ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835
35
www.acclock.com
Accredited Lock Supply
DL2800 TRILOGY ACCESS CONTROL SYSTEMS WITH AUDIT TRAIL - WEATHER RESISTANT
• Rugged clutch mechanism insures long life & durability
• 150 scheduled events, including 4 “quick schedules” for programming the 4 most common time
schedules in one step
• 200 user codes including: Master, Manager, Supervisor and Basic User. Also one-time entry
Service Code
• Weather resistant performance with operational temperature range of + 151°F to -20°F
(+66°C to -29°C)
• Times entry allowance from 5-15 seconds
• Greater security with “Temporary Keypad Lockout” after 3 unsuccessful code-entry attempts.
“Keep would-be intruders arbitrarily guessing codes out!”
• Audit Trail with Time/Date Stamp for a printable record of all electronic activity
• Real Time Clock allows logging of events to within 1 second of accuracy
• Relay may be programmed to energize when one or more selected events occur
• 4 Time-Out functions allow a user to enable other users or unlock the lock for some time
period without needing to return to the lock
• 1000 Event Log
• Easy to install. Retrots most cylindrical locksets and digital locks
• Battery operated; uses 5 AA batteries
• Available in standard key override and interchangeable core models accepting 6 or 7 pin cores
from Arrow, Best, Falcon or KSP. Other IC core preps available.
• Available in standard Trilogy leverset (straight) or with Regal (curved) lever.
Part No. Description Finish Retail
AKDL2800-US26D Digital Lever Handed Lockset w/KO Satin Chrome 1046.00
AKDL2800IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 1069.00
C
TRILOGY - STANDALONE ACCESS CONTROL SYSTEMS
TRILOGYTM DL2700 SERIES DIGITAL LOCKS • Clutch mechanism insures long life
and durability
• Self-contained, fully programmable 12
digit metal keypad
• Battery operated, uses 5 AA batteries
• Low power audible alert
• Visual and audible entry indicators
• UL Listed re rated
• Rekeyable and accepts cylinders key-
able to most key systems
• Key bypass
• Remote override
Backset: 2 3/4" standard. Comes
with 5 AA alkaline batteries.
The self-contained, battery powered trilogy provides valuable digital security features
for virtually the same cost as most mechanical digital locks. Trilogy allows up to (100)
different group or individual codes with easy keypad programming. Clutch mechanism
permits turning lever without retracting latch and reduces stress on Flex Drive® mo-
tor. Outside lever free turning in locked position. Entering access code, key bypass, or
remote bypass will allow lever to retract latch. Inside lever always free. Built in remote
release eliminates the need for electric strike.
UL Fire Rated, meets or exceedsANSI/BHMA Certication Requirements A156.2, Series
4000 Grade 1, FCC Certied, conforms to ADA requirements.
Regal Curved Handle available, extra charge.
Standard IC models accept 6 & 7 pin cylinders from Best, Falcon,
Arrow, KSP, Medeco Keymark & Kaba Peaks.
IC core models prepped for 6 & 7 pin Yale, Medeco, Sargent,
Corbin Russwin & Schlage* also available. Extra Charge.
AKS6061 Battery Pack for Most
Trilogies 47.00
NEW! LocDownTM Model!
DL2700 w/LocDownTM capability via wireless
key fob. Inside housing has a light bar that
indicates that the door is locked down.
WITH LEVER HANDLE (Regal handle available)
Part No. Description Finish Retail
AKDL2700-US26D Digital Lever Handed Lockset w/KO Satin Chrome 853.00
AKDL2700-US3 Digital Lever Handed Lockset w/KO Polished Brass 980.00
AKDL2700WP-26D Digital Lockset - Weatherproof Satin Chrome 959.00
AKDL2700IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 889.00
AKDL2700IC-US3 Digital Lever Lockset for Int.Core Polished Brass 998.00
AKDL2700WPIC-26D Digital Lockset - Weatherproof IC Satin Chrome 975.00
AKDL2700LD-US26D Digital Lockset w/LocDown Satin Chrome 900.00
AKDL2700LDIC-26D Digital Lockset w/LocDown IC Satin Chrome 930.00
Regal Curved
Handle
*Schlage IC requires Regal handle.
Regal Curved
Handle
*Schlage IC requires Regal handle.
Use Pro-Lok IN15-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN15-FP-S Flat Plate
Regal Curved Handle available, extra charge.
