Locks 42001 Yale Commercial Price Book May 1, 2018 Ya 5 1
User Manual: Locks May 1, 2018 Mayflower Sales - Current Price Lists
Open the PDF directly: View PDF
.
Page Count: 220 [warning: Documents this large are best viewed by clicking the View PDF Link!]
An ASSA ABLOY Group brand
Commercial Price List #32
Effective May 1, 2018
Canada Effective July 3, 2018
TABLE OF CONTENTS
TOOLS AND RULES
ASSA ABLOY Door Security Solutions®Customer Service Business
Hours & Holiday Schedule ............................................................4
Finish Chart ........................................................................................4
ASSA ABLOY FLASHship™ Program and Locations..........................5
Ordering Tips......................................................................................6
Check List When Placing an Order .....................................................6
Key Definitions and Stamping Rules ...................................................7
Order Forms
Factory Non-Keyed.......................................................................8
Stock Condensed .........................................................................9
Master Keyed ........................................................................10-14
Key Systems Information Request Form...........................................15
Ebusiness .........................................................................................16
On-Line Order Entry..........................................................................17
Fax Program.....................................................................................17
Terms and Conditions..................................................................18-20
Limited Warranty...............................................................................21
Merchandising Aids/Display Mounts............................................22-23
CYLINDERS/KEYS/KEYING
Key Systems Security Policy.............................................................25
Customer Bittings and Sample Keys/Cross Keying...........................25
Bitting List Charges ..........................................................................26
Key Wizard®......................................................................................26
Keying Charges and Keys.................................................................27
Stamping Charges............................................................................28
Key Blanks and Cut Keys............................................................29-30
Construction Core Program ..............................................................31
Cylinders
Component (Cylindrical Lock) .....................................................32
Fixed Core Mortise......................................................................33
Deadlock ....................................................................................33
Fixed Core Rim ...........................................................................34
Electrical Switch..........................................................................34
Hotel ...........................................................................................34
Thumbturn ..................................................................................34
Interchangeable Core .................................................................35
Cores................................................................................................35
Housing Assemblies .........................................................................36
Rings ................................................................................................36
Plugs/Shells......................................................................................36
Security (all types)........................................................................37-38
High Security (UL437).......................................................................39
Security Keys....................................................................................39
Keying Kits .......................................................................................40
Cams................................................................................................41
Cylinder/Miscellaneous Parts.......................................................40-42
Yale®KeyMark®Keying Charges, Keys and Key Blanks ....................43
Yale®KeyMark®Cylinders, Cores and Housings................................44
Yale®KeyMark®Cylinder Parts and Accessories ..........................45-46
Yale®KeyMark®Tools and Service Equipment...................................46
8800 SERIES/GRADE 1/MORTISE LOCKS
Variations ..........................................................................................47
8800FL Series Mortise Locks with Lever Trim ............................48-52
8800 Series Mortise Locks with Knob Trim .................................53-54
8800FL Series Mortise Deadlocks
with A/F, Cylinders & Thumbturns ...............................................55
8800(FL) Series Mortise Lock Bodies................................................56
Trim Packs (Standard Lever Designs)................................................57
Parts ...........................................................................................58-60
8800FL Series Electrified Mortise Locks .....................................61-63
with Lever Trim
8800 Series Electrified Mortise Locks ..............................................64
with Knob Trim
8800(FL) Series Electrified Mortise Lock Bodies ...............................65
SL8800FL Series Security Mortise Locks with Lever Trim............66-67
REFLECTIONS®SERIES MORTISE TRIM
Variations ..........................................................................................68
8800RL Series Mortise Locks ....................................................69-70
8800RL Series Mortise Lock Bodies.................................................71
8800RL Series Trim Packs................................................................71
8800RL Series Trim Parts .................................................................72
8800RL Series Electrified Mortise Locks ..........................................73
8800RL Series Electrified Mortise Lock Bodies.................................74
5400LN SERIES/GRADE 1/CYLINDRICAL LEVER LOCKS
Variations ..........................................................................................75
5400LN Series Cylindrical Locks .....................................................76
5400LN Series Electrified Cylindrical Locks .....................................77
Parts ...........................................................................................78-80
5400CK SERIES/GRADE 1/CYLINDRICAL KNOB LOCKS
Variations ..........................................................................................81
5400CK Series Cylindrical Locks ......................................................82
Parts.................................................................................................83
5300LN SERIES/GRADE 2/CYLINDRICAL LEVER LOCKS
Variations ..........................................................................................85
5300LN Series Cylindrical Locks ......................................................86
5300LN Series Electrified Cylindrical Locks ......................................87
Parts ...........................................................................................88-90
4700LN SERIES/GRADE 1/CYLINDRICAL LOCKS
Variations ..........................................................................................91
4700LN Series Cylindrical Lever Locks.............................................92
4700LN Series Electrified Cylindrical Locks ......................................93
Parts and Cylinders ..........................................................................94
4600(LN) SERIES/GRADE 2/CYLINDRICAL LOCKS
Variations ..........................................................................................95
4600LN Series Cylindrical Lever Locks.............................................96
4600 Series Cylindrical Knob Locks..................................................96
Parts and Cylinders ..........................................................................96
4300LN SERIES/GRADE 2/TUBULAR LEVER LOCKS
Variations ..........................................................................................97
4300LN Series Tubular Locks ...........................................................98
Parts.................................................................................................99
RL SERIES/TUBULAR LEVER LOCKS
Variations ........................................................................................101
RL Series Tubular Locks .................................................................102
Parts...............................................................................................102
6400LN SERIES/MONOLOCK RETROFIT
Variations ........................................................................................103
6400LN Series Monolocks..............................................................104
Parts .......................................................................................105-106
AUXILIARY LOCKS/CABINET LOCKS/PADLOCKS
Variations ........................................................................................107
Cylindrical Deadbolts
D100 & D200 Series .................................................................108
Parts & Accessories..................................................................109
350 Series Mortise Deadlocks ........................................................110
Auxiliary Latch ................................................................................110
Auxiliary Locks................................................................................111
Padlocks
PD400 Series............................................................................112
PD500 Series............................................................................113
PD600 Series............................................................................114
Cabinet Locks ................................................................................114
7000 SERIES/ARCHITECTURAL EXIT DEVICES
Variations ........................................................................................115
How to Order..................................................................................116
Mechanical Options ........................................................................117
7100 Series Exit Devices ................................................................117
7100 Series Trim .....................................................................118-120
7130 Series Mortise Exit Devices....................................................121
7130 Series Trim.............................................................................122
7200 Series Narrow Stile Exit Devices ............................................123
7200 Series Trim.............................................................................124
7000 Series Electrified Exit Devices Options ...................................125
7000 Series Alarm Kits ...................................................................125
7000 Series Delayed Egress ..........................................................126
Cylinders .................................................................................127-128
Miscellaneous..........................................................................128-130
Removable Mullions ................................................................131-132
2
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
6000 SERIES/ARCHITECTURAL EXIT DEVICES
Variations ........................................................................................133
How to Order..................................................................................134
Mechanical Options ........................................................................135
6100 Series Exit Devices ................................................................135
6100 Series Trim .....................................................................136-138
6130 Series Mortise Exit Devices....................................................139
6130 Series Trim.............................................................................140
6200 Series Narrow Stile Exit Devices ............................................141
6200 Series Trim.............................................................................142
6000 Series Electrified Exit Devices Options ...................................143
6000 Series Alarm Kits ...................................................................143
Cylinders .................................................................................144-145
Miscellaneous..........................................................................146-147
Removable Mullions ................................................................148-149
2100 SERIES/FLATBAR EXIT DEVICES
Variations ........................................................................................151
How to Order..................................................................................152
2100 Series Exit Devices ................................................................153
2100 Series Trim .....................................................................154-155
Cylinders.........................................................................................156
Miscellaneous .................................................................................157
Removable Mullions........................................................................158
1800 SERIES/FLATBAR EXIT DEVICES
Variations ........................................................................................159
How to Order..................................................................................160
1800 Series Exit Devices ................................................................161
1800 Series Trims ...........................................................................161
Cylinders and Miscellaneous...........................................................162
Mullions--- ......................................................................................163
Mullion Parts...................................................................................163
1500 SERIES/TRADITIONAL EXIT DEVICES
Variations ........................................................................................165
How to Order..................................................................................166
1500 Series Exit Devices ................................................................167
1500 Series Trim .....................................................................169-169
Cylinders.........................................................................................170
Miscellaneous .................................................................................171
Removable Mullions........................................................................172
5800 SERIES/CAST IRON DOOR CLOSERS
5800 Series Door Closers and Parts ...............................................173
4400 SERIES / INSTITUTIONAL DOOR CLOSERS
Variations ........................................................................................175
4400/4400S Series Closers ............................................................176
Accessories ....................................................................................177
Closer Bodies and Screw Packages...............................................178
Arms and Arm Assemblies ......................................................179-182
Track Assemblies and Parts............................................................183
3000 SERIES / ARCHITECTURAL DOOR CLOSERS
Variations ........................................................................................185
3101/3301 Series Closers ..............................................................186
3501 Series Closers .......................................................................187
Accessories ...................................................................................188
Closer Bodies and Screw Packages...............................................189
Arms and Arm Assemblies ......................................................190-192
2700 SERIES / ARCHITECTURAL DOOR CLOSERS
2700 Series Door Closer and Parts ................................................193
51 SERIES / INDUSTRIAL DOOR CLOSERS
Variations ........................................................................................195
51 Series Closer .............................................................................196
Accessories ....................................................................................197
V51 Series Visual Pack Closers ......................................................198
Closer Bodies and Screw Packages...............................................199
Arms and Arm Assemblies..............................................................200
1100 SERIES / INDUSTRIAL DOOR CLOSERS
1100 Series Door Closer and Parts ................................................201
1900 SERIES / TRADITIONAL DOOR CLOSERS
Variations ........................................................................................203
1900 Series Closers and Accessories.............................................204
Arms and Arm Assemblies..............................................................205
Screw Packages.............................................................................206
YDC200 SERIES / ECONOMY DOOR CLOSERS
YDC200 Series Door Closer and Parts ...........................................207
ELECTRIFIED PRODUCTS
Door Alarm
SDA16 Door Alarm, Options and Cylinders...............................208
Accessories ..............................................................................210
nexTouch™ Cylindrical Lock...........................................................211
Variations ..................................................................................212
Cylinders...................................................................................212
Accessories ..............................................................................213
nexTouch Sectional Mortise Lock
Variations ..................................................................................216
Lock Body ................................................................................217
Cylinders...................................................................................217
Accessories ..............................................................................218
3
DISTRIBUTOR LIST PRICES
TABLE OF CONTENTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
ASSA ABLOY DOOR SECURITY SOLUTIONS
CUSTOMER SERVICE - MONROE
8:00 a.m. – 4:30 p.m. (Eastern)
1902 Airport Road
Monroe, NC 28110
Telephone #: (800) 438-1951
Fax #: (800) 338-0965
TECHNICAL PRODUCT SUPPORT
8:00 a.m. – 4:30 p.m. (Eastern)
Telephone #: (800) 438-1951
support@yalelocks.com
ELECTRIFIED TECHNICAL PRODUCT SUPPORT
8:00 a.m. – 4:30 p.m. (Eastern)
Telephone #: (800) 810-WIRE (9473)
Fax #: (203) 603-5981
ASSA ABLOY DOOR SECURITY SOLUTIONS
CANADA CUSTOMER SERVICE - VAUGHAN
8:00 a.m. – 4:30 p.m. (Eastern)
160 Four Valley Drive
Vaughan ON L4K 4T9
Telephone #: (800) 461-3007
Fax #: (800) 461-8989
ASSA ABLOY Door Security Solutions
Customer Service - Monroe will be CLOSED
on the following holidays:
• May 28, 2018
• July 4, 2018
• September 3, 2018
• November 22-23, 2018
• December 24-26, 2018
• January 1, 2019
ASSA ABLOY Door Security Solutions
Customer Service - Vaughan
• May 21, 2018
• July 2, 2018
• August 6, 2018
• September 3, 2018
• October 8, 2018
• November 23, 2018
• December 25, 2018
• December 26, 2018
• January 1, 2019
Technical Product Support will be CLOSED
on the following holidays:
• May 28, 2018
• July 4, 2018
• September 3, 2018
• November 22-23, 2018
• December 24-25, 2018
• January 1, 2019
4
HOLIDAY SCHEDULE*
DISTRIBUTOR LIST PRICES
BUSINESS HOURS
ANSI/BHMA
CODE FINISH DESCRIPTION
600 Primed for Painting
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated
611 Bright Bronze, Clear Coated
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened, Satin Relieved
Clear Coated
618 Bright Nickel Plated, Clear Coated
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin Relieved,
Clear Coated
FINISH CHART
ANSI/BHMA
CODE FINISH DESCRIPTION
625 Bright Chrome Plated
626 Satin Chrome Plated
629 Bright Stainless Steel
630 Satin Stainless Steel
676 Flat Black Powder Coat
689 Aluminum Painted
690 Dark Bronze Painted
691 Light Bronze Painted
693 Black Painted
694 Medium Bronze Painted
695 Dark Bronze Painted
696 Satin Brass Painted
BSP Black Suede Powder Coat
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide sample. Refer to individual sections for specific product availability.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted by DSS.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Dates subject to change.
5
DISTRIBUTOR LIST PRICES
7 Brands...One Invoice
in a Flash!
The ASSA ABLOY FLASHship™ program, with products from your favorite brands of Markar, McKinney, Norton, Pemko, Rixson, Rockwood
and Yale, offers the convenience of placing ONE purchase order coupled with 24-hour processing. Products may be ordered in any
combination with only a $50 minimum. Same day order entry and eligibility for buying program discounts makes this your one-stop for these
popular products!
What types of products are available on the FLASHship program?
– Markar, McKinney and Pemko continuous and architectural hinges
– Pemko thresholds, gasketing, and aluminum geared hinges
– Rixson pivots, stops and holders
– Rockwood door hardware and trim
– Norton door controls
– Yale mortise locks, Grade 1 and Grade 2 cylindrical locks/deadbolts, exit devices, door closers,
nexTouch™ keypad access locks and others
How do I place an order?
FLASHship WebShop
FLASHship WebShop makes ordering your favorite ASSA ABLOY products easier than ever before.
Enhancements include:
– User-friendly interface for simplified navigation
– High resolution product images for easy identification
– Several ways to shop: search by keyword or filter by product type
– Streamlined order & payment processing for quick checkout
– Saved order history - reorder in just a few clicks
– Helpful ordering tools including Quick Order, multiple carts, and lists
Traditional Order Submittal.
1. Use the FLASHship Order Form found in the current FLASHship program catalog
OR prominently indicate “FLASHship Program” on purchase order
2. Use the part numbers listed in the FLASHship catalog to indicate products
3. Fax all orders to 877-888-2772 or email to flashship@assaabloy.com
Notes:
• Minimum order is $50
• Prepaid freight on orders over $1500
• Only products listed in the FLASHship program catalog are eligible
• Reference the program catalog for a complete list of Terms & Conditions
ASSA ABLOY FLASHSHIP™ PROGRAM
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1-877-888-2772
flashship@assaabloy.com
FLASHship East
at ASSA ABLOY New England Service Center
225 Episcopal Rd.
Berlin, CT 06037
FLASHship South
at ASSA ABLOY Southeast Service Center
825 Riverside Parkway
Suite 500
Austell, GA 30168
FLASHship West
at ASSA ABLOY Southwest Service Center
5678 Concours
Ontario, CA 91764
FLASHship Chicago
at ASSA ABLOY Midwest Service Center
235 East Lies Road
Carol Stream, IL 60188
FLASHship Dallas
at ASSA ABLOY South Central Service Center
2855 Marquis #160
Garland, TX 75042
ASSA ABLOY FLASHSHIP™ LOCATIONS
Note that some products may not be available in Canada
as well as some of the programs offered in this price
book may differ between the USA and Canada.
Please contact your sales representative for more information.
Before placing your order, check for the following …
• Purchase Order on Company Letterhead
• Purchase Order is Legible
• Purchase Order Number
• Account Number
• Ship To Address
• Contact Person for additional information requirements
• Pricing Requirements – Buying Program or CPQ (please attach)
• FlashShip™ Order (FlashShip™ Order Form or FlashShip™ #’s
Included)
• Contract Order (Keyed Lead Sheets attached)
• Keysets for ALL Keyed Product
• Handing (if applicable)
• Design (if applicable)
• Backset & Strike (if applicable)
• Finish (if applicable)
• Please submit ASSA ABLOY FLASHship™ Product Orders and Plant Product Orders on separate order forms.
• Please use FLASHship™ Order Forms for all FLASHship™ Product Orders and include FLASHship™ Part Numbers.
• Order Forms are included in the Yale®Price Book and at www.yalelocks.com.
• Please include Job Name and Registry Number for all contract orders.
• Keyed Lead Sheets A and B are required for contract orders that require Master Keying.
• Remember to include Keysets on all contract orders.
• Be sure to include Handing for mortise locks and exit devices.
• If you have a Quote, please include it with the purchase order. Orders without this information included may be delayed.
• Be sure to include Design.
• Be sure to include Backset and Strike on the 4300 and 5300 knobs and levers.
• Be sure to include Finish.
When submitting purchase orders for processing, please remember that certain cylinder types and/or keyways require additional
administrative documentation before the order can be entered.
Purchase orders will be held and questioned if the following keyway/cylinder types do not have the proper administrative documentation
submitted with each purchase order:
• Yale®KeyMark®products
• Security cylinders and keys
• High security cylinders and keys
All of the above product types must be accompanied by additional administrative documents unless they are shipping direct to the end user
facility. These administrative documents include, but may not be limited to, the following:
• Letter of Authorization – must be submitted on the end user facility letterhead, dated and signed by an authorized individual from the facility.
Letter must be quantity-specific for certain product types. Yale®does not keep letters of authorization on file.
• Registration Certificate – only required for Yale KeyMark.
6
ORDERING TIP ADMINISTRATIVE DOCUMENTATION
DISTRIBUTOR LIST PRICES
ORDERING TIPS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CHECKLIST
7
DISTRIBUTOR LIST PRICES
KEY STAMPING DEFINITIONS AND RULES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Below are stamping codes and their definitions:
Code Definition
VKC0 No keyset, registry number, or bitting stamping any keys. Includes master keys and change keys. Keys will be stamped with
keyway designation. (Keys will be tagged.)
VKC1 Master keys stamped with their keyset symbol and registry number. Change keys stamped with their keyset symbol. (Standard
for high security, security and Yale®KeyMark®cylinders.)
VKC2 Master keys stamped with their keyset symbol and registry number. Change keys stamped with their keyset symbol. Cylinders
stamped with their keyset symbol on the face of the plug. (Not available for high security cylinders, security cylinders or Yale
KeyMark.)
VKC3 Master keys stamped with their keyset symbol and registry number. Change keys stamped with their bitting. Cylinders
stamped with their keyset symbol on the face of the plug. (Not available for high security cylinders, security cylinders or Yale
KeyMark.)
CKC2 Master keys stamped with their keyset symbol and registry number. Change keys stamped with their keyset symbol. Cylinders
stamped with their keyset symbol in a concealed location.
CKC3 Master keys stamped with their keyset symbol and registry number. Change keys stamped with their bitting. Cylinders
stamped with their keyset symbol in a concealed location. (Not available for high security cylinders, security cylinders or Yale
KeyMark.)
The following examples indicate what will be stamped on the thumb (logo) side of the keys when the codes are used. (Thumb side is
determined by holding the key normally in your right hand.)
1. KEYS FOR MASTER KEYED CYLINDERS
A. Master Keys: B. Change Keys:
2. CHANGE KEYS FOR KEYED RANDOM CYLINDERS
Code Stamping Location Example
N/A System + Bitting Top Line E253653
NONE Bottom Line
3. CHANGE KEYS FOR 0-BITTED CYLINDERS
Code Stamping Location Example
NONE
In addition, other standard practices for stamping Yale®keys are:
• For all Yale keys the keyway is stamped on the index finger side (non-logo side) of the key.
• The keyway will not be stamped on the key for stock keyway (Para), or keys for security cylinder, high security cylinders or Yale KeyMark®.
• “Do Not Duplicate” or any special stamping will be stamped on the index finger side (non-logo side) of the key.
• The Yale logo is standard on all keys unless otherwise requested.
• VKC1 is standard for all keys for high security cylinders, security cylinders and Yale KeyMark.
• VKC2, VKC3 or CKC3 is not available with high security cylinders, security cylinders or Yale KeyMark.
• All Yale KeyMark keys are coined on the index finger side of the key with the Yale logo. All stamping is done on the thumb side.
Code Stamping Location Example
VKC0 NONE ------- Keys will be
tagged
VKC1, VKC2,
VKC3, CKC3, or
CKC3
Registry Number
Keyset
Top Line
Bottom Line
R69596
GMA
No VKC or CKC Registry Number
Keyset
Top Line
Bottom Line
R69596
GMA
Code Stamping Location Example
VKC0 NONE ------- Keys will be tagged
VKC1, VKC2 or
CKC2
Keyset
NONE
Top Line
Bottom Line AA1
VKC3, CKC3 or No
VKC, No CKC
System + Bitting
NONE
Top Line
Bottom Line E253653
8
9
Stock - Condensed Order Form
Sheet of
This Sheet Only
Customer Name Purchase Order No.
Qty. Series, Function and Trim Cylinder Finish Options
(Latch, Strike, etc.)
*Cylinder Requirements Length Pins: Keyway: Cam/TP:
Special Notes:
Item Qty. Hand (Specify quantity) Door Number
(Up to 10 characters)
Heading
(Up to 10 characters)
RH LH RHR LHR
10
Keyed Order - Lead Sheet “A”
(Use with Keyed Order-Condensed Form)
Sheet of
Date:
Sold To: Ship To:
Job Name and Address
Purchase Order Number:
Date Required:
❏New
❏Existing Registry Number
Order Number
❏Customer Bittings (please attach)
❏1 - SKD ❏2- MK
❏3 - GM ❏4 - GGM
❏High Security ❏IC ❏Conventional
❏Yale®Keymark®❏Other
*To avoid order delay please attach required documention
Keyway Selection:
❏Stock - Para ❏Stock GA ❏Restricted
❏Specific Keyway
Number of Pins: ❏5❏6 (Default) ❏7
Key Bow Style:
Key Stamping:
*Refer to current price book for applicable stamping charges
❏
VKCO - No No Bitting or Keyset Stamped - Keys AreTagged
❏VKC1 - VIsual Key Control - Keys Only
❏VKC2 - Visual Key Control - Keys and Cyllnders
❏VKC3 - Visual Key Control - Cylinders Only
❏CKC2 - Concealed Key Control - Cylinders and VKC Keys
❏CKC3 - Concealed Key Control - Cyllnders Only
❏Blttlngs ( Standard for change keys)
❏DO NOT DUPLICATE
❏US PROPERTY DO NOT DUPLICATE
❏No Logo ❏Keys ❏Cylinder Face
❏Special Stamplng: ❏Die Stamp: ❏New or ❏Existing
❏Keyset and Bitting
❏Keyset in Lieu of Bitting
2 System Status
3 Highest Level Of System
4 System Type
5 Keys
6 Key Quantity
Two cut change keys standard per lock/cylinder. Key blanks
cannot be substituted for cut keys.
Master Level Qty.
❏GGM
❏GM
❏MK/Group
❏Other
❏Other
❏Other
7 Cross Keying
Key Symbol To Be Operated By
8 Construction Master Keying
This Order ❏Yes ❏No
❏Establish For Future Use Only
Ship Construction Keys To:
Attention:
This section does
not refer to Temp.
Construction Cores
Change Keys Qty.
Per Cylinder
Per KA Group
Per KD Cylinder
Total # of Keys Supplied
No change keys provvided
when keyed to master key
only
Special Functions Qty.
❏Control
❏CMK
❏CMK Control
❏Emergency
❏SKD Control
❏SKD CMK
❏Blockout
❏Maintenance
❏Housekeeping
❏Mechanical
❏Janitorial
❏Other
11
Keyed Order - Lead Sheet “B”
(Use with Keyed Order-Condensed Form)
Sheet of
Date:
Sold To:
Purchase Order Number:
Date Required:
9 Pricing 12 Bitting List
Provide Bitting List for This Order: ❏Yes ❏No
Letter of Authorization: ❏Attached
Mail Bitting List To:
Attention:
If Ship To for B/L is other than the end user B/L will not be sent
unless LOA is attached.
Additional Information (Use Additional Sheets if Needed)
System Expansion Requirements, Special Remarks, etc.
Order subject to the following pricing:
❏Price List Dated
❏Special Job Quote
❏Date Quoted
❏Quote Number
Discounts Quoted
❏Cylindrical Locks
❏Mortise Locks
❏Auxiliary Locks
❏Cylinders Only
❏Exit Devices
❏Exit Devices
❏Door Closers
❏Electrical Options
❏Other
❏Other
10 Packing and Marking
❏Pack Change Keys With Locks (Standard)
❏Pack Keys Separately (Std on HS, KM and CMK)
Label Boxes: ❏Key Symbol
❏Door Number
❏Heading
Special Instructions for Change Keys:
11 Shipping Instructions for Master Keys
Ship Master Keys To:
Attention:
13 Contacts
Name if individual in your organization who is
knowledgeable about this project, should any clarification
be necessary. (Please type or print.)
Name
Phone
Fax
12
Keyed Order - Condensed Form “C”
(Use with Keyed Order Lead Sheet)
Sheet of
This Sheet Only
Total Qty Customer Name Purchase Order No.
Pg Qty. Series, Function and Trim Cylinder Finish Options
(Latch, Strike, etc.)
Special Notes:
Item Qty. O/S Key
Symbol
I/S Key
Symbol
Hand (Specify quantity) Door Number
(Up to 10
characters)
Heading
(Up to 10
characters)
RH LH RHR LHR
13
Sheet of
Total Qty
Pg Qty Finish
Heading
Length
Keyed Order - Condensed Form "D"
(Cylinders Ordered Separately)
This Sheet Only
Purchase Order Number
Customer Name
Item
Qty
Special Notes:
Key Function
(Up to 10 characters)
Used
Door Number
Key Symbol
Collar#:
Collar Size:
Cylinder
Pins
Cam/Tailpiece
Finish
14
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Sheet of
Total Qty
Pg Qty
RH LH RHR LHR
Item
(Up to 10 characters)
Non-Keyed Items "E"
(Use with Keyed Order Lead Sheet)
(Up to 10 characters)
Hand (Specify Quantity)
Door Number
Heading
Qty
This Sheet Only
Purchase Order Number
Customer Name
Options
Special Notes
Function
Trim
Finish
Series
15
Effective Date: May 1, 2018
Canada Effective July 3, 2018
16
DISTRIBUTOR LIST PRICES
WEBSITE
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Visit www.yalelocks.com to sign up for eBusiness access.
ASSA ABLOY Door Security Solutions provides sales and support for Yale Locks & Hardware.
To sign up for eBusiness, follow the simple instructions below. Register today!
eBusiness offers anytime access to:
• Place Orders with On-Line Order Entry
• Order Status
• Order Check by P.O.
• Stock Status Check
• Cross Reference Guide
• Key Systems Administrative Forms
• Key Wizard®Ordering
• Newsletters
• Online Store
• Contact Webmaster
• Extended Literature (Price Books, Order Forms, Keyed Lead Sheets)
• Fax Program Signup
• Order Acknowledgement
• Invoice
• Return Good Authorizations
How to sign up for eBusiness:
Step 1: Visit our website at www.yalelocks.com.
Step 2: Click Extranet in top navigation bar.
Step 3: Click "Sign up for Extranet Account" to complete our eBusiness sign-up form.
Yale Locks & Hardware’s website at www.yalelocks.com is the place to go for all your Yale product information needs. Easy-to-navigate
menus and intuitive icons allow simple and fast access to the latest on new products, as well as the most up-to-date
catalogs, templates and installation instructions.
From the Yale website, you can click to the ASSA ABLOY eBusiness site. This site, for Yale account customers only, provides information
about your orders, invoices and RGAs. See the eBusiness section below for more information.
EBUSINESS
17
DISTRIBUTOR LIST PRICES
TABLE OF CONTENTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
ONLINE ORDER ENTRY
Would you like to receive your acknowledgements, invoices and Return Good Authorizations quickly and efficiently?
If so, ASSA ABLOY Door Security Solutions offers the Order Acknowledgement, Invoice and Return Good Authorization Fax Program. Please
see the simple steps below to get signed up today!
Requirement: Valid eBusiness User ID and Password
(If you do not have an eBusiness User ID and Password, please refer to eBusiness Sign-up Section included in this Price Book.)
Step 1: Log into eBusiness. Go to "Customer Service".
Step 2: Click on "Fax Program Signup".
Step 3: Fill in appropriate information.
Step 4: Click on “Sign up for Fax Program!”
TABLE OF CONTENTS
FAX PROGRAM
Would you like to reduce the time to get your
orders entered to the factory and eliminate
errors associated with manual order entry?
Then try our on-line order entry system. Our
convenient web-based order forms can help
you submit your orders directly to the factory
in minutes.
Contact your customer service representative
who will be able to issue your user name and
password as well as set up appropriate
training sessions for you and your staff.
ACCEPTANCE
Yale®reserves the right to decline an order, in whole or in part, when the
type or quantity of goods or credit worthiness of the Purchaser is not
satisfactory to us in our sole and absolute discretion.
Purchase Orders, Quote requests, Acknowledgements or the like issued
by the Purchaser that have contrary standard terms and conditions are
not binding on Yale, unless such terms and conditions are approved in a
separate written agreement by Yale authorized representatives. In the
event of an acceptance of Purchaser’s Purchase Order by Yale, the
Purchaser agrees that such acceptance is solely conditioned on
Purchaser’s acceptance of the terms and conditions set forth in this
instrument, regardless of the terms and conditions specified in
Purchaser’s Purchase Order. The terms and conditions in Purchaser’s
Purchase Order which conflict with the terms and conditions of this
instrument shall be disregarded and are hereby rejected, and this
instrument shall constitute the entire agreement between Yale and the
Purchaser.
In the event that Yale does not enforce or require strict performance of
any term or condition hereof, or of any other document, instrument or
other agreement relating to goods sold, such lack of enforcement or
requirement of strict performance will not waive, affect or diminish any
right of Yale to enforce or require strict performance of such term or
condition in the future.
PRICES
All prices are subject to change without notice and are not guaranteed.
All shipments will be made at prices in effect at the time of shipment.
Possession of this price list does not constitute an agreement to sell.
We reserve the right to correct clerical, stenographic and other obvious
errors at any time.
TERMS
Invoices dated the 1st through the 15th will be due for 2% discount on
the *10th of the following month. Invoices dated the 16th through the
31st will be due for 2% discount on the *25th of the following month.
*Net immediately thereafter. (Yale retains the right to sell or to decline to
sell to any Customer for any reason whatsoever that in its judgment is
deemed sufficient.)
It is understood that Yale may impose and charge a finance charge which
is the lesser of one and one-half percent (1-1/2%) per month or the
highest rate allowed by law on any amount which becomes past due and
delinquent. Additionally the Customer shall be responsible for all
collection costs, court costs and reasonable attorney’s fees (where
allowed by law) in connection with the recovery of any delinquent
amount.
FREIGHT
All orders are shipped FOB factory/warehouse, except as expressly
provided below. When delivered to the Transportation Company, the
Purchaser assumes the risk of loss or damage in transit.
Customer orders with net product value in excess of $7,000.00 will be
shipped prepaid by the Yale carrier of choice to a single destination point
in the United States.
Customer orders with net product value less than $7,000.00 will be
shipped prepaid by the Yale carrier of choice and freight and handling
charges will be added to the customer’s invoice.
A minimum freight and handling charge of $15.00 will be charged on
orders with net product value of $400.00 or less. The minimum freight
and handling charge will not apply to orders for only Cut (bitted) keys of
any type, Master keys, Master keyed cylinders or padlocks and factory
generated bitting lists that do not have any other product types included
on the order. Freight on these orders will be charged as the percentage
of invoice value.
For orders with net product value greater than $400.00 and less than
$7,000.00, freight charges will be calculated as a percentage of the net
invoice value and will be added to Customer’s invoice. The percentage is
based on the National U.S. Average On Highway Diesel Fuel Prices as
reported by the US Department of Energy in effect at the beginning of
each quarter. On the first Monday of each quarter, the new rate will be
published on the Yale and Door Security Solutions extranet and will go
into effect on the 2nd Monday of the quarter. Please refer to the Yale
distributor extranet for the rate chart and information on the current
freight charge percentage. The percentage in effect at the time of
shipment of the order will be charged.
Great Grand Master keys, Grand Master keys, Master keys, Construction
Master keys, Control Keys, and Change Keys which are shipped
separate from customer order for security reasons, on orders with total
net product value in excess of $7,000.00 will be shipped prepaid by the
Yale carrier of choice. If the total order value is less than $7,000.00, the
shipping charges will be added to Customer’s invoice.
If a customer provides their own freight account number for the freight
charges, Yale will apply a handling fee of $25.00 to the invoice.
Expedited shipping options – If the customer requests an expedited
method of shipment such as “Next Day Air” the charges will be prepaid
by Yale and the full rate for the service, as published by the carrier, will be
added to the customer’s invoice.
Packing – Yale will pack, mark and ship the products according to its
standard procedures for shipment, unless the parties agree, in writing,
that Yale will comply with any special instructions provided by the
customer. Special instructions must be submitted, in writing, at time of
order placement. Compliance with special instructions may result in an
increased price.
MINIMUM ORDER
Minimum order value for complete product is $250.00 net product value.
The minimum order value for parts orders is $100.00 net product value.
In the event that the net product value does not meet the required net
minimum, Yale may, at its sole discretion (a) apply a minimum order
charge, (b) reject the order or (c) waive the minimum requirement
provided that the waiver of the requirement for one order shall not
constitute a waiver of the requirement for any future orders.
The following products are exempt from this policy: Cut (bitted) keys of
any type, Master keys, Master keyed cylinders or padlocks and factory
generated bitting lists.
QUOTATIONS
If Yale elects to offer a quote, such quote will be valid until the expiration
date on that quote. Complete shipment of the order must be accepted
by Purchaser within standard lead times.
The quote number must be referenced on the order. Any invoiced order
that has the incorrect discount applied to it and did not have
the quote number written on the order will have a service fee of $100.00
net DEDUCTED from any sales credit issued for the difference in
discount.
The quote is null and void if the Purchase Order does not include ALL
product lines listed on the quote or if the quantities for any item covered
by the quote deviate by 10% or more.
With the issuance and acceptance of a quote for the purchase of
products, the Purchaser agrees that products so purchased will not be
resold or transferred to any Distributor not authorized by Yale to sell its
products. This would be inclusive of branches of the quoted Distributor.
Failure to abide by this restriction may result in the Distributor’s ineligibility
for Quotations, or other actions at Yale discretion.
Yale and its sales representatives reserve the right, in their sole
discretion and for any reason, to refuse a Distributor’s request to quote a
price other than the Yale standard list price and regardless of whether
Yale or its sales representatives have previously quoted discounted prices
to the Distributor on some or all of its orders.
NON-CATALOGED PRODUCTS
Products not cataloged or listed in this price book will be considered as
special products, and will not be manufactured without prior written
approval from Yale.
A minimum special handling charge of $50.00 will be added for non-
cataloged product. Any additional labor or material required will be
charged accordingly. If products have already been made and/or are
located in the shipping room, the 45% restocking fee will apply.
Special products require special handling, and therefore standard lead
times may not apply. Please consult with your Yale®Sales Representative
for further details.
18
DISTRIBUTOR LIST PRICES
TERMS & CONDITIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
19
DISTRIBUTOR LIST PRICES
TERMS & CONDITIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CHANGES/CANCELLATION OF ORDERS
Changes or cancellations to an order will result in a charge of costs for
material and labor expenses that have been incurred prior to
notification from Customer. Handling charges are billed on Customer’s
original order. If products have already been made and/or are located in
the shipping room, the 45% restocking fee will apply.
All Non-Cataloged Goods and Yale®Quick Ship Orders may not be
changed or cancelled.
All change requests for goods, other than for the reasons stated above,
must be submitted in writing to Customer Service within two (2) business
days of receipt of acknowledgment of the order.
ADD-ON ORDERS TO QUOTE
Any new order requesting special pricing to match an existing quote
number, which has already been ordered, will be accepted up to sixty (60)
days after the acknowledgement of the original order. All add-on orders
must reference the original factory order number and the corresponding
quote number to receive the quoted pricing discount. Add-on orders for
stock will not be accepted.
PACKAGING
Many items are defined as to Case Lot Packaging or Minimum Order. The
Case Lot policy does not apply to hardware to be used on a specific
hardware project.
DELIVERY
Orders will be acknowledged and given a scheduled delivery date based
on estimated manufacturing lead times. Complete information is required
to process all orders. Orders with insufficient information for processing
(i.e. door sizes, handing, etc.) may be subject to extended lead times
which are relative to the time required in obtaining the necessary
information for order processing. Manufacturing lead time will begin once
all information is received to process an order. Yale will use reasonable
efforts to deliver products as estimated, but makes no guarantees as to
delivery dates.
Yale will not be liable for back charges incurred based on availability of
product or as a result of delays in delivery caused by insufficient
information required to process an order. Yale will not be held responsible
for delays in delivery caused by strikes, fires, floods or any other causes
beyond our control, including the delivery of material to us. Under no
circumstances shall Yale be liable or accountable for consequential
damages due to failure of delivery.
CLAIMS
In the event of Company or Customer error, claims for shortages, pricing
errors and/or incorrectly filled orders must be submitted in writing to
Customer Service within thirty (30) days from receipt of material.
Any claims for shortages or damage by the Carrier must be made by the
Customer directly to the Carrier.
INVOICE DEDUCTION
A Yale Sales Representative or Customer Service Representative must be
notified of any disputed invoices within sixty (60) days from the date of
invoice. Deductions should only be taken for the disputed amount and the
balance of the invoice is due and payable within standard payment terms.
RETURNED GOODS
It is the policy of Yale to not accept returns of any materials that are
correctly furnished as per the Distributor’s Purchase Order. Return of
product due to customer order error or accommodation must be pre-
arranged with Yale and approved in writing by Yale Sales Management.
All products returned as “Goodwill” must meet the following criteria to be
considered a return:
• Be in original, unmarked and undamaged cartons.
• Be valued in excess of $250.00 net.
• Shipped and invoiced within the previous 120 days.
• Custom, non-cataloged goods, master-keyed or Yale Quick Ship
product is not returnable.
A MINIMUM restocking fee of 45% will be charged. Upon receipt and
verification by Yale that the returned merchandise meets the foregoing
conditions, a credit will be issued for the original invoice amount less the
MINIMUM 45% restocking fee.
“Goodwill” products that meet the foregoing criteria may be returned by
fulfilling the following conditions:
• Send an RGA request in writing to the Yale Sales Representative
serving the Purchaser’s area.
• Ensure the RGA labels that are sent to Purchaser by Yale are visible on
return goods shipment.
• Ensure that the RGA number appears on the return shipment label and
is legible.
• Return the authorized merchandise within sixty (60) days from the date
of RGA issuance date.
• Return shipments must be freight prepaid to the location specified on
the RGA. Yale is not liable for damages to product during shipping.
No credit may be taken or issued prior to RGA approval and receipt
of product.
All defective goods within the terms of our limited warranty may be
returned for credit or replacement.
TAXES
Prices do not include any present or future Federal, State, or Local
property, license, privilege, sales, use, excise, gross receipts or other like
taxes or assessments, which may result from transactions or any services
performed in connection herewith.
GOVERNING LAW
The rights and obligations of the parties shall be governed by the laws of
the State of North Carolina, excluding any conflicts of law provisions. The
United Nations Convention on Contracts for the International Sale of
Goods shall not apply to this Agreement.
LIMITED WARRANTY
The Terms and Conditions outlined above are subject to the Yale Limited
Warranty, which is included in this Price List and incorporated herein by
reference.
PRODUCT MODIFICATIONS
Yale products are not designed or intended for aftermarket modification.
The warranty on Yale products becomes void if the product is modified in
any way, regardless of whether the modification causes or contributes to
any alleged defect. Warranty voiding modifications include, but are not
limited to, third-Party electrification of non-electric products and/or the
installation of non-approved or
non-Yale components.
If a Yale product is modified it no longer meets industry certification and
quality control standards applicable to the original product and is no longer
a genuine Yale product. A modified product may not be sold as a Yale
product and no Yale®trademarks or certification marks based on the
original Yale product, such as U.L. or ANSI/BHMA marks, may appear
anywhere on the modified product or on any packaging, literature, or
instructions sold with the modified product.
All original Yale branded packaging and literature carries Yale trademarks
and must be destroyed if the original Yale product is modified. Portions of
the product that carry a Yale trademark or certification mark must be
discarded and/or replaced by the party making the modification. U.L. and
other certification testing and marking are also the responsibility of the
party making modification. The use of Yale trademarks on modified
products constitutes trademark infringement.
CYLINDERS FOR COMPETITOR PRODUCTS
Cylinder Service Fee: YALE cylinders or cores for use in non-YALE
manufactured locking devices for which YALE has an equivalent, will be
assessed an additional Cylinder Service Fee. This fee applies to
masterkeyed cylinder only orders, 1 bitted high security cylinders and zero
or 1 bitted restricted cylinder orders
20
DISTRIBUTOR LIST PRICES
TERMS AND CONDITIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
FIRE RATED OPENINGS
Any retrofit or other field modification to a fire rated opening can
potentially impact the fire rating of the opening, and Yale makes no
representations or warranties concerning what such impact may be
in any specific situation. When retrofitting any portion of an existing
fire rated opening, or specifying and installing a new fire-rated
opening, please consult with a code specialist or local code official
(Authority Having Jurisdiction) to ensure compliance with all
applicable codes and ratings.
TRADEMARK USE POLICY: ASSA ABLOY AMERICAS
The following policy (“Policy”) of ASSA ABLOY Americas (“ASSA
ABLOY”), and all of its affiliated group companies (collectively, the
“Group Companies”), applies to the use of certain intellectual
property of all such Group Companies, including all trademarks,
names, logos, product images, and related information (the “ASSA
ABLOY Marks”). ASSA ABLOY Marks are proprietary and critical to
the success of ASSA ABLOY and the Group Companies, and may
only be used in strict compliance with this Policy.
This Policy covers any person or entity reselling any product of any
Group Company with the consent of such Group Company (each,
an “Approved Reseller”). Each Approved Reseller has a non-
exclusive right to use certain of the ASSA ABLOY Marks relating to
any of the Group Companies for which it is an Approved Reseller,
subject to the following
conditions:
(1) Approved Reseller’s use of ASSA ABLOY Marks must be truthful,
fair, and not misleading;
(2) Approved Reseller’s advertising must clearly indicate that it is
advertising of the Approved Reseller, and is not advertising of
ASSA ABLOY;
(3) Approved Reseller may not use any ASSA ABLOY Marks as part
of or in connection with a domain name;
(4) Approved Reseller’s advertising must not imply or suggest an
association between the Approved Reseller and ASSA ABLOY
other than that of buyer and seller;
(5) Approved Reseller’s use of ASSA ABLOY Marks must be a
positive representation of ASSA ABLOY, the Group Companies,
and their products;
(6) Approved Reseller’s trade name must be more predominant on
Approved Reseller’s advertising than the ASSA ABLOY Marks;
(7) Approved Reseller’s use of ASSA ABLOY Marks must include
the trademark symbol ® or TM, as appropriate, along with the
following trademark legend printed in legible text on the Web
page or document containing ASSA ABLOY Marks:
“[describe ASSA ABLOY Marks] are trademarks or
registered trademarks of ASSA ABLOY, Inc. or
one of its affiliates in the United States and other
countries.”;
(8) Approved Reseller must not make modifications of any ASSA
ABLOY Marks; and
(9) Approved Reseller may use only ASSA ABLOY Marks associated
with the Group Companies for which it is an Approved Reseller
(e.g., an Approved Reseller that sells Group Company X
products but not Group Company Y products may use Group
Company X trademarks in connection with its sale of Group
Company X products, but may not use Group Company Y
trademarks).
ASSA ABLOY reserves the right to review Approved Reseller’s
usage of ASSA ABLOY Marks at any time and may:
(a) require changes to the use of ASSA ABLOY Marks at any
time in its sole discretion, which changes must be
implemented within 30 days of written notice to Approved
Reseller;
(b) condition the use of ASSA ABLOY Marks on ASSA ABLOY’s
prior approval of such use, which approval may be
withheld in its sole discretion;
(c) revoke permission to use ASSA ABLOY Marks at any time for
any or no reason upon 30 days prior written notice to
Approved Reseller; and
(d) revoke permission to use ASSA ABLOY Marks immediately
upon notice to Approved Reseller in the event Approved
Reseller is in violation of this Policy, or of any other agreement
with ASSA ABLOY or any Group Company.
Approved Reseller’s right to use ASSA ABLOY Marks in no way
conveys to Approved Reseller any proprietary or economic interest in
any ASSA ABLOY Marks.
Use of ASSA ABLOY Marks in violation of this Policy may result in
severe civil and criminal liabilities. ASSA ABLOY will vigorously
enforce this Policy by seeking all appropriate legal remedies,
including, but not limited to, pecuniary damages and injunctive relief.
TECHNICAL INFORMATION AND ADVICE
(a) All designs, data, and specifications provided by Company are
proprietary and will not be disclosed or reused by Customer without
the prior written consent of Company; (b) Company assumes no
obligation or liability for any advice given by Company, the results
obtained, or damages incurred, and all such advice is given and
accepted at Customer’s risk.
For Terms & Conditions and Warranty information pertaining to
product sales in Canada, please visit www.assaabloy.ca/terms.
Electromechanical:
All components of electromagnetic products are covered by a limited warranty
period of one year after invoice date thereof of the original purchaser from us.
Keying Systems:
All bittings shall be originated or authorized by the Yale Key Systems
Department to be compatible with one another in a specific type of cylinder
(conventional, patented, security, high security, interchangeable core) and
within a particular keying system.
Warranty for Cylinders Factory or Field Combinated:
Cylinders shall be periodically lubricated depending on environmental
conditions. Dry graphite, molybdenum disulfide or Polylube™ are
recommended. Petroleum based liquid lubricants should only be used in
cylinders in harsh or corrosive environments and should not be mixed with dry
lubricants. Cylinder and/or core warranty will be voided if used in non-Yale
locking devices.
Warranty for Cylinders Field Combinated:
1. Keys shall be cut to the Yale key bitting specifications required for the
particular keyway and depth system.
2. All pin lengths shall be selected according to prevailing factory standards.
3. Original Yale cylinders and cylinder components, including pin tumblers and
key blanks, shall be used. We reserve the right to void the warranty if we
deem that a malfunction is a result of non-original components which do
not conform to Yale standards.
General Procedure
Product repair or replacement, or associated charges, will not be accepted
under this warranty unless prior authorization from Yale has been given. Upon
receipt of products returned for repair or replacement, we will determine
whether products qualify for repair or replacement under this warranty. If they
do not, we will obtain authorization prior to proceeding. We have no liability to
pay any costs of repair performed by anyone other than qualified personnel
authorized by Yale prior to the work being done.
The Company will not pay for the cost of repair performed other than in
accordance with this warranty. Written notice of a product or component part
believed to be defective as covered by this warranty should be sent to Yale
Security, Inc., 1902 Airport Road, Monroe, North Carolina 28110, and should
include your name and address, an identification of the product or component
part and a brief description of the defect. Upon receipt of such notice, the
Company will inform you where to ship such product or component part,
shipping charges prepaid for examination and, in the event such examination
reveals a defect covered by this warranty, the product will be repaired or
replaced. The Company reserves the right to replace discontinued product
with an equivalent product as deemed by the Company.
THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. TO
THE EXTENT PERMITTED BY LAW, ALL IMPLIED WARRANTIES ARE
LIMITED TO THE DURATION OF THIS WARRANTY. YALE SECURITY, INC.
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
21
DISTRIBUTOR LIST PRICES
LIMITED WARRANTY
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Locks
8800 series mortise locks 10 years
8800 electrified series mortise locks 2 years
5400 series cylindrical knob locks (Discontinued October 2015) 2 years
5400CK series cylindrical knob locks 10 years
5400LN series cylindrical lever locks 7 years
5400LN electrified series cylindrical lever locks 2 years
5300LN series cylindrical lever locks 5 years
5300LN electrified series cylindrical lever locks 1 year
4600 series cylindrical knob locks 3 years
4600LN series cylindrical lever locks 3 years
4700 series cylindrical knob locks (Discontinued October 2015) 5 years
4700LN series cylindrical lever locks 5 years
4700LN electrified series cylindrical lever locks 1 year
4800LN series interconnected locks (Discontinued April 1, 2016) 1 year
6400LN series monolock/retrofit 7 years
inTouch®series touchscreen access locks (Discontinued
October 1, 2016) 3 years
nexTouch™ Keypad Access Lock 3 years
All other locksets 1 year
4400, SC400/SC4400 (Discontinued April 2013) and 3000
series closers 25 years
51 series closers 15 years
2500 (Discontinued September 2012) and 5100 series closers 5 years
Aluminum shells of all Yale door closers (in the building in which
originally installed)
Lifetime of
building
All other door controls 10 years
Door Controls
Yale Security, Inc. (the “Company”) warrants that its products sold under
the Yale®trade name in the United States of America are free from
defects in work-manship and materials under normal use and service.
This warranty does not cover defects or damage arising from improper
installation, lack of or improper maintenance, improper storage, shipping
and handling, corrosion, erosion, ordinary wear and tear, misuse, abuse,
accident, unauthorized service, or use with unauthorized non-Yale
products or parts. This warranty is void if any modification is made to the
product, regardless of whether the modification causes or contributes to
the alleged defect. All modifications are made at the risk of the party
making the modification.
The only liability of the Company in tort or contract whether under
this warranty or otherwise shall be limited to the repair or
replacement of any product or component part which shall prove
defective as covered by this warranty, within the stated time frame
listed below, after delivery to the original purchaser.
Exit Devices and Trims
1500 series exit devices 1 year
1800 series exit devices 3 years
2100 series exit devices 3 years
6000 series exit devices 10 years
7000 series exit devices 5 years
Electrified exit devices 2 years
600F series exit device trims 5 years
580F and 540F series exit device trims 3 years
440F series exit device trims 2 years
All other exit device and trim products 1 year
5400LN & 5300LN series cylindrical locks against lever sag
and lever spring breakage Lifetime
Yale®KeyMark®keys Lifetime
All other Yale products 1 year
Finishes
PVD (Discontinued January 2012) Lifetime
All other finishes 1 year
Other
Authorized Channel Partner Products
Affinity®smart card locks 1 year
Symphony®series mortise locks 10 years mechanical, 2 years electrical
Symphony®series cylindrical locks 7 years mechanical, 2 years electrical
Symphony®series exit device hardware 5 years mechanical, 2 years electrical
7180(F)TD multi-point exit device 7 years
7370 series multi-point auto deadlock 7 years
7380(F) series multi-point auto deadlock 7 years
Multi-point Locking Systems
LIST PRICE
Product Installation $43.00
Mount Only $140.00
#202 10" WIDE MORTISE LEVER HANDLE
Oak Finish
13-0202-9002-999
LIST PRICE
Product Installation $43.00
Mount Only $80.00
#112 CYLINDRICAL FOR 5400LN/5300LN
2-3/4" or 2-3/8" Backset
Oak Finish
13-5400-0001-999
22
DISTRIBUTOR LIST PRICES
DISPLAY MOUNTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
LIST PRICE
Product Installation $44.00
Mount Only $254.00
PART NUMBER MODEL NUMBER FOR DEVICE
60-7000-9380-999 380* 7100 X Exit Only
60-7000-9381-999 381* 7100 X 626F
60-7000-9382-999 382* 7100 X 633F
60-7000-9383-999 383 7130 X Exit Only
60-7000-9384-999 384 7130 X 656F
60-7000-9385-999 385 7130 X 673F
60-7000-9386-999 386* 7110 X Exit Only
60-7000-9387-999 387* 7110 X 626F
60-7000-9388-999 388* 7110 X 633F
*Can also be used for 6000, 2100 or 1800 series devices.
23
DISTRIBUTOR LIST PRICES
DISPLAY MOUNTS (CONTINUED)
Effective Date: May 1, 2018
Canada Effective July 3, 2018
LIST PRICE
Product Installation $63.00
Mount Only $353.00
DEADBOLT MOUNT
Shows 3 deadbolts
Oak Finish
13-0118-9005
LIST PRICE
Product Installation $60.00
Mount Only $336.00
nexTouch™
Cylindrical for NTB600 Series
Plexi/Steel
022234
24
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
25
DISTRIBUTOR LIST PRICES
KEY SYSTEMS SECURITY POLICY
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: All cylinders requested to be keyed to combinations not supplied by Yale will be subject to this charge. Yale
releases all liabilities to systems generated by customer-supplied bittings and/or sample keys that are supplied by
others. Purchase orders with customer-supplied bittings or sample keys not meeting Yale's specifications will be
processed "0" bitted in the specified keyway.
The purpose of this security policy is to enforce our policies concerning high security, security and protected keyway
product, as well as master key system information. The purpose for the establishment of any security system is to
provide an increased level of protection for the Facility owner.
No master key system information or security related product is to be given or sold to anyone other than the
Facility owner through written correspondence. Verification must be submitted (fax copy will be acceptable)
to Key Systems Administration. The verification must be on the Facility's letterhead and signed by a Facility
authorized systems administrator. Key Systems Administration does not maintain "Letters of Authorization"
on file. Each order must be accompanied by proper authorization.
