LigoWave DLBPROP5 Broadband Digital Transmission System User Manual
LigoWave LLC Broadband Digital Transmission System
LigoWave >
User manual
LigoDLB Propeller 5
LigoDLB Propeller 2
installation
PoE power
adapter
Power cord
Insert brancket
Package content Assembling Mounting Operating modes
Power cord is region dependent
LAN + PoE
Data In
Wall/pole mount
x2 plastic clamps
x4 screws and
plastic inserts
LAN + PoE
Reset
Power LED
LAN LED
RSSI LEDs
Wall mounting Pole mounting
PoE connection
CPE mode AP mode
15o60o
Azimuth beamwidth Azimuth beamwidth
