MC MOBILE E U MINI GSM Mobile Phone User Manual mc
MC MOBILE E.U. GSM Mobile Phone mc
user manual
MC MOBILE E.U.
Product Name: GSM Mobile Phone
Brand Name: MC-MOBILE
Model Name: MINI
FCC ID: 2AACKMINI
Page 2
Thank you for purchasing this mobile. For the best
performance, we recommend that you read the manual carefully.
MENU .................................................................................. 3
PHONEBOOK .......................................................................... 3
MESSAGE .............................................................................. 5
CALL LOGS ............................................................................. 9
SETTINGS ............................................................................ 11
FILE MGR ............................................................................. 17
GAMES ................................................................................ 18
ORGANIZER. ......................................................................... 25
SHORTCUTS ......................................................................... 26
Page 3
MENU
Phonebook
■Phonebook
View: View the information of current record
Send text message: send text messages to the current
record
Call: Make a call of current number.
IP dial: Choose SIM1 or SIM2 to make the IP dial to
current record.
Edit: Edit the items of current number.
Delete: Delete the current record
Copy: Provide two ways of copying: from SIM1/SIM2
card to mobile, and from mobile to SIM1/SIM2.
Page 4
Move: Move the number from phone to SIM1/SIM2, or
from SIM1/SIM2 to the phone.
Send contact:send the current contact by SMS,MMS.
【Copy contacts】： Provide four ways of copying: from
SIM1/SIM2 card to mobile, and from mobile to SIM1/SIM2
card.
【Move contacts】: Provide four ways of moving: from
SIM1/SIM2 card to mobile, and from mobile to SIM1/SIM2
card.
【Delete all contacts 】： Delete all the records in the
SIM1/SIM2 card or the mobile. Note：You need to input the
password ‘0000’ to delete records from the SIM1/SIM2 card or the
mobile.
【Owner number】: edit and sent my number
【Preferred storage】：Choose the storage position for the
Page 5
【Memory status】：Check the storage capacity of the
SIM card and phonebook
Message
【Write message.】: Edited the content
you have options of Sim1 and Sim2 to send.
You have options of Sim1 and Sim2, and also can Finish：
The message have finished and you can send it to your
receiver.
You have options of SIM1 and SIM2， when the message
have finished you can send it to you receiver by SIM1 or
SIM2.
Send To：input the number you will send to or find it
from the phone book.
Send : The message have finished and you can send it
to certain number.
Page 6
Edit recipient: edit the input number
Save :save the SMS to the outbox.
Writing language:Choose the input method.
[Inbox]：
View:View received Text messages of SIM1 or SIM2.
Reply by sms：Reply the message directly.
Call Sender:choser the SIM card one or two to call the
sender.
Forward:Forward the message to others.
Delete:Delete the SMS in current SIM card.
Delete All: Delete the all SMS in current SIM card.
Del sms by num:Delete the SMS send from the same
number.
Page 7
Save to Phonebook：save the number which send
message to you to the phone book.
Mark several
■ Mark:chose the corresponding SMS to
delete ,copy or move,
■ Mark All: chose all the SMS to delete ,copy or
move,
[Outbox]：Read and modify the messages stored in the
Outbox of SIM1 and SIM2。.
[SMS Settings]： Set the relative parameters for messages
Profile settings：Profile 1/2/3/4.
Note：The menu display changes depend on the SIM card.
SC Address.
Valid Period.
Page 8
Message type
Common settings:Turn on or off the Function of
Sending a report,returning path,chose whether to save the
sent messages.
[Memory status]: View the memory status of SIM card or
the phone.
[Voice mail]：Choose SIM1 or SIM2 to receive voice
messages.
[Call voicemail]:quick connect current vioce mail
number.
[Edit]：Add or modify the number of the voice mail.
Note：The voice mail function needs support from network.
【Broadcast message】：
The broadcast is a network service sending information like
weather forecast, traffic status, etc to all the GSM users in
Page 9
the zone by the network vendor. You have options of SIM1 or
SIM2.
[Receive mode] ：Activate or deactivate the broadcast
function.
[Channel settings]：Set the channel of broadcast message.
Note ：The voice mail function needs support from
network
Call logs
You can view your recent call situation.
