576
www.acclock.com
Accredited Lock Supply
PADLOCKING DEADBOLT
Durable, surface-mounted deadbolt for use on inswinging or outswinging doors
in high security areas. Made of die cast Zamack alloy, it features a 1" bolt throw
with hardened steel pins to resist sawing and withstand up to one ton of thrust.
Compatible with any 5/16" shackle padlock; but recommended for use with
Sargent & Greenleaf 8077 combination padlock which meets Federal specifica-
tion FF-P110-F.
May be secured in either a locked or unlocked position to conform with fire code
regulations and ensure clear fire escape routes.
Dimensions: 5 1/4"(L) x 1 1/2"(W) x 1 2/3"(H).
SG1881-004
w/#14 strike
17217
KEYLOCKING DEADBOLT
High security keylocking deadbolt designed for use on in swinging or out swinging
doors. Surface-mounted, easy to install and recommended for use on metal or solid
wood doors. Features a changeable key cylinder, two concealed base screws and
a 1" deadbolt throw. Constructed of Zamack alloys with steel pin inserts to resist
sawing and up to one ton of thrust. May be secured in either a locked or unlocked
position to meet fire code standards and insure clear fire escape routes.
Dimensions: 5 1/4"(L) x 1 1/2"(W) x 1 2/3"(H).
SG1883-002
w/#12 strike
19834
GROUP 2 MECHANICAL SAFE LOCKS
Includes standard spindle lengths for 3.406" door thickness. Models carried provide
Relock feature.
Black finish with white fill and standard bolt.
P/N Dial Price
SG6730-010 Bolt Only 117.03
SG6730-100 D300/R211 137.70
SG6730-101 D003 Front Reading, Small Knob 137.70
SG6730-102 D220 Spy Proof, Large Knob, B & W 163.10
SG6730-103 D690 Front Reading, Key Lock, 181.38
Large Knob
SAFE DEPOSIT LOCKS
3857
PADLOCK
Changeable Combination. Open Shackle.
Chrome finish.
SG8077-108
45261
4440 SERIES
Double Horn. Fixed Lever.
SG4440-LH Double Small Left Hand
SG4440-RH Double Small Right Hand
SG4442-LH Large Small Left Hand
SG4442-RH Large Small Right Hand
SG4443-LH Double Large Left Hand
SG4443-RH Double Large Right Hand
SG1881-001
w/o strike
12626
SG1883-003
w/#13 strike
19834
SG1883-001
w/o strike
15246
C
Comes with 2 renter keys only.
Cut guard keys sold separately.
Go To Table of Contents
ENCYCLOPEDIA OF LOCKSMITH SUPPLIES
1.800.652.2835 577
www.acclock.com
Accredited Lock Supply
6120 ELECTRONIC COMBINATION & MOTORIZED LOCK
KEYBLANKS
ELECTRONIC SAFE LOCKS
An industry standard, the S & G electronic combination lock. Using an electronic
lock is as easy as dialing a touch tone telephone - your customers will appreciate
how much easier it is to open their safe.
• Lock allows master code & up to 8 user codes
• Locks out after 4 consecutive incorrect tries
• Time delay of up to 9 minutes, user program mable
• Management Reset Code - in case of lost codes
• Internal relock trigger protects against physical attack
• 1,000,000 possible combinations
• 8,000 openings per set of alkaline batteries
UL Listed Type 1 lock
SG6120-305 Satin Chrome Keypad 290.49
C
BIOMETRIC KEYPAD
The S&G Biometric Keypad is a replacement
keypad that works with many Sargent and
Greenleaf electronic safe locks to provide a
whole new level of security and convenience.
Its unobtrusive, easy-to-use fingerprint reader
lets you operate your lock by authorized finger-
print alone, or by code and fingerprint.
P/N Finish Price
SG6120-410 Buffed Chrome 773.01
SG6120-411 Satin Chrome 773.01
SG6120-412 Buffed Brass 783.33
Special Keypad Features:
• Designed for a quick, easy retrot upgrade on many
existing Sargent and Greenleaf electronic safe locks.
• Diameter and mounting screw locations are
the same as for most other S&G electronic safe
locks, so youknow the Biometric Keypad will fit
your application without hardware modifications.
• Top-mounted ngerprint reader is easily accessible.
• You can quickly open your safe in total darkness,
if necessary.
• Front-mounted LCD guides you through the process
of enrolling fingerprints and programming the keypad
functions.
• You select the level of security and convenience.
Allows your safe lock to be opened by:
1—fingerprint only
2—fingerprint and PIN code
3—PIN code only
• Enroll one ngerprint for each PIN position in the
lock.
• Quickly remove authorized ngerprints from the
system when necessary.
• Integral battery compartment makes battery
changes a snap.
• Available in bright chrome, satin chrome,
bright brass and 24-carat gold finishes.
