Lightcomm Technology NSP16AT10 10.1-Inch Wi-Fi Android Tablet User Manual Users manual
Lightcomm Technology Co., Ltd. 10.1-Inch Wi-Fi Android Tablet Users manual
Users manual
8"/10.1" Wi-Fi Android™ Tablet
NS-P16AT08/NS-P16AT10
Before using your new product, please read these instructions to prevent any damage.
User Guide
v1
R1
Table of Contents
Welcome 5
Features 5
Package contents 5
8-inch tablet overview 6
10-inch tablet overview 9
Home screen 12
Get started 13
Charge the battery 14
Turn on your tablet for the first time 15
Understand the basics 15
Turn your tablet on or off 15
Restart your tablet 16
Adjust the volume 16
Navigate with gestures 17
Navigate with on-screen function buttons 18
Use the Recents screen 20
Use the keyboard 20
Download apps 21
Capture and view a screenshot 22
View a status item or notification 22
Check for updates 23
Change basic settings 25
Customize the Home screen 25
Customize the lock screen 27
Set and use the screen lock 28
Set the date and time 29
Adjust the screen brightness 29
Adjust the power saving settings 30
Setting the screen font size 31
Adjust system sounds 31
Select your language 32
Connect to a computer 33
Windows 33
Mac 34
www.insigniaproducts.com
2
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Transfer or download an e-book 36
Set up wireless connections 36
Connect to a Wi-Fi network 36
Add a Wi-Fi network 37
Check network status 38
Connect to a Bluetooth device 38
Use the Internet 38
View web pages 39
Search for text on a web page 40
Copy text on a web page 41
Check and clear history 41
Manage bookmarks 43
Manage downloads 44
Use Gmail™ 45
Set up a Gmail account 45
Manage Gmail accounts 45
View a Gmail 47
Create a Gmail 48
Create and manage contacts 49
Use the calendar 49
Work with photos and video 50
Use the camera 50
View photos and video 51
Edit photos 52
Share photos or videos 52
Listen to music 53
Control playback 53
Using playlists 53
Manage storage space 53
Use a Micro SD card 53
View storage space 54
Clear app cache and data 55
Uninstall apps 56
Free up storage space 57
www.insigniaproducts.com
3
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Reset to default settings 57
Troubleshooting 57
Maintenance 58
Specifications 60
8"Tablet (NS-P16AT08) 60
10.1" Tablet (NS-P16AT10) 61
Customer support 61
Safety information 62
Legal notices 62
One-Year Limited Warranty 66
www.insigniaproducts.com
4
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Welcome
Thank you for purchasing an Insignia 8"/10.1" Wi-Fi Android™ Tablet (NS-
P16AT08 or NS-P16AT10). Your tablet is a state of the art Android design that will
give you reliable and trouble-free performance.
Features
Familiarize yourself with your tablet's features below.
Wi-Fi Connectivity
Connect to the Internet wherever you are with the latest Wi-Fi technology.
Touch Screen
The screen responds to your touch instantly.
Third-party Application Support
Install a large number of third-party applications on your tablet.
Built-in Cameras
Use the built-in front and back cameras as a webcam or to record videos.
Built-in G-sensor
Rotate the tablet to automatically switch between landscape and portrait modes.
Entertainment
Enjoy music, movies, pictures, and e-books on a single device.
PACKAGE CONTENTS
l8"/10.1" Wi-Fi Android™ Tablet
lMicro USBcable
lAC power adapter
lQuick Setup Guide
lImportant Information
www.insigniaproducts.com
5
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
8-INCH TABLET OVERVIEW
Learn more about your 8-inch (NS-P16AT08) tablet's features. Or, view the 10-
inch tablet overview (on page9) (NS-P16AT10).
Front
Item Description
Front camera Take pictures or record video. See Use
the camera (on page50).
www.insigniaproducts.com
6
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Back
Item Description
Power on/off
button
Press briefly to lock or unlock the
screen.
Press and hold to turn your tablet on/off.
Press and hold for ten seconds to
restart your tablet if it freezes.
Volume up/down
button
Press to increase or decrease the
volume.
Rear camera Take pictures or record video. See Use
the camera (on page50).
Speakers Play audio from your tablet.
www.insigniaproducts.com
7
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Side
Item Description
Earphone jack Connect 3.5 mm headphones to listen
to audio.
Micro USB port Connect the micro USBcharging cable
to charge your tablet.
Reset hole
Insert a paper clip if your tablet freezes.
[Do customers need to hold it? If so,
how long?]
microSD™ card
slot
Insert a microSDcard to increase your
tablet's memory.
Microphone Speak into the microphone to capture
your voice.
www.insigniaproducts.com
8
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
10-INCH TABLET OVERVIEW
Learn more about your 10-inch (NS-P16AT10) tablet's features. Or, view the 8-
inch tablet overview (on page6) (NS-P16AT08).
Front
Item Description
Front camera Take pictures or record video. See Use
the camera (on page50).
www.insigniaproducts.com
9
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Back
Item Description
Power on/off
button
Press briefly to lock or unlock the
screen.
Press and hold to turn your tablet on/off.
Press and hold for ten seconds to
restart your tablet if it freezes.
Reset hole
Insert a paper clip if your tablet freezes.
[Do customers hold it down? If so, how
long?]
Volume
up/down button
Press to increase or decrease the
volume.
www.insigniaproducts.com
10
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Item Description
Rear camera Take pictures or record video. See Use
the camera (on page50).
Speakers Play audio from your tablet.
Side
Item Description
Earphone jack Connect 3.5 mm headphones to listen
to audio.
Micro HDMI jack Connect your tablet to a TV or other
devices with a micro HDMIcable.
Micro USB port Connect the micro USBcharging cable
to charge your tablet.
microSD™ card
slot
Insert a microSDcard to increase your
tablet's memory.
Microphone Speak into the microphone to capture
your voice.
www.insigniaproducts.com
11
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
HOME SCREEN
See Navigate with gestures (on page17) for information on using the touch
screen. See Navigate with on-screen function buttons (on page18) for
information on navigating on your tablet.