Only after the authorization has been verified will the order be processed for production.
This security policy refers to the following:
• Bitting information (even one bitting, absolutely no top-level master keys)
• Bitting lists (all formats; i.e., hard copy, disc)
• High Security systems
• Keyblanks and systems components
• Protected keyway systems
• Security cylinder systems
No orders are to be processed through Key Systems Administration without proper authorization.
Only orders with appropriate authorization attached will be given priority.
Requests for Systems information without proper authorization from the owner will be denied.
Requests for information regarding the purchase of any systems support products as listed above will be referred to the
local authorized sales agency.
PRODUCT DESCRIPTION LIST PRICE
Customer Bittings and Sample Keys ADD $16.00
CUSTOMER BITTINGS AND SAMPLE KEYS:
(MASTER KEYING OR CMK CHARGES NOT INCLUDED)
Disclaimer: Yale reserves the right to release total liability of any factory-generated master key system which incorporates
cross keying, both controlled and uncontrolled. A master key system incorporating cross keying yields less security and
jeopardizes system expansion.
Controlled Cross Keying: A condition in which two or more different keys of the same level of keying and under the
same higher level key(s) operate one cylinder by design; e.g., XAA1 operated by AA2.
Uncontrolled Cross Keying: A condition in which two or more different keys under different higher level keys operate
one cylinder by design; e.g., XAA1 operated by AB, AB1.
CROSS KEYING: (NO CHARGE)
KEY SYSTEMS ADMINISTRATION
26
DISTRIBUTOR LIST PRICES
KEY SYSTEMS ADMINISTRATION
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Lead times may vary; consult Key Systems Administration
HOTEL LOCKS/CYLINDERS
When ordering a factory-keyed system that includes hotel function locks that are to be operated by the
GMK, MK and change keys, all cylinders in the system have to be 7-Pin length with 7-Pin keys.
BITTING LISTS
A letter of authorization from the end user is required to release a copy of the bitting list for a factory established system.
To protect the security of keying systems, bitting lists will only be sent to the end user or his designated agent, via
Certified Mail Return Receipt Requested or UPS AOD. Copies will not be transmitted via fax. The complete name and
address where the bitting list is to be sent must be indicated on the letter of authorization and on the purchase order.
NOTE: Bitting Lists requested for keysets ordered with factory keyed product for either a new or existing system will be
provided at no charge, except when KeyWizard®disc requested. For existing system, pricing above will apply, for new
system, see Key Management section below.
• Additional Bittings or P.O.’s for Bitting Lists Only – EXISTING MASTER KEY GROUPS
Up to 10 total for keysets tied to existing master key groups will be provided at no charge
11 or more bittings will be charged per above chart
• Additional Bittings or P.O.’s for Bitting Lists Only – NEW MASTER KEY GROUPS
Regardless of the quantity being requested, will be charged per above chart
Bitting lists will be billed at 50% off of list price – No additional discounts will apply.
These prices are for a hierarchial Master Key system with no cross-keying of selected keys.
For special requirements or for systems prior to 1999, consult Key Systems Administration for a quote.
Yale releases all liabilities for cylinders not pinned to factory master key systems.
Yale is not liable for cylinders pinned incorrectly in the field.
NUMBER OF BITTINGS DISCOUNT OF 50% ONLY
1-50 $183.00
51-200 $281.00
201-1000 $375.00
1001-3000 $473.00
3001-6000* $547.00
6001-9000* $821.00
Over 9000* Consult Key Systems Administration
Key Wizard®: Special online ordering procedures – contact customer service for more information.
PRODUCT DESCRIPTION LIST PRICE
Key Wizard®Single Version $1,109.00
Key Wizard®Network Version $1,334.00
Upgrade from Single Version to Network Version $671.00
New Yale®factory key system formatted for importing to Key Wizard®. For existing systems, see
Bitting Lists pricing above.
NOTE: Not available for key systems established prior to 1999. May not be available for
systems since 1999. Consult Key Systems Administration for eligibility of system.
$525.00
KEY WIZARD®: (Discount of 50% Only)
KEY MANAGEMENT
27
DISTRIBUTOR LIST PRICES
KEYING CHARGES AND KEYS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PRODUCT DESCRIPTION LIST PRICE
Masterkeying, Grand Masterkeying, Great Grand Masterkeying
(all cylinders except security cylinders and IC cores) ADD $16.00
MK, GMK, GGMK for 5000, U5000 Series Security Cylinders ADD $0.00
MK, GMK, GGMK for 1210, 1220, 1210H, or A600 IC Cores ADD $0.00
Cylinder or Lock Operated by Two or More Keys Not MK or GMK ADD $16.00
Customer Bittings and Sample Keys (Discount of 50% Only) ADD $16.00
Construction Masterkeying suffix CMK or CGMK
(in addition to masterkeying charges)
NOTE: Not available with 5000, U5000 Series Security Cylinders.
ADD $16.00
Schlage C Keyed Alike (KA) keying charge ADD $12.00
7-Pin Cylinders, Locksets, Deadlocks (add to each cylinder) ADD $2.00
KEYING CHARGES: (Discounted with Product)
NOTE: Two cut change keys are standard per lockset/cylinder. Keyblanks cannot be substituted for cut keys.
Cylinders pinned directly to GMK or MK level keys do not include two cut keys.
MK and GMK keys are ordered as a separate item.
PRODUCT DESCRIPTION LIST PRICE
MASTER KEYS, CONSTRUCTION MASTER KEYS, CONTROL KEYS:
Standard Bow All Keys (except Security Keys) $9.80
"A" or "F" Bow All Keys (except Security Keys) $10.10
Security Keys (see page 37-38) $12.50
Extra Standard Bow Change Keys ordered with cylinder/lockset
Change Keys/Cut Keys ordered separately priced on page 29 $3.30
Extra "A" or "F" Bow Change Keys ordered with cylinder/lockset
Change Keys/Cut Keys ordered separately priced on page 29 $3.60
KEYS:
28
DISTRIBUTOR LIST PRICES
STAMPING CHARGES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Not available for Yale®KeyMark®, security and high security cylinders.
NOTE: See page 7 for code definitions and examples.
STAMPING: (Discounted with Product)
VISUAL KEY CONTROL: (Discounted with Product)
CONCEALED KEY CONTROL: (Discounted with Product)
DESCRIPTION LIST PRICE
VKC0 - No stamping except keyway designation (keys will be tagged) ADD $4.30
VKC1 - Keys only No Charge
VKC2 - Cylinder and keys* ADD $8.00
VKC3 - Cylinders only* ADD $8.00
DESCRIPTION LIST PRICE
CKC2 - Cylinders with VKC Keys ADD $8.00
CKC3 - Cylinders only* ADD $8.00
DESCRIPTION LIST PRICE
Stamping letters or numbers on cylinder or padlock body (VASCP or CASCP) $4.00
Stamping letters or numbers on keybows in lieu of keyset symbols or bittings (max. 8 characters) No Charge
Stamping letters or numbers on keybows in addition to keyset symbols or bittings (max. 8
characters) (per key) (VASK) $4.00
Stamping letters or numbers on keyblanks (max. 8 characters) (per key) (VASK)
Special stamping on keybows - “Do Not Duplicate”, “US Property - Do Not Duplicate” No Charge
Special stamping on keybows with custom or existing die stamp (per key) $4.00
New custom die stamp - one time charge $840.00
NOTE: See page 7 for code definitions and examples
NOTE: Security systems typically use the "A" key bow, although conventional systems blanks. All orders for security key
blanks must be specific and reference the master key systems registry numbers, if existing. All orders for security
key blanks must also be accompanied by proper authorization. See page 39 for security key blank prices.
STOCK SECTION: Includes PARA/EIR
SINGLE SECTION: Includes G, S, T Single Series Sections. (GA, GB, GC, GD, GF, GG, GH, SA, SB,
SC, SD, SE, SF, SG, SH, TA, TB, TC, TD, TE, TF, TG, TH)
MULTIPLEX SECTIONS: Includes any combination of G, S, T Series Sections. (GST, GMK, GAH, GBG,
GCE, GDF, SMK, SAH, SBG, SCE, SDF, TMK, TAH, TBG, TCE, TDF)
RESTRICTED SECTIONS: Includes K, L, P, V, Y, Z Series Sections.
29
DISTRIBUTOR LIST PRICES
NOTE: Bows of control key blanks are stamped "CONTROL."
KEYS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # OLD
LIST NUMBER
STOCK
SECTION
SINGLE
SECTION
MULTIPLEX
SECTIONS
RESTRICTED
SECTIONS
RN8 8 N.S. $1.96 $1.96
$4.78 $5.10
RN11 11 N.S.
RN117 (7 Pin) 117 $3.40 $4.58
RN411 411F
FN411 –– $3.88 $4.80 $5.02 $5.30
FN411S 411FS
LEGEND:
.51 PIN TUMBLER
CONTROL KEY BLANKS
MODEL # PRODUCT DESCRIPTION LIST PRICE
FN117C For 1210 Core "0" Bitted 6-Pin with #1 7th cut
$8.80
FN118C For 1220, 1210H Cores "0" Bitted 7-Pin with #1 8th cut
COMPETITOR KEYWAYS
KEYWAYS AVAILABLE: Best®= A, B, C, D, E, F, G, H, J, K, L and M
Schlage®= C
MODEL # PRODUCT DESCRIPTION LIST PRICE
BN67 6/7-Pin Keyblanks for Best®. Specify Keyway. $2.06
SC11 6-Pin Keyblanks for Schlage®. Specify Keyway. $2.06
KEY BLANKS:
MODEL # OLD
LIST NUMBER
STOCK
SECTION
SINGLE
SECTION
MULTIPLEX
SECTIONS
RESTRICTED
SECTIONS
RN8 8 N.S. $10.94 $10.94
$11.44 $11.84
RN11 11 N.S.
RN117 (7 Pin) 117 $10.94 $11.44
RN411 411F
FN411 –– $10.94 $11.94 $12.44 $12.84
FN411S 411FS
CUT KEYS:
NOTE: For "A" or "F" Bows per key ADD $0.30
30
DISTRIBUTOR LIST PRICES
KEY BLANKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # OLD
LIST NUMBER
STOCK
SECTION
SINGLE
SECTION
MULTIPLEX
SECTIONS
RN9 9, 9 1/2-109, 109 1/2 N.S. $2.16 $2.34 $3.53
.51 PIN TUMBLER
MODEL # STOCK
SECTION
E503 (used for cylindrical locks)
$2.66E203 (used for mortise locks)
E502 (used for D291/D292 deadbolts)
EMERGENCY KEYS
PROGRAM A: LARGE FORMAT INTERCHANGEABLE CORES
ALL locksets and cylinders ordered with large format interchangeable temporary cores will be provided with keyed alike standard 1210 or
1220 temporary cores.
When ordering locksets to be used with Yale®KeyMark®permanent cores, use the following cylinder designations (no full cylinder deduct with
the Added to Lock price):
31
DISTRIBUTOR LIST PRICES
CONSTRUCTION CORE PROGRAMS
CUT KEYS: Specify the required number of change keys and control keys on the order. Two control keys are provided at no charge.
Two change keys are provided at no charge for the first 20 units ordered. One additional change key is provided for every 10 additional
units at no charge. Additional keys will be invoiced at control key price.
RETURN TEMP. CORES: Contact your Customer Service Representative for a Return Goods Authorization. Provide the factory order
number and the year of the original order. Credit will be issued for all cores returned in good operating condition; credit is based on the net
price after discount on the construction core at the time of the original order.
PRODUCT DESCRIPTION LIST PRICE
1210 6-Pin Temporary Core ADD $58.00
1220 7-Pin Temporary Core ADD $60.00
CONSTRUCTION CORES: (Discount with Product)
PERMANENT CORES: Use a separate purchase order or line item to order the permanent cores. Permanent cores will be discounted
the same as the product in which the core will be used if the order is marked with the correct number of cores for each product series, original
factory order number, and the Competitive Price Quotation (CPQ) number. Product discounts do not apply to Yale®KeyMark®
PRODUCT DESCRIPTION ADDED TO LOCK ORDERED
SEPARATELY
Mortise/Rim - order K625/K645 x CT6SD for 6-Pin and CT7SD for 7-Pin
$0.00
$70.00
Mortise Tapered - order K635 x CT6SD for 6-Pin and CT7SD for 7-Pin $74.00
Cylindrical - order K925 x CT6SD for 6-Pin and CT7SD for 7-Pin See Below
PROGRAM B: SMALL FORMAT INTERCHANGEABLE CORES
Option 1 - Disposable SFIC (K925)
All locksets and cylinders will be provided with disposable thumbturn type cores.
No keys are required. These cores are disposable and cannot be returned.
PRODUCT DESCRIPTION ADDED TO LOCK ORDERED
SEPARATELY
Mortise/Rim - order K625/K645 x CT6SL for 6-Pin or CT7SL for 7-Pin
$29.00
$99.00
Mortise Tapered - order K635 x CT6SL for 6-Pin or CT7SL for 7-Pin $103.00
Cylindrical - order K926 x CT6SL for 6-Pin or 7-Pin See Below
PRODUCT DESCRIPTION LIST PRICE
K925 Disposable Cores (for 6- or 7-Pin) - order in multiples of ten EACH $4.80
K926 (for 6- or 7-Pin) Lockable Cores - order in multiples of ten EACH $29.00
Option 2 - Lockable SFIC (K926)
All locksets and cylinders will be provided with keyed alike standard SFIC cores that are unrelated to the permanent
master key system. Temporary operating and control keys are required; quantities must be specified. At the
completion of the construction phase, these temporary cores may be returned.
PROGRAM C: SFIC PRODUCTS ORDERED SEPARATELY.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
TYPE MODEL NUMBER* ADDED TO LOCK ORDERED
SEPARATELY
Mortise x 6-Pin K825 x CT6LL $58.00 $128.00
Mortise x 7-Pin K825 x CT7LL $60.00 $130.00
Rim x 6-Pin K845 x CT6LL $58.00 $128.00
Rim x 7-Pin K845 x CT7LL $60.00 $130.00
*Note: These LFIC cylinders are not discounted with the product.
32
DISTRIBUTOR LIST PRICES
STANDARD FIXED CORE CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
FIXED CORE COMPONENT/CYLINDRICAL LOCK & EXIT TRIM CYLINDERS:
MODEL # NO. OF
PINS APPLICATIONS 606/626
FINISHES
CONVENTIONAL KEYWAYS
1801 6 Standard for 5300 & 5400 series knob locks and 540F series trim $62.00
1801A 7 Standard for 5400 series knob locks and 540F series trim $64.00
1802 6
Standard for 5300LN, 5400LN, 6400LN & inTouch®series lever locks and 440F, 540F &
580F series trims
Optional for 4700LN series lever locks
$62.00
1802A 7 Standard for 5400LN & 6400LN series lever locks and 540F & 580F series trims $64.00
1802L 6 Standard for 5300LN series locks used with 2"-2-1/4" thick doors
$62.00
1802S 6 Standard for 5417LN & 6417LN function inside lever locks
1804 6 Standard for 4700LN series lever locks
Optional for 5300LN series lever locks
1805 6 Standard for 4600 & 4700 series knob locks $53.00
1806 6 Standard for 4600LN series lever locks
1812 6 Standard for 4300, 4300LN & 4800LN series knob/lever locks
$62.00
1803-54L 6 Standard for Corbin Russwin CL3100(YC) & Sargent 11 Line (YC-) series lever locks.
Optional for 4300LN, 4600LN & 4800LN series lever locks.
1803A-54L 7 Standard for Corbin Russwin CL3100(YC7), Sargent 11 Line (YC-7P-) series lever locks
1803-54K 6 Standard for 5400CK series knob locks and YH Collection lever locks
1803-53L 6 Standard for nexTouch™ cylindrical series lever locks
Optional for inTouch®series lever locks
1803-47L 6 Optional for 4700LN, 5300LN and 440F series trim
1803-46K 6 Optional for 4600 series knob locks
OTHER MANUFACTURERS' KEYWAYS
2801 6 Schlage®"C" keyway for 5300 & 5400 series locks and 540F series trim
$62.002802 6 Schlage®"C" keyway for 5300LN, 5400LN, 6400LN & inTouch® series lever locks and
440F, 540F & 580F series trims
2804 6 Schlage®"C" keyway for 4700LN series lever locks
2805 6 Schlage®"C" keyway for 4600 & 4700 series knob locks $53.00
2806 6 Schlage®"C" keyway for 4600LN series lever locks
2812 6 Schlage®"C" keyway for 4300, 4300LN & 4800LN series knob/lever locks
$62.00
2803-54L 6 Optional for Corbin Russwin CL3100(YC) & Sargent 11 Line (YC-) series lever locks.
Optional for 4300LN, 4600LN & 4800LN series lever locks.
2803-54K 6 Schlage®"C" keyway for 5400CK series knob locks and YH Collection lever locks
2803-53L 6 Schlage®"C" keyway for nexTouch™ cylindrical series lever locks
Optional for inTouch®series lever locks
2803-47L 6 Optional for 4700LN, 5300LN and 440F series trim
2803-46K 6 Optional for 4600 series knob locks
3804 6 Other manufacturer’s keyway for 4700LN, 5300LN, 5400LN, 6400LN & inTouch®series
lever locks and 440F, 540F & 580F series trims $77.00
3805 6 Other manufacturer’s keyway for 4700 series knob locks
3806 6 Other manufacturer’s keyway for 4600 & 4600LN series knob/lever locks $68.00
3803-54L 6 Optional for Corbin Russwin CL3100(YC) & Sargent 11 Line (YC-) series lever locks.
Optional for 4300LN, 4600LN & 4800LN series lever locks.
$77.00
3803-54K 6 Other manufacturer’s keyway for 5400CK series knob locks and YH Collection lever locks
3803-53L 6 Other manufacturer’s keyway for nexTouch™ cylindrical series lever locks
Optional for inTouch®series lever locks
3803-47L 6 Optional for 4700LN, 5300LN and 440F series trim
3803-46K 6 Optional for 4600 series knob locks
100CV1 6 Arrow AR keyway for nexTouch™ cylindrical series lever locks $62.00
Schlage®C – Available Keyed Random or 0-Bitted
Other Manuf keyway – Available Keyed Random only, specify keyway Sargent LA, Schlage®E, Corbin Russwin L4, Corbin 60, Russwin D1
33
DISTRIBUTOR LIST PRICES
MISCELLANEOUS CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Additional length available, price on application.
FIXED CORE MORTISE CYLINDERS:
MODEL # PRODUCT DESCRIPTION LENGTHS CAM ALL FINISHES
1108 Dummy Mortise Cylinder 1" - 1-3/4" N/A $50.00
1152 Standard for Cast Iron Mortise Except for 1" Deadlocks 1" - 1-3/4" 1161
$70.00
1152 For Cast Iron Mortise with Optional Cam (Key Switches) 1" - 1-3/4" 1161G
2153 Standard Cylinder for 8800FL, 8800, 8800RL, 350 Series
Deadlocks 1" - 1-3/4" 2160 $70.00
2123 Extra Length Cylinder for 8800FL, 8800, 8800RL *1-7/8" - 3-1/2" 2160 $98.00
2153S Standard Inside Cylinder for 8817-2 Function 1" - 1-3/4" 2130 $70.00
2123S Extra Length Inside Cylinder for 8817-2 Function *1-7/8" - 3-1/2" 2130 $98.00
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed
Random 1-1/8" 2160 $70.00
7-Pin Cylinders ADD –– — $2.00
FIXED CORE COMPONENT/DEADBOLT CYLINDERS:
NOTE: Cylinder rings/collars not furnished with locksets or other products when ordered less cylinders.
Cylinder rings/collars furnished at no charge when ordered with cylinders/housings.
Schlage®C – Available Keyed Random or 0-Bitted
Other Manuf keyway – Available Keyed Random only, specify keyway Sargent LA, Schlage®E, Corbin Russwin L4, Corbin 60, Russwin D1
MODEL # NO. OF
PINS APPLICATIONS 606/626
FINISHES
CONVENTIONAL KEYWAYS
1807 6 Standard for D series deadbolts, single cylinder functions $53.00
1808 6 Standard for D series deadbolts, double cylinder functions
1814 6 Standard for 4800LN series deadbolt
$62.001803-134S 6 Standard for YH Collection Deadbolt used with interconneted lock (non-face removable)
Optional for D Series deadbolts, single cylinder functions
1803-134D 6 Optional for D Series deadbolts, double cylinder functions
OTHER MANUFACTURERS' KEYWAYS
2807 6 Schlage®"C" keyway for D series deadbolts, single cylinder functions $53.00
2808 6 Schlage®"C" keyway for D series deadbolts, double cylinder functions
2814 6 Schlage®"C" keyway for 4800LN series deadbolt
$62.002803-134S 6
Schlage®"C" keyway for YH Collection Deadbolt used with interconneted lock (non-face
removable)
Optional for D Series deadbolts, single cylinder functions
2803-134D 6 Schlage®"C" keyway for D Series deadbolts, double cylinder functions
3806 6 Other manufacturer’s keyway for D series deadbolts $68.00
3803-134S 6
Other manufacturer’s keyway for YH Collection Deadbolt used with interconneted lock (non-
face removable)
Optional for D Series deadbolts, single cylinder functions
$77.00
3803-134D 6 Other manufacturer’s keyway for D Series deadbolts, double cylinder functions $68.00
34
DISTRIBUTOR LIST PRICES
MISCELLANEOUS CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
HOTEL CYLINDERS:
MODEL # PRODUCT DESCRIPTION LENGTHS CAM ALL FINISHES
S2053 Cylinder for 8800 1" or 1-1/8" 2160 $84.00
S2053S Inside Cylinder for 8834 1" or 1-1/8" 2130
THUMBTURN CYLINDERS:
PRODUCT DESCRIPTION ALL FINISHES
C910, C910A, C910B, C910C, C910D $63.00
C911, C911A, C911B, C911C, C911D
$74.00C920, C920A, C920B, C920C, C920D
C921, C921A, C921B, C921C, C921D
C922, C922A, C922B, C922C, C922D $78.00
C930, C930A, C930B, C930C, C930D $88.00
C900 SERIES CYLINDERS FOR ELECTRICAL SWITCHES:
If operated by two or more different keys, see page 27 for additional keying charges. Collar required must be specified.
MODEL # PRODUCT DESCRIPTION LENGTH CAM ALL FINISHES
MORTISE
1194H LFIC Hotel Cylinder 6-Pin 1-11/16" 1160E $208.00
1196H LFIC Hotel Cylinder 6-Pin for 310 Series Deadlocks 1-11/16" 1160R
1719 Standard Hotel Cylinder 6-Pin for Cast Iron Mortise Locks 1-3/8" 1160 $155.00
2196H LFIC Hotel Cylinder 6-Pin 1-11/16" 2160 $208.00
2719 Standard Hotel Cylinder 6-Pin 1-3/8" 2160 $155.00
RIM
1179 Standard Hotel Cylinder 6-Pin 1-5/8" — $155.00
MODEL # PRODUCT DESCRIPTION *ALL FINISHES
1109 Standard Cylinder $70.00
1709 CMK Cylinder (Price Includes Construction Master Keying) $86.00
2109** Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
FIXED CORE RIM CYLINDERS:
*Rim cylinders not available in 629 or 630.
**Only available in 605, 606, 613, and 626 finishes.
35
DISTRIBUTOR LIST PRICES
INTERCHANGEABLE CORE CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Prices include masterkeying or grand masterkeying. Cores "0" Bitted, no deduct.
COMPLETE CYLINDERS: LFIC
MODEL # PRODUCT DESCRIPTION 606/626 FINISHES
1210 Large Format Core Only, 6-Pin $58.00
1210H Large Format Core Only for Hotel Cylinders, 6-Pin $138.00
1220 Large Format Core Only, 7-Pin $60.00
A600 Small Format Core Only, 6- or 7-Pin $50.00
*CORES ONLY:
NOTE: See page 36 for housing assemblies.
COMPLETE CYLINDERS: SFIC
Note: A620, A630 & A640 include Best®keyway core (A600), specify keyway.
MODEL # PRODUCT DESCRIPTION LENGTH CAM ALL FINISHES
MORTISE
1194 LFIC Cylinder 6-Pin 1-1/2" 1160E $128.00
1194 LFIC Cylinder 7-Pin 1-11/16" 1160E $130.00
1196 LFIC Cylinder 6-Pin for 310 Series Mortise Deadlocks 1-1/2" 1160R $128.00
1196 LFIC Cylinder 7-Pin for 310 Series Mortise Deadlocks 1-11/16" 1160R $130.00
2196 LFIC Cylinder 6-Pin 1-1/2", 1-3/4", 2" 2160 $128.00
2196S LFIC Inside Cylinder 6-Pin for 8817-2 Function 1-1/2" 2130 $128.00
2197 LFIC Cylinder 7-Pin 1-11/16", 2" 2160 $130.00
2197S LFIC Inside Cylinder 7-Pin for 8817-2 Function 1-11/16 2130 $130.00
RIM
1193 LFIC Cylinder 6-Pin — — $128.00
1193 LFIC Cylinder 7-Pin — — $130.00
1193L LFIC Cylinder 6-Pin with Lazy Cam — — $128.00
MODEL # PRODUCT DESCRIPTION LENGTH CAM ALL FINISHES
MORTISE
A620 SFIC Cylinder 6- or 7-Pin 1-1/4", 1-3/8", 1-3/4" KC1 $120.00
A630 SFIC Tapered Cylinder 6- or 7-Pin 1-1/4", 1-3/8" KC1 $124.00
RIM
A640 SFIC Cylinder 6- or 7-Pin 1-1/4", 1-3/8" KT1 $120.00
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder.
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder. 36
HOUSING ASSEMBLIES:
DISTRIBUTOR LIST PRICES
CYLINDER COMPONENTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION *ALL FINISHES
1212 For 1193 Rim Cylinder (6-Pin)
$70.00
1212B For 1193 Rim Cylinder (7-Pin)
1213 For 1196 Mortise Cylinder (7-Pin)
1213 For 1196H Mortise Cylinder (6-Pin)
1214 For 1194 Mortise Cylinder (6-Pin)
1214 For 1194 Mortise Cylinder (7-Pin)
1214H For 1194H Mortise Cylinder (6-Pin)
1221 For 1196 Mortise Cylinder (6-Pin)
2221 For 2196 Mortise Cylinder (6-Pin)
2213 For 2197 & 2196H Mortise Cylinder (7-Pin)
2214S For 2196S Mortise Cylinder (6-Pin)
2217S For 2197S Mortise Cylinder (7-Pin)
K660 SFIC Mortise Housing (1-1/4", 1-3/8", 1-3/4")
K670 SFIC Tapered Mortise Housing (1-1/4", 1-3/8") $74.00
K680 SFIC Rim Housing (1-1/4", 1-3/8")
$70.00K860 LFIC Mortise Housing (1-1/2", 1-11/16", 1-3/4", 2")
K880 LFIC Rim Housing (1-7/16", 1-5/8")
*Rim cylinders not available in 629 or 630.
*Specify dimension. Cylinder collars not furnished with locksets or other products when ordered less cylinders. When
cylinders ordered separately, collar length must be specified.
PRODUCT DESCRIPTION PARA(EIR) SECTION ALL OTHER SECTIONS
606 & 626 Only
Mortise Cylinders (i.e. 2153)
$15.10 $16.60Rim Cylinders (i.e. 1109)
Cylindrical Lock Cylinders (specify cylinder, i.e.1802)
Hotel Cylinders (i.e. 1179) $17.00 $18.50
Interchangeable Core (i.e.1210) $15.10 $16.60
7-Pin Cylinder Plugs ADD $2.00 $2.00
PLUGS ONLY:
-MODEL # PRODUCT DESCRIPTION ALL FINISHES
KP3 Wave Washer (funished standard with 1765 collar) $3.90
KP4 Cylinder Collar for Rim Cylinders
599 Recessed Cylinder Collar for Mortise and Rim $40.60
1765
Recessed Cylinder Collar for Mortise and Rim
.062" - .219" $33.40
.250" - .656"
1766 Tubular Spacer Collar for Mortise and Rim High Security $47.80
*CYLINDER COLLARS:
PRODUCT DESCRIPTION ALL FINISHES
Mortise Cylinder (i.e.2153) $32.00
Rim Cylinders (i.e. 1109 - 629, 630 not available)
Cylindrical Lock Cylinder (i.e. 1802 - unfinished) $8.90
Hotel Cylinders (i.e. 1179) $38.00
7-Pin Cylinder Shells ADD $2.00
SHELLS ONLY:
37
DISTRIBUTOR LIST PRICES
SECURITY CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION CAM ORDERED
SEPARATELY
ORDERED WITH
LOCKSET ADD
MORTISE
5152 Security Cylinder 6-Pin 1161 $280.00 $210.00
5152 Security Cylinder 7-Pin 1161 $284.00 $214.00
5153 Security Cylinder 6-Pin 2160 $280.00 $210.00
5153 Security Cylinder 7-Pin 2160 $284.00 $214.00
5719 Security Hotel Cylinder 6-Pin (1-3/8") 2160 $435.00 $365.00
RIM
5109 Security Cylinder 6-Pin — $280.00 $210.00
5109 Security Cylinder 7-Pin — $284.00 $214.00
MODEL # NO. OF
PINS APPLICATIONS
606/626
FINISHES
ORDERED
SEPARATELY
ORDERED WITH
LOCKSET ADD
COMPONENT: CYLINDRICAL LOCKS & EXIT DEVICE TRIM
5801C 6 Optional for 5300 & 5400 series knob locks and 540F series trim $246.00 $184.00
5801A 7 Optional for 5400 series knob locks and 540F series trim $250.00 $188.00
5802 6 Optional for 4700LN, 5300LN, 5400Ln, 6400LN & inTouch®series lever
locks and 440F, 540F & 580F series trims $246.00 $184.00
5802A 7 Optional for 5400LN & 6400LN series lever locks and 540F & 580F
series trims $250.00 $188.00
5812 6 Optional for 4300, 4300LN & 4800LN series knob/lever locks
$246.00 $184.00
5803-54L 6 Optional for Corbin Russwin CL3100(YC) & Sargent 11 Line (YC-) series
lever locks. Optional for 4300LN, 4600LN & 4800LN series lever locks.
5803A-54L 7 Optional for Corbin Russwin CL3100(YC7), Sargent 11 Line (YC-7P-)
series lever locks.
5803-54K 6 Optional for 5400CK series knob locks and YH Collection lever locks
5803-53L 6
Optional for nexTouch™ cylindrical series lever locks
Optional for 4700LN, 5300LN & inTouch®series lever locks and 440F
series trim
5803-46K 6 Optional for 4600 series knob locks
COMPONENT: DEADBOLTS
5814 6 Optional for 4800LN series deadbolt $280.00 $218.00
5803-134S 6
Optional for YH Collection Deadbolt used with interconneted lock (non-
face removable)
Optional for D Series deadbolts, single cylinder functions $246.00 $184.00
5803-134D 6 Optional for D Series deadbolts, double cylinder functions
38
DISTRIBUTOR LIST PRICES
SECURITY CYLINDERS WITH INTERCHANGEABLE CORE
When Ordering: Specify finish.
NOTE: Security systems typically use the "A" key bow, although conventional systems can also use this bow. Ordering AN11 or AN117 does
not guarantee security blanks. All orders for security keyblanks must be specific and reference the master key systems registry numbers, if
existing. All orders for security keyblanks must also be accompanied by proper authorization.
NOTE: All Security Cylinders and High Security Cylinders includes Master Keying or Grand Master Keying. Construction Master Keying not
available. Cylinders "0" Bitted, no deduct.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION LENGTH CAM
ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
ADD
MORTISE - COMPLETE
5194 LFIC Security Cylinder 6-Pin 1-1/2" 1160E $348.00 $278.00
5194 LFIC Security Cylinder 7-Pin 1-11/16" 1160E $352.00 $282.00
5196 LFIC Security Cylinder 6-Pin 1-1/2" 2160 $348.00 $278.00
5196S LFIC Security Inside Cylinder 6-Pin for 8817-2 Function 1-1/2" 2130
5196H LFIC Security Hotel Cylinder 6-Pin 1-11/16" 2160 $559.00 $489.00
5197 LFIC Security Cylinder 7-Pin 1-11/16" 2160 $352.00 $282.00
5197S LFIC Security Inside Cylinder 7-Pin for 8817-2 Function 1-11/16" 2130
RIM - COMPLETE
5193 LFIC Security Cylinder 6-Pin — — $348.00 $278.00
5193 LFIC Security Cylinder 7-Pin — — $352.00 $282.00
CORES ONLY
5210 Large Format Security Core Only 6-Pin — — $226.00 $226.00
5220 Large Format Security Core Only 7-Pin — — $230.00 $230.00
5210H Large Format Security Core Only for Hotel Cylinders 6-Pin — — $458.00 $458.00
39
DISTRIBUTOR LIST PRICES
U.L. HIGH SECURITY CYLINDERS
When Ordering: Specify finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PRODUCT DESCRIPTION ORDERED
SEPARATELY
Extra Change Keys $12.50
Key Blanks & Control Key Blanks $12.60
Master Keys & Control Keys $12.50
All Security Keys Requested with Conventional Cylinders (each key) $12.50
NOTE: Security systems typically use the "A" key bow, although conventional systems can also use this bow. Ordering AN11 or AN117 does
not guarantee security blanks. All orders for security keyblanks must be specific and reference the master key systems registry numbers,
if existing. All orders for security keyblanks must also be accompanied by proper authorization.
NOTE: All Security Cylinders and High Security Cylinders includes Master Keying or Grand Master Keying. Construction Master Keying not
available. Cylinders "0" Bitted, no deduct.
SECURITY KEYS
MODEL # PRODUCT DESCRIPTION CAM ORDERED
SEPARATELY
ORDERED WITH
LOCKSET ADD
MORTISE
U5152 High Security Cylinder 6-Pin 1161 $376.00 $306.00
U5152 High Security Cylinder 7-Pin 1161 $380.00 $310.00
U5153 High Security Cylinder 6-Pin 2160 $376.00 $306.00
U5153 High Security Cylinder 7-Pin 2160 $380.00 $310.00
U5719 High Security Hotel Cylinder 6-Pin 2160 $520.00 $450.00
RIM
U5109 High Security Cylinder 6-Pin — $376.00 $306.00
U5109 High Security Cylinder 7-Pin — $380.00 $310.00
40
KEYING KITS:
DISTRIBUTOR LIST PRICES
KEYING KITS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
PRODUCT DESCRIPTION LIST PRICE
SK-12 (.019" Step) $241.00
SK-13 (.025" Step)
R19 Refill Set (.019" Step) $116.00
R25 Refill Set (.025" Step)
020 Plug Follower for .51" plug (plastic) $16.10
021 Tweezers $19.50
DK1 Depth Keys $133.00
KG1 Key Gauge (.019" and .025" step) $15.70
.51 CYLINDER PARTS:
CYLINDER PARTS
MODEL # PRODUCT DESCRIPTION LIST PRICE PKG. OF 100
151 Cylinder Spring
$13.70
PKG.
251 Bottom Pins - .019" step (indicate size 0-9) PKG.
251A Bottom Pins - .025" step (indicate size 0-7) PKG.
351 Top Pins - .019"/.025" steps (indicate size 1-4) PKG.
451 Master Pins - .019" step (indicate size 2-8) PKG.
451A Master Pins - .025" step (indicate size 2-7) PKG.
751-3 BUMP Pins - .019" step (Qty. 300) $172.00 —
41
CYLINDER CAMS:
DISTRIBUTOR LIST PRICES
CYLINDER PARTS (CONTINUED)
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION LIST PRICE
EACH
1160 Std for 1153, S1053H, 1719, 5719, U5719
$5.18
1160E Std for 1194, 1194H, 5194, 5194H
1160L Opt for 1194, 1194H, 5194, 5194H
1161 Std for 1123, 1152, S1052H, 5152, U5152
1161E Opt for 1194, Std for 2153 when used for 2100 cylinder dogging
1161G Opt for 1194, 1194H, 5194, 5194H
1161L Opt for 1123, 1152, S1052H, 5152, U5152
1161U Opt for 1194, 1194H, 5194, 5194H
1161T Opt for 1123, 1152, 1186, S1052H, 5152, U5152
2130 Std for 2123S, 2153S, S2053S, 2196S, 2197S, 5196S, 5197S
2160 Std for 2123, 2153, S2053, 2719, 5153, U5153, 5719, 2196, 2197,
2196H, 5196, 5197, 5196H
10-6120-9010 Cam Disc $0.96
All cams and cam discs illustrated actual size.
Optional Cams to Operate
Corbin Russwin Mortise Locks
Optional Cams to Operate
Adams Rite Narrow Stile Door Locks
Optional Cam to
Operate key switches
L
*Will also operate Sargent®mortise locks.
*
Effective Date: May 1, 2018
Canada Effective July 3, 2018
.640"
No. 1161E
E
.795"
42
DISTRIBUTOR LIST PRICES
MISCELLANEOUS PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION LIST PRICE
1145 Connecting Bar Regular for 1109-1179
$2.00
1147 Connecting Bar Long for 1109
1151 Connecting Screw Regular for 1109-1179
$1.46
1151A Connecting Screw Long for 1109
1451 Retainer for 1109-1179
$0.961451A Retainer for 1709-1179
9072 Spring
10-1194-2302-999 Spring Cover for 1210 Core, Fixed Core Mortise & Rim
$0.59
10-1194-2303-999 Spring Cover for 1220 Core, Fixed Core Mortise & Rim
013 Plug Nut $4.54
014 Plug Nut Retainer
$0.971191 1/2 Knob Screw
9999-4561 Plug Retainer
LOCKSMITH'S REPAIR TOOLS:
PRODUCT # PRODUCT DESCRIPTION LIST PRICE
018 Plug Follower for .51" (metal) $56.00
022 Plug Follower for .40" (metal) $182.00
M33 Vice held plug holder for set up (multiple plug diameters) $216.00
M36 Set up plug for .51" cylinder $699.00
M38 Set up plug for .40" cylinder $840.00
M43 Shove Knife $47.00
OPTIONS:
PREFIX DESCRIPTION LIST PRICE
D Dust Guard, Prefix to Cylinder Model Number ADD $47.00
SP Steel Pin, Prefix to Cylinder Model Number $32.00
MISCELLANEOUS PARTS:
SUFFIX DESCRIPTION LIST PRICE
BUMP BUMP Resistant Cylinders - Suffix to Cylinder Model Number ADD $26.00
43
DISTRIBUTOR LIST PRICES
YALE®KEYMARK®KEYING CHARGES, KEYS AND KEY BLANKS
NOTE: Key blanks can not be substituted for cut keys.
PRODUCT DESCRIPTION LIST PRICE
Masterkeying, Grand Masterkeying, Great Grand Masterkeying
(all fixed core cylinders, charge for each cylinder) ADD $16.00
Masterkeying, Grand Masterkeying, Great Grand Masterkeying
(LFIC and SFIC Cores) ADD $0.00
Uncombinated Cylinders and Cores - key blanks not included DEDUCT $5.00
KEYING CHARGES:
PRODUCT DESCRIPTION LIST PRICE
VKC0 - No stamping (keys will be tagged) ADD $4.30
VKC1 - Keys only (standard) ADD No Charge
VKC2 - Not Available –– ––
VKC3 - Not Available –– ––
VISUAL KEY CONTROL:
PRODUCT DESCRIPTION LIST PRICE
Master Keys and Control Keys - each –– $9.60
Two Keys ordered with cylinder/lockset (standard) –– $0.00
Extra Change Keys ordered with cylinder/lockset - each ADD $9.60
Change Keys ordered separately - each —
KEYS:
PRODUCT DESCRIPTION LIST PRICE
Single Section 6 & 7 pin EACH $5.10
Multi-Section 6 & 7 pin EACH $5.80
Control Keys KN117C, 118C, 91C EACH
KEY BLANKS:
PRODUCT DESCRIPTION LIST PRICE
CKC2 - Cylinders and Keys ADD $8.00
CKC3 - Cylinders only - Not Available –– ––
CONCEALED KEY CONTROL:
NOTE: See page 7 for code definitions and examples.
NOTE: See page 7 for code definitions and examples.
CONSTRUCTION MASTER KEYING:
For security reasons, Yale®KeyMark®cylinders are not available construction master keyed. Temporary construction cores
are available for both SFIC and LFIC. Temporary cores for SFIC are available with either disposable or locking cores.
Temporary cores for LFIC are available with only lockable cores. Temporary cores are not available in competitor formats.
See page 31 for construction core program.
When Ordering: Specify finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MASTERKEY SERVICES: The value-added service of a customized masterkey security solution is provided when requested for a nominal
charge with the purchase of complete Yale®keyed locking devices. In addition to the standard masterkeying charge, a masterkey service
charge will be assessed, based on quantity, cylinder type, key system type, for an order that includes only Yale cylinders or cores for use in
non-Yale manufactured locking devices for whichYale has an equivalent.
44
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
NOTE: Yale®KeyMark®products are priced separately.
Yale®KeyMark®cylinders are not discounted the same as locksets or other products in which the cylinders are used.
Collars are furnished only when cylinders or housings are ordered with mortise locks or exit trims.
MORTISE CYLINDERS:
MODEL # PRODUCT DESCRIPTION LENGTHS ALL FINISHES
K100 Fixed Core Mortise Cylinder 1-1/8", 1-1/4" $83.00
K100 Fixed Core Mortise Cylinder 1-1/2", 1-3/4", 2" $177.00
K620 SFIC Mortise Cylinder 1-1/4", 1-3/8", 1-3/4" $150.00
K630 SFIC Tapered Mortise Cylinder 1-1/4", 1-3/8" $154.00
K820 LFIC Mortise Cylinder 1-1/2", 1-11/16", 1-3/4", 2" $153.00
HOUSINGS:
MODEL # PRODUCT DESCRIPTION LENGTHS ALL FINISHES
K660 SFIC Mortise Housing 1-1/4", 1-3/8",1-3/4" $70.00
K670 SFIC Tapered Mortise Housing 1-1/4", 1-3/8" $74.00
K680 SFIC Rim Housing 1-1/4", 1-3/8"
$70.00
K860 LFIC Mortise Housing 1-1/2", 1-11/16", 1-3/4", 2"
K880 LFIC Rim Housing 1-7/16", 1-5/8"
RIM CYLINDERS:
MODEL # PRODUCT DESCRIPTION LENGTHS ALL FINISHES
K300 Fixed Core Rim Cylinder 1-1/8" $90.00
K640 SFIC Rim Cylinder 1-1/4", 1-3/8" $150.00
K840 LFIC Rim Cylinder 1-7/16", 1-5/8" $153.00
CYLINDRICAL LOCKS & EXIT DEVICE TRIM:
CORES:
MODEL # PRODUCT DESCRIPTION ALL FINISHES
K600 SFIC Core $80.00
K800 LFIC Core $83.00
K890 LFIC Core for Schlage
YALE®KEYMARK®CYLINDERS, CORES AND HOUSINGS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # NO. OF
PINS APPLICATIONS 606/626
FINISHES
CYLINDRICAL LOCKS & EXIT DEVICE TRIM
K400 6 Optional for 5300 & 5400 series knob locks and 540F series trim
$78.00
K402 6 Optional for 4700LN, 5300LN, 5400LN, 6400LN & inTouch®series lever locks and 440F,
540F & 580F series trims
K402 7 Optional for 5400LN &6400LN series lever locks and 540F series trim
K404 6 Optional for 4800LN series lever locks
K490 6 Optional for Schlage®A, D & ND series lever locks $83.00
K403-54L 6 Optional for Corbin Russwin CL3100(YC) & Sargent 11 Line (YC-) series lever locks.
Optional for 4600LN & 4800LN series lever locks.
$78.00
K403A-54L 7 Optional for Corbin Russwin CL3100(YC7), Sargent 11 Line (YC-7P-) series lever locks
K403-54K 6 Optional for 5400CK series knob locks and YH Collection lever locks
K403-53L 6 Optional for nexTouch™ cylindrical series lever locks and inTouch®series lever locks
K403-47L 6 Optional for 4700LN, 5300LN and 440F series trim
K403-46K 6 Optional for 4600 series knob locks
DEADBOLTS
K202 6 Optional for 4800LN series deadbolt $78.00
K290 6 Optional for Schlage®B series deadbolt $83.00
K403-134S 6 Optional for YH Collection Deadbolt used with interconneted lock (non-face removable)
Optional for D Series deadbolts, single cylinder functions $78.00
K403-134D 6 Optional for D Series deadbolts, double cylinder functions
45
DISTRIBUTOR LIST PRICES
YALE®KEYMARK®CYLINDER PARTS AND ACCESSORIES
CYLINDER PLUGS: 6-PIN & 7-PIN
MODEL # PRODUCT DESCRIPTION LENGTHS ALL FINISHES
EACH
K150 Mortise - order in multiples of 10 1-1/8", 1-1/4" $37.00
K150 Mortise - order in multiples of 10 1-1/2" $47.00
K250 Deadlocks - order in multiples of 10 ––
$37.00
K350 Rim - order in multiples of 10 1-1/8"
K450 Key In Knob/Lever - order in multiples of 10 ––
K850 Large Format IC - order in multiples of 10 ––
SFIC Not Available - order K600 UC –– ––
CYLINDER SHELLS: 6-PIN & 7-PIN
MODEL # PRODUCT DESCRIPTION LENGTHS ALL FINISHES
EACH
K151 Mortise - order in multiples of 10 1-1/8", 1-1/4" $57.00
K151 Mortise - order in multiples of 1 each 1-1/2" $146.00
K251 Deadlocks - order in multiples of 10 ––
$57.00
K351 Rim - order in multiples of 10 ––
K451 Key In Knob/Lever - order in multiples of 10 ––
K851 Large Format IC - order in multiples of 10 ––
SFIC Not Available - order K600 UC –– ––
PINS, SPRINGS & CAPS
MODEL # PRODUCT DESCRIPTION EACH
K702-K719* Master, Build Up & Top Pins - order in multiples of 100 $0.06
K720-K729* Bottom Pins - order in multiples of 100 $0.06
K730 Tumbler Springs - order in multiples of 100 $0.04
K731 Pin Chamber Caps for K600 - order in multiples of 100
K732 Spring Cover 6-Pin for K800 - order in multiples of 100
$0.52
K733 Spring Cover 7-Pin for K800 - order in multiples of 100
K734 Spring Cover 6-Pin for K200 & K400 - order in multiples of 100
K735 Spring Cover 7-Pin for K200 & K400 - order in multiples of 100
K736 Set Screws for K100 & K300 - order in multiples of 100 $0.31
When Ordering: Specify finish on plugs and shells.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
* Refer to Yale®KeyMark®Service Manual (42250) for details on pin sizes.
46
DISTRIBUTOR LIST PRICES
TAILPIECES, CAMS & COLLARS
MODEL # PRODUCT DESCRIPTION EACH
K739 Plug Retainer for K300 - order in multiples of 10
$1.46K740 Plug Retainer for K800 - order in multiples of 10
K741 Plug Retainer for K200 & K400 - order in multiples of 10
KC1-KC10* Cams - order in multiples of 20 $62.40
KP1 Cam Washers - order in multiples of 100 $0.90
KP2 Cam Screws - order in multiples of 100 $0.50
KP4 Collars in all finishes - order in multiples of 10 $3.90
KT1 Break Off Tailpiece & Retainer for K300 & K640 & K840 - order in multiples of 10 $3.25
KT2-KT7* Tailpiece for K200 & K400 - order in multiples of 10 $10.62
KT8 Tailpiece for K202 $12.25
YALE®KEYMARK®TOOLS AND SERVICE EQUIPMENT
TOOLS & EQUIPMENT
MODEL # PRODUCT DESCRIPTION EACH
K915 Key Gauge $26.00
K918 Pin Kit $396.00
When Ordering: Specify finish on plugs and shells.
YALE®KEYMARK®CYLINDER PARTS AND ACCESSORIES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
* Refer to Yale®KeyMark®Service Manual (42250) for details on cams and tailpieces.
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER: Specify "x LC"
Cylinder rings/collars not furnished with locksets ordered less cylinders. $70.00 ––
Hotel Function Locksets - Less Cylinder $155.00 —
IC Housing ordered with locksets (ICLC) –– $0.00
7-PIN CYLINDERS: Add to 6-Pin cylinder –– $2.00
DUST GUARD: Prefix "D" to model number (refer to catalog for available cylinders) –– $47.00
INTERCHANGEABLE CORE CYLINDERS:
2196 - LFIC 6-Pin (Includes MK or GMK)
Ordering Example: AUR8807FL x 2196 x RH x 626 –– $58.00
2196H - LFIC Hotel Lock (Includes MK or GMK and EMK) –– $138.00
A620 - SFIC 6-or 7-Pin (Includes MK or GMK)
Ordering Example: AUR8807 x A620 x RH x 626 –– $50.00
TORX®SECURITY HEAD SCREWS: Standard size only (add for each screw) –– $1.00
Quantity Required: Sectional Trim = 4 —$4.00
Escutcheon Trim = 6 — $6.00
SPECIAL STRIKES:
Strikes with lip lengths other than 1-1/8" or 1-1/4" –– $13.00
SPLIT DESIGNS AND SPLIT FINISHES Higher List Price Applies
LEAD LINED –– $284.00
KNURLING: Available for all knob and levers in any finish except HA, PN and all Reflections®levers
Outside or Inside Only –– $75.00
Both Sides –– $150.00
ABRASIVE COATING: Knob or Lever
Outside or Inside Only –– $46.00
Both Sides –– $92.00
DOORS 1-7/8" THICK TO 3-1/4" THICK:
Non-keyed –– $103.00
Single cylinder keyed –– $162.00
Double cylinder keyed –– $181.00
OCCUPANCY INDICATOR: Specify “x IND" — $90.00
MICROSHIELD®:Antimicrobial coating. Specify option "YMS" — $65.00
47
DISTRIBUTOR LIST PRICES
8800 SERIES MORTISE LOCK VARIATIONS
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
NICKEL:
618 Bright Nickel Plated, Clear Coated
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin
Relieved, Clear Coated
PAINTED:
693 Black Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated
BRONZE:
611 Bright Bronze
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened, Satin Relieved,
Clear Coated
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide a sample.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
48
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
8800FL SERIES MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Price Includes Hotel Indicator.
2. Levers are Nickel Plated to match Stainless Steel
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62926302693
SINGLE CYLINDER:
8805FL Storeroom or Closet
$671.00 $695.008807FL Entrance
8808FL Classroom
8809FL Classroom or Office with Thumbturn $681.00 $705.00
8824FL Hold Back
$671.00 $695.00
8829FL Closet
8833FL Exit
8834FL All Purpose
8864FL Bathroom with Indicator $771.00 $795.00
SINGLE CYLINDER WITH DEADBOLT:
8822FL Dormitory
$691.00 $715.00
8823FL Storeroom
8840FL Storeroom
8847FL Entrance or Apartment
8860FL Entrance or Storeroom
8861FL Dormitory or Storeroom
8867FL Dormitory or Exit
DOUBLE CYLINDER:
8808-2FL Classroom
$741.00 $765.00
8817-2FL Apartment, Exit or Public Toilet
8830-2FL Asylum
8834-2FL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2FL Classroom Deadbolt
$761.00 $785.00
8812-2FL Classroom Security
8818-2FL Classroom Security Intruder
8860-2FL Entrance or Storeroom
HOTEL/MOTEL:
8820FL1Hotel/Motel $777.00 $801.00
8827FL1Hotel/Motel
8832FL Hotel/Motel $756.00 $780.00
NON-KEYED:
8801FL Passage $573.00 $597.00
8802FL Privacy $621.00 $645.00
8828FL Exit $573.00 $597.00
8835FL Exit with Thumbturn $603.00 $627.00
8862FL Bathroom $601.00 $625.00
8865FL Bathroom with Thumbturn $611.00 $635.00
DUMMY TRIM:
855FL Single $242.50 $254.50
838AFL Pair $485.00 $509.00
838BFL Pair (Strike available upon request) $510.00 $534.00
8870FLDT Plain
$573.00 $597.008871FLDT Latchbolt
8872FLDT Latchbolt x Deadbolt
LEVER DESIGNS: Augusta - AU Monroe - MO
Carmel - CR Pacific Beach - PB
ROSE DESIGN: Copenhagen - R
R3, R4, R5, R6, R7, R8
49
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
8800FL SERIES MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Price Includes Hotel Indicator.
