OWNER’S MANUAL

DVD Receiver System

MODEL

HT965TZ (HT965TZ, SH95TZ-S/ C/ W)

P/NO : MFL63284246

FOR THE WARRANTY TERMS & CONDITIONS,

PLEASE REFER TO BACK COVER OF THIS MANUAL.

Please read this manual carefully before operating

your set and retain it for future reference.

HT965TZ-DH_BGBRLL_ENG_4246.indd 1 2010-02-02 ¿ÀÈÄ 7:16:04

2Safety Information

Safety Information

1

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK) NO USER-

SERVICEABLE PARTS INSIDE REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

This lightning ash with arrowhead

symbol within an equilateral triangle is

intended to alert the user to the presence

of uninsulated dangerous voltage within

the product’s enclosure that may be of

sucient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK

HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN

OR MOISTURE.

WARNING: Do not install this equipment in a

conned space such as a book case or similar unit.

CAUTION: This product employs a Laser System.

To ensure proper use of this product, please read

this owner’s manual carefully and retain it for future

reference. Shall the unit require maintenance,

contact an authorized service center.

Use of controls, adjustments or the performance of

procedures other than those specied herein may

result in hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try

to open the enclosure. Visible laser radiation when

open. DO NOT STARE INTO BEAM.

CAUTION: The apparatus shall not be exposed to

water (dripping or splashing) and no objects lled

with liquids, such as vases, shall be placed on the

apparatus.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a

dedicated circuit;

That is, a single outlet circuit which powers only

that appliance and has no additional outlets or

branch circuits. Check the specication page of this

owner’s manual to be certain. Do not overload wall

outlets. Overloaded wall outlets, loose or damaged

wall outlets, extension cords, frayed power cords, or

damaged or cracked wire insulation are dangerous.

Any of these conditions could result in electric

shock or re. Periodically examine the cord of your

appliance, and if its appearance indicates damage

or deterioration, unplug it, discontinue use of the

appliance, and have the cord replaced with an exact

replacement part by an authorized service center.

Protect the power cord from physical or mechanical

abuse, such as being twisted, kinked, pinched, closed

in a door, or walked upon. Pay particular attention

to plugs, wall outlets, and the point where the cord

exits the appliance. To disconnect power from the

mains, pull out the mains cord plug. When installing

the product, ensure that the plug is easily accessible.

1

Safety Information

HT965TZ-DH_BGBRLL_ENG_4246.indd 2 2010-02-02 ¿ÀÈÄ 7:16:04

3

Safety Information

Safety Information

1

Disposal of your old a ppliance

1. When this crossed-out wheeled bin

symbol is attached to a product it

means the product is covered by the

European Directive 2002/96/EC.

2. All electrical and electronic products

should be disposed of separately

from the municipal waste stream

via designated collection facilities

appointed by the government or the

local authorities.

3. The correct disposal of your old

appliance will help prevent potential

negative consequences for the

environment and human health.

4. For more detailed information about

disposal of your old appliance,

please contact your city oce, waste

disposal service or the shop where

you purchased the product.

LG Electronics hereby declares that this/

these product(s) is/are in compliance

with the essential requirements and

other relevant provisions of Directive

2004/108/EC, 2006/95/EC, and

2009/125/EC.

European representative :

LG Electronics Service Europe B.V.

Veluwezoom 15, 1327 AE Almere, The

Netherlands (Tel : +31–(0)36–547–8888)

WARNING: Do not install this equipment in a

conned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings.

Install in accordance with the manufacturer's

instructions.

Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the

product and to protect it from overheating.

The openings should be never be blocked by placing

the product on a bed, sofa, rug or other similar

surface. This product should not be placed in a built-

in installation such as a bookcase or rack unless

proper ventilation is provided or the manufacturer's

instruction have been adhered to.

HT903 trans

HT965TZ-DH_BGBRLL_ENG_4246.indd 3 2010-02-02 ¿ÀÈÄ 7:16:04

4Safety Information

Safety Information

1

This device is equipped with a portable battery or

accumulator.

Safe way to remove the battery or the battery

from the equipment:

Remove the old battery pack, follow the steps

in reverse order than the assembly. To prevent

contamination of the environment and bring on

possible threat to human and animal health, the

old battery or the battery put in the appropriate

container at designated collection points. Do not

dispose of batteries or battery together with other

waste. It is recommended that you use local, free

reimbursement system batteries and accumulators.

The battery shall not be exposed to excessive heat

such as sunshine, re or the like.

Copyrights

It is forbidden by law to copy, broadcast, show,

broadcast via cable, play in public, or rent

copyrighted material without permission. This

product features the copy protection function

developed by Macrovision. Copy protection signals

are recorded on some discs. When recording and

playing the pictures of these discs picture noise

will appear. This product incorporates copyright

protection technology that is protected by U.S.

patents and other intellectual property rights. Use

of this copyright protection technology must be

authorized by Macrovision, and is intended for home

and other limited viewing uses only unless otherwise

authorized by Macrovision. Reverse engineering or

disassembly is prohibited.

CONSUMERS SHOULD NOTE THAT NOT ALL HIGH

DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE

WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS

TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525

OR 625 PROGRESSIVE SCAN PICTURE PROBLEMS,

IT IS RECOMMENDED THAT THE USER SWITCH THE

CONNECTION TO THE ‘STANDARD DEFINITION

’ OUTPUT. IF THERE ARE QUESTIONS REGARDING

OUR TV SET COMPATIBILITY WITH THIS MODEL 525p

AND 625p UNIT, PLEASE CONTACT OUR CUSTOMER

SERVICE CENTER.

You have to set the disc format option to [Mastered]

in order to make the discs compatible with the LG

players when formatting rewritable discs. When

setting the option to Live File System, you cannot

use it on LG players.

(Mastered/ Live File System : Disc format system for

Windows Vista)

HT965TZ-DH_BGBRLL_ENG_4246.indd 4 2010-02-02 ¿ÀÈÄ 7:16:04

5Safety Information

Safety Information

1

POWER: This unit operates on a mains supply of

200-240V~, 50/60Hz.

WIRING: This unit is supplied with a BSI 1363 approved

13 amp mains plug, fused at 5 amp. When replacing the

fuse always use a 5 amp BS 1362, BSI or ASTA approved

type. Never use this plug with the fuse cover omitted.

To obtain a replacement fuse cover contact your dealer.

If the type of plug supplied is not suitable for the mains

sockets in your home, then the plug should be removed

and a suitable type tted. Please refer to the wiring

instructions below:

WIRING: A mains plug removed from the mains lead of

this unit must be destroyed. A mains plug with bared

wires is hazardous if inserted in a mains socket. Do not

connect either wire to the earth pin, marked with the

letter E or with the earth symbol or coloured green

or green and yellow. If any other plug is tted, use a 5

amp fuse, either in the plug, or at the distribution board.

IMPORTANT: The wires in this mains lead are coloured

in accordance with the following codes:

- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the

wires in the mains lead of this unit may not correspond

with the coloured marking identifying the terminals

in your plug, proceed as follows: The wire which is

coloured blue must be connected to the terminal

which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected

to the terminal which is marked with the letter L or

coloured red.

HT965TZ-DH_BGBRLL_ENG_4246.indd 5 2010-02-02 ¿ÀÈÄ 7:16:04

6Contents

1

2

3

4

5

6

7

8

Contents

Safety Information

2 CAUTION

Preparation

8 Unique Features

8 Accessories

9 Introduction

9 Playable Discs

9 About the  Symbol Display

9 Symbol Used in this Manual

9 Regional Codes

10 Playable file Requirement

11 Remote control

13 Front panel

14 Rear panel

Installation

15 Assembling the speaker stand to

the speaker

17 Mounting the speakers to a wall

18 Attaching the speakers to the unit

19 Positioning the system

20 Connections to Your TV

20 Component Video Connection

21 HDMI Out Connection

22 Video Connection

22 To connect to a TV with the

SCART jack

23 Resolution Setting

23 Video Output Resolution

24 Optional Equipment Connection

24 HDMI IN connection

25 AUX IN Connection

25 AUDIO (PORT. IN) In

Connection

25 Listening to music from your

portable player or external

device

26 USB Connection

27 OPTICAL In connection

27 Antenna Connection

28 Adjust the setup settings

28 OSD Initial language settings

28 To display and exit the Setup

menu

29 Language

29 Display

30 Audio

31 Lock (Parental Control)

32 Others

Operation

33 Using the Home Menu

33 Basic Operations

34 Other Operations

34 Displaying Disc Information on-

screen

35 To display the DVD Menu

35 To display the DVD title

HT965TZ-DH_BGBRLL_ENG_4246.indd 6 2010-02-02 ¿ÀÈÄ 7:16:04

7Contents

1

2

3

4

5

6

7

8

35 1.5 times speed playback

35 Screen Saver

35 Starting play from selected

time

35 Resume playback

36 Marked Playback

36 Changing subtitle code page

37 Viewing a PHOTO file

37 Options while viewing a photo

38 Sleep Timer Setting

38 Dimmer

38 Turn off the sound temporarily

38 Last Scene Memory

38 System Select - Optional

38 Adjust the speaker level

settings

39 Radio Operations

39 Presetting the Radio Stations

39 Deleting all the saved stations

39 Deleting a saved station

39 Improving poor FM reception

40 Seeing information about a

radio station

41 Sound adjustment

41 Setting the surround mode

42 Advanced Operations

42 Recording to USB

43 Playing the iPod

44 Enjoying iPod on the screen

44 Enjoying the iPod IN mode

Maintenance

46 Notes on Discs

46 Handling the Unit

Troubleshooting

47 Handling the Unit

Appendix

48 Language Codes

49 Area Codes

50 Trademarks and Licenses

51 Specifications

Warranty

53 Warranty

HT965TZ-DH_BGBRLL_ENG_4246.indd 7 2010-02-02 ¿ÀÈÄ 7:16:04

8Preparation

Preparation

2

2

Preparation

Unique Features

Portable In

Listens to music from your portable device.

