Loyal Electronics 8004RX Dongle User Manual 1
Shenzhen Loyal Electronics Co., Ltd. Dongle 1
Manual
KG8004
Wireless mini keyboard
Art.no Model
concerning technical problems please contact our Customer Services.
Product description
• Wireless mini keyboard with optical trackball and integrated mouse buttons.
• Range: up to 15 m.
• Compatible with Windows 7 (32/64-bit), Vista (32/64-bit) and XP.
• Comes with USB receiver and batteries.
Operation
1.
Depress [ FN ] and then press [ Insert Num LK
function keys [ 0 ] – [ 9 ], marked with blue.
Keep [ FN
FN ] to return to normal letter functioning.
2.
FN F11 ].
Care and maintenance
cleaning agents.
Troubleshooting
1. ON to OFF and
back to ON.
2.
3.
Disposal
When it is time to dispose of this product, do so in accordance with local regula-
Specifications
Frequency range 2.4000–2.4835 GHz
Range Up to 15 m
Power supply 2 x AAA/LR03 batteries (1.5 V),
alkaline batteries recommended.
USB Interface 1.1
Size (W x H x D) 265 x 127 x 17 mm
Note:
•
•
• Turn off any existing wireless equipment to see if that could be causing
•
and receiver.
1.
2.
3.
4. ON/OFF switch
5. USB receiver
6.
7.
System requirements
• USB port
• Windows XP/VISTA/Win 7
Contents
• Wireless mini keyboard
•
• 2 x AAA/LR03 batteries
• Instruction manual
Installation
1.
2.
3.
4. ON
5.
6.
window will appear once installation is complete.
1 2 3
4 5 6 7
Matching the receiver and keyboard again via pressing the three keys together:
ESC;key 1;key ahead of backspace
When the green LED starts flashing ,pls insert the USB receiver into any port
available on PC/ Notebook within 10 seconds,place the keyboard around the
USB receiver within 30cm to enter the pairing connection.
Upon the successful pairing, the LED Indicator stops flashing
4.
FCC NOTE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician
for help.
FCC Caution
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate this equipment.