Standard IC models accept 6 & 7 pin cylinders from Best,
Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.
IC core models prepped for 6 & 7 pin Yale, Medeco,
Sargent, Corbin Russwin & Schlage* also available.
Extra Charge.
Use Pro-Lok IN15-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN15-FP-S Flat Plate
Go To Table of Contents
36
www.acclock.com
Accredited Lock Supply
C
T3 Stand Alone Access Systems push all the right buttons to get your
foot in the door with the best in reliable single-door access, now with
something extra - comprehensive logging of user entry by time and date,
plus access scheduling.
These rugged, self-contained, battery powered systems provide remarkably
sophisticated keyless access with the features and multiple security levels
that meet or surpass even the most discriminating consumers' needs.
DIGITAL ACCESS SYSTEM FEATURING:
• 300 User Codes: Master, Manager, Supervisor & Basic Users
• 4 Programming Levels
• 4 User Groups
• 3,4,5 or 6 Digit Codes
• 1 -Time Service Code
• Real Time Clock
• Time Zones
• 150 Scheduled Events (Lock/Unlock, Code Disable/Enable)
• 4 “Quick Schedules” of the most common routines built in.
• 100% Fingertip Programmable or PC Programmable with Intuitive-Use Alarm
Lock DL-WINDOWS Windows Software with built-in error check.
• Non-volatile Memory
• 1600 Event Log
• Passage Mode Enabled by Master’s and Manager’s Codes
• Optional Hand-Held AL-IR1 Infrared Printer may be used to Print the Event Log and
User Code List
• ADA-Compliant Leverset Clutch Design.
• UL-Listed Electrically-controlled single-point lock.
Part No. Description Finish Retail
AKDL3000-US26D Digital Lever Handed Lockset w/KO Satin Chrome 1270.00
AKDL3000 Digital Lever Handed Lockset w/KO 3,10B 1359.00
AKDL3000IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 1265.00
AKDL3000IC Digital Lever Lockset for Int. Core 3,10B 1337.00
AKAL-DTMIII Data Transfer Module 448.00
AKAL-IR1 Hand Held Infrared Printer 520.00
AKAL-PCI2-U Personal Computer Interface Cable-Serial/USB 237.00
AKMX1130 Serial to USB Adapter 118.00
Part No. Description Finish Retail
AKPDL3000-US26D Digital Lever Handed Lockset w/KO Satin Chrome 1782.00
AKPDL3000IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 1811.00
AKPDL3000 Digital Lever Lockset w/KO 3, 10B 1860.00
AKPDL3000IC Digital Lever Lockset for Int.Core 3, 10B 1882.00
AKALHID1326 Proximity Access Card 100/box 505.00
AKAL-IR1 Hand Held Infrared Printer 520.00
AKAL-PCI2 PC Interface Cable (w/DL-Windows) 129.00
Regal Curved Handle available, extra charge.
Standard IC models accept 6 & 7 pin cylinders from
Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba
Peaks.
IC core models prepped for 6 & 7 pin Yale, Medeco,
Sargent, Corbin Russwin & Schlage* also available.
Extra Charge.
*Schlage IC requires Regal handle.
Optional Accessories
With optional IR
printer
• Accepts most HID Proximity cards and keyfobs including 26 - 48 bit formats
• 2000 User codes; Master; manager; supervisor; basic users
• Users are individually programmed to use a card only, code only, or for the highest
security - both card and code
• Card data can be added to software via the lock, card reader module or PC
• Batch enroll feature allows many cards to be quicldy added to the software via
the lock without the use of a PC
• Weatherproof and operates from -200 F to 1510 F (-290 C to 660 C)
• Fingertip (keypad) or Windows PC-programmable
• Program data transferred to lock via AL-PCI (PC interface) or AL-DTM (data transfer module)
• Real time clock enables up to 500 scheduled events and holiday schedules
• Up to 40,000 event Audit Trail with printed time/date-stamped log of all electronic activity can be
extracted from the lock by using the AL-IRI (infrared printer), the AL-DTM (data transfer module)
or AL-PCI (PC interface)
• 5 AA batteries furnished; 60,000 cycles typical. Audible low battery alert
• ‘Quick Passage’ Mode enabled with an authorized user code and function code
(does not require lock to be in program mode)
• Available in four nishes (US 26D, 26, 5 & 3), plus special order nishes
(including Duronodic US10B)
• Comes with either a standard or Regal curved handle trim
TRILOGY PROX LOCK WITH AUDIT TRAIL
Use Pro-Lok IN15-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN15-FP-S Flat Plate
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835
37
www.acclock.com
Accredited Lock Supply
C
TRILOGY MORTISE LOCKS DL3500 SERIES
Similar in functionality to T3 DL3000 Series, but with:
• 300 User codes: Master, manager, supervisor & basic users
• Weatherproof - operates from -200F to 1510F (-290C to 660C)
• Fingerp or Windows PC-programmable
• Real me clock enables up to 500 scheduled events and holiday schedules
• 40,000 Event Audit Tra provides a printed me/date-stamped log of all electronic activity
• Long-life batteries and low-battery alert
• US versions: Choose either Classroom or Deadbolt versions and left or right handing (if reverse hand
is required, lock is eld reversible.)
