Logitech® Wireless Mouse M545
Setup Guide
On
AA
1
3
2
English
Advanced features:
Software is optional for this mouse!
Download the free mouse software
at www.logitech.com/support/m545
to customize button functions,
adjust speed of tracking and scrolling.
Note: If other USB 3.0 devices are in use,
please try to plug Pico receiver into other
USB port at a distance.
简体中文
高级功能：
可选择为此鼠标安装软件！
可在 www.logitech.com/support/
m545 下载免费鼠标软件，以自定义按键
功能并调整跟踪和滚动速度。
注意： 如果正在使用其他 USB 3.0
设备，请尝试将微型接收器插入一定距离
以外的其他 USB 端口。
© 2013 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may
be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any
errors that may appear in this manual. Information contained herein is subject to change without notice.
版权所有 ©2013 年罗技。 罗技、罗技标志、Logitech 和其他罗技商标均归罗技所有，并或已注册。 所有其它商标
均是其各自所有者的财产。 罗技对于本手册中可能出现的任何错误不承担任何责任。 本手册中包含的信息如有更改，
恕不事先通知。
620-003584.002
www.logitech.com
Logitech® Wireless Mouse M545
Setup Guide
USB
设置指南
设置指南
English
Help with setup:
Mouse not working
đƫ Is the mouse powered on?
đƫ Is the Pico receiver securely
plugged into a computer USB port?
Try changing USB ports.
đƫ If the Pico receiver is plugged into
a USB hub, try plugging it directly
into a USB port on your computer.
đƫ Try moving the Pico receiver to
a USB port closer to the mouse.
đƫ Remove metallic objects between
the mouse and the Pico receiver.
đƫ Check the orientation of the battery
inside the mouse. Replace the battery
if necessary. The mouse uses one AA
alkaline battery.
đƫ Try reconnecting the mouse and Pico
receiver using the Logitech Unifying
software. (Refer to the Unifying section
in this guide.)
đƫ If other USB 3.0 devices are in use,
try plugging Pico receiver into other
USB port at a distance.
简体中文
设置帮助:
鼠标不工作
・ 鼠标是否已接通电源?
・ 微型接收器是否已牢固插入电脑的
USB 端口？ 尝试更换 USB 端口。
・ 如果微型接收器已插入 USB 集线器，
则尝试将其直接插入电脑的
USB 端口。
・ 尝试将微型接收器移至离鼠标较近的
USB 端口。
・ 移除鼠标和微型接收器之间的金属
物体。
・ 检查鼠标内的电池方向。 如有必要，
请更换电池。本鼠标使用一节 AA 碱
性电池。
・ 尝试使用罗技 Unifying 软件重新连接
鼠标和微型接收器。（请参考此指南的
Unifying 部分。）
・ 如果正在使用其他 USB 3.0 设备，
则尝试将微型接收器插入一定距离以外
的其他 USB 端口。
English
The Logitech®
Unifyingreceiver
Plug it. Forget it. Add to it.
Your new Logitech product ships
with a Logitech® Unifying receiver.
Did you know you can add a compatible
Logitech wireless device that uses
the same receiver as your current
Logitech Unifying product?
Are you Unifying-ready?
If you have a Logitech wireless device
that’s Unifying-ready, you can pair
it with additional Unifying devices.
Just look for the orange Unifying logo
on the new device or its packaging.
Build your ideal combo. Add something.
Replace something. It’s easy, and you’ll use
only one USB port for up to six devices.
Getting started is easy
If you’re ready to pair your device(s)
via Unifying, here’s what you need to do:
1. Make sure your Unifying receiver
is plugged in.
2. If you haven’t already, download
the Logitech® Unifying software from
www.logitech.com/unifying.
3. Start the Unifying software* and follow
the onscreen instructions to pair the
new wireless device with your existing
Unifying receiver.
*Go to Start / All Programs / Logitech /
Unifying / Logitech Unifying Software
简体中文
罗技 Unifying 接收器
随插即忘、一联百通。
全新的罗技产品将随附 Unifying 接收
器。您知道吗，您可以将兼容的罗技无线
设备添加到现有罗技 Unifying 产品正在
使用的接收器上。
您已准备好开始使用 Unifying 了吗？
如果您有可以使用 Unifying 的罗技无线
设备，您可以将该设备与其他 Unifying
设备配对使用。只需确认新设备或其包
装上有橙色的 Unifying 徽标。打造您的
理想组合。添加设备。替换设备。这很简
单，而且您只需一个 USB 端口就可连接
多达六个设备。
简单入门
如果您已准备好通过 Unifying 配对使用
您的设备，您需要：
1. 确认已插入 Unifying 接收器。
2. 如果您还没有下载 Logitech® Unifying
软件，请访问 www.logitech.com/
unifying 下载该软件。
3. 启动 Logitech Unifying 软件*并按照
屏幕上的说明进行操作，将新的设备与
现有的 Unifying 接收器配对。
*依次单击“开始”/“所有程序”/“罗技”/
“Unifying”/“罗技 Unifying 软件”
www.logitech.com/support/m545
English
Features
1. Left and right mouse buttons
2. Scroll wheel
3. Battery LED—Flashes green when
mouse is powered on, and it flashes
red when the battery power is low
4. Middle button—The function of this
button depends on your operating
system and the application being used.
For example, if you are browsing
the Internet in Windows and click
on a link using the Middle button,
typically the link opens in a new tab.
5. Tilt button
đƫWindow 7 and Windows 8
without software: Tilt left/right
for backward/forward.
đƫWindows 8 with software installed:
Tilt left to show the Application
Switcher; Tilt right to show
the Charm Bar.
6. Side button
đƫWindows 7: Press to toggle
between minimizing all applications
(Show Desktop) and restoring
all applications.
đƫWindows 8: Press to switch
to Desktop mode in Start Screen
or applications.
7. Side button
đƫWindows 8: Press to switch
between the Start Screen
and the last open application.
đƫWindows 7: Press to open
the Start Menu.
8. On/O slider switch
9. Pico receiver storage—When the
mouse is not in use, you can store
the Pico receiver inside the mouse.
10. Battery door
简体中文
功能
1. 左/右鼠标按键
2. 滚轮
3. 电池 LED 指示灯 — 鼠标电源处于
开启状态时闪烁绿灯，电池电量低时
闪烁红灯
4. 中键 — 此键的功能取决于您的操作
系统和所使用的应用程序。 例如，
如果您在 Windows 系统中浏览网页
并使用“中键”点击链接，则链接通
常会在新的标签中打开。
5. 倾斜键
・ 未安装软件的 Windows 7 和
Windows 8： 向左/右倾斜即可后
退/前进。
・ 安装有软件的 Windows 8：
向左倾斜即可显示“应用程序切换
程序”；向右倾斜则可显示“Charm
工具栏”。
6. 侧面按键
・ Windows 7： 按下按键即可在最小
化所有应用程序（“显示桌面”）和还
原所有应用程序之间切换自如。
・ Windows 8： 在“开始”屏幕或应
用程序中，按下按键即可切换至桌
面模式。
7. 侧面按键
・ Windows 8： 按下按键即可在
“开始”屏幕和最后一个打开的应用
程序之间切换。
・ Windows 7： 按下按键即可打开
“开始”菜单。
8. 开启/关闭滑动开关
9. 微型接收器的收存 — 鼠标处于停
用状态时，可将微型接收器收存到
鼠标内。
10. 电池盖
AA
3
1
4
5
8
9
10
2
6
7
