Users Manual
Item no. 365488S8, 365488S8C
www.bratz.com
TM & © MGA Entertainment, Inc.
BRATZ™, BRATZ PETZ™, LIL’ BRATZ™,
BRATZ BABYZ™, BRATZ KIDZ™ and all
related logos, names, characters,
distinctive likenesses and slogans,
as well as the packaging and images
appearing thereon, are the
exclusive property of MGA.
16300 Roscoe Blvd.
Van Nuys, CA 91406 USA
(800) 222-4685
Printed in China.
1007-0-E
The preferred method of contact for
Customer Service is through our e-mail
contact form at www.mgae.com
Please keep this manual as it contains important information.
FCC Compliance
NOTE: This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
The Transmitter carrier frequency is 98.5 MHz and the field strength is 166 µV/m at the measurement
distance of 3m.
This radiocommunication device complies with all the requirements of Industrial Canada Standard
IC RSS-210.
Look and sound like a rock star with this awesome headset microphone! Just attach your MP3 player
to the transmit module and hook it to your belt. Both your MP3 player’s music and your voice will
come out through the radio together! Sing along with your fav MP3’s and belt it out like the pros!
FCC STATEMENT
AGES 6+
ADULT BATTERY INSTALLATION REQUIRED.
INTRODUCTION
CONTENTS
• 1 Bratz™ Plugged-In Headset Boom Mic
• 1 Audio Cable
• 2 x AAA Heavy Duty Batteries
• 1 Microphone Transmit Module with the following parts:
a) MP3 Player Holder
b) On/Off Switch
c) Microphone Volume Dial
d) Audio In Volume Dial
e) MP3/Audio Input Jack
f) Headset Input Jack
g) Antenna
h) Belt Clip
NOTE: MP3 Player and FM radio
not included.
Headset Boom Mic
14
Audio Cable
(f) Headset Input Jack
(d) Audio in
Volume
Dial
(c) Microphone
Volume
Dial
Top
Front
(e) MP3/Audio
Input Jack
(g) Antenna
(b) On/Off Switch
(a) MP3 Player Holder
ON OFF
(h) Belt Clip
Transmit Module
Illustration may vary from actual contents.
MP3
-
+
MIC
-
+
‘Let’s care for the environment!’
The wheelie bin symbol indicates that the product must not be disposed of with other household
waste. Please use designated collection points or recycling facilities when disposing of the item.
Do not treat old batteries as household waste. Take them to a designated recycling facility.
• Your FM Microphone has been fully tested and adjusted prior to shipment. Do not attempt to
touch, replace or service any of components inside.
• After use, turn your microphone OFF to save the batteries.
• Under an environment with electrostatic discharge, this product may malfunction and require the
user to reset the unit by changing the batteries.
• Your FM microphone must be within 30 feet (approx. 10 meters) of your FM radio for optimal
reception.
• If you need to get closer to the radio in order to get a signal, replace the batteries.
• Use alkaline batteries for best performance and longer life.
• Use only the type battery recommended for the unit.
• Batteries should be replaced only by an adult.
• Insert batteries with the correct polarity ( + and – ).
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
• Do not short-circuit batteries.
• When not used for an extended time, remove batteries to prevent possible
leakage and damage to the unit.
• Do not mix rechargeable and non-rechargeable batteries.
• Rechargeable batteries are to be removed from the toy before charging.
• Rechargeable batteries are to be recharged only under adult supervision.
• Do not recharge non-rechargeable batteries.
• Exhausted batteries are to be removed from the toy.
• Do not dispose of batteries in fire as they may leak or explode.
DISPOSAL OF BATTERIES: Do not treat old batteries as household waste. Take them to a
designated recycling facility.
NOTE: The voltage of a fully-charged, rechargeable battery is often lower than that of a fresh alkaline
battery. Therefore, it is recommended that alkaline batteries be used instead of rechargeable
batteries for best performance and for longest play time.
5. Clip the Transmit Module to your belt or waistband.
6. Place the Headset on your head and adjust it to fit. (Fig. 2).
7. On the Transmit Module, turn the On/Off Switch to ON.
8. Turn on a nearby radio (not included) and select the FM band.
9. Tune your radio to 100MHz FM. If there is a radio station at 100MHz with a strong signal, it may
overpower your microphone. If so, move the tuner slightly to either 99 or 101 MHz.
10. Hold your headset microphone close to the radio while your radio is tuned to about 100MHz.
11. Turn on your MP3 Player and play your favorite music track. You will hear it through the radio!
12. Talk through your headset microphone and your voice will also come through the radio!
13. Slowly increase volume by turning the Microphone Volume Dial and the Audio-In volume
counter-clockwise until both are at a comfortable listening level.
14. Now you can sing into your microphone and you will hear your voice through the radio
along with music from your MP3 Player! Rock on!
NOTE: The radio volume should not be set to maximum. This may cause either a sharp “Feedback”
whistle or dead silence from the radio.
1. Attach your MP3 Player (not included) to the Holder on the side of the Transmit Module. If your
MP3 Player does not fit in the holder, you can clip it to your belt or place it in a pocket.
2. Attach the Audio Cable to the Headphone Jack of your MP3 Player.
3. Attach the other end of the Audio Cable to the Audio Input Jack on the Transmit Module.
4. Plug the Headset cord into the Headphone Jack of the Transmit Module. Your Headset
Microphone and MP3 player should be connected as shown. (Fig. 1).
QUICK START
IMPORTANT NOTES
SAFE BATTERY USAGE
32
BEFORE YOU BEGIN
Ask an adult to help you install batteries by
following these easy steps:
1. Using a Phillips screwdriver (not included)
remove the screw and battery compartment
cover from the back of the Transmit Module.
2. Install two (2) 1.5V AAA fresh batteries
(included) making sure the (+) and (-) ends
face the proper direction as indicated inside the
battery compartment.
3. Replace the compartment cover and tighten the
screw.
Fig. 2
MP3 Player
MP3 Player Holder
Fig. 1
MP3
-
+
MIC
-
+
WARNING: Damage to your hearing from loud noise is often not apparent until it is too late.
Often this kind of damage is irreversible.
To help establish a safe “Listening Level” with your headset, please use the following guidelines:
1. Start with the volume setting all the way down.
2. Slowly increase it to a comfortable level.
3. Make note of the level on your dial for future reference.
4. Avoid prolonged exposure to excessive noise.
Making these adjustments now will help keep your hearing healthy.
1.5 V AAA/LR03
1.5 V AAA/LR03
1.5 V AAA/LR03
1.5 V AAA/LR03
2 x AAA
Batteries
