MC Devices 1927007R True Sounds Digital Audio Monitor User Manual TRUE AUDIO INSTRUCTS R2

MC Devices Co., Ltd. True Sounds Digital Audio Monitor TRUE AUDIO INSTRUCTS R2

Users Manual

FEATURES & COMPONENTSQUICK START GUIDE USING YOUR MONITOR (CONTINUED)USE AND CAREHELPFUL HINTSUSING YOUR MONITORTROUBLESHOOTINGIF YOU ARE STILL HAVING PROBLEMS, PLEASE CALL TOLL FREE FOR HELP! (800) 544-1108.IMPORTANT:SAFETY INSTRUCTIONSBATTERY INSTALLATION & USEPlease read the following instructions and warnings carefully.Keep these instructions for future reference.Thank you for purchasing this product by Safety1st. We are not only about safety,we're also about your satisfaction. If you have any questions or comments,please call our Consumer Relations department at 1-800-544-1108 ore-mail us at consumer@safety1st.comBATTERY INSTALLATION:1. Remove the battery compartment cover from the parent unit. 2. Insert 2 AAA rechargeable batteries (included). Make sure batteries align properly to the correct positive “+” and negative “-” polarity marked in the battery compartment.3. Replace the battery compartment cover.• Check the reception regularly. • Certain electronic devices are sensitive to magnetic fields and may be damaged permanently or temporarily disabled if exposed to a magnetic field that is too strong.• To remove AC adapter from the outlet, firmly grasp the adapter "brick." DO NOT pull on the cord, as this could damage it. • The LEDs emit IR (infra red) light that is not harmful.This monitor is not intended to be used as a medical monitor and its use should not replace proper adult supervision. You should check your child’s activity at regular intervals as this monitor will not alert parents to the silent activities of a child.CAUTION!For indoor use only. To reduce the risk of fire or electrical shock, do not expose this product to water or moisture. NEVER attempt to disassemble the product. This is dangerous and will void the warranty.WARNING!DO NOT PLACE UNITS IN CRIB OR MOUNT ON CRIB. KEEP OUT OF REACH OF CHILDREN.AC ADAPTERThe Parent Unit operates on household electricity with the AC Adapter or with 2 AAA rechargeable batteries (included). The Baby Unit operates on household electricity with the AC Adapter only. The Parent Unit will automatically convert to AC operation when used with the AC Adapter. It is not necessary to remove the battery during AC operation. The Parent Unit will automatically switch back to battery power when plug is disconnected from the AC Adapter. The AC Adapter should be used whenever possible on the Parent Unit to save battery life. This is done by inserting the AC Adapter into the AC Adapter jack. Then simply plug the AC Adapter into a nearby standard household outlet (120V AC outlet). The AC Adapters may become slightly warm to the touch during operation. This is normal.This AC Adapter is a low voltage power source which allows you to use your household electricity to run the Baby and Parent Units when it connects to the AC Adapter jack in the Parent Unit and in the Baby Unit, and plugs into any standard electrical outlet in your home.To remove AC adapter from the outlet, firmly grasp the adapter "brick." DO NOT pull on the cord, as this could damage it. CAUTION: This AC Adapter was made with a specific design for this Monitor by Safety 1st. It cannot be used with any other appliance, and never use a different type of adapter with this Monitor.Baby Unit (Transmitter):PROPER POSITIONINGIMPORTANT: When choosing locations to set up the Baby Unit and Parent Unit, follow these guidelines:• For best sound quality, place Baby Unit 3 feet (0.9 meters) away from the baby.• Adjust volume (+/-) buttons on Parent Unit to appropriate level to minimize feedback.• During use of the monitor, sound quality deteriorates as you reach the limits of the monitor's range. If this happens, you will need to move the Parent Unit in closer proximity to the Baby Unit.• Adjust the volume to a comfortable level for your environment.The first time you use your monitoring system, two adults should test it in the following way:• Place Parent Unit at least 20 ft. (6m) away from Baby Unit. • Have an adult speak into Baby Unit at various levels (soft to loud) while another adult checks Parent Unit for the proper sound reception. Try Parent Unit in every location that it will be used.Care and Cleaning:Use a soft, dry cloth to keep your monitor free from dust. DO NOT immerse product in water.IMPORTANT – CHECK RECEPTION:Use household electricity whenever possible. When the AC Adapter is used with your household electricity, you will find that the power is stronger and more consistent than when you rely solely on the battery. Range and sound quality also depends on the construction of your house. Steel reinforced wall, for example, reduces the effective range of the monitor. Conserve the battery so you will have power when you don’t have easy access to AC outlets.When not using the Unit, remove AC Adapter and be sure the power button is “OFF”. When you are not using the AC Adapter, remove it from the Unit and store it in a safe, dry place until you need it again. If the AC Adapter is plugged into the Parent Unit but not being used in an electrical outlet, the AC Adapter will prevent battery operation of the Unit.When using the AC Adapter with household electricity, make sure the outlet is “ON”. Some electrical outlets are powered through a switch in the room. If the Baby Unit is plugged in and turned “ON”, the