headphones plug is inserted in the PHONES
jack.
21Installation
Installation
3
Settings
Adjusting the Setup Settings
You can change the settings of the unit in the
[Setup] menu.
1. Press SETUP.
The [Setup] menu appears.
2. Use U/u to select the rst setup option, and
press i to move to the second level.
3. Use U/u to select a second setup option,
and press ENTER ( ) to move to the third
level.
4. Use U/u to select a desired setting, and
press ENTER ( ) to conrm your selection.
[Language] Menu
Menu Language
Select a language for the [Setup] menu and
on-screen display.
[Display] Menu
TV Aspect
Select which screen aspect to use based on
the shape of your TV screen.
[4:3]
Select when a standard 4:3 TV is connected.
[16:9]
Select when a 16:9 wide TV is connected.
Display Mode
The Display Mode setting works only when the
TV Aspect mode is set to 4:3.
[Letterbox]
Displays a wide picture with bands on the
upper and lower portions of the screen.
[Panscan]
Automatically displays the wide picture on
the entire screen and cuts o the portions
that do not t.
Resolution
Sets the output resolution of the HDMI video
signal. Refer to “Resolution Setting” for details
about the resolution (page 16).
[Auto]
If the HDMI OUT jack is connected to
TVs providing display information (EDID),
automatically selects the resolution best
suited to the connected TV.
22 Installation
Installation
3
[576i]
Outputs 576 lines of interlaced video.
[576p]
Outputs 576 lines of progressive video.
[720p]
Outputs 720 lines of progressive video.
[1080i]
Outputs 1080 lines of interlaced video.
[1080p]
Outputs 1080 lines of progressive video.
[Audio] Menu
Speaker Setup
Make the following settings for the built-in 5.2
channel surround decoder.
1. Select [Speaker Setup] on the [Audio]
menu.
2. Press ENTER ( )
The [SPEAKER] menu appears.
3. Use I/i to select the desired speaker.
4. Adjust options using U/u/I/i buttons.
5. After adjusting the desired options, press
RETURN (O). The menu moves to the
previous screen.
[Speaker]
Select a speaker that you want to adjust.
NOTE
Certain speaker settings are prohibited by the
Dolby Digital licensing agreement.
[Size]
Since the speaker settings are xed, you
cannot change the settings.
[Volume]
Press I/i to adjust the output level of the
selected speaker.
- Front L/R : 0 ~ -5
- SubWoofer, Rear L/R, Center : 5 ~ -5
[Distance]
After you connected speakers to your unit,
set the Distance between the speakers and
your listening point if the distance of Center
or Rear speakers is bigger than the distance
of Front speakers. This allows the sound
from each speaker to reach the listener
at the same time. Press I/i to adjust the
Distance of the selected speaker. This
distance is equivalent to a dierence of the
distance between Center or Rear speaker
and Front speakers.
[Speaker Test Start]/ [Speaker Test Stop]
Select [Speaker Test Start] by using the U/
u and press ENTER ( ). Press ENTER ( )
again to stop. Adjust the volume to match
the volume of test signals memorized in the
system.
23Installation
Installation
3
DRC (Dynamic Range Control)
When a title encoded in Dolby Digital or Dolby
Digital Plus is playing back, you may wish to
compress the dynamic range of the audio
output (the dierence between the loudest
sounds and the quietest ones). This allows you
to listen to a movie at a lower volume without
losing clarity of sound. Set [DRC] to [On] for
this eect.
HD AV Sync
Sometimes Digital TV encounters a delay
between picture and sound. If this happens
you can compensate by setting a delay on the
sound so that it eectively ‘waits’ for the picture
to arrive: this is called HD AV Sync. Use U/u
(on the remote control) to scroll up and down
through the delay amount, which you can set
at anything between 0 and 300m .
sec. NOTE
This function is only operated on the USB mode.
[Others] Menu
DivX(R) VOD
ABOUT DIVX VIDEO: DivX® is a digital video
format created by DivX, Inc. This is an ocial
DivX Certied device that plays DivX video.
