P/NO : MFL68027902 (1402-REV01)

Please read this manual carefully before operating your set and retain it

for future reference.

www.lg.com

42LB6300

47LB6300

55LB6300

60LB6300

65LB6300

47LB6350

55LB6350

42LB6500

47LB6500

50LB6500

55LB6500

60LB6500

60LB7100

65LB7100

70LB7100

55LB7200

*MFL68027902*

OWNER’S MANUAL

LED TV*

* LG LED TV applies LCD screen

with LED backlights.

Click! User Guide

ENG

ENGLISH

2IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

Always comply with the following precautions to avoid dangerous situations and ensure peak

performance of your product.

yDo not use this apparatus near water.

yClean only with a dry cloth.

yDo not block any ventilation openings. Install

in accordance with the manufacturer’s

instructions.

yDo not install near any heat sources such

as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

yDo not defeat the safety purpose of the

polarized or grounding-type plug. A polarized

plug has two blades with one wider than the

other. A grounding type plug has two blades

and a third grounding prong. The wide blade or

the third prong are provided for your safety. If

the provided plug does not fit into your outlet,

consult an electrician for replacement of the

obsolete outlet (Can differ by country).

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

WARNING/CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK DO

NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of

uninsulated dangerous voltage within the

product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

WARNING/CAUTION

- TO REDUCE THE RISK OF FIRE AND ELECTRIC

SHOCK, DO NOT EXPOSE THIS PRODUCT TO

RAIN OR MOISTURE.

WARNING

If you ignore the warning message, you may be

seriously injured or there is a possibility of accident

or death.

CAUTION

If you ignore the caution message, you may be

slightly injured or the product may be damaged.

NOTE

The note helps you understand and use the

product safely. Please read the note carefully

before using the product.

WARNING: This product contains chemicals known to

the State of California to cause cancer and birth defects

or other reproductive harm.

:DVKKDQGVDIWHUKDQGOLQJ

ENGENGLISH

3

IMPORTANT SAFETY INSTRUCTIONS

yDo not press strongly upon the panel with a hand

or a sharp object such as a nail, pencil or pen, or

make a scratch on it.

yProtect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

yOnly use attachments/accessories specified by

the manufacturer.

yUse only with a cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

yUnplug this apparatus during lightning storms or

when unused for long periods of time.

yRefer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

yDo not stick metal objects or any other

conductive material into the power cord. Do

not touch the end of the power cord while it is

plugged in.

yKeep the packing anti-moisture material or vinyl

packing out of the reach of children. Anti-moisture

material is harmful if swallowed. If swallowed

by mistake, force the patient to vomit and visit

the nearest hospital. Additionally, vinyl packing

can cause suffocation. Keep it out of the reach of

children.

yCAUTION concerning the Power Cord

(Can differ by country):

It is recommended that appliances be placed

upon a dedicated circuit; that is, a single outlet

circuit which powers only that appliance and

has no additional outlets or branch circuits.

Check the specification page of this owner’s

manual to be certain. Do not connect too many

appliances to the same AC power outlet as

this could result in fire or electric shock. Do not

overload wall outlets. Overloaded wall outlets,

loose or damaged wall outlets, extension cords,

frayed power cords, or damaged or cracked wire

insulation are dangerous. Any of these conditions

could result in electric shock or fire. Periodically

examine the cord of your appliance, and if its

appearance indicates damage or deterioration,

unplug it, discontinue use of the appliance, and

have the cord replaced with an exact replacement

part by an authorized service. Protect the power

cord from physical or mechanical abuse, such

as being twisted, kinked, pinched, closed in a

door, or walked upon. Pay particular attention to

plugs, wall outlets, and the point where the cord

exits the appliance. Do not move the TV with the

power cord plugged in. Do not use a damaged

or loose power cord. Be sure do grasp the plug

when unplugging the power cord. Do not pull on

the power cord to unplug the TV.

yWarning - To reduce the risk of fire or electrical

shock, do not expose this product to rain,

moisture or other liquids. Do not touch the TV

with wet hands. Do not install this product near

flammable objects such as gasoline or candles, or

expose the TV to direct air conditioning.

ENG

ENGLISH

4IMPORTANT SAFETY INSTRUCTIONS

yDo not expose to dripping or splashing and do

not place objects filled with liquids, such as

vases, cups, etc. on or over the apparatus (e.g. on

shelves above the unit).

yGrounding

(Except for devices which are not grounded.)

Ensure that you connect the earth ground wire to

prevent possible electric shock (i.e. a TV with a

three-prong grounded AC plug must be connected

to a three-prong grounded AC outlet). If grounding

methods are not possible, have a qualified

electrician install a separate circuit breaker. Do not

try to ground the unit by connecting it to telephone

wires, lightning rods, or gas pipes.

Short-circuit

Breaker

Power Supply

yAs long as this unit is connected to the AC wall

outlet, it is not disconnected from the AC power

source even if the unit is turned off.

yDo not attempt to modify this product in any way

without written authorization from LG Electronics.

Unauthorized modification could void the user’s

authority to operate this product.

yOutdoor Antenna Grounding

(Can differ by country):

If an outdoor antenna is installed, follow the

precautions below. An outdoor antenna system

should not be located in the vicinity of overhead

power lines or other electric light or power circuits,

or where it can come in contact with such power

lines or circuits as death or serious injury can occur.

Be sure the antenna system is grounded so as to

provide some protection against voltage surges

and built-up static charges. Section 810 of the

National Electrical Code (NEC) in the U.S.A. provides

information with respect to proper grounding of the

mast and supporting structure, grounding of the

lead-in wire to an antenna discharge unit, size of

grounding conductors, location of antenna discharge

unit, connection to grounding electrodes and

requirements for the grounding electrode.

Antenna grounding according to the National

Electrical Code, ANSI/NFPA 70

Ground Clamp

Grounding Conductor

(NEC Section 810-21)

Antenna Lead in Wire

Electric Service

Equipment

Antenna Discharge Unit

(NEC Section 810-20)

Ground Clamp

Power Service Grounding

Electrode System

(NEC Art 250, Part H)

NEC: National Electrical Code

yCleaning

When cleaning, unplug the power cord and wipe

gently with a soft cloth to prevent scratching. Do

not spray water or other liquids directly on the TV

as electric shock may occur. Do not clean with

chemicals such as alcohol, thinners or benzine.

yMoving

Make sure the product is turned off, unplugged and

all cables have been removed. It may take 2 or more

people to carry larger TVs. Do not press or put stress

on the front panel of the TV.

yVentilation

Install your TV where there is proper ventilation. Do

not install in a confined space such as a bookcase.

Do not cover the product with cloth or other materials

while plugged. Do not install in excessively dusty

places.

yIf you smell smoke or other odors coming from the

TV, unplug the power cord and contact an authorized

service center.

yKeep the product away from direct sunlight.

yNever touch this apparatus or antenna during a

thunder or lightning storm.

yWhen mounting a TV on the wall, make sure not to

install the TV by hanging the power and signal cables

on the back of the TV.

yDo not allow an impact shock or any objects to fall

into the product, and do not drop anything onto the

screen.

yDisconnecting the Main Power

The power outlet used with this device must remain

easily accessible.

yStore the accessories (battery, etc.) in a safe location

out of the reach of children.

yThis apparatus use batteries. In your community

there might be regulations that require you to dispose

of these batteries properly due to environmental

considerations. Please contact your local authorities

for disposal or recycling information.

yDo not dispose of batteries in a fire.

yDo not short circuit, disassemble or allow the

batteries to overheat.

ENGENGLISH

5

IMPORTANT SAFETY INSTRUCTIONS

yDot Defect

The Plasma or LCD panel is a high technology

product with resolution of two million to six million

pixels. In a very few cases, you could see fine dots

on the screen while you’re viewing the TV. Those

dots are deactivated pixels and do not affect the

performance and reliability of the TV.

yGenerated Sound

Cracking noise A cracking noise that occurs when

watching or turning off the TV is generated by plastic

thermal contraction due to temperature and humidity.

This noise is common for products where thermal

deformation is required.

Electrical circuit humming/panel buzzing A low level

noise is generated from a high-speed switching

circuit, which supplies a large amount of current

to operate a product. It varies depending upon the

product.

This generated sound does not affect the

performance and reliability of the product.

yTake care not to touch the ventilation openings.

When watching the TV for a long period, the

ventilation openings may become hot. This does

not affect the performance of the product or cause

defects in the product.

yDo not install this product on a wall if it could be

exposed to oil or oil mist. This may damage the

product and cause it to fall.

yIf the TV feels cold to the touch, there may be a small

flicker when it is turned on. This is normal, there is

nothing wrong with TV. Some minute dot defects

may be visible on the screen, appearing as tiny red,

green, or blue spots. However, they have no adverse

effect on the TV’s performance. Avoid touching the

LCD screen or holding your finger(s) against it for

long periods of time. Doing so may produce some

temporary distortion effects on the screen.

Preventing Image burn or Burn-in on

your TV screen

yIf a fixed image displays on the TV screen for a long

period of time, it will be imprinted and become

a permanent disfigurement on the screen. This

is image burn or burn-in and not covered by the

warranty.

yIf the aspect ratio of the TV is set to 4:3 for a long

period of time, image burn may occur on the

letterboxed area of the screen.

yAvoid displaying a fixed image on the TV screen for

a long period of time (2 or more hours for LCD, 1

or more hours for the Plasma TV) to prevent image

burn.

For USA and Canada

FCC NOTICE

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instructions, may cause harmful interference

to radio communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to

try to correct the interference by one or more of

the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the

equipment and the receiver.

- Connect the equipment to an outlet on a circuit

different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV

technician for help.

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference and (2) this device must accept any

interference received, including interference that

may cause undesired operation of the device.

Any changes or modifications in construction of

this device which are not expressly approved by

the party responsible for compliance could void

the user’s authority to operate the equipment.

NOTE TO CABLE/TV INSTALLER

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the

National Electric Code (U.S.A.). The code provides

guidelines for proper grounding and, in particular,

specifies that the cable ground shall be connected

to the grounding system of the building, as close

to the point of the cable entry as practical.

ENG

ENGLISH

6IMPORTANT SAFETY INSTRUCTIONS

Viewing 3D Imaging

(For 3D models)

WARNING

Viewing Environment

yViewing Time

-

When watching 3D contents, take 5 to

15 minute breaks every hour. Viewing 3D

contents for a long period of time may cause

headache, dizziness, fatigue or eye strain.

Those that have a photosensitive seizure or

chronic illness

ySome users may experience a seizure or

other abnormal symptoms when they are

exposed to a flashing light or particular

pattern from 3D contents.

yDo not watch 3D videos if you feel nausea,

are pregnant and/ or have a chronic illness

such as epilepsy, cardiac disorder, or blood

pressure disease, etc.

y3D Contents are not recommended to

those who suffer from stereo blindness

or stereo anomaly. Double images or

discomfort in viewing may be experienced.

yIf you have strabismus (cross-eyed),

amblyopia (weak eyesight) or astigmatism,

you may have trouble sensing depth and

easily feel fatigue due to double images. It

is advised to take frequent breaks than the

average adult.

yIf your eyesight varies between your right

and left eye, revise your eyesight prior to

watching 3D contents.

Symptoms which require discontinuation or

refraining from watching 3D contents

yDo not watch 3D contents when you feel

fatigue from lack of sleep, overwork or

drinking.

yWhen these symptoms are experienced,

stop using/watching 3D contents and get

enough rest until the symptom subsides.

- Consult your doctor when the symptoms

persist. Symptoms may include headache,

eyeball pain, dizziness, nausea, palpitation,

blurriness, discomfort, double image,

visual inconvenience or fatigue.

CAUTION

Viewing Environment

yViewing Distance

-

Maintain a distance of at least twice the

screen diagonal length when watching 3D

contents. If you feel discomfort in viewing

3D contents, move further away from the TV.

Viewing Age

yInfants / Children

- Usage/ Viewing 3D contents for children

under the age of 5 are prohibited.

- Children under the age of 10 may overreact

and become overly excited because their

vision is in development (for example: trying

to touch the screen or trying to jump into

it. Special monitoring and extra attention is

required for children watching 3D contents.

- Children have greater binocular disparity of

3D presentations than adults because the

distance between the eyes is shorter than

one of adults. Therefore they will perceive

more stereoscopic depth compared to

adults for the same 3D image.

yTeenagers

- Teenagers under the age of 19 may be

stimulated to light coming from 3D videos.

Advise them not to watch 3D videos for a

long time when they are tired.

yElderly

- The elderly may perceive less of a 3D

effect than the youth. Do not sit closer to

the TV than the recommended distance.

Cautions when using the 3D glasses

yMake sure to use LG 3D glasses.

Otherwise, you may not be able to view 3D

videos properly.

yDo not use 3D glasses instead of your

normal glasses, sunglasses or protective

goggles.

yUsing modified 3D glasses may cause eye

strain or image distortion.

yDo not keep your 3D glasses in extremely

high or low temperatures. It will cause

deformation.

yThe 3D glasses are fragile and are easy to be

scratched. Always use a soft, clean piece of

cloth when wiping the lenses. Do not scratch

the lenses of the 3D glasses with sharp

objects or clean/wipe them with chemicals.

ENGENGLISH

7

LICENSES / OPEN SOURCE SOFTWARE NOTICE

LICENSES

Supported licenses may differ by model.

For more information about licenses, visit

www.lg.com

.

OPEN SOURCE SOFTWARE NOTICE

To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained

in this product, please visit

http://opensource.lge.com

.

In addition to the source code, all referred license terms, warranty disclaimers and copyright notices

are available for download.

LG Electronics will also provide open source code to you on CD-ROM for a charge covering the

cost of performing such distribution (such as the cost of media, shipping and handling) upon email

request to

opensource@lge.com

. This offer is valid for three (3) years from the date on which you

purchased the product.