2. Levers and Escutcheons are Nickel Plated to match Stainless Steel.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62926302693
SINGLE CYLINDER:
8805FL Storeroom or Closet
$691.00 $715.008807FL Entrance
8808FL Classroom
8809FL Classroom or Office with Thumbturn $701.00 $725.00
8824FL Hold Back
$691.00 $715.00
8829FL Closet
8833FL Exit
8834FL All Purpose
8864FL Bathroom with Indicator $791.00 $815.00
SINGLE CYLINDER WITH DEADBOLT:
8822FL Dormitory
$711.00 $735.00
8823FL Storeroom
8840FL Storeroom
8847FL Entrance or Apartment
8860FL Entrance or Storeroom
8861FL Dormitory or Storeroom
8867FL Dormitory or Exit
DOUBLE CYLINDER:
8808-2FL Classroom
$761.00 $785.00
8817-2FL Apartment, Exit or Public Toilet
8830-2FL Asylum
8834-2FL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2FL Classroom Deadbolt
$781.00 $805.00
8812-2FL Classroom Security
8818-2FL Classroom Security Intruder
8860-2FL Entrance or Storeroom
HOTEL/MOTEL:
8820FL1Hotel/Motel $797.00 $821.00
8827FL1Hotel/Motel
8832FL Hotel/Motel $776.00 $800.00
NON-KEYED:
8801FL Passage $593.00 $617.00
8802FL Privacy $641.00 $665.00
8828FL Exit $593.00 $617.00
8835FL Exit with Thumbturn $623.00 $647.00
8862FL Bathroom $621.00 $645.00
8865FL Bathroom with Thumbturn $631.00 $655.00
DUMMY TRIM:
855FL Single $252.50 $264.50
838AFL Pair $505.00 $529.00
838BFL Pair (Strike available upon request) $530.00 $554.00
8870FLDT Plain
$593.00 $617.008871FLDT Latchbolt
8872FLDT Latchbolt x Deadbolt
LEVER DESIGNS: Augusta - AU Monroe - MO
Carmel - CR Pacific Beach - PB
ESCUTCHEON DESIGN: Camden - CN
E3, E4
50
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
8800FL SERIES MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Price Includes Hotel Indicator.
2. Levers are Nickel Plated to match Stainless Steel
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62926302693
SINGLE CYLINDER:
8805FL Storeroom or Closet
$774.00 $798.008807FL Entrance
8808FL Classroom
8809FL Classroom or Office with Thumbturn $784.00 $808.00
8824FL Hold Back
$774.00 $798.00
8829FL Closet
8833FL Exit
8834FL All Purpose
8864FL Bathroom with Indicator $874.00 $898.00
SINGLE CYLINDER WITH DEADBOLT:
8822FL Dormitory
$794.00 $818.00
8823FL Storeroom
8840FL Storeroom
8847FL Entrance or Apartment
8860FL Entrance or Storeroom
8861FL Dormitory or Storeroom
8867FL Dormitory or Exit
DOUBLE CYLINDER:
8808-2FL Classroom
$844.00 $868.00
8817-2FL Apartment, Exit or Public Toilet
8830-2FL Asylum
8834-2FL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2FL Classroom Deadbolt
$864.00 $888.00
8812-2FL Classroom Security
8818-2FL Classroom Security Intruder
8860-2FL Entrance or Storeroom
HOTEL/MOTEL:
8820FL1Hotel/Motel $880.00 $904.00
8827FL1Hotel/Motel
8832FL Hotel/Motel $859.00 $883.00
NON-KEYED:
8801FL Passage $676.00 $700.00
8802FL Privacy $724.00 $748.00
8828FL Exit $676.00 $700.00
8835FL Exit with Thumbturn $706.00 $730.00
8862FL Bathroom $704.00 $728.00
8865FL Bathroom with Thumbturn $714.00 $738.00
DUMMY TRIM:
855FL Single $294.00 $306.00
838AFL Pair $588.00 $612.00
838BFL Pair (Strike available upon request) $613.00 $637.00
8870FLDT Plain
$676.00 $700.008871FLDT Latchbolt
8872FLDT Latchbolt x Deadbolt
LEVER DESIGNS: Arcadia - AR Pinehurst - PN
Jefferson - JN Virginia - VI
ROSE DESIGN: Copenhagen - R
R3, R4, R5, R6, R7, R8
51
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
8800FL SERIES MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62926302693
SINGLE CYLINDER:
8805FL Storeroom or Closet
$794.00 $818.008807FL Entrance
8808FL Classroom
8809FL Classroom or Office with Thumbturn $804.00 $828.00
8824FL Hold Back
$794.00 $818.00
8829FL Closet
8833FL Exit
8834FL All Purpose
8864FL Bathroom with Indicator $894.00 $918.00
SINGLE CYLINDER WITH DEADBOLT:
8822FL Dormitory
$814.00 $838.00
8823FL Storeroom
8840FL Storeroom
8847FL Entrance or Apartment
8860FL Entrance or Storeroom
8861FL Dormitory or Storeroom
8867FL Dormitory or Exit
DOUBLE CYLINDER:
8808-2FL Classroom
$864.00 $888.00
8817-2FL Apartment, Exit or Public Toilet
8830-2FL Asylum
8834-2FL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2FL Classroom Deadbolt
$884.00 $908.00
8812-2FL Classroom Security
8818-2FL Classroom Security Intruder
8860-2FL Entrance or Storeroom
HOTEL/MOTEL:
8820FL1Hotel/Motel $900.00 $924.00
8827FL1Hotel/Motel
8832FL Hotel/Motel $879.00 $903.00
NON-KEYED:
8801FL Passage $696.00 $720.00
8802FL Privacy $744.00 $768.00
8828FL Exit $696.00 $720.00
8835FL Exit with Thumbturn $726.00 $750.00
8862FL Bathroom $724.00 $748.00
8865FL Bathroom with Thumbturn $734.00 $758.00
DUMMY TRIM:
855FL Single $304.00 $316.00
838AFL Pair $608.00 $632.00
838BFL Pair (Strike available upon request) $633.00 $657.00
8870FLDT Plain
$696.00 $720.008871FLDT Latchbolt
8872FLDT Latchbolt x Deadbolt
1. Price Includes Hotel Indicator.
2. Levers and Escutcheons are Nickel Plated to Match Stainless Steel.
LEVER DESIGNS: Arcadia - AR Pinehurst - PN
Jefferson - JN Virginia - VI
ESCUTCHEON DESIGN: Camden - CN
E3, E4
52
DISTRIBUTOR LIST PRICES
8800FL SERIES DESIGNER MORTISE LOCKS
When Ordering: Specify design, function, hand finish and trim.
1. Price Includes Hotel Indicator.
MODEL # PRODUCT DESCRIPTION
ROSE TRIM
605 606
619 625 626
ESCUTCHEON
TRIM
605 606
619 625 626
SINGLE CYLINDER:
8805FL Storeroom or Closet
$796.00 $898.00
8807FL Entrance
8808FL Classroom
8809FL Classroom or Office with Thumbturn $806.00 $908.00
8824FL Holdback
$796.00 $898.00
8829FL Closet
8833FL Exit
8834FL All Purpose
8864FL Bathroom with Indicator $896.00 $998.00
SINGLE CYLINDER WITH DEADBOLT:
8822FL Dormitory
$816.00 $918.00
8823FL Storeroom
8840FL Storeroom
8847FL Entrance or Apartment
8860FL Entrance or Storeroom
8861FL Dormitory or Storeroom
8867FL Dormitory or Exit
DOUBLE CYLINDER:
8808-2FL Classroom
$866.00 $968.00
8817-2FL Apartment, Exit or Public Toilet
8830-2FL Asylum
8834-2FL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2FL Classroom Deadbolt
$886.00 $988.00
8812-2FL Classroom Security
8818-2FL Classroom Security Intruder
8860-2FL Entrance or Storeroom
HOTEL/MOTEL:
8820FL1Hotel/Motel $902.00 $1,004.00
8827FL1Hotel/Motel
8832FL Hotel/Motel $881.00 $983.00
NON-KEYED:
8801FL Passage $698.00 $800.00
8802FL Privacy $746.00 $848.00
8828FL Exit $698.00 $800.00
8835FL Exit with Thumbturn $728.00 $830.00
8862FL Bathroom $726.00 $828.00
8865FL Bathroom with Thumbturn $736.00 $838.00
DUMMY TRIM:
855FL Single $305.00 $356.00
838AFL Pair $610.00 $712.00
838BFL Pair (Strike available upon request) $635.00 $737.00
8870FLDT Plain
$698.00 $800.008871FLDT Latchbolt
8872FLDT Latchbolt x Deadbolt
LEVER DESIGN: Hampton - HA ESCUTCHEON DESIGNS: E3, E4,
Camden - CN
ROSE DESIGNS: R3, R4, R5, R6,
R7, R8, Copenhagen - R
Effective Date: May 1, 2018
Canada Effective July 3, 2018
53
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
1. Price Includes Hotel Indicator.
2. Price Includes Heat-Treated Base and Torx®.
3. Knobs are Nickel Plated to Match Stainless Steel.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62936303693
SINGLE CYLINDER:
8805 Storeroom or Closet
$644.00 $668.008807 Entrance
8808 Classroom
8809 Classroom or Office with Thumbturn $654.00 $678.00
8824 Holdback
$644.00 $668.00
8829 Closet
8833 Exit
8834 All Purpose
8864 Bathroom with Indicator $744.00 $768.00
SINGLE CYLINDER WITH DEADBOLT:
8822 Dormitory $664.00 $688.00
8823 Storeroom
88312Detention $749.00 $773.00
8840 Storeroom
$664.00 $688.00
8847 Entrance or Apartment
8860 Entrance or Storeroom
8861 Dormitory or Storeroom
8867 Dormitory or Exit
DOUBLE CYLINDER:
8808-2 Classroom
$714.00 $738.00
8817-2 Apartment, Exit or Public Toilet
8830-2 Asylum
8834-2 All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2 Classroom Deadbolt
$734.00 $758.00
8812-2 Classroom Security
8818-2 Classroom Security Intruder
8860-2 Entrance or Storeroom
HOTEL/MOTEL:
88201Hotel/Motel $750.00 $774.00
88271Hotel/Motel
8832 Hotel/Motel $729.00 $753.00
NON-KEYED:
8801 Passage $546.00 $570.00
8802 Privacy $594.00 $618.00
8828 Exit $546.00 $570.00
8835 Exit with Thumbturn $576.00 $600.00
8862 Bathroom $574.00 $598.00
8865 Bathroom with Thumbturn $584.00 $608.00
DUMMY TRIM:
855 Single $229.00 $241.00
836A Pair $458.00 $482.00
836B Pair (Strike available upon request) $483.00 $507.00
8870DT Plain
$546.00 $570.00
8871DT Latchbolt
8872DT Latchbolt x Deadbolt
KNOB DESIGNS: Copenhagen - CO
Litchfield - LF
ROSE DESIGN: Copenhagen - R
R3, R4, R5, R6, R7, R8
8800 SERIES MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
54
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
8800 SERIES MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Price Includes Hotel Indicator.
2. Price Includes Heat Treated Base and TORX®.
3. Knobs and Escutcheons are Nickel Plated to match Stainless Steel.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62936303693
SINGLE CYLINDER:
8805 Storeroom or Closet
$664.00 $688.008807 Entrance
8808 Classroom
8809 Classroom or Office with Thumbturn $674.00 $698.00
8824 Holdback
$664.00 $688.00
8829 Closet
8833 Exit
8834 All Purpose
8864 Bathroom with Indicator $764.00 $788.00
SINGLE CYLINDER WITH DEADBOLT:
8822 Dormitory $684.00 $708.00
8823 Storeroom
88312Detention $769.00 $793.00
8840 Storeroom
$684.00 $708.00
8847 Entrance or Apartment
8860 Entrance or Storeroom
8861 Dormitory or Storeroom
8867 Dormitory or Exit
DOUBLE CYLINDER:
8808-2 Classroom
$734.00 $758.00
8817-2 Apartment, Exit or Public Toilet
8830-2 Asylum
8834-2 All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2 Classroom Deadbolt
$754.00 $778.00
8812-2 Classroom Security
8818-2 Classroom Security Intruder
8860-2 Entrance or Storeroom
HOTEL/MOTEL:
88201Hotel/Motel $770.00 $794.00
88271Hotel/Motel
8832 Hotel/Motel $749.00 $773.00
NON-KEYED:
8801 Passage $566.00 $590.00
8802 Privacy $614.00 $638.00
8828 Exit $566.00 $590.00
8835 Exit with Thumbturn $596.00 $620.00
8862 Bathroom $594.00 $618.00
8865 Bathroom with Thumbturn $604.00 $628.00
DUMMY TRIM:
855 Single $239.00 $251.00
836A Pair $478.00 $502.00
836B Pair (Strike available upon request) $503.00 $527.00
8870DT Plain
$566.00 $590.00
8871DT Latchbolt
8872DT Latchbolt x Deadbolt
KNOB DESIGNS: Copenhagen - CO
Litchfield - LF
ESCUTCHEON DESIGN: Camden - CN
E3, E4
55
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
8800FL SERIES MORTISE DEADLOCKS WITH A/F, CYLINDERS & THUMBTURNS
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
DEADLOCKS:
8813ST Single Cylinder with Thumbturn $373.00
8813ST-2 Double Cylinder with Thumbturn $443.00
8814 Single Cylinder $318.00
8814-2 Double Cylinder $388.00
8815 Single Cylinder with Thumbturn $373.00
8833-2 Double Cylinder $388.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
56
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
MORTISE LOCK COMPONENTS
NOTE: Trim priced separately.
Armor Fronts and Strikes included with lockbodies only. Finish must be specified.
Cylinders are not furnished with lock bodies; cylinders must be ordered separately.
Limited quantities of armor fronts available for mortise locks shipped prior to March 2012. Contact factory for more information.
FUNCTION LOCKBODY MODEL # LIST PRICE
LEVERS:
8801FL LBDY8801FL $323.00
8802FL LBDY8802FL $410.00
8805FL LBDY8805FL
$373.00
8807FL LBDY8807FL
8808FL LBDY8808FL
8809FL LBDY8809FL
8864FL LBDY8864FL
8808-2FL LBDY8808FL
8811-2FL LBDY8811FL $410.00
8812-2FL LBDY8812FL
8817-2FL LBDY8817FL $373.00
8818-2FL LBDY8818FL
$410.00
8820FL LBDY8820FL
8822FL LBDY8822FL
8823FL LBDY8823FL
8824FL LBDY8824FL
8827FL LBDY8827FL
8832FL LBDY8832FL
8835FL LBDY8835FL
8840FL LBDY8840FL
8847FL LBDY8847FL
8828FL LBDY8828FL $327.00
8829FL LBDY8829FL $373.00
8830-2FL LBDY8830FL $399.00
8833FL LBDY8833FL
$373.00
8833-2FL LBDY8833FL
8834FL LBDY8834FL
8834-2FL LBDY8834FL
8860FL LBDY8860FL
$399.00
8860-2FL LBDY8860FL
8861FL LBDY8861FL
8862FL LBDY8862FL $373.00
8865FL LBDY8865FL
8867FL LBDY8867FL $399.00
MORTISE LOCK BODIES (WITH ARMOR FRONT AND STRIKE)
FUNCTION LOCKBODY MODEL # LIST PRICE
KNOBS:
8801 LBDY8801 $323.00
8802 LBDY8802 $410.00
8805 LBDY8805
$373.00
8807 LBDY8807
8808 LBDY8808
8809 LBDY8809
8864 LBDY8864
8808-2 LBDY8808
8811-2 LBDY8811 $410.00
8812-2 LBDY8812
8817-2 LBDY8817 $373.00
8818-2 LBDY8818
$410.00
8820 LBDY8820
8822 LBDY8822
8823 LBDY8823
8824 LBDY8824
8827 LBDY8827
8832 LBDY8832
8835 LBDY8835
8840 LBDY8840
8847 LBDY8847
8828 LBDY8828 $327.00
8829 LBDY8829 $373.00
8830-2 LBDY8830 $399.00
8831 LBDY8831
8833 LBDY8833
$373.00
8833-2 LBDY8833
8834 LBDY8834
8834-2 LBDY8834
8860 LBDY8860
$399.008860-2 LBDY8860
8861 LBDY8861
8862 LBDY8862 $373.00
8865 LBDY8865
8867 LBDY8867 $399.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PART NUMBER USED WITH
PRODUCT
SHIPPED BETWEEN MARCH
2012 AND AUGUST 2014
PART NUMBER USED WITH
PRODUCT SHIPPED AFTER
AUGUST 2014
LOCK FUNCTION ALL FINISHES
ARMOR FRONT & STRIKE PACKS:
50-0010-8801-FIN 50-0020-8801-FIN 8801, 8862, 8865
$54.00
50-0010-8802-FIN 50-0020-8802-FIN 8802, 8811, 8822, 8823, 8860, 8861
50-0010-8805-FIN 50-0020-8805-FIN 8805, 8808, 8809, 8817, 8824, 8828, 8829,
8830, 8833, 8834, 8834-2, 8864
50-0010-8807-FIN 50-0020-8807-FIN 8807
50-0010-8813-FIN 50-0020-8813-FIN 8813, 8814, 8815
50-0010-8820-FIN 50-0020-8820-FIN 8812, 8818, 8820, 8831, 8832, 8835
50-0010-8847-FIN 50-0020-8847-FIN 8827, 8847
50-0010-8867-FIN 50-0020-8867-FIN 8867
57
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
TRIM PACKS
MORTISE LOCK COMPONENTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PRODUCT
CODE PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
611 612 616
618 619 620 625
62916301693
LEVERS WITH ROSES:
AUR Specify lock function
$454.00 $478.00
CRR Specify lock function
MOR Specify lock function
PBR Specify lock function
ARR Specify lock function
$549.00 $573.00
JNR Specify lock function
PNR Specify lock function
VIR Specify lock function
LEVERS WITH ESCUTCHEONS:
AUCN Specify lock function
$473.00 $497.00
CRCN Specify lock function
MOCN Specify lock function
PBCN Specify lock function
ARCN Specify lock function
$570.00 $594.00
JNCN Specify lock function
PNCN Specify lock function
VICN Specify lock function
KNOBS WITH ROSES:
COR Specify lock function $431.00 $455.00
LFR Specify lock function
KNOBS WITH ESCUTCHEONS:
COCN Specify lock function $453.00 $477.00
LFCN Specify lock function
1. Levers, Knobs and CN Escutcheons are Nickel Plated to match Stainless Steel.
58
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
MODEL # PRODUCT
DESCRIPTION
613E 626
BSP
605 606 609
611 612 616
618 619 620 625
62916301693
ESCUTCHEON PLATES:
CN87 Inside $90.00 $94.00
CN88 Outside
NOTE: When ordering escutcheons separately, specify the model number of the escutcheon plate suffixed with the spacing number. The
spacing number indicates the hole preparation in the escutcheon plate to coordinate with the lock functions.
• 211, 251 inside escutcheon include thumbturn
• 211 outside escutcheon has hole for emergency release tool
• 260, 261, & 262 used with CN escutcheon only. These are an assembly which includes indicator.
• 262 used with CN88 only
1. CN Escutcheons are Nickel Plated to match Stainless Steel.
201 208 211 250 251 260 261 262
MORTISE LOCK PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ALL FINISHES
STRIKES:
2815 Latchbolt and Deadbolt, Curved Lip (8800)
$37.002816 Latchbolt and Deadbolt, Flat Lip (8800)
497B Blank Filler Plate
718 Open Back Strike (black) $147.00
202 Strike Box $2.00
NOTE: Standard strike pack does not include TORX screws. Add $2.00 to strike for TORX screws.
MODEL # PRODUCT
DESCRIPTION
613E 626
BSP
605 606 611 612
618 619 625 6291
6301US10BL
US20D
ESCUTCHEON PLATES:
E3-88 Outside
$225.00 $249.00
E3-87 Inside
E4-88 Outside
E4-87 Inside
59
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
OUTSIDE INSIDE 613E 626
BSP
605 606 609 611
612 616 618 619
620 625 62916301693
LEVER HANDLES – PAIRS WITH SPINDLES:
CR904 X CR905
$337.00 $361.00
AU904 X AU905
MO904 X MO905
PB904 X PB905
VI904 X VI905
AR902 X AR903
$439.00 $463.00JN902 X JN903
PN904 X PN905
PRODUCT # 613E 626
BSP
605 606 609 611
612 616 618 619
620 625 62916301693
KNOBS – PAIRS WITH SPINDLES:
CO35S $307.00 $319.00
LF35S
PRODUCT # PRODUCT
DESCRIPTION
613E 626
BSP
605 606 609
611 612 616
618 619
620 625 629
630 693
ROSES – EACH:
CO505 Inside Rose $80.00 $84.00
CO506 Outside Rose
PRODUCT # PRODUCT DESCRIPTION ALL FINISHES
TURN KNOBS – EACH:
GF1824 Round Plate $55.00
EMERGENCY KEY PLATES:
GF1826 Round Plate $55.00
THUMBTURNS FOR DESIGNER TRIM*:
50-1824-0033 For Rose 1-3/4" Door $141.00
OUTSIDE X INSIDE ALL FINISHES
DESIGNER LEVER HANDLES - PAIRS WITH SPINDLES:
HA904 X HA905 $464.00
MORTISE LOCK PARTS
1. Levers are Nickel Plated to match Stainless Steel.
*For escutcheon trim, inside plate must be ordered. See page 58.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Knobs are Nickel Plated to match Stainless Steel.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 611 612
618 619 625 62916301
US10BL US20D
ROSE ASSEMBLIES:
R3-505 Inside
$71.00 $95.00
R3-506 Outside
R4-505 Inside
R4-506 Outside
R5-505 Inside
R5-506 Outside
R6-505 Inside
R6-506 Outside
R7-505 Inside
R7-506 Outside
R8-505 Inside
R8-506 Outside
60
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION 612
626
RABBETED KITS:
RK245 Latchbolt & Deadbolt, 1-3/4" & 2" Door $215.00
TOOLS:
S1064 Knob & Rose Wrench $3.00
E203 Emergency Key $2.66
OCCUPANCY INDICATOR KIT:
IND-K Retrofit Kit Used with Sectional Trim Only for 8802(FL) and 8862(FL). Specify Finish.
$90.00
CIND-K Retrofit Kit Used with Sectional Trim Only for 8818-2(FL), 8822(FL) and 8832(FL).
Specify Finish. Not available for use with R1, R2, R3, R4, or R5 roses.
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
SPINDLE (PARTS):
1173L Straight Spindle 3/8"
$42.001178L Swivel Spindle 3/8" for Lever x Lever
F1198 Threaded Hook Spindle 3/8"
DUMMY SPINDLE (PARTS):
1424 Dummy Spindle Assembly (P/N 50-1424-0003-048) $37.00
Note: Limited quantities of armor fronts available for mortise locks shipped prior to March 2012. Contact factory for more information.
For "X" in part number, specify finish required:
- For 605, 606, 609, 611, 612, 613, 616, 618, 619, 620, 625, 626, 693 or 722 substitute "X" with "2"
- For 629 or 630 substitute "X" with "7"
Example = 50-8847-7219 would be used for an 8847 mortise lock in 630 finish.
PART NUMBER USED WITH
PRODUCT
SHIPPED BETWEEN MARCH
2012 AND AUGUST 2014
PART NUMBER USED WITH
PRODUCT SHIPPED AFTER
AUGUST 2014
LOCK FUNCTION ALL FINISHES
ARMOR FRONTS:
50-8801-X119 50-8801-X219 8801, 8862, 8865
$30.00
50-8802-X119 50-8802-X219 8802, 8811, 8822, 8823, 8860, 8861
50-8805-X119 50-8805-X219 8805, 8808, 8809, 8817, 8824, 8828, 8829,
8830, 8833, 8834, 8834-2, 8864
50-8807-X119 50-8807-X219 8807
50-8813-X119 50-8813-X219 8813, 8814, 8815
50-8820-X119 50-8820-X219 8812, 8818, 8820, 8831, 8832, 8835
50-8847-X119 50-8847-X219 8827, 8847
50-8867-X119 50-8867-X219 8867
81-00X2-0404 81-00X2-0404 Armor Front Screw (each) $0.30
MORTISE LOCK PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
61
DISTRIBUTOR LIST PRICES
8800FL SERIES ELECTRIFIED MORTISE LOCKS
When Ordering: Specify design, hand and finish.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609 611
612 616 618 619
620 625 62916301693
SINGLE CYLINDER:
8890FL Fail Safe $889.00 $913.00
8891FL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896FL Fail Safe
$909.00 $933.00
8897FL Fail Secure
8898FL Fail Safe
8899FL Fail Secure
DOUBLE CYLINDER:
8894-2FL Fail Safe $959.00 $983.00
8895-2FL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2FL Fail Safe
$979.00 $1,003.00
8897-2FL Fail Secure
8898-2FL Fail Safe
8899-2FL Fail Secure
NO CYLINDER OVERRIDE:
8880FL Fail Safe
$819.00 $843.00
8881FL Fail Secure
8884FL Fail Safe
8885FL Fail Secure
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609 611
612 616 618 619
620 625 62916301693
SINGLE CYLINDER:
8890FL Fail Safe $909.00 $933.00
8891FL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896FL Fail Safe
$929.00 $953.00
8897FL Fail Secure
8898FL Fail Safe
8899FL Fail Secure
DOUBLE CYLINDER:
8894-2FL Fail Safe $979.00 $1,003.00
8895-2FL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2FL Fail Safe
$999.00 $1,023.00
8897-2FL Fail Secure
8898-2FL Fail Safe
8899-2FL Fail Secure
NO CYLINDER OVERRIDE:
8880FL Fail Safe
$839.00 $863.00
8881FL Fail Secure
8884FL Fail Safe
8885FL Fail Secure
LEVER DESIGNS: Augusta - AU Pacific Beach - PB
Monroe - MO Carmel - CR
ESCUTCHEON DESIGN: Camden - CN
E3, E4
LEVER DESIGNS: Augusta - AU Pacific Beach - PB
Monroe - MO Carmel - CR
ROSE DESIGN: Copenhagen - R
R3, R4, R5, R6, R7, R8
1. Levers and Escutcheons are Nickel Plated to match Stainless Steel.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
62
DISTRIBUTOR LIST PRICES
8800FL SERIES ELECTRIFIED MORTISE LOCKS
When Ordering: Specify design, hand and finish.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609 611
612 616 618 619
620 625 62916301693
SINGLE CYLINDER:
8890FL Fail Safe $992.00 $1,016.00
8891FL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896FL Fail Safe
$1,012.00 $1,036.00
8897FL Fail Secure
8898FL Fail Safe
8899FL Fail Secure
DOUBLE CYLINDER:
8894-2FL Fail Safe $1,062.00 $1,086.00
8895-2FL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2FL Fail Safe
$1,082.00 $1,106.00
8897-2FL Fail Secure
8898-2FL Fail Safe
8899-2FL Fail Secure
NO CYLINDER OVERRIDE:
8880FL Fail Safe
$922.00 $946.00
8881FL Fail Secure
8884FL Fail Safe
8885FL Fail Secure
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609 611
612 616 618 619
620 625 62916301693
SINGLE CYLINDER:
8890FL Fail Safe $1,012.00 $1,036.00
8891FL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896FL Fail Safe
$1,032.00 $1,056.00
8897FL Fail Secure
8898FL Fail Safe
8899FL Fail Secure
DOUBLE CYLINDER:
8894-2FL Fail Safe $1,082.00 $1,106.00
8895-2FL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2FL Fail Safe
$1,102.00 $1,126.00
8897-2FL Fail Secure
8898-2FL Fail Safe
8899-2FL Fail Secure
NO CYLINDER OVERRIDE:
8880FL Fail Safe
$942.00 $966.00
8881FL Fail Secure
8884FL Fail Safe
8885FL Fail Secure
LEVER DESIGNS: Arcadia - AR Pinehurst - PN
Jefferson - JN Virginia - VI
ROSE DESIGN: Copenhagen - R
R3, R4, R5, R6, R7, R8
LEVER DESIGNS: Arcadia - AR Pinehurst - PN
Jefferson - JN Virginia - VI
ESCUTCHEON DESIGN: Camden - CN
E3, E4
1. Levers and Escutcheons are Nickel Plated to match Stainless Steel.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
63
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
MODEL # PRODUCT DESCRIPTION
ROSE TRIM
605 606
619 625 626
ESCUTCHEON
TRIM
605 606
619 625 626
SINGLE CYLINDER:
8890FL Fail Safe $1,014.00 $1,116.00
8891FL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896FL Fail Safe
$1,034.00 $1,126.00
8897FL Fail Secure
8898FL Fail Safe
8899FL Fail Secure
DOUBLE CYLINDER:
8894-2FL Fail Safe $1,084.00 $1,216.00
8895-2FL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2FL Fail Safe
$1,104.00 $1,136.00
8897-2FL Fail Secure
8898-2FL Fail Safe
8899-2FL Fail Secure
NO CYLINDER OVERRIDE:
8880FL Fail Safe
$944.00 $1,046.00
8881FL Fail Secure
8884FL Fail Safe
8885FL Fail Secure
8800FL SERIES ELECTRIFIED MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
LEVER DESIGN: Hampton - HA ESCUTCHEON DESIGNS: E3, E4,
Camden - CN
ROSE DESIGNS: R3, R4, R5, R6,
R7, R8, Copenhagen - R
64
DISTRIBUTOR LIST PRICES
8800 SERIES ELECTRIFIED MORTISE LOCKS
When Ordering: Specify design, hand and finish.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609 611
612 616 618 619
620 625 62916301693
SINGLE CYLINDER:
8890 Fail Safe $862.00 $886.00
8891 Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896 Fail Safe
$882.00 $906.00
8897 Fail Secure
8898 Fail Safe
8899 Fail Secure
DOUBLE CYLINDER:
8894-2 Fail Safe $932.00 $956.00
8895-2 Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2 Fail Safe
$952.00 $976.00
8897-2 Fail Secure
8898-2 Fail Safe
8899-2 Fail Secure
NO CYLINDER OVERRIDE:
8880 Fail Safe
$792.00 $816.00
8881 Fail Secure
8884 Fail Safe
8885 Fail Secure
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609 611
612 616 618 619
620 625 62916301693
SINGLE CYLINDER:
8890 Fail Safe $882.00 $906.00
8891 Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896 Fail Safe
$902.00 $926.00
8897 Fail Secure
8898 Fail Safe
8899 Fail Secure
DOUBLE CYLINDER:
8894-2 Fail Safe $952.00 $976.00
8895-2 Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2 Fail Safe
$972.00 $996.00
8897-2 Fail Secure
8898-2 Fail Safe
8899-2 Fail Secure
NO CYLINDER OVERRIDE:
8880 Fail Safe
$812.00 $836.00
8881 Fail Secure
8884 Fail Safe
8885 Fail Secure
KNOB DESIGNS: Copenhagen - CO
Litchfield - LF
ROSE DESIGN: Copenhagen - R
R3, R4, R5, R6, R7, R8
KNOB DESIGNS: Copenhagen - CO
Litchfield - LF
ESCUTCHEON DESIGN: Camden - CN
E3, E4
1. Knobs and Escutcheons are Nickel Plated to match Stainless Steel.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
65
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
FUNCTION LOCKBODY
MODEL # DESCRIPTION LIST PRICE
KNOBS:
8880 LBDY8880 Fail Safe
$591.00
8881 LBDY8881 Fail Secure
8884 LBDY8884 Fail Safe
8885 LBDY8885 Fail Secure
8890 LBDY8890 Fail Safe
8891 LBDY8891 Fail Secure
8894-2 LBDY8894 Fail Safe
8895-2 LBDY8895 Fail Secure
8896 LBDY8896 Fail Safe
$628.00
8896-2 LBDY8896 Fail Safe
8897 LBDY8897 Fail Secure
8897-2 LBDY8897 Fail Secure
8898 LBDY8898 Fail Safe
8898-2 LBDY8898 Fail Safe
8899 LBDY8899 Fail Secure
8899-2 LBDY8899 Fail Secure
FUNCTION LOCKBODY
MODEL # DESCRIPTION LIST PRICE
LEVERS:
8880FL LBDY8880FL Fail Safe
$591.00
8881FL LBDY8881FL Fail Secure
8884FL LBDY8884FL Fail Safe
8885FL LBDY8885FL Fail Secure
8890FL LBDY8890FL Fail Safe
8891FL LBDY8891FL Fail Secure
8894-2FL LBDY8894FL Fail Safe
8895-2FL LBDY8895FL Fail Secure
8896FL LBDY8896FL Fail Safe
$628.00
8896-2FL LBDY8896FL Fail Safe
8897FL LBDY8897FL Fail Secure
8897-2FL LBDY8897FL Fail Secure
8898FL LBDY8898FL Fail Safe
8898-2FL LBDY8898FL Fail Safe
8899FL LBDY8899FL Fail Secure
8899-2FL LBDY8899FL Fail Secure
ELECTRIFIED AND MECHANICAL OPTIONS:
LBM: SPDT switch that monitors full retraction of latchbolt (available option for electrified functions
only)
ADD
$212.00
DBM: SPDT switch that monitors full retraction of deadbolt
REX: SPDT switch that monitors activation of free lever $190.00
ITS: Integrated Total Security - Monitoring includes Request to Exit (REX), Lock Performance
Monitoring (LPM), Concealed Door Position Status (DPS), and Cylinder Monitoring (CX). Available
with 8890FL/8891FL only.*
$762.00
NOTE: Trim priced separately.
Armor Fronts and Strikes included with lockbodies only. Finish must be specified.
Cylinders are not furnished with lock bodies; cylinders must be ordered separately.
Limited quantities of armor fronts available for mortise locks shipped prior to March 2012. Contact factory for more information.
ELECTRIFIED MORTISE LOCK BODIES (WITH ARMOR FRONT AND STRIKE)
OPTION:
SL trim: ADD $386.00
See page 210 for power supplies and electrified accessories.
*Locksets ordered with ITS option must be provided with Yale cylinder. Not available less cylinder. Handing must be specified.
PART NUMBER USED WITH
PRODUCT
SHIPPED BETWEEN MARCH
2012 AND AUGUST 2014
PART NUMBER USED WITH
PRODUCT SHIPPED AFTER
AUGUST 2014
LOCK FUNCTION ALL FINISHES
ARMOR FRONT & STRIKE PACKS:
50-0010-8805-FIN 50-0020-8805-FIN 8880, 8881, 8884, 8885, 8890, 8891, 8892,
8893, 8894, 8894-2, 8895, 8895-2 $54.00
50-0010-8820-FIN 50-0020-8820-FIN 8896, 8896-2, 8897, 8897-2, 8898,
8898-2. 8899, 8899-2
MORTISE LOCK COMPONENTS AND OPTIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: Includes armor front and strike, finish must be specified.
66
DISTRIBUTOR LIST PRICES
SL8800FL SERIES SECURITY MORTISE LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify design, function and hand.
Security Locks are 50% off list only unless special factory quotation allowed.
1. Price Includes Hotel Indicator.
2. Levers are Nickel Plated to match Stainless Steel.
DESIGNS: Arcadia - ARSL Augusta - AUSL Carmel - CRSL Jefferson - JNSL
Monroe - MOSL Pacific Beach - PBSL Virginia - VISL
MODEL # PRODUCT DESCRIPTION 6302
SINGLE CYLINDER:
SL8805FL Storeroom or Closet
$885.00SL8807FL Entrance
SL8808FL Classroom
SL8809FL Classroom or Office with Thumbturn $895.00
SL8829FL Closet $885.00
SL8831FL Detention $970.00
SL8833FL Exit $885.00
SINGLE CYLINDER WITH DEADBOLT:
SL8822FL Dormitory
$905.00
SL8823FL Storeroom
SL8840FL Storeroom
SL8847FL Entrance or Apartment
SL8860FL Entrance or Storeroom
SL8861FL Dormitory or Storeroom
SL8867FL Dormitory or Exit
DOUBLE CYLINDER:
SL8808-2FL Classroom
$955.00SL8817-2FL Apartment, Exit or Public Toilet
SL8830-2FL Asylum
DOUBLE CYLINDER WITH DEADBOLT:
SL8811-2FL Classroom Deadbolt
$975.00
SL8812-2FL Classroom Security
SL8818-2FL Classroom Security Intruder
SL8860-2FL Entrance or Storeroom
HOTEL/MOTEL:
SL8820FL1Hotel/Motel $991.00
SL8827FL1Hotel/Motel
SL8832FL Hotel/Motel $970.00
NON-KEYED:
SL8801FL Passage $787.00
SL8802FL Privacy $835.00
SL8828FL Exit $787.00
SL8835FL Exit with Thumbturn $817.00
SL8862FL Bathroom $815.00
SL8865FL Bathroom with Thumbturn $825.00
DUMMY TRIM:
855FL Single $349.50
838AFL Pair $699.00
838BFL Pair (Strike available upon request) $724.00
8870FLDT Plain
$787.008871FLDT Latchbolt
8872FLDT Latchbolt x Deadbolt
67
DISTRIBUTOR LIST PRICES
SL8800FL SERIES SECURITY LOCK PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify design, function and hand.
MODEL # PRODUCT DESCRIPTION 630
LEVER HANDLE WITH SPINDLE (two required per lock):
ARSL904 (specify hand)
$260.00
AUSL904
CRSL904
JNSL904
MOSL904
PBSL904
VISL904
ESCUTCHEON PLATES:
SL87 I/S $117.00
SL88 O/S
NOTE: Cylinders are not furnished with lock bodies. Cylinder must be ordered separately.
NOTE: When ordering escutcheons separately, specify the model number of the escutcheon plate suffixed with the
spacing number. The spacing number indicates the hole preparation in the escutcheon plate to coordinate with
the lock functions. See page 58 for spacing numbers.
FUNCTION LOCKBODY MODEL # 630
MORTISE LOCK BODIES (WITH ARMOR FRONT & STRIKE):
SL8801FL LBDYSL8801 $360.00
SL8802FL LBDYSL8802 $469.00
SL8805FL LBDYSL8805
$436.00
SL8807FL LBDYSL8807
SL8808FL LBDYSL8808
SL8809FL LBDYSL8809
SL8820FL LBDYSL8820
$469.00
SL8822FL LBDYSL8822
SL8823FL LBDYSL8823
SL8827FL LBDYSL8827
SL8832FL LBDYSL8832
SL8835FL LBDYSL8835
SL8840FL LBDYSL8840
SL8847FL LBDYSL8847
SL8828FL LBDYSL8828 $363.00
SL8829FL LBDYSL8829 $436.00
SL8831FL LBDYSL8831
$469.00
SL8860FL LBDYSL8860
SL8861FL LBDYSL8861
SL8862FL LBDYSL8862
SL8865FL LBDYSL8865
SL8867FL LBDYSL8867
SL8808-2FL LBDYSL8808
SL8811-2FL LBDYSL8811 $436.00
SL8812-2FL LBDYSL8812 $469.00
SL8817-2FL LBDYSL8817 $436.00
SL8818-2FL LBDYSL8818 $469.00
SL8830-2FL LBDYSL8830 $436.00
SL8860-2FL LBDYSL8860 $469.00
68
DISTRIBUTOR LIST PRICES
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
BRONZE:
611 Bright Bronze, Clear Coated
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
N/A US10BL Dark Oxidized Satin Bronze,
Clear Coated
N/A US20D Statuary Dark Bronze, Clear
Coated
1. Yale finishes are designated by ANSI/BHMA codes. There is not equivalent designation for US10BL and US20D and requests will be processed by special order.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
NICKEL:
618 Bright Nickel Plated, Clear Coated
619 Satin Nickel Plated, Clear Coated
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
PAINTED:
BSP Black Suede Powder Coat
PRODUCT DESCRIPTION DEDUCT ADD
LESS CYLINDER: (Specify "x LC")
Cylinder rings/collars not furnished with locksets ordered less cylinders. $70.00 —
IC Housing ordered with locksets — $0.00
7-PIN CYLINDERS:
Add to 6-Pin cylinder — $2.00
INTERCHANGEABLE CORE CYLINDERS:
2196 - LFIC 6-Pin (Includes MK or GMK)
Ordering Example: TBR3-8807FL x 2196 x RH x 605 — $58.00
2196H - LFIC Hotel Lock (Includes MK or GMK and EMK) — $138.00
A620 - SFIC 6-or 7-Pin (Includes MK or GMK)
Ordering Example: TBR3-8807 x A620 x RH x 626 — $50.00
SPECIAL STRIKES:
Strikes with lip lengths other than 1-1/8" or 1-1/4" — $13.00
DOORS 1-7/8" THICK TO 3-1/4" THICK:
Non-keyed — $103.00
Single cylinder keyed — $162.00
Double cylinder keyed — $181.00
MICROSHIELD®:Antimicrobial coating. Specify option "YMS". — $65.00
KNURLING: Not available –– ––
REFLECTION LEVERS: The following levers are no longer available in 629 and 630
finishes, TT, TU, TV, TW, TX, TY, UW, UX, TZ, TG, TJ, TK, TO, TE, TI and TD. — —
REFLECTIONS®SERIES MORTISE VARIATIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
69
DISTRIBUTOR LIST PRICES
8800RL SERIES MORTISE LOCKS
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, TY, UW, TX, UX, TZ
Niagara: MA, RA, RB, RC
ROSE DESIGNS: R3, R4, R5, R6, R7, R8
Copenhagen - R
1. Price includes Hotel indicator.
2. See the Variations page for details.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 611
612 618 619
625 62926302
US10BL US20D
SINGLE CYLINDER:
8805RL Storeroom or Closet
$774.00 $798.008807RL Entrance
8808RL Classroom
8809RL Classroom or Office with Thumbturn $784.00 $808.00
8824RL Hold Back
$774.00 $798.00
8829RL Closet
8833RL Exit
8834RL All Purpose
8864RL Bathroom with Indicator $874.00 $898.00
SINGLE CYLINDER WITH DEADBOLT:
8822RL Dormitory
$794.00 $818.00
8823RL Storeroom
8840RL Storeroom
8847RL Entrance or Apartment
8860RL Entrance or Storeroom
8861RL Dormitory or Storeroom
8867RL Dormitory or Exit
DOUBLE CYLINDER:
8808-2RL Classroom
$844.00 $868.00
8817-2RL Apartment, Exit or Public Toilet
8830-2RL Asylum
8834-2RL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2RL Classroom Deadbolt
$864.00 $888.00
8812-2RL Classroom Security
8818-2RL Classroom Security Intruder
8860-2RL Entrance or Storeroom
HOTEL/MOTEL:
8820RL1Hotel/Motel $880.00 $904.00
8827RL1Hotel/Motel
8832RL Hotel/Motel $859.00 $883.00
NON-KEYED:
8801RL Passage $676.00 $700.00
8802RL Privacy $724.00 $748.00
8828RL Exit $676.00 $700.00
8835RL Exit with Thumbturn $706.00 $730.00
8862RL Bathroom $704.00 $728.00
8865RL Bathroom with Thumbturn $714.00 $738.00
DUMMY TRIM:
855RL Single $294.00 $306.00
838ARL Pair $588.00 $612.00
838BRL Pair (Strike available upon request) $613.00 $637.00
8870RLDT Plain
$676.00 $700.008871RLDT Latchbolt
8872RLDT Latchbolt x Deadbolt
Effective Date: May 1, 2018
Canada Effective July 3, 2018
70
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
8800RL SERIES MORTISE LOCKS
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, TY, UW, TX, UX, TZ
Niagara: MA, RA, RB, RC
ESCUTCHEON DESIGNS: E3, E4, CN
1. Price includes Hotel indicator.
2. See the Variaions page for details.
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 611 612
618 619 625
62926302
US10BL US20D
SINGLE CYLINDER:
8805RL Storeroom or Closet
$794.00 $818.008807RL Entrance
8808RL Classroom
8809RL Classroom or Office with Thumbturn $804.00 $828.00
8824RL Hold Back
$794.00 $818.00
8829RL Closet
8833RL Exit
8834RL All Purpose
8864RL Bathroom with Indicator $894.00 $918.00
SINGLE CYLINDER WITH DEADBOLT:
8822RL Dormitory
$814.00 $838.00
8823RL Storeroom
8840RL Storeroom
8847RL Entrance or Apartment
8860RL Entrance or Storeroom
8861RL Dormitory or Storeroom
8867RL Dormitory or Exit
DOUBLE CYLINDER:
8808-2RL Classroom
$864.00 $888.00
8817-2RL Apartment, Exit or Public Toilet
8830-2RL Asylum
8834-2RL All Purpose
DOUBLE CYLINDER WITH DEADBOLT:
8811-2RL Classroom Deadbolt
$884.00 $908.00
8812-2RL Classroom Security
8818-2RL Classroom Security Intruder
8860-2RL Entrance or Storeroom
HOTEL/MOTEL:
8820RL1Hotel/Motel $900.00 $924.00
8827RL1Hotel/Motel
8832RL Hotel/Motel $879.00 $903.00
NON-KEYED:
8801RL Passage $696.00 $720.00
8802RL Privacy $744.00 $768.00
8828RL Exit $696.00 $720.00
8835RL Exit with Thumbturn $726.00 $750.00
8862RL Bathroom $724.00 $748.00
8865RL Bathroom with Thumbturn $734.00 $758.00
DUMMY TRIM:
855RL Single $304.00 $316.00
838ARL Pair $608.00 $632.00
838BRL Pair (Strike available upon request) $633.00 $657.00
8870RLDT Plain
$696.00 $720.008871RLDT Latchbolt
8872RLDT Latchbolt x Deadbolt
71
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
8800RL SERIES MORTISE LOCK PARTS
NOTE: Trim priced separately.
Armor Fronts and Strikes are included with lockbodies only.
Finish must be specified.
Cylinders are not furnished with lock bodies; cylinders must be
ordered separately.
Limited quantities of armor fronts available for mortise locks
shipped prior to March 2012. Contact factory for more
information.
FUNCTION LOCKBODY MODEL # LIST PRICE
LEVERS:
8801RL LBDY8801RL $360.00
8802RL LBDY8802RL $469.00
8805RL LBDY8805RL
$436.00
8807RL LBDY8807RL
8808RL LBDY8808RL
8809RL LBDY8809RL
8864RL LBDY8864RL
8808-2RL LBDY8808RL
8811-2RL LBDY8811RL $436.00
8812-2RL LBDY8812RL
8817-2RL LBDY8817RL $436.00
8818-2RL LBDY8818RL
$469.00
8820RL LBDY8820RL
8822RL LBDY8822RL
8823RL LBDY8823RL
8824RL LBDY8824RL
8827RL LBDY8827RL
8832RL LBDY8832RL
8835RL LBDY8835RL
8840RL LBDY8840RL
8847RL LBDY8847RL
MORTISE LOCK BODIES (WITH ARMOR FRONT AND STRIKE)
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, TY, UW, TX, UX, TZ
Niagara: MA, RA, RB, RC
ROSE DESIGNS: R3, R4, R5, R6, R7, R8, Copenhagen - R
ESCUTCHEON DESIGNS: E3, E4, CN
PRODUCT CODE PRODUCT DESCRIPTION 613E 626
BSP
605 606 611 612 618
619 625 629 630
US10BL US20D
LEVERS WITH ROSES:
Specify lever design x rose design Specify lock function $612.00 $636.00
LEVERS WITH ESCUTCHEONS:
Specify lever design x escutcheon design Specify lock function $632.00 $656.00
FUNCTION LOCKBODY MODEL # LIST PRICE
LEVERS:
8828RL LBDY8828RL $363.00
8829RL LBDY8829RL $436.00
8830-2RL LBDY8830RL $436.00
8833RL LBDY8833RL
$436.008834RL LBDY8834RL
8834-2RL LBDY8834RL
8860RL LBDY8860RL
$469.00
8860-2RL LBDY8860RL
8861RL LBDY8861RL
8862RL LBDY8862RL
$469.008865RL LBDY8865RL
8867RL LBDY8867RL
REFLECTIONS®TRIM PACKS
8800RL lockbodies are ONLY for use with Reflections®levers shipped BEFORE October 2011. For use with Reflections trim
shipped after this date, please see page 56 for lockbodies.
PART NUMBER USED WITH
PRODUCT
SHIPPED BETWEEN MARCH
2012 AND AUGUST 2014
PART NUMBER USED WITH
PRODUCT SHIPPED AFTER
AUGUST 2014
LOCK FUNCTION ALL FINISHES
ARMOR FRONT & STRIKE PACKS:
50-0010-8801-FIN 50-0020-8801-FIN 8801, 8862, 8865
$54.00
50-0010-8802-FIN 50-0020-8802-FIN 8802, 8811, 8822, 8823, 8860, 8861
50-0010-8805-FIN 50-0020-8805-FIN 8805, 8808, 8809, 8817, 8824, 8828, 8829,
8830, 8833, 8834, 8834-2, 8864
50-0010-8807-FIN 50-0020-8807-FIN 8807
50-0010-8813-FIN 50-0020-8813-FIN 8813, 8814, 8815
50-0010-8820-FIN 50-0020-8820-FIN 8812, 8818, 8820, 8831, 8832, 8835
50-0010-8847-FIN 50-0020-8847-FIN 8827, 8847
50-0010-8867-FIN 50-0020-8867-FIN 8867
72
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
REFLECTIONS®TRIM PARTS
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 611 612
618 619 625 62916301
US10BL US20D
LEVER ASSEMBLY - OUTSIDE:
Design x 904 Specify Lever Design x 904 x Hand
Ordering Example: TB904 x RH $151.00 $175.00
LEVER ASSEMBLY - INSIDE:
Design x 905 Specify Lever Design x 905 x Hand
Ordering Example: TB905 x RH $151.00 $175.00
ROSE ASSEMBLIES:
R3-505 Inside
$71.00 $95.00
R3-506 Outside
R4-505 Inside
R4-506 Outside
R5-505 Inside
R5-506 Outside
R6-505 Inside
R6-506 Outside
R7-505 Inside
R7-506 Outside
R8-505 Inside
R8-506 Outside
ESCUTCHEON PLATES:
E3-88 Outside
$225.00 $249.00
E3-87 Inside
E4-88 Outside
E4-87 Inside
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, TY, UW, TX, UX, TZ
Niagara: MA, RA, RB, RC
ROSE DESIGNS: R3, R4, R5, R6, R7, R8
ESCUTCHEON DESIGNS: E3, E4
NOTE: When ordering escutcheons separately, specify the model number of the escutcheon plate suffixed with the spacing number. The
spacing number indicates the hole preparation in the escutcheon plate to coordinate with the lock functions.
See page 58 for escutcheon plate numbers.
1. See the Variations page for details.
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
73
8800RL SERIES ELECTRIFIED MORTISE LOCKS
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, UW, TX, TY, UX, TZ
Niagara: MA, RA, RB, RC
ROSE DESIGNS: R3, R4, R5, R6, R7, R8, Copenhagen - R
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, UW, TX, TY, UX, TZ
Niagara: MA, RA, RB, RC
ESCUTCHEON DESIGNS: E3, E4, CN
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 611 612 618
619 625 62916301
US10BL US20D
SINGLE CYLINDER:
8890RL Fail Safe $1,012.00 $1,036.00
8891RL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896RL Fail Safe
$1,032.00 $1,056.00
8897RL Fail Secure
8898RL Fail Safe
8899RL Fail Secure
DOUBLE CYLINDER:
8894-2RL Fail Safe $1,082.00 $1,106.00
8895-2RL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2RL Fail Safe
$1,102.00 $1,126.00
8897-2RL Fail Secure
8898-2RL Fail Safe
8899-2RL Fail Secure
NO CYLINDER OVERRIDE:
8880RL Fail Safe
$942.00 $966.00
8881RL Fail Secure
8884RL Fail Safe
8885RL Fail Secure
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 611 612 618
619 625 62916301
US10BL US20D
SINGLE CYLINDER:
8890RL Fail Safe $992.00 $1,016.00
8891RL Fail Secure
SINGLE CYLINDER WITH DEADBOLT:
8896RL Fail Safe
$1,012.00 $1,036.00
8897RL Fail Secure
8898RL Fail Safe
8899RL Fail Secure
DOUBLE CYLINDER:
8894-2RL Fail Safe $1,062.00 $1,086.00
8895-2RL Fail Secure
DOUBLE CYLINDER WITH DEADBOLT:
8896-2RL Fail Safe
$1,082.00 $1,106.00
8897-2RL Fail Secure
8898-2RL Fail Safe
8899-2RL Fail Secure
NO CYLINDER OVERRIDE:
8880RL Fail Safe
$922.00 $946.00
8881RL Fail Secure
8884RL Fail Safe
8885RL Fail Secure
1. See the Variations page for details.
74
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
ELECTRIFIED LOCK BODIES
FUNCTION LOCKBODY MODEL # DESCRIPTION LIST PRICE
LEVERS:
8880RL LBDY8880RL Fail Safe
$591.00
8881RL LBDY8881RL Fail Secure
8884RL LBDY8884RL Fail Safe
8885RL LBDY8885RL Fail Secure
8890RL LBDY8890RL Fail Safe
8891RL LBDY8891RL Fail Secure
8894-2RL LBDY8894RL Fail Safe
8895-2RL LBDY8895RL Fail Secure
8896RL LBDY8896RL Fail Safe
$628.00
8896-2RL LBDY8896RL Fail Safe
8897RL LBDY8897RL Fail Secure
8897-2RL LBDY8897RL Fail Secure
8898RL LBDY8898RL Fail Safe
8898-2RL LBDY8898RL Fail Safe
8899RL LBDY8899RL Fail Secure
8899-2RL LBDY8899RL Fail Secure
ELECTRIFIED AND MECHANICAL OPTIONS:
LBM: SPDT switch that monitors full retraction of latchbolt (available option for electrified functions
only)
ADD
$212.00
DBM: SPDT switch that monitors full retraction of deadbolt
REX: SPDT switch that monitors activation of free lever $190.00
ITS: Integrated Total Security - Monitoring includes Request to Exit (REX), Lock Performance
Monitoring (LPM), Concealed Door Position Status (DPS), and Cylinder Monitoring (CX). Available
with 8890RL/8891RL only.*
$762.00
NOTE: Trim priced separately.
Armor Fronts and Strikes included with lockbodies only. Finish must be specified.
Cylinders are not furnished with lock bodies; cylinders must be ordered separately.
Limited quantities of armor fronts available for mortise locks shipped prior to March 2012. Contact factory for more information.
NOTE: See page 210 for power supplies and electrified accessories.
