84
www.acclock.com
Accredited Lock Supply
B
CROSS REFERENCE OF FINISH IDENTIFICATION NUMBERS
Finish Description US No. Baldwin BHMA No.
The Lifetime FinishTM from Baldwin Polished Brass 003
Polished Brass (Highly polished brass and lacquered) 3 030 605
Polished Brass, (No Lacquer, Highly polished brass) 3NL 031
Vintage Brass 033
Lacquered Vintag Brass 034
Antique Brass 037
Aged Brass 038
Satin Brass (Satin polished and lacquered) 4 040 606
Satin Brass & Black (Oxidized relieved and lacquered) 5 050 609
Lifetime (PVD) Polished Nickel 055
Lifetime (PVD) Satin Nickel 056
Satin Brass & Brown(Oxidized, relieved and lacquered) 6 060 608
Oil Rubbed Bronze (Dull slightly oxidized, oil rubbed) 10B 102 613
Venetian Bronze (Relieved and matte lacquered) 112
Satin Nickel Plated (Satin polished brass, nickel plated) 15 150 619
Antique Nickel, Dull (Nickel plated brass, oxidized, relieved & lacquered) 15A 151 620
Satin Black (Black lacquer over sanded brass) 19 190 622
Polished Chromium (Highly polished, plated on brass) 26 260 625
Satin Chromium (Satin polished, plated on brass) 26D 264 626
Bright Stainless Steel (Highly polished) 32 320 629
Satin Stainless Steel (Satin polished) 32D 324 630
Distressed Oil Rubbed Bronze 402
Distressed Venetian Bronze 412
Rustic Bronze 432
Distressed Antique Nickel (matte lacquer) 452
Accredited Lock
sells the complete line of
Baldwin Hardware.
Call our sales representatives
if you need items not featured
on these pages.
Over
8,500
Items in Stock
including:
Hinges
Kick Plates
Letter Box Plates
Push/Pull Plates
• Lighting Products
Hardware NOT Available Distressed Includes:
All Mortise Locks, Cylinders, Latches & Strikes
Certain Levers & Handleset Trim
NOW STOCKING - THE RESERVETM LINE
The Reserve portfolio is for people who want more. They’re looking for more ways to express
themselves with the distinctive look of Baldwin and find value in a company with more years
of experience and a bona fide commitment to greater quality. Far beyond just a lock in a box,
Reserve opens the door to a customizable world flowing with inspiration. And it’s all ready
to go whenever inspiration strikes because it’s ready to ship in just 5-7 days. Reserve is the
best of both worlds: accessibility and artful appeal. Make a lasting impression with Reserve.
Chesapeake SeattleElizabeth
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 85
www.acclock.com
Accredited Lock Supply B
Tremont
INSIDE ESCUTCHEON: No. 6796
STOCK FINISHES: 003-060-260
OUTSIDE TRIM ONLY: No. 6605
KNOB: No. 5066
BA6542-003 Polished Brass-Lifetime Finish 870.00
BA6542-060 Satin Brass and Brown 795.00
BA6542-150 Satin Nickel 795.00
BA6542-151 Antique Nickel, Dull 795.00
BA6542-260 Polished Chromium 795.00
OUTSIDE TRIM ONLY: No. 6624 INSIDE ESCUTCHEON: No. 6790
KNOB: No. 5108 STOCK FINISHES: 003-150-151
Kensington
HANDLESET TRIM (FORGED BRASS)
Sets include outside trim and inside escutcheons only. Mortise lock and cylinder sold separately.
Hamilton
Inside
INSIDE ESCUTCHEON: No. 6791
STOCK FINISHES: 003-060-102
Outside
OUTSIDE TRIM ONLY: No. 6622
KNOB: No. 152
Springfield
BA6573-003 Polished Brass-Lifetime Finish 570.00
BA6573-060 Satin Brass and Brown 495.00
BA6573-150 Satin Nickel Plated 495.00
BA6573-102 Oil Rubbed Bronze 495.00
OUTSIDE TRIM ONLY: No. 6628 INSIDE ESCUTCHEON: No. 6798
KNOB: No. 5025 STOCK FINISHES: 003-050-060-102-150
BA6544-003 Polished Brass-Lifetime Finish 870.00
BA6544-060 Satin Brass and Brown 795.00
BA6544-102 Oil Rubbed Bronze 795.00
BA6950-003 Polished Brass-Lifetime Finish 870.00
BA6950-150 Satin Nickel Plated 795.00
BA6950-151 Antique Nickel, Dull 795.00
Use Pro-Lok IN65-PRO/INCL-PRO Templates
Go To Table of Contents
86
www.acclock.com
Accredited Lock Supply
B
Edinburgh
No. 6952
P/N Finish Function Retail
BA6952-003-LDBL Lifetime Brass LH Double Cyl 870.00
BA6952-003-RDBL Lifetime Brass RH Double Cyl 870.00
BA6952-003-LENT Lifetime Brass LH Entrance 870.00
BA6952-003-RENT Lifetime Brass RH Entrance 870.00
BA6952-003-LFD Lifetime Brass LH Full Dummy 870.00
BA6952-003-RFD Lifetime Brass RH Full Dummy 870.00
OUTSIDE TRIM: No. 6652
INSIDE ESCUTCHEON: No. 6789
LEVER: No. 5122
TURN KNOB: No. 6725
Westminster
No. 6961
ESCUTCHEON: No. 6790
LEVER: No. 5103
TURN KNOB: No. 6725
P/N Finish Function Retail
BA6961-003-LENT Lifetime Brass LH Entrance 570.00
BA6961-003-RENT Lifetime Brass RH Entrance 570.00
BA6961-003-LFD Lifetime Brass LH Full Dummy 570.00
BA6961-003-RFD Lifetime Brass RH Full Dummy 570.00
FENWICK
No. 6962
ESCUTCHEON: No. 6739
LEVER: No. 5122
TURN KNOB: No. 6725
P/N Finish Function Retail
BA6962-003-LENT Lifetime Brass LH Entrance 570.00
BA6962-003-RENT Lifetime Brass RH Entrance 570.00
BA6962-003-LFD Lifetime Brass LH Full Dummy 570.00
BA6962-003-RFD Lifetime Brass RH Full Dummy 570.00
LEXINGTON
No. 6560
BA6560-003 Polished Brass-Lifetime Finish 570.00
BA6560-050 Satin Brass and Black 495.00
BA6560-060 Satin Brass and Brown 495.00
BA6560-102 Oil Rubbed Bronze 495.00
Outside
OUTSIDE TRIM ONLY: No. 6621
KNOB: No. 5025
Inside
INSIDE ESCUTCHEON: No. 6795
STOCK FINISHES: US003-050-060-102
Sets include outside trim and inside escutcheons only. Mortise lock and cylinder sold separately.
HANDLESET TRIM (FORGED BRASS)
Use Pro-Lok IN65-PRO/INCL-PRO Templates
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 87
www.acclock.com
Accredited Lock Supply B
MORTISE LOCK BODIES
Heavy Duty Functions For doors 1 3/8"-1 3/4" thick, and over. Available in
the following finishes: 030, 050, 060, 102, 151, 190, 260, 264.
Standardized heavy steel case is smooth, easy to mortise, and assures
snug and solid fit in door mortise. Vital interior working parts are made of
solid hot forged brass of steel for a lifetime of trouble-free operation. Armored
front provides maximum strength and protection against tampering. Most
lock functions are completely reversible. The bevel of front is adjustable from
flat to standard level .125" on 2".
UL LISTING: Listed by Underwriters Laboratories Inc. on all series of single-
point locks or latches lllustrated in this section. Control No. F-901Y.
STRIKE: Wrought brass and bronze finished to match. Supplied to ANSI
standard A115.1 1/4" lip to center. Locks furnished standard with straight
lip strike(Universal) and wrought Box. Curved lip and special length strikes
available.
TEMPLATE: Metal doors/frames to be prepared in accordance with ANSI
A1151.2 or A115.11 FACE CUTOUTS ARE SUBJECT TO VARIATION. ALWAYS
REVIEW TRIM REQUIREMENTS BEFORE DOOR PREPARATION.
FEDERAL SPECIFICATION: Conforms to Federal Specifications FF-H106,
Series 86/87 and to all Performance and Structural Specifications of ANSI A
156. 13, Series 1000. Grade 1.
2 3/4" BACKSET
STEEL CASE: .875" x 5.5".
FRONT: Hot forged brass .218" x 1.25" x 8". Adjustable for beveled conditions.
SCALP: Wrought brass and bronze, available in standard finishes.
ANTI-FRICTION LATCH BOLT: Hot forged brass 5/8" x 1" x7.5" throw. Furnished
in US4 and 26D finishes to match trim.
DEAD BOLT: .5" x 1 1/4" x 1" throw with two saw-proof inserts. Furnished in
US4 and 26D finishes to match trim.
HANDLESET TRIM
MORTISE LOCK BODIES
HUB SIZE: 29" (7mm) with two-way rotation. Broached on the diamond. (One-way
rotation on LS functions).
SPACING: Center to center of: Knob Hub to cylinder 3.437" Knob Hub to turn
piece 2 1/4".
CYLINDER: Standard mortise type with 03 keyway and two nickel silver keys.
Locks furnished separately are supplied with a 1.125" length cylinder unless
specified otherwise.
KEYING: All levels of Keying including Construction Keying are available.