(MP3, Notebook, etc)

USB Direct Recording

Records music from CD to your USB device.

Full HD up-scaling

Views Full HD picture quality with simple setup.

Home Theater Speaker ez

Setup

listens sound form TV, DVD and Digital divce

with vivid 5.1 (2.1 or 2.0) ch mode.

HDMI In

Simple connection with digital divice (Set Top

Box, DVD player etc.) through HDMI.

Made for iPod

Enjoys music form IPod with simple

connection.

Accessories

Please check and identify the supplied

accessories.

RCA to SCART cable

(1)

Speaker cables (6)

Remote control (1) Batteries (2)

FM antenna (1)

HT965TZ-DH_BGBRLL_ENG_4246.indd 8 2010-02-02 ¿ÀÈÄ 7:16:05

9Preparation

Preparation

2

Introduction

Playable Discs

This unit plays DVD±R/RW and CD-R/RW that

contains audio titles, DivX, MP3, WMA and/or

JPEG les. Some DVD±RW/DVD±R or CD-

RW/CD-R cannot be played on this unit due to

the recording quality or physical condition of

the disc, or the characteristics of the recording

device and authoring software.

DVD-VIDEO (8 cm / 12 cm disc)

Discs such as movies that can be

purchased or rented.

DVD±R (8 cm / 12 cm disc)

Video mode and nalized only

DVD-RW (8 cm / 12 cm disc)

Video mode and nalized only

DVD+R: Video mode only

Supports the double layer disc

also

DVD+RW (8 cm / 12 cm disc)

Video mode and nalized only

Audio CD: Music CDs or CD-R/CD-

RW in music CD format that can

be purchased.

About the  Symbol Display

“  ” may appear on your TV display during

operation and indicates that the function

explained in this owner’s manual is not

available on that disc.

Symbol Used in this Manual

All discs and le listed below ALL

MP3 les MP3

DVD and nalized DVD±R/RW DVD

WMA les WMA

DivX les DivX

Audio CDs ACD

JPG les JPG

NOTE

Indicates special notes and operating features.

TIP

Indicates tip and hints for making the task

easier.

CAUTION

Indicates cautions for preventing possible

damages from abuse.

Regional Codes

This unit has a regional code printed on the

rear of the unit. This unit can play only DVD

discs labeled same as the rear of the unit or

“ALL”.

• Most DVD discs have a globe with one or

more numbers in it clearly visible on the

cover. This number must match your unit’s

regional code or the disc cannot play.

• If you try to play a DVD with a dierent

regional code from your unit, the message

“Check Regional Code” appears on the TV

screen.

HT965TZ-DH_BGBRLL_ENG_4246.indd 9 2010-02-02 ¿ÀÈÄ 7:16:05

10 Preparation

Preparation

2

Playable file

Requirement

MP3/ WMA music file requirement

MP3/ WMA le compatibility with this unit is

limited as follows :

• Sampling frequency : within 32 to 48 kHz

(MP3), within 32 to 48 kHz (WMA)

• Bit rate : within 32 to 320 kbps (MP3),

40 to 192 kbps (WMA)

• Support Version : v2, v7, v8, v9

• Maximum les : Under 999

• File extensions : “.mp3”/ “.wma”

• CD-ROM le format : ISO9660/ JOLIET

• We recommend that you use Easy-CD

Creator, which creates an ISO 9660 le

system.

Photo file requirement

Photo le compatibility with this unit is limited

as follows :

• Max pixel in width : 2760 x 2048 pixel

• Maximum les : Under 999

• Some discs may not operate due to a

dierent recording format or the condition

of disc.

• File extensions: “.jpg”

• CD-ROM le format : ISO9660/ JOLIET

DivX file requirement

DivX le compatibility with this unit is limited

as follows :

• Available resolution: within 720x576 (W x H)

pixels.

• The le name of the DivX subtitle should be

entered within 45 characters.

• If there is impossible code to express in the

DivX le, it may be displayed as " _ " mark

on the display.

• Frame rate : less than 30 fps.

• If the video and audio structure of recorded

les is not interleaved, either video or audio

is outputted.

• Playable DivX le : ".avi", ".mpg", ".mpeg",

".divx"

• Playable Subtitle format : SubRip (*.srt/

*.txt), SAMI (*.smi), SubStation Alpha (*.ssa/

*.txt), MicroDVD (*.sub/ *.txt), SubViewer 2.0

(*.sub/ *.txt), Vobsub (*.sub)

• Playable Codec format : "DIVX3.xx", "DIVX4.

xx", "DIVX5.xx", "MP4V3", "3IVX".

• Playable Audio format : "AC3", "DTS", "PCM",

"MP3", "WMA".

• Sampling frequency : within 32 to 48 kHz

(MP3), within 32 to 48 kHz (WMA)

• Bit rate : within 32 to 320 kbps (MP3), 40 to

192 kbps (WMA)

• For Discs formatted in Live le system, you

can not it on this unit.

• If the name of movie le is dierent from

that of the subtitle le, during playback of a

DivX le, subtitle may not be display.

• If you play a DivX le dier from DivXspec, it

may not operate normally.

HT965TZ-DH_BGBRLL_ENG_4246.indd 10 2010-02-02 ¿ÀÈÄ 7:16:05

11Preparation

Preparation

2

Remote control

Remote control

a

b

c

d

e

f

g

OPEN / RADIO &

CLOSE INPUT

SOUND

EFFECT

SPEAKER

LEVEL

REPEAT

CLEAR

OPTICAL

VOL

MUTE

VOL

VOL

AV / INPUT

ENTER

TITLE

RETURN

DISC MENU

PRESET

PRESET

PR/CH

PR/CH

REC

MARKER

MONO/STEREO

SCAN SKIPSKIP

HOME HOME

TUNING

TUNING

SLEEP

• • • • • • • • • • a • • • • • • • • •

1 (POWER) : Switches the unit ON or OFF.

Z OPEN/CLOSE : Opens and closes the disc

Drawer.

t RADIO&INPUT: Changes input sources.

• • • • • • • • • • b • • • • • • • • •

0 to 9 numerical buttons : Selects numbered

options in a menu.

CLEAR : Removes a number when setting the

password.

s REPEAT : Selects a play mode. (Repeat/

Random)

• • • • • • • • • • c • • • • • • • • •

./> SKIP : Goes to next or previous

chapter/ track/ le.

m/M SCAN : Searchs backward or forward.

x (STOP) : Stops playback or recording.

B (PLAY), MONO/STEREO : Starts playback.

Selects Mono/ Stereo.

X (PAUSE/STEP) : Pauses playback.

• • • • • • • • • • d • • • • • • • • •

SPEAKER LEVEL: Sets the sound level of

desired speaker.

SOUND EFFECT: Selects a sound eect mode.

VOL -/+(Volume) : Adjusts speaker volume.

OPTICAL: Changes input source to optical

directly.

MUTE : Mutes the sound.

Put the batteries into the remote control.

Make sure for the + (plus) and – (minus) on

the batterise to be matched on the remote

control.

HT965TZ-DH_BGBRLL_ENG_4246.indd 11 2010-02-02 ¿ÀÈÄ 7:16:05

12 Preparation

Preparation

2

Remote control

OPEN / RADIO &

CLOSE INPUT

SOUND

EFFECT

SPEAKER

LEVEL

REPEAT

CLEAR

OPTICAL

VOL

MUTE

VOL

VOL

AV / INPUT

ENTER

TITLE

RETURN

DISC MENU

PRESET

PRESET

PR/CH

PR/CH

REC

MARKER

MONO/STEREO

SCAN SKIPSKIP

HOME HOME

TUNING

TUNING

SLEEP

• • • • • • • • • • e • • • • • • • • •

HOME: Displays the [Home] menu.

INFO./DISPLAY : Accesses On-Screen

Display.

U/u/I/i (up/ down/ left/ right): Used to

navigate on-screen displays.

PRESET (+/-) : Selects programme of Radio.

TUNING -/+ : Tunes in the desired radio station.



ENTER : Acknowledges menu selection.

Presetting the radio stations.

O RETURN : Moves backwards in the menu

or exits the setup menu.

TITLE : If the current DVD title has a menu, the

title menu appears on the screen. Otherwise,

the disc menu may not appear.

DISC MENU : Accesses the menu on a DVD

disc.

• • • • • • • • • • f • • • • • • • • •

MARKER : Marks play list.

SLEEP : Sets the System to turn o

automatically at a specied time. (Dimmer :

The display window will be darken by half.)

z REC : USB Direct Recording.

RDS : Radio Data System.

PTY : Views the various displays of the RDS.

• • • • • • • • • • g • • • • • • • • •

TV Control buttons : Controls the TV. (LG TV

only)

Controlling the TV.