ENG

ENGLISH

8TABLE OF CONTENTS

2 IMPORTANT SAFETY

INSTRUCTIONS

6 Viewing 3D Imaging

(For 3D models)

7 LICENSES

7 OPEN SOURCE SOFTWARE

NOTICE

8 TABLE OF CONTENTS

9 INSTALLATION PROCEDURE

9 ASSEMBLING AND PREPARING

9 Unpacking

11 Optional Extras

12 Parts and Buttons

13 - Using the Joystick button

14 Lifting and Moving the TV

15 Setting Up the TV

15 - Attaching the Stand

17 - Mounting on a Table

18 - Tidying Cables

19 - Mounting on a Wall

21 MAKING CONNECTIONS

21 Connecting to an Antenna or Cable

22 Connecting to a HD receiver, DVD Player,

or VCR

22 - HDMI Connection

23 - DVI to HDMI Connection

24 - Connecting to a mobile phone

25 - Component Connection

26 - Composite Connection

27 Connecting to a PC

27 - HDMI Connection or DVI to HDMI

Connection

29 Connecting to an Audio System

29 - Digital Optical Audio Connection

30 Connecting a USB Drive

31 MAGIC REMOTE FUNCTIONS

32 Registering Magic Remote

32 How to use Magic Remote

32 Precautions to Take when Using the

Magic Remote

33 USING THE USER GUIDE

34 SPECIFICATIONS

37 EXTERNAL CONTROL DEVICE

SETUP

38 MAINTENANCE

38 Cleaning Your TV

38 - Screen, Frame, Cabinet, and Stand

38 - Power Cord

38 TROUBLESHOOTING

TABLE OF CONTENTS

yImage shown may differ from your TV.

yYour TV’s OSD (On Screen Display) may

differ slightly from that shown in this

manual.

yThe available menus and options may

differ from the input source or product

model that you are using.

yNew features may be added to this TV in

the future.

NOTE

ENGENGLISH

9

INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING

INSTALLATION PROCEDURE

1 Open the package and make sure all the accessories are included.

2 Attach the stand to the TV set.

3 Connect an external device to the TV set.

4 Make sure the network connection is available.

You can use the TV network functions only when the network connection is made.

* When the TV is turned on for the first time after being shipped from the factory, initialization of

the TV may take up to one minute.

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the

local dealer where you purchased your product. The illustrations in this manual may differ from the

actual product and item.

yDo not use any unapproved items to ensure the safety and product life span.

yAny damages or injuries by using unapproved items are not covered by the warranty.

yIn case of some model, the thin film on screen is a part of TV, So don’t take it off.

CAUTION

yThe items supplied with your product may vary depending upon the model.

yProduct specifications or contents of this manual may be changed without prior notice due to

upgrade of product functions.

yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm

(0.39 inches) thick and 18 mm (0.7 inches) width.

yUse an extension cable that supports USB 2.0 if the USB cable or USB FLASH DRIVE does not

fit into your TV’s USB port.

B

AA

B

*A 10 mm (0.39 inches)

*B 18 mm (0.7 inches)

NOTE

ENG

ENGLISH

10 ASSEMBLING AND PREPARING

Magic Remote,

Batteries (AA)

(See page 31.)

Owner’s Manual Power Cord

(Depending upon model)

(For 42LB6300, 42LB6500)

Tag On

Tag On

(Depending upon model)

Wall Mount Spacer

2 EA

(See page 20.)

Stand Screws

4 EA, M4 x L14

(See page 15, 16.)

Cable Holder

(Depending upon model)

(See page 18.)

Cable Management

2 EA

(See page 18.)

Cinema 3D Glasses

The number of 3D glasses

may differ depending upon

the model or country.

(For 42/47/55LB6300,

47/55LB6350,

42/47/50/55LB6500)

(For 60/65LB6300,

60LB6500,

60/65/70LB7100,

55LB7200)

Stand Base

(See page 16.)

Stand Base/Stand Body

(See page 15.)

ENGENGLISH

11

ASSEMBLING AND PREPARING

Optional Extras

Optional extras can be changed or modified for quality improvement without any notification.

Contact your dealer for buying these items.

These devices only work with certain models.

The model name or design may be changed manufacturer’s circumstances or policies.

AN-MR500

Magic Remote

AG-F***

Cinema 3D Glasses

AN-VC5**

Video Call Camera

AG-F***DP

Dual Play Glasses

LG Audio Device Tag On

AN-BL***

Wireless IR Blaster

(Depending upon model)

AN-WF500

Wi-Fi/Bluetooth DONGLE

(Depending upon model)

ENG

ENGLISH

12 ASSEMBLING AND PREPARING

Parts and Buttons

Screen

Joystick Button2

yRemoving the protective film on the bottom of the TV

(Depending upon model)



» The protective film was applied to the TV face to protect it from

scratches and other damage during shipping.



» When the TV is installed, peel the film off the bottom of the

cabinet.

NOTE

1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding

environment.

2 Joystick button is located below the screen of TV.

(For 42/47/55LB6300, 47/55LB6350,

42/47/50/55LB6500)

Power Indicator

Speakers Remote Control Sensor and

Intelligent Sensor1

(For 60/65LB6300, 60LB6500,

60/65/70LB7100, 55LB7200)

Screen

Joystick Button2

Power Indicator

Speakers Remote Control Sensor and

Intelligent Sensor1

ENGENGLISH

13

ASSEMBLING AND PREPARING

Using the Joystick button

You can operate the TV by pressing the button or moving the joystick left, right, up, or down.

Basic functions

Power On When the TV is turned off, place your finger on the joystick button and press

it once and release it.

Power Off When the TV is turned on, place your finger on the joystick button and press

it once for a few seconds and release it.

Volume Control If you place your finger over the joystick button and move it left or right, you

can adjust the volume level you want.

Channels Control If you place your finger over the joystick button and move it up or down, you

can scrolls through the saved channels you want.

yWhen your finger over the joystick button and push it up, down, left or right, be careful not to

press the joystick button. If you press the joystick button first, you can not adjust the volume

level and saved channels.

NOTE

Adjusting the menu

When the TV is turned on, press the joystick button one time.

You can adjust the Menu items ( , , ) moving the joystick button left or right.

TV Off Turns the power off.

CLOSE Clears on-screen displays and returns to TV viewing.

INPUT Changes the input source.

ENG

ENGLISH

14 ASSEMBLING AND PREPARING

Lifting and Moving the TV

When moving or lifting the TV, read the following

to prevent the TV from being scratched or

damaged and for safe transportation regardless

of its type and size.

yAvoid touching the screen at all times, as

this may result in damage to the screen.

yDo not place the product on the floor with

its front facing down without padding.

Failure to do so may result in damage to

the screen.

CAUTION

yIt is recommended to move the TV in the

box or packing material that the TV originally

came in.

yBefore moving or lifting the TV, disconnect

the power cord and all cables.

yWhen holding the TV, the screen should

face away from you to avoid damage.

yHold the top and bottom of the TV frame

firmly. Make sure not to hold the transparent

part, speaker, or speaker grill area.

yUse at least two people to move a large

TV.

yWhen transporting the TV by hand,

hold the TV as shown in the following

illustration.

yWhen handling the TV, be careful not to

damage the protruding joystick button.

yWhen transporting the TV, do not expose

the TV to jolts or excessive vibration.

yWhen transporting the TV, keep the TV

upright; never turn the TV on its side or tilt

towards the left or right.

ENGENGLISH

15

ASSEMBLING AND PREPARING

1

2

Setting Up the TV

You can mount your TV to a wall or attach the stand if you wish to place the TV on an entertainment

center or other furniture.

Attaching the Stand

If you are not mounting the TV to a wall, use the following instructions to attach the stand.

yWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or

flat surface to protect the screen from scratches.

yMake sure that the screws are fastened tightly. (If they are not fastened securely enough, the

TV may tilt forward after being installed.)

yDo not tighten the screws with too much force; otherwise they may be damaged and come

loose later.

CAUTION

yRemove the stand before installing the TV on a wall mount by performing the stand attachment

in reverse.

NOTE

B stand base

A stand base

(For 60/65LB6300, 60LB6500,

60/65/70LB7100, 55LB7200)

Stand Base/

Stand Body

3

4 EA

M4 x L14

1 Attach the stand to the TV using the upper

mounting hole on the back of the TV.

2 Attach the stand to the TV using the lower

connection on the back of the TV.

1

2

ENG

ENGLISH

16 ASSEMBLING AND PREPARING

1

2

(For 42/47/55LB6300, 47/55LB6350,

42/47/50/55LB6500)

Stand Base

B stand base

A stand base

4 EA

M4 x L14

3

Using the Kensington security system

(optional)

(Depending upon model)

yImage shown may differ from your TV.

The Kensington security system connector is

located at the rear of the TV.

For more information of installation and

using, refer to the manual provided with the

Kensington security system or visit

http://www.

kensington.com

.

Connect the Kensington security system cable

between the TV and a table.

yThe Kensington security system is optional.

You can obtain additional accessories from

your local dealer.

NOTE

1

2

1 Attach the stand to the TV using the upper

mounting hole on the back of the TV.

2 Attach the stand to the TV using the lower

connection on the back of the TV.

ENGENGLISH

17

ASSEMBLING AND PREPARING

Mounting on a Table

1 Lift and tilt the TV into its upright position on

a table.

- Leave a 10 cm (4 inch) (minimum) space

from the wall for proper ventilation.

10 cm

10 cm

10 cm

10 cm

(4 inches)

2 Connect the power cord to a wall outlet.

yDo not place the TV near or on sources

of heat, as this may result in fire or other

damage.

CAUTION

Securing the TV to a wall (optional)

(Depending upon model)

1 Insert and tighten the eye-bolts, or TV

brackets and bolts on the back of the TV.

- If there are bolts inserted at the eye-bolts

position, remove the bolts first.

2 Mount the wall brackets with the bolts to

the wall.

Match the location of the wall bracket and

the eye-bolts on the rear of the TV.

3 Connect the eye-bolts and wall brackets

tightly with a sturdy rope or cable.

Make sure to keep the rope parallel to the

flat surface.

yMake sure that children do not climb on

or hang on the TV.

CAUTION

yUse a platform or cabinet that is strong

and large enough to support the TV

securely.

yBrackets, bolts, and ropes are optional.

You can obtain additional accessories

from your local dealer.

NOTE

ENG

ENGLISH

18 ASSEMBLING AND PREPARING

Tidying Cables

1 Gather and bind the cables with the cable

holder.

2 Gather and bind the cables with the cable

management.

(For 60/65LB6300, 60LB6500, 60/65LB7100,

55LB7200)

Cable Holder

Cable

Management

(For 70LB7100)

Cable

Management

Cable Holder

yDo not move the TV by holding the cable

holder and cable management, as the

cable holders may break, and injuries and

damage to the TV may occur.

CAUTION

(For 42/47/55LB6300, 47/55LB6350,

42/47/50/55LB6500)

1 Gather and bind the cables with the cable

holder.

2 Gather and bind the cables with the cable

management.

Cable Holder

Cable

Management

yDo not move the TV by holding the cable

holder and cable management, as the

cable holders may break, and injuries and

damage to the TV may occur.

CAUTION

ENGENGLISH

19

ASSEMBLING AND PREPARING

Mounting on a Wall

An optional wall mount can be used with your

LG Television. Consult with your local dealer for

a wall mount that supports the VESA standard

used by your TV model. Carefully attach the wall

mount bracket at the rear of the TV. Install the

wall mount bracket on a solid wall perpendicular

to the floor. If you are attaching the TV to other

building materials, please contact qualified

personnel to install the wall mount. Detailed

instructions will be included with the wall

mount. We recommend that you use an LG

brand wall mount.

10 cm

10 cm

10 cm

10 cm

(4 inches)

Make sure to use screws and wall mounts that

meet the VESA standard. Standard dimensions

for the wall mount kits are described in the

following table.

Model 42/47/55LB6300

47/55LB6350

42/47/50/55LB6500

VESA (A x B)

A

B

400 x 400

Standard screw M6

Number of screws 4

Wall mount bracket

(optional)

MSW240

LSW440B

Model 60/65LB6300

60LB6500

60/65LB7100

55LB7200

VESA (A x B)

A

B

400 x 400

Standard screw M6

Number of screws 4

Wall mount bracket

(optional)

LSW440B

Model 70LB7100

VESA (A x B)

A

B

600 x 400

Standard screw M6

Number of screws 4

Wall mount bracket

(optional)

LSW640B

Wall mount bracket (optional)

LSW440B

LSW640B

MSW240

ENG

ENGLISH

20 ASSEMBLING AND PREPARING

yDisconnect the power first, and then

move or install the TV. Otherwise electric

shock may occur.

yIf you install the TV on a ceiling or slanted

wall, it may fall and result in severe injury.

Use an authorized LG wall mount and

contact the local dealer or qualified

personnel.

yDo not over tighten the screws as this

may cause damage to the TV and void

your warranty.

yUse the screws and wall mounts that

meet the VESA standard. Any damages

or injuries by misuse or using an improper

accessory are not covered by the

warranty.

CAUTION

yUse the screws that are listed on the VESA

standard screw specifications.

yThe wall mount kit includes an installation

manual and necessary parts.

yThe wall mount bracket is optional. You can

obtain additional accessories from your local

dealer.

yThe length of screws may differ depending

upon the wall mount. Make sure to use the

proper length.

yFor more information, refer to the manual

supplied with the wall mount.

yWhen attaching a wall mounting bracket to

the TV, insert the wall mount spacers into

the TV wall mount holes to adjust the vertical

angle of the TV.

(For 42LB6300, 42LB6500)

NOTE

Wall Mount

Spacers

ENGENGLISH

21

MAKING CONNECTIONS

MAKING CONNECTIONS

yThis section uses illustrations of the LB7100 series.

You can connect various external devices to the TV. Supported external devices are: HD receivers,

DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external

devices. For more information on external device’s connection, refer to the manual provided with

each device.

yIf you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal

input cable to the TV through a DVD recorder or VCR. For more information of recording, refer

to the manual provided with the connected device.

yThe external device connections shown may differ slightly from illustrations in this manual.

yConnect external devices to the TV regardless of the order of the TV port.

yIf you connect a gaming device to the TV, use the cable supplied with the gaming device.

yRefer to the external equipment’s manual for operating instructions.

NOTE

Connecting to an Antenna or Cable

Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations

may differ from the actual items and a RF cable is optional.

yMake sure not to bend the copper wire

of the RF cable.

yComplete all connections between

devices, and then connect the power

cord to the power outlet to prevent

damage to your TV.

CAUTION

Copper wire

yUse a signal splitter to use 2 TVs or more.

yDTV Audio Supported Codec: MPEG,

Dolby Digital.

NOTE

ANTENNA/

CABLE IN

VHF Antenna

UHF Antenna

Antenna

Coaxial (75Ω)

Terminal

(*Not Provided)

ENG

ENGLISH

22 MAKING CONNECTIONS

Connecting to a HD receiver, DVD Player, or VCR

Connect a HD receiver, DVD Player, or VCR to the TV and select an appropriate input mode.

HDMI Connection

HDMI is the best way to connect a device.

Transmits the digital video and audio signals from an external device to the TV. Connect the external

device and the TV with the HDMI cable as shown in the following illustration.

yUse the latest High Speed HDMI™ Cable with CEC (Customer Electronics Control) function.

yHigh Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.

yHDMI Audio Supported Format: PCM (Up to 192 kHz, 32 kHz / 44.1 kHz / 48 kHz / 88 kHz / 96

kHz / 176 kHz / 192 kHz)

NOTE

HDMI

IN

1

(ARC)

IN

3

(MHL)

IN

2

DVD / Blu-Ray / HD Cable Box / HD STB

Choose any HDMI input port to connect.