DEVONSHIRE - EMERGENCY EGRESS TUBULAR HANDLESET
No. 6401
LEVER: No. 5152
P/N Finish Function Retail
BA6401-003-LENT Lifetime Brass LH Entrance 725.00
BA6401-003-RENT Lifetime Brass RH Entrance 725.00
BA6401-003-LFD Lifetime Brass LH Full Dummy 650.00
BA6401-003-RFD Lifetime Brass RH Full Dummy 650.00
TUBULAR LOCKSET
Go To Table of Contents
88
www.acclock.com
Accredited Lock Supply
B
RESIDENTIAL ENTRANCE-EMERGENCY EGRESS
36500
003 Finish
055, 056
Latch bolt by knob from either side, except when outside knob is locked by stop
in front; then latch bolt by key outside and knob inside. Dead bolt by key outside
and turn piece inside. When dead bolt is thrown, stop is automatically activated
making outside knob rigid. Inside knob retracts latch and dead bolt simultaneously
but DOES NOT free outside knob. 1" throw dead bolt with saw-proof inserts is
standard equipment. When extended, Deadbolt deadlocks latch bolt.
FEDERAL SPECIFICATION EQUIVALENTS; ANSI Series: 1000-F12/F20
ENTRANCE-EMERGENCY EGRESS
RESIDENTIAL ENTRANCE
Latch bolt by thumb piece outside and knob inside, except when thumb piece
is locked by stop in front; then latch bolt by key outside and knob inside. Dead
bolt by key outside turn piece inside. Continuous turn of key outside retracts
both latch and dead bolt 1" throw dead bolt with saw-proof inserts is standard.
When extended, dead bolt deadlocks latch bolt.
FEDERAL SPECIFICATION EQUIVALENT: Government Type: 122A
BA6075 Knob Function
BA6075 LS Lever Function
Latch bolt by Knob from either side, except when outside knob is locked by
stop in front; then latch bolt by key outside and knob inside. Deadbolt by key
outside and turn piece inside. Continuous turn of key outside retracts both latch
and Deadbolt. 1" throw dead bolt with saw-proof inserts is standard equipment.
When extended, Deadbolt deadlocks latch bolt.
FEDERAL SPECIFICATION EQUIVALENTS;
ANSI Series: 1000-F08/F10
RESIDENTIAL ENTRANCE
BA6021 Knob Function
BA6021 LS Lever Function
BA6001 Knob Function
BA6001 LS Lever Function BA6020 Knob Function
BA6020 LS Lever Function
Latch bolt by thumbpiece outside, and knob inside; except when thumbpiece is
locked by stop in front; then latch bolt by key outside and knob inside. Dead bolt
by key outside and turn piece inside. When dead bolt is thrown, stop is automati-
cally activated making outside thumbpiece rigid. Inside knob retracts latch and
dead bolt simultaneously but DOES NOT free outside thumbpiece. 1" (25mm)
throw dead bolt with saw-proof inserts is standard equipment. When extended,
Deadbolt deadlocks latch bolt.
2 3/4" Backset
35500
040 Finish
050, 060, 102,
150, 151
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 89
www.acclock.com
Accredited Lock Supply B
RESIDENTIAL ENTRANCE
RESIDENTIAL - EMERGENCY EGRESS
ENTRANCE AND APARTMENT-EMERGENCY EGRESS
Latch bolt by knob from either side, except when outside knob is locked by stop in
front; then latch bolt by key outside and knob inside. Dead bolt by key outside and
turn piece inside. When dead bolt is thrown, stop is automatically activated mak-
ing outside knob rigid. 1" (25mm) throw dead with saw-proof inserts is standard
equipment. When extended, Deadbolt deadlocks latch bolt.
Latch bolt by thumbpiece outside, and knob inside; except when thumbpiece is
locked by stop in front; then latch bolt by key outside and knob inside. Dead bolt
by key outside and turn piece inside. When dead bolt is thrown, stop is automati-
cally activated making outside thumbpiece rigid. Inside knob retracts latch and
dead bolt simultaneously but DOES NOT free outside thumbpiece. 1" (25mm)
throw dead bolt with saw-proof inserts is standard equipment. When extended,
Deadbolt deadlocks latch bolt.
Latch bolt by knob from either side, except when outside knob is locked by stop in
front; then latch bolt by key outside and knob inside. Deadbolt by key outside and
turn piece inside. When Deadbolt is thrown, stop is automatically activated making
outside knob ridgid. Inside knob retracts both latch and Deadbolt simultaneously but
DOES NOT free outside knob. 1" throw Deadbolt with saw-proof inserts is standard
equipment. When extended, Deadbolt deadlocks latch bolt.
MORTISE LOCK BODIES
BA6375 Knob Function
BA6375 LS Lever Function
BA6301 Knob Function
BA6301 LS Lever Function
BA6321 Knob Function
BA6321 LS Lever Function
RESIDENTIAL ENTRANCE
Latch bolt by thumbpiece outside and knob inside, except when thumbpiece is
locked by stop in front; then latch bolt by key outside and knob inside. Deadbolt
by key outside and turn piece inside. Continuous turn of key outside retracts both
latch and Deadbolt. 1" (25mm) throw Deadbolt with saw-proof inserts is standard
equipment. When extended, Deadbolt deadlocks latch bolt.
BA6320 Knob Function
BA6320 LS Lever Function
2 1/2" Backset
Not Field
Reversible
Not Field
Reversible
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
36500
003 Finish
055, 056
35500
040 Finish
050, 060, 102,
150, 151
Go To Table of Contents
90
www.acclock.com
Accredited Lock Supply
B
DECORATIVE FORGED BRASS KNOB DESIGNS
Roses and Spindles Sold Separately
Roses & Spindles Sold Separately Price/pr
BA5064-003 Lifetime Brass 170.00
BA5064-030 Polished Brass 150.00
BA5064-060 Satin Brass/ Brown 150.00
BA5064-150 Satin Nickel 150.00
Roses & Spindles Sold Separately Price/pr
BA5015-003 Lifetime Brass 140.00
BA5015-030 Polished Brass 120.00
BA5015-060 Satin Brass and Brown 120.00
BA5015-102 Oil Rubbed Bronze 120.00
BA5015-260 Polished Chromium 120.00
BA5015-264 Satin Chromium 120.00
Roses & Spindles Sold Separately Price/pr
BA5020-003 Lifetime Brass 140.00
BA5020-030 Polished Brass 120.00
BA5020-060 Satin Brass and Brown 120.00
BA5020-260 Polished Chromium 120.00
Roses & Spindles Sold Separately Price/pr
BA5011-003 Lifetime Brass 180.00
BA5011-030 Polished Brass 160.00
BA5011-060 Satin Brass and Brown 160.00
BA5011-150 Satin Nickel 160.00
Roses & Spindles Sold Separately Price/pr
BA5023-003 Lifetime Brass 140.00
BA5023-102 Oil Rubbed Bronze 120.00
BA5023-112 Venetian Bronze 120.00
BA5023-402 Distressed Oil Rubbed Bronze 140.00
Roses & Spindles Sold Separately Price/pr
BA5005-003 Lifetime Brass 170.00
BA5005-030 Polished Brass 150.00
BA5005-050 Satin Brass and Black 150.00
BA5005-060 Satin Brass and Brown 150.00
Roses & Spindles Sold Separately Price/pr
BA5077-003 Lifetime Brass 140.00
BA5077-030 Polished Brass 120.00
BA5077-150 Satin Nickel 120.00
BA5077-260 Polished Chromium 120.00
BA5077-264 Satin Chromium 120.00
Roses & Spindles Sold Separately Price/pr
BA5025-003 Lifetime Brass 140.00
BA5025-030 Polished Brass 120.00
BA5025-060 Satin Brass and Brown 120.00
BA5025-102 Oil Rubbed Bronze 120.00
BA5025-260 Polished Chromium 120.00
BA5025-264 Satin Chromium 120.00
Roses & Spindles Sold Separately Price/pr
BA5066-003 Lifetime Brass 180.00
BA5066-030 Polished Brass 160.00
BA5066-060 Satin Brass and Brown 160.00
BA5066-260 Polished Chromium 160.00
Roses & Spindles Sold Separately Price/pr
BA5041-003 Lifetime Brass 140.00
BA5041-030 Polished Brass 120.00
BA5041-102 Oil Rubbed Bronze 120.00
BA5041-150 Satin Nickel 120.00
BA5041-260 Polished Chromium 120.00
BA5041-264 Satin Chromium 120.00
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 91
www.acclock.com
Accredited Lock Supply B
DECORATIVE FORGED BRASS LEVER DESIGNS
Roses and Spindles Sold Separately
Roses & Spindles Sold Separately Price/pr
BA5116-003 Lifetime Brass 180.00
BA5116-030 Polished Brass 160.00
BA5116-060 Satin Brass and Brown 160.00
Roses & Spindles Sold Separately Price/pr
BA5117-003 Lifetime Brass 170.00
BA5117-030 Polished Brass 150.00
BA5117-102 Oil Rubbed Bronze 150.00
BA5117-260 Polished Chromium 150.00
BA5117-264 Satin Chromium 150.00
Roses & Spindles Sold Separately Price/pr
BA5161-003 Lifetime Brass 170.00
BA5161-030 Polished Brass 150.00
BA5161-060 Satin Brass and Brown 150.00
BA5161-260 Polished Chromium 150.00
Roses & Spindles Sold Separately Price/pr
BA5104-003 Lifetime Brass 170.00
BA5104-030 Polished Brass 150.00
BA5104-060 Satin Brass and Brown 150.00
Roses & Spindles Sold Separately Price/pr
BA5128-050 Satin Brass & Black 116.60
BA5128-060 Satin Brass and Brown 116.60
BA5128-151 Antique Nickel 116.60
Roses & Spindles Sold Separately Price/pr
BA5152-003 Lifetime Brass 170.00
BA5152-030 Polished Brass 150.00
BA5152-060 Satin Brass and Brown 150.00
Roses & Spindles Sold Separately Price/pr
BA5162-003 Lifetime Brass 170.00
BA5162-030 Polished Brass 150.00
BA5162-060 Satin Brass and Brown 150.00
DWO - Call for availability
Go To Table of Contents
92
www.acclock.com
Accredited Lock Supply
B
Designed for attractiveness and easy reading. Numerals are surface applied with truss
head wood screws for easy installation. Comes complete with fasteners. Packed on a
merchandising card, 5 per box. 5" NUMBERS
DECORATIVE FORGED BRASS HOUSE NUMBERS
BA90670 ..............0
BA90671 ..............1
BA90672 ..............2
BA90673 ..............3
BA90674 ..............4
BA90675 ..............5
BA90676 ..............6
BA90677 ..............7
BA90678 ..............8
BA90679 ..............9
•NUMBERS •SLIDING DOOR LOCKS
Code Finish Price
BA90670-BA90679 003 Lifetime Brass 23.00
BA90670-BA90679 055 Lifetime Polished Nickel 23.00
BA90670-BA90679 056 Lifetime Satin Nickel 23.00
BA90670-BA90679 102 Oil Rubbed Bronze 20.00
BA90670-BA90679 112 Venetian Bronze 20.00
BA90670-BA90679 150 Satin Nickel 20.00
BA90670-BA90679 151 Antique Nickel 20.00
BA90670-BA90679 190 Satin Black 20.00
Introducing the new pocket door lock from Baldwin. Check out the Boulder, Palo Alto and Santa Monica large and small. Available
in up to 20 finishes, and four styles, we have the pocket door lock for every design aesthetic. Baldwin offers these four styles in
privacy, passage and keyed entry, in the highest quality; just what you expect from Baldwin. Unlock your design inspiration.