You can control the sound level, input

source, and power switching of LG TVs as

well. Hold POWER (TV) and press PR/CH

(+/–) button repeatedly until the TV turns on

or o.

a

b

c

d

e

f

g

HT965TZ-DH_BGBRLL_ENG_4246.indd 12 2010-02-02 ¿ÀÈÄ 7:16:05

13Preparation

Preparation

2

Front panel

a 1/\ (POWER)

Switches the unit ON or OFF.

b Disc Tray

c iPod Dock

d Display window

Shows the current status of the unit.

e Z (OPEN/CLOSE)

Opens or closes the disc tray.

f VOLUME

Adjusts speaker volume.

g F (FUNCTION)

Changes the input source or function.

h ./> (SKIP)

Go to next or previous le/track/chapter.

Searches backward or forward (Press and

hold)

Tunes in the desired radio station.

i x (STOP)

Stops playback.

j N/X (PLAY / PAUSE)

Starts playback.

Pause playback temporarily, press again to

exit pause mode.

k USB Port

Connect a USB device.

l PORT. IN

Connect to a portable player with audio

outputs.

  lk ji h g f

 a b c d e

HT965TZ-DH_BGBRLL_ENG_4246.indd 13 2010-02-02 ¿ÀÈÄ 7:16:06

14 Preparation

Preparation

2

Rear panel

a Power cord

b Speakers connectors

Connect the speaker cables.

c Cooling Fan

d Antenna Connector

FM- Connects the FM wired antenna

e VIDEO OUT

Connect to a TV with video inputs.

f HDMI OUT (Version 1.2A)

Connect to TV with HDMI inputs.

(Interface for digital audio and video)

g HDMI IN (Version 1.2A) 1/2

Connect to an external source with HDMI

output.

h OPTICAL IN

Connect to optical audio equipment.

i COMPONENT VIDEO (Y PB PR)OUTPUT

(PROGRESSIVE SCAN)

Connect to a TV with Y PB PR inputs.

j AUX (L/R) INPUT

Connect to an external source with 2

channel audio outputs.

 a b c de

 ji h g f

HT965TZ-DH_BGBRLL_ENG_4246.indd 14 2010-02-02 ¿ÀÈÄ 7:16:06

15Installation

Installation

3

3

Installation

Assembling the

speaker stand to the

speaker

Preparation

Pole

Cable

Base

Screw

Speaker

1. Attach the pole to the base, then secure the

connection with a supplied screw.

Step 1

Speaker

Pole

Base

Screw

Cable

2. Insert a speaker wire from the bottom of

the base.

Step 2

Speaker

Pole

Base

Screw

Cable

HT965TZ-DH_BGBRLL_ENG_4246.indd 15 2010-02-02 ¿ÀÈÄ 7:16:06

16 Installation

Installation

3

3. Draw the speaker wire through the inside of

the pole and also through the hole on the

bottom of the speaker.

Step 3

Speaker

Pole

Base

Screw

Cable

4. Attach the speaker to the pole, the secure

the connection with a supplied screw.

Step 4

Speaker

Pole

Base

Screw

Cable

5. Connect the speaker wire to the terminal

on the speaker.

Make sure the wire marked black goes in

to the terminal marked “–” (minus) and the

other wire goes in to the terminal marked

“+” (plus).

Step 5

Speaker

Pole

Base

Screw

Cable

CAUTION

Be careful that the speaker

should not fall down.

Otherwise it may result in the

speaker malfunctioning and

causing personal injury and/

or property damage.

HT965TZ-DH_BGBRLL_ENG_4246.indd 16 2010-02-02 ¿ÀÈÄ 7:16:06

17Installation

Installation

3

Mounting the

speakers to a wall

You can mount the speakers to a wall. Prepare

screws and brackets supplied.

1. Attach the wall bracket to the wall with

screws as shown in the illustration below.

When you mount to a wall (concrete) use

the wall plugs. (supplied)

Screw length

3.5 mm (0.14 inch)

25 mm (0.98 inch)

Step 1

Wall plug

Screw

2. Attach the speaker bracket to the speaker

and fasten the screws.

Step 2

3. Hang the speaker bracket onto the wall

bracket.

Step 3

4. Press the speaker to secure the brackets.

Step 4

HT965TZ-DH_BGBRLL_ENG_4246.indd 17 2010-02-02 ¿ÀÈÄ 7:16:06

18 Installation

Installation

3

Attaching the

speakers to the unit

1. Connect the wires to the unit.

Match each wire’s colored band to the

same colored connection terminal on the

rear of the unit. To connect the cable to the

unit, press each plastic nger pad to open

the connection terminal. Insert the wire and

release the nger pad.

Connect the black end of each wire to the

terminals marked -(minus) and the other

end to the terminals marked + (plus).

2. Connect the wires to the speakers.

Connect the other end of each wire to

the correct speaker according to the color

coding:

Color Speaker Position

Grey Rear Rear right

Blue Rear Rear left

Green Center Center

Orange Sub woofer Any front position

Red Front Front right

White Front Front left

To connect the cable to the speakers, press

each plastic nger pad to open the connection

terminals on the base of each speaker. Insert

the wire and release the nger pad.

CAUTION

Be careful to make sure children not to put their

hands or any objects into the *speaker duct.

*Speaker duct: A hall for plentiful bass sound on

speaker cabinet (enclosure).

HT965TZ-DH_BGBRLL_ENG_4246.indd 18 2010-02-02 ¿ÀÈÄ 7:16:06

19Installation

Installation

3

Positioning the

system

The following illustration shows an example

of positioning the system. Note that the

illustrations in these instructions dier from the

actual unit for explanation purposes.

For the best possible surround sound, all the

speakers other than the subwoofer should be

placed at the same distance from the listening

position (A).

A

B

D

D

E

E

F

F

AAA

A

A

G

G

C

CAB

A

A Front left speaker (L)/

B Front right speaker (R):

Place the front speakers to the sides of the

monitor or screen and as ush with the screen

surface as possible.

C Center speaker:

Place the center speaker above or below the

monitor or screen.

D Surround left speaker (L)/

E Surround right speaker (R):

Place these speakers behind your listening

position, facing slightly inwards.

F Subwoofer:

The position of the subwoofer is not so

critical, because low bass sounds are not

highly directional. But it is better to place

the subwoofer near the front speakers. Turn

it slightly toward the center of the room to

reduce the wall reections.

G Unit

HT965TZ-DH_BGBRLL_ENG_4246.indd 19 2010-02-02 ¿ÀÈÄ 7:16:06

20 Installation

Installation

3

Connections to Your

TV

Make one of the following connections,

depending on the capabilities of your existing

equipment.

NOTE

• Depending on your TV and other equipment

you wish to connect, there are various ways

you could connect the unit. Use only one of the

connections described in this manual.

• Please refer to the manuals of your TV, Stereo

System or other devices as necessary to make

the best connections.

• Make sure the unit is connected directly to

the TV. Tune the TV to the correct video input

channel.

• Do not connect your unit via your VCR. The

image could be distorted by the copy protection

system.

Component Video Connection

Connect the COMPONENT VIDEO OUTPUT

(PROGRESSIVE SCAN) jacks on the unit to the

corresponding input jacks on the TV using

component cables.

You can hear the sound through the system’s

speakers.

Component Connection

Unit

TV

Green

Blue

Red

HT965TZ-DH_BGBRLL_ENG_4246.indd 20 2010-02-02 ¿ÀÈÄ 7:16:07

21Installation

Installation

3

HDMI Out Connection

If you have a HDMI TV or monitor, you can

connect it to this unit using a HDMI cable.

Connect the HDMI OUT jack on the unit to

the HDMI IN jack on a HDMI compatible TV or

monitor.

Set the TV’s source to HDMI (refer to TV’s

Owner’s manual).

HDMI Connection

HDMI IN 2

Unit

TV

TIP

• You can fully enjoy digital audio and video

signals together with this HDMI connection.

• When you use HDMI connection, you can

change the resolution for the HDMI output.

(Refer to “Resolution Setting” on page 24.)

NOTE

• If a connected HDMI device does not accept

the audio output of the unit, the HDMI device

’s audio sound may be distorted or may not

output.

• When you connect a HDMI or DVI compatible

device make sure of the following:

- Try switching o the HDMI/DVI device and this

unit. Next, switch on the HDMI/DVI device and

leave it for around 30 seconds, then switch on

this unit.

- The connected device’s video input is set

correctly for this unit.

- The connected device is compatible with

720x480i (or 576i), 720x480p (or 576p),

1280x720p,1920x1080i or 1920x1080p video

input.

• Not all HDCP-compatible HDMI or DVI devices

will work with this unit.

- The picture will not be displayed properly with

non-HDCP device.

- This unit does not playback and TV screen is

changed to black or green screen or the snow

noise may occur on the screen.

• If there is noise or lines on the screen, please

check the HDMI cable and usea higher version

cable than 1.2A HDMI cable.

CAUTION

• Changing the resolution when the connection

has already been established may result in

malfunctions. To solve the problem, turn o the

unit and then turn it on again.

• When the HDMI connection with HDCP is

not veried, TV screen is changed to black or

green screen or the snow noise may occur on

the screen. In this case, check the the HDMI

connection, or disconnect the HDMI cable.

HT965TZ-DH_BGBRLL_ENG_4246.indd 21 2010-02-02 ¿ÀÈÄ 7:16:07

22 Installation

Installation

3

Video Connection

Connect the VIDEO OUT jack on the unit to the

video in jack on the TV using a video cable.

