DC-DC 模组:
尺寸: 50×30×17.7mm
输入: 20~36V / 1A(MAX) 输出: 9V 2A
无线充电模组:
使用手册
无线充电器
型号: QI02
注意事项
1. 不要接触液体。
2. 不要拆卸产品。
3. 避免跌落。
4. 避免高温。
技术参数
输出: 5W / 7.5W / 10W Max
充电距离: 1. 0-4.5mm 无线充电器和手机之间的距离。
2. 8mm 无线充电器 TX 线圈到 RX 线圈的
距离。
充电范围: 10×10mm 产品尺寸: ø59.5mm×18mm
输入: 9V 2A
配件清单
无线充电器 x 1 防盗片 x 1
螺丝 x 3
安装和使用方法
1. 将无线充电器按下图所示用螺丝固定在桌子上。
本产品是桌子嵌入式快速无线充电器，符合WPC Qi 1.2.4
BPP的标准。此产品能支持所有Qi充电协议的设备5W无线
输出，同时能支持苹果7.5W和三星10W无线快速充电。
2. 把手机放在有安装无线充电器的桌子的指定桌面位置。
User Manual
Wireless Charger TX
Model: QI02
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
2. Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
3. NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Made in China
Attention
1. Don’t expose to liquids.
2. Don’t disassemble.
3. Avoid dropping.
4. Avoid extreme temperatures.
Specifications
Wireless charger TX:
Charge distance: 1. 0-4.5mm Between wireless charger
housing to Phone
2. 8mm Between wireless charger TX
Coil to RX Coil
Charge area: 10×10mm Size：ø59.5mm×18mm
Input: 9V 2A Output: 5W / 7.5W / 10W Max
DC-DC Module:
Size: 50×30×17.7mm
Input: 20~36V / 1A(MAX) Output: 9V 2A
Accessories list
Wireless Charging TX x 1 Anti-theft parts x 1
Screw x 3
Installation and use methods
1. Attach the wireless charger TX to the table with screws.
This product is a fast wireless charger compaible with WPC
Qi 1.2.4 BPP standard. It can support Apple 7.5W,
Samsung 10W fast wireless charging and all Qi-enabled
devices with 5W standard wireless charging.
2. Place your phone on the designated position of the table
that have attached the charger.
FCC Radiation Exposure
Statement
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
