ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 579
www.acclock.com
Accredited Lock Supply B
The AD-Series electronic locks from Schlage are designed to provide more options to choose from, more functionality in the lock and more
compatibility with existing systems. Its patent-pending modular design allows the solution to be customized to fit your application now, and can
change to meet future needs without removing it from the door.
AD-SERIES ELECTRONIC LOCKS
The AD-Series features a variety of options including card readers, network configurations, locking
functions, lever styles and finishes. It also offers a wide selection of features that can be configured
in the field to customize your openings.
The AD-Series is built on an open architecture platform that means that it can be easily integrated into
virtually any access control system. And its flexible panel interface options such as RS485, Wiegand
and Clock & Data ensure seamless communication with your system
OFFLINE SOLUTIONS
AD-200 Rights on Locks
Operates like a traditional electronic lock. The locks
are programmed with access rights and schedules
using software and a handheld device, or manually
programmed directly at the keypad.
SCAD-200-CY-70 Classroom/Storeroom 1604.00
SCAD-200-CY-50 Office 1614.00
SCAD-200-CY-40 Privacy 1614.00
SCAD-200-CY-60 Apartment 1614.00
Keypad standard.
AD-250 Rights on Card
This is a smart and economical solution for campus-like
environments with a large number of users. The access
rights and schedules are stored on a magnetic stripe
credential rather than the lock. This gives the manager
the ability to change rights for certain credentials without
having to tour the locks. The lock still maintains an
audit trail of events.
SCAD-250-CY-70 Classroom/Storeroom 1699.00
SCAD-250-CY-50 Office 1709.00
SCAD-250-CY-40 Privacy 1709.00
SCAD-250-CY-60 Apartment 1709.00
Magnetic Stripe Standard
NETWORKED SOLUTIONS
AD-300 Networked Hardwired
A hardwired networked solution gives you instant
control of your system. Whether you’re trying to lock
down or unlock one door or every door in your facility,
add or remove a user, or simply see the status of the
opening – you can be confident that you’re doing so
in real-time right from your computer.
The AD-Series combines all the hardware components required for a complete access control system into one integrated design that
includes the electrified lock, credential reader, request-to-enter and -exit sensors, door position switch and more. This integrated
design saves you both time and money when installing your system.
SCAD-300-CY-70 Classroom/Storeroom 1604.00
SCAD-300-CY-50 Office 1614.00
SCAD-300-CY-40 Privacy 1614.00
SCAD-300-CY-60 Apartment 1614.00
Keypad Standard
AD-400 Networked Wireless
The AD-400 networked wireless lock gives you all the
benefits of a hardwired access control system – without
the wires. This allows you to secure doors that were
traditionally difficult to run wires to in the past – and
increase the security throughout your facility. A wire-
less solution also allows for a quicker and more cost-
efficient installation that causes minimal disruption to
your environment – saving you both time and money.
SCAD-400-CY-70 Classroom/Storeroom 1786.00
SCAD-400-CY-50 Office 1796.00
SCAD-400-CY-40 Privacy 1796.00
SCAD-400-CY-60 Apartment 1796.00
Keypad Standard
NON-FUNCTIONING DUMMY TRIM FOR EXIT
Call for exact configurations and options.
SCAD-993LLL Dummy trim less reader 569.00
SCAD-993DT Dummy trim w/dummy 581.00
reader cover
Use Pro-Lok IN500-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN500-FP-S Flat Plate
Go To Table of Contents
580
www.acclock.com
Accredited Lock Supply
B
The CO-Series from Schlage makes it easy to upgrade from traditional mechanical solutions to electronic access control. Electron-
ic access control provides added security, convenience and efficiency.
Security
• Grant user rights to designated doors at specic times
• Audit trails give you visibility to who went where and when
• Electronic credentials can be easily added or deleted
Convenience
• Automatic lock and unlock can be scheduled for specic time zones
• Holiday Schedules
• Multiple ways to utilize credentials including normal, toggle, freeze & pass through
Efficiency
• Utilize existing master key system
• Low lifetime cost of ownership
• Easy to install and service in the eld
CO-100
The CO-Series is the ideal solution for customers seeking the added security and convenience of electronic access control without the cost or complexity of a fully
networked system.
The CO-100 is an offline lock that is manually programmable. User rights for the CO-100 are stored on the lock. Unique PIN codes can be assigned to each user. This
minimizes the number of mechanical keys issued which protects the integrity of your key system. PIN codes can be easily added or deleted at anytime right at the door.
The CO-100 from Schlage offers you many choices. Cylindrical, mortise, and exit trim chassis options are available as well as a wide variety of finishes and levers to
suite with your existing hardware.
Mechanical key override is standard and compatible with multiple cylinder types. The CO-Series is also compatible with many popular brands of exit devices.
Features
• Manually Programmable
• Up to 500 unique 3-6 digit PIN codes stored on the lock
• ANSI/BHMA Grade 1 certied and UL 294 listed*
• Classroom/Storeroom function and Ofce function available
• Chassis options include cylindrical, mortise, and exit trim
• Compatible with most major brands of key systems and exit devices
• Normal, toggle, pass through, and freeze credential attributes available.
CO-250
Choosing Which Model is Best For Your:
Credential Type
Electronic credentials such as PIN codes and cards allow to you issue fewer mechanical keys which protects the integrity of your key system. They also allow you to
easily add and delete users right at the lock for added security.
• PIN: If for simplicity you wish to only manage PIN codes we recommend the CO-100; an ofine manually programmable lock with a keypad reader.
• Card or Card + PIN: If you would like the added security of card or card plus PIN we recommend the CO-200 or CO-250; both are computer programmable locks.
Number of Users
Each opening within a facility is unique. To determine the right solution you must consider how many users need access to the opening.
• Small: For opening with a small number of users the CO-100 is an option. It can store up to 500 users on the lock.
• Medium: The CO-200 can store up to 2000 users on the lock, so it can be used for openings with a small or medium number of users.
• Large: The CO-250 allows for dynamic rights management via the magnetic stripe credential; making it and ideal solution for large campus like environments with a
large number of users.
Sensitivity of the Opening
Certain openings within your facilty may pose more of a security concern than others. We offer a variety of solutons for each that can all work together within your facility.
• Low: The CO-100 is manually programmable and therefore does not offer audit trails, making it a preferable solution for openings where risk mitigation is not the
primary concern.
• Medium: The CO-200 & CO-250 offer audit trails which provide added security by giving you visiabity to when a valid or invalid credential is presented; making them
an ideal solution for sensitive openings.
• High: For openings that are very sensitive a AD-Series networked solutions should be considered becuase they allow you to monitor and make updates in real-time.
Efficiency
Some openings only require the basics. For other openings you want additional features that increase efficiency.
• Basic: CO-100 locks provide address the basic needs of electronic access control.
• Advanced: CO-200 and CO-250 locks provide additional features such as the ability to schedule time zones, holidays, and auto-unlocks for added convenience.
SCCO-100-CY-70-KP Classroon/Storeroom w/keypad 774.00
SCCO-100-CY-50-KP Office w/keypad 784.00
Also available as exit trim.
CO-100 CO-200
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 581
www.acclock.com
Accredited Lock Supply B
The CO-200 is computer programmable with users rights stored on the lock. The Handheld Device (HHD) used in conjunction with your access control software, allows
you to easily add or delete users and retrieve audits.
By issuing electronic credentials you can minimize the number of mechanical keys issued which protects the integrity of your key system. A variety of credential readers
are also available including: keypad only, magnetic stripe, and proximity. The magnetic stripe and proximity readers are also available with keypad for the added security
of dual authentication.
Cylindrical, mortise, mortise deadbolt, and exit trim chassis options are available as well as a wide variety of finishes and levers to suite with your existing hardware.
Mechanical key override is standard and compatible with multiple cylinder types. The CO-Series is also compatible with many popular brands and types of exit devices.
Features
• Computer programmable with audit trail
• Up to 2000 users & up to 2000 audits*
• Up to 32 holidays & 16 time zones*
• ANSI/BHMA Grade 1 certied and UL 294 listed
• User rights stored on the lock
• The ability to add and delete users at the lock
• Available in cylindrical, mortise, mortise deadbolt, and exit trim
• Compatible with major brands of key systems and exit devices
• Classroom/Storeroom, Ofce, and Privacy functions available
CO-200
The CO-250 is a computer programmable ofine lock that stores user rights on the magnetic stripe credential, and captures an audit trail in the lock. The CO-250 provides
dynamic rights management, meaning you do not have to visit the door to change user access rights. This makes it a cost effective solution for offline environments
with a large number of users. The CO-250 also allows you to retrieve audits by using the Handheld Device (HHD) in conjunction with your access control software.
The CO-250 from Schlage offers you many choices. Cylindrical, mortise, mortise deadbolt, and exit trim chassis options are available as well as a wide variety of nishes
and levers to suite with your existing hardware.
Mechanical key override is standard and compatible with multiple cylinder types. The CO-Series is also compatible with many popular brands of exit devices.
Features
• Computer programmable with audit trail
• Unlimited number of users and up to 4000 audits*
• Available with Magnetic Stripe and Magnetic Stripe plus Keypad
• Up to 32 holidays & 16 time zones*
• ANSI/BHMA Grade 1 certied and UL 294 listed**
• User rights stored on the magnetic stripe credential
• The ability to easily add and delete users
• Available in cylindrical, mortise, mortise deadbolt, and exit trim
• Compatible with major brands of key systems and exit devices
• Classroom/Storeroom, Ofce, and Privacy functions available
CO-250
CO-993DT
Non-Functioning Dummy Trim for Exit
SCCO-993DT Dummy trim w/dummy 623.00
reader cover
SCCO-200-CY-70 Classroon/Storeroom 941.00
SCCO-200-CY-50 Office 951.00
SCCO-200-CY-40 Privacy 951.00
Also available as exit trim.
Readers available: KP-Keypad, Std. MS-Magnetic Stripe, 86.80
MSK-Magnetic Stripe+Keypad, 144.00 PR-Proximity, 144.00
PRK-Proximity+Keypad, 201.00
SCCO-250-CY-70 Classroon/Storeroom 1033.00
SCCO-250-CY-50 Office 1043.00
SCCO-250-CY-40 Privacy 1043.00
Also available as exit trim.
Readers available: MS-Magnetic Stripe, Std.
MSK-Magnetic Stripe+Keypad, 57.40
Use Pro-Lok IN51/IN510-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN510-FP-S Flat Plate
Go To Table of Contents
582
www.acclock.com
Accredited Lock Supply
B
M490/M492 High Security Series Electromagnetic Lock
M490/M492
• Automatic Voltage Selection (AVS) senses the voltage applied to the lock
and responds accordingly
M490P/M492P
• Magnetic Bond Sensor (MBS) monitors the strength of the bond between
the lock and armature so you know the door is secure
• Door Position Switch (DPS) monitors whether the door is open or closed
• Relock Time Delay (RTD) provides a relock delay that is adjustable from 0.5
to 30 seconds
Optional
- Anti-Tamper Switch (ATS) provides an indication that the cover of the magnet
is securely fastened to the lock and that the on board circuitry is secure
- MBS Indicator (LED) provides visual indication of magnetic bond at the lock
SCM490 Single Lock 607.00
SCM492 Double Lock w/Single Housing 1270.00
SCM490P Single Lock 786.00
SCM492P Double Lock w/Single Housing 1628.00
Options:
SCHDB490 Herculite Door Bracket 305.00
SCTJ490 Top Jamb (inswinging doors) 148.00
All M400 Series locks have automatic voltage sensing for 12 and 24 volts along
with polarity protection to make wiring less complex.
The M490 is tested and certied to meet or exceed UL1034 and BHMA 1500lb. hold
force requirements. 1500 lbs. hold force.
M420/M422 High Security Series - Electromagnetic Lock
The M420 electromagnetic lock comes in two congurations to meet your specific
security needs. The M420 provides basic security, while the M420P provides intel-
ligent sensing and reporting features needed to integrate with access control systems.
Additional options are available for the M420P. Kits are available for top jam, double
door, and glass door applications. 500 lbs. hold force.
M420/M422
• Automatic Voltage Selection
(AVS) senses the voltage applied to the
lock and responds accordingly
M420P/M422P
• Magnetic Bond Sensor (MBS)
monitors the strength of the bond
between the lock and armature so you
know the door is secure
• Door Position Switch (DPS) monitors whether the door is open or closed
• Relock Time Delay (RTD) provides a relock delay that is adjustable from
0.5 to 30 seconds
Optional
- Anti-Tamper Switch (ATS) provides an indication that the cover of the magnet
is securely fastened to the lock and that the on board circuitry is secure
- MBS Indicator (LED) provides visual indication of magnetic bond at the lock
SCM420 Single Lock 485.00
SCM422 Double Lock w/Single Housing 1026.00
SCM420P Single Lock 668.00
SCM422P Double Lock w/Single Housing 1371.00
Options:
SCHDB420 Herculite Door Bracket 305.00
SCTJ420 Top Jamb (inswinging doors) 148.00
M450/M452 High Security Series Electromagnetic Lock
M450/M452 - 1000 lbs. hold force
• Automatic Voltage Selection (AVS) senses the
voltage applied to the lock and responds accordingly
M450P/M452P
• Magnetic Bond Sensor (MBS) monitors the strength of the bond between
the lock and armature so you know the door is secure
• Door Position Switch (DPS) monitors whether the door is open or closed
• Relock Time Delay (RTD) provides a relock delay that is adjustable from 0.5
to 30 seconds
Optional
- Anti-Tamper Switch (ATS) provides an indication that the cover of the magnet
is securely fastened to the lock and that the on board circuitry is secure
- MBS Indicator (LED) provides visual indication of magnetic bond at the lock
SCM450 Single Lock 554.00
SCM452 Double Lock w/Single Housing 1163.00
SCM450P Single Lock 737.00
SCM452P Double Lock w/Single Housing 1530.00
Options:
SCHDB450 Herculite Door Bracket 305.00
SCTJ450 Top Jamb (inswinging doors) 148.00
M490DE DELAYED EGRESS SERIES
with lifetime Warranty
Standard Features
• Delayed egress with plunger switch and
external switch input
• Designed to meet NFPA 101 Life Safety Code
• Automatic voltage selection
• UL294 Special locking arrangement including BOCA*
• Authorized release input
• On-board audible alarm
• On-board bi-color LED
• Fire alarm terminals
* Only available on Plus models
SCM490DE Single Lock 1303.00
SCM490DEP Door Status Monitor (DSM) 1956.00
Magnetic Bond Sensor (MBS)
Relocking Time Delay (RTD)
Options:
SCHDB490 Herculite Door Bracket 305.00
1500 lbs. hold force
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 583
www.acclock.com
Accredited Lock Supply B
Schlage introduces the integrator’s answer to retrofit needs for electromagnetic locks. These “Full Featured”
electromagnetic locks are easy to stock, easy to select and easy to install. With common templating and standard
features, the 40 and 70 Series Electromagnetic Locks for retrot make
sense for virtually every application.