PATIO DOOR LOCKS
SANTA MONICA - LARGE
8.3" H
2.3" W
Minimum Door
Thickness: 1.75"
2.5" Backset
BAPD005-003-PASS Passage Lifetime Brass 520.00
BAPD005-151-PASS Passage Antique Nickel 470.00
BAPD005-003-PRIV Privacy Lifetime Brass 590.00
BAPD005-151-PRIV Privacy Antique Nickel 535.00
5.5" H
2.3" W
Minimum Door
Thickness: 1.375"
SANTA MONICA - SMALL
2.5" Backset
BAPD006-003-PASS Passage Lifetime Brass 480.00
BAPD006-151-PASS Passage Antique Nickel 430.00
BAPD006-003-PRIV Privacy Lifetime Brass 550.00
BAPD006-151-PRIV Privacy Antique Nickel 495.00
8.1" H
2.4" W
Minimum Door
Thickness: 1.375"
9.3" H
2.3" W
Minimum Door
Thickness: 1.375"
BOULDER
PALO ALTO
2.5" Backset
BAPD007-003-PASS Passage Lifetime Brass 480.00
BAPD007-151-PASS Passage Antique Nickel 430.00
BAPD007-003-PRIV Privacy Lifetime Brass 550.00
BAPD007-151-PRIV Privacy Antique Nickel 495.00
2.5" Backset
BAPD016-003-PASS Passage Lifetime Brass 500.00
BAPD016-151-PASS Passage Antique Nickel 450.00
BAPD016-003-PRIV Privacy Lifetime Brass 570.00
BAPD016-151-PRIV Privacy Antique Nickel 515.00
MORTISE LOCK BODIES
• Standardized heavy steel case is smooth, easy to
mortise, and assures snug and solid fit in door mortise.
• Vital interior working parts are made of solid hot forged
brass or steel for a lifetime of trouble-free operation.
• All lock cases are constructed of heavy gauge steel
(.093-2.4mm) material and plated with a protective
rust-resistant coating to retard oxidation.
BA8601-003 Passage Lifetime Brass 280.00
BA8601-151 Passage Antique Nickel 260.00
2 .5" Backset
BA8632-003 Pri./Ent. Lifetime Brass 310.00
BA8632-151 Pri./Ent. Antique Nickel 290.00
Passage
Privacy/
Entry
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 93
www.acclock.com
Accredited Lock Supply B
SIZE: 8.5" x 4.125"(216 x 104mm)
CTC of bolts: 4.75" (121mm)
BA0129
Use with Colonial Designs
IMPERIAL
DECORATIVE ENTRANCE DOOR KNOCKERS
Always specify the door thickness when ordering door knockers with Observ-O-Scopes, otherwise the standard for 1 3/4" (44mm.) doors will be provided.
Available in finishes other than the stock items listed below.
Polybagged, packed one in a box, with necessary fasteners.
VICTORIAN
SIZE: 7.00" x 3.5" (178 x 89mm)
CTC of bolts: 6.437" (163mm)
BA0175
Use with Modern Designs
SIZE: 4.25" x 5.5" (108 x 140mm)
CTC of bolts: 3.75" (95mm)
RING
SIZE: 5.5" x 4.03"
CTC of bolts: 4"
TAHOE
1800/ea.
003 Finish
SCREW COVERS
Specially designed 1"-diameter screw cover that conceals the screw
head. When ordering, specify finish to match door knocker.
STOCK FINISHES: Available in finishes to match our door knockers.
KNOCKERS Knockers Accesories
BA0195-003 Lifetime Brass 140.00
BA0195-260 Polished Chromium 119.00
BA0116-003 Lifetime Polished Brass 92.00
BA0116-030 Polished Brass 79.00
BA0116-050 Satin Brass & Black 79.00
BA0116-056 Lifetime Satin Nickel 92.00
BA0116-060 Satin Brass and Brown 79.00
BA0116-102 Oil Rubbed Bronze 79.00
BA0116-112 Venetian Bronze 79.00
BA0116-150 Satin Nickel 79.00
BA0116-151 Antique Nickel 79.00
"S" KNOCKER
SIZE: 2" dia. base (51mm)
7.75" high (197mm)
2.75" projection (70mm)
CTC of Bolts: 5" (127mm)
BA0113-003 Lifetime Brass 163.00
BA0113-060 Satin Brass and Brown 138.00
BA0113-102 Oil Rubbed Bronze 138.00
BA0113-112 Venetian Bronze 138.00
BA0113-150 Satin Nickel 138.00
BA0113-151 Antique Nickel, Dull 138.00
BA0110-003 Lifetime Polished Brass 92.00
BA0110-060 Satin Brass and Brown 69.00
BA0110-150 Satin Nickel 69.00
BA0110-151 Antique Nickel, Dull 69.00
SIZE: 6.5" x 3.5" (165 x 89mm)
CTC of bolts: 4" (102mm)
COLONIAL
BA0102-003
Lifetime Brass
74.00
BA0102-151
Antique Nickel
63.00
w/Observ-O-Scope
BA0103-003
Lifetime Brass
96.00
BA0103-151
Antique Nickel
81.00
BA0105-003 Lifetime Polished Brass 103.00
BA0105-050 Satin Brass and Black 87.00
BA0105-056 Lifetime Satin Nickel 103.00
BA0105-102 Oil Rubbed Bronze 87.00
BA0105-112 Venetian Bronze 87.00
BA0105-150 Satin Nickel 87.00
BA0105-151 Antique Nickel 87.00
BA0105-190 Satin Black 87.00
BA0105-264 Satin Chrome 87.00
BA0105-452 Distressed Antique Nickel 103.00
Go To Table of Contents
94
www.acclock.com
Accredited Lock Supply
B
RESIDENTIAL FLUSH BOLTS
FEATURES: Smooth forged brass construction. Sharply
defined edge and recess. Smooth working action with
automatic holding spring for both retracted and projected
positions. High quality flush bolt; not to be mistaken for
wrought metal types.
PACKED: Individually polybagged with screws and strike;
10 in a box.
Catalog Throw Backset Bolt Head
Number of Rod Diameter
0626 1" .468" .5"
(25 mm) (12 mm) (13 mm)
Code Trim Backset Price
Passage
BA5510-030 Knob 2 3/8" 55.00
BA5513-030 Lever 2 3/8" 55.00
BA5520-030 Knob 2 3/4" 55.00
BA5523-030 Lever 2 3/4" 55.00
Privacy
BA5510-P-030 Knob 2 3/8" 55.00
BA5513-P-030 Lever 2 3/8" 55.00
BA5520-P-030 Knob 2 3/4" 55.00
BA5523-P-030 Lever 2 3/4" 55.00
EXTENSION FLUSH BOLTS
FOR WOOD/METAL DOORS
Solid Forged Brass Construction
SIZE: Face Plate - 1" x 6 3/4"
FEATURES: HOT FORGED extension bolt with over 3/4" throw. Unique push button
design of lever and delay action for easy operation. Lever does not engage the bolt
until it is hinged freely to 45o angle. At this position, it is easy to move the bolt head.
Lever snaps automatically when hinged beyond 45o angle. Made to template for easy
installation in metal door frames. Use of strike optional.
Bolt Head Diameter: .5". Rod Backset: 3/4".
PACKED: One in a box with 12" rod. Each bolt is individually polybagged with combi-
nation machine/wood screws for all conditions.
UL LISTINGS: Listed by Underwriters Laboratories Inc. under Control NO. 760N.
FEDERAL SPECIFICATIONS EQUIVALENTS: Government Type: 1049; BHMA Designa-
tion: L04201.
BA0626-030 Polished Brass 22.00
BA0626-102 Oil Rubbed Bronze 22.00
BA0626-264 Satin Chromium 22.00
TUBULAR LATCH SETS
A step above ordinary zinc die cast tubular latches. Features sturdy
non-corrosive construction and heavy gauge stainless steel housing. All
components are forged brass.