Visit www.divx.com for more information and
software tools to convert your les into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied® device must be registered in order to
play DivX Video-on-Demand (VOD) content.
To generate the registration code, locate the
DivX VOD section in the device setup menu.
Go to vod.divx.com with this code to complete
the registration process and learn more about
DivX VOD.
[Register]
Displays the registration code of your unit.
[Deregister]
Deactivate your unit and display the
deactivation code.
NOTE
All the downloaded videos from DivX VOD with
this player’s registration code can only be played
back on this unit.
24 Operation
Operation
4
Turning On the unit
Before connecting the power cord, connect all
your speakers and AV components.
1. Plug the power cord into an AC wall outlet.
2. Press the POWER (1-or 1/[) button.
The unit turns on, the display window lights
up.
To turn o the unit, press the POWER (1 or
1/[) button.
Selecting the input
source
This section explains how to select the input
source (i.e., the AV component that you want
to listen to or watch).
1. Press POWER (1-or 1/[) to turn the unit
on.
2. Select a source by rotating the INPUT
SELECTOR on the front panel.
The selected source appears in the display
window.
To select the Display
Component connected to
AV IN 1 jack
AV 1
Component connected to
AV IN 2 jack
AV 2
Portable device connected
to PORT. IN jack
PORTABLE
Component connected to
OPTICAL IN 1 jack
OPTICAL 1
Component connected to
OPTICAL IN 2 jack
OPTICAL 2
Component connected to
COAXIAL IN 1 jack
COAXIAL 1
Component connected to
COAXIAL IN 2 jack
COAXIAL 2
Component connected to
HDMI jack
HDMI IN
Built-in tuner Tuner or
frequency
USB device connected to
USB port
USB
4
Operation
25Operation
Operation
4
To select the required input source using
the remote control, use the INPUT buttons.
To select the Button
Component connected to
AV IN 1/2 jack
AV
Portable device connected
to PORT. IN jack
PORTABLE
Component connected to
OPTICAL IN 1/2 jack
OPTICAL
Component connected to
COAXIAL IN 1/2 jack
COAXIAL
Component connected to
HDMI jack
HDMI IN
Built-in tuner RADIO
USB device connected to
USB port
USB
3. Turn on the component and start playback.
4. To adjust the volume, rotate the MASTER
VOLUME on the front panel, or press VOL
(-/+) on remote control.
To activate the muting function
Press MUTE ( ) on the remote control. To
cancel, press MUTE ( ) on the remote control
again or rotate the MASTER VOLUME on the
front panel.
Adjusting the speaker
levels
You can adjust the level of each speaker. These
settings are applied to all sound elds. You can
adjust from -5 to +5 in 1 step.
1. Press SPEAKER LEVEL repeatedly to select a
desired speaker to set.
The indicator changes cyclically in the
display window as follows.
SW t FL t C t FR t RR t RL
2. Press VOL (-/+) to adjust the sound level of
the selected speaker while the indicator is
displayed in the display window.
Display Description
SW Subwoofer (-5 to +5)
FL Front speaker (left) (-5 to 0)
C Center speaker (-5 to +5)
FR Front speaker (right) (-5 to
0)
RR Rear speaker (right) (-5 to
+5)
RL Rear speaker (left) (-5 to +5)
3. Repeat and adjust the sound level of the
other speakers.
26 Operation
Operation
4
Enjoying various
sound mode
You can enjoy various sound mode. For details,
refer to the Sound Eect, Bass Blast, and USER
EQ. (Pages 26-27)
Sound Effect
You can select a suitable sound mode. Press
SOUND EFFECT repeatedly until the desired
mode appears in the display window.
Display Description
NAT PLUS You can enjoy the natural
sound eect same as a
5.2-channel.
NATURAL You can enjoy comfortable
and natural sound.
Local
specialization
equalizer
Regionally optimized
sound eect. (DANGDUT/
ARABIC/ PERSIAN/ INDIA/
REGUETON/ MERENGUE/
SAMBA/ SALSA/ CUMBIA/
AFRO)
AUTO EQ Sets the sound equalizer to
the mode that is the most
similar to the genre which
is included in the MP3 ID3
tag of song les.