8-inch tablet
10-inch tablet
www.insigniaproducts.com
12
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Notifications
Swipe down from the top edge of the screen with one finger.
Status items
Swipe down from the top edge of the screen with two fingers.
OR
Open notifications, then swipe down again.
Get started
This section has resources to help you start using your tablet right away. You can
also check out Features (on page5) to familiarize yourself with your new tablet.
For more information about using and customizing your tablet, see Understand
the basics (on page15) and Change basic settings (on page25).
www.insigniaproducts.com
13
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
CHARGE THE BATTERY
Before charging your tablet battery for the first time, use your tablet until the battery
is completely empty, then charge it fully before using it again. This will help
increase your battery's efficiency and life. After the first time, charge your battery
when it is less than 15% full.
1. Insert the micro USB cable into your tablet's micro USB port.
2. Insert the other end into the AC power adapter, then connect it to a power
outlet.
Note:It takes about four hours to fully charge your tablet.
Conserve battery power
lTurn off Wi-Fi when you aren't using it.
lLower the screen brightness. See Adjust the screen brightness (on
page29).
lClose apps that you aren't using. See Use the Recents screen (on
page20).
lIf your tablet is inactive, your tablet sleeps with the screen off (depending on
the screen timeout setting. See Customize the lock screen (on page27)).
Press to wake it up.
lIf you are using an animated wallpaper, change it to a static wallpaper.
Helpful tips
lFor the best battery performance, use your tablet often.
lMake sure that you charge it at least once a month.
lUse the power adapter that came with your tablet for charging.
lYou can use your tablet while it is being charged. However, to conserve
your tablet's battery life, it isn't recommended.
www.insigniaproducts.com
14
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
TURN ON YOUR TABLET FOR THE FIRST TIME
1. Press and hold the button on the side of your tablet until you see the
Welcome screen.
2. Select your language, then follow the instructions on the screen to complete
setup.Note:You can use your tablet without connecting to the Internet and
signing into a Google™ account, but you won't be able to use the Play
Store or receive software updates.
Understand the basics
Learn the basics about customizing and navigating your tablet, plus other helpful
features.
TURN YOUR TABLET ON OR OFF
Turn on your tablet
lPress and hold the button. Your tablet turns on.
Note
If you don't touch your tablet for a while (depending on the screen timeout
setting), it may sleep with the screen off. Press briefly to wake it up.
www.insigniaproducts.com
15
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Turn off your tablet
1. Press and hold the button until the Power off screen opens.
2. Tap Power off. Your tablet turns off.
RESTART YOUR TABLET
lIf your tablet freezes, insert a paper clip or pin into the reset hole, then turn
on your tablet again. Your stored data and customized settings aren't
affected.
[Reviewers:Does customers need to hold it in place for any length of time? If
so, how long?]
Note
To reset your tablet back to factory settings, see Reset to default settings (on
page57).
ADJUST THE VOLUME
Note
See Adjust system sounds (on page31) for more information.
lPress the volume +or –button to raise or lower the volume.
OR
If you have the 10-inch tablet (NS-P16AT10), you can tap (lower volume)
or (raise volume) at the bottom of the screen.
www.insigniaproducts.com
16
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
NAVIGATE WITH GESTURES
Gesture Action
Tap
Tap an app or another item with
your finger to open or select it.
Touch & hold
Touch an item with your finger and
do not release it until your tablet
responds.
Drag
Touch and hold an item with your
finger, then move your finger to the
position where you want the item.
Swipe
Quickly slide your finger either
vertically or horizontally across the
screen to scroll up and down or right
to left.
Pinch
Pinch your fingers together or move
them apart to zoom in and out.
www.insigniaproducts.com
17
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Gesture Action
Rotate Turn your tablet sideways to switch
between landscape and portrait.
Tip: If the orientation does not
change, swipe down from the top of
your screen with two fingers, then
tap Landscape or Portrait to turn off
the rotation lock.
NAVIGATE WITH ON-SCREEN FUNCTION BUTTONS
Icon Tap to...
Start a text search on
Google™.
Start a voice search on
Google.
Return to the previous screen.
Return to the home screen.
Open the list of recently used
and running applications. See
Use the Recents screen (on
page20).
View all apps installed on
your tablet. Swipe the screen
to the left to see more apps.
www.insigniaproducts.com
18
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
USE THE RECENTS SCREEN
The Recents screen lets you quickly switch to recently used and open apps. If you
have too many apps running, your tablet may run slower or shorten your battery
life. Close apps you are not using to improve your tablet's performance.
lOn the home screen, tap Recents. A list of the most recently used or
running apps appears.
lTo see more apps, swipe up or down.
lTo open an app, tap the app window.
lTo close an app, drag the app screen left, right, or tap x.
USE THE KEYBOARD
The keyboard automatically opens when you start a program or select an item that
needs text or numbers.
Icon Description
Switch between uppercase or lowercase letters.
?123 Switch between number/symbol or text mode.
Note:Tap ABC to open the standard keyboard.
OR
Change keyboard language. SeeSelect your language (on
page32) to enable languages.
Note:These icons are not always available.
www.insigniaproducts.com
20
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Icon Description
Close the keyboard.
Tap to delete a character.
Tap and hold to delete all characters to the left of the cursor.
Open the emoji keyboard.
Note: This icon is not always available. Tap ABC to open the
standard keyboard.
Confirm that you are finished entering information.
Search for text you entered.
lTo insert a character, tap the character to the left of where you want it, then
use the keyboard to type.
lTo delete a character, touch to the right of it, then tap (delete).
lWhen you don’t need the keyboard, press at the bottom of the screen to
close it.
lTo adjust keyboard sound settings, see Adjust system sounds (on
page31).
DOWNLOAD APPS
Caution
To protect your tablet and personal data, only download apps from trusted
sources.
You must connect to the Internet to download apps. See Connect to a Wi-Fi
network (on page36) for more information.
www.insigniaproducts.com
21
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
1. Tap Apps >Play Store.
2. Search for an app or browse the categories to find apps, then follow the on-
screen instructions to install.
