User’s
QuickStart Guide
Model 30711
Mobile Personal Emergency Response System
Pendant Functions
Speaker
Emergency
Button
TEST
Button
Microphone
Manufacturer’s Disclaimers and Limited Warranty
The Manufacturer’s warranty period is one year from time of purchase.
COMMUNICATION AND RESPONSE LIMITATIONS: Purchaser acknowledges
that signals pass through communication networks wholly beyond the control
of The Manufacturer and are not maintained by The Manufacturer, and,
therefore, The Manufacturer shall not be responsible for any equipment or
communication failure which prevents transmission signals from reaching your
contact list including emergency 911 operators or damages arising therefrom.
Purchaser acknowledges that The Manufacturer provides no response to the
System’s equipment. The Manufacturer shall not be responsible for ambulance,
police or other emergency response.
TESTING AND SERVICE OF THIS EQUIPMENT: The equipment, once installed, are
in the exclusive possession and control of the Purchaser, and it is Purchaser’s sole
responsibility to test the operation of equipment and request warranty service if the
equipment is under warranty.
PURCHASER’S EXCLUSIVE REMEDY: Purchaser’s exclusive remedy for The
Manufacturer’s default hereunder is to require The Manufacturer to repair or replace,
at The Manufacturer’s option, any equipment or part of the personal emergency alert
system which is non-operational during The Manufacturer’s warranty period.
LIMITATION OF LIABILITY: This equipment is not designed or guaranteed
to prevent any loss or injury. This Limited Warranty and Disclaimer of Liability
constitutes the terms of sale and use of the equipment, and if there should arise
any liability on the part of The Manufacturer as a result of any cause whatsoever,
regardless of whether or not such loss, damage, or personal injury was caused by
or contributed to by The Manufacturer’s negligence to any degree or failure to
perform any obligation or strict products liability, such liability will be limited to an
amount paid by the Purchaser to The Manufacturer for the product, or to the sum
of $350.00, whichever is greater. For warranty information, contact Customer
Service at LogicMark, LLC.
v 5.2 Model 30711
FCC ID TYD30711
RED Charging Light
Low Battery Warning:
Flashes when battery is at less than
25% capacity
GREEN Power Light
Battery Charging:
Green Light is Blinking.
Fully charged:
Green Light is Solid.
Light is OFF when
removed from charging
base
BLUE Call In Process Light
Solid when connected to a
cellular network
PLUS
G
uardian
911
a
lert
PLUS
Guardian911
alert
PRESS & HOLD
Test
![](/img.php?id=2699043&img=bg2.png)
Before First Use:
Fully charge handset by putting it in the charging cradle prior
to use. It may take 3 to 4 hours to ensure a full charge. The
Charging Light on the handset will blink Green when charging
and turn solid Green when fully charged. SEE ILLUSTRATION
BELOW.
Press the TEST button for 4 seconds.
1. User pushes the TEST button for 4 seconds
2. Handset announces “Power ON,” Handset turns on
3. Handset announces Version number
4. Handset checks battery status and announces:
“Battery OK” if Battery greater than 25%
“Recharge Battery Soon” if battery less than 25%
5. Handset then checks for cellular service and announces:
“Service Coverage OK” – Good Cellular service coverage
“No Service Coverage” – No Cellular service
6. Handset announces whether Battery Supervision feature is “On” or “Off”
7. Handset announces “Power OFF,” Handset then returns to standby
System Check
The Battery Supervision feature allows the GuardianAlert
911 Plus to automatically check the status of its battery
every 24 hours.
