Powerline 4-Port

Network Adapter

Model: PLTS200

Easily network your home using existing

electrical outlets

The Powerline 4-port Network Adapter lets you easily create a network using the existing

electrical outlets in your home. Now you don’t have to drill holes in walls and climb

through the attic or cellar to install network cables—just use the wires that already run

through the building.

The Powerline 4-port Network Adapter connects computers, or any other wired Ethernet

device, using the HomePlug® 1.0 with Turbo network standard. It also works with older

HomePlug 1.0 devices. Adding devices to the network is as simple as plugging the

Powerline 4-port Adapter into an electrical outlet, and connecting up to four Ethernet-

equipped devices to the built-in Ethernet ports. Additional devices can be connected to

the same network using additional Powerline Adapters plugged into any electrical outlet

anywhere in the house.

Once your computers are connected to the network, they can share resources like printers

and storage space, and all kinds of files—music, digital pictures, and documents. With up

to 85Mbps data rates, you can play lag-free head-to-head network computer games, and

run applications like Voice over IP telephony. Plug your Internet connected router into

a Powerline 4-port Network Adapter and you’ll be able to get to the Internet from any

Powerline attached computer in the house.

The Linksys Powerline 4-port Network Adapter is the perfect solution for easy, “no new

wires”, home or office networking.

DATASHEET

Use your existing powerlines to

network your computers and other

devices

Share files, printers, storage, and

networked games throughout your

home—connect it to a router to share

your cable or DSL Internet connection

Built-in 4-port Ethernet switch

HomePlug 1.0 with Turbo technology

for data rates up to 85Mbps*, also

compatible with HomePlug 1.0

* Actual data throughput will vary,

depending on network traffic and

environmental conditions such as

building wiring type and routing.

56-bit encryption keeps your

data secure

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: sales@linksys.com

Web: www.linksys.com

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical Support

contacts, visit our worldwide website at

www.linksys.com

Check the product package and contents for specic features supported. Specications are subject to change without notice.

Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its aliates in the U.S. and

certain other countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks

or registered trademarks of their respective holders.

8072210NC-JL Model: PLTS200

Specifications

Model PLTS200

Standards HomePlug 1.0 with Turbo, IEEE 802.3, IEEE 802.3u

Ports Power, Ethernet 1-4

LEDs Power, Powerline, Ethernet 1-4

Modulations Supports QAM 256/64/16, DQPSK, DBPSK and ROBO

Modulation Schemes

Security Features 56-Bit DES Link Encryption

Security Key Bits 56-Bit Encryption

Environmental

Dimensions 5.83" x 1.38" x 4.06" (148 x 35 x 103 mm)

Weight 6.70 oz (190 g)

Power 100-240V AC, 50-60 Hz

Certication FCC, IC, CE, Recycle Logo

Operating Temp. 32 to 104°F (0 to 40°C)

Storage Temp. -4 to 140°F (-20 to 60°C)

Operating Humidity 10 to 80% Noncondensing

Storage Humidity 5 to 90% Noncondensing

Package Contents

Powerline 4-Port Network Adapter•

Powerline Utility and User Guide on CD-ROM•

Ethernet Network Cable•

Power Cord•

Stand•

Quick Installation Guide•

Minimum Requirements

PC or other device with Ethernet Network Adapter•

AC Power Outlet•

Another HomePlug® 1.0 or HomePlug Turbo enabled Device •

Powerline Utility Requires PC with CD-ROM Drive Running Windows XP, Vista, or Vista •

64-Bit with Latest Updates

Features

Works with HomePlug® 1.0 •

enabled devices

Enable data transferring •

through existing power line

85Mbps transfer rate at physical •

layer

56-bit DES encryption with key •

management

CSMA/CA scheme with •

automatic repeat request

(ARQ) for reliable delivery of

Ethernet packets via packet

encapsulation

Supports TCP/IP, compatible •

with standard routers and

networked devices

Windows-based utility for •

device management

Integrated Quality of Service •

(QoS) features: prioritized

random access, contention-free

access, and segment bursting

Built-in 4 Ethernet ports provide •

connection to up to four devices