Notes
lIf a third-party application does not work on your tablet, contact the app
developer for more information.
lSee Uninstall apps (on page56) for information on permanently
deleting an app.
CAPTURE AND VIEW A SCREENSHOT
lTo capture a screenshot, press and hold the and Vol – buttons at the same
time.
lTo view the screenshot:
1. Tap Apps >Photos.
2. Tap the thumbnail of the screenshot. See View photos and video (on
page51) for more information on navigating your photos.
VIEW A STATUS ITEM OR NOTIFICATION
Status and notification information are located at the top of the screen.
www.insigniaproducts.com
22
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
lDrag your finger down from the top of the screen to view notifications (such
as email, calendar, and time).
lDrag two fingers down from the top of the screen to view status items (such
as Wi-Fi, Bluetooth, and battery information).
CHECK FOR UPDATES
Make sure that you have the most up-to-date software.
Update your tablet
Warning
Back up your personal data before updating your tablet. Updates may delete
your data.
www.insigniaproducts.com
23
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
1. Tap Apps >Settings >About tablet.
2. If you have the 8-inch tablet, tap Update >Check update. If an update is
available, your tablet displays the update version information.
OR
If you have the 10-inch tablet, tap System updates >
CHECKFORUPDATE. If an update is available, your tablet displays the
update version information.
3. Follow the on-screen instructions to install.
Update your apps
1. Tap Apps >Play Store.
2. Tap (menu) in the upper-left corner, then tap My apps.
3. Locate the app you want to update from the INSTALLED tab. .
Note:If there is no Updates heading, all your apps are up-to-date.
Tip
Tap the Allow automatic updating check box (to let your tablet
automatically update the app in the future.
4. Tap the app to open the app page, then tap UPDATE.
5. Tap CONTINUEor ACCEPTif you agree to the app permissions. Your app
is updated.
www.insigniaproducts.com
24
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Change basic settings
Customize settings on your tablet to fit your personal taste.
CUSTOMIZE THE HOME SCREEN
Change the wallpaper
1. Touch and hold on the home screen until a menu appears.
2. Tap WALLPAPERS.
3. Tap the wallpaper you want to use. To select a photo you took, tap Pick
image.
4. Tap Set wallpaper.
Tip
Animated wallpapers use more battery. To conserve battery, use a
static wallpaper.
Add an item to the home screen
1. Tap Apps to show all apps.
2. Touch and hold the app you want to add until it moves to the home screen.
Tip
You can also add or remove items from the favorites tray.
Move a home screen item
1. Touch and hold the item you want to move until it's highlighted.
2. Drag the item to where you want it, then release your finger.
www.insigniaproducts.com
25
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Remove a home screen item
Note
Removing an item from the home screen doesn't delete the app. See
Uninstall apps (on page56).
1. Touch and hold the item you want to remove until it is highlighted.
2. Drag the item to Xuntil it turns red, then release your finger.
Create a folder
1. Touch and hold the app you want to move into a folder until it is highlighted.
2. Drag the app on top of another app until a white circle appears, then release
your finger. A folder is created.
www.insigniaproducts.com
26
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
3. Tap the folder to open it, then tap Unnamed Folder to open the keyboard
and name the folder. Tap when finished.
4. To add more items, drag them into the folder.
Note
To remove apps from a folder, open the folder, touch and hold the app, then
drag it back to the home screen. The folder is deleted when only one app is
left inside.
CUSTOMIZE THE LOCK SCREEN
Add owner info
Tip
For information on changing your screen lock, see Set and use the
screen lock (on the next page).
1. Tap Apps >Settings >Security >Owner info.
2. Tap the check box next to Show owner info on lock screen, then type the text
you want to display on the lock screen.
3. Press to put your tablet to sleep, then press again to wake it up. The lock
screen opens and your text is displayed.
Remove owner info
1. Tap Apps >Settings >Security>Owner info.
2. Uncheck the box next to Show owner info on lock screen.
www.insigniaproducts.com
27
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
SET AND USE THE SCREEN LOCK
Change your lock type
1. Tap Apps >Settings >Security >Screen lock.
2. Tap the screen lock type you want to use, then follow the on-screen
instructions.
Unlock the screen
There are several ways to unlock your tablet, depending on which screen lock is
enabled. You may need to:
lSwipe up on the screen.
lSay a voice command.
lDrag your finger to enter a pattern.
lEnter a PINor password.
www.insigniaproducts.com
28
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Set the lock screen timeout
1. Tap Apps >Settings >Display.
2. Tap Sleep, then select how long before your inactive tablet sleeps.
SET THE DATE AND TIME
1. Tap Apps >Settings > Date &time.
lAutomatically or manually set your date and time.
lSelect your time zone.
lChoose your hour format (12-hour or 24-hour).
lChoose your date format.
ADJUST THE SCREEN BRIGHTNESS
lDrag your two fingers down from the top of the screen to view status items,
then drag the slider left or right.
www.insigniaproducts.com
29
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
ADJUST THE POWER SAVING SETTINGS
Tip
To conserve battery life, turn off Wi-Fi when you're not using it.
1. Tap Apps >Settings >Battery.
2. Tap (options) in the upper-right corner, then tap Battery saver.
3. Tap the slider to turn on Battery saver mode.
www.insigniaproducts.com
30
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Conserve battery power
lTurn off Wi-Fi when you aren't using it.
lLower the screen brightness. See Adjust the screen brightness (on
page29).
lClose apps that you aren't using. See Use the Recents screen (on
page20).
lIf your tablet is inactive, your tablet sleeps with the screen off (depending on
the screen timeout setting. See Customize the lock screen (on page27)).
Press to wake it up.
lIf you are using an animated wallpaper, change it to a static wallpaper.
SETTING THE SCREEN FONT SIZE
1. Tap Apps >Settings >Display >Font size.
2. Select the font size you want.
ADJUST SYSTEM SOUNDS
Change your notification tones, system volume, and other sound settings.
