Notice
Copyright © 2006 LibreStream Technologies Inc. All rights reserved. No part of this
document may be transmitted or reproduced without the expressed written consent of
LibreStream Technologies Inc.
Introduction
About n_sight
This innovative product is the first mobile device that incorporates all the components
necessary to participate in a wireless, full duplex voice and video collaboration session
with a remote user. n_sight extends the reach and leverages the benefits of an
organization’s conferencing infrastructure into the workplace, where mission critical
issues need to be reviewed and dealt with on a real-time basis. It provides collaboration
capabilities to locations previously inaccessible to real-time conferencing, such as test
labs, health care facilities, factory floors, service departments, remote suppliers, first
article inspection areas, customer facilities, and other remote work team locations.
Applications and Benefits
The n_sight system enhances productivity by allowing technical experts and remote
operators to jointly view, consult, diagnose and resolve issues in the shortest amount of
time, at the lowest possible cost. n_sight transports high-resolution video, sound and still
images through streaming multimedia from the scene right to your office desktop for
quick and easy collaboration. Using a stylus for on-screen graphic marking, the
telestration function instantly highlights areas of interest. n_sight brings you there in real-
time: saving downtime and travel expense, and improves productivity and customer
satisfaction.
Specifications
System Architecture
• High performance, multiprocessor architecture optimized for realtime multimedia
processing and communications in a hand-held form factor
• Microsoft WinCE 5.0
• SIP-based session control
• Windows-based PC Client allowing for easy call initiation and camera control
Physical Characteristics
• Size – 174 (6.86”) mm wide x 96.0 (3.78”) mm high x 87.1 (3.43”) mm deep
• Weight – 720 grams (1.59 pounds)
• Non slip hand grips
• Integrated LED-based illumination
Page 3
• Integrated water resistant doors for all external connectors
Optical Performance
• CCD image sensor – capable of high precision close-up video
• 10x optical zoom, f=4.2 mm (wide) to 42 mm (tele), F1.8 to F2.9
• 10 mm minimum working distance (wide end)
• 1000 mm minimum working distance (tele end)
• 1.5 lx (50 IRE) minimum illumination
• Automatic white balance
• Manual or automatic focus
Video Standard
• MPEG-4 Simple Profile @ L3
• Up to 2.5 Mbps
• User selectable resolutions and frame rates up to D1 (720 x 480) at 30 fps
User Interface & Features
• VGA (640 x 480) display/viewfinder
• Integrated touch screen
• User friendly graphical user interface
• Dedicated call send and end buttons – simple end-user experience much like a
cellular telephone
• Freeze frame button
• Stream button – video stream can be started and stopped by pushing one button
• Four-way, context sensitive cursor pad buttons (includes volume controls,
microphone mute, and illumination control)
• Media record button
• Manual focus button
• OSD (On Screen Display) button for easy access to status and other information
• Integrated contacts directory
• End user selectable streaming parameters
• LED indicators for power, stream/record, power/charging, and network link
Collaboration Features
• Form factor and software optimized to allow real time voice and video
collaboration related to subject matter being filmed by the camera
• Telestration: allowing both the camera operator and PC operator to draw on top of
the video or frozen image – both “ends” of the conversation see the drawing
simultaneously
• Remote control of major camera features – zoom, focus, freeze frame,
illumination, and stream parameters
Audio Features
• Omni-directional microphone for VoIP support
Page 4
• Directional microphone for capture of subject audio while minimizing pickup of
unwanted sounds
• Wired and wireless headset support for high noise environments
• Speakerphone with acoustic echo cancellation
• Silence suppression of VoIP communications to minimize network bandwidth
utilization
• Dynamic jitter buffer adjusts to changing network conditions to balance low
latency with a low voice dropout rate
Audio Standards
• VoIP: G.711, G.723, GSM
• Subject Audio: ISO/IEC MPEG-1 Layer III (MP3)
Security
• User ID and password control
• WLAN Network Authentication: WPA, WPA-PSK, or open
• WLAN Data Encryption: WEP, TKIP, or disabled
• Hardware-based AES-128 stream encryption
External Interfaces
• SD Memory Card
• S-video in
• AC power in
• Headset
• 10/100 Mb Ethernet
• USB host
• Audio Line-in
Communications
• IP calls – SIP
• Integrated 802.11 b/g radio
• RJ-45 Network LAN
Power
• Rechargeable 2400 mAH Li-Ion battery pack
• External AC power
Operating Environment
• Operating temperature: 0-50 C
• Storage temperature: -20-60 C
PC Client Software
• Displays video from remote camera
• Supports automatic resizing according to video stream parameters
Page 5
• Full duplex VoIP support
• Remote control of camera illumination, freeze frame, zoom, manual focus, and
stream parameters
• Telestration – remote drawing support
• Easy to use connection manager – familiar instant-messaging-like interface
FCC Information to Users
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This equipment was tested for RF Exposure compliance and meets the requirements with
Maximum Peak Spatial-Average SAR1g of 0.01 W/kg. No metallic accessories should be
used with this device and multiple devices should not be co-located at a distance of less
than 20 cm.
Warning: Changes or modifications not expressly approved by LibreStream
Technologies Inc. could void the user’s authority to operate this equipment.