POP
CLASSIC
JAZZ
ROCK
This program lends an
enthusiastic atmosphere to
the sound, giving you the
feeling you are at an actual
rock pop, jazz or classic
concert.
MP3-OPT This function is optimized
for compressible MP3 le. It
improves the treble sound.
BASS BLAST During playback, reinforces
the bass sound.
LOUDNESS Improves the bass and
treble sound.
VIRTUAL You can enjoy more virtual
surround sound.
PL MOVIE
PL MUSIC
Dolby Pro Logic II enables
you to play stereo source
on 5.2-channel.
BYPASS You can enjoy the 2 channel
sound from front speakers
and subwoofer.
NOTE
• In some of surround modes, some speakers,
there’s no sound or low sound. It depends on
the mode of surround and the source of audio,
it is not defective.
• You may need to reset the surround mode, after
switching the input, sometimes even after the
sound track changed.
• This function is not operated when the
microphone is connected to the unit.
27Operation
Operation
4
Bass Blast
You can set the BASS BLAST sound mode
directly.
Press BASS BLAST repeatedly.
Display Description
BASS BLAST During playback, reinforces
the bass sound.
BYPASS You can enjoy the 2 channel
sound from front speakers
and subwoofer.
NOTE
This function is not operated when the
microphone is connected to the unit.
Setting the USER EQ
You can listen to music with desired sound
eect by adjusting the BASS, MIDDLE and
TREBLE.
1. Press USER EQ on the front panel.
“USER EQ” appears in the display window.
2. Press PLAY/PAUSE on the front panel while
the “USER EQ” is displayed in the display
window.
3. Select the BASS, MIDDLE or TREBLE by
pressing ENTER on the front panel.
4. Rotate MULTI CONTROL on the front panel
to set sound level.
5. Press PLAY/PAUSE on the front panel to
nish the settings.
NOTE
This function is not operated when the
microphone is connected to the unit.
Listening to FM/AM
radio
You can listen to FM and AM broadcasts
through the built-in tuner. Before operation,
make sure you have connected the FM and AM
antennas to the unit. (Page 19)
Automatic tuning
1. Rotate INPUT SELECTOR to select tuner (FM
or AM). Or press RADIO with the remote
control to select tuner (FM or AM).
2. Press TUNING - or TUNING + for more than
2 seconds.
Press TUNING - for more than 2 seconds to
scan from high to low.
Press TUNING + for more than 2 seconds to
scan from low to high.
The unit stops scanning whenever a station
is received.
In case of poor FM stereo reception
If the FM stereo reception is poor and “ST.”
ashes in the display window, select monaural
audio so that the sound will be less distorted
by pressing the MONO/STEREO.
The “ST.” indicator disappears in the display
window. There will be no stereo eect, but the
reception will improve. Press the button again
to restore the stereo eect.
Manual tuning
Press TUNING - or TUNING + briey and
repeatedly on the FM or AM mode to select a
station you want. Or rotate MULTI CONTROL on
the unit.
28 Operation
Operation
4
Presetting radio stations
You can preset up to 50 FM or AM stations.
Then you can easily tune in the stations you
often listen to.
1. Rotate INPUT SELECTOR to select tuner (FM
or AM). Or press RADIO with the remote
control to select tuner (FM or AM).
2. Tune in the station that you want to preset
using Automatic tuning or Manual tuning.
3. Press ENTER ( ).
A preset number ashes in the display
window for a few seconds. When a preset
number ashes, do the step 4.
4. Press PRESET - or PRESET+ to select a preset
number you want.
If a preset number is not ashed before you
select the preset number, start again from
the step 3.
5. Press ENTER ( ) again.
The station is stored to the selected preset
number. If a preset number is not ashed
before you press ENTER ( ), start again
from the step 3.
6. Repeat the steps 2 to 5 to preset another
station.
Tuning to preset stations
Before tuning to preset stations, make sure you
preset radio stations. (Page 28)
1. Rotate INPUT SELECTOR to select tuner (FM
or AM). Or press RADIO with the remote
control to select tuner (FM or AM).
