User Manual
10" Flex™ Tablet for Android™
NS-P10A8100
Before using your new product, please read these
instructions
to prevent any damage.
NS-P10A8100
www.insigniaproducts.com
2
Table of Contents
Welcome 5
Features 5
Package contents 5
Tablet overview 6
Home screen 9
Get started 10
Charge the battery 10
Turn on your tablet for the first time 11
Understand the basics 12
Turn your tablet on or off 12
Restart your tablet 13
Adjust the volume 13
Navigate with gestures 13
Navigate with on-screen function buttons 14
Use the
Recents
screen 15
Use the keyboard 15
Download apps 16
Capture and view a screenshot 17
View a
status
item or notification 18
Check for updates 20
Change basic settings 21
Customize the Home screen 21
Set and use the screen lock 23
Customize the lock screen 24
Set the date and time 25
Adjust the screen brightness 25
Adjust the power saving settings 26
Setting the screen font size 27
Adjust system sounds 27
Select your language 27
Connect to a computer 29
10" Flex™ Tablet for Android™
www.insigniaproducts.com
3
Windows 29
Transfer or download an e-book 29
Set up wireless connections 30
Connect to a
W
i-
F
i network 30
Add a
W
i-
F
i network 30
Check
network
status 32
Connect to a Bluetooth device 32
Use the Internet 33
View web pages 33
Search for text on a web page 34
Copy text on a web page 34
Check and clear history 34
Manage bookmarks 36
Manage downloads 37
Use Gmail™ 38
Set up a
Gmail
account 38
Manage
Gmail
accounts 38
View a Gmail 40
Create a Gmail 42
Create and manage contacts 43
Use the calendar 43
Work with photos and video 43
Use the camera 43
View
photos
and video 46
Edit photos 46
Share
photos
or videos 47
Listen to music 48
Control
playback 48
Using playlists 48
Manage storage space 48
NS-P10A8100
www.insigniaproducts.com
4
Use a Micro SD card 49
View storage space 50
Clear app cache and data 50
Uninstall
apps 51
Free up storage space 51
Reset to default settings 51
Troubleshooting 52
Maintenance 53
Specifications 54
Customer support 55
Safety information 55
Legal notices 56
One-Year Limited Warranty 59
10" Flex™ Tablet for Android™
www.insigniaproducts.com
5
Welcome
Thank you for purchasing an Insignia 10" Flex™ Tablet for Android™ (NS-
P10A8100). Your tablet is a state of the art Android design that will give you
reliable and trouble-free performance.
Features
Familiarize yourself with your tablet's features below.
Wi-Fi Connectivity
Connect to the Internet wherever you are with the latest Wi-Fi technology.
Touch Screen
The screen responds to your touch instantly.
Third-party Application Support
Install a large number of third-party applications on your tablet.
Built-in Cameras
Use the built-in front and rear cameras as a webcam or to record videos.
Built-in G-sensor
Rotate the tablet to automatically switch between landscape and portrait modes.
Entertainment
Enjoy music, movies, pictures, and e-books on a single device.
PACKAGE CONTENTS
l
10" Flex™ Tablet for Android™
l
Micro USB cable
l
Wall charger
l
Quick Setup
G
u
i
d
e
l
Important
I
n
f
o
r
m
a
t
i
on
10" Flex™ Tablet for Android™
www.insigniaproducts.com
7
Back
Item Description
Speakers Play audio from your tablet.
Power
Press briefly to lock or unlock the
screen.
Press and hold to turn your tablet on/off.
Press and hold for ten seconds to
restart.
Volume Press to increase or decrease the
volume.
Rear camera Take pictures or record video. See Use
the camera (on page 43).
NS-P10A8100
www.insigniaproducts.com
8
Side
Item Description
Micro USB port Connect the micro USB cable to charge
your tablet.
Microphone Speak into the microphone to capture
your voice.
Earphone jack Connect 3.5 mm headphones to listen
to audio.
microSD™ card
slot
Insert a microSD card to increase your
tablet's memory.
10" Flex™ Tablet for Android™
www.insigniaproducts.com
9
HOME SCREEN
See Navigate with gestures (on page 13) for information on using the touch
screen. See Navigate with on-screen function buttons (on page 14) for
information on navigating on your tablet.
Notifications
Swipe down from the top edge of the screen with one finger.
Voice Search
Text Search
Home screen
Favorites
Back
Recents
Home
NS-P10A8100
www.insigniaproducts.com
10
Status items
Swipe down from the top edge of the screen with two fingers.
OR
Open notifications, then swipe down again.
Get started
This section has resources to help you start using your tablet right away. You can
also check out Features (on page 5) to familiarize yourself with your new tablet.
For more information about using and customizing your tablet, see Understand
the basics (on page 12) and Change basic settings (on page 21).
CHARGE THE BATTERY
Charge your tablet fully (4.5 hours) before using it the first time. After the first time,
charge your battery when it is less than 15% full.
1. Insert the micro USB cable into your tablet's micro USB port.
2. Insert the other end into the wall charger, then connect it to a power outlet.
Note: It takes about 4.5 hours to fully charge your
t
able
t.
10" Flex™ Tablet for Android™
www.insigniaproducts.com
11
Conserve battery power
l
Turn on battery saver mode. See Adjust the power saving settings (on
page 26).
l
Turn off Wi-Fi when you aren't using it.
l
Lower the screen brightness. See Adjust the screen brightness (on
page 25).
l
Close apps that you aren't using. See Use the Recents screen (on
page 15).
l
If your tablet is inactive, your tablet sleeps with the screen off (depending on
the screen timeout setting. See Customize the lock screen (on page 24)).