【Call history】
View the call log of the current SIM card, press the left
softkey, display like follows:
[All calls]: show all missed, received, dialed phone list, can
select a particular view of the phone the last time did not
happen then the date and time, telephone number,
Page 10
frequency.
[Sim1/Sim2 Missed calls] Display the missed calls about the
latest time and date, caller‟s number and calling times.
[Sim1/Sim2 Dialled calls] Display the dialed calls about the
latest time and date, caller‟s number and calling times.
[Sim1/Sim2 Received Calls] Display the answered calls
about the latest time and date, caller‟s number and calling
times.
Press the right softkey to enter the options menu can be
more than the number of call records in the following:
View:see the current record
Call:call the current number.
Send text message: send text messages to the current
record
Save :save to SIM or phone
Edit before call:on the current record for editing
Delete: choose to delete the current record
Page 11
Settings
[ User profiles]
[Tone settings]:
incoming call：Set ring for incoming calls .
message: Set up the alert style of new message of
SIM
Keypad: Set up the keypad tone
[Volume]
Ring tone：Set the ring volume
Key tone: Set the volume for pressing the keys.
[Alert type]：There are ringing, vibration, the vibration and
ringing and ringing after the vibration of the four methods
prompted calls for you to choose from
[Ring type]：Out there, or continuous ringing crescendo of the
Page 12
three types available.
Note: except for a specific function keys (such as on / off button,
etc.).
[ Time and date]:
◆ Set time/date: Set the display date and time
◆ Set format: Choose the time and date format
◆ Update with time zone:you can turn off or turn on it.
【Phone settings】：
[Language]：Display Language for your mobile. The mobile
provides Simple English languages, and so on
[Shortccuts]: Customizable key.
[Auto keypad lock]: choose the keypad lock for 5
sec.,15 sec.,30 sec.,1 min.,5 min.
[Display]
◆ WallPaper：Set the stand-by wallpaper.
◆ LCD backlight：time of LCDbacklingt can be set up
Page 13
【Call settings】
Setup the current SIM card.
[SIM1/SIM2 call settings]：Call transfer and call waiting and
other functions can be set in the menu.
Call waiting：Select the functions of open, close or
inquire call waiting.
Call divert：Choose to open, close or enquire the call
forwarding function.
Call barring：Select to restrict some talking function.
Note: network support is required.
Line switching:select line 1 or line 2.Note:if the line 1
is selected it may lead to failure to dial out and the menu
will decide the display because the different categories of
the SIM card used.
[Common call settings]
Auto redial
Page 14
Choose whether automatic redial will be implemented
when the called party is in the busy or have no response.
IP number：
Select to open or close IP dial and edit IP number
Choose to activate or inactivate the SIM1/SIM2 IP dial, and
edit the IP numbers
Answer mode ：Select whether to answer the
incoming call by pressing any key.
【Network settings】Choose setup SIM1 or SIM2 network
[Network selection]：Select automatic or manual method to
search the network.
[Preferrences]：Set prior network.
【Security settings】
[SIM1 or SIM2 Security settings]
◆ SIM1/2 Lock：Activate or deactivate the SIM or SIM2
lock
Page 15
◆ Fixed Dial：If the function is activated (which needs to
input PIN2 code), you can only call the numbers stored
in the fixed dialing list, while the phonebook will be out of
use.
◆ Barred dial：Set barred outgoing calls. This function
needs the support from network.
◆ Change password： Set new passwords including PIN1,
PIN2 and phone password. Note：Please remember
your password firmly in time after changing.
[Phone Lock]：:Activate or deactivate the keypad lock
and lock duration.
[Change password]: Setup the new password of the
phone. Note: Please remember your new password
after modified it
【Bluetooth】
[Power] Activity the Bluetooth function.
[Inquire audio device] :Choose and the handset auto search
Page 16
the device nearby (within 10 m)
[My device]: Display the bluetoth earphone and other device,
and search the equipment
[Active devices]: Display the connected Bluetooth
[Settings]：
◆Visibility: to choose whether or not may be to search for
other Bluetooth devices.