*Locksets ordered with ITS option must be provided with Yale cylinder. Not available less cylinder. Handing must be specified.
8800RL electrified lockbodies are ONLY for use with Reflections®levers shipped BEFORE October 2011. For use with
Reflections trim shipped after this date, please see page 65 for lockbodies.
PART NUMBER USED WITH
PRODUCT
SHIPPED BETWEEN MARCH
2012 AND AUGUST 2014
PART NUMBER USED WITH
PRODUCT SHIPPED AFTER
AUGUST 2014
LOCK FUNCTION ALL FINISHES
ARMOR FRONT & STRIKE PACKS:
50-0010-8805-FIN 50-0020-8805-FIN 8880, 8881, 8884, 8885, 8890, 8891, 8892,
8893, 8894, 8894-2, 8895, 8895-2 $54.00
50-0010-8820-FIN 50-0020-8820-FIN 8896, 8896-2, 8897, 8897-2, 8898,
8898-2. 8899, 8899-2
75
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
5400LN SERIES GRADE 1 LEVER LOCKS VARIATIONS
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
NICKEL:
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin
Relieved, Clear Coated
PAINTED:
693 Black Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated
BRONZE:
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened, Satin Relieved,
Clear Coated
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide a sample.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
Note: Security and Yale®KeyMark®Cylinders: see page 78 for pricing. These cylinders are priced and discounted separately.
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: AU5407LN x LC $62.00 —
Large format interchangeable core prep less core, for 6-pin, specify "x ICLC"
Ordering Example: AU5407LN x ICLC $0.00 $0.00
7-PIN CYLINDERS AND LFIC CORES:
Add to 6-Pin cylinder/core — $2.00
INTERCHANGEABLE CORES:
1210 – LFIC 6-Pin (includes MK or GMK)
Ordering Example: AU5407LN x 1210 x 626 — $58.00
A600 Best®Keyway SFIC 6-or 7-Pin (includes MK or GMK)
Ordering Example: B-AU5407LN x A600 — $50.00
NOTE: 5421LN, 5429LN, 5430LN, 5439LN Not Available with IC Cores.
CYLINDER OPTIONS: (See Page 77 for Ordering Examples)
Lockset with SFIC Core Prep (less core) $0.00 $0.00
Lockset with Medeco®/ASSA®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®Standard Cylinder Prep (less cylinder) $25.00 $0.00
Lockset with Schlage®" C" Keyway Cylinder (specify cylinder model number 2802) $0.00 $0.00
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent®"LA" or
Schlage®"E" Keyway Cylinder. (specify cylinder model number 3804 x keyway) $0.00 $15.00
SPECIAL STRIKES:
ANSI Strike 497 with 1 -1/8", 1-1/2" or 1-3/4" lip — $13.00
371 Strike with 1", 1-1/2", 1-3/4" or 2" Lip with Box — $2.00
SPLIT FINISHES: Higher List Price Applies
LEAD SHIELDED: — $181.00
KNURLING:
Outside or Inside Only –– $75.00
Both Sides –– $150.00
ABRASIVE COATING:
Outside or Inside Only –– $46.00
Both Sides –– $92.00
DOORS 1-3/4" THICK: — STD
DOORS 1-3/8" THICK: — $31.00
DOORS 2-1/4" THICK: — $4.00
FLUSH TURN BUTTON: Available for 5425LN Function only. Suffix "FTB" $0.00 $0.00
LOCKSET TO MEET FEMA 320: Suffix “TD”
Ordering Example: AU5407LN x TD x 626 $0.00 $0.00
MICROSHIELD®:Antimicrobial coating. Specify option "YMS". — $65.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
76
DESIGNS: Augusta - AU Monroe - MO Pacific Beach - PB
DISTRIBUTOR LIST PRICES
5400LN SERIES HEAVY-DUTY CYLINDRICAL LOCKS
MODEL # PRODUCT DESCRIPTION 613E 626 BSP
605 606 609
612 616 619
620 625 693
SINGLE CYLINDER:
5404LN Entry
$569.00 $585.00
5405LN Storeroom or Closet
5406LN Service Station
5407LN Entry
5408LN Classroom
5422LN Corridor
5429LN Communicating Classroom
5439LN Communicating Storeroom
DOUBLE CYLINDER:
5417LN Apartment, Exit or Public Toilet
$631.00 $647.00
5418LN Intruder Classroom Security
5421LN Communicating
5430LN Utility, Asylum or Institutional
NON-KEYED LATCHSETS:
5401LN Passage or Closet $458.00 $474.00
5402LN Privacy, Bedroom or Bath
$506.00 $522.00
5403LN Patio or Privacy
5409LN Exit Latch
5425LN Privacy
5428LN Communicating Passage $458.00 $474.00
DUMMY TRIM:
455LN Single Dummy Trim $279.00 $287.00
455LN-D Double Dummy Trim $558.00 $574.00
When Ordering: Specify design, function and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CASE LOT: 10
SHIPPING WEIGHT: 6 Lbs. per lock
NOTE: See following page for optional cylinder preps, optional IC Core preps, and optional cylinders furnished with locks.
77
DESIGNS: Augusta - AU Monroe - MO Pacific Beach - PB
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, function and finish.
ELECTRIFIED 5400LN SERIES HEAVY-DUTY CYLINDRICAL LOCKS
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 609
612 616 619
620 625 693
CYLINDER OVERRIDE:
5490LN Fail Safe $787.00 $803.00
5491LN Fail Secure
NO CYLINDER OVERRIDE:
5480LN Fail Safe $725.00 $741.00
5481LN Fail Secure
LOCKBODIES:
5480LN Fail Safe
$586.00 $602.00
5481LN Fail Secure
5490LN Fail Safe
5491LN Fail Secure
OPTIONS
MODEL # PRODUCT DESCRIPTION LIST PRICE
REX
(Request to Exit)
SPDT switch that monitors activation of inside lever (ordered with lock)
Example: 5490LN x REX $190.00
REX
Retrofit Kit
SPDT switch that monitors activation of inside lever (used with existing 5400LN
locks, lock function must be specified when ordering.)
Example: REX Retrofit Kit for 5405LN
Part Number: 81-9500-1651-000
$137.00
CASE LOT: 10
SHIPPING WEIGHT: 6 Lbs. per lock
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Note: See page 210 for power supplies and electrified accessories.
SFIC Core Prep: prefix "B" to trim designation. Accepts all SFIC cores, 6- or 7-Pin.
Example: B-AU5407LN x Less Core.
Medeco®/ASSA®IC Core Prep: prefix "M" to trim designation. Not Available with MO or PB Levers. 6-Pin only.
Example: M-AU5407LN x Less Core.
Schlage®IC Core Prep: prefix "SI" to trim designation. 6-Pin only.
Example: SI-AU5407LN x Less Core.
Schlage®Standard Cylinder Prep: prefix "S" to trim designation. 6-Pin only.
Example: S-AU5407LN x Less Cylinder.
Lockset with Sargent®"LA" Keyway Cylinder. 6-Pin only.
Example: AU5407LN x 3804.
Lockset with Schlage®"C" Keyway Cylinder. 6-Pin only.
Example: AU5407LN x 2802.
78
DISTRIBUTOR LIST PRICES
5400LN SERIES HEAVY-DUTY CYLINDRICAL LOCK PARTS
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
PLAIN LATCHBOLTS:
693 Beveled, 2-3/4" Backset, 1/2" Throw $70.00 STD
F693 Flat, 2-3/4" Backset, 1/2" Throw N/C
3693 Beveled, 3-3/4" Backset, 1/2" Throw $77.00 $6.00
DEADLOCKING LATCHBOLTS:
694 Beveled, 2-3/4" Backset, 1/2" Throw $92.00 STD
F694 Flat, 2-3/4" Backset, 1/2" Throw N/C
3694 Beveled, 3-3/4" Backset, 1/2" Throw $102.00 $10.00
480B Beveled, 2-3/4" Backset, 3/4" Throw $173.00 $81.00
F480B Flat, 2-3/4" Backset, 3/4" Throw
3480B Beveled, 3-3/4" Backset, 3/4" Throw $182.00 $90.00
BACKSET LINKS:
481 Extension Link $47.00 $47.00
481DL Extension Link (use with deadlocking latchbolts)
482 Extension Link $64.00 $64.00
484 Extension Link $141.00 $141.00
STRIKES:
371 Strike 1-1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike 1-1/4" Lip $37.00 NC
497 ANSI Strike 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
497B Blank ANSI Strike 1-1/8" Lip $37.00 —
202 Strike Box (not plated) $2.00 $2.00
When Ordering: Specify finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
CYLINDERS:
1802 Standard Cylinder 6-Pin $62.00 N/C
1802S Standard Inside Cylinder 6-Pin for 5417LN Function
1802A Standard Cylinder 7-Pin $64.00 $2.00
5802 Security Cylinder 6-Pin $246.00 $184.00
5802A Security Cylinder 7-Pin $250.00 $188.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
1220 Large Format Interchangeable Core Only 7-Pin $60.00 $60.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
5220 Security Large Format Interchangeable Core Only 7-Pin $230.00 $230.00
K402 Yale®KeyMark®Cylinder $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-or 7-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $62.00 N/C
3804 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $77.00 $15.00
107S Schlage®Cylinder Adapter Kit $18.50 $18.50
79
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
5400LN SERIES HEAVY-DUTY CYLINDRICAL LOCK PARTS
DESCRIPTION FUNCTIONS AU MO PB
LEVERS ONLY:
Plain Inside 01, 05, 08, 09,
28, 455LN 14-5401-6063 14-5401-6064 14-5401-6062
Plain Outside 01 14-5401-6063 14-5401-6064 14-5401-6062
Privacy Outside 02 14-5402-6025 14-5402-6024 14-5402-6023
Cylinder std 6 or 7 pin 04, 05, 06, 07, 08, 17,
18, 21, 22, 29, 30 14-5407-6038 14-5407-6042 14-5407-6062
Button 02, 03, 06, 07, 22, 25 14-5407-6038 14-5407-6042 14-5407-6062
I/S Yale®IC 6-Pin 17, 18 14-5417-6021 14-5417-6030 14-5417-6040
I/S Yale®IC 7-Pin 17, 18 14-5417-6022 14-5417-6031 14-5417-6041
I/S SFIC 6- or 7-Pin 17, 18 14-5417-6029 14-5417-6032 14-5417-6042
I/S Schlage®IC 6-Pin 17, 18 14-5417-6059 14-5417-6061 14-5417-6060
I/S Medeco®/ASSA®IC 17, 18 14-5417-6023 N/A N/A
DESCRIPTION FUNCTIONS AU MO PB
LEVER ASSEMBLIES:
Plain O/S Security 03, 09 14-5403-0051 14-5403-0052 14-5403-0053
O/S Yale®IC 6-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0076 14-5407-0019 14-5407-0030
O/S Yale®IC 7-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0077 14-5407-0021 14-5407-0031
O/S SFIC 6- or 7-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0040 14-5407-0041 14-5407-0042
O/S Schlage®IC 6-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0904 14-5407-6209 14-5407-0905
O/S Medeco®/ASSA®IC 6-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0078 N/A N/A
PRODUCT DESCRIPTION ALL FINISHES
ALL LEVERS $107.00
PRODUCT DESCRIPTION ALL FINISHES
ALL LEVER ASSEMBLIES $132.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
80
DISTRIBUTOR LIST PRICES
5400LN SERIES HEAVY-DUTY CYLINDRICAL LOCK PARTS
MODEL # PRODUCT DESCRIPTION PART NUMBER ALL FINISHES
LOCKBODIES: (specify finish)
5401LN Passage or Closet 14-5401-0914 $97.00
5402LN Privacy, Bedroom or Bath 14-5402-0902 $113.00
5403LN Patio or Privacy 14-5402-0902
5404LN Entry 14-5404-0528
$141.00
5405LN Storeroom or Closet 14-5405-0901
5406LN Service Station 14-5406-0402
5407LN Entry 14-5407-0902
5408LN Classroom 14-5408-0901
5409LN Exit Latch 14-5405-0901 $113.00
5417LN Apartment, Exit or Public Toilet 14-5417-0902
$161.005418LN Intruder Classroom Security 14-5418-0902
5421LN Communicating 14-5421-0901
5422LN Corridor 14-5422-0902 $141.00
5425LN Privacy 14-5425-0114 $113.00
5428LN Communicating Passage 14-5428-0111 $97.00
5429LN Communicating Classroom 14-5429-0007 $141.00
5430LN Utility, Asylum or Institutional 14-5430-0901 $161.00
5439LN Communicating Storeroom 14-5439-0001 $141.00
PRODUCT DESCRIPTION PART NUMBER NO FINISH
MISCELLANEOUS PARTS:
Rose Scalp 14-5401-2711-(specify finish) $24.70
Spacers for 1-3/8" Door - Available only in sets 00-0000-1661-000 $31.00
Inside Rose and Shank Assembly 14-5401-0655-048 $36.70
Outside Rose and Shank Assembly 14-5407-0108-048 $42.40
Through Bolts (price each - 2 required) 81-0011-0588-036 $2.80
Retainer Spring Pad 14-5407-9034-999 $2.40
Blank Rose Assembly 14-5401-0909-000 $48.50
Dummy Rose Assembly 14-5455-0081-048 $34.40
Screw Pack for ANSI Strike and Latch 81-9400-0038-(specify finish) $2.40
Screw Pack for "T" Strike and Latch 81-9400-0009-(specify finish)
When Ordering: Specify finish where noted.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
81
DISTRIBUTOR LIST PRICES
5400CK SERIES GRADE 1 KNOB LOCKS VARIATIONS
When Ordering: Specify finish where noted.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
BRONZE:
613E Dark Oxidized Satin Bronze - equivalent
PRODUCT OPTION DEDUCT ADD
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: CA5407CK x LC $62.00 —
INTERCHANGEABLE CORES:
A600 Best®Keyway SFIC 6-or 7-Pin (includes MK or GMK)
Ordering Example: B-CA5407CK x A600 — $50.00
CYLINDER OPTION:
Lockset with SFIC Core Prep (less core) Carolina (CA) Knob only. — $0.00
SPECIAL STRIKES:
ANSI Strike 497 with 1 1/8", 1 1/2" or 1 3/4" lip — $13.00
371 Strike 1-1/4" Lip with Box — N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box — $2.00
SPLIT FINISHES: Not available
KNURLING: Not available
ABRASIVE COATING: Not available
MICROSHIELD®:Not available
ANSI/BHMA
CODE FINISH DESCRIPTION
STAINLESS STEEL:
630 Satin Stainless Steel
82
DISTRIBUTOR LIST PRICES
5400CK SERIES HEAVY-DUTY CYLINDRICAL LOCKSETS
When Ordering: Specify design, function and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DESIGNS: Carolina - CA
MODEL # PRODUCT DESCRIPTION 605 613E
630
SINGLE CYLINDER:
5405CK Storeroom or Closet
$481.005407CK Entry
5408CK Classroom
DOUBLE CYLINDER:
5430CK Utility, Asylum or Institutional $543.00
NON-KEYED LATCHSETS:
5401CK Passage or Closet $380.00
5402CK Privacy, Bedroom or Bath $383.00
DUMMY TRIM:
5455CK Single Dummy Trim $206.00
CASE LOT: 10
SHIPPING WEIGHT: Approx. 3 Lbs. per lock
SFIC Core Prep: prefix "B" to trim designation, 6- or 7-Pin.
Example: B-CA5407CK x Less Core.
83
DISTRIBUTOR LIST PRICES
5400CK SERIES HEAVY-DUTY CYLINDRICAL LOCK PARTS
When Ordering: Specify finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
PLAIN LATCHBOLTS:
693A Universal, 2-3/4" Backset, 1/2" Throw $69.00 STD
DEADLOCKING LATCHBOLTS:
694A Universal, 2-3/4" Backset, 1/2" Throw $83.00 STD
STRIKES:
371 Strike 1-1/4" Lip with Box (Optional) $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box (Optional) $14.00 $2.00
497 ANSI Strike 1-1/4" Lip $37.00 NC
497 ANSI Strike 1-1/2" or 1-3/4" Lip Length $44.00 $13.00
497B ANSI Blank Strike (Optional) $37.00 —
202 Strike Box (not plated) $2.00 $2.00
MISCELLANEOUS:
81-0022-0420 #8-32 x 1" Phillips flat head machine screw (specify finish) $1.00 $1.00
81-2012-0416 #8-8-32 x 3/4" Phillips flat head combination screw pack (specify finish)
$2.00 $2.0081-2022-0416 #8-8-32 x 3/4" Phillips flat head combination screw pack (specify finish)
81-2012-0620 #12-12-24 x 1" Phillips flat head combination screw pack (specify finish)
14-5400-0608 Screw pack (includes latchbolt, strike and through bolt screws) Specify finish $5.30 $5.30
14-5400-0610-999 SFIC Tailpiece Kit (includes tailpiece plus spacer for 6-pin) $18.10 $18.10
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
CYLINDER X TAILPIECE:
1803-54K Standard Cylinder 6-Pin $62.00 N/C
5803-54K Security Cylinder 6-Pin $246.00 $184.00
K403-54K Yale®KeyMark®Cylinder $78.00 $78.00
K600 Yale®KeyMark®Cylinder Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
84
DISTRIBUTOR LIST PRICES
When Ordering: Specify design and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
85
DISTRIBUTOR LIST PRICES
5300LN SERIES GRADE 2 LEVER LOCKS VARIATIONS
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
NICKEL:
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin
Relieved, Clear Coated
PAINTED:
693 Black Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated
BRONZE:
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened, Satin Relieved,
Clear Coated
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide a sample.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: AU5307LN x LC $62.00 —
Large format interchangeable core prep less core, for 6-pin, specify "x ICLC"
Ordering Example: AU5307LN x ICLC $0.00 $0.00
CYLINDERS AND LFIC CORES: 6-Pin only
INTERCHANGEABLE CORES:
1210 – LFIC 6-Pin (includes MK or GMK)
Ordering Example: AU5307LN x 1210 x 626 — $58.00
A600 Best®Keyway SFIC 6-or 7-Pin (includes MK or GMK)
Ordering Example: B-AU5307LN x A600 — $50.00
NOTE: 5318LN, 5321LN, 5329LN, 5330LN, 5339LN not available with IC Cores.
CYLINDER OPTIONS: (See page 87 for ordering example)
Lockset with SFIC Core Prep (less core) $0.00 $0.00
Lockset with Medeco®/ASSA®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®Standard Cylinder Prep (less cylinder) $25.00 $0.00
Lockset with Schlage®"C"Keyway Cylinder (specify cylinder model number 2802) $0.00 $0.00
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent®"LA" or
Schlage®"E" Keyway Cylinder. (specify cylinder model number 3804 x keyway) $0.00 $15.00
SPECIAL STRIKES:
ANSI Strike 497 with 1-1/8", 1-1/2" or 1-3/4" lip — $13.00
SPLIT FINISHES: Higher List Price Applies
KNURLING: Available for all levers in 613E, 626 and BSP finishes only
Outside or Inside Only –– $75.00
Both Sides –– $150.00
ABRASIVE COATING:
Outside or Inside Only –– $46.00
Both Sides –– $92.00
DOORS 1-3/4" THICK: Adjustable to 2" Thick — STD
DOORS 1-3/8" OR 2-1/4" THICK: — $4.00
FLUSH TURN BUTTON: Available for 5325LN Function only. Suffix "FTB" $0.00 $0.00
MICROSHIELD®:Antimicrobial coating. Specify "YMS". — $65.00
When Ordering: Specify design and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Note: Security and Yale®KeyMark®Cylinders: see page 88 for pricing. These cylinders are priced and discounted separately.
86
DESIGNS: Augusta - AU Pacific Beach - PB Monroe - MO
DISTRIBUTOR LIST PRICES
5300LN SERIES CYLINDRICAL LEVER LOCKS
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 609
612 616 619
620 625 693
SINGLE CYLINDER:
5304LN Entry
$275.00 $291.00
5305LN Storeroom or Closet
5306LN Service Station
5307LN Entry
5308LN Classroom
5322LN Corridor
5329LN Communicating Classroom
5339LN Communicating Storeroom
DOUBLE CYLINDER:
5318LN Intruder Classroom Security
$334.00 $350.005321LN Communicating
5330LN Utility, Asylum or Institutional
NON-KEY LATCHSETS:
5301LN Passage or Closet $204.00 $220.00
5302LN Privacy, Bedroom or Bath
$226.00 $242.00
5303LN Patio or Privacy
5309LN Exit Latch
5325LN Privacy
5328LN Communicating Passage $204.00 $220.00
DUMMY TRIM:
355LN Single Dummy Trim $97.00 $105.00
355LN-D Double Dummy Trim $192.00 $208.00
When Ordering: Specify design, function, hand and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CASE LOT: 10
SHIPPING WEIGHT: 4.8 Lbs. per lock
ELECTRIFIED 5300LN SERIES CYLINDRICAL LEVER LOCKS
87
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
87
DESIGNS: Augusta - AU Monroe - MO Pacific Beach - PB
When Ordering: Specify design, function and finish.
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 609
612 616 619
620 625 693
CYLINDER OVERRIDE:
5390LN Fail Safe $493.00 $509.00
5391LN Fail Secure
NO CYLINDER OVERRIDE:
5380LN Fail Safe $431.00 $447.00
5381LN Fail Secure
LOCKBODIES:
5380LN Fail Safe
$456.00 $472.00
5381LN Fail Secure
5390LN Fail Safe
5391LN Fail Secure
SFIC Core Prep: prefix "B" to trim designation. Accepts all SFIC cores, 6- or 7-Pin.
Example: B-AU5307LN x Less Core.
Medeco®/ASSA®IC Core Prep: prefix "M" to trim designation. Not Available with MO or PB Levers. 6-Pin only.
Example: M-AU5307LN x Less Core.
Schlage®IC Core Prep: prefix "SI" to trim designation. Not Available with MO Levers. 6-Pin only.
Example: SI-AU5307LN x Less Core.
Schlage®Cylinder Prep: prefix "S" to trim designation. 6-Pin only.
Example: S-AU5307LN x Less Cylinder.
Lockset with Sargent®"LA" Keyway Cylinder. 6-Pin only.
Example: AU5307LN x 3804.
Lockset with Schlage®"C" Keyway Cylinder. 6-Pin only.
Example: AU5307LN x 2802.
CASE LOT: 10
SHIPPING WEIGHT: 4.8 Lbs. per lock
Note: See page 210 for power supplies and electrified accessories.
5300LN SERIES CYLINDRICAL LEVER LOCK PARTS
88
DISTRIBUTOR LIST PRICES
88
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
STRIKES:
70S Full Lip Strike (Optional) $6.00 N/C
71S 1/4" Radius Full Lip Strike (Optional) N/C
202 Strike Box (Not Plated) $2.00 $2.00
371 Strike 1-1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike Lip 1-1/4" $37.00 STD
497 ANSI Strike with 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
497B Blank ANSI Strike (Optional) $37.00 ––
*PLAIN LATCHBOLTS:
380BN 2-3/4" Backset, 2-1/4" x 1-1/8" Front $30.00 STD
380DN 2-3/4" Backset, 2-1/4" x 1" Front $30.00 N/C
378N 2-3/8" Backset, 2-1/4" x 1" Front $30.00 N/C
3380BN 3-3/4" Backset, 2-1/4" x 1-1/8" Front $39.00 $9.00
3380DN 3-3/4" Backset, 2-1/4" x 1" Front $39.00 $9.00
*DEADLOCKING LATCHBOLTS:
380AN 2-3/4" Backset, 2-1/4" x 1-1/8" Front
$35.00
STD
380CN 2-3/4" Backset, 2-1/4" x 1" Front N/C
380N 2-3/8" Backset, 2-1/4" x 1" Front N/C
3380AN 3-3/4" Backset, 2-1/4" x 1-1/8" Front $49.00 $14.00
3380CN 3-3/4" Backset, 2-1/4" x 1" Front
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
CYLINDERS:
1802, *1802L Standard Cylinder 6-Pin $62.00 N/C
5802, *5802L Security Cylinder 6-Pin $246.00 $184.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
K402 Yale®KeyMark®Cylinder $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802, *2802L Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $62.00 N/C
3804, *3804L Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $77.00 $15.00
108S, *108L Schlage®Cylinder Adapter Kit $18.50 $18.50
14-5300-1058 Cylinder Retainer Spring $0.84 $0.84
9053 Cylinder Sleeve for 1802 Cylinder $7.70 $7.70
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
BACKSET EXTENSION LINKS:
381N Link 5" Total Backset for 378N/380N Latchbolts $24.00 $24.00
381AN Link 5" Total Backset for 380AN/380BN Latchbolts
When Ordering: Specify finish.
* All latches have universal fronts for both flat and beveled door edges.
*2-1/4" Door
Effective Date: May 1, 2018
Canada Effective July 3, 2018
89
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, function and finish.
MODEL # PRODUCT DESCRIPTION 1-3/8"*, 1-3/4", 2"
DOOR 2-1/4" DOOR ALL FINISHES
LOCKBODIES: (specify finish)
5301LN Passage or Closet 14-5401-0914 14-5401-0924 $97.00
5302LN Privacy Bedroom or Bath 14-5402-0902 14-5402-0903 $113.00
5303LN Patio or Privacy 14-5402-0902 14-5402-0903
5304LN Entry 14-5407-0902 14-5407-0903
$141.00
5305LN Storeroom or Closet 14-5405-0901 14-5405-0902
5306LN Service Station 14-5406-0402 14-5406-0403
5307LN Entry 14-5407-0902 14-5407-0903
5308LN Classroom 14-5408-0901 14-5408-0902
5309LN Exit Latch 14-5405-0902 14-5405-0902 $113.00
5318LN Intruder Classroom Security 14-5418-0902 14-5418-0903 $161.00
5321LN Communicating 14-5421-0901 14-5421-0902
5322LN Corridor 14-5422-0903 14-5422-0906 $141.00
5325LN Privacy 14-5406-0402 14-5406-0403 $113.00
5328LN Communicating Passage 14-5428-0111 14-5428-0112 $97.00
5329LN Communicating Classroom 14-5429-0007 14-5429-0008 $141.00
5330LN Utility, Asylum or Institutional 14-5430-0901 14-5430-0902 $161.00
5339LN Communicating Storerrom 14-5439-0001 14-5439-0002 $141.00
Lockbodies for 1-3/8" or 2-1/4" doors ADD $4.00
MODEL # PRODUCT DESCRIPTION AU MO PB ALL FINISHES
LEVERS ONLY:
350L Plain Inside 14-5301-6040 14-5301-6902 14-5301-6054
$57.00
350L Passage Outside 14-5301-6040 14-5301-6902 14-5301-6054
350PO Patio Outside 14-5303-6060 14-5303-6067 14-5303-6066
350EK Outside Emergency Key 14-5302-6058 14-5302-6585 14-5302-6062
350LK Cylinder 14-5300-6039 14-5305-6056 14-5305-6054
350LP Button 14-5300-6039 14-5305-6056 14-5305-6054
350LR Yale®IC 1-3/4" Door 14-5305-0006 14-5305-0014 14-5305-0010
$70.00
350LR Yale®IC 2-1/4" Door 14-5305-0018 14-5305-0026 14-5305-0022
350LB SFIC 1-3/4" Door 14-5305-0008 14-5305-0016 14-5305-0012
350LB SFIC 2-1/4" Door 14-5305-0020 14-5305-0028 14-5305-0024
350LS Schlage®IC 1-3/4" Door 14-5305-0009 N/A 14-5305-0013
350LS Schlage®IC 2-1/4" Door 14-5305-0021 14-5305-0025
5300LN SERIES CYLINDRICAL LEVER LOCK PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: Lockbodies for use with locksets ordered prior to March 2012 will require a new rose plate assembly. Therefore,
part number 14-5300-0030-010 must also be ordered.
*1-3/8" doors must be specified in the order
90
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, function and finish.
5300LN SERIES CYLINDRICAL LEVER LOCK PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PRODUCT DESCRIPTION PART NUMBER ALL FINISHES
OTHER COMPONENTS:
Lever Support Spring 14-5300-1021-999 $4.50
Inside Rose Support Assembly 14-5301-0703-048
$26.60
Inside Rose Support Assembly (5321LN,5329LN) 14-5321-0003-048
Outside Rose Support Assembly 14-5303-0001-048
Outside Rose Support Assembly (5301LN,5302LN) 14-5301-0704-048
Rose Scalp (specify finish) 14-5300-X024-(specify finish) $19.20
Blank Rose 14-5401-6003-(specify finish) $38.40
Dummy Rose Assembly 14-0355-0002-048 $14.50
Screw Pack for ANSI Strike & Latch 81-9400-0038-(specify finish)
$2.40
Screw Pack for "T" Strike and Latch 81-9400-0009-(specify finish)
Through Bolt Screws 1-3/8" & 1-3/4" Doors (2 required) 81-0011-0580-036 (each)
Through Bolt Screws 2" & 2-1/4" Doors (2 required) 81-0011-0582-036 (each)
91
DISTRIBUTOR LIST PRICES
4700LN GRADE 1 CYLINDRICAL LOCKS VARIATIONS
STANDARD FINISHES: Products will be furnished only in the following finishes.
LEVER
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
BRONZE:
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
1. 613 and 722 finishes available by Special Product Application
Request only. This form is available on the Yale extranet and should
be submitted to TPS.
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: AU4707LN x LC $62.00 —
Large format interchangeable core prep less core, for 6-pin, specify "x ICLC"
Ordering Example: AU4707LN x ICLC $0.00 $0.00
CYLINDERS AND LFIC CORE: 6-Pin only
INTERCHANGEABLE CORES:
1210 – LFIC 6-Pin (includes MK or GMK)
Ordering Example: AU4707LN x 1210 x 626 — $58.00
A600 Best®Keyway SFIC 6-or 7-Pin (includes MK or GMK)
Ordering Example: B-AU4707LN x A600 — $50.00
NOTE: 4718LN, 4721LN, 4729LN, 4730LN, 4739LN not available with IC Cores.
CYLINDER OPTIONS: (See page 93 for ordering example)
Lockset with SFIC Core Prep (less core) $0.00 $0.00
Lockset with Medeco®/ASSA®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®Standard Cylinder Prep (less cylinder) $25.00 $0.00
Lockset with Schlage®"C" Keyway Cylinder (specify cylinder model number
2804) $0.00 $0.00
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent®"LA" or
Schlage®"E" Keyway Cylinder. (specify cylinder model number 3804 x keyway) — $15.00
SPECIAL STRIKES:
371 Strike with 1", 1-1/2", 1-3/4" or 2" lip with box — $2.00
ANSI Strike 497 with 1 -1/8", 1-1/2" or 1-3/4" lip — $13.00
KNURLING: Available for all levers in 613E, 626 and BSP finishes only
Outside or Inside Only –– $75.00
Both Sides –– $150.00
ABRASIVE COATING:
Outside or Inside Only –– $46.00
Both Sides –– $92.00
DOORS 1-3/4" THICK: Adjustable to 2" thick — STD
DOORS 1-3/8" OR 2-1/4" THICK: — $4.00
MICROSHIELD®:Antimicrobial coating. Specify "YMS". — $65.00
Note: Security and Yale®KeyMark®Cylinders: see page 94 for pricing. These cylinders are priced and discounted separately.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
LEVER
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
PAINTED:
BSP Black Suede Powder Coat
92
DISTRIBUTOR LIST PRICES
4700LN SERIES GRADE 1 CYLINDRICAL LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
LEVER DESIGN: Augusta-AU Pacific Beach - PB Monroe - MO
CASE LOT: 10
SHIPPING WEIGHT: 4 Lbs. per lock
MODEL # PRODUCT DESCRIPTION 613E 626 BSP 605 606
612 625
SINGLE CYLINDER:
4704LN Entry
$442.00 $458.00
4705LN Storeroom or Closet
4706LN Service Station
4707LN Entry
4708LN Classroom
4722LN Corridor
4729LN Communicating Classroom
4739LN Communicating Storeroom
DOUBLE CYLINDER:
4718LN Intruder Classroom Security
$504.00 $520.004721LN Communicating
4730LN Utility, Asylum or Institutional
NON-KEY LATCHSETS:
4701LN Passage or Closet $341.00 $357.00
4709LN Exit Latch
$400.00 $416.00
4702LN Privacy, Bedroom or Bath
4703LN Patio or Privacy
4725LN Privacy
4728LN Communicating Passage $341.00 $357.00
DUMMY TRIM
4755LN Single Dummy Trim $220.00 $228.00
4755LN-D Double Dummy Trim $440.00 $456.00
93
DISTRIBUTOR LIST PRICES
ELECTRIFIED 4700LN SERIES CYLINDRICAL LEVER LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DESIGNS: Augusta - AU Monroe - MO Pacific Beach - PB
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606
612 625
CYLINDER OVERRIDE:
4790LN Fail Safe $660.00 $676.00
4791LN Fail Secure
NO CYLINDER OVERRIDE:
4780LN Fail Safe $598.00 $614.00
4781LN Fail Secure
LOCKBODIES:
4780LN Fail Safe
$459.00 $475.00
4781LN Fail Secure
4790LN Fail Safe
4791LN Fail Secure
SFIC Core Prep: prefix "B" to trim designation. Accepts all SFIC cores, 6- or 7-Pin.
Example: B-AU4707LN x Less Core.
Medeco®/ASSA®IC Core Prep: prefix "M" to trim designation. Not Available with MO or PB Levers. 6-Pin only.
Example: M-AU4707LN x Less Core.
Schlage®IC Core Prep: prefix "SI" to trim designation. Not Available with MO Levers. 6-Pin only.
Example: SI-AU4707LN x Less Core.
Schlage®Cylinder Prep: prefix "S" to trim designation. 6-Pin only.
Example: S-AU4707LN x Less Cylinder.
Lockset with Sargent®"LA" Keyway Cylinder. 6-Pin only.
Example: AU4707LN x 3804.
Lockset with Schlage®"C" Keyway Cylinder. 6-Pin only.
Example: AU4707LN x 2802.
CASE LOT: 10
SHIPPING WEIGHT: 4.8 Lbs. per lock
Note: See page 210 for power supplies and electrified accessories.
94
DISTRIBUTOR LIST PRICES
4700LN SERIES GRADE 1 CYLINDRICAL LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
CYLINDERS:
1804 Standard Cylinder 6-Pin $62.00 N/C
5802 Security Cylinder 6-Pin $246.00 $184.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
K402 Yale®KeyMark®Cylinder 6-Pin $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
2804 Schlage®“C” Keyway Cylinder 6-Pin 0-bitted or Keyed Random $62.00 N/C
3804 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $77.00 $15.00
A600 Best®Keyway Small Format Interchangeable Core Only 6- or 7-Pin,
Specify Keyway $50.00 $50.00
108S Schlage®Cylinder Adapter Kit $18.50 $18.50
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
PLAIN LATCHBOLTS:
693 Beveled, 2-3/4" Backset, 1/2" Throw $70.00 STD
F693 Flat, 2-3/4" Backset, 1/2" Throw N/C
3693 Beveled, 3-3/4" Backset, 1/2" Throw $77.00 $6.00
DEADLOCKING LATCHBOLTS:
694 Beveled, 2-3/4" Backset, 1/2" Throw $92.00 STD
F694 Flat, 2-3/4" Backset, 1/2" Throw N/C
3694 Beveled, 3-3/4" Backset, 1/2" Throw $102.00 $10.00
480B Beveled, 2-3/4" Backset, 3/4" Throw $173.00 $81.00
F480B Flat, 2-3/4" Backset, 3/4" Throw
3480B Beveled, 3-3/4" Backset, 3/4" Throw $182.00 $90.00
BACKSET LINKS:
481 Extension Link $47.00 $47.00
481DL Extension Link (use with deadlocking latchbolts)
482 Extension Link $64.00 $64.00
484 Extension Link $141.00 $141.00
STRIKES:
202 Strike Box (Not Plated) $2.00 $2.00
371 Strike 1-1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike Lip 1-1/4" $37.00 STD
497 ANSI Strike 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
95
DISTRIBUTOR LIST PRICES
4600(LN) GRADE 2 CYLINDRICAL LOCKS VARIATIONS
STANDARD FINISHES: Products will be furnished only in the following finishes.
LEVER
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
BRONZE:
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
PRODUCT OPTIONS DEDUCT ADD
CYLINDERS: 6-pin Only
LESS CYLINDER OR LESS CORE:
Standard cylinder prep only. Specify "x LC" $0.00 —
Small format interchangeable core prep less core, prefix "B" to trim
and specify "Less Core" — $0.00
Ordering Example: B-AU-4607LN x Less Core — —
CYLINDER OPTIONS:
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent®"LA"
or Schlage®"E" Keyway Cylinder. (specify cylinder model number 3806 x
keyway)
— $15.00
Lockset with Schlage®"C" Keyway Cylinder $0.00 $0.00
Lockset with A600 Best®Keyway Small Format Interchangeable Core — $50.00
SPECIAL STRIKES:
371 Strike with 1", 1-1/2", 1-3/4" or 2" lip with box — $2.00
ANSI Strike 497 with 1 -1/8", 1-1/2" or 1-3/4" lip — $13.00
DOORS 1-3/4" THICK: Adjustable to 1-3/8" thick — STD
KNURLING: Not Available
ABRASIVE COATING: (4600LN levers only)
Outside or Inside Only –– $46.00
Both Sides –– $92.00
KNOB
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
BRONZE:
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
Effective Date: May 1, 2018
Canada Effective July 3, 2018
96
DISTRIBUTOR LIST PRICES
4600(LN) SERIES GRADE 2 CYLINDRICAL LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CASE LOT: 10
SHIPPING WEIGHT: 2 Lbs. per lock
LEVER DESIGN: Augusta-AU Pacific Beach - PB Monroe - MO
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
CYLINDERS:
1805 Standard Cylinder 6-Pin for Knob Designs
$53.00 N/C
1806 Standard Cylinder 6-Pin for Lever Designs
2805 Schlage®“C” Keyway Cylinder 6-Pin 0-bitted or Keyed Random for Knob Designs
2806 Schlage®“C” Keyway Cylinder 6-Pin 0-bitted or Keyed Random for Lever Designs
3806 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway for Knob/Lever Designs $68.00 $15.00
A600 Best®Keyway Small Format Interchangeable Core Only 6- or 7-Pin, Specify Keyway $50.00 $50.00
CASE LOT: 10
SHIPPING WEIGHT: 4 Lbs. per lock
*All latches have universal fronts for both flat and beveled door edges.
When Ordering: Specify design, function, hand and finish.
MODEL # PRODUCT DESCRIPTION 613E 626 605 606 612 625
SINGLE CYLINDER:
4604LN Entry
$122.00 $138.00
4605LN Storeroom or Closet
4607LN Entry
4608LN Classroom
NON-KEY LATCHSETS:
4601LN Passage or Closet $108.00 $124.00
4602LN Privacy, Bedroom or Bath $110.00 $126.00
4628LN Communicating Passage
DUMMY TRIM:
4655LN Single Dummy Trim $40.00 $48.00
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
STRIKES:
70S Full Lip Strike (Optional) $6.00 N/C
71S 1/4" Radius Full Lip Strike (Optional)
202 Strike Box (Not Plated) $2.00 $2.00
371 Strike 1-1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike Lip 1-1/4" $37.00 N/C
497 ANSI Strike 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
*PLAIN LATCHBOLTS:
MCP234 2-3/4" Backset, 2-1/4" x 1-1/8" Square Front
$32.00
STD
MCP238 2-3/8" Backset, 2-1/4" x 1" Square Front N/C
MCP238R 2-3/8" Backset, 2-1/4" x 1" Round Front
*DEADLOCKING LATCHBOLTS:
MCD234 2-3/4" Backset, 2-1/4" x 1-1/8" Square Front
$37.00
STD
MCD238 2-3/8" Backset, 2-1/4" x 1" Square Front N/C
MCD238R 2-3/8" Backset, 2-1/4" x 1" Round Front
MODEL # PRODUCT DESCRIPTION 613E 630 605 606
612 629
SINGLE CYLINDER:
4605 Storeroom or Closet
$84.00 $100.004607 Entry
4608 Classroom
NON-KEY LATCHSETS:
4601 Passage or Closet $57.00 $73.00
4602 Privacy, Bedroom or Bath $60.00 $76.00
DUMMY TRIM:
4655 Single Dummy Trim $34.00 $42.00
KNOB DESIGN: Carolina-CA
97
DISTRIBUTOR LIST PRICES
4300LN SERIES GRADE 2 LEVER LOCKS VARIATIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Simulated painted finish meeting ANSI/BHMA standards for wear
and durability.
2. These finishes will be provided per factory standard. To assure color
match, please provide a sample.
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
ANSI/BHMA
CODE FINISH DESCRIPTIONS
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated2
BRONZE:
613 Dark Oxidized Satin Bronze, Oil Rubbed1
ANSI/BHMA
CODE FINISH DESCRIPTIONS
CHROME:
625 Bright Chrome Plated
626 Satin Chrome, Plated
NICKEL:
619 Satin Nickel Plated, Clear Coated
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: AU4307LN x LC $0.00 —
CYLINDERS:
6-Pin only — STD
INTERCHANGEABLE CORE:
Large/Small Format - Not Available — —
CYLINDER OPTION: See Page 98 for Ordering Example
Lockset with Schlage®"C" Keyway Cylinder (specify cylinder model number 2812) $0.00 $0.00
STRIKES:
ANSI Strike 497 — $4.00
DOOR THICKNESS:
Adjustable 1-3/8" to 1-3/4" — STD
SPLIT FINISHES: Available only with 4302LN Privacy Function. When privacy sets
with different trim finishes on each side are required, specify outside finish first.
Latchbolt fronts and strike finish to match inside trim unless otherwise specified.
$0.00 $0.00
Note: Yale®KeyMark®Cylinders: see page 99 for pricing. These cylinders are priced and discounted separately.
When Ordering: Specify finish.
98
DISTRIBUTOR LIST PRICES
4300LN SERIES LIGHT/MEDIUM DUTY LEVER LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DESIGNS: Augusta - AU *Madrid - MA Pacific Beach - PB Monroe - MO
MODEL # PRODUCT DESCRIPTION
605 606 609
613 619
625 626
SINGLE CYLINDER:
4305LN Storeroom or Closet
$238.00
4307LN Entry
4308LN Classroom
NON-KEYED LATCHSETS:
4301LN Passage or Closet $175.00
4302LN Privacy, Bedroom or Bath1
$183.00
4328LN Communicating Passage
4355LN Single Dummy Trim $140.00
CASE LOT: 12 each
SHIPPING WEIGHT: 2.5 Lbs. per lock
Locksets supplied with Schlage®"C" keyway cylinder. 6-Pin only.
Same List Price as Lockset with Standard Cylinder.
EXAMPLE: AU4307LN x 2812 x 605
* Specify Hand for Madrid Lever Sets.
1. SPLIT FINISHES (4302LN only)
605 x 625 Bright Brass x Bright Chrome
605 x 626 Bright Brass x Satin Chrome
606 x 625 Satin Brass x Bright Chrome
606 x 626 Satin Brass x Satin Chrome
NOTE: For AU, PB and MO designs, handing is field reversible for Entrance, Passage and Privacy functions.
When Ordering: Specify function and finish.
Specify hand for Madrid.
99
DISTRIBUTOR LIST PRICES
4300LN SERIES LIGHT/MEDIUM DUTY LEVER LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
* Failure to use fire cup voids UL rating.
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
DEADLOCKING LATCHBOLTS:
280N Square Corner Front x 2-3/8" B.S. (2-1/4" x 1")
$24.00 N/C
280RN Round Corner Front x 2-3/8" B.S. (2-1/4" x 1")
280DN Square Corner Front x 2-3/4" B.S. (2-1/4" x 1-1/8") STD
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
STRIKES:
271 Strike 1-1/4" Lip $7.30 STD
20S Full Lip Strike Square Corner $7.90 N/C
21S Full Lip Strike Round Corner
497 ANSI Strike $37.00 $4.00
202 Strike Box (not plated)
$2.00 $2.00301 2-3/4" Dust Box for 271 Strike (not plated)
302 2-1/4" Dust Box for 20S & 21S Strike (not plated)
MISCELLANEOUS:
*10C Fire Cup for UL Rating $7.30
STDSP100 Screw Pack (specify finish) $5.10
43LS 1" Latch Sleeve $0.72
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
CYLINDERS:
1812 Standard Cylinder 6-Pin $62.00 N/C
2812 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $62.00 N/C
Yale®KeyMark®products are priced separately. Yale KeyMark cylinders are not discounted the same as the locksets.
100
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
101
DISTRIBUTOR LIST PRICES
RL SERIES TUBULAR LOCKS VARIATIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
BRONZE:
611 Bright Bronze, Clear Coated
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
N/A US10BL Dark Oxidized Satin Bronze,
Clear Coated1
N/A US20D Statuary Dark Bronze, Clear
Coated1
PRODUCT OPTIONS DEDUCT ADD
UL 3-Hour Fire Rating - Suffix 'F' to model number. Available for RL201, RL202, RL228 — $7.00
STRIKES:
ANSI Strike 497 — $4.00
DOOR THICKNESS:
Adjustable 1-3/8" to 1-3/4" — STD
1-7/8" to 2" (latchbolt centered in total door thickness) —$0.00
KNURLING: Not available. —STD
MICROSHIELD®:Antimicrobial coating. Specify option "YMS". —$65.00
REFLECTION LEVERS: The following levers are no longer available in 629 and 630
finishes, TT, TU, TV, TW, TX, TY, UW, UX, TZ, TG, TJ, TK, TO, TE, TI and TD. — —
1. Yale finishes are designated by ANSI/BHMA codes. There is not equivalent designation for US10BL and US20D and requests will be processed
by special order.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted
to TPS.
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
NICKEL:
618 Bright Nickel Plated, Clear Coated
619 Satin Nickel Plated, Clear Coated
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
PAINTED:
BSP Black Suede Powder Coat
102
DISTRIBUTOR LIST PRICES
RL SERIES TUBULAR LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 611 612 618
619 625 62916301
US10BL US20D
RL201 Passage or Closet $218.00 $228.00
RL228 Communicating Passage Exit Latch
RL202 Privacy, Bedroom or Bath $229.00 $239.00
RL255 Single Dummy Trim - Through-Bolted $127.00 $132.00
RL255D Double Dummy Trim $190.00 $200.00
RL255S Single Dummy Trim - Surface Mounted $95.00 $100.00
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH
LOCKSET
STRIKES:
202 Strike Box (Not Plated) $2.00 $2.00
371 Strike 1-1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike Lip 1-1/4" $37.00 $4.00
497 ANSI Strike with 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
LATCHBOLTS:
RLP34 Square Corner Front 2-1/4" x 1-1/8" Faceplate, used with RL202
$36.00
STD
RLP34A Square Corner Front 2-1/4" x 1-1/8" Faceplate, used with RL201 &
RL228
RLP38 Square Corner Front 2-1/4" x 1" Faceplate, used with RL202
N/C
RLP38A Square Corner Front 2-1/4" x 1" Faceplate, used with RL201 &
RL228
PARTS:
LEVER DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, UW, TX, TY, UX, TZ
ROSE DESIGNS: R3, R4, R5
1. See the Variations page for details.
103
DISTRIBUTOR LIST PRICES
6400LN SERIES LEVER MONOLOCKS VARIATIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: AU6407LN x LC $62.00 —
Large format interchangeable core prep less core, for 6-pin, specify "x ICLC"
Ordering Example: AU6407LN x ICLC $0.00 $0.00
7-PIN CYLINDERS AND LFIC CORE:
Add to 6-Pin cylinder/core — $2.00
INTERCHANGEABLE CORES:
1210 - LFIC 6-Pin (includes MK or GMK)
Ordering Example: AU6407LN x 1210 x 626 — $58.00
A600 Best®Keyway SFIC 6-or 7-Pin (includes MK or GMK)
Ordering Example: B-AU6407LN x A600 — $50.00
CYLINDER OPTIONS: See Page 104---- for Ordering Examples
Lockset with SFIC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®IC Core Prep (less core)
Lockset with Medeco®/ASSA®IC Core Prep (less core) $0.00 $0.00
Lockset with Schlage®Cylinder Prep (less cylinder) $25.00 —
Lockset with Schlage®"C"Keyway Cylinder (specify cylinder model number 2802) $0.00 $0.00
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent®"LA" or
Schlage®"E" Keyway Cylinder. (specify cylinder model number 3804 x keyway) $0.00 $15.00
SPECIAL STRIKES:
ANSI Strike 497 with 1 1/8", 1 1/2" or 1 3/4" lip — $13.00
SPLIT FINISHES: Higher List Price Applies
KNURLING: Available for all levers in 626 finish only
Outside or Inside Only –– $75.00
Both Sides –– $150.00
ABRASIVE COATING:
Outside or Inside Only –– $46.00
Both Sides –– $92.00
MICROSHIELD®:Antimicrobial coating. Specify option "YMS". — $65.00
NOTE: Fits doors 1-3/4" thick only.
NOTE: Security and Yale®KeyMark®Cylinders: see page 105 for pricing. These cylinders are priced and discounted separately.
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
626 Satin Chrome Plated
When Ordering: Specify design finish.
104
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, function, hand and finish.
6400LN SERIES HEAVY-DUTY MONOLOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DESIGNS: Augusta - AU Monroe - MO Pacific Beach - PB
MODEL # PRODUCT DESCRIPTION 626
SINGLE CYLINDER:
6404LN Entry
$1,090.00
6405LN Storeroom or Closet
6406LN Service Station
6407LN Entry
6408LN Classroom
6422LN Corridor
6429LN Communicating Classroom
DOUBLE CYLINDER:
6417LN Apartment, Exit or Public Toilet
$1,152.00
6418LN Intruder Classroom Security
6421LN Communicating
6430LN Utility, Asylum or Institutional
NON-KEYED LATCHSETS:
6401LN Passage or Closet $979.00
6428LN Communicating Passage
6402LN Privacy, Bedroom or Bath
$1,027.00
6403LN Patio or Privacy
6409LN Exit Latch
6425LN Privacy
CASE LOT: 10
SHIPPING WEIGHT: 6 Lbs. per lock
SFIC Core Prep: prefix "B" to trim designation. Accepts all SFIC cores. Specify 6- or 7-Pin.
Example: B-AU6407LN x Less Core.
Medeco®/ASSA®IC Core Prep: prefix "M" to trim designation. Not Available with MO or PB Levers. 6-Pin only.
Example: M-AU6407LN x Less Core.
Schlage®IC Core Prep: prefix "SI" to trim designation number. 6-Pin only.
Example: SI-AU6407LN x Less Core.
Schlage®Standard Cylinder Prep: prefix "S" to trim designation. 6-Pin only.
Example: S-AU6407LN x Less Cylinder.
Lockset with Sargent®"LA" Keyway Cylinder. 6-Pin only.
Example: AU6407LN x 3804.
Lockset with Schlage®"C" Keyway Cylinder. 6-Pin only.
Example: AU6407LN x 2802.
105
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
6400LN SERIES HEAVY-DUTY MONOLOCK PARTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCK
CYLINDERS:
1802 Standard Cylinder 6-Pin $62.00 N/C
1802S Standard Cylinder 6-Pin for 6417LN inside lever
1802A Standard Cylinder 7-Pin $64.00 $2.00
5802 Security Cylinder 6-Pin $246.00 $184.00
5802A Security Cylinder 7-Pin $250.00 $188.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
1220 Large Format Interchangeable Core Only 7-Pin $60.00 $60.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
5220 Security Large Format Interchangeable Core Only 7-Pin $230.00 $230.00
K402 Yale®KeyMark®Cylinder $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-or 7-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $62.00 N/C
3804 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $77.00 $15.00
107S Schlage®Cylinder Adapter Kit $18.50 $18.50
PRODUCT DESCRIPTION PART NUMBER LIST PRICE
MISCELLANEOUS PARTS:
Rose Scalp 14-5401-2711-(specify finish) $24.70
Lever Spring 14-5401-1641-999 $7.70
Inside Rose Assembly 14-5401-0655-048 $36.70
Outside Rose and Shank Assembly 14-5407-0108-048 $42.40
Through-Bolts (price each - 2 required) 81-0011-0588-036 $2.80
Retainer Spring Pad 14-5407-9034-999
$2.40
Inside Handle Set Screw 81-6419-2979-999
Screw Pack for ANSI Strike and Latch 81-9400-0038-(specify finish)
Screw Pack for "T" Strike and Latch 81-9400-0009-(specify finish)
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCK
STRIKES:
371 Strike 1-1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike 1-1/4" Lip $37.00 STD
497 ANSI Strike 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
497B Blank ANSI Strike 1-1/8" Lip $37.00 ––
202 Strike Box (not plated) $2.00 $2.00
DESCRIPTION FUNCTIONS AU MO PB
LEVERS ONLY:
Plain Inside 01, 05, 08, 09,
28, 455LN 14-5401-6063 14-5401-6064 14-5401-6062
Plain Outside 01 14-5401-6063 14-5401-6064 14-5401-6062
Privacy Outside 02 14-5402-6025 14-5402-6024 14-5402-6023
Cylinder std 6 or 7-Pin 04, 05, 06, 07, 08, 17,
18, 21, 22, 29, 30 14-5407-6038 14-5407-6042 14-5407-6062
Button 02, 03, 06, 07, 22, 25 14-5407-6038 14-5407-6042 14-5407-6062
I/S Yale®IC 6-Pin 17, 18 14-5417-6021 14-5417-6030 14-5417-6040
I/S Yale®IC 7-Pin 17, 18 14-5417-6022 14-5417-6031 14-5417-6041
I/S SFIC 6 or 7-Pin 17, 18 14-5417-6029 14-5417-6032 14-5417-6042
I/S Schlage®IC 6-Pin 17, 18 14-5417-6059 14-5417-6061 14-5417-6060
I/S Medeco®/ASSA®IC 17, 18 14-5417-6023 N/A N/A
PRODUCT DESCRIPTION ALL FINISHES
ALL LEVERS $107.00
DESCRIPTION FUNCTIONS AU MO PB
LEVERS ASSEMBLIES:
Plain O/S Security 03, 09 14-5403-0051 14-5403-0052 14-5403-0053
O/S Yale®IC 6-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0076 14-5407-0019 14-5407-0030
O/S Yale®IC 7-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0077 14-5407-0021 14-5407-0031
O/S SFIC 6 or 7-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0040 14-5407-0041 14-5407-0042
O/S Schlage®IC 6-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0904 14-5407-6209 14-5407-0905
O/S Medeco®/ASSA®IC 6-Pin 04, 05, 06, 07,
08, 17, 18, 22 14-5407-0078 N/A N/A
PRODUCT DESCRIPTION ALL FINISHES
ALL LEVER ASSEMBLIES $132.00
106
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
6400LN SERIES HEAVY-DUTY MONOLOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
D100 AND D200 SERIES DEADBOLTS
350 SERIES DEADLOCKS & PADLOCKS
107
DISTRIBUTOR LIST PRICES
DEADLOCKS - PADLOCKS - AUXILIARY LOCKS - CABINET LOCKS VARIATIONS
STANDARD FINISHES: Product will be furnished only in the finishes in which it is priced.
