Life Sensing Instrument BWID K-1003 User Manual TM 8 DUAL LEAD TRANSMITTER
Life Sensing Instrument Company Inc. K-1003 TM 8 DUAL LEAD TRANSMITTER
User Manual
1
BWID SERIAL DATA TRANSMITTER
FCC ID: OF8-BWID
LIFE SENSING INSTRUMENTS, Inc.
1815 Hillsboro Blvd
MANCHESTER, TENNESSEE 37355
(931- 728-7259)
declares that the device manufactured as model no. BWID
does conform to the regulations as outlined in Title 47 of the US code of federal
regulations, Part 15 covering Class B personal computers and peripherals, and
Part 95, subpart H covering Wireless Medical Telemetry Service (WMTS).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Parts 15 and 95 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
or television communications. However, there is no guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna of the interfered device. Increase the separation between the
equipment and interfered device.
• Connect the equipment to a different outlet on a circuit other than the one the interfered device is
connected to.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufacturer can void the user’s
authority to operate the equipment. It is the responsibility of the equipment user to maintain compliance with
the FCC rules. To ensure compliance, use only those cables and/or accessories prescribed by the
manufacturer.
2
CAUTION:To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.
This device has been designed to operate with the antennas listed below, and having a maximum gain of 2.5 dB. Antennas
not included in this list or having a gain greater than 2.5 dB are strictly prohibited for use with this device. The required
antenna impedance is 50 ohms.
SHAMFDRA (611MHz), manufacturer, RW BADLAND, LTD (UK)
MPORTANT: To comply with the FCC RF exposure requirements, users should avoid grasping the transmitter
for any extended period of time while the device is in operation.
OPERATING INSTRUCTIONS
IMPORTANT - Operation of a BWID requires prior coordination with the ASHE
frequency coordination designator. For further guidance visit the ASHE website
at:
www.wmtssearch.com
The BWID serial data transmitter is a frequency synthesized transmitter operating in the UHF (608 -
614Mhz) range. The device’s sole purpose is to transmit non-HIPPA patient data from an ECG
bedside monitor to a receiving central station monitor.
Supply voltage in the range of 5 – 12Vdc is supplied by the host machine. The device’s permanently
attached cable connects to the host machine’s serial data output connector (DB9) and begins
operation immediately upon receiving power.
The device’s transmit frequency, last 5 digits of the serial number, has been factory preset and will be
entered on a corresponding channel of the central station monitor.
No other user-interface action is required for operation.