2. Press PRESET - or PRESET+ repeatedly to
select the preset station you want.
Each time you press the button, you can
select a preset station.
Deleting the preset stations
You can delete a preset station you want.
1. Rotate INPUT SELECTOR to select tuner (FM
or AM). Or press RADIO with the remote
control to select tuner (FM or AM).
2. Select the preset station to delete by
pressing PRESET - or PRESET+.
3. Press CLEAR.
4. Press CLEAR again while the preset number
ashes in the display window for a few
seconds.
The preset station is deleted.
5. Repeat the steps 2 to 4 to delete another
preset station.
Deleting all the preset stations
1. Press and hold CLEAR for about two
seconds.
“ERASE ALL” appears in the display window.
2. Press CLEAR again while “ERASE ALL” is
displayed.
All the preset stations are cleared.
29Operation
Operation
4
Playing the USB
device
This unit can play movie, music and photo les
contained in the USB device.
Basic operations
1. Insert an USB device to the USB port until it
ts into place.
USB device connection
Unit
USB device
2. Rotate INPUT SELECTOR on the front
panel to select until the “USB” appears in
the display window. Or press USB on the
remote control.
When you connect the USB device
contained music les only in the USB device,
the unit plays music les automatically. If
the USB device is containing various types
of les, the [USB] menu for the le type
selection will appear.
[USB] menu
3. Select [Music], [Movie] or [Photo] using I/
i, and press ENTER ( ) to play the le.
To stop playback
MUSIC
MOVIE
Press x (STOP) during playback.
To pause playback
MUSIC
MOVIE
Press X (PAUSE) during playback.
Press B (PLAY) to resume playback.
To scan forward or backward
MUSIC
MOVIE
Press m or M to play fast forward or fast
reverse during playback.
You can change the various playback speeds
by pressing m or M repeatedly.
Press B (PLAY) to return to normal speed.
To skip to the next/previous chapter/
track/file
MUSIC
MOVIE
During playback, press . or > to go to
the next chapter/track/le or to return to the
beginning of the current chapter/track/le.
Press . twice briey to step back to the
previous chapter/track/le.
During playback, press . or > to go to
the previous/next le.
30 Operation
Operation
4
To slow down the playing speed
MOVIE
While the playback is paused, press M
repeatedly to play various speeds of slow
motion.
Resume playback
MUSIC
MOVIE
The unit records the point where you pressed
the x (STOP) depending on the le.
If “Xx-(Resume Stop)” appears on the screen
briey, press B (PLAY)-to resume playback
(from the scene point).
If you press x (STOP) twice, “x (Complete
Stop)” appears on the screen. The unit will clear
the stopped point.
Removing the USB device from the
unit
1. Choose a dierent function mode or press
x (STOP) twice in a row.
2. Remove the USB device from the unit.
Compatible USB Devices
-MP3 Player : Flash type MP3 player.
-USB Flash Drive : Devices that support USB
2.0 or USB 1.1.
-Some USB device may not work with this
unit.
NOTE
• Devices which require additional program
installation connected to a computer, are not
supported.
• Do not extract the USB device while in
operation.
• For a large capacity USB, it may take longer than
a few minute to be searched.
• Regular back up is recommended to prevent
data loss.
• If you use a USB extension cable or USB hub, the
USB device is not recognized.
• Using NTFS le system is not supported.
(Only FAT(16/32) le system is supported.)
• This unit is not supported when the total
number of les is 1 000 or more.
• External HDD, Card readers, Locked devices, or
hard type usb devices are not supported.
• USB Port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
• USB device: USB device that supports USB 1.1
and USB 2.0.
• Digital camera and mobile phone are not
supported.
31Operation
Operation
4
Listening to music
You can play music les contained in a USB
device.
1. Select [Music] using I/i on the [USB]
menu.
2. Press ENTER ( ).
The unit plays music les automatically.
Using the [MUSIC] menu
[MUSIC] menu
Options Buttons Description
UP
FOLDER
Select a
desired
option
using U/u/
I/i.