Press to wake it up.
l
If you are using an animated wallpaper, change it to a static wallpaper.
Helpful tips
l
For the best battery performance, use your tablet often.
l
Make sure that you charge it at least once a month.
l
Use the wall charger that came with your tablet for charging.
l
You can use your tablet while it is being charged. However, to conserve
your tablet's battery life, it isn't recommended.
TURN ON YOUR TABLET FOR THE FIRST TIME
1. Press and hold the button on the side of your tablet until you see the
Welcome
screen.
2. Select your language, then follow the instructions on the screen to complete
setup.
Note: You can use your tablet without connecting to the Internet and signing
into a Google™ account, but you won't be able to use the Play Store or
receive software updates.
NS-P10A8100
www.insigniaproducts.com
12
Understand the basics
Learn the basics about customizing and navigating your tablet, plus other helpful
features.
TURN YOUR TABLET ON OR OFF
Turn on your tablet
l
Press and hold the button. Your tablet turns on.
Note
If you don't touch your tablet for a while (depending on the screen timeout
setting), it may sleep with the screen off. Press briefly to wake it up.
Turn off your tablet
1. Press and hold the button until the
Power off
screen opens.
2. Tap Power off. Your tablet turns off.
10" Flex™ Tablet for Android™
www.insigniaproducts.com
13
RESTART YOUR TABLET
l
Press and hold the power button for 10 seconds. Your stored data and
customized settings aren't affected.
Note
To reset your tablet back to factory settings, see Reset to default settings (on
page 51).
ADJUST THE VOLUME
Note
See Adjust system sounds (on page 27) for more information.
l
Press the volume + or – button to raise or lower the volume.
NAVIGATE WITH GESTURES
Gesture Action
Tap
Tap an app or another item with your finger to open or select
it.
Touch
& hold
Touch an item with your finger and do not release it until your
tablet responds.
Drag
Touch and hold an item with your finger, then move your
finger to the position where you want the item.
NS-P10A8100
www.insigniaproducts.com
14
Gesture Action
Swipe
Quickly slide your finger either vertically or horizontally across
the screen to scroll up and down or right and left.
Pinch
Pinch your fingers together or move them apart to zoom in
and out.
Rotate Turn your tablet sideways to switch between landscape and
portrait.
Tip: If the orientation does not change, swipe down from the
top of your screen with two fingers, then tap Landscape or
Portrait to turn off the rotation lock.
NAVIGATE WITH ON-SCREEN FUNCTION BUTTONS
Icon Tap to...
Google Voice Search™.
Return to the previous screen.
Return to the home screen.
Open the list of recently used and running applications. See Use the
Recents screen (on the facing page).
View all apps installed on your tablet. Swipe the screen to the left to
see more apps.
Open the options menu.
Close the keyboard.
10" Flex™ Tablet for Android™
www.insigniaproducts.com
15
Icon Tap to...
Open the side menu.
USE THE RECENTS SCREEN
The
Recents
screen lets you quickly switch to recently used and open apps. If you
have too many apps running, your tablet may run slower or shorten your battery
life. Close apps you are not using to improve your tablet's performance.
l
On the home screen, tap Recents. A list of the most recently used or
running apps appears.
l
To see more apps, swipe up or down.
l
To open an app, tap the app window.
l
To close an app, drag the app screen left, right, or tap x.
l
To close all apps, tap .
USE THE KEYBOARD
The keyboard automatically opens when you start a program or select an item that
needs text or numbers.
Icon Description
Switch between uppercase or lowercase letters.
?123 Switch between number/symbol or text mode.
Note: Tap ABC to open the standard keyboard.
NS-P10A8100
www.insigniaproducts.com
16
Icon Description
O
R
Change keyboard language. See Select your language (on
page 27) to enable languages.
Note: These icons are not always available.
Close the keyboard.
Tap to delete a character.
Tap and hold to delete all characters to the left of the cursor.
Open the emoji keyboard.
Note: This icon is not always available. Tap ABC to open the
standard keyboard.
Confirm that you are finished entering information.
Search for text you entered.
l
To insert a character, tap the character to the left of where you want it, then
use the keyboard to type.
l
To delete a character, touch to the right of it, then tap (delete).
l
When you don’t need the keyboard, press at the bottom of the screen to
close it.
l
To adjust keyboard sound settings, see Adjust system sounds (on
page 27).
DOWNLOAD APPS
Caution
To protect your tablet and personal data, only download apps from trusted
sources.
You must connect to the Internet to download apps. See Connect to a Wi-Fi
network (on page 30) for more information.
10" Flex™ Tablet for Android™
www.insigniaproducts.com
17
1. Tap Apps > Play Store.
2. Search for an app or browse the categories to find apps, then follow the on-
screen instructions to install.
Notes
l
If a third-party application does not work on your tablet, contact the app
developer for more information.
l
See Uninstall apps (on page 51) for information on permanently
deleting an app.
CAPTURE AND VIEW A SCREENSHOT
l
To capture a screenshot, press and hold the and Vol – buttons at the
same time.
l
To view the screenshot:
1. Tap Apps > Photos.
2. Under
Screenshots,
tap the thumbnail of the screenshot. See View
photos and video (on page 46) for more information on navigating
your photos.
