User Manual
![](/img.php?id=3510094&img=bg1.png)
Quick Setup Guide | NS‐SPBTBRICK
Bluetooth Stereo Speaker with Powerbank
Before using your new product, please read these instructions to prevent any damage.
CHARGING AN EXTERNAL DEVICE
1 Open the port cover on the back of the speaker.
2 Plug one end of a USB cable into your external device and the other
end into the DC OUT port on the speaker.
3 Switch the ON/OFF switch to . Your external device is being
charged.
CONNECTING WITH BLUETOOTH
1 Make sure that your Bluetooth device is turned on and within 33 feet
(10 meters) of your speaker.
2 On your speaker, press and hold the button. Your speaker enters
pairing mode, and the LED on your speaker blinks. Your speaker
remains in pairing mode until it pairs with a Bluetooth device.
Note: Press and hold the button to return to pairing mode.
3 Turn on your Bluetooth device and turn on Bluetooth. Set your device
to pairing mode, then select NS-SPBTBRICK. See the instructions that
came with your Bluetooth device for information about pairing.
4 If you are asked for a password, enter 0000. When pairing is
complete, the LED on your speaker lights solid blue.
5 To disconnect from the paired Bluetooth device, press and hold the
button on your speaker for three seconds. You will hear a beep. Your
speaker disconnects from the Bluetooth device and enters pairing
mode again.
SAFETY INSTRUCTIONS
• Never expose the product to re as this could result in personal injury.
• Do not store the product in an extremely cold or warm environment.
• Never dismantle the product.
• Never let children play with the product.
• Do not expose the product to dampness or moisture.
• The product should not be exposed to dripping or splashing.
CHARGING YOUR SPEAKER
1 Connect the small end of the charging cable to the micro USB port on
the back of your speaker.
2 Connect the other end to a USB port on your computer.
Note: When the battery is low, you will hear beeps. About ve minutes later, the
speaker will power o automatically.
TURNING YOUR SPEAKER ON AND OFF
• Slide the ON/OFF to ON. The LED indicator blinks quickly and the
speaker enters pairing mode.
PACKAGE CONTENTS
• Bluetooth speaker
• USB cable
• Quick Setup Guide
FEATURES
• Wirelessly stream from any Bluetooth device
• Rechargeable battery lasts up to 30 hours
• Integrated power bank charges your mobile devices
• Water-resistant body
Top view
Back view LED
Blinks blue
Solid blue
DESCRIPTION
Speaker is in pairing mode
Speaker is paired OR an AUX device is connected
CHARGING INDICATOR
Solid red
O
DESCRIPTION
Charging
Fully charged
Your speaker loses the
Bluetooth connection if you...
Turn o your speaker.
Move the Bluetooth device out
of range.
Turn o your Bluetooth device.
Turn o Bluetooth on your
Bluetooth device.
Connect your Bluetooth device
to another Bluetooth device.
To reconnect...
Turn on your speaker. Your speaker searches
for the last connected Bluetooth device and
reconnects.
Make sure that your Bluetooth device is
within 33 feet of your speaker.
Turn on your Bluetooth device, then make
sure that Bluetooth is on.
Turn on Bluetooth on your Bluetooth device.
Disconnect your Bluetooth device from the
other Bluetooth device, then set your device
to pairing mode. Select NS-SPBTBRICK on
your Bluetooth device.
Flat size (W×H): 355.6 × 139.7 mm
Final folded size: 44.45 × 139.7 mm
Microphone
LED indicator
Play/pause/phone
Bluetooth pairing
Previous Next Volume down
Volume up
Charging indicator
AUX IN jackDC OUT
ON/OFF/000
switch
Micro USB charging port
RECONNECTING TO A PAIRED DEVICE
When your speaker is not paired to a device, the LED blinks blue.
Notes:
• If a device does not automatically reconnect, you may need to reselect
NS-SPBTBRICK on your Bluetooth device.
• If you move your device out of range, it will remain paired for 10 minutes, but
no sound will come from the speaker until you come back within range. After
10 minutes, the speaker will reenter pairing mode.
LISTENING TO MUSIC
1 Slide the ON/OFF switch to ON, then connect to your Bluetooth
device.