40 and 70 SERIES FULL FEATURED SERIES
40 Specifications
Holding Force: BHMA 500 lb rating
Input Voltage: 12/24 VDC
Current Draw: .32A @ 12 VDC
.15A @ 24VDC
Length: 8”
Height: 1 7/8”
Depth: 1 5/8”
Weight: 3.5 lbs.
Certifications: ANSI/BHMA A156.23,
UL10C & UL1034
SC40 378.00
70 Specifications
Holding Force: BHMA 1000 lb rating
Input Voltage: 12/24 VDC
Current Draw: .25A @ 12 VDC
.12 @24 VDC
Length: 8”
Height: 3”
Depth: 1 7/8”
Weight: 7.5 lbs.
Certifications: ANSI/BHMA A156.23,
UL10C & UL1034
SC70 481.00
The Schlage M490G Electromagnetic Gate Lock is a
weather resistant electromagnetic lock with 1500 lbs.
of holding force, designed for use on all types of sliding
and swinging gates.
As a high security magnetic lock it can accommodate
misalignment problems while supplying superior
holding force.
A 1/2" compression connector is provided for installa-
tion of 1/2" EMT conduit, insuring protection of hook-up
wiring from weather and vandalism. Heavy duty plating
resists corrosion of mating surfaces providing a low
maintenance locking device.
A modified Top Jamb mounting bracket allows a single
M490G to be mounted in a variety of positions. The
M490G Gate Lock may be mounted to any gate frame
or post. Special brackets may be required to adapt the
lock to a particular frame or post.
It is important that the lock is mounted so that the
armature pulls straight back from the magnet face.
The M490G can be eld congured for either 12 or 24
VDC operation. Magnetic Bond Sensor (MBS) and Gate
Status Monitor (DPS) are standard.
1500 lbs. hold force
SCM490G 612.00
M490G ELECTROMAGNETIC GATE
LOCK
GF3000 Adjustable from top edge of door 971.00
GF3000TRD Mounting assembly which provides
armature adjustable from the latch edge of the door.
Recommended with zero clearance condition between
top of door and ceiling. 1335.00
GF3000BRD Mounting assembly to mortise armature
into bottom rail of door. Magnet is installed in floor/
threshold. Provides solution when no top rail is avail-
able. 1432.00
OPTIONS
DSM/MBS Door Status Monitor/Magnetic Bond Sensor
239.00
GF3000 SHEAR LOCK MORTISE SERIES
Features and Benefits
• Automatic voltage selection 12/24 VDC (Filtered)
• 3000 lbs. of hold force
• Requires ltered, regulated power supply
• Built-in Automatic Relock Switch
• Adjustable time delay on relock, 0-30 seconds
• Low temperature operation
• Microprocessor controlled
• Optional Magnetic Bond Sensor (MBS) to monitor the
secure/not secure condition of the lock
• Optional Door Status Monitor (DSM) to sense the
open/closed position of the door
• UL 10C Positive Pressure Fire Tests of Door Assem-
blies, cUL, CSFM and MEA listed to use on re labeled
openings
• Meet ANSI/BHMA A156.23 standards
GF3000 SHEAR LOCK SURFACE SERIES
SM
TJ
GF3000SM Standard Unit (outswinging doors). Adjust-
able from top edge of armature. Available in special
finishes. 1184.00
GF3000TJ Top Jamb Unit (inswinging doors). Magnet
mounts on inside top jamb. Adjustable from top edge
of armature. Available in special finish. 1184.00
OPTIONS
DSM/MBS Door Status Monitor/Magnetic Bond Sen-
sor 239.00
Features and Benefits
• Automatic Voltage Selection 12/24 VDC (ltered)
• 3000 lbs. of holding force
• Requires ltered, regulated power supply
• Built-in Automatic Relock Switch
• Adjustable time delay on relock, 0-30 seconds
• Low temperature operation
• Microprocessor controlled
• Optional Magnetic Bond Sensor (MBS) to monitor the
secure/not secure condition of the lock
• Optional Door Status Monitor (DSM) to sense the
open/closed position of the door
• Modular, slide-in in nish plates on SM and TJ models
• UL10C Positive Pressure Fire Test of Door Assemblies,
cUL, CSFM and MEA listed to use on re labeled
openings
• Meets ANSI/BHMA 156.23 standards
672 SERIES TOUCHBAR
The 672 Touchbar is a request-to-exit device used
to release electromagnetic locks. Designed for easy
installation, smooth operation and maximum durability.
RHR is standard, LHR is optional.
SC672-628 Aluminum 309.00
SC672-313 Dark Satin Bronze 338.30
692 SERIES SMARTBAR
• Push pad with "PUSH TO EXIT" signage
• Touch any point on the pushpad to release locking
device
• Audible alarm
• Heavy duty aluminum extrusion and powder coated
zinc end caps
• Directionally opposed infrared detection circuits
SC692-628 Aluminum 561.00
SC692-313 Dark Satin Bronze 590.30
Use Pro-Lok IN52-PRO/INCL-PRO Templates
Go To Table of Contents
584
www.acclock.com
Accredited Lock Supply
B
KEY CONTROL
EverestTM key control for your existing Best® 7 pin interchangeable core systems.
All the benets of easy rekeying, with Schlage Everest key control.
For those not wanting to change their keying systems, you can purchase Schlage
products that accomodate the standard Best® style interchangeable cores, in 6 or 7 pin.
Introducing Everest, the new patented cylinder family from Schlage. Whether you
need convenient key duplication or restricted key control, Everest has a product to
address your security issues. What sets Everest apart from the rest? Everest is a
patent protected keying system that provides you as much key control as you need.
Direct replacement for original Schlage cylinders in all locksets
CYLINDERS
SC30-021 Mortise cyl., L cam, no collar 77.00
SC26-021 Mortise cyl., straight cam, no collar 80.00
SC22-002 B series insert cyl., no tailpiece 70.00
SC21-002 A/H knob cylinder 70.00
SC21-002-122 A/H Orbit knob cylinder 70.00
SC21-020 AL cylinder 70.00
SC23-001 D knob cylinder 70.00
SC23-013 D lever cylinder 70.00
SC23-065 ND lever cylinder 70.00
SC23-030 Interchangeable core, full size 79.00
SC80-037 Interchangeable core, small format 73.00
Specify keyway (C123, C145), nish (606, 626), KD or KA KEYBLANKS
SC35-009-C123 Key Blank 3.00
SC35-009-C145 Key Blank 3.00
SC35-009-C124 Key Blank 3.00
SC35-009-C135 Key Blank 3.00
SC35-002-C100 Key Blank, Master DND 3.00
SC35-002-C150 Key Blank, Master DND 3.00
SC35-003-C123 Key Blank, Control 5.00
SC35-003-C145 Key Blank, Control 5.00
SC35-003-C124 Key Blank, Control 5.00
SC35-003-C135 Key Blank, Control 5.00
SC35-003-C120 Key Blank, Control, Master Section 5.00
SC35-003-C150 Key Blank, Control, Master Section 5.00
SC35-003-C100 Key Blank, Control, Master Section 5.00
NEW! ASK ABOUT:
Everest 29 Primus XP Controlled Access
and High Security (Patented until 2029)
C
New Keyways Available - Ask Your Sales Representative
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 585
www.acclock.com
Accredited Lock Supply B
A SERIES HEAVY DUTY LOCKSETS
Lock mechanisms are precision made of high strength steel, plated and
dichromated for superior corrosion resistance and maintenance-free
performance.
Available in a wide variety of function and nishes; in many knob and
lever designs.
Ideal for quality residential and light commercial buildings.
Applications:
Heavy duty residential, light and medium commercial.
Certifications:
ANSI A156.2-2003, Series 4000 Grade 2. (Formerly
FF-H-10B Series 160) UL listed for 3 hour re door
(1/2" Throw latch functions).
Exposed Trim:
Wrought brass, bronze or stainless steel. Levers are
pressure cast zinc, plated to match finish symbols.
Keying
6 Pin tumbler with two nickel silver keys per lock. Stock
locks are keyed 5-pin.
Door Range:
1-3/8" to 1-7/8" Standard 2" to 2-1/2" regular parts
assembled to order.
Backset:
2-3/8" Standard. 2-3/4" and 3-3/4" backset latches
available 5", 7", 10", 18" or over, backset links available.
Quantity Discounts Available. Call for Quote.
A10S Passage latch F75-2
Both knobs always unlocked
A40S Bath/bedroom privacy lock F76-2
Push button locking. Can be opened from
outside with small screwdrivers or flat narrow
tool. Turning inside knob or closing door
releases button.
A53PD Entrance lock F81-2
Turn/push button locking:
Pushing and turning button locks outside
knob requiring use of key until button is
manually unlocked.
Push button locking:
Pushing button locks outside knob until
unlocked by key or by turning inside knob.
A70PD Classroom lock F84-2
Outside knob locked and unlocked by key.
Inside knob always unlocked.
A SERIES HEAVY DUTY LOCKSETS
Go To Table of Contents
586
www.acclock.com
Accredited Lock Supply
B
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCA40SGE04-605 Bright Brass 2-3/4" 140.00
SCA40SGE04-605/625 Bright Brass/ 2-3/4" 140.00
Bright Chromium Plated
SCA40SGE04-609 Satin Brass Blackened 2-3/4" 140.00
SCA40SGE04-609/625 Satin Brass Blackened/ 2-3/4" 140.00
Bright Chromium Plated
SCA40SGE08-605 Bright Brass 2-3/8" 140.00
SCA40SGE08-605/625 Bright Brass/ 2-3/8" 140.00
Bright Chromium Plate
SCA40SGE08-609 Satin Brass Blackened 2-3/8" 140.00
SCA40SGE08-609/625 Bright Brass Blackened/ 2-3/8" 140.00
Satin Chromium Plated
PASSAGE LATCH
Both Knobs Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA10SGE04-605 Bright Brass 2-3/4" 140.00
SCA10SGE04-609 Satin Brass Blackened 2-3/4" 140.00
SCA10SGE08-605 Bright Brass 2-3/8" 140.00
SCA10SGE08-609 Satin Brass Blackened 2-3/8" 140.00
STOREROOM LOCK
Keyed Side Always Locked; Other Side Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA80PDGEO8-605 Bright Brass 2-3/8" 239.00
SCA80PDGEO8-609 Satin Brass Blackened 2-3/8" 239.00
CLASSROOM LOCK
Keyed One Side; Inside Always Unlocks. 20 per case.
Code Finish Backset Price/Ea.
SCA70PDGEO8-605 Bright Brass 2-3/8" 239.00
SCA70PDGEO8-609 Satin Brass Blackened 2-3/8" 239.00
ENTRANCE LOCK
Keyed One Side; Turn-Pushbutton on Other Side. 20 per case.
Code Finish Backset Price/Ea.
SCA53PDGE04-605 Bright Brass 2-3/4" 239.00
SCA53PDGE04-609 Satin Brass Blackened 2-3/4" 239.00
SCA53PDGE08-605 Bright Brass 2-3/8" 239.00
SCA53PDGE08-609 Satin Brass Blackened 2-3/8" 239.00
GEORGIAN
Symbol: GEO
Material: Wrought brass.
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Price/Ea.
SCA170GEO-605 Bright Brass 70.00
SCA170GEO-609 Satin Brass Blackened 70.00
A SERIES HEAVY DUTY LOCKSETS
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCA40LEV4-605 Bright Brass 2-3/4" 140.00
SCA40SLE4-605/625 Bright Brass/ 2-3/4" 140.00
Bright Chromium Plated
SCA40SLEV4-626 Satin Chromium Plated 2-3/4" 128.00
SCA40SLEV8-605 Bright Brass 2-3/8" 140.00
SCA40SLEV8-626 Satin Chromium Plated 2-3/8" 128.00
PASSAGE LATCH
Both Levers Always unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA10SLEV4-605 Bright Brass 2-3/4" 140.00
SCA10SLEV4-626 Satin Chromium Plated 2-3/4" 128.00
SCA10SLEV8-605 Bright Brass 2-3/8" 140.00
SCA10SLEV8-626 Satin Chromium Plated 2-3/8" 128.00
STOREROOM LOCK
Keyed Side Always Locked; Other Side Unlocked. Lever Inside Only. 20 per case.
Code Finish Backset Price/Ea.
SCA80PDLEV8-626 Satin Chromium Plated 2-3/8" 227.00
LEVON
Symbol: LEV
Material: Pressure cast zinc.
Wrought brass or bronze rose.
LEVON-ORBIT
ENTRANCE-ORBIT
Keyed One Side; Turn-Pushbutton on Other side. 20 per case.
Code Finish Backset Price/Ea.
SCA53PDL-O4-605 Bright Brass 2-3/4" 239.00
SCA53PDL-O4-626 Satin Chromium Plated 2-3/4" 227.00
SCA53PDL-O8-605 Bright Brass 2-3/8" 239.00
SCA53PDL-O8-626 Satin Chromium Plated 2-3/8" 227.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Price/Ea.
SCA170LEV-605 Bright Brass 70.00
SCA170LEV-626 Satin Chromium Plated 64.00
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 587
www.acclock.com
Accredited Lock Supply B
PLYMOUTH
Symbol: PLY
Material: Wrought brass,
bronze or stainless steel.
PASSAGE LATCH
Both Knobs Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA10SPLY4-605 Bright Brass 2-3/4" 140.00
SCA10SPLY4-612 Satin Bronze 2-3/4" 140.00
SCA10SPLY4-626 Satin Chromium Plated 2-3/4" 128.00
SCA10SPLY8-605 Bright Brass 2-3/8" 140.00
SCA10SPLY8-612 Satin Bronze 2-3/8" 140.00
SCA10SPLY8-626 Satin Chromium Plated 2-3/8" 128.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCA40SPLY4-605 Bright Brass 2-3/4" 140.00
SCA40SPLY4-605/625 Bright Brass/Chrome 2-3/4" 140.00
SCA40SPLY4-612 Satin Bronze 2-3/4" 140.00
SCA40SPLY4-612/625 Satin Bronze/Chrome 2-3/4" 140.00
SCA40SPLY4-626 Satin Chromium Plated 2-3/4" 128.00
SCA40SPLY8-605 Bright Brass 2-3/8" 140.00
SCA40SPLY8-605/625 Bright Brass/Chrome 2-3/8" 140.00
SCA40SPLY8-612 Satin Bronze 2-3/8" 140.00
SCA40SPLY8-612/625 Satin Bronze/Chrome 2-3/8" 140.00
SCA40SPLY8-626 Satin Chromium Plated 2-3/8" 128.00
ENTRANCE LOCK
Keyed One Side; Turn-Pushbutton on Other Side. 20 per case.