NS-P10A8100
www.insigniaproducts.com
18
VIEW A STATUS ITEM OR NOTIFICATION
Status and notification information are located at the top of the screen.
l
Drag your finger down from the top of the screen to view notifications (such
as email, calendar, and time).
l
Drag two fingers down from the top of the screen to view status items (such
as Wi-Fi, Bluetooth, and battery information).
19
10" Flex™ Tablet for Android™
www.insigniaproducts.com
Change notification interruptions
•
Press a volume button on your tablet. A volume menu opens.
You
can
•
Drag the slider to adjust the notification volume.
•
Tap ,
the
n
drag the slider to adjust the media volume.
•
Tap ,
the
n
drag the
slider to adjust the alarm
volume.
NS-P10A8100
www.insigniaproducts.com
20
CHECK FOR UPDATES
Make sure that you have the most up-to-date software.
Update your tablet
Warning
Back up your personal data before updating your tablet. Updates may delete
your data.
1. Tap Apps > Settings > About tablet.
2. Tap System Update > Check update. If an update is available, your tablet
displays the update version information.
3. Follow the on-screen instructions to install.
Update your apps
1. Tap Apps > Play Store.
2. Tap (menu) in the upper-left corner of the search bar, then tap My apps.
3. Locate the app you want to update from the
ALL
tab.
4. Tap the app to open the app page, then tap UPDATE.
5. Tap CONTINUE or ACCEPT if you agree to the app permissions. Your app
is updated.
www.insigniaproducts.com
21
10" Flex™ Tablet for Android™
Change basic settings
Customize settings on your tablet to fit your personal taste.
CUSTOMIZE THE HOME SCREEN
Change the wallpaper
1. Touch and hold on the home screen until a menu appears.
2. Tap WALLPAPERS.
3. Tap the wallpaper you want to use. To select a photo you took, tap Pick
image.
4. Tap Set wallpaper.
Tip
Animated wallpapers use more battery. To conserve battery, use a
static wallpaper.
Add an item to the home scree
n
1. Tap Apps to show all apps.
2. Touch and hold the app you want to add until it moves to the home screen.
Tip
You can also add or remove items from the favorites tray.
Move a home screen item
1. Touch and hold the item you want to move until it's highlighted.
2. Drag the item to where you want it, then release your finger.
NS-P10A8100
www.insigniaproducts.com
22
Remove a home screen
i
tem
Note
Removing an item from the home screen doesn't delete the app. See
Uninstall apps (on page 51).
1. Touch and hold the item you want to remove until it is highlighted.
2. Drag the item over the X, then release your finger.
Create a folder
1. Touch and hold the app you want to move into a folder until it is highlighted.
2. Drag the app on top of another app until a white circle appears, then release
your finger. A folder is created.
www.insigniaproducts.com
23
10" Flex™ Tablet for
3. Tap the folder to open it, then tap Unnamed Folder to open the keyboard
and name the folder. Tap when finished.
4. To add more items, drag them into the folder.
Note
To remove apps from a folder, open the folder, touch and hold the app, then
drag it back to the home screen. The folder is deleted when only one app is
left inside.
SET AND USE THE SCREEN LOCK
Change your lock type
1. Tap Apps > Settings > Security > Screen lock.
2. Tap the screen lock type you want to use, then follow the on-screen
instructions.
www.insigniaproducts.com
24
NS-P10A8100
Unlock the screen
There are several ways to unlock your tablet, depending on which screen lock is
enabled. You may need to:
l
Swipe up on the screen.
l
Drag your finger to enter a pattern.
l
Enter a PIN or password.
Set the lock screen timeout
1. Tap Apps > Settings > Display.
2. Tap Sleep, then select how long before your inactive tablet sleeps.
CUSTOMIZE THE LOCK SCREEN
Add lock screen message
Tip
For information on changing your screen lock, see Set and use the
screen lock (on the previous page).
1. Tap Apps > Settings > Security > Lock screen message.
2. Type the text you want to display on the lock screen, then tap SAVE.
3. Press to put your tablet to sleep, then press again to wake it up.
T
he
lock screen opens and your text is displayed.
www.insigniaproducts.com
25
10" Flex™ Tablet for
Remove owner info
1. Tap Apps > Settings > Security > Lock screen message.
2. Delete all the text, then tap SAVE.
Turn on or off lock screen notifications
1. Tap Apps > Settings > Sound & notification.
2. Under
Notification,
tap When device is locked.
3. Tap Show all notification content to display notifications on your lock
screen.
OR
Tap Don't show notifications at all to hide notifications on your lock screen.
SET THE DATE AND TIME
l
Tap Apps > Settings > Date & time.
l
Automatically or manually set your date and time.
l
Select your time zone.
l
Choose your hour format (12-hour or 24-hour).
l
Choose your date format.
ADJUST THE SCREEN BRIGHTNESS
l
Drag your two fingers down from the top of the screen to view status items,
then drag the slider left or right.
www.insigniaproducts.com
26
NS-P10A8100
ADJUST THE POWER
SAVING
SETTINGS
To help improve battery life, battery saver reduces your device's performance and
limits vibration, location services, and most background data. Email, messaging,
and other apps that rely on syncing may not update unless you open them. To turn
on battery saver mode:
1. Tap Apps > Settings > Battery > Battery saver
2. Tap the slider to turn on Battery saver mode. The edges of your screen may
turn orange while battery saver mode is turned on.