SAFE DEPOSIT KEYBLANKS
P/N Desig. Description Price
SG9500-005 60 Used for renter key with 4442 & 4443 2.95
SG9500-001 87H Std. guard key blank for 4420,4440,4442, 4.53
4444, and 4500 series safe dep.locks
SG9500-016 92H Use for R132 series key locking dial ring 3.52
SG9500-003 96 Std. renter key blank for 4231,4420,4440, 2.95
4444,4100 and 4500 series locks
SG9500-004 9609 Use for the guard key with 4443 safe dep. 2.95
locks
SG9500-002 SY3B Used for the guard key for the 4231 safe 13.98
deposit lock (Yale matchwork)
Go To Table of Contents
578
www.acclock.com
Accredited Lock Supply
• Underwriters Laboratories Listed Type 1, VdS Class 2, CEN B, A2P B, DNV, and RoHS (Reduction of Hazardous
Substances) compliant.
• Lock bolt retraction and extension is controlled by the movement of the safe’s boltwork.
• The Titan™ PivotBolt™ automatically locks to re-secure the safe whenever the container’s boltwork moves to
the fully closed position, discouraging the common (non-secure) practice of day-locking.
• The Titan™ PivotBolt™ is connected to the keypad only by cable, which means the lock does not need to be
placed directly behind the keypad. It can be located anywhere on the inside of the safe door.
• All PivotBolt models use the standard S&G Magic Module footprint, allowing for easy retrot without the need
for boltwork or mounting screw location changes. Plus, it’s universally handed and reversible for RH, LH, VU,
and VD mounting.
• Three modes of operation: Multi-User, Manager/Employee, Dual Control.
• Management reset code, one master code, one supervisor code, eight user codes, and one time delay over-
ride code*. The management reset code (MRC) lets you set a new master code of your own choosing if the old
master code is lost or forgotten.
• The Titan™ PivotBolt™ has a penalty time feature to prevent opening by entering sequential or random codes
until a valid code is found.
• All programming is quickly and easily done via the keypad (no separate programming equipment required).
• The lock bolt model withstands 225 lbs. (1000 newtons) of bolt end pressure for a high level of security in
boltwork blocking applications.
• Can be used with the S&G 2-battery keypad, standard 1-battery keypad, or the non-rotating low prole keypad.
SG2006-108 Titan PivotboltTM with standard 1 battery keypad 178.28
ADVANCED DESIGN PIVOTBOLTTM ELECTRONIC SAFE LOCK
ADVANCED DEISIGN DIRECT DRIVE ELECTRONIC SAFE LOCK
• Underwriters Laboratories Listed Type 1, VdS Class 2, CEN B, A2P B, DNV, and RoHS (Reduction of Hazardous
Substances) compliant.
• The Titan™ D-Drive™ lock features a new design, motor driven locking mechanism for an extra measure of
security and longer battery life.
• Lock bolt retraction and extension is controlled by turning of the keypad, offering dependable manual control
of the locking bolt. And the sure-grip, low profile keypad gives a good, solid feel for the action of the lock.
• The Titan™ D-Drive™ uses the standard S&G Magic Module footprint, allowing for easy retrot without the need
for boltwork or mounting screw location changes. Plus, it’s universally handed for RH, LH, VU, and VD mounting.
• Three modes of operation:
Multi-User—The Master Code, Supervisor Code, and any User Code can open the lock with a single code.
Manager/Employee—Code holders can access the safe only when it’s been enabled by a Master Code or Su-
pervisor Code holder.
Dual Control—Multi-User mode is the factory default, but Dual Control is keypad selectable as an alternate,
permanent mode of operation. Two different lock codes must be entered within one minute of each other to
open the safe. This provides a higher level of security.
• Management reset code, one master code, one supervisor code, eight user codes, and one time delay over-
ride code. The management reset code (MRC) lets you set a new master code of your own choosing if the old
master code is lost or forgotten.
• The Titan™ D-Drive™ has a penalty time feature to prevent opening by entering sequential or random codes
until a valid code is found.
• The lock bolt model withstands 225 lbs. (1000 newtons) of bolt end pressure for a high level of security in
boltwork blocking applications.
SG2007-102 TitanTM D-Drive lock with D-Drive keypad & spindle 196.43
C
ADVANCED DEISIGN D•DRIVETM ELECTRONIC SAFE LOCK - SPARTAN
• Reliable, secure motor actuated locking mechanism.
• Lock bolt is retracted and extended by manually rotating the keypad bezel.
• One million codes to choose from. •Field programmable (via keypad) . • One master code, One user code.
• Factory programmed Management Reset Code can be changed to an MRC of your own choosing during the
initial lock setup.
• Penalty lockout feature shuts the lock down for ten minutes if ve or more incorrect codes are entered in a
row to deter random code entry attempts.
• All programming is accomplished via the keypad; no special programming tools required.
• Deadlocking, motor-blocked bolt withstands over 225 lbs. of end and side pressure.
SG1007-102 SpartanTM D-Drive lock with D-Drive keypad & spindle 173.24
Go To Table of Contents