You can hear the sound through the

system’s speakers.

Video Connection

Unit

TV

Yellow

To connect to a TV with the

SCART jack

Connect the RCA to SCART cable form the

VIDEO OUT on the rear of the unit to the SCART

jack on your TV.

RCA to SCART

Unit

TV

HT965TZ-DH_BGBRLL_ENG_4246.indd 22 2010-02-02 ¿ÀÈÄ 7:16:07

23Installation

Installation

3

Resolution Setting

The unit provides several output resolutions for

HDMI OUT and COMPONENT VIDEO OUT jacks.

You can change the resolution using [Setup]

menu.

1. Press HOME.

2. Use I/i to select the [Setup] and press



ENTER. The [Setup] menu appears.

3. Use U/u to select [Display] option then

press i to move to the second level.

4. Use U/u to select the [Resolution] option

then press i to move to the third level.

5. Use U/u to select the desired resolution

then press



ENTER to conrm your

selection.

NOTE

If your TV does not accept the resolution you have

set on the player, you can set resolution to 480p (or

576p) as follows:

Press x (STOP) for more than 5 seconds.

Video Output

Resolution

Displayed resolution in display window and

outputted resolution may dierent according

to connection type.

[HDMI OUT]: 1080p, 1080i, 720p and 480p (or

576p) and 480i (or 576i)

[COMPONENT VIDEO OUT]: 480p (or 576p) and

480i (or 576i)

[VIDEO OUT]: 480i (or 576i)

HT965TZ-DH_BGBRLL_ENG_4246.indd 23 2010-02-02 ¿ÀÈÄ 7:16:08

24 Installation

Installation

3

Optional Equipment

Connection

HDMI IN connection

You can enjoy the pictures and sound of your

component with this connection.

Connect the HDMI IN 1 or HDMI IN 2 jack on

the unit to the HDMI output jack on your Set-

Top box (or Digital Device etc.) using an HDMI

cable. Set the external source to HDMI IN 1 or

HDMI IN 2 by pressing t RADIO&INPUT.

HDMI IN Connection

To the MDMI OUT jack

of your component

(set-top box, digital

satellite receiver,

video game machine,

etc.)

NOTE

• You cannot change the video resolution at the

HDMI IN 1 or HDMI IN 2 mode. Change the

video resolution of the connected component.

• If the video output signal is abnormal when

your personal computer is connected to HDMI

IN 1 or HDMI IN 2 jack, change the resolution of

your personal computer to 480p (or 576p), 720p,

1080i or 1080p.

• The video signal from the HDMI input cannot be

output from the component or composite video

outputs.

• The player sends audio from the HDMI inputs

to both the HDMI output and to the unit’s

speakers.

• You cannot operate SIMPLINK function at the

HDMI IN mode.

HT965TZ-DH_BGBRLL_ENG_4246.indd 24 2010-02-02 ¿ÀÈÄ 7:16:08

25Installation

Installation

3

AUX IN Connection

Connect an Output of auxiliary device to the

AUX (L/R) INPUT Connector.

AUX IN Connection

Unit

Red

White

To the audio output jacks

of your component

(TV, VCR, etc.)

NOTE

If your TV has only one output for audio (mono),

connect it to the left (white) audio jack on the unit.

AUDIO (PORT. IN) In

Connection

Connect an output of portable device (MP3

or PMP etc) to the AUDIO (PORT. IN) input

connector.

PORT.IN Connection

MP3 player, etc...

Listening to music from your

portable player or external

device

The unit can be used to play the music from

many types of portable player or external

devices.

1. Connect the portable player to the

PORT.IN(PORTABLE IN) connector of the

unit.

Or

Connect the external device to the AUX

connector of the unit.

2. Turn the power on by pressing 1 (POWER).

3. Select the PORTABLE or AUX (L/R) INPUT

function by pressing t RADIO&INPUT.

4. Turn on the portable player or external

device and start it playing.

HT965TZ-DH_BGBRLL_ENG_4246.indd 25 2010-02-02 ¿ÀÈÄ 7:16:08

26 Installation

Installation

3

USB Connection

Connect the USB port of USB Memory (or MP3

player, etc.) to the USB port on the front of the

unit.

USB Connection

Removing the USB Device from the unit

1. Choose a dierent function mode or

press STOP (x) twice in a row.

2. Remove the USB device from the unit.

Compatible USB Devices

• MP3 Player : Flash type MP3 player.

• USB Flash Drive : Devices that support

USB2.0 or USB1.1.

• The USB function of this unit does not

support some USB devices.

USB device requirement

• Devices which require additional program

installation connected to a computer, are

not supported.

• Do not extract the USB device while in

operation.

• For a large capacity USB, it may take longer

than a few minute to be searched.

• To prevent data loss, back up all data.

• If you use a USB extension cable or USB

hub, the USB device is not recognized.

• Using NTFS le system is not supported.

(Only FAT(16/32) le system is supported.)

• This unit is not supported when the total

number of les is 1 000 or more.

• External HDD, Card readers, Locked devices,

or hard type usb devices are not supported.

• USB port of the unit cannot be connected

to PC. The unit can not be used as a storage

device.

HT965TZ-DH_BGBRLL_ENG_4246.indd 26 2010-02-02 ¿ÀÈÄ 7:16:08

27Installation

Installation

3

OPTICAL In connection

Connect an optical output of Unit (or Digital

Device etc) to the OPTICAL IN connector.

OPTICAL IN Connection

To the digital

optical output jack

of your component

Home theater speaker ez setup

Listen to sound from TV, DVD and Digital

Device with 5.1(2.1 or 2)ch mode. Even in

power o mode, if you press OPTICAL, then

power is on and automatically changed to AUX

OPT mode.

1. Connect the unit’s OPTICAL IN jack to jack

on optical out of your TV (or Digital Device

etc.).

2. Select the AUX OPT by using the OPTICAL.

To select the AUX OPT directly

3. Listen sound with 5.1(2.1 or 2)ch speaker.

4. To escape from AUX OPT by using the

OPTICAL.

Function is retuned to previous one.

Antenna Connection

Connect the supplied FM antenna for listening

to the radio.

Connect the FM Wire antenna to the FM

antenna connector.

Antenna Connection

NOTE

Be sure to fully extend the FM wire antenna.

After connecting the FM wire antenna, keep it as

horizontal as possible.

HT965TZ-DH_BGBRLL_ENG_4246.indd 27 2010-02-02 ¿ÀÈÄ 7:16:08

28 Installation

Installation

3

Adjust the setup

settings

By using the Setup menu, you can make

various adjustments to items such as picture

and sound.

You can also set a language for the subtitles

and the Setup menu, among other things. For

details on each Setup menu item, see pages 28

to 32.

OSD Initial language settings

During the rst use of this unit, the initial

language setup menu appears on your TV

screen. You must complete initial language

selection before using the unit. English will be

selected as the initial language.

1. Press 1 (POWER) to turn the unit on. The

language setup menu will appear on the

screen.

2. Use U u I i to select a language then

press



ENTER.

The conrm menu will appear.

3. Use I i to select the [Enter] then press



ENTER to nish the language setup.

To display and exit the Setup

menu

1. Press HOME.

Displays the [Home] Menu.

2. Select an [Setup] by using I i.

3. Press



ENTER.

Displays the [Setup]

4. Press HOME or O RETURN to exit in

the [Setup] Menu.

About help menu for Setup

Menu Buttons Operation

v V

Move

U u Moving to another

menu.

b

Move IMoving to previous

level.

B

Move

i

Moving to next level

or selecting menu.

O

Close

O

RETURN

To exit the [Setup]

menu or [ 5.1

Speaker Setup].



Select



ENTER To conrm menu.

HT965TZ-DH_BGBRLL_ENG_4246.indd 28 2010-02-02 ¿ÀÈÄ 7:16:09

29Installation

Installation

3

Language

Menu Language

Select a language for the Setup menu and

then on screen display.

Disc Audio / Disc Subtitle / Disc

Menu

Select the language you prefer for the audio

track (disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the

disc was recorded.

[Other]

To select another language, press numeric

buttons and then



ENTER to enter the

corresponding 4-digit number according

to the language code list on the page 46. If

you enter the wrong language code, press

CLEAR.

[O (for Disc Subtitle)]

Turn o Subtitle.

Display

TV Aspect

Select which screen aspect to use based on

the shape of your TV screen.

[4:3]

Select when a standard 4:3 TV is connected.

[16:9]

Select when a 16:9 wide TV is connected.

Display Mode

The Display Mode setting works only when the

TV Aspect mode is set to 4:3.

[Letterbox]

Displays a wide picture with bands on the

upper and lower portions of the screen.

[Panscan]

Automatically displays the wide picture

on the entire screen and cuts o the

portions that do not t. (If the disc/le is not

compatible with Pan Scan, the picture is

displayed at Letterbox ratio.)

Resolution

Sets the output resolution of the Component

and HDMI video signal. Refer to “Resolution

Setting” for details about the resolution (page

23).

[Auto]

If the HDMI OUT jack is connected to

TVs providing display information (EDID),

automatically selects the resolution

best suited to the connected TV. If the

COMPONENT VIDEO OUT is only connected,

this changes the resolution to 480i (or 576i)

as default resolution.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[480p (or 576p)]

Outputs 480 (or 576) lines of progressive

video.

[480i (or 576i)]

Outputs 480 (or (576) lines of interlaced

video.

