MOBASE ELECTRONICS SEKS-SL10ATX Remote Keyless Entry System User Manual
Daedong Co. Ltd. Remote Keyless Entry System
User manual
2. PRODUCT SPECIFICATION
2.1 SCOPE OF REMOTE KEYLESS ENTRY SYSTEM
21.1 KEY PART : TRANSMITTER is inside of the REMOTE KEY, and it
sends the rolling code to the RECEIVER by radio frequency.
2.1.2 RECEIVER : It receives the ROLLING CODE and decodes that,
thereafter RECEIVER drives the actuator.
2.2 SPECIFICATIONS
2.2.1 TRANSMITTER
2.2.2 RECEIVER
Storage temperature range - 30 ~ + 80℃
Modulation FSK
ITEM SPECIFICATION
Rated supply voltage DC 3V
Operating voltage range DC 2.5 ~ 3.2V
Operating temperature range - 20 ~ + 60℃
Frequency 315.00MHz
Code Rolling Code(Hopping Algorithm)
- 30 ~ + 80℃
Max Humidity 95%
Battery life 2 Year(10Times/Day)(Lithium 3V 1EA)
Below than 5mA
(in alarm setting condition)
Standby Current
Specification
Item
DC 9 ~ 16V Operating Voltage
DC 12V Rated Supply Voltage
Operating Temperature