• Available in standard Trilogy US leverset (straight) or with new Regal (curved) handle trim.
• Five nishes (US 26D, 26, 5, 3 & IOB, plus special order nishes)
Specify Handing - RH or LH
Part No. Description Finish Retail
AKDL3500CRR-US26D Straight Lever,Classroom Function Satin Chrome 1471.00
AKDL3500CRR Straight Lever, Classroom Function 3,10B 1543.00
AKDL3500DBR-US26D Straight Lever, Deadbolt Function Satin Chrome 1471.00
AKDL3500DBR Straight Lever, Deadbolt Function 3,10B 1543.00
TRILOGY ELECTRONIC DOUBLE SIDED DIGITAL LOCKS
• 2000 user access using PIN-code and/or HID Prox card/fob with multilevel access
hierarchy
• Keypad and/or computer programmable
• Direction-specic access assignable per user programmable access for each user for
one or both sides of door
• Up to 40,000 event directional audit trail with time/date
• 500 scheduled events including 4 "quick schedules"
• Real time clock allow logging of events to withing 1 second of accuracy
• Programmable relays energize when one or more selected events occur
• "Temporary Keypad Lockout" after 3 unsuccessful attempts to enter code/ID
• Weatherproof performance for indoor and outdoor applications, wide operating tem-
perature range of -310F for +1510F (-350C to +660C)
• Grade 1 BHMA Certied durability and rugged clutch mechanism
• Quick Passage Mode
• 5 AA battery operation; 60,000 cycles, typical
Part No. Description Finish Retail
AKDL5300-US26D Digital Lever Handed Lockset w/KO Satin Chrome 1814.00
AKDL5300IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 1819.00
AKPDL5300-US26D Digital Lever Lockset w/KO & PROX Satin Chrome 2163.00
AKPDL5300IC-US26D Digital Lever Lockset Int.Core/PROX Satin Chrome 2179.00
AKALHID1326 Proximity Access Card 100/box 505.00
AKAL-IR1 Hand Held Infrared Printer 520.00
AKAL-PCI2 PC Interface Cable (w/DL-Windows) 129.00 Part No. Description Finish Retail
AKDL5200-US26D Digital Lever Handed Lockset w/KO Satin Chrome 1442.00
AKDL5200IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 1464.00
Double Sided Version of the 2700
USB to RS-232 CABLE ADAPTER
This mini USB to RS-232 cable adds a high speed RS-
232 serial port conveniently via USB 2.0 or USB 1.1
port connection.
Cable length of 10" and 2 LED's for port monitoring.
AKMX1130
11800
Go To Table of Contents
38
www.acclock.com
Accredited Lock Supply
C
TRILOGY NARROW STILE ACCESS LOCKS
DL 1200 Series supports 100 users, ngertip/keypad programmable. (Includes 2 Lithium 3V batteries).
DL 1300 Series supports 2000 users and includes 40,000 event audit trail and 500 event schedule. Keypad
or PC programmable. (Includes 2 Lithium 3Vbatteries).
PDL 1300 Series supports 2000 PIN or Prox users and includes 40,000 event audit trail and 500 event
schedule. Keypad or PC programmable. (Includes 2 Lithium 3V batteries)
ALL MODELS FEATURE:
• Aluminum door retrot outside trim for Adams Rite® 1850, 1950,4710,4070,4730,4900 Series and MS1850S
and MS1950S Series latch locks.
• PIN code and PIN/Prox Models support 100 to 2000 users (see model info.)
