Litra >
User manual
3000-6000K
THE WORLD’S FIRST
FULL SPECTRUM COMPACT LIGHT.™
Litra, LLC
pro
Intelligent Design
• 0-100% fully dimmable light
• Blended/smooth lux beam (No center hot spot)
• Battery life up to 10 hrs (low) 1 hr (high)
• Standard Micro-USB charge port
• Use cordless or with external power
• Intelligent thermal management
• OLED display
Ultra Rugged
• Waterproof to 27m / 90ft.
• 810G MIL SPEC
Multiple Mounting Options
• 2 x 1/4” 20 mounts on the bottom and side
• Fits seamlessly on standard cameras and tripods
• Endless mounting options
Best in Class LED Technology
• 1200 Lumen
• Adjustable Color Temperature from 3000 - 6000k
• Flicker free at all Sutter angles
SPECSHEET
Size
Weight
Color Temp.
Color Render Index
Lumen
70mm X 50mm X 30mm
2.75in x 2in x 1.2in
170 Grams / 6 oz.
3000 - 6000K
>95
1200lm
70°
>10 hr low
>45 min on high
Standard Micro-USB Charge Port
810G MIL SPEC
Shock/Drop/Thermal/Salt Spray
2 x 1/4 20 Side and Bottom
Beam Angle
Battery Life
Charging
Ruggedness
Mounting
Bluetooth App
• Single or multiple light control
• Factory or user defined presets
• Available on Apple and Android
• Factory Calibrated LEDs to +/- 100k accuracy
• Full Spectrum LEDs with no green spike and
enhanced red spectrum
• Aluminum body
pro
HANDLE
COLD SHOE
BALL MOUNT
ACCESSORIES
LITRA.COM
INFO@LITRA.COM
1125 RANCHO CARMEL DR. #500592
SAN DIEGO, CA 92150
888.466.1566
DIFFUSER
BULB
OPTIONAL ACCESSORIES.
pro
DOUBLE MOUNT
IN THE BOX.
DSLR
MOUNT
BARN DOOR SOFT BOX
TRIPLE MOUNT
FILTER SET
*Charge cord and carry bag also included
Set Up:
1. Download Litra App.
2. Power LitraPro on.
3. Connect LitraPro in App.
FUNCTION
pro
OLED &
Controls
+/-
Brightness
+/-
CCT Power USB
Brightness
Levels
Connectivity CCT Level
Battery Life
OLED &
Controls
Power
USB
Lens
USB
Lens
1/4 20
Mounts
For step-by-step instructions go to:
litra.com/pages/quickstart
FAQ:
1. What is the CCT / Light Color range for the LitraPro?
The LitraPro has a CCT range from 3000k to 6000k. The
manual and App will change the CCT in 100 k increments.
2. What is the max light output for the LitraPro?
The LitraPro has a max light output of 1200 lumen
3. How long will the LitraPro last on high?
The LitraPro will last for 45 mins on the highest setting
and over 10 hrs at 10% brightness. The LitraPro can also be
run on external power for longer run times.
4. Is the LitraPro waterproof?
Yes, the LitraPro is waterproof up to 90 ft / 30 m.
5. What is the CRI on the LitraPro?
The LitraPro has a CRI of up to 95 CRI.
For more FAQ’s visit litra.com/pages/faqs
Warranty:
Litra warrants LitraTorch™ against defects in material or
workmanship for a period of 1 year from the original date of
purchase of the product by the original end user (the
“Warranty Period”). Litra does not warrant, and is not
responsible for, any device made by anyone other than
See full warranty at litra.com/pages/warranty
Product Registration:
To register your product please go to
litra.com/pages/product-registration
MOREINFO
pro
MODEL: LP1200
INPUT: 5V DC, 2A
OUTPUT: 12W
WARNING
FCC Warning:
This device complies with part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harm-
ful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and
receiver.
— Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician
for help.
SAR Warning:
The equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