Tip
Battery saver mode automatically turns off when your tablet is
charging.
3. Use the available options to change additional power settings, as needed.
Conserve battery power
l
Turn on battery saver mode. See Adjust the power saving settings
(above).
l
Turn off Wi-Fi when you aren't using it.
l
Lower the screen brightness. See Adjust the screen brightness (on the
previous page).
l
Close apps that you aren't using. See Use the Recents screen (on
page 15).
l
If your tablet is inactive, your tablet sleeps with the screen off (depending on
the screen timeout setting. See Customize the lock screen (on page 24)).
Press to wake it up.
l
If you are using an animated wallpaper, change it to a static wallpaper.
www.insigniaproducts.com
27
10" Flex™ Tablet for
SETTING
THE SCREEN FONT SIZE
1. Tap Apps > Settings > Display > Font size.
2. Select the font size you want.
ADJUST
SYSTEM
SOUNDS
Change your notification tones, system volume, and other sound settings.
Adjust media, alarm, and notification volume level
1. Tap Apps > Settings > Sound & notification.
2. Under
Sound,
use the sliders to adjust your media, alarm, and notification
volume.
Turn on or off keyboard or screen lock volume
1. Tap Apps > Settings > Sound & notification.
2. Under
Sound,
tap Other sounds.
3. Tap the sliders to turn on or off the screen lock, charging, and touch
feedback.
SELECT YOUR LANGUAGE
Change your system language or add an additional language to your keyboard.
Change the system language
1. Tap Apps > Settings > Language & input > Language.
2. Select the language you want from the list. Your system (including the
keyboard) language changes.
www.insigniaproducts.com
28
NS-P10A8100
Add a keyboard language
By default, your tablet uses the system language as its keyboard language. If you
want to add an additional language to your keyboard:
1. While the keyboard is open, touch and hold / (slash) or , (comma) until a
settings icon appears.
2. Tap Languages.
3. Tap the languages you want to use on your keyboard.
Note
If the languages are grayed out, tap Use system language to
enable them.
Switch keyboard language
Make sure that you have enabled additional languages on your keyboard (see
steps above).
l
Tap to toggle between keyboard languages. The keyboard language
appears in the space bar.
www.insigniaproducts.com
29
10" Flex™ Tablet for
Connect to a computer
For more information on viewing and transferring files, see your computer's
documentation.
WINDOWS
1. Connect the Micro USB cable from your tablet to your computer.
2. Open
Computer
or My
Computer,
then click your model number (NS-
P10A8100) icon to view or transfer files.
3. Open Notifications, then tap the USB connection entry. The Use USB
f
o
r
window open
s.
4. Tap File transfers.
5. Unplug the cable when you are finished.
Transfer or download an e-book
Note
Make sure that your e-books are in the PDF, EPUB, TXT, RB2, RTF, or PDB
format.
Transfer an e-book from your computer
1. Connect your tablet to your computer. See Connect to a computer (above).
2. Copy an e-book file from your computer to a folder on your tablet.
Download an e-book from the Play Store
1. Tap Apps > Play Store.
2. Tap Books to browse for books or tap to search for a specific book.
NS-P10A8100
www.insigniaproducts.com
30
Set up wireless connections
Learn how to set up wireless connections such as Wi-Fi and Bluetooth.
CONNECT
TO
A WI-FI NETWORK
1. Tap Apps > Settings > Wi-Fi.
2. Tap the slider to turn on Wi-Fi . Your tablet automatically scans for
available networks.
3. Tap a Wi-Fi network.
l
If the network is open, your tablet connects automatically.
l
If the Wi-Fi icon has a (lock), the network is secured. Enter the
password, then tap CONNECT.
A connection icon appears in the status bar when your tablet is connected.
ADD A WI-FI NETWORK
1. Tap Apps > Settings > Wi-Fi.
2. Tap the slider to turn on Wi-Fi .
3. Tap (options), then tap Add network.
10" Flex™ Tablet for
www.insigniaproducts.com
31
4. Enter the Network SSID (name), then select the type of security you want
from the drop-down menu. You can select:
l
None—No security.
l
WEP—Wired Equivalent Privacy. Note: A password is required.
l
WPA/WPA2 PSK—Wi-Fi Protected Access. Note: A password is
required.
l
802.1x EAP—802.1x Extensible Authentication Protocol.
Note
If you aren't sure which security type to select, see your network setup
documentation.
5. Tap CONNECT. Your new network appears in the list of available networks.
Note
See Connect to a Wi-Fi network (on the previous page) for connection
instructions.
NS-P10A8100
www.insigniaproducts.com
32
CHECK NETWORK STATUS
1. Tap > Settings > Wi-Fi.
2. Make sure that the Wi-Fi slider is turned On. A list of available networks
appears.
l
Secured networks are noted with a lock icon.
l
If you are connected to a network, "Connected" appears below the
network name.
l
Signal strength is noted with an icon to the left of the network name.
CONNECT
TO
A BLUETOOTH DEVICE
1. Tap > Settings > Bluetooth.
2. Tap the slider to turn on Bluetooth. Your tablet searches for devices.
3. Turn on Bluetooth on the device you want to pair to your tablet and make
sure that your device is visible to other Bluetooth devices. See the
documentation that came with your Bluetooth device for instructions.
4. Tap an available device to pair with from the list. Follow the on-screen
prompts. Some devices connect automatically, while others may require a
PIN.