Adjust general volume and feedback settings
1. Tap Apps >Settings >Sound ¬ification.
2. Next to General, tap (settings).
3. Use the available options to adjust your tablet's volume. You can:
lAdjust the alarm and notification volume level.
lChange the default notification sound.
lTurn system sound settings on or off (including Touch sounds and
Screen lock sound).
Turn the keyboard sound on or off
1. Tap Apps >Settings >Sound & notification.
2. Next to General, tap (settings).
3. Under System, tap Touch sounds.
www.insigniaproducts.com
31
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
SELECT YOUR LANGUAGE
Change your system language or add an additional language to your keyboard.
Change the system language
1. Tap Apps >Settings >Language &input >Language.
2. Select the language you want from the list. Your system (including the
keyboard) language changes.
Add a keyboard language
By default, your tablet uses the system language as its keyboard language. If you
want to add an additional language to your keyboard:
1. While the keyboard is open, touch and hold /(slash) or ,(comma) until a
settings icon appears.
www.insigniaproducts.com
32
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
2. Tap Languages.
3. Tap the languages you want to use on your keyboard.
Note
If the languages are grayed out, tap Use system language to
enable them.
Switch keyboard language
Make sure that you have enabled additional languages on your keyboard. See
Add a keyboard language (on the previous page) .
lTap to toggle between keyboard languages. The keyboard language
appears in the space bar.
Connect to a computer
For more information on viewing and transferring files, see your computer's
documentation.
WINDOWS
1. Connect the USBcable from your tablet to your computer.
2. Open Computer or My Computer, then click your model number (NS-
P16AT08 or NS-P16AT10) icon to view or transfer files.
Note
If your computer does not recognize your tablet, check your
tablet's USB connection type:
1. Connect the USBcable from your tablet to your computer.
2. Tap Apps >Settings >Storage > (options) >
USB computer connection.
3. Tap Media device (MTP)to view and transfer all files on
your tablet.
3. When you are finished, safely remove your tablet before unplugging the
cable.
www.insigniaproducts.com
33
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
MAC
You must install software on your Mac computer to transfer files to or from your
tablet.
To install Android File Transfer software:
1. On your Mac computer, go to www.android.com/filetransfer, then click
DOWNLOAD NOW. Your computer downloads a file.
2. Open your Downloads folder, then double-click androidfiletransfer.dmg.
3. If prompted, click Open.
4. Drag the Android File Transfer icon to the Applications icon.
www.insigniaproducts.com
34
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
To transfer files:
1. Connect the USBcable from your tablet to your Mac computer.
2. Open Applications, then double-click Android File Transfer.
Note
If computer does not recognize your tablet, check your tablet's
USB connection type:
1. Connect the USBcable from your tablet to your computer.
2. Tap Apps >Settings >Storage > (options) >
USB computer connection.
3. Tap Media device (MTP)to view and transfer all files on
your tablet.
3. In the Android file transfer window you can:
lCopy: Drag files between the file transfer window and your Mac's
Finder.
lDelete:Control-click a file, then click Delete.
Note:You must transfer files to your computer to open them.
4. When you are finished, make sure that all files are done transferring, then
disconnect your tablet.
www.insigniaproducts.com
35
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Transfer or download an e-book
Note
Make sure that your e-books are in the PDF, EPUB, TXT, RB2, RTF, or PDB
format.
Transfer an e-book from your computer
1. Connect your tablet to your computer. See Connect to a computer (on
page33).
2. Copy an e-book file from your computer to a folder on your tablet.
Download an e-book from the Play Store
1. Tap Apps >Play Store.
2. Tap Books to browse for books or tap to search for a specific book.
Set up wireless connections
Learn how to set up wireless connections such as Wi-Fi and Bluetooth.
CONNECT TO A WI-FI NETWORK
1. Tap Apps >Settings >Wi-Fi.
2. Tap the slider to turn on Wi-Fi . Your tablet automatically scans for
available networks.
3. Tap a Wi-Fi network.
lIf the network is open, your tablet connects automatically.
lIf the network is secured, enter a password. Tap Connect.
A connection icon appears in the status bar when your tablet is connected.
www.insigniaproducts.com
36
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
ADD A WI-FI NETWORK
1. Tap Apps >Settings >Wi-Fi.
2. Tap the slider to turn on Wi-Fi .
3. Tap (options), then Add network.
4. Enter the Network SSID(name), then select the type of security you want
from the drop-down menu. You can select:
lNone—No security.
lWEP—Wired Equivalent Privacy. Note:A password is required.
lWPA/WPA2 PSK—Wi-Fi Protected Access. Note:A password is
required.
l802.1x EAP—802.1x Extensible Authentication Protocol.
Note
If you aren't sure which security type to select, see your network setup
documentation.
5. Tap CONNECT. Your new network appears in the list of available networks.
Note
See Connect to a Wi-Fi network (on the previous page) for connection
instructions.
www.insigniaproducts.com
37
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
CHECK NETWORK STATUS
1. Tap > Settings >Wi-Fi.
2. Make sure the Wi-Fi slider is turned On. A list of available networks
appears.
lSecured networks are noted with a lock icon.
lIf you are connected to a network, "Connected" appears below the
network name.
lSignal strength is noted with an icon to the left of the network name.
CONNECT TO A BLUETOOTH DEVICE
1. Tap > Settings >Bluetooth.
2. Tap the slider to turn on Bluetooth. Your tablet searches for devices.
3. Turn on Bluetooth on the device you want to pair to your tablet and make
sure that your device is visible to other Bluetooth devices. See the
documentation that came with your Bluetooth device for instructions.
4. Tap an available device to pair with from the list. Follow the on-screen
prompts. Some devices connect automatically, while others may require a
PIN.
Use the Internet
Learn how to navigate the Internet and adjust browser settings with your tablet.
Note
These instructions are for Google Chrome™. If you
are using a different browser, see the browser's
online help.
www.insigniaproducts.com
38
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
VIEW WEB PAGES
Connect to a Wi-Fi network to browse the Internet. See Connect to a Wi-Fi
network (on page36).
