MAGIT TECHNOLOGY BS-26L Bluetooth Speaker User Manual Manual
MAGIT TECHNOLOGY LIMITED Bluetooth Speaker Manual
Manual
Bluetooth Speaker
Model:BS-26L
User’s manual
Thanks for your purchase of our Bluetooth Speaker!
Like all our products, great care has been taken in its design. A combination of advanced engineering
and state-of- the-art materials will provide you with years of listening pleasure.
Charging The Battery
z Before using, fully charge the battery using the supplied USB cable. Plug in to any USB port supplying
power (Laptop, Computer, AC Charger, Car Charger, etc.).
z A solid red LED indicates that the speaker is charging, when fully charged it will turn off.
Power on/off
Move the power switch to the “on” or “off” side to power on /off the device.
Bluetooth® Pairing
With the Speaker turned on, it comes to pairing mode with flashing light. Open the Bluetooth® settings
of your phone, tablet or other Bluetooth® enabled audio device and select K5.When prompted for the
pairing code, enter 0000.
Once paired, an audible voice will be heard.
Playing Music
z Select a song, artist, genre, or playlist on your phone, tablet or other Bluetooth enabled audio
device.
z Press the play/pause button to start or pause the music.
z Press the next/V+ or the last/V- button to choose songs.
z Long pressing the next/V+ or the last/V- button to adjust the volume.
Hands-free for calling
z Answer or Drop a call by pressing the play/pause button once quickly.
z Reject a call by pressing the Play Button for about 3 seconds.
TF playing
z Play music of TF directly when insert in TF card.
Turn to FM mode when press Mode button at TF mode.
Note
z After making or dropping a call the speaker will re-start your music.
z Press the light button to choose the LED mode： flashing with music – flashing – off
LED Indicator Status of the speaker
Red LED light on Battery is charging
Red LED light off while charging Battery is full
Specifications
Bluetooth Version V2.1+EDR
Bluetooth profiles HSP, HFP, A2DP,
Range Up to 10 meters
Music playing time Up to 6 hours
Charging time About 3 hours
Dimensions D70 * H125 mm
Weight 190g
Package Contents:
z USB-mini USB cable
z 3.5mm Audio cable
z This Owners’ manual
FCC Statement
z Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
z This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation
