English - 1
Table of contents
Copyright Information ..................................................................................... 4
Chapter 1 Safety Instructions ...................................................................... 5
Safety Precautions ........................................................................ 6
FCC Warning ................................................................................. 6
EN55022 (CE Radiation) Warning ................................................ 6
Revisions .......................................................................................................... 7
Chapter 2 Package Contents ....................................................................... 8
Chapter 3 Product Overview ........................................................................ 9
3.1 Relative Operation Position ......................................................... 10
3.2 Recommend distance .................................................................. 10
3.3 Incorrect Use ............................................................................... 11
Chapter 4 Installation and Connections ................................................... 12
4.1 System Diagram .......................................................................... 12
4.2 Connecting to a computer ........................................................... 12
4.3 Connecting to an Interactive Whiteboard (IWB) .......................... 12
4.4 Mounting the PC120.................................................................... 13
4.5 Installing application software ..................................................... 13
Chapter 5 Start Using .................................................................................. 19
Chapter 6 Function Menu ........................................................................... 20
6.1 IN WINDOWS .............................................................................. 20
6.1.1 Main Function Menu .................................................................... 20
6.1.2 Annotation Tools .......................................................................... 21
6.1.3 Camera Settings .......................................................................... 22
6.1.4 Options ........................................................................................ 23
6.1.5 Time Lapse .................................................................................. 24
6.2 IN MAC ........................................................................................ 25
6.2.1 Software Screen Introduction ...................................................... 25
6.2.2 Thumbnail .................................................................................... 26
English - 2
6.2.3 Main Function Menu .................................................................... 27
6.2.4 Annotation ................................................................................... 28
6.2.5 Camera Settings .......................................................................... 29
6.2.6 Options ........................................................................................ 30
6.2.7 Time Lapse .................................................................................. 31
Chapter 7 Descriptions of Major Functions
– IN Windows ........................ 32
7.1 I would like to display a live image .............................................. 32
7.2 I would like to optimize the image ............................................... 32
7.3 I would like to use the auto focus ................................................ 32
7.4 I would like to adjust the brightness ............................................ 32
7.5 I would like to turn on/off the lamp .............................................. 32
7.6 I would like to zoom in/zoom out ................................................. 32
7.7 I would like to capture images ..................................................... 32
7.8 I would like to record videos ........................................................ 33
7.9 I would like to set up the timer. .................................................... 34
7.10 I would like to freeze images ....................................................... 34
7.11 I would like to annotate the live image ........................................ 35
7.12 I would like to add text to the live image ..................................... 36
7.13 Working with Other Applications ................................................. 37
Chapter 8 Descriptions of Major Functions – IN MAC ............................... 41
8.1 I would like to display a live image .............................................. 41
8.2 I would like to optimize the image ............................................... 41
8.3 I would like to use the auto focus ................................................ 41
8.4 I would like to adjust the brightness ............................................ 41
8.5 I would like to turn on/off the lamp .............................................. 41
8.6 I would like to zoom in/zoom out ................................................. 41
8.7 I would like to capture images ..................................................... 42
8.8 I would like to capture images continuously ................................ 42
8.9 I would like to freeze the live image ............................................ 42
8.10 I would like to annotate the displayed image .............................. 42
8.11 I would like to add textual annotation to images ......................... 43
8.12 I would like to record videos ........................................................ 44
English - 3
8.13 I would like to use the mask mode .............................................. 45
8.14 I would like to use the spotlight mode ......................................... 45
8.15 I would like to manage saved image files.................................... 46
Chapter 9 Connecting to a Microscope .................................................... 48
Chapter 10 Troubleshooting ...................................................................... 49
English - 4
Copyright Information
Copyrights © Lumens Digital Optics Inc. All rights reserved.
Lumens is a trademark that is currently being registered by Lumens Digital Optics
Inc.
Copying, reproducing or transmitting this file is not allowed if a license is not
provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of
backup after purchasing this product.
In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves
the right to make changes to product specifications without prior notice. The
information in this file is subject to change without prior notice.
To fully explain or describe how this product should be used, this manual may
refer to names of other products or companies, nevertheless without any intention
of infringement.
Disclaimer of warranties: Lumens Digital Optics Inc. is neither responsible for any
possible technological, editorial errors or omissions, nor responsible for any
incidental or related damages arising from providing this file, using, or operating
this product.
English - 5
Chapter 1 Safety Instructions
Always follow these safety instructions when setting up and using the Document Camera:
1. Do not place Document Camera in tilted position.
2. Do not place the Document Camera on an unstable trolley, stand or table.
3. Do not use the Document Camera near water or source of heat.
4. Use attachments only as recommended.
5. Use the type of power source indicated on the Document Camera. If you are not sure
of the type of power available, consult your dealer or local electricity company for
advice.
6. Place the Document Camera on a place that it can be unplugged easily.
7. Always take the following precautions when handling the plug. Failure to do so may
result in sparks or fire.
Ensure the plug is free of dust before inserting it into a socket.
Ensure that the plug is inserted into the socket securely.
8. Do not overload wall sockets, extensions leads or multi-way plug boards as this may
cause fire or electric shock.
9. Do not place the Document Camera where the cord can be stepped on as this may
result in fraying or damage to the lead or the plug.
10. Unplug the projector from the wall socket before cleaning. Use a damp cloth for
cleaning. Do not use liquid or aerosol cleaners.
11. Do not block the slots and openings in the projector case. They provide ventilation and
prevent the Document Camera from overheating. Do not place the Document Camera
on a sofa, rug or other soft surface or in a built-in installation unless proper ventilation
is provided.
12. Never push objects of any kind through cabinet slots. Never allow liquid of any kind to
spill into the Document Camera.
13. Except as specifically instructed in this User Manual, do not attempt to operate this
product by yourself. Opening or removing covers may expose you to dangerous
voltages and other hazards. Refer all servicing to licensed service personnel.
14. Unplug the Document Camera during thunderstorms or if it is not going to be used for
an extended period, do not place the Document Camera or remote control on top of
heat-emitting equipment or heated objects such as a car and etc.
15. Unplug the Document Camera from the wall outlet and refer serving to licensed
service personnel when the following situations happen:
If the power cable or plug becomes damaged or frayed.
If liquid is spilled into it or the Document Camera has been exposed to rain or
water.
English - 6
Safety Precautions
Warning: To reduce the risk of fire or electric shock, do not expose this appliance to
rain or moisture.
Note: To reduce the risk of electric shock. Do not remove cover (or back). No
user-serviceable parts inside. Refer servicing to licensed service Personnel.
This symbol indicates that this
equipment may contain
dangerous voltage which
could cause electric shock.
This symbol indicates that there
are important operating and
maintenance instructions in this
User Manual with this unit.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A or B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
EN55022 (CE Radiation) Warning
This product is intended for use in a commercial, industrial, or educational environment. It is
not intended for residential use.
This is a Class A product. In a domestic environment it may cause radio interference, in
which case the user may be required to take adequate measures. The typical use is in a
conference room, meeting room or auditorium.
Note
Risk of Electric Shock
English - 7
Revisions
English - 8
Chapter 2 Package Contents
PC120
Quick Start Guide
4-Step Card
(For download of other
language versions, please
visit Lumens web site)
Download and Safety
Instruction
USB Cable
Carry Bag (Optional)
Extension USB Cable
(Optional)
Microscope Adapter
(Optional)
English - 9
Chapter 3 Product Overview
2. Lens
4. Gooseneck
3. AF button
1. LED indicator
5. Microphone
6. Lamp
English - 10
3.1 Relative Operation Position
3.2 Recommend distance
English - 11
3.3 Incorrect Use
English - 12
USB Cable
COMPUTER
Chapter 4 Installation and Connections
4.1 System Diagram
4.2 Connecting to a computer
Shown as the above figure.
4.3 Connecting to an Interactive Whiteboard (IWB)
USB Cable
PROJECTOR
COMPUTER
VGA Cable
USB Cable
English - 13
4.4 Mounting the PC120
1. Please purchase the standard VESA installation base.
2. Please use appropriate screws: Screw length = 5 mm + base thickness (H1);
M4 screw (P = 0.7)
VESA bolt pitch 75*75mm
VESA base thickness (H1)
Screw length = 5 mm + base
thickness (H1)
M4 screw (P = 0.7)
4.5 Installing application software
After installing LumensTM image software, you can use the following functions:
Control the PC120.
Capture and record images.
Annotate the image, highlight important details and save it.
Support the full screen function.
4.5.1 System requirements
Windows XP
Windows Vista / Windows 7
MAC OS X 10.4 / 10.5 / 10.6
(32-bits Kernel) /
10.7 (64-bits Kernel)
- CPU: P4 2.8 GHz and
above
- Memory: 512MB
- Support Direct x9
- Resolution: 1024x768
- 100MB Min Disc Space
- Windows XP SP2 and
above
- Min CPU: P4 2.8 GHz
- Min Memory: 1GB
(32-bits)/2GB(64-bits)
- Direct X 9 Compatible
- Min Resolution: 1024x768
- 100MB Min Disc Space
- Min CPU: PowerPC G4
866MHz or Intel Pentium®
1.83GHz Intel Core 2 Duo
- Min Memory: 512MB
- Min resolution 1024x768
- 24-bit color display monitor
- 1GB Min Disc Space
- Min QuickTime 7.4.5
English - 14
4.5.2 Install with Windows XP/Vista
1. Please download the Podium View™ software after connected to the
Lumens™ web site.
2. Click the EXE file after decompressing the downloaded file.
3. Select Language.
4. The installation wizard will guide you through the process. Please follow the
on-screen instructions and click [Next] for the next step.
English - 15
4. Click [Yes] to create Podium View™ shortcut on your desktop.
5. Please click the [Finish] button then reboot the system.
4.5.3 Install with MAC
1. Please download the Podium View™ software after connected to the
Lumens™ web site.
2. Click the [Podium View] file after decompressing the downloaded file.
3. Run the installation process by following the onscreen instructions.
Yes
No
English - 16
4. Click [Continue] to continue.
English - 17
5. Click [Install] to continue.
6. Enter your username and password, then click [OK].
7. Click [Continue Installation] to continue.
English - 18
8. Click [Restart] to finish installing the software.
English - 19
Chapter 5 Start Using
<Note>: Ensure that the USB cable is connected and Podium View™
software is installed at first. Refer to Chapter 4 Installation and Connections
in this user manual.
1. Double click on icon to begin Podium View™ Software.
2. Move the mouse to icon, and the main function menu will be displayed.
3. Place an object to be displayed under the camera.
4. Press [PREVIEW] to display the POWER Frequency setting page, and
then follow the on-screen instructions for setting. The live video will be
available after the setting is completed. (*This setting is required only when
you are using for the first time.)
Note: You are advised to confirm the local voltage/frequency before setting
the POWER Frequency. For example, 60Hz is applicable for America, Taiwan,
Japan, etc; 50Hz is applicable for Europe or other regions.
5. Click button to optimize the image. You are ready to teach/present.
6. Adjust the gooseneck as needed and click [FOCUS] button.
* Each time the camera head is moved, click the [FOCUS] button to refocus the
lens.
USB Cable
FOCUS
English - 20
Chapter 6 Function Menu
6.1 IN WINDOWS
6.1.1 Main Function Menu
Power On / Off
Lamp On/Off
Image Optimization
Live Image Preview
Set up the recording format
BRIGHTNESS
Begin the main function
menu, and click the right
button to display the
information about the
software.
To adjust the size of image
Adjust the live image focus,
Photo/Text mode, etc.
Advanced Function Menu
Freeze the current image
Annotation Tools
Close the software
Timer
Record the current image
Image Capture
English - 21
6.1.2 Annotation Tools
Icon
Function Descriptions
Pointer tool
Laser tool
Insert text
Draw a line
Draw an ellipse
Draw a rectangle
Free-hand drawing tool
Eraser
Clear all
Select the color
Select the line width
English - 22
6.1.3 Camera Settings
Control the live image via the Camera Settings interface.
Click to open Camera Settings interface.
1. Auto Focus Automatically adjust focal length on an object.
2. Focus Manually adjust focal length on an object.
3. Auto Exposure Set on/off.
4. Auto White Balance Set on/off.
5. Rotate Rotate the image by 0/180 degree.
6. output resolution Set output resolution.
7. Power frequency The power frequency may vary with
countries. Please check it before using.
<Note> In most parts of the world this is 50 Hz, although in the
Americas it is typically 60 Hz.
English - 23
6.1.4 Options
Click to open Options Menu.
1. Language: Set the language.
2. Factory Reset Activate the factory reset.
3. Video Compress Codec Format Set the video format.
<Note> You need to enable the [Enable Video Compress] before
setting.
4. Enable Audio Recorder Enable the audio record device and set the
audio source.
5. Software mode: Select the Interactive whiteboard mode/ Live mode.
English - 24
6.1.5 Time Lapse
Click to open Time Lapse Menu.
1. Select file directory to change the default.
2. Specify a file name.
3. Set the start time.
4. Capture images at a pre-set intervals.
English - 25
6.2 IN MAC
6.2.1 Software Screen Introduction
1. Live image
2. Main Menu
3. Thumbnail Window
4. File Management Function Menu
English - 26
6.2.2 Thumbnail
1. Close/Open Thumbnail
2. Thumbnail image of saved video or
captured image (It will be displayed
as if it’s a video)
3. Save the video which has been
edited
4. Save as a new file
5. Change the storage folder
6. Delete file
7. Send captured image via e-mail
English - 27
6.2.3 Main Function Menu
POWER:
Turn the Document Camera
on/off.
LAMP:
Turn the lamp on/off.
AUTO TUNE:
Automatically adjust the image
to have the best brightness and
focusing performance.
DISPLAY LIVE IMAGES:
Display live images.
OPTIONS:
Select video compression
method and the audio source.
6.2.6 Options is the reference
of the selecting screen.
BRIGHTNESS:
Manually adjust the brightness
of the image.
PODIUM VIEW:
Launch the main functions
menu. Right click on this icon to
show information about the
Podium View™.
ZOOM:
Increase or decrease the
image size.
MASK:
Open the mask mode. Please
refet to 8.8 I would like to use
the mask mode.
CAMERA SETTING:
Launch the Camera Setting
window to adjust live images.
6.2.5 CAMERA Settings is the
reference of the selecting
screen.
FREEZE:
Freeze the live image.
ANNOTATION:
Open the annotation tools.
Please refet to 6.2.4
Annotation.
SPOTLIGHT:
Open the emphasizing mode.
Please refet to 8.9 I would like
to us the spotlight mode.
TIME LAPSE CAPTURE:
Use the burst mode and adjust
the interval of automatical
image capturing. Please refet
to 8.3 I would like to capture
images continuously.
RECORD VIDEO :
Record the current image.
CAPTURE STILL IMAGES:
Image Capture.
English - 28
6.2.4 Annotation
Click to
open annotation
tools
Icon
Description
Pointer tool
Laser tool
Insert text
Eraser (Clear marks of
free-hand drawing tool)
Draw a line
Draw an ellipse
Draw a rectangle
Delete
Free-hand drawing tool
Back
Next
Clear all
Select pen color
Select line thickness
Select transparency
Select Font
Select Font Size
English - 29
6.2.5 Camera Settings
Control the live image via the Camera Settings interface.
Click to open Camera Settings interface.
1. Auto Focus: Automatically adjust the best focal length.
2. Focus: Manually adjust focal length on an object.
3. Auto Exposure: Set on/off.
4. Auto White Balance: Set on/off.
5. Rotate: Rotate the image by 0/180 degree.
6. Output resolution: Set output resolution.
7. Power frequency: The power frequency may vary with countries.
Please check it before using.
<Remark> In most parts of the world this is 50 Hz, although in
the Americas it is typically 60 Hz.
English - 30
6.2.6 Options
Click to open Options Menu.
1. Factory Reset: Activate the factory reset.
2. Video Compression Type: Set up the recording format.
3. Enable Audio Recorder: Enable the audio record device and set the
audio source.
English - 31
6.2.7 Time Lapse
Click to open Time Lapse Menu
1. Specify a file name.
2. Set the start time.
3. Set the interval and the length of time of image capturing.
English - 32
Chapter 7 Descriptions of Major
Functions
– IN Windows
7.1 I would like to display a live image
1. Click to display a live image.
7.2 I would like to optimize the image
1. Click .
7.3 I would like to use the auto focus
1. Click the AF button on the camera head of main unit.
7.4 I would like to adjust the brightness
1. Click to show the brightness scroll.
2. Move upward to increase brightness, or downward to decrease
brightness.
