MINEW TECHNOLOGIES F3 Anti-lost Device User Manual Manual
Shenzhen Minew Technologies Co.,Ltd. Anti-lost Device Manual
Manual
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 1
Minew Technologies F3 Anti-Lost Device
Datasheet V1.0
A
An
nt
ti
i-
-L
Lo
os
st
t
D
De
ev
vi
ic
ce
e
(
(N
Ne
ev
ve
er
r
l
lo
os
st
t
y
yo
ou
ur
r
s
st
tu
uf
ff
f
a
ag
ga
ai
in
n)
)
D
Da
at
ta
as
sh
he
ee
et
t
V
V1
1.
.0
0
Model Description
F3-W White casing, portable Anti-Lost with external ON/OFF push button(based on
BLE 4.0 technology), RoHS
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 2
Minew Technologies F3 Anti-Lost Device
Datasheet V1.0
The Anti-Lost F3 is a smart and tiny tracking device; it is developed based on a new kind of Bluetooth radio
system (Low energy 4.0 technology). The F3 not only help you to find your stuff where it is, but also help
you to keep your stuff never lost again.
It is easy to be attached to your wallets, bags, car keys, remotes and other stuff.
FEATURES
- Find & anti-lost function
- LED and buzzer indication
- Replaceable coin battery
- External ON/OFF push button to save the battery lifetime
- Ultra-low power consumption chipset nRF51822 with ARM core
- Easy to print a customization Logo/branding on the case
- Portable device, keychain and neck string available for optional
TURN ON/OFF Anti-Lost F3
Turn ON F3:
1) Press the button (at the center of top cover of beacon) and keep holding 5 to 10 seconds;
2) Then the Blue LED will be light on 5 seconds then off; it means that the beacon start broadcasting;
Turn OFF F3:
1) Press the button (at the center of top cover of beacon) and keep holding 5 to 10 seconds;
2) Then the Blue LED will flash 5 times then off; it means that the beacon is off and stops broadcasting;
ELECTRONIC PARAMETERS
Item Value Remarks
Case Color White Other colors can be customized
Battery Model CR2025 Coin battery, 1pc
Operation Voltage 1.8-3.6V DC
Transmission Circuit 10.5mA (Max.) Tested at 0dBm transmission power
Transmission Range 30 meters Maximum
Antenna 50ohm On board / PCB Antenna
Net Weight 11.0g With battery
Size 32 x 32 x 6 mm Null
F3 Anti-Lost (BLE 4.0)
Image 1
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 3
Minew Technologies F3 Anti-Lost Device
Datasheet V1.0
TECHNICAL SUPPORT
Item Version File Name Updated Date
Datasheet V1.0 F3_Anti-Lost Datasheet_1.0.pdf 1
st
March, 2016
Instruction V1.0 Instructions_Anti-Lost_V1.0.pdf 1
th
March, 2016
SDK V1.0 Android Reference Source Code;
iOS Reference Source Code; 28th February, 2016
* Minew sales team will send you these documents after the sample arrived.
PACKING INFORMATION
Details Box Carton
Quantity(C8) 40pcs per box 400pcs per carton
Net Weight 0.45Kg 4.5Kg
Gross Weight 0.75Kg 8.0Kg
Size 30.5 x 11 x 7.5 cm 32 x 23 x 40 cm
APPDENDIX
1. J-LINK Programmer Kit;
2. Over-the-Air Function;
Please contact with Minew sales team to ask more related information if needed.
DECLARATION
The contents of this datasheet are subject to change without prior notice for further improvement.
Minew team reserves all the rights for the final explanation.
<END>
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
