Regulatory Notice
MX-Proximity-Box
Standard Delivery
MX-Proximity-Box
Federal Communications Commission (FCC) and Industry Canada (IC)
Notice for MX-PROX-BOX
(M/N: MX-Proximity-Box)
(FCC ID: YYRPROXCE, IC ID: 9357A-PROX)
NOTICE:
This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference that may cause undesired operation.
NOTICE:
Le présent appareil est conforme aux CNR d‘Industrie Canada applicables aux appareils radio exempts de licence.
L‘exploitation est autorisée aux deux conditions suivantes:
(1)
l‘appareil ne doit pas produire de brouillage, et
(2)
l‘appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d‘en
compromettre le fonctionnement.
NOTICE:
Changes or modications made to this equipment not expressly approved by MOBOTIX AG may void the FCC
authorization to operate this equipment.
NOTICE:
This Class B digital apparatus complies with Canadian ICES-003.
NOTICE:
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Ministry of Internal Aairs and Communications Notice for MX-PROX-BOX
NOTICE:
• This device has been granted a designation number by Ministry of Internal Aairs and Communications.
• This device should not be modied (otherwise the granted designation number will be invalid).
Dimensions
75 mm/2.95 in
MX-Proximity-Box
Motion Detection with
Radar Sensor Technology
Radar-based detection for any
camera with MxBus connector
More information:
www.mobotix.com > Products > Accessories > Interface Boxes
• MX-Proximity-Box
• 1 screwdriver
• 1 plug 3 to 5 mm
• 1 plug 5 to 7 mm
•1 MxBus cable 0.5 m/1.64
• 2 washers 4.3 mm dia.
• 2 stainless steel wood screws 4x40 mm
• 2 screw anchors S6
MOBOTIX Corp.
80 Broad Street, Suite 702
New York, NY 10004
U.S.A.
Phone: +1 (212) 385 6126
Fax: +1 (212) 385 6129
us-sales@mobotix.com
www.mobotix.com
Declaration of Conformity: www.mobotix.com > Support > MX Media Library > Certicates
MOBOTIX, the MX logo, MxControlCenter, MxEasy, MxPEG and MxActivitySensor are trademarks of MOBOTIX AG
registered in the European Union, the U.S.A., and other countries • Information subject to change without notice •
MOBOTIX does not assume any liability for technical or editorial errors or omissions contained herein • All rights
reserved • © MOBOTIX AG 2015
Notes
• This product must not be used in locations exposed to the dangers of explosion.
• Please follow the notes on installing and operating the device in the
MOBOTIX MX-Proximity-Box Quick
Install
document (www.mobotix.com in the Support > Manuals section).
•
Electrical installation: Electrical systems and equipment may only be installed, modied and maintained
by a qualied electrician or under the direction and supervision of a qualied electrician in accordance
with the applicable electrical guidelines. Make sure to properly set up all electrical connections.
• Network security: MOBOTIX products include all of the necessary conguration options for operation
in Ethernet networks in compliance with data protection laws. The operator is responsible for the data
protection concept across the entire system. The basic settings required to prevent misuse can be con-
gured in the soware and are password-protected. This prevents unauthorized parties from accessing
these settings.
• Make sure the device is not operated outside of its operating conditions:
– MX-Proximity-Box: IP66, –20 to +60 °C/–4 to +140 °F
Declaration of Conformity
Konformitätserklärung
Declaration of Conformity
Déclaration de conformité
Hersteller:
Manufacturer:
Fabricant :
MOBOTIX AG
Produkt:
Product:
Produit :
Modul zur Objekterkennung
Object Detector Module
Module à détection d’objets
Typ:
Type:
Type :
MX-PROX-BOX
(M/N: MX-Proximity-Box)
Das oben bezeichnete Produkt erfüllt die Bestimmungen der im Folgenden aufgeführten Richtlinien.
The product identied above complies with the requirements of the guideline RoHS 2011/65/EU.
Le produit désigné ci-dessus est conforme aux exigences fondamentales des directives suivants.
Kurzname
Short Name
Abréviation
Richtlinie
Guideline
Directive
Harmonisierte Normen
Harmonised standards
Normes harmonisées
R&TTE
1999/5/EC
Funkanlagen und Telekommunikationsendeinrichtungen und die
gegenseitige Anerkennung ihrer Konformität
Radio equipment and telecommunications terminal equipment and the
mutual recognition of their conformity
Équipements hertziens et les équipements terminaux de télécommuni-
cations et la reconnaissance mutuelle de leur conformité
EN 300 330-1 (V1.8.1)
EN 300 330-2 (V1.6.1)
EMC
2014/30/EU
Harmonisierung der Rechtsvorschriften der Mitgliedstaaten über die
elektromagnetische Verträglichkeit
Harmonisation of the laws of the Member States relating to electro-
magnetic compatibility
Harmonisation des législations des États membres concernant la com-
patibilité électromagnétique
EN 301 489-1 (V1.9.2)
EN 301 489-3 (V1.4.1)
ERM-SRD Elektromagnetische Verträglichkeit und
Funkspektrumangelegenheiten (ERM) – Funkanlagen mit geringer
Reichweite
Electromagnetic compatibility and Radio spectrum Matters (ERM),
Short range devices
Compatibilité électromagnétique et spectre radioélectrique (ERM) -
Dispositifs à courte portée
ETSI EN 300 440-1
(V1.6.1)
ETSI EN 300 440-2
(V1.4.1)
Draft ETSI EN 300 440
(V2.1.0)
ROHS
2011/65/EU
Beschränkung der Verwendung bestimmter gefährlicher Stoe in
Elektro- und Elektronikgeräten
Restriction of the use of certain hazardous substances in electrical
and electronic equipment
Limitation de l’utilisation de certaines substances dangereuses dans
les équipements électriques et électroniques
EN 50581:2012
Safety
89/391/EEC
Durchführung von Maßnahmen zur Verbesserung der Sicherheit und
des Gesundheitsschutzes der Arbeitnehmer bei der Arbeit
Introduction of measures to encourage improvements in the safety
and health of workers at work
Mise en oeuvre de mesures visant à promouvoir l’amélioration de la
sécurité et de la santé des travailleurs au travail
EN 60950-1:2006/
A11:2009/A1:2010/
A12:2011
Weitere angewendete Normen:
Other harmonised standards applied:
Autres normes harmonisées :
CFR 47, FCC Part 15B,
Part 15C
RSS 210 Issue 8
Test Standards for Japan:
•Ordinance concerning Technical Regulations Conformity Certication etc. of Specied Radio Equipment
Article 2 clause (1) Item (8)
•Ordinance Regulating Radio Equipment, Chapter I – IV, Article 49 14 11
Adresse:
Address:
Adresse :
MOBOTIX AG
Kaiserstrasse
67722 Langmeil
Germany
Dr. Oliver Gabel
CTO, MOBOTIX AG
Fon:
Fax:
E-Mail:
+49 6302 981 6-103
+49 6302 981 6-190
info@mobotix.com
Ort, Datum
Place & date
Lieu et date
Langmeil, 10.10.2016
Langmeil, October 10, 2016
Langmeil, 10 octobre 2016
This device is granted pursuant to the Japanese Radio Law (電波法)
This device should not be modied (otherwise the granted designation number will become invalid)
