ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 275

www.acclock.com

Accredited Lock Supply

STOREFRONT HARDWARE

Ilco® Mortise Locks with Deadbolt, Hookbolt and Deadlatch feature a steel case with corrosion resistant plating. Each style ac-

cepts a standard 1 5/32” (29.4mm) diameter mortise cylinder and can be purchased with one, two or without faceplate.

For narrow jambs and sliding glass doors, the shorter, hook style bolt is used to secure the door.

Deadbolt - 185 Series

360° turn of the key or thumbturn retracts

the bolt. The bolt provides maximum security

on single leaf doors.

• Steel case, corrosion resistant plating

• Available in straight or hook bolt

• Five ply bolt with hardened steel pin,

stainless steel bolt optional

• Accepts standard diameter mortise cyl-

inder or thumbturn

• Aluminum faceplate (at, left or right

bevel, radius, radius w/weather strip)

• Cycle testing exceeds ANSI Grade 1

standards

Sets come with two faceplates. Non-handed.

Deadbolt

P/N Backset Finish List

IL185-F-2NH-628/313 31/32" Aluminum/Dark Bronze 23.38

IL185-F-3NH-628/313 1 1/8" Aluminum/Dark Bronze 23.38

IL185-F-4NH-628/313 1 1/2" Aluminum/Dark Bronze 23.38

Hookbolt

ILHB185-F-2NH-628/313 31/32" Aluminum/Dark Bronze 23.38

ILHB185-F-3NH-628/313 1 1/8" Aluminum/Dark Bronze 23.38

ILHB185-F-4NH-628/313 1 1/2" Aluminum/Dark Bronze 23.38

HB185 185 451

Deadlatch - 451 Series

Offers exibility of trafc control for buildings that require free

entrance during speciﬁc times and exit only at other times. A

reverse turn of the key, while the bolt is retracted, retains the

bolt for two-way trafﬁc.

Interchangeable with the 185 Series Deadbolts.

• Steel case, corrosion resistant plating

• Zinc latch with Delrin insert for quiet operation

• Auxiliary metal latch bolt feature prevents “loiding” or jimmying

• Accepts standard diameter mortise cylinder

• Field reversible handing

• Aluminum faceplate (at, left or right bevel, radius, radius

with weather strip)

• Cycle testing exceeds ANSI Grade 1 standards

Left Hand

P/N Backset Finish List

IL451-F-2LH-628/313 31/32" Aluminum/Dark Bronze 35.00

IL451-F-3LH-628/313 1 1/8" Aluminum/Dark Bronze 35.00

IL451-F-4LH-628/313 1 1/2" Aluminum/Dark Bronze 35.00

Right Hand

IL451-F-2RH-628/313 31/32" Aluminum/Dark Bronze 35.00

IL451-F-3RH-628/313 1 1/8" Aluminum/Dark Bronze 35.00

IL451-F-4RH-628/313 1 1/2" Aluminum/Dark Bronze 35.00

Push/Pull Paddle – 459 Series

Push or pull in the direction of the door swing to unlatch.

• Corrosion resistant extruded aluminum construction

• Escutcheon is zinc alloy with black hard coat nish

• Enhanced double spring construction for durability

• Binder post insures secure attachment of the push/

pull handle to the door

• Self-adhesive Push / Pull decals included

• Field reversible handing using cam plug and Push/Pull

feature

• Cycle testing exceeds ANSI Grade 1 standards

Door Thickness = 1 3/4"

P/N Finish Function List

IL459-01-00-313 Dark Bronze Pull to left 44.80

IL459-01-00-628 Aluminum Pull to left 44.80

IL459-02-00-313 Dark Bronze Push to left 44.80

IL459-02-00-628 Aluminum Push to left 44.80

IL459-03-00-313 Dark Bronze Pull to right 44.80

IL459-03-00-628 Aluminum Pull to right 44.80

IL459-04-00-313 Dark Bronze Push to right 44.80

IL459-04-00-628 Aluminum Push to right 44.80

Lever Handles – 456 Series

This series of lever handles are available in straight and euro return styles.

Downward movement retracts latch.

• Left or Right handing, reversible using the cam plug

• Cast aluminum construction

• Escutcheon assembly includes heat treated spindle

• Cam plug is secured to handle escutcheon with hardened steel pins

Door Thickness = 1 3/4"

P/N Finish List

IL456RE-LH-01-DU Dark Bronze 23.24

IL456RE-LH-01-AL Aluminum 23.24

IL456RE-RH-01-DU Dark Bronze 23.24

IL456RE-RH-01-AL Aluminum 23.24

IL456S-LH-01-DU Dark Bronze 21.84

IL456S-LH-01-AL Aluminum 21.84

IL456S-RH-01-DU Dark Bronze 21.84

IL456S-RH-01-AL Aluminum 21.84

NEW! HEAVY DUTY DEADLATCH 452 SERIES

Easily Re-handed in the Field • Depth Adjusting Tube Spacers

IL452-F-3RH-628/313 1 1/8" Aluminum/Dark Bronze 38.08

Strikes Not

Included

Go To Table of Contents

276

www.acclock.com

Accredited Lock Supply

SPEED 040 AUTOMATIC/MANUAL

ILSPEED040-110

2,53000

SPEED 044 SEMI-AUTOMATIC DUPLICATOR

ILSPEED044-110

2,32000

110VAC

SPEED 045 MANUAL DUPLICATOR

Economical Operation

ILSPEED045-110

1,87000

ILSPEED046-110

1,88000

Same features as above.

Duplicates at steel and bit keys.

BRAVO III w/EZ-JawTM

High quality, semi-automatic professional duplicating machine with four-way jaws

which enable quick and easy duplication of all types of residential, commercial,

padlock and automotive keys without adapter.

Comes with the versatile CU50A cutter and a corresponding cutter guide. The durable

cobalt steel cutter ensures a smooth, clean, accurate cut every time.

• New EZ-JawTM vise mechanism allows the machine operator to switch from one

vise station to another faster, and with minimal effort.

• EZ-JawTM makes it possible to rotate

the vise jaw without having to lift it up...

simply grasp the vise jaw and twist it

to access the vise position desired.

• Features a "soft-touch" deburring

nylon brush.

Dimensions: 10"H x 15"W x 20"D

Weight: 47 Lbs.

Volts: 110/60 Hz, 1/4 HP capacitor start

ILBRAVOIII-USA

4,78600

NEW! Speed 04X Series Performance HD Series

Warranty: Two Years

Design: Open concept for ease of cleaning

Cutter: One style (040, 044, 045) - Stock 1, Service 3 - TiN (Titanium Nitride) coated

Tracer: One standard for all edge cut keys

Brush: 3” (76.2 mm) Nylon, 3/8” (9.525 mm) wide, 5/8” (15.87 mm) bristles,

shielded for safety

Clamps: 4-sided, nickel plated with slotted surface to accommodate tip stop bars

Spacing Between Clamps: 3 1/2", to accomodate large bow and long blade keys

Shoulder Gauge: Spring loaded metal rod with quick adjustable tabs for shoulder

gauging

Cutter Shield: Large shield, storage solution for accessories

Swarf “Chip” Tray: Large tray under carriage

Calibration: Micro-dial type adjustment for precise calibration Increments of

.00098” (0.025mm)

Power Switch: Sealed safety switch; manually re-set the switch after a power

interruption

Mounting Bracket: Included

Cutter Motor: 120V-60Hz, single phase and speed

Tool Speed: 1,404 rpm

18.9"W x 18.5"D x 11.8"H

44 lbs.

22.8"W x 18.1"D x 9.8"H

31 lbs.

18.1"W x 18.1"D x 10.2"H

31 lbs.

Speed 04X Series Mounting Bracket

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 277

www.acclock.com

Accredited Lock Supply

The 009B is an economical solution for duplicating standard tubular keys. It is

easy to set up, simple to operate and provides accurate duplicates in just seconds.

The 009B is simple to operate. It features a unique key positioning device to

assure quick, accurate gauging of the key blank.

 Designed to duplicate "mid size" 7 and 8 cut* tubular keys

 Transparent cover offers clear visibility and protection during the cutting process

 Simple to operate and provides accurate duplicating results

 Durable high torque motor

 Solidly constructed for lasting performance *Not intended for

Motor: 110VAC cutting steel keys

Weight; 8 lbs.