Notes
lThese instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
lRotate your tablet to landscape view for the best viewing experience.
Open a web browser
lTap Apps >Chrome.
Note:If you have installed a different browser, tap the corresponding icon
from Apps to use it.
Navigate a web page
lTap the address bar to enter a web address or search, then tap (enter).
lTap , then speak to search.
lDrag your finger up, down, left, or right to scroll.
lPinch your fingers together or spread them apart to zoom in and out.
lTap a tab at the top to switch windows or open a new browser window.
lTap xon the tab to close a window.
lTap , to return to the previous page.
lTap , to view menu items.
www.insigniaproducts.com
39
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
SEARCH FOR TEXT ON A WEB PAGE
Note
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
1. In your browser, tap (options), then Find in page.
2. Use the keyboard to type the text you want to find. As you type, matching
characters on the web page are highlighted.
3. Tap ▲ or ▼ to go to the previous or next matching item.
4. Tap xto close the search bar and keyboard.
www.insigniaproducts.com
40
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
COPY TEXT ON A WEB PAGE
1. In your browser, touch and hold the text until a blue ribbon covers the text.
2. Drag the blue selectors to the left or right to select text.
3. Tap COPY on the top of the screen.
4. Go to where you want to paste the text (such as an email), touch and hold
the area, then tap PASTE.
CHECK AND CLEAR HISTORY
Note
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
lIn your browser, tap (options), then tap History.
www.insigniaproducts.com
41
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
You can:
lTap a website to open the page.
lTap to search for a website.
lTap xto remove a single website from your browsing history.
OR
Tap CLEAR BROWSINGDATA... to clear all browsing history. Select
the kinds of data you want to delete, then tap Clear.
www.insigniaproducts.com
42
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
MANAGE BOOKMARKS
You can store an unlimited number of bookmarks.
Note
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
Save a bookmark
1. Go to the website that you want to bookmark.
2. Tap in the address bar.
3. Name your bookmark, select the folder you want to save it in, then tap Save.
www.insigniaproducts.com
43
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Open a bookmark
lIf you saved the bookmark to a folder, tap (options), Bookmarks, then
select the website from the list.
MANAGE DOWNLOADS
View a download
1. Tap Apps >Downloads.
2. To open a download, tap the file name. If needed, select the program you
want to use to open the file.
Delete a download
1. Tap Apps >Downloads.
2. Touch and hold the file name until it is selected, then tap .
www.insigniaproducts.com
44
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Share a download
1. Tap Apps >Downloads.
2. Touch and hold the file name until it is selected, tap , then select how you
want to share the file.
Use Gmail™
Use the Gmail app to add your email accounts from Google and other web-based
providers like Outlook and Yahoo®.
SET UP A GMAIL ACCOUNT
You may have set up a Gmail account when you set up your tablet.
1. Tap Apps >Gmail.
2. Follow the on-screen instructions to set up your account.
Note
To set up another Gmail account, see Manage Gmail accounts
(below).
MANAGE GMAIL ACCOUNTS
Add an additional Gmail account
1. Tap Apps >Settings >Accounts >+ Add account.
2. Follow the on-screen instructions to set up your account.
www.insigniaproducts.com
45
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Change Gmail account settings
1. Tap Apps >Gmail. > Menu >Settings.
2. Tap your account name.
3. Change your account settings as needed.
VIEW A GMAIL
lTap Apps >Gmail.
Note:If you have more than one email account, the last account you used
opens. To open a different account, tap (menu) in the upper-left corner,
then select a different account.
lDrag your finger up and down to scroll through your Gmails.
lTap a Gmail to open it.
lTap (menu) in the upper-left corner to display folders or select a
different Gmail account.
lTap to search.
www.insigniaproducts.com
47
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
lTouch and hold a Gmail to select it and display options such as
archive, delete, mark as read or unread, or move the email.
lTouch and hold a Gmail to deselect the it.
lTap to compose a new Gmail. See Create a Gmail (below) for more
information.
CREATE A GMAIL
1. Tap Apps > Gmail. > (compose).
Note
To open a different account, tap in the upper-left corner, then select a
different account.
www.insigniaproducts.com
48
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
2. Enter the recipient's email address. As you enter the address, your tablet
displays your contacts that match the characters you've entered. You can tap
a contact or continue entering the address.
Note
To send the email to more than one person, separate the email
addresses with a comma.
3. Enter a subject in the subject field (optional).
4. Enter your message, then tap SEND when you are finished.
Note
Tap Save draft under options or (back) to save your email as a
draft. To access your drafts, tap in the upper-left corner, then tap
Drafts.
Create and manage contacts
lTap Apps >Contacts. You can:
lTap to search for a contact.
lTap (in the lower, right corner) to add a new contact.
lTap a contact to view or edit its information.
Use the calendar
lTap Apps >Calendar.
lTap +to add a new event.
lTap to change calendars or settings.
lTap to change the calendar view or search for an event.
www.insigniaproducts.com
49
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Work with photos and video
Learn how to take pictures and video with your tablet. Then, learn how to view and
edit them before sharing with your friends and family.
USE THE CAMERA
Note
See View photos and video (on the next page) for information on how to
view your pictures.
Take a picture
1. Tap Apps >Camera.
2. Tap to switch between front and rear-facing cameras.
3. Swipe through the toolbar to select a picture mode:
l:Normal mode
l: Live Photo mode
l: Face beauty mode
l: Panorama mode
4. Tap to take a photo.
Record a video
1. Tap Apps >Camera.
2. Tap to start and stop recording.
www.insigniaproducts.com
50
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Change camera settings
1. Tap Apps >Camera.
2. Tap to open the settings menu.
l: Adjust general settings
l: Adjust picture settings
l: Adjust video settings
lTo restore defaults, tap , then Restore Defaults.