◆change device name: amend the local Bluetooth device
name
◆Audio path: to "stay in the mobile phone" or "go-free
device." Note: Due to this Bluetooth headset has the voice
channel switching function, so when set to "remain in the
mobile phone", click the multi-function Bluetooth headset
button can also be connected to telephones, voice, but
remain in the mobile phone side. Please refer to the
specific operational guidelines of the Bluetooth headset,
and recommended that users use standard headphones
Page 17
◆Storage : to preserve choice in the mobile phone or
memory card to receive the document
【Music Light】to open Light, calls, play music, Mobile
phone switch machine unit Light
According to "ON" is open
According to "OFF" is closed
【Restore factory settings】：Restore the default setting of
the phone. You need to enter the phone lock password, and
the default password is „1122‟.
File mgr
【Phone】：
Open: Unfold a selected folder.
New folder: Built up a new folder
Sort by: L ine the folders according to you selected
Page 18
Format: Format the file system note: You‟ll lose all
information in the file system.
【Memory card】: Need the T-flash card support.
Games
【games】: Offer interesting little game.
Multimedia
【Image viewer】： View or modify photos saved in the
album.
View: View the selected images:View: View the
selected photos
Send:you can send the phone by Bluetooth.
Use as:use the phone as wallpaper,screen saver,boot
animation,shutdown animation or call picture.
Rename: Rename the current picture. Note: If the
picture has set up to the wall paper\ screen picture and so
Page 19
on, it will back to the default settings
Delete: Delete the picture chosen
Delete all files: Delete the all pictures
[Adio player]
[play]:play the music.
[Refresh list]：Update the items of songs (updating shall be
implemented after the name/names of song(s) are changed
or some of the songs are deleted)
[Settings]：Set up relevant information of music player.
Pre.playlist: Play music from handset or T-Flash card
List auto gen.: Display as “Refresh Play List ” when set
to “ON” ,or “Add” when set to “OFF”
Repeat: Can be set to “OFF”, single song repeat ,or all
songs repeat .
Shuffle: Songs will be played random when this option
set to “ON”,otherwise ,songs will be played by order they
Page 20
displayed in the list.
Background play: As this option set to “ON”,Songs will
be played in background when idle screen is
displayed,otherwise ,the music is stopped when display
idle screen.
【Camera】：
Taking a picture：When you are taking a picture, the screen
acts as a viewfinder, you can tune the focal length by
pressing the up and down navigation keys; tune exposure
compensation by pressing the left and right navigation keys;
You can access the „Option‟ menu to set and save these
settings. Position the scene in the viewfinder and press „„OK
key‟ to take the picture, and you will hear a shutter sound at
the same time. To guarantee the image quality, please hold
the camera steadily. The image will display on the screen
after you shoot (the current status is called still status).
Photos：View the photos that you saved.
Page 21
Camera setting：Set related parameters of the camera.
Image settings：Set the size and quality of the photos
White balance: Choose the mode to keep white
balance.
Scene mode: Choose the Auto or Night mode
Effect settings：Set the special effects of photos.
Storage：Choose the position where the photos will be
saved.
Restore default：Restore the camera settings to default.
【Video Recorder】：
Video settings：Set related parameters for the video clip.
White balance: Choose the mode to keep white
balance.
Effect settings：Set special effects of the video clip.
Page 22
Storage：Select the position where video clips will be
saved.
Restore default：Restore the video camera setting to
defaults.
【Video player】：
Play: Play the current video files.
Send:Send the current video file to bule tooth.
Rename: Rename the current video file.
Delete: delete the current video file
Delete all files: delete all of the video files in the video player.
Storage ：Select to play the video files in the cell phone or
memory card.
【Sound Recorder】
New record：Start recording.
Page 23
Play：Play a selected record.
Append：Make additional recording for the selected
record in .amr format.
Rename：Rename a selected record. Note：Renaming
a record which has been set as incoming ring will make
the settings back to defaults.
Delete：Delete a selected record.
List: View the recording of .amr files.
Settings：Set the position and the file format to save
records.
Use as：Use the record in a situation mode.
Send： or send the record by BT
Note：The recording time depends on the memory capacity
of the mobile.
Page 24
【FM radio】: This phone support the FM radio function,
choose and receive the programs and you also can insert
the earphone. Press the left/ right direction key to search the
channel at the FM interface; and press the side key to adjust
the volume,; press the “*” key to switch on/of the FM radio
player.