power indicator light should be lit. If it is not, try turning the light switch in the room “ON”.Parent Unit (Receiver):POWER INDICATORThe power indicator is a green LED that indicates that the unit is on and functioning.LOW BATTERY INDICATORLow battery power is indicated by the blinking red LED, which signals when the batteries needs to be replaced. When batteries are charging, LED is blinking red.LINK INDICATOR - OUT OF RANGEWhen unit is operating on battery power, the link/out of range indicator is a blinking and beeping green LED, which means contact is lost between the Baby and Parent Units. When unit is plugged in, the link/out of range indicator is a blinking and beeping red LED, which means contact is lost between the Baby and Parent Units.SOUND LIGHTSAs baby’s voice gets louder, the sound light red LEDs will illuminate. Low sound is one LED illuminated and rises incrementally as baby’s noise level increases until all 3 LEDs are illuminated.SPEAKERThe speaker picks up sounds from the Baby Unit’s microphone. The speaker will continuously beep as a warning signal when contact is lost between the Baby and Parent Units. The speaker will emit short beeps as a warning signal when rechargeable batteries are low. The short beeps will stop when batteries are recharging.POWER ON/OFF BUTTONPress and hold down the Power On/Off Button to turn Parent Unit on.To turn off Parent Unit, hold down Power On/Off Button again.VOLUME (+/-) BUTTONSVolume can be easily adjusted to any desired listening level by pressing the + and - Volume Buttons, so you can be sure to hear your baby at all times. The sounds are transmitted through the wide range speaker. It is essential to check reception regularly. Refer to Use and Care section.POWER INDICATORThe power indicator is a green LED that indicates that the unit is on and functioning.LINK INDICATOR - OUT OF RANGEThe link/out of range indicator is a blinking green LED, which means contact is lost between the Baby and Parent Units.POWER ON/OFF BUTTONPress and hold down the Power On/Off Button to turn Baby Unit on. To turn off Baby Unit, hold down Power On/Off Button again.MICROPHONEThe microphone transmits sounds to the speaker on the Parent Unit.NIGHT LIGHT BUTTONPress the Night Light Button on the top of the Baby Unit, which will activate the night light feature. Night light will remain on until you press the Night Light Button again.PAGER BUTTONThe Pager Button is helpful to locate a misplaced Parent Unit. With the Baby Unit on, press the pager button on the Baby Unit. Any button press on the parent unit will turn off pager beeper. NOTE: The Parent Unit will only beep if it is powered on.1 Connect AC adapter to the back of Parent Unit.4 Hold down Power On/Off Button to turn Parent Unit on. To turn off Parent Unit, hold down Power On/Off Button again.5 Hold down Power On/Off Button to turn Baby Unit on. To turn off Baby Unit, hold down Power On/Off Button again.ABCDEFGHJKILMNOPQUTRSVParent Unit (Receiver)Sound LightsMicrophonePower On/Link/Low Battery IndicatorVolume - ButtonPower On/Off ButtonTalk ButtonVolume + ButtonVOX Switch (background noise elimination)Belt ClipBattery Compartment (2 AAA rechargeable batteries, included)AC Adapter JackBaby Unit (Transmitter)Night LightPower On/Link IndicatorMicrophoneSpeaker AC Adapter JackPager ButtonNight Light Activation ButtonPower On/Off ButtonVolume +/- ButtonsRechargeable BatteriesAAA Rechargeable Batteries (2)AC AdaptersAC Adapters (2)AMLBCParent Unit/ReceiverBaby Unit/TransmitterDEFGHIJKPOUVAC Adapters (2)“AAA” RechargeableBatteries (2)Plug in here2 Connect AC adapter to the back of Baby Unit. Baby UnitPower On/Off ButtonTALK BUTTONPress and hold down the Talk Button to turn on the talk back feature.Talk Back will turn off after button is released.VOX SWITCH (Background Noise Elimination)Slide VOX switch to the On position. The Baby Unit will operate in voice activated mode (also known as background noise elimination), which means the speaker will only turn on when it picks up higher level sounds from the Baby Unit’s microphone. Slide VOX switch to the Off position to turn off background noise elimination mode.CAUTION!• DO NOT mix old and new batteries.• DO NOT mix alkaline, standard (carbon zinc), or rechargeable (nickel-cadmium) batteries.• Non rechargeable batteries are not to be recharged.• Rechargeable batteries are only to be charged under adult supervision.• Only batteries of the same or equivalent type as recommended are to be used.• Batteries are to be inserted with the correct polarity.• Exhausted batteries are to be removed from the unit.• The supply terminals are not to be short-circuited.• Check that all contact surfaces are clean and bright before installing batteries.• Keep batteries out of child’s reach. Swallowing a battery could be fatal.• Used batteries should be disposed of properly. Do not dispose of batteries in fire - they may explode or leak and cause injury.• Remove batteries when stored for long periods of non-use.• DO NOT use audio monitor system in portable mode when batteries are low.