3. Tap to adjust:
l: Exposure level
l: Color effect
l: White balance
l: Scene mode
VIEW PHOTOS AND VIDEO
View photos
1. Tap Apps >Photos.
lDrag your finger to the left or right to browse your photos.
lTap a photo thumbnail to view in full screen.
Tip
Videos have a ► (play) icon and photos don't.
lTo zoom in or out, pinch your fingers together or apart.
lTo view more options, select a photo, then tap . Options may include:
lDetails – View information about your photo.
lPrint – Print a photo with a connected printer.
lSlideshow – Start a slideshow of the photos in the current folder.
lSet as… – Set your photo as your wallpaper or contact photo.
lSettings – View photo settings.
lFeedback – Feedback photos information.
lHelp – View help information online.
View videos
1. Tap Apps >Photos.
2. Tap a video thumbnail, then tap ► (play).
Tip
Videos have a ► (play) icon and photos don't.
www.insigniaproducts.com
51
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
EDIT PHOTOS
1. Tap Apps >Photos.
2. Tap the photo you want to edit, then .
3. Use the available options to edit your photo.
4. When finished, click Done. Your edited photo is automatically saved.
SHARE PHOTOS OR VIDEOS
1. Tap Apps >Photos.
2. Select the photo or video you want, then tap (share).
3. Tap the program you want to use to share the photo or video.
Note
If you shared a photo or video before, the program you used has an
easy-access icon next to the share button.
4. Follow the on-screen prompts to send your photo or video.
Note
You may need to install social media apps (such as Facebook
and Twitter) to share photos on those sites.
www.insigniaproducts.com
52
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Listen to music
Learn how to control your audio playback and create a playlist.
CONTROL PLAYBACK
1. Tap Apps >Play Music.
2. Tap (menu), then My Library to view your music.
3. Tap a category (Genres,Artists,Albums, or Songs), then select a song to
start playback.
4. While listening to a song, you can:
lTap to turn shuffle on or off.
lTap to cycle through repeat mode, which include:Repeating all
songs,Repeating current song, or Repeat is off.
lTap to pause and ► to resume playback.
lDrag the progress bar to the playback point you want.
Note
For more audio options, tap (options)next to a song title in the list.
USING PLAYLISTS
Create a playlist
1. Tap Apps >Play Music.
2. Find a song that you want to add, tap (options), then Add to playlist.
3. Follow the on-screen prompts to select an existing playlist or create new
playlist.
Play a playlist
1. Tap Apps >Play Music.
2. Tap (menu), then Playlists.
3. Tap a playlist, then tap ► (play).
Note:SeeControl playback (above) for more information.
Manage storage space
Learn how to keep your tablet running at peak efficiency by managing your
storage space.
USE A MICRO SD CARD
Install a microSD card
1. Insert the microSD card into the slot with the label facing the back of your
tablet. It should click into place.
www.insigniaproducts.com
53
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Note
If prompted to change the default write disk:
lTap Cancel to make no changes.
lTap OK to go to Storage settings then select where you want
your tablet to write files.
Access files on a microSD card
1. Tap Apps >File Manager >Home >SD card.
2. Navigate to the file you want to open, tap it, then select an app to open it (if
prompted).
Move files to or from a microSD card
1. Tap Apps > File Manager.
2. Navigate to the file, then touch and hold the file name to select it.
3. Tap to copy the file.
OR
To move the existing file to a new location:
lIf using the 8-inch tablet, tap (options), then Cut.
lIf using the 10-inch tablet, tap (cut).
4. Navigate to where you want to save the file, then touch (paste).
Remove a microSD card
1. Tap Apps >Settings >Storage >Unmount SD card >OK.
2. Push the microSD card in then release to remove it from the card slot.
VIEW STORAGE SPACE
lTap Apps >Settings >Storage.
www.insigniaproducts.com
54
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Note
lYou may not be able to remove pre-installed
apps.
lTap DISABLE to prevent an app from
running.
FREE UP STORAGE SPACE
If your tablet is low on storage space, try the following:
lClear your Internet browser's temporary files and browser history. See your
browser's online help for more information.
Note:If you use Google Chrome™, see Clear app cache and data (on
page55).
lMove files such as pictures, videos, or music to a microSD™ memory card or
a computer. See Use a Micro SD card (on page53).
lMove apps to a microSD memory card if they will run there.
RESET TO DEFAULT SETTINGS
Caution
Resetting to factory defaults deletes all personal data and settings. To restart
your tablet without removing your stored data or customized settings, see
Restart your tablet (on page16).
1. Connect your tablet to a power outlet.
2. Tap App >Settings >Backup &reset >Factory data reset >
Reset tablet.
3. Wait for your tablet to reset, then go through the initial setup again. See Turn
on your tablet for the first time (on page15) for more information.
Troubleshooting
What should I do if Icannot turn on my tablet?
lConnect the charger and check the battery level on the screen. Make sure
that the battery is fully charged. If the battery is too low, your tablet will not
turn on. Connect your tablet to the power adapter and fully charge the
battery.
Can I open Microsoft Office and PDF files on my tablet?
lYou can purchase and download third party applications to read these files.
What should I do if my tablet won't recognize the microSD™ card?
lMake sure that you have inserted a certified microSD card.
lMake sure that you have inserted a microSD card correctly and securely.
www.insigniaproducts.com
57
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
lWith the micoSD card inserted, turn off your tablet, then turn it back on.
lMake sure that you are attempting to view your files in the correct location on
your tablet. Go to a file management app, such as the Gallery app, to view
your files.
What should I do if Ican't access the web?
lCheck the wireless signal indicator in the status bar at the top of the screen.
If there is no signal, you are not connected.
lMake sure that Wi-Fi is turned on. See Connect to a Wi-Fi network (on
page36).
lMake sure that you select the right network and enter the correct password.
See Connect to a Wi-Fi network (on page36).
What should Ido if there is no sound coming from my tablet?
lIf listening through headphones, unplug and reconnect your headphones.