Cutter: 16TW End Mill 14"W x 4.25"D x 4.25"H

 Special vise jaws featuring ratchet type handles

 Spring loaded key guide

 Angles base for easy operation

• Safety light and cutter shroud

A cost-effective method of cutting virtually any detention key. Utilizes the principle

of parallel operating key vises for greater cutting accuracy. A four-way key guide

provides the exibility to make four cut widths in keys. Special vise jaws are preci-

sion engineered to hold keys tight with a minimum of effort. Cuts Folger-Adam,

Adtec and Southern Steel keys. Cuts Folger-Adam Mogul keys by using the optional

"V"-Cutter Kit.

Shipping Weight: 32lbs.

Cutter: CU30-88 Slotter.

Dimensions: 13" (W) x 16" (D) x 10" (H).

Features:

IL031-110

3,37500

O31 DETENTION KEY DUPLICATOR TUBULAR KEY MACHINE

IL009B-110

1,33000

110VAC

ILFLASH008-110

1,05000

SILCA FLASH 008 KEY MACHINE

Manual Duplicator for Edge Cut Keys

UNIVERSAL II CODE CUTTING MACHINE

Voltage: 110VAC/3.5 amps

Motor: 1/4 hp (capacitor start type)

Weight: 37.5 lbs.

Dimensions: 12" W x 14" D x 10" H

Features:

• Utilizes code cards, allowing the operator to change the machine setup quickly

and add new applications at minimal cost

• Easy view code card design enhances accuracy and speed

• Superior dial depth adjustment system provides quicker,more precise calibration

• "Flapper Style" key blank alignement gauge ensures accurate, level key placement

• Titanium nitride coating provides extra long cutter life

• Quick rate depth and spacing drive shafts speed up the key cutting process

• Up-to-date card selection covers current key applications

• Tilting cutter head for making angled cuts on Medeco® keys & similar types

• Capacitor start motor enables use with 12 volt DC power inverters

• Durable powder coat nish

ILUNIVERSALII

4,40200

120 CODE CARDS • T14MC & TCW-1011 CUTTERS INCL • STD & U SHAPED TIP-STOPS

• Large ergonomic jaw (clamp) knobs for ease of clamping with a minimum of force.

• Four sided, nickel plated jaws with tip gauge slots for ease of gauging and clamp-

ing virtually all edge cut keys presently on the market.

• 3½” spacing between clamps allows clamping of keys with large bows (heads),

long blades and ip style automotive keys.

• Smooth rotation of jaws by simply loosening the knob and twisting into position.

• Carriage handle and rotating knob ensure precise horizontal movements (the

carriage can also be easily moved manually)

• Teon® coated carriage shaft bushings guarantee a smoother, quieter movement.

• Depth tracer with micro adjustment system for fast, precise calibration

• AlTiN coated cutter for longer life (almost double that of the 008B) and oxidation

resistance.

• Motor is within the housing making the cutting operation quieter.

• Increased motor power and longer life.

• Key gauge is more rigid and accurate.

• Rigid carriage to reduce vibration during the key cutting process.

• Electro-magnetic safety switch (machine must be manually re-started after a power

interruption) with easy switch access.

• Mounting bracket included for securing the machine to a work bench.

• Two year warranty vs. one year on the 008B model.

Go To Table of Contents

278

www.acclock.com

Accredited Lock Supply

THE MATRIX II

ILMATRIX II 5892.00

TWISTER II AUTOMOTIVE HI-SECURITY KEYS DUPLICATOR

ILTWISTER II Hi-Security Key Duplicator 3402.00

EZ®-CODE II

ILEZ®-CODE II

10,20000

SILCA TRI-CODE H/S

Electronic Code Cutting of Automotive High Security Keys

The Triax H/S cuts laser type high

security automotive keys by code,

bitting # or duplication. It is simple to

operate and eliminates the guess work

and effort involved with cutting laser

type automotive keys. The keys being

duplicated are automatically decoded

for depth of cut and spacing. If wear

is detected, the machine converts back

to original factory speciﬁcations. The

Triax H/S comes with a full 3 year fac-

tory warranty from date of purchase.

• Fast, easy to operate

• Automatic compensation for worn cuts

• Electronically controlled operation

• Internal database contains key codes and

cut speciﬁcations for almost any automo-

tive "Laser Key" application

• Automatic "hands free" calibration

ILTRI-CODE-H.S.-110V With H101 Cobalt Tool 17,590.00

Steel Cutter

The Kreate-A-KeyTM Software Program is the easiest

way to make keys by code. Forget the hassels with using

codebooks and cards... IIco just made your life easier.

ILKREATE-A-KEY 1,714.28

The Matrix II is a new and improved re-design of the

Matrix S machine that has been offered by Ilco since

1994. Just as with the previous generation, the Matrix II

combines rugged construction, precision and features

that have made it the professional’s choice in laser

style key duplication.

The Matrix II will offer the following new improvements

from the previous model for your customers interested

in a premium duplicator for laser keys.

• Electromechanical calibration with alarm to indicate

when properly calibrated

• Micrometer calibrating dial (tracer side, placed out of

the working area, above the protective shield)

• LED lighting of work area with manual on-off switch

above the cutting area

• Wider transparent safety shield minimizes exposure to moving parts and chips

during operation.

• Convenient built-in storage tray on hood of machine for key blanks or tools

• Cutter motor does not start until the Z-axis lever is lowered and stops when it is

raised for additional safety

• Quiet cutting cycle

• HSS cutters and tracers with a new alloy composition to improve cutter life

• Colored plastic collars (red on cutters and black on tracers) have cutter and tracer

numbers on collars for easy identiﬁcation

• Larger tool and accessory pull out storage drawer

Kaba Ilco Corp. is pleased to introduce

the second generation Ilco EZ®-Code. The

Ilco EZ®-Code II looks the same as the ﬁrst

generation. The difference is in the many

hardware and ﬁrmware changes made to

accommodate the OEM Keys from Asia.

The more noticeable improvements found

in the Ilco EZ®-Code II are the elimination

of backlash and minimization of stepper

motor slippage to ensure synchronized

movements of components when cutting

keys made of harder materials. These changes also yield a more accurate mea-

surement when calibrating the machine and when using the duplication feature.

In addition to hardware and ﬁrmware updates, the entire database has been revised

to ensure accuracy of the bitting information. Rather than relying on an electrical

contact to determine the reference point to begin cutting a key, the Ilco EZ®-Code

II uses a hard ﬁxed datum for reference, resulting in more accurately cut keys.

New Duplication Feature – the Ilco EZ®-Code II will have the capability to duplicate

a key back to factory speciﬁcations or duplicate as measured. Once the pattern

key is measured it allows the user to select the option of (1) USE CARD DEPTHS

which would cut the key to OEM speciﬁcations or (2) USE MEASURED DEPTHS

which would duplicate the key based on the actual measurements of the pattern key.

Kaba Ilco Corp. is pleased to introduce the

Twister II, an economical manual key cutting

machine for duplicating a wide range of “la-

ser” (sidewinder), at cut dimple and Fichet®

type keys. Optional accessories expand the

capability of the Twister II to duplicate tubular

and Ford® Tibbe® keys.

The Twister II will offer the following beneﬁts

for your customers interested in a manual

duplicator:

• Spring loaded tracer point for duplication

of dimple keys with at cuts.

• Standard accessories include a HSS 2.5mm

cutter and tracer for laser keys and a second

HSS .65mm cutter and tracer used for a

wide variety of dimple keys with at cuts

• Optional cutters, tracers, and accessories

expand the range of keys that can be duplicated

• Small footprint (9.8” W x 14.6” D x 14.6”

H - 250mm W x 370mm D x 370mm H)

• LED lighting of work area

• Wide transparent safety shield minimizes exposure to moving parts and chips

during operation

• Master Safety Switch with separate cutter motor switch.

• Quiet cutting cycle

• Replaceable jaw surface plates provide an economical repair solution for normal

vise jaw wear.

• Lockable carriage for cutting dimple keys and to prevent movement during transport

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 279

www.acclock.com

Accredited Lock Supply A

The UC199 performs high quality key duplication

from the original key, copies with adjustments (Stand

Alone Mode) or by code and decoding (PC Mode)

with Ilco Kreate-A-Key™ program

It combines precision and ease of use and offers

high quality results due to it’s innovative functions

and laser technology.