2 Begin playback on your Bluetooth device.
3 Adjust the volume on your speaker by pressing the + or - buttons.
Note: Press the to start playback. Press the and to go to the
next or previous track.
NS-SPBTBRICK_15-0655_QSG_V2_EN.ai 1 8/4/2015 2:09:20 PMNS-SPBTBRICK_15-0655_QSG_V2_EN.ai 1 8/4/2015 2:09:20 PM
V2
FINAL
FOR PRINT
![](/img.php?id=3510094&img=bg2.png)
Before
using
your
new
product
,
please
read
these
instructions
to
prevent
any
damage
.
V2 ENGLISH 15-0655
PLAYING MUSIC FROM AN EXTERNAL SOUND
SOURCE
1 Connect an external sound source, such as an MP3 player, by
plugging an audio cable with a 3.5 mm plug (not included) into the
AUX IN jack on the right side of your speaker.
Notes:
• When an AUX cable is connected, Bluetooth goes into standby mode. To play
music from your Bluetooth device, press play ( ) on the speaker or your
Bluetooth device. To return to AUX mode, press pause or stop on the speaker
or your Bluetooth device.
• When playing music via audio cable, you should pause the Bluetooth sound
source paired to your speaker or disconnect the Bluetooth device.
2 Start playback on the external device.
3 Press + or – to adjust the volume.
4 Control playback using the controls on the external device.
TAKING A CALL
1 Press the button briey to accept an incoming call.
OR
Press and hold the button to reject an incoming call.
2 Press the button during a call to end the call.
RESETTING THE SPEAKER
Caution: This will remove all paired Bluetooth devices.
• Turn on the speaker, then press and hold the previous button ( )
and the volume up + buttons at the same time for approximately
ve seconds. You will hear a warning tone and LED indicator will
blink, then power o.
TROUBLESHOOTING LEGAL NOTICES
FCC
This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions: 1) this device may not cause harmful
interference, and 2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged
to try correct the interference by one or more of the following measures:
- Reorient the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into and outlet on a circuit dierent from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modications not expressly approved
by the party responsible for compliance could void your authority to
operate the equipment.
RSS
IC Statement
This device complies with Industry Canada licence exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicable
s aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suiv antes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accept er tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en comprom
ettre le fonctionnement.
PROBLEM
No power
No sound or low volume
Cannot establish Bluetooth
connection
My Bluetooth device keeps
unpairing
“NS-SPBTBRICK” does not
appear on my Bluetooth
device
SOLUTION
• Make sure that your speaker’s battery is charged.
• Make sure that your speaker is turned on.
• Make sure that your Bluetooth device is turned on, Bluetooth is turned
on, and NS-SPBTBRICK is selected.
• Turn up the volume on your speaker.
• Turn up the volume on your Bluetooth device.
• Make sure that your Bluetooth device is not muted.
• Make sure that your speaker is not paired to another Bluetooth device.
• Make sure that your Bluetooth device is not paired to another Bluetooth
device.
• Shorten the distance between your speaker and your Bluetooth device.
• Make sure that your speaker is in pairing mode. Press and hold the
button to reenter pairing mode.
• Shorten the distance between your speaker and your Bluetooth device.
• Turn your devices o, then on. Re-pair your speaker and your Bluetooth
device.
• Make sure that your speaker is not paired to another Bluetooth device.
• Make sure that your speaker and Bluetooth device are both in pairing
mode.
• Make sure that your Bluetooth device supports Bluetooth v4.0 and
below.
• Make sure that your Bluetooth device is not connected to any other
device.
• Make sure that you have selected NS-SPBTBRICK on your Bluetooth
device.
• Make sure that AUX external device is not connected. Disconnect the
AUX cable and reenter pairing mode.
• Shorten the distance between your speaker and your Bluetooth device.
• If the battery on your Bluetooth device is low, recharge the battery.
• If the battery on your speaker is low, recharge the battery.
• Shorten the distance between your speaker and your Bluetooth device.
• Put your speaker into pairing mode, then refresh your list of Bluetooth
devices. For more information, see the documentation that came with
your Bluetooth device.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
1-877-467-4289 (U.S. and Canada)
01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
©2015 Best Buy. All rights reserved.
Made in China