Packed one per box supplied with wrought box strike, wood fasteners
and template.
Specify choice of finish: 030, 040, 050, 060, 100, 151, 260, 264
Passage
Privacy
FLUSH BOLTS LATCHES
Extension Flush Bolts • SURFACE BOLTS
BA0600-003 Lifetime Brass 29.00
BA0600-030 Polished Brass 28.00
BA0600-102 Oil Rubbed Bronze 28.00
BA0600-260 Polished Chromium 28.00
BA0600-264 Satin Chromium 28.00
ORNAMENTAL HEAVY DUTY
SURFACE BOLTS
Rugged, yet attractive. Heavy gauge
strikes can absorb great abuse.
Ornamental cover plates that conceal
mounting guides under the bolts without
marring the surface of the rod. Features
a large - 1 1/4" diameter knob for easy
operation. Codes BA0378 and BA0379
are packed five in a box with a Universal
strike and screws. All other reference
numbers are packed individually, with
Universal strike and screws.
Width of rod: 5/8" (16 mm.) Width of
guide: 1 3/4" (44mm.)
Code Finish Bolt No. of Price
Length Covers
BA0378-030 Polished Brass 4" 2 60.00
BA0379-030 Polished Brass 6" 2 75.00
BA0380-003 Lifetime Brass 8" 2 111.00
BA0380-102 Oil Rubbed Bronze 8" 2 95.00
BA0381-102 Oil Rubbed Bronze 12" 3 119.00
BA0382-030 Polished Brass 18" 3 138.00
BA0383-030 Polished Brass 24" 4 164.00
Also available in
the following finishes:
050 Satin Brass & Black
060 Satin Brass & Brown
112 Venetian Bronze
150 Satin Nickel
260 Polished Chromium
FOR ESTATE KNOBS & LEVERS ONLY
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 95
www.acclock.com
Accredited Lock Supply B
MECHANICAL FEATURES-TWO-POINT LOCK SETS
• SOLID FORGED BRASS: Entrance handle, cylinder collar, knob, rose and
turn piece are manufactured of solid forged brass for maximum strength
and durability.
• INSTALLATION: Images lock sets are designed for easy installation on
wood or metal doors with use of template provided.
• DOOR THICKNESS: Lock sets accommodate a door thickness of 1-3/4"
(44mm) to 2" (51 mm). For thicker doors, weld extension to tailpiece.
• CASE: Deadbolt and latch case are formed of steel for strength. Most
interior working parts are made of solid brass or steel for maximum strength
and smooth operation.
• BACKSET: Adjustable backset 2-3/8" (60mm), 2-3/4" (70mm) latch and
deadbolt supplied standard.
• FACE PLATE: Deadbolt and latch supplied with a 1" (25mm) face plate.
TWO-POINT LOCKING HANDLESETS • STRIKE: Deadbolt is furnished with a specially designed reinforcing
strike constructed of high grade steel for ultimate strength and durability.
The strike is installed with two (2) 3" (76mm) security jamb screws and a
dust box. The security strike is covered with an armored front to conceal
the fasteners. The 3" screws securing the inside face of the double cylinder
deadbolt resist tampering and guard against theft. Latches are supplied
standard with a box strike (other strikes are available at an additional charge.)
• DISTANCE BETWEEN CENTER OF LATCH AND DEADBOLT (CTC): Lockset
accommodates any center-to-center dimension greater than 4-3/4" (121mm).
• BOLT: Deadbolt and latch bolt constructed of solid brass. Deadbolt has
1" (25mm) throw when extended and a hardened steel insert for maximum
protection and security. Latch bolt has a .5" (13mm) throw when extended
to fully engage the door jamb.
• CYLINDER: Cylinder supplied with 5-pin keying. Cylinder is protected
with a free-turning cylinder guard to resist gripping or twisting.
• KEYS: Designed with a 1-1/4" (32mm) wide bow surface to facilitate use
by disabled and physically challenged people.
• DOOR PREP: Designed to fit 2-1/8" face bore with 3-hole prep.
LANDON
Egg Knob Wave Lever
Part No. . Lockset Description Finish. Retail
BA5345-003-2ENT Entrance, Single Cyl. w/Dblt Lifetime Brass 625.00
BA5345-003-2DC Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 650.00
BA5345-003-2FD Full Dummy, Dummy Ddblt. Lifetime Brass 550.00
w/Egg Knob
Part No. . Lockset Description Finish. Retail
BA5345-003-2LH Entrance, Single Cyl. w/Dblt. Lifetime Brass 625.00
BA5345-003-2RH Entrance, Single Cyl. w/Dblt Lifetime Brass 625.00
BA5345-003-2DCR Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 650.00
BA5345-003-2DCL Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 650.00
BA5345-003-2RFD Full Dummy Lifetime Brass 550.00
BA5345-003-2LFD Full Dummy Lifetime Brass 550.00
w/Wave Lever (specify RH or LH)
Call For Stocked Finishes
Go To Table of Contents
96
www.acclock.com
Accredited Lock Supply
B
ASHTON
2 Pt. Entrance Locks
SOHO
BA5385
Available Finishes: 003, 031,050, 055,
056, 102, 112, 150,
151,190, 260, 264,
402, 412, 452
Many finishes and functions in stock. Call
your sales rep for more information.
w/Soho Lever (specify RH or LH)
Part No. . Lockset Description Finish. Retail
BA5365-003-2ENT Entrance, Single Cyl. w/Dblt Lifetime Brass 675.00
BA5365-003-2DC Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 700.00
BA5365-003-2FD Full Dummy, Dummy Ddblt. Lifetime Brass 600.00
w/Colonial Knob
Part No. . Lockset Description Finish. Retail
BA5365-003-2LH Entrance, Single Cyl. w/Dblt. Lifetime Brass 675.00
BA5365-003-2RH Entrance, Single Cyl. w/Dblt Lifetime Brass 675.00
BA5365-003-2DCR Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 700.00
BA5365-003-2DCL Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 700.00
BA5365-003-2RFD Full Dummy Lifetime Brass 600.00
BA5365-003-2LFD Full Dummy Lifetime Brass 600.00
w/Wave Lever (specify RH or LH)
Part No. . Lockset Description Finish. Retail
BA5385-003-2LH Entrance, Single Cyl. w/Dblt. Lifetime Brass 675.00
BA5385-003-2RH Entrance, Single Cyl. w/Dblt Lifetime Brass 675.00
BA5385-003-2DCR Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 700.00
BA5385-003-2DCL Entrance, Dbl. Cyl. w/Deadbolt Lifetime Brass 700.00
BA5385-003-2RFD Full Dummy Lifetime Brass 600.00
BA5385-003-2LFD Full Dummy Lifetime Brass 600.00
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 97
www.acclock.com
Accredited Lock Supply B
ENTRANCE SETS, TUBULAR
Tubular entrance sets are featured in both traditional and contemporary styles in
our most popular finishes (please consult Cross Reference of Finish Identification
Numbers chart for details). Interior latchset designs coordinate beautifully with lockset
styles to enable customers to carry a specific design theme throughout the home.
Distinctive packaging exudes upscale image and reflects Baldwin’s tradition of
quality. Each Images lockset is packed complete in a distinctive presentation package.
Functions available include:
Entrance
From exterior:
Thumb piece operates handleset latch; key operates dead-
bolt.
From interior:
Knob operates latch; turnpiece operates deadbolt.
Double Cylinder
From exterior:
Thumb piece operates handleset latch; key operates
deadbolt.
From interior:
Knob operates latch; key operates deadbolt.
Full Dummy
Trim for non-working side of double doors. Matching
dummy trim (non-functioning) handleset and interior trim.
CanterburyTM
IMAGE SERIES LATCHES
Latchbolts have a .5"(13mm) throw, are reversible with
fully adjustable fronts for use on beveled doors. For
use with Images Sectional,Escutcheon and Emergency
Exit Entrance Locksets. All latchbolts have an adjust-
able backset feature to accommodate 2 3/8" or 2 3/4"
backsets. Packed without fasteners.
Part No. Backset Front Front Price
Length Width
BA5300-XXX.9 2 3/8"-2 3/4" 2 1/4" 1" 43.00
• ENTRANCE HANDLES
Adjustable backset: 2 3/8" or 2 3/4"
BLAKELY
No. 5360
Adjustable backset
Part No. . Lockset Description Finish. Retail
BA5360-003-ENTR Entrance, Single Cyl. Lifetime Brass 675.00
BA5360-003-FD Full Dummy Lifetime Brass 600.00
BA5360-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 600.00
BA5360-150-ENTR Entrance, Single Cyl. Satin Nickel 600.00
BA5360-151-ENTR Entrance, Single Cyl. Antique Nickel 600.00
BUCKINGHAM
No. 5380
Adjustable backset
Part No. . Lockset Description Finish. Retail
BA5380-003-ENTR Entrance, Single Cyl. Lifetime Brass 575.00
BA5380-003-FD Full Dummy Lifetime Brass 500.00
BA5380-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 500.00
BA5380-150-ENTR Entrance, Single Cyl. Satin Nickel 500.00
BA5380-151-ENTR Entrance, Single Cyl. Antique Nickel 500.00
Part No. . Lockset Description Finish. Retail
BA5305-003-ENTR Entrance, Single Cyl. Lifetime Brass 525.00
BA5305-003-FD Full Dummy Lifetime Brass 450.00
BA5305-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 450.00
BA5305-150-ENTR Entrance, Single Cyl. Satin Nickel 450.00
BA5305-151-ENTR Entrance, Single Cyl. Antique Nickel 450.00
ALSO AVAILABLE WITH INTERIOR LEVER
Call For Stocked Finishes
DEADLOCKING LATCHBOLT
For Keyed Entry Locksets &
Two Point Handlesets
FEATURES: Latchbolts have a 1/2" throw, are revers-
ible and can be used on beveled doors. Latches are
supplied with 1" face plates.