It does not matter which port you use.

(*Not Provided)

ARC (Audio Return Channel)

yWhen connected with a high-speed HDMI cable,

digital audio can be sent to a compactible device

without an additional optical audio cable.

yARC is only supported on the HDMI IN 1(ARC) port.

An external audio device that supports ARC should

be connected to HDMI IN 1(ARC) if you wish to use

ARC.

ENGENGLISH

23

MAKING CONNECTIONS

AUDIO OUT

DVI OUT

VIDE

O

/

PC-AUDIO I

N

L/MONO

A

UDI

O

R

COMPONENT IN

/AV IN

IN

1

(ARC)

IN

3

(MHL)

IN

2

Y

P

P

B

B

P

P

R

R

DVI to HDMI Connection

Transmits the digital video signal from an external device to the TV. Connect the external device and

the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal,

connect an audio cable.

yWhen using the HDMI/DVI cable, Single link is only supported.

NOTE

Choose any HDMI input port to connect.

It does not matter which port you use.

WHITE

RED

(*Not Provided)

(*Not Provided)

DVD / Blu-Ray / HD Cable Box

ENG

ENGLISH

24 MAKING CONNECTIONS

Connecting to a mobile phone

Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from

mobile phones to television sets.

yConnect the mobile phone to the HDMI IN 3 (MHL) port to view the phone screen on the TV.

yThis only works for the MHL-enabled phone.

yWith some MHL supporting mobile phones, you can use the TV remote to control the phone.

yAn MHL passive cable is needed to connect the TV and a mobile phone.

yRemove the MHL cable from the TV when:

- the MHL function is disabled.

- your mobile device is fully charged in standby mode.

NOTE

(*Not Provided)

MHL Cable

Mobile phone

IN

3

(MHL)

ENGENGLISH

25

MAKING CONNECTIONS

Component Connection

Transmits analog video and audio signals from an external device to the TV. Connect the external

device and the TV with a component cable as shown in the following illustration.

yIf cables are installed incorrectly, it could cause the image to display in black and white or with

distorted color.

yCheck to ensure the cables are matched with the corresponding color connection.

NOTE

AUDIO

VIDEO

LR

P

C

-AUDI

O

I

N

L/MONO

AU

DI

O

R

COMPONENT IN

/AV IN

VIDE

O

/

Y

P

P

B

B

P

P

R

R

(*Not Provided)

(*Not Provided)

DVD / Blu-Ray / HD Cable Box

GREEN GREEN

BLUE BLUE

RED RED

RED RED

WHITE WHITE

ENG

ENGLISH

26 MAKING CONNECTIONS

PC-AUDIO I

N

L/MONO

A

UDI

O

R

COMPONENT IN

/AV IN

VIDEO

MONO

( )

AUDIOLR

/

Y

P

P

B

B

P

P

R

R

Composite Connection

Transmits analog video and audio signals from an external device to the TV. Connect the external

device and the TV with the composite cable as shown in the following illustration.

yIf you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of

the TV.

yCheck to ensure the cables are matched with the corresponding color connection.

NOTE

VCR / DVD / Blu-Ray / HD Cable Box

YELLOW

RED

WHITE

YELLOW

RED

WHITE

(*Not Provided)

ENGENGLISH

27

MAKING CONNECTIONS

Connecting to a PC

yUse an HDMI connection for the best image quality.

yDepending upon the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use.

yIn PC mode, there may be noise associated with the resolution, vertical pattern, contrast or

brightness. If noise is present, change the PC output to another resolution, change the refresh

rate to another rate or adjust the brightness and contrast on the PICTURE menu until the picture

is clear.

yThe synchronization input form for horizontal and vertical frequencies is separate.

yDepending upon the graphics card, some resolution settings may not allow the image to be

positioned on the screen properly.

yIf you are using DVI out from a PC, you have to connect analog audio separately. Refer to the

instructions on the next page.

yWhen using the HDMI/DVI cable, Single link is only supported.

NOTE

HDMI Connection or DVI to HDMI Connection

Choose method A or B to make connection.

Method A: HDMI Connection

IN

1

(ARC)

IN

3

(MHL)

IN

2

HDMI

(*Not Provided)

PC

Choose any HDMI input port to connect.

It does not matter which port you use.

ENG

ENGLISH

28 MAKING CONNECTIONS

Method B: DVI to HDMI Connection

IN

1

(ARC)

IN

3

(MHL)

IN

2

AUDIO OUT DVI OUT

P

C

-AUDI

O

I

N

L/MONO A

U

DI

O

R

COMPONENT IN

/AV IN

VIDE

O

/

Y

P

P

B

B

P

P

R

R

(*Not Provided)

PC

(*Not Provided)

WHITE

RED

Choose any HDMI input port to connect.

It does not matter which port you use.

ENGENGLISH

29

MAKING CONNECTIONS

OPTICAL AUDIO IN

OPTICAL

DIGITAL

AUDIO OUT

Digital Audio System

(*Not Provided)

Connecting to an Audio System

You may use an optional external audio system instead of the built-in speaker.

Digital Optical Audio Connection

Transmits a digital audio signal from the TV to an external device. Connect the external device and

the TV with the optical audio cable as shown in the following illustration.

yDo not look into the optical output port. Looking at the laser beam may damage your vision.

yAudio with ACP (Audio Copy Protection) function may block digital audio output.

NOTE

ENG

ENGLISH

30 MAKING CONNECTIONS

USB IN 2

USB IN 3

USB IN 1

(*Not Provided)

Choose any USB input port to connect.

It does not matter which port you use.

USB

USB HUB

Connecting a USB Drive

Connect a USB storage device such as a USB flash thumbdrive, external hard drive, or a USB

memory card reader to the TV and access the SmartShare menu to use various multimedia files.

ySome USB Hubs may not work. If a USB device connected using a USB Hub is not detected,

connect it to the USB port on the TV directly.

NOTE

ENGENGLISH

31

MAGIC REMOTE FUNCTIONS

MAGIC REMOTE FUNCTIONS

When the message

Magic remote control battery is low. Change the battery

.

is displayed, replace the battery. To install batteries, open the battery cover,

replace batteries (1.5 V AA) matching and ends to the label inside the

compartment, and close the battery cover. Failure to match the correct polarities

of the battery may cause the battery to burst or leak, resulting in fire, personal

injury, or ambient pollution. Be sure to point the remote control at the remote control sensor on the

TV. To remove the batteries, perform the installation actions in reverse.

yDo not mix old and new batteries, as this may damage the remote control.

CAUTION

This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote

sensor.

(POWER)

Turns the TV on or off.

Navigation buttons

(up/down/left/right)

Press the up, down, left or right button

to scroll the menu.

If you press buttons while

the pointer is in use, the pointer will

disappear from the screen and Magic

Remote will operate like a general

remote control.

To display the pointer on the screen

again, shake Magic Remote to the left

and right.

(Smarthome)

Accesses the Smarthome menu.

(BACK)

Returns to the previous screen.

#(EXIT to LIVE)

Switches among broadcast (antenna) and

various inputs.

Wheel (OK)

Press the center of the Wheel button

to select a menu.

You can change channels and scroll

the menu by using the Wheel

button.

VOL

Adjusts the volume level.

/INPUT

Displays the Screen Remote.

* Accesses the Universal Control Menu in

some regions.

* Pressing and holding the button will

display a menu to select an external device

that is connected to the TV.

Used for viewing 3D video.

(MUTE)

Mutes all sounds.

* By pressing and holding the button,

VD function will be enabled.

SAP(Secondary Audio Program) Feature can

also be enabled by pressing the key.

.

CH

Scrolls through the saved channels.

/INPUT

VOL CH

(Voice recognition)

Network connection is required to use

the voice recognition function.

1. Press the voice recognition button.

2. Speak when the voice display

window appears on the left of the TV

screen.

* Use the Magic Remote no further

than 10 cm (4 inch) from your face.

* The voice recognition may fail when

you speak too fast or too slowly.

* The recognition rate may vary

depending upon the user’s

characteristics (voice, pronunciation,

intonation, and speed) and the

environment (noise and TV volume).

Color buttons

These access special functions in

some menus.

(: Red, : Green, : Yellow,

: Blue)

ENG

ENGLISH

32 MAGIC REMOTE FUNCTIONS

Registering Magic Remote

The Magic Remote operates by pairing with

your TV.

How to register the Magic Remote

(Wheel)

To use the Magic Remote, first pair it

with your TV.

1 Put batteries into the Magic Remote

and turn the TV on.

2 Point the Magic Remote at your TV

and press the Wheel (OK) on the

remote control.

* If the TV fails to register the Magic

Remote, try again after turning the TV

off and back on.

How to deregister the Magic Remote

(BACK)

(Smart

home)

Press the (BACK) and

(Smarthome) at the same time, for five

seconds, to unpair the Magic Remote

with your TV.



»Pressing and holding the (EXIT to

LIVE) button will let you cancel and

re-register Magic Remote at once.

How to use Magic Remote

yShake the Magic Remote slightly to

the right and left or press

(Smarthome), /INPUT, buttons to

make the pointer appear on the

screen.

(In some TV models, the pointer will

appear when you turn the Wheel

button.)

y If the pointer has not been used for

a certain period of time or Magic

Remote is placed on a flat surface,

then the pointer will disappear.

y If the pointer does not move as you

wish, shake Magic Remote to the

left and right. The pointer will move

to the center of the screen.

y The Magic Remote depletes

batteries faster than a normal remote

due to the additional features.

Precautions to Take when Using

the Magic Remote

yUse the Magic remote within the maximum

communication distance (10 m, 32.8 ft). Using the

remote control beyond this distance, or with an

object obstructing it, may cause a communication

failure.

yA communication failure may occur due to nearby

devices. Electrical devices such as a microwave

oven or wireless LAN product may cause

interference, as these use the same bandwidth (2.4

GHz) as the Magic remote.

yThe Magic remote may be damaged or may

malfunction if it is dropped or receives a heavy

impact.

yTake care not to bump into nearby furniture or other

people when using the Magic remote.

yManufacturer and installer cannot provide service

related to human safety as the applicable wireless

device has possibility of electric wave interference.

yIt is recommended that an Access Point (AP) be

located more than 1 m (3.28 ft) away from the TV.

If the AP is installed closer than 1 m (3.28 ft), the

Magic remote may not perform as expected due to

frequency interference.

ENGENGLISH

33

USING THE USER GUIDE

USING THE USER GUIDE

User Guide allows you to easily access detailed

TV information.

1 Press (Smarthome) button to access the

Smarthome menu.

2 Select

User Guide and press the Wheel

(OK) button.

Ö

ENG

ENGLISH

34 SPECIFICATIONS

SPECIFICATIONS

Product specifications may be changed without prior notice due to upgrade of product functions.

Power requirement AC 100 - 240 V ~ 50 / 60 Hz

AC 120V ~ 50 / 60 Hz (For 70LB7100)

Television System NTSC-M, ATSC, 64 & 256 QAM

Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135

External Antenna Impedance 75 Ω

Environment

condition

Operating

Temperature

0 - 40 °C (32 °F ~ 104 °F)

Operating

Humidity

Less than 80 %

Storage

Temperature

-20 - 60 °C (- 4 °F ~ 140 °F)

Storage

Humidity

Less than 85 %

MODELS 42LB6300

(42LB6300-UQ)

47LB6300

(47LB6300-UQ)

47LB6350

(47LB6350-UQ)

Dimensions

(W x H x D)

With stand 960 x 612 x 193 (mm) 1,072 x 675 x 230 (mm)

37.7 x 24 x 7.5 (inch) 42.2 x 26.5 x 9.0 (inch)

Without stand 960 x 567 x 54.5 (mm) 1,072 x 629 x 54.5 (mm)

37.7 x 22.3 x 2.1 (inch) 42.2 x 24.7 x 2.1 (inch)

Weight With stand 9.9 kg (21.8 Ibs) 13.3 kg (29.3 Ibs)

Without stand 9.6 kg (21.1 Ibs) 13.0 kg (28.6 Ibs)

Current Value / Power consumption 1.0 A / 100 W 1.1 A / 110 W

MODELS

55LB6300

(55LB6300-UQ) 60LB6300

(60LB6300-US)

55LB6350

(55LB6350-UQ)

Dimensions

(W x H x D)

With stand 1,241 x 769 x 224 (mm) 1,351 x 833 x 289 (mm)

48.8 x 30.2 x 8.8 (inch) 53.1 x 32.7 x 11.3 (inch)

Without stand 1,241 x 725 x 55.5 (mm) 1,351 x 785 x 57.5 (mm)

48.8 x 28.5 x 2.1 (inch) 53.1 x 30.9 x 2.2 (inch)

Weight With stand 18.6 kg (41 Ibs) 22.5 kg (49.6 Ibs)

Without stand 18.3 kg (40.3 Ibs) 21.8 kg (48 Ibs)

Current Value / Power consumption 1.3 A / 130 W 1.3 A / 130 W

ENGENGLISH

35

SPECIFICATIONS

MODELS 65LB6300

(65LB6300-UE)

Dimensions

(W x H x D)

With stand 1,462 x 898 x 314 (mm)

57.5 x 35.3x 12.3 (inch)

Without stand 1,462 x 850 x 59.2 (mm)

57.5 x 33.4 x 2.3 (inch)

Weight With stand 30.5 kg (67.2 Ibs)

Without stand 29 kg (63.9 Ibs)

Current Value / Power consumption 1.9 A / 190 W

MODELS 42LB6500

(42LB6500-UM)

47LB6500

(47LB6500-UM)

Dimensions

(W x H x D)

With stand 960 x 612 x 193 (mm) 1,072 x 675 x 230 (mm)

37.7 x 24 x 7.5 (inch) 42.2 x 26.5 x 9 (inch)

Without stand 960 x 567 x 54.5 (mm) 1,072 x 629 x 54.5 (mm)

37.7 x 22.3 x 2.1 (inch) 42.2 x 24.7 x 2.1 (inch)

Weight With stand 9.9 kg (21.8 Ibs) 13.3 kg (29.3 Ibs)

Without stand 9.6 kg (21.1 Ibs) 13.0 kg (28.6 Ibs)

Current Value / Power consumption 1.0 A / 100 W 1.1 A / 110 W

MODELS 50LB6500

(50LB6500-UM)

55LB6500

(55LB6500-UM)

Dimensions

(W x H x D)

With stand 1,127 x 710 x 230 (mm) 1,241 x 769 x 224 (mm)