Code Finish Backset Price/Ea.
SCA53PDPLY4-605 Bright Brass 2-3/4" 239.00
SCA53PDPLY4-612 Satin Bronze 2-3/4" 239.00
SCA53PDPLY4-626 Satin Chromium Plated 2-3/4" 227.00
SCA53PDPLY8-605 Bright Brass 2-3/8" 239.00
SCA53PDPLY8-612 Satin Bronze 2-3/8" 239.00
SCA53PDPLY8-626 Satin Chromium Plated 2-3/8" 227.00
CLASSROOM LOCK
Keyed One Side; Always Unlocked on the other Side. 20 per case.
Code Finish Backset Price/Ea.
SCA70PDPLY8-605 Bright Brass 2-3/8" 239.00
SCA70PDPLY8-612 Satin Bronze 2-3/8" 239.00
SCA70PDPLY8-626 Satin Chromium Plated 2-3/8" 227.00
STOREROOM LOCK
Keyed Side Always Locked; Other Side Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA80PDPLY8-605 Bright Brass 2-3/8" 239.00
SCA80PDPLY8-612 Satin Bronze 2-3/8" 239.00
SCA80PDPLY8-626 Satin Chromium Plated 2-3/8" 227.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Price/Ea.
SCA170PLY-605 Bright Brass 70.00
SCA170PLY-612 Satin Bronze 70.00
SCA170PLY-626 Satin Chromium Plated 64.00
A SERIES HEAVY DUTY LOCKSETS
Quantity Discounts Available. Call for Quote.
Go To Table of Contents
588
www.acclock.com
Accredited Lock Supply
B
STOREROOM LOCK
Keyed Side Always Locked; Other Sided Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA80PDORB8-605 Bright Brass 2-3/8" 239.00
SCA80PDORB8-609 Satin Brass Blackened 2-3/8" 239.00
SCA80PDORB8-613 Oil Rubbed Bronze 2-3/8" 257.00
SCA80PFORB8-625 Bright Chromium Plated 2-3/8" 239.00
SCA80PDORB8-626 Satin Chromium Plated 2-3/8" 227.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Price/Ea.
SCA170ORB-605 Bright Brass 70.00
SCA170ORB-609 Satin Brass Blackened 70.00
SCA170ORB-613 Oil Rubbed Bronze 80.00
SCA170ORB-625 Bright Chromium Plated 70.00
SCA170ORB-626 Satin Chromium Plated 64.00
CLASSROOM
Keyed One Side; Always Unlocked on the Other. 20 per case.
Code Finish Backset Price/Ea.
SCA70PDORB8-605 Bright Brass 2-3/8" 239.00
SCA70PDORB8-609 Satin Brass Blackened 2-3/8" 239.00
SCA70PDORB8-613 Oil Rubbed Bronze 2-3/8" 257.00
SCA70PDORB8-625 Bright Chromium Plated 2-3/8" 239.00
SCA70PDORB8-626 Satin Chromium Plated 2-3/8" 227.00
ENTRANCE LOCK
Keyed One Side; Turn-Pushbutton on Other Side. 20 per case.
Code Finish Backset Price/Ea.
SCA53PDORB4-605 Bright Brass 2-3/4" 239.00
SCA53PDORB4-609 Satin Brass Blackened 2-3/4" 239.00
SCA53PDORB4-613 Oil Rubbed Bronze 2-3/4" 257.00
SCA53PDORB4-625 Bright Chromium Plated 2-3/4" 239.00
SCA53PDORB4-626 Satin Chromium Plated 2-3/4" 227.00
SCA53PDORB8-605 Bright Brass 2-3/8" 239.00
SCA53PDORB8-609 Satin Brass Blackened 2-3/8" 239.00
SCA53PDORB8-613 Oil Rubbed Bronze 2-3/8" 257.00
SCA53PDORB8-625 Bright Chromium Plated 2-3/8" 239.00
SCA53PDORB8-626 Satin Chromium Plated 2-3/8" 227.00
PASSAGE LATCH
Both Knobs Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA10SORB4-605 Bright Brass 2-3/4" 140.00
SCA10SORB4-609 Satin Brass Blackened 2-3/4" 140.00
SCA10SORB4-613 Oil Rubbed Bronze 2-3/4" 158.00
SCA10SORB4-625 Bright Chromium Plated 2-3/4" 140.00
SCA10SORB4-626 Satin Chromium Plated 2-3/4" 128.00
SCA10SORB8-605 Bright Brass 2-3/8" 140.00
SCA10SORB8-609 Satin Brass Blackened 2-3/8" 140.00
SCA10SORB8-613 Oil Rubbed Bronze 2-3/8" 158.00
SCA10SORB8-625 Bright Chromium Plated 2-3/8" 140.00
SCA10SORB8-626 Satin Chromium Plated 2-3/8" 128.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/ea.
SCA40SORB4-605 Bright 2-3/4" 140.00
SCA40SORB4-605/625 Bright Brass/ 2-3/4" 140.00
Bright Chromium Plated
SCA40SORB4-609 Satin Brass Blackened 2-3/4" 140.00
SCA40SORB4-609/625 Satin Brass Blackened/ 2-3/4" 140.00
Bright Chromium Plated
SCA40SORB4-613 Oil Rubbed Bronze 2-3/4" 158.00
SCA40SORB4-613/625 Oil Rubbed Bronze/ 2-3/4" 158.00
Bright Chromium Plated
SCA40SORB4-625 Bright Chromium Plated 2-3/4" 140.00
SCA40SORB4-626 Satin Chromium Plated 2-3/4" 128.00
SCA40SORB8-605 Bright Brass 2-3/8" 140.00
SCA40SORB8-605/625 Bright Brass/ 2-3/8" 140.00
Bright Chromium Plated
SCA40SORB8-609 Satin Brass Blackened 2-3/8" 140.00
SCA40SORB8-609/625 Satin Brass Blackend/ 2-3/8" 140.00
Bright Chromium Plated
SCA40SORB8-613 Oil Rubbed Bronze 2-3/8" 158.00
SCA40SORB8-613/625 Oil Rubbed Bronze/ 2 3/8" 158.00
Bright Chromium Plated
SCA40SORB8-625 Bright Chromium Plated 2-3/8" 140.00
SCA40SORB8-626 Satin Chromium Plated 2-3/8" 128.00
ORBIT
Symobol: ORB
Material: Wrought brass or bronze.
A SERIES HEAVY DUTY LOCKSETS
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 589
www.acclock.com
Accredited Lock Supply B
BATH/BEDROOOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCA40STUL4-605 Bright Brass 2-3/4" 140.00
SCA40STUL4-605/625 Bright Brass/ 2-3/4" 140.00
Bright Chromium Plated
SCA40STUL4-612 Satin Bronze 2-3/4" 140.00
SCA40STUL4-612/625 Satin Bronze/ 2-3/4" 140.00
Bright Chromium Plated
SCA40STUL4-626 Satin Chromium Plated 2-3/4" 128.00
SCA40STUL8-605 Bright Brass 2-3/8" 140.00
SCA40STUL8-605 Bright Brass/ 2-3/4" 140.00
Bright Chromium Plated
SCA40STUL8-612 Satin Bronze 2-3/8" 140.00
SCA40STUL8-612/625 Satin Bronze/ 2-3/4" 140.00
Bright Chromium Plate
SCA40STUL8-626 Satin Chromium Plated 2-3/8" 128.00
TULIP
Symbol: TUL
Material: Wrought brass,
bronze or stainless steel
PASSAGE LATCH
Both Knobs Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA10STUL4-612 Satin Bronze 2-3/4" 140.00
SCA10STUL4-605 Bright Brass 2-3/4" 140.00
SCA10STUL4-626 Satin Chromium Plated 2-3/4" 128.00
SCA10STUL8-605 Bright Brass 2-3/8" 140.00
SCA10STUL8-612 Satin Bronze 2-3/8" 140.00
SAC10STUL8-626 Satin Chromium Plated 2-3/8" 128.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Price/Ea.
SCA170TUL-612 Satin Bronze 70.00
SCA170TUL-626 Satin Chromium Plated 70.00
SAC170TUL-605 Bright Brass 64.00
ENTRANCE LOCK
Keyed One Side; Turn-Pushbutton on Other Side. 20 per case.
Code Finish Backset Price/Ea.
SCA53PDTUL4-605 Bright Brass 2-3/4" 239.00
SCA53PDTUL4-612 Satin Bronze 2-3/4" 239.00
SCA53PDTUL8-626 Satin Chromium Plated 2-3/4" 227.00
SCA53PDTUL8-605 Bright Brass 2-3/8" 239.00
SCA53PDTUL8-612 Satin Bronze 2-3/8" 239.00
SCA53PDTUL8-626 Satin Chromium Plated 2-3/8" 227.00
CLASSROOM LOCK
Keyed One Side; Always Unlocked on the Other. 20 per case.
Code Finish Backset Price/Ea.
SCA70PDTUL8-605 Bright Brass 2-3/8" 239.00
SCA70PDTUL8-612 Satin Bronze 2-3/8" 239.00
SCA70PDTUL8-626 Satin Chromium Plated 2-3/8" 227.00
STOREROOM LOCK
Keyed Side Always Locked; Other Side Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCA80PDTUL8-605 Bright Brass 2-3/8" 239.00
SCA80PDTUL8-612 Satin Bronze 2-3/8" 239.00
SCA80PDTUL8-626 Satin Chromium Plated 2-3/8" 227.00
A SERIES LOCKSETS
Reduce Cylinder Inventory
Multiple tailpiece cylinders allow high inventory flexibility
with low investment. Included with each cylinder are
tailpieces to suit these locks:
• A-Series (all designs)
• AL -Series
• O-Series Knobs
• O-Series Levers
• H-Series Knobs (all designs)
• NO-Series Levers
Cylinders are furnished 0-bitted. Conventional cylinders
are furnished with two (2) blank keys.
MULTIPLE TAILPIECE REPLACEMENT CYLINDER
Classic Conventional
(1) Pre-assembled cylinder a-bitted, less tailpiece
(1) A301-338 tailpiece, A & H-Series Orbit
(1) A700-031 tailpiece, A, AL, H-Series (except Orbit)
(1) C603-524 tailpiece, D-Series Levers
(1) C604-243 tailpiece, D-Series Knobs
(1) N523-023 tailpiece, ND-Series Levers (silver)
(2) C503-115 cap pin springs
(2) C503-116 cap pins
2 35-101 ke blanks
Everest® Conventional All 'C' Family
(1) Pre-assembled cylinder a-bitted, less tailpiece
(1) A301-338 tailpiece, A & H-Series Orbit
(1) A700-031 tailpiece, A, AL, H-Series (except Orbit)
(1) C603-524 tailpiece, D-Series Knobs
(1) C604-243 tailpiece, D-Series Levers
(1) N523-022 tailpiece, ND-Series Levers (black)
(2) C503-115 cap pin springs
(2) C503-116 cap pins
(2) 35-009 key blanks
SC40-100
5500
Specify
Keyway
(open keyways
only, restricted
keyways
higher price)
Quantity Discounts Available. Call for Quote.
Go To Table of Contents
590
www.acclock.com
Accredited Lock Supply
B
A & AL SERIES LATCHES AND STRIKE
“A” Series latches are adjustable for at or beveled edge doors.
Latches and strike are furnished in brass, bronze or chrome finishes
compatiable with lock trim. Faceplates and strikes are packaged with
a removable covering to protect finishes before installation. When
ordering, specify quantity, part number, finish and strike lip length.
Standard latches and strikes are shown in bolt type.
Square Corner Latches Drive-In Latches
Springlatch
Springlatch Deadlatch
Deadlatch
SPRINGLATCH
Code Description Finish Throw Backset HSG. Dia. Price/Ea.
SC11-068-605 1" x 2-1/4" Square Corner Bright Brass 1/2" 2-3/8" 7/8" 52.20
SC11-068-626 1" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 2-3/8" 7/8" 52.20
SC11-069-605 1" x 2-1/4" Round Corner Bright Brass 1/2" 2-3/8" 7/8" 52.20
SC11-069-626 1" x 2-1/4" Round Corner Satin Chromium Plated 1/2" 2-3/8" 7/8" 52.20
SC11-110-605 1" Circular Drive-In Non-UL Bright Brass 1/2" 2-3/8" 1" 52.20
SC11-110-626 1" Circular Drive-In Non-UL Satin Chromium Plated 1/2" 2-3/8" 1" 52.20
SC11-111-605 1" x 2-1/4" Square Corner Bright Brass 1/2" 2-3/4" 7/8" 52.20
SC11-111-626 1" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 2-3/4" 7/8" 52.20
SC11-112-605 1" x 2-1/4" Round Corner Bright Brass 1/2" 2-3/4" 7/8" 52.20
SC11-112-626 1" x 2-1/4" Round Corner Satin Chromium Plated 1/2" 2-3/4" 7/8" 52.20
SC11-113-605 1" Circular Drive-In Non-UL Bright Brass 1/2" 2-3/4" 1" 52.20
SC11-116-605 1-1/8" x 2-1/4" Bright Brass 1/2" 2-3/4" 1" 52.20
SC11-116-626 1-1/8" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 2-3/4" 1" 52.20
SC11-118-605 1-1/8" x 2-1/4" Square Corner Bright Brass 1/2" 3-3/4" 1" 56.20
SC11-118-626 1-1/8" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 3-3/4" 1" 56.20
SC41-005 5" Backset Link Use w/2 3/8" latch 19.70
DEADLATCH
Code Description Finish Throw Backset HSG. Dia. Price/Ea.