UNOCODE 199 ELECTRONIC KEY

DUPLICATING MACHINE

• Precise duplication with the electronic optical reader

• Compact and ergonomic shape

• High quality carbide cutter (standard)

• Two types of uses: Stand-Alone and PC driven

• Fast key cutting cycle

• Semi-automatic gauging function for both standard and automatic clamp

• Communication with Ilco Kreate-A-Key™ and other software programs in the

industry

• Web updates available for Kreate-A-Key™

ILUNOCODE

16,20000

FUTURA PRO- THE ULTIMATE ELECTRONIC KEY MACHINE

ILFUTURAPRO

16,80000

The original Futura electronic key cutting machine was the ﬁrst machine on the market

to combine two cutting stations in one user-friendly device. Now, the Futura Pro

delivers even more including faster cutting cycles and a new tablet with upgraded

electronics and software for faster response times on the new tablet.

Futura Pro is a powerful machine for the professional key cutters yet also ideal for the

less experienced users with step-by-step prompts throughout the cutting processes.

Ultramodern in design and engineered to the highest quality standards; you can

be assured of the most accurate, precise cutting of a variety of key styles on one

innovative, amazing machine.

Work Efﬁciencies

• Faster cutting cycles with a motor that delivers up to three times more power

and cutters that reach speeds of 1,585 rpm for edge cut keys and 12,100 rpm for

laser and dimple keys

• The tablet together with upgraded electronics delivers quick start up, faster response

times and an all-round improvement in the machine performance.

• Two USB ports; one for charging the tablet and a second port is used to tether

the tablet. The tethering connection allows the Futura Pro and tablet to remain

connected and operational even when the Wiﬁ connection is unstable or lost. The

second port may also be used to connect the USB ash drive (supplied) to import

code tables or for machine software updates.

• New tip stop tool for the edge cut clamp station to be used in position 4

• Kreate-A-Key/Instacode Interface is included

• Interchangeable jaws on the Laser/Dimple clamp station saves time and reduces

cost.

• LED color changing lights indicate the status of the cutting process (white=ready,

yellow, cutting in process, green=cutting complete).

• Carbide laser cutter for longer life cycle.

• Stainless steel exposed screws resist wear.

• Ergonomic clamp handle design offers a comfort grip and holds keys securely

on the edge cut side.

• Built-in hood accessory tray for easy access to tools and/or keys

• Multi-language support

One Machine with Two Cutters and Two Clamps...

Two cutting stations: one for edge cut and cruciform style keys, and one for laser

and dimple keys. The wide range of optional accessories will further increase

capabilities to duplicate tubular, Tibbe® style keys, and more.

Edge Cut and Cruciform Station

• Decode via optical reader to OEM specications

• Copy by original function via optical reader for an exact duplicate of the original

• Guided calibration of the cutting station.

• Durable, long lasting HSS (High Speed Steel) milling cutter

• Four position, quick rotating jaw (clamp) accommodates a wide variety of keys

• Ergonomic clamp handle to easily tighten the key securely in place.

• Automotive keys and most residential keys cut in one smooth pass.

Laser and Dimple station

• Decode and copy by electrical contact to OEM specications

• Automatic Calibration

• Interchangeable clamp jaws

• 01J, 02J and 19J jaws included will accommodate all North American laser

style keys with the exception of BMW and Mercede (requires optional 04J jaw)

• Durable carbide laser cutter

• Expand capabilities to include Tibbe®, tubular and other keys with optional ac-

cessories.

Go To Table of Contents

280

www.acclock.com

Accredited Lock Supply

ELECTRONIC KEYS

EH3 EH3LB EH3P GTH

EB3-A-Y160*† EB3-B-H72* EB3-C-H73* EB3-D-H84* EB3-E-TOY43* EB3-F-TOY48*† EB3-G-TOY40*† EB3-H-NI02*† EB3-J-MAZ24* EB3-K-MIT8* EB3-L-MIT9*†

EB3-M-MIT14*† EB3-N-SUB1* EB3-P-SUB4* EB3-R-B111† EB3-S-HOO3† EB3-T-Y170† EB3-U-HD111† EB3-V-HU100† EB3-W-B114R† EB3-X-GM45† EB3-Z-HU64†

ILEB3-A-Y160 Chrysler Electronic Key Blade 7.90

ILEB3-B-H72 Ford Electronic Key Blade 7.90

ILEB3-C-H73 Ford Electronic Key Blade 7.90

ILEB3-D-H84 Ford Electronic Key Blade 7.90

ILEB3-E-TOY43 Toyota Electronic Key Blade 7.90

ILEB3-F-TOY48 Toyota Electronic Key Blade 7.90

ILEB3-G-TOY40 Toyota Electronic Key Blade 7.90

ILEB3-H-NI02 Nissan Electronic Key Blade 7.90

ILEB3-J-MAZ24 Mazda Electronic Key Blade 7.90

ILEB3-K-MIT8 Mitsubishi Electronic Key Blade 7.90

ILEB3-L-MIT9 Mitsubishi Electronic Key Blade 7.90

ILEB3-M-MIT14 Mitsubishi Electronic Key Blade 7.90

ILEB3-N-SUB1 Subaru Electronic Key Blade 7.90

ILEB3-P-SUB4 Subaru Electronic Key Blade 7.90

ILEB3-R-B111 GM Electronic Key Blade 7.90

ILEB3-S-HOO3 Honda Electronic Key Blade 7.90

ILEB3-T-Y170 Chrysler Electronic Key Blade 7.90

ILEB3-U-HD111 Acura Electronic Key Blade 7.90

ILEB3-V-HU100 GM Electronic Key Blade 7.90

ILEB3-W-B114R Saturn Electronic Key Blade 7.90

ILEB3-X-GM45 Pontiac Electronic Key Blade 7.90

ILEB3-Z-HU64 Sprinter Electronic Key Blade 7.90

H003-GTS Honda Look Alike® Shell 5.90

MAZ24R-GTS Mazda Look Alike® Shell 5.90

TOY43-GTS Toyota Look Alike® Shell 5.90

H72-GTS Ford Look Alike® Shell 5.90

H84-GTS Ford Look Alike® Shell 5.90

NI02-GTS Nissan Look Alike® Shell 5.90

B111-GTS GM Look Alike® Shell 5.90

Y160-GTS Chrysler Look Alike® Shell 5.90

FO21-GTS Ford/Jaguar Look Alike® Shell 5.90

SIP22-GTS Fiat Look Alike® Shell 5.90

TOY40B-GTS Lexus Look Alike® Shell 5.90

KW16-GTS Kawasaki Look Alike® Shell 5.90

SZ17R-GTS Suzuki Look Alike® Shell 5.90

KIA3R-GTS Kia/Hyundai Look Alike® Shell 5.90

HU101-GTS Ford/Land Rover Look Alike® Shell 5.90

HYN6-GTS Hyundai/Kia Look Alike® Shell 5.90

HYN14R-GTS Hyundai/Kia Look Alike® Shell 5.90

VA2-GTS Smart Fortwo Look Alike® Shell 5.90

Order No. Description Price

H003-GTS MAZ24R-GTS TOY43-GTS H72-GTS H84-GTS NI02-GTS B111-GTS Y160-GTS FO21-GTS

SIP22-GTS TOY40B-GTS KW16-GTS SZ17R-GTS KIA3R-GTS HU101-GTS HYN6-GTS HYN14R-GTS VA2-GTS

ILEH3 Electronic Key head (Uses blades with ‘*‘) 53.00

ILEH3LB Electronic Key Head less battery 53.00

ILEH3P Electronic Key head (Uses blades with ‘†’) 53.00

ILGTH Electronic Key head (Uses all blades) 58.00

ILGTI GTI Multi Transponder 53.00

Order No. Description Price

Order No. Description Price Order No. Description Price

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 281

www.acclock.com

Accredited Lock Supply

ILRW4-PLUS

5,00000

ILMBOXSNOOP

1,49800

RW4-PLUS w/SNOOP

Designed for professional use, the RW4 PLUS lets you take control of Texas Instruments (TI) and Philips encrypted

code and xed code transponder keys. When the RW4 PLUS is utilized in conjuction with Ilco® electronic keys,

you can eliminate the two master (original) key requirements for "on-board" programming. It is a stand-alone devce

with no PC, internet connection or additional software required.