HT965TZ-DH_BGBRLL_ENG_4246.indd 29 2010-02-02 ¿ÀÈÄ 7:16:09

30 Installation

Installation

3

Audio

5.1 Speaker Setup

Make the following settings for the built-in 5.1

channel surround decoder.

1. Select [5.1 Speaker Setup] on the [Audio]

menu.

2. Press



ENTER.

The [5.1 Speaker setup] appears.

3. Use I i to select the desired speaker.

4. Adjust options using U u I i buttons.

5. Returns to the previous menu by pressing

O RETURN.

[Speaker selection]

Select a speaker that you want to adjust.

NOTE

Certain speaker settings are prohibited by the

Dolby Digital licensing agreement.

[Size]

Since the speaker settings are xed, you

cannot change the settings.

[Volume]

Press I i to adjust the output level of the

selected speaker.

Front L/R : 0 ~ -5

SubWoofer, Rear L/R, Center : 5 ~ -5

[Distance]

After you connected speakers to your unit,

set the Distance between the speakers and

your listening point if the distance of Center

or Rear speakers is bigger than the distance

of Front speakers. This allows the sound

from each speaker to reach the listener

at the same time. Press I i to adjust the

Distance of the selected speaker. This

distance is equivalent to a dierence of the

distance between Center or Rear speaker

and Front speakers.

[Test]

Select [Speaker Test Start] by using the U u

and press



ENTER. Press



ENTER again

to stop. Adjust the volume to match the

volume of test signals memorized in the

system.

HT965TZ-DH_BGBRLL_ENG_4246.indd 30 2010-02-02 ¿ÀÈÄ 7:16:09

31Installation

Installation

3

DRC (Dynamic Range Control)

Make the sound clear when the volume is

turned down (Dolby Digital only). Set to [On]

for this eect.

Vocal

Select [On] to mix karaoke channels into

normal stereo.

This function is eective for multi-channel

karaoke DVDs only.

HD AV Sync

Sometimes Digital TV encounters a delay

between picture and sound. If this happens

you can compensate by setting a delay on the

sound so that it eectively ‘waits’ for the picture

to arrive: this is called HD AV Sync. Use U u

(on the remote control) to scroll up and down

through the delay amount, which you can set

at anything between 0 and 300m sec.

Lock (Parental Control)

Initial Setting the Area Code:

When you use this unit for the rst time, you

have to set the Area Code.

1. Select the [Lock] menu and then press i.

2. Press i.

To access the [Lock] options, you must

input the password you have created. Input

a password and press



ENTER. Enter it

again and press



ENTER to verify. If you

make a mistake before pressing



ENTER,

press CLEAR.

3. Select the rst character using U u buttons.

4. Press



ENTER and select the second

character using U u buttons.

5. Press



ENTER to conrm your Area code

selection.

Rating

Blocks playback of rated DVDs based on their

contents. Not all discs are rated.

1. Select [Rating] on the [Lock] menu then

press i.

2. Input a password and press



ENTER.

3. Select a rating from 1 to 8 using the U u

buttons.

[Rating 1-8]

Rating one (1) has the most restrictions and

rating eight (8) is the least restrictive.

[Unlock]

If you select unlock, parental control is not

active and the disc plays in full.

4. Press



ENTER to conrm your rating

selection.

HT965TZ-DH_BGBRLL_ENG_4246.indd 31 2010-02-02 ¿ÀÈÄ 7:16:09

32 Installation

Installation

3

Password

You can enter or change password.

1. Select [Password] on the [Lock] menu and

then press i.

2. Input a password and press



ENTER.

To change the password, press



ENTER

when the [Change] option is highlighted.

Input a password and press



ENTER. Enter

it again and press



ENTER to verify.

3. Press HOME to exit the menu.

NOTE

If you forget your password, you can clear it using

the following steps:

1. Select the [Setup] menu on the [Home] menu.

2. Input the 6-digit number “210499” and press



ENTER. The password is cleared.

Area Code

Enter the code of the area whose standards

were used to rate the DVD video disc, based

on the list on page 49.

1. Select [Area Code] on the [Lock] menu then

press i.

2. Input a password and press



ENTER.

3. Select the rst character using U u buttons.

4. Press



ENTER and select the second

character using U u buttons.

5. Press



ENTER to conrm your Area code

selection.

Others

DivX VOD

We provide you with the DivX® VOD (Video On

Demand) registration code that allows you to

rent and purchase videos using the DivX® VOD

service.

For more information, visit www.divx.com/vod.

Press



ENTER when [DivX(R) VOD] is

highlighted and you can view the registration

code of the unit.

NOTE

All the downloaded videos from DivX VOD can

only be played back on this unit.

HT965TZ-DH_BGBRLL_ENG_4246.indd 32 2010-02-02 ¿ÀÈÄ 7:16:09

33Operation

Operation

4

4

Operation

Using the Home Menu

1. Press HOME.

Displays the [Home] menu.

2. Select an option by using I i.

3. Press



ENTER then selected option menu.

[Music] – Displays [MUSIC] menu.

[Movie] – Start video media’s playback or

displays the [MOVIE] menu.

[Photo] – Displays [PHOTO] menu.

[Setup] – Displays the [Setup] menu.

NOTE

You can not select the [Music], [Movie] or [Photo]

option when the USB device is not connected or a

disc is not inserted.

Basic Operations

1. Insert the disc by using the Z OPEN/

CLOSE or Connect the USB device to the

USB port.

2. Press HOME.

Displays the [Home] Menu.

3. Select an option by using I i.

If you select the [Movie], [Photo] or [Music]

option when you connect up to two

devices, it appears as belows. Select a

media then press



ENTER.

4. Press



ENTER then selected option menu.

NOTE

• For the most Audio CD and DVD-ROM discs,

playback starts automatically.

• The unit plays only music le contained in the

USB storage device or disc automatically.

HT965TZ-DH_BGBRLL_ENG_4246.indd 33 2010-02-02 ¿ÀÈÄ 7:16:09

34 Operation

Operation

4

To Do this

Stop Press x (STOP)

Playback Press B (PLAY), MONO/

STEREO.

Pause Press X (PAUSE/STEP).

Frame-

by-Frame

playback

Press X (PAUSE/STEP)

repeatedly to play title

Frame-by-Frame. (DVD, DivX

only)

Skipping to

the next/

previous

chapter/ track/

le

During playback, press

./> SKIP to go to

the next chapter/ track/

le or to return to the

beginning of the current

chapter/ track/ le.

Press . SKIP twice

briey to step back to the

previous chapter/ track/ le.

Locating a

point quickly

by playing

a le in fast

forward or fast

reverse

During playback, press

m/M SCAN repeatedly

to select the required scan

speed.

To return to normal speed,

press B (PLAY), MONO/

STEREO.

Playing

repeatedly or

randomly

Press s REPEAT

repeatedly, and the current

title, chapter or track will be

played back repeatedly or

randomly.

- DVD : Chapter/ Title/ O

- DivX : Title/ All/ O

- Audio CD/ MP3/ WMA :

Track/ All/ Random/ O

Slowing down

the playing

speed

In the pause mode, press

SLOW (bb or BB) to

select the required speed.

(DVD, DivX only) The DivX

le cannot be slow down

reverse playback.

Other Operations

Displaying Disc Information

on-screen

You can display various information about the

disc loaded on-screen.

1. Press INFO./DISPLAY to show various

playback information.

The displayed items dier depending on

the disc type or playing status.

2. You can select an item by pressing U u and

change or select the setting by pressing

I i.

Title – Current title number/ total number of

titles.

Chapter – Current chapter number/ total

number of chapters.

Time – Elapsed playing time.

Audio – Selected audio language or channel.

Subtitle – Selected subtitle.

Angle – Selected angle/ total number of

angles.

NOTE

If any button is not pressed for a few

seconds, the on-screen display disappears.

HT965TZ-DH_BGBRLL_ENG_4246.indd 34 2010-02-02 ¿ÀÈÄ 7:16:09

35Operation

Operation

4

To display the DVD Menu DVD

When you play a DVD which contains several

menu, you can select the menu you want

using the Menu.

1. Press DISC MENU.

The disc’s menu appears.

2. Select the menu by using U u I i.

3. Press B (PLAY), MONO/STEREO to conrm.

To display the DVD title DVD

When you play a DVD which contains several

title, you can select the title you want using the

Menu.

1. Press TITLE.

The disc’s title appears.

2. Select the menu by pressing U u I i.

3. Press B (PLAY), MONO/STEREO to conrm.

1.5 times speed playback DVD

The 1.5 speed allows you to watch the pictures

and listen to the sound quicker than playing at

a normal speed.

1. During playback, press B (PLAY), MONO/

STEREO to play at 1.5 times speed. “BX1.5”

appears on the screen.

2. Press B (PLAY), MONO/STEREO again to

exit.

Screen Saver

The screen saver appears when you leave the

unit in Stop mode for about ve minutes.

Starting play from selected

time DVD DivX

To start playing at any chosen time on the le

or title.

1. Press INFO./DISPLAY during playback.

2. Press U u to select the time clock icon and

“--:--:--” appears.

3. Input the required start time in hours,

minutes, and seconds from left to right. If

you enter the wrong numbers, press CLEAR

to remove the numbers you entered. Then

input the correct numbers.

For example, to nd a scene at 1 hour, 10

minutes, and 20 seconds, enter “11020” by

using numerical buttons.

4. Press



ENTER to conrm. Playback starts

from the selected time.