PACKED: One per box.
BA5210-003, 055, 056 - 4500
Other finishes in stock - 4500
Go To Table of Contents
98
www.acclock.com
Accredited Lock Supply
B
LoganTM
MadisonTM
• ENTRANCE HANDLES
Part No. Lockset Description Backset Retail
BA5375-003-DBLC Glennon Entrance Adj. 600.00
BA5375-003-ENTR Glennon Entrance Adj. 575.00
BA5375-003-FD Glennon Full Dummy 500.00
NantucketTM
GlennonTM
Adjustable Backset
Adjustable Backset
Adjustable Backset
Adjustable Backset
Part No. . Lockset Description Finish. Retail
BA5315-003-ENTR Entrance, Single Cyl. Lifetime Brass 525.00
BA5315-003-FD Full Dummy Lifetime Brass 450.00
BA5315-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 450.00
BA5315-150-ENTR Entrance, Single Cyl. Satin Nickel 450.00
BA5315-151-ENTR Entrance, Single Cyl. Antique Nickel 450.00
BA5315-190-ENTR Entrance, Single Cyl. Satin Black 450.00
Part No. . Lockset Description Finish. Retail
BA5370-003-ENTR Entrance, Single Cyl. Lifetime Brass 575.00
BA5370-003-FD Full Dummy Lifetime Brass 500.00
BA5370-003-DBLC Entrance, Double Cyl. Lifetime Brass 600.00
Part No. . Lockset Description Finish. Retail
BA5320-003-ENTR Entrance, Single Cyl. Lifetime Brass 525.00
BA5320-003-DBLC Entrance, Dble. Cyle Lifetime Brass 550.00
BA5320-003-FD Full Dummy Lifetime Brass 450.00
BA5320-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 450.00
BA5320-150-ENTR Entrance, Single Cyl. Satin Nickel 450.00
BA5320-151-ENTR Entrance, Single Cyl. Antique Nickel 450.00
ALSO AVAILABLE WITH INTERIOR LEVER
ALSO AVAILABLE
WITH INTERIOR
LEVER
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 99
www.acclock.com
Accredited Lock Supply B
Part No. Lockset Description Backset Retail
BA5350-003-LENT Manchester Entrance LH Adj. 625.00
BA5350-003-LFD Manchester Full Dummy LH 600.00
BA5350-003-RENT Manchester Entrance RH Adj. 625.00
BA5350-003-RFD Manchester Full Dummy RH 600.00
Part No. Lockset Description Backset Retail
BA5355-003-LENT Stonegate Entrance LH Adj. 625.00
BA5355-003-LFD Stonegate Full Dummy LH 600.00
BA5355-003-RENT Stonegate Entrance RH Adj. 625.00
BA5355-003-RFD Stonegate Full Dummy RH 600.00
ManchesterTM
Emergency Egress
StonegateTM
• ENTRANCE HANDLES
Adjustable Backset
Adjustable Backset
TahoeTM Emergency Egress
TahoeTM
Adjustable Backset
Adjustable Backset
Part No. Lockset Description Finish. Retail
BA5340-452-ENTR Entrance, Single Cyl. Distressed Ant.Nickel 700.00
BA5340-003-LHRH Entrance, LH & RH Lifetime Brass 700.00
BA5340-003-LRFD Full Dummy, LH & RH Lifetime Brass 640.00
BA5340-190-LHRH Entrance, LH & RH Satin Black 625.00
BA5340-190-LRFD Full Dummy, LH & RH Satin Black 565.00
Part No. Lockset Description Finish. Retail
BA5325-003-ENTR Entrance, Single Cyl. Lifetime Brass 500.00
BA5325-112-LHRH Entrance, LH & RH Venetian Bronze 425.00
BA5325-190-ENTR Entrance, Single Cyl. Satin Black 425.00
BA5325-190-LHRH Entrance, LH & RH Satin Black 425.00
BA5325-190-LRFD Full Dummy, LH & RH Satin Black 365.00
BA5325-402-LHRH Entrance, LH & RH Dist.Oil Rubbed Bnz 440.00
BA5325-412-ENTR Entrance, Single Cyl. Dist.Venetian Bronze 440.00
LHRH & LRFD COME WITH INTERIOR LEVER, SPECIFY LH OR RH
LHRH & LRFD COME WITH INTERIOR
LEVERS, SPECIFY LH or RH
Stonegate Emergency
EgressDWO - Call For Availability
DWO - Call For Availability
Go To Table of Contents
100
www.acclock.com
Accredited Lock Supply
B
BethpageTM
Sectional Trim
Part No. Lockset Description Finish. Retail
BA5327-003-ENTR Entrance, Single Cyl. Lifetime Brass 525.00
BA5327-003-LHRH Entrance, LH & RH Lifetime Brass 525.00
BA5327-050-ENTR Entrance, Single Cyl. Satin Brass & Black 450.00
BA5327-050-FD Full Dummy Satin Brass & Black 375.00
BA5327-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 450.00
BA5327-102-FD Full Dummy Oil Rubbed Bronze 375.00
BA5327-112-ENTR Entrance, Single Cyl. Venetian Bronze 450.00
BA5327-112-FD Full Dummy Venetian Bronze 375.00
BA5327-150-ENTR Entrance, Single Cyl. Satin Nickel 450.00
BA5327-150-FD Full Dummy Satin Nickel 375.00
BA5327-151-ENTR Entrance, Single Cyl. Antique Nickel 450.00
BA5327-151-FD Full Dummy Antique Nickel 375.00
BA5327-190-ENTR Entrance, Single Cyl. Satin Black 450.00
BA5327-190-FD Full Dummy Satin Black 375.00
BA5327-402-ENTR Entrance, Single Cyl. Dist. Oil Rubbed Brnz 525.00
BA5327-402-FD Full Dummy Dist. Oil Rubbed Brnz 475.00
BA5327-452-ENTR Entrance, Single Cyl. Dist. Antique Nickel 525.00
BA5327-452-FD Full Dummy Dist. Antique Nickel 450.00
LHRH & LRFD COME WITH INTERIOR LEVER
Part No. Lockset Description Finish. Retail
BA5337-003-ENTR Entrance, Single Cyl. Lifetime Brass 675.00
BA5337-003-LHRH Entrance, LH & RH Lifetime Brass 675.00
BA5337-102-ENTR Entrance, Single Cyl. Oil Rubbed Bronze 600.00
BA5337-102-FD Full Dummy Oil Rubbed Bronze 525.00
BA5337-112-ENTR Entrance, Single Cyl. Venetian Bronze 600.00
BA5337-112-FD Full Dummy Venetian Bronze 525.00
BA5337-150-ENTR Entrance, Single Cyl. Satin Nickel 600.00
BA5337-150-FD Full Dummy Satin Nickel 525.00
BA5337-151-ENTR Entrance, Single Cyl. Antique Nickel 600.00
BA5337-151-FD Full Dummy Antique Nickel 525.00
BA5337-260-ENTR Entrance, Single Cyl. Satin Black 600.00
BA5337-260-FD Full Dummy Satin Black 525.00
LHRH & LRFD COME WITH INTERIOR LEVER
Bethpage Emergency Egress
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 101
www.acclock.com
Accredited Lock Supply B
5015 Series
PRE-CONFIGURED SETS
• SOLID FORGED BRASS: Knobs, levers, and roses are manufactured of solid
forged brass for maximum strength and durabilty.
• LATCHES: Images latches are constructed for exceptional durability and smooth
operation. The heavy latch bolt springs are performance tested to eliminate lever
sag. All latches are reversible to accommodate all door conditions.
• FACEPLATE: Latches are supplied with a 1" (25mm) faceplate. 1.125" (29mm)
faceplate is NOT available.
• FUNCTIONS: Four (4) functions are available: passage, privacy, full dummy and
half dummy.
• Passage and privacy functions are supplied standard with a 2.375" (60mm)
backset latch. A 2.75" (70mm) backset latch is available.
• Privacy function has a locking push button feature with automatic release on the
interior door trim and an emergency release feature on the exterior door trim.
• ROSES: Images roses are designed to conceal a 2.125" (54mm) pre-drilled door
condition. The rose snaps onto the adaptor housing.
• DOOR CUTOUT: The adaptor easily installs into a 2.125" (54mm) cutout and
aligns the latch with the trim.
• DOOR THICKNESS: Images locksets fit 1.375" (35mm) and 1.75" (49mm) doors.