• Includes Snoop (for Philips Cloning); Captures the communications between the vehicle and the keys

• Clones TI and Philips encrypted code and xed code (T2, T5) transponder keys

• Software updated are based on new vehicle information & technology

• Identies presence of a transponder and indicates chip type

• Code generation capable

• Archiving function

• Easy to read LCD screen

• Free updates for one year from purchase

• Multiple language support

• Built in "Soft Touch" keypad

• 12V DC power adapter included

• USB and Serial Port

15 VDC Power Supply

Speciﬁcations:

Dimensions: 6.5"D x 9.5"W x 3.25"H (16.5cm x 24.1cm x 8.26cm)

Weight: .61 lbs. (.27kg)

We Stock the Entire Line of Ilco Transponder Equipment & Keys

Modernize Your Automotive Capabilities With Accredited Lock Supply and Ilco

PLUS Box

Update Your RW4 to Clone Philips Encrypted Keys

Clone Philips Encrypted

transponder keys. By

combining the Plus-Box

with the RW4 and adding

Ilco Electronic Keys, you

can eliminate the need

for 2 master (original)

keys that are required for

"on-board" programming,

or a lengthy programming

cycle.

• Easily attaches to the bottom of existing RW4

• No loose cables or modules to be damaged or lost

Includes:

SNOOP

Serial Cable

Power Supply

Transponder Program Software

Speciﬁcations:

Dimensions: 6.25"D x 9.625"W x 1.5"H (15.88cm x 24.45cm x 3.81cm)

Weight: 1 lbs. (.45kg)

ILRW4-PLUSBOX

2,78100

The Ilco ID48 Complete Cloning Solution adds the capability to clone Megamos®

Encrypted (ID48) transponder keys increasing the Ilco cloning system’s capability

up to 95% of the vehicles on the road today.

The Ilco ID48 Compete Cloning Solution consists of the M-Box, which is added to

the existing Ilco/Silca brand Cloning system* and a simple software upgrade. The

kit includes the new M-Snoop, which is the only device on the market today that

can read original key data without the need for cutting a new key.

A PC or ﬁxed Internet connection is not required to clone. Cloning can be done via

a smartphone or tablet’s hotspot function.

The new T48 glass transponder, which ﬁts original keys and remotes as well as Ilco

replacement vehicle keys, is then used to complete the cloning process.

* RW4 Plus, Ilco EZ®-Clone Plus, RW4 with Plus Box, Ilco EZ®-Clone with Plus Box

ID48 COMPLETE CLONING SOLUTION

ILT48

Transponder Chip

3500

Go To Table of Contents

282

www.acclock.com

Accredited Lock Supply

The T-Code Pro is the leading vehicle key and

remote programmer for most vehicle makes

and models worldwide. Designed and engi-

neered in the UK by Advanced Diagnostics,

the pioneering and trustworthy manufacturer

for aftermarket key programming tools, the

T-Code Pro is ideal for auto technicians and

locksmiths providing high quality key and re-

mote programming services. All new software

developed in the future must be purchased

from your local distributor.

• Read and clear fault codes

• Clear key memory

• Program keys, proximity keys, smart keys,

ip keys, remotes

• Program aftermarket and OEM keys and fobs

• Read immobilizer pin codes

• Read pre-code data

• Display live data

• Component actuation

• ECU identication

• Simple user interface

Some of the functions above are make/model

dependent

TCode Pro

ILTCODEPRO

Pro Master KIt

17,99000

If you are new to the industry or simply

looking for a cost effective way to offer a key

programming service to your customers, then

the MVP Pro is the solution. Designed and en-

gineered in the UK by Advanced Diagnostics,

the pioneering and trustworthy manufacturer

for after- market key programming tools, the

MVP Pro is ideal for auto technicians and lock-

smiths providing high quality key and remote

programming services on a ‘pay as you go’

basis. All new software is free. Additional

“tokens” can be purchased from your local

distributor. In general, it only takes one token

per job.

MVP Pro

• Read and clear fault codes

• Clear key memory

• Program keys, proximity keys, smart keys,

ip keys, remotes

• Program aftermarket and OEM keys and fobs

• Read immobilizer pin codes

• Read pre-code data

• Display live data

• Component actuation

• ECU identication

• Simple user interface

Some of the functions above are make/model

dependent

ILMVPPRO

Pro Machine w/10

tokens

7,69500

The innovative Smart Dongle designed by Advanced Diag-

nostics has many features and beneﬁts for the automotive

locksmith providing a unique solution that replaces the

current range of dongles with one automatic conﬁgurable

dongle. Smart Dongle is suitable for use with the T-Code

Pro and the MVP Pro.

• Automatically congures programmer for car key /

remote programming

• Replaces current range of dongles (except Dongle B)

• Can be used on all makes of cars worldwide

• User-friendly and portable

• Integrated smartcard / calculator security

• Integrated Nissan® and Hyundai® / Kia® PIN Code

Dongles**

• Expansion port for additional hardware:

• Smart EEPROM Reader*

• Smart Aerial for transponder reading and pre-coding*

* Optional modules - additional costs apply.

** Existing ADC198 and ADC190 customers

will have this functionality added free.

ILADC-240

Smart Dongle

1,39800

SMART DONGLE TOKEN PACKAGES

(No, they're not really

something you can hold

in your hand.)

Tokens, for use on the MVP

programmer.

ILMVP-TK10 Ten Tokens 800.00

ILMVP-TK25 Twenty-ﬁve Tokens 1650.00

ILMVO-TK50 Fifty Tokens 2700.00

ILMVP-TK250 Two hundred and ﬁfty Tokens 6500.00

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 283

www.acclock.com

Accredited Lock Supply A

B111-PT Y160-PT

NI04T

HD106-PT5H72-PT HY021-PT MIT14-PT TOY57-PT Y165-PT

WE STOCK ILCO TRANSPONDER KEYS

GM LIST

ILB103-PT 18.90

ILB103-PT5 18.90

ILB111-PT Circle + 14.14

ILB112-PT PK+ 25.50

ILB119-PT 27.20

ILB120-PT 15.40

ILB97-PT GM Master 11.90

ILB97-PT5 GM Master 11.90

ILB99-PT GM Master 12.32

ILB99-PT5 GM Master 12.32

ILPT04-PT/B107-PT 04 Grand Prix 16.88

ILPT04-PT5/B107-PT5 04 Grand Prix 16.34

DAEWOO

ILDWO4RT5 Daewoo Nubia 26.60

ILDWO5RT5 Daewoo Lanos 26.60

ILDWO5T5 Daewoo Leganza 26.60

FORD

ILH72-PT 9.10

ILH72-PT-CLEAR 10.40

ILH73-PT 16.20

ILH74-PT 14.58

ILH82-PT Lincoln Valet 17.50

ILH84-PT 21.00

ILH86-PT Focus, Escape, Tribute 14.58

HONDA

ILHD106-PT 14.84

ILHD106-PT5 14.84

ILHO01-PT 18.90

ILHO01-PT5 18.64

ILHO03-PT 20.12

ILHO05-PT 2013-2016 27.00

EUROPEAN

ILHU46T2 Opel 33.60

ILHU66AT6 Audi 29.70

ILHU66T24 VW 49.00

HYUNDAI LIST

ILHY20-PT Azera 21.20

ILHY021-PT 24.98

ILHY022-PT 24.98

MAZDA

ILMAZ24RT5 18.64

MITSUBISHI

ILMIT12-PT 21.20

ILMIT13-PT 21.20

ILMIT14-PT 23.76

ILMIT17A-PT 21.20

ILMIT8-PT Diamante/M 21.20

ILMIT9-PT Galant/ECL 19.30

NISSAN

ILNI01T 18.76

ILNI02T 14.00

ILNI04T 20.38

ILNI05T Emergency Key 38.48

ILNI06P Chipless Emergency Key 20.12

ILNSN11T2 Nissan Eur w/Trans-SI 22.28

TOYOTA

ILTOY40BT4 Lexus 24.30

ILTOY43AT4 18.64

ILTOY44D-PT 32.00

ILTOY44G-PT "G" Transponder Key 32.00

ILTOY48BT4 Lexus 29.70

ILTOY50-PT Lexus 30.50

ILTOY57-PT 21.74

CHRYSLER

ILY160-PT 16.20

ILY164-PT 15.94

ILY165-PT 23.00

ILY170-PT Emergency Pod Key 25.78

ILY171-P Emergency "J" Key 18.90

More Transponder Keys in Stock -

Call For Your Requirements

Go To Table of Contents

284

www.acclock.com

Accredited Lock Supply

TITANIUM NITRIDE COATED MILLING CUTTERS

The Toughest Cutters at an Affordable Price

The best value in key machine cutters,

the titanium nitride coating provides a

smoother, sharper cutting edge. With

a useful life 3 times longer than high

speed steel, these cutters will get the

job done with precision and economy.