Resume playback

DVD

DivX

ACD

MP3

WMA

The unit records the point where you pressed

the x (STOP) depending on the disc.

If “Xx (Resume Stop)” appears on the screen

briey, press B (PLAY), MONO/STEREO to

resume playback (from the scene point).

If you press x (STOP) twice or unload the disc,

“x”(Complete Stop) appears on the screen.

The unit will clear the stopped point.

NOTE

The resume point may be cleared when a button

is pressed (for example; 1 (POWER), Z OPEN/

CLOSE, etc).

HT965TZ-DH_BGBRLL_ENG_4246.indd 35 2010-02-02 ¿ÀÈÄ 7:16:09

36 Operation

Operation

4

Marked Playback ACD MP3

WMA

The mark function enables you to store your

favourite les from any disc or USB device in

the unit memory.

1. Select [Music] on the [Home] menu.

Music menu

Returning to the upper

folder. (MP3/ WMA only)

Moving to the previous or

next le list.

Selecting all tracks/ les.

Deselecting all tracks/les.

File information will be displayed

according to the ID3TAG

information on the appropriate

music le. (MP3 only)

2. Select a desired music on the [List] by using

the U u then press MARKER to appears the

mark on the list.

3. Press



ENTER or B (PLAY), MONO/

STEREO.

Displays the play mode.

4. Select the play mode by using the U u and

press



ENTER.

[Mark Play]

Marked playback.

[Current Play]

Normal playback

NOTE

If you want to select all les on the list, select

[Select All] and press



ENTER.

To delete a Marker

1. Use U u to select the track that you wish to

erase from the marked le.

2. Press MARKER.

To delete all Markers

Use U u I i to select [Deselect All] then press



ENTER in program edit mode.

NOTE

The markers are also cleared when the disc or

USB device is removed, the unit is switched to

power o or the function is switched to others.

Changing subtitle code page

DivX

If the subtitle is not displayed properly, you

can change the subtitle code page to view the

subtitle le properly.

1. During playback, press INFO/DISPLAY to

display the On-Screen display.

2. Use U u to select the [Code Page] option.

3. Use I i to select desired code option.

4. Press O RETURN to exit the On-Screen

display.

HT965TZ-DH_BGBRLL_ENG_4246.indd 36 2010-02-02 ¿ÀÈÄ 7:16:09

37Operation

Operation

4

Viewing a PHOTO file JPG

This unit can play discs with photo les.

1. Select [Photo] on the [Home] menu and

press



ENTER.

Photo menu

Moving to the previous or

next le list.

Returning to the upper

folder.

2. Press U u to select a folder, and then press



ENTER.

3. If you want to view a slide show, press U

u to highlight a le and press B (PLAY),

MONO/STEREO.

About help menu in the [Photo] menu.

Menu Buttons Operation

BSlide

Show

B (PLAY),

MONO/

STEREO

Viewing a slide

show.

vVbB

Move

U u I i

Moving to

another le or

content.

 Select



ENTER Viewing a

particular le.

O Close O

RETURN

Returning to

the [Home]

menu.

About help menu in the full screen.

Menu Buttons Operation

Menu INFO./

DISPLAY

Displaying the

Option menu.

b/B

Prev./ Next I/i Moving to

another le

O Close O

RETURN

Returning to

the [Photo]

menu.

Options while viewing a photo

You can use various options during viewing a

photo in full screen.

1. While viewing a photo in full screen, press

INFO./DISPLAY to display the option

menu.

2. Select an option using U u I i.

a

 b c d e

aCurrent photo/ Total number of photos

– Use I i to view previous/next photo.

bSlide Show N/ X– Press



ENTER to

start or pause slide show.

cSpeed x3/ x2/ x1 – Use



ENTER to

select a delaying speed between photos

in a slide show.

dRotate – Press



ENTER to rotate the

photo.

eGo to list – Press



ENTER to return

[Photo] menu.

HT965TZ-DH_BGBRLL_ENG_4246.indd 37 2010-02-02 ¿ÀÈÄ 7:16:09

38 Operation

Operation

4

Sleep Timer Setting

Press SLEEP one or more times to select delay

time between 10 and 180 minutes, after the

unit will turn o.

To check the remaining time, press SLEEP.

To cancel the sleep function, press SLEEP

repeatedly until “SLEEP 10” appears, and then

press SLEEP once again while “SLEEP 10” is

displayed.

NOTE

You can check the remaining time before the

Unit turns o.

Press SLEEP The remaining time appears in the

display window.

Dimmer

Press SLEEP once. The display window will

be darken by half. To cancel it, press SLEEP

repeatedly until dim o.

Turn off the sound temporarily

Press MUTE to mute your unit.

You can mute your unit in order, for example,

to answer the telephone, appears the MUTE in

the display window.

Last Scene Memory DVD

This unit memorizes last scene from the last

disc that is viewed. The last scene remains in

memory even if you remove the disc from the

unit or switch o the unit. If you load a disc

that has the scene memorized, the scene is

automatically recalled.

System Select - Optional

You must select the appropriate system mode

for your TV system. Press and hold X (PAUSE/

STEP) for more than ve seconds to be able

to select a system in the [Home] menu. (PAL/

NTSC)

NOTE

If the USB device is connected or a disc is inserted,

this function is not operated.

Adjust the speaker level

settings

You can adjust the sound level of each speaker.

1. Press SPEAKER LEVEL repeatedly to select

a desired speaker to set.

2. Press VOL -/+ to adjust the sound level of

the selected speaker while the level setting

memu is displayed on the display window.

3. Repeat and adjust the sound level of the

other speakers.

HT965TZ-DH_BGBRLL_ENG_4246.indd 38 2010-02-02 ¿ÀÈÄ 7:16:09

39Operation

Operation

4

Radio Operations

Be sure that both FM aerials are connected.

(Refer to the page 27)

Listening to the radio

1. Press t RADIO&INPUT until FM appears

in the display window.

The last received station is tuned in.

2. Press and hold TUNING (-/+) for about

two seconds until the frequency indication

starts to change, then release. Scanning

stops when the unit tunes in a station.

or

Press TUNING (-/+) repeatedly.

3. Adjust the volume by rotating VOLUME on

the front panel or by pressing VOL (+/- )on

the remote control repeatedly.

Presetting the Radio Stations

You can preset 50 stations for FM.

Before tuning, make sure that you have turned

down the volume.

1. Press t RADIO&INPUT until FM appears

in the display window.

2. Select the desired frequency by using

TUNING (-/+)

3. Press



ENTER a preset number will ash

in the display window.

4. Press PRESET (-/+) to select the preset

number you want.

5. Press



ENTER.

The station is stored.

6. Repeat the steps 2 to 5 to store other

stations.

Deleting all the saved stations

1. Press and hold CLEAR for two seconds.

"ERASE ALL" will ash up on the unit display.

2. Press CLEAR to erase all saved of the radio

stations.

Deleting a saved station

1. Press PRESET - / + to Select a preset

number you want to delete.

2. Press CLEAR, the preset number will blink

in the display window.

3. Press CLEAR again, to delete the selectd

preset number.

Improving poor FM reception

Press B (PLAY), MONO/STEREO on the

remote control. This will change the tuner

from stereo to mono and usually improve the

reception.

HT965TZ-DH_BGBRLL_ENG_4246.indd 39 2010-02-02 ¿ÀÈÄ 7:16:09

40 Operation

Operation

4

Seeing information about a radio

station

The FM tuner is supplied with the RDS (Radio

Data System) facility. This shows information

about the radio station being listened to. Press

RDS repeatedly to cycle through the various

data types. :

PS (Programme Service Name)

The name of the channel will appear

in the display

PTY (Programme Type Recognition)

The programme type (e.g. Jazz or

News) will appear in the display.

RT (Radio Text)

A text message contains special

information from the broadcast

station. This text may scroll across

the display.

CT (Time controlled by the channel)

This shows the time and date as

broadcast by the station.

You can search the radio stations by

programme type by pressing RDS. The display

will show the last PTY in use. Press PTY

one or more times to select your preferred

programme type. Press I i. The tuner will

search automatically, when a station is found

the search will stop.

HT965TZ-DH_BGBRLL_ENG_4246.indd 40 2010-02-02 ¿ÀÈÄ 7:16:09

41Operation

Operation

4

Sound adjustment

Setting the surround mode

This system has a number of pre-set surround

sound elds. You can select a desired sound

mode by using SOUND EFFECT.

You can change the SOUND EFFECT using

I i arrow key while the sound eect

information is displayed on.

The displayed items for the equalizer maybe

dierent depending on sound sources and

eects.

On Display Description

NAT PLUS

You can enjoy the natural

sound eect same as a

5.1-channel.

NATURAL You can enjoy comfortable

and natural sound

Local

specialization

equalizer

Regionally optimized

sound eect. (DANGDUT/

ARABIC/ PERSIAN/ INDIA/

REGUETON/ MERENGUE/

SAMBA/ SALSA/ CUMBIA/

AFRO)

AUTO EQ

Realizes the sound equalizer

that is the most similar

to the genre of which is

included in the MP3 ID3 tag

of song les.

POP

CLASSIC

JAZZ

ROCK

This program lends an

enthusiastic atmosphere to

the sound, giving you the

feeling you are at an actual

rock pop, jazz or classic

concert.

BASS

During playback, reinforce

the treble, bass and

surround sound eect.

