MET MTYH3692 Portable Speaker with Bluetooth Wireless Technology User Manual
MET INDUSTRIAL LTD Portable Speaker with Bluetooth Wireless Technology
MET >
User Manual
![](/img.php?id=3851945&img=bg1.png)
PORTABLE SPEAKER
with Bluetooth® Wireless Technology
PORTABLE SPEAKER
with Bluetooth® Wireless Technology
Model: CMA3692
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
Owner's Manual
Size: 148.5(W) x 210(H)mm (A5)
![](/img.php?id=3851945&img=bg2.png)
LIMITED WARRANTY
2
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
FCC WARNING:
To assure continued operation, follow the attached installation instructions and
use only shield cables when connecting to other devices. Changes or
modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
![](/img.php?id=3851945&img=bg3.png)
3
2
1
5
4
6
3
7
1. Power On / Off Button
2. Blue BT (Bluetooth) Indicator
3. Button
4. Button
5. Button
6. DC 5V (Micro USB) Port (For charging only)
7. Red Charging Indicator
8. Speaker
The unit has a built-in Li-ion rechargeable battery, recharge it before first time use or when it
is drained as follow:
1. Connect the small plug from the supplied USB Connection Cable to the DC 5V (Micro USB)
Port on the rear of unit.
2. Connect the full size USB Plug from the supplied USB Connection Cable to the USB Port on
the Personal Computer or USB Charger (Personal Computer and USB Charger not included).
3. When charging, the Red Charging Indicator on the rear of unit will illuminate.
When charging is complete, it will turn off.
To Computer or any USB Charger
NOTES:
Your battery will last longer if you following these simple guidelines for caring and storing:
A. Before first time use, recharge the unit approximately 4 hours until the unit is fully charged.
B. Charge and store the unit within the temperature range of 5°C - 35°C (40°F - 95°F).
C. Do not overcharge (longer than 24 hours). Excessive charging or running the unit until battery
fully drains will damage battery. Battery life will be extended if you keep the battery fully charged.
D. Battery life naturally shortens slowly over time.
E. The rechargeable battery incorporated in this product is not user replaceable.
8
POWER SOURCE:
LOCATION OF CONTROLS:
![](/img.php?id=3851945&img=bg4.png)
4
4. During playback:
● Press the Button on the unit to pause, press again to resume normal playback.
●
● Press and hold the or Buttons repeatedly to skip tracks.
Notes:
● When the external BT Device searched the unit, our model number “CMA3692”
will appear on the display of external BT Device.
● If while pairing you are asked for a code please try "0000" or "1234".
Normal operation after pairing:
1. Power on the external BT Device and enter to BT playback mode.
2. Press and hold the Power On/Off Button on the front of unit approximately
0.5 second to power on the unit. The Blue BT (Bluetooth) Indicator on front of the
unit will illuminate and blink.
3. Wait a few seconds until the unit is automatically paired to the external BT Device.
The Blue BT Indicator will stop blinking.
4. After pairing is complete you may now play music with your external BT Device.
Press and release the or Buttons to adjust volume level as desired.
BT (Bluetooth) pairing:
First time use or re-pairing the unit to a new BT Device, Pair as follows:
1. Press and hold the Power On/Off button on the front of unit approximately
0.5 second to power on the unit. The Blue BT (Bluetooth) Indicator on front of the
unit will illuminate and blink.
2. Power on the external BT Device and enter to BT searching mode. Start pairing
following the on screen instructions from the external BT Device. When paired,
the Blue BT Indicator will stop blinking.
3. If pairing is complete you may now play music with your external BT Device.
5. When finished listening, press the Power On/Off Button to shut off the unit.
The Blue BT Indicator will not light.
BT Mode:
OPERATION:
![](/img.php?id=3851945&img=bg5.png)
Check the following before requesting service:
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
Can’t power on Buit-in battery drained Recharge the battery as page 3
The unit in power off mode Press and hold the Power On/Off Button
on the front of unit approximately 0.5 second
to power on the unit.
No sound or
sound weak
Volume of the unit was set to minimum
position
Increase the volume level by press and
release the Button repeatedly
Volume level of paired BT device is
in low level
Rise the volume level of the paired
BT device
Sound distortion
Volume level too high Reduce the volume level by press and
release the Button repeatedly
Volume level of the paired BT device
too high
Reduce the volume level of the paired
BT device
BT not
functioning
The external BT device had not paired
to the unit
Pair the external BT device to the unit as
page 4
The external BT device too far from
\the unit
Place the external BT device close to the unit
The external BT device too far from
the unit
The external BT device too far
from the unit
5
TROUBLE SHOOTING GUIDE
![](/img.php?id=3851945&img=bg6.png)
BT Version 4.1
BT Operation Distance
≧
32 Feet in open area
Audio Power 1.5 W (RMS)
Power Source
Impedance of Speakers
2 W; 3 ohm
Built-in DC 3.7V, 400 mAh (1.48 WH) rechargeable Li-ion battery;
Recharge by DC 5V through the DC 5V (Mirco USB) Port
1 x Owner’s Manual
1 x USB Connection Cable (For charge only)
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
SPECIFICATIONS:
PACKAGE INCLUDES
6
![](/img.php?id=3851945&img=bg7.png)
Craig warrants this product to be free from manufacturing defects in material and
workmanship under normal use for a period of 90 days from date of purchase. If service
is required, please return the product to the store where it was purchased for exchange;
or, pack the unit in the original packing material with all accessories if applicable, a copy
of your sales receipt and a Cashier’s check or Money Order for $3.00 (to cover shipping
and handling costs) payable to Craig Electronics Inc. For consumers in Canada, please
make sure that the cashier check or money order is redeemable through a U.S. bank.
Ship your product freight pre-paid. Your unit will be repaired, replaced or if the unit can
not be repaired or replaced, a refund will be forwarded to you within four weeks of receipt
of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a commercial application or
rental. b) Damaged through misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d) Damaged because it is
improperly connected to any other equipment.
Note: This warranty does not cover: a) Ordinary adjustments as outlined in the Owner’s
Manual which can be performed by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping the product for repair. d)
Damage to the product not used in the USA.
This warranty is not transferable and only applies to the original purchase. Any implied
warranties, including the warranty of merchantability, are limited in duration to the period
of this expressed warranty and no warranty whether expressed or implied shall apply to
the product thereafter.
Under no circumstance shall Craig be liable for any loss or consequential damage arising
out of the use of this product. This warranty gives specific legal rights. However, you may
have other rights which may vary from state to state. Some states do not allow limitations
on implied warranties or exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China CMA3692_WC_E0GZ1_B0US