• 40,000 event audit trail in 1300 Series models, provides door usage activity reports at wireless handheld printer,
laptop or PC.
• All-metal, vandal-resistant 12-button keypad supports 3-6 digit PIN codes, and multilevel user hierarchy
(master, manager, supervisor, basic users)
• Keypad or PC programmable (see model info). Quickly and easily add or delete users and enter “passage
mode”, service codes, group lock-out & group-enable
• HID Prox 10 cards, keyfobs and prox tags supported in PDL-1300 Series models featuring built in Prox reader.
(High security applications can require use of both PIN code plus Prox 10 for access.)
• Real time clock and PC programmable automatic lock/unlock scheduling for 500 events (1300 Series models).
• Wide weatherproof operating range from -31 to 151°F (-35 to 66C)
• Wireless standalone locks: Long-life, battery- operated; Includes audible and visual low battery alert.
Uses standard off-the-shelf batteries, or AKS6170 battery pack (preferred).
• Non-handed; fully eld-reversible .
• Key override; interchangeable cores supported (Corbin/Russwin, Yale, Schlage, Medeco) .
• Mortise Cylinder, 1-1/4" supplied. (Supports 1-1/8, 1-1/4 and 1-3/8")
• Compact styling 14-3/8"H x 1-5/8"D x 1-3/4"W
• Backsets 31/32",1-1/8" and 1-1/2" ; Stile thickness 1-3/4"
• Two attractive standard nishes US26D Satin Chrome, US10B Duronodic
Part No. Description Finish Retail
AKDL1200-26D1 Digital Lever Lockset w/KO Satin Chrome 652.00
AKDL1225-26D2 Digital Thumb Turn Lockset w/KO Satin Chrome 652.00
AKDL1250-26D2 Digital Knob Lockset w/KO Satin Chrome 652.00
AKDL1300-26D1 Digital Lever Lockset w/KO Satin Chrome 818.00
AKDL1350-26D2 Digital Knob Lockset w/KO Satin Chrome 818.00
AKPDL1300-26D1 Digital Lever Lockset w/KO & PROX Satin Chrome 1186.00
AKPDL1350-26D2 Digital Knob Lockset w/KO & PROX Satin Chrome 1186.00
AKALHID1326 Proximity Access Card 100/box 520.00
AKAL-IR1 Hand Held Infrared Printer 520.00
AKAL-PCI2 Serial PC Interface Cable (w/DL-Windows) 129.00
AKAL-PCI2-U Serial/USB Interface Cable (w/DL-Windows) 237.00
ACCESS KEYPADS: 12V/24V W/TRILOGY FEATURES
• 100% ngertip or PC programmable
• 2,000 user codes, master, manager, supervisor and basic
• Weatherproof, rugged all-metal 12-button keypad
• 2 high-current rated 10A relays for entry, alarm zone shunning or lock release by real-time schedule
• Timed egress input allows door open for 5, 10 or 15 seconds
• Ideal for use with 12V or 24V (AC or DC) electric door strikes, mag lock or Alarm Lock
Remote Release Mag Lock Kit
• Easiest installation in minutes: Wall mount or single gang box
• 40,000 event audit trail: query by PC or handheld printer or DTM module
• Real time clock with time-zone adjustments, enables 500 scheduled or holiday events
• Remote-release feature/request-to-exit input
• Independent tamper -reports attempts to vandalize or remove DK3000 via an alarm system
• Available in 5 nishes: US26D Satin Chrome, US10B Duronodic, US3 Brass, MS Metallic Silver,
and MB Metallic Bronze
DK3000
DK3000 PDK3000
All the features of the DK3000 plus:
• Accepts most HID proximity cards and keyfobs • Users are individually programmed to use a card only, code only, or for the highest security -both card and code
PDK3000
Part No. Finish Retail
AKDK3000-26D Satin Chrome 813.00
AKDK3000-3 Polished Brass 813.00
AKDK3000MS Metallic Silver 662.00
AKDK3000MB Metallic Bronze 662.00
AKPDK3000-26D Satin Chrome 1175.00
AKPDK3000-3 Polished Brass 1175.00
AKPDK3000MS Metallic Silver 1035.00
AKPDK3000MB Metallic Bronze 1035.00
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835
39
www.acclock.com
Accredited Lock Supply C
TRILOGY EXIT/ TRILOGY EXIT WITH PROX
TRILOGY EXIT
• Field-proven clutch Mechanism ensures long life and durability
• Fingertip and/or Windows Programmable
• 2000 User Codes: Master, manager, supervisor and users
• Real Time Clock for up to 40,000 Event Time/Date-Stamped Audit Trail
• Up to 500 Lock/Unlock Schedules (with Time Zone Support)
• Rugged 12-Button Weather-Resistant Metal Keypad
• Non-Handed; Fully Field Reversible
• Adaptable to most major manufacturers of standard RIM and IC RIM Cylinders
• Battery operated; uses 5 AA batteries
• Battery pack mounts to interior door. Located over or under panic bar (position
dependent upon exit device manufacturer).