Make sure that the connector is pushed in all the way.
lIf listening through your tablet's speakers, unplug any devices connected to
the headphone jack.
lThe volume may be muted or set too low. Increase the volume setting. See
Adjust the volume (on page16).
lCheck the software volume in Settings. See Adjust system sounds (on
page31).
Why is the actual storage less than storage in the specification?
lYour tablet has the full amount of storage listed in the specification.
However, some of this space is used for system applications and data files.
What should Ido if the display freezes or does not respond?
lPress and hold the button for 10 seconds to turn off your tablet, then turn it
back on.
lUse a paper clip to press Reset on the back of your tablet.
Maintenance
lKeep your tablet dry.
lAvoid exposing your tablet to extreme hot or cold temperatures.
lAvoid placing your tablet close to lit cigarettes, open flames, or any heat
source.
lDo not drop, knock, or shake your tablet. Rough handling may break internal
circuit boards.
lKeep your tablet in a clean and dust-free place.
www.insigniaproducts.com
58
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Disclaimer:Best Buy does not recommend the use of any ammonia or alcohol-
based cleaners on the LCD screen or plastic casing. Some chemical cleaners
have been reported to damage the screen or display case. Best Buy will not be
liable for damage resulting from the use of any ammonia or alcohol-based
cleaners.
www.insigniaproducts.com
59
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Specifications
Specifications are subject to change without notice.
8"TABLET (NS-P16AT08)
Operating system Android 5.0 (Lollipop)
CPU Quad-Core
Display
8" diagonal panel (20.3 cm)
1280 × 800 IPS
Capacitive 5 Points touch panel
Wireless/Connectivity Wi-Fi 802.11 a/b/g/n
Bluetooth 4.0, GPS
Storage 16 GB internal memory
Expandable microSD slot (up to 32 GB)
Camera 0.3 MP front-facing (fixed focus)
2 MP rear-facing (auto focus)
Sensors G-Sensor
Audio Internal Stereo Speakers
MP3, AAC
Battery and power 4000mAh Lithium battery
Up to six hours video playback
Power supply 5V/2A
Video H.264, MPEG4
Input and output
microSD slot (up to 32 GB)
3.5 mm stereo headphone jack
Micro USB
Built-in stereo speaker
Dimensions (W×H×D) 8.5 × 5.5 × 0.4 in. (21.6 × 14.0 × 1.0 cm)
Weight .9 lbs (0.4 kg)
www.insigniaproducts.com
60
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
10.1" TABLET (NS-P16AT10)
Operating system Android 5.0 (Lollipop)
CPU Quad-Core
Display
10.1" diagonal panel (25.7 cm)
1280 × 800 IPS
Capacitive 10 points touch panel
Wireless/Connectivity Wi-Fi 802.11 a/b/g/n
Bluetooth 4.0, GPS
Storage 16 GB internal memory
Expandable microSD slot (up to 32 GB)
Camera 2 MP front-facing (fixed focus)
5 MP rear-facing (auto focus)
Sensors G-Sensor, Gyroscope, E-compass,
Ambient light sensor
Audio Internal stereo speakers
MP3, AAC
Battery and power 6000mAh Lithium battery
Up to eight hours video playback
Power supply 5V/2A
Video H.264, MPEG4
Input and output
microSD slot (up to 32 GB)
3.5 mm stereo headphone jack
Micro USB, Micro HDMI
Built-in stereo speakers
Dimensions 10.0 × 6.6 × 0.4 in. (25.4 × 16.7 × 1.0
cm)
Weight 1.2 lbs. (0.5 kg)
Customer support
For more help, see Troubleshooting (on page57).
To contact customer service, call 1-877-467-4289.
www.insigniaproducts.com
61
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Your tablet model number is: NS-P16AT08 (8" tablet) or NS-P16AT10 (10.1"
tablet)
Safety information
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water. Do not touch your device with wet hands.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not expose the device to direct sunlight.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
product.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this device during lightning storms or when unused for long periods
of time.
13. To reduce the risk of fire or electric shock, do not expose this device to rain,
moisture, dripping, or splashing.
14. Do not crush or puncture the product. Avoid exposing the device to high
external pressure. Do not operate the device in a very cold or very hot
temperature, such as in cold weather or in an un-air-conditioned motor
vehicle during intense heat.
15. Do not remove the cover or back to reduce the risk of electric shock. There
are no user-serviceable parts inside. Refer servicing to qualified personnel.
16. Do not place the device on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, resulting in possible damage or injury.
17. To prevent hearing damage, do not use the headphones at a high volume.
18. Never place heavy or sharp objects on the LCD panel or device.
19. Only use the AC adapter included with the device. Using any other adapter
will void your warranty.
Legal notices
Android, Google, Google Play, Gmail and other marks are trademarks of Google,
Inc.
www.insigniaproducts.com
62
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation.
FCC Part 15
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance with the FCC Rules could void the user’s authority to operate this
equipment.
Note:
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment.
RSS-Gen & RSS-210 Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
www.insigniaproducts.com
63
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
(i)the device for operation in the band 5150-5250MHZ is only for indoor use to
reduce the potential for harmful interference to co-channel mobile satellite
systems;
(i) l'appareil pour fonctionner dans la bande 5150-5250MHZ est uniquement pour
un usage intérieur afin de réduire les risques d'interférence nuisible aux systèmes
mobiles par satellite co-canal;
(ii)the maximum antenna gain permitted for devices in the band 5725-5825 MHz
shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-
point operation as appropriate;
(ii) le gain d'antenne maximal autorisé pour les dispositifs fonctionnant dans la
bande 5725-5825 MHz doivent respecter le pire limites spécifiées pour le point-à-
point et l'exploitation non point à point, le cas échéant;
(iii)User should also be advised that hight-power radars are allocated as primary
users(i.e. priority users) of the bands 5250-5350 MHz and that these radars could
cause interference and/or to LE-LAN device;
(iii) L'utilisateur doit également être informé que les radars hight-puissance sont
désignés comme utilisateurs principaux (à savoir les utilisateurs prioritaires) des
bandes 5250-5350 MHz et que ces radars pourraient cause des interférences et /
ou à l'appareil LE-LAN;
RSS-102 Statement
This equipment complies with Industry Canada radiation exposure limits set forth
for an uncontrolled environment.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada
limites établies pour un environnement non contrôlé.