Advantages of

Titanium Nitride

Coated Cutters

 Last up to 3 times

longer than regular

cutters

 Provides a smoother,

better cutting edge

 Cut downtime

 Affordable value

Code Dia. Thick/mm. Hole Dia. Price Use

ILP-19MC 2 7/8" 7.14 1/2" 197.00 ILCO 2183DM, 218HM, 010-006; KIEL 1, 1 1/2 10

ILP-34MC 2 1/4" 6.35 1/2" 190.72 ILCO 2585DU, H2584CV, 2184CD; KIEL 4 1/2, 12 1/2, 13 1/2, 15

ILP-9MC 2 7/8" 5.23 1/2" 232.00 ILCO 016, 017, 018

ILP-X23MC 2 1/4" 6.35 1/2" 186.78 ILCO 2184CD, H2584CV, 2585DU, 008, 190, DL 145,145M, 147M

149M; HPC 9100, 9110; TAYLOR KD1, KD5, KD20;

KIEL 4 1/2, 12 1/2 ,13 1/2; CURTIS 2000

ILP-45SMS 2 3/8" .045 1/2" 242.58 ILCO 2584SMS,H2585SMS,2184CD,2584CV;HPC 9110, KEIL12S,

12 1/2S, 15S 15 1/2S

CUTTERS KEY MACHINES CODE CUTTER

Milling Manual

ILEK3RT

10820

ENGRAVE-IT PRO

Capable of using either a "diamond

drag" or rotary cutter engraving

process, the Engrave-It PRO lets the

operator select the style best suited

to the items they need to mark. Using

its powerful engraving software (and

customer supplied PC) an operator

can quickly pick from a range of com-

mon tasks (engrave keys, cylinders,

etc.) or create their own custom

settings for additional item types.

Durable and versatile, the Engrae-It

PRO delivers professional results.

ILENGRAVE-IT-PRO

18,72938

EK3 DISASSEMBLY TOOL

Reduce potential damage to the components of electronic two-

part keys while trying to disassemble. The handy EK3 Disas-

sembly Tool is a compact, affordable tool that will separate the

two-piece keys in seconds.

• Affordable, compact design

• Quickly disassembles two-piece electronic keys

• No damage to key components

• Accomodates the most popular two-piece electronic key designs with "snap tabs"

• The only electronic key disassembly tool on the market

• Made in the USA

• Makes battery replacement easy

Speciﬁcations:

Dimensions: 2.25"L x 2.75"W x 3.25"H (5.7cm x 7cm x 8.3cm)

Weight: 1 lbs. (.45kg)

• Capable of marking keys, typical lock cylinders (including IC), padlocks, I.D. plates/

tags, laminates, and other commonly marked items

• Excellent marking quality; suitable for virtually any application

• Capable of ne quality engraving of presentation plaques, etc.

• Provides various fonts and marking styles

• Engraves using either "diamond drag" or rotary cutter process

• Various clamping options provided to secure items being engraved

• Powerful engraving software: simplies common tasks and provides versatility

for more advanced projects

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 285

www.acclock.com

Accredited Lock Supply

CUTTERS

ILCO® brand cutters are Number One among locksmiths because they are scientifcally engineered and carefully crafteed from the ﬁnest materials. Each cutter passes

rigorous quality control inspections before leaving the plant and delivers accuracy, speed and value in key cutting operations.

CUTTERS

Milling Side Milling Slotter

MILLING CUTTERS

High Speed Steel

Code Dia. Thick/mm. Hole Dia. Price Use

IL10MC 2 3/4" 7.11 7/8" 280.42 DL 125A, 130AM, 132AM, 150AM, 128AM, 128SM

IL11MC 2 1/4" 7.36 1/2" 248.14 DL 144M, 144MA, ILCO 024; TAYLOR 144MT-A

IL14MC 2 3/8" 9.52 3/8" 263.86 ILCO 2178U, 2178UA, 2178UC, 178U; HPC 1200CM

IL19MC 2 7/8" 7.14 1/2" 148.86 ILCO 2183DM, 2183HM, 010-006; KIEL 1 , 1 1/2, 10

ILX23MC 2 3/8" 2.36 1/2" 143.58 DL 143M, 145M; TAYLOR 145MT-A;

IL34MC 2 1/4" 6.35 1/2" 115.00 ILCO 2585DU,H2584CV,2184CD; KIEL 4 1/2, 12 1/2, 13 1/2, 15

IL37MC 2 1/4" 5.08 1/2" 301.72 ILCO 2184CD, 2585DU; HPC 9100, 9110; DL 135, 135M 145,

145M; TAYLOR KD5

Tungsten Steel

Code Dia. Thick/mm. Hole Dia. Price Use

IL9MC 2 7/8" 5.23 1/2" 191.00 ILCO 016, 017, 018

FINE MILLING CUTTER (ROTARY FILE)

Tungsten Steel

Code Dia Thick/mm. Hole Dia. Price Use

IL23RF 2 1/4" 6.35 1/2" 83.70 ILCO 2184CD, H2584CV, 2585DU,008,190,DL145,145M, 147M,

149M; HPC 9100, 9110; TAYLOR KD1, KD5,

KD20; KIEL 4 1/2, 12 1/2, 13 1/2; CURTIS 2000

IL5RF 2 3/8" 4.75 3/8" 71.50 ILCO 2177-ID, 2175-IA

SIDE MILLNG SLOTTER CUTTER

High Speed Steel

Code Dia. Thick/mm. Hole Dia. Price Use

IL30SMS 2 3/8" .76 1/2" 109.14 ILCO H258SMS, 2184CD, 2584CV,HPC 9110;KEIL 12S,12 1/2S,

15S. 15 1/2S

IL45SMS 2 3/8" .045 1/2" 156.72 ILCO 2584SMS, H2585SMS, 2184CD, 2584CV; HPC 9110;

KEIL 12S, 12 1/2S, 15S, 15 1/2S

SLOTTER CUTTER

High Speed Steel

Code Dia Thick/mm. Hole Dia. Price Use

IL27 2 1/4" 1.14 1/2" 75.28 ILCO 2184CD, H258CV; DL 146 146M, HPC 9100, 9110;

TAYLOR KD1; KIEL 4 1/2, 12 1/2

IL3FS-HS 2 1/2" 1.40 3/8" 69.42 ILCO 2177-ID, 2179-IM, 2175-IA, 178U

SILCA CUTTERS

Code Price Use

SLD700875ZB 245.70 Bravo USA, Rekord 2000, Poker Plus, Rekord Plus

SLCU50A 308.00 Bravo II, Bravo III

SLD911868ZR 226.28 Delta, Delta Plus

SLD401866ZZ 153.90 Scout

SLD706766ZB 271.42 Cadet

SLD716549ZB 324.42 Ultracode, EZ®-Code

SLD705933ZB 1120.00 Unocode (carbide)