10" Flex™ Tablet for
www.insigniaproducts.com
33
Use the Internet
Learn how to navigate the Internet and adjust browser settings with your tablet.
Note
These instructions are for Google Chrome™. If you
are using a different browser, see the browser's
online help.
VIEW WEB PAGES
Connect to a Wi-Fi network to browse the Internet. See Connect to a Wi-Fi
network (on page 30).
Notes
l
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
l
Rotate your tablet to landscape view for the best viewing experience.
Open a web browser
l
Tap Apps > Chrome.
Note: If you have installed a different browser, tap the corresponding icon
from Apps to use it.
Navigate a web page
l
Tap the address bar to enter a web address or search, then tap (enter).
l
Tap , then speak to search.
l
Drag your finger up, down, left, or right to scroll.
l
Pinch your fingers together or spread them apart to zoom in and out.
l
Tap a tab at the top to switch windows or open a new browser window.
l
Tap x on the tab to close a window.
l
Tap , to return to the previous page.
l
Tap , to view menu items.
NS-P10A8100
www.insigniaproducts.com
34
SEARCH FOR TEXT ON A WEB PAGE
Note
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
1. In your browser, tap (options), then tap Find in page.
2. Use the keyboard to type the text you want to find. As you type, matching
characters on the web page are highlighted.
3. Tap ▲ or ▼ to go to the previous or next matching item.
4. Tap x to close the search bar and keyboard.
COPY TEXT ON A WEB PAGE
1. In your browser, touch and hold the text until a blue ribbon covers the text.
2. Drag the blue selectors to the left or right to select text.
3. Tap COPY in the menu that appears.
4. Go to where you want to paste the text (such as an email), touch and hold
the area, then tap PASTE.
CHECK AND CLEAR HISTORY
Note
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
10" Flex™ Tablet for
www.insigniaproducts.com
35
l
In your browser, tap (options), then tap History.
You can:
l
Tap a website to open the page.
l
Tap to search for a website.
l
Tap x to remove a single website from your browsing history.
OR
Tap CLEAR BROWSING DATA... to clear all browsing history. Select
the kinds of data you want to delete, then tap CLEAR DATA.
NS-P10A8100
www.insigniaproducts.com
36
MANAGE BOOKMARKS
You can store an unlimited number of bookmarks.
Note
These instructions are for Google Chrome. If you are using a different
browser, see the browser's online help.
Save a bookmark
1. Go to the website that you want to bookmark.
2. Tap in the address bar.
3. Tap again to rename your bookmark or select a folder, then tap outside
the menu to save.
4. Name your bookmark, select the folder you want to save it in, then tap
outside the menu.
10" Flex™ Tablet for
www.insigniaproducts.com
37
Open a bookmark
l
If you saved the bookmark to a folder, tap (options), Bookmarks, then
select the website from the list.
MANAGE DOWNLOADS
View a download
1. Tap Apps > Downloads.
2. To open a download, tap the file name. If needed, select the program you
want to use to open the file.
Delete a download
1. Tap Apps > Downloads.
2. Touch and hold the file name until it is selected, then tap .
NS-P10A8100
www.insigniaproducts.com
38
Share a download
1. Tap Apps > Downloads.
2. Touch and hold the file name until it is selected, tap , then select how you
want to share the file.
3. Follow the on-screen prompts to share the file.
Use Gmail™
Use the Gmail app to add your email accounts from Google and other web-based
providers like Outlook and Yahoo®.
SET UP A GMAIL ACCOUNT
You may have set up a Gmail account when you set up your tablet.
1. Tap Apps > Gmail.
2. Follow the on-screen instructions to set up your account.
Note
To set up another Gmail account, see Manage Gmail accounts
(below).
MANAGE GMAIL ACCOUNTS
Add an additional Gmail account
1. Tap Apps > Gmail > Menu > Settings > Add account.
2. Follow the on-screen instructions to set up your account.
NS-P10A8100
www.insigniaproducts.com
40
Change Gmail account settings
1. Tap Apps > Gmail > Menu > Settings.
2. Tap your account name.
3. Change your account settings as needed.
Switch Gmail accounts
1. Tap Apps > Gmail > Menu
2. Tap ▼ (drop-down) next to your account name, then select a different
account from the list displayed.
VIEW A GMAIL
l
Tap Apps > Gmail.
Note: If you have more than one email account, the last account you used
opens. See Manage Gmail accounts (on page 38) for instructions on
switching between accounts.
l
Drag your finger up and down to scroll through your Gmails.
l
Tap a Gmail to open it.
10" Flex™ Tablet for
www.insigniaproducts.com
41
l
Tap (menu) in the upper-left corner to display folders or select a
different Gmail account.
l
Tap to search.
l
Touch and hold a Gmail to select it and display options such as
archive, delete, mark as read or unread, or move the email.
l
Touch and hold a Gmail to deselect it.
l
Tap to compose a new Gmail. See Create a Gmail (on the next
page) for more information.
NS-P10A8100
www.insigniaproducts.com
42
CREATE A
G
M
AI
L
1. Tap Apps > Gmail > (compose).
Note
To open a different account, tap in the upper-left corner, then select
a different account.
2. Enter the recipient's email address. As you enter the address, your tablet
displays your contacts that match the characters you've entered. You can tap
a contact or continue entering the address.
Note
To send the email to more than one person, separate the email
addresses with a comma.