Specific Absorption Rate (SAR) Certification Information
Your wireless mobile device is a radio transmitter and receiver. It is designed and
manufactured not to exceed the exposure limits for Radio Frequency (RF) energy
set by the Federal Communications Commission (FCC) of the U. S. Government.
www.insigniaproducts.com
64
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
These FCC RF exposure limits are derived from the recommendations of two
expert organizations: The National Council on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical and Electronics Engineers
(IEEE). In both cases, the recommendations were developed by scientific and
engineering experts drawn from industry, government, and academia after
extensive reviews of the scientific literature related to the biological effects of RF
energy.
The RF exposure limit set by the FCC for wireless mobile devices employs a unit
of measurement known as the Specific Absorption Rate (SAR). The SAR is a
measure of the rate of absorption of RF energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC requires wireless devices to comply
with a safety limit of 1.6 watts per kilogram (1.6 W/kg).
The FCC SAR limit incorporates a substantial margin of safety to give additional
protection to the public and to account for any variations in measurements.
SAR tests are conducted using standard operating positions accepted by the FCC
with the mobile device transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the mobile device while operating can be well below
the maximum reported value. This is because the mobile device is designed to
operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna, the
lower the power output of the mobile device.
Before a new model mobile device is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the SAR limit established by
the FCC. Tests for each model mobile device are performed in positions and
locations (e.g. near the body) as required by the FCC.
By typical operations, this mobile device has been tested and meets FCC SAR
guidelines.
Use of other accessories may not ensure compliance with FCC RF exposure
guidelines. The FCC has granted an Equipment Authorization for this mobile
device with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines.
SAR information on this and other model mobile devices can be accessed online
on the FCC’s website through http://transition.fcc.gov/oet/rfsafety/sar.html. To find
information that pertains to a particular model mobile device, this site uses the
mobile device FCC ID number, which is usually printed somewhere on the case of
the mobile device.
www.insigniaproducts.com
65
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
Once you have the FCC ID number for a particular mobile device, follow the
instructions on the website and it should provide values for typical or maximum
SAR for a particular mobile device. Additional SAR information can also be
obtained at http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-cellular-
telephones.
IFETEL Statement
La operación de este equipo está sujeta a las siguientes dos condiciones:
1. es posible que este equipo o dispositivo no cause interferencia perjudicial y
2. este equipo debe aceptar cualquier interferencia, incluyendo la que pueda
causar su propia operación no deseada.
One-Year Limited Warranty
Definitions:
The Distributor* of Insignia branded products warrants to you, the original
purchaser of this new Insignia-branded product (“Product”), that the Product shall
be free of defects in the original manufacturer of the material or workmanship for a
period of one (1) year from the date of your purchase of the Product (“Warranty
Period”).
For this warranty to apply, your Product must be purchased in the United States or
Canada from a Best Buy branded or Future Shop branded retail store or online at
www.bestbuy.com,www.bestbuy.ca, or www.futureshop.ca and is packaged with
this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the
Product. Your purchase date is printed on the receipt you received with the
Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or
workmanship of the Product is determined to be defective by an authorized
Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair
the Product with new or rebuilt parts; or (2) replace the Product at no charge with
new or rebuilt comparable products or parts. Products and parts replaced under
this warranty become the property of Insignia and are not returned to you. If
service of Products or parts are required after the Warranty Period expires, you
must pay all labor and parts charges. This warranty lasts as long as you own your
Insignia Product during the Warranty Period. Warranty coverage terminates if you
sell or otherwise transfer the Product.
www.insigniaproducts.com
66
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail store location,
please take your original receipt and the Product to any Best Buy store. Make sure
that you place the Product in its original packaging or packaging that provides the
same amount of protection as the original packaging. If you purchased the
Product from a Best Buy or Future Shop online web site (www.bestbuy.com,
www.bestbuy.ca, or www.futureshop.ca), mail your original receipt and the
Product to the address listed on the web site. Make sure that you put the Product
in its original packaging or packaging that provides the same amount of protection
as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY or Canada
call 1-866-BESTBUY. Call agents may diagnose and correct the issue over the
phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded
retail stores or websites to the original purchaser of the product in the county
where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
lCustomer instruction/education
lInstallation
lSet up adjustments
lCosmetic damage
lDamage due to weather, lightning, and other acts of God, such as power
surges
lAccidental damage
lMisuse
lAbuse
lNegligence
lCommercial purposes/use, including but not limited to use in a place of
business or in communal areas of a multiple dwelling condominium or
apartment complex, or otherwise used in a place of other than a private
home.
lModification of any part of the Product, including the antenna
lDisplay panel damaged by static (non-moving) images applied for lengthy
periods (burn-in).
lDamage due to incorrect operation or maintenance
lConnection to an incorrect voltage or power supply
www.insigniaproducts.com
67
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
lAttempted repair by any person not authorized by Insignia to service the
Product
lProducts sold “as is” or “with all faults”
lConsumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
lProducts where the factory applied serial number has been altered or
removed
lLoss or Theft of this product or any part of the product
lDisplay panels containing up to three (3) pixel failures (dots that are dark or
incorrectly illuminated) grouped in an area smaller than one tenth (1/10) of
the display size or up to five (5) pixel failures throughout the display. (Pixel
based displays may contain a limited number of pixels that may not function
normally.)
lFailures or Damage caused by any contact including but not limited to
liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR
EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL
EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTIES OF AND CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER
THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE
TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
©2015 Best Buy. All rights reserved.
Made in China
www.insigniaproducts.com
68
Insignia NS-P16AT08/NS-P16AT10 8"/10.1" Wi-Fi Android™ Tablet
1-877-467-4289 (U.S. and Canada)
01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
©2015 Best Buy. All rights reserved.
Made in China.
V1 ENGLISH
15-0246