Go To Table of Contents

286

www.acclock.com

Accredited Lock Supply

ILFJ-DDGA44-BLACK JACKET,CHRYSLER 4 BUTTON IRKE

ILFJ-DDGA44-BLUE JACKET,CHRYSLER 4 BUTTON IRKE

ILFJ-DDGA44-PINK JACKET,CHRYSLER 4 BUTTON IRKE

ILFJ-DDGA55-BLACK JACKET,CHRYSLER 3 BUTTON IRKE

ILFJ-DDGA55-BLUE JACKET,CHRYSLER 3 BUTTON IRKE

ILFJ-DDGA55-PINK JACKET,CHRYSLER 3 BUTTON IRKE

ILFJ-DDGA66-BLACK JACKET,CHRYSLR 4-7 BUTTON IRKE

ILFJ-DDGA66-BLUE JACKET,CHRYSLR 4-7 BUTTON IRKE

ILFJ-DDGA66-PINK JACKET,CHRYSLR 4-7 BUTTON IRKE

ILFJ-FRDB13-BLACK JACKET,FORD 3 BUTTON IRKE

ILFJ-FRDB13-BLUE JACKET,FORD 3 BUTTON IRKE

ILFJ-FRDB13-PINK JACKET,FORD 3 BUTTON IRKE

ILFJ-FRDB24-BLACK JACKET,FORD 4 BUTTON RKE

ILFJ-FRDB24-BLUE JACKET,FORD 4 BUTTON RKE

ILFJ-FRDB24-PINK JACKET,FORD 4 BUTTON RKE

ILFJ-FRDB34-BLACK JACKET,FORD 4 BUTTON IRKE

ILFJ-FRDB34-BLUE JACKET,FORD 4 BUTTON IRKE

ILFJ-FRDB34-PINK JACKET,FORD 4 BUTTON IRKE

ILFJ-GMC13-BLACK JACKET, GM 3 BUTTON RKE

ILFJ-GMC13-BLUE JACKET, GM 3 BUTTON RKE

ILFJ-GMC13-PINK JACKET, GM 3 BUTTON RKE

ILFJ-GMC24-BLACK JACKET, GM 4 BUTTON RKE

ILFJ-GMC24-BLUE JACKET, GM 4 BUTTON RKE

ILFJ-GMC24-PINK JACKET, GM 4 BUTTON RKE

ILFJ-GMC34-BLACK JACKET, GM 4 BUTTON RKE

ILFJ-GMC34-BLUE JACKET, GM 4 BUTTON RKE

ILFJ-GMC34-PINK JACKET, GM 4 BUTTON RKE

ILFJ-GMC55-BLACK JACKET, GM 5 BUTTON RKE

ILFJ-GMC55-BLUE JACKET, GM 5 BUTTON RKE

ILFJ-GMC55-PINK JACKET, GM 5 BUTTON RKE

ILFJ-HNDAD33-BLACK JACKET, HONDA 3 BUTTON IRKE

ILFJ-HNDAD33-BLUE JACKET, HONDA 3 BUTTON IRKE

ILFJ-HNDAD33-PINK JACKET, HONDA 3 BUTTON IRKE

ILFJ-HNDAD44-BLACK JACKET, HONDA 4 BUTTON IRKE

ILFJ-HNDAD44-BLUE JACKET, HONDA 4 BUTTON IRKE

ILFJ-HNDAD44-PINK JACKET, HONDA 4 BUTTON IRKE

ILFJ-HYKIK23-BLACK JACKET,HYNDAI/KIA 3 BUTTON RKE

ILFJ-HYKIK23-BLUE JACKET,HYNDAI/KIA 3 BUTTON RKE

ILFJ-HYKIK23-PINK JACKET,HYNDAI/KIA 3 BUTTON RKE

ILFJ-LXUSI23-BLACK JACKET, LEXUS 3 BUTTON IRKE

ILFJ-LXUSI23-BLUE JACKET, LEXUS 3 BUTTON IRKE

ILFJ-LXUSI23-PINK JACKET, LEXUS 3 BUTTON IRKE

ILFJ-NSSNF13-BLACK JACKET, NISSAN 3 BUTTON RKE

ILFJ-NSSNF13-BLUE JACKET, NISSAN 3 BUTTON RKE

ILFJ-NSSNF13-PINK JACKET, NISSAN 3 BUTTON RKE

ILFJ-NSSNF24-BLACK JACKET, NISSAN 4 BUTTON RKE

ILFJ-NSSNF24-BLUE JACKET, NISSAN 4 BUTTON RKE

ILFJ-NSSNF24-PINK JACKET, NISSAN 4 BUTTON RKE

ILFJ-NSSNF44-BLACK JACKET, NISSAN 4 BUTTON PROX

ILFJ-NSSNF44-BLUE JACKET, NISSAN 4 BUTTON PROX

ILFJ-NSSNF44-PINK JACKET, NISSAN 4 BUTTON PROX

ILFJ-TOYTAG12-BLACK JACKET, TOYOTA 2 BUTTON RKE

ILFJ-TOYTAG12-BLUE JACKET, TOYOTA 2 BUTTON RKE

ILFJ-TOYTAG12-PINK JACKET, TOYOTA 2 BUTTON RKE

ILFJ-TOYTAG23-BLACK JACKET, TOYOTA 3 BUTTON RKE

ILFJ-TOYTAG23-BLUE JACKET, TOYOTA 3 BUTTON RKE

ILFJ-TOYTAG23-PINK JACKET, TOYOTA 3 BUTTON RKE

ILFJ-TOYTAG64-BLACK JACKET, TOYOTA 4 BUTTON IRKE

ILFJ-TOYTAG64-BLUE JACKET, TOYOTA 4 BUTTON IRKE

ILFJ-TOYTAG64-PINK JACKET, TOYOTA 4 BUTTON IRKE

Automotive fobs are expensive to replace!

Protect them with stylish remote fob jackets.

Constructed of Silicone rubber, The Jacket Auto

Remote Cover™ provides a custom ﬁt for a

variety of factory remotes. The affordable price

point makes this a perfect choice for consumer

impulse purchase.

THE JACKET AUTO REMOTE COVER™

The Jacket Auto Remote Cover™ provides pro-

tection for expensive automotive remote FOBS

from wear, scratches and breaks. Jackets are

made of lightweight silicone, much like the

protective cell phone covers that are popular with

consumers.

Unlike competitive products that are limited to a

few generic styles, The Jacket has been designed

to provide a “snug”, custom t for FOBS.

20 different styles are available, each in 3 popular

colors (Black, Blue, Pink). The Jacket Auto

Remote Cover™ may be purchased individually,

in a box containing 6 pieces (same style and

color), or choose from three assortments.

1090 ea

Master Distributor of the Complete Line of ILCO Keyblanks. Over 5,000 in Stock

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 287

www.acclock.com

Accredited Lock Supply

BIT KEY MORTISE LOCKSET

Black Enamel with Satin Brass Knobs. Universal replacement

lock which includes two knobs(No. 209-54). #20 thread

spindles(No. 751) lock body, two trim plates, strike, screws

and two keys. Trim plates: 7" x 2 1/4" Strike: 4" x 1" 1/16"

Visual Pack; 5 per carton

IL215-04-51 Keyblank: IL2B

2399

Bronze Lacquer

ﬁnish. Angle strike.

Single cylinder;

operates by key

outside. Turn knob

inside.

Visual Pack; 5 per

carton.

Bronze Lacquer ﬁnish.

Angle strike. Double

cylinder; operates by

key on both sides.

Comes with one-way

screws. Packed in

boxes; 5 per carton.

605 SERIES ZINC DIE CAST RIM CYLINDER

Satin Brass ﬁnish

IL535-53-51

2100

IL530-53-51

1700

DOUBLE CYLINDER JIMMYPROOF LOCK

SINGLE CYLINDER JIMMYPROOF LOCK

MAILBOX LOCKS

STANDARD TYPE MAIL

BOX LOCK

Flat tumbler type replacement lock.

IL1600-04-11

819

MAIL BOX LOCK

1/2" bolt at tumbler lock.

IL1625-04-11

898

MAIL BOX LOCK

Flat tumbler replacement mailbox

lock for Couch.

IL1675-04-11

1638

MAIL BOX LOCK

Long ear at tumbler replacement

mailbox lock.

IL1650-04-11

898

Versatile, 5 pin tumbler die cast cylinder. The tailpiece

adapts for horizontal or vertical application and the cylinder

is rekeyable by traditional means.

Fits doors 1 1/4" - 2 1/4" thick.

Packed with two break off screws, one universal

backplate, one cylinder ring and two keys.

Individually boxed; 10 per carton.

NIGHT LATCH

Handsome Rose Gold nish.

Economical night latch, operates by

key outside, turn knob inside. Bolt

may be held back by turning knob

inside. Box-packed 5 per carton.

IL220-53-51 13.00

RIM DEADLOCK

Bronze Lacquer ﬁnish.

Single cylinder; operates by key

outside, turn knob inside. Bolt

extends 3/4". Two strikes furnished

for door opening in or out.