7.5 I would like to turn on/off the lamp
1. Click to turn on/off the lamp.
7.6 I would like to zoom in/zoom out
1. Click to display the image scrollbar.
2. Scroll up/down to enlarge/reduce the image.
7.7 I would like to capture images
1. Click to show the advanced menu.
2. Click to capture and save images.
English - 33
7.8 I would like to record videos
1. Click to show the advanced menu.
2. Click to begin the recording tool.
<Remark>: Click to change settings including recording format
and audio.
3. Click [Record] to show the “Save AS” window.
4. After entering the file name, click [Save] to begin recording.
5. Click [Stop] to stop recording.
6. Click to close the recording tool.
English - 34
7.9 I would like to set up the timer.
1. Click to show the advanced menu.
2. Click to show the “Time Lapse” window.
A. Set up the file directory.
B. Set up the file name
C. Set up the start time.
D. Set up the time lapse.
3. Click [OK] to exit and the timer takes effect.
7.10 I would like to freeze images
1. Click to freeze the current image on the screen.
A
B
C
D
English - 35
7.11 I would like to annotate the live image
1. Click to show annotation tools
2. The default is the arrow tool [Pointer]. You can select the other
annotation tool.
3. Select the color of the annotation tool, .
4. Set up the line width, .
5. Select transparency.
6. Mark or annotate the live image.
<Remark>: Click to capture the annotated image.
English - 36
7.12 I would like to add text to the live image
1. Click to show annotation tools
2. Select the text tool to show [Text Tool] window.
3. Click to set up font, size, and color.
4. After entering text, click .
<Remark>: Click to capture the text image.
English - 37
7.13 Working with Other Applications
7.13.1. I would like to insert a photo in MS-Paint
<Remark>: Support Windows XP Operation System only.
1. Click [File/From Scanner or Camera] in MS-Paint as shown in the bottom
left figure.
2. Click [Get Picture] will capture the photos of live images and insert the
files in use shown as top right figure.
7.13.2. I would like to insert a photo in MS-Word
<Remark>: For Windows Office 2003 or later versions, please use the
function with OneNote.
1. Click [Insert/Image/From Scanner or Camera] in MS-Word.
English - 38
2. Select [USB Video Device #5] and click [Custom Insert].
3. Click [Get Picture]. It will capture the photo of live image.
7.13.3. I would like to change the setting of the PC120 and then
capture a photo in MS-Word
<Remark>: For Windows Office 2003 or later versions, please use the
function with OneNote.
1. Click [Insert/Image/From Scanner or Camera] in MS-Word.
English - 39
2. Select [Lumens Document Camera TWAIN] and click [Custom Insert].
3. A window showing a live image (see below) will be displayed.
4. Click [Setting].
When the Camera Settings window pops up, the live image can be
adjusted.
5. Click [Capture] to capture images in MS-Word.
6. Click [Cancel] to exit.
English - 40
7.13.4. I would like to set the PC120 as a webcam for Skype
The PC120 can be used as a webcam for instant message software such as
Skype and MSN. With Skype as an example, operating instructions are
provided below:
1. Begin Skype and enter [Tools] > [Options].
2. Select [Video Settings], check [Start my video automatically when I am in
a call] and select [USB Video Device] (XP) or [Lumens PC120]
(Vista/Windows 7) as a webcam.
3. Start calling your contact. When both parties are connected, Skype will
display the video screen.
English - 41
Chapter 8 Descriptions of Major
Functions – IN MAC
8.1 I would like to display a live image
Click to display the live image.
8.2 I would like to optimize the image
Click
8.3 I would like to use the auto focus
Click the [FOCUS] button on the camera head of main unit.
8.4 I would like to adjust the brightness
Click to show the brightness scroll.
Move upward to increase brightness, or downward to decrease
brightness.
8.5 I would like to turn on/off the lamp
Click to turn on/off the lamp.
8.6 I would like to zoom in/zoom out
1. Click to display the image scrollbar.
2. Scroll up/down to enlarge/reduce the image.
English - 42
8.7 I would like to capture images
Click to capture images.
[Note] The captured images will be displayed in the Thumbnail
area.
8.8 I would like to capture images continuously
Click to open burst mode setting. Click [OK] after setting.
<Note> Please refer to 6.2.7 Time Lapse for more Time Lapse
settings.
<Note> The captured images will be displayed in the Thumbnail
window.