Part No. Description Backset Retail
BA5015-003-FD Full Dummy Knob Set 160.00
BA5015-003-IDM Half Dummy Knob Set 80.00
BA5015-003-PASS Passage Knob Latch Set 2 3/8" 190.00
BA5015-003-PRIV Privacy Knob Latch Set 2 3/8" 190.00
BA5015-260-FD Full Dummy Knob Set 130.00
BA5015-260-IDM Half Dummy Knob Set 65.00
BA5015-260-PASS Passage Knob Latch Set 2 3/8" 160.00
BA5015-260-PRIV Privacy Knob Latch Set 2 3/8" 160.00
• Knobsets
Part No. Description Backset Retail
BA5020-003-FD Full Dummy Knob Set 160.00
BA5020-003-IDM Half Dummy Knob Set 80.00
BA5020-003-PASS Passage Knob Latch Set 2 3/8" 190.00
BA5020-003-PRIV Privacy Knob Latch Set 2 3/8" 190.00
BA5020-260-FD Full Dummy Knob Set 130.00
BA5020-260-IDM Half Dummy Knob Set 65.00
BA5020-260-PASS Passage Knob Latch Set 2 3/8" 160.00
BA5020-260-PRIV Privacy Knob Latch Set 2 3/8" 160.00
5415 Series
5020 Series
Part No. Description Backset Retail
BA5415-003-FD Full Dummy Knob Set 95.00
BA5415-003-IDM Half Dummy Knob Set 47.00
BA5415-003-PASS Passage Knob Latch Set 2 3/8" 121.00
BA5415-003-PRIV Privacy Knob Latch Set 2 3/8" 121.00
BA5415-260-FD Full Dummy Knob Set 79.00
BA5415-260-IDM Half Dummy Knob Set 40.00
BA5415-260-PASS Passage Knob Latch Set 2 3/8" 100.00
BA5415-260-PRIV Privacy Knob Latch Set 2 3/8" 100.00
BA5415-326-PRIV Privacy Knob Latch Set 2 3/8" 100.00
BA5416-003-PASS Passage Knob Latch Set 2 3/4" 121.00
BA5416-003-PRIV Privacy Knob Latch Set 2 3/4" 121.00
BA5416-260-PASS Passage Knob Latch Set 2 3/4" 100.00
BA5416-260-PRIV Privacy Knob Latch Set 2 3/4" 100.00
DWO - Call For Availability
Go To Table of Contents
102
www.acclock.com
Accredited Lock Supply
B
Part No. Description Backset Retail
BA5460-003-FD Full Dummy Lever Set 95.00
BA5460-003-LDM Half Dummy Lever Set 47.00
BA5460-003-PASS Passage Lever Latch Set 2 3/8" 121.00
BA5460-003-PRIV Privacy Lever Latch Set 2 3/8" 121.00
BA5460-003-RDM Half Dummy Lever Set 47.00
BA5460V-260-FD Full Dummy Lever Set 120.00
BA5460V-260-LDM Half Dummy Lever Set 60.00
BA5460V-260-PASS Passage Lever Latch Set 2 3/8" 150.00
BA5460V-260-PRIV Privacy Lever Latch Set 2 3/8" 150.00
BA5460V-260-RDM Half Dummy Lever Set 60.00
BA5460V-326-PRIV Privacy Lever Latch Set 2 3/8" 100.00
5460 Series
Part No. Description Backset Retail
BA5455V-003-FD Full Dummy Lever Set 160.00
BA5455V-003-LDM Half Dummy Lever Set 80.00
BA5455V-003-PASS Passage Lever Latch Set 2 3/8" 190.00
BA5455V-003-PRIV Privacy Lever Latch Set 2 3/8" 190.00
BA5455V-003-RDM Half Dummy Lever Set 80.00
BA5455V-150-FD Full Dummy Lever Set 130.00
BA5455V-150-LDM Half Dummy Lever Set 65.00
BA5455V-150-RDM Half Dummy Lever Set 65.00
BA5455V-150-PASS Passage Lever Latch Set 160.00
BA5455V-150-PRIV Privacy Lever Latch Set 160.00
BA5455V-151-FD Full Dummy Lever Set 130.00
BA5455V-151-LDM Half Dummy Lever Set 65.00
BA5455V-151-RDM Half Dummy Lever Set 65.00
BA5455V-151-PASS Passage Lever Latch Set 160.00
BA5455V-151-PRIV Privacy Lever Latch Set 160.00
BA5455V-260-FD Full Dummy Lever Set 130.00
BA5455V-260-LDM Half Dummy Lever Set 65.00
BA5455V-260-PAS Passage Lever Latch Set 2 3/8" 160.00
BA5455V-260-PRIV Privacy Lever Latch Set 2 3/8" 160.00
BA5455V-260-RDM Half Dummy Lever Set 65.00
5455V Series
5440 Series
Part No. Description Backset Retail
BA5445V-003-FD Full Dummy Lever Set 160.00
BA5445V-003-LDM Half Dummy Lever Set 80.00
BA5445V-003-PASS Passage Lever Latch Set 2 3/8" 190.00
BA5445V-003-PRIV Privacy Lever Latch Set 2 3/8" 190.00
BA5445V-003-RDM Half Dummy Lever Set 80.00
BA5445V-150-FD Full Dummy Lever Set 130.00
BA5445V-150-LDM Half Dummy Lever Set 65.00
BA5445V-150-RDM Half Dummy Lever Set 65.00
BA5445V-150-PASS Passage Lever Latch Set 2 3/8" 160.00
BA5445V-150-PRIV Privacy Levery Latch Set 2 3/8" 160.00
BA5445V-260-FD Full Dummy Lever Set 130.00
BA5445V-260-LDM Half Dummy Lever Set 65.00
BA5445V-260-PASS Passage Lever Latch Set 2 3/8" 160.00
BA5445V-260-PRIV Privacy Lever Latch Set 2 3/8" 160.00
BA5445V-260-RDM Half Dummy Lever Set 65.00
Part No. Description Basckset Retail
BA5440-003-FD Full Dummy Lever Set 95.00
BA5440-003-LDM Half Dummy Lever Set 47.00
BA5440-003-PASS Passage Lever Latch Set 2 3/8" 121.00
BA5440-003-PRIV Privacy Lever Latch Set 2 3/8" 121.00
BA5440-003-RDM Half Dummy Lever Set 47.00
BA5440V-150-FD Full Dummy Lever Set 120.00
BA5440V-150-LDM Half Dummy Lever Set 60.00
BA5440V-150-RDM Half Dummy Lever Set 60.00
BA5440V-150-PASS Passage Lever Latch Set 2 3/8" 150.00
BA5440V-150-PRIV Privacy Lever Latch Set 2 3/8" 150.00
BA5440-260-FD Full Dummy Lever Set 79.00
BA5440-260-LDM Half Dummy Lever Set 40.00
BA5440-260-PASS Passage Lever Latch Set 2 3/8" 100.00
BA5440-260-RDM Half Dummy Lever Set 100.00
5445V Series
2 3/4" backset available
2 3/4" backset available 2 3/4" backset available
2 3/4" backset available
DWO - Call For Availability
DWO - Call For Availability
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 103
www.acclock.com
Accredited Lock Supply B
Part No. Description Backset Retail
BA5450-003-LDM Half Dummy Lever Set 49.00
BA5450-003-PRIV Privacy Lever Latch Set 2 3/8" 121.00
BA5450-030-PASS Passage Lever Latch Set 2 3/8" 83.00
BA5450-030-PRIV Privacy Lever Latch Set 2 3/8" 91.00
BA5450-150-PRIV Privacy Lever Latch Set 2 3/8" 100.00
BA5450-150-LDM Half Dummy Lever Set 40.00
BA5450-150-RDM Half Dummy Lever Set 40.00
BA5450-150-FD Full Dummy Lever Set 80.00
BA5450-260-FD Full Dummy Lever Set 80.00
BA5450-260-LDM Half Dummy Lever Set 40.00
BA5450-260-PASS Passage Lever Latch Set 2 3/8" 92.00
BA5450-260-PRIV Privacy Lever Latch Set 2 3/8" 100.00
BA5450-260-RDM Half Dummy Lever Set 40.00
BA5450-326-LPRI Privacy Lever Set, LH 2 3/8" 100.00
BA5450-326-RPRI Privacy Lever Set, RH 2 3/8" 100.00
BA5451-003-PASS Passage Lever Latch Set 2 3/4" 111.00
BA5451-003-PRIV Privacy Lever Latch Set 2 3/4" 121.00
BA5451-260-PASS Passage Lever Latch Set 2 3/4" 92.00
BA5451-260-PRIV Privacy Lever Latch Set 2 3/4" 100.00
5450 Series
• Lever Locksets
Part No. . Description . Backset . Retail
BA5025-003-FD Full Dummy Knob Set 160.00
BA5025-003-IDM Half Dummy Knob Set 80.00
BA5025-003-PASS Passage Knob Latch Set 2 3/8" 160.00
BA5025-003-PRIV Privacy Knob Latch Set 2 3/8" 160.00
BA5025-150-FD Full Dummy Knob Set 130.00
BA5025-150-LDM Half Dummy Knob Set 65.00
BA5025-150-RDM Half Dummy Knob Set 65.00
BA5025-150-PASS Passage Knob Latch Set 160.00
BA5025-150-PRIV Privacy Knob Latch Set 160.00
BA5025-260-FD Full Dummy Knob Set 130.00
BA5025-260-IDM Half Dummy Knob Set 65.00
BA5025-260-PASS Passage Knob Latch Set 2 3/8" 160.00
BA5025-260-PRIV Privacy Knob Latch Set 2 3/8" 160.00
5025 Series
THICK DOOR KITS FOR NEW MECHANICS
BA5399xxx.A For all Sectional and Escutcheon Single Cylinder Entrance function
handlesets to fit 2" & 21/4" thick door 45.00
BA5399.xxx.B For all Sectional and Escutcheon Double Cylinder Entrance handlesets
to fit 2" & 2 1/4" thick doors 45.00
BA5399.xxx.C For all Emergency Egress function handlesets to fit 2" & 2 1/4" thick
doors 45.00
BA5399.xxx.D For all Full Dummy handle functions-Sectional, Escutcheon and
Emergency Egress to fit 2" & 2 1/4" thick doors 15.00
REPAIR KITS FOR NEW MECHANICS
BA5399 xxx G For active Sectional and Escutcheon handlesets (except Tahoe® ) with
lnterior Knobs, Including Single Cylinder (ENTR) and Double Cylinder(DBLC)sets
45.00
BA5399.xxx.H For active Sectlonal and Escutcheon handlesets (except Tahoe®)with
Interior Levers, Including Single Cylinder (LHRH) and Double Cylinder (LRDB) sets
45.00
BA5399.xxx.I For active Tahoe® Sectional handlesets with lnterior Knobs including
Single Cylinder (ENTR) and Double Cylinder (DBLC) sets 45.00
BA5399.xxx.J For active Tahoe® Sectional handlesets with Interior Levers including
Single Cylinder (LHRH) and Double Cylinder (LRDB) sets 45.00
BA5399.xxx.K For Full Dummy (FD or LRFD) Sectional, Escutcheon, and Emergency
Egress handlesets (except Tahoe®) with a Traditional oval thumbpiece including
Interior Knobs or Levers 35.00
BA5399.xxx.L For Full Dummy (FD or LRFD) Tahoe® handlesets with a rectangular
thumbpiece including Interior Knobs or Levers. Use this kit for the following Trim
Set: Tahoe® 35.00
BA5399.xxx.M For active Emergency Egress handlesets (ENTR) wittl an oval egress
cartridge, a Traditional oval thumbpiece, and an Interior Knob 45.00
BA5399.xxx.N For active Emergency Egress handlesets (LENT or RENT) with a
rectangular egress cartridge, a Traditional oval thumbpiece, and an Interior Lever
45.00
BA5399.xxx.O For actlve Tahoe® Emergency Egress handlesets(ENTR or LHRH) with
an oval egress cartridge, a rectangular thumbpiece and an Interior Knob or Lever
45.00
NOTE: All parts must be installed for proper lock function.