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
626 Satin Chrome Plated
NICKEL:
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin
Relieved, Clear Coated
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
PAINTED:
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated
BRONZE:
611 Bright Bronze, Clear Coated
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened, Satin Relieved,
Clear Coated
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide a sample.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
PRODUCT OPTIONS DEDUCT ADD
CYLINDERS OMITTED 350 SERIES ONLY: $70.00
IC Housing ordered with 350 Series $0.00 $0.00
DUST GUARD: For cylinders prefix "D" to model number (refer to catalog) — $47.00
7-PIN CYLINDERS AND LFIC CORES: — $2.00
INTERCHANGEABLE CORE CYLINDERS:
2196 - LFIC 6-Pin (includes MK or GMK)
Ordering Example: 353 x 2196 x 626 — $58.00
A620 - SFIC 6-or 7-Pin (Includes MK or GMK)
Ordering Example: 353 x A620 x 626 — $50.00
SECURITY SCREWS 300 SERIES: Standard sizes only (each screw) — $1.00
SPLIT FINISHES: Higher List Price Applies
LEAD LINED 350 SERIES: — $181.00
MICROSHIELD®:Antimicrobial coating. Specify "YMS". — —
Mortise Deadlocks — $65.00
When Ordering: Specify finish.
PRODUCT OPTIONS DEDUCT ADD
CYLINDERS: 6-pin Only
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC" $0.00 $0.00
Large format interchangeable core prep less core, for 6-pin, specify "x ICLC"
Ordering Example: D112 x 1210 Prep x Less Core (available for D100 or D200 series)
Note: List price add is for D200 series only. D100 series does not require an add.
$0.00 $25.00
Small format interchangeable core prep less core, for 6-or 7-pin, specify with "B" prefix "x Less Core"
Ordering Example: B-D112 x Less Core (available for D100 or D200 series) $0.00 $0.00
7-PIN (available for SFIC and LFIC - for LFIC, specify "x 1220"):
Add to 6-Pin core — $2.00
INTERCHANGEABLE CORES:
1210 - LFIC 6-Pin (available for D100 series - includes MK or GMK)
Ordering Example: D112 x 1210 x 626 — $58.00
1210 - LFIC 6-Pin (available for D200 series - includes MK or GMK)
Ordering Example: D212 x 1210 x 626 — $83.00
A600 Best®Keyway SFIC 6-or 7-Pin (available for D100 or D200 series - includes MK or GMK)
Ordering Example: B-D112 x A600 x 626 — $50.00
CYLINDER OPTIONS:
Deadbolt with Schlage®"C" Keyway Cylinder $0.00 $0.00
Deadbolt with Corbin Russwin "L4", Corbin®"60", Russwin®"D1", Sargent®"LA" or Schlage "E" — $15.00
SPECIAL STRIKES: (For Use with YSSL10)
371 Strike with 1", 1-1/2", 1-3/4" or 2" lip with box — $2.00
DOORS 1-3/4" THICK: Adjustable to 1-3/8" thick — STD
Effective Date: May 1, 2018
Canada Effective July 3, 2018
108
DISTRIBUTOR LIST PRICES
When Ordering: Specify function and finish.
D100 AND D200 SERIES DEADBOLTS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # BACKSET FRONT 613E 626 BSP 605 606 612
619 625
APPROX. SHIPPING
WT. LBS.
CYLINDER x THUMBTURN:
D211 2-3/8" 2-1/4" X 1" $82.00 $86.00 24
D212 2-3/4" 2-1/4" X 1"
CYLINDER x CYLINDER:
D221 2-3/8" 2-1/4" X 1" $103.00 $107.00 24
D222 2-3/4" 2-1/4" X 1"
CYLINDER x BLANK ROSE:
D231 2-3/8" 2-1/4" X 1" $82.00 $86.00 24
D232 2-3/4" 2-1/4" X 1"
BLANK PLATE x THUMBTURN:
D241 2-3/8" 2-1/4" X 1" $50.00 $54.00 24
D242 2-3/4" 2-1/4" X 1"
BLANK PLATE x CYLINDER
D251 2-3/8" 2-1/4" X 1" $82.00 $86.00 24
D252 2-3/4" 2-1/4" X 1"
CYLINDER x CLASSROOM THUMBTURN
D261 2-3/8" 2-1/4" X 1" $92.00 $96.00 24
D262 2-3/4" 2-1/4" X 1"
THUMBTURN X OCCUPANCY INDICATOR
D291 2-3/8" 2-1/4" X 1" $68.00 $72.00 24
D292 2-3/4" 2-1/4" X 1"
NOTE: 1-1/8" front filler supplied standard with each deadbolt.
Case Lot: 10
MODEL # BACKSET FRONT 613E 626 BSP 605 606 612
619 625
APPROX. SHIPPING
WT. LBS.
CYLINDER x THUMBTURN:
D111 2-3/8" 2-1/4" X 1"
$152.00 $156.00 24
D112 2-3/4" 2-1/4" X 1"
B-D171 2-3/8" 2-1/4" X 1"
B-D172 2-3/4" 2-1/4" X 1"
CYLINDER x CYLINDER:
D121 2-3/8" 2-1/4" X 1" $184.00 $188.00 24
D122 2-3/4" 2-1/4" X 1"
CYLINDER x BLANK ROSE:
D131 2-3/8" 2-1/4" X 1" $152.00 $156.00 24
D132 2-3/4" 2-1/4" X 1"
BLANK PLATE x THUMBTURN:
D141 2-3/8" 2-1/4" X 1" $126.00 $130.00 24
D142 2-3/4" 2-1/4" X 1"
BLANK PLATE x CYLINDER
D151 2-3/8" 2-1/4" X 1" $152.00 $156.00 24
D152 2-3/4" 2-1/4" X 1"
CYLINDER x CLASSROOM THUMBTURN
D161 2-3/8" 2-1/4" X 1"
$162.00 $166.00 24
D162 2-3/4" 2-1/4" X 1"
B-D181 2-3/8" 2-1/4" X 1"
B-D182 2-3/4" 2-1/4" X 1"
D100 GRADE 1 DEADBOLTS
D200 GRADE 2 DEADBOLTS
109
DISTRIBUTOR LIST PRICES
When Ordering: Specify function and finish.
D100 AND D200 SERIES PARTS AND ACCESSORIES
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
DEADBOLT ASSEMBLIES:
D38 2-3/8" Backset, 2-1/4" x 1" Square Front, includes 1-1/8" Front Filler
$12.00 N/C
D34 2-3/4" Backset, 2-1/4" x 1" Square Front, includes 1-1/8" Front Filler
D38R 2-3/8" Backset, 2-1/4" x 1" Radius Front, includes 1-1/8" Front Filler
D34R 2-3/4" Backset, 2-1/4" x 1" Radius Front, includes 1-1/8" Front Filler
STRIKES:
D243 Strike pack which includes 2-3/4" x 1-1/8" both wood and metal frame strikes
and corresponding screws $4.00 STD
D244 Strike Reinforcement $2.10
SCREW PACKS:
14-3211-0100-XXX Includes mounting and strike screws for DX11, DX12, DX31, DX32, DX61, DX62.
XXX = specify finish.
$1.60 STD
14-3221-0104-XXX Includes mounting and strike screws for DX21, DX22, DX51, DX52, D171,
D172, D181, D182
XXX = specify finish.
14-3241-0100-XXX Includes mounting and strike screws for DX41, DX42, D291, D292
XXX = specify finish.
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
CYLINDERS:
1807 Standard Cylinder 6-pin for use with DX11, DX12, DX31, DX32, DX51, DX52,
DX61, DX62
$53.00 N/C
1808 Standard Cylinder 6-pin for use with DX21, DX22
2807 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random for use with
DX11, DX12, DX31, DX32, DX51, DX52, DX61, DX62
2808 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random for use with
DX21, DX22
3806 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway for D
Series $68.00 $15.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
1220 Large Format Interchangeable Core Only 7-Pin $60.00 $60.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
5220 Security Large Format Interchangeable Core Only 7-Pin $230.00 $230.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-or 7-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6- or 7-Pin, Specify
Keyway $50.00 $50.00
NOTE: X in model number = '1' for Grade 1 and '2' for Grade 2
NOTE: X in model number = '1' for Grade 1 and '2' for Grade 2
Effective Date: May 1, 2018
Canada Effective July 3, 2018
110
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
AUXILIARY LATCH:
YSSL10 Security SideLite Auxiliary Latch $139.00
AUXILIARY LATCH
MODEL # PRODUCT DESCRIPTION 613E 626
BSP
605 606 611 612 618
619 625 629 630
US10BL US20D
350 SERIES DEADLOCKS:
351 Double Cylinder $356.00 $361.00
352 Single Cylinder Outside x Thumbturn Inside $334.00 $339.00
353 Single Cylinder Outside $286.00 $291.00
354 Exit (Thumbturn Inside Only) $264.00 $269.00
356 Double Cylinder with Thumbturn Inside $404.00 $409.00
357 Single Cylinder Outside x Thumbturn Inside $334.00 $339.00
MODEL # PRODUCT DESCRIPTION
ORDERED
WITH
LOCKSET
ORDERED
SEPARTELY
THUMBTURNS AND STRIKES:
1827 Thumbturn for 352, 354, 356 & 357 N/C $56.00
30S Strike 3-1/2" x 1-1/8" (standard) STD $33.00
545N Strike 4-7/8" x 1-1/4" (optional) N/C $22.00
31S Strike Box - not plated (optional) $2.00 $2.00
350 SERIES MORTISE DEADLOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
111
DISTRIBUTOR LIST PRICES
AUXILIARY LOCKS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Add suffix "F" for doors opening outward.
SHELF BOX: 1
NOTE: Standard cylinders included with auxiliary locks are supplied PARA Keyed Different. If cylinders for these locks are
required to be masterkeyed or keyed alike you must include the price of an additional cylinder and keying charges. No
deduct for omitting cylinder.
VISUAL PACK AUXILIARY LOCKS
MODEL # PRODUCT DESCRIPTION PRICE
EACH CASE LOT APPROX.
SHIPPING WT.
AUXILIARY RIM LOCKS:
88 Auxiliary Security Latchlock $69.00 30 35
80 Auxiliary Security Latchlock 30 49
*112 Auxiliary Heavy-Duty Deadbolt $113.00 6 12-1/2
*112 1/4 Auxiliary Heavy-Duty Deadbolt $132.00 6 14
*197 Auxiliary Jimmy-Proof Deadlock $113.00 6 12-1/2
*197 1/4 Auxiliary Jimmy-Proof Deadlock $132.00 6 14
NOTE: Standard cylinders included with auxiliary locks are supplied PARA Keyed Different. If cylinders for these locks
are required to be masterkeyed or keyed alike you must include the price of an additional cylinder and keying charges.
No deduct for omitting cylinder.
MODEL # PRODUCT DESCRIPTION PRICE
EACH CASE LOT APPROX.
SHIPPING WT.
AUXILIARY RIM LOCKS:
V80 Auxiliary Security Latchlock $69.00 5 17
V197 Auxiliary Jimmy-Proof Deadlock $113.00 5 12
V197 1/4 Auxiliary Jimmy-Proof Deadlock $132.00 5 12
MODEL # PRODUCT DESCRIPTION PRICE
EACH
STRIKES:
8RB Reverse Bevel Strike (for use with 80, 88) $6.00
112F Strike (for use with 112) $17.80
197F Flat Strike (for use with 197, 197 1/4) $30.20
When Ordering: Specify function and finish.
112
DISTRIBUTOR LIST PRICES
PADLOCKS PD400 SERIES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify design, hand and finish.
MODEL # DESCRIPTION KEYED ALIKE / KEYED
DIFFERENT
FIXED CORE:
PD416 6-Pin, 5/16" Diameter Shackle $70.00
PD2416 6-Pin, 5/16" Diameter & 2" Extended Shackle $73.00
PD3416 6-Pin, 5/16" Diameter & 3" Extended Shackle $75.00
OPTIONS
Chain attached to shackle
Steel (Suffix "S42S" to model number) ADD $4.30
Brass (Suffix "S42A" to model number) ADD $5.10
Brass Shackles (Suffix "B" to model number) ADD $4.30
Master Keyed ADD $16.00
NOTE: Padlocks operated by two (2) or more different keys same price as master keying. Furnished standard keyed
different with 1801 cylinder. See pages 32, 37 and 44 for optional 2801, 5801 or K400 cylinder pricing.
INTERCHANGEABLE CORE:
113
DISTRIBUTOR LIST PRICES
PADLOCKS PD500 SERIES
OPTIONS
Chain attached to shackle
Steel (Suffix "S42S" to model number) ADD $4.30
Brass (Suffix "S42A" to model number) ADD $5.10
Chain attached to case
Steel (Suffix "C42S" to model number) ADD $4.30
Brass (Suffix "C42A" to model number) ADD $5.10
Brass Shackles (Suffix "B" to model number) ADD $4.30
PD516 or PD526 x Less Cylinder DEDUCT $62.00
PD516 or PD526 x MK ADD $16.00
NOTE: Padlocks operated by two (2) or more different keys same price as master keying.
NOTE: LFIC and SFIC Padlocks furnished standard less core. Add master keyed core price when ordered with core. See pages 35 and 44 for
available core pricing.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # DESCRIPTION LESS CORE CASE LOT SHIPPING
WT. LBS.
LFIC PADLOCKS
PD514 6-Pin, 5/16" Diameter Shackle $110.00 20 19PD524 6-Pin, 3/8" Diameter Shackle
PD534 7-Pin, 3/8" Diameter Shackle
$112.00PD2514 6-Pin, 5/16" Diameter & 2" Extended Shackle
18
17PD2524 6-Pin, 3/8" Diameter & 2" Extended Shackle
PD2534 7-Pin, 3/8" Diameter & 2" Extended Shackle
$114.00PD3514 6-Pin, 5/16" Diameter & 3" Extended Shackle
19
PD3524 6-Pin, 3/8" Diameter & 3" Extended Shackle
PD3534 7-Pin, 3/8" Diameter & 3" Extended Shackle $116.00
SFIC PADLOCKS:
PD515 6- or 7-Pin, 5/16" Diameter Shackle $51.00
20
19
PD525 6- or 7-Pin, 3/8" Diameter Shackle
PD2515 6- or 7-Pin, 5/16" Diameter & 2" Extended Shackle $53.00
PD2525 6- or 7-Pin, 3/8" Diameter & 2" Extended Shackle
PD3515 6- or 7-Pin, 5/16" Diameter & 3" Extended Shackle $55.00 18
PD3525 6- or 7-Pin, 3/8" Diameter & 3" Extended Shackle
FIXED CORE:
MODEL # DESCRIPTION KEYED ALIKE /
KEYED DIFFERENT CASE LOT SHIPPING
WT. LBS.
FIXED CORE PADLOCKS
PD516 6-Pin, 5/16" Diameter Shackle $113.00 20
19
PD526 6-Pin, 3/8" Diameter Shackle
PD2516 6-Pin, 5/16" Diameter & 2" Extended Shackle $115.00
18
PD2526 6-Pin, 3/8" Diameter & 2" Extended Shackle
PD3516 6-Pin, 5/16" Diameter & 3" Extended Shackle $118.00
PD3526 6-Pin, 3/8" Diameter & 3" Extended Shackle
NOTE: Fixed core padlocks are 6-pin and furnished standard keyed different with 1801 cylinder. See pages 32, 37 and 44 for optional 2801, 5801 or
K400 cylinder pricing.
114
DISTRIBUTOR LIST PRICES
PADLOCKS PD600 SERIES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify function and finish.
MODEL # DEPTH FINISH REGULAR
KEYING MK or GMK
APPROX.
SHIPPING
WT. LBS.
CABINET LOCKS:
*511S 3/4", 1", 1-1/8", 1-3/8" 605-606-625-626 $166.00 $182.00 1
MODEL # PRODUCT
DESCRIPTION FINISH REGULAR
KEYING MK or GMK
APPROX.
SHIPPING
WT. LBS.
SPECIAL CYLINDERS:
C970 Cabinet Lock All Finishes $117.00 $133.00 1/2
C1810 Letter Box Lock 606-626 $75.00 $91.00 1/4
MODEL # PRODUCT DESCRIPTION 605 625
STRIKES:
511S Angle Strike $4.00 $4.00
*Specify hand.
CABINET LOCKS
MODEL # LIST PRICE CASE LOT APPROX.
SHIPPING WT.
CHAINS:
42A $5.10 12 3/4
42S $4.30 12 3/4
MODEL # DESCRIPTION KEYED ALIKE / KEYED
DIFFERENT
FIXED CORE:
PD616 6-Pin, 5/16" Diameter Shackle $113.00
PD2616 6-Pin, 5/16" Diameter & 2" Extended Shackle $115.00
OPTIONS
Chain attached to shackle
Steel (Suffix "S42S" to model number) ADD $4.30
Brass (Suffix "S42A" to model number) ADD $5.10
Chain attached to case
Steel (Suffix "C42S" to model number) ADD $4.30
Brass (Suffix "C42A" to model number) ADD $5.10
Master Keyed ADD $16.00
NOTE: Padlocks operated by two (2) or more different keys same price as master keying. Furnished standard keyed
different with 1801 cylinder. See pages 32, 37 and 44 for optional 2801, 5801 or K400 cylinder pricing.
115
DISTRIBUTOR LIST PRICES
7000 SERIES EXIT DEVICES
When Ordering: Specify design, hand and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
VARIATIONS: Exit Devices and Trims are priced separately. In order to determine the full list price of a 7000 Series
Exit Device with trim, it is necessary to add the list price of the device model number and the list price of the trim
model number.
STANDARD FINISHES: Products will be furnished only in the following finishes.
PRODUCT OPTIONS ADD
DESIGNER LEVER: (HA) $233.00
DUST GUARD: Prefix "D" to model number (refer to Cylinders/Keys catalog for available cylinders) $47.00
DOOR WIDTH:
24" Door Width (Suffix -24 ) See note 4 page 116. $0.00
30"-36" Door Width (Suffix -36 ) STD
36"-48" Door Width (Suffix -48) $48.00
Door thickness: Doors over 2-1/4" $41.00
SLEEVE NUTS: Factory orders only for exact quantity
SN-104 (For interlock bracket on fire-rated mullions) $4.00
SN-134 (4 Pack) $5.40
TORX®SECURITY HEAD SCREWS: Standard size only
Rim Exit Device $37.00
UL Rim Exit Device
Surface Vertical Rod Exit Device (SVR) $96.00
Concealed Vertical Rod Exit Device (CVR) $37.00
Mortise Exit Device $67.00
630F, 660F, 670F Series Trim $6.00
121NL, 350F, 540F, 620F, 650F, 680F, 690F Series Trim N/A
ABRASIVE COATING: On Touchbar Pad $74.00
KNURLING: .
On Touch Pad, available in all finishes $142.00
For outside trim $75.00
MICROSHIELD®:Antimicrobial coating. Suffix YMS to model number for each exit device or trim that
the coating will be applied. $78.00
REFLECTION LEVERS: The following levers are no longer available in 629 and 630 finishes, TT, TU,
TV, TW, TX, TY, UW, UX, TZ, TG, TJ, TK, TO, TE, TI and TD. —
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
625 Bright Chrome Plated
(540F Series Trim Only)
626 Satin Chrome Plated (trim only)
NICKEL:
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin
Relieved, Clear Coated
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
PAINTED:
693 Black Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened, Satin Relieved,
Clear Coated
BRONZE:
611 Bright Bronze, Clear Coated
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened, Satin Relieved,
Clear Coated
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide a sample.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
CYLINDERS: Standard 6-Pin cylinders included with 540F Series Rose Trim only. All other keyed trim priced less
cylinder, the list price of the cylinder must be added if cylinders are required. Specify cylinder and cylinder collar with
collar size.
NOTES:
1. Required for electrical feature, Suffix “-SAFE” or “-SECURE”.
2. LBR available on 7160(F90) and 7170(F90) devices only.
3. For double cylinder devices, suffix “-2” after fourth digit.
4. If “-24” device is to be used with a DOW greater than 24", the
device will ship without UL label. The 12" touchpad will not cover
50% of the device touchbar length.
5. “WS” applies only to 7150(F), 7250M(F) and 7170(F) devices.
6. Maximum opening size 8'0" x 8'0".
7. Contact Ceco, Curries®or Fleming for detailed frame/door
requirements and limitations.
DISTRIBUTOR LIST PRICES
HOW TO ORDER
MAX. OPENING DOOR TYPE FIRE RATING MODEL NO. STYLE STRIKE
SURFACE VERTICAL ROD (2 point latch):
4' x 10' Metal or Wood None 7110 Wide Surface
8' x 8' Metal or Wood 3 Hour “A” 7110F Wide Surface
4' x 10' Metal or Wood None 7210M Wide Surface
8' x 8' Metal or Wood 3 Hour “A” 7210MF Wide Surface
4' x 10' Alum/Metal None 7210 Narrow Surface
4' x 10' Metal or Wood None 7170 Wide Surface
8' x 10' Metal or Wood 1-1/2 Hour “B” 7170F90 Wide Surface
CONCEALED VERTICAL ROD (2 point latch):
4' x 10' Metal None 7120 Wide Surface
8' x 8' Metal 3 Hour “A” 7120F Wide Surface
4' x 10' Metal or Wood None 7160 Wide Mortise
8' x 10' Metal or Wood 1-1/2 Hour “B” 7160F90 Wide Mortise
4' x 10' Metal or Wood None 7220M Wide Surface
8' x 8' Metal 3 Hour “A” 7220MF Wide Surface
4' x 10' Alum/Metal None 7220 Narrow Surface
NOTE: Height must be specified when ordering Vertical Rod Exit Devices.
“-7” Openings up to 7' - Standard on 7110(F), 7210, 7210M(F), 7170 SVR.
“-8” Openings 7' to 8' - Optional on SVR. Std on 7120(F), 7220, 7220M(F), 7160
“-9” Openings 8' to 9' - Optional on 7170(F90), 7160(F90) CVR only.
“-10” Openings 9' to 10' - Optional on 7170(F90), 7160(F90) CVR only.
116
Effective Date: May 1, 2018
Canada Effective July 3, 2018
7 X X X Suffix Size Design Trim Finish Other Info.
Second
Digit:
“1”
Standard
device,
4-1/2"
(114mm) or
wider door
stile.
“2”
Narrow stile
door or
narrow
escutcheon
trim (500F,
510F Series)
Third Digit:
“0”
Rim Device,
Pullman Latch
"1"
SVR Device
“2”
CVR Device,
Metal Doors
“3”
Mortise Device
“5”
SquareBolt®,
Rim Security
“6”
CVR Device
“7”
SVR Device
Fourth
Digit:
“0”
Standard
“5”
Cylinder
Dogging
(Not with
suffix “F”)
Mechanical Feature
“F” - Fire Exit Device
“M” - Narrow escutcheon Trim in
4-1/2" (114mm) or wider door stile
“LBR” - Less Bottom Rod (Note 2)
“K5” - Mortise Device, EO or Entry by
Key with/ without Rigid Knob.
“K8” - Mortise Device, Entry by Knob
“L5” - Mortise Device, Entry by Key
with/ without Rigid Lever. (Note 1)
“L8” - Mortise Device, Entry by Lever
“T5” - Mortise Device with
Thumbpiece Trim
“T8” - Mortise Device, Active
Thumbpiece Trim
“2” - Double Cylinder Device (Note 3)
“WS” - Windstorm Certified Products
(Note 5, 6, 7)
ELECTRICAL FEATURE
“-A” - Alarm Kit
“-B” - Bar Monitor or Signaling
“-D” - Delayed Egress
“-G” - Electric Dogging
“-H” - Security Package (DPS)
“-O” -Outside Trim Monitor or
Signaling
“-P” - Latch Pullback
“-S” - Bolt Status Monitor or Signaling
“-Safe” - Mortise Device Trim Control
(Lever Only)
“-Secure” - Mortise Device Trim
Control (Lever Only)
Size:
DOW -
(Door
Opening
Width)
“24”
24" DOW
“36”
30" to 36"
DOW
“48”
36" to 48"
DOW
Door
Height:
-8 = 8'
(2.44m)
-9 = 9'
(2.74m)
-10 = 10'
(3.05m)
Trim
Design
(Lever or
knob only)
Trim
Model
Number
See
Page
114
Other
Information:
Door Hand
RHR or LHR
Door
Thickness
Over 1-3/4"
(45mm)
Fastener
Options
TORX®Security
Screws SNB
(wood, compos-
ite, or unrein-
forced metal
doors)
Specialty
Cylinders &
components
*Not approved for LBR
^Handed unit, handing must be specified
117
DISTRIBUTOR LIST PRICES
MECHANICAL OPTIONS
MODEL # PRODUCT DESCRIPTION
605 606 609 611 612
613E 616 619 620
629 630 693 BSP
RIM:
7100 Panic Rated $1,515.00
7100-2^ Panic Rated Double Cylinder $1,725.00
7100F Fire Rated $1,678.00
7100F-2^ Fire Rated Double Cylinder $1,888.00
SQUAREBOLT®:
7150 Panic Rated $1,583.00
7150-2^ Panic Rated Double Cylinder $1,793.00
7150WS Panic Rated Windstorm Certified $1,691.00
7150F Fire Rated $1,746.00
7150F-2^ Fire Rated Double Cylinder $1,956.00
7150FWS Fire Rated Windstorm Certified $1,854.00
SURFACE VERTICAL ROD:
7110 Panic Rated $1,959.00
7110F Fire Rated $2,122.00
7170 Panic Rated $2,012.00
7170WS* Panic Rated Windstorm Certified $2,120.00
7170F Fire Rated $2,175.00
7170FWS* Fire-Rated Windstorm Certified $2,283.00
CONCEALED VERTICAL ROD:
7120 Panic Rated $2,191.00
7120F Fire Rated $2,354.00
7160 Panic Rated $2,296.00
7160F Fire Rated $2,459.00
When Ordering: Specify width, hand and finish.
Specify height for vertical rods.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
7100 SERIES EXIT DEVICES
OPTION DESCRIPTION LIST PRICE
ADD
BPL Bottom Pullman Latch. Suffix BPL to 7110 & 7210M Panic Rated surface
vertical rod exits. $32.00
LBR Less Bottom Rod. Suffix LBR to 7160 & 7170 series only. $0.00
LUM Lumi-Lite®Photoluminescence Powder Coat. Suffix LUM to 7000 Series
touchpad cover only. $405.00
WS Windstorm certified. Suffix WS to 7150, 7170, 7250M
series exits. $108.00
YMS MicroShield®antimicrobial coating. Suffix YMS to model number for each
exit device or trim that the coating will be applied. $78.00
Cylinder Dogging Inside cylinder dogging for Panic Rated Exits only. Change fourth digit of
model number from “0” to “5”. (Less cylinder) $90.00
Door Height over 8' to 10' See catalog $102.00
988Y Surface Bolt Kit – For approved Windstorm code applications.
Bright zinc. $132.00
118
When Ordering: Specify design and finish.
MODEL # PRODUCT DESCRIPTION All Finishes
*121NL Nightlatch Trim $57.00
DISTRIBUTOR LIST PRICES
TRIM
FOR 7100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Not recommended for VR exit devices. See page 127 for cylinder options.
ROSE TRIMS
FOR 7100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(STANDARD CYLINDERS INCLUDED)
MODEL # PRODUCT DESCRIPTION 689 691 695
605 606 609 612
613E 616 619 620
625 626 693 BSP
541F AU-MO-PB Key-In-Lever – Nightlatch $429.00 $455.00
546F AU-MO-PB Key-In-Lever – Classroom
548F AU-MO-PB Active Lever – Dummy Free Wheeling $367.00 $393.00
549F AU-MO-PB Rigid Lever – Dummy Rigid
OPTIONS
B- Prefix for SFIC core prep Key-In-Lever Trim
Available with AU, MO, and PB levers.
ADD
$0.00
M- Prefix for Medeco®/ASSA®IC Core Prep Key-In-Lever Trim
Available with AU levers. $0.00
S- Prefix for Schlage®cylinder prep Key-In-Lever Trim
Available with AU, MO, and PB levers. $0.00
SI- Prefix for Schlage®IC Core Prep Key-In-Lever Trim.
Available with AU, MO, and PB levers.
NOTE: See Page 128 for other cylinder options.
Heavy-duty 600F Trim required for 7160 CVR Series escutcheon applications. 540F Rose Trim available.
119
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
HEAVY-DUTY ESCUTCHEON TRIMS
FOR 7100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 609 6112612 613E 616 619
620 626162916301693 BSP
620F Blank Escutcheon – Exit Only-Lever/Knob Prep $300.00
626F Lever x Escutcheon x Cylinder – Classroom/Storeroom
AR-AU-CR-JN-MO-PB-PN-VI-HA*
$511.00
627F Lever x Escutcheon x Cylinder – Nightlatch
AR-AU-CR-JN-MO-PB-PN-VI-HA*
628F Lever x Escutcheon – Passage and Dummy Free Wheeling
AR-AU-CR-JN-MO-PB-PN-VI-HA*
629F Lever x Escutcheon – Dummy Rigid
AR-AU-CR-JN-MO-PB-PN-VI-HA*
632F Pull x Escutcheon x Cylinder – Nightlatch $300.00
633F Pull x T.P. x Escutcheon x Cylinder – Classroom/Storeroom $422.00
634F Pull x Escutcheon – Dummy $300.00
635F Pull x T.P. x Escutcheon – Dummy/T-Piece $422.00
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
2. 611 finish is not available on 630, 660 and 670 Series Trims.
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
See Page 127 for cylinders if required.
MODEL # PRODUCT DESCRIPTION 605 606 611 612 613E
619 626162916301BSP
626F Lever x Escutcheon x Cylinder – Classroom/Storeroom
$511.00
627F Lever x Escutcheon x Cylinder – Nightlatch
628F Lever x Escutcheon – Passage and Dummy Free Wheeling
629F Lever x Escutcheon – Dummy Rigid
WITH REFLECTIONS®SERIES LEVER DESIGNS:
120
DISTRIBUTOR LIST PRICES
HEAVY-DUTY OFFSET PULL TRIMS
FOR 7100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
When Ordering: Specify design and finish.
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 626162916301693 BSP
680F Offset Pull x Escutcheon (7-1/4") – Dummy $485.00
681F Offset Pull x Escutcheon x Cyl (7-1/4") – Nightlatch
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 626162916301693 BSP
690F Lever x Escutcheon x Cylinder x Fail Safe
AR-AU-CR-JN-MO-PB-PN-VI
$1,069.00
691F Lever x Escutcheon x Cylinder x Fail Secure
AR-AU-CR-JN-MO-PB-PN-VI
SM SPDT Lock and Unlock Monitor Switch $272.00
EX Trim Gasket for Exterior Applications $29.00
HEAVY-DUTY ELECTRIFIED TRIM
FOR 7100 SERIES RIM, SQUAREBOLT®, SVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
See Page 126 for cylinders if required.
NOTE: Heavy-duty 600F Trim required for 7160 CVR Series escutcheon applications. 540F Rose Trim available.
MODEL # PRODUCT DESCRIPTION 605 606 611 612 613E 619
626162916301BSP
690F Lever x Escutcheon x Cylinder x Fail Safe $1,069.00
691F Lever x Escutcheon x Cylinder x Fail Secure
WITH REFLECTIONS®SERIES LEVER DESIGNS:
121
DISTRIBUTOR LIST PRICES
7130 SERIES MORTISE EXIT DEVICES
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 629 630 693 BSP
MORTISE:
7130 Panic Rated $1,979.00
7130-2 Panic Rated Double Cylinder $2,189.00
7130F Fire Rated $2,142.00
7130F-2 Fire Rated Double Cylinder $2,352.00
When Ordering: Specify weight, height, hand and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
122
DISTRIBUTOR LIST PRICES
When Ordering: Specify design and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
HEAVY-DUTY ESCUTCHEON TRIMS
FOR 7130 SERIES MORTISE EXIT DEVICES
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 609 6112612 613E 616
619 620 626162916301693 BSP
620F Blank Escutcheon – Exit Only-Lever/Knob Prep $300.00
634F Pull x Escutcheon – Dummy $300.00
656F Lever x Escutcheon x Cylinder – Nightlatch
AR-AU-CR-JN-MO-PB-PN-VI $511.00
658F Lever x Escutcheon – Dummy Trim
AR-AU-CR-JN-MO-PB-PN-VI
661F Escutcheon x Cylinder – Nightlatch $217.00
662F Pull x Escutcheon x Cylinder – Nightlatch $300.00
673F Pull x T.P. x Escutcheon x Cylinder – Classroom/Storeroom x TT $422.00
675F Pull x T.P. x Escutcheon – Passage x T-Piece
HEAVY-DUTY OFFSET PULL TRIM
FOR 7130 SERIES MORTISE EXIT DEVICES
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616 619
620 626162916301693 BSP
684F Offset Pull x Escutcheon x Cylinder (7-1/4") – Nightlatch $514.00
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trim if ordered less cylinder.
See Page 127 for cylinders are required.
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
2. 611 finish is not available on 630, 660 and 670 Series Trims.
MODEL # PRODUCT DESCRIPTION 605 606 611 612 613E
619 626162916301BSP
656F Lever x Escutcheon x Cylinder – Nightlatch $511.00
658F Lever x Escutcheon – Dummy
WITH REFLECTIONS®SERIES LEVER DESIGNS:
123
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
7200 SERIES NARROW STILE EXIT DEVICES
When Ordering: Specify width, hand and finish.
Specify height for vertical rods.
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 629 630 693 BSP
PANIC EXIT DEVICES:
7200 Rim Panic Rated $1,897.00
7250 SquareBolt®Panic $1,965.00
7210 SVR Panic Rated $2,341.00
7220 CVR Panic Rated $2,453.00
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 629 630 693 BSP
RIM:
7200M Panic Rated $1,897.00
7200MF Fire Rated $2,060.00
SQUAREBOLT®:
7250M Panic Rated $1,965.00
7250MWS Panic Rated Windstorm Certified $2,073.00
7250MF Fire Rated $2,128.00
7250MFWS Fire Rated Windstorm Certified $2,236.00
SURFACE VERTICAL ROD:
7210M Panic Rated $2,341.00
7210MF Fire Rated $2,504.00
CONCEALED VERTICAL ROD:
7220M Panic Rated $2,453.00
7220MF Fire Rated $2,616.00
7200M SERIES NARROW DESIGN EXIT DEVICES
MODEL # PRODUCT DESCRIPTION All Finishes
*121NL Nightlatch Trim $57.00
TRIM
FOR 7200 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
Not recommended for VR exit devices. See page 127 for cylinder options.
TRIM
124
DISTRIBUTOR LIST PRICES
When Ordering: Specify design and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NARROW ESCUTCHEON TRIMS
FOR 7200 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trims ordered less cylinders.
See Page 127 for cylinders if required.
1. See the Variations page for details.
STANDARD DUTY OFFSET PULL TRIMS
FOR 7200 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 626 629 630 693 BSP
480F Offset Pull x Escutcheon (7-1/4") – Dummy
$426.00
481F Offset Pull x Escutcheon x Cyl (7-1/4") – Nightlatch
482F Offset Pull x Escutcheon (9", 15" & 18") – Dummy
483F Offset Pull x Esc x Cyl (9", 15" & 18") – Nightlatch
MODEL # PRODUCT DESCRIPTION 605 606 611 612
613E 619 626 62916301
506F Lever x Escutcheon x Cylinder – Classroom/Storeroom
$572.00508F Lever x Escutcheon – Passage/Dummy
509F Lever x Escutcheon – Dummy
WITH REFLECTIONS®SERIES LEVER DESIGNS:
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 626 629 630 693 BSP
500F Blank Escutcheon – Exit Only $222.00
501F Escutcheon x Cylinder – Nightlatch
502F Knob x Escutcheon x Cylinder – Classroom/Storeroom
CO-LF $396.00
503F Thumbturn x Escutcheon x Cylinder – Classroom/Storeroom x TT $434.00
504F Knob x Escutcheon – Passage
CO-LF $396.00
505F Knob x Escutcheon – Dummy
CO-LF
506F Lever x Escutcheon x Cylinder – Classroom/Storeroom
AR-AU-CR-JN-MO-PB-PN-VI-HA* $572.00
507F Thumbturn x Escutcheon – Passage x TT $434.00
508F Lever x Escutcheon – Passage/Dummy
AR-AU-CR-JN-MO-PB-PN-VI-HA* $572.00
509F Lever x Escutcheon – Dummy
AR-AU-CR-JN-MO-PB-PN-VI-HA*
512F Pull x Escutcheon x Cylinder – Nightlatch $255.00
513F Pull x Escutcheon x Thumbturn x Cylinder – Classroom/Storeroom x TT $532.00
514F Pull x Escutcheon – Nightlatch – Dummy Trim $255.00
517F Pull x Escutcheon x Thumbturn – Classroom/Storeroom x TT – Passage $532.00
518F Pull x Escutcheon x Thumbpiece x Cylinder – Classroon/Storeroom x
T-Piece $503.00
519F Pull x Escutcheon x Thumbpiece – Passage x T-Piece
ELECTRIFIED OPTIONS CHART:
ELECTRIFIED OPTIONS:
*Only available for rim and SquareBolt®devices when used with Delayed Egress option.
NOTE: Latchbolt status monitor required for 7110, 7170 and 7210 series surface vertical rod exit devices with alarms.
Example: 7110AS x Door Width x Door Height x RHR x 630
7000 SERIES ELECTRIFIED EXIT DEVICES
OPTION DESCRIPTION LIST PRICE
ADD
A Alarm Kit (less cylinder) $700.00
B Touchbar Monitoring or Signaling $220.00
D Delayed Egress $1,658.00
G Electric Dogging $450.00
H* Security Package (DPS) $493.00
O Trim Monitoring or Signaling $220.00
P Latch Retraction $941.00
S Latchbolt Status Monitoring or Signaling $235.00
SAFE Mortise Device Lock with Outside Trim Control (Fail Unlock) – Lever Trims Only $735.00
SECURE Mortise Device Lock with Outside Trim Control (Fail Lock) – Lever Trims Only
125
DISTRIBUTOR LIST PRICES
When Ordering: Specify design and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
7000 SERIES ELECTRIFIED EXIT DEVICES
MODEL # PRODUCT DESCRIPTION LIST PRICE
7116-36 Alarm Kit (Less cylinder)
$700.007116-48 Alarm Kit (Less cylinder)
7216-36 Alarm Kit (Less cylinder)
NOTE: The 7116 alarm kit cannot be retrofitted in the filed to the 7110(F), 7170(F), 7210 or 7210M(F) surface vertical rod
exit devices. This option is available as a factory order only.
ALARM KITS:
MODEL # EXIT DEVICE DESCRIPTION A B D G H O P S SAFE SECURE
7100(F) Rim Exit Device (Wide) x x x x x x x x
7110(F) Surface Vertical Rod (Wide) x x x x x x x
7120(F) Concealed Vertical Rod (Wide) x x x x x x x
7130(F) Mortise Exit Device (Wide) x x x x x x x x x
7150(F) Rim SquareBolt®Device (Wide) x x x x x x x x
7150(F)WS Rim SquareBolt®Windstorm (Wide) x x x x x
7160(F90) Concealed Vertical Rod (Wide) x x x x x x x
7170(F90) Surface Vertical Rod (Wide) x x x x x x x
7170(F90)WS Surface Vertical Rod Windstorm (Wide) x x x x x
7200(M)(F) Rim Exit Device (Narrow) x x x x x x
7210(M)(F) Surface Vertical Rod (Narrow) x x x x x x
7220(M)(F) Concealed Vertical Rod (Narrow) x x x x x x
7250(M)(F) Rim SquareBolt®Device (Narrow) x x x x x x
When Ordering: Specify finish.
Specify cylinder ring/collar size where required. 126
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
7000 SERIES DELAYED EGRESS EXIT DEVICES
SUFFIX PRODUCT DESCRIPTION LIST PRICE
OPTION ADDS
NFPA 30 30-Second Delay Board "NFPA"
N/CBOCA 15 15-Second Delay Board "BOCA"
BOCA 30 30-Second Delay Board "BOCA"
OPTIONS AVAILABLE WITH RIM, SQUAREBOLT®EXITS:
D Delayed Exit Only or with Outside Trim Entry $1,658.00
D x S Delayed Exit Only or Outside Trim Entry with Bolt Monitor $1,893.00
D x H Delayed Exit Only with Security Package $2,151.00
D x H x S Delayed Exit Only with Security Package and Bolt Monitor $2,386.00
D x H x O Delayed Exit with Outside Trim Entry with Security Package $2,371.00
D x H x O x S Delayed Exit with Outside Trim Entry with Security Package and Bolt Monitor $2,606.00
OPTIONS AVAILABLE WITH CONCEALED VERTICAL ROD EXITS:
D Delayed Exit Only or Outside Trim Entry $1,658.00
D x S Delayed Exit Only or Outside Trim Entry with Vertical Rod Monitor $1,893.00
D x O Delayed Exit with Outside Trim Entry with DPS by others $1,878.00
D x S x O Delayed Exit with Outside Trim Entry with Vertical Rod Monitor and DPS by others $2,113.00
OPTIONS AVAILABLE WITH MORTISE EXITS:
D Delayed Exit Only or Outside Trim Entry $1,658.00
D x O Delayed Exit with Outside Trim Entry with DPS by others $1,878.00
D x SAFE Delayed Exit with Electric Trim Control Fail Safe $2,393.00
D x SECURE Delayed Exit with Electric Trim Control Fail Secure
NOTES: Suffix options required to product model number.
See page 210 for power supplies and electrified accessories.
127
DISTRIBUTOR LIST PRICES
CYLINDERS
When Ordering: Specify finish.
Specify cylinder ring/collar size where required.
MODEL # PRODUCT DESCRIPTION *ALL
FINISHES
RIM CYLINDERS FOR 480F, 500F, 510F, 620F, 630F, 680F, 690F SERIES AND 121NL NIGHTLATCH TRIM:
1109 Standard Cylinder 6-Pin $70.00
1109 Standard Cylinder 7-Pin $72.00
1709 CMK Cylinder 6-Pin $86.00
1709 CMK Cylinder 7-Pin $88.00
1193 Large Format Interchangeable Core Cylinder 6-Pin $128.00
1193 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5109 Security Cylinder 6-Pin $280.00
5109 Security Cylinder 7-Pin $284.00
U5109 High Security Cylinder 6-Pin $376.00
U5109 High Security Cylinder 7-Pin $380.00
5193 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5193 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K300 Yale®KeyMark®Cylinder 6- or 7-Pin $90.00
K840 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K640 Yale KeyMark Small Format Interchangeable Core Cylinder 6- or 7-Pin $150.00
A640 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
2109 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
MORTISE CYLINDERS FOR 650F, 660F, 670F, 680F SERIES TRIM & CYLINDER DOGGING:
2153 Standard Cylinder 6-Pin $70.00
2153 Standard Cylinder 7-Pin $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5153 Security Cylinder 6-Pin $280.00
5153 Security Cylinder 7-Pin $284.00
U5153 High Security Cylinder 6-Pin $376.00
U5153 High Security Cylinder 7-Pin $380.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin $83.00
K820 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K620 Yale KeyMark Small Format Interchangeable Core Cylinder 6-Pin or 7-Pin $150.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: Cylinder rings/collars furnished at no charge when ordered with cylinder.
Specify ring/collar size when ordering.
*Rim cylinders not available in 629 or 630 finishes.
128
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CYLINDERS
When Ordering: Specify finish.
Specify cylinder ring/collar size where required.
MISCELLANEOUS
MODEL # PRODUCT DESCRIPTION LIST PRICE
LONG SPINDLE KIT:
81-9500-1665-000 2" – 2-1/2" door thickness for 620F and 630F series trim $37.00
81-9500-1635-000 2-1/2" – 3-1/2" door thickness for 620F and 630F series trim $78.00
81-9500-1636-000 3-1/2" – 4-1/2" door thickness for 620F and 630F series trim
MISCELLANEOUS
MODEL # PRODUCT DESCRIPTION ADD TO
TRIM
ORDERED
SEPARATELY
COMPONENT CYLINDERS FOR 540F SERIES TRIM:
1802 Standard Cylinder 6-Pin STD $62.00
1802A Standard Cylinder 7-Pin $2.00 $64.00
5802 Security Cylinder 6-Pin $184.00 $246.00
5802A Security Cylinder 7-Pin $188.00 $250.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
1220 Large Format Interchangeable Core Only 7-Pin $60.00 $60.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
5220 Security Large Format Interchangeable Core Only 7-Pin $230.00 $230.00
K402 Yale®KeyMark®Cylinder $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-or 7-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $0.00 $62.00
3804 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $15.00 $77.00
Yale®KeyMark®and Security products are priced separately. The cylinders are not discounted the same as the trim.
MISCELLANEOUS
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
CYLINDER DOGGING KIT:
715-48 Cylinder Dogging Kit (less cylinder) $166.00
129
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E
616 619 620 629 630 693 BSP
DUMMY PUSH BAR:
720 DB Dummy Push Bar $656.00
MODEL # PRODUCT DESCRIPTION ORDERED W/
DEVICE ADD
ORDERED
SEPARATELY
TOUCH PAD COVERS: (INDICATE LENGTH, 36" OR 48")
730 BN Black Nylon Finish $69.00 $135.00
730 SS Stainless Steel N/C $120.00
730 (FIN) Specify Finish –– $137.00
730 LUM Lumi-Lite®Photoluminescence Powder Coat (Indicate "LUM" option with device) $405.00 $499.00
MODEL # PRODUCT DESCRIPTION ORDERED W/
DEVICE ADD
ORDERED
SEPARATELY
STRIKES (BLACK):
702 Floor Strike (optional) –– $35.00
712 Strike for Overlapping Astragal (optional for 7130) ––
718 Open Back Strike (optional) $112.00 $147.00
726 Strike and Angle Bracket –– $67.00
757F Rim Strike 7100(F), 7200M(F) –– $62.00
757FWS Rim Strike for Windstorm Devices 7150(F)WS, 7250M(F)WS –– $88.00
759 Rim Strike, 7200 –– $45.00
761 Top Strike Recessed 7160(F) –– $67.00
790 Floor Strike –– $35.00
791 Top Strike –– $67.00
793 Rim Strike (optional) –– $57.00
794 Bottom Flush Strike (optional) –– $35.00
797 Top Strike Bracket (SVR optional) –– $6.00
798 Mortise Strike –– $35.00
202 Strike Box (not finished, optional) $2.00 $2.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MISCELLANEOUS
130
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish where required.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MISCELLANEOUS
PRODUCT # PRODUCT DESCRIPTION ALL
FINISHES
EXTENSIONS FOR 7000 SERIES VERTICAL RODS:
7010-2 2" Extension $70.00
7010-6 6" Extension $84.00
7010-12 12" Extension $98.00
7010-24 24" Extension $119.00
DOGGING KEY: (size 5/16" - no finish) $2.00
DRILL JIG: (throw away - no finish)
PRODUCT # PRODUCT DESCRIPTION BLACK
SHIM KITS TO CLEAR GLASS MOLDING:
723 7100 Series Rim, Mortise & CVR $104.00
723NS 7200 Series Rim & CVR
724 7110, 7170 Series SVR $140.00
724NS 7210 Series SVR
723WS 7150(F)WS Windstorm
$153.00723NSWS 7250M(F)WS Windstorm
724WS 7170(F)WS Windstorm
ANTI-PRY:
725 7100 Rim and 7150 SquareBolt®Anti-pry Bracket $53.00
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
MORTISE LOCKS:
35LF Mortise Lock Storeroom - Lever Trim
$585.00
35KF Mortise Lock Storeroom - Knob Trim
35TF Mortise Lock Storeroom - Thumbpiece Trim
38LF Mortise Lock Classroom - Lever Trim
38KF Mortise Lock Classroom - Knob Trim
38TF Mortise Lock Classroom - Thumbpiece Trim
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
END CAP KITS AND MISC:
ECK1 Flush End Cap Kit (81-9500-0620-FIN) No charge when ordered with device. $80.00
ECK3 Reinforced End Cap Kit (specify finish). When Ordered with Device or When Ordered
Separately. $60.00
ECK7 Standard End Cap Kit
No charge when ordered with device. $69.00
60-7000-0815 Schlage®cam and housing assembly $27.00
1145VD Tailpiece for 1109 cylinders to operate Von Duprin®$4.10
PART # PRODUCT DESCRIPTION LIST PRICE
60-7000-9100-999 Plastic Installation Template used for installation of all 7100 and 7200 Devices $3.30
131
DISTRIBUTOR LIST PRICES
REMOVABLE MULLIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: Cylinder collars are furnished at no charge when ordered with cylinder. Specify collar size when ordering.
MODEL # PRODUCT DESCRIPTION 600 628 695
REMOVABLE MULLIONS:
M200 Steel Mullion - Panic Rated x 7' $622.00
—
M200 Steel Mullion - Panic Rated x 8' $638.00
M200 Steel Mullion - Panic Rated x 10' $777.00
M200F Steel Mullion – 3 Hour Fire Rated x 7' $865.00
M200F Steel Mullion – 3 Hour Fire Rated x 8' $880.00
M200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 7'* $1,189.00
M200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 8'* $1,206.00
M300 Aluminum Mullion —$1,037.00
KEYED REMOVABLE MULLIONS:
KRM200 Steel Mullion - Panic Rated x 7' $1,035.00
—
KRM200 Steel Mullion - Panic Rated x 8' $1,047.00
KRM200 Steel Mullion – Panic Rated x 10' $1,184.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 7' $1,250.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 8' $1,266.00
KRM200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 7' $1,552.00
KRM200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 8' $1,565.00
*For use with UL Listed door assemblies that comply to FEMA 361 and ICC 500.
NOTE: Cylinders ordered separately, not included with KRM mullions
MODEL PRODUCT DESCRIPTION CYLINDER
LENGTH
COLLAR SIZE ALL
FINISHES
STD. MULLION / WS
MULLION
MORTISE CYLINDERS FOR KRM SERIES: (CYLINDERS ARE NOT INCLUDED WITH MULLIONS, MUST BE ORDERED
SEPARATELY)
2153 Standard Cylinder 6-Pin 1-1/8" 1765.312 1765.156 $70.00
2153 Standard Cylinder 7-Pin 1-1/4" 1765.500 1765.250 $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 1765.500 $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 1765.719 $130.00
5153 Security Cylinder 6-Pin 1-1/8" 1765.312 1765.156 $280.00
5153 Security Cylinder 7-Pin 1-1/4" 1765.500 1765.250 $284.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 1765.500 $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 1765.719 $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/8" 1765.312 1765.156 $83.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/4" 1765.500 1765.250
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/2" 1765.750 1765.500 $177.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 1765.500 $153.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 1765.719
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 1765.250
$150.00
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6- or
7-Pin 1-3-8" 1765.563 1765.500
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 1765.250
$120.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or
7-Pin 1-3-8" 1765.563 1765.500
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random 1-1/8" 1765.312 1765.156 $70.00
132
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
M102S Mullion Stabilizer Kit (for M300) $83.00
M203 Door Frame Spacer Block
$46.00
M204 Door Frame Angle Bracket
60-7000-0750 Locking Mechanism for KRM200(F) $445.00
60-7000-0752 Locking Mechanism for KRM200FWS $466.00
60-7000-0755 Top Retainer Pack for KRM200(F) $194.00
60-7000-0757 Top Retainer Pack for KRM200FWS
$206.00
60-7000-0758 Top Retainer Pack for M200FWS x 7' or 8'
60-7000-0759 Top Retainer Pack for M200(F) x 7' or 8' $194.00
60-7000-0760 Bottom Retainer Pack for KRM200(F) $131.00
60-7000-0761 Bottom Retainer Pack for KRM200FWS
$206.00
60-7000-0762 Bottom Retainer Pack for M200FWS x 7' or 8'
60-7000-0763 Bottom Retainer Pack for M200(F) x 7' or 8' $131.00
PARTS AND ACCESSORIES
133
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
132
Effective Date: May 1, 2018
Canada Effective July 3, 2018
6000 SERIES EXIT DEVICES
When Ordering: Specify design, hand and finish.