Returning to the
upper folder.
m/MMoving to the
previous or next
page.
Select All Marking all the
les.
Deselect
All
Deselecting all
the marked les.
s Mark MARKER Marking the
selected les.
bBvV-
Move
U/u/I/iMoving to
another le.
Select ENTER ( ) Activating a le.
O-Close RETURN
(O)
Returning to
the [USB]
menu.
NOTE
• The le requirements are described on page 32.
• You can use various playback functions. Refer to
pages 29-30.
Playing your favorite music
This enables you to play the marked music in
order by marking your favorite les.
1. During playback, select your favorite les
using U/u.
2. Press MARKER.
The s indicator appears on the [MUSIC]
menu.
3. Repeat steps 1-2.
4. Press B (PLAY) or ENTER ( ).
The play mode is displayed on the [MUSIC]
menu.
Mark Play
Current Play
5. Select the desired play mode using U/u.
[Mark Play]: Plays the marked les in order.
[Current Play]: Plays the les in order from
the highlighted position.
6. Press ENTER ( ).
NOTE
• If you want to delete a marker, select the marked
le and then press MARKER.
• The markers are also cleared when the USB
device is removed, the unit is switched to power
o or the function is switched to others.
32 Operation
Operation
4
Playing repeatedly or randomly
During playback, press -REPEAT repeatedly
to select a desired mode.
Display Description
REPEAT The current le will be
played repeatedly.
REPEAT ALL All the les will be played
repeatedly.
RANDOM The les will be played in
random order.
O
(No display)
Returns to normal playback.
AUTO DJ playback
AUTO DJ blends the end of one song into the
beginning of another for seamless playback.
During playback, press AUTO DJ repeatedly to
select a desired mode.
Display Description
AUTO DJ
RANDOM
The music is played
randomly on this mode.
AUTO DJ
SEQUENTIAL
The music is played
repeatedly on this mode.
AUTO DJ OFF Returns to normal playback.
Music file requirement
Music le compatibility with this unit is limited
as follows :
• Sampling frequency : within 32 to 48 kHz
(MP3), within 32 to 48 kHz (WMA)
• Bit rate : within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
• Support Version : v2, v7, v8, v9
• Maximum les : Under 999
• File extensions : “.mp3”/ “.wma”
• CD-ROM le format : ISO 9660/ JOLIET
• We recommend that you use Easy-CD
Creator, which creates an ISO 9660 le
system.
Playing a movie file
You can play movie les contained in a USB
device.
1. Select [Movie] using I/i on the [USB]
menu.
2. Select a le using U/u/I/i, and press B
(PLAY) or ENTER ( ) to play the le.
Displaying content information on-
screen
You can display and adjust various information
and settings about the content.
1. During playback, press INFO/DISPLAY ( ) to
show various playback information.
a
e
d
c
b
33Operation
Operation
4
aTitle – current title number/total number
of titles
bTime – elapsed playing time/total
playback time
cAudio – selected audio language or
channel
dSubtitle – selected subtitle
eCode Page – selected subtitle code page
2. Select an option using U/u.
3. Use I/i to adjust the selected option
value.
4. Press INFO/DISPLAY ( ) or RETURN (O) to
exit the On-Screen display.
NOTE
If no button is pressed for a few seconds, the on-
screen display disappears.
Playing from selected time
1. Press INFO/DISPLAY ( ) during playback.
The time search box shows the elapsed
playing time.
2. Select the [Time] option and then input the
required start time in hours, minutes, and
seconds from left to right.
For example, to nd a scene at 2 hours, 10
minutes, and 20 seconds, enter “21020”.
3. Press ENTER ( ) to start playback from
selected time.
Hearing different audio
1. During playback, press INFO/DISPLAY ( ) to
display the On-Screen display.
2. Use U/u-to select the [Audio] option.
3. Use I/i-to select desired audio language,
audio track or audio channel.
Selecting a subtitle language
1. During playback, press INFO/DISPLAY ( ) to
display the On-Screen display.