TRILOGY EXIT WITH PROX
• Accepts most HID Proximity cards and keyfobs
• Users are individually programmed to use a card only, code only, or for the highest
security -both card and code
• 2000 User Codes: Master, manager, supervisor & users
• Real Time Clock for up to 40,000 Event Time/Date-Stamped Audit Trail
• Up to 500 Lock/Unlock Schedules (with Time Zone Support)
• Prox Card data can be added to software by uploading from lock, by using AL-PRE or
entering directly from computer using DL-Windows software.
• Field-proven clutch Mechanism ensures long life and durability
• Fingertip and/or Windows Programmable
• Rugged 12-Button Weather-Resistant Metal Keypad; Non-Handed; Fully Field Reversible
• Adaptable to most major manufacturers of standard RIM and IC RIM Cylinders
• Battery pack mounts to interior door. Located over or under panic bar (position dependent
upon exit device manufacturer). Battery operated; uses 5 AA batteries.
TRILOGY EXIT
Part No. Description Finish Retail
AKETDLS1G/26DV99 Trilogy Exit Trim, Von Duprin 99 Satin Chrome 1281.00
AKETDLS1G/26DY71 Trilogy Exit Trim, Yale 7100 Satin Chrome 1281.00
AKETDLS1G/26DS88 Trilogy Exit Trim, Sargent 8800 Satin Chrome 1281.00
AKETDLS1G/26DM99 Trilogy Exit Trim, Marks M9900 Satin Chrome 1281.00
TRILOGY EXIT WITH PROX
Part No. Description Finish Retail
AKETPDLS1G/26DV99 Trilogy Exit w/Prox, Von Duprin 99 Satin Chrome 1671.00
Models available for: Von Duprin 99 Yale 7100
Corbin ED5000 Precision 1100 & 1200
Dorma 9300 Cal Royal 9800
Arrow 3800 Marks M9900
Sargent 8800 Sargent 8888
Cylinder adapter kit required when ordering.
Trilogy Remote Release Kit - Retrot Wireless
Convenience to any Cylindrical Trilogy
• Add Remote Release convenience to any cylindrical Trilogy installation with
keyfob(s) or desk-mounted button
• Easy & Cost Effective
• Retrots Cylindrical Trilogy Locks dating all the way back to 2000 with a service-
able battery pack
• Buy components separately -or -the Keyfob & Receiver in the
For Networx Locks, too! Solely purchase either the keyfob or desk-mount release
button
AKRR-TRILOGYKIT: Remote release kit for all Trilogy Cylindrical models includes the
RR-1BUTTON for desk mount applications and RR-RECEIVER which is designed to
be installed inside the battery compartment next to the battery pack of any cylindrical
Trilogy lock. The RR- RECEIVER connects to the 2 white remote release wires inside
the battery compartment and to the black and red battery pack wires to power the
receiver. These kits will retro t to any existing cylindrical Trilogy manufactured
since 1994. 221.00
AKRR-RECEIVER: You will need to purchase separately either an RR-1BUTTON OR
4BKEYFOB to activate the receiver. 128.00
AKRR-1BUTTON: Remote release desk mounted button designed to be used with
any existing Networx lock enrolled with a simple keypad program. 92.00
AKRR-4BKEYFOB: Remote release 4 button keyfob designed to be used with any
existing Networx lock enrolled with a simple keypad program. 103.00
AKRR-MORTISEKIT: Remote release kit for all Trilogy Mortise Locks, includes the
RR-1BUTTON for desk mount applications and a RECEIVER mounted on a Lexan
battery cover. 242.00
AKRR-EXITTRIMKIT: Remote release kit for all Trilogy Exit Trim Locks, includes
the RR-1BUTTON for desk mount applications and a RECEIVER mounted on a
Lexan battery cover. 242.00
Discount Code 'E'
AK9ETBATCASE
Replacement Battery
48.00
Go To Table of Contents
40
www.acclock.com
Accredited Lock Supply
E
Trilogy Networx Lock Specications:
Weatherproof locks for indoor/outdoor use with wide operating temperature range (-31 to 151 degrees F). Industrial strength BHMA Grade 1 durability and vandal-
resistant all-metal keypad for PIN codes. PDL6100 version, also has built in HID prox reader. ADA-compliant leversets. Easy-to-install modied ANSI A115 Series door
prep; easily/neatly retrot standard cylindrical knobsets and mechanical standalone locks, in under an hour. Non-handed. 3 hour UL re-rated deadlatch.