Press the left soft key to “options”, display as following:
[Power on]: Click "ok" is on or off
[Channel list]: Set up the channel list and frequency
[Manuel input]: In put the frequency by manual
[Volume]: Used to adjust the volume
[Auto search]: choose the “yes” then auto searching the
channels
[Settings]: Activate or inactivate the background and the
speaker
Page 25
[Append]:On the choice of a particular. Amr format
sound recordings for additional recording.
Organizer.
【Calendar】：
Jump to date: Jump to the appointed date quickly when
you input a date to search.
Go to today: View the same day date
Go to weekly view: View the date according to weeks
【TORCH】：Add records as needed.
According to "ON" is open
According to "OFF" is closed
【Alarm】： You can set5alarm times with this mobile. For
each of them, you can set the alarm status to be open or not,
set the alarm time and alarm frequency ( once, daily or on
several self-defined dates).
Page 26
【Calculator】： The cell phone support continuous four
mixed arithmetic operation and the operation is simple,
practical and convenient.
Shortcuts
You can Enter each menu can quickly enter for you to use
WARNING!! Read this information before using
your phone
In August 1986 the Federal Communications
Commission (FCC) of the United States with its
action in Report and Outer FCC 96-326 adopted an
updated safety standard for human exposure to
radio frequency (RF) electromagnetic energy
emitted by FCC regulated transmitters. Those
guidelines are consistent with the safety standard
previously set by both U.S. and international
standards bodies. The design of this phone
Page 27
complies with the FCC guidelines and these
international standards. Use only the supplied or
an approved antenna. Unauthorized antennas
modifications, or attachments could impair call
quality, damage the phone, or result in violation of
FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement
antenna.
BODY-WORN OPERATION:
This device was tested for typical body-worn
operations with the back of the phone kept 1.5cm
from the body. To comply with FCC RF exposure
requirements, a minimum separation distance of
1.5cm must be maintained between the user's body
and the back of the phone, including the antenna,
whether extended or retracted. Third-party
Page 28
belt-clips, holsters and similar accessories
containing metallic components shall not be used.
Body-worn accessories
that cannot maintain 1.5cm separation distance
between the user’s body and the back of the phone,
and have not been tested for typical body-worn
operations may not comply with FCC RF exposure
limits and should be avoided.
For more information about RF exposure, please
visit the FCC website at www.fcc.gov
Your wireless handheld portable telephone is a low
power radio transmitter and receiver. When it is
ON, it receives and also sends out radio frequency
(RF) signals. In August, 1996, the Federal
Communications Commissions (FCC) adopted RF
exposure guidelines with safety levels for
hand-held wireless phones. Those guidelines are
consistent with the safety standards previously set
Page 29
by both U.S. and international standards bodies:
<ANSIC95.1> (1992) / <NCRP Report 86> (1986) /
<ICIMIRP> (1996)
Those standards were based on comprehensive and
periodic evaluations of the relevant scientific
literature. For example, over 120 scientists,
engineers, and physicians from universities,
government health agencies, and industry
reviewed the available body of research to develop
the ANSI Standard (C95.1). Nevertheless, we
recommend that you use a hands-free kit with your
phone (such as an earpiece or headset) to avoid
potential exposure to RF energy. The design of
your phone complies with the FCC guidelines (and
those standards).
Use only the supplied or an approved replacement
Page 30
antenna. Unauthorized antennas, modifications, or
attachments could damage the phone and may
violate FCC regulations.
NORMAL POSITION:
Hold the phone as you would any other telephone
with the antenna pointed up and over your
shoulder.
TIPS ON EFFICIENT OPERATION:
For your phone to operate most efficiently:
• Extend your antenna fully.
• Do not touch the antenna unnecessarily when the
phone is in use. Contact with the antenna affects call
quality and may cause the phone to operate at a
higher power level than otherwise needed.
Page 31
RF
Exposure Information:
FCC RF Exposure requirements: The highest
SAR value reported under this standard during
product certification for use next to the body
with the minimum separation distance of 1.5cm
is 0.183
W
/
kg
, next to the head is
0.236
W/kg.
This transmitter must not be
collocated or operating in conjunction with any
other antenna or transmitter.
This device complies with part 15 of the FCC
Page 32
rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference,
and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for
any radio or TV interference caused by
unauthorized modifications to this equipment.
Such modifications could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
Page 33
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates
uses and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
Page 34
- Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help
Do not use the device with the environment
which below minimum -10℃ or over maximum
50℃ ，the device may not work.
Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