• Ensure that the battery compartment is completely secure after replacing batteries.3 Plug Parent Unit and plug Baby Unit into wall to operate AC power.Strangulation Hazard - Children have STRANGLED in cords. Keep cords out of reach of children more than 3 feet (0.9 m) away.WARNING!THE USER SHOULD NOT ATTEMPT TO SERVICE OR REPAIR THE MONITOR. ALL SERVICING SHOULD BE REFERRED TO SAFETY 1ST CUSTOMER SERVICE DEPARTMENT: (800) 544-1108.To protect your privacy, always turn the monitor off when not in use. Always remember that you are using public airwaves. Sound may be broadcast to other receiving devices outside your home. Conversations, even from rooms nearby, may be broadcast.CAUTION!It is essential to check reception regularly. Please see Use and Care section.VENTILATION: The Monitor should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings, or placed in an enclosed installation, such as a book case or cabinet that may impede the flow of air through the ventilation openings.• Position the Transmitter, Receiver and AC adapters to allow adequate ventilation and prevent these components from overheating. HEAT: The Monitor should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances that produce heat. Also keep these components out of direct sunlight.POWER SOURCE: The Monitor should be connected to a power supply only of the type described in these operating instructions.POWER CORD PROTECTION: The power supply cord should be routed so that it is not likely to be walked on or pinched by items placed upon or against it. Pay particular attention to the cord at the plug, convenience receptacle, and at the point it exits from the Monitor. NOTE: Do not place adapter under a window where a child might use it to step on and reach something that might be dangerous.• Check to make sure outlet plates are not unusually hot to the touch. If they are, immediately unplug cords from these outlets. Check that all outlet connections are in good condition so that adapter is not loose or that no wiring is exposed. Have a qualified, licensed electrician check the wiring as soon as possible.OBJECT AND LIQUID ENTRY: Care should be taken so that objects do not fall onto, and liquids are not spilled into the enclosure through the openings.DAMAGE REQUIRING SERVICE: The Monitor should be serviced by qualified service personnel when: A. The power supply cord has been damaged; or B. Objects have fallen or liquid has been spilled into the product; or C. The Monitor has been exposed to rain; or D. The Monitor does not appear to operate normally or exhibits a marked change in its performance; or E. The Monitor has been dropped or the enclosure damaged.WARNING!Strangulation Hazard - Children have STRANGLED in cords. Keep cords out of reach of children more than 3 feet (0.9 m) away.PROBLEMPower indicator light not workingStatic or interference in the signal transmissionParent Unit is making loud noisesWeak sound coming from Parent UnitCan’t hear baby’s sounds I'm talking to babybut can't hear babyPOSSIBLE CAUSEPower is not getting to the UnitAppliances with loud fans near Units may be blocking transmissionUnit may be under fluorescent lightsLocal interference from electrical or radio frequency appliance near your locationUnits are too close togetherVolume on Parent Unit may be too highBattery may be weakUnits may be too far away from each otherVolume may be too lowSOLUTIONMake sure wall outlet is working; may possibly need to be turned on by a switchParent’s Unit has no sound Volume is too low Out of rangeAdjust the volume Bring Parent’s Unit closer to Baby’s UnitMake sure AC adapter is plugged into wall and the UnitLook for any noise source in baby’s room.Remove noise source or move Baby Unit away from the sourceReduce the distance between the two Units or turn off lightsTurn off the appliances that may be causing interferenceParent Unit needs to be at least 3 feet / 0.9 meters away from the Baby UnitTurn down volume on the Parent UnitCheck battery; recharge if necessaryNeed to release Talk Back button to hear baby response Release Talk Back button after speaking to babyBattery life is short Battery life in the parent unit will last approximately 24hrs Use unit cautiously during battery operation to conserve your battery lifeMove the Units closer to each otherPress the Volume + Button to turn up volumeTQ SRNPlug in hereParent UnitPower On/OffButtonTrue Sounds™digitalaudio monitorBABIES “R” US is a mark of (est une marque de/é uma marca de) Geoffrey, LLC and (et/e) Toys “R” Us (Canada) Ltd. (Ltée), © 2013 Geoffrey, LLC, Made in China / Fabriqué en Chine / Fabricado na China, Distributed in the United States by (Distribué aux États-Unis par/Distribuído nos Estados Unidos por) Toys “R” Us, Inc., Wayne, NJ 07470, Imported in Canada by (Importé par/Importado no Canadá por) by Toys “R” Us (Canada) Ltd. (Ltée), 2777 Langstaff Road, Concord ON L4K 4M5, Imported in Australia by (Importé par/Importado na Austrália por) Toys “R” Us (Australia) Pty Ltd., Regents Park NSW 2143.WWW.BABIESRUS.COM# 1927007FCC WarningIC WarningAny Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example-use only shielded interface cables when connecting to computer or peripheral devices).This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.Radiation Exposure Statement: This product is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on the safety standards previously set by both U.S. and international standards bodies. These standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This product has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE 1528-2003".For body worn operation, this handset has also been tested and meets the FCC RF exposure guideline when used with the belt clip supplied with this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body for baby unit.Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