44.3 x 27.9 x 9 (inch) 48.8 x 30.2 x 8.8 (inch)

Without stand 1,127 x 660 x 54.5 (mm) 1,241 x 725 x 55.5 (mm)

44.3 x 25.9 x 2.1 (inch) 48.8 x 28.5 x 2.1 (inch)

Weight With stand 14.6 kg (32.1 Ibs) 18.6 kg (41 Ibs)

Without stand 14.3 kg (31.5 Ibs) 18.3 kg (40.3 Ibs)

Current Value / Power consumption 1.2 A / 120 W 1.3 A / 130 W

MODELS 60LB6500

(60LB6500-UP)

Dimensions

(W x H x D)

With stand 1,351 x 833 x 289 (mm)

53.1 x 32.7 x 11.3 (inch)

Without stand 1,351 x 785 x 57.5 (mm)

53.1 x 30.9 x 2.2 (inch)

Weight With stand 22.5 kg (49.6 Ibs)

Without stand 21.8 kg (48 Ibs)

Current Value / Power consumption 1.3 A / 130 W

ENG

ENGLISH

36 SPECIFICATIONS

MODELS 60LB7100

(60LB7100-UT)

65LB7100

(65LB7100-UB)

Dimensions

(W x H x D)

With stand 1,351 x 833 x 289 (mm) 1,462 x 898 x 314 (mm)

53.1 x 32.7 x 11.3 (inch) 57.5 x 35.3 x 12.3 (inch)

Without stand 1,351 x 785 x 57.5 (mm) 1,462 x 850 x 59.2 (mm)

53.1 x 30.9 x 2.2 (inch) 57.5 x 33.4 x 2.3 (inch)

Weight With stand 22.5 kg (49.6 Ibs) 30.5 kg (67.2 Ibs)

Without stand 21.8 kg (48 Ibs) 29 kg (63.9 Ibs)

Current Value / Power consumption 1.5 A / 150 W 1.9 A / 190 W

MODELS 70LB7100

(70LB7100-UC)

Dimensions

(W x H x D)

With stand 1,574 x 964 x 344 (mm)

61.9 x 37.9 x 13.5 (inch)

Without stand 1,574 x 916 x 60.2 (mm)

61.9 x 36 x 2.3 (inch)

Weight With stand 31.6 kg (69.6 Ibs)

Without stand 30.1 kg (66.3 Ibs)

Current Value / Power consumption 2.6 A / 260 W

MODELS 55LB7200

(55LB7200-UB)

Dimensions

(W x H x D)

With stand 1,231 x 769 x 247 (mm)

48.4 x 30.2 x 9.7 (inch)

Without stand 1,231 x 718 x 55.1 (mm)

48.4 x 28.2 x 2.1 (inch)

Weight With stand 19 kg (41.8 Ibs)

Without stand 18.5 kg (40.7 Ibs)

Current Value / Power consumption 1.3 A / 130 W

ENGENGLISH

37

SPECIFICATIONS / EXTERNAL CONTROL DEVICE SETUP

Wireless module (LGSBW41) Specifications

Wireless Lan Bluetooth

Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0

Frequency Range

2400 to 2483.5 MHz

5150 to 5250 MHz

5725 to 5850 MHz

Frequency Range 2400 to 2483.5MHz

Output PoweU (Max.)

802.11a: 11.5 dBm

802.11b: 11 dBm

802.11g: 10.5 dBm

802.11n - 2.4GHz: 11 dBm

802.11n - 5GHz: 12.5 dBm

Output Power (Max.) 10 dBm or Lower

yBecause band channel used by the country could be different, the user can not change or

adjust the operating frequency and this product is set for the regional frequency table.

yThis device should be installed and operated with minimum distance 20 cm (7.8 inch)

between the device and your body. And this phrase is for the general statement for

consideration of user environment.

yContains FCC ID: BEJLGSBW41 / Contains IC: 2703H-LGSBW41

EXTERNAL CONTROL DEVICE SETUP

To obtain the external control device setup information, please visit

www.lg.com

.

ENG

ENGLISH

38 MAINTENANCE / TROUBLESHOOTING

MAINTENANCE

Cleaning Your TV

Clean your TV regularly to keep it at peak performance and to extend the product lifespan.

yMake sure to turn the power off and disconnect the power cord and all other cables first.

yWhen the TV is left unattended or unused for a long time, disconnect the power cord from the

wall outlet to prevent possible damage from lightning or power surges.

CAUTION

Screen, Frame, Cabinet, and Stand

To remove dust or light dirt, wipe the surface with a dry, clean, and soft cloth.

To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild

detergent. Then wipe immediately with a dry cloth.

yDo not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in

scratches on the screen and image distortions.

yDo not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air

fresheners, or lubricants, as these may damage the screen’s finish and cause discoloration.

yDo not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock,

or malfunction.

CAUTION

Power Cord

Remove the accumulated dust or dirt on the power cord regularly.

TROUBLESHOOTING

Problem Solution

Cannot control the TV with

the remote control.

yCheck the remote control sensor on the product and try again.

yCheck if there is any obstacle between the product and the remote control.

yCheck if the batteries are still working and properly installed ( to , to ).

No image display and no

sound is produced.

yCheck if the product is turned on.

yCheck if the power cord is connected to a wall outlet.

yCheck if there is a problem in the wall outlet by connecting other products.

The TV turns off suddenly.

yCheck the power control settings. The power supply may be interrupted.

yCheck if the Sleep Timer/Timer Power off is activated in the TIMERS settings.

yIf there is no signal while the TV is on, the TV will turn off automatically after 15

minutes of inactivity.

THE CONSUMER ELECTRONICS INDUSTRY CARES

BVcj[VXijgZgh! gZiV^aZgh VcY i]Z gZhi d[ i]Z XdchjbZg ZaZXigdc^Xh ^cYjhign VgZ Xdbb^iiZY id

bV`^c\]dbZZciZgiV^cbZcihV[ZVcYZc_dnVWaZ#

6hndjZc_dnndjgiZaZk^h^dc!eaZVhZcdiZi]ViVaaiZaZk^h^dch¸cZlVcYdaY"bjhiWZhjeedgiZYdc

egdeZghiVcYhdg^chiVaaZYVXXdgY^c\idi]ZbVcj[VXijgZg½hgZXdbbZcYVi^dch#IZaZk^h^dchi]Vi

VgZ^cVeegdeg^ViZanh^ijViZYdcYgZhhZgh!Wdd`XVhZh!h]ZakZh!YZh`h!heZV`Zgh!X]Zhih!XVgih!ZiX#!

bVn[VaadkZg!gZhjai^c\^c^c_jgn#

TUNE IN TO SAFETY

 ALWAYS[daadli]ZbVcj[VXijgZg½hgZXdbbZcYVi^dch[dgi]ZhV[Z^chiVaaVi^dcd[ndjgiZaZk^h^dc#

ALWAYSgZVYVcY[daadlVaa^chigjXi^dch[dgegdeZgjhZd[ndjgiZaZk^h^dc#

NEVERVaadlX]^aYgZcidXa^bWdcdgeaVndci]ZiZaZk^h^dcdgi]Z[jgc^ijgZdcl]^X]i]ZiZaZk^h^dc

^heaVXZY#

NEVER eaVXZ i]Z iZaZk^h^dc dc [jgc^ijgZ i]Vi XVc ZVh^an WZ jhZY Vh hiZeh! hjX] Vh V X]Zhi d[

YgVlZgh#

ALWAYS^chiVaai]ZiZaZk^h^dcl]ZgZ^iXVccdiWZejh]ZY!ejaaZYdkZgdg`cdX`ZYYdlc#

ALWAYSgdjiZXdgYh VcYXVWaZhXdccZXiZYidi]Z iZaZk^h^dchdi]Vi i]ZnXVccdiWZig^eeZY

dkZg!ejaaZYdg\gVWWZY#

WALL OR CEILING MOUNT YOUR TELEVISION

ALWAYSXdciVXindjggZiV^aZgVWdjiegd[Zhh^dcVa^chiVaaVi^dc^[ndj]VkZVcnYdjWihVWdjindjg

VW^a^inidhV[ZanbdjcindjgiZaZk^h^dc#

ALWAYSjhZVbdjcii]Vi]VhWZZcgZXdbbZcYZYWni]ZiZaZk^h^dcbVcj[VXijgZgVcY]VhV

hV[ZinXZgi^ÅXVi^dcWnVc^cYZeZcYZciaVWdgVidgnhjX]VhJA!8H6!:IA#

ALWAYS[daadlVaa^chigjXi^dchhjeea^ZYWni]ZiZaZk^h^dcVcYbdjcibVcj[VXijgZgh#

ALWAYSbV`ZhjgZi]Vii]ZlVaadgXZ^a^c\l]ZgZndjVgZbdjci^c\i]ZiZaZk^h^dc^hVeegdeg^ViZ#

HdbZbdjcihVgZcdiYZh^\cZYidWZbdjciZYidlVaahVcYXZ^a^c\hl^i]hiZZahijYhdgX^cYZg

WadX`XdchigjXi^dc#>[ndjVgZjchjgZ!XdciVXiVegd[Zhh^dcVa^chiVaaZg#

IZaZk^h^dch XVc WZ ]ZVkn#  6 b^c^bjb d[ ild eZdeaZ ^h gZfj^gZY [dg V lVaa dg XZ^a^c\ bdjci

^chiVaaVi^dc#

MOVING AN OLDER TELEVISION TO A NEW PLACE IN

YOUR HOME

BVcncZliZaZk^h^dcWjnZghbdkZi]Z^g daYZg8GIiZaZk^h^dch^cidV hZXdcYVgngddbV[iZgi]Z

ejgX]VhZd[VÆVi"eVcZaiZaZk^h^dc#HeZX^VaXVgZh]djaYWZbVYZ^ci]ZeaVXZbZcid[daYZg8GI

iZaZk^h^dch#

ALWAYSeaVXZndjgdaYZg8GIiZaZk^h^dcdc[jgc^ijgZi]Vi^hhijgYnVcYVeegdeg^ViZ[dg^ihh^oZ

VcYlZ^\]i#

NEVER eaVXZndjgdaYZg8GIiZaZk^h^dcdcVYgZhhZgl]ZgZX]^aYgZcbVnWZiZbeiZYidjhZi]Z

YgVlZghidXa^bW#

ALWAYSbV`ZhjgZndjgdaYZg8GIiZaZk^h^dcYdZhcdi]Vc\dkZgi]ZZY\Zd[ndjg[jgc^ijgZ#

CHILD SAFETY:

PROPER TELEVISION PLACEMENT MATTERS

CE.org/safety

LG Customer Information Center

For inquires or comments, visit www.lg.com or call;

1-800-243-0000 USA, Consumer User

1-888-865-3026 USA, Commercial User

1-888-542-2623 CANADA

Register your product Online!

www.lg.com

This product qualifies for ENERGY STAR in

the factory default (Home Use) setting.

Changing the factory default settings or

enabling other features may increase power

consumption that could exceed the limits

necessary to quality for ENERGY STAR.

Declaration of Conformity

Trade Name LG

Model 42LB6300-UQ, 47LB6300-UQ,

55LB6300-UQ, 60LB6300-US,

65LB6300-UE

47LB6350-UQ, 55LB6350-UQ

42LB6500-UM, 47LB6500-UM

50LB6500-UM, 55LB6500-UM

60LB6500-UP,

60LB7100-UT, 65LB7100-UB,

70LB7100-UC, 55LB7200-UB

Responsible

Party

LG Electronics Inc.

Address 1000 Sylvan Ave.

Englewood Cliffs NJ 07632

U.S.A

TEL 201 - 266 - 2534

The model and serial number of the TV are located

on the back and one side of the TV.

Record them below should you ever need service.

MODEL

SERIAL

8LG

Lofe

's

Good

SMART

TV

Quick Setup Guide

*


shown

may

differ

from

your

TV.

*


shown

on

a

PC

or

mobile

phone

may

vary

depending

upon

the

Operating

System

(OS).

11111111111111111111111111

* M B M 6 4 1 0 1 9 0 2 *

Wireless

Network

Connection

+

.....

I

..

Wireless

AP

(Router}

Wired

Network

Connection

LAN

Wired

router

.--•

Internet

connection

4 Internet

P/NO

:

MBM64101902

(1402-REVOl)

Printed

in

Mexico

Network

Settings

Premium

Apps

are

pre-installed

on

the

TV.

These

may

vary

by

country.

Depending

upon

the

version

of

the

software,

icon

position

can

be

changed.

1

Press

the

(Smart)

button

to

access

the

home

menu.

Select

0

(Settings)

and

press

<JD

Wheel

(OK).

0

2

Select

the

Network

tl

Wired

Connection

or

Wi-Fi

Connection.

NETWORK

r

-.

·•

-:.:a-

..

-·

-··-:-··-

)

3

The

device

automatically

tries

to

connect

to

the

network

available (wired

network

first).

When

you

select

the

Wi-Fi

Connection,

the

network

list

available is

displayed.

Choose

the

network

you

wish

to

use

.

--------

WI-FI

(,.

....

*

)

..

·-:-:.

-··

..

:

~

':::"

-·-:-

:.

··

..

··

':::"

':::"

:-i.

-,

-r.-·

::.·· ·

.•

,:_··.

:-

i.''!.·'·1i.·''.

For w1reless

AP

(Router)

that

have

the

i

symbol,

you

need

to

enter

the

security

key

4

If

the

connection

is

completed,

Connected is

displayed.

NETWORK

(

I

·t-+!.

·-

-

n.

-··.

You

can

check

the

status

of

connection

in Advanced Settings.

WI-FI

:-t.··t-!.--''··H.··•

...

·•

••

::

..

••

..

(:·

!.+!.···

..

;;

...

)

Please call LG

Customer

Service

if

you experience any problems.

Troubleshooting

Network

Problems

Depending

upon

the

version

of

the

software,

icon

position

can

be

changed.

1

Press

the

(Smart)

button

to

access

the

2

home

menu.

Select

0 (Settings)

and

press

<ID

Wheel

(OK).

Se

lect

the

Network

fl

Wired

Connection

or

Wi-Fi

Connection

fl

Advanced Settings.

NETWORK

WI-FI

Check

the

AP

(Router)

or

consult your

Internet

service provider.

When

X appears

next

to

Gateway:

0

Unplug

the

power

cord

of

the

AP

(Router).

cable

modem,

wait

10

seconds.

Reapply

power.

@

Initialize (Reset)

the

AP

(Router)

or

cable

modem.

@)

Contact

internet

service

provider

or

AP

(Router)

companies.

DNS

X@

'"""'...,.

____

_,)

When

X appears

next

to

DNS

:

Follow

the

Instructions

below

that

correlate

to

your

network

status.

