Linpa Technology LBS10 Wireless Speaker User Manual
Shenzhen Linpa Technology Co.,Ltd Wireless Speaker
User manual
LBS 10 Product Description
Connect to LBS10
Slide Power button to ON
Searching the Bluetooth Speaker named LBS10 when the blue led is
flashing.
connect LBS10 without password
Hand Free
Press Hand Free to answer coming call
Press Hand Free again to hang it up
AUX INPUT
It will change to AUX status automatically when you plug in 3.5mm audio
cable.
TF INPUT
It will change to TF status automatically when you plug in TF Card
Charging
Charges LBS10 via Micro USB Cable, Red LED will be flashing when
charging, and keep on after full charging.
Technical Features
Drive Units 2x45mm
Amplifier power 3 w
Frequency response 150Hz - 20kHz
Signal-to-noise ratio >80 dB
Battery type Li-ion
Frequency range 2.402-2.480GHz
Transmitter power 0-4dBm
of AUDIO
Transmitter modulation GFSK
Working time >5 hours @ 0.2W
Battery capacity 600mah
Battery charge time 2 hours
Dimensions (L x W x H) 155x47x42mm
Operation Instruction
FCC Warning Statement
FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation .
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