Supports 1-5/8 to 1-7/8” door thickness; 2-3/4” backset (2-3/8” available.) Manual key override standard; most IC cores also supported on interchangeable core models.
Wide choice of seven architectural nishes and IC core preps (6-7 pin).
Ordering Information:
PDL6100 Cylindrical Trilogy Networx™ PIN/Prox. Wireless Access
Control Lock with built in HID proximity ID card reader, full-metal digital
keypad, integral bi-directional radio, 4-C cell battery-operated (batteries
supplied), serial number ID card, standard format SC1 keyway for manual
key override, 4-7/8” ASA Strike (included).
DL6100 Cylindrical Trilogy® Networx PIN-Code Wireless Access Control
Lock, as above, with full-metal digital keypad only.
PDL6500 Mortise version Networx PIN/Prox. lock, similar to 6100 Series
above.
DL6500 Morise version Networx PIN-code only lock, similar to 6100
Series above.
DL-WINDOWS Free Alarm Lock Trilogy Microsoft Windows-based
software application, v4.0.1 or higher, supports Trilogy Networx
and Trilogy standalone locks, with single database. No-charge,
downloadable online at www.alarmlock.com
AL-IM80211 Hardwire/Wireless Gateway Interface Module, with integral
bi-directional radio, interfaces Networx locks with PC network with
hardwired Ethernet and wireless 802.11. Powered with Class 2, 6VAC
transformer (supplied). Supports up to 63 Networx Locks. Two antennas.
Ceiling or wall mountable.
AL-IME Hardwire Gateway Interface Module, supports up to 63 Networx
Locks, similar to above, but using hardwired connection to the network
via RJ45 Ethernet cable. One antenna. Powered with Class 2, 6VAC
transformer (supplied). Ceiling or wall mountable.
AL-IMEPOEP Hardwire Gateway Interface Module + POE, supports up
to 63 Networx Locks, as above, but using hardwired Ethernet and Power
Over Ethernet (P.O.E.), plus hardwire gateway interface capability. Connects
directly to a network via Ethernet cable. One antenna. Ceiling or wall mountable.
Part No. Description Finish Retail
AKDL6100-US26D Digital Lever Lockset Satin Chrome 1452.00
AKDL6100IC-US26D Digital Lever Lockset for Int.Core Satin Chrome 1472.00
AKPDL6100-US26D Prox Digital Lever Lockset Satin Chrome 1864.00
AKPDL6100IC-US26D Prox Digital Lever Lockset for Int.Core Satin Chrome 1879.00
AKDL6500-US26D* Mortise Digital Lever Lockset Satin Chrome 1586.00
AKPDL6500-US26D* Prox Mortise Digital Lever Lockset Satin Chrome 1951.00
AKAL-IME Ethernet Connected Gateway w/AC Adapter 510.00
AKAL-IM80211 Wi-Fi Gateway to Connect to 802.11 network 710.00
AKAL-IMEPOEP Power Over Ethernet,plus hardware gateway 610.00
AKAL-IME-USB USB Gateway 300.00
AKAL-NSG Networx Signal Generator 240.00
AKAL-NSM Networx Signal Meter 296.00
*Specify RH or LH
Part No. Description Finish Retail
AKETDLN-US26D Digital Lever Exit Trim Satin Chrome 1426.00
AKETPDN-US26D Prox Digital Lever Exit Trim Satin Chrome 1766.00
Compatible Panic Devices:
V99 Von Duprin 99
C50 Corbin ED5000
Y71 Yale 7100
D93 Dorma 9300
A38 Arrow 3800
S88 Old Style Sargent 8800
NS8 New Style Sargent 8888
P11 Precision 1100
CR8 Cal Royal 9800
Cylinder Adapter Kits for Exit Trim
AKET-AL Alarm Lock standard (SC1) 57.00
AKET-AR Arrow Standard Rim Cylinder 57.00
AKET-AS ASSA Standard Rim Cylinder 57.00
AKET-C Corbin Standard Rim Cylinder 57.00
AKET-M Medeco Standard Rim Cylinder 57.00