3. Enter a subject in the subject field (optional).
4. Enter your message, then tap SEND when you are finished.
Note
Tap Save draft under options or (back) to save your email as a
draft. To access your drafts, tap in the upper-left corner, then tap
Drafts.
10" Flex™ Tablet for
www.insigniaproducts.com
43
Create and manage contacts
l
Tap Apps > Contacts. You can:
l
Tap to search for a contact.
l
Tap (in the lower, right corner) to add a new contact.
l
Tap a contact to view or edit its information.
Use the calendar
l
Tap Apps > Calendar.
l
Tap to add a new event.
l
Tap to change the calendar view.
l
Tap , then Settings to access calendar settings.
Work with photos and video
Learn how to take pictures and video with your tablet. Then, learn how to view and
edit them before sharing with your friends and family.
USE THE CAMERA
Note
See View photos and video (on page 46) for information on how to view your
pictures.
Take a picture
1. Tap Apps > Camera.
2. Swipe right, then tap Camera.
NS-P10A8100
www.insigniaproducts.com
44
3. Tap to adjust options, if needed.
4. Swipe up or down to zoom in or out.
5. Tap to take a photo.
Record a video
1. Tap Apps > Camera.
2. Swipe right, then tap Video.
3. Tap to adjust options, if needed.
4. Tap to start and stop recording, then tap ■ (stop) when finished.
10" Flex™ Tablet for
www.insigniaproducts.com
45
Change camera sett
ing
s
1. Tap Apps > Camera
.
2. Swipe right, then tap (settings). A settings menu opens.
3. Use the available options to change your settings. You can change your
settings such as:
l
Camera resolution and quality
l
Sound capture
l
Location
l
Fullsize preview
l
Face detection
l
Restore default settings
NS-P10A8100
www.insigniaproducts.com
46
VIEW PHOTOS AND VIDEO
View photos
l
Tap Apps >
Pho
t
o
s
.
l
Drag your finger up and down to browse your photos.
l
Tap a photo thumbnail to view in full screen.
Tip
Videos have a ► (play) icon and photos don't.
l
To zoom in or out, pinch your fingers together or apart.
l
To view more options, select a photo, then tap . Options may include:
l
Share
l
Edit
l
Information
l
Delete
View videos
1. Tap Apps > Video.
2. Tap a video thumbnail, then tap ► (play). You can also:
l
Tap or to skip the previous or next video.
l
Tap to pause the video.
l
Tap (More) to view more options.
EDIT PHOTOS
1. Tap Apps > Photos.
2. Tap the photo you want to edit, then tap .
10" Flex™ Tablet for
www.insigniaproducts.com
47
3. Use the available options to edit your photo.
4. When finished, tap SAVE.
SHARE PHOTOS OR VIDEOS
1. Tap Apps > Photos.
2. Select the photo or video you want, then tap (share).
3. Tap the program you want to use to share the photo or video.
Note
If you shared a photo or video before, the program you used has an
easy-access icon next to the share button.
4. Follow the on-screen prompts to send your photo or video.
Note
You may need to install social media apps (such as Facebook
and Twitter) to share photos on those sites.
NS-P10A8100
www.insigniaproducts.com
48
Listen to music
Learn how to control your audio playback and create a playlist.
CONTROL PLAYBACK
1. Tap Apps > Play Music.
2. Tap (menu), then tap Music library to view your music.
3. Tap a category (PLAYLISTS, STATIONS, ARTISTS, ALBUMS, SONGS, or
GENRES), select a song, then tap ► (play) to start playback (if needed)
.
4. While listening to a song, you can:
l
Tap to turn shuffle on or off.
l
Tap to cycle through repeat mode, which include: Repeating all
songs, Repeating current song, or Repeat is off.
l
Tap to pause and ► to resume playback.
l
Drag the progress bar to the playback point you want.
Note
For more audio options, tap (options) next to a song title in the list.
USING
PLAYLISTS
Create a playlist
1. Tap Apps > Play Music.
2. Find a song that you want to add, tap (options), then tap Add to playlist.
3. Follow the on-screen prompts to select an existing playlist or create new
playlist.
Play a playlist
1. Tap Apps > Play Music.
2. Tap (menu) > Music library > PLAYLISTS.
3. Tap a playlist, then tap ► (play).
Note: See Control playback (above) for more information.
Manage storage space
Learn how to keep your tablet running at peak efficiency by managing your
storage space.
10" Flex™ Tablet for
www.insigniaproducts.com
49
USE A MICRO SD CARD
Install a microSD card
l
Insert the microSD card into the slot with the label facing the front of your
tablet. It should click into place.
Note
If prompted to change the default write disk:
l
Tap Cancel to make no change
s.
l
Tap OK to go to
Storage settings
then select where you want
your tablet to write files.
Access files on a microSD car
d
1. Tap Apps > File Explorer > SD card.
Note
Your tablet may display your SD card's name instead of
"SD card."
2. Navigate to the file you want to open, tap it, then select an app to open it (if
prompted).
Move files to or from a microSD card
1. Tap Apps > File Explorer.
2. Navigate to the file, then touch and hold the file name to select it.
3. Tap to copy the file.
4. Navigate to where you want to save the file, touch and hold the screen until
a menu opens, then tap (paste).
