QUICK SETUP GUIDE
Bluetooth Speaker
for iPad 2
RF-TRSPIPAD
Thank you for purchasing this high quality
Rocketsh product. Your Bluetooth speaker
represents the state-of-the-art in iPad®
accessories and is designed to integrate
easily into your iPad’s Smart Cover.
Charging your speakers fully for
the rst time
Plug the small end of the included USB cable
into the speakers and the other end into an
available USB port on your computer. It
takes approximately two hours to fully
charge your speakers.
Note: You can charge your speakers and
listen to audio at the same time.
Installing the speaker unit into
the Smart Cover
Place the highlighted areas of the speaker
unit and the Smart Cover together in the
orientation illustrated in Step 1, then
proceed with the rest of the steps.
Turning on and pairing your
devices
Turn on the speakers by pushing in on the
side with the power on icon. This should
turn on the unit and automatically put it in
pairing mode. (Repeat the action on the
opposite side to pop out the other speaker
for better audio quality.)
To pair with your iPad:
From the Home screen, choose Settings >
General > Bluetooth and turn Bluetooth on.
iPad searches for nearby Bluetooth
accessories.
Choose and Accept the Bluetooth accessory.
This device is identied as RF-TRSPIPAD.
If needed, please refer to your iPad manual
for additional pairing information.
LED is Constant Green if connection is
established with iPad 2.
Established
connection
(Green LED)
Charging in
Progress indicator
(Red blinking LED)
Full Charge indicator
(Constant green LED)
Note: Speakers will work with
most Bluetooth audio devices.
Speaker unit
Smart Cover
RF-TRSPIPAD_11-1052_QSG_V2_EN.eps 1 9/19/2011 7:22:16 PMRF-TRSPIPAD_11-1052_QSG_V2_EN.eps 1 9/19/2011 7:22:16 PM
V2
FINAL
FOR PRINT
ENGLISH 11-1052
LED blinks red and green alternately when
no connection is established. Speaker
goes into sleep mode after 3 minutes, and
LED turns o.
Note: Please make sure to disconnect
(unpair) the RF-TRSPIPAD speakers from
your iPad before attempting to pair your
speakers with another Bluetooth device.
Reset
When pairing is not established after 3
minutes repeat the “turning on” sequence,
by rst pushing in the side of the speaker
unit with the power on icon.
Enjoying your speakers
To enjoy your music or videos, place your
iPad 2 with speakers in either orientation
indicated.
LED indicators
Charge status
Full Charge indicator: Green LED
Charge not Full: Blinking Red LED
Pairing status
Connection: Constant Green LED
No Connection: LED blinking alternately red
and green
Out of range: Constant Red LED
Legal notice
FCC and IC information (English version)
This device complies with Part 15 of the FCC
Rules and Industry license-exempt RSS
standard(s). Operation is subject to the
following two conditions: (1) this device may
not cause interference, and (2) this device
must accept any interference, including
interference that may cause undesired
operation of the device.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruc-
tions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment o
and on, the user is encouraged to try to
correct the interference by one or more of
the following measure:
- Reorient or relocate the receiving antenna
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
This equipment complies with IC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be
installed and operated with minimum
distance 20 cm between the radiator and
your body.
Warning: Changes or modications not
expressly approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
One-year limited warranty
Visit www.rocketshproducts.com for
details.
Contact Rocketsh:
For customer service, call 1-800-620-2790
www.rocketshproducts.com
© 2011 BBY Solutions, Inc. All Rights Reserved.
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richeld, MN USA 55423-3645
ROCKETFISH is a trademark of BBY Solutions, Inc. All other
products and brand names are trademarks of their
respective owners.