SC11-085-605 1" x 2-1/4" Square Corner Bright Brass 1/2" 2-3/8" 7/8" 52.20
SC11-085-613 1" x 2-1/4" Square Corner Oil Rubbed Bronze 1/2" 2-3/8" 7/8" 52.20
SC11-085-626 1" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 2-3/8" 7/8" 52.20
SC11-088-605 1" x 2-1/4" Round Corner Bright Brass 1/2" 2-3/8" 7/8" 52.20
SC11-088-626 1" x 2-1/4" Round Corner Satin Chromium Plated 1/2" 2-3/8" 7/8" 52.20
SC11-091-605 1" x 2-1/4" Square Corner Bright Brass 1/2" 2-3/4" 7/8" 52.20
SC11-091-626 1" x 2-1/4" Square Corner Satin Chormium Plated 1/2" 2-3/4" 7/8" 52.20
SC11-092-605 1" x 2-1/4" Round Corner Bright Brass 1/2" 2-3/4" 7/8" 52.20
SC11-092-626 1" x 2-1/4" Round Corner Satin Chromium Plated 1/2" 2-3/4" 7/8" 52.20
SC11-096-605 1-1/8" x 2-1/4" Square Corner Bright Brass 1/2" 2-3/4" 1" 52.20
SC11-096-610 1-1/8" x 2-1/4" Square Corner Bright Brass, Blackened 1/2" 2-3/4" 1" 52.20
SC11-096-626 1-1/8" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 2-3/4" 1" 52.20
SC11-103-605 1-1/8" x 2-1/4" Square Corner Bright Brass 1/2" 3-3/4" 1" 56.20
SC11-103-626 1-1/8" x 2-1/4" Square Corner Satin Chromium Plated 1/2" 3-3/4" 1" 56.20
SC11-104-605 1" Circular Drive-in Non-UL Bright Brass 1/2" 2-3/8" 1" 52.20
SC11-104-626 1" Circular Drive-in Non-UL Satin Chromium Plated 1/2" 2-3/8" 1" 52.20
SC11-105-605 1" Circular Drive-in Non-UL Bright Brass 1/2" 2-3/4" 1" 52.20
SC11-105-626 1" Circular Drive-in Non-UL Satin Chromium Plated 1/2" 2-3/4" 1" 52.20
C
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 591
www.acclock.com
Accredited Lock Supply B
AL SERIES STANDARD DUTY COMMERCIAL LOCKSETS
For standard duty, commercial exterior and interior doors for medical, office, hotel/motel, public buildings, religious, multi-family, retail/storefront and government
facilities. Also for heavy duty residential.
Certifications: ANSI A156.2-2003, Series 4000 Grade 2.
UL listed for all functions up to 3-hour doors.
Exposed Trim: Wrought brass and bronze. Levers are pressure cast zinc, plated
to match finish symbols.
Keying: 6 pin tumbler with two nickel silver keys per lock. Stock locks are
keyed 5 pin. Other keying options available from factory include
masterkeying, grandmasterkeying, construction keying and inter-
changeable core.
Door Range: 1-3/8" to 1-7/8" standard.
Backset: 2-3/4" standard. 2-3/8" and 3-3/4" backset latches available. 5"
backset links are also available.
The AL-Series keyed lever lock utilizes the Schlage original
A-Series cylindrical chassis with stylish lever designs supported
by heavy duty spring cages. This design provides strength and
performance in the more abusive commercial Grade 2 applica-
tions. The AL-Series is available in a wide variety of keyed and
non-keyed functions and in the most popular finishes. The AL-
Series also features lever designs that are compatible with the
complete family of Schlage ADA compliant commercial grade
levers.
P/N Function Finish Price
SCAL10SSAT-605 Passage Polished Brass 180.00
SCAL10SSAT-626 Passage Satin Chromium 168.00
SCAL40SSAT-605 Privacy Polished Brass 203.00
SCAL40SSAT-626 Privacy Satin Chromium 191.00
SCAL40SSAT-605/625 Bath Brass/Chrome 203.00
SCAL53PDSAT-605 Entrance Polished Brass 256.00
SCAL53PDSAT-625 Entrance Polished Chrome 256.00
SCAL53PDSAT-626 Entrance Satin Chromium 244.00
SCAL70PDSAT-605 Classroom Polished Brass 256.00
SCAL70PDSAT-626 Classroom Satin Chromium 244.00
SCAL80PDSAT-605 Storeroom Polished Brass 256.00
SCAL80PDSAT-626 Storeroom Satin Chromium 244.00
SCAL170SAT-605 Single Dummy Polished Brass 103.00
SCAL170SAT-626 Single Dummy Satin Chromium 97.00
SATURN
Door Preparation
Quantity Discounts Available. Call for Quote.
Use Pro-Lok IN20-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN20-FP-S-9
or EWP-IN20-FP-S-14 Flat Plate
Go To Table of Contents
592
www.acclock.com
Accredited Lock Supply
B
P/N Function Finish Price
SCAL10SJUP-605 Passage Polished Brass 180.00
SCAL10SJUP-606 Passage Satin Brass 180.00
SCAL10SJUP-625 Passage Polished Chrome 180.00
SCAL10SJUP-626 Passage Satin Chromium 168.00
SCAL40SJUP-605 Privacy Polished Brass 203.00
SCAL40SJUP-606 Privacy Satin Brass 203.00
SCAL40SJUP-625 Privacy Polished Chrome 203.00
SCAL40SJUP-626 Privacy Satin Chromium 191.00
SCAL40SJUP-605/625 Bath Brass/Chrome 203.00
SCAL53PDJUP-605 Entrance Polished Brass 256.00
SCAL53PDJUP-606 Entrance Satin Brass 256.00
SCAL53PDJUP-625 Entrance Polished Chrome 256.00
SCAL53PDJUP-626 Entrance Satin Chromium 244.00
SCAL70PDJUP-605 Classroom Polished Brass 256.00
SCAL70PDJUP-606 Classroom Satin Brass 256.00
SCAL70PDJUP-625 Classroom Polished Chrome 256.00
SCAL70PDJUP-626 Classroom Satin Chrome 244.00
SCAL80PDJUP-605 Storeroom Polished Brass 256.00
SCAL80PDJUP-606 Storeroom Satin Brass 256.00
SCAL80PDJUP-625 Storeroom Polished Chrome 256.00
SCAL80PDJUP-626 Storeroom Satin Chromium 244.00
SCAL170JUP-605 Single Dummy Polished Brass 103.00
SCAL170JUP-606 Single Dummy Satin Brass 103.00
SCAL170JUP-625 Single Dummy Polished Chrome 103.00
SCAL170JUP-626 Single Dummy Satin Chromium 97.00
P/N Function Finish Price
SCAL10SNEP-605 Passage Polished Brass 180.00
SCAL10SNEP-625 Passage Polished Chrome 180.00
SCAL10SNEP-626 Passage Satin Chromium 168.00
SCAL40SNEP-605 Privacy Polished Brass 203.00
SCAL40SNEP-625 Privacy Polished Chrome 203.00
SCAL40SNEP-626 Privacy Satin Chromium 191.00
SCAL40SNEP-605/625 Bath Brass/Chrome 203.00
SCAL53PDNEP-605 Entrance Polished Brass 256.00
SCAL53PDNEP-625 Entrance Polished Chrome 256.00
SCAL53PDNEP-626 Entrance Satin Chromium 244.00
SCAL70PDNEP-605 Classroom Polished Brass 256.00
SCAL70PDNEP-625 Classroom Polished Chrome 256.00
SCAL70PDNEP-626 Classroom Satin Chromium 244.00
SCAL80PDNEP-605 Storeroom Polished Brass 256.00
SCAL80PDNEP-625 Storeroom Polished Chrome 256.00
SCAL80PDNEP-626 Storeroom Satin Chromium 244.00
SCAL170NEP-605 Single Dummy Polished Brass 103.00
SCAL170NEP-625 Single Dummy Polsihed Chrome 103.00
SCAL170NEP-626 Single Dummy Satin Chromium 97.00
NEPTUNE
JUPITER
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 593
www.acclock.com
Accredited Lock Supply B
D SERIES KNOBS/ND SERIES LEVERS EXTRA HEAVY DUTY COMMERICAL LOCKSETS
Top-of-the-line in heavy duty commerical locking applications. Specified when the highest quality lock mechanisms are required. Precision manufactured to high
tolerances and exacting specifications.
D Series is best suited for commercial, institutional and industrial installations.
D Series D53PD
Applications:
Extra heavy duty commerical, residential, institutional and gov-
ernment buildings. (Knobs are not ADA approved)
Certifications:
ANSI A156.2-2003, Series 4000, Grade 1.
(FF-H-106C Series 161.) UL Listed for 3-hour re door.
Cylindrical Housing:
Heavy gauge cold rolled steel mechanisms are corrossion treated
for normal atmosphere conditions.
Keying:
6 Pin tumbler with two nickel silver keys per lock. Stock locks
are keyed 5 pin.
Door Range:
1-3/8" to 2" standard. 2" to 2-1/2" regular parts assembled to order.
Backset:
2-3/4" standard. 2-3/8" and 3-3/4" backset latches available. 5"
links available.
Handing:
All ND-Series lever locksets are non-handed.
Door Thickness:
1-5/8" to 2-1/8” (41mm-54mm) standard including
Vandlgard® functions.
B ackset:
2-3/4" (70mm) standard. 2-3/8", 3-3/4" and 5" (60mm, 95mm, 127 mm) optional.
Faceplate:
Brass, bronze or stainless steel. 1-1/8” x 2-1/4" (29 mm x 57mm) square corner,
beveled.
Lock Chassis:
Zinc plated for corrosion resistance.
Latch Bolt:
Steel, 1/2" (12mm) throw, deadlocking on keyed and exterior functions. 3/4"
(19mm) throw anti-friction latch available for pairs of re doors.
Exposed Trim:
Levers: Pressure cast zinc, plated to match finish symbols. Roses: Solid brass.
Strike:
ANSI curved lip strike 1-1/4" x 4-7/8” X 1-3/16" lip to center standard. Optional
strikes, lip lengths and ANSI strike box available.
Cylinder & Keys:
6-pin Everest C123 keyway standard with two patented nickel silver keys per lock.
Keying Options:
Interchangeable core and Primus® high security cylinders. Master keying, grand
master keying and construction keying.
Warranty:
Seven-year limited for all functions including Vandlgard® .
ANSI
Meets or exceeds A156.2-2003, Series 4000, Grade 1 strength and operational
requirements. Meets A117.1 Accessibility Code.
Federal
Meets FF-H-I06C Series 161.
California State Reference Code
(Formerly Tide 19, California State Fire Marshal Standard)
All levers with returns comply; levers return to within 1/2" of door face.
Use Pro-Lok IN20-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN20-FP-S-9
or EWP-IN20-FP-S-14 Flat Plate
Go To Table of Contents
594
www.acclock.com
Accredited Lock Supply
B
PASSAGE LATCH
Both Sides Always Unlocked. 10 per case.
Code Finish Backset Price/Ea.
SCD10STUL4-605 Bright Brass 2-3/4" 456.00
SCD10STUL4-612 Satin Bronze Plated 2-3/4" 456.00
SCD10STUL4-626 Satin Chromium Plated 2-3/4" 444.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 10 per case.
Code Finish Backset Price/Ea.
SCD40STUL4-605 Bright Brass 2-3/4" 567.00
SCD40STUL4-605/625 Bright Brass/ 2-3/4" 567.00
Bright Chromium Plated
SCD40STUL4-612 Satin Bronze Plated 2-3/4" 567.00
SCD40STUL4-612/625 Satin Bronze/ 2-3/4" 567.00
Bright Chromium
SCD40STUL4-626 Satin Chromium Plated 2-3/4" 555.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 10 per case.
Code Finish Backset Price/Ea.
SCD53PDTUL4-605 Bright Brass 2-3/4" 659.00
SCD53PDTUL4-612 Satin Bronze Plated 2-3/4" 659.00
SCD53PDTUL4-626 Satin Chromium Plated 2-3/4" 647.00
CLASSROOM LOCK
Keyed On Outside; Always Unlocked Inside. 10 per case.
Code Finish Backset Price/Ea.
SCD70PDTUL4-605 Bright Brass 2-3/4" 659.00
SCD70PDTUL4-612 Satin Bronze Plated 2-3/4" 659.00
SCD70PDTUL4-626 Satin Chromium Plated 2-3/4" 647.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlock. 10 per case.
Code Finish Backset Price/Ea.
SCD80PDTUL4-605 Bright Brass 2-3/4" 659.00
SCD80PDTUL4-612 Satin Bronze Plated 2-3/4" 659.00
SCD80PDTUL4-626 Satin Chromium Plated 2-3/4" 647.00
TULIP
Symbol: TUL
Material: Wrought brass,
bronze or stainless steel.
ORBIT
Symbol: ORB
Material: Wrought brass,
bronze or stailnless steel.
D SERIES EXTRA HEAVY DUTY COMMERCIAL LOCKSETS
PASSAGE LATCH
Both Sides Always Unlocked. 10 per case.
Code Finish Backset Price/Ea.
SCD10SORB4-605 Bright Brass 2-3/4" 456.00
SCD10SORB4-626 Satin Chromium Plated 2-3/4" 444.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 10 per case.
Code Finish Backset Price/Ea.
SCD40SORB4-605 Bright Brass 2-3/4" 567.00
SCD40SORB4-605/625 Bright Brass/ 2-3/4" 567.00
Bright Chromium Plated
SCD40SORB4-626 Satin Chromium Plated 2-3/4" 555.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 10 per case.
Code Finish Backset Price/Ea.
SCD53PDORB4-605 Bright Brasss 2-3/4" 659.00
SCD53PDORB4-626 Satin Chromium Plated 2-3/4" 647.00
CLASSROOM LOCK
Keyed On Outside; Always Unlocked Inside. 10 per case.
Code Finish Backset Price/Ea.
SCD70DORB4-605 Bright Brass 2-3/4" 659.00
SCD70DORB4-626 Satin Chromium Plated 2-3/4" 647.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 10 per case.
Code Finish Backset Price/Ea.
SCD80PDORB4-605 Bright Brass 2-3/4" 659.00
SCD80PDORB4-626 Satin Chromium Plated 2-3/4" 647.00
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 595
www.acclock.com
Accredited Lock Supply B
PLYMOUTH
Symbol: PLY
Material: Wrought brass,
bronze or stainless steel.
RHODES
Material: Lever; pressure
cast zinc. Rose; wrought
brass or bronze.
Symbol: RHO
PASSAGE LATCH
Both Sides Always Unlocked. 10 per case.
Code Finish Backset Price/Ea.
SCD10SPLY4-605 Bright Brass 2-3/4" 456.00
SCD10SPLY4-612 Satin Bronze 2-3/4" 456.00
SCD10SPLY4-626 Satin Chromium Plated 2-3/4" 444.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 10 per case.