Visual Pack; 5 per carton.

IL545-53-51 13.00

COLONIAL KNOBS

Bright Brass ﬁnish.

Sold in pairs; 5 pairs per carton.

IL197-03-51

1286/pair

GLASS KNOBS

Clear, brass hardware

Sold in pairs; 5 pairs per carton.

ILAG30A

1166/pair

RIM LOCKSETS

Black Enamel with Satin Brass Knobs.

Packed 5 per carton

IL590-04-51 Vertical style

IL591-04-51 Horizontal style

2200

IL605KW-04-41

IL605SC-04-41

525

590 591

Keyblank for all: IL1270D

Go To Table of Contents

288

www.acclock.com

Accredited Lock Supply

THUMBTURN

MORTISE CYLINDERS

Code Length Finish Price/Ea.

IL7161 1" 25 Satin Chrome 12.45

46 Duranodic

IL7181 1 1/8" 03 Polished Brass 12.45

46 Duranodic

IL7201 1 1/4" 03 Polished Brass 12.45

46 Duranodic

Arrow K5,K6,L6A AA

Composite NA

Composite NB

Corbin 60 CA

Corbin 67 CB

Corbin 77 CC

Corbin CD

Corbin/Russwin CE

Dexter XE

Dominion 1054F DA

Dominion 1054F DB

Ilco X1054K UA

Kwikset 1176 KS

Lockwood 1004 LA

Lori L100 UB

Lori 90 UD

Lori 80 UE

Medeco ME

Russwin 981R RA

Russwin D1 RB

Russwin RC

Sargent LA GA

Sargent (LA-LC) GB

Sargent (RA-RC) GC

Schlage C SC

Schlage C-K SX

Schlage E SE

Schlage F SF

Segal 9 FA

Weiser E/Falcon WA

Yale 8 YA

Yale GA YG

REPLACEMENT RIM CYLINDERS IN THE

BEST SELLING KEYWAYS

Precision engineered solid bar brass cylinders. Tailpiece can

be converted from horizontal to vertical position. Cylinders

come with Ilco Look Alike blanks and are packed with break-off

screws, back plate and cylinder ring.

Drilled for 6 pins, Pinned 5.

IL7075 13.50

Specify Satin Chrome (25) or Polished Brass(03) ﬁnish when

ordering

REPLACEMENT MORTISE CYLINDERS

IN THE BEST SELLING KEYWAYS

Precision engineered solid bar brass cylinders. Cylinders

have standard diameter and thread and come with Ilco

Look Alike blanks.

Drilled For 6 Pins, Pinned 5

IL7185

1 1/8" 12.65

Drilled For 7 Pins, Pinned 5

IL7205 1 1/4" 12.75

Specify Satin Chrome(25),

Duranodic(46) or Polished

Brass(03) ﬁnish when ordering.

Drilled For 5 Pins, Pinned 5

IL7165 1" 12.55

Specify Satin Chrome (25) or

Duranodic (46) ﬁnish when ordering.

DUMMY MORTISE CYLINDERS

The secure way to seal existing mortise

cylinder openings. Manufactured from

precision engineered bar brass.

Code Length Finish Price/Ea.

IL7160 1" 25 Satin Chrome 7.60

46 Duranodic

IL7180 1-1/8" 25 Satin Chrome 7.60

46 Duranodic

IL7200 1-1/4" 25 Satin Chrome 7.60

03 Polished Brass

ADJUSTABLE COLLARS

Available in two solid ﬁnishes, (03)

Bright Brass, (25)Satin Chrome

Solid Brass

IL861A-03-10 Bright Brass 6.45

IL861A-26D-10 Satin Chrome 6.45

Steel

IL861V-03-10 Brass Plate 3.35

IL861V-26-10 Chrome Plate 3.35

ALUMINUM

SPACING COLLARS

FOR MORTISE CYLINDERS

A complete range of size for every situ-

ation.Available in (03)Bright Brass, (28)

Aluminum, (46)Duracolor

IL861C-10 3/32" 2.25

IL861D-10 1/8" 2.25

IL861E-10 5/32" 2.25

IL861K-10 3/16" 2.25

IL861L-10 7/32" 2.25

IL861F-10 1/4" 2.25

IL861M-10 9/32" 2.35

IL861N-10 5/16" 2.35

IL861P-10 11/32" 2.35

IL861Q-10 3/8" 2.65

IL861R-10 1/2" 2.65

IL861T-10 5/8" 2.65

IL869-00-10

Cash Box Nut-Fits Thread

on Std.Mortise Cylinder 370

KEYWAYS TABLE

REPLACEMENT CYLINDERS COLLARS

Rim Dummy Thumbturn CAMS

PART NO. DESCRIPTION

IL863 Yale

IL863A Adams Rite

IL863D Standard/:ockwood

IL863E Narrow

IL863F Marks

IL863G Standard

IL863M Schlage L

IL863N Sargent/Yale

IL863P Segal/Emhart

IL863R Lori Deadbolt

IL863S Corbin/Russwin

Best Cloverleaf

IL863T Adams Rite 4070 Cam

IL863U Sargent Offset Cam

IL863H Dominion 14PR-RM

IL863J Dominion 22PR-A-RM

IL863K Dominion 22PR-E-RM

1.40

CAMS

863T 863U

IL7245 1 1/2" Drilled for 7 pins, Pinned 5 24.35

IL7305 1 7/8" Drilled for 6 pins, Pinned 5 53.85

IL7325 2" Drilled for 6 pins, Pinned 5 60.00

ADA

Turnknob

Code Length Finish Price/Ea.

ILADA7161TK2 1" 25 Satin Chrome 16.80

ILADA7181TK1 1 1/8" 25 Satin Chrome 16.80

Now With

Screw Cap!

Rim Turnknob

IL7011 25.65

Dummy Rim

IL7010 10.20

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 289

www.acclock.com

Accredited Lock Supply

Arrow M,H,K,S or

Schlage A,C,D,H Series

KNOB/DEADBOLT CYLINDERS

For Schlage and Arrow Locks

Compatible and convertible replacement 6-pin cylinder for Schlage, Arrow and

keyways of all the leading manufacturers. Shown here is the most complete

variety of keyway sections to key other manufacturers’ locks in the installation.

A great time and money saver. Locksmiths should always keep a supply with

them in their service vehicles.

Available in top quality Satin Chrome (US26D) and Brass (US4) ﬁnishes.

A high quality product, manufactured to rigorous speciﬁcations for precise

compatibility with orginal manufacturer’s keyways. Drilled 6; pinned 5. Packed

10 per box; including tail peices.

IL15395 SC, KS, YA Stock Cylinders ONLY 11.45

IL15395 For All Other Keyways 14.00

15995 COMBINATION CYLINDER

Operates most Grade 1 & 2 locksets and leversets plus Arrow D, E, F, K; Schlage

B100, B200, B400; H series deadlocks. 5 pin, drilled 6

RW KEYWAY - RESTRICTED KEY CONTROL AT AN

AFFORDABLE PRICE

The RW restricted keyway is the affordable restricted keyway you can use to offer

your customers key control, without the expensive buy-in associated with high

security key control systems.

A simple $500 buy-in gets you a small restricted area in which you control the keyway.

The key is a neuter bowed, plain brass key. Uses regular Schlage spaces & depths.

P/N Description Finish Price

IL15395RW-04-KD K-I-K Cylinder Satin Brass 16.40

IL15395RW-26-KD K-I-K Cylinder Satin Chrome 16.40

IL15995RW-04-KD Combination Cyl. Satin Brass 18.12

IL15995RW-26-KD Combination Cyl. Satin Chrome 18.12

IL7015RW8-03-KD Rim Cylinder Polished Brass 19.87

IL7015RW8-26D-KD Rim Cylinder Satin Chrome 19.87

IL7165RW2-26D-KD 1" Mortise Cylinder Satin Chrome 15.50

IL7165RW2-46-KD 1" Mortise Cylinder Duranodic 15.50

IL7185RW1-03-KD 1 1/8" Mortise Cylinder Polished Brass 15.84

IL7185RW1-26D-KD 1 1/8" Mortise Cylinder Satin Chrome 15.84

IL7205RW1-03-KD 1 1/4" Mortise Cylinder Polished Brass 16.38

IL7205RW1-26D-KD 1 1/4" Mortise Cylinder Satin Chrome 16.38

ILALRW-5

5 Pin Keyblank

94¢

ILALRW-6

6 Pin Keyblank

94¢

IL15995 SC, KS, YA Stock Cylinders ONLY 11.80

IL15995 For All Other Keyways 15.50

15695 EMTEK® REPLACEMENT CYLINDER

Will ﬁt Emtek® single and double deadbolts. Will

also ﬁt Emtek® Key-in-Knob and Key-in-Lever

applications

• Drilled 6, pinned 5

• Machined to exacting specications

• Master Key and Grand Master Key compatible

into OEM systems

Available in Arrow and SC1 keyways,

04 and 26D ﬁnishes.