ACCESSORIES FOR TUBULAR HANDLESETS
2 3/4" backset available
DWO - Call for availability
Go To Table of Contents
104
www.acclock.com
Accredited Lock Supply
B
IMAGES KEYED ENTRY LOCKSETS
Images Keyed Entry Locksets are featured in our most popular styles, and are available in The Lifetime Finish _ from Baldwin or oil rubbed bronze
(please consult price list for details.) Images interior latchset designs coordinate beautifully with the Keyed Entry Lockset styles to enable consumers
to carry a specific design theme throughout the home. Each Images Keyed Entry Lockset is packed in a complete set and includes graphic
installation instructions. Meets Grade 2 requirements.
THE IMAGES COLLECTION KEYED ENTRY LOCKSETS - MECHANICAL FEATURES
• SOLID BRASS: Knobs, levers, and roses are manufactured of solid brass for maximum strength and
durability.
• EASE OF INSTALLATION: Images Keyed Entry Locksets are designed for easy installation in standard
pre-bored wood or metal doors. The adapter
aligns the unit for a perfect fit each time. Graphic instructions make installation FAST!
• CONCEALED FASTENERS: All Images Keyed Entry Locksets are designed with screw-on solid brass
roses, which conceal the mounting hardware
for a high quality appearance.
• EMERGENCY EXIT FUNCTION: Interior knob always retracts latch to allow immediate exit.
• FULLY REVERSIBLE: Accommodates all door conditions and facilitates installation.
• DOOR THICKNESS: Locksets accommodate 1-3/8" (35mm) or 1-3/4" (44mm) thick doors.
• CASE: Latch case is formed of steel for strength. Interior working parts are made of brass or steel for maximum strength and smooth operation.
• BACKSET: Entry function supplied with an adjustable backset latch which will accommodate 2-3/8" (60mm) and 2-3/4" (70mm) backsets.
• FACEPLATE: Latch faceplate supplied is 1" (25mm) wide x 2-1/4" (57mm).
• STRIKE: All entry locksets are supplied with a full lip strike.
• CYLINDER: Solid brass rekeyable cylinder supplied standard with 03 keyway and two nickel silver keys. See catalog pages for 5 pin or 6 pin capability.
• KEYS: Designed with 1-1/4" (32mm) wide bow surface to facilitate use by physically challenged people. (2 keys supplied per lock).
GRADE 2: Meets Grade 2 requirements for security and endurance.
Replacement cylinders in stock.
Part No. Finish Price
BA5250-003-LENT Lifetime Brass 145.00
BA5250-003-RENT Lifetime Brass 145.00
BA5250-003-FD Lifetime Brass 131.00
BA5250-050-LENT Satin Brass & Black 152.00
BA5250-050-RENT Satin Brass & Black 152.00
BA5250-050-FD Satin Brass & Black 138.00
BA5250-150-LENT Satin Nickel 152.00
BA5250-150-RENT Satin Nickel 152.00
BA5250-150-FD Satin Nickel 138.00
BA5250-151-LENT Antique Nickel 152.00
BA5250-151-RENT Antique Nickel 152.00
BA5250-151-FD Antique Nickel 138.00
BA5250-260-LENT Polished Chrome 152.00
BA5250-260-RENT Polished Chrome 152.00
BA5250-260-FD Polished Chrome 138.00
5250.XXX.LENT Entrance Set-Adjustable Backset
5250.XXX.RENT Entrance Set-Adjustable Backset
5250.XXX.FD Full Dummy Set
Keying: Solid brass 6
pin cylinder, keyed 5
pin
5250 Series - Keyed Locksets
AVAILABLE IN ALL POPULAR FINISHES
DWO - Call for availability
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 105
www.acclock.com
Accredited Lock Supply B
Part No. Finish Price
BA5205-003-ENTR Lifetime Brass 250.00
BA5205-003-FD Lifetime Brass 220.00
BA5205-150-ENTR Satin Nickel 220.00
BA5205-151-ENTR Antique Nickel 220.00
Part No. Finish Price
BA5210-003-ENTR Lifetime Brass 250.00
BA5210-003-FD Lifetime Brass 220.00
BA5210-150-ENTR Satin Nickel 220.00
BA5210-151-ENTR Antique Nickel 220.00
Part No. Finish Price
BA5215-003-ENTR Lifetime Brass 250.00
BA5215-003-FD Lifetime Brass 220.00
BA5215-150-ENTR Satin Nickel 220.00
BA5215-151-ENTR Antique Nickel 220.00
Part No. Finish Price
BA5225-003-ENTR Lifetime Brass 250.00
BA5225-003-FD Lifetime Brass 220.00
BA5225-150-ENTR Satin Nickel 220.00
BA5225-151-ENTR Antique Nickel 220.00
AVAILABLE IN ALL POPULAR FINISHES
CLASSIC KNOB
COLONIAL KNOB
CONTEMPORARY KNOB W/CONTEMPORARY ROSE
Go To Table of Contents
106
www.acclock.com
Accredited Lock Supply
B
Part No. Finish Price
BA5270-003-ENTR Lifetime Brass 158.00
BA5270-003-FD Lifetime Brass 143.00
Part No. Finish Price
BA5280-003-ENTR Lifetime Brass 158.00
BA5280-003-FD Lifetime Brass 143.00
Part No. Finish Price
BA5245-003-ENTR Lifetime Brass 250.00
BA5245-003-FD Lifetime Brass 220.00
BA5245-150-ENTR Satin Nickel 220.00
Part No. Finish Price
BA5255-003-ENTR Lifetime Brass 250.00
BA5255-003-FD Lifetime Brass 220.00
BA5255-150-ENTR Satin Nickel 220.00
BA5255-151-ENTR Antique Nickel 220.00
5345.XXX.LENT Entrance Set-Adjustable Backset 2.15lbs (.98kg)
5245.XXX.RENT Entrance Set-Adjustable Backset 2.15lbs (.98kg)
5245.XXX.FD Full Dummy Set 1.95lbs (.89kg)
Keying: Solid brass 6 pin cylinder, keyed 5 pin
5255.XXX.LENT Entrance Set-Adjustable Backset 2.80lbs (1.27kg)
5255.XXX.RENT Entrance Set-Adjustable Backset 2.80lbs (1.27kg)
5255.XXX.FD Full Dummy Set 2.00lbs (.91kg)
Keying: Solid brass 6 pin cylinder, keyed 5 pin
5270.XXX.LENT Entrance Set-Adjustable Backset 2.95lbs (1.34kg)
5270.XXX.RENT Entrance Set-Adjustable Backset 2.95lbs (1.34kg)
5270.XXX.LFD Left Dummy 2.05lbs (.93kg)
5270.XXX.RFD Right Dummy 2.05lbs (.93kg)
5280.XXX.LENT Entrance Set-Adjustable Backset 2.95lbs (1.34kg)
5280.XXX.RENT Entrance Set-Adjustable Backset 2.95lbs (1.34kg)
5280.XXX.LFD Left Dummy 2.05lbs (.93kg)
5280.XXX.RFD Right Dummy 2.05lbs (.93kg)
Keying: Solid brass 5 pin cylinder
Keying: Solid brass 5 pin cylinder
AVAILABLE IN ALL POPULAR FINISHES
Call For Stocked Finishes
Call For Stocked Finishes
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 107
www.acclock.com
Accredited Lock Supply B
DEADBOLT
FEATURES: All Deadbolts are furnished with a 1" (25mm) throw. Each contains
a saw-proof, hardened steel insert to prevent tampering. Fronts are adjusble for
beveled door conditions. All deadbolts have an adjustable backset feature to ac-
comodate 2 3/8" or 2 3/4" backsets.
PACKED: Without fasteners. Case quantity is twelve (12).