8.9 I would like to freeze the live image
Click to freeze the live image of Podium View™.
Click once again to lift the freeze.
8.10 I would like to annotate the displayed image
<Note> To annotate the saved image, please open the pictures of
the Thumbnail area.
Click to open the annotation tools.
Select a annotation tool.
English - 43
Select pen color.
Select line thickness.
Select transparency.
Mark or annotate the displayed
image.
<Remark> You can Click to capture images if they are live images.
You can click [SAVE] or [SAVE AS] to save the files if they
are image files opened from the Thumbnail.
<Remark> You can add annotation when recording, but you can’t save it
8.11 I would like to add textual annotation to images
Click to open the annotation tools.
English - 44
Select
Select pen color.
Select transparency.
Select font and font size.
Drag a block on the picture then start to enter text.
<Remark> You can Click to capture images if they are live
images. You can click [SAVE] or [SAVE AS] to save files if
they are image files.
8.12 I would like to record videos
Click to open the recording tool.
<Note> Click to open the interface of video format and
audio source setting, please refer to 6.2.6 Options for more
details
English - 45
Click to start recording.
Press to stop recording.
Click to close the recording tool.
<Remark> You can use annotation tools when recording, but you
can’t save it.
8.13 I would like to use the mask mode
Click to open the mask mode.
You can directly modify the length and the
width of the block with mouse.
Click to modify the transparency of
the block.
Click to close the mask mode.
8.14 I would like to use the spotlight mode
Click to open Spotlight mode.
Modify the length and the width with
mouse.
Click to modify the shape and
transparency of the block.
Click to close the Spotlight mode.
English - 46
8.15 I would like to manage saved image files.
8.15.1 Save as a new file
First, double-click the picture or image file in the “Thumbnail”
window on the left side of the screen.
Click [Save as] , then “Save As” window will pop up.
After inputting “file name”, click [SAVE] to finish saving.
8.15.2 Change the location of file access
Click [Directory] , then “OPEN” window will pop up.
English - 47
After selecting the location of the folder, click [Choose] to change
the folder for saving pictures next time.
8.15.3 Delete File
First, double-click the picture in the “Thumbnail” window on the left
side of the screen.
Click [Delete] , then “Delete File” window will pop up. Click
[Yes] to delete files.
8.15.4 Send files by E-mail function.
First, double-click the picture in the “Thumbnail” window on the left
side of the screen.
Click [E-mail] , then “Email File” window will pop up. Click
[Yes] to open e-mail.
English - 48
Chapter 9 Connecting to a Microscope
1. Mount the microscope adapter onto the microscope.
<Note>: Please choose an appropriate microscope adapter. Microscope
adapter accessories are applicable to eyepieces of Ø 28 mm.
2. The lens of PC120 connects with the microscope adapter.
3. If the image is not clear
3.1 Click the [FOCUS] button on the PC120 camera head of main unit to
activate the auto focus.
English - 49
Chapter 10 Troubleshooting
This chapter describes problems you may encounter while using PC120. If you
have questions, please refer to related chapters and follow all the suggested
solutions. If the problem still occurred, please contact our distributors or service
center.
No.
Problems
Solutions
1
Boot without power
signal
Ensure that the USB cable is connected.
2
Unable to focus
Probably the document is too close. Pull away the
distance between document and lens, then click
[FOCUS].
3
PC120 cannot
operate normally
Probably the machine cannot operate normally due to
that the power supply of the USB port at the front end of
the computer is insufficient. Try to connect to a USB port
at the rear end or a USB hub with a power adapter.
4
Cannot identify
PC120
Outdated or incomplete OS versions might not be able to
identify USB devices like PC120. Please use Windows
XP SP2 or newer versions that are compatible.
5
Output screen is
flickering
By default, the voltage/frequency value of Podium ViewTM
is 60Hz. If voltage/frequency of 50Hz is required in your
country, flickering of screen may occur when the Podium
ViewTM is used. Please refer to 6.1.3 and 6.2.5 Camera
Settings of Chap 6 Function Menu to change the
POWER frequency setting to 50Hz.
6
Digital Zoom is
disabled
Please click Options to make sure whether
Software Mode is on Annotation Mode. For details,
please refer to 6.1.4 Options of Chap 6 Function
Menu.