Code Finish Backset Price/Ea.
SCD40SPLY4-605 Bright Brass 2-3/4" 567.00
SCD40SPLY4-605/625 Bright Brass/ 2-3/4" 567.00
Satin Chromium Plated
SCD40SPLY4-612 Satin Bronze 2-3/4" 567.00
SCD40SPLY4-626 Satin Chromium Plated 2-3/4" 555.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 10 per case.
Code Finish Backset Price/Ea.
SCD53PDPLY4-605 Bright Brass 2-3/4" 689.00
SCD53PDPLY4-612 Satin Bronze 2-3/4" 659.00
SCD53PDPLY4-626 Satin Chromium Plated 2-3/4" 647.00
CLASSROOM LOCK
Keyed on Outside; Always Unlocked inside. 10 per case.
Code Finish Backset Price/Ea.
SCD70PDPLY4-605 Bright Brass 2-3/4" 659.00
SCD70PDPLY4-612 Satin Bronze 2-3/4" 659.00
SCD70PDPLY4-626 Satin Chromium Plated 2-3/4" 647.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 10 per case.
Code Finish Backset Price/Ea.
SCD80PDPLY4-605 Bright Brass 2-3/4" 659.00
SCD80PDPLY4-612 Satin Bronze 2-3/4" 659.00
SCD80PDPLY4-626 Satin Chromium Plated 2-3/4" 647.00
PASSAGE LATCH
Both Sides Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND10SRHO4-605 Bright Brass 2-3/4" 391.00
SCND10SRHO4-626 Satin Chromium Plated 2-3/4" 379.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 6 per case.
Code Finish Backset Price/Ea.
SCND40SRHO4-605 Bright Brass 2-3/4" 448.00
SCND40SRHO4-626 Satin Chromium Plated 2-3/4" 436.00
ENTRANCE/OFFICE LOCK
Push Button Locking.Pushing button locks outside lever until unlocked with key or
by turning inside lever. 6 per case.
Code Finish Backset Price/Ea.
SCND50PDRHO4-605 Bright Brass 2-3/4" 529.00
SCND50PDRHO4-626 Satin Chromium Plated 2-3/4" 517.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 6 per case.
Code Finish Backset Price/Ea.
SCND53PDRHO4-605 Bright Brass 2-3/4" 529.00
SCND53PDRHO4-626 Satin Chromium Plated 2-3/4" 517.00
CLASSROOM LOCK
Keyed On Outside; Always Unlocked inside. 6 per case.
Code Finish Backset Price/Ea.
SCND70PDRHO4-605 Bright Brass 2-3/4" 529.00
SCND70PDRHO4-626 Satin Chromium Plated 2-3/4" 517.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND80PDRHO4-605 Bright Brass 2-3/4" 529.00
SCND80PDRHO4-626 Satin Chromium Plated 2-3/4" 517.00
INTERCHANGEABLE CORE (cores not included)
Designed to accept SFIC interchangeable core cylinders .
Code Function Backset Price/Ea.
SCND53BDRHO4-626 Entrance 2-3/4" 517.00
SCND70BDRHO4-626 Classroom 2-3/4" 517.00
SCND80BDRHO4-626 Storeroom 2-3/4" 517.00
SCND82BDRHO4-626 Institution 2-3/4" 615.00
D SERIES EXTRA HEAVY DUTY COMMERCIAL LOCKSETS
Quantity Discounts Available. Call for Quote.
Go To Table of Contents
596
www.acclock.com
Accredited Lock Supply
B
ATHENS
Material: Lever; pressure
cast zinc. Rose; wrought
brass or bronze.
Symbol: ATH
PASSAGE LATCH
Both Sides Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND10SATH4-605 Bright Brass 2-3/4" 391.00
SCND10SATH4-606 Satin Brass 2-3/4" 391.00
SCND10SATH4-625 Polished Chrome 2-3/4" 391.00
SCND10SATH4-626 Satin Chromium Plated 2-3/4" 379.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 6 per case.
Code Finish Backset Price/Ea.
SCND40SATH4-605 Bright Brass 2-3/4" 448.00
SCND40SATH4-606 Satin Brass 2-3/4" 448.00
SCND40SATH4-625 Polished Chrome 2-3/4" 448.00
SCND40SATH4-626 Satin Chromium Plated 2-3/4" 436.00
ENTRANCE/OFFICE LOCK
Push Button Locking.Pushing button locks outside lever until unlocked with key or
by turning inside lever. 6 per case.
Code Finish Backset Price/Ea.
SCND50PDATH4-605 Bright Brass 2-3/4" 529.00
SCND50PDATH4-606 Satin Brass 2-3/4" 529.00
SCND50PDATH4-625 Polished Chrome 2-3/4" 529.00
SCND50PDATH4-626 Satin Chromium Plated 2-3/4" 517.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 6 per case.
Code Finish Backset Price/Ea.
SCND53PDATH4-605 Bright Brass 2-3/4" 529.00
SCND53PDATH4-606 Satin Brass 2-3/4" 529.00
SCND53PDATH4-625 Polished Chrome 2-3/4" 529.00
SCND53PDATH4-626 Satin Chromium Plated 2-3/4" 517.00
CLASSROOM LOCK
Keyed On Outside; Always Unlocked inside. 6 per case.
Code Finish Backset Price/Ea.
SCND70PDATH4-605 Bright Brass 2-3/4" 529.00
SCND70PDATH4-626 Satin Chromium Plated 2-3/4" 517.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND80PDATH4-605 Bright Brass 2-3/4" 529.00
SCND80PDATH4-626 Satin Chromium Plated 2-3/4" 517.00
SPARTA
Material: Lever; pressure
cast zinc. Rose; wrought
brass or bronze.
Symbol: SPA
PASSAGE LATCH
Both Sides Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND10SSPA4-605 Bright Brass 2-3/4" 391.00
SCND10SSPA4-626 Satin Chromium Plated 2-3/4" 379.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 6 per case.
Code Finish Backset Price/Ea.
SCND40SSPA4-605 Bright Brass 2-3/4" 448.00
SCND40SSPA4-626 Satin Chromium Plated 2-3/4" 436.00
ENTRANCE/OFFICE LOCK
Push Button Locking.Pushing button locks outside lever until unlocked with key or
by turning inside lever. 6 per case.
Code Finish Backset Price/Ea.
SCND50PDSPA4-605 Bright Brass 2-3/4" 529.00
SCND50PDSPA4-626 Satin Chromium Plated 2-3/4" 517.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 6 per case.
Code Finish Backset Price/Ea.
SCND53PDSPA4-605 Bright Brass 2-3/4" 529.00
SCND53PDSPA4-626 Satin Chromium Plated 2-3/4" 517.00
CLASSROOM LOCK
Keyed On Outside; Always Unlocked inside. 6 per case.
Code Finish Backset Price/Ea.
SCND70PDSPA4-605 Bright Brass 2-3/4" 529.00
SCND70PDSPA4-626 Satin Chromium Plated 2-3/4" 517.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND80PDSPA4-605 Bright Brass 2-3/4" 529.00
SCND80PDSPA4-626 Satin Chromium Plated 2-3/4" 517.00
ALSO STOCKED IN SATIN BRASS (606) &
POLISHED CHROME (625)
Use Pro-Lok IN20-PRO/INCL-PRO Templates
Use Pro-Lok EWP-IN20-FP-S-9
or EWP-IN20-FP-S-14 Flat Plate
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 597
www.acclock.com
Accredited Lock Supply B
OMEGA
Material: Pressure cast zinc
lever. Wrought brass rose.
Symbol: OME
PASSAGE LATCH
Both Sides Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND10SOME4-605 Bright Brass 2-3/4" 391.00
SCND10SOME4-619 Satin Nickel 2-3/4" 391.00
SCND10SOME4-626 Satin Chromium Plated 2-3/4" 379.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 6 per case.
Code Finish Backset Price/Ea.
SCND40SOME4-605 Bright Brass 2-3/4" 448.00
SCND40SOME4-619 Satin Nickel 2-3/4" 448.00
SCND40SOME4-626 Satin Chromium Plated 2-3/4" 436.00
ENTRANCE/OFFICE LOCK
Push Button Locking.Pushing button locks outside lever until unlocked with key or
by turning inside lever. 6 per case.
Code Finish Backset Price/Ea.
SCND50PDOME4-605 Bright Brass 2-3/4" 529.00
SCND50PDOME4-619 Satin Nickel 2-3/4" 529.00
SCND50PDOME4-626 Satin Chromium Plated 2-3/4" 517.00
ENTRANCE LOCK
Keyed on Outside; Turn-Pushbutton on Inside. 6 per case.
Code Finish Backset Price/Ea.
SCND53PDOME4-605 Bright Brass 2-3/4" 529.00
SCND53PDOME4-619 Satin Nickel 2-3/4" 529.00
SCND53PDOME4-626 Satin Chromium Plated 2-3/4" 517.00
CLASSROOM LOCK
Keyed On Outside; Always Unlocked inside. 6 per case.
Code Finish Backset Price/Ea.
SCND70PDOME4-605 Bright Brass 2-3/4" 529.00
SCND70PDOME4-626 Satin Chromium Plated 2-3/4" 517.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 6 per case.
Code Finish Backset Price/Ea.
SCND80PDOME4-605 Bright Brass 2-3/4" 529.00
SCND80PDOME4-626 Satin Chromium Plated 2-3/4" 517.00
Quick facts about NDE Series and ENGAGE:
• ENGAGE™ is a connectivity platform that simplies the ability to connect people
and openings to deliver cost effective intelligence and efficiency to any facility.
• Conveniently retrots into standard ND door prep without drilling additional holes
• Installs in about 15 minutes with just a Phillips screwdriver
• Compatible with proximity as well as aptiQ™ and aptiQmobile™ smart credentials
• ENGAGE™ cloud-based web and mobile apps make it simple to congure lock
settings, add users, and view audits and alerts from anywhere
• For added features and benets, the NDE Series wireless lock can be managed
with software from one of our access control alliance partners.
ENGAGE™ Technology Solutions - NDE SERIES
NDE Storeroom Function (cores not included)
Designed to accept Schlage FSIC interchangeable core cylinders .
Code Style Backset Price/Ea.
SCNDE80JDRHO-626 Rhodes 2-3/4" 766.00
SCNDE80JDSPA-626 Sparta 2-3/4" 766.00
SCNDE80JDATH-626 Athens 2-3/4" 766.00
Other cylinder configurations available, call for your exact needs.
Flexible solutions that fit your business needs
ENGAGE technology streamlines the ability to manage access using electronic
credentials.
Cloud-based mobile and web apps make it easy to manage locks and users from
wherever you are, quickly changing and tracking who has access to each door.
Use the ENGAGE apps for the following:
• Congure and manage locks • Enroll and manage credentials
• View history (audits) and alerts by lock • Perform diagnostics (mobile app only)
Updates to the locks can be sent in two different ways, depending on your business
needs. NDE wireless locks are Wi-Fi-enabled and can be connected to the IT network
for daily updates. These updates are scheduled by the ENGAGE cloud to occur
automatically within 24 hours of the requested change. In addition, the ENGAGE
mobile app can send updates to the lock while the user is at the door—which is
beneficial when the lock is in a space where Wi-Fi connectivity is not practical or
when changes to the lock need to be made immediately.
The new Schlage® NDE Series wireless lock with ENGAGE™ technology is designed
to be easy to install, connect, manage and use. Developed specifically for facilities
that want to upgrade to electronic credentials for improved security and efficiency,
it is ideal for interior office doors, common area doors and sensitive storage spaces
with a cylindrical door prep.
Go To Table of Contents
598
www.acclock.com
Accredited Lock Supply
B
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 30 per case.
Code Finish Backset Price/Ea.
SCF40NBEL8-605 Bright Brass 2-3/8 to 3/4" 29.00
SCF40NBEL8-605/625 Bright Brass/ 2-3/8 to 3/4" 35.00
Bright Chromium Plated
ENTRANCE LOCK
Keyed on Outside; Turn Button on Inside. 20 per case.
Code Finish Backset Price/Ea.
SCF51ANBEL8-605 Bright Brass 2-3/8 to 3/4" 47.00
SCF51ANBEL8-626 Satin Chromium 2-3/8 to 3/4" 53.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCF80NBEL8-605 Bright Brass 2-3/8 to 3/4" 57.00
SINGLE DUMMY TRIM
For One Side of Door. 30 per case.
Code Finish Backset Price/Ea.
SCF170BEL-605 Bright Brass 2-3/8 to 3/4" 14.00
PASSAGE LATCH
Both Sides Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCF10FLA-505 Lifetime Bright Brass 2-3/8 to 3/4" 57.00
SCF10FLA-605 Bright Brass 2-3/8 to 3/4" 49.00
SCF10FLA-609 Satin Brass Blackened 2-3/8 to 3/4" 55.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCF40FLA-605 Bright Brass 2-3/8 to 3/4" 51.00
SCF40FLA-609 Satin Brass Blackened 2-3/8 to 3/4" 57.00
SCF40FLA-625 Bright Chromium Plated 2-3/8 to 3/4" 57.00
SCF40FLA-LH-605/625 Bright Brass/
Bright Chromium Plated 2-3/8 to 3/4" 57.00
ENTRANCE LOCK
Keyed on Outside; Turn Button on Inside. 20 per case.
Code Finish Backset Price/Ea.
SCF51AFLA-505 Lifetime Bright Brass 2-3/8 to 3/4" 107.00
SCF51AFLA-605 Bright Brass 2-3/8 to 3/4" 99.00
SCF51AFLA-609 Satin Brass Blackened 2-3/8 to 3/4" 105.00
SCF51AFLA-625 Bright Chromium Plated 2-3/8 to 3/4" 105.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Backset Price/Ea.
SCF170FLA-605 Bright Brass 2-3/8 to 3/4" 25.00
SCF170FLA-609 Satin Brass Blackened 2-3/8 to 3/4" 28.00
PASSAGE LATCH
Both Knobs Always Unlocked. 30 per case.
Code Finish Backset Price/Ea.
SCF10NBEL8-605 Bright Brass 2-3/8 to 3/4" 27.00
BELL
Symbol: BEL
Material: Wrought brass or bronze.
FLAIR
Specify LH or RH
PASSAGE LATCH
Both Knobs Always Unlocked. 30 per case.
Code Finish Backset Price/Ea.
