Contents

user manual

INSTRUCTION MANUAL
BLUETOOTH
HEADSET
A38
ASTRO Gaming's A38 Wireless Headset offers a solution
for the audio-savvy citizen who equally measures
business and pleasure. Professionally-tuned Astro Audio
paired with Active Noise Canceling audio and
microphone. APTx Bluetooth sound packs an aural
one-two punch. Whether you're gaming, enjoying a
feature film, or have tunes in need of heavy rotation--
control over bass and ambient noise is all just a touch
away.
Congratulations on your
sound investment.
A38 HEADSET
ANC
APTx
USB CHARGING CABLE
Charges your A38 Headset.
CARRYING CASE
For safe transport and storage.
Package Contents
Contents
So... you've breached the boxy exterior, and you're working
your way along the inside. You'll find that your A38 comes
simply bundled.
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
ASTRO AUDIO
SUPERIOR
TOURNAMENT
COMPETITIVE
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
ASTRO AUDIO
SUPERIOR
TOURNAMENT
COMPETITIVE
UI/IO
Power
Power /
Pairing
LEDs
Volume
USB Port
Charging LED
Multi-
Function
Control
Mute
(Red: Muted
White: Mic On)
POWER & PAIRING
POWER
To turn on: Press Power Button once
(Audio Wake Up Tone Confirmation)
To turn off: Hold Power Button for 1s
(Audio Power Down Tone Confirmation)
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
Blinks Blue: On
Pairing
1. Enable Bluetooth Pairing / Scanning on device host
2. Hold Power Button on A38 for 3s to enter pairing mode
(Series Beep Confirmation, LED alternates red and blue)
Pairing Successful: (Audio Rising Tone Confirmation)
Pairing Failed: (Audio Failture Tone Confirmation)
Device is listed as “ASTRO A38”
To connect to previous device, turn on A38 and hold
power button for 2s.
For optimal connectivity, minimize obstructions between
Bluetooth device and Bluetooth Antenna on A38
A38 will auto power off after 5 minutes of inactivity
If you need technical support please submit a support
ticket at astrogaming.com/support
NFC PAIRING
NFC PAIRING
1. Enable NFC on device
2. Hold NFC device to A38 left ear cup
To disconnect from NFC device:
Hold NFC device to A38 left ear cup
To power A38 on and pair with NFC:
If A38 is off, enable NFC on device
Hold NFC device to A38 left ear cup
A38 will turn on and pair.
*Success may vary between devices
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
NFC Tag
Bluetooth
Antenna
Left Side
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
ASTRO AUDIO
SUPERIOR
TOURNAMENT
COMPETITIVE
CONTROLS
Power
Power /
Pairing
LEDs
Volume
USB Port
Charging LED
Multi-
Function
Control
Mute
(Red: Muted
White: Mic On)
Solid Amber: Charging
Amber Off: Charge Complete
Volume Control
Increase Volume: Press or Hold +
Decrease Volume: Press or Hold -
Multi Function Control
Pick up / End Call: Press once
Reject Call / Call Waiting: Hold for 1s
Answer Call Waiting: Press once
Track Forward: Press twice
Track Back: Hold for 1s and release
Play / Pause: Press once
Airplane Mode On / Off:
Hold for 5s (Red + Blue)
Charging
Plug in USB to any power source
Troubleshooting
See FAQ:
http://www.astrogaming.com/a50/a50-wireless-system
All products purchased directly from ASTRO Gaming comes with an automatic 1 year
warranty on defective parts or faulty workmanship. No registration is required. That
being said, if you register your product with us, we will be able to provide you with
even better customer service *and* we’ll cover your shipping in both directions if a
repair is needed for domestic customers. Furthermore, if you purchased one of our
products from a retailer other than ASTRO Gaming, you’ll need to register it with us
otherwise we’ll have no idea who you are.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Register ASTRO products here:
http://www.astrogaming.com/register
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
SUPPORT
Federal Communications Commission (FCC)
Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Warning words used in IC : Need both French and English;
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
This Class【B】 digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
FCC STATEMENT