On Display Description

CLRVOICE

This program make voice

sound clear, improving the

quality of voice sound. (We

encourage to use this EQ

when you watch the movie

of 5.1 channel.)

GAME

You can enjoy more virtual

sound while playing video

games.

NIGHT

This may be useful when

you want to watch movies

at low volume late at night.

RETOUCH

When listening to MP3 les

or other compressed music,

you can enhance the sound.

This mode is available only

to 2 channel sources.

LOUDNESS Improves the bass and

treble sound.

VIRTUAL You can enjoy more virtual

surround sound.

PLII MOVIE

PLII MUSIC

Dolby Pro Logic II enables

you to play stereo source on

5.1-channel.

BYPASS You can enjoy the sound

without equalizer eect.

NOTE

• In some of surround modes, some speakers,

there's no sound or low sound. It depends on

the mode of surround and the source of audio,

it is not defective.

• You may need to reset the surround mode,

after switching the input, sometimes even

after the sound track changed.

HT965TZ-DH_BGBRLL_ENG_4246.indd 41 2010-02-02 ¿ÀÈÄ 7:16:09

42 Operation

Operation

4

Advanced Operations

Recording to USB

You can record music or sound souce to USB

device by connecting in to the port on the

unit.

1. Connect the USB device to the unit.

2. Select a mode in which you want to record.

Play back a sound source rst.

3. Start the recording by pressing z REC.

4. To stop recording, press x (STOP).

[All tracks/ les recording]

Record to USB in stop or play mode.

[Program list recording]

After marking desired le(s) and you can

record it to USB (Refer to the page 36).

It'll be stored as follows

Audio CD

MP3/ WMA

The other

sources

(Tuner, AUX,

Portable)

NOTE

• You can check the recording percentage rate

for the USB record on the screen during the

recording. (Audio CD or MP3/ WMA CD only)

• During recording MP3/WMA, there is no

sound.

• When you stop recording during playback, the

le that has been recorded at that time will be

stored. (Audio CD only)

• Do not remove the USB device or turn o

the unit during USB recording. If not, an

incomplete le may be made and not deleted

on PC.

• If USB recording does not work, the message

like “NO USB”, “ERROR”, “USB FULL” or “NO REC” is

displayed on the display window.

• Multi card reader divice or external HDD can

not be used for USB recording.

• A le is recorded by 128 Mbyte (about 2 hours)

when you record for a long term. There are

recorded less than 4 les.

• When you stop recording during playback, the

le will not be stored.

• In the state CD-G, DTS disc USB record is not

operated.

• The les in the sub-folders are not recorded

during all track recording.

• You may not record more than 999 les.

• The nunbering of the recording le is entered

from the lowest number. So if you delete some

of the recording les, the next recording le

could be the lowest number among them.

The making of unauthorized copies of copy-

protected material, including computer

programs, les, broadcasts and sound recordings,

may be an infringement of copyrights and

constitute a criminal oense. This equipment

should not be used for such purposes.

Be responsible

Respect copyrights.

HT965TZ-DH_BGBRLL_ENG_4246.indd 42 2010-02-02 ¿ÀÈÄ 7:16:10

43Operation

Operation

4

Playing the iPod

You can enjoy the media les with your iPod.

For details about iPod, refer to the iPod’s User

Guide.

Preparation

• To view iPod’s Videos and Photos on the TV

screen.

- Be sure to use the video connection

through the VIDEO OUT jack on the rear

panel of this unit. Select the appropriate

video input mode on the TV.

- Depending on the iPod, make sure that

select Videos > Video settings, and then

set TV Out to Ask or On from your iPod.

For details about Video Settings, refer to

the iPod User Guide.

- The viewing photos is available only if this

unit is in iPod IN mode and you can view

photos only as a slide show. You have to

start a slide show on your iPod to view a

photo on a TV. For details about a slide

show, refer to the iPod User Guide.

• Before connecting the iPod, turn this unit

o and reduce the volume of this unit to its

minimum.

• Connect the iPod rmly.

To open the iPod Dock, pull iPod dock.

Connect the iPod

• If you turn this unit on, your iPod is

automatically turned on and recharging

starts.

• If your iPod is completely discharged,

charge the battery rst.

HT965TZ-DH_BGBRLL_ENG_4246.indd 43 2010-02-02 ¿ÀÈÄ 7:16:10

44 Operation

Operation

4

Enjoying iPod on the screen

You can operate your iPod by controlling menu

on the screen.

1. Connect the iPod rmly.

2. Press HOME.

3. Select [Music] or [Movie] using I/i, and

press



ENTER.

If you connected the other device

(CD or USB), select the iPod on the menu

and ENTER.

If you select the [Music] option when

you connect iPod, the unit plays a music

automatically.

4. Select a content using U/u/I/i, and press



ENTER to play.

Moving to the previous or

next le list.

File information will be displayed

according to the ID3TAG

information on the appropriate

music le. (MP3 only)

5. Operate iPod.

Refer to basic operation section.

NOTE

• If the iPod’s OSD language is selected to

simple chinese, the power scroll function is not

operated correctly.

• The controls on your iPod are not operational in

this mode.

Enjoying the iPod IN mode

You can operate your iPod by using the

supplied remote control and controls on your

iPod.

1. Connect the iPod rmly.

2. Press t RADIO&INPUT to select iPod IN

mode.

U/u/I/iSelects an option in the menu.

B (PLAY),

MONO/

STEREO

/



ENTER

Starts playback the music or

video.

XTo pause while it is playing.

To resume playing, press B

(PLAY), MONO/STEREO again.

m / M

SCAN

Fast-forward or rewind a song

or video

./>

SKIP

Skip the playback forward or

backward .

s

REPEAT

To select a desired repeat

mode: Track ( ), All ( ), O

(No display).

HT965TZ-DH_BGBRLL_ENG_4246.indd 44 2010-02-02 ¿ÀÈÄ 7:16:10

45Operation

Operation

4

NOTE

• An error message “CHECK IPOD” or “Connected

iPod model is not supported.” appears when:

- your iPod is not available for the function to be

operated.

• An error message “CHECK IPOD” or “Please

update iPod’s software.” appears when:

- your iPod has an old software version.

t Update your iPod software to latest version.

• If this unit displays an error message, follow the

message. An error message “CHECK IPOD” or

“Please check your iPod.” appears when:

- the communication between this unit and

your iPod is failed.

t Undock & re-dock your iPod in this unit.

- your iPod is not connected rmly.

- this unit recognizes your iPod as unknown

device.

- your iPod is exceptionally low on power.

t The battery needs to be charged.

t If you charge the battery while iPod is

extremely low in power, it maytake longer

to charge.

• You may use the dock adapter which should

be supplied with your iPod to the dock for the

stable use of the iPod. If you need an adapter,

consult your iPod dealer.

• Compatibility with your iPod may vary

depending on the type of your iPod.

• iPod touch and iPhone have any dierence in

operation other than iPod. You may need any

additional control to use them with this unit.

(e.g. “slide to unlock”)

• If you use an application, make a call, or send

and receive SMS text message, etc. on iPod

touch or iPhone, disconnect it from iPod dock of

this unit and then use it.

• Depending on your iPod’s software version, it

may not be possible to control your iPod from

this unit. We recommend installing the latest

software version.

• The video quality depends on the video sources

on your iPod.

• If you have a problem with your iPod, please visit

www.apple.com/support/ipod.

• You cannot use the microphone on the iPod

mode.

HT965TZ-DH_BGBRLL_ENG_4246.indd 45 2010-02-02 ¿ÀÈÄ 7:16:10

46 Maintenance

Maintenance

5

Notes on Discs

Handling Discs

Never stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not

expose the disc to direct sunlight or sources of

heat and never leave it in a parked car exposed

to direct sunlight.

Cleaning Discs

Do not use strong solvents such as alcohol,

benzine, thinner, commercially available

cleaners, or anti-static spray intended for older

vinyl records.

Handling the Unit

When shipping the unit

Please save the original shipping carton and

packing materials. If you need to ship the unit,

for maximum protection, re-pack the unit as it

was originally packed at the factory.

Keeping the exterior surfaces clean

• Do not use volatile liquids such as

insecticide spray near the unit.

• Wiping with strong pressure may damage

the surface.

• Do not leave rubber or plastic products in

contact with the unit for a long period of

time.

Cleaning the unit

To clean the player, use a soft, dry cloth. If

the surfaces are extremely dirty, use a soft

cloth lightly moistened with a mild detergent

solution. Do not use strong solvents such as

alcohol, benzine, or thinner, as these might

damage the surface of the unit.

Maintaining the Unit

The unit is a high-tech, precision device. If

the optical pick-up lens and disc drive parts

are dirty or worn, the picture quality could be

diminished. For details, please contact your

nearest authorized service center.

5

Maintenance

HT965TZ-DH_BGBRLL_ENG_4246.indd 46 2010-02-02 ¿ÀÈÄ 7:16:10

47Troubleshooting

Troubleshooting

6

PROBLEM CAUSE CORRECTION

No power The power cord is disconnected. Plug the power cord into the wall outlet

securely.

No picture

The TV is not set to receive the DVD signal.

Select the appropriate video input mode

on the TV so the picture from the unit

appears on the TV screen.

The video cables are not connected

securely.

Connect the video cables securely to both

the TV and unit.

There is little or

no sound

Equipment connected via the audio cable

is not set to receive DVD signal output.

Select the correct input mode of the unit

so you can hear the sound from the unit.