Remove a microSD card
1. Tap Apps > Settings > Storage & USB.
2. Tap (eject) next to your SD card's name.
3. Push the microSD card in then release to remove it from the card slot.
10" Flex™ Tablet for
www.insigniaproducts.com
51
UNINSTALL APPS
1. Tap Apps, then locate the app you want to uninstall.
2. Touch and hold the app, then drag it to the (trash) icon on the left side of
the screen until the app turns red.
Note
You may not be able to remove pre-installed apps. Instead, tap DISABLE to
prevent an app from running.
FREE UP STORAGE SPACE
If your tablet is low on storage space, try the following:
l
Clear your Internet browser's temporary files and browser history. See your
browser's online help for more information.
Note: If you use Google Chrome™, see Clear app cache and data (on the
previous page).
l
Move files such as pictures, videos, or music to a microSD™ memory card or
a computer. See Use a Micro SD card (on page 49).
l
Move apps to a microSD memory card if they will run there.
RESET
TO
DEFAULT SETTINGS
Caution
Resetting to factory defaults deletes all personal data and settings. To restart
your tablet without removing your stored data or customized settings, see
Restart your tablet (on page 13).
1. Connect your tablet to a power outlet.
2. Tap App > Settings > Backup & reset > Factory data reset >
RESET TABLET.
NS-P10A8100
www.insigniaproducts.com
52
3. Wait for your tablet to reset, then go through the initial setup again. See Turn
on your tablet for the first time (on page 11) for more information.
Troubleshooting
What should I do if I cannot turn on my tablet?
l
Connect the charger to check the battery level on the screen. If the battery is
too low, your tablet will not turn on. Fully charge the battery.
Can I open Microsoft Office and PDF files on my tablet?
l
You can purchase and download third party applications to read these files.
What should I do if my tablet won't recognize the microSD™ card?
l
Make sure that you have inserted a microSD card correctly and securely.
l
With the microSD card inserted, turn off your tablet, then turn it back on.
l
Make sure that you are attempting to view your files in the correct location on
your tablet.
What should I do if I can't access the Internet?
l
Look for a wireless signal indicator ( ) in the status bar at the top of the
screen. If there is no icon, you are not connected.
l
Make sure that Wi-Fi is turned on. See Connect to a Wi-Fi network (on
page 30).
l
Make sure that you select the right network and enter the correct password.
See Connect to a Wi-Fi network (on page 30).
l
Turn your tablet off, then back on.
l
Reset your Wi-Fi router/modem.
What should I do if there is no sound coming from my tablet?
l
If listening through headphones, unplug and reconnect your headphones.
Make sure that the connector is pushed in all the way.
l
If listening through your tablet's speakers, unplug any devices connected to
the headphone jack.
l
The volume may be muted or set too low. Increase the volume setting.
l
Check your tablet's sound settings. See Adjust system sounds (on
page 27).
Why is the actual storage less than storage in the specification?
l
Your tablet has the full amount of storage listed in the specification.
However, some of this space is used for system applications and data files.
How do I reset my tablet to factory defaults?
Caution: Resetting your tablet to factory defaults will delete all personal apps and
data from your tablet.
10" Flex™ Tablet for
www.insigniaproducts.com
53
1. Tap Apps > Settings > Backup & reset.
2. Tap Factory data reset, then tap RESET TABLET.
How do I set a screen lock?
1. Tap Apps > Settings > Security > Screen lock.
2. Select a screen lock type, then follow the on-screen prompts to set it up.
What should I do if the display freezes or does not respond?
l
Press and hold the button for 10 seconds to turn off your tablet, then turn it
back on.
Maintenance
l
Keep your tablet dry.
l
Avoid exposing your tablet to extreme hot or cold temperatures.
l
Avoid placing your tablet close to lit cigarettes, open flames, or any heat
source.
l
Do not drop, knock, or shake your tablet. Rough handling may break internal
circuit boards.
l
Keep your tablet in a clean and dust-free place.
Disclaimer: Best Buy does not recommend the use of any ammonia or alcohol-
based cleaners on the LCD screen or plastic casing. Some chemical cleaners
have been reported to damage the screen or display case. Best Buy will not be
liable for damage resulting from the use of any ammonia or alcohol-based
cleaners.
NS-P10A8100
www.insigniaproducts.com
54
Specifications
Specifications are subject to change without notice.
Operating system Android 7.0 (Nougat)
CPU MTK Quad-Core
Display
10.1" diagonal panel (25.4 cm)
800 × 1280 IPS
Capacitive 5-Point Touch Panel
Wireless/Connectivity
802.11 a/b/g/n
Bluetooth 4.1
GPS
Storage 32GB Internal Memory
Camera 2 MP front-facing (fixed focus)
2 MP rear-facing (auto focus)
Sensors G-Sensor/Accelerometer
Audio Internal stereo speakers, MP3, AAC
Battery and power 6000mAh Lithium Ion
Up to six hours video playback
Power supply 5V/2A
Video H.264, MPEG4
Input and output
Micro SD Slot (up to 128GB)
3.5 mm Stereo Headphone Jack
Micro USB
Dimensions 9.9 × 6.7 × 0.4 in. (25.2 × 17.1 × 1.1 cm)
Weight 1.1 lbs. (0.5 kg)
10" Flex™ Tablet for
www.insigniaproducts.com
55
Customer support
For more help, see
Troubleshooting
(on page 52). To contact customer service,
call 1-877-467-4289.
Your tablet model number is: NS-P10A8100
Safety information
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water. Do not touch your device with wet hands.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not expose the device to direct sunlight.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
product.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this device during lightning storms or when unused for long periods
of time.