VARIATIONS: Exit Devices and Trims are priced separately. In order to determine the full list price of a 6000 Series Exit Device with trim,
it is necessary to add the list price of the device model number and the list price of the trim model number.
STANDARD FINISHES: Exit devices will have an anodized aluminum rail assembly in a complimentary finish. Touchpad scalp and
exit device head cover are available in the following finishes.
PRODUCT OPTIONS ADD
DESIGNER LEVER: (HA) $233.00
DUST GUARD: Prefix "D" to model number (refer to Cylinders/Keys catalog for available cylinders) $47.00
DOOR WIDTH:
30"-36" Door Width (Suffix -36 ) STD
36"-48" Door Width (Suffix -48) $48.00
Door thickness: Doors over 2-1/4" $41.00
SLEEVE NUTS: Factory orders only for exact quantity
SN-104 (For interlock bracket on fire-rated mullions) $4.00
SN-134 (4 Pack) $5.40
TORX®SECURITY HEAD SCREWS: Standard size only
Rim Exit Device $37.00
UL Rim Exit Device
Surface Vertical Rod Exit Device (SVR) $96.00
Concealed Vertical Rod Exit Device (CVR) $37.00
Mortise Exit Device $67.00
630F, 660F, 670F Series Trim $6.00
121NL, 350F, 540F, 620F, 650F, 680F, 690F Series Trim N/A
ABRASIVE COATING: On Touchbar Pad $74.00
KNURLING: .
On Touch Pad, available in all finishes $142.00
For outside trim $75.00
MICROSHIELD®:Antimicrobial coating. Suffix YMS to model number for each exit device or trim that
the coating will be applied. Coating applied to exit device touchpad & cover only. $78.00
REFLECTION LEVERS: The following levers are no longer available in 629 and 630 finishes, TT, TU,
TV, TW, TX, TY, UW, UX, TZ, TG, TJ, TK, TO, TE, TI and TD. —
ANSI/BHMA
CODE FINISH DESCRIPTION
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
PAINTED:
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
BRONZE:
613E Dark Oxidized Satin Bronze - equivalent
CYLINDERS: Standard 6-Pin cylinders included with 540F Series Rose Trim only. All other keyed trim priced less
cylinder, the list price of the cylinder must be added if cylinders are required. Specify cylinder and cylinder collar with
collar size.
NOTES:
1. Required for electrical feature, Suffix “-SAFE” or “-SECURE”.
2. LBR available on 6160(F90) and 6170(F90) devices only.
3. For double cylinder devices, suffix “-2” after fourth digit.
4. “WS” applies only to 6150(F) and 6170(F) devices.
5. Maximum opening size 8'0" x 8'0".
6. Contact Ceco, Curries®or Fleming for detailed frame/door
requirements and limitations.
DISTRIBUTOR LIST PRICES
HOW TO ORDER
MAX. OPENING DOOR TYPE FIRE RATING MODEL NO. STYLE STRIKE
SURFACE VERTICAL ROD (2 point latch):
4' x 10' Alum/Metal None 6210 Narrow Surface
4' x 10' Metal or Wood None 6170 Wide Surface
8' x 10' Metal or Wood 1-1/2 Hour “B” 6170F Wide Surface
CONCEALED VERTICAL ROD (2 point latch):
4' x 10' Metal or Wood None 6160 Wide Mortise
8' x 10' Metal or Wood 1-1/2 Hour “B” 6160F Wide Mortise
4' x 10' Alum/Metal None 6220 Narrow Surface
NOTE: Height must be specified when ordering Vertical Rod Exit Devices.
“-7” Openings up to 7' - Standard on 6170(F), 6210, 6170 SVR.
“-8” Openings 7' to 8' - Optional on SVR. Std on 6160(F), 6220, 6160
“-9” Openings 8' to 9' - Optional on 6170(F90), 6160(F90) CVR only.
“-10” Openings 9' to 10' - Optional on 6170(F90), 6160(F90) CVR only.
134
6 X X X Suffix Size Design Trim Finish Other Info.
Second
Digit:
“1”
Standard
device,
4-1/2"
(114mm) or
wider door
stile.
“2”
Narrow stile
door or
narrow
escutcheon
trim (500F,
510F Series)
Third Digit:
“0”
Rim Device,
Pullman Latch
"1"
SVR Device
“2”
CVR Device
“3”
Mortise Device
“5”
SquareBolt®,
Rim Security
“6”
CVR Device
“7”
SVR Device
Fourth
Digit:
“0”
Standard
“5”
Cylinder
Dogging
(Not with
suffix “F”)
Mechanical Feature
“F” - Fire Exit Device
“LBR” - Less Bottom Rod (Note 2)
“K5” - Mortise Device, EO or Entry by
Key with/ without Rigid Knob.
“K8” - Mortise Device, Entry by Knob
“L5” - Mortise Device, Entry by Key
with/ without Rigid Lever. (Note 1)
“L8” - Mortise Device, Entry by Lever
“T5” - Mortise Device with
Thumbpiece Trim
“T8” - Mortise Device, Active
Thumbpiece Trim
“2” - Double Cylinder Device (Note 3)
“WS” - Windstorm Certified Products
(Note 4,5,6)
ELECTRICAL FEATURE
“-A” - Alarm Kit
“A-ALR” - Alarm Kit (less cylinder)
with red screen printed touchpad
“-B” - Bar Monitor or Signaling
“-G” - Electric Dogging
“-H” - Security Package (DPS)
“-O” -Outside Trim Monitor or
Signaling
“-P” - Latch Pullback
“-S” - Bolt Status Monitor or Signaling
“-Safe” - Mortise Device Trim Control
(Lever Only)
“-Secure” - Mortise Device Trim
Control (Lever Only)
Size:
DOW =
Door
Opening
Width)
“24” -
24” DOW
“36” -
30" to 36"
DOW
42" -
36"-42"
DOW
“48” -
42" to 48"
DOW
Door
Height:
-7 = 7'
standard
-8 = 8'
(2.44m)
-9 = 9'
(2.74m)
-10 = 10'
(3.05m)
Trim
Design
(Lever or
knob only)
Trim
Model
Number
See
Page
133
Other
Information:
Door Hand
RHR or LHR
Door
Thickness
Over 1-3/4"
(45mm)
Fastener
Options
TORX®Security
Screws SNB
(wood, compos-
ite, or unrein-
forced metal
doors)
Specialty
Cylinders &
components
Effective Date: May 1, 2018
Canada Effective July 3, 2018
135
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Not approved for LBR
^Handed unit, handing must be specified
MECHANICAL OPTIONS
MODEL # PRODUCT DESCRIPTION 605 606 613E 629 630 BSP
RIM:
6100 Panic Rated $957.00
6100-2^ Panic Rated Double Cylinder $1,167.00
6100F Fire Rated $1,120.00
6100F-2^ Fire Rated Double Cylinder $1,330.00
SQUAREBOLT®:
6150 Panic Rated $1,025.00
6150-2^ Panic Rated Double Cylinder $1,235.00
6150WS Panic Rated Windstorm Certified Currently Not Available
6150F Fire Rated $1,188.00
6150F-2^ Fire Rated Double Cylinder $1,398.00
6150FWS Fire Rated Windstorm Certified Currently Not Available
SURFACE VERTICAL ROD:
6170 Panic Rated $1,329.00
6170WS* Panic Rated Windstorm Certified Currently Not Available
6170F Fire Rated $1,492.00
6170FWS* Fire-Rated Windstorm Certified Currently Not Available
CONCEALED VERTICAL ROD:
6160 Panic Rated $1,399.00
6160F Fire Rated $1,562.00
When Ordering: Specify width, hand and finish.
Specify height for vertical rods.
6100 SERIES EXIT DEVICES
OPTION DESCRIPTION LIST PRICE
ADD
BPL Bottom Pullman Latch. Suffix BPL to 6210 Panic Rated surface vertical rod
exits. $32.00
LBR Less Bottom Rod. Suffix LBR to 6160 & 6170 series only. $0.00
WS Windstorm certified. Suffix WS to 6150, 6170 series exits. Currently not
Available
YMS MicroShield®antimicrobial coating. Suffix YMS to model number for each
exit device or trim that the coating will be applied. $78.00
Cylinder Dogging Inside cylinder dogging for Panic Rated Exits only. Change fourth digit of
model number from “0” to “5”. (Less cylinder) $90.00
Door Height over 8' to 10' See catalog $102.00
988Y Surface Bolt Kit – For approved Windstorm code applications.
Bright zinc.
Currently not
Available
136
When Ordering: Specify design and finish.
MODEL # PRODUCT DESCRIPTION All Finishes
*121NL Nightlatch Trim $57.00
DISTRIBUTOR LIST PRICES
TRIM
FOR 6100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
Not recommended for VR exit devices. See page 145 for cylinder options.
ROSE TRIMS
FOR 6100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(STANDARD CYLINDERS INCLUDED)
MODEL # PRODUCT DESCRIPTION 605 606 613E
626 BSP
541F AU-MO-PB Key-In-Lever – Nightlatch $455.00
546F AU-MO-PB Key-In-Lever – Classroom
548F AU-MO-PB Active Lever – Dummy Free Wheeling $393.00
549F AU-MO-PB Rigid Lever – Dummy Rigid
TRIM OPTION PREFIXES
B- Prefix for SFIC core prep Key-In-Lever Trim
Available with AU, MO, and PB levers.
ADD
$0.00
M- Prefix for Medeco®/ASSA®IC Core Prep Key-In-Lever Trim
Available with AU levers. $0.00
S- Prefix for Schlage®cylinder prep Key-In-Lever Trim
Available with AU, MO, and PB levers. $0.00
SI- Prefix for Schlage®IC Core Prep Key-In-Lever Trim.
Available with AU, MO, and PB levers.
NOTE: See Page 146 for other cylinder options.
Heavy-duty 600F Trim required for 6160 CVR Series escutcheon applications. 540F Rose Trim available.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
137
DISTRIBUTOR LIST PRICES
When Ordering: Specify design, hand and finish.
136
HEAVY-DUTY ESCUTCHEON TRIMS
FOR 6100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 613E
62916301BSP
626F Lever x Escutcheon x Cylinder
AR-AU-CR-JN-MO-PB-PN-VI
$511.00
627F Lever x Escutcheon x Cylinder
AR-AU-CR-JN-MO-PB-PN-VI
628F Lever x Escutcheon
AR-AU-CR-JN-MO-PB-PN-VI
629F Lever x Escutcheon
AR-AU-CR-JN-MO-PB-PN-VI
632F Pull x Escutcheon x Cylinder $300.00
633F Pull x T.P. x Escutcheon x Cylinder $422.00
634F Pull x Escutcheon $300.00
635F Pull x T.P. x Escutcheon $422.00
1. Escutcheon is plated to simulate Stainless Steel.
NOTE: Cylinder reference indicates function only, all trims are less cylinder. See Page 145 for cylinders if required.
See page 161 for 420F and 440F trim pricing.
MODEL # PRODUCT DESCRIPTION 605 606 613E
62916301BSP
626F Lever x Escutcheon x Cylinder
$511.00
627F Lever x Escutcheon x Cylinder
628F Lever x Escutcheon
629F Lever x Escutcheon
WITH REFLECTIONS®SERIES LEVER DESIGNS:
MODEL # PRODUCT DESCRIPTION 626
ROSE TRIMS: (Standard Cylinders Included)
441F AU-MO-PB Key-In-Lever $183.00
446F AU-MO-PB Key-In-Lever
448F AU-MO-PB Active Lever $151.00
449F AU-MO-PB Rigid Lever
MODEL # PRODUCT DESCRIPTION 630
420F Blank Escutcheon Plate $221.00
421F Escutcheon x Cylinder
426F Lever x Escutcheon x Cylinder AU-MO-PB
$296.00
427F Lever x Escutcheon x Cylinder AU-MO-PB
428F Lever x Escutcheon AU-MO-PB
429F Lever x Escutcheon AU-MO-PB
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trims ordered less cylinders.
All 420F series and 440F series trims are discounted the same as the 2100 exit.
NOTE: All 420F series and 440F series trims are discounted the same as the 2100 exit.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
138
DISTRIBUTOR LIST PRICES
HEAVY-DUTY ELECTRIFIED TRIM
FOR 6100 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
When Ordering: Specify design and finish.
MODEL # PRODUCT DESCRIPTION 605 606 613E
62916301BSP
690F Lever x Escutcheon x Cylinder x Fail Safe
AR-AU-CR-JN-MO-PB-PN-VI
$1,069.00
691F Lever x Escutcheon x Cylinder x Fail Secure
AR-AU-CR-JN-MO-PB-PN-VI
SM SPDT Lock and Unlock Monitor Switch $272.00
EX Trim Gasket for Exterior Applications $29.00
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
See Page 145 for cylinders if required.
NOTE: Heavy-duty 600F Trim required for 6160 CVR Series escutcheon applications. 540F Rose Trim available.
MODEL # PRODUCT DESCRIPTION 605 606 613E 62916301BSP
690F Lever x Escutcheon x Cylinder x Fail Safe $1,069.00
691F Lever x Escutcheon x Cylinder x Fail Secure
WITH REFLECTIONS®SERIES LEVER DESIGNS:
Effective Date: May 1, 2018
Canada Effective July 3, 2018
139
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
6130 SERIES MORTISE EXIT DEVICES
MODEL # PRODUCT DESCRIPTION 605 606 613E 629 630 BSP
MORTISE:
6130 Panic Rated $1,283.00
6130-2 Panic Rated Double Cylinder $1,493.00
6130F Fire Rated $1,446.00
6130F-2 Fire Rated Double Cylinder $1,656.00
When Ordering: Specify weight, height, hand and finish.
140
DISTRIBUTOR LIST PRICES
When Ordering: Specify design and finish.
HEAVY-DUTY ESCUTCHEON TRIMS
FOR 6130 SERIES MORTISE EXIT DEVICES
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 613E 62916301BSP
634F Pull x Escutcheon – Dummy $300.00
651F Escutcheon x Cylinder – Nightlatch
656F Lever x Escutcheon x Cylinder – Nightlatch
AR-AU-CR-JN-MO-PB-PN-VI $511.00
658F Lever x Escutcheon – Dummy
AR-AU-CR-JN-MO-PB-PN-VI
662F Pull x Escutcheon x Cylinder – Nightlatch $300.00
673F Pull x T.P. x Escutcheon x Cylinder – Classroom/Storeroom $422.00
675F Pull x T.P. x Escutcheon – Dummy/T-Piece
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trim if ordered less cylinder.
See Page 145 for cylinders are required.
MODEL # PRODUCT DESCRIPTION 605 606 613E 62916301BSP
656F Lever x Escutcheon x Cylinder – Nightlatch $511.00
658F Lever x Escutcheon – Dummy Trim
WITH REFLECTIONS®SERIES LEVER DESIGNS:
Effective Date: May 1, 2018
Canada Effective July 3, 2018
141
DISTRIBUTOR LIST PRICES
140
6200 SERIES NARROW STILE EXIT DEVICES
When Ordering: Specify width, hand and finish.
Specify height for vertical rods.
MODEL # PRODUCT DESCRIPTION 605 606 613E 629 630 BSP
PANIC EXIT DEVICES:
6200 Rim Panic Rated $1,227.00
6250 SquareBolt®Panic $1,295.00
6210 SVR Panic Rated $1,546.00
6220 CVR Panic Rated $1,564.00
MODEL # PRODUCT DESCRIPTION All Finishes
*121NL Nightlatch Trim $57.00
TRIM
FOR 6200 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
Not recommended for VR exit devices. See page 145 for cylinder options.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
142
DISTRIBUTOR LIST PRICES
When Ordering: Specify design and finish.
NARROW ESCUTCHEON TRIMS
FOR 6200 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trims ordered less cylinders.
See Page 145 for cylinders if required.
1. See the Variations page for details.
STANDARD DUTY OFFSET PULL TRIMS
FOR 6200 SERIES RIM, SQUAREBOLT®, SVR, CVR EXITS
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 613E 629 630 BSP
480F Offset Pull x Escutcheon (7-1/4")
$426.00
481F Offset Pull x Escutcheon x Cyl (7-1/4")
482F Offset Pull x Escutcheon (9")
483F Offset Pull x Esc x Cyl (9")
MODEL # PRODUCT DESCRIPTION 605 606 613E 62916301
506F Lever x Escutcheon x Cylinder
$572.00508F Lever x Escutcheon
509F Lever x Escutcheon
WITH REFLECTIONS®SERIES LEVER DESIGNS:
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 626 629 630 693 BSP
500F Blank Escutcheon $222.00
501F Escutcheon x Cylinder
502F Knob x Escutcheon x Cylinder
CO-LF $396.00
503F Thumbturn x Escutcheon x Cylinder $434.00
504F Knob x Escutcheon
CO-LF $396.00
505F Knob x Escutcheon
CO-LF
506F Lever x Escutcheon x Cylinder
AR-AU-CR-JN-MO-PB-PN-VI-HA* $572.00
507F Thumbturn x Escutcheon $434.00
508F Lever x Escutcheon
AR-AU-CR-JN-MO-PB-PN-VI-HA* $572.00
509F Lever x Escutcheon
AR-AU-CR-JN-MO-PB-PN-VI-HA*
512F Pull x Escutcheon x Cylinder $255.00
513F Pull x Escutcheon x Thumbturn x Cylinder $532.00
514F Pull x Escutcheon $255.00
517F Pull x Escutcheon x Thumbturn $532.00
518F Pull x Escutcheon x Thumbpiece x Cylinder $503.00
519F Pull x Escutcheon x Thumbpiece
Effective Date: May 1, 2018
Canada Effective July 3, 2018
ELECTRIFIED OPTIONS CHART:
ELECTRIFIED OPTIONS:
*Only available for rim and SquareBolt®devices when used with Delayed Egress option.
NOTE: Latchbolt status monitor required for 6170 and 6210 series surface vertical rod exit devices with alarms.
Example: 6170AS x Door Width x Door Height x RHR x 630
7000 SERIES ELECTRIFIED EXIT DEVICES
OPTION DESCRIPTION LIST PRICE
ADD
A Alarm Kit (less cylinder) $700.00
A-ALR Alarm Kit (less cylinder) with red screen printed touchpad – only 36" length devices $700.00
B Touchbar Monitoring or Signaling $220.00
D Delayed Egress Currently Not
Available
G Electric Dogging $450.00
H* Security Package (DPS) $493.00
O Trim Monitoring or Signaling $220.00
P Latch Retraction $941.00
S Latchbolt Status Monitoring or Signaling $235.00
SAFE Mortise Device Lock with Outside Trim Control (Fail Unlock) – Lever Trims Only $735.00
SECURE Mortise Device Lock with Outside Trim Control (Fail Lock) – Lever Trims Only
143
DISTRIBUTOR LIST PRICES
142 When Ordering: Specify design and finish.
Specify cylinder ring/collar size where required.
6000 SERIES ELECTRIFIED EXIT DEVICES
MODEL # PRODUCT DESCRIPTION LIST PRICE
6116-36 Alarm Kit (Less cylinder)
$700.006116-48 Alarm Kit (Less cylinder)
6216-36 Alarm Kit (Less cylinder)
NOTE: The 6116 alarm kit cannot be retrofitted in the field to the 6170(F) or 6210 surface vertical rod exit devices. This option is available as
a factory order only.
ALARM KITS:
MODEL # EXIT DEVICE DESCRIPTION A A-ALR B D G H O P S SAFE SECURE
6100(F) Rim Exit Device (Wide) x x x x x x x x
6130(F) Mortise Exit Device (Wide) x x x x x x x x
6150(F) Rim SquareBolt®Device (Wide) x x x x x x x
6150(F)WS Rim SquareBolt®Windstorm (Wide)
6160(F) Concealed Vertical Rod (Wide) x x x x x x
6170(F) Surface Vertical Rod (Wide) x x x x x x
6170(F)WS Surface Vertical Rod Windstorm (Wide)
6200(F) Rim Exit Device (Narrow) x x x x x
6210 Surface Vertical Rod (Narrow) x x x x x
6220 Concealed Vertical Rod (Narrow) x x x x x
6250 Rim SquareBolt®Device (Narrow) x x x x x
SUFFIX PRODUCT DESCRIPTION LIST PRICE
OPTION ADDS
NFPA 30 30-Second Delay Board "NFPA"
N/CBOCA 15 15-Second Delay Board "BOCA"
BOCA 30 30-Second Delay Board "BOCA"
NOTES: Suffix options required to product model number.
See page 210 for power supplies and electrified accessories.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
144
When Ordering: Specify finish.
Specify cylinder ring/collar size where required.
MODEL # PRODUCT DESCRIPTION *ALL
FINISHES
RIM CYLINDERS FOR 480F, 500F, 620F, 630F, 680F, 690F SERIES AND 121NL NIGHTLATCH TRIM:
1109 Standard Cylinder 6-Pin $70.00
1109 Standard Cylinder 7-Pin $72.00
1709 CMK Cylinder 6-Pin $86.00
1709 CMK Cylinder 7-Pin $88.00
1193 Large Format Interchangeable Core Cylinder 6-Pin $128.00
1193 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5109 Security Cylinder 6-Pin $280.00
5109 Security Cylinder 7-Pin $284.00
U5109 High Security Cylinder 6-Pin $376.00
U5109 High Security Cylinder 7-Pin $380.00
5193 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5193 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K300 Yale®KeyMark®Cylinder 6- or 7-Pin $90.00
K840 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K640 Yale KeyMark Small Format Interchangeable Core Cylinder 6- or 7-Pin $150.00
A640 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
2109 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
MORTISE CYLINDERS FOR 650F, 660F, 670F, 680F SERIES TRIM & CYLINDER DOGGING:
2153 Standard Cylinder 6-Pin $70.00
2153 Standard Cylinder 7-Pin $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5153 Security Cylinder 6-Pin $280.00
5153 Security Cylinder 7-Pin $284.00
U5153 High Security Cylinder 6-Pin $376.00
U5153 High Security Cylinder 7-Pin $380.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin $83.00
K820 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K620 Yale KeyMark Small Format Interchangeable Core Cylinder 6-Pin or 7-Pin $150.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
DISTRIBUTOR LIST PRICES
CYLINDERS
NOTE: Cylinder rings/collars furnished at no charge when ordered with cylinder.
Specify ring/collar size when ordering.
*Rim cylinders not available in 629 or 630 finishes.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
145
DISTRIBUTOR LIST PRICES
CYLINDERS
When Ordering: Specify finish.
Specify cylinder ring/collar size where required.
MISCELLANEOUS
MODEL # PRODUCT DESCRIPTION LIST PRICE
LONG SPINDLE KIT:
81-9500-1665-000 2" – 2-1/2" door thickness for 620F and 630F series trim $37.00
81-9500-1635-000 2-1/2" – 3-1/2" door thickness for 620F and 630F series trim $78.00
81-9500-1636-000 3-1/2" – 4-1/2" door thickness for 620F and 630F series trim
MISCELLANEOUS
MODEL # PRODUCT DESCRIPTION ADD TO
TRIM
ORDERED
SEPARATELY
COMPONENT CYLINDERS FOR 540F SERIES TRIM:
1802 Standard Cylinder 6-Pin STD $62.00
1802A Standard Cylinder 7-Pin $2.00 $64.00
5802 Security Cylinder 6-Pin $184.00 $246.00
5802A Security Cylinder 7-Pin $188.00 $250.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
1220 Large Format Interchangeable Core Only 7-Pin $60.00 $60.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
5220 Security Large Format Interchangeable Core Only 7-Pin $230.00 $230.00
K402 Yale®KeyMark®Cylinder $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-or 7-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $0.00 $62.00
3804 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $15.00 $77.00
Yale®KeyMark®and Security products are priced separately. The cylinders are not discounted the same as the trim.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
CYLINDER DOGGING KIT:
615-L Cylinder Dogging Kit (less cylinder) - 24", 36", 36" NS, 42", 42" NS, 48", 48" NS $166.00
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION 605 606 613E 629 630 BSP
DUMMY PUSH BAR:
620 DB Dummy Push Bar $656.00
MODEL # PRODUCT DESCRIPTION ORDERED W/
DEVICE ADD
ORDERED
SEPARATELY
STRIKES (BLACK):
702 Floor Strike (optional) –– $35.00
712 Strike for Overlapping Astragal (optional for 6130) ––
618 Open Back Strike (optional) $112.00 $147.00
726 Strike and Angle Bracket –– $67.00
757F Rim Strike 6100(F) –– $62.00
757FWS Rim Strike for Windstorm Devices 6150(F)WS –– Currently Not
Available
759 Rim Strike, 6200 –– $45.00
761 Top Strike Recessed 6160(F) –– $67.00
790 Floor Strike –– $35.00
791 Top Strike –– $67.00
793 Rim Strike (optional) –– $57.00
794 Bottom Flush Strike (optional) –– $35.00
797 Top Strike Bracket (SVR optional) –– $6.00
798 Mortise Strike –– $35.00
202 Strike Box (not finished, optional) $2.00 $2.00
146
DISTRIBUTOR LIST PRICES
MISCELLANEOUS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MISCELLANEOUS
147
DISTRIBUTOR LIST PRICES
146
MISCELLANEOUS
When Ordering: Specify finish where required.
PRODUCT # PRODUCT DESCRIPTION ALL
FINISHES
EXTENSIONS FOR 6000 SERIES VERTICAL RODS:
7010-2 2" Extension $70.00
7010-6 6" Extension $84.00
7010-12 12" Extension $98.00
7010-24 24" Extension $119.00
DOGGING KEY: (size 5/16" - no finish) $2.00
DRILL JIG: (throw away - no finish)
PRODUCT # PRODUCT DESCRIPTION BLACK
SHIM KITS TO CLEAR GLASS MOLDING:
623SK 6100 Series Rim, Mortise & CVR $104.00
623NS 6200 Series Rim & CVR
624SK 6110, 6170 Series SVR $140.00
624NS 6210 Series SVR
623WS 6150(F)WS Windstorm Currently Not
Available
624WS 6170(F)WS Windstorm
ANTI-PRY:
625AP 6100 Rim and 6150 SquareBolt®Anti-pry Bracket $53.00
MODEL # PRODUCT DESCRIPTION 606 626
MORTISE LOCKS:
35LF Mortise Lock Storeroom - Lever Trim
$585.00
35KF Mortise Lock Storeroom - Knob Trim
35TF Mortise Lock Storeroom - Thumbpiece Trim
38LF Mortise Lock Classroom - Lever Trim
38KF Mortise Lock Classroom - Knob Trim
38TF Mortise Lock Classroom - Thumbpiece Trim
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
MISC:
60-7000-0815 Schlage®cam and housing assembly $27.00
1145VD Tailpiece for 1109 cylinders to operate Von Duprin®$4.10
PART # PRODUCT DESCRIPTION LIST PRICE
60-7000-9100-999 Plastic Installation Template used for installation of all 6100 and 6200 Devices $3.30
Effective Date: May 1, 2018
Canada Effective July 3, 2018
148
DISTRIBUTOR LIST PRICES
REMOVABLE MULLIONS
NOTE: Cylinder collars are furnished at no charge when ordered with cylinder. Specify collar size when ordering.
MODEL # PRODUCT DESCRIPTION 600 628 695
REMOVABLE MULLIONS:
M200 Steel Mullion - Panic Rated x 7' $622.00
—
M200 Steel Mullion - Panic Rated x 8' $638.00
M200 Steel Mullion - Panic Rated x 10' $777.00
M200F Steel Mullion – 3 Hour Fire Rated x 7' $865.00
M200F Steel Mullion – 3 Hour Fire Rated x 8' $880.00
M200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 7'* Currently Not Available
M200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 8'*
M300 Aluminum Mullion —$1,037.00
KEYED REMOVABLE MULLIONS:
KRM200 Steel Mullion - Panic Rated x 7' $1,035.00
—
KRM200 Steel Mullion - Panic Rated x 8' $1,047.00
KRM200 Steel Mullion – Panic Rated x 10' $1,184.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 7' $1,250.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 8' $1,266.00
KRM200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 7' Currently Not Available
KRM200FWS Steel Mullion – 3 Hour Fire Rated, Windstorm Certified x 8'
*For use with UL Listed door assemblies that comply to FEMA 361 and ICC 500.
NOTE: Cylinders ordered separately, not included with KRM mullions
MODEL PRODUCT DESCRIPTION CYLINDER
LENGTH
COLLAR SIZE ALL
FINISHES
STD. MULLION / WS
MULLION
MORTISE CYLINDERS FOR KRM SERIES: (CYLINDERS ARE NOT INCLUDED WITH MULLIONS, MUST BE ORDERED
SEPARATELY)
2153 Standard Cylinder 6-Pin 1-1/8" 1765.312 1765.156 $70.00
2153 Standard Cylinder 7-Pin 1-1/4" 1765.500 1765.250 $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 1765.500 $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 1765.719 $130.00
5153 Security Cylinder 6-Pin 1-1/8" 1765.312 1765.156 $280.00
5153 Security Cylinder 7-Pin 1-1/4" 1765.500 1765.250 $284.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 1765.500 $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 1765.719 $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/8" 1765.312 1765.156
$83.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/4" 1765.500 1765.250
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/2" 1765.750 1765.500 $177.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 1765.500
$153.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 1765.719
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 1765.250
$150.00
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6- or
7-Pin 1-3-8" 1765.563 1765.500
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 1765.250
$120.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or
7-Pin 1-3-8" 1765.563 1765.500
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random 1-1/8" 1765.312 1765.156 $70.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
149
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PARTS AND ACCESSORIES
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
M102S Mullion Stabilizer Kit (for M300) $83.00
M203 Door Frame Spacer Block
$46.00
M204 Door Frame Angle Bracket
60-7000-0750 Locking Mechanism for KRM200(F) $445.00
60-7000-0752 Locking Mechanism for KRM200FWS Currently Not Available
60-7000-0755 Top Retainer Pack for KRM200(F) $194.00
60-7000-0757 Top Retainer Pack for KRM200FWS
Currently Not Available
60-7000-0758 Top Retainer Pack for M200FWS x 7' or 8'
60-7000-0759 Top Retainer Pack for M200(F) x 7' or 8' $194.00
60-7000-0760 Bottom Retainer Pack for KRM200(F) $131.00
60-7000-0761 Bottom Retainer Pack for KRM200FWS
Currently Not Available
60-7000-0762 Bottom Retainer Pack for M200FWS x 7' or 8'
60-7000-0763 Bottom Retainer Pack for M200(F) x 7' or 8' $131.00
150
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
151
DISTRIBUTOR LIST PRICES
2100 SERIES EXIT DEVICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DOOR WIDTHS: Prices are for standard sizes only. When ordering, suffix width as follows: 21X0-36, 21X0-42 or
21X0-48. No other sizes available.
VARIATIONS: Exit Devices and Trims are priced separately. In order to determine the full list price of a 2100 Series Exit Device with trim,
it is necessary to add the list price of the device model number and the list price of the trim list number.
STANDARD FINISHES: Products will be furnished only in the following finishes.
CYLINDERS: Standard 6-Pin cylinders included with 440F, 580F Series Rose Trim only. All other keyed trim priced less cylinder, the list
price of the cylinder must be added if cylinders are required. Specify cylinder and cylinder collar with collar size.
ANSI/BHMA
CODE FINISH DESCRIPTION
EXIT DEVICES:
613E Dark Oxidized Satin Bronze - equivalent
630 Satin Stainless Steel
689 Aluminum Painted
691 Light Bronze Painted
693 Black Painted
695 Dark Bronze Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
TRIMS:
613E Dark Oxidized Satin Bronze - equivalent
626 Satin Chrome Plated
630 Satin Stainless Steel
689 Aluminum Painted
691 Light Bronze Painted
693 Black Painted
695 Dark Bronze Painted
BSP Black Suede Powder Coat
PRODUCT OPTIONS ADD
DESIGNER LEVER: (HA) $233.00
DUST GUARD: Prefix “D” to model number (refer to catalog for available cylinders) $47.00
DOOR WIDTH:
36" Door Width - Specify 21 X0-36 STD
42" Door Width - Specify 21 X0-42 $0.00
48" Door Width - Specify 21 X0-48 $48.00
“X” Specify “0” for Rim or “1” for Vertical Rod or "5" for SquareBolt®
Door Thickness: Doors over 2-1/4" $41.00
SLEEVE NUTS: Factory orders only for exact quantity
SN-104 (For interlock bracket on fire-rated mullions) $4.00
SN-134 (4 Pack) $5.40
TORX®SECURITY HEAD SCREWS: Standard size only
Rim Exit Device $37.00
UL Rim Exit Device
Surface Vertical Rod Exit Device (SVR) $96.00
Concealed Vertical Rod Exit Device (CVR) $37.00
630F Series Trim $0.00
121NL, 210F, 440F, 580F, 620F, 690F Series Trim N/A
ABRASIVE COATING: On Touchbar Pad $74.00
MICROSHIELD®:Antimicrobial coating. Suffix YMS to model number for each exit device or trim
that the coating will be applied. $78.00
REFLECTION LEVERS: The following levers are no longer available in 629 and 630 finishes, TT, TU,
TV, TW, TX, TY, UW, UX, TZ, TG, TJ, TK, TO, TE, TI and TD. —
When Ordering: Specify finish where required.
150
When Ordering: Specify design, hand and finish.
Specify width for all exits and height for SVR. 152
NOTE: 1.Vertical rod exit devices are 7' standard.
2. Panic Rated use rod extensions up to 10'.
3. Fire Rated use rod extensions up to 8'.
4. “WS” applies only to 2100(F) rim device. Contact Fleming-Baron Door Products for detailed frame/door
requirements and limitations.
DISTRIBUTOR LIST PRICES
2100 SERIES HOW TO ORDER
Effective Date: May 1, 2018
Canada Effective July 3, 2018
2 1 X 0 Suffix -XX Outside Trim Finish Other Info
Third
Digit:
“0” - Rim
Device,
Pullman
Latch
“1” - SVR
Device
“5” -
SquareBolt®
Rim
Security
“7” - SVR
Device
Fourth
Digit:
“0” -
Standard
No Suffix -
Panic label
“F” - Fire exit
device
“WS” -
Windstorm
Certified
Products4
Size:
(DOW=Door
Opening
Width)
“36” - 30" -
36" (0.76m to
0.91m) DOW
“42” - 36" to
42" (0.91m to
1.07m) DOW
“48” - 42" to
48" (1.07m to
1.22m) DOW
Trim Model
Number
613E
630
689
691
693
695
BSP
Door Hand - RHR or LHR (SVR or lever
escutcheon trim only). Devices are field
reversible.
SN-134, 1/4-20 Sleeve Nuts (pack of 4).
SN-104, 10-24 Sleeve Nuts (pack of 4).
Door thickness: over 1-3/4" (45mm).
Rod Extensions: (quantity) 2010-2
(quantity) 2010-6
(quantity) 2010-12
(quantity) 2010-24
Shim Kits: (quantity) 223
(quantity) 224
Optional Strike
Bottom Pullman Latch (SVR devices)
Removable Mullion: M200, Panic Exit
M200F, Fire Exit
Custom Cylinder & Cylinder Ring
Factory Keying
153
DISTRIBUTOR LIST PRICES
2100 SERIES FLAT BAR EXIT DEVICE
When Ordering: Specify design, hand and finish.
Specify width for all exits and height for SVR.
152
Effective Date: May 1, 2018
Canada Effective July 3, 2018
OPTIONS
BPL Bottom Pullman Latch. Suffix BPL to 2110 Panic Rated surface vertical rod
exits.
ADD
$32.00
LBR Less Bottom Rod Suffix LBR to 2170 or 2160 only. 1-1/2 hr rating. $0.00
WIDE Wide Style Latch Head Cover $0.00
WS Windstorm certified. Suffix WS to 2100(F) rim device. $108.00
YMS MicroShield®antimicrobial coating. Suffix YMS to model number for each exit
device or trim that the coating will be applied. $78.00
Door Height over
8' to 10' See catalog $102.00
MODEL # PRODUCT DESCRIPTION 689 691
693 695 613E 630 BSP
APPROX.
SHIPPING
WT. LBS.
RIM:
2100 Panic Rated $426.00 $676.00 11
2100WS Panic Rated Windstorm Certified $534.00 $784.00 11
2100F Fire Rated $571.00 $821.00 11
2100FWS Fire Rated Windstorm Certified $679.00 $929.00 11
SQUAREBOLT®:
2150 Panic Rated $492.00 $742.00 12
2150F Fire Rated $637.00 $887.00 12
SURFACE VERTICAL ROD:
2110 Panic Rated $684.00 $934.00 16
2110F Fire Rated $829.00 $1,079.00 16
2170 Panic Rated $740.00 $990.00 16
2170F Fire Rated $885.00 $1,135.00 16
CONCEALED VERTICAL ROD:
2120 Panic Rated $938.00 $1,188.00 16
2120F Fire Rated $1,083.00 $1,333.00 16
2160 Panic Rated $1,043.00 $1,293.00 16
2160F Fire Rated $1,188.00 $1,438.00 16
154
DISTRIBUTOR LIST PRICES
2100 SERIES TRIMS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Not recommended for VR exit devices.
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
2. See page 149 for HA lever add
NOTES: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trims ordered less cylinders.
See page 156 for cylinders if required.
MODEL # PRODUCT DESCRIPTION 613E 6261
6301693 BSP
*121NL Nightlatch Trim N/A
603F Thumbturn x Escutcheon x Cylinder $387.00
620F Blank Escutcheon Plate $300.00
621F Escutcheon x Cylinder
622F Knob x Escutcheon x Cylinder CO-LF
$511.00
623F Knob x Escutcheon x Cylinder CO-LF
624F Knob x Escutcheon CO-LF
625F Knob x Escutcheon CO-LF
626F Lever x Escutcheon x Cylinder AR-AU-CR-JN-MO-PB-PN-VI-HA2
627F Lever x Escutcheon x Cylinder AR-AU-CR-JN-MO-PB-PN-VI-HA2
628F Lever x Escutcheon AR-AU-CR-JN-MO-PB-PN-VI-HA2
629F Lever x Escutcheon AR-AU-CR-JN-MO-PB-PN-VI-HA2
630F Blank Escutcheon Plate $217.00
631F Escutcheon x Cylinder
632F Pull x Escutcheon x Cylinder $300.00
633F Pull x T.P. x Escutcheon x Cylinder $422.00
634F Pull x Escutcheon $300.00
635F Pull x T.P. x Escutcheon $422.00
MODEL # PRODUCT DESCRIPTION 613E 6261
6301BSP
626F Lever x Escutcheon x Cylinder
$511.00
627F Lever x Escutcheon x Cylinder
628F Lever x Escutcheon
629F Lever x Escutcheon
WITH REFLECTIONS®SERIES LEVER DESIGNS:
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 689 691
695
213F Escutcheon x Cylinder
$71.00214F Pull Plate
217F Pull Plate x Cylinder
155
DISTRIBUTOR LIST PRICES
2100 SERIES TRIMS
154
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 689 691
695
613E 626
693 BSP
ROSE TRIMS: (Standard Cylinders Included)
441F AU-MO-PB Key-In-Lever – Nightlatch $156.00 $183.00
446F AU-MO-PB Key-In-Lever – Classroom
448F AU-MO-PB Active Lever – Dummy Free Wheeling $124.00 $151.00
449F AU-MO-PB Rigid Lever – Dummy Rigid
MODEL # PRODUCT DESCRIPTION 689 613E 626 BSP
ROSE x ESCUTCHEON TRIMS: (Standard Cylinders Included)
581F AU-MO-PB Key-In-Lever – Nightlatch $429.00 $455.00
586F AU-MO-PB Key-In-Lever – Classroom
588F AU-MO-PB Active Lever – Dummy Free Wheeling $367.00 $393.00
589F AU-MO-PB Rigid Lever – Dummy Rigid
WITH REFLECTIONS®SERIES LEVER DESIGNS:
OPTIONS
B- Prefix for SFIC core prep Key-In-Lever Trim
Available with AU, MO, and PB levers.
ADD
$0.00
M- Prefix for Medeco®/ASSA®IC Core Prep Key-In-Lever Trim
Available with AU levers. $0.00
S- Prefix for Schlage®cylinder prep Key-In-Lever Trim
Available with AU, MO, and PB levers. $0.00
SI- Prefix for Schlage®IC Core Prep Key-In-Lever Trim.
Available with AU and PB levers.
MODEL # PRODUCT DESCRIPTION 613E 62616301693 BSP
ELECTRIFIED TRIM: (Trims Priced Less Cylinder)
690F Lever x Escutcheon x Cylinder x Fail Safe
AR-AU-CR-JN-MO-PB-PN-VI-HA2
$1,069.00
691F Lever x Escutcheon x Cylinder x Fail Secure
AR-AU-CR-JN-MO-PB-PN-VI-HA2
SM SPDT Lock and Unlock Monitor Switch $272.00
EX Trim Gasket for Exterior Applications $29.00
MODEL # PRODUCT DESCRIPTION 613E 62616301BSP
ELECTRIFIED TRIM: (Trims Priced Less Cylinder)
690F Lever x Escutcheon x Cylinder x Fail Safe $1,069.00
691F Lever x Escutcheon x Cylinder x Fail Secure
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
See page 156 for cylinders if required.
2. See page 151 for HA lever add
Note: Specified finish will apply to rose/lever finish only. Escutcheon provided in 689 (Aluminum Painted) finish for all.
440F trim available in 6 pin only. See 540F, page 117, if 7-pin required.
440F trim available in 6 pin only. See 540F in 7000 series section if 7-pin required.
Yale®KeyMark®and Security products are priced separately. The cylinders are not discounted the same as the trim.
MODEL # PRODUCT DESCRIPTION *ALL
FINISHES
RIM CYLINDERS FOR 210F, 620F, 630F, 690F SERIES AND 121NL NIGHTLATCH TRIM:
1109 Standard Cylinder 6-Pin $70.00
1109 Standard Cylinder 7-Pin $72.00
1709 CMK Cylinder 6-Pin $86.00
1709 CMK Cylinder 7-Pin $88.00
1193 Large Format Interchangeable Core Cylinder 6-Pin $128.00
1193 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5109 Security Cylinder 6-Pin $280.00
5109 Security Cylinder 7-Pin $284.00
U5109 High Security Cylinder 6-Pin $376.00
U5109 High Security Cylinder 7-Pin $380.00
5193 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5193 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K300 Yale®KeyMark®Cylinder 6- or 7-Pin $90.00
K840 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K640 Yale KeyMark Small Format Interchangeable Core Cylinder 6- or 7-Pin $150.00
A640 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
2109 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
156
DISTRIBUTOR LIST PRICES
CYLINDERS
When Ordering: Specify design, hand and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION ADD TO
TRIM
ORDERED
SEPARATELY
COMPONENT CYLINDERS FOR 440F, 580F SERIES TRIM:
1802 Standard Cylinder 6-Pin for Lever Designs N/C $62.00
1802A Standard Cylinder 7-Pin for Lever Designs $2.00 $64.00
5802 Security Cylinder 6-Pin for Lever Designs $184.00 $246.00
5802A Security Cylinder 7-Pin for Lever Designs $188.00 $250.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
1220 Large Format Interchangeable Core Only 7-Pin $60.00 $60.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
5220 Security Large Format Interchangeable Core Only 7-Pin $230.00 $230.00
K402 Yale®KeyMark®Cylinder for Lever Designs $78.00 $78.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-or 7-Pin $83.00 $83.00
K600 Yale®KeyMark®Small Format Interchangeable Core Only 6-or 7-Pin $80.00 $80.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random for Lever Designs N/C $62.00
3804 Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway for Lever
Designs $15.00 $77.00
NOTE: Cylinder Rings/Collars no charge if ordered with cylinder.
Specify ring/collar and size when ordering.
*Rim cylinders not available in 630 finish.
157
DISTRIBUTOR LIST PRICES
2100 SERIES MISCELLANEOUS
When Ordering: Specify finish where required.
156
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION BLACK
STRIKES:
702 V.R. Bottom Strike for Pullman Latch (optional) $35.00
757F Rim Strike (Panic and Fire Devices) $62.00
257FWS Rim Strike for Windstorm Devices 2100(F)WS $88.00
790 V.R. Bottom Strike for Deadbolt $35.00
791 V.R. Top Roller Strike $67.00
793 Rim Strike for Doors Pairs (optional) $57.00
794 V.R. Bottom Strike for Deadbolt (optional) $35.00
797 V.R. Top Bracket (optional) $6.00
SHIM KITS TO CLEAR GLASS MOLDINGS:
223 1/4" Shim Kit for Rim Device $62.00
224 1/4" Shim Kit for V.R. Device $91.00
NOTE: See page 210 for power supplies and electrified accessories.
PART # DESCRIPTION LIST PRICE
60-7000-1131 Dogging Key $2.00
60-7000-9100 Plastic Installation Template used for installation of all 2100 Devices $3.30
MODEL # PRODUCT DESCRIPTION 689 691
693 695
605 606 612
613E 630 BSP
EXTENSION RODS:
2010-2 2" Extension $44.00 $69.00
2010-6 6" Extension $58.00 $83.00
2010-12 12" Extension $72.00 $97.00
2010-24 24" Extension (2170 only) $93.00 $118.00
158
DISTRIBUTOR LIST PRICES
REMOVABLE MULLIONS
When Ordering: Specify finish where required.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 600
REMOVABLE MULLIONS:
M200 Steel Mullion - Panic Rated x 7' $622.00
M200 Steel Mullion - Panic Rated x 8' $638.00
M200 Steel Mullion - Panic Rated x 10' $777.00
M200F Steel Mullion – 3 Hour Fire Rated x 7' $865.00
M200F Steel Mullion – 3 Hour Fire Rated x 8' $880.00
KEYED REMOVABLE MULLIONS:
KRM200 Steel Mullion - Panic Rated x 7' $1,035.00
KRM200 Steel Mullion - Panic Rated x 8' $1,047.00
KRM200 Steel Mullion – Panic Rated x 10' $1,184.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 7' $1,250.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 8' $1,266.00
NOTE: Cylinders ordered separately, not included with KRM mullions
MODEL PRODUCT DESCRIPTION CYLINDER
LENGTH
COLLAR SIZE ALL
FINISHES
STD. MULLION
MORTISE CYLINDERS FOR KRM SERIES: (CYLINDERS ARE NOT INCLUDED WITH MULLIONS, MUST BE ORDERED SEPARATELY)
2153 Standard Cylinder 6-Pin 1-1/8" 1765.312 $70.00
2153 Standard Cylinder 7-Pin 1-1/4" 1765.500 $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 $130.00
5153 Security Cylinder 6-Pin 1-1/8" 1765.312 $280.00
5153 Security Cylinder 7-Pin 1-1/4" 1765.500 $284.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/8" 1765.312 $83.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/4" 1765.500
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/2" 1765.750 $177.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 $153.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 $150.00
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6- or 7-Pin 1-3-8" 1765.563
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 $120.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin 1-3-8" 1765.563
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random 1-1/8" 1765.312 $70.00
NOTE: Cylinders ordered separately, not included with KRM mullions
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
M203 Door Frame Spacer Block $46.00
M204 Door Frame Angle Bracket
60-7000-0750 Locking Mechanism for KRM200(F) $445.00
60-7000-0755 Top Retainer Pack for KRM200(F) $194.00
60-7000-0759 Top Retainer Pack for M200(F) x 7' or 8' $194.00
60-7000-0760 Bottom Retainer Pack for KRM200(F) $131.00
60-7000-0763 Bottom Retainer Pack for M200(F) x 7' or 8' $131.00
159
DISTRIBUTOR LIST PRICES
1800 SERIES GRADE 1 EXIT DEVICES
DOOR WIDTHS: Prices are for standard sizes only. When ordering, suffix width as follows: 18X0-36, 18X0-42 or 18X0-48. No other
sizes available.
VARIATIONS: Exit Devices and Trims are priced separately. In order to determine the full list price of a 1800 Series Exit Device with trim,
it is necessary to add the list price of the device model number and the list price of the trim model number.
STANDARD FINISHES: Products will be furnished only in the following finishes.
CYLINDERS: Standard 6-Pin cylinders included with 440F Series Rose Trim only. All other keyed trim priced less cylinder, the list price
of the cylinder must be added if cylinders are required. Specify cylinder and cylinder collar with collar size.
ANSI/BHMA
CODE FINISH DESCRIPTION
EXIT DEVICES:
689 Aluminum Painted
691 Light Bronze Painted
693 Black Painted
695 Dark Bronze Painted
ANSI/BHMA
CODE FINISH DESCRIPTION
TRIMS:
626 Satin Chrome Plated
630 Satin Stainless Steel
689 Aluminum Painted
691 Light Bronze Painted
693 Black Painted
695 Dark Bronze Painted
PRODUCT DESCRIPTION ADD
DOOR WIDTH:
36" Door Width - Specify 18 X0-36 STD
42" Door Width - Specify 18 X0-42 $0.00
48" Door Width - Specify 18 X0-48 $48.00
“X” Specify “0” for Rim or “1” for Vertical Rod
Door Thickness: Doors over 2-1/4" $41.00
SLEEVE NUTS: Factory orders only for exact quantity
SN-104 (For interlock bracket on fire-rated mullions) $4.00
SN-134 (4 Pack) $5.40
TORX®SECURITY HEAD SCREWS: Standard size only
Rim Exit Device $37.00
UL Rim Exit Device
Vertical Rod Exit Device $96.00
UL Vertical Rod Exit Device
420F Series $6.00
210F, 440F Series Trim N/A
158
Effective Date: May 1, 2018
Canada Effective July 3, 2018
160
DISTRIBUTOR LIST PRICES
1800 SERIES EXIT DEVICE HOW TO ORDER
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: Vertical rod exit devices are 7' standard.
Panic and Fire Rated use rod extensions up to 8'.
1 8 X 0 Suffix -XX Outside Trim Finish Other Info
Third
Digit:
“0” - Rim
Device
“1” - SVR
Device
No Suffix -
Panic label
“F” - Fire exit
device
Size:
(DOW=Door
Opening
Width)
“36” - 30" -
36" (76cm to
91cm) DOW
“42” - 36" to
42" (91cm to
107cm) DOW
“48” - 42" to
48" (107cm
to 122cm)
DOW
Trim Model
Number
689
691
693
695
Door Hand - RHR or LHR (SVR or lever
escutcheon trim only). Devices are field
reversible.
SN-134, 1/4-20 Sleeve Nuts (pack of 4).
SN-104, 10-24 Sleeve Nuts (pack of 4).
Door thickness: over 1-3/4" (45mm).
Rod Extensions: (quantity) 2010-2
(quantity) 2010-6
(quantity) 2010-12
Shim Kits: (quantity) 223
(quantity) 224
Optional Strike
Bottom Pullman Latch (SVR device)
Removable Mullion: M200 (Panic)
M200F (Fire)
KRM200 (Panic)
KRM200F (Fire)
Custom Cylinder & Cylinder Ring
Factory Keying
When Ordering: Specify design, hand and finish.
Specify width for all exits and height for SVR.
161
DISTRIBUTOR LIST PRICES
1800 SERIES GRADE 1 FLAT BAR EXIT DEVICE
MODEL # PRODUCT DESCRIPTION 689 691
693 695
APPROX.
SHIPPING
WT. LBS.
RIM:
1800 Panic Rated $234.00 11
1800F Fire Rated $323.00 11
SURFACE VERTICAL ROD:
1810* Panic Rated $356.00 16
1810F Fire Rated $445.00 16
* Bottom Pullman Latch (Not for Fire Rated) $32.00 —
MODEL # PRODUCT DESCRIPTION 689 691
693 695 630
213F Escutcheon x Cylinder – Nightlatch
$71.00 —214F Pull Plate – Dummy Trim
217F Pull Plate x Cylinder – Dummy Trim
420F Blank Escutcheon Plate – Exit Only $194.00 $221.00
421F Escutcheon x Cylinder – Nightlatch
426F Lever x Escutcheon x Cylinder AU-MO-PB – Nightlatch
$269.00 $296.00
427F Lever x Escutcheon x Cylinder AU-MO-PB – Nightlatch
428F Lever x Escutcheon AU-MO-PB – Dummy Trim
429F Lever x Escutcheon AU-MO-PB – Dummy Trim
1800 SERIES EXIT DEVICE TRIMS
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
Cylinder rings/collars not furnished with trims ordered less cylinders.