The audio cables are not connected to the

speakers or unit securely.

Connect the audio cables into the

connection terminals correctly.

The audio cables are damaged. Replace with a new audio cable.

The DVD picture

quality is poor The disc is dirty. Clean the disc using a soft cloth with

outward strokes.

A DVD/CD will

not play

No disc is inserted. Insert a disc.

An unplayable disc is inserted. Insert a playable disc (check the disc type,

colour system and regional code).

The disc is inserted upside down. Place the disc with the label or printed

side facing upwards.

There is a parental lock which prevents the

playback of DVDs with a certain rating.

Enter your password or change the rating

level.

Humming noise

heard while a

DVD or CD is

playing

The disc is dirty. Clean the disc using a soft cloth with

outward strokes.

The unit is located too close to the TV,

causing feedback.

Move unit and audio components further

away from your TV.

Radio stations

can’t be tuned in

properly

The antenna is positioned or connected

poorly.

Check the antenna connection and adjust

its position.

Attach an external aerial if necessary.

The signal strength of the radio station is

too weak. Tune to the station manually.

No stations have been preset or preset

stations have been cleared (when tuning

by scanning preset channels).

Preset some radio stations, see page 39 for

details.

The remote

control doesn’t

work well / at all

The remote is not pointed directly at the unit.

Point the remote directly at the unit.

The remote is too far from the unit. Use the remote within 23 feet (7m) of the

unit.

There is an obstacle in the path between

the remote control and the unit. Remove the obstacle.

The battery in the remote control are at. Replace the batteries with new ones.

6

Troubleshooting

HT965TZ-DH_BGBRLL_ENG_4246.indd 47 2010-02-02 ¿ÀÈÄ 7:16:10

48 Appendix

Appendix

7

7

Appendix

Language Codes

Use this list to input your desired language for the following initial settings: Disc Audio, Disc

Subtitle, Disc Menu.

Language Code Language Code Language Code Language Code

Afar 6565

Afrikaans 6570

Albanian 8381

Ameharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Javanese 7487

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laothian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

HT965TZ-DH_BGBRLL_ENG_4246.indd 48 2010-02-02 ¿ÀÈÄ 7:16:10

49Appendix

Appendix

7

Area Codes

Choose a area code from this list.

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Netherlands Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan TW

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

Area Code Area Code Area Code

HT965TZ-DH_BGBRLL_ENG_4246.indd 49 2010-02-02 ¿ÀÈÄ 7:16:10

50 Appendix

Appendix

7

Trademarks and

Licenses

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol are

trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent

#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;

6,487,535 & other U.S. and worldwide patents

issued & pending. DTS and DTS Digital Surround

are registered trademarks and the DTS logos and

Symbol are trademarks of DTS, Inc. © 1996-2007

DTS, Inc. All Rights Reserved.

HDMI, the HDMI logo and High-Denition

Multimedia Interface are trademarks or registered

trademarks of HDMI licensing LLC.

“DVD Logo” is a trademark of DVD Format/Logo

Licensing Corporation.

DivX is a registered trademark of DivX, Inc., and is

used under license.

Energy Saving ( Extremely Low Power

Consumption)

On the LG products, an innovative power

consumption system in stand-by mode is built.

It consumes less than 0.09 watts in that mode.

Therefore, the small amounts of electricity are

consumed even though the power plug is

inserted.

iPod is trademark of Apple Inc., registered in

the U.S. and other countries.

iPhone is a trademark of Apple Inc.

“Made for iPod” means that an electronic accessory

has been designed to connect specically to iPod

and has been certied by the developer to meet

Apple performance standards.

“Works with iPhone” means that an electronic

accessory has been designed to connect

specically to iPhone and has been certied by the

developer to meet Apple performance standards.

Apple is not responsible for the operation of

this device or its compliance with safety and

regulatory standards

HT965TZ-DH_BGBRLL_ENG_4246.indd 50 2010-02-02 ¿ÀÈÄ 7:16:10

51Appendix

Appendix

7

What is SIMPLINK?

Some functions of this unit are controlled

by TV’s remote control when this unit

and LG TV with SIMPLINK are connected

through HDMI connection. Controllable

functions by LG TV’s remote control; Play,

Pause, Scan, Skip, Stop, Power O, etc.

• Refer to the TV owner’s manual for the

details of SIMPLINK function.

• LG TV with SIMPLINK function has the

logo as shown above.

• Use a higher version cable than 1.2 A

HDMI cable.

Specifications

General

Power requirements:

Refer to main label

Power consumption:

Refer to main label

Dimensions (W x H x D):

430 x 62.5 x 283.6 mm without foot

Net Weight (Approx.):

3.8 kg

Operating temperature:

41 °F to 95 °F (5 °C to 35 °C)

Operating humidity:

5 % to 90 %

Bus Power supply (USB):

DC 5 V 500 mA

Inputs/ Outputs

VIDEO OUT:

1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1

COMPONENT VIDEO OUT:

(Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1,

(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2

HDMI IN/OUT (video/audio):

19 pin (HDMI standard, Type A)

HDMI version : 1.2A

ANALOG AUDIO IN:

2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1

DIGITAL IN (OPTICAL 1):

3 V (p-p), Optical jack x 1

PORT. IN:

0.5 Vrms (3.5 mm stereo jack)

Tuner

FM Tuning Range:

87.5 to 108.0 MHz or 87.50 to 108.00 MHz

•

•

•

•

•

•

•

•

•

•

•

•

•

HT965TZ-DH_BGBRLL_ENG_4246.indd 51 2010-02-02 ¿ÀÈÄ 7:16:10

52 Appendix

Appendix

7

Amplifier

Stereo mode: 180 W + 180 W (4 Ω at 1 KHz)

Surround mode:

Front 180 W + 180 W (4 Ω at 1 KHz)

Center 180 W (4 Ω at 1 KHz)

Surround 180 W + 180 W (4 Ω at 1 KHz)

Subwoofer 200 W (3 Ω at 60 Hz)

•

•

Speakers

Front speaker

Type: 2 Way 3 speaker

Impedance : 4 Ω

Rated Input Power: 180 W

Max. Input power: 360 W

Net Dimensions

(W x H x D): 280 x 1 212 x 194 mm

Net Weight: 2.5 kg

Rear speaker

Type: 2 Way 3 speaker

Impedance 4 Ω

Rated Input Power: 180 W

Max. Input power: 360 W

Net Dimensions

(W x H x D): 280 x 1 212 x 194 mm

Net Weight: 2.5 kg

Center speaker

Type: 2 Way 3 speaker

Impedance: 4 Ω

Rated Input Power: 180 W

Max. Input power: 360 W

Net Dimensions

(W x H x D): 400 x 75 x 52 mm

Net Weight: 0.55 kg

Passive Subwoofer

Type: 1 Way 1 speaker

Impedance: 3 Ω

Rated Input Power: 200 W

Max. Input power: 400 W

Net Dimensions

(W x H x D): 196 x 394 x 320 mm

Net Weight: 5.8 kg

•

•

•

•

HT965TZ-DH_BGBRLL_ENG_4246.indd 52 2010-02-02 ¿ÀÈÄ 7:16:10

53Warranty

Warranty

8

Technology with the human touch

GUARANTEE

LG Electronics U.K. Ltd. will provide the following services in order toexpedite this Guarantee.

1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period

of 12 months from the original date of purchase.

2. The dealer (or his service agent) who sold the product will be

reimbursed for any labour provided in the repair of this LG equipment, for a period of 12 months from the

original date of purchase. These claims must be made in accordance with the published scale of

service charges and relevant claims procedure.

PLEASE NOTE:

A. The dealer may restrict the guarantee to the original purchaser.

B. The dealer is not obliged to carry out service under guarantee if unauthorized modications are made to

the apparatus, or if non standard components are used or if the serial number of the apparatus is removed,

defaced, misused, or altered.

C. Any claims made under guarantee must be directed to the dealer from whom the equipment was

originally purchased. The dealer may, before carrying out service under guarantee, require a receipted

account as evidence of the date of purchase.

D. We respectfully point out that your dealer is not obligated to replace batteries if they become exhausted

or worn in use.

E. Aerial alignment and consumer control adjustments are not covered by this guarantee.

This guarantee does not aect your statutory rights.

REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:

RETAIN YOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OF YOUR RECEIPT MUST BE SURRENDERED

AT THE TIME GUARANTEE SERVICE IS PROVED.

Product Registration Card :

It is helpful to complete at least your name, address, phone, model & serial numbers and return it. This

will enable LG to assist you in the future should you lose your receipt, your units be stolen, or should

modications be necessary.

To obtain information or assistance: Call 0870 873 5454 Monday-Friday 9.00am-4.30pm

MODEL NO.* SERIAL NO.* DATE OF PURCHASE.*

•

•

•

•

In all cases of diculty - consult your LG dealer from whom the product was purchased

LGEUK Website : www.lge.co.uk

( service website : www.lgelectronics.co.uk )

HT965TZ-DH_BGBRLL_ENG_4246.indd 53 2010-02-02 ¿ÀÈÄ 7:16:10

As an ENERGY STAR® Partner,

LG has determined that this

product or product models meet

the ENERGY STAR® guidelines

for energy efficiency.

ENERGY STAR® is a U.S. registered mark.

HT965TZ-DH_BGBRLL_ENG_4246.indd 54 2010-02-02 ¿ÀÈÄ 7:16:10