SCF10NGE08-605 Bright Brass 2-3/8 to 3/4" 27.00
SCF10NGE08-609 Satin Brass Blackened 2-3/8 to 3/4" 33.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 30 per case.
Code Finish Backset Price/Ea.
SCF40NGE08-605 Bright Brass 2-3/8 to 3/4" 29.00
SCF40NGE08-605/625 Bright Brass/ 2-3/8 to 3/4" 35.00
Bright Chromium Plated
SCF40NGE08-609 Satin Brass Blackened 2-3/8 to 3/4" 35.00
SCF40NGE08-609/625 Satin Brass Blackened 2-3/8 to 3/4" 35.00
Bright Chromium Plated
ENTRANCE LOCK
Keyed on Outside; Turn Button on Inside. 20 per case.
Code Finish Backset Price/Ea.
SCF51ANGEO8-605 Bright Brass 2-3/8 to 3/4" 47.00
SCF51ANGEO8-609 Satin Brass Blackened 2-3/8 to 3/4" 53.00
GEORGIAN
F SERIES STANDARD DUTY RESIDENTIAL LOCKSETS
Quantity Discounts Available. Call for Quote.
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 599
www.acclock.com
Accredited Lock Supply B
PASSAGE LATCH
Both Knobs Always Unlocked. 30 per case.
Code Finish Backset Price/Ea.
SCF10NORB8-605 Bright Brass 2-3/8 to 3/4" 34.00
SCF10NORB8-609 Satin Brass Blackened 2-3/8 to 3/4" 40.00
SCF10NORB8-626 Satin Chromium Plated 2-3/8 to 3/4" 40.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 30 per case.
Code Finish Backset Price/Ea.
SCF40NORB8-605 Bright Brass 2-3/8 to 3/4" 36.00
SCF40NORB8-605/625 Bright Brass/ 2-3/8 to 3/4" 42.00
Bright Chromium Plated
SCF40NORB8-609 Satin Brass Blackened 2-3/8 to 3/4" 42.00
SCF40NORB8-609/625 Satin Brass Blackened/ 2-3/8 to 3/4" 42.00
Bright Chromium Plated
SCF40NORB8-626 Satin Chromium Plated 2-3/8 to 3/4" 42.00
BATH/BEDROOM PRIVACY LOCK
Pushbutton Locking. 30 per case.
Code Finish Backset Price/Ea.
SCF40NPLY8-605 Bright Brass 2-3/8 to 3/4" 29.00
SCF40NPLY8-605/625 Bright Brass/ 2-3/8 to 3/4" 35.00
Bright Chromium Plated
SCF40NPLY8-626 Satin Chromium Plated 2-3/8 to 3/4" 35.00
ENTRANCE LOCK
Keyed on Outside; Turn Button on Inside. 20 per case
Code Finish Backset Price/Ea.
SCF51ANPLY8-605 Bright Brass 2-3/8 to 3/4" 47.00
SCF51ANPLY8-626 Satin Chromium Plated 2-3/8 to 3/4" 53.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 20 per case
Code Finish Backset Price/Ea.
SCF80NPLY8-605 Bright Brass 2-3/8 to 3/4" 57.00
SCF80NPLY8-626 Satin Chromium Plated 2-3/8 to 3/4" 63.00
PASSAGE LATCH
Both Knobs Always Unlocked. 30 per case.
Code Finish Backset Price/Ea.
SCF10NPLY8-605 Bright Brass 2-3/8 to 3/4" 27.00
SCF10NPLY8-626 Satin Chromium Plated 2-3/8 to 3/4" 33.00
ORBIT
Symbol: ORB
Material: Wrought brass or
bronze.
ENTRANCE LOCK
Keyed on Outside; Turn Button Inside. 20 per case.
Code Finish Backset Price/Ea.
SCF51ANORB8-605 Bright Brass 2-3/8 to 3/4" 54.00
SCF51ANORB8-609 Satin Brass Blackened 2-3/8 to 3/4" 60.00
SCF51ANORB8-626 Satin Chromium Plated 2-3/8 to 3/4" 60.00
STOREROOM LOCK
Outside Always Locked; Inside Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCF80NORB8-605 Bright Brass 2-3/8 to 3/4" 64.00
SCF80NORB8-609 Satin Brass Blackened 2-3/8 to 3/4" 70.00
SCF80NORB8-626 Satin Chromium Plated 2-3/8 to 3/4" 70.00
SINGLE DUMMY TRIM
For One Side of Door. 30 per case.
Code Finish Backset Price/Ea.
SCF170NORB8-605 Bright Brass 2-3/8 to 3/4" 17.00
SCF170NORB8-609 Satin Brass Blackened 2-3/8 to 3/4" 20.00
SCF170NORB8-626 Satin Chromium Plated 2-3/8 to 3/4" 20.00
PLYMOUTH
Symbol: PYL
Material: Wrought brass
or bronze.
F SERIES STANDARD DUTY RESIDENTIAL LOCKSETS
SINGLE DUMMY TRIM
For One Side of Door. 30 per case.
Code Finish Backset Price/Ea.
SCF170NPLY8-605 Bright Brass 2-3/8 to 3/4" 14.00
SCF170NPLY8-626 Satin Chromium Plated 2-3/8 to 3/4" 17.00
Go To Table of Contents
600
www.acclock.com
Accredited Lock Supply
B
PASSAGE LATCH
Both Sides Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCF10ELA-605 Bright Brass 2-3/8 to 3/4" 46.00
SCF10ELA-626 Satin Chromium 2-3/8 to 3/4" 52.00
BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCF40ELA-605 Bright Brass 2-3/8 to 3/4" 48.00
SCF40ELA-605/625 Bright Brass/ Chromium 2-3/8 to 3/4" 54.00
SCF40ELA-626 Satin Chromium 2-3/8 to 3/4" 54.00
PASSAGE LATCH
Both Sides Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCF10JAZ-605 Bright Brass 2-3/8 to 3/4" 46.00
ELAN
JAZZ
F SERIES STANDARD DUTY RESIDENTIAL LOCKSETS
ACCENT
Specify LH/RH
PASSAGE LATCH
Both Sides Always Unlocked. 20 per case.
Code Finish Backset Price/Ea.
SCF10ACC-505 Lifetime Bright Brass 2-3/8 to 3/4" 57.00
SCF10ACC-608 Satin Brass 2-3/8 to 3/4" 55.00
SCF10ACC-618 Polished Nickel 2-3/8 to 3/4" 55.00
SCF10ACC-619 Satin Nickel 2-3/8 to 3/4" 55.00
SCF10ACC-621 Distressed Nickel 2-3/8 to 3/4" 61.00
SCF10ACC-622 Matte Black 2-3/8 to 3/4" 61.00
SCF10ACC-626 Satin Chrome 2-3/8 to 3/4" 55.00
SCF10ACC-716 Aged Bronze 2-3/8 to 3/4" 57.00
Artisan Finishes (505, 608, 619, 621, 622, 716 available in all functions)
ENTRANCE LOCK
Keyed on Outside; Turn Button on Inside. 20 per case.
Code Finish Backset Price/Ea.
SCF51AACC-505 Lifetime Bright Brass 2-3/8 to 3/4" 107.00
SCF51AACC-605 Bright Brass 2-3/8 to 3/4" 99.00
SCF51AACC-609 Satin Brass Blackened 2-3/8 to 3/4" 105.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Backset Price/Ea.
SCF170ACC-605 Bright Brass 2-3/8 to 3/4" 25.00
SCF170ACC-609 Satin Brass Blackened 2-3/8 to 3/4" 28.00
BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCF40ACC-605 Bright Brass 2-3/8 to 3/4" 51.00
SCF40ACC-605/625 Bright Brass/ Chromium 2-3/8 to 3/4" 57.00
SCF40ACC-609 Satin Brass Blackened 2-3/8 to 3/4" 57.00
BEDROOM PRIVACY LOCK
Pushbutton Locking. 20 per case.
Code Finish Backset Price/Ea.
SCF40JAZ-605 Bright Brass 2-3/8 to 3/4" 48.00
SCF40JAZ-605/625 Bright Brass/Chromium 2-3/8 to 3/4" 54.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Backset Price/Ea.
SCF170JAZ-605 Bright Brass 2-3/8 to 3/4" 23.00
ENTRANCE LOCK
Keyed on Outside; Turn Button on Inside. 20 per case.
Code Finish Backset Price/Ea.
SCF51AELA-505 Lifetime Bright Brass 2-3/8 to 3/4" 104.00
SCF51AELA-605 Bright Brass 2-3/8 to 3/4" 96.00
SCF51AELA-626 Satin Chromium 2-3/8 to 3/4" 102.00
SINGLE DUMMY TRIM
For One Side of Door. 20 per case.
Code Finish Backset Price/Ea.
SCF170ELA-605 Bright Brass 2-3/8 to 3/4" 23.00
SCF170ELA-609 Satin Brass Blackened 2-3/8 to 3/4" 26.00
SCF170ELA-625 Bright Chromium 2-3/8 to 3/4" 26.00
Quantity Discounts Available. Call for Quote.
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 601
www.acclock.com
Accredited Lock Supply B
NEW 'F SERIES' STYLE LOCKSETS
Avanti
St. Annes
SienaSacramentoMeranoManhattan
LatitudeChampagneCallingtonBroadway
BoweryBirminghamAvila
Finishes
505 Lifetime Bright Brass
605 Bright Brass
608 Satin Brass
618 Polished Nickel
619 Satin Nickel
621 Distressed Nickel
622 Matte Black
626 Satin Chrome
716 Aged Bronze
Functions
F10 Hall & Closet
F40 Bed & Bath
F51A Keyed Entry
F80 Storeroom Lock
F170 Non-turning (Single Dummy)
Not all styles available in every finish and function.
Call for pricing and more information.
Go To Table of Contents
602
www.acclock.com
Accredited Lock Supply
B
'F SERIES' HANDLESETS - EXTERIOR TRIMS
Addison Greenwich Plymouth WakefieldCenturyCamelotBrookshire
F58 Series
Style/Design 505 605 609 619 620 621 622 625 716
ADD-Addison 186.00 151.00 181.00 181.00 201.00 201.00 201.00 181.00 186.00
BRK-Brookshire 186.00 151.00 181.00 181.00 201.00 186.00
CAM-Camelot 181.00 146.00 176.00 176.00 196.00 196.00 176.00 181.00
CEN-Century 181.00 146.00 176.00 176.00 196.00 176.00 181.00
GRW-Greenwich 181.00 201.00 181.00 186.00
PLY-Plymouth 173.00 138.00 168.00 168.00 188.00 188.00 168.00 173.00
WKF-Wakefield 186.00 151.00 181.00 181.00 201.00 201.00 181.00 186.00
Choose from these exterior handle trims, then select an interior trim from the next page.
Finishes
505 Lifetime Bright Brass
605 Bright Brass
608 Satin Brass
609 Antique Brass
613 Oil-Rubbed Bronze
618 Polished Nickel
619 Satin Nickel
620 Antique Pewter
621 Distressed Nickel
622 Matte Black
625 Bright Chrome
626 Satin Chrome
716 Aged Bronze
Boxed.
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 603
www.acclock.com
Accredited Lock Supply B
STYLE 605 608 609 613 618 619 620 621 622 625 626 716
ACC-Accent 99.00 105.00 105.00 111.00 105.00 105.00 111.00 111.00 111.00 105.00 105.00 107.00
AVA-Avanti 109.00 115.00 121.00 102.00 121.00 115.00 117.00
VLA-Avila 96.00 102.00 102.00 102.00 102.00 104.00
BIR-Birmingham 110.00 110.00 112.00
BRW-Broadway 110.00 110.00 110.00 112.00
CLT-Callington 109.00 115.00 121.00 115.00 121.00 122.00 115.00 115.00 117.00
CHP-Champagne 109.00 115.00 121.00 115.00 121.00 115.00 115.00 117.00
ELA-Elan 96.00 102.00 102.00 102.00 104.00
FLA-Flair 99.00 105.00 105.00 111.00 105.00 111.00 105.00 105.00 107.00
JAZ-Jazz 96.00 102.00 102.00 102.00
LAT-Latitude 105.00 105.00 111.00 105.00 105.00 107.00
MNH-Manhattan 99.00 105.00 105.00 105.00
MER-Merano 110.00 116.00 110.00 110.00 112.00
SAC-Sacramento 102.00 102.00 102.00 102.00 104.00
STA-St Annes 104.00 110.00 116.00 110.00 116.00 110.00 110.00 112.00
AND-Andover 84.00 90.00 96.00 90.00 96.00 90.00 90.00 92.00
BEL-Bell 77.00 83.00 83.00
BWE-Bowery 90.00 90.00 96.00 90.00 90.00
GEO-Georgian 77.00 83.00 83.00 83.00 89.00 89.00 89.00 83.00 83.00 85.00
ORB-Orbit 84.00 90.00 96.00 90.00 96.00 90.00 90.00
PLY-Plymouth 77.00 83.00 89.00 83.00 89.00 89.00 83.00 83.00 85.00
SIE-Siena 91.00 97.00 103.00 97.00 103.00 103.00 97.00 97.00 99.00
Avanti
Siena
SacramentoMeranoManhattanLatitude
ChampagneCallington
Broadway
Bowery
BirminghamAvila
Plymouth
Orbit
Georgian
Bell
Andover
St. Annes
Jazz
FlairElan
Accent
F59
Single Cylinder
Also available:
F92
Inactive Handleset Ext.
F94
Inactive trim,Interior
'F SERIES' HANDLESETS - INTERIOR TRIMS
Boxed.
Go To Table of Contents
604
www.acclock.com
Accredited Lock Supply
B
Addison Plymouth
CenturyCamelot
Avanti
Siena
Merano
ManhattanLatitude
Birmingham
Plymouth
Georgian
Flair
Accent
F60 Series
Style/Design Ext. Style/Design Int. 605 608 609 619 716
ADD-Addison ACC-Accent 306.00
BIR-Birmingham 318.00
GEO-Georgian 291.00
CAM-Camelot ACC-Accent 265.00 301.00
AVA-Avanti 306.00 306.00
GEO-Georgian 279.00 279.00 279.00
SIE-Siena 293.00
CEN-Century LAT-Latitude 301.00
MER-Merano 306.00 313.00
PLY-Plymouth ACC-Accent 235.00 271.00 271.00 278.00
FLA-Flair 257.00 293.00 300.00
GEO-Georgian 235.00 271.00 271.00 278.00
PLY-Plymouth 235.00 271.00 271.00 2 78.00
'F SERIES' HANDLESETS - VISUAL PACK SETS
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 605
www.acclock.com
Accredited Lock Supply B
SCHLAGE KEYPAD LOCKS
No more hiding keys under the doormat. No more losing, forgetting, or making extras keys time and time again. Step up to a more secure and
flexible solution with Schlage electronic security products. Install a new keyless door lock or deadbolt yourself—with nothing more than a
screwdriver. You’re free to add, change, or delete user codes in just seconds—and to come and go as you please.