2. Use U/u-to select the [Subtitle] option.
3. Use I/i-to select desired subtitle language.
4. Press RETURN (O) to exit the On-Screen
display.
Changing subtitle code page
If the subtitle is not displayed properly, you
can change the subtitle code page to view the
subtitle le properly.
1. During playback, press INFO/DISPLAY ( ) to
display the On-Screen display.
2. Use U/u-to select the [Code Page] option.
3. Use I/i-to select desired code option.
4. Press RETURN (O) to exit the On-Screen
display.
34 Operation
Operation
4
Movie file requirement
Movie le compatibility with this unit is limited
as follows :
• Available resolution: within 720 x 576
(W x H) pixels.
• The le name of the DivX subtitle should be
entered within 45 characters.
• If there is impossible code to express in the
DivX le, it may be displayed as “ _ “ mark on
the display.
• Frame rate : less than 30 fps.
• If the video and audio structure of recorded
les is not interleaved, either video or audio
is outputted.
• Playable movie le : “.avi”, “.mpg”, “.mpeg”,
“.divx”
• Playable Subtitle format : SubRip (*.srt/
*.txt), SAMI (*.smi), SubStation Alpha (*.ssa/
*.txt), MicroDVD (*.sub/ *.txt), SubViewer 2.0
(*.sub/ *.txt), Vobsub (*.sub)
• Playable Codec format : “DIVX3.xx”,
“DIVX4. xx”, “DIVX5.xx”, “MP4V3”, “3IVX”.
• Playable Audio format : “AC3”, “DTS”, “PCM”,
“MP3”, “WMA”.
• Sampling frequency : within 32 to 48 kHz
(MP3), within 32 to 48 kHz (WMA)
• Bit rate : within 32 to 320 kbps (MP3), 40 to
192 kbps (WMA)
• For Discs formatted in Live le system, you
can not it on this unit.
• If the name of movie le is dierent from
that of the subtitle le, during playback of a
DivX le, subtitle may not be display.
• If you play a DivX le dier from DivXspec, it
may not operate normally.
Viewing a photo
You can view photo les contained in a USB
device.
1. Select [Photo] using I/i on the [USB]
menu.
The [PHOTO] menu appears.
[PHOTO] menu
Options Buttons Description
UP
FOLDER
Select a
desired
option
using U/u/
I/i.
Returning to the
upper folder.
m/MMoving to the
previous or next
page.
B-Slide
Show
B (PLAY) Viewing a slide
show.
bBvV-
Move
U/u/I/iMoving to
another le or
content.
Select ENTER ( ) Viewing a
particular le.
O-Close RETURN
(O)
Returning to the
[USB] menu.
2. Select a le using U/u/I/i, and press B
(PLAY) or ENTER ( ) to play the le.
Options Buttons Description
B-Slide
Show
B (PLAY) Viewing a slide
show.
Select ENTER ( ) Viewing a
particular le.
35Operation
Operation
4
To stop a slide show
Press x (STOP) during slide show.
To pause a slide show
Press X (PAUSE) during slide show.
Press B (PLAY) or X (PAUSE) to re-start the
slide show.
To skip to the next/previous photo
While viewing a photo in full screen, press I or
i to go to the previous or next photo.
Options while viewing a photo
You can use various options while viewing a
photo in full screen.
1. While viewing a photo in full screen, press
INFO/DISPLAY ( ) to display the option
menu.
2. Select an option using U/u/I/i.
a
ed
c
b
aCurrent photo/Total number of photos
– Use I/i to view previous/next photo.
bSlide Show – Press ENTER ( ) to start or
pause slide show.
cSpeed – Use ENTER ( ) to select a delay
time between photos in a slide show.
dRotate – Press ENTER ( ) to rotate the
photo clockwise/counterclockwise.
eGo to list– Press ENTER ( ) to return
[Photo] menu.
3. Press RETURN (O) or INFO/DISPLAY ( ) to
exit the option menu.
Photo file requirement
Photo le compatibility with this unit is limited
as follows :
• Max pixel in width : 2 760 x 2 048 pixel
• Maximum les : Under 999
• Some les may not operate due to a
dierent recording format or the condition
of le.