Check

the

TV

or

the

AP

(Router).

When

X appears

next

to

TV:

0

Check

the

connection

status

of

the

TV,

AP

(Router)

and

cable

modem

.

@

Power

off

and

power

on

in

the

following

order;

(1st)

the

cable

modem,

wa1t

for

the

cable

modem

to

reset

(2nd)

the

AP

(Router),

wait

for

the

AP

(Router)

to

reset

and

the

(3rd)

TV

@)

If

you

are us1ng a

static

IP,

enter

the

IP

directly.

0

Contact

internet

service

provider

or

AP

(Router)

companies.

0

Unplug

the

power

cord

of

the

cable

modem

or

the

AP

(Router),

wait

10

seconds.

Reapply

power.

@

After

the

cable

modem

or

AP

(Router)

has

Ini

ti

alized (Reset),

try

to

reconnect.

@)

Check

that

the

MAC

address

of

the

TV/

AP

(Router)

is

registered

with

your

Internet

service

provider.

(The

MAC

address

displayed

on

the

right

pane

of

the

network

status

window

should

be

registered

with

your

Internet

service

provider.)

0

Check

the

AP

(Router)

manufacturer's

website

to

make

sure

your

router

has

the

latest

firmware

version

installed

SmartShare PC

SW

Installation

&

Setting

Install

the

SmartShare

PC

SW

program

on

your

PC.

1

2

3

Go

to

www.lg.com.

Then,

select

your

region.

Select

SUPPORT

.

Then,

search

for

your

model.

Select

Drivers

&

Software

or

SOFTWARE

UPDATE.

Then,

select

SmartShare PC

SW

.

4

Download

the

SmartShare

PC

SW

and

Install

it

on

your

PC. You

can

run

the

program

when

installation

is

complete.

• !

...

~~;.~ervice

is

only

available

if

TV

and

other

devices

are

connected

via a

single

AP

(Ro~

1

2

SmartShare

Connection

to

Smartphone

Check

that

Wi-Fi

is

enabled

on

your

smartphone.

To

use

SmartShare,

both

devices

must

on

the

same

local

network.

Install/run

the

app

for

sharing

content

on

your

smartphone

(It's

called

SmartShare

on

LG

phones)

.

3

Enable

your

smartphone

to

share

content

files

with

other

devices.

4

Open

SmartShare

application

on

TV. · (Smart)

fl

SmartShare

5

Select

the

file

type

you

want

to

play

(movie, aud1o

or

photo)

.

6

Select

a

movie,

music

or


file

to

play

on

the

TV.

7

Play

the

media

file

to

view

and

enjoy

it

on

your

TV.

Please call LG Customer Service

if

you

experience any problems.

Updating

the

TV

Firmware

(Smart)

t]

0 (Settings)

t]

t.

General

t]

ABOUT

THIS

TV

t]

Software Version

You

can

check

the

Software

Version

and

update

it.

If

you

check

the

Allow

Automatic

Updates,

the

TV

will

check

for

updated

software

automatically

each

time

the

set is

turned

on

(Internet

Connectio

n is

required).

*When

the

TV is

turned

on

for

the

first

time

a

ft

er

a

software

update,

initialization

of

the

TV

may

take

up

to

one

minute.

GENERAL

.·:.•t

•.

:

••

:.

!

•.••.

: :

•.•

•

.•

0

~

.........

.

::.··

..

··

..

::

.··.

... ..

..

..

..

••

....

•

••••

0 •

...

...

...

•

••

• •

••

·

00

••••

.

•:,

':'1.'

..

··::.

(

:-:.·.;.:

..

·'·"·

ABOUT

THIS

TV

·.:

·.:.:.··

..

::

.··

..

··

.

.

.......

.

..

..

.. .. ..

...

.

..

.....

.

:-:.·-:.:.···

..

::.··

:-:.·-;-:.

-

·-::.···

.

>:.·-:-:.-··

..

::.···

.

)

Wi-Fi

Direct

Setting

(Smart)

fl

0 (Settings)

fl

(0

Network

fl

W i

-Fi

DIRECT

If

a local

network

is

not

available,

you

can

connect

a

portab

le

dev

i

ce

directly

to

the

TV

using

Wi-Fi

Direct.

With

SmartShare

,

you

can

share

files

or

screens

of

devices

connected

to

Wi

-Fi Direct.

1

If

Wi-Fi

Direct

is

se

t

to

On

, a

list

of

available

devices

appears.

Select

your

device.

2

When

you

are

promp

t

ed

to th

e

connection

request,

select

Yes

.

Wi-Fi

Direct

is

now

connec

t

ed

to

your

TV

"

If

you

are

not

using

Wi-Fi

Direct

to

minimize

t

he

interference

between

Wi-Fi

devices,

it

is

recommended

to

set

Wi-Fi

Di

rect

to

Off

. You

can

only

use

devices

that

support

Wi-Fi

Direct.

Please call LG

Customer

Service

if

you experience any problems.

Miracast

Setting

Miracast

allows

a

portable

device

to

securely

send

video

and

sound

to

the

TV

wirelessly.

(Smart)

fl

ScreenShare

1

Miracast

should

be

set

to

ON

on

your

portable

device.

2

When

your

TV

is

detected,

select

the

device

on

your

portable

device

.

When

connection

is

completed,

the

TV

screen

appears

on

the

device

screen.

WiDi

(Wireless Display)

Setting

Intel's

WiDi

(Wireless

Display)

technology

enables

easy

and

fast

connection

without

wires

or

internet

network

for

mirrored

and

dual

monitor

display

on

your

TV. You

can

sit

back

and

experience

your

favorite

movies,

videos,

photos,

online

shows

and

more

in

full

HD

on

your

TV

with

great


clarity

and

sound

.

oft-

(Smart)

fl

ScreenShare

1

On

the

TV

Intel's

WiDi

is

set

to

On. Your

laptop

runs

the

Intel

WiDi

(fj)

program.

* LG

TVs

do

not

need

to

register.

* For

more

in

form

ation

on

Intel

WiDi,

visit

http:/

/intel.com/go/widi

.

*You

can

control

your

PC

using

the

Magic

Remote

Control.

(above

WiDi

version

4 .

2)

2

It

detects

LG

Sma

rt

TVs

avail

able,

which

supports

WiDi.

In

the

list,

select

the

TV

you

want

and

clic

k

Connect.

Enter

the

number

shown

on

the

screen

into

the

input

field

(C))

on

your

laptop

and

then

click

Continue.

,----,

--,"'-·-"¥-

'

....

'

'----·

I

Notebook

Screen

3

The

laptop

screen

appears

on

the

TV

screen.

The

wireless

environment

may

affect

the

screen

display

.

If

the

connection

is

poor,

the

Intel

WiDi

connection

may

be

lost.

Magic

Remote

User

Information

Model

Name

:

AN-MR500G

.LG

Ufe'sGood

MBM63935925

(1401-Rev01)

Nome

do

Modelo

AN-MRSOOG

.iJ!i!i!T~

'1~,

2.400GHi:;'

2.483SGI:lz

'

canais

79

canais

~~

··

c

-86d8m

2.~

1

l

47.3

X E

34.4

X A

152.7

(llliel<lncia±lmm)

'

(~~)

AA

l.SV,

lliliza-se

2

pilhas

alcalinas

O'Ci60'C

(I)

lfis

lroca

de

pihas

de\0

emparelhar

riC1o'alll<fle

o

comando

com

a

televisao,

de

acr:xOJ

mm

omaooaldoa~.

(2)

Se

o

oomando

reJrdD

nio

fir<iooar

ap6s

a

1JOOl

de

pilhas,

"""""·as

eiEnle110'10

~hamentnde

ilCIJr1lo

can

o

manual

doOlr'IJOOreJrdD,

(3)SenioutiOarooonlroloreJrdDpora~rgadosperiodosi

~rerTl<M!faspihas.

(4!Niiodesnmeou""""as~lha<

(5

Niiodeixeairaspihasou1JJ0e!laosdramqualquerinpacto

forte,

!~

Niioroolleaspillas.

Perigo

de""""""'"

aiJa<

aspillas

na

posi;iioerrada.

8

CDioqueas~llasemlooil~.

.

3:

5UPoite

.

~

.

~

1/f!s

dildos

para

OOitato

iiTlp!OSSO

oo

Manual

de

Tv.

lndic:e

1.

Sumario

y especifk:acione

del

control

remoto

am

...

~

~~

1.

~.!i!t!2l

7HR

'll

~tl'!!

(1)

7H

R

(2)

Xj(

~

2.

<j>2j

Altf

3,

:il~

:l:ll'!!

.1.

~.!i!t!2l

711.11

'j/

~f,!

(117Kll

Dl~

2.l£l:!2.1

A~

~~g

TV

DN~~~

~~5~J.iiR

Ol

~S'.j'!g

A)§X)7)

"'lii~IAI

~S'.~i

-'fi!

0)-\'-"'i~

A)l!5101

TVI

~011

*

IJ.!E

~~.

Jle

~.21~

21£~1

~CZ!{tOII

~'I~

'i~

'1~!1'2!

~"1!01

"'lll10

m

OILIIOIAI

\!1!001

~i'!~O

I

:>101

il'l'

'1/E

a•

GHzlll

RF

~S'.I:!OICf.l~'1!'!'1fJ)

(2)

Xll!!

fi,

•.lr &·Willllil!

£

IIi

~

AN-MRSOOG

<;'11!9

lll"'

2,400

GHz

N

2,4835

Gl1z

'H

\;!

79

:iN'i!

*

~

~

£ -86

dBm

3:

71 ( m m I

~

47,3

X

~JJII

34.4

X

~01

152,7

(~Xt±

1

mm)

....

~I

<lwil

~~·Mu~>

~

l'! AA

15

V

~1'12!'1!

i'!olXI

27K

A)~

~'I

gs;

O'C~SO'C

2.

<i>2l

Al!t

(1)

i'!C!XI

i!

.i>~l~

~OIIE

2!£1:!

A~~OI

I

012!

~IOIOJ

~OIIA~~Cf.

(2)

{!~XI.

-""11

~

l!i'ft)XII'JECf~.

<!~XI.

~

1

71

.f.

Ail!~OII

012!

OIOI~ii

'i!AI£~Cf.

(3)

~t71l!"

2.15!l:!~

.-l.l·

~~f}::l

?l~

?;1~,

{:!~;J:

I~

Ailllii~

C!:

>iOI

iCf

(~~~;~:~

~

~tMiitllli.

~~

7t8HA1E:

~

!f!ct.

(5)

i'!C!XI

~

'!!01££21714.

>llO

I

"ll

Hit!

'ij£.5'.

"f~~

ii'!1

~

~Ajje

'1!

8Cf

.

(6)

<!~>I

t

!1011

'i01A11=

~

8Cf.

(7)

{!~XI

i!

ll'l'.ii'.

~~AI

"\\!!QJ

¥1~0

1

'1/Cf

.

(8)

Xl'il8

g±OII

Ail!~

{!~XI

~

lllill

~Cf.

(1)

SUmario

(2)

Especificadones

2.Cuidados

3. 5oporte

al

diente

1:

Sumattoy

espedllcaclooM!S

del

ci

contrOl

remoto

(I)Sornario

Lasilslnx!Xrespaaldila'elmomadotmaM!gimestinenel

maooalde

Ia

Tv.

:,==-~=::'=i'=decr:tl1

Wlbol!srerTKinsaO)Ilnianoj>CD1Yendor.11esque-kls

paiK!Dslllicadosderlrodelraci>de~m

,

esunalrlrdren<iD

~4.~0:::.=-!~=.r~omsin

(2)Especificadones

~

~~

Modelo

AN-MRSOOG

Bardo

de

lreruenda

2.400

GHz-

2.4835

GHz

Conal

.

GniOOde~

79

canales

-86d8m

Dimensiones

(mm)

Feso

-""'>473

x(l'r.'r~)XB!P

152.7

Energ~

~de(!IEiadlin

2.Culdados

(~t:~)

2

~s

1

a~Jinas

0

t:

-60

t:

(l)~~r=~a~OS:!elmando

(2)

sin

nof\11dona~de<XIIocar~spilas,

reintef1te

empar$r

el

mando.

(3)

5I

oo

lliliza

el

rontro1

ret0010

por

Ill

tiempo

prolongado,

es

nmnendable

qtitar

las

plas

.

!~

No

desarme

las

pilas

~

apiiq"'

calor.

No

deje

caer

las

~las

ni

gapee

~

caja

para

evitar

daiial1a

6

No

sutnefja

las

pitas

en

agua

8

~\':s~~~~~~::.V="ea't~·

3.

5oporte

al

dlente

vea

las

direcdones

y

los

tetefonos

de

servido

en

el

manual

de

Ia

1Y.

3.

:il~

:1:1\!1

TV

DK'rr'l!QJ

Ai"l"

~"1>1t

§~Will<

[KC

~%

01.3.

'l.!

~%'1!~]

~

~ ~

~

:

I!!>I~XK?

I

'1!l!\'!~

:

MS

I

P-cRM

-

LGE-MR500G

'11~\'!tl:

2014

.

~~~X)/'1

1

~"f7)

:

'l!!XI~>K?I/i:l1~'1!"f

7I

XI'i!QJ

~W£\!~

: IO'il±f"'

.!f{1717

l(

.!f{1

rf

O

I

El~

~

AI~~§

.!f~7171)/AN-MR500G

Table

of

Contents

1.

Overview

and

spedfication of the

remote control

m=tion

2. Precautions

3.

Customer

Support

1. Overview

and

Speclllcatlol•

for

the

RenloCI!

Control

(I)

CM!rview

~ror~lhe~R8oclealrlrdareolhe1VITIOlJO.

~~=':j~..:\,~~:~J~Iq,t).

ootre<~Jire

~be

poirledatthetv.(>OirerecogritionSI.IJIX)rt)

-

Model

No.

Range

of

frequency

Olannel

Reception

sensi1My

Dimensioos

(mm)

Power

source

~

~

AN-MRSOOG

(OlO

Gtz N

2.4835

Gtz

79

dlamels

-86dllm

Wiclh

47J

X 1lidlre;s

34.4

X

l8\lh

!52}

(lijerar<ed±!nm)

(~6kvi

AAI.SV,

2

alkaline

batteries

are

used

0<>601::

El

~

1.

ii~afl9ll!!~:&~fi~~Jt

(1)

-~

121

mmi1

2.

il~·IM

3.§FIIH~

1.

lU!IIti!J

••

&P!i'~l!illt

(1)1!'11!

i<'JI!iliUliHe<iit!lliS!IIJlili''!I@&'IIP'FIIII.

~~liH~!llP~a~~ffimitm~•~~li

l@llile<JF!il.,

l!lltllil'IO!I~ftalmi!HR~iJI!Iliill'F

~~~-~e<Jrn~~Fiil..~~H~~~~li~

~10m~~~.