AKET-R Sargent Standard Rim Cylinder 57.00
AKET-S Schlage Standard Rim Cylinder 57.00
AKET-Y Yale Standard Rim Cylinder 57.00
AKET-ARIC Arrow IC 6/7 Pin Rim Cylinder 79.00
AKET-BIC Best IC 6/7 Pin Rim Cylinder 79.00
AKET-CIC Corbin IC Rim Cylinder 79.00
AKET-MIC Medeco IC 6/7 Pin Rim Cylinder 79.00
AKET-RIC Sargent IC Rim Cylinder 79.00
AKET-SIC Schlage IC Rim Cylinder 79.00
AKET-YIC Yale IC 6 Pin Rim Cylinder 79.00
These Are Adapter KIts, They Do Not Include Cylinders
Cylindrical
and
Mortise Locks
Exit Trim
Locks
AKS6196
Replacement Battery
Pack
47.00
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835
41
www.acclock.com
Accredited Lock Supply
UL PANIC DEVICE WITH DEADLOCK
SAFEGARD MODEL 700 x 28
AK700 x 28
55600
Solid deadbolt and deadlatch bar and channel
design for long lasting protection. Full door
coverage for 36" door (48" length available). Can
be shortened for narrow doors. Depressing bar
retracts deadbolt and deadlatch while sounding
95 dB alarm. Bypass and alarm reset by key.
Specify single or double doors. Optional alarm shutdown after two minutes if de-
sired. Low battery warning beep. Includes (9) volt battery. Bar dogging. Requires
rim cylinder (not included). Accepts outside rim cylinder and model 707 pull.
Finish: metallic silver. (Duranodic available).
AK710-US28 Rearming 595.00
AK715-US28 15 Second Exit Delay 1046.00
Meets NFPA 101 Life Safety Requirement
Includes: armored door cable, transformer and egress interface.
Dimensions: 4 1/2" x 10" x 3"
Overall width to end of clapper: 18"
Weight: 8 lbs.
MULTIGUARD EXIT ALARM
MODEL 250 X 28 (WITHOUT CYLINDER) AK250 x 28
46000
OUTSIDE ACCESS DOOR PULL
Allows outside access for alarm lock panic devices.
After deadbolt is retracted by outside key, a slight pull
releases deadlatch and opens door.
Dimensions:8" x 1 1/2" Note: Not for use with Model 11
A. Finish: Metallic Silver (Duranodic available)
Requires rim cylinder (not included).
AK707MS
13300
EMERGENCY EXIT ALARM DEADBOLT LOCK
SENTRYGARD MODEL 11A
AK11A
58000
The best features of a panic device; plus a deadbolt, plus a warning alarm. Provides
full time locking of emergency exit doors while complying with standard safety,
re and building department codes. For maximum day and night security and a
powerful deterrent against pilferage-from within or without. Always panic proof,
with instant automatic exit in case of emergency.
Supplied without cylinders. Locks will accommodate all standard rim cylinders.
May be operated from outside the door by mounting an extra cylinder.
EXIT ALARMS • BATTERY ELIMINATOR
PULL HANDLE • DOOR HOLDER
AC POWER SUPPLY
Provides constant power supply with battery
backup for Models 11A, PG10, PG20, 80, 250, 260,
700, 710.
Built-in circuit breaker with push-button
reset eliminates fuse replacement. Includes
a camlock cylinder and six ft. of armored
cable. Plug-in installation.
117 volt AC to 6 or 9 volt DC.
Maximum protection from unauthorized use with easy,
instant emergency exit. Specify single or double doors.
Depressing paddle retracts deadbolt and deadlatch while sounding 95dB alarm.
Bypass and alarm reset by key. Low battery warning beep. Optional alarm shutdown
after two minutes if desired. Includes (9) volt battery. Requires rim cylinder (not
included). Accepts outside rim cylinder and model 707 pull.