• File extensions: “.jpg”
• CD-ROM le format : ISO 9660/ JOLIET
Dimmer
Press DIMMER once. The display window will
be darken by half. To cancel it, press DIMMER
again.
Screen Saver
The screen saver appears when you leave the
unit in Stop mode for about ve minutes.
36 Operation
Operation
4
Using the Sleep Timer
You can set the unit to turn o automatically at
a specied time.
Press SLEEP repeatedly.
The indicator changes cyclically in the display
window as follows.
SLEEP 180 t 150 t 120 t 90 t 80 t 70
t 60 t 50 t 40 t 30 t 20 t 10 t
O (No display)
To check the remaining time, press SLEEP. The
remaining time appears in the display window.
To cancel the sleep function, press SLEEP
repeatedly until “SLEEP 10” appears, and then
press SLEEP once again while “SLEEP 10” is
displayed.
NOTE
When the sleep timer is activated, the display
window dims.
Using microphone
1. Connect a microphone ( 6.3 mm) to MIC
jack.
Microphone connection
ON
Unit
Microphone
“ “ is displayed in the display window.
2. Play the music you want.
3. Sing along with the accompaniment.
4. Adjust the microphone volume by pressing
MIC VOL (-/+).
5. Adjust the echo volume by pressing ECHO
VOL (-/+).
NOTE
• When not using the microphone, set the
microphone volume to minimum or turn o the
microphone and remove the microphone from
the MIC jack.
• If the microphone is set too near the speaker, a
howling sound may be produced. In this case,
move the microphone away from the speaker
or decrease the sound level by using the MIC
VOL(+/-) button.
• The microphone function is not operated in
the digital (COAXIAL 1 , COAXIAL 2, OPTICAL 1,
OPTICAL 2 or HDMI IN) mode.
37Maintenance
Maintenance
5
Handling the Unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit,
for maximum protection, re-pack the unit as it
was originally packed at the factory.
Keeping the exterior surfaces clean
• Do not use volatile liquids such as
insecticide spray near the unit.
• Wiping with strong pressure may damage
the surface.
• Do not leave rubber or plastic products in
contact with the unit for a long period of
time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If
the surfaces are extremely dirty, use a soft
cloth lightly moistened with a mild detergent
solution. Do not use strong solvents such as
alcohol, benzine, or thinner, as these might
damage the surface of the unit.
Maintaining the Unit
The unit is a high-tech, precision device. If
the optical pick-up lens and disc drive parts
are dirty or worn, the picture quality could be
diminished. For details, please contact your
nearest authorized service centre.
5
Maintenance
38 Troubleshooting
Troubleshooting
6
6
Troubleshooting
Troubleshooting
PROBLEM CAUSE CORRECTION
No power. • The power cord is
disconnected.
• Plug the power cord into the wall
outlet securely.
No sound. • The speaker wires are
disconnected.
• The MASTER VOLUME is
adjusted too low.
• The MUTE button is pressed
to ON.
• The selected decoding
mode is not matched to the
input signal format.
• Incorrect selection of input
source.
• Incorrect connections
between the components.
• Check the speaker connections.
• Adjust the MASTER VOLUME.
• Press the MUTE button to cancel
the muting eect.
• Select the available decoding
mode.
• Select the desired input source
correctly.
• Make connections correctly.
Radio stations can’t
be tuned in properly.
• The antenna is positioned or
connected poorly.
• The signal strength of the
radio station is too weak.
• No stations have been
preset or preset stations
have been cleared (when
tuning by scanning preset
channels).
• Check the antenna connection
and adjust its position.
• Tune to the station manually.
• Preset some radio stations, see
page 28 for details.
39Troubleshooting
Troubleshooting
6
Preset stations cannot
be received.
• An incorrect station
frequency has been
memorized.
• The memorized stations are
cleared.
• Memorize the correct station
frequency.
• Memorize the stations again.
Poor FM reception. • No antenna is connected.
• The antenna is not
positioned for the best
reception.
• Connect the antenna.