1t.l3.hl-ifi'JJJiol~~iJI!Ili2.4

GHz

iB~~I@!llle<iRFmi!H

.

('Rlfli:~iRE~)

(2)

IIUI!!i!!

"'liill

~~

;ra

ll!!~~~

II$1BIII

2.400GHzN2

.

4835GI1z

!lllllll

790

9!U

-86<1lm

2.

ilat~IM

lliDI@ii!!Fc.

il«!lll!WHit!llJ'JiZi~i!Fcit!ll.

(21

Yl@ii!!Fc~O:ItitilEli!it!ll.

ii«IN"FI@ii!!Fc~J;:i!mif.lil.

(3)

tEJGlffli:it!lli!ilil!lli'J.IIjTJN"FI@il!!.

(4)

~$J'fll@il!!aiG~EI!itiJnOII.\

,

(5)

'f'ft~il!EI!il!!aiG!1§hO~M!J1;1;1llif<

r'ft~llliJ!fl'lF!I[;4>ffi

.

'f'

'*'

2.

Precautions

(I)

litEs

replacement

rithe

bat!By,

LOe

the-

CXlntrol

folkrMr<J

p>rilg

in

ao:oolanre

wilh

user

manual.

(2)ff_.~~a:=:=~~:'

user

manual

(3)Hthe-rontrollerisootbeirgusedforprolongedperiodri

line,

~

is

reamnended

you

ren1CM!

the

batiBy

from

the

lrit.

(4!00

ootdismartle

or

exert

heaiD

the

battefy

.

(5

00

oot

drop

batiBy

(J

exert

extrene

inpad

that

may.....,

caLOethecaseiDbedarnaQOO.

!~

00

ooti"""""'

the

batiBy

in

wateo:

ls!=:~~~~thebat!Byis-revt!Seiy

.

3.

OI&IDmer

Support

Refer

ID

lfle

oorlact

number

for

""""'

provided

in

the

TV

Manual.

In

halt

1.

Besdlreibung

und

technische

Spezlllkatlon

der

Fembedlenung

m==~pezifikation

2.

Wamhinweise

3.

Kundendienst

1.

llesclvelbull!i

lind tedlnlscbe .

·.

Spezlftkatlon

der

Fembedlenung

(l)~'t-l'<jclerMagic.fent.d

....

l'<jfindenSiei1

derl!ed~ljur<J!hres~.

DieFembedenOOJirannwieEinesdli"<JIIoseMausveroendetweroen

um

den

Femseher

zu

be<ienen.

1m

Gegensatz

zu

hell<iimmli:llen

Fembedentl1Q01ot

denen

der

ferr6eher

ru

aus

ku.,.

rmnz

bedient

weroenlrann,

lrann

man

ml

dieser

RF

feTlledeoong

mit

hem

2.4

GHz

freqJembereid1

den

fem;eher

...

igendeiler

beiO!iigen

RichbJng

at£

in

lhrem

Mausund

belonem.obs1and

100

tis

zu!Ombe<ienen.{Voia!Rerog-UOO!rslibtJlg)

Modell

Frequen2bereict

Kana

I

~

2.100

GHz

N 2,

4835

Gl1z

Kanal79

·86dBm

(7)

El!il!!&lol!lllAii'J

,

'IO~~Iaj$e<JFo;ll&

.

(8)

'fEI!il!!!!i'!l!miJ!IllE~I'Ii

.

3.3Flll~

illfi;II!ITViJI.IIJl'l>fl'li~~JII(!IHd:

.

El

•

1.

ii~~!il'Si~B}j~lfl.l§i1

(1)1!!~

(2)

lfl.l§i1

2. il!UI!M

3.§JSDiii~

1.

ll~llllJS~mB,IjftJi!ll!li1

(1) Ill

'II!

WK~liHe<Jit!llm~aiiMe<Jit!ll'FOO'*'·

.lalil&Hil!llJS«~$'10it!ll

.lllifllil!!te<Jl!i\UliiiiiM.

l!lH'IOe<Jn?flai&lil!llllmliili'J

a~m~m~11~.

~iai&liH

i&liiUI«it'*'lO~R~J~.

~fffi!JJ'Jiol~lmllli'F'*'e<li&liH

.

(llti&liHUililillilll~J;IJimi

12iii!H

;l;:t],(mm)

..

IIlli

IIJtFU

-&idBm

lllfl

47.3

X

llllf!

34.4

X llif!

152.7

{~~tlmm)

~~ll!i~\)

AA

1.5

V,

iile!ll200M11!1ZIIIIil!!

01::-601::

2. Want:llnwelle

(I)

Nachdem

Sie

die

Batterien

atfi9elausd1t

haben,

veiWel1den

Sie

c1e

Ferrlledier<Jr<J

der

Besdlrebung

folgend

•

(2)

Wenn

die

Fembedierur<Jnach

dem

l3a\:terienwedl

nicht

funktioriert,

nehmen

Sie

cle

Batterien

nod1einmal

hefaus

und

(3)=

~

~

~fil~n~ngere

7d

nicht

benut>En,

1st

es

besser

die

Batterien

herauszunehrnen.

(4!ZerlegenundemmnSieclellatterienrjcht.

(5

Lassen

Sie

<1e

Batter'on

nidlt

fallen

tJld

OO.n

5~

keinen

Obenna8igen

0ruc1<

auf

die

l'errllalienung

aus.

(6)

Die

Batterien

sollen

keinen

KDntakt

ml

wasser

haben.

(7)Esbestet1tExplosioroo;jeiiYwennSiedieBatterienlle!kehrt

einse12en.

(8)

EnOOgen

Sie

die

Batrerien

an

einem

dafiir

vorgeseiler<n

0rt.

J.Kailjclendlenst

Die

Kundendienst

RLinummer

fl1den

Sie

in

der

Bedienungsanleitur<J

des

FeTosel-.rs.

mmll

~

Table

des

matieres

1. Apercu

et

specifications de

Ia

telecOmmande

m=cations

2.~utlons

3. Support dlent

1.

Aperi;u

et

sP8dftc:atiGI•

de

Ia

lllleconvna11de

(l)~nstrudlonsclutilisation

de~

tEI!oommande

Magic

Reloote

se

lrolrlent

dans

le

man"'l

de~

1Y.

Cette

tEI!oommande

"""

pennet

de

controler

wtre

telfviseur

en

l'utilisant

o:mme

une

SOIJis

sans

til.

Ave<

cettE

tel!oommande

~li

lliise

~

radiofrequen<E

2.4Ghz,

=.=.e.;:.~~).'

porte.

de

1011

3.f!FJ=;JIIl~

Oll.II!ITVl!iiiJl.~(I'JJGJjj!lllll!ll!li!l

.

COAepJKaHHe

1. ICpaTkoe

OnMCIHMe

M

TexHM'IeCI!Me

napaMeTJIW

AMcraHLIMOHHoro

nynbTa

ynpaaneHM•

(1)

KparKoe

onHcaHHe

(2)

TexHH4ecKHE!

napaMerpbl

2.

Mepw

nl)eAOCTOpOlKttOM

3.

TexHM~ecKaa

IIOAAI!P*Ka

LKpmcoe_"_

....-.pw

nym.TajiiiCTII_...-o

.,...,..,_

(l)i(pa1l(oeOrlltCOHite

~ro"""'blOBaHIIOnynbra/IIMagi:HaXOIIflT01B

py!<!JOl/¥:18erll~-·

.QatfHblii

AHCJaHUIQII:oiH

ll'(llbT

ynpa~

HOm'

6YTb

llllOilb.XeaH

ll/lJIY'I"

.....

_rK¥1<6<>~··"'"'1111'

K()II'I«JJ'ee)a,~P~Qt)

lOO'OTYB2

.

4fTUHBOTI1WiteOTI'(lelKHMXMQllelleMM~f~Wa!<pa01biX

11'(11bTOB,KOT'Oplle00300/IIU1I'IyrJ)a81Nl'b~B~

Bl4liHMOCTM,3TaMQlleiiii"DlBCC.MeT)TIPilarunb8111000H~

8-B-10MeTPOB.(~paclllllHa80H"'roooca)

(2)T-napaHe1]11<

.tT~

~

\~~.;-

-~~

,

!?!_~I

,

l!@i!

"

1

iif~·tt

Ha3BaHHe

MOAe11H

AN·MRSOOG

lltana»tlliWIO""""

2.400rru-2.483Srru

l<aHaJlbl

79

KaHana

2.400

Gl1z

-

2.4835

GHz

Olaine

79

chaines

~

-86d8m

Dimensions

(mm)

47.3

(L)(~~~&l

~

w·7

(E)

Flllds(g)

(non~~plles)

Sect... 2

P~

1

a~nes

"""""',.,~-

ooca60oc

2.

Precautions

(II

Apesawir

dlangi

de

i>atterie,

procidez

a •

svr<h-de

•

teleolmmande

en

SLivant

ie

mode

d'emploi.

(2)

~

~

1l!licommande

ne

fcnctionne

pas

mime

apres

iiVOr

dlangi

de

batterie,

enleYez

cette

demiere,

puis

essayez

a

nouveau

l'appareilement

suivart

ie

mode

d'emploi.

(3)

En

cas

de

oon

wisation

de

Ia

tEI!oommande

per<lant

une

long"'

p<!tiode,

il

vaut

nleux

·-

~

batterie.

(4)

Ne

pas

~isser

les

pies

pres

d~ne

source

de

dlale!J'

(5)

Ne

faites

pas

su~r

de

chocs

ala

tEI!oommande,

cela

""'"""

endommager

soo

boftier

et

son

fooctionnement

(6)

Ne

pas

mettre

les

piles

dans

de

reau

(7)"""

introdulsez

les

~les

a

renvers

II

y a

un

nsq"'

de

<literiolationouclexplosioo

(8)

Les

piles

usees-

etre

jetees

dans

tJl

endroit

adaptol

3. support client

Veuilez

0111SUiter

1es

ooordonnees

du

sef'lice

affichees

dans

le

manuel

de~-.

m!i!lm

li:lili!lll

indic:e

l.lnbod~

e

espedfica~

do

controle

remoto

(

1)

IntrodU<jio

(2)

Especifica¢es

2.Cuidados

3. Suporte ao Cliente

'ly8aairrenblllll:n.oonena

P03Hepbl

(mm)

Bee

Hcr~HMK

mfTaHM~

PaW..'

reMnePalYpa

·66

A6M

WMPMHO

47.3x

T01111111H0

34.4

X

tlnMHa

152.7

(Aonya<

±

IMM)

71rp.±5rp

(6e3 6arapeeK)

UW10'<H~~2WT

0 t:

-60

t:

3.

T-

ftOMIIP*IGI

no

eonpocaM

3K~

K?AeJ!H$1

M cepeoo«:lf''

o6cnylKMBaHHA

o6pa~

6uryw.f;y

1"'IAfleP))I01

Kt1HeHT08

nl)

T~HI

'y'Ka3attfbiH6M~

1103K0111yaTal,f411Te11eBH3Clpa.

L

'J'E:::.::

....

Q)lll!l'cttl*

(I)

II

<~7)'J~o:-a>llfl!iill~.

'Tvt:a>.,IUI'IIII:IIIt~~

n

•<t

•

<h)

'J

~o:-1~.

?{-\'vH?:<a>t;l:llJIIL

t'fvt:!'ll

Ua>MI')~O/'l'lt.

'Tvt:a>!ltii:'J~o

·

i'>I!<~•JtLidfi.

'~')'J~o:-1~.

2.

4G<•Illll

l<llllt9:<<'.

•Joo:-a>AHll:to:<¢<.1111

I

10m~Pia>U<'IIflto:<!''li!H

.

ii"D

wot.

l

(3)

(4)

(5)

(6)

(7)

(8)

(9)

3.

:b

.

~H:_.ft±..

.

~~

,.

**111(7)~!llll!li=ICe~ntdJA?<'-"t

;f(-H!/?-(7)ill5~'!'·1ft!L

-c<t=~~

'"

t

~

KC

Slal!menl(!!il)

'Aii~J:

f

~

~xp:

fE-

011~

!ft!~t:JI

7f

~nt:gt!

7

~~01

~

£.!:!

£

C2J';!t~{l~

~

E'1~

A

it:J

I

~E

~

4

~~·

llirediva

R&m

1'»9/5/a

ProdUSIJdesaismaisusestemnformw~~ale

di-spedlloie.

Reprezentanteurq>ean:

LGEledrorlcsKrljgsman

1,

11860MAmslelveen,Oiivlda

(6hllrAP0<11J

6eneMaca

0TH0010

cwrrweTC:tWM C

HOIMf1":

HI

EC

:

CHiiCTOIIU¥JTOLGEiedronics~,'ET03MI1XlAYK'f

CbOTBeTl"TBaHaCJIEWifre~.

R&m_.,,.,m/5/K

E8pa1Ei40<Io

npeac•••••••"

LGEJedronicsKrljgsman

1,

11860M-M!en,

H_.,._

(S>e<SI<A)

-

...

~,

LGEJedronicsi-h:lnnedattdenh!rprod.-..,py~~erlilljande

gOl-d-:

R&m-drd<!M!t1999{S{EG

OYan

nilnrda

pro<ljclerstanm!rOYerens

med

de!11J1(1!gga00e

kr.M!nsomiWlQOSI-.

Europelskrepresentant:

LGEJedronicsKrljgsman1,11860M-,Ned81!rdema

(NOASI(]

-I'WEU:

LGEJedronicserldle«rheM!dat-prod-.-lherllokltilde

f!llgolded-.

R&m-d.-

I'HJ/5/EC

----"""""~-ideanglle

drel<iYere

.

Europeisk-rt:

LGEledrorlcsKrljgsman!,U860M-,Nedo1ard

(DAHSK)

-.-....

:

LGEiedrttts-.,""""'«"""!'O<W_flligeOOe_.

R&m-d.-

1'»9/5/f£

O.procioJdl:o;deror-...m,,~de-kr.wi

deaf9Yne-

ANAlB.-

(Para Brazil)

Esle

e<!Ji>amenlll

""""'

em

Cl!l'ilter

secuooario,

isto

e.

nao

tom

dretn

a

~oont1a

inten.reroa

prejudicial,

mesmo

de

esta¢es

do

mesmo

lipo e

nao

pode

causar

irtener!nda

a

sistemas

operando

em

carOler

prim!rio

.