IL15695

1550

IC CORES AND CYLINDER HOUSINGS

Solid Brass I.C.Cores

• Solid brass plug and housing

• 6 or 7 pin cores replace Arrow, Best, Falcon, KSP

• 04 or 26D nish (keyblanks not included)

Available keyways:

BA: Best A BE: Best E BJ: Best J

BB: Best B BF: Best F BK: Best K

BC: Best C BG: Best G BL: Best L

BD: Best D BH: Best H BM: Best M

BQ: Best Q

IL28016 6 pin Uncombinated 13.70

IL28017 7 pin Uncombinated 14.10

Solid brass housings, with removeable cam/tailpiece.

Thin head mortise can be converted to a rim cylinder

in the ﬁeld. Comes standard with 1/4" ring.

ILR28106-1 6 Pin Thin head mortise w/std. cam 15.10

ILR28107-1 7 Pin Thin head mortise w/std. cam 15.10

ILR28406-2 6 Pin Tapered head mortise w/AR cam 15.40

ILR28407-2 7 Pin Tapered head mortise w/AR cam 15.40

ILR28206 6 Pin Rim with tail 15.80

ILR28207 7 Pin Rim with tail 15.80

Std.Yale

Lori Fan

Can

Falcon/

Saok

Sargent/

Yale

Schlage LCloverleafAdams Rite

Cams: 1.40 ea

10/pack

IL862A: 1.60 ea

2 3/8" Tail-

piece

Go To Table of Contents

290

www.acclock.com

Accredited Lock Supply

MORTISE CYLINDER DEADLOCKS

Single Cylinder.

Packed 10 per case.

IL4512 US26D 2" Backset

IL4513 US26D 2 3/8" Backset

IL4514 US26D 2 3/4" Backset

IL4515 US26D 2 3/8" Drive-In

IL4516 US26D 2 3/4" Drive-In

IL4512 03P 2" Backset

IL4513 03P 2 3/8" Backset

IL4514 03P 2 3/4" Backset

IL4515 03P 2 3/8" Drive-In

IL4516 03P 2 3/4" Drive-In

5800 5800

Double Cylinder

Packed 10 per case.

IL4522 03P 2" Backset

IL4523 03P 2 3/8" Backset

IL4524 03P 2 3/4" Backset

IL4525 03P 2 3/8" Drive-In

IL4526 03P 2 3/4" Drive-In

6765

IL4522 US26D 2 Backset

IL4523 US26D 2 3/8" Backset

IL4524 US26D 2 3/4" Backset

IL4525 US26D 2 3/8" Drive-In

IL4526 US26D 2 3/4" Drive-In

6765

Bright Brass Permanent

Satin Chrome

Code Size Mounting Finish

IL1701-04-41 3/4" Horizontal Brass

IL1701-81-41 3/4" Horizontal Cadmium

IL1702-01-41 7/8" Horizontal Brass

IL1702-81-41 7/8" Horizontal Cadmium

IL1703-04-41 1 1/8" Horizontal Brass

IL1703-81-41 1 1/8" Horizontal Cadmium

IL1751-04-41 3/4" Vertical Brass

IL1751-81-41 3/4" Vertical Cadmium

IL1752-04-41 7/8" Vertical Brass

IL1752-81-41 7/8" Vertical Cadmium

IL1753-04-41 1 1/8" Vertical Brass

IL1753-81-41 1 1/8" Vertical Cadmium

1029 ea.

5740

Available in Dexter, Kwikset, Schlage C, and Weiser

keyways. US3 and US26D ﬁnishes.

Packed 10 per box.

IL247-14-11

1118 IL53225 Double Cylinder

IL52225 Single Cylinder

SHOWCASE LOCK LOW PROFILE CYLINDERS

Available Keyed Alike

or Keyed Different.

Packed 6 per box.

DRAWER LOCKS

Arrow K5,K6,L6A AA

Composite NA

Composite NB

Corbin 60 CA

Corbin 67 CB

Corbin 77 CC

Corbin CD

Corbin/Russwin CE

Dexter XE

Dominion 1054F DA

Dominion 1054F DB

Ilco X1054K UA

Kwikset 1176 KS

Lockwood 1004 LA

Lori L100 UB

Lori 90 UD

Lori 80 UE

Medeco ME

Russwin 981R RA

Russwin D1 RB

Sargent LA GA

Sargent (LA-LC) GB

Sargent (RA-RC) GC

Schlage C SC

Schlage C-K SX

Schlage E SE

Schlage F SF

Segal 9 FA

Weiser E/Falcon WA

Yale 8 YA

Yale GA YG

KEYWAYS TABLE

5 pin

Keyblank: ILN1054G

Keyblank: ILO1014S

Go To Table of Contents

ENCYCLOPEDIA OF LOCKSMITH SUPPLIES

1.800.652.2835 291

www.acclock.com

Accredited Lock Supply A

Accredited Lock Supply - Your Source for All Ilco Keyblanks

Transponders Automotive

EZ Keys Look-Alike Keys

Team Keys

Personalized Keys

Electronic Keys

Logo Keyblanks

College Keys

US Armed Forces Keys

Go To Table of Contents

292

www.acclock.com

Accredited Lock Supply

• 4 button control operates up to 4 different doors and/or gates from just one device

• Program within minutes thanks to the “head-to-head” add on procedure, without

opening the case

• No dip switches to set or re-set while programming

• Compact size and lightweight design

• Replaceable battery (CR2032) provides long lasting, dependable service.

• Splash and dust resistant (IP64) certication

• Compatible with popular brands, including: Sears® Craftsman®, Chamberlain®,

Genie®, Linear®, Liftmaster®, Overhead Door®.

• Includes visor clip and lanyard

• Clips to the vehicle’s visor or is easily added to a key ring

Trademarks and Tradenames herein are property of the respective owners.

EZ®-4U UNIVERSAL RESIDENTIAL REMOTE

Duplication of an existing remote is quick and simple, takes only minutes and does

not require any tools. Plus, this universal remote may be programmed to operate

up to four different opener units.

ILEZ4U-00-51

Clamshell Pack

Includes:

EZ4U remote

Visor Clip

Lanyard

6000

ILTAEZ4U-00-55

Display + Remotes

Includes:

5 EZ4U Remote Packs

30000

Smart4Car™ Universal Automotive Remote System

All-in-one Solution

•A physical key available in 2 versions; Modular (1 Universal) and Flip Head (4

integrated, 1 Universal) to ﬁt Ilco blades

•Transponder chip

•Remote keyless entry(RKE) transmitter

•New programming tool (Smart Remote Programmer) to preset the RKE portion

of the product

•The Smart Remote Programmer communicates to app via USB or Bluetooth

capability (Mobile Phone or PC)

•After the target vehicle has been obtained, the Smart Remote Programmer will

generate (precode) the RKE (Smart4Car remote key) wirelessly via NFC

•Smart4Car remote added to the vehicle via OBP or diagnostic tool (MVP)

•Covers approximately 44 brands, 800+ vehicles globally

•North American coverage will continue to expand year after year

•APP or software program on a PC to determine the proper remote le by one or more:

 Year/Make/Model

 Vin Number

 Smart match

 Frequency + image to recognize OEM remote

•94% of applications covered with APP or PC, 6% PC with internet connection

ILSMARTREMOTE

PROGRAMMER

60000

ILSMARTMODULARHEAD

5925

ILSMARTFLIPGTI

Flip key w/GTI transponder

5925

ILSMARTFLIP

Flip key w/o GTI transponder

3300

Go To Table of Contents

Locks View PDF Ilco Hq

Navigation menu

Versions of this User Manual:

Views

Navigation