13. To reduce the risk of fire or electric shock, do not expose this device to rain,
moisture, dripping, or splashing.
14. Do not crush or puncture the product. Avoid exposing the device to high
external pressure. Do not operate the device in a very cold or very hot
temperature, such as in cold weather or in an un-air-conditioned motor
vehicle during intense heat.
15. Do not remove the cover or back to reduce the risk of electric shock. There
are no user-serviceable parts inside. Refer servicing to qualified personnel.
16. Do not place the device on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, resulting in possible damage or injury.
17. To prevent hearing damage, do not use the headphones at a high volume.
18. Never place heavy or sharp objects on the LCD panel or device.
19. Only use the AC adapter included with the device. Using any other adapter
will void your warranty.
NS-P10A8100
www.insigniaproducts.com
56
Legal notices
Android, Google, Google Play, Gmail, and other marks are trademarks of Google,
Inc.
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation.
FCC Part 15
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
l
Reorient or relocate the receiving antenna.
l
Increase the separation between the equipment and receiver.
l
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
l
Consult the dealer or an experienced radio/TV technician for help.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance with the FCC Rules could void the user’s authority to operate this
equipment.
Note:
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment.
RSS-Gen & RSS-210 Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
10" Flex™ Tablet for
www.insigniaproducts.com
57
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
RSS-102 Statement
This equipment complies with Industry Canada radiation exposure limits set forth
for an uncontrolled environment.
Within the 5.15 to 5.25 GHz band, UNII devices will be restricted to indoor operations to
reduce any potential for harmful interference to co-channel Mobile Satellite System
(MSS) operations.
This device complies with CAN ICES-3 (B)/NMB-3(B).
The device complies with RF specifications. Ensure that the
device accessories, such as a device case and device holster, are not composed of
metal components. Keep the device away from your body to meet the distance
requirement.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada
limites établies pour un environnement non contrôlé.
Specific Absorption Rate (SAR) Certification Information
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported to the FCC
for this device type complies with this limit.
IFETEL Statement
La operación de este equipo está sujeta a las siguientes dos condiciones:
1. es posible que este equipo o dispositivo no cause interferencia perjudicial y
2. este equipo debe aceptar cualquier interferencia, incluyendo la que pueda
causar su propia operación no deseada.
NS-P10A8100
www.insigniaproducts.com
58
One-Year Limited Warranty
Definitions:
The Distributor* of Insignia branded products warrants to you, the original
purchaser of this new Insignia-branded product (“Product”), that the Product shall
be free of defects in the original manufacturer of the material or workmanship for a
period of one (1) year from the date of your purchase of the Product (“Warranty
Period”).
For this warranty to apply, your Product must be purchased in the United States or
Canada from a Best Buy branded retail store or online at www.bestbuy.com or
www.bestbuy.ca and is packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the
Product. Your purchase date is printed on the receipt you received with the
Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or
workmanship of the Product is determined to be defective by an authorized
Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair
the Product with new or rebuilt parts; or (2) replace the Product at no charge with
new or rebuilt comparable products or parts. Products and parts replaced under
this warranty become the property of Insignia and are not returned to you. If
service of Products or parts are required after the Warranty Period expires, you
must pay all labor and parts charges. This warranty lasts as long as you own your
Insignia Product during the Warranty Period. Warranty coverage terminates if you
sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location, please take your
original receipt and the Product to any Best Buy store. Make sure that you place
the Product in its original packaging or packaging that provides the same amount
of protection as the original packaging. If you purchased the Product from a Best
Buy online web site (www.bestbuy.com or www.bestbuy.ca), mail your original
receipt and the Product to the address listed on the web site. Make sure that you
put the Product in its original packaging or packaging that provides the same
amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY or Canada
call 1-866-BESTBUY. Call agents may diagnose and correct the issue over the
phone.
NS-P10A8100
www.insigniaproducts.com
60
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded
retail stores or websites to the original purchaser of the product in the county
where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
l
Customer instruction/education
l
Installation
l
Set up adjustments
l
Cosmetic damage
l
Damage due to weather, lightning, and other acts of God, such as power
surges
l
Accidental damage
l
Misuse
l
Abuse
l
Negligence
l
Commercial purposes/use, including but not limited to use in a place of
business or in communal areas of a multiple dwelling condominium or
apartment complex, or otherwise used in a place of other than a private
home.
l
Modification of any part of the Product, including the antenna
l
Display panel damaged by static (non-moving) images applied for lengthy
periods (burn-in).
l
Damage due to incorrect operation or maintenance
l
Connection to an incorrect voltage or power supply
l
Attempted repair by any person not authorized by Insignia to service the
P
rodu
ct
l
Products sold “as is” or “with all faults”
l
Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
l
Products where the factory applied serial number has been altered or
removed
l
Loss or Theft of this product or any part of the product
l
Display panels containing up to three (3) pixel failures (dots that are dark or
incorrectly illuminated) grouped in an area smaller than one tenth (1/10) of
the display size or up to five (5) pixel failures throughout the display. (Pixel
based displays may contain a limited number of pixels that may not function
normally.)
10" Flex™ Tablet for
www.insigniaproducts.com
61
l
Failures or Damage caused by any contact including but not limited to
liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR
EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL
EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTIES OF AND CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER
THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE
TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
©2016 Best Buy. All rights reserved.
Made in China