MODEL # PRODUCT DESCRIPTION 689 691
695 626 693
ROSE TRIMS: (Standard Cylinders Included)
441F AU-MO-PB Key-In-Lever $156.00 $183.00
446F AU-MO-PB Key-In-Lever
448F AU-MO-PB Active Lever $124.00 $151.00
449F AU-MO-PB Rigid Lever
160
Effective Date: May 1, 2018
Canada Effective July 3, 2018
162
DISTRIBUTOR LIST PRICES
MISCELLANEOUS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 689 691
693 695
EXTENSION RODS:
2010-2 2" Extension $44.00
2010-6 6" Extension $58.00
2010-12 12" Extension $72.00
DOGGING KEY 60-7000-1131: (no finish) $2.00
MODEL # PRODUCT DESCRIPTION BLACK
RETROFIT KIT:
ECK2 Replacement Metal End Cap $42.00
STRIKES:
702 V.R. Bottom Strike for Pullman Latch (Optional) $35.00
757F Rim Strike (Panic and Fire Devices) $62.00
790 V.R. Bottom Strike for Deadbolt $35.00
791 V.R. Top Roller Strike $67.00
793 Rim Strike for Doors Pairs (optional) $57.00
794 V.R. Bottom Strike for Deadbolt (optional) $35.00
797 V.R. Top Bracket (optional) $6.00
SHIM KITS TO CLEAR GLASS MOLDINGS:
223 1/4" Shim Kit for Rim Device $62.00
224 1/4" Shim Kit for V.R. Device $91.00
OPTION
B- Prefix for SFIC Core Prep for Key-in-Lever Trim, Less Core ADD $0.00
MODEL # PRODUCT DESCRIPTION ADD TO TRIM 606 626
COMPONENT CYLINDERS FOR 440F SERIES TRIM:
1802 Standard Cylinder 6-Pin $0.00 $62.00
A600 Best®Keyway Small Format Interchangeable Core Only 6-or 7-Pin $50.00 $50.00
2802 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $0.00 $62.00
NOTE: Cylinder Rings/Collars no charge if ordered with cylinder.
Specify ring/collar and size when ordering.
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
RIM CYLINDERS FOR 210F, 420F SERIES TRIM:
1109 Standard Cylinder 6-Pin $70.00
1709 CMK Cylinder 6-Pin $86.00
A640 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
2109 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
163
DISTRIBUTOR LIST PRICES
MULLIONS
MODEL # PRODUCT DESCRIPTION 600
REMOVABLE MULLIONS:
M200 Steel Mullion - Panic Rated x 7' $622.00
M200 Steel Mullion - Panic Rated x 8' $638.00
M200 Steel Mullion - Panic Rated x 10' $777.00
M200F Steel Mullion – 3 Hour Fire Rated x 7' $865.00
M200F Steel Mullion – 3 Hour Fire Rated x 8' $880.00
KEYED REMOVABLE MULLIONS:
KRM200 Steel Mullion - Panic Rated x 7' $1,035.00
KRM200 Steel Mullion - Panic Rated x 8' $1,047.00
KRM200 Steel Mullion – Panic Rated x 10' $1,184.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 7' $1,250.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 8' $1,266.00
NOTE: Cylinders ordered separately, not included with KRM mullions
NOTE: Cylinder collars are furnished at no charge when ordered with cylinder. Specify collar size when ordering.
MODEL PRODUCT DESCRIPTION
CYLINDER
LENGTH
COLLAR
SIZE
ALL
FINISHES
MORTISE CYLINDERS FOR KRM SERIES: (Cylinders are not included with mullions, must be ordered separately)
2153 Standard Cylinder 6-Pin 1-1/8" 1765.312 $70.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder
6-Pin 1-1/4" 1765.500
$120.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder
6- or 7-Pin 1-3-8" 1765.563
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed
Random 1-1/8" 1765.312 $70.00
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
M203 Door Frame Spacer Block $46.00
M204 Door Frame Angle Bracket
60-7000-0750 Locking Mechanism for KRM200(F) $445.00
60-7000-0755 Top Retainer Pack for KRM200(F) $194.00
60-7000-0759 Top Retainer Pack for M200(F) x 7' or 8' $194.00
60-7000-0760 Bottom Retainer Pack for KRM200(F) $131.00
60-7000-0763 Bottom Retainer Pack for M200(F) x 7' or 8' $131.00
162
Effective Date: May 1, 2018
Canada Effective July 3, 2018
164
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
165
DISTRIBUTOR LIST PRICES
1500 SERIES EXIT DEVICES
When Ordering: Specify design, hand and finish.
VARIATIONS: Exit devices and Trim are priced separately. In order to determine the full list price of a 1500 series
device with trim, it is necessary to add the list price of the device model number and the list price of the trim model
number.
STANDARD FINISHES: Products will be furnished only in the following finishes.
CYLINDERS: Keyed trim priced less cylinder, the list price of the cylinder must be added if cylinders are required.
Specify cylinder and cylinder collar with collar size.
ANSI/BHMA
CODE FINISH DESCRIPTION
BRASS:
605 Bright Brass, Clear Coated
606 Satin Brass, Clear Coated
609 Satin Brass, Blackened,
Satin Relieved, Clear Coated
BRONZE:
611 Bright Bronze, Clear Coated
612 Satin Bronze, Clear Coated
613E Dark Oxidized Satin Bronze - equivalent
616 Satin Bronze, Blackened,
Satin Relieved, Clear Coated
ANSI/BHMA
CODE FINISH DESCRIPTION
CHROME:
626 Satin Chrome Plated
NICKEL:
619 Satin Nickel Plated, Clear Coated
620 Satin Nickel Plated, Blackened, Satin
Relieved, Clear Coated
STAINLESS STEEL:
629 Bright Stainless Steel
630 Satin Stainless Steel
PAINTED:
693 Black Painted
BSP Black Suede Powder Coat
PRODUCT DESCRIPTION ADD
DUST GUARD: Prefix "D" to model number (refer to catalog for available cylinders) $47.00
SLEEVE NUTS: Factory orders only for exact quantity
Rim, Mortise and CVR $14.00
UL Rim, Mortise and CVR $24.00
Surface Vertical Rod (SVR) $24.00
UL Surface Vertical Rod (SVR) $24.00
REINFORCED CROSSBAR: $48.00
48" CROSSBAR $55.00
CROSSBAR OVER 48" $178.00
ABRASIVE COATING: On Crossbar $48.00
Door Thickness: Doors over 2-1/4" $41.00
REFLECTION LEVERS: The following levers are no longer available in 629 and 630 finishes, TT, TU,
TV, TW, TX, TY, UW, UX, TZ, TG, TJ, TK, TO, TE, TI and TD.—
1. 609, 616 and 620 finishes will be provided per factory standard. To assure color match, please provide a sample.
2. 613 and 722 finishes available by Special Product Application Request only. This form is available on the Yale extranet and should be submitted to TPS.
164
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify width, hand and finish.
Specify height for vertical rods. 166
DISTRIBUTOR LIST PRICES
1500 SERIES EXIT DEVICES - HOW TO ORDER
Effective Date: May 1, 2018
Canada Effective July 3, 2018
NOTE: Vertical rod exit devices are 7' standard.
Panic Rated use rod extensions up to 10'.
Fire Rated use rod extensions up to 8'.
15 X 0 Suffix Size Design Trim Finish Other Info
Third Digit:
"0" - Rim
Device
"1" - SVR
Device
"2" - CVR
Device
"3" - Mortise
Device
Mechanical Feature:
“F”
Fire Exit Device
“K5"
Mortise Device, EO or Entry by
Key with/without Rigid Knob.
“K8”
Mortise Device, Entry by Knob.
“L5”
Mortise Device, Entry by Key
with/without Rigid Lever.
“L8”
Mortise Device, Entry by Lever.
“T5”
Mortise Device with Thumbpiece
Trim
“T8”
Mortise Device, Active
Thumbpiece Trim.
Size:
(DOW=Door
Opening
Width)
"36"
30" to 36"
DOW
"48"
36" to 48"
DOW
Trim
Design:
(Lever or
knob only.)
Trim
Model
Number
See Page
165
Other Information:
Door Hand
All devices and lever
handle trim.
Door Thickness
over 1-3/4" (45mm).
Fastener Options
Torx®security
screws, SNB (wood,
composite or unrein-
forced metal doors).
Specialty
Cylinders &
Components
167
DISTRIBUTOR LIST PRICES
1500 SERIES EXIT DEVICES
MODEL # PRODUCT DESCRIPTION 605 606 609 611 612 613E 616
619 620 626 629 630 693 BSP
RIM:
1500 Panic Rated $1,704.00
1500F Fire Rated $1,946.00
SURFACE VERTICAL ROD:
1510 Panic Rated $2,076.00
1510F Fire Rated $2,318.00
CONCEALED VERTICAL ROD:
1520 Panic Rated $2,232.00
1520F Fire Rated $2,474.00
MORTISE:
1530 Panic Rated $1,982.00
1530F Fire Rated $2,224.00
OPTION:
Bottom Pullman Latch for 1510 SVR Exit Device ADD $32.00
When Ordering: Specify width, hand and finish.
Specify height for vertical rods.
166
Effective Date: May 1, 2018
Canada Effective July 3, 2018
168
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
2. 611 finish is not available on 630, 660 and 670 Series Trims.
3. See page 163 for HA lever add
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
See Page 170 if cylinders are required.
DISTRIBUTOR LIST PRICES
ESCUTCHEON TRIMS
FOR 1500 SERIES RIM, VERTICAL ROD AND CVR DEVICES
(ALL TRIMS PRICED LESS CYLINDER)
MODEL # PRODUCT DESCRIPTION 605 606 609 6112612 613E 616 619
620 626162916301693 BSP
620F Blank Escutcheon $300.00
621F Escutcheon x Cylinder
622F Knob x Escutcheon x Cylinder
CO-LF
$511.00
623F Knob x Escutcheon x Cylinder
CO-LF
624F Knob x Escutcheon
CO-LF
625F Knob x Escutcheon
CO-LF
626F Lever x Escutcheon x Cylinder
AR-AU-CR-JN-MO-PB-PN-VI-HA3
627F Lever x Escutcheon x Cylinder
AR-AU-CR-JN-MO-PB-PN-VI-HA3
628F Lever x Escutcheon
AR-AU-CR-JN-MO-PB-PN-VI-HA3
629F Lever x Escutcheon
AR-AU-CR-JN-MO-PB-PN-VI-HA3
630F Blank Escutcheon $217.00
631F Escutcheon x Cylinder
632F Pull x Escutcheon x Cylinder $300.00
633F Pull x T.P. x Escut. x Cyl. $422.00
634F Pull x Escutcheon $300.00
635F Pull x T.P. x Escutcheon $422.00
When Ordering: Specify design and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 605 606 611 612 613E
619 6261 62916301
626F Lever x Escutcheon x Cylinder
$511.00
627F Lever x Escutcheon x Cylinder
628F Lever x Escutcheon
629F Lever x Escutcheon
WITH REFLECTIONS®SERIES LEVER DESIGNS:
169
DISTRIBUTOR LIST PRICES
ESCUTCHEON TRIMS
FOR 1530 SERIES MORTISE DEVICES
(ALL TRIMS PRICED LESS CYLINDER)
When Ordering: Specify design, hand and finish.
168
1. Escutcheon is plated to simulate Stainless Steel. See the Variations page for details.
2. 611 finish is not available on 630, 660 and 670 Series Trims.
3. See page 163 for HA lever add
NOTE: Cylinder reference indicates function only, all trims are less cylinder.
See Page 170 for cylinders if cylinders are required.
MODEL # PRODUCT DESCRIPTION
605 606 609 6112
612 613E 616 619 620
626162916301693 BSP
620F Blank Escutcheon – Exit Only - Lever/Knob Prep $300.00
630F Blank Escutcheon – Exit Only - Pull Handle Prep $217.00
634F Pull x Escutcheon – Dummy Trim Pull Plate $300.00
651F Escutcheon x Cylinder – Nightlatch
652F Knob x Escutcheon x Cylinder – Classroom/Storeroom
CO-LF $511.00
654F Knob x Escutcheon – Dummy Trim Rigid
CO-LF
356F Lever x Escutcheon x Cylinder – Classroom
AR-AU-CR-JN-MO-PB-PN-VI-HA3
$515.00
358F Lever x Escutcheon – Passage and Dummy Rigid Lever
AR-AU-CR-JN-MO-PB-PN-VI-HA3
661F Escutcheon x Cylinder – Nightlatch $217.00
662F Pull x Escutcheon x Cylinder – Nightlatch x Pull $300.00
673F Pull x T.P. x Escutcheon x Cylinder – Classroom/T-Piece $422.00
675F Pull x T.P. x Escutcheon – Passage/T-Piece
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 605 606 611 612 613E 619
626162916301BSP
356F Lever x Escutcheon x Cylinder – Classroom $515.00
358F Lever x Escutcheon – Passage and Dummy Rigid Lever
WITH REFLECTIONS®SERIES LEVER DESIGNS:
When Ordering: Specify finish where required. 170
*Rim cylinders not available in 629 or 630 finishes.
NOTES: Cylinder rings/collars furnished at no charge when ordered with cylinder.
Specify ring/collar size when ordering.
Yale®KeyMark®and Security products are priced separately. The cylinders are not discounted the same as the trim.
DISTRIBUTOR LIST PRICES
CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION *ALL
FINISHES
RIM CYLINDERS FOR 620F, 630F SERIES TRIM:
1109 Standard Cylinder 6-Pin $70.00
1109 Standard Cylinder 7-Pin $72.00
1709 CMK Cylinder 6-Pin $86.00
1709 CMK Cylinder 7-Pin $88.00
1193 Large Format Interchangeable Core Cylinder 6-Pin $128.00
1193 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5109 Security Cylinder 6-Pin $280.00
5109 Security Cylinder 7-Pin $284.00
U5109 High Security Cylinder 6-Pin $376.00
U5109 High Security Cylinder 7-Pin $380.00
5193 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5193 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K300 Yale®KeyMark®Cylinder 6- or 7-Pin $90.00
K840 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K640 Yale KeyMark Small Format Interchangeable Core Cylinder 6- or 7-Pin $150.00
A640 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
2109 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
MORTISE CYLINDERS 350F, 650F, 660F, 670F SERIES TRIM:
2153 Standard Cylinder 6-Pin $70.00
2153 Standard Cylinder 7-Pin $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5153 Security Cylinder 6-Pin $280.00
5153 Security Cylinder 7-Pin $284.00
U5153 High Security Cylinder 6-Pin $376.00
U5153 High Security Cylinder 7-Pin $380.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin $83.00
K820 Yale KeyMark Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K620 Yale KeyMark Small Format Interchangeable Core Cylinder 6-Pin or 7-Pin $150.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
171
DISTRIBUTOR LIST PRICES
1500 SERIES MISCELLANEOUS
When Ordering: Specify finish where required.
170
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
STRIKES:
702 Floor Strike (for bottom Pullman Latch, optional) $35.00
712 Strike for overlapping astragal (optional for 1530)
718 Open Back Strike (optional) $147.00
790 Bottom Deadbolt Strike $35.00
791 Upper Latch Strike $67.00
793 Rim Strike (optional) $57.00
794 Bottom Deadbolt Strike (optional) $35.00
797 Bracket for Flush Doors (optional) $6.00
798 ANSI Universal Strike (for 1530) $35.00
799 Rim Strike $70.00
202 Strike Box (optional) $2.00
MORTISE LOCKS:
15KF Mortise Lock Knob or Pull Trim, F01-F02-F03
$700.00
15LF Mortise Lock Lever Trim, F01-F02-F03
18KF Mortise Lock Knob Trim, F08
18LF Mortise Lock Lever Trim, F08
18TF Mortise Lock Thumbturn Trim, F05
EXTENSION RODS:
7010-2 2" Extension $70.00
7010-6 6" Extension $84.00
7010-12 12" Extension $98.00
7010-24 24" Extension $119.00
Effective Date: May 1, 2018
Canada Effective July 3, 2018
172
DISTRIBUTOR LIST PRICES
REMOVABLE MULLIONS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION 600
REMOVABLE MULLIONS:
M200 Steel Mullion – Panic Rated x 7' $622.00
M200 Steel Mullion – Panic Rated x 8' $638.00
M200 Steel Mullion – Panic Rated x 10' $777.00
M200F Steel Mullion – 3 Hour Fire Rated x 7' $865.00
M200F Steel Mullion – 3 Hour Fire Rated x 8' $880.00
KEYED REMOVABLE MULLIONS:
KRM200 Steel Mullion – Panic Rated x 7' $1,035.00
KRM200 Steel Mullion – Panic Rated x 8' $1,047.00
KRM200 Steel Mullion – Panic Rated x 10' $1,184.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 7' $1,250.00
KRM200F Steel Mullion – 1-1/2 Hour Fire Rated x 8' $1,266.00
NOTE: Cylinders ordered separately, not included with KRM mullions
NOTE: Cylinders ordered separately, not included with KRM mullions
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
M203 Door Frame Spacer Block $46.00
M204 Door Frame Angle Bracket
60-7000-0750 Locking Mechanism for KRM200(F) $445.00
60-7000-0755 Top Retainer Pack for KRM200(F) $194.00
60-7000-0759 Top Retainer Pack for M200(F) x 7' or 8'
60-7000-0760 Bottom Retainer Pack for KRM200(F) $131.00
60-7000-0763 Bottom Retainer Pack for M200(F) x 7' or 8'
MODEL PRODUCT DESCRIPTION CYLINDER
LENGTH
COLLAR SIZE ALL
FINISHES
STD. MULLION
MORTISE CYLINDERS FOR KRM SERIES: (CYLINDERS ARE NOT INCLUDED WITH MULLIONS, MUST BE ORDERED SEPARATELY)
2153 Standard Cylinder 6-Pin 1-1/8" 1765.312 $70.00
2153 Standard Cylinder 7-Pin 1-1/4" 1765.500 $72.00
2196 Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 $128.00
2197 Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 $130.00
5153 Security Cylinder 6-Pin 1-1/8" 1765.312 $280.00
5153 Security Cylinder 7-Pin 1-1/4" 1765.500 $284.00
5196 Security Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 $348.00
5197 Security Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844 $352.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/8" 1765.312 $83.00
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/4" 1765.500
K100 Yale®KeyMark®Cylinder 6- or 7-Pin 1-1/2" 1765.750 $177.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 6-Pin 1-1/2" 1765.750 $153.00
K820 Yale®KeyMark®Large Format Interchangeable Core Cylinder 7-Pin 1-11/16" 1765.844
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 $150.00
K620 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6- or 7-Pin 1-3-8" 1765.563
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6-Pin 1-1/4" 1765.500 $120.00
A620 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin 1-3-8" 1765.563
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random 1-1/8" 1765.312 $70.00
173
DISTRIBUTOR LIST PRICES
5800 SERIES CAST IRON DOOR CLOSERS
172
Effective Date: May 1, 2018
Canada Effective July 3, 2018
STANDARD FINISHES: Products will be furnished only in the following finishes.
ANSI/BHMA
CODE FINISH DESCRIPTION
689 Aluminum Painted
690 Dark Bronze Painted
Adjustable Sizes 1 thru 6
MODEL # PRODUCT DESCRIPTION CASE
QUANTITY
APPROX.
SHIPPING
WT. LBS.
EACH
LIST PRICE
NON-HOLD OPEN:
5801 Regular, Parallel, Top Jamb to 3" Reveal 4 12 $394.00
5801DL Regular, Parallel, Top Jamb to 3" Reveal with Delayed Action 4 12 $434.00
5821 Stop Only 4 14 $442.00
5831 Stop Only with Spring 4 14 $554.00
HOLD OPEN:
5811 Regular, Parallel, Top Jamb to 2-3/4" Reveal 4 12 $422.00
5821T Holder/Stop Thumbturn 4 14 $470.00
5831T Holder/Stop Thumbturn with Spring 4 14 $582.00
ACCESSORIES AND PARTS
MODEL # PRODUCT DESCRIPTION LIST PRICE
DROP PLATES:
5800RDP Narrow Frame Drop Plate (Regular Arm) $81.00
5800PDP Narrow Top Rail Drop Plate (Parallel Arm)
COVER:
5800COV Cover Only $25.00
SCREW PACKS:
5800SP Screw Pack $12.00
SN-134 Sleeve Nuts Only 1-3/4" Door $5.40
TBGN134-47 Through-Bolts and Grommet Nuts 1-3/4" Door $11.90
Note: Sleeve Nuts furnished standard with all models. For heavy-duty parallel rigid arm applications, specify 5821 or 5821T, stop is
removable.
*No charge when ordered with closer.
MODEL # PRODUCT DESCRIPTION LIST PRICE
2730KIT Door Saver Spring Stop $135.00
Specify finish.
174
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
175
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
4400 SERIES INSTITUTIONAL DOOR CLOSERS
174
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*Metal Cover suffix “M” to closer model number. Cost of
metal cover included in plating charge.
ANSI/BHMA
CODE FINISH DESCRIPTION
600 Primed for Painting
613E Dark Oxidized Satin Bronze - equivalent
689 Aluminum Painted
690 Dark Bronze Painted
691 Light Bronze Painted
693 Black Painted
694 Medium Bronze Painted
696 Satin Brass Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
605^ Bright Brass, Clear Coated
606^ Satin Brass, Clear Coated
611^ Bright Bronze, Clear Coated
612^ Satin Bronze, Clear Coated
625^ Bright Chrome Plated
626^ Satin Chrome Plated
PRODUCT OPTIONS ADD
SPECIAL FINISHES: Contact factory for availability and price. Minimum of fifty (50) units.
6FIN - Sprayed Finish Samples $36.00
600 special rust inhibiting prime coat. $34.00
LEAD-LINED METAL COVER: (4400M only) $170.00
*GROMMET NUTS: Suffix “TBGN” to model number (1-3/8", 1-3/4" doors)
Ordered with closer - PKG of 4 each N/C
*SLEEVE NUTS: Bolts excluded
Ordered with closer - Steel base material - PKG of 4 each $2.00
Ordered with closer or separately - Stainless Steel - PKG of 4 each (1-3/4" door only) $78.00
*SECURITY TORX®HEAD SCREWS: Standard sizes only - each screw (machine screws only - no
self-drilling/self-tapping or wood screws available) $1.00
TORX®TOOL KIT #20-0040-0868-005
Includes one handle/driver and six bits; T10, T15, T20, T25, T27 and T30
NOTE: Furnished no charge with first 30 closers.
Another kit furnished with each additional 50 closers.
$172.00
ADDITIONAL FINISHING
CHARGES
605, 606, 611,
612, 625, 626
Arm $302.00
*Cover - Metal $208.00
Drop Plates $182.00
Sleeve Nuts $29.00
Soffit Plates $92.00
*See Page 178 for packages.
Refer to Page 178 for Torx®screw packages.
DOOR CLOSER PAINT (PRICE PER CAN)
MODEL
#
PRODUCT
DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST
PRICE
1A Aluminum Spray
Paint (689) 8
$44.00
2B Light Bronze Spray
Paint (691) 8
5S Dark Bronze Spray
(STAT) Paint (690) 8
6SB Gold Spray Paint
(696) 8
FINISHES AND FASTENERS
Closer bodies and plastic covers are available in water-
borne acrylic finishes; arms and metal covers are available
in powder coat or plated finishes.
^ Plated finish; metal cover required
When Ordering: Specify finish.
Specify hand, reveal and door width where noted. 176
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
SERIES 4400, 4400S CLOSERS
4400 SERIES CLOSER - Adjustable Sizes 1 thru 6 (6 per case)
MODEL # PRODUCT DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST PRICE
NON-HOLD OPEN:
4400 Regular, Parallel, Top Jamb to 3" Reveal 13
$486.00
TJS4400 Top Jamb Only Reveals 0-3" (Handed) 13
TJ4400 Top Jamb Only Reveals 2-3/4" to 7" (to 150°) 13
TJL4400 Top Jamb Only Reveals 2-3/4" to 7" (to 180°) 13
PR4400 Parallel Rigid Arm 13 $507.00
4480 Regular Low Profile Arm 13 $486.00
PA4480 Parallel Low Profile Arm 13
4400ST Pull Side Slide Track 13
$542.00
P4400ST Push Side Slide Track 13
4440ST Pull Side Low Profile Slide Track 13
P4440ST Push Side Low Profile Slide Track 13
4420 Stop Only 14 $542.00
4430 Stop Only with Spring 15 $678.00
^UNI4400 UNI Stop™ Door Control 15 $702.00
*UNIJ4400 Top Jamb UNI Stop™ Door Control 15 $740.00
HOLD OPEN:
4410 Regular, Parallel, Top Jamb to 3" Reveal 13
$528.00TJ4410 Top Jamb Only Reveals 2-3/4" to 6-3/4" (to 150°) 13
TJL4410 Top Jamb Only Reveals 2-3/4" to 6-3/4" (to 180°) 13
PR4410 Parallel Rigid Arm (Handed) 13 $557.00
4410ST Pull Side Slide Track 13
$579.00
P4410ST Push Side Slide Track 13
4450ST Pull Side Low Profile Slide Track 13
P4450ST Push Side Low Profile Slide Track 13
4420T Holder/Stop Thumbturn 14 $595.00
4430T Holder/Stop Thumbturn with Spring 15 $732.00
^UNI4410 UNI Stop™ Door Control 15 $774.00
*UNIJ4410 Top Jamb UNI Stop™ Door Control 15 $822.00
Stainless Steel Closers not discounted beyond 50%. Excluded from Buying Program.
MODEL # PRODUCT DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST PRICE
NON-HOLD OPEN: Not Tri-Packed
4400S Regular Arm or Top Jamb to 3" Reveal 14
$1,016.00PA4400S Parallel Arm 14
TJ4400S Top Jamb 2-3/4" to 7" Reveal 14
4400S SERIES CORROSION RESISTANT CLOSER: (4 per case)
OPTIONS
Delayed Action suffix "DL" to model number ADD $42.00
Double Egress suffix "DE" to Slide Track model number (handed)
hinge side only (N/A in Stainless Steel) ADD $71.00
Enhanced Backcheck suffix "EBC" to model number ADD $33.00
Metal Cover suffix "M" to model number (N/A in Stainless Steel) ADD $4.00
ABS Cover suffix "G" to model number ADD
Offset Soffit Plate prefix "PRO" to model number ADD $25.00
Regular rigid heavy-duty arm prefix "R" to model number
TORX®screws not included (N/A in stainless steel). See Page 178 for
TORX®screw package.
ADD $42.00
*When Ordering Specify Reveal. ^When Ordering Specify Door Width.
NOTE: Sleeve Nuts furnished standard with PR, Holder/Stop, Holder/Stop Spring and UNI Stop™ arms.
MODEL # PRODUCT DESCRIPTION LIST PRICE
RP44-4040 Retrofit Plate for LCN 4040
$71.00RP44-4010 Retrofit Plate for LCN 4010
RP44-M2020 Retrofit Plate for Rixson®
RETROFIT PLATES FOR 4400 SERIES:
177
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
When Ordering: Specify finish. Specify hand where noted.
ACCESSORIES FOR SERIES 4400 CLOSERS
BACK PLATES & DROP PLATES FOR 4400 SERIES CLOSERS
MODEL # PRODUCT DESCRIPTION LIST PRICE
486 Narrow Frame Drop Plate
$81.00
486OH Overhead Door Holder Drop Plate
486JP Slide Track Back Plate
487 Low Ceiling Clearance Drop Plate
488 Narrow Top Rail Drop Plate
440 Adaptor Plate for Converting 43L, 44, 45
MODEL # PRODUCT DESCRIPTION LIST PRICE
*289 Standard Soffit Plate, Non-Hold Open $27.10
289A-SS Stainless Steel Soffit Plate, Non-Hold Open $56.60
*588 Standard Soffit Plate, Hold Open $23.00
*413A Soffit Bracket (Mounting Between Doors)
$38.20
*297 Narrow Frame/Removable Stop Soffit Plate
*299 Blade/Applied Stop Soffit Plate
*290 Extra-Clearance Offset Soffit Plate
*293L Flush Rabbeted Transom Angle Bracket $28.20
*293S Spacer Block $8.80
*589L Flush Transom Angle Bracket
$38.20*291, 291A Molded/Bull Nose Trim Bracket
292 Molded/Bull Nose Trim Bracket
**6190 UNI Stop™ Soffit Plate Support Bracket $41.50
6191 UNI Stop™ Wide Frame Reinforcing Kit $52.10
890 Narrow Frame Support Bracket $47.60
891 Clearance/Support Blade Stop
498 Standard Drop Corner Bracket $46.00
2498 Extra Drop Mounting Bracket $211.00
COVERS:
400P 4400 Series Plastic Covers - Sprayed $34.00
400PG 4400 ABS Plastic Covers - Sprayed
$38.00400M 4400 Series Metal Covers - Sprayed
TJ400M TJ4400 Metal Covers - Sprayed (Handed)
400MP 4400 Series Metal Covers - Plated $246.00
TJ400MP TJ4400 Metal Covers - Plated (Handed)
ACCESSORIES FOR 4400 SERIES CLOSERS:
* No charge when ordered with closer.
** Furnished regularly with all Parallel Arm UNI Stop™, no extra. When ordering 6191 in place of 6190, no extra.
176
Effective Date: May 1, 2018
Canada Effective July 3, 2018
178
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
CLOSER BODIES AND SCREW PACKAGES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
Specify door closer size where noted.
SCREW PACKS:
CLOSER BODIES:
MODEL # PRODUCT DESCRIPTION LIST PRICE
4400LAP 4400 Door Closer Body $353.00
4400SLAP 4400S Corrosion Resistant Door Closer Body $701.00
OPTIONS
Delayed Action suffix "DL" to model number ADD $42.00
MODEL # PRODUCT DESCRIPTION LIST PRICE
SN-134 Sleeve Nuts Only 1-3/4" Door $5.40*
SN-214 Sleeve Nuts Only 2-1/4" Door $60.00
SNB134-47 Sleeve Nuts and Bolts 1-3/4" Door $16.40
SNB200-47 Sleeve Nuts and Bolts 2" Door
SNB214-47 Sleeve Nuts and Bolts 2-1/4" Door $82.00
SN-134SS Stainless Steel Sleeve Nuts Only for 1-3/4" Door $78.00
SNB134SS-47 Stainless Steel Sleeve Nuts and Bolts for 1-3/4" Door $82.00
TBGN138-47 Through-Bolts & Grommet Nuts 1-3/8" Door $11.90
TBGN134-47 Through-Bolts & Grommet Nuts 1-3/4" Door
NOTE: Sleeve Nuts furnished standard with PR, Holder/Stop, Holder/Stop Spring and UNI Stop™ arms.
*For PLATED steel sleeve nuts or sleeve nuts and bolts add $29.00 to list price.
TORX®SCREW PACKS:
MODEL # PRODUCT DESCRIPTION LIST PRICE
TX47 TORX®Screw Pack, Standard $44.00
PRTX47 TORX®Screw Pack, Parallel Rigid, Holder/Stop or Holder/Stop Spring $44.00
RTX47 TORX®Screw Pack, Regular Rigid Heavy-Duty Arm $44.00
UNITX47 TORX®Screw Pack, UNI Stop™ Arm $44.00
179
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
ARMS AND ARM ASSEMBLIES (PARTS)
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION LIST PRICE
Y400-1 Regular Arm Assembly Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-111 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Shoe $77.00
Y400-11 Rod & Shoe Assembly $33.00
Y400-1A J Top Jamb Arm Assembly Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-121 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Shoe $77.00
Y400-11A Rod & Shoe Assembly $33.00
Y400-1B JL Top Jamb Arm Assembly Non-Hold Open $86.00
400-2M Main Arm $46.00
Y400-131 Secondary Arm Assembly $49.00
Y400-2W Arm Assembly Less Rod and Soffit Plate $77.00
Y400-11B Rod & Shoe Assembly $33.00
Y400-5 Parallel Arm w/ 289 Soffit Plate, Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-115 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Soffit Plate $77.00
Y400-15 Rod & 289 Soffit Plate Assembly $33.00
*Y400-5A Parallel Arm w/ 289 Soffit Plate, Non-Hold Open $86.00
400-1M Main Arm $46.00
*Y400-115A Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Soffit Plate $77.00
*Y400-15A Rod & 289 Soffit Plate Assembly $33.00
400-3 Regular Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-113 Secondary Arm Assembly $82.00
400-3W Main Arm & Rod Assembly $77.00
400-31 Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
400-3A J Top Jamb Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-123 Secondary Arm Assembly $82.00
400-3WA Main Arm & Rod Assembly $77.00
400-31A Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
400-3B JL Top Jamb Hold Open Arm Assembly $128.00
400-2M Main Arm $46.00
400-133 Secondary Arm Assembly $82.00
400-3WB Main Arm & Rod Assembly $77.00
400-31B Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
400-8 Parallel Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-118 Secondary Arm Assembly w/ 588 Soffit $82.00
400-3W Main Arm & Rod Assembly $77.00
400-13 Holder Shoe & Loop Assembly $51.00
400-31B Adjusting Rod $16.20
Y400-25 Regular & Parallel Arm w/ 289A Soffit - Tri-Pkg, Non-Hold Open $86.00
*180° door swing using special template for doors hung on 6" to 8" wide throw hinges
REGULAR, TOP JAMB AND PARALLEL ARMS
178
Effective Date: May 1, 2018
Canada Effective July 3, 2018
180
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
ARMS AND ARM ASSEMBLIES (PARTS)
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
MODEL # PRODUCT DESCRIPTION LIST PRICE
4020-5 Stop Arm Assembly, Non-Hold Open $151.00
4020T-8 Holder/Stop Arm Assembly $207.00
4020P Hole Plug $10.30
4020S Removable Stop
HOLDER/STOP ARMS (4420, 4420T)
RIGID ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
R400-1 Regular Rigid Heavy-Duty Arm Non-Hold Open $132.00
PR400-5 Parallel Rigid Arm Non-Hold Open $113.00
PR400-8R Parallel Rigid Arm Hold Open, Right Hand $154.00
PR400-8L Parallel Rigid Arm Hold Open, Left Hand
PRO400-5 Parallel Rigid Offset Arm, Non-Hold Open $135.00
PRO400-8R Parallel Rigid Offset Arm Hold Open, Right Hand $156.00
PRO400-8L Parallel Rigid Offset Arm Hold Open, Left Hand
MODEL # PRODUCT DESCRIPTION LIST PRICE
4030-5 Stop with Spring Arm Assembly, Non-Hold Open $294.00
4030T-8 Holder/Stop Spring Arm Assembly Hold Open $352.00
4020P Hole Plug $10.30
4030KIT Holder/Stop Spring Kit $135.00
HOLDER/STOP SPRING ARMS (4430, 4430T)
181
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
ARMS AND ARM ASSEMBLIES (PARTS)
180
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish and hand.
UNI STOP™ ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
6100-11 Arm Assembly Non-Hold Open Door Width 28" to 32"
$315.00 6100-13 Arm Assembly Non-Hold Open Door Width 33" to 41"
6100-14 Arm Assembly Non-Hold Open Door Width 42" to 48"
6100-1 Arm Assembly Hold Open Door Width 28" to 32"
$398.00 6100-3 Arm Assembly Hold Open Door Width 33" to 41"
6100-4 Arm Assembly Hold Open Door Width 42" to 48"
TOP JAMB UNI STOP™ ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
J6100-4 Arm Assembly Non-Hold Open Frame Reveals 2-1/8" to 3-1/4"
$352.00
J6200-4 Arm Assembly Non-Hold Open Frame Reveals 1/2" to 2"
J6400-4 Arm Assembly Non-Hold Open Frame Reveals 3-3/8" to 4-1/4"
J6500-41 Arm Assembly Non-Hold Open Frame Reveals 4-3/8" to 5-3/8"
J6500-42 Arm Assembly Non-Hold Open Frame Reveals 5-1/2" to 6-3/8"
J6500-43 Arm Assembly Non-Hold Open Frame Reveals 6-1/2" to 7-3/8"
J6600-4 Arm Assembly Non-Hold Open Frame Reveals 0" to 3/8"
J6100-7 Arm Assembly Hold Open Frame Reveals 2-1/8" to 3-1/4"
$447.00
J6200-7 Arm Assembly Hold Open Frame Reveals 1/2" to 2"
J6400-7 Arm Assembly Hold Open Frame Reveals 3-3/8" to 4-1/4"
J6500-71 Arm Assembly Hold Open Frame Reveals 4-3/8" to 5-3/8"
J6500-72 Arm Assembly Hold Open Frame Reveals 5-1/2" to 6-3/8"
J6500-73 Arm Assembly Hold Open Frame Reveals 6-1/2" to 7-3/8"
J6600-7 Arm Assembly Hold Open Frame Reveals 0" to 3/8"
182
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
ARMS AND ARM ASSEMBLIES (PARTS)
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
STAINLESS STEEL ARMS (4400S)
MODEL # PRODUCT DESCRIPTION LIST PRICE
400S-1 Regular Arm Assembly Non-Hold Open (SS) $332.00
400S-1M Main Arm (SS) Assembly $171.00
400S-11 Adjusting Rod and Shoe $81.00
400S-111 Secondary Arm Assembly (SS) $171.00
400S-1A J Top Jamb Arm Assembly Non-Hold Open $332.00
400S-1M Main Arm (SS) Assembly $171.00
400S-121 Secondary Arm Assembly (SS)
400S-6 Parallel Arm Assembly Non-Hold Open (SS) $332.00
400S-1M Main Arm (SS) Assembly $171.00
400S-16 Adjusting Rod and Soffit Plate $81.00
400S-116 Secondary Arm Assembly (SS) $171.00
400S-AS Arm Shoe Assembly $44.00
400S-ES Elbow Screw and Washer Assembly $8.40
LOW PROFILE ARMS (4480)
MODEL # PRODUCT DESCRIPTION LIST PRICE
2400-1 Regular Arm, Low Profile, Non-Hold Open $86.00
2400-1MR Main Arm & Adjusting Rod Assembly $77.00
2400-1TS Tube & Shoe/Soffit Assembly $33.00
2400-5 Parallel Arm, Low Profile, Non-Hold Open $86.00
2400-1MR Main Arm & Adjusting Rod Assembly $77.00
2400-5TS Tube & Soffit 289 Assembly $33.00
2400-25 Low Profile, Tri-Pkg, Non-Hold Open $86.00
LOW PROFILE SLIDE TRACK ASSEMBLIES
MODEL # PRODUCT DESCRIPTION LIST PRICE
440ST-1T Pull Side Slide Track Assy Non-Hold Open $165.00
440ST-5T Push Side Slide Track Assy Non-Hold Open
440ST-3T Pull Side Slide Track Assy Hold Open $249.00
440ST-8T Push Side Slide Track Assy Hold Open
440ST-1A Arm Assembly $91.00
440ST-1AR Adjusting Rod Assembly $48.00
400ST-1AT Arm Tube Assembly
440SLD Slider Assembly Non-Hold Open $87.00
440HSLD Slider Assembly Hold Open $120.00
183
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
TRACK ASSEMBLIES AND PARTS
182
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder.
STANDARD SLIDE TRACK ASSEMBLIES
MODEL # PRODUCT DESCRIPTION LIST PRICE
400ST-1T Pull Side Slide Track Assy Non-Hold Open
$165.00400ST-5T Push Side Slide Track Assy Non-Hold Open
400ST-1T180 Pull Side Slide Track Assy Non-Hold Open 180°
400ST-3T Pull Side Slide Track Assy Hold Open $249.00
400ST-8T Push Side Slide Track Assy Hold Open
400ST-1A Arm Assembly (all except STP) $91.00
400STP-1A Arm Assembly (STP only)
400PT-DE-1R Double Egress Arm Assembly Right Hand $165.00
400PT-DE-1L Double Egress Arm Assembly Left Hand
400ST-1ATR Double Egress Arm Tube Assy Right Hand $120.00
400ST-1ATL Double Egress Arm Tube Assy Left Hand
400ST-1AT Arm Tube Assembly (except STP)
$48.00400ST-1AR Adjusting Rod Assembly (all units)
400STP-1AT Arm Tube Assembly (STP only)
400STEC End Cap Non-Hold Open and Hold Open (2 required) $6.40
400SLD Slider Assembly $87.00
400ASR Retaining Ring $2.90
400AS Arm Stud $6.10
400ASC Arm Stud Clip $7.80
MISCELLANEOUS PARTS
MODEL # PRODUCT DESCRIPTION LIST PRICE
1543R Jackscrew (holder loop to bracket) Right Hand $11.40
1543L Jackscrew (holder loop to bracket) Left Hand
455 Locknut (holder loop to bracket) $10.50
1554 Friction Disc (holder loop) $6.40
400-AS Arm Shoe Assembly $18.80
400-HS Hex Screw $0.90
400-ES Elbow Screw & Washer Assembly $7.60
400-MAS Main Arm Screw $7.10
400-ALAS Arm Length Adjusting Screw $5.40
400-HSS Holder Set Screw $7.20
184
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
184 185
DISTRIBUTOR LIST PRICES
3000 SERIES ARCHITECTURAL DOOR CLOSERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder.
*Metal Cover suffix "M" to closer model number. Cost of
metal cover included in plating charge.
ANSI/BHMA
CODE FINISH DESCRIPTION
600 Primed for Painting
613E Dark Oxidized Satin Bronze - equivalent
689 Aluminum Painted
690 Dark Bronze Painted
691 Light Bronze Painted
693 Black Painted
694 Medium Bronze Painted
696 Satin Brass Painted
BSP Black Suede Powder Coat
ANSI/BHMA
CODE FINISH DESCRIPTION
605^ Bright Brass, Clear Coated
606^ Satin Brass, Clear Coated
611^ Bright Bronze, Clear Coated
612^ Satin Bronze, Clear Coated
625^ Bright Chrome Plated
626^ Satin Chrome Plated
PRODUCT OPTIONS ADD
SPECIAL FINISHES: Contact factory for availability and price. Minimum of fifty (50) units.
6FIN - Sprayed Finish Samples $36.00
600 special rust inhibiting prime coat. $34.00
LEAD-LINED METAL COVER: (3500M series only) $170.00
*GROMMET NUTS: Suffix "TBGN" to model number (1-3/8", 1-3/4", 2-1/4" doors)
Ordered with closer - PKG of 4 each N/C
*SLEEVE NUTS: Bolts excluded
Ordered with closer - Steel base material - PKG of 4 each $2.00
Ordered with closer or separately - Stainless Steel - PKG of 4 each (1-3/4" doors only) $78.00
*SECURITY TORX®HEAD SCREWS: Standard sizes only - each screw (machine screws only - no
self-drilling/self-tapping or wood screws available) $1.00
TORX®TOOL KIT #20-0040-0868-005
Includes one handle/driver and six bits; T10, T15, T20, T25, T27 and T30
NOTE: Furnished no charge with first 30 closers.
Another kit furnished with each additional 50 closers.
$172.00
ADDITIONAL
FINISHING CHARGES
605, 606, 611,
612, 625, 626
Arm $302.00
*Cover - Metal $208.00
Drop Plates $182.00
Sleeve Nuts $29.00
Soffit Plates $92.00
*See Page 189 for packages.
Refer to Page 189 for Torx®screw packages.
DOOR CLOSER PAINT (PRICE PER CAN)
MODEL
#
PRODUCT
DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST
PRICE
1A Aluminum Spray
Paint (689) 8
$44.00
2B Light Bronze Spray
Paint (691) 8
5S Dark Bronze Spray
(STAT) Paint (690) 8
6SB Gold Spray Paint
(696) 8
FINISHES AND FASTENERS
Closer bodies and plastic covers are available in water-
borne acrylic finishes; arms and metal covers are avail-
able in powder coat or plated finishes.
^ Plated finish; metal cover required
186
DISTRIBUTOR LIST PRICES
SERIES 3101, 3301 CLOSERS
When Ordering: Specify finish and size.
Specify hand, reveal and door width where noted.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*When Ordering Specify Reveal.
^When Ordering Specify Door Width.
NOTE: Sleeve Nuts furnished standard with PR, Holder/Stop, and Holder/Stop Spring UNI Stop™ arms.
3301 SERIES WITH SLIM LINE COVER - Adjustable Sizes 1 thru 6 (4 per case)
OPTIONS
Delayed Action suffix "DL" to model number ADD $42.00
Offset Soffit Plate prefix "PRO" to model number ADD $25.00
ABS Plastic Cover suffix "G" to model number ADD $4.00
MODEL # PRODUCT DESCRIPTION APPROX. SHIPPING
WT. LBS. LIST PRICE
NON-HOLD OPEN:
3301 Regular, Parallel, Top Jamb to 3" Reveal 8 $344.00
TJ3301 Top Jamb 2-3/4" to 7" Reveal 8
PR3301 Parallel Rigid Arm 8 $365.00
3381 Regular Low Profile Arm 8 $344.00
PA3381 Parallel Low Profile Arm 8
3321 Stop Only 9 $400.00
3331 Stop Only with Spring 10 $536.00
^UNI3301 UNI Stop™ Door Control 10 $560.00
*UNIJ3301 Top Jamb UNI Stop™ Door Control 10 $598.00
HOLD OPEN:
3311 Regular, Parallel, Top Jamb to 2-3/4" Reveal 8 $386.00
TJ3311 Top Jamb 2-3/4" to 6-3/4" Reveal 8
PR3311 Parallel Rigid Arm (Handed) 8 $415.00
3321T Holder/Stop Thumbturn 9 $453.00
3331T Holder/Stop Thumbturn with Spring 10 $590.00
^UNI3311 UNI Stop™ Door Control 10 $632.00
*UNIJ3311 Top Jamb UNI Stop™ Door Control 10 $680.00
3101 SERIES WITHOUT COVER - Specify Size 1 thru 6 (4 per case)
MODEL # PRODUCT DESCRIPTION APPROX. SHIPPING
WT. LBS. LIST PRICE
NON-HOLD OPEN:
3101 Regular, Parallel, Top Jamb to 3" Reveal 8 $327.00
TJ3101 Top Jamb 2-3/4" to 7" Reveal (to 150°) 8
PR3101 Parallel Rigid Arm 8 $348.00
3181 Regular Low Profile Arm 8 $327.00
PA3181 Parallel Low Profile Arm 8
HOLD OPEN:
3111 Regular, Parallel, Top Jamb to 3" Reveal 8 $369.00
TJ3111 Top Jamb 2-3/4" to 6-3/4" Reveal 8
PR3111 Parallel Rigid Arm (Handed) 8 $398.00
187
DISTRIBUTOR LIST PRICES
SERIES 3501 CLOSERS
When Ordering: Specify finish and size.
Specify hand, reveal and door width where noted.
186
Effective Date: May 1, 2018
Canada Effective July 3, 2018
3501 SERIES WITH FULL COVER - Adjustable Sizes 1 thru 6 (4 per case)
MODEL # PRODUCT DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST PRICE
NON-HOLD OPEN:
3501 Regular, Parallel, Top Jamb to 3" Reveal 8 $356.00
TJ3501 Top Jamb 2-3/4" to 7" Reveal 8
PR3501 Parallel Rigid Arm 8 $377.00
3581 Regular Low Profile Arm 8 $356.00
PA3581 Parallel Low Profile Arm 8
3521 Stop Only 14 $412.00
3531 Stop Only with Spring 9 $548.00
^UNI3501 UNI Stop™ Door Control 9 $572.00
*UNIJ3501 Top Jamb UNI Stop™ Door Control 9 $610.00
HOLD OPEN:
3511 Regular, Parallel, Top Jamb to 2-3/4" Reveal 8 $398.00
TJ3511 Top Jamb 2-3/4" to 6-3/4" Reveal 8
PR3511 Parallel Rigid Arm (Handed) 8 $427.00
3521T Holder/Stop Thumbturn 14 $465.00
3531T Holder/Stop Thumbturn with Spring 9 $602.00
^UNI3511 UNI Stop™ Door Control 9 $644.00
*UNIJ3511 Top Jamb UNI Stop™ Door Control 9 $692.00
*When Ordering Specify Reveal.
^When Ordering Specify Door Width.
NOTE: Sleeve Nuts furnished standard with PR, Holder/Stop, Holder/Stop Spring and UNI Stop™ arms.
OPTIONS
Delayed Action suffix "DL" to model number ADD $42.00
Plastic Architectural Cover suffix "A" to model number (sprayed only) ADD $0.00
Metal Cover suffix "M" to model number ADD $7.00
ABS Plastic Cover suffix "G" to model number ADD $4.00
Metal Architectural Cover suffix "MA" to model number (sprayed or plated finishes) ADD $7.00
Offset Soffit Plate prefix "PRO" to model number ADD $25.00
188
DISTRIBUTOR LIST PRICES
ACCESSORIES FOR SERIES 3301, 3501 CLOSERS
When Ordering: Specify finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
BACK PLATES & DROP PLATES
MODEL # PRODUCT DESCRIPTION LIST PRICE
3146 Narrow Top Rail/Concealed Door Holder Drop Plate
$47.00
3148 Low Ceiling Clearance Drop Plate
3158 Exposed-Back/Narrow Top Rail Drop Plate
3445 Molded Full Cover Decorative Back Plate
3446 Exposed-Back Drop Plate Kit $94.00
3545 Exposed-Back Back Plate $47.00
3545A $57.00
3546 Concealed Door Holder Drop Plate $47.00
3546A $90.00
3547 Low Ceiling Clearance/Overhead Door Holder Drop Plate
$57.00
3547A
3548
Exposed-Back/Narrow Top Rail Drop Plate3548A
3549 $94.00
3549A Exposed-Back/Narrow Top Rail Drop Plate Kit $104.00
ACCESSORIES
MODEL # PRODUCT DESCRIPTION LIST PRICE
BRACKETS:
*289A Standard Soffit Plate Non-Hold Open $27.10
*588 Standard Soffit Plate Hold Open $23.00
*413A Soffit Bracket (Mounting Between Doors)
$38.20
*297 Narrow Frame/Removable Stop Soffit Plate
*299 Blade/Applied Stop Soffit Plate
*290 Extra-Clearance Offset Soffit Plate
*293L Flush Rabbeted Transom Angle Bracket $28.20
*293S Spacer Block $8.80
*589L Flush Transom Angle Bracket
$38.20
*291
Molded/Bull Nose Trim Bracket*291A
292
**6190 UNI Stop™ Soffit Plate Support Bracket $41.50
6191 UNI Stop™ Wide Frame Reinforcing Kit $52.10
890 Narrow Frame Support Bracket $47.60
891 Clearance/Support Blade Stop Spacer Block
COVERS:
3200P Plastic Slim Line Cover $17.00
3200PG ABS Plastic Slim Line Cover $24.00
3400P Plastic Full Cover $29.00
3400A Optional Plastic Architectural Cover
3400PG ABS Plastic Full Cover $34.00
3400M Metal Cover $36.00
3400M When Ordered with Closer in Place of 3400P $7.00
3400MA Optional Metal Architectural Cover $36.00
3400MA When Ordered with Closer in Place of 3400P $7.00
*No charge when ordered with closer.
** Furnished regularly with all Parallel Arm UNI Stop™ no extra. When ordering 6191 in place of 6190, no extra.
189
DISTRIBUTOR LIST PRICES
CLOSER BODIES AND SCREW PACKAGES
When Ordering: Specify finish.
Specify door closer size where noted.
188
Effective Date: May 1, 2018
Canada Effective July 3, 2018
CLOSER BODIES:
MODEL # PRODUCT DESCRIPTION LIST PRICE
3101LAP 3301 Door Closer Body $248.00
3101LAP 3501 Door Closer Body
OPTIONS
Delayed Action suffix "DL" to model number ADD $42.00
MODEL # PRODUCT DESCRIPTION LIST PRICE
SN-134 Sleeve Nuts Only 1-3/4" Door $5.40*
SN-214 Sleeve Nuts Only 2-1/4" Door $60.00
SNB134-38 Sleeve Nuts and Bolts 1-3/4" Door $16.40
SNB200-38 Sleeve Nuts and Bolts 2" Door
SNB214-38 Sleeve Nuts and Bolts 2-1/4" Door $82.00
SN-134SS Stainless Steel Sleeve Nuts Only for 1-3/4" Door $78.00
SNB134SS-38 Stainless Steel Sleeve Nuts and Bolts for 1-3/4" Door $82.00
TBGN138-38 Through-Bolts & Grommet Nuts 1-3/8" Door
$11.90
TBGN134-38 Through-Bolts & Grommet Nuts 1-3/4" Door
TBGN214-38 Through-Bolts & Grommet Nuts 2-1/4" Door
NOTE: Sleeve Nuts furnished standard with PR, Holder/Stop, Holder/Stop Spring and UNI Stop™ arms.
*For PLATED steel sleeve nuts or sleeve nuts and bolts add $29.00 to list price.
MODEL # PRODUCT DESCRIPTION LIST PRICE
TX38 TORX®Screw Pack - Standard $44.00
PRTX38 TORX®Screw Pack - Parallel Rigid, Holder/Stop or Holder/Stop Spring $44.00
UNITX38 TORX®Screw Pack - UNI Stop™ Arm $44.00
TORX®SCREW PACKS
SCREW PACKS:
190
DISTRIBUTOR LIST PRICES
ARMS AND ARM ASSEMBLIES (PARTS)
When Ordering: Specify finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION LIST PRICE
Y400-1 Regular Arm Assembly Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-111 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Shoe $77.00
Y400-11 Rod & Shoe Assembly $33.00
Y400-1A J Top Jamb Arm Assembly Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-121 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Shoe $77.00
Y400-11A Rod & Shoe Assembly $33.00
Y400-6 Parallel Arm w/ 289A Soffit Plate, Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-116 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Soffit Plate $77.00
Y400-16 Rod & Shoe Assembly $33.00
400-3 Regular Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-113 Secondary Arm Assembly $82.00
400-3W Main Arm & Rod Assembly $77.00
400-31 Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
400-3A J Top Jamb Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-123 Secondary Arm Assembly $82.00
400-3WA Main Arm & Rod Assembly $77.00
400-31A Adjusting Rod $16.20
400-13 Holder Shoe and Loop Assembly $51.00
Y400-6A Parallel Arm w/ 289A Soffit Plate, Non-Hold Open $86.00
400-1M Main Arm $46.00
*Y400-116A Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Soffit Plate $77.00
*Y400-16A Rod & Shoe Assembly $33.00
400-8 Parallel Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-118 Secondary Arm Assembly w/588 Soffit $82.00
400-3W Main Arm & Rod Less Holder Shoe Assembly $77.00
400-18 Holder Shoe & Loop Assembly $51.00
400-31 Adjusting Rod $16.20
Y400-26 Regular & Parallel Arm w/ 289A Soffit, Tri-Pkg, Non-Hold Open $86.00
*180° door swing using special template for doors hung on 6" to 8" wide throw hinges
REGULAR, TOP JAMB AND PARALLEL ARMS
191
DISTRIBUTOR LIST PRICES
ARMS AND ARM ASSEMBLIES (PARTS)
When Ordering: Specify finish.