• Automatically relocks after 5 seconds; no need to remember to relock the door
• Backset: 2 3/8" or 2 3/4"
• No programming required; preset with two user codes so it's ready to use right out of the box
• ANSI/BHMA Grade 2 Certied
• Fits standard door prep
• Battery operated with over 3 year battery life
FE595PLY x FLAIR
P/N Function Finish Price
SCFE575CAM/ACC-505 Entry-Auto Lock Lifetime Brass 230.00
SCFE575CAM/ACC-619 Entry-Auto Lock Satin Nickel 225.00
SCFE575CAM/ACC-620 Entry-Auto Lock Antique Pewter 235.00
SCFE575CAM/ACC-626 Entry-Auto Lock Satin Chrome 225.00
SCFE575CAM/ACC-716 Entry-Auto Lock Aged Bronze 230.00
SCFE575PLY/ELA-626 Entry-Auto Lock Satin Chrome 241.00
SCFE575PLY/FLA-505 Entry-Auto Lock Lifetime Brass 230.00
SCFE575PLY/FLA-609 Entry-Auto Lock Antique Brass 225.00
SCFE575PLY/FLA-619 Entry-Auto Lock Satin Nickel 225.00
SCFE575PLY/FLA-620 Entry-Auto Lock Antique Pewter 235.00
SCFE575PLY/FLA-626 Entry-Auto Lock Satin Chrome 225.00
SCFE575PLY/FLA-716 Entry-Auto Lock Aged Bronze 230.00
SCFE575PLY/JAZ-626 Entry-Auto Lock Satin Chrome 241.00
SCFE575PLY/ACC-619 Entry-Auto Lock Satin Nickel 225.00
SCFE575PLY/ACC-620 Entry-Auto Lock Antique Pewter 235.00
SCFE595CAM/ACC-505 Entry-Flex Lifetime Brass 240.00
SCFE595CAM/ACC-609 Entry-Flex Antique Brass 235.00
SCFE595CAM/ACC-619 Entry-Flex Satin Nickel 235.00
SCFE595CAM/ACC-620 Entry-Flex Antique Pewter 245.00
SCFE595CAM/ACC-626 Entry-Flex Satin Chrome 235.00
SCFE595CAM/ACC-716 Entry-Flex Aged Bronzed 240.00
FE575CAM x ACCENT
FE575 Automatically relocks after 5 seconds.
FE595 Flexibility: Choose from automatic relocking or
lock as desired.
SCHLAGE KEYPAD DEADBOLTS
BE365 PLYMOUTH
BE365 CAMELOT
P/N Function Finish Price
SCBE365CAM-505 Single Cylinder Lifetime Brass 220.00
SCBE365CAM-609 Single Cylinder Antique Brass 215.00
SCBE365CAM-619 Single Cylinder Satin Nickel 215.00
SCBE365CAM-620 Single Cylinder Antique Pewter 225.00
SCBE365CAM-626 Single Cylinder Satin Chrome 215.00
SCBE365CAM-716 Single Cylinder Aged Bronzed 220.00
SCBE365PLY-505 Single Cylinder Lifetime Brass 220.00
SCBE365PLY-609 Single Cylinder Antique Brass 215.00
SCBE365PLY-619 Single Cylinder Satin Nickel 215.00
SCBE365PLY-620 Single Cylinder Antique Pewter 225.00
SCBE365PLY-626 Single Cylinder Satin Chrome 215.00
SCBE365PLY-716 Single Cylinder Aged Bronzed 220.00
• Innovative Turn Lock feature allows you to lock & leave without a key
• Provides the convenience of keyless access; customizable to t your security needs
• Backset: 2 3/8" or 2 3/4"
SCFE595PLY/ACC-619 Entry-Flex Satin Nickel 235.00
SCFE595PLY/ACC-620 Entry-Flex Antique Pewter 245.00
SCFE595PLY/ACC-716 Entry-Flex Aged Bronze 240.00
SCFE595PLY/FLA-505 Entry-Flex Lifetime Brass 240.00
SCFE595PLY/FLA-609 Entry-Flex Antique Brass 235.00
SCFE595PLY/FLA-619 Entry-Flex Satin Nickel 235.00
SCFE595PLY/FLA-620 Entry-Flex Antique Pewter 245.00
SCFE595PLY/FLA-626 Entry-Flex Satin Chrome 235.00
SCFE595PLY/FLA-716 Entry-Flex Aged Bronze 240.00
SCFE595PLY/LAT-619 Entry-Flex Satin Nickel 235.00
SCFE595PLY/LAT-626 Entry-Flex Satin Chrome 235.00
SCFE595PLY/MER-619 Entry-Flex Satin Nickel 215.00
SCFE595CAM/GEO-505 Entry-Flex Lifetime Brass 240.00
SCFE595CAM/GEO-609 Entry-Flex Antique Brass 220.00
SCFE595CAM/GEO-619 Entry-Flex Satin Nickel 220.00
SCFE595CAM/GEO-716 Entry-Flex Aged Bronze 225.00
For UL listed, add 'F', plus $60
Example, SCBE365FCAM-505
For 20 minute Fire rating, add 'F20', plus $10
Example, SCBE365F20CAM-505
Go To Table of Contents
606
www.acclock.com
Accredited Lock Supply
B
Features:
• Numeric Touchscreen
• Fingerprint-resistant
• Works in the rain and when you’re wearing gloves
• Slim Prole
• Sleek without sacricing strength
• Easily ts between the front door and screen door
• Durable, Smart Design
• Grade 2 security rating, for strong performance across
a range of residential applications
• 2-year battery life with a 9V battery backup
•LED Down Lighting Illumination when you need it, on
both the numbers and the lever
• Dedicated Icons - For both low battery and program-
ming mode
• Enhanced Security-100% bump-proof;100% pick-
proof
• Exceptional Convenience
• Installs in minutes with just a screwdriver
• Memory for 19 access codes
• No more keys to lose, hide, carry or forget
Specifications:
• ANSI/BHMA Grade 2
• Exterior dimensions: 3" x 5.4" x 5.2"
• 3-Year Limited Electronics Warranty
• Limited Lifetime Mechanical Finish War-
ranty
• Uses 1 9V battery
• Door thickness: 1 3/8" to 1 3/4"
• Stores up to 19 four-digit user codes
SCHLAGE TOUCHTM ELECTRONIC LEVERS
Camelot w/Accent Lever
Century w/Broadway Lever
P/N Function Finish Price
SCFE695CAM/ACC-605 Keypad Lock Polished Brass 265.00
SCFE695CAM/ACC-609 Keypad Lock Antique Brass 265.00
SCFE695CAM/ACC-619 Keypad Lock Satin Nickel 265.00
SCFE695CAM/ACC-622 Keypad Lock Matte Black 265.00
SCFE695CAM/ACC-625 Keypad Lock Polished Chrome 265.00
SCFE695CAM/ACC-626 Keypad Lock Satin Chrome 265.00
SCFE695CAM/ACC-716 Keypad Lock Aged Bronze 270.00
SCFE695CAM/FLA-605 Keypad Lock Polished Brass 265.00
SCFE695CAM/FLA-609 Keypad Lock Antique Brass 265.00
SCFE695CAM/FLA-619 Keypad Lock Satin Nickel 265.00
SCFE695CAM/FLA-626 Keypad Lock Satin Chrome 265.00
SCFE695CAM/FLA-716 Keypad Lock Aged Bronze 270.00
SCFE695CEN/BRW-619 Keypad Lock Satin Nickel 270.00
SCFE695CEN/BRW-622 Keypad Lock Matte Black 275.00
SCFE695CEN/BRW-625 Keypad Lock Polished Chrome 270.00
SCFE695CEN/BRW-626 Keypad Lock Satin Chrome 270.00
SCFE695CEN/BRW-716 Keypad Lock Aged Bronze 275.00
SCFE695CEN/ELA-626 Keypad Lock Satin Chrome 265.00
SCFE695CEN/LAT-619 Keypad Lock Satin Nickel 265.00
SCFE695CEN/LAT-622 Keypad Lock Matte Black 265.00
SCFE695CEN/LAT-625 Keypad Lock Polished Chrome 265.00
SCFE695CEN/LAT-626 Keypad Lock Satin Chrome 265.00
SCFE695CEN/LAT-716 Keypad Lock Aged Bronze 270.00
SCFE695CEN/MER-619 Keypad Lock Satin Nickel 270.00
SCFE695CEN/MER-622 Keypad Lock Matte Black 275.00
SCFE695CEN/MER-625 Keypad Lock Polished Chrome 270.00
SCFE695CEN/MER-626 Keypad Lock Satin Chrome 270.00
SCFE695CEN/MER-716 Keypad Lock Aged Bronze 275.00 Century w/Merano Lever
Century w/Latitude Lever
Camelot w/Flair Lever
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 607
www.acclock.com
Accredited Lock Supply B
SCHLAGE CONNECTTM
Features:
• ANSI Grade 1 Highest Residential Security
•Durable Resistive Touchscreen with matte nish to
protect your residential security deadbolt lock against
fingerprints and smudges
• Anti-pick shield protects against lock tampering
• Strong motorized bolt automatically locks and unlocks
when a user code is entered
• Build-in Alarm Technology senses movement of the
door and alerts homeowners with an audible alert
• Select between three touchscreen alarm door lock
alerts: activity, tamper or forced entry alert
• Employs Z-Wave®, a wireless technology that makes
your house smarter, safer and far more convenient
•Connect with your home via computer, tablet or
smartphone with the service provider of your choice
and get the exact features* you want
• Holds up to 30 user codes
• Easy installation with just a screwdriver- no wiring
required
*Connectivity features dependent upon service provider
BE469NX Century
Specifications:
Applications: Residential single family doors
Certifications: Grade 1 ANSI/BHMA certied
Keying: 5-pin tumbler, C Keyway, 1 key included
Door range: 1-3/8” to 1-3/4” (35mm-44mm) standard
Operating Temperatures: Outside escutcheon: -35C to
66C, Inside escutcheon: -10C to 49C
P/N Finish Price
SCBE469NXCAM-605 Polished Brass 435.00
SCBE469NXCAM-619 Satin Nickel 435.00
SCBE469NXCAM-622 Matte Black 440.00
SCBE469NXCAM-625 Polished Chrome 435.00
SCBE469NXCAM-716 Aged Bronze 440.00
SCBE469NXCEN-619 Satin Nickel 435.00
SCBE469NXCEN-622 Matte Black 440.00
SCBE469NXCEN-625 Polished Chrome 435.00
SCBE469NXCEN-626 Satin Chrome 435.00
SCBE469NXCEN-716 Aged Bronze 440.00
Grade 1, with alarm
P/N Finish Price
SCBE468NXCAM-605 Polished Brass 385.00
SCBE468NXCAM-619 Satin Nickel 385.00
SCBE468NXCAM-625 Polished Chrome 385.00
SCBE468NXCAM-716 Aged Bronze 390.00
SCBE468NXCEN-619 Satin Nickel 385.00
SCBE468NXCEN-625 Polished Chrome 385.00
SCBE468NXCEN-626 Satin Chrome 385.00
SCBE468NXCEN-716 Aged Bronze 390.00
Grade 2, without alarm
BE469NX Camelot
SCHLAGE SENSETM
You speak. It listens. The Schlage Sense™ Smart Deadbolt works with Apple HomeKit™ technology and responds
to Siri®, letting you use your iPhone®, iPad® or iPod touch® to “talk to unlock” your door
When the Schlage Sense™ lock is placed near an Apple TV®, you gain even more control, like the ability to
communicate with your lock via iPhone®, iPad® or iPod touch®—anywhere, anytime
Apple HomeKit™ technology provides advanced security with end-to-end encryption and authentication between
the Schlage Sense™ Smart Deadbolt and your iPhone®, iPad® or iPod touch®
Designed to work with Bluetooth® Smart technology • Built-in alarm technology senses potential door attacks
Meets the highest industry rating for security and durability
Easy to set up and program using the Schlage Sense™ app
Homeowners can assign codes or designate phones through the Schlage Sense™ app
No fees or subscriptions
Lock holds up to 30 access codes
ANSI/BHMA Grade 1
Interior dimensions: 2.1" x 3" x 8.2"
Exterior dimensions: 3" x 5"
3-Year Limited Electronics Warranty
Limited Lifetime Mechanical Finish Warranty
Uses 4 AA alkaline batteries (included)
Door thickness: 1 3/8" to 1 3/4"; thick door kit extends 1 7/8" to 2 1/2"
Camelot Century
P/N Finish Price
SCBE479AACAM-619 Satin Nickel 485.00
SCBE479AACAM-716 Aged Bronze 490.00
SCBE479AACEN-619 Satin Nickel 485.00
SCBE479AACEN-622 Matte Black 490.00
Go To Table of Contents
608
www.acclock.com
Accredited Lock Supply
B
The Schlage L-Series mortise lock line is a heavy duty commercial mortise lock containing a wide array of knob and lever designs. It is available in a variety of keyed
and non-keyed functions, and in most popular decorative finishes. It is UL Listed and can be specified for applications in offices, schools, hospitals, hotels, commercial/
industrial buildings as well as residences.
Equipped with conventional cylinders and sectional trim, the L-Series extra heavy duty mortise lock provides ANSI 156.13, Grade 2 security to enhance its existing Grade
1 operational requirements for mortise locks with sectional and escutcheon trim. The series continues to exceed Grade 1 security requirements with concealed cylinders.
COMMERCIAL MORTISE LOCKS
• Levers: Levers are available in forged brass or bronze and cast stainless steel. Designs available to match D-Series levers.
• Escutcheons: L escutcheons are cold forged brass or bronze and stainless steel. N escutcheons are heavy wrought reinforced brass, bronze and stainless steel.
L = 8" x 1 3/4" x 7/16" (203 mm x 44 mm x 11 mm). N = 8" x 2 9/16" x 7/16" (203 mm x 65 mm x 11 mm).
• Roses: A = 2 1/8" (54 mm) diameter wrought brass, bronze or stainless steel. B = 2 9/16" (65 mm) diameter wrought brass, bronze or stainless steel.
