Linpa Technology SAMSDLBTSPK Lamp speaker User Manual HSD306A CALENDAR RADIO
Shenzhen Linpa Technology Co.,Ltd Lamp speaker HSD306A CALENDAR RADIO
User Manual
Instruction Manual
Main Features and Technical Parameters
1. Max power for lamp: 3.5W
2. Max power for speaker output : 2.5W
3. Speaker: 4Ω*1
4. Bluetooth audio playback
5. Capacitive touch switches
6.Φ3.5mm audio input port
7. Frenquency response: 100Hz-20kHz
8. Light Source: light-emitting diode (LED)
9. Three mode light switch: natural—white—yellow
10. Power Supply: charge by DC5V/3A adapter
11. Charging indicator, status indicator
12. Bluetooth receiving distance:≧10M
Product Illustration
Buttons Function
No
Current
mode
Function
operating
Button
Operation
Indicator
1
Power off
Power on
Play/
pause
Hold down
Blue status
indicator
flashes
rapidly
2
Power on
Power off
Play/
pause
Hold down
Status
indicator off
3
Power on
Bluetooth
pairing
manually pair
Blue status
indicator
flashes
rapidly
4
Power on
Bluetooth
paired
successfully
Automatically
pair
Blue status
indicator
flashes
slowly
5
Play
mode
Volume up
+
Hold down
6
Play
mode
Volume
down
-
Hold down
7
Play
mode
Previous
song
-
Touch once
8
Play
mode
Next song
+
Touch once
9
Play
mode
pause/play/m
ute
Play/
pause
Touch once
10
Bluetooth
mode
AUX Line
in
Insert audio
cable
Blue status
indicator on
11
Bluetooth
mode
Disconnect
bluetooth
Play/
pause
Hold down for
2 seconds
12
Power on
Lamp
ON/OFF
Lamp
ON/OF
F
Touch once
13
Lamp on
Dimming
Lamp
ON/OF
F
Hold down
14
Lamp on
Light
mode switch
M
Touch once
Bluetooth playback
1. Connect DC5V/3A adapter to the product, power indicator on.
Hold down play/pause to turn on the speaker. The status indicator
will flash quickly and the speaker will release a prompt tone to
indicate it’s turned on.
2. Turn on Bluetooth on your phone/tablet and scan for Bluetooth
devices.
3. Upon device found (Hiting), click the device name to pair (if
your phone requests a pairing code, pleases enter 0000). After
successfully pairing, the speaker produces a connected tone and
the status indicator light will be flashing slowly indicating it’s
ready to play music wirelessly. Touch Play / Pause button to play
music.
4. If the pairing timeout or status indicator stops flashing, please
turn off the power to restart, then repeat steps 1-3.
5. After successfully pairing, hold down Play / Pause button for 2
seconds to disconnect the current Bluetooth connection, and the
status indicator will flash quickly and re-enter pairing state.
Touch Play/Pause again to connect the previous device, and
holding down would turn off the Bluetooth.
Audio input
The speaker will automatically switch to Audio Input mode
when inserting the audio cable, and the status indicator is on.
Please insert the other end of the audio cable into the audio port
of MP3, IPOD, cell phone or other audio devices, adjust the
device’s volume to achieve the best sound.
Lamp function
1. Connect DC5V/3A adapter to the product, power indicator on.
Touch lamp On/Off switch once to turn the light on and touch again
to turn it off. To adjust the brightness of the LED light, hold down the
lamp On/Off switch.
2. Click “M” to switch light mode: natural light—white light
—yellow light.
USB output
Connect DC5V/3A adapter to the product, USB output
voltage 5V current2A.
Cautions
1. Only power adapter of the same standard with the one included in
package content can be used to supply power for the lamp.
2. When the LED light is on, please keep your eyes away from the
lamp to avoid being hurt.
3. This lamp is for indoor use only.
4. Please keep this lamp away from rain, water, fire or other high
temperature environment.
5. Please do not bend the lamp pole, or it may be damaged.
6. Please make sure the output current is at least 2A when supply
power for the lamp with DC5V power adapter.
Troubleshooting
Failure Manifest
Solutions
Fail to connect
Move the bluetooth device closer to the speaker
Turn off & restart.
Make sure the device is with Bluetooth function.
Re-connect.
Make sure the speaker connects with one device
only.
Choose "Hiting" as audio output device when
connected with a computer.
Music intermittent in
Bluetooth playback
Move the bluetooth device closer to the speaker or
change the location of audio devices.
Lamp flashes while
lighting or music playing
Check if the power adapter meets basic standard.
Packing Accessories
1. Line in audio cable * 1. 2. Power adapter * 1.
3. Instruction manual * 1.
Warning Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly
approved by manufacturer could void your authority to operate this
equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