If Battery Supervision is turned ON:
1. Estimated standby time between charges will be 2-3 months
2. It will check the status of the battery every day at the same time,
beginning 24 hours after the feature is turned ON
3. When the battery reaches 25% capacity or less, the handset
will announce “Recharge battery soon”. The announcement will
be made daily until the handset is recharged
If Battery Supervision is turned OFF:
1. Estimated standby time between charges will be 6-12 months
2. The user will have to manually perform a System Check
periodically to check the status of the battery
Turning Battery Supervision ON or OFF:
1. Perform a System Check – Push and HOLD the Gray TEST
button for 4 seconds
2. When you hear “Version Number” – Push and HOLD the Gray
TEST button again for 4 seconds. The Blue Light will blink twice
3. The System Check voice prompt will then confirm the Battery
Supervision status – either Battery Supervision ON or Battery
Supervision OFF
Simply repeat steps 1-3 to toggle the Battery Supervision feature
ON or OFF
1. User Pushes the BLUE EMERGENCY button for 1 second:
a. Blue Light flashes and short musical chime is heard
b. Handset calls 911
2. User talks to the 911operator using the speakerphone in the handset
3. Call can be ended one of two ways:
a. Handset detects 911 has hung up, automatically ends the call, and the Handset returns to standby
b. User pushes the TEST button on the handset to end the call and hang up
4. Handset announces “Hanging Up” and returns to Standby
Placing an Emergency Call
3
Battery Supervision
4
2
Troubleshooting
5
If you are having problems using
your handset, please call:
1-866-541-VETS (8387)
Plug Base into power and
charge handset
1
RED Light
Low battery Warning
GREEN Light
Battery Charging
BLUE Light
Call in Process
911
PLUSPLUS
GUARDIANGUARDIAN
911
ALERTALERT
PLUS
G
uardian
911
a
lert
PLUS
G
uardian
911
a
lert
Test Button
Emergency Call Button
PRESS & HOLD
PRESS & HOLD
Test
Things The FCC would like for you to know:
1. This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement:
Your 3G mobile phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications Commission
of the U.S. Government. These limits are part of comprehensive guidelines of
the U.S. Government. These limits are part of and establish comprehensive
guidelines of the U.S. Government. These limits are part of and establish
permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health. The exposure
standard for 3G mobile phones employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/
kg. * Tests for SAR are conducted with 3 G mobile phone transmitting at
its highest certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the actual SAR
level of 3G mobile phone while operating can be well below the maximum
value. This is because 3G mobile phone is designed to operate at multiple
power levels so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station antenna, the lower
the power output. Before a 3G mobile phone model is available for sale
to the public, it must be tested and certified to the FCC that it does not
exceed the limit established by the government adopted requirement for
safe exposure. The tests are performed in positions and locations (e.g., at
the ear and and worn on the body) as required by the FCC for each model.
The highest SAR value for this model 3G mobile phone when tested for
worn on the body, as described in this user guide, is 1.40 W/Kg(Body-
worn measurements differ among 3G mobile phone models,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various 3G mobile
phone and at various positions, they all meet the government
requirement for safe exposure. The FCC has granted an Equipment
authorization for this model Tablet interference will not occur in a
particular installation. If this equipment does cause 3G mobile phone
with all reported SAR levels evaluate as in compliance with the FCC RF
exposure guidelines. SAR information on this 3G mobile phone is on file
with the FCC and can be found under the Display Grant section of http://
www.fcc. gov/ oet/fccid.
FCC ID: TYD-GA30711 Additional information on Specific Absorption
Rates (SAR) can be found on the Cellular Telecommunications Industry
Asso-ciation (CTIA) web-site at http://www.wow-com.com. * In the
United States and Canada, the SAR limit for Tablet PC used by the public
is 1.6watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a sub-stantial margin of safety to give additional protection
for the public and to account for any variations in measurements.
Body-worn Operation:
This device was tested for typical body-worn operations. To comply with
RF exposure requirements, a minimum separation distance of 10mm must
be maintained between the user’s body and the handset, including the
antenna. Third-party belt-clips, including the antenna. Third-party belt-
clips, holsters, and similar accessories used by this device should not
contain any metallic components. Body-worn accessories that do not
meet these requirements may not comply with RF exposure requirements
and should be avoided. Use only the supplied or an approved antenna.
v5.1
FCC ID TYD-GA30711