Finish: metallic silver (Duranodic available)
AK260 x 28 Rearming 477.00
C
AKPP100
26500
DOUBLE DOOR HOLDER
Secures the inactive door to the door frame while
the active door is closed. Releasing the active door
automatically allows both doors to swing freely.
Reversible; right or left hand doors. Cast aluminum.
Dimensions: 8 1/2"(L) x 3" (W) x 2 1/2" (H) AK44
12500
CABLE ENERGY SWITCH
Use with electried locks, this equipment
provides a unique way of bringing electrical
current from the lock side of the door frame
to the door. Power ows only when the door
is closed. Stainless Steel trim
AK261 7200
ARMORED DOOR LOOP
For Use With Electric Locks
An easy way to bring electric current from the hinge
side of a door frame to the door. 18" exible armored
cable. End brackets are deep drawn anodized aluminum
to conceal wire connections. AK271
5600
AK250WP x 28
52200
AK700WP x 28
63400
AK707MB
13300
Go To Table of Contents
42
www.acclock.com
Accredited Lock Supply
BATTERY PACK
For PG-10 & LL1 & 11A Exit Door Alarm
AKBP6
3700
EXIT DOOR ALARM
PILFERGARD MODEL PG21
A modern, high-tech annunciator that ts a variety of
doors and motifs because of its sleek prole design. Even
narrow stile doors easily accept the PG20.
Multi-purpose, easy-to-install, with selectable options
for an unprecedented range of applications: magnetic
contacts, automatic shutoff or continuous operation,
immediate or 15-second delayed alarm sounding.
Solid-state circuitry. Piercing 85dB alarm.
Packed with hardware mounting kit, template and warning
signs. Less mortise cylinder and key. Rim cylinder for
outside key control not included.
Slim-line, metallic-silver nish.Dim: 9" x 2 2/3" 2 1/2"
AKPG21MS Silver 289.00
AKPG21MB Bronze 289.00
AKPG21MSS w/yellow strobe 355.00
AK103 (Fail unlocked)
349.00
AK103-12VDC
(Fail unlocked) 411.00
AK104RA
(Fail locked) 416.00
EXIT DOOR ALARM
PILFERGARD MODEL PG-10
The original and industry-standard “anti-pilferage”
exit door alarm for over 15 years. Budget-priced
yet extremely effective against unauthorized use of
emergency doors by both customers and employees.
Doors can be safely maintained and unlocked as
required by building and safety codes. Used by
factories, chain stores, warehouses.
Less mortise, cylinder and key.
Dimensions: 8 1/2" x 4 1/4" x 3 3/8"
Weight: 3 lbs. 14 oz. (with battery)
Finish: handsome gray aluminum
AKPG10 289.00
AKLL1 same w/strobe light 300.00
ELECTRONIC LOCKS DOOR KEEPER SWITCHES
A compact unit designed for narrow stile doors.
Comes complete with keepers for easy installation
on all types of doors and windows - single, pairs,
double acting or overhead.
When the lock is aligned with the keeper, the bolt
projects into the keeper and locks the door. The
bolt is retracted and the door unlocked by either a
remote switch, a key switch, time programmer or
other electrical contract which interrupts the power.
Ideally suited for laundromats, lobby doors of public
buildings and other unattended areas.
Dimensions: 1 3/4" x 6 3/4" (including keeper)
Bolt diameter is 5/8" and projects 5/8"
MODEL 103 FAIL SAFE WITH ALL KEEPERS
C
EXIT DOOR ALARM PG-30
Top-of-the-line keypad-controlled nar-
row stile door alarm, simmilar to the
PG21E, but also featuring the following
advanced features:
• Digital codes for Master,
Management and Passage
(used for Auto - Arming)
• 3 security levels for:
a. High Security
b. Unattended Operations
c. Flexible control for delivery
doors, etc.
• Audible low battery warning
• 3 programmable 95db siren styles:
sweep, pulsed and steady
• Logo key is dual function test
button
AKPG30MB Metallic Bronze 344.00
AKPG30MS Metallic Silver 344.00
AKPG30KPD Keypad for External 199.00
Control of PG30
CYLINDER FINGER PULL 711
An inexpensive door pull for use when outside key
only access is required. Less cylinder
AK711-28
Aluminum Finish
3200
OUTSIDE EMERGENCY PULL 22
To permit entrance from exterior roof or when outside
key only access is required. For use with clapper
design only.
AK22
9200
Go To Table of Contents