-COmmunlcationsOlmmiosion(fCC)Siatoment

Yoo

are

catAioned

that

dlanges

or

modifiollions

oot

e>q>res<ly

OfllliO'Od

bylhe

partre5(Xli1Siblelor<Xllf1l(iancecoUdwid

111e

usel's

...mnty

Ill

operate

111e

eq.ipment.

Ttis

e<!Jipmert

has

been

rested

and

found

Ill

CXlOlply

v.ith

lhefimilsloraO...Bdi}taldeW:e,pursuantlllpart15<J

lheFO:rules.

=i=~"e:f~~....:m~~

equipment

generates,

uses

and

can

-radio~

energy

and,

W

oot

installed

and

used

in~

v.ith

111e

inslnldioro,

may

cause

hamtulinterferena!tn

radio

commlJI'lications..

HoweYer,

there

Is

no

guarartee

that

interference

wil

not

oa:ur

in

a

partioJiar

instalation.

U

this

eq~Jilmen!

does

cause

hamtul

i1terfereno!

Ill

radio

or

television~.

1\hdlcan

bedetmrined

byi!Jnjng

ll1e

equipment

off

and

on,

ll1e

user

is

en:ouoaged

10

tJy

Ill

cooect

tt.e

irtsferenc2

by

one

or

more

<J

ll1e

folowing

measures:

-

Reoriertorrelocatelhe

rec>iving

antenna.

-

-lhe

sep;ration

between

ll1e

equipmert

and

""""""'

-

Olnned:

ll1e

equipmert

im

an

o.Aiel

oo

a cio.t

c11eet

from

thatlll\\hdllhe'"""""ls0l1111E<ted

·Cms>Aihe-oranel<fll'liermlrD!(TI/Ifdvidanf!rhell-

Ttis

deYia!

CXlOlplies

v.ith

Part

IS

<J

ll1e

FCC

RUes.

Openljon

is

subject

llllhe

folowing

two

oondllons:

I)

this

devia!may

oot

cause

hamtul

intfrferena!,

and

2)

this

device

must

i1C0!Jt

any

lrterference

receiVed,

inc1Jdi1g

intelference

that

may

cause

undested

operatiion

<J

ll1e

device.

FCCC.ution

~~:!.~~=~~party

oper.lle

this~

and

For

indoor

use

oo~,

use

OW1oor.;

or

in

-modes

oot

CXI\'ered

by

this

manual

may

vkllatelhe

FCC

regJallon

and

violate

ll1e

user

...mnty

Ill

use

ll1e

prodJ<t

FCC

Rf

Radlallon

Exposure-:

This

e<Wment

COOl~ies

with

FO:

radation""""""

~mils

set

Et.rnpa!isi<-

LG

EJedronics

l<rijgsman

1,

1186

OM

Amslelveen,

Holland

(SUOMQ

~-usll-:

LG

Eledronics

vakwttaa

t:aten,

etta

tarna

bJcte

on

seuaavietl

drektiMenmOOinen.

R&TTE<l-

1999{5/EC

&lelimai.-..ttuotleetovaterit!Jtyjen--

vaatlrTM.JStenmOOisia.

Edust!ja

Euroopa$a:

LGEledrorlcsKrijgsman

1,

11860M-,Alani<Dmaat

~ltus:

l<iiesolevagakiYllablGEJedroni<s,et.,.,_Otikllbjijlg'miste

droldiividega

..

Raadfo!oad-ja

telekomnu1-Mirgu

iippseaanete

d-

1'»9/5/BJ

~----mii'llluddroldiivideoluisteniiuelele.

_

..

nob;:

LGEledrorlcsKrijgsmani,11860MAmslelveen,Holland

(UE11MV

KJ

EB-

deldalodjo:

.lGElEdrol;cs"parei!ida,kad!isproduktasilliMatnldasdk<klyvas.

R&m

d~

1'»9/5/EB

Auklliaujvririi

pnxloktlii!lltii<a

nLJO<Iybjd~esn1"us

reikaiMnus.

AlslllvasEtropoje:

LGEJedronlcsi<rijgsman1,11860MAmslelveen,Nydertandai

(lATVlESu)

Pazl!lOJumspor-lluEScl-

:

LGEJedronicsac!opazi)o,ka!isilsbadajtrns-tupmiil<

m~diekiMm

.

R&mdRktivai'HJ/5/EK

lepriei<Sap!ai<siiieizsWd!jumiatt;lst.mdlodireldMJbOO;i<ajam

--

-OaEiropii:

LGEJedronicsKrijgsmanl,li860M_,_

(SlO'IENSt!NA)

lzjovl

osldld-

EU:

lG

Bedronics

lzjavlja,

da

je

ta

izdelek

v

stda!lJ

z

naslemjimi

f!rlh

lor

an

unoorlrolled

envionmert

End

uses

must

follow

111e

spedic

operating

inslruclioos

f!r

satislyi1g

RF

e>posure

<llfT'Illanre.

Industry

Clnada(IC)

-

~~:'~":~~~~

I)

this

re.ice

may

not

cause

i1terfereno!

and

2)

this

re.ice

must

i1C0!Jt

any

ilterference.

Jnduding

intfrferena!

that

may

cause

Llldesired

operation

<J

device.

Avlsd1nclustrie

canada

cet

appare11

est

contoone

a

norme

CNR-210

des

ri(iemerls

d'lr<MII'o

canada.

Soo

ftrdiorrerertest sujet

aux

deux

oonditiions

suM.vltes:

I)

cet

appareil

ne

dolt

pas

(lroi'Oquer

cfinterrerenres

et

2)

Cet

appareil

dolt

""'flfer

toote

les

lntBferenres.

v

CXlOlpris

O!lles

pouvant-

son

dys-

fonc!ionroem!nt

IC

Radiation

ExposureSiatoment:

This

equ.,.,-.ent

Cllll'jlies

v.ith

IC

r.dation

exposure

limits

set

f!rlh

lor

an

uncontrolled

eovirom1ent

tmf:

TilE

MANlJFACII.mU'

IS

00

T

RESI'ONSIIIU'

FOR

Nrf

RADIO

OR

TV

llmRfERfNCE

CA1JSED

BY

UNAIJI1IORIZED

MOOIACATIOOS

10

TliiSEQUIFMENT.

5001

MODIACATIONS

rotJLD

VOID

TliE

USER~

AIJIIIORIIY

10

OPERATE

1liE

EQUIPMENT.

Avis

d1nclustrie

canada

....

rexpooltlon

aux

~:..e~contoone

aux

liritesdeJ<(lOSiion

aux

~

d1nckJsbie

canaca

poor

lJlellVironnemert

non

REMAAQUE:

IE

lilllljiCANT

rfEST

PAS

~Blf

DES

III1WERENas

RADI~QUES

<;AIJSEES

PAl\

DE$

MOOIACATIONS

NON

AUlUUSEES

APPOimES

APPOimES

A

CET

APPARBL

DE

TELLe;

MiJI)IFICATIONS

POURRA!T

ANNUlER

OOIORISATION

ACl:XW>EE

A

l\ITIUSATBJR

DE

liiiRE

FONCTI~ER

OOI'ARBL

~-)

La

..

· :

deestl!e<!Jipoest>lsujetaalassiguientesdos

(I)

es

poslble

que

est!!

equpo

o

dispositiW

no

cause

-peljuclcialy

(2)~~==..~~~~·

CESiatoment

EU

Confonnly

Notire:

CE

0197

LG

Eledronlcs

hereby

dedares

that

this

product

is

il

CXlOl~~nce

v.ithlhefolioy,;ngllirectiYes.

<lrel<tiv.vri

.

llioel<tiva

I'HJ/5/ES

o

Oldijsl<i

opremi

il

telekonu1i<adjs

--

opremi

!Ermedsebo)lem

prizna,Y>ljusldacilo!tlleopren-.

Zgooljop6aniildelkii2porljujejobisMne!ahteYenaYeden~-

Ewopold

zaslOprik:

LGEJedronicsKrijgsmanl,li86DM-,N-

[SRPSKI)

Napomenl

o

Ullda&tenosd

sa

standirdlnw~:

LG

Eledrorlcs<Mm

izjaYijujedajeovaj

proiMld-

sa

!ledeCin

drektivama:.

R&mdRktiva1'HJ/5/K

Preth:Kh:lopisaniproizvodiustdadenisusCISOOVI'inzahtevinaiz

---

Ewopold

predstavnik:

LGEJedronicsKrijgsman

1,

U860MAmslelveen,Holandija

(HRVATSKl]

"-o-sEU-:

LG

Eledronics<Mm

~

izjaYijujecll

je

ovaj

proiMld

-·

sijede(imllirektivama.

R&mdRi<tiva1'HJ/5/EC

Goreop6an

proiMld

.,kladan

je"""""m

~ma

na>edenll

d.-a

Z..Upni<laEuropu:

LGEJedronicsKrljgsman1,11860M-,N-

[Tii<KI;E)

MUygu-lllclrlml

:

LG

Eledronlcs,

burada

bu

liMOn~

Oiek1lfler

le

IJI'lnW

oklJ!junu

beyan

eder.

R&m

o.-I'HJ/5/EC

Yukanda

anlablcrl

UrOnler,

belirtllen

difek:tifterin

gereklilikleri

le

U'{lll1it.W.

AV11.1>'-ici(i:

LGEJedronicsKrijgsman

1,

11860MAmsteiv<en,HQianda

(Sf«l1P)

DeldlnltaeKoniO!mltetit

pirllf-ni:

LGEledrorlcs-jetkesajdeldironsekyprodukl-ne

~me

Dlrei<tivatem<poshtme

.

DirektiYenR&m

1'»9/5/KE

-ep!rshkruo:arri!Bipi!rpul!lenmekl!rl<esatl!lelbi!&Jretii

R&m

llirectiYei999/S/EC

====~lheessenlial

Ttis

re.ice

is

a

2.4

Gil

wideband

transmission

!>ySiem,

-

for

use

In

~I

EU

member

states

and

EFTA

<:<><.mies

~~I,

1186DMAmsteM!en,

The

-

a Nolful

Bodv

statement:

:~~~~~e~~-===:~uct

reqJired

Ill

take

adequate

measures.

Explosive

re.ice

pro>limity

wami1g

-

Do

oot

operate

a

portable

transmller

(sudl

as

a

wireless

netwol1<device)

._unshielded

blasting

caps

or

ilan

explosive

envionment

lllless

ll1e

device

has

been

modfied

Ill

be

qualified

lor

sudl

use.

(DE\JlSOi]

EU---.,.

:

LGEJedronicserkiartt;ennl,dassdiesesProciU<!denfoigendefl

Ridilnienenlspridt:

R&Tru<i<tllilo

I'HJ/5/K

Die-

besclw1ebere1

Plodu~

entspredlen

den

gnrdegenden

ArtoldeMgen

der

angegeberon

_,_

-fii'Euopa

:

LGEJedronicsll1c.Krljgsmani,11860MAmslelveen,Nledel1ande

(FRANI;AIS)

-·-UE:

LG

Electronicsattestequeces

poOOitsest

en

cooformlteavec

les

--·

llioedive

I'HJ/5/r:£

des

R&m

les,.-di!ai!sd-<le!alssoolenc:orlonr;O\iM!Ciese>cigenres

es>enllelsdesdrectM!s~

Representant

en

Europe:

LGEledrorlcslrc.Krljgsman1,11860MAmslelveen,f>ay>&ls

(ITAUAI())

Awlooci-EU

:

LG-dlequesto~e<Xriamealeseguenti<ln!lli'le.

DiettivaR&m1m/5/a

1piO(I:;lidesoitll!qlfasonooortom;ore<pJsitl""""""idelo

di'etti>espedficale.

Rappresertanlewq>eO:lGEJedronicsll1c.Krijgsman1,11860M

-·--

diek!Na'letii"""""""'.

P8faqesueO

evropian:

LGEJedronicsKrijgsman1,11860MAmsteiv<en,Hoiande

(80SAN510]

-o-saproplslmaEU

:

LG

EJedronics

<Mm

pU!m

i1javljuje

da

je

ovaj

proiMld

ustdaclen

sa

sljedeiindRktivama:

Direkliva

0

radijsl<i>j

opremi;

telei«lmri<adjj

"""""""'-

1999{5/EC

Opisani

proizvo<l-1

su

saldjulnin

zahljeYma

naYedenil

dRktiva.

-

..

Europu:

lGEJedronicsKrljgsman1,11860MAmslelveen,Hoiandija

(HAI<F,!IOHCl<H)

lbeecJyaaMa~coEY:

LG

Electronics}ciBHo

K3jaByBa

AeKa

oeoj

fllOKlliOAe

eocornacHOCTco

_...,.,.,.__

R&mAM-I'HJ/5/EC

npoM38CWfl'e

OI'1KUiHt

norope

rM

ltCJ"'O'tf''8M

OCJiOettKT'e

ycnoat

t¥1

,.,._..lii4P'J(I>IBM.

Eoporoot

npermeHMK:

LGEJedronicsl<rijgsman

1,

1186DMAmslelveen,~

(I\A3AI\WA)

EOaii-lYJIIIIW_.-,1:

LGEJedronicsOCI<'I¥'0'-~-~.....,

Alfj)ei(TMaarepFa

ail

emfil M;llltwifAj.

""'""

....

___

l'HJ/5/E<:.

_.,oacw

}f(oFapbi,QaOII'laT1aiFciH6HiM,Qep~~li

-

.......

-caA

.......

eypo._.,.

-"

LGEiectrOO<sl<rijgsman

1,

11860MAmslelveen,

H_,.HO

(PYOOG1~)

Y.....,....o~NOpMMEC

:

KoMrat1A

LG

Eledront:s

~

3aii3IRl

o

TOM,

'fTO

.QatH)e

-~--""-

·

~R&mi'HJ/5/EC

0nHCatfttblel!biWeK3Qeii!SI000'1'8eT'a8y100CH08tt:oiHT):le6oe:aHHAM

y!WatflbiX

W4)ei(TM8

.

0l)eACl"aBKreelbCT80

8

Eapone:

(ESI\INol]

Avilode-ClOIIlaUE:

,..~,...,...,

LGEJedronlcscledaraqueesteprodudo~<XJn

tlssigulerlesdieclivas.

Dleclivasobreeqwposooioel0cb1oosv~-de

-I'HJ/5/(E

Losprocltdos--CIJI1l(en<XJniosreQU-

eserdalesdetlsdiredivase!!Jedj-.cadas.

~-:

LGEJedronicsll1c.Krljgsman1,11860M-,PaisesBajos

(FOR100Jfs)

Avilode-claUE:

ALGEJedronicsdedalapreslemeioqueesteprodi.OoeOliem

<Oftonn-Olmassego.illesllirectivas.