• Trim Combinations: Available with knob both sides, lever both sides, or knob by lever with rose or escutcheon both sides.
• Keying: 6-pin cylinder with two nickel silver Everest® patented keys standard. Keying options available from factory are master keying, construction keying, inter-
changeable core, SFIC and Primus® high security cylinders.
• Door Range: 1 3/4" (44mm) Standard. 1 3/8" (35mm) to 2 1/2" (64mm) Regular parts assembled to order. Over 2 1/2" (64mm) door ranges vary by function. N escutch-
eon available for 1 3/4" (44mm) doors standard. 2" (51mm) to 2 3/8" (60mm) Regular parts assembled to order. Specify door thickness if other than 1 3/4" (44 mm).
• Case Size: 4 7/16" x 6 1/16" x 1" (113mm x 154mm x 25mm).
• Armored Front: 1 1/4" x 8" x 7/32" (32mm x 203mm x 6mm). Standard.1 1/16" x 8" x 7/32" (27mm x 203mm x 6mm) Optional.
• Spacing: Knob or lever to cylinder, 3 7/8" (98mm); knob or lever to thumbturn hub, 2 11/16" (68mm).
• Deadbolt: 1" (25mm) Throw stainless steel.
• Latchbolt: 3/4" (19mm) Throw stainless steel with anti-friction tongue
• Backset: 2 3/4" (70mm) Only.
L9453P series mortise
body with 17 lever
07
Omega
06
N escutcheon
with 03 lever
P/N Function Lever Price
SCL9010-OME-A-626 Passage Omega 597.00
SCL9040-OME-A-626 Privacy Omega 687.00
SCL9050P-OME-A-626 Ofce/Inner Entry Omega 766.00
SCL9070P-OME-A-626 Classroom Omega 766.00
SCL9080P-OME-A-626 Storeroom Omega 766.00
SCL9453P-OME-A-626 Entry w/deadbolt Omega 790.00
All prices for 626 Satin Chrome Finish
'A' Rose = 2 1/8" Diameter
P/N Function Price
SCL9010-XXX-626 Passage 597.00
SCL9040-XXX-626 Privacy 687.00
SCL9050P-XXX-626 Ofce/Inner Entry 766.00
SCL9070P-XXX-626 Classroom 766.00
SCL9080P-XXX-626 Storeroom 766.00
SCL9453P-XXX-626 Entry w/deadbolt 790.00
Substitute for 'XXX': 06A, 07A or 17A
P/N Function Price
SCL9010-XXX-626 Passage 624.00
SCL9040-XXX-626 Privacy 714.00
SCL9050P-XXX-626 Ofce/Inner Entry 793.00
SCL9070P-XXX-626 Classroom 793.00
SCL9080P-XXX-626 Storeroom 793.00
SCL9453P-XXX-626 Entry w/deadbolt 817.00
Substitute for 'XXX': 06N, 07N or 17N
P/N Function Lever Price
SCL9010-OME-N-626 Passage Omega 624.00
SCL9040-OME-N-626 Privacy Omega 714.00
SCL9050P-OME-N-626 Ofce/Inner Entry Omega 793.00
SCL9070P-OME-N-626 Classroom Omega 793.00
SCL9080P-OME-N-626 Storeroom Omega 793.00
SCL9453P-OME-N-626 Entry w/deadbolt Omega 817.00
w/rose w/escutcheon
w/rose w/escutcheon
Use Pro-Lok IN50-PRO/INCL-PRO/
IN51/INJIGC-MORT Templates
Use Pro-Lok EWP-IN50-FP-S Flat Plate
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 609
www.acclock.com
Accredited Lock Supply B
The B580 Series deadbolt is thrown by the
turnpiece from the inside only. No external
cylinder or trim on the outside.
1-1/8" Square Corner Strike
Code Finish Backset Price/Ea.
SCB580-605 Bright Brass 2-3/8" to 2-3/4" 61.00
SCB580-609 Satin Brass Blackened 2-3/8" to 2-3/4" 61.00
SCB580-626 Satin Chromium Plated 2-3/8" to 2-3/4" 55.00
Single Cylinder
Code Finish Backset Price/Ea.
1-1/8" x 2-3/4" Square Corner Faceplace
SCB560P-605 Bright Brass 2-3/8" to 2-3/4" 78.00
SCB560P-609 Satin Brass Blackened 2-3/8" to 2-3/4" 78.00
SCB560P-626 Satin Chromium Plated 2-3/8" to 2-3/4" 72.00
B580 TURN BOLT
B560 SERIES STANDARD DUTY - GRADE 2
A standard duty deadbolt that provides an added measure of security to the residential
or commerical application. The deadbolt features a 1/4" hardened steel roller to add
resistance to sawing or cutting through the bolt.
The large thumbpiece turn unit on the inside adds to the ease of operation of
the lock.
The deadbolt is adjustable for 2-3/8" to 2-3/4" backset.
Code Finish Backset Price/Ea.
1-1/8" x 2-3/4" Square Corner Faceplate
SCB562P-605 Bright Brass 2-3/8" to 2-3/4" 102.00
SCB562P-609 Satin Brass Blackened 2-3/8" to 2-3/4" 102.00
SCB562P-626 Satin Chromium Plated 2-3/8" to 2-3/4" 96.00
DEADLOCKS
B250 SERIES DEADLATCHES
• 1-3/8" or 1-3/4" Door Installation
• 9/16" Throw Deadlatch
• Wrought Brass or Bronze Trim Rings
• 6 Pin Solid Brass Cylinder
Code Finish Backset Price/Ea.
Single Cylinder
SCB250PD-605 Bright Brass 2-3/8" 244.00
SCB250PD-626 Satin Chromium Plated 2-3/8" 238.00
Double Cylinder
SCB252PD-605 Bright Brass 2-3/8" 270.00
SCB252PD-626 Satin Chromium Plated 2-3/8" 264.00
Double Cylinder
COMMERCIAL MORTISE LOCKS
B660P HEAVY DUTY DEADBOLT
A commerical quality deadbolt that provides an extra
measure of security to the residential or commerical
application. The deadbolt features a 1/4" hardened
steel roller to add resistance to sawing or cutting
through the bolt.
SINGLE CYLINDER
Code Finish Backset Price/Ea.
SCB660P-605 Bright Brass 2-3/4" 177.00
SCB660P-626 Satin Chromium 2-3/4" 171.00
DOUBLE CYLINDER
SCB662P-605 Bright Brass 2-3/4" 226.00
SCB662P-626 Satin Chromium 2-3/4" 220.00
SINGLE CYLINDER OUTSIDE, CLASSROOM TURN INSIDE
SCB663P-626 Satin Chromium 2-3/4" 179.00
Go To Table of Contents
610
www.acclock.com
Accredited Lock Supply
B
DEADBOLTS
Single Cylinder
Code Finish Backset Price/Ea.
SCB60N-505/605 Lifetime/Bright Brass 2-3/8" to 2-3/4" 61.00
SCB60N-605 Bright Brass 2-3/8" to 2-3/4" 53.00
SCB60N-609 Antique Brass 2-3/8" to 2-3/4" 59.00
SCB60N-613 Oil Rubbed Bronze 2-3/8" to 2-3/4" 65.00
SCB60N-619 Satin Nickel 2-3/8" to 2-3/4" 59.00
SCB60N-620 Antique Pewter 2-3/8" to 2-3/4" 65.00
SCB60N-622 Matte Black 2-3/8" to 2-3/4" 65.00
SCB60N-625 Bright Chrome 2-3/8" to 2-3/4" 59.00
SCB60N-626 Satin Chromium Plated 2-3/8" to 2-3/4" 59.00
SCB60N-716 Aged Bronzed 2-3/8" to 2-3/4" 61.00
Double Cylinder
Code Finish Backset Price/Ea.
SCB62N-505/605 Lifetime/Bright Brass 2-3/8" to 2-3/4" 86.00
SCB62N-605 Bright Brass 2-3/8" to 2-3/4" 78.00
SCB62N-609 Antique Brass 2-3/8" to 2-3/4" 84.00
SCB62N-613 Oil Rubbed Bronze 2-3/8" to 2-3/4" 90.00
SCB62N-619 Satin Nickel 2-3/8" to 2-3/4" 84.00
SCB62N-620 Antique Pewter 2-3/8" to 2-3/4" 90.00
SCB62N-622 Matte Black 2-3/8" to 2-3/4" 90.00
SCB62N-625 Bright Chrome 2-3/8" to 2-3/4" 84.00
SCB62N-626 Satin Chromium Plated 2-3/8" to 2-3/4" 84.00
SCB62N-716 Aged Bronzed 2-3/8" to 2-3/4" 84.00
• Unique Snap & Stay™ design
• Easy installation: One-person project; no extra hands needed
• ANSI Grade 1--professional grade security
•Biggest adjustable bolt available
• Pick and bump resistant
• Adjusts to t all standard door preparations
•Quality nishes for lasting beauty
• Lifetime nish and mechanical guarantee
• Applications: Residential single- and multi-family doors
• Certications: Meets Grade 1 BHMA requirements
• U.L. Listed: Locks for up to three-hour re doors available
• Keying: 5-pin tumbler C keyway standard,
with two brass keys. 6-pin cylinder available
• Door thickness range: 1-3/8” to 1-3/4” standard
• Backset: Universal deadbolts t 2-3/8” or 2-3/4” backset
B60 SERIES DEADBOLT
One-sided Deadbolt
Code Finish Backset Price/Ea.
SCB80N-605 Bright Brass 2-3/8" to 2-3/4" 35.00
SCB80N-609 Antique Brass 2-3/8" to 2-3/4" 41.00
SCB80N-613 Oil Rubbed Bronze 2-3/8" to 2-3/4" 47.00
SCB80N-619 Satin Nickel 2-3/8" to 2-3/4" 41.00
SCB80N-620 Antique Pewter 2-3/8" to 2-3/4" 47.00
SCB80N-622 Matte Black 2-3/8" to 2-3/4" 47.00
SCB80N-625 Bright Chrome 2-3/8" to 2-3/4" 41.00
SCB80N-626 Satin Chromium Plated 2-3/8" to 2-3/4" 41.00
SCB80N-716 Aged Bronzed 2-3/8" to 2-3/4" 43.00
One-sided Deadbolt w/Trim
Code Finish Backset Price/Ea.
SCB81N-505/605 Lifetime/Bright Brass 2-3/8" to 2-3/4" 46.00
SCB81N-605 Bright Brass 2-3/8" to 2-3/4" 38.00
SCB81N-609 Antique Brass 2-3/8" to 2-3/4" 44.00
SCB81N-613 Oil Rubbed Bronze 2-3/8" to 2-3/4" 50.00
SCB81N-619 Satin Nickel 2-3/8" to 2-3/4" 44.00
SCB81N-620 Antique Pewter 2-3/8" to 2-3/4" 50.00
SCB81N-626 Satin Chromium Plated 2-3/8" to 2-3/4" 44.00
Adder for decorative trim - add to price for standard B60N single cylinder deadbolt above.
Style/Design 505 605 609 619 620 621 622 625 716
ADD-Addison 16.00 16.00 16.00 16.00 16.00 16.00 16.00
BRK-Brookshire 16.00 16.00 16.00
CAM-Camelot 16.00 16.00 16.00 16.00 16.00 16.00 16.00 16.00
CEN-Century 16.00 16.00 16.00 16.00
GRW-Greenwich 16.00 16.00 16.00 16.00
WKF-Wakefield 16.00 16.00 16.00 16.00 16.00 16.00 16.00
Addison Wakefield
GreenwichCenturyCamelotBrookshire
We now stock Combo
Packs of Decorative
Knobs/Levers with
Deadbolts.
Many styles and finishes.
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 611
www.acclock.com
Accredited Lock Supply B
Code Description Price/Ea.
SC35-100-C 5-Pin C Section 1.40
SC35-100-E 5-Pin E Section 1.40
SC35-100-F 5-Pin F Section 1.40
SC35-101-C 6-Pin C Section 1.90
SC35-101-E 6-Pin E Section 1.90
SC35-101-F 6-Pin F Section 1.90
Code Finish Throw Backset Price/Ea.
SC12-100-605 Bright Brass 9/16" 2-3/8" 76.30
SC12-100-626 Satin Chromium Plated 9/16" 2-3/8" 76.30
SC12-103-605 Bright Brass 9/16" 2-3/4" 76.30
SC12-103-626 Satin Chromium Plate 9/16" 2-3/4" 76.30
KEY BLANKS-Classic
50 per box.
B SERIES BOLT AND LATCHES
Standard “B” Series deadbolts and latches have adjustable faceplates for RH or LH
flat or beveled edge doors. Faceplates are furnished in finishes compatible with the
lock trim. All deadbolts feature a concealed hardened steel roller for added resistance
to sawing or cutting.
DEADLOCKS
Accessories KEYBLANKS
DEADBOLT FOR B600 SERIES
1-1/8" x 2-3/4" Square Corner. 1" to 1-1/16" HSG Diameter.
Code Finish Throw Backset Price/Ea.
SC12-630-605 Bright Brass 1" 2-3/8" 46.10
SC12-630-626 Satin Chromium Plated 1" 2-3/8" 46.10
SC12-631-605 Bright Brass 1" 2-3/4" 46.10
SC12-631-626 Satin Chromium Plated 1" 2-3/4" 46.10
SC12-632-605 Bright Brass 1" 3-3/4" 80.60
SC12-632-626 Satin Chromium Plated 1" 3-3/4" 80.60
SC12-633-605 Bright Brass 1" 5" 80.60
SC12-633-626 Satin Chromium Plated 1" 5" 80.60
SC12-640 Drive-in 1" 2-3/8" 46.10
SC12-641 Drive-in 1" 2-3/4" 46.10
SC12-643 Drive-in 1" 5" 80.60
C
Code Finish Throw Backset Price/Ea.
SC12-288-605 Bright Brass 1" 2-3/8" to 2-3/4" 32.20
SC12-288-626 Satin Chromium Plated 1" 2-3/8" to 2-3/4" 32.20
SC12-289-605* Bright Brass 1" 2-3/8" to 2-3/4" 32.20
SC12-289-626* Satin Chromium Plated 1" 2-3/8" to 2-3/4" 32.20
* Radius round corner
DEADBOLTS FOR B500 SERIES
1" x 2-1/4" Square Corner. 7/8" HSG Diameter, 2-3/8" or 2-3/4" Backset.
DEADLATCH FOR B250 SERIES
1-1/8" x 2-1/4" Square Corner. 1" HSG Diameter.
Go To Table of Contents