BA8201-003-DB Double Cyl Lifetime Bright Brass 40.00
BA8208-003-DB Single Cyl Lifetime Bright Brass 40.00
BA1035-Square-3.5"x3.5"
BA1041-Square-4"x4"
Part No. Finish Price
BA1035-003 Lifetime Brass 48.00
BA1035-030 Polished Brass 38.00
BA1040-003 Lifetime Brass 51.00
BA1040-030 Polished Brass 41.00
BA1045-003 Lifetime Brass 54.00
BA1045-030 Polished Brass 44.00
Part No. Finish Price
BA1090-003 Lifetime Brass 16.00
BA1091-003 Lifetime Brass 16.00
BA1091-151 Antique Nickel 14.00
BA1092-003 Lifetime Brass 16.00
BA1092-190 Satin Black 14.00
BA1093-003 Lifetime Brass 16.00
BA1093-151 Antique Nickel 14.00
Hinges - Ball Bearing
BA1051-Square-5"x5"
Part No. Finish Price
BA1041-003 Lifetime Brass 60.00
BA1041-030 Polished Brass 50.00
BA1046-003 Lifetime Brass 63.00
BA1046-030 Polished Brass 53.00
BA1051-003 Lifetime Brass 92.00
BA1051-030 Polished Brass 76.00
Hinges
Hinge Finials - are specially designed to thread
into the top & bottom of the hinge barrel.
BA1090 BA1092BA1093 BA1091 Available Finial & Hinge Finishes: 003, 030, 050, 055, 056, 102,
112, 150, 151, 190, 260, 264.
BA1040-Square-4"x4" BA1045-Square-4.5"x4.5"
BA1046-Square-4.5"x4.5"
Go To Table of Contents
108
www.acclock.com
Accredited Lock Supply
B
Part No. Description Backset Retail
BA8011-003 Deadbolt, Double Cylinder 2 3/8" 135.00
BA8011-102 Deadbolt, Double Cylinder 2 3/8" 120.00
BA8011-260 Deadbolt, Double Cylinder 2 3/8" 120.00
BA8011-264 Deadbolt, Double Cylinder 2 3/8" 120.00
BA8013-060 Deadbolt, Double Cylinder 2 3/8" 83.10
BA8013-102 Deadbolt, Double Cylinder 2 3/8" 83.10
BA8013-260 Deadbolt, Double Cylinder 2 3/8" 83.10
BA8013-264 Deadbolt, Double Cylinder 2 3/8" 83.10
BA8015-060 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8015-102 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8015-260 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8015-264 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8017-060 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8017-102 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8017-260 Deadbolt, Double Cylinder 2 3/4" 83.10
BA8017-264 Deadbolt, Double Cylinder 2 3/4" 83.10
Inside
Cylinder
DEADBOLTS
• CASE: Deadbolt case is formed of heavy gauge steel for strength and assures
solid fit in door preparations. Most interior working parts are made of solid brass
for maximum strenghth and smooth operation.
• DEADBOLT: All deadbolts are of solid brass construction. Deadbolt has .625" x
.875" x 1" (16x22x25mm) throw when extended and a hardened steel insert for
maximum protection and security. Deadbolt is furnished in US4 and 26D finishes
to match trim.
• BACKSET: Deadbolts available in 2.375" (60mm) and 2.75" (70mm) backset.
• NON-HANDED design facilitates specification and installation.
• STRIKE: Every deadbolt illustrated in this section is furnished with a specially
designed reinforcing strike constructed of high grade steel for ultimate strength
and durability.
• DOOR CONDITIONS: Deadbolts fit 1.625" (41mm) diameter cutouts. Trim rings
No. 8090 available for doors drilled with 2.125" (54mm) diameter holes.
• DOOR THICKNESS: Deadbolts fit 1.75" (44mm) thick doors. Deadbolts are avail-
able for 2" (51mm) and 2.25" (57mm) thick doors at an additional charge. Door
spacers No. 8097 are available for 1.375" (35mm) thick doors.
Double Cylinder
Contemporary Design
8011 Series
1 5/8" Prep
Steel Case:8011 and 8013 - .960" Diameter x 3.125"(24x79mm)
8015 and 8017 - .960" Diameter x 3.5" (24x89mm)
Front: 8011 and 8015 - .156" x 1" x 2.25" (4x25x57mm)
8013 and 8017 - .156" x 1.125" x 2.25" (4x29x57mm)
DEADBOLTS - 2 1/8" PREP
Traditional Design
Steel Case: .960" diameter x 3.312" or
3.750" extended
Front: .156" x 1" x 2.25"
Backset: Adjustable backset deadbolt,
2 3/8" or 2 3/4"
BA8231-003 Lifetime Brass Finish Single Cyl. 110.00
BA8231-050 Satin Brass & Black Single Cyl. 95.00
BA8231-260 Polished Chromium Single Cyl 95.00
BA8231-102 Oil Rubbed Bronze Single Cyl 95.00
BA8231-150 Satin Nickel Plated Single Cyl 95.00
BA8231-151 Antique Nickel, Dull Single Cyl 95.00
BA8232-003 Lifetime Brass Finish Double Cyl. 135.00
BA8232-260 Polished Chromium Double Cyl 120.00
Contemporary Design
Steel Case: .960" diameter x 3.312" or
3.750" extended
Front: .156" x 1" x 2.25"
Backset: Adjustable backset deadbolt,
2 3/8" or 2 3/4"
CYLINDER COLLAR SPACER FOR 8200 SERIES FOR 1 3/8" DOOR
DIMENSIONS: 2.5" Dia. (64mm)
FEATURES: For installation on 1 3/8" (35mm)
doors. Always used under cylinder collar. Two
rings are required for double cylinder funtions.
One ring is required for cylinder/turnpiece
functions. Finished to match deadbolt cylinder
collar. 1 per box.
BA8297-003 Lifetime Brass 20.00
BA8097-003 Lifetime Brass 15.00 (For 8000 series)
BA8241-003 Lifetime Brass Finish Single Cyl 110.00
BA8241-260 Polished Chromium Single Cyl 95.00
BA8241-102 Oil Rubbed Bronze Single Cyl 95.00
BA8241-150 Satin Nickel Plated Single Cyl 95.00
BA8241-151 Antique Nickel, Dull Single Cyl 95.00
BA8242-003 Lifetime Brass Finish Double Cyl 135.00
BA8242-260 Polished Chromium Double Cyl 120.00
Available Finishes: 003, 031, 038, 050, 055, 056, 060, 102, 112,
150, 151, 190, 260, 264, 402, 412, 452
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 109
www.acclock.com
Accredited Lock Supply B
Part No. Description Backset Retail
BA8021-003 Deadbolt, Double Cylinder 2 3/8" 135.00
BA8021-102 Deadbolt, Double Cylinder 2 3/8" 120.00
BA8021-260 Deadbolt,Double Cylinder 2 3/8" 120.00
BA8023-060 Deadbolt, Double Cylinder 2 3/8" 88.60
BA8023-102 Deadbolt, Double Cylinder 2 3/8" 88.60
BA8023-260 Deadbolt, Double Cylinder 2 3/8" 88.60
BA8025-060 Deadbolt, Double Cylinder 2 3/4" 88.60
BA8025-102 Deadbolt, Double Cylinder 2 3/4" 88.60
BA8025-260 Deadbolt, Double Cylinder 2 3/4" 88.60
BA8027-060 Deadbolt, Double Cylinder 2 3/4" 88.60
BA8027-102 Deadbolt, Double Cylinder 2 3/4" 88.60
BA8027-260 Deadbolt, Double Cylinder 2 3/4" 88.60
Part No. Description Backset Retail
BA8041-003 Deadbolt, Single Cylinder 2 3/4" 110.00
BA8041-150 Deadbolt, Single Cylinder 2 3/4" 95.00
BA8041-151 Deadbolt, Single Cylinder 2 3/4" 95.00
Part No. Description Backset Retail
BA8031-003 Deadbolt, Single Cylinder 2 3/8" 110.00
BA8031-050 Deadbolt, Single Cylinder 2 3/8" 95.00
BA8031-150 Deadbolt, Single Cylinder 2 3/4" 95.00
BA8031-151 Deadbolt, Single Cylinder 2 3/4" 95.00
Cylinder/Turnpiece
Traditional Design
8031 Series
1 5/8" Prep
Inside
Turnpiece
Steel Case: 8031 - .960" Diameter x 3.125"(24x79mm)
Front: 8031 -.156" x 1" x 2.25" (4x25x57mm)
Double Cylinder
Traditional Design
8021 Series
1 5/8" Prep
Steel Case: 8041 -.960" Diameter x 3.312" or 3.75"(24x89 or 95mm)
Front: 8041 -.156" x 1" x 2.25" (4x25x57mm)
Cylinder/Turnpiece
Contemporary Design
8041 Series
1 5/8" Prep
Steel Case: 8021 and 8023- .960" Diameter x 3.125"(24x79mm)
8025 and 8027 -.960" Diameter x 3.5" (24x89mm)
Front: 8021 and 8025 -.156" x 1" x 2.25" (4x25x57mm)
8023 and 8027 - .156" x 1.125" x 2.25" (4x29x57mm)
Inside
Cylinder
TRIM RINGS
DIMENSIONS: 2.5" Dia. (64)mm
FEATURES: Trim rings are designed for
use with installation of 8000 series (1 5/8" door
prep) deadbolts in 2 1/8" diameter door prepara-
tion. One pair of rings is required for use in this
application for either double cylinder or cylinder/
turnpiece functions. Rings are finished match
deadbolts. Packed one pair per box.
Part No. . Finish Retail/pair
BA8090-003 Lifetime Brass 15.00
BA8090-030 Polished Brass 15.00
BA8090-060 Satin Brass/Brown 15.00
BA8090-102 Oil Rubbed Bronze 15.00
BA8090-260 Polished Chromium 15.00
BA8090-264 Satin Chromium 15.00
KEY BLANKS
1.25" width bow designed for the disabled and
handicapped people.
'C' keyway
Nickel Silver 50/box
Part No. Price/ea
BA8335-152 5 Pin 3.00
BA8336-152 6 Pin 3.00
Go To Table of Contents