OiredivaR&mi999/Sta

Os(>OCIJIDsadmadescrilllsestaoem-Olmo;requi!;IDs

.....-.:ialsdasdiedivas----

~aropeu:

LG

EJedronicsll1c.

Krljgsman

I,

1186

OM-,

Holanda

(t£DER1ANDS)

~(EU]:

LG>e1cllarthierllijdatcltproduct-aande'lliQenderd<li(nen.

R&TTE-ndilii'

I'HJ/5/EC

O.hiertJ<Mngenoemdeprocl.denYOidoenaande-

-

van

de

gespedlia<rde

ridltljnen.

Euqlees-

LGEJedronicslrc.Krijgsmanl,ll860MAmslelveen,Neder1and

(EMIMIOI]

6it~Mo~l~E.E.:

H

LG

-~

im"'

...,0.

r¢iiv""""""""'

fiE

nc;

ffff;()lqjlo;:

OO]lio1'HJ/S/EI<r<P~,.,r~

T"""""""E\OfWoi.<IO(R&TTE)

To-"""'f'll(liivra~fJE"'OIIOOClOOc;onoor,o.c;

ThJVCJV!olT!jJwo&r/oWv.

EupoJOOO<Iic;~

LG

Eledronics

Krljgsman

I,

1186

OM-·

ilM<Jv&

(M;&AR)

EU

meglolel6oigl

nyilatllozat:

AzLGEJedronicsezidookijelenli,hogya""""'n-eftlel•-.ai

lGBeclroni:sKrijJsman

1,

1186DMAmsb!IYeen,~

(YKpili«>o<a)

...._

..

~-EC:

ljMH-lGEJedronics-~""""

~

Ellf<ralollKJI!ICTMB.

U,f)

nepenNeHI

HKlk'l!.

~R&TIE,l'HJ/5/EC

ClrH::aHi

~

nPQilYKlM

Bianoei.qalon.

(l(M(l(HIM

M«lf<<M

BKa3aHMX

...

__

-00l6a

y€sponl:

LGEJedronicsKrijgsmanl,ll860MAiroleM!en,Hi<fepnatwl

LGa.ctronluJapan(.)'IJA,~-~-t--t~'-

'

-!;.~!!~~!!~3

=-~~r~

.

:~··

1

m:~56/s-7Jll

1

-

~·

-

-

00<0--:IOcGD

•:t•·B•·

tll!

OHI0--1.ao1•-·()

~IMIJOI)lepe

:

nn·nrEneKrpoHi•c~THa',

Y~epa1Ha,01004,M.KMT•

•

.yn.

6&oetl~ta,

•

(rhepeA)

.

Teii.:

+38(044)201..Q-50

,

¢,aKC:+38(044)201-43-73

lsnlel

MoC

ID

Moe:

51-40461

Moe:

51-40800

Oman

....,__,

l'HJ/5{8(R&m~

A-bem--12ijeslika~i<lnye!Yek

~-

Eu6paikfpviselet

LGEJedronicsKrijgsman1,11860M-,Holandia

[POl5KI]

Ooldarao;ll~z-UE

:

F'rnlalGEJedronicsniliejszl'nzaSwiadcza,ietenpnxloktspelrja

wvn-"'ponii:;z)dodyrektyw.

Dyrejclywa1'HJ{S/WEwSllfOv.iell2ij(l1e\radk!wydll~

""""""~

Powyiej

wymieniale

pnxlokly

spelrjaJillll5aCilicle

wvn-"'

~dyrektyw.

-noEuqll::

LGEledrorlcsKrljgsmani,11860MAmslelveen,Holandla

~

·-·leglolallwu

Bl

:

SpoielrostlGEJedronicstiliopnilla!uje,!el!riDV'/rol>Ekje

..

sl>ldl!snOsleciJ1cln;..-........;.

Sm!micoo-a-..-"""""'idl

zalizerO:hi'HJ/5/E<:.

llj!e~produklyjsouvlO'Jaci.Jse-poladMy

uvedenjd1

sm!mic.

~vEvrope:

LGEJedronicsKrijgsman1,11860MAmslelveen,-

~-pro-ai

:

S!ld<iros1'

LG

EledrorlcsljmlovyliaoQe,

!el!riD~dooalllje

S1lad

s

nasleclJ)'Dni

srneml3nl

Smemca

R&m

I'HJ/5/ES

Vy;!iepopisane

vjroiJky

~

zOidadnjm

~

uvedenjd1

srnen-k.

EIJiJpskezasll.!>llel'st-.o:

LGEJedronicsKrljgsman1,11860M--

(ROMANEm]

_,...

...

_UE:

Plilpre20flla,LGI3edrorlcs-o!ace;tJlll)dusesle<Oitonnru

unnilloorelelliedlve.

BRAZIL

South

Africa

'f:

TA-2013/1704

ICX.SJ\

·· APPROVED

e"lANATEL

3805-13-9946

11111111111111111111111111111111111111111111

(01

)07893299650659

PhifiA>Ines

Rusoio,

'-T=R=-:A:-----,

:--

~~~1~~mfo:

OEALER

No:

0014318/08

o-~

o-~

[Specification)

I)

Model

Name:

AN-MRSOOG

2)

Bab:NSerial

No.:

-

3)

Mal1<iactu'er:

LG

Eledronlcs

Inc.

4)

Factory:

OHSUt«>

Eledronics/

IWlSLtlG

Eledrorlcs

5)

Ptoduct

Name:

Magic

Rerrol2

Please

direct

all

service-related

questions

or

comments

to

www.lgusa.com/support

or

call

1.800.243.0000

CMZ01

LG

Electronics

-

LG

Electronics

PO

BOX

174355

DENVER

CO,

80217-4355

First-Class

postage

required.

Post

Office

will

not

deliver

without

proper

postage.

PROTECT YOUR INVESTMENT

DON'T

FORGET TO REGISTER!

online

at

www.lgusa.com/register

G Fill

out

and

return

this

card

Registering

is

important,

quick

and

easy!

Thank

you

for

purchasing

an

LG

product!

We

hope

you

are

enjoying

your

new

product

and

look

forward

to

sharing

some

insider

tips

and

tricks

with

you

soon.

Registering

your

LG

product

is

simple

and

also

serves

as a

verification

of

ownership

if

your

product

is

stolen

or

lost.

In

addition,

you'll

receive

the

following

benefits

and

many

more:

•

Helpful

emails

on

how

to

make

the

most

of

your

product

•

Reminders

about

product

downloads

and

firmware

•

More

efficient

warranty

service

•

Exclusive

information

on

new

products

and

innovations

•

Special

offers

and

promotions

Welcome

to

the

LG

family!

Please seal

with

tape.

Do

not

staple.

11111111111111111111111111111111111111111111111111111111111111111

*

3 8 4 0 V A 0 0 4 2 G

*

P/N:

3840VA0042G

(1312-REV07)

Printed

in

Mexico

CMZ01

LG

Electronics

PROTECT YOUR INVESTMENT

DON'T

FORGET TO REGISTER!

online

at

www.lgusa.com/register

G Fill

out

and

return

this

card

within

the

next

10

days

1.

0

Mr

. 0

Mrs

. 0

Ms

. 0

Miss

First

name

Initial

Last

name

Street

Apt

City

State

I

Province

ZIP

I

Postal

Code

Email

address

2.

Telephone

number

4.

Model

number

( )

3.

Date

of

purchase

5.

Serial

number

I I

Month

Day

Year

6.

Name

of

store

where

purchased

www.lgusa.com/privacy

Failure

to

return

this

card

will

not

diminish

your

warranty

rights.

Copyright©

2013

All

Rights

Reserved

•

LG

Electronics,

Inc.

LCD

I

LED Television

Limited

Warranty

-USA

Your

LG

Electronics ("LG")

LCD

I

LED

Television

("unit")

will be repaired

or

replaced,

at

LG's option,

if it

proves

to

be defective in material

or

workmanship

under

normal use, during the

warranty

period ("Warranty Period") listed

below, effective

from

the

date

("Date

of

Purchase")

of

original consumer purchase

of

the

unit.

This

warranty

is good

only

to

the

original purchaser

of

the

unit

and effective only when used in

the

United States, excluding U.S. Territories.

WARRANTY PERIOD I HOW SERVICE

IS

HANDLED

LABOR:

One

(1)

Year

from

the

Date

of

Purchase.

PARTS:

One

(1)

Year

from

the

Date

of

Purchase.

Replacement Units and Repair Parts

may

be new

or

factory remanufactured.

Replacement Units and Repair Parts are warranted

for

the

remaining portion

of

the

original unit's

warranty

period.

Please

retain

dealer's dated bill

of

sale

or

delivery

ticket

as evidence

of

the

Date

of

Purchase

for

proof

of

warranty, and

submit

a copy

of

the

bill

of

sale

to

the

service person

at

the

time

warranty

service is provided.

CONSUMER USER

Please

Call

1-800-243-0000

for

instructions on

getting

the

defective

unit

repaired

or

replaced.

Visit

our

website

at:

http://www.lg.com

COMMERCIAL

USER

Please

Call

(888)

865-3026

for

instructions on

getting

the

defective

unit

repaired

or

replaced.

Visit

our

website

at:

http://www.lg.com/us/commercial/display

THIS

WARRANTY

IS

IN

LIEU

OF

ANY

OTHER

WARRANTY,

EXPRESS

OR

IMPLIED,

INCLUDING

WITHOUT

LIMITATION,

ANY

WARRANTY

OF

MERCHANTABILITY

OR

FITNESS

FOR

A

PARTICULAR

PURPOSE.

TO

THE

EXTENT

ANY

IMPLIED

WARRANTY

IS

REQUIRED

BY

LAW,

IT

IS

LIMITED

IN

DURATION

TO

THE

EXPRESS

WARRANTY

PERIOD

ABOVE.

NEITHER

THE MANUFACTURER

NOR

ITS

U.S.

DISTRIBUTOR

SHALL

BE

LIABLE

FOR

ANY

INCIDENTAL,

CONSEQUENTIAL,

INDIRECT,

SPECIAL,

OR

PUNITIVE

DAMAGES OF

ANY

NATURE,

INCLUDING

WITHOUT

LIMITATION,

LOST

PROFITS,

LOST

OR

CORRUPTED

PROGRAMMING

OR

DATA,

OR

ANY

OTHER

DAMAGE

WHETHER

BASED

IN

CONTRACT,

TORT,

OR

OTHERWISE.

Some states

do not allow

the

exclusion

or

limitation

of

incidental

or

consequential damages

or

limitations on how long an implied

warranty lasts, so the above exclusion

or

limitation

may

not

apply

to

you. This

warranty

gives you specific legal

rights and you

may

also have

other

rights

that

vary

from state

to

state.

THIS

LIMITED

WARRANTY

DOES

NOT

APPLY

TO:

• damage caused in shipping

or

transit

• service required

as

a result

of

improper

installation,

including incorrect

or

insufficient

AC

supply (please

consult

the

owner's manual

for

power

supply

requirements).

• installation

or

repair

of

antenna systems, cable

converters, cable company supplied equipment,

or

other

components in a video system

• set-up

or

adjustment

on consumer controls,

or

damage caused by

improper

adjustments

• damage caused

by

other

system components

• any

unit

that

has been modified

or

incorporated into

any

other

unit.

• replacement

of

batteries on

the

remote control.

• damage (including cosmetic damage), failure, loss

or

personal

injury

due

to

misuse, abuse, negligence,

improper

maintenance

or

storage,

or

to

acts

of

nature

or

other

causes beyond

our

control. (Causes

beyond

our

control include

but

are

not

limited

to

lightning strike,

power

surges,

power

outages and

water

damage.)

• image burn-in

• repair

or

replacement

of

warranted

parts

by

other

than

an

LG

authorized service centers.

• units purchased

or

serviced outside

of

the

U.S.A.

• units where

the

original factory serial numbers have

been removed, defaced

or

changed in any way.

• units sold and labeled as

"as

is, where

is"

or

similar

disclaimer.

The co

st

of

repair

or

replacement und

er

these excluded circumstances shall be borne by

th

e cons

um

er.

LCD I LED

Television

Limited

Warranty

-USA

(continued)

CUSTOMER

INTERACTIVE

CENTER

NUMBERS

CONSUMER USER

Please

call

1-800-243-0000

To

obtain

Customer

Assistance,

Product

Information,

or

Dealer

or

Authorized

Service

Center

location:

and select

the

appropriate

option

from

the

menu.

Or

visit

our

website

at:

http://www.lg.com

COMMERCIAL

USER

Please

call

(888)

865-3026

and select

the

appropriate option

from

the

menu.

Or

visit

our

website

at:

http://www.lg.com/us/

commercial/

display

CONCERNING

PIXEL

FUNCTIONALITY:

Your LCD/LED television contains hundreds

of

thousands

of

individual pix-

els. LCD/LED displays typically contain a small

number

of

pixels

that

do

not

function normally. Your display has been

inspected and is in compliance with manufacturer's specifications, indicating

that

any

pixel defects

do

not

effect

the

operation

or

use

of

your

display.

BEFORE

CALLING

FOR

SERVICE:

Please have

your

unit's

model number, serial number, and

the

date

of

purchase available.

Under some circumstances you

may

be

asked

to

provide credit card information

for

a non-warranty service fee, as a

deposit

for

advanced shipment,

or

cost

of

unreturned loaner unit.

If

a replacement

unit

is received, please use

the

carton and packaging

from

that

replacement

unit

in returning

the

defective

unit

to

an

LG

authorized service center.

Parts and service in accordance

with

the

LG

warranty

is LG's responsibility and will be provided

without

charge.

Other

service requirements will be

at

the

owner's expense.

If

you have problems in obtaining satisfactory

warranty

service,

write

or

call

the

LG

Customer

Interactive

Center.

To

assure

proper

credit and avoid unnecessary charges, you

must

obtain a Return Authorization before

returning

any

unit

to

the

Factory Service Center. Contact

the

Customer

Interactive

Center

for

details.

Service

for

your

LG

Television is provided

through

LG

Electronics Alabama, Inc.,

the

authorized

LG

Service Center

for

the

United States.

TO

CONTACT

LG

ELECTRONICS BY

MAIL:

LG

Customer

Interactive

Center

P.

0.

Box

240007

201

James Record Road

Huntsville, Alabama

35824

ATTN: CIC

LG

LCD/LED Televisions are

marketed

and

distributed

in

the

United States

by:

LG

Electronics U.S.A., Inc.,

1000

Sylvan Avenue, Englewood Cliffs,

NJ

07632

11

11

1

11

1

1111111111111111

1

1111111

11

11

11

1

11

1

11

1111111

11

11

111

1

11

1

11

1

* 3 8 4 0 T W L 0 5 6 A

*

P/NO : 3840TWL056A (1312-REV02)

Printed in Mexico