• Change the position of the
antenna.
The remote control
doesn’t work well / at
all.
• The remote control is not
pointed directly at the unit.
• The remote control is too far
from the unit.
• There is an obstacle in the
path between the remote
control and the unit.
• The battery in the remote
control are at.
• Point the remote directly at the
unit.
• Use the remote within 23 feet
(7m) of the unit.
• Remove the obstacle.
• Replace the batteries with new
ones.
40 Appendix
Appendix
7
Trademarks and Licenses
7
Appendix
HDMI, the HDMI logo and High-Denition Multimedia
Interface are trademarks or registered trademarks of
HDMI licensing LLC.
DivX®, DivX Certied® and associated logos are
registered trademarks of DivX, Inc. and are used
under license.”
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
Manufactured under licence under U.S. Patent #’s:
5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents issued & pending.
DTS and the Symbol are registered trademarks & DTS
Digital Surround and the DTS logos are trademarks
of DTS, Inc. Product includes software. © DTS, Inc. All
Rights Reserved.
41Appendix
Appendix
7
General
• Power requirements: Refer to main label.
• Power consumption: Refer to main label.
• Dimensions (W x H x D): 430 x 150 x 312 mm
• Net Weight (Approx.): 4.1 kg
• Operating temperature:
41 °F to 95 °F (5 °C to 35 °C)
• Operating humidity: 5 % to 90 %
• Bus Power supply (USB): DC 5 V 500 mA
Inputs/ Outputs
• AUDIO OUT:
2.0 Vrms (1 kHz, 0 dB), 600 Ω,
RCA jack (L, R) x 1
• VIDEO OUT:
1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
• HDMI IN/OUT (video/audio):
19 pin (HDMI standard, Type A), HDMI
version 1.2A
• OPTICAL IN 1/2: 3 V (p-p), Optical jack x 2
• COAXIAL IN 1/2: 3 V (p-p), Coaxial jack x 2
• ANALOG AUDIO IN (AV1/AV2):
2.0 Vrms (1 kHz, 0 dB), 600 Ω,
RCA jack (L, R) x 2
• ANALOG VIDEO IN (AV1/AV2):
1.0 V (p-p), 75 Ω, sync negative, RCA jack x 2
• PORT. IN: 0.5 Vrms ( 3.5 mm stereo jack)
Tuner
• FM Tuning Range:
87.50 to 108.00 MHz or 87.5 to 108.0 MHz
• AM Tuning Range:
522 to 1 620 kHz or 530 to 1 720 kHz
Amplifier
• Stereo mode: 100 W + 100 W (4 Ω at 1 kHz)
• Surround mode:
Front: 100 W + 100 W (4 Ω at 1 kHz)
Center: 100 W (4 Ω at 1 kHz)
Rear: 100 W + 100 W (4 Ω at 1 kHz)
Subwoofer: 150 W + 150 W (3 Ω at 1 kHz)
Specifications
42 Appendix
Appendix
7
Speakers
• Front speaker
Type: 2 Way 2 speaker
Impedance: 4 Ω
Rated Input Power: 100 W
Max. Input power: 200 W
Net Dimensions (W x H x D):
230 x 905 x 335 mm
Net Weight: 13.8 kg
• Rear speaker
Type: 2 Way 2 speaker
Impedance: 4 Ω
Rated Input Power: 100 W
Max. Input power: 200 W
Net Dimensions (W x H x D):
175 x 453 x 249 mm
Net Weight: 3.4 kg
• Center speaker
Type: 2 Way 3 speaker
Impedance: 4 Ω
Rated Input Power: 100 W
Max. Input power: 200 W
Net Dimensions (W x H x D):
515 x 175 x 254 mm
Net Weight: 5.0 kg
• Subwoofer
Type: 1 Way 1 speaker
Impedance: 3 Ω
Rated Input Power: 150 W
Max. Input power: 300 W
Net Dimensions (W x H x D):
275 x 377 x 319 mm
Net Weight: 6.8 kg
Designs and specications are subject to change without prior notice.
43Appendix
Appendix
7