190
Effective Date: May 1, 2018
Canada Effective July 3, 2018
RIGID ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
PR400-5 Parallel Rigid Arm Non-Hold Open $113.00
PR400-8R Parallel Rigid Arm Hold Open, Right Hand $154.00
PR400-8L Parallel Rigid Arm Hold Open, Left Hand
MODEL # PRODUCT DESCRIPTION LIST PRICE
4020-5 Stop Arm Assembly, Non-Hold Open $151.00
4020T-8 Holder/Stop Arm Assembly, Hold Open $207.00
4020P Hole Plug $10.30
4020S Removable Stop
HOLDER/STOP ARMS (3321, 3321T, 3521, 3521T)
MODEL # PRODUCT DESCRIPTION LIST PRICE
4030-5 Stop w/ Spring Arm Assembly, Non-Hold Open $294.00
4030T-8 Holder/Stop w/ Spring Assembly, Hold Open $352.00
4020P Hole Plug $10.30
4030KIT Holder/Stop Spring Kit $135.00
HOLDER/STOP SPRING ARMS (3331, 3331T, 3531, 3531T)
UNI STOP™ ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
6100-11 Arm Assembly Non-Hold Open Door Width 28" to 32"
$315.00 6100-13 Arm Assembly Non-Hold Open Door Width 33" to 41"
6100-14 Arm Assembly Non-Hold Open Door Width 42" to 48"
6100-1 Arm Assembly Hold Open Door Width 28" to 32"
$398.00 6100-3 Arm Assembly Hold Open Door Width 33" to 41"
6100-4 Arm Assembly Hold Open Door Width 42" to 48"
192
DISTRIBUTOR LIST PRICES
When Ordering: Specify finish and hand.
ARMS AND ARM ASSEMBLIES (PARTS)
Effective Date: May 1, 2018
Canada Effective July 3, 2018
TOP JAMB UNI STOP™ ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
J6100-4 Arm Assembly Non-Hold Open Frame Reveals 2-1/8" to 3-1/4"
$352.00
J6200-4 Arm Assembly Non-Hold Open Frame Reveals 1/2" to 2"
J6400-4 Arm Assembly Non-Hold Open Frame Reveals 3-3/8" to 4-1/4"
J6500-41 Arm Assembly Non-Hold Open Frame Reveals 4-3/8" to 5-3/8"
J6500-42 Arm Assembly Non-Hold Open Frame Reveals 5-1/2" to 6-3/8"
J6500-43 Arm Assembly Non-Hold Open Frame Reveals 6-1/2" to 7-3/8"
J6600-4 Arm Assembly Non-Hold Open Frame Reveals 0" to 3/8"
J6100-7 Arm Assembly Hold Open Frame Reveals 2-1/8" to 3-1/4"
$447.00
J6200-7 Arm Assembly Hold Open Frame Reveals 1/2" to 2"
J6400-7 Arm Assembly Hold Open Frame Reveals 3-3/8" to 4-1/4"
J6500-71 Arm Assembly Hold Open Frame Reveals 4-3/8" to 5-3/8"
J6500-72 Arm Assembly Hold Open Frame Reveals 5-1/2" to 6-3/8"
J6500-73 Arm Assembly Hold Open Frame Reveals 6-1/2" to 7-3/8"
J6600-7 Arm Assembly Hold Open Frame Reveals 0" to 3/8"
LOW PROFILE ARMS (3381, 3581)
MODEL # PRODUCT DESCRIPTION LIST PRICE
2400-1 Regular Arm, Low Profile, Non-Hold Open $86.00
2400-1MR Main Arm & Adjusting Rod Assembly $77.00
2400-1TS Tube & Shoe/Soffit Assembly $33.00
2400-6 Parallel Arm, Low Profile, Non-Hold Open $86.00
2400-1MR Main Arm & Adjusting Rod Assembly $77.00
2400-6TS Tube and Soffit 289A Assembly $33.00
2400-26 Low Profile, Tri-Pkg, Non-Hold Open $86.00
MISCELLANEOUS PARTS
MODEL # PRODUCT DESCRIPTION LIST PRICE
1543R Jackscrew (holder loop to bracket) Right Hand $11.40
1543L Jackscrew (holder loop to bracket) Left Hand
455 Locknut (holder loop to bracket) $10.50
1554 Friction Disc (holder loop) $6.40
400-AS Arm Shoe Assembly $18.80
400-ES Elbow Screw and Washer Assembly $7.60
400-HS Hex Screw $0.90
400-HSS Holder Set Screw $7.20
1639 Pinion Cap $4.50
193
DISTRIBUTOR LIST PRICES
2700 SERIES ARCHITECTURAL DOOR CLOSERS
STANDARD FINISHES: Products will be furnished only in the following finishes.
ANSI/BHMA
CODE FINISH DESCRIPTION
689 Aluminum Painted
690 Dark Bronze Painted
Adjustable Sizes 1 thru 6
MODEL # PRODUCT DESCRIPTION CASE
QUANTITY
APPROX.
SHIPPING
WT. LBS.
EACH
LIST PRICE
NON-HOLD OPEN:
2701 Regular, Parallel, Top Jamb to 3" Reveal 6 6.5 $224.00
2701DL Regular, Parallel, Top Jamb to 3" Reveal with Delayed Action 6 6.5 $266.00
2721 Stop Only 4 7.75 $321.00
2731 Stop Only with Spring 4 7.75 $224.00
HOLD OPEN:
2711 Regular, Parallel, Top Jamb to 2-3/4" Reveal 4 6.5 $303.00
2721T Holder/Stop Thumbturn 4 7.75 $349.00
2731T Holder/Stop Thumbturn with Spring 4 7.75 $459.00
ACCESSORIES AND PARTS
MODEL # PRODUCT DESCRIPTION LIST PRICE
DROP PLATES:
3148 Low Ceiling Clearance Drop Plate $47.00
3158 Exposed-Back/Narrow Top Rail Drop Plate
BRACKETS:
*293L Flush Rabbeted Transom Angle Bracket $28.20
COVER:
2700COV Cover Only $28.00
SCREW PACKS:
2700SP Screw Pack $12.00
SN-134 Sleeve Nuts Only 1-3/4" Door $5.40
TBGN134-38 Through-Bolts and Grommet Nuts 1-3/4" Door $11.90
Note: Sleeve Nuts furnished standard with all models. For heavy-duty parallel rigid arm applications, specify 2721 or 2721T, stop is
removable.
*No charge when ordered with closer.
192
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION LIST PRICE
2730KIT Door Saver Spring Stop $135.00
Specify finish.
194
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
195
DISTRIBUTOR LIST PRICES
51 SERIES INDUSTRIAL DOOR CLOSERS
ANSI/BHMA
CODE FINISH DESCRIPTION
600 Primed for Painting
613E1Dark Oxidized Satin Bronze - equivalent
689 Aluminum Painted
690 Dark Bronze Painted
691 Light Bronze Painted
693 Black Painted
694 Medium Bronze Painted
696 Satin Brass Painted
ANSI/BHMA
CODE FINISH DESCRIPTION
6051Bright Brass, Clear Coated
6061Satin Brass, Clear Coated
6111Bright Bronze, Clear Coated
6121Satin Bronze, Clear Coated
6251Bright Chrome Plated
6261Satin Chrome Plated
PRODUCT OPTIONS ADD
SPECIAL FINISHES: Contact factory for availability and price. Minimum of fifty (50) units.
6FIN - Sprayed Finish Samples $36.00
600 special rust inhibiting prime coat. $34.00
*GROMMET NUTS: Suffix "TBGN" to model number (1-3/8", 1-3/4", 2-1/4" doors)
Ordered with closer - PKG of 4 each N/C
*SLEEVE NUTS: Bolts excluded
Ordered with closer - Steel base material - PKG of 4 each $2.00
*SECURITY TORX®HEAD SCREWS: Standard sizes only - each screw (machine screws only - no
self-drilling/self-tapping or wood screws available) $1.00
TORX®TOOL KIT #20-0040-0868-005
Includes one handle/driver and six bits; T10, T15, T20, T25, T27 and T30
NOTE: Furnished no charge with first 30 closers.
Another kit furnished with each additional 50 closers.
$172.00
ADDITIONAL
FINISHING CHARGES
605, 606, 611,
612, 625, 626
Arm $302.00
*See Page 199 for packages.
Refer to Page 199 for Torx®screw package.
DOOR CLOSER PAINT (PRICE PER CAN)
MODEL
#
PRODUCT
DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST
PRICE
1A Aluminum Spray
Paint (689) 8
$44.00
2B Light Bronze Spray
Paint (691) 8
5S Dark Bronze Spray
(STAT) Paint (690) 8
6SB Gold Spray Paint
(696) 8
FINISHES AND FASTENERS
194
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1. Available on arms only
196
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
SERIES 51 CLOSERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
51 SERIES CLOSER - Adjustable Sizes 1 thru 6 (6 per case)
When Ordering: Specify finish.
Specify size, hand, reveal and door width where noted.
MODEL # PRODUCT DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST PRICE
NON-HOLD OPEN:
51 Regular, Parallel, Top Jamb to 3" Reveal 8 $229.00
TJ51 Top Jamb Only Reveals 2-3/4" to 7" 8
HOLD OPEN:
151 Regular, Parallel, Top Jamb to 3" Reveal 9 $271.00
TJ151 Top Jamb Only Reveals 2-3/4" to 6-3/4" 9
OPTIONS
Cover suffix "P" to model number ADD $18.00
MODEL # PRODUCT DESCRIPTION LIST PRICE
214 Overhead Door Holder Drop Plate $40.00
214C Narrow Top Rail Drop Plate
599 Retrofit Adaptor Plate $49.00
587 Low Ceiling Clearance/Overhead Holder Drop Plate $40.00
BACK PLATES & DROP PLATES
MODEL # PRODUCT DESCRIPTION LIST PRICE
*289A Standard Soffit Plate Non-Hold Open $27.10
*588 Standard Soffit Plate, Hold Open $23.00
2350 Universal Corner Bracket $111.00
294 Retrofit Adaptor Plate
$38.20
*413A Soffit Bracket (Mounting Between Doors)
*297, 299 Narrow Frame/Removable Stop Soffit Plate
*290 Extra-Clearance Offset Soffit Plate
*589L Flush Transom Angle Bracket
*291, 291A Molded/Bull Nose Trim Bracket $38.20
292
50P Plastic Cover $18.00
1639 Pinion Cap $4.50
197
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
ACCESSORIES FOR SERIES 51 CLOSERS
ACCESSORIES
*No charge when ordered with closer.
When Ordering: Specify finish. Specify size of closers.
196
Effective Date: May 1, 2018
Canada Effective July 3, 2018
198
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
VISUAL PACK DOOR CLOSERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify size and finish.
VISUAL PACK DOOR CLOSERS
MODEL # PRODUCT DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST PRICE
NON-HOLD OPEN:
V51 Regular, Parallel, Top Jamb to 3" Reveal 8 $229.00
HOLD OPEN:
V151 Regular, Parallel, Top Jamb to 3" Reveal 9 $271.00
199
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
CLOSER BODIES AND SCREW PACKAGES
198
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
Specify door closer size where noted.
CLOSER BODIES
MODEL # PRODUCT DESCRIPTION LIST PRICE
51LAP 51 Door Closer Body $160.00
MODEL # PRODUCT DESCRIPTION LIST PRICE
SN-134 Sleeve Nuts Only 1-3/4" Door $5.40*
SN-214 Sleeve Nuts Only 2-1/4" Door $60.00
SNB134-38 Sleeve Nuts and Bolts 1-3/4" Door $16.40
SNB200-38 Sleeve Nuts and Bolts 2" Door
SNB214-38 Sleeve Nuts and Bolts 2-1/4" Door $82.00
SN-134SS Stainless Steel Sleeve Nuts Only for 1-3/4" Door $78.00
TBGN138-38 Through-Bolts & Grommet Nuts 1-3/8" Door
$11.90TBGN134-38 Through-Bolts & Grommet Nuts 1-3/4" Door
TBGN214-38 Through-Bolts & Grommet Nuts 2-1/4" Door
*For PLATED steel sleeve nuts add $29.00 to list price.
SCREW PACKS
MODEL # PRODUCT DESCRIPTION LIST PRICE
TX38 TORX®Screw Pack - Standard $44.00
TORX®SCREW PACKS
MISCELLANEOUS PARTS
MODEL # PRODUCT DESCRIPTION LIST PRICE
400-AS Arm Shoe Assembly $18.80
400-ES Elbow Screw and Washer Assembly $7.60
400-HS Hex Screw $0.90
200
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
ARMS AND ARM ASSEMBLIES (PARTS)
Effective Date: May 1, 2018
Canada Effective July 3, 2018
When Ordering: Specify finish.
REGULAR, TOP JAMB AND PARALLEL ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
Y400-1 Regular Arm Assembly Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-111 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Shoe $77.00
Y400-11 Rod & Shoe Assembly $33.00
Y400-1A J Top Jamb Arm Assembly Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-121 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Shoe $77.00
Y400-11A Rod & Shoe Assembly $33.00
Y400-1B JL Top Jamb Arm Assembly Non-Hold Open $86.00
400-2M Main Arm $46.00
Y400-131 Secondary Arm Assembly $49.00
Y400-2W Arm Assembly Less Rod and Soffit Plate $77.00
Y400-11B Rod & Shoe Assembly $33.00
Y400-6 Parallel Arm w/ 289A Soffit Plate, Non-Hold Open $86.00
400-1M Main Arm $46.00
Y400-116 Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Soffit Plate $77.00
Y400-16 Rod & 289A Soffit Plate Assembly $33.00
400-3 Regular Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-113 Secondary Arm Assembly $82.00
400-3W Main Arm & Rod Assembly $77.00
400-31 Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
400-3A J Top Jamb Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-123 Secondary Arm Assembly $82.00
400-3WA Main Arm & Rod Assembly $77.00
400-31A Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
400-3B JL Top Jamb Hold Open Arm Assembly $128.00
400-2M Main Arm $46.00
400-133 Secondary Arm Assembly $82.00
400-3WB Main Arm & Rod Assembly $77.00
400-31B Adjusting Rod $16.20
400-13 Holder Shoe & Loop Assembly $51.00
Y400-6A Parallel Arm w/ 289A Soffit Plate, Non-Hold Open $86.00
400-1M Main Arm $46.00
*Y400-116A Secondary Arm Assembly $49.00
Y400-1W Arm Assembly Less Rod & Soffit Plate $77.00
*Y400-16A Rod & 289A Soffit Plate Assembly $33.00
400-8 Parallel Hold Open Arm Assembly $128.00
400-1M Main Arm $46.00
400-118 Secondary Arm Assembly w/588 Soffit $82.00
400-3W Main Arm & Rod Assembly $77.00
400-18 Holder Shoe & Loop Assembly w/ 588 Soffit $51.00
400-31 Adjusting Rod $16.20
Y400-26 Regular & Parallel Arm w/ 289A Soffit - Tri-Pkg, Non-Hold Open $86.00
*180° door swing using special template for doors hung on 6" to 8" wide throw hinges
201
DISTRIBUTOR LIST PRICES
1100 SERIES INDUSTRIAL DOOR CLOSERS
STANDARD FINISHES: Products will be furnished only in the following finishes.
ANSI/BHMA
CODE FINISH DESCRIPTION
689 Aluminum Painted
690 Dark Bronze Painted
MODEL # PRODUCT DESCRIPTION CASE
QUANTITY
APPROX.
SHIPPING
WT. LBS.
689 690
1101BF Multi-sized Closer - Non-Hold Open 6 6 $186.00
1101BFCOV Multi-sized Closer - Non-Hold Open with Cover 6 6 $204.00
1104BC Size 4 Closer with Backcheck - Non-Hold Open 6 6 $173.00
1111BF Multi-sized Closer - Hold Open 4 8 $221.00
MISCELLANEOUS PARTS:
MODEL # PRODUCT DESCRIPTION 689 690
1100COV Cover Only $18.00
200
Effective Date: May 1, 2018
Canada Effective July 3, 2018
Note: Sleeve Nuts furnished standard with all models.
202
DISTRIBUTOR LIST PRICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
203
DISTRIBUTOR LIST PRICES
1900 SERIES TRADITIONAL DOOR CLOSERS
ANSI/BHMA
CODE FINISH DESCRIPTION
STANDARD FINISHES:
600 Primed for Painting
689 Aluminum Painted
690 Dark Bronze Painted
691 Light Bronze Painted
693 Black Painted
694 Medium Bronze Painted
696 Satin Brass Painted
PRODUCT OPTIONS ADD
SPECIAL FINISHES: Contact factory for availability and price. Minimum of fifty (50) units.
6FIN - Sprayed Finish Samples $36.00
600 special rust inhibiting prime coat. $34.00
*GROMMET NUTS: Suffix "TBGN" to model number (1-3/8", 1-3/4", 2-1/4" doors)
Ordered with closer - PKG of 4 each N/C
*SLEEVE NUTS: Bolts excluded
Ordered with closer - Steel base material - PKG of 4 each $2.00
*See Page 206 for packages.
DOOR CLOSER PAINT (PRICE PER CAN)
MODEL
#
PRODUCT
DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST
PRICE
1A Aluminum Spray
Paint (689) 8
$44.00
2B Light Bronze Spray
Paint (691) 8
5S Dark Bronze Spray
(STAT) Paint (690) 8
6SB Gold Spray Paint
(696) 8
FINISHES AND FASTENERS
202
Effective Date: May 1, 2018
Canada Effective July 3, 2018
204
DISTRIBUTOR LIST PRICES
SERIES 1900 TRADITIONAL SURFACE CLOSERS
When Ordering: Specify finish and hand.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
1900 SERIES TRADITIONAL CLOSERS (4 per case)
MODEL # PRODUCT DESCRIPTION
APPROX.
SHIPPING
WT. LBS.
LIST PRICE
NON-HOLD OPEN:
1902/4 Regular Arm 10
$975.00
1905/6 Regular Arm 10
PA1902/4 Parallel Arm 10
PA1905/6 Parallel Arm 10
1902/4DL* Delayed Action Regular Arm Only 10 $1,017.00
1905/6DL* Delayed Action Regular Arm Only 10
PR1902/4 Parallel Rigid Arm (SN included) 10 $996.00
PR1905/6 Parallel Rigid Arm (SN included) 10
^UNI1902/4 UNI Stop™ Door Control 13 $1,191.00
^UNI1905/6 UNI Stop™ Door Control 13
HOLD OPEN:
1912/4 Regular 90° - 180° Holder Arm 11
$1,017.00
1915/6 Regular 90° - 180° Holder Arm 11
PA1912/4 Parallel 90° - 180° Holder Arm 11
PA1915/6 Parallel 90° - 180° Holder Arm 11
PR1912/4 Parallel Rigid Arm (SN included) 11 $1,046.00
PR1915/6 Parallel Rigid Arm (SN included) 11
^UNI1912/4 UNI Stop™ Door Control 13 $1,263.00
^UNI1915/6 UNI Stop™ Door Control 13
ACCESSORIES
MODEL # PRODUCT DESCRIPTION LIST PRICE
1950 Corner Bracket $152.00
2950 Corner Bracket, Extra Drop $160.00
964 Adjustable Bracket (Arched or Circular Top Door)
974 Offset Adjustable Bracket (Arched or Circular Top Door) $233.00
*289 Soffit Plate Non-Hold Open $27.10
*413A Soffit Bracket (Mounting Between Doors)
$38.20
*297 Narrow Frame/Removable Stop Soffit Plate
*299 Blade/Applied Stop Soffit Plate
*290 Extra-Clearance Offset Soffit Plate
292 Molded/Bull Nose Trim Bracket
*293L Flush Transom Angle Bracket $28.20
293S Spacer Block $8.80
*589L Flush Transom Angle Bracket $38.20
*291, 291A Molded/Bull Nose Trim Bracket
**6190 UNI Stop™ Soffit Plate Support Bracket $41.50
6191 UNI Stop™ Wide Frame Reinforcing Kit $52.10
890 Narrow Frame Support Bracket $47.60
891 Clearance/Support Blade Stop
1983 Retrofit Adaptor Plate $91.00
1986 Retrofit Adaptor Plate
^When Ordering Specify Door Width.
*Specify hand when ordering.
*No charge when ordered with closer.
**Furnished standard with all Parallel Arm UNI Stop™ no extra.
When ordering 6191 in place of 6190, no extra.
MODEL # PRODUCT DESCRIPTION LIST PRICE
1988 Narrow Top Rail Drop Plate $90.60
BACK PLATES & DROP PLATES FOR 1900 SERIES CLOSERS
205
DISTRIBUTOR LIST PRICES
ARMS AND ARM ASSEMBLIES (PARTS)
When Ordering: Specify finish where required.
MODEL # PRODUCT DESCRIPTION LIST PRICE
Y1900-1 Regular Arm Assembly Non-Hold Open $86.00
1900-1M Main Arm $46.00
Y1900-1W Main Arm and Adjusting Tube $77.00
1900-11 Rod and Shoe $33.00
1900-3 Regular Arm Assembly Hold Open 90° to 180° $128.00
1900-1M Main Arm $46.00
1900-3W Main Arm and Rod Less Holder Shoe & Loop Assembly $77.00
1900-13 Holder Shoe and Loop $51.00
Y1900-5 Parallel Arm Assembly Non-Hold Open $86.00
1900-1M Main Arm $46.00
Y1900-1W Main Arm Less Rod and Soffit Plate $77.00
1900-15 Rod and Soffit Plate $33.00
1900-8 *Parallel Arm Assembly Hold Open 90° to 180° (Handed) $128.00
1900-1M Main Arm $46.00
1900-3W Main Arm and Rod Less Holder Shoe & Loop Assembly $77.00
1900-18 *Soffit Plate Holder & Loop Assembly $74.00
REGULAR AND PARALLEL ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
24BD B/D Spring $129.00
56EF E/F Spring $144.00
230BC Spring (prior to 1978 model) $456.00
230D Spring (prior to 1978 model) $281.00
230EF Spring (prior to 1978 model) $208.00
1543R Jackscrew (holder loop to bracket) Right Hand $11.40
1543L Jackscrew (holder loop to bracket) Left Hand
455 Locknut (holder loop to bracket) $10.50
1554 Friction Disc (holder loop) $6.40
MISCELLANEOUS PARTS
*Specify Hand
RIGID ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
PR1900-5 Parallel Rigid Arm Non-Hold Open $140.00
PR1900-8R Parallel Rigid Arm Hold Open, Right Hand $157.00
PR1900-8L Parallel Rigid Arm Hold Open, Left Hand
UNI STOP™ ARMS
MODEL # PRODUCT DESCRIPTION LIST PRICE
6130-17 Arm Assembly Non-Hold Open Door Width 28" to 32"
$315.00 6130-18 Arm Assembly Non-Hold Open Door Width 33" to 41"
6130-19 Arm Assembly Non-Hold Open Door Width 42" to 48"
6130-7 Arm Assembly Hold Open Door Width 28" to 32"
$398.00 6130-8 Arm Assembly Hold Open Door Width 33" to 41"
6130-9 Arm Assembly Hold Open Door Width 42" to 48"
204
Effective Date: May 1, 2018
Canada Effective July 3, 2018
206
DISTRIBUTOR LIST PRICES
SCREW PACKAGES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
SCREW PACKS
MODEL # PRODUCT DESCRIPTION LIST PRICE
SN-134 Sleeve Nuts Only 1-3/4" Door $5.40
SN-214 Sleeve Nuts Only 2-1/4" Door $60.00
TBGN 138-38 Through-bolts and Grommet Nuts 1-3/8" door
$11.90TBGN 134-38 Through-bolts and Grommet Nuts 1-3/4" door
TBGN 214-38 Through-bolts and Grommet Nuts 2-1/4" door
CLOSER BODIES
1902/4LAP 1902/4 Closer Body $779.00
1905/6LAP 1905/6 Closer Body
207
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
YDC200 SERIES DOOR CLOSER
206
Effective Date: May 1, 2018
Canada Effective July 3, 2018
STANDARD FINISHES: Products will be furnished only in the following finishes.
ANSI/BHMA
CODE FINISH DESCRIPTION
689 Aluminum Painted
690 Dark Bronze Painted
MODEL # PRODUCT DESCRIPTION CASE
QUANTITY
APPROX.
SHIPPING
WT. LBS.
689 690
YDC201 Multi-Sized (1-4) Closer - Non-Hold Open 6 6 $144.00
YDC204 Size 4 Closer with Backcheck - Non-Hold Open 6 6 $132.00
MISCELLANEOUS PARTS:
MODEL # PRODUCT DESCRIPTION 689 690
200COV Cover Only $18.00
SN134 Sleeve Nuts Only – 1-3/4" Thick Door $5.40
Note: Sleeve Nuts furnished standard with all models.
208
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
208 209
DISTRIBUTOR LIST PRICES
DOOR ALARM
When Ordering: Specify design, hand and finish.
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION LIST PRICE
SDA16-1 Battery Operated Door Alarm with YA1 Cam Lock $346.00
SDA16XL-1 Battery Operated Door Alarm with Remote Mounting and YA1
Cam Lock $399.00
OPTIONS:
INSIDE CYLINDER: Ordered Separately - See Below
OUTSIDE CYLINDER: Ordered as 121NL - Specify Cylinder - See Below (Available for SDA16 only)
MODEL # PRODUCT DESCRIPTION RING/
COLLAR
ALL
FINISHES
RIM CYLINDERS FOR OUTSIDE OPTION
1109 Standard Cylinder 6-Pin
1765-.250
$70.00
1109 Standard Cylinder 7-Pin $72.00
1709 CMK Cylinder 6-Pin $86.00
1709 CMK Cylinder 7-Pin $88.00
1193 Large Format Interchangeable Core Cylinder 6-Pin $128.00
1193 Large Format Interchangeable Core Cylinder 7-Pin $130.00
5109 Security Cylinder 6-Pin $280.00
5109 Security Cylinder 7-Pin $284.00
U5109 High Security Cylinder 6-Pin $376.00
U5109 High Security Cylinder 7-Pin $380.00
5193 Security Large Format Interchangeable Core Cylinder 6-Pin $348.00
5193 Security Large Format Interchangeable Core Cylinder 7-Pin $352.00
K300 Yale®KeyMark®Cylinder 6- or 7-Pin $90.00
K840 Yale®KeyMark®Large Format Interchangeable Core Cylinder 6-Pin or 7-Pin $153.00
K640 Yale®KeyMark®Small Format Interchangeable Core Cylinder 6- or 7-Pin $150.00
A640 Best®Keyway Small Format Interchangeable Core Cylinder 6- or 7-Pin $120.00
2109 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $70.00
CYLINDERS
NOTE: See page 210 for power supplies and electrified accessories.
MODEL PRODUCT DESCRIPTION
CYLINDER
LENGTH
COLLAR
SIZE
ALL
FINISHES
MORTISE CYLINDERS FOR INSIDE OPTION
2153 Standard Mortise Cylinder 6-Pin 1-1/8" N/A $70.00
2153 Standard Mortise Cylinder 7-Pin 1-1/4" N/A $72.00
2196 Large Format Interchangeable Core Mortise Cylinder 6-Pin 1-1/2" KP4 $128.00
2197 Large Format Interchangeable Core Mortise Cylinder 7-Pin 1-11/16" 1765.250 $130.00
5153 Security Mortise Cylinder 6-Pin 1-1/8" N/A $280.00
5153 Security Mortise Cylinder 7-Pin 1-1/4" N/A $284.00
5196 Security Large Format Interchangeable Core Mortise Cylinder 6-Pin 1-1/2" KP4 $348.00
5197 Security Large Format Interchangeable Core Mortise Cylinder 7-Pin 1-11/16" 1765.250 $352.00
K100 Yale®KeyMark®Mortise Cylinder 6- or 7-Pin 1-1/8" N/A
$83.00
K100 Yale®KeyMark®Mortise Cylinder 6- or 7-Pin 1-1/4" N/A
K100 Yale®KeyMark®Mortise Cylinder 6- or 7-Pin 1-1/2" KP4 $177.00
K820 Yale®KeyMark®Large Format Interchangeable Core Mortise Cylinder 6-Pin 1-1/2" KP4 $153.00
K820 Yale®KeyMark®Large Format Interchangeable Core Mortise Cylinder 6-Pin 1-11/16" 1765.250
K620 Yale®KeyMark®Small Format Interchangeable Core Mortise Cylinder 6-Pin 1-1/4" N/A
$150.00
K620 Yale®KeyMark®Small Format Interchangeable Core Mortise Cylinder 6- or 7-Pin 1-3-8" N/A
A620 Best®Keyway Small Format Interchangeable Core Mortise Cylinder 6-Pin 1-1/4" N/A $120.00
A620 Best®Keyway Small Format Interchangeable Core Mortise Cylinder 6- or 7-Pin 1-3-8" N/A
MISCELLANEOUS ACCESSORIES:
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
00-0000-3425 Plug-in wall transformer with 12' cable assembly for 784 power supply $50.00
00-0000-3426 Gel cell battery – optional for use with 784 power supply $57.00
B-12-4 12V Battery (2 required for 24V) $70.00
EPT Electrical power transfer = up to 120 degree swing $95.00
EPTL Electrical power transfer – long = over 120 degree swing $127.00
Yale recommends McKinney®, Pemko and Securitron®for power transfer devices and other electronic accessories.
210
DISTRIBUTOR LIST PRICES
ELECTRIFIED ACCESSORIES AND WIRING DIAGRAM SERVICES
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION LIST PRICE
782 Controller - controls two "P" latch retraction exit devices $768.00
784 9VDC with plug-in wall transformer used with 7116 alarm kits, SDA16 door alarm, inTouch®
touchscreen locks and eBoss®keypad locks $472.00
BPS-24-1 1 AMP @ 24VDC $332.00
BPS-24-2 2 AMP @ 24VDC $675.00
BPS-24-4 4 AMP @ 24VDC $1,096.00
BPS-12-1 1 AMP @ 12VDC $332.00
BPS-12-3 3 AMP @ 12 VDC $675.00
POWER SUPPLIES:
WIRE HARNESS:
MODEL # PRODUCT DESCRIPTION LIST PRICE
WH-11 Hardwired harness for 36" exit devices used with 7116 alarm kits. Also used with SDA-16. $133.00
WH-12 Hardwired harness for 48" exit devices used with 7116 alarm kits.
WH-13 Hardwired harness for 36" surface vertical rod exit devices used with 7116 alarm kits. $161.00
WH-14 Hardwired harness for 48" surface vertical rod exit devices used with 7116 alarm kits.
WH-28 inTouch/nexTouch remote power and request to enter harness $61.00
CUSTOM WIRING DIAGRAM SERVICES:
MODEL # PRODUCT DESCRIPTION LIST PRICE
WD-BASIC Basic Riser/Elevation Diagram
Contact
800-810-WIRE
for pricing
WD-SPEC Specification package
WD-P2P Point to Point package
WD-SYSPK System Package
WD-SWP Special Wiring Package
Note: Consult Electromechanical Technical Services at 800-810-WIRE (9473) to establish the price, type and number of wiring diagrams required for project.
For 8800 Series Electrified Mortise Locksets, see pages 61-65 and 73-75
For 5400LN Series Electrified Cylindrical Locksets, see page 77
For 5300LN Series Electrified Cylindrical Locksets, see page 87
For 4700LN Series Electrified Cylindrical Locksets, see page 3
For 7000 Series Electrified Exit Devices, see pages 125-126
For 6000 Series Electrified Exit Devices, see pages 143-144
211
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
NEXTOUCH™ CYLINDRICAL LOCK
PRODUCT OPTIONS DEDUCT ADD
CYLINDERS: 6-Pin Only
LESS CYLINDER OR LESS CORE:
Standard cylinder prep less cylinder, specify "x LC"
Ordering Example: AU-NTB610-NR $62.00 —
Large format interchangeable core prep less core, for 6-pin, specify "x 1210
Prep x Less Core"
Ordering Example: AU-NTB610-NR x 1210 Prep x Less Core
— $0.00
INTERCHANGEABLE CORE CYLINDERS:
1210 - LFIC 6-Pin (includes MK or GMK)
Ordering Example: AU-NTB610-NR x 1210 x 626 — $58.00
A600 Best®Keyway SFIC 6-or 7-Pin (includes MK or GMK)
Ordering Example: Ordering Example: B-AU-NTB610-NR x A600 — $50.00
CYLINDER OPTIONS:
Lockset with SFIC Core Prep (less core) Prefix B to trim designation. Specify 6
or 7-pin.
Ordering Example: B-AU-NTB610-NR x Less Core
$0.00 $0.00
Lockset with Medeco®/ASSA®IC Core Prep (less core) Prefix M to trim
designation. Not available with MO or PB levers. 6-pin only.
Ordering Example: M-AU-NTB610-NR x Less Core
$0.00 $0.00
Lockset with Schlage®IC Core Prep (less core) Prefix SI to trim designation.
Not available with MO levers. 6-pin only.
Ordering Example: SI-AU-NTB610-NR x Less Core
$0.00 $0.00
Lockset with Corbin Russwin IC Core Prep (less core) Prefix R to trim
designation. Not available with MO or PB levers. 6-pin only.
Ordering Example: R-AU-NTB610-NR x Less Core
$0.00 $0.00
Lockset with Sargent IC Core Prep (less core) Prefix SG to trim designation.
Not available with MO levers. 6-pin only.
Ordering Example: SG-AU-NTB610-NR x Less Core
$0.00 $32.00
Lockset with Schlage®Standard Cylinder Prep (less cylinder) Prefix S to trim
designation. 6-pin only.
Ordering Example: S-AU-NTB610-NR x Less Cylinder
$25.00 $0.00
Lockset with Schlage®"C" Keyway Cylinder (specify cylinder model
number 2802)
Ordering Example: AU-NTB610-NR x 2803-53L x 626
$0.00 $0.00
Lockset with Arrow "AR" Keyway Cylinder (specify cylinder model 100CV1)
Ordering Example: AU-NTB-610 x 100CV1 x 626 $0.00 $0.00
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent®"LA"
or Schlage®"E" Keyway Cylinder. (specify cylinder model number 3804 x
keyway)
Ordering Example: AU-NTB610-NR x 3803-53L x 626
$0.00 $15.00
KNURLING: Available for all levers in 613E, 626 and BSP finishes only
Outside or Inside Only — $75.00
Both Sides — $150.00
ABRASIVE COATING:
Outside or Inside Only — $46.00
Both Sides — $92.00
DOOR THICKNESS: 1-3/4" (For 1-3/8" thick doors, thin door kit must be used) — STD
ANSI/BHMA
CODE FINISH DESCRIPTION PART
DESIGNATION
BRASS:
605 Bright Brass, Clear Coated 003
BRONZE:
613E Dark Oxidized Satin Bronze -
equivalent 13E
NOTE: SECURITY & YALE®KEYMARK®CYLINDERS: See next page for pricing. These cylinders are priced and discounted separately.
210
Effective Date: May 1, 2018
Canada Effective July 3, 2018
ANSI/BHMA
CODE FINISH DESCRIPTION PART
DESIGNATION
CHROME:
626 Satin Chrome Plated 025
PAINTED:
BSP Black Suede Powder Coat BSP
212
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
NEXTOUCH™ CYLINDRICAL LOCK
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DESIGNS: Augusta-AU Monroe - MO Pacific Beach - PB
CASE LOT: 3
SHIPPING WEIGHT: 7.2 lbs. per lock
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED
WITH LOCKSET
STRIKES:
202 Strike Box (Not Plated) $2.00 $2.00
371 Strike 1 1/4" Lip with Box $8.00 N/C
371 Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box $14.00 $2.00
497 ANSI Strike Lip 1-1/4" $37.00 STD
497 ANSI Strike with 1-1/8", 1-1/2" or 1-3/4" Lip $44.00 $13.00
DEADLOCKING LATCHBOLTS:
694 Beveled, 2-3/4" Backset, 1/2" Throw, 2-1/4" x 1-1/8" Front $92.00 STD
F694 Flat, 2-3/4" Backset, 1/2" Throw, 2-1/4" x 1-1/8" Front N/C
480B Beveled, 2-3/4" Backset, 3/4" Throw, 2-1/4" x 1-1/8" Front $173.00 $81.00
F480B Flat, 2-3/4" Backset, 3/4" Throw, 2-1/4" x 1-1/8" Front
380N 2-3/8" Backset, 2-1/4" x 1" Front $35.00 N/C
MODEL # PRODUCT DESCRIPTION ORDERED
SEPARATELY
ORDERED WITH
LOCKSET
CYLINDERS:
1803-53L Standard Cylinder 6-Pin $62.00 N/C
5803-53L Security Cylinder 6-Pin $246.00 $184.00
K800 Yale®KeyMark®Large Format Interchangeable Core Only 6-Pin $83.00 $83.00
K403-53L Yale®KeyMark®Cylinder $78.00 $78.00
1210 Large Format Interchangeable Core Only 6-Pin $58.00 $58.00
5210 Security Large Format Interchangeable Core Only 6-Pin $226.00 $226.00
K600 Yale®KeyMark®Small Format Interchangeable Core $80.00 $80.00
2803-53L Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random $62.00 N/C
3803-53L Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway $77.00 $15.00
100CV1 Arrow "AR" Keyway Cylinder $62.00 N/C
A600 Best®Keyway Small Format Interchangeable Core 6-or 7-Pin, Specify Keyway $50.00 $50.00
108S Schlage®Cylinder Adapter Kit $18.50 $18.50
MODEL # PRODUCT DESCRIPTION ALL FINISHES
NO RADIO OPTIONS
NTB610-NR Bored Lock w/Pushbutton Keypad - Cylinder Override $552.00
NTB630-NR Bored Lock w/Pushbutton Keypad - Without Cylinder Override $490.00
NTB620-NR Bored Lock w/Capacitive Touchscreen - Cylinder Override $576.00
NTB640-NR Bored Lock w/Capacitive Touchscreen - Without Cylinder Override $514.00
RADIO OPTIONS
NTB610-HA2 Bored Lock w/Pushbutton Keypad - Cylinder Override - ZigBee radio module $677.00
NTB630-HA2 Bored Lock w/Pushbutton Keypad - Without Cylinder Override - ZigBee radio module $615.00
NTB620-HA2 Bored Lock w/Capacitive Touchscreen - Cylinder Override - ZigBee radio module $701.00
NTB640-HA2 Bored Lock w/Capacitive Touchscreen - Without Cylinder Override - ZigBee radio module $639.00
NTB610-ZW2 Bored Lock w/Pushbutton Keypad - Cylinder Override - Z-Wave radio module $677.00
NTB630-ZW2 Bored Lock w/Pushbutton Keypad - Without Cylinder Override - Z-Wave radio module $615.00
NTB620-ZW2 Bored Lock w/Capacitive Touchscreen - Cylinder Override - Z-Wave radio module $576.00
NTB640-ZW2 Bored Lock w/Capacitive Touchscreen - Without Cylinder Override - Z-Wave radio module $514.00
213
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
NEXTOUCH™ CYLINDRICAL LOCK
212
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PARTS
LEVERS ONLY: PART NUMBER
AU
PART NUMBER
MO
PART NUMBER
PB
605 613E
626 BSP
Plain Inside (for use with NTB600) 14-YM00-6040 14-5301-6902 14-5301-6054
$56.00
Plain Outside (for use with NTB630/640) 14-YM00-6060 14-5303-6066 14-5303-6062
Standard Cylinder Outside (for use with
NTB610-NR/620) 14-YM00-6039 14-5305-6056 14-5305-6054
SFIC Outside (for use with NTB610-NR/620) 14-YM00-6030 14-5305-0016 14-5305-0012 $69.00
LFIC Outside (for use with NTB610-NR/620) 14-YM00-6028 14-5305-6059 14-5305-6051
OTHER COMPONENTS: PART NUMBER NO FINISH
Motorized Lock Chassis (1-3/8" & 1-3/4" door) 14-5361-0902-048 $110.00
Battery Cover 14-B600-0200-999 $34.00
Weather Gasket Kit (replacement inside & outside gaskets) 14-B600-0201-999
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
ACCESSORIES:
784 Optional remote 9VDC power supply with plug-in wall
transformer $472.00
WH-28 Remote power and request to enter wire harness $61.00
00-0000-3425 Replacement Plug-in wall transformer with 12' cable assembly
for 784 power supply $50.00
00-0000-3426 Gel cell battery – optional for use with 784 power supply $57.00
14-4761-0106 1-3/8" Thin door kit. Includes inside and outside escutcheon
spacers as well as a 2-3/8" latchbolt $71.00
MODEL # PRODUCT DESCRIPTION LIST PRICE
RADIO MODULES:
ZW2 USA Zwave $125.00
HA2 HA1.2 Zigbee
214
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
215
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
NEXTOUCH™ SECTIONAL MORTISE LOCK
214
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PRODUCT OPTIONS DEDUCT ADD
LESS CYLINDER: Specify "x LC"
Cylinder rings/collars not furnished with locksets ordered less cylinders. $70.00 —
Hotel Function Locksets - Less Cylinder $155.00 —
IC Housing ordered with locksets (ICLC) — $0.00
7-PIN CYLINDERS: Add to 6-Pin cylinder — $0.00
DUST GUARD: Prefix "D" to model number (refer to catalog for available cylinders) — $47.00
INTERCHANGEABLE CORE CYLINDERS:
2196 - LFIC 6-Pin (Includes MK or GMK)
Ordering Example: NTM610-NR x 2196 x LH x 626 — $58.00
A620 - SFIC 6-or 7-Pin (Includes MK or GMK)
Ordering Example: NTM610-NR x A620 x RH x 626 — $50.00
TORX®SECURITY HEAD SCREWS: Standard size only (add for each screw) — $50.00
Quantity Required: Sectional Trim = 4 — $1.00
Escutcheon Trim = 6 — $4.00
SPECIAL STRIKES:
Strikes with lip lengths other than 1-1/8" or 1-1/4" — $6.00
KNURLING: Available for all knob and levers in any finish except HA, PN and all Reflections®levers
OUTSIDE OR INSIDE ONLY — $75.00
Both Sides — $150.00
ABRASIVE COATING: Lever
Outside or Inside Only — $46.00
Both Sides — $92.00
DOORS 1-3/4" THICK TO 2-1/4" THICK:
Non-keyed — $103.00
Single cylinder keyed — $162.00
Double cylinder keyed — $181.00
ANSI/BHMA
CODE FINISH DESCRIPTION PART
DESIGNATION
BRASS:
605 Bright Brass, Clear Coated 003
BRONZE:
613E Dark Oxidized Satin Bronze - equivalent 13E
CHROME:
626 Satin Chrome Plated 025
PAINTED:
BSP Black Suede Powder Coat BSP
216
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
NEXTOUCH™ SECTIONAL MORTISE LOCK
Effective Date: May 1, 2018
Canada Effective July 3, 2018
DESIGNS: Augusta-AU Monroe - MO Pacific Beach - PB
REFLECTIONS DESIGNS: Hudson: TB, TC, UB, UC, TD
Danube: TE, TI
Seine: TG, TO, TJ, TK
Thames: TM, TN, TP, TQ, TR, TS
Victoria: TT, TU, TV, TW, TY, UW, TX, UX, TZ
Niagara: MA, RA, RB, RC
ROSE DESIGNS: R3, R4, R5, R6, R7, R8
Copenhagen - R
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
NO RADIO OPTIONS
NTM610-NR Mortise Lock w/Pushbutton Keypad - Cylinder Override $786.00
NTM615-NR Mortise Lock w/Pushbutton Keypad - Cylinder Override w/Thumbturn $806.00
NTM630-NR Mortise Lock w/Pushbutton Keypad - Without Cylinder Override $716.00
NTM635-NR Mortise Lock w/Pushbutton Keypad - Without Cylinder Override w/Thumbturn $736.00
NTM620-NR Mortise Lock w/Capacitive Touchscreen - Cylinder Override $810.00
NTM625-NR Mortise Lock w/Capacitive Touchscreen - Cylinder Override w Thumbturn $830.00
NTM640-NR Mortise Lock w/Capacitive Touchscreen - Without Cylinder Override $740.00
NTM645-NR Mortise Lock w/Capacitive Touchscreen - Without Cylinder Override w/Thumbturn $760.00
RADIO OPTIONS
NTM610-HA2 Mortise Lock w/Pushbutton Keypad - Cylinder Override - ZigBee radio module $911.00
NTM615-HA2 Mortise Lock w/Pushbutton Keypad - Cylinder Override - -w/Thumbturn ZigBee radio module $931.00
NTM630-HA2 Mortise Lock w/Pushbutton Keypad - Without Cylinder Override - ZigBee radio module $841.00
NTM635-HA2 Mortise Lock w/Pushbutton Keypad - Without Cylinder Override - w/Thumbturn ZigBee radio
module $861.00
NTM620-HA2 Mortise Lock w/Capacitive Touchscreen - Cylinder Override - ZigBee radio module $935.00
NTM625-HA2 Mortise Lock w/Capacitive Touchscreen - Cylinder Override - -w/Thumbturn ZigBee radio module $955.00
NTM640-HA2 Mortise Lock w/Capacitive Touchscreen - Without Cylinder Override - ZigBee radio module $865.00
NTM645-HA2 Mortise Lock w/Capacitive Touchscreen - Without Cylinder Override - -w/Thumbturn ZigBee radio
module $885.00
NTM610-ZW2 Mortise Lock w/Pushbutton Keypad - Cylinder Override - Z-Wave radio module $911.00
NTM615-ZW2 Mortise Lock w/Pushbutton Keypad - Cylinder Override - -w/Thumbturn Z-Wave radio module $931.00
NTM630-ZW2 Mortise Lock w/Pushbutton Keypad - Without Cylinder Override - Z-Wave radio module $841.00
NTM635-ZW2 Mortise Lock w/Pushbutton Keypad - Without Cylinder Override - w/Thumbturn Z-Wave radio
module $861.00
NTM620-ZW2 Mortise Lock w/Capacitive Touchscreen - Cylinder Override - Z-Wave radio module $935.00
NTM625-ZW2 Mortise Lock w/Capacitive Touchscreen - Cylinder Override - w/Thumbturn Z-Wave radio module $955.00
NTM640-ZW2 Mortise Lock w/Capacitive Touchscreen - Without Cylinder Override - Z-Wave radio module $865.00
NTM645-ZW2 Mortise Lock w/Capacitive Touchscreen - Without Cylinder Override - w/Thumbturn Z-Wave radio
module $885.00
MODEL # PRODUCT DESCRIPTION ALL
FINISHES
STRIKES:
2815 Latchbolt and Deadbolt , Curved Lip (8800) $37.00
2816 Latchbolt and Deadbolt , Flat Lip (8800) $37.00
217
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
MORTISE MOTORIZED LOCK BODY
216
Effective Date: May 1, 2018
Canada Effective July 3, 2018
PART NUMBER DESCRIPTION LIST PRICE
50-M600-0100-014 Lockbody No Deadbolt $348.00
50-M605-0100-014 Lockbody w/Deadbolt $460.00
FIXED CORE MORTISE CYLINDERS
MODEL # PRODUCT DESCRIPTION CAMS ORDERED
SEPARATELY
2153 Standard Cylinder for 8800FL, 8800, 8800RL, 350 Series
Deadlocks 1" - 1-3/4" 2160 $70.00
2123 Extra Length Cylinder for 8800FL, 8800, 8800RL *1-7/8" - 3-1/2" 2160 $98.00
2553 Schlage®"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed
Random 1-1/8" 2160 $70.00
7-Pin Cylinders ADD –– — $2.00
INTERCHANGEABLE CORE MORTISE CYLINDERS: LFIC
MODEL # PRODUCT
DESCRIPTION LENGTH CAM ALL FINISHES
MORTISE
2196 LFIC Cylinder 6-Pin 1-1/2", 1-3/4", 2" 2160 $128.00
2197 LFIC Cylinder 7-Pin 1-11/16", 2" 2160 $130.00
SECURITY CYLINDERS
MODEL # PRODUCT
DESCRIPTION CAM ORDERED
SEPARATELY
ORDERED WITH
LOCKSET ADD
MORTISE
5153 Security Cylinder 6-Pin 2160 $280.00 $210.00
5153 Security Cylinder 7-Pin 2160 $284.00 $214.00
218
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
U.L. HIGH SECURITY CYLINDERS
Effective Date: May 1, 2018
Canada Effective July 3, 2018
MODEL # PRODUCT DESCRIPTION CAM ORDERED
SEPARATELY
ORDERED WITH
LOCKSET ADD
MORTISE
U5153 High Security Cylinder 6-Pin 2160 $376.00 $306.00
U5153 High Security Cylinder 7-Pin 2160 $380.00 $310.00
SECURITY INTERCHANGEABLE CORE MORTISE CYLINDERS
MODEL # PRODUCT DESCRIPTION CAM ORDERED
SEPARATELY
ORDERED WITH
LOCKSET ADD
MORTISE
5196 LFIC Security Cylinder 6-Pin 2160 $348.00 $278.00
5197 LFIC Security Cylinder 7-Pin 2160 $352.00 $282.00
COMPLETE CYLINDERS: SFIC
Note: A620 include Best®keyway core (A600), specify keyway.
MODEL # PRODUCT DESCRIPTION CAM ALL FINISHES
MORTISE
A620 SFIC Cylinder 6- or 7-Pin KC1 $120.00
YALE®KEYMARK®CYLINDERS, CORES AND HOUSINGS
MODEL # PRODUCT DESCRIPTION LENGTHS ALL FINISHES
K100 Fixed Core Mortise Cylinder 1-1/8", 1-1/4" $83.00
K100 Fixed Core Mortise Cylinder 1-1/2", 1-3/4", 2" $177.00
K620 SFIC Mortise Cylinder 1-1/4", 1-3/8", 1-3/4" $150.00
K630 SFIC Tapered Mortise Cylinder 1-1/4", 1-3/8" $154.00
K820 LFIC Mortise Cylinder 1-1/2", 1-11/16", 1-3/4", 2" $153.00
MORTISE CYLINDERS:
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder.
MODEL # PRODUCT DESCRIPTION ALL FINISHES
K600 SFIC Core $80.00
K800 LFIC Core $83.00
K890 LFIC Core for Schlage $83.00
MORTISE CORES:
MORTISE HOUSINGS:
MODEL# PRODUCT DESCRIPTION LENGTHS ALL FINISHES
K660 SFIC Mortise Housing 1-1/4", 1-3/8",1-3/4" $70.00
K670 SFIC Tapered Mortise Housing 1-1/4", 1-3/8" $74.00
K860 LFIC Mortise Housing 1-1/2", 1-11/16", 1-3/4", 2" $70.00
219
DDIISSTTRRIIBBUUTTOORR LLIISSTT PPRRIICCEESS
CYLINDER COMPONENTS & OPTIONS
218
Effective Date: May 1, 2018
Canada Effective July 3, 2018
*CYLINDER COLLARS:
MODEL # PRODUCT DESCRIPTION ALL FINISHES
KP3 Wave Washer (funished standard with 1765 collar) $3.90
1765 .062" - .219" $33.40
.250" - .656"
1766 Tubular Spacer Collar for Mortise and Rim High Security $47.80
*Specify dimension. Cylinder collars not furnished with locksets or other products when ordered less cylinders. When cylinders ordered
separately, collar length must be specified.
MODEL/PART # PRODUCT DESCRIPTION LIST PRICE
ACCESSORIES:
784 Optional remote 9VDC power supply with plug-in wall transformer $472.00
WH-28 Remote power and request to enter wire harness $61.00
00-0000-3425 Replacement Plug-in wall transformer with 12' cable assembly for 784 power supply $50.00
00-0000-3426 Gel cell battery – optional for use with 784 power supply $57.00
MODEL # PRODUCT DESCRIPTION LIST PRICE
RADIO MODULES:
ZW2 USA Zwave $125.00
HA2 HA1.2 Zigbee
Yale Locks & Hardware
Address: 225 Episcopal Road, Berlin, CT 06037-4004 USA
Tel: 1-800-438-1951 •Fax: 1-800-338-0965 •www.yalelocks.com
ASSA ABLOY Door Security Solutions Canada
Address:160 Four Valley Drive, Vaughan, ON L4K 4T9
Tel: 1-800.461.3007 •Fax: 1-800.461.8989 •www.assaabloydss.ca
ONLINE LITERATURE AND TEMPLATES
Copyright © 2002-2018, Yale Security, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Yale Security, Inc. is prohibited. Patent pending and/or
patent www.assaabloydss.com/patents.
YALE, with its unique global reach and range of products, is the world’s favorite lock.
ASSA ABLOY is the global leader in door opening solutions, dedicated to satisfying end-user needs for security, safety and convenience.
An ASSA ABLOY Group brand
42001-3/18R
For the latest information on Yale Locks & Hardware products,
visit our website at www.yalelocks.com.
Click "Library" to find:
Catalogs
–
Parts Manuals
–
Templates
–
Specifications
–
Installation Instructions
Yale® customers can click "Extranet" on the website to register and:
Check the status of orders
–
Check availability of quick ship items
–
Track your order and confirm delivery
–
Receive email notification of template changes
–
And more…